Probler P2
Dispense Gun
For use with non-ammable foam and polyurea.
Not for use in explosive atmospheres.
90-110 psi (0.62-0.76 MPa, 6.2-7.6 bar) Air Inlet Pressure Range
3500 psi (24.1 MPa, 241 bar) Maximum Static Fluid Pressure
Important Safety Instructions
Read all warnings and instructions in
this manual. Save these instructions.
Models:
GCP2RA
GCP2R0
GCP2R1
GCP2R2
GCP2R3
GCP2R4
GCP2R5
USER MANUAL
ti19826a
Table Of Contents
Section 1 Installation
Warnings ............................................................................................................................................................ 3
Introduction ........................................................................................................................................................ 7
Standard Equipment .......................................................................................................................................... 8
Translations ........................................................................................................................................................ 8
Equipment Assembly ......................................................................................................................................... 9
Section 2 Operation
Start-up Instructions ........................................................................................................................................... 11
Section 3 General Information
Assembly Drawings ............................................................................................................................................. 13
Maintenance ........................................................................................................................................................ 15
Options ................................................................................................................................................................ 20
Section 4 Warranty and Reference Information
Graco Warranty .................................................................................................................................................. 26
Technical Assistance ........................................................................................................................................... 27
For Your Reference ............................................................................................................................................. 28
2
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation
point symbol alerts you to a general warning and the hazard symbol refers to procedure-specic risk. Refer back to these
warnings. Additional, product-specic warnings may be found throughout the body of this manual where applicable.
WARNING
TOXIC FLUID OR FUMES HAZARD
Toxic uids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or swal-
lowed.
Read MSDS’s to know the specic hazards of the uids you are using.•
Store hazardous uid in approved containers, and dispose of it according to applicable guidelines.•
Always wear impervious gloves when spraying or cleaning equipment.•
PERSONAL PROTECTIVE EQUIPMENT
You must wear appropriate protective equipment when operating, servicing, or when in the operating area of
the equipment to help protect you from serious injury, including eye injury, inhalation of toxic fumes, burns,
and hearing loss. This equipment includes but is not limited to:
Protective eyewear•
Clothing and respirator as recommended by the uid and solvent manufacturer•
Gloves•
Hearing protection•
SKIN INJECTION HAZARD
High-pressure uid from gun, hose leaks, or ruptured components will pierce skin. This may look like just a
cut, but it is a serious injury that can result in amputation. Get immediate surgical treatment.
Do not point gun at anyone or at any part of the body.•
Do not put your hand over the spray tip.•
Do not stop or deect leaks with your hand, body, glove, or rag.•
Close material shutoff valves and shutoff or disconnect air supply when not spraying.•
Follow Pressure Relief Procedure in this manual, when you stop spraying and before cleaning, checking, •
or servicing equipment.
BURN HAZARD
Equipment surfaces and uid that’s heated can become very hot during operation. To avoid severe burns, do
not touch hot uid or equipment. Wait until equipment/uid has cooled completely.
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help prevent re
and explosion:
Use equipment only in well ventilated area.•
Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop •
cloths (potential static arc).
Keep work area free of debris, including solvent, rags and gasoline.•
Do not plug or unplug power cords, or turn power or light switches on or off when ammable fumes are •
present.
Ground all equipment in the work area.•
Use only grounded hoses.•
Hold gun rmly to side of grounded pail when triggering into pail.•
If there is static sparking or you feel a shock, stop operation immediately. Do not use equipment until •
you identify and correct the problem.
Keep a working re extinguisher in the work area.•
3
Warnings
WARNING
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
Do not operate the unit when fatigued or under the inuence of drugs or alcohol.•
Do not exceed the maximum working pressure or temperature rating of the lowest rated system compo-•
nent. See Technical Data in all equipment manuals.
Use uids and solvents that are compatible with equipment wetted parts. See Technical Data in all •
equipment manuals. Read uid and solvent manufacturer’s warnings. For complete information about
your material, request MSDS forms from distributor or retailer.
Check equipment daily. Repair or replace worn or damaged parts immediately with genuine manufactur-•
er’s replacement parts only.
Do not alter or modify equipment.•
Use equipment only for its intended purpose. Call your distributor for information.•
Route hoses and cables away from trafc areas, sharp edges, moving parts, and hot surfaces.•
Do not kink or over bend hoses or use hoses to pull equipment.•
Keep children and animals away from work area.•
Comply with all applicable safety regulations.•
PRESSURIZED ALUMINUM PARTS HAZARD
Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon
solvents or uids containing such solvents in pressurized aluminum equipment. Such
use can cause serious chemical reaction and equipment rupture, and result in death,
serious injury, and property damage.
4
Warnings
Isocyanate Hazard
Spraying materials containing isocyanates creates
potentially harmful mists, vapors, and atomized
particulates.
Read material manufacturer’s warnings and
material MSDS to know specic hazards and
precautions related to isocyanates.
Prevent inhalation of isocyanate mists, vapors, and
atomized particulates by providing sufcient ventilation in the work area. If sufcient ventilation is not
available, a supplied-air respirator is required for
everyone in the work area.
To prevent contact with isocyanates, appropriate
personal protective equipment, including chemically
impermeable gloves, boots, aprons, and goggles, is
also required for everyone in the work area.
To prevent exposing ISO to moisture:
Always use a sealed container with a desiccant dryer •
in the vent, or a nitrogen atmosphere. Never store ISO
in an open container.
Keep the ISO lube pump reservoir lled with Graco •
Throat Seal Liquid (TSL), Part 206995. The lubricant
creates a barrier between the ISO and the atmosphere.
Use moisture-proof hoses specically designed for •
ISO, such as those supplied with your system.
Never use reclaimed solvents, which may contain •
moisture. Always keep solvent containers closed when
not in use.
Never use solvent on one side if it has been contami-•
nated from the other side.
Always park pumps when you shutdown.•
Always lubricate threaded parts with Part 217374 ISO •
pump oil or grease when reassembling.
Material Self-Ignition
Some materials may become self-igniting if applied
too thickly. Read material manufacturer’s warnings
and material MSDS.
Moisture Sensitivity of
Isocyanates
Isocyanates (ISO) are catalysts used in two component
foam and polyurea coatings. ISO will react with moisture
(such as humidity) to form small, hard, abrasive crystals,
which become suspended in the uid. Eventually a lm will
form on the surface and the ISO will begin to gel, increasing in viscosity. If used, this partially cured ISO will reduce
performance and the life of all wetted parts.
The amount of lm formation and rate of crystal-
lization varies depending on the blend of ISO,
the humidity, and the temperature.
5
Warnings
Keep Components A and B
Separate
CAUTION
To prevent cross-contamination of the equipment’s wet-
ted parts, never interchange component A (isocyanate)
and component B (resin) parts. The gun is shipped with
the A side on the left. The uid manifold, uid housing, side seal assembly, check valve cartridge, and mix
chamber are marked on the A side.
Foam Resins with 245 fa
Blowing Agents
New foam blowing agents will froth at temperatures above
90°F (33 °C) when not under pressure, especially if agitated. To reduce frothing, minimize preheating in a circulation
system.
Changing Materials
When changing materials, ush the equipment mul-•
tiple times to ensure it is thoroughly clean.
Always clean the uid inlet strainers after ushing.•
Check with your material manufacturer for chemical •
compatibility.
Most materials use ISO on the A side, but some use •
ISO on the B side.
Epoxies often have amines on the B (hardener) side. •
Polyureas often have amines on the B (resin) side.
6
Introduction
Section 1 - Installation: Introduction
Before operating, maintaining or servicing any GlasCraft system, read and understand all of the technical
and safety literature provided with GlasCraft products.
If you do not have the proper or related manuals and
safety literature for your GlasCraft system, contact your
GlasCraft distributor.
In this GlasCraft technical and safety publication, the
following advisories will be provided where appropriate:
Information about the procedure in progress.
WARNING
Indicates a hazardous situation that can result in death
or serious injury.
The information in this document is intended only to indi-
cate the components and their normal working relationship
typical use. Each assembly should be directed by a GlasCraft distributor or made from the GlasCraft Assembly
instructions provided.
This manual provides information for the assembly, opera-
tion, maintenance and service of this GlasCraft product as
used in a typical conguration. While it lists standard speci-
cations and procedures, some deviations may be found.
In order to provide our users with the most up-to-date
technology possible, we are constantly seeking to improve
products. If a technological change occurs after a prod-
uct is on the market, we will implement that technology in
future production and, if practical, make it available to current users as a retrot, update or supplement. If you nd
a discrepancy between your unit and the available documentation, contact your GlasCraft distributor to resolve the
difference.
Careful study and continued use of this manual will provide a better understanding of the equipment and process,
resulting in more efcient operation, longer trouble-free
service and faster, easier troubleshooting.
7
7
Section 1 - Installation: Standard Equipment
Standard Equipment
Part
Number
GCP2RX Probler P2 Dispense Gun
313213 User Manual
Description
Translations
Manual No. Language
3A0472 Spanish
3A0473 French
8
Section 1 - Installation: Equipment Assembly
How The Gun Works
The trigger actuates a small valve in the gun handle that
controls the ow of air into the piston assembly. When the
trigger is pulled, air ows through the valve to the front of
the piston. Air pressure forces the piston towards the rear
of the gun, simultaneously closing off the purge air and
moving the mixing chamber to a position where the mixing
chamber orices are aligned with the orices in both the
side block seal and check valve assemblies.
The proper alignment of the orices is determined by
the setting of the adjustment nut, located on the pis-
ton lock assembly. This adjustment nut determines
the length of travel of the air piston and has been
preset at the factory and should not require adjustment. (SEE MAINTENANCE SECTION)
The two uids (isocyanate and polyol) then ow through
the material shut-off valves, seal, and check valve assemblies and into the mixing chamber. The two uids impinge
against one another and exit the mixing chamber in a swirling, conical spray pattern.
When the trigger is released, the mixing chamber returns
to its original position and purge air ows into the mixing
chamber housing. The front tip o-ring, keeps air purge inside the gun head, forcing all of the air through the orices
in the mixing chamber, for a complete, total and constant
purge.
Piston Lock
Engage piston lock whenever you stop spraying, to avoid
accidental triggering.
Always use piston lock in conjunction with uid ball valves
to avoid accidental triggering.
WARNING
Read warnings, page 3.
To engage Piston lock: push knob in and turn clockwise.
If engaged, gun will not actuate.
r_257826_313266_1_2b
To disengage piston lock: push knob in and turn coun-
terclockwise until it pops out. There will be a gap between
knob and gun body.
This purge air continues to ow through the mixing cham-
ber until the air switch is pulled up to shut-off all air to the
gun; or until the trigger is pulled again.
r_257826_313266_1_1b
See page 19 for piston lock adjustment or installation.
Loss of Air Pressure
In event of loss of air pressure, gun will continue to spray.
To shut off gun, do one of the following:
Push in piston lock, see • Engage piston lock.
Close ball valves A and B.•
9
Section 1 - Installation: Equipment Assembly
GlasCraft Equipment
Air Hose is ¼ in. NPS
JIC and SAE Fittings DO NOT require the use of PTFE
tape.
Once the ttings are attached and tight, refer to system
manuals for start-up instructions.
ISO
*AIR
POLY
Installing P2 on Other Equipment
WARNING
Do not place any part of the body in the path of the
material spray. Do not point the gun at or near other
personnel. Do not look into the mixing chamber ori-
ce at any time. Because of the hazardous materials
used in this equipment, it is recommended that the
operator use an air mask, goggles, protective cloth-
ing, and other safety equipment as prescribed by
current regulations, recommendations of the chemi-
cal suppliers, and the laws in the area where the
equipment is being used.
If original equipment does not require the use of an unheated whip hose or isolation hose, the P2 can be directly
installed on to the material hose.
Remove the ttings from the original gun.1.
Remove swivel ttings from ball valves. Ball valves 2.
are 1/8 in. NPT female. Remove swivel tting from
air slide valve. The air slide valve is a ¼ in. NPSM.
ti21609a
*Fitting GC2394 is an unattached part that may need to be
connected to the air hose rst, depending on air hose tting,
then connected to the gun.
Install the original ttings into ball valves.3.
It is recommended to use a non-permanent thread
lock on the 1/8 in. NPT threads to assist as a sealant
and keep the ttings from twisting with gun move-
ment.
Install the gun on the original hoses.4.
WARNING
Relieve ALL system uid and air pressure according
to manufacturer’s instructions.
ti21610a
10
Section 2 - Operation: Start-Up Instructions
Refer to specic system user manuals for complete
system installation.
Pre operation Checklist
Check that all ttings are tight and air regulators are
turned to “zero pressure”.
WARNING
If purge air is to be turned OFF, BOTH MATERIAL SHUTOFF VALVES, MUST BE TURNED TO THEIR “OFF” POSITION AND PISTON-LOCK ENGAGED BEFORE TURNING
“OFF” THE PURGE AIR !
Failure to follow this procedure will possibly result in the
gun head becoming encased with mixed product.
WARNING
Do not place any part of the body in the path of the material
spray.
Do not point the gun at or near other personnel.
Do not look into the mixing chamber orice at anytime.
Because of the hazardous materials used in this equip-
ment, it is recommended that the operator use an air mask,
goggles, protective clothing, and other safety equipment
as prescribed by current regulations, recommendations of
the chemical suppliers, and the laws in the area where the
equipment is being used.
Operating Requirements
• 8-10 CFM at 90-110 psi (0.62-0.76 MPa,
6.2-7.6 bar)
• MAXIMUM Static Fluid Pressure - 3500 psi (24.1
MPa, 241 bar)
WARNING
The GlasCraft Probler P2 Gun is designed and manufac-
tured to operate at a maximum static uid pressure not to
exceed 3500 psi (24.1 MPa, 241 bar). When attached to
a GlasCraft proportioning system, this pressure will not
be exceeded. However, if the GlasCraft Probler P2 Gun is
installed on any other manufacturer’s self-designed equip-
ment, great care must be taken to ensure that the maxi-
mum static uid pressure not be exceeded.
For proper purging following use, the air switch must be left
OPEN for at least 15 SECONDS after the trigger has been
released.
The ow of material into the mixing chamber is controlled
by the ON or OFF position of the two material shut-off
valves.
Both material shut-off valves must be FULLY OPEN
and piston lock DISENGAGED during dispens-
ing and must be FULLY CLOSED and piston lock
ENGAGED during service or extended shut-down
periods.
WARNING
BOTH MATERIAL SHUT-OFF VALVES, MUST BE
TURNED TO THEIR “OFF” POSITION AND ALL FLUID
PRESSURE RELIEVED BEFORE REMOVING SIDE
BLOCK SCREWS!!
Failure to follow this procedure will possibly result in the
gun head becoming encased with mixed product.
If the gun is being used for short periods of spraying,
GlasCraft recommends that the purge air be left ON.
ti19823a
ON OFF
Refer to system manuals for start-up and
shut-down procedures.
11
Section 2 - Operation: Start-Up Instructions
Spray Technique
Always operate safely and follow all safety procedures
outlined.
To achieve the optimum spray pattern for each application,
the appropriate mixing chambers are available in seven
spray sizes.
The standard mixing chamber supplied with your gun will
be adequate for all but the smallest and largest applications.
Foam rise and cure times will vary according to the material and substrate temperature. Higher material or substrate
temperature will increase rise and cure times; lower material or substrate temperatures will decrease rise and cure
times. Consult your chemical manufacturer’s data specication sheets for their recommended spray temperatures.
Under most circumstances, both components will be used
at identical temperatures.
Higher pressures and temperatures may be used to
increase material break-up, improve mixing and speed
rise times. With hose lengths over 50 ft., or when mater-
ial viscosities are high, higher material pump pressures
may be necessary.
The gun air switch assembly MUST BE OPENED (down
position) prior to spraying to provide air for trigger operation
and purge air when the trigger is released.
When spraying, the gun trigger may be depressed con-
tinuously, or triggered at the end of each stroke. A smooth,
even layer is best achieved by moving the gun back and
forth in a slow, even motion, overlapping the previous pass
about 50 to 75 percent. DO NOT SPRAY OVER RISING
FOAM! The ideal gun-to-surface distance is about 18 to 24
inches. Be sure to point the gun directly at the surface to
be sprayed. Spraying at an angle to the surface will cause
the foam to be rough and will generate overspray.
12
Section 3 - General Information: GCP2RX P2 Dispense Gun
25
12
B
A
23
36
49
52
8d
8c
8b
51
1a
54
18
ti19827a
21
32
35
8a
5
47
40
39
22
34
22
35
32
31
34
21
10
19
2
17
51
54
8
1b
38
48
53
55
42
16
43
37
30
14
15
45
44
46
55
27
4
24
r_gcp2ra_313213_1_4d
33
31
7
10
20
56c
r_257826_313213_1_1b
41
56a
Hardware Kit
3
56f
29
3
A B
56e
2
1
56b
56d
2
56
GCP2R1 GC2501 GC2511 GC1947
GCP2R0 GC2500 GC2510 GC1947
surfaces specied.
Apply permanent threadlocker and torque to 35-40 in-lbs (4-4.5 N•m).
Apply liberal coating of lubricant (Part No. 118665) to seals and
Adjust counter-clockwise until it bottoms out.
2
1
3
GCP2RA GC250A GC251A GC1948
Probler P2
GCP2R2 GC2502 GC2512 GC1947
GCP2R3 GC2503 GC2513 GC1947
GCP2R4 GC2504 GC2514 GC1949
GCP2R5 GC2505 GC2515 GC1949
13
Section 3 - General Information: GCP2XX P2 Parts List
Ref.
No.
Part No. Description Qty.
8a 110242 O-RING 1
8b 106555 O-RING 2
8c GC0126 AIR SWITCH
TUBE
1
8d GC0127 AIR SWITCH
SPOOL
1
Ref.
No.
Part
No.
Description Qty.
56a AIR CAP 1
56b ♦
STOP SHAFT 1
56c ♦
PISTON STOP 1
56d ♦
COMPRESSION SPRING 1
56e ♦
O-RING 1
56f ADJUSTMENT NUT 1
Ref.
No.
1a 256459 ISO BALL VALVE 1
1b 256460 POLY BALL VALVE 1
Part
No.
2 GC2340 PROBLER TRIGGER 1
3 GC2341 COMPRESSION SPRING 1
4 117634 SWIVEL HOSE FITTING 1
5 117635 SWIVEL HOSE FITTING 1
6* 15B772 1/4 NPSM (FBE) AIR HOSE
7 248130 O-RING (QTY. 6) 1
Description Qty.
(18 in.)
8 GC0128 AIR SWITCH ASSEMBLY 1
10 GC0259 1/4 DIA BALL 3
12 100846 LUBE FITTING 1
13* GC2394 SWIVEL FITTING 1
14 GC1898 1-3/8” AIR PISTON 1
15 GC1899 1-1/2” AIR PISTON 1
16 GC1900 CYLINDER SPACER 1
17 GC1901 VALVE INSERT 1
18 16N599 ISO SIDE BLOCK 1
19 16N600 POLY SIDE BLOCK 1
20 16P010 CHECK VALVE FILTER 2
21 GC2494 SEAL 2
22 GC2495 SEAL HOUSING 2
23 GC1914 AIR CAP 1
24 GC2499 HANDLE 1
25 GC1916 PROBLER P2 HEAD 1
27 GC1918 TRIGGER PISTON 1
29 GC1920 TRIGGER PLUG 1
30 GC1921 RETAINING RING 1
31 X GC1922 SPRING 3
32 GC1923 SPRING 2
33 X GC2496 FILTER SCREEN, 40 MESH 2
34 GC2498 SEAL 2
35 111450 O-RING 2
36 117517 O-RING 1
37 C20988 O-RING 1
38 GC2056 O-RING 1
39 110242 O-RING 1
40 GC2057 O-RING 1
41 GC2058 O-RING 3
1
Ref.
No.
42 108833 O-RING 1
43 107563 O-RING 1
44 GC2059 O-RING 1
45 C20207 O-RING 1
46 GC2060 O-RING 1
47 GC2079 SET SCREW 1
48 GC2081 SET SCREW 11
49* GC2187 MACHINE SCREW 2
51 15U395 1/8 NPT ADAPTER 2
52 GC2237 SHOULDER SCREW 1
53 GC2243 SET SCREW 1
54 GC2248 MACHINE SCREW 4
55 GC2241 SET SCREW 2
56 258761 PISTON LOCK ASSEMBLY 1
Part
No.
* 118665 HIGH ADHESION, WATER
* 117773 LOW VISCOSITY GREASE
* 117792 GREASE GUN
Description Qty.
RESITANT, LITHIUM GREASE
(4 OZ.)
(3 OZ.)
(3 OZ. CARTRIDGE)
1
1
1
* Not shown.
100 Mesh lter GC2497 also available.
♦ Included with kit 258762.
X Available in bulk kits. See page 21.
14
Section 3 - General Information: Maintenance
1/8
WARNING
Before attempting to perform any maintenance on
this gun, relieve All Fluid and Air Pressures!
To relieve uid and air pressures:•
Turn OFF all air supplies at system except gun trigger •
air.
Trigger the gun until all uid pressures have been •
relieved.
Turn OFF the gun trigger air at the system.•
Turn proportioner off.•
Trigger the gun until all trigger air pressure has •
been relieved.
Perform Gun maintenance as follows:
Check the material valves, p/n 256459 and 256460 for 2.
any leaks:
Turn OFF both material valves.•
ti19825a
Check for leaking seals (34):1.
Engage piston lock.•
Turn OFF the gun incoming air by closing gun air •
switch.
Air Switch
Wait approximately 10 - 20 seconds, then turn ON •
the incoming air by opening gun air switch.
Repeat two or three times.•
If any material has been purged from the gun, the •
seals (34) are leaking, or o-ring (35).
Correct leaks by replacing the seals or o-rings and •
re-checking.
Disengage piston lock.•
Trigger the gun several times.•
Wait approximately 10-20 seconds.•
Trigger the gun several times. •
If additional material is purged, the material valves •
are leaking.
Correct the leaks by loosening the set screw and •
removing red or blue handle. Turn the valve packing
nut clockwise in 1/8-turn increments until leak is
corrected. Re-check.
ti19008a
Check side blocks3.
Turn OFF the air switch on the gun.•
WARNING
Before removing the side blocks make certain that both
material valves are in the OFF positions and trigger several
times to depressurize uid in gun!
If the material valves are on when the side blocks are
removed the gun will quickly become encased in urethane!
WARNING
Point gun side blocks down, away from all personnel.
Existing uid pressures could cause material to exit the
side blocks with considerable force.
15
Section 3 - General Information: Maintenance
Take the side blocks off by removing screws.•
ti21611a
Examine the sides of the mixing chamber for scratch- •
es and/or material build-up. Carefully, without
scratching the seal surfaces (sides), remove any
accumulated material. Solvent can be used to wash
accumulated material off of chamber, side blocks, etc.
Keep the gun chamber tilted toward the ground so
that solvent does not run back into gun. Certain
solvents will attack o-rings on chamber shaft causing
swelling and deterioration of o-rings.
Use correct size drill bit to clean out the mixing •
chamber exit passage. Use correct size drill bit to
clean the inlet side holes of the mixing chamber tak-
ing care not to scratch the mixing chamber’s polished
surfaces (refer to the drill chart).
Re-assemble the side blocks and tighten the screws. •
Grease should appear at the tip of the mixing cham ber.
Place generous amounts of high quality, white lithium •
grease (Part No. 117773) in each side of the gun
front housing and on the side block seals.
ti21611a
DO NOT open the air switch on the gun because this
will purge grease from the gun. The grease should
be allowed to remain in the gun overnight.
16
Section 3 - General Information: Maintenance
Daily Shut-Down
For experienced users
Once you have used the gun with a product and system,
and you have become comfortable with techniques on
how all the variables are affecting your operations and
maintenance requirements, Daily, Weekly, and Monthly
maintenance requirements can be addressed specic to
your operation.
Turn the ball valves off, activate and deactivate the gun 1.
5 - 6 times to purge residual pressure.
ti19825a
Engage piston lock.2.
Use grease gun (Part No. 117792) to inject white lithium 5.
grease (Part No. 117773) into zerk tting until a light
mist of grease is purged through the snout. Shut off the
air purge.
ti21611a
Zerk Fitting
Remove the air cap and set to side. If solvent soaking 6.
is required, remove the o-ring before soaking.
Remove the snout insert and soak in solvent until next 7.
usage.
Air Cap
Insert
Drill out the chamber insert snout with correct size drill 3.
bit for insert (see drill chart).
Pull slide valve halfway back to limit the air purge.4.
Air Switch
ti21611a
O-ring
ti21613a
Daily Start-Up
Clean the snout insert. Be sure both, the face and bot- 8.
tom at are clean. Drill the snout bore out with the cor-
rect size bit for snout (see drill chart).
Clean the inner bore of the chamber. Drill out the cham- 9.
ber snout inlet bore as required.
Install the snout insert.10.
Install the air cap on to the chamber. Tighten nger 11.
tight until the cap bottoms out. Snug down with a ½
in. wrench. This does not require high torque. Over
tightening can result in chamber damage.
17
Section 3 - General Information: Maintenance
Refer to specic system user manuals for complete
system installation.
Parts Replacement Procedure
WARNING
Before attempting to perform any maintenance on this
gun OR before removing the side blocks, make certain
that both gun material valves are in the OFF positions
and trigger several times to depressurize uid in gun!
If the material valves are on when side blocks are
removed, the gun will quickly become encased in urethane!
Routine Care
WARNING
Before attempting to perform any maintenance on this
gun OR before removing side blocks, make certain that
both gun material valves are in the fully OFF positions
and trigger several times to depressurize uid in gun!
If the material valves are on when side blocks are
removed, the gun will quickly become encased in urethane!
It is recommended that the following service be performed on a daily basis.
Read each procedure entirely before beginning and 1.
refer to the illustrations as needed.
Flush and clean all chambers and passages as they 2.
become accessible.
Clean all parts before assembly.3.
Replace all o-rings and seals with new parts from the 4.
appropriate kit.
Inspect all parts for wear or damage and replace as re- 5.
quired with new genuine GlasCraft replacement parts
from your authorized GlasCraft distributor.
Inspect all threads for wear or damage and replace as 6.
required.
Tighten all threaded parts securely, but not excessively, 7.
upon assembly.
Clean the gun using a brush and an appropriate clean 1.
solvent.
Inspect the side block seals making certain they are 2.
clean and free of scratches, nicks or foreign material.
Clean and replace as required.
Remove, clean or replace the lter screen.3.
Maintain a reasonable stock level of “wear” items such 4.
as seals and o-rings. (see Service & Repair Parts Kits
listed in Parts & Illustrations section.)
Grease gun daily to prevent 2 component curing and 5.
keep uid passages clean. Purge air carries grease
mist through air chamber and impingement ports then
out the mix chamber nozzle, coating all surfaces. Use
Part No. 117773 grease.
Lightly lubricate all o-rings and threads with 8.
grease (Part No. 118665).
Check all springs for resilience. They should return 9.
quickly to their original (new) length.
18
Section 3 - General Information: Maintenance
Piston Lock Adjustment and Installation
Procedure
The P2 gun piston throw is factory set and as a rule, should
not require adjustment. The piston throw refers to how far
back the air piston will travel when the gun is triggered.
Proper throw adjustment will align the mixing chamber side
ports with the side block seal thru port.
Determine if the piston throw is correct:
Follow the 1. pressure relief procedure on page 15 and
disconnect material hoses from the gun.
Turn the material ball valves to the OFF position.2.
Remove one of the side block seal housings, from side 5.
block. Leave the seal (34) in housing and rinse with
suitable solvent.
ti21614a
Place the side seal housing in the gun head so the face 6.
of the seal sets against the mix chamber.
WARNING
If the material valves are on when side blocks are
removed, the gun will quickly become encased in urethane!
Verify that the piston lock cap has been tightened and 3.
fully threaded into the gun.
Remove the side blocks.4.
ti19825a
ti21612a
Turn the gun trigger air supply on , then trigger the gun.7.
The purge air will not shut off with the side block
removed.
If the impingement port is not fully visible through the 8.
side seal housing turn the trigger-air off and trigger the
gun to relieve pressure. Use a 9/16 in. open-end
wrench to adjust the adjustment nut in the appropriate
direction. Repeat steps 7 and 8 until it is
adjusted properly.
If the impingement port on the mix chamber is fully 9.
visible through the side seal housing (either on
center or slightly forward), the piston lock adjustment
nut is properly aligned.
Non-permanent thread locker can be applied to the
adjustment nut if necessary.
Reassemble the gun.10.
Before each use: Verify that the piston lock assembly is
installed and working properly.
Engage piston lock.•
Pressurize the system to working pressure.•
Open material ball valves.•
Point the gun in a safe direction and trigger gun. No •
material should ow from gun tip.
DO NOT USE IF IT IS NOT WORKING PROPERLY.•
19
Section 3 - General Information: Options
Optional Equipment
Part Description
GC1938 Flat Spray Kit
GC1952 Jet Stream Nozzle (.059 ID)
GC1953 Jet Stream Nozzle (.070 ID)
GC1954 Pour Adapter
GC1892 * P2 Elite Conversion Kit
* Maximum working pressure 3200 psi (22 MPa, 220 bar)
GC1892
Part Description Qty.
GC0024 PIPE PLUG 3
GC0275 FITTING 1
GC0490 ELBOW FITTING 1
GC0502 FITTING 1
GC0712 ELBOW FITTING 2
GC1842 BALL VALVE 1
GC1880 P2-ELITE HEAD 1
GC1881 POLY SIDE BLOCK 1
GC1882 ISO SIDE BLOCK 1
GC1883 PISTON SPACER 1
GC1884 MOUNTING PLATE 1
GC1885 SWIVEL ADAPTER 1
GC1886 WHIP HOSE 1
GC1887 WHIP HOSE 1
GC2212 FITTING 3
GC2244 SET SCREW 1
GC2334 FITTING 3
GC2337 BALL VALVE 2
313266 USER MANUAL 1
20
Service & Repair Kits
Section 3 - General Information: Options
GC1946, Side Seal Kit
Part Description Qty.
GC2498 SST Side Seal 2
111450 O-Ring 2
GC1947, Hardware Kit 00-03
Part Description Qty.
249112 Drill Bit 1
GC0069 Drill Bit 1
246629 Drill Bit 1
246630 Drill Bit 1
GC0083 Drill Bit 1
GC2394 Fitting 1
GC2212 Fitting 1
GC2334 Fitting 1
GC0086 3/16” Ball Driver 1
GC0087 5/32” Ball Driver 1
117661 Pin Vise 1
GC2496 Screen Filter 2
246628 Drill Bit 1
246627 Drill Bit 1
246625 Drill Bit 1
117517 O-Ring 1
111450 O-Ring 2
GC1948, Hardware Kit -AA
Part Description Qty.
248891 Drill Bit 1
276984 Drill Bit 1
GC0086 Ball Driver 1
GC0087 Ball Driver 1
117661 Vise Pin 1
GC2496 Filter Screen 2
111450 O-Ring 2
117517 O-Ring 1
GC1949, Hardware Kit 04-05
Part Description Qty.
GC0086 3/16” Ball Driver 1
GC0087 5/32” Ball Driver 1
117661 Pin Vise 1
GC2496 Screen Filter 2
246624 Drill Bit 1
246623 Drill Bit 1
117517 O-Ring 1
111450 O-Ring 2
GC2394 Adapter Fitting 1
GC2212 Connector Fitting 1
GC2334 Connector Fitting 1
258762, Piston Lock Repair
Kit
Part Description Qty.
Stop Shaft 1
Piston Stop 1
Compression
Spring
O-Ring 1
1
Gun Cover
244914 Covers
Keeps gun clean while spraying. Pack of
10.
Lubricant for Gun Rebuild
248279, 4 oz (113 gram) [10]
High adhesion, water resistant, lithiumbased lubricant. MSDS sheet available at
www.graco.com.
Grease Cartridge for Gun
Shutdown
248280 Cartridge, 3 oz [10]
Specially formulated low viscosity grease
ows easily through gun passages, to
prevent 2 component curing and keep uid
passages clean.
Bulk Kits
24R894, 40 Mesh Filter Screens Kit
Ref Part Description Qty.
33 GC2496 Filter Screen, 40 mesh 10
24R895, 100 Mesh Filter Screens Kit
Ref Part Description Qty.
(33) GC2497 Filter Screen, 100 mesh 10
24R896, Springs Kit
Ref Part Description Qty.
31 GC1922 Spring 12
21
Service & Repair Kits
Section 3 - General Information: Options
Ref.
6 113137 O-Ring 2
7 248130 O-Ring (Qty. 6) 1
8a 106555 O-Ring 2
35 111450 O-Ring 2
36 117517 O-Ring 1
37 C20988 O-Ring 1
38 GC2056 O-Ring 1
39 110242 O-Ring 2
40 GC2057 O-Ring 1
41 GC2058 O-Ring 3
42 108833 O-Ring 1
43 107563 O-Ring 1
44 GC2059 O-Ring 1
45 C20207 O-Ring 1
46 GC2060 O-Ring 1
GC1937, Standard Repair Kit
Part Description Qty.
Complete O-ring Kit Placement Guide
37
38
39
8a
40
41
Ref.
6 113137 O-Ring 2
7 248130 O-Ring (Qty. 6) 1
8a 111316 O-Ring 2
35 111450 O-Ring 2
36 117517 O-Ring 1
37 GC1931 O-Ring 1
38 111516 O-Ring 1
39 111450 O-Ring 2
40 118594 O-Ring 1
41 GC1932 O-Ring 3
42 GC1933 O-Ring 1
43 GC1934 O-Ring 1
44 GC1935 O-Ring 1
45 GC1936 O-Ring 1
46 117610 O-Ring 1
42
GC1950, Premium Repair Kit
Part Description Qty.
43
44
45
46
6
22
7
35
36
Section 3 - General Information: Options
Round Mixing
Chamber
Mixing Chamber Nozzle
Cleaning Drill
GC250A 248891 .033 276984 .022
GC2500 GC0083 .049 GC0080 .035
GC2501 249112 .057 246629 .042
GC2502 GC0069 .071 246628 .052
GC2503 246625 .086 246627 .059
GC2504 246624 .094 296297 .067
GC2505 246623 0.116 246625 .086
DRILL PIN VISE 117661
Tungsten Carbide Tip
Part No.
Orice
Diameter
Spray Width
(degrees)
FAN
Code
GC2573 0.015 in. 25° 215
GC2574 0.015 in. 40° 415
GC2575 0.017 in. 25° 217
GC2576 0.017 in. 40° 417
GC2577 0.017 in. 50° 517
GC2578 0.021 in. 25° 221
GC2579 0.021 in. 40° 421
GC2580 0.021 in. 50° 521
GC2582 0.023 in. 25° 223
GC2583 0.023 in. 40° 423
GC2584 0.023 in. 50° 523
GC2585 0.023 in. 70° 723
GC2586 0.027 in. 40° 427
GC2587 0.027 in. 50° 527
GC2589 0.031 in. 25° 231
GC2590 0.031 in. 40° 431
GC2591 0.031 in. 50° 531
GC2592 0.035 in. 25° 235
GC2593 0.035 in. 40° 435
GC2594 0.035 in. 50° 535
GC2595 0.039 in. 40° 439
GC2596 0.039 in. 50° 539
Mixing Chamber
Hole Cleaning Drill
Tungsten Carbide Tip
Part No.
Orice
Diameter
Spray Width
(degrees)
FAN
Code
GC2597 0.043 in. 50° 543
GC2599 0.051 in. 30° 351
GC2600 0.051 in. 40° 451
GC2601 0.051 in. 50° 551
GC2602 0.051 in. 70° 751
GC2604 0.061 in. 40° 461
GC2605 0.061 in. 50° 561
GC2606 0.061 in. 65° 661
GC2607 0.071 in. 40° 471
GC2608 0.071 in. 50° 571
Spacer Seals
Use only Brown series C spacer seals with series B
spray-tips, failure to do so may result in material clogging.
Series C Spacer Seals (Brown)
Short Version Long Version
Use with tips LPA2-147-1525
through LPA2-147-3850
GC2335 16V976
23564-00 16V972
23572-00 16V973
LPA2-121G 16V974
LPA2-124S 16V975
2
1
Use with tips LPA2-147-4325
through LPA2-147-7250
1
2
1 : Tip Spacer Seal (Series C)
2: Spray-tip (Series B)
23
P2 Spray Options
Section 3 - General Information: Options
E
D
Standard Round Spray Air Cap
D
N
A
P
GC1938 Standard Flat Spray Kit Conguration
Tungsten airless tip
R
(See page 22)
D
Pour Conguration
B
C
KJ
Jet Stream Conguration
D
M
P2 Spray Options
Ref. Part Description
A GC1916 Gun Head
B GC250X Mix Chamber Body
C GC251X Mix Chamber Insert
D 117517 O-ring
E GC1914 Front Tip
J GC1954 Pour Cap
K * Tubing, 1/4 in. ID
GC1952
M
GC1953
GC2335
N
16V976
P GC0257 Retaining Nut
R GC1926 Flat Spray Adapter
* Purchase locally.
Jet Nozzle
Seal
24
Static Mixer Kit
GC1956
Section 3 - General Information: Options
GC0257
Tungsten airless tip
(See page 22)
GC2335
GC0480
GC1956, Static Mixer Kit
Part
Number
GC2335
16V976
GC0257 Nozzle Nut 1
GC0331 Plug Fitting 1
GC0480 Spiral Mixing Element 1
117517 O-Ring 1
GC1955 Static Mixer Adapter 1
Description Qty.
Fluid Nozzle Seal 1
GC0331
117517
GC1955
25
Graco Standard Warranty
Graco warrants all equipment referenced in this document which is manufactured by Graco and bearing its name to be free from defects
in material and workmanship on the date of sale to the original purchaser for use. With the exception of any special, extended, or limited
warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment
determined by Graco to be defective. This warranty applies only when the equipment is installed, operated and maintained in accordance
with Graco’s written recommendations.
This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by
faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of non-Graco component parts. Nor shall Graco be liable for malfunction, damage or wear caused by the incompatibility of Graco
equipment with structures, accessories, equipment or materials not supplied by Graco, or the improper design, manufacture, installation,
operation or maintenance of structures, accessories, equipment or materials not supplied by Graco.
This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized Graco distributor for
verication of the claimed defect. If the claimed defect is veried, Graco will repair or replace free of charge any defective parts. The
equipment will be returned to the original purchaser transportation prepaid. If inspection of the equipment does not disclose any defect
in material or workmanship, repairs will be made at a reasonable charge, which charges may include the costs of parts, labor, and transportation.
THIS WARRANTY IS EXCLUSIVE, AND IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO WARRANTY OF MERCHANTABILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE.
Graco’s sole obligation and buyer’s sole remedy for any breach of warranty shall be as set forth above. The buyer agrees that no other
remedy (including, but not limited to, incidental or consequential damages for lost prots, lost sales, injury to person or property, or any
other incidental or consequential loss) shall be available. Any action for breach of warranty must be brought within two (2) years of the
date of sale.
GRACO MAKES NO WARRANTY, AND DISCLAIMS ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, IN CONNECTION WITH ACCESSORIES, EQUIPMENT, MATERIALS OR COMPONENTS SOLD BUT NOT
MANUFACTURED BY GRACO. These items sold, but not manufactured by Graco (such as electric motors, switches, hose, etc.), are
subject to the warranty, if any, of their manufacturer. Graco will provide purchaser with reasonable assistance in making any claim for
breach of these warranties.
In no event will Graco be liable for indirect, incidental, special or consequential damages resulting from Graco supplying equipment hereunder, or the furnishing, performance, or use of any products or other goods sold hereto, whether due to a breach of contract, breach of
warranty, the negligence of Graco, or otherwise.
FOR GRACO CANADA CUSTOMERS
The Parties acknowledge that they have required that the present document, as well as all documents, notices and legal proceedings
entered into, given or instituted pursuant hereto or relating directly or indirectly hereto, be drawn up in English. Les parties reconnaissent
avoir convenu que la rédaction du présente document sera en Anglais, ainsi que tous documents, avis et procédures judiciaires exécutés,
donnés ou intentés, à la suite de ou en rapport, directement ou indirectement, avec les procédures concernées.
Graco Information
For the latest information about Graco products, visit www.graco.com.
For patent information, see www.graco.com/patents.
TO PLACE AN ORDER, contact your Graco distributor or call to identify the nearest distributor.
Phone: 612-623-6921 or Toll Free: 1-800-328-0211 Fax: 612-378-3505
26
Technical Assistance
Thank You for selecting GlasCraft spray equipment
Should you have any questions or need technical assistance, contact your factory authorized
GlasCraft distributor.
Distributor: _________________________
Phone: ____________________________
Contact: ___________________________
For any issues your distributor cannot address, the GlasCraft technical service department is
always available to assist you with the operation of your spray equipment. To help our technical
representatives expedite your call and better address your questions, please have the following
information ready and available when you phone GlasCraft.
* If your questions are not urgent, You can e-mail all correspondence to service@glascraft.com
For Air Powered Systems:
Model: _____________________________ Air compressor size: __________________
Serial number: _______________________ CFM generated: _____________________
Type of spray gun: ____________________ Pressure at the system:
Serial number: _______________________
Hydraulic ________ Pneumatic _________
Is your equipment: Dynamic uid pressure:
Single phase: _______ Three phase ______ ISO __________ POLY ___________
What is the inbound voltage Spray gun chamber size: ______________
to your equipment: ____________________
Material being sprayed: _______________
Temperature setting ISO: _______________
Viscosity: ISO _________ POLY ________
Temperature setting POLY: ______________ Approximate material temperature: ______
Temperature setting HOSE: _____________
27
For Your Reference
Date Purchased __________________________________________________
Distributor ______________________________________________________
______________________________________________________
Contact ______________________________________________________
Phone ______________________________________________________
E-mail ______________________________________________________
GlasCraft manufactures a complete line of polyurethane foam and polyurea coating spray systems.
If your application is in-plant or a eld contractor - GlasCraft has a system package to meet your
requirements.
GUARDIAN - AIR POWERED / A5 & A6 SERIES EQUIPMENT
. 6000 OR 12000 WATTS OF HEAT
. 1600, 2200, OR 3000 PRESSURE SET-UPS AVAILABLE
MH, MH II, & MH III HYDRAULIC POWERED SYSTEMS
. UP TO 45 LBS / MINUTE OUTPUT
. EXCELLENT PERFORMANCE AND RELIABILITY
GUARDIAN MMH - MOBILE MODULAR HYDRAULIC SYSTEMS
. SPECIFICALLY DESIGNED FOR ANY TYPE OF SPRAY RIG
. GIVE COMPLETE UTILIZATION OF FLOOR SPACE IN MOBILE RIG
PROBLER P2 SPRAY GUN
. IMPINGEMENT MIX / AIR PURGE
. OPTIONAL NOZZLE FOR SPRAYING STUD WALLS, POURING & STREAM JET
For more information concerning any of these GlasCraft products,
contact your local authorized Graco distributor or visit www.graco.com
Notes
Quality and Performance…
GENUINE GLASCRAFT
www.glascraft.com
313213U
EN
Original instructions.
This manual contains English.
Revised June 2014
GRACO INC. AND SUBSIDIARIES
P.O. BOX 1441
MINNEAPOLIS MN 55440-1441
USA
Phone 612-623-6921
Toll Free 1-800-328-0211
Fax 612-378-3505
Loading...
