GN Hearing A S DA13R, DA13I, DA312I, DA312R User Manual
USER GUIDE
CUSTOM HEARING INSTRUMENTS
400332000-GB-14.10-Rev.A.indd 1 19-11-2014 12:48:23
Hearing instrument type designations for models included in this user guide are: DA312r, FCC ID:
X26DA312
R, IC: 6941C-DA312R; DA13r, FCC ID: X26DA13R, IC: 6941C-DA13R; DA312i, FCC ID:
X26DA312I, IC: 6941C-DA312I; and DA13i, FCC ID: X26DA13I, IC: 6941C-DA13I. Please see page 10, 12
and 14 for lists of models referring to these types.
Statement:
This device complies with part 15 of the FCC rules and ICES-003 of the IC rules.
Operation is subject to the following two conditions: (1) this device may not cause harmful inter ference,
and (2) this device must accept any interference received, including interference that may cause undesired
operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules and ICES-003 of the IC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from the one in which the receiver is con-
nected.
• Consult the dealer or an experienced radio/TV technician for help.
2
400332000-GB-14.10-Rev.A.indd 2 19-11-2014 12:48:23
Changes or modifications can void the user´s authority to operate the equipment.
Intended use
Generic air-conduction hearing instruments are wearable sound-amplifying devices intended to compensate for impaired hearing. The fundamental operating principle of hearing instruments is to receive, amplify,
and transfer sound to the ear drum of a hearing impaired person.
The products are in compliance with the following regulatory requirements:
• In the EU: the device conforms to the Essential Requirements according to Annex I of Council Directive
93/42/EEC for medical devices (MDD) and essential requirements and other relevant provisions of Directive 1999/5/EC (R&TTE).
• The declaration of conformity may be consulted at www.resound.com
• In US: FCC CFR 47 Part 15, subpart C.
• Other identified applicable international regulatory requirements in countries outside the EU and US.
Please refer to local country requirements for these areas.
• In Canada: these hearing instruments are certified under the rules of IC.
• Japanese Radio Law and Japanese Telecommunications Business Law Compliance. This device is
granted pursuant to the Japanese Radio Law (電波法) and the Japanese telecommunications Business
Law (電気通信事業法) This device should not be modified (otherwise the granted designation number
will become invalid).
• Patents:
US 7,593,537 US 8,00,849
3
400332000-GB-14.10-Rev.A.indd 3 19-11-2014 12:48:23
Introduction
Congratulations on the purchase of your new hearing instruments. ReSound’s innovative sound technology
and design, combined with the customised device programming selected by your hearing care professional, will make hearing a more enjoyable experience. Hearing instruments will enable you to hear sounds
that you may not have heard in years because of your hearing loss. Practice and a positive attitude are
important in learning to use hearing instruments. Your ReSound instruments have been adjusted according
to your individual hearing loss and needs. Some people adjust quickly to wearing hearing instruments in
their ears and hearing new sounds; other people may need more time.
This product is a custom-made device.
Please read this manual carefully in order to wholly benefit from the use of your hearing instruments. With
proper care, maintenance, and usage, your hearing instruments will aid you in better communication for
many years. Ask your hearing care professional if you have any questions.
ReSou nd is a reg istred t rade ma rk of ReS ound A /S
4
400332000-GB-14.10-Rev.A.indd 4 19-11-2014 12:48:23
Hearing instrument model:
Model IIC: Battery size 10
Model CIC: Battery size 10
Model ITC: Battery size 13 or 312 (circle one)
Model ITE: Battery size 13 or 312 (circle one)
Model MIH: Battery size 13, 312, or 10 for MIH-S (circle one)
Left serial number:
Right serial number:
Specific features supported by your hearing system:
Smart Smart .....................16
Volume control ...................22
Program button...................23
Wireless ..................17, 25, 30
Phone Now......................27
Tinnitus Sound Generator...........35
Telecoil/Tele-loop system ...........25
Power device-exceeds 132 dB SPL .....
Ask your h eari ng care profess ional to m ark the o ptions s uppor ted by you r hear ing syste m.
400332000-GB-14.10-Rev.A.indd 5 19-11-2014 12:48:23
5
Contents
Statement .............................2
Intended use ..........................3
List of countries ........................3
Introduction............................4
Specific features supported by your
hearing system .........................5
Description of the hearing instruments .......8
Getting started ........................14
On/Off function ........................14
SmartStart ...........................14
Inserting/Replacing the battery............15
Low battery indicator when paired with
wireless accessories only ................16
Inserting/removing hearing instruments .....17
Operation of the hearing instrument . . . . . . . . 20
Volume control (optional).................20
Programme button (optional) .............21
Flight mode...........................22
Telephone use.........................23
Telecoil ..............................23
Listen to radio or TV ....................24
6
400332000-GB-14.10-Rev.A.indd 6 19-11-2014 12:48:23
Using ReSound Hearing Instruments with
iPhone®, iPad®, and iPod touch®.............24
Using ReSound hearing instruments with
smart phone apps . . . . . . . . . . . . . . . . . . . . . 24
Cellular phones .......................25
PhoneNow ...........................25
Tele-loop systems......................27
Care and maintenance ..................27
Daily maintenance......................28
Replacing wax filters....................28
General precautions ....................29
General warnings ......................30
Intended use for the TSG module ..........32
Prescription use of this TSG hearing
instrument............................32
User instructions for the TSG module .......33
Important notice for prospective
sound generator users ..................33
The scientific concepts that form the
basis for the device .....................34
TSG warnings .........................35
TSG precautions.......................35
TSG warning to hearing healthcare
professionals..........................36
Battery warning information ..............37
Hearing instrument expectations. ..........37
Warning to hearing aid dispensers .........38
Important notice for prospective
hearing aid users ......................38
Children with hearing loss................39
Troubleshooting guide ..................40
Technical data.........................44
Warranty and repairs....................45
Temperature test, transport and
storage information .....................45
7
400332000-GB-14.10-Rev.A.indd 7 19-11-2014 12:48:23
Mic in Helix (M IH-S) hearing instrument models
with size 10A battery are available in the following
variants:
LS9MIH-S UP, LS9MIH-S HP, LS9MIH-S MP,
LS9MIH-S LP, LS7MIH-S UP, LS7MIH- S HP,
LS7MIH-S MP, LS7MIH-S LP, LS5MIH- S UP,
LS5MIH-S HP, LS5MIH-S MP, LS5MIH-S LP
Mic in Helix (MIH) h
(including type DA312r with FCC ID
X26DA312R, IC number 6941C-DA312R models
designated by a “W”) with size 312 battery and
Custom Mic in Helix hearing instruments
(including type DA13r with FCC ID X26DA13R, IC
number 6941C-DA13R models designated by a
earing instruments
“W”) with size 13 battery are available in the
following variants:
LS9MIH-W UP, LS9MIH-W HP, LS9MIH-W MP,
LS9MIH-W LP, LS9MIH UP, LS9MIH HP, LS9MIH
MP, LS9MIH LP, LS7MIH-W UP, LS7MIH-W HP,
LS7MIH-W MP, LS7MIH-W LP, LS7MIH UP, LS7MIH
HP, LS7MIH MP, LS7MIH LP L
LS5MIH-W HP, LS5MIH-W MP, LS5MIH-W LP,
LS5MIH UP, LS5MIH HP, LS5MIH MP, LS5MIH LP
8
400332000-GB-14.10-Rev.A.indd 8 19-11-2014 12:48:24
S5MIH-W UP,
1. Programme button (optional)
4
2. Battery compartment and On/Off switch
3. Removal cord (optional)
4. Sound outlet
9
5. Wax filter
6. Vent
7. Microphone sound inlet
1
8. Remote microphone and tubing
(for remote microphone devices)
9. Volume control (optional)
10. Model
11. Manufacturer
12. Serial number
2
3
8
7
4
5
8
2
8
GN ReSound
ReSound Verso
XXXXXXX
11
10
6
400332000-GB-14.10-Rev.A.indd 9 19-11-2014 12:48:25
3
12
6
9
Invisible-in-the-canal (IIC) and
completely-in-the-canal (CIC) hearing
instruments with size 10A battery are available in
the following variants:
LS9IIC, LS7IIC, LS9CIC UP, LS9CIC HP,
LS9CIC MP, LS9CIC LP, LS7CIC UP,
LS7CIC HP, LS7CIC MP, LS7CIC LP, LS5IIC,
LS5CIC UP, LS5CIC HP, LS5CIC MP,
LS5CIC LP
n-the-canal (ITC) hearing instruments (including
I
type DA312i with FCC ID X26DA312I, IC number
6941C-DA312I models designated by a “W”) with
size 312 battery are available in the following
variants:
LS9ITC-DW UP, LS9ITC-DW HP,
LS9ITC-DW MP, LS9ITC-DW LP, LS9ITC-D UP,
LS9ITC-D HP, LS9ITC-D MP, LS9ITC-D LP,
LS9ITC-W UP, LS9ITC-W HP, LS9ITC-W MP,
LS9ITC-W LP, LS9ITC UP, LS9ITC HP,
LS9ITC MP, LS9ITC LP, LS7ITC-DW UP,
LS7ITC-DW HP, LS7ITC-DW MP,
LS7ITC-DW LP, LS7ITC-D UP, LS7ITC-D HP,
LS7ITC-D MP, LS7ITC-D LP, LS7ITC-W UP,
LS7ITC-W HP, LS7ITC-W MP, LS7ITC-W LP,
LS7ITC UP, LS7ITC HP, LS7ITC MP, LS7ITC LP,
LS5ITC-DW UP, LS5ITC-DW HP, LS5ITC-DW MP,
LS5ITC-DW LP, LS5ITC-D UP, LS5ITC-D HP,
LS5ITC-D MP, LS5ITC-D LP, LS5ITC-W UP,
LS5ITC-W HP, LS5ITC-W MP, LS5ITC-W LP,
LS5ITC UP, LS5ITC HP, LS5ITC MP, LS5ITC LP
10
400332000-GB-14.10-Rev.A.indd 10 19-11-2014 12:48:26
1. Programme button (optional)
2. Battery compartment and On/Off switch
7
1
7
3. Removal cord (optional)
4. Sound outlet
5. Wax filter
6. Vent
7. Microphone sound inlet(s)
8. Volume control (optional)
9. Model
10. Manufacturer
11. Serial number
2
6
8
4
5
8
7
1
3
3
GN ReSound
ReSound Verso
XXXXXXX
10
9
2
400332000-GB-14.10-Rev.A.indd 11 19-11-2014 12:48:26
6
11
11
In-the-ear (ITE) he
aring instruments (including
type DA13i with FCC ID X26DA13I, IC number
6941C-DA13I models designated by a “W”) with
size 13 battery are available in the following
variants:
LS9ITE-DW UP, LS9ITE-DW HP,
LS9ITE-DW MP, LS9ITE-D UP, LS9ITE-D HP,
LS9ITE-D MP, LS9ITE-W UP, LS9ITE-W HP,
LS9ITE-W MP, LS9ITE UP, LS9ITE HP,
LS9ITE MP, LS7ITE-DW UP, LS7ITE-DW HP,
LS7ITE-DW MP, LS7ITE-D UP, LS7ITE-D HP,
LS7ITE-D MP, LS7ITE-W UP, LS7ITE-W HP,
LS7ITE-W MP, LS7ITE UP, LS7ITE HP,
LS7ITE MP, LS5ITE-DW UP, LS5ITE-DW HP,
LS5ITE-DW MP, LS5ITE-D UP, LS5ITE-D HP,
LS5ITE-D MP, LS5ITE-W UP, LS5ITE-W HP,
LS5ITE-W MP, LS5ITE UP, LS5ITE HP,
LS5ITE MP
12
400332000-GB-14.10-Rev.A.indd 12 19-11-2014 12:48:27
1. Programme button (optional)
2. Battery compartment and On/Off switch
3. Sound outlet
4. Wax filter
5. Vent
6. Microphone sound inlet(s)
7. Volume control (optional)
8. Model
9. Manufacturer
10. Serial number
3
2
4
6
9
8
GN ReSound
ReSound Verso
XXXXXXX
4
5
1
7
6
5
10
13
400332000-GB-14.10-Rev.A.indd 13 19-11-2014 12:48:27
Getting started
On/Off function
1. When the battery door is closed, the hearing instrument
will turn on, and the default program will be activated.
2. To turn the hearing instrument off, open the battery door.
Many individuals can use their fingernail to pull it open.
Tip: Whenever the hearing instruments are not in use, remember to open the
i
battery doors to avoid unnecessary battery consumption.
On
Off
SmartStart
Hearing instruments can be turned on once you have placed them on your ears. If you
prefer to turn them on just prior to placing them in your ears, your hearing care professional can activate a function called SmartStart. This function will delay the time in which
the hearing instruments turn on by several seconds after the batter y compartment is
closed. With SmartStar t, a beep will be heard for each second of the delay period.
14
400332000-GB-14.10-Rev.A.indd 14 19-11-2014 12:48:28
Inserting/Replacing the battery
1. Open the battery door completely by using your fingernail. Remove the used battery if present.
2. Prepare the new battery (Please ask your hearing care professional what battery size is used for your
hearing instrument). Remove the protective foil and wait 2 minutes before inserting the battery into the
hearing instrument to allow activation of the batter y.
3. Insert the new battery with the positive side in the correct position.
4. Gently close the batter y door.
1 2 3
Tip:
i
1. Always use new Zinc-Air batteries that have a minimum remaining shelf life of 1 year.
2. Whenever the hearing instruments are not in use, remember to turn
them off to avoid unnecessary battery consumption.
15
400332000-GB-14.10-Rev.A.indd 15 19-11-2014 12:48:30
Loading...
