Gmc ACADIA DENALI (2014) Quick Reference Guide [ru]

Review this Quick Reference Guide for an overview of some important features in your GMC Acadia. More detailed information can be found in your Owner Manual. Some optional equipment described in this guide may not be included in your vehicle.

If you have additional questions about the features and controls in your vehicle, press the blue OnStar button to speak with a customer assistance representative who can provide more information.

www.gmc.com

Instrument Panel

Cruise Control

Buttons

Turn Signal

Lever/Windshield

Wipers Lever

Driver

Information

Center

Audio Steering

Wheel

Controls

Head-Up

Display

Controls

Exterior Lamps

Control

Symbols

Low Fuel Traction Control Off

Engine Coolant

Temperature

Brake System

Cruise Control Set

Ambient Light

Control

Security

Oil Pressure

Instrument Panel

Illumination Control/

Dome Lamp Off Button

Low Tire Pressure StabiliTrak Active StabiliTrak Off

Check Engine

Tilt/Telescopic

Steering Wheel

Lever

Charging System

Safety Belt Reminder

Airbag Readiness

Antilock Brake

System Side Blind Zone Alert

Driver

Information

Center

Buttons

USB Port

(inside storage

compartment)

Audio System/

Navigation

System

Hazard

Warning

Flashers Button

Lane Departure

Warning

ButtonF/Forward

Collision Alert

Button

Driver’s Heated/

Cooled Seat

Buttons

Rear Wiper Switch/

Traction Control Off Button/Tow/

Haul Mode ButtonF/

Accessory

Power

Outlet

Passenger’s

Heated/

Cooled Seat

Buttons

Climate

Controls

Power Liftgate

Switch

Refer to your Owner Manual to learn about the information being relayed by the lights, gauges and indicators on the instrument cluster.

See In Brief in your Owner Manual.

F Optional equipment

Front Seats

Manual Seats

A. Seat Fore/Aft Adjustment

Lift the handle under the front of

the seat to slide the seat forward or rearward.

B. Seat Height Adjustment

Ratchet the middle lever up or down

repeatedly to raise or lower the seat.

C. Seatback Recline Adjustment

Lift the rear lever to recline or raise the

seatback.

D. Lumbar Adjustment

Pull up/push down the lever on the

inboard side of the seatback to adjust

the amount of lumbar support.

Power Seats

A B

Head Restraints

F Optional equipment

A. Seat Adjustment

Move the horizontal control to move the

seat forward or rearward and to raise, lower or tilt the seat.

B. Seatback Recline Adjustment

Move the vertical control to recline or

raise the seatback.

C. Lumbar Adjustment (Driver’s Seat Only)

Press the switch to adjust the amount

of lumbar support.

The driver and front passenger head restraints are adjustable.

Press the button on the left side of the

head restraint to raise or lower the head restraint, or move it rearward. Move the head restraint forward by pulling it forward.

See Seats and Restraints in your Owner Manual.

Enter or Exit the 3rd-Row Seats

Slide the Seat

2nd-Row Seats

1. Make sure nothing is on the 2nd-row

seat or the oor in front of or behind

the seat.

2. Fold up the armrest(s) and make sure the safety belt is unfastened and in the stowed position.

3. Rotate the release lever (A) on the upper-outboard side of the seatback forward.

4. Push the top of the seatback forward. The seat cushion will fold and the entire seat will slide forward.

5. After entering/exiting, push the top of the seatback rearward until the seat-

back and oor tracks lock.

6. Push down at the rear of the seat cushion to lock it in place.

1. Make sure nothing is on the oor in

front of or behind the 2nd-row seat.

2. Pull outward on the handle (B) on the outboard side of the seat cushion and slide the seat forward or rearward.

3. Release the handle.

Fold/Recline the Seatback

1. Make sure the seat is all the way rearward (when folding the seat), the armrest(s) are upright and the safety belt is unfastened.

2. Pull forward on the strap (C) on the outboard side of the seatback.

3. Fold down or recline the seatback.

See Seats and Restraints in your Owner Manual.
