USER GUIDE

CUSTOM MODELS:

CIC

REMOTE MICROPHONE

MINI-CANAL

ITC (IN-THE-CANAL) & ITE (IN-THE-EAR)

Hearing instrument type designations for models included in this user guide are: BO312, FCC ID: X26BO312, BO13, FCC ID: X26BO13, and PH13, FCCID: X26PH13. Please see page 10 and 14 for list of models referring to both types.

Statement:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful inter ference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from the one in which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Changes or modiﬁcations can void the user´s authority to operate the equipment

Intended use

Generic air-conduction hearing instruments are wearable sound-amplifying devices intended to compensate for impaired hearing. The fundamental operating principle of hearing instruments is to receive, amplify, and transfer sound to the ear drum of a hearing impaired person.

List of countries:

Products without wireless functionality are intended for worldwide sales.

Products with wireless functionality are intended for sale in countries within the European Economic Area as well as Switzerland.

Speciﬁcation of restrictions: You are not allowed to operate the equipment within 20 km of the centre of Ny Ålesund, Norway.

The products are in compliance with the following regulatory requirements:

• In the EU: the device conforms to the Essential Requirements according to Annex I of Council Directive 93/42/EEC for medical devices (MDD) and essential requirements and other relevant provisions of Directive 1999/5/EC (R&TTE). The declaration of conformity may be consulted at www.resound.com

• In US: FCC CFR 47 Part 15, subpart C, section 15.249.

• Other identiﬁed applicable international regulatory requirements in countries outside the EU

and US. Please refer to local country requirements for these areas.

• Products are categorized as class 2 receiver according to EN 300 440

Introduction

Congratulations on the purchase of your new hearing instruments. ReSound’s innovative sound technology and design, combined with the customised device programming selected by your hearing care professional, will make hearing a more enjoyable experience. Hearing instruments will enable you to hear sounds that you may not have heard in years because of your hearing loss. Practice and a positive attitude are important in learning to use hearing instruments Your ReSound instruments have been adjusted according to your individual hearing loss and needs. Some people adjust quickly to wearing hearing instruments in their ears and hearing new sounds; other people may need more time. Please read this manual carefully in order to wholly beneﬁt from the use of your hearing instruments. With proper care, maintenance, and usage, your hearing instruments will aid you in better communication for many years. Ask your hearing care professional if you have any questions.

ReSou nd is a registred trade mark of Re Sound A /S

Hearing instrument model:

Battery size:

Left serial number:

Receiver tube length:

Dome size:

Right serial number:

CONTENTS

Statement .........................2

Intended use .......................4

List of countries .....................4

Introduction ........................6

Description of the hearing instruments ...10

Getting started .....................16

On/Off function ....................16

SmartStart ........................17

Inserting/Replacing the battery .........18

Low battery indicator ................19

Inserting/removing hearing instruments...20

Operation of the hearing instrument .....25

Volume control (optional)..............25

Programme button (optional)...........27

Flight mode .......................29

Telephone use .....................30

Telecoil ..........................31

Listen to radio or TV ................31

Cellular phones ....................32

PhoneNow .......................32

Tele-loop systems ..................35

Care and maintenance ...............36

Daily maintenance ..................37

Replacing wax ﬁlters.................38

General precautions.................40

General warnings...................41

Battery warning Information ...........43

Troubleshooting guide ...............44

Technical data .....................52

Warranty and repairs ................55

Temperature test, transport and

storage information..................56

Cust om remo te mic he aring i nstr ument m odels w ith si ze 10A batt ery are avail able in t he foll owing v arian ts: AL 910-M P, AL 910-M, AL 710- MP, AL 710-M , AL 510-MP, AL 510-M

Cust om remo te mic he aring i nstr ument m odels w ith si ze 312 batt ery (t ype BO 312) are ava ilabl e in the fo llowin g varia nts: AL 930 -MUW, A L 930- MPW, AL 93 0-MW, A L 930- MU, AL 930 -MP, AL 930 -M AL 730- MUW, AL 73 0-M PW, AL 730- MW, AL 730- MU, AL 73 0-M P, AL 730-M AL 530 -MUW, A L 530- MPW, AL 53 0-MW, AL 530- MU, AL 530 -MP, AL 530 -M

Cust om remo te mic he aring i nstr ument m odels w ith si ze 13 batt ery (t ype BO13) a re avai lable i n the fol lowin g varia nts: AL 950 -MUW, A L 950- MPW, AL 95 0-MW, AL 950- MU, AL 950 -MP, AL 950 -M AL 750- MUW, AL 750 -MP W, AL 750-MW, AL 750- MU, AL 750 -MP, AL 750 -M AL 550 -MUW, AL 550- MPW, AL 5 50-M W, AL 550- MU, AL 550 -MP, AL 55 0-M

1. Programme button (optional)

2. Battery compartment and On/Off switch

3. Removal cord (optional)

4. Sound outlet

5. Wax ﬁlter

6. Venting

7. Microphone sound inlet(s)

8. Remote microphone and tubing (for remote microphone devices)

9. Volume control (optional)

10. Model

11. Manufactu rer

12. Serial number

GN ReSound

ReSound Alera

XXXXXXX

Description of the hearing instruments: Completely-in-the-canal (CIC), mini-canal, In-the-canal (ITC).

AL910 - AL910-P - AL920 - AL920-P AL930 - AL930-P - AL930-D - AL930-DP AL710 - AL710-P - AL720 - AL720-P AL730 - AL730-P - AL730-D - AL730-DP AL510 - AL510-P - AL520 - AL520 -P AL530 - AL530-P - AL530-D - AL530-DP AL410 - AL410-P - AL420 - AL420-P AL430 - AL430-P - AL430-D - AL430-DP

1. Programme button (optional)

2. Battery compartment and On/Off switch

3. Removal cord (optional)

4. Sound outlet

5. Wax ﬁlter

6. Venting

7. Microphone sound inlet(s)

8. Volume control (optional)

9. Model

10. Manufacturer

11. Serial number

GN ReSound

ReSound Alera

XXXXXXX

Description of the hearing instruments: In-t he-ear (ITE ) (type PH13)

AL940 - A L940-P - AL940-D - AL940- DP AL950 - A L950- P - AL950 -D - AL950-DP AL950 -W - AL950-PW - A L950-DW AL950-DPW AL740 - AL740-P - AL740-D - AL740-DP AL750 - AL750-P - AL750-D - AL750-D P AL750-W - AL750- PW - AL750-DW AL750 -D PW AL540 - AL540 -P - AL540-D - AL540 -DP AL550 - AL550 -P - AL550-D - AL550 -DP AL550-W - AL550-PW - AL550-DW AL550-DPW AL440 - AL440 -P - AL440-D - AL440 -DP AL450 - AL450 -P - AL450-D - AL450 -DP AL450-W - AL450-PW - AL450-DW AL450-DPW

1. Programme button (optional)

2. Battery compartment and On/Off switch

3. Removal Cord (optional)

4. Sound outlet

5. Wax ﬁlter

6. Venting

7. Microphone sound inlet(s)

8. Volume control (optional)

9. Model

10. Manufacturer

11. Serial number

GN ReSound

ReSound Alera

XXXXXXX

Getting started

On/Off function

1. When the battery door is closed, the hearing instrument will turn on, and the default program will be activated.

2. To turn the hearing instrument off, open the battery door. Many individuals can use their ﬁngernail to pull it open.

Tip: Whenever the hearing instruments are not in use, remember to open the battery doors to avoid unnecessary battery consumption.

Off

SmartStart

Hearing instruments can be turned on once you have placed them on your ears. If you prefer to turn them on just prior to placing them in your ears, your hearing care professional can activate a function called SmartStart. This function will delay the time in which the hearing instruments turn on by several seconds after the battery compartment is closed. With SmartStart, a beep will be heard for each second of the delay period.

Inserting/Replacing the battery

Open the battery door completely by using your ﬁngernail.

1. Remove the used battery if present. Insert the new battery with the positive side in the correct position.

has a ‘+’ indicator to help determine the correct insertion.

The battery door

2. Always use new Zinc-Air batteries that have a minimum remaining shelf life of 1 year

3. Gently close the battery door.

Tip: Remove the batteries to prevent battery leakage or corrosion when the hearing instruments are not in use for an extended period of time.

Low battery indicator

Your hearing care professional can activate a low battery indicator in your hearing instruments. The hearing instrument will reduce ampliﬁcation and emit a beep signal if battery power gets too low. This signal will recur every ﬁve minutes until the hearing instrument automatically switches off. The low battery indicator can vary slightly, depending on the type of battery used. It is recommended that you keep spare batteries on hand.

Low battery indicator (instruments paired with accessories only)

Active usage of the ReSound Unite accessories (Remote Control, Phone Clip and Unite TV) requires more battery power from the hearing instruments than when these are working without accessories which means that battery life is highly dependent on the amount of wireless accessory usage. When the battery in the hearing instrument has depleted to a level at which use of the ReSound Unite TV and Phone Clip cannot be supported, the hearing instrument will play two sets of descending tones. After this, your hearing instrument and ReSound Unite Remote
