Gigaset S790, S795 User Guide

S790 - S795

Gigaset Communications GmbH Frankenstr. 2a, D-46395 Bocholt Manufactured by Gigaset Communications GmbH under trademark license of Siemens AG. As of 1 Oct. 2011 Gigaset products bearing the trademark 'Siemens' will exclusively use the trademark 'Gigaset'.

www.gigaset.com

S790 - S795

GIGASET. INSPIRING CONVERSATION.

Gigaset S790/S795 – more than just a telephone

Your telephone sets new standards for the way you communicate at home. The configuration and user interface of the cordless phone are excellent, providing you with first-class voice quality in speaker mode, while the USB port offers you enormous flexibility.

The large TFT display, user-friendly keypad and clearly laid out menu are very simple to use.

Your phone can do a whole lot more:

u You can synchronise the directories on your telephone, mobile pho ne and PC via

the USB port using the Gigaset QuickSync software (

u You can save appointments (¢page 44) and anniversaries, e.g., birthdays

¢ page 34), in your phone and it will remind you of them in advance.

(

u You can designate important people as VIPs to identify important calls from the

ringtone (

u You can assign a picture to entries in the directory – in the future the picture will

appear every time you receive a call from this number (

u If you do not want to take calls where the caller has withheld their number, just

set your handset to only ring if Calling Line Identification (CID) has not been blocked (

u If you do not wish to be disturbed, you can simply set up a time control so that

your phone will only ring when it is convenient ( connected during this time.

u You can assign important numbers to the number keys on your phone. The

number is then dialed by simply pressing a key (

u Adapt your Gigaset to suit your handsfree requirements (¢ page 54). u View your personal pictures as a screensaver slide show (¢page 53). u You can set the display to large font to increase readability in particularly impor-

tant situations (e.g. the directory and lists) (

u You can adapt the menu display to suit your individual requirements so that only

the most important functions (standard mode) or all functions (expert mode expert mode are marked with the

u Gigaset Green Home — Be environmentally aware when using your phone.

Details about our ECO DECT products can be found at www.gigaset.com/customercare

¢ page 32).

¢ page 55).

) display (¢page 26). Menu options that are only available in

•

¢ page 53).

icon.

•

¢ page 63).

¢ page 32).

¢ page 55). VIP calls are still

¢ page 52).

You can find additional information about your phone at www.gigaset.com/gigasets790

Have fun using your new phone!

The handset at a glance

Ã V

07:15am

INT 1 Oct 14

INT Calls

The handset at a glance

1 Display in idle status 2 Battery charge status ( 3 Side keys

Set call (

¢page 54) or ringtone volume

¢page 55)

( 4 Display keys ( 5 Message key (

Access to call and message lists;

Flashes: new message or new call 6 End call key, On/Off key

End call, cancel function, go back one menu

level (press briefly), back to idle status (press

and hold), activate/deactivate handset (press

and hold in idle status) 7 Pound key

Keypad lock on/off (press and hold in idle sta-

tus);

toggles between upper/lower case and digits 8 MUTE key (

Mute the microphone 9 Microphone

10 FLASH key

- Flashes: Consultation call

- Insert a dialing pause (press and hold)

11 Star key

Ringtone on/off (press and hold);

with an open connection: switch between

pulse dialing/tone dialing (press briefly);

text input: open table of special characters

12 Headset connection ( 13 Key 1

Dial answering machine (S795 only)/

network mailbox (press and hold)

14 Talk k ey

Flashes: incoming call;

Accept a call; open redial list (press briefly);

start dialing (press and hold)

15 Speaker key

Switch between earpiece and speaker mode

16 Control key ( 17 Signal strength (

Green: Eco Mode (¢page 44) activated

18 Answering machine symbol (S795 only)

Answering machine switched on;

Flashes: answering machine is recording a

message or is being operated by another inter-

nal party

¢page 21)

¢page 31)

¢page 20)

¢page 16)

¢page 37)

¢page 18)

¢page 16)

The handset at a glance

Signaling

External call (¢ page 29)

ØåÚ Ø

Internal call (¢page 48)

answering machine is recording (

¢ page 38)

i Ã

Û 08:00

07:15am

INT 1 Oct 14

™



02 10 08

INT Calls

ØðÚ

Anniversary (¢ page 45)

ØìÚ

Alarm (¢ page 46)

Signal strength i (¢page 44)

Answering machine switched on (S795 only)(¢ page 4)

Ringtone switched off (

¢ page 55)

Keypad lock switched on (

¢ page 23)

ØáÚ

Appointment (¢ page 45)

Batteries are charged (¢ page 16) Charge status of the batteries (

¢ page 16)

Alarm switched on and wake-up time set (

¢ page 46)

Current time (¢page 15)

Current day and month (

¢ page 15)

Name of the handset (

¢ page 50)

Number of new messages:

u Ã on the network mailbox (¢page 37) u ™ in the list of missed calls (¢ page 37) u  in the list of missed appointments (¢ page 37)

Display symbols

The following symbols may display, depending on the settings and the operating status of your telephone:

The base at a glance

You can use the keys on the base to register handsets to the base, search for handsets (paging) grated answering machine (Gigaset S795 only).

Gigaset S795 base

(¢ page 48) and operate the inte-

During message playback:

4 Play/Stop button

Play back new messages from answering

machine or cancel playback (press briefly).

Play back new and old messages (press and

hold). 5 Skip to next message (press once) or skip

ahead two messages (press twice). 6 Skip back five seconds (press briefly once),

skip back to the beginning of the message

(press and hold) or skip back to the previous

message (press twice). 7 Delete current message. 8 Adjust volume during message playback:

= quieter;

While an external call is being signaled: adjust

ringtone volume.

ø = louder.

Please note:

If the answering machine is being operated from a handset or if it is recording a message (00 flashes), it cannot be operated from the base at the same time.

Gigaset S790 base

1 Registration/Paging button

Press briefly: search for handsets (paging) (

¢page 48).

Press and hold: register handsets and DECT devices (

2 On/Off button

Activating/deactivating the answering machine.

3 Display

Lights up: answering machine is activated. The number of saved messages displays. 00 flashes: the answering machine is recording a new message. Flashes slowly: there are new messages. The number of new messages displays. 99 flashes quickly: the answering machine is full.

¢page 47).

Registration/Paging button

– Press briefly: search for handsets (paging)

(

¢page 48).

– Press and hold: register handsets and DECT

devices (

¢page 47).

Gigaset S790/S795 – more than just a telephone . . . . . . . . . . . . . . . . . . . . 1

The handset at a glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Display symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

The base at a glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

First steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Checking the package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Setting up the base and charger (if included) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Connecting the base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Connecting the charger (if included) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Setting up the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Setting the date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Setting up area codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Connecting the headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Connecting the USB data cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

What would you like to do next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Using the phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Control key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Display keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Keys on the keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Side keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Correcting incorrect entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Using the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Activating/deactivating the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Activating/deactivating the keypad lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Using this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Making calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Making an external call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Ending a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Accepting a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Using the speaker mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Switching to mute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Contents

Using the directory and lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Redial list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Answering machine list (Gigaset S795 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Call lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Opening lists with the message key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

List of missed alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Operating the Gigaset S795 base answering machine . . . . . . . . . . . . . . 38

Operating via the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Activating/deactivating call screening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Setting the recording parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Resetting fast access for the answering machine using key 1 . . . . . . . . . . . . . . . . . . 42

Operating when on the move (remote operation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Using the network mailbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Configuring fast access for the network mailbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Viewing the network mailbox message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

ECO DECT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Setting an appointment (calendar) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Displaying missed appointments, anniversaries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Setting the alarm clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Using multiple handsets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Registering handsets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

De-registering handsets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Locating a handset ("Paging") . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Changing the base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Making internal calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Listening in to an external call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Changing the name of a handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Changing a handset's internal number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Using a handset as a room monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Handset settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Quick access to numbers and functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Changing the display language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Setting the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Setting keypad illumination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Activating/deactivating auto answer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Changing the speaker/earpiece volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Setting a handsfree profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Changing ringtones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Resource Directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Activating/deactivating advisory tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Setting long-distance and area codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Restoring the handset default settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Contents

Setting the base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Changing the Gigaset S795 base ringtones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Activating/deactivating music on hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Protecting against unauthorized access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Resetting the base to the factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Connecting the base to the PABX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Dialing modes and recall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Setting pauses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Switching temporarily to tone dialing (DTMF) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Caring for your telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Contact with liquid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Writing and editing text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Additional functions via the PC interface . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Industry Canada Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

FCC / ACTA Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Service (Customer Care) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

End-user limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Mounting the base on the wall (Gigaset S790 only) . . . . . . . . . . . . . . . . . 72

Mounting the charger on the wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Safety precautions

Warning

Be sure to read this user guide and the safety precautions before using your telephone.

Explain their content and the potential hazards associated with using the telephone to your children.

Use only the power adapter supplied, as indicated on the underside of the base.

Use only rechargeable batteries that correspond to the specification provided on page 62, as this could otherwise result in significant health risks and personal injury. Do not charge the handset in charging unit or base while the headset is connected.

Using your telephone may affect nearby medical equipment. Be aware of the technical conditions in your particular environment, e.g., doctor's surgery.

Do not hold the rear of the handset to your ear when it is ringing or when speaker mode is activated. You risk serious and permanent damage to your hearing.

Your Gigaset is compatible with the majority of digital hearing aids on the market. However, perfect function with all hearing aids cannot be guaranteed.

The handset may cause an unpleasant humming or whistling noise in hearing aids or cause them to overload. For assistance, please contact the hearing aid supplier.

Do not install the base or charger in bathrooms or shower rooms. The base and charger are not splashproof (

¢ page 61).

Do not use your phone in environments with a potential explosion hazard (e.g., paint shops).

If you give your phone to a third party, make sure you also give them the user guide.

Remove faulty bases from use or have them repaired by our Service department, as they could interfere with other wireless services.

Please note

Not all of the functions described in this user guide are available in all countries.

First steps

345

Checking the package contents

First steps

1 One Gigaset S790 or S795 base 2 One power adapter 3 One Gigaset S79H handset 4 One phone cord 5 Two batteries 6 One battery cover 7 One belt clip 8 One plastic headset connection cover 9 One user guide

If you have purchased a

model with multiple handsets the package should

contain one additional set of each of the following items for each handset: battery sets, battery cover, belt clip, handset, and charging

9 with power

cradle adapter

First steps

Setting up the base and charger (if included)

The base and charger are designed for use in dry rooms in a temperature range of +41°F to +113°F.

¤ Set up the base at a central point in the building on a level, non-slip surface or

mount the base (Gigaset S790 only) or charger on the wall (

Please note

Pay attention to the range of the base. This is up to 984 feet in unobstructed outdoor areas and up to 165 feet inside buildings. The range is reduced when Eco Mode (

The phone's feet do not usually leave any marks on surfaces. However, due to the multitude of different varnishes and polishes used on today's furnishings, the occurrence of marks on the surfaces cannot be completely ruled out.

Please note:

u Never expose the telephone to the influence of heat sources, direct sunlight or

other electrical devices.

u Protect your telephone from moisture, dust, corrosive liquids and fumes.

¢ page 44) is activated.

Connecting the base

¤ First connect the

power adapter 1.

¤ Then connect the

telephone jack 2 and insert the cables into the cable ducts.

¢ page 72).

Please note:

u The power adapter

must always be connected, as the phone will not operate without.

u Use only the power adapter and phone cord supplied. Pin connections on tele-

phone cables can vary (

¢ page 62).

Connecting the charger (if included)

¤ Plug the power adapter into the plug

socket 2.

¤ Connect the flat plug from the power

adapter 1.

To disconnect the plug from the charger, press the release button 1 and disconnect the plug 2.

First steps

¤ Insert the batteries with

the polarity in the correct direction. The polarity is indicated in/on the battery compartment.

¤ First insert the battery

cover at the top a.

¤ Then press the cover b

until it clicks into place.

To open the battery cover, for instance to replace the batteries, insert a coin into the cavity on the left-hand side of the casing, then pull the battery cover in an upward direction.

Setting up the handset

The display and keypad are protected by plastic films.

Remove the protective films!

Inserting the batteries and closing the battery cover

Use only rechargeable nickel-metal hydride (NiMH) UL-approved AAA batteries. Never use conventional (non-rechargeable) batteries, as this could result in significant health risks and personal injury. For example, the outer casing of the batteries could be damaged or the batteries could explode. The phone could also malfunction or be damaged as a result of using batteries that are not of the recommended type.

Warning

¤ Insert the plastic cover provided for the

headset socket to ensure optimum sound in speaker mode.

Attaching the belt clip

The handset has notches on each side to attach the belt clip.

¤ To att ach — press the belt clip

onto the back of the handset so that the protrusions on the belt clip engage with the notches.

¤ To remov e — press the center of

the belt clip firmly with your right thumb, push the fingernail of your left index finger up between the clip and the housing and pull the clip in an upward direction.

First steps

Placing the handset in the base/charger

¤ Place the handset in the base/charger with its display facing forward.

Each handset is registered with the base at the factory. You do not need to register the handset again. If you wish to use your handset with a different base or use further handsets with your base, register the handset manually (

To charge the batteries, leave the handset in the base/charger.

Please note

Only place the handset in the designated base/charger included with the handset.

¢ page 47).

First steps

¤ Charge the handset for 8.5 hours in the base/

charger.

¤ Then remove the handset

from the base/charger and do not replace it until the batteries are fully discharged.

8.5 hrs

First battery charge and discharge

The correct charge level can only display if the batteries are first fully charged and discharged.

Please note

u After the first battery charge and discharge, you may replace your handset in

the base/charger after every call.

u Always repeat the charging and discharging procedure if you remove the

batteries from the handset and reinsert them.

u The batteries may warm up during charging. This is not dangerous. u After a while, the charge capacity of the batteries will decrease for technical

reasons.

Setting the date and time

Date/Time

Date:

10/14/2009

Time:

00:00am

AM/PM Save

¤ Press the key below §Time§ on the dis-

play to open the input field. If you have already set the time and

date, open the input field via the menu (

¢ page 28.)

The Date/Time submenu displays.

¤ The active input position flashes. Enter

the month, day and year as an 8-digit number via the keypad, e.g., Q42QQ O for 10/14/2009.

Date/Time

Date:

01/31/2009

Time:

00:00am

AM/PM Save

INT Time

Press the right or left control key to change the input position and correct an entry.

¤ When you switch to time entry, the Back

display key turns to AM/PM. Enter the hours and minutes in 4-digit format via the keypad, e.g., QM5 for 07:15 am. Change the input position with the control key if necessary. If necessary, press the AM/PM display key to change the time setting from AM to PM.

¤ Press down on the control key to switch

to the time input field.

Set the date and time so that the correct date and time can be assigned to incoming calls, and so that the alarm can be used.

First steps

¤ Press the key below §Save§ on the dis-

play to confirm your entry.

The display shows Saved. You will hear a confirmation tone and the handset automatically returns to idle status.

Back Save

Date/Time

‰

Saved

07:15 am

INT 1 Oct 14

INT Calls

Display in idle status

After registering the phone and setting the time, the idle display shows as in this example. If the answering machine is activate, the answering machine icon displays in the header.

Displays

u Reception between the base and the handset:

u Charge status of the batteries:

u INT 1

Your answering machine is set with a pre-recorded announcement.

Your phone is now ready to use!

– Poor to good: ÒÑiÐ –No reception: | flashes Green: Eco Mode activated (

– yy{{ (empty to full) – yflashes red: batteries almost empty – xyx{x{ (charging)

Internal name of the handset (

¢ page 44)

¢ page 50)



Setting up area codes

Before you can return a call from the Calls list (¢ page 36), you must store the local area code of the area in which your phone is being used. If your phone is in a multiple area code area, you must also store the extra codes for that area.

Local Area Code

v ¢Ï ¢ Te le ph on y ¢ Local Area Code ~ Enter the local area code.

§Save§ Press the Display key.

a When the Saved message displays, press and hold to return to idle sta-

tus.

Extra Codes

v ¢Ï ¢ Te le ph on y ¢ Extra Codes ~ Enter the extra code.

§Save§ Press the Display key.

a When the Saved message displays, press and hold to return to idle sta-

tus.

Repeat the above steps until all the extra codes have been entered for your area. A maximum of five (5) extra codes can be stored.

First steps

Connecting the headset

After removing the plastic cover, you can connect a headset to the left-hand side of your telephone with the 2.5 mm jack connector. See the relevant product page at www.gigaset.com information on recommended headsets. The headset volume corresponds to the settings for the handset volume (

After using the headset, replace the plastic cover to enable optimum sound in speaker mode.

Warning

Do not charge the handset in charging unit or base while the headset is connected.

Connecting the USB data cable

You can connect a standard USB data cable with a mini-B connector to the back of your handset to connect the handset to a PC (

¤ Remove the belt clip (if attached)

¢ page 13).

(

¤ Remove the battery cover (¢page 12). ¤ Connect the USB data cable to the USB

socket

for

¢ page 54).

¢ page 63).

Please note

Please connect your handset directly to the PC; do not connect via a USB hub.

What would you like to do next?

Now that you have successfully set up your phone, you will certainly want to adapt it to your personal requirements. Use the following guide to quickly locate the most important topics.

If you are unfamiliar with menu-driven devices such as other Gigaset telephones, read the section entitled "Using the phone" (

Information about ... ... go to...

Setting the ringtone and volume page 55

Setting the earpiece volume page 54

First steps

¢ page 20) first.

Recording your own announcement for the answering machine

Setting Eco Mode page 44

Operating the telephone on a PABX page 59

Registering existing Gigaset handsets to a base page 47

Transferring directory entries from existing Gigaset handsets to new handset(s)

Connecting the phone to the PC page 63

If you have any questions about using your phone, please read the tips on troubleshooting ( (

¢ page 68).

¢ page 60) or contact our Customer Care team

page 38

page 34

Using the phone

Control key

Below, the side of the control key that you must press in the respective operating situation is marked in black (top, bottom, right, left, center), e.g., v for "press right on the control key" or w for "press the center of the control key".

The control key has a number of different functions:

When the handset is in idle status

s Open the directory. v Open the main menu. u Open the list of handsets. t Call up the menu for setting the handset's call volume (¢ page 54).

In the main menu

t, s, v or u

Navigate to the required function.

In submenus and lists

t / s Scroll up/down line by line.

In input fields

Use the control key to move the cursor up t, down s, right v or left u. Press and hold v or u to move the cursor word by word.

During an external call

s Open the directory. u Initiate an internal consultation call. t Adjust the volume for earpiece and speaker mode.

Functions when pressing the middle of the control key

Depending on the operating situation, the key has different functions.

u In idle status the key opens the main menu. u In submenus, selection and input fields, the key takes on the function of the

display keys

§OK§, §Yes§, §Save§, §Select§ or §Change§.

Please note

These instructions demonstrate the main menu being opened by pressing the right of the control key and functions being actuated by pressing the appropriate display key. However, if you prefer, you can use the control key as described above.

Display keys

Back Save

Current display key functions.

Display keys

Options

Back

Save

The functions of the display keys change depending on the particular operating situation. Example:

Some important display keys:

Open a menu for further functions.

Confirm selection.

Delete key: delete character by character/word at a time from right to left.

Go back one menu level or cancel operation.

Store entry.

Open the redial list.

Forward a call to the answering machine.

Keys on the keypad

c / Q / * etc.

Press the matching key on the handset.

~ Enter digits or letters.

Using the phone

Side keys

Correcting incorrect entries

ø / ÷ Press the keys on the right of the handset to set the volume for the

handset, ringtone, speaker, alarm, signaling of appointments and the headset depending on the situation.

You can correct characters in the input fields by navigating to the incorrect entry using the control key. You can then:

u Delete the character to the left of the cursor with the display key or delete the

entire word by pressing and holding Ñ

u Insert characters at the cursor position u Overwrite the highlighted (flashing) character, e.g. when entering time and

date.

Using the phone

Settings

á Â

Back OK

Settings

Date/Time

Display

Language

Registration

Telephony

Back OK

Using the menus

You can access your telephone's functions using a menu that has a number of levels.

The menu display can be extended (expert mode mode). Expert mode is the default setting.

Settings or functions that are only available in expert mode are marked in these instructions by the

For more information regarding "switching" between standard mode/expert mode and Menu Overview, please refer to page 26. (

Main menu (first menu level)

¤ When the handset is in idle status press the right control key v to open the

main menu.

The main menu functions display with icons. The icon for the selected function is highlighted in orange and the name of the associated function appears in the display header.

To access a function, i.e., to open the corresponding submenu (next menu level):

¤ Use the control key p to select the required func-

tion and press the display key

Briefly press the display key §Back§ or the end call key a to revert back to idle status.

•

icon.

§OK§.

) or restricted (standard

•

¢ page 26).

Submenus

The functions in the submenus are displayed as lists (as shown on the right).

To access a function:

¤ Scroll to the function with the control key q and

Briefly press the display key §Back§ or the end call key a to return to the previous menu level/cancel the operation.

press

§OK§.

Reverting to idle status

You can revert to idle status from anywhere in the menu as follows:

¤ Press and hold the end call key a.

or:

¤ Do not press any key: after 2 minutes the display will automatically rev ert to i dle

status.

Settings that have not been saved by selecting the display keys

§Change§ are lost.

An example of the display in idle status is shown on page 16.

Activating/deactivating the handset

a With the phone in idle status, press and hold the end call key (confir-

mation tone) to switch off the handset. Press and hold the end call key again to switch the handset on.

Please note

When the handset is switched on, an animation showing the Gigaset logo displays for several seconds.

Activating/deactivating the keypad lock

The keypad lock prevents any unauthorized or accidental use of the phone. # Press and hold the pound key in idl e status to activate or deactivate the

keypad lock. You will hear the confirmation tone.

If the keypad lock is activate, you will see a message when you press a key.

The keypad lock deactivates automatically when you receive a call. It is reactivated when the call is finished.

Using the phone

§OK§, §Yes§, §Save§ or

Please note

When the keypad lock is active, you cannot call emergency numbers.

Emergency numbers cannot be dialed if the keypad lock is activated!

Using the phone

¤ Press right on the control key v

to open the main menu.

¤ Press right, left, down and up on

the control key p to navigate to the Settings submenu.

¤ Press the display key §OK§ to confirm

your selection.

¤ Press down on the control key

until the Display menu option appears on the display.

¤ Press the display key §OK§ to confirm

your selection.

Settings

Date/Time

Display

Language

Registration

Tel ep h on y

Back OK

Settings

á Â

Back OK

Using this guide

The operating steps are shown in abbreviated form.

Example:

The illustration:

v ¢

means:

¢ Display ¢ Large Font (³ =on)

Using the phone

The change is effective immediately and does not need to be confirmed.

¤ Press down on the control key

until the Large Font menu option appears on the display.

¤ Press the display key §Change§ to

activate/deactivate the function.

Display

Screensaver

Large Font

Color Schemes

Backlight

Back Change

Display

Screensaver

Large Font

Color Schemes

Backlight

Back Change

¤ Press the key below §Back§ on the dis-

play to jump back to the previous menu level.

or Press and hold the end call key a to

return to idle status.

Menu overview

Setting standard mode or expert mode

The menu display can be extended (expert mode •) or restricted (standard mode). Menu options that are only available in expert mode are marked with the

To change these settings: Select v ¢Ï ¢ Menu View ¢ Simplified (standard mode) or Complete (expert mode)

¢ §Select§ (the active mode is marked with Ø)

Open the main menu: Press v when the phone is in idle mode.

•

icon.

Audio Settings

Resource Directory

Screensavers ¢page 56

Caller Pictures

Sounds

Capacity

Additional Features

Room Monitor ¢page 50

Alarm Clock

Call Lists

All Calls ¢page 36

Outgoing Calls

Accepted Calls

Missed Calls

Handset Volume ¢page 54

Handsfree Profiles

Advisory Tones ¢ page 57

•

Ringtones(Handset)

Ringtones (Base)*

Music on Hold ¢ page 58

•

¢page 56 ¢page 56 ¢page 56

¢page 46

¢page 36 ¢page 36 ¢page 36

¢page 54

¢page 55 ¢page 58

* Base with answering machine only

Voice Mail

Play Messages Network Mailbox ¢page 43

Answering Machine *

Activation *

Announcements * Rec. Announcement *

Recordings * ¢ page 41

•

Call Screening * ¢page 41

•

Network Mailbox ** ¢ page 43

•

Set Key 1 * Network Mailbox ¢page 43

•

* Base with answering machine only ** Base without answering machine only

Organizer

Calendar ¢page 44

Missed Alarms

¢page 38

Play Announcement *

Del. Announcement *

Rec. Advisory Msg. * ¢page 38

•

Play Advisory Msg. * ¢page 39

•

Del. Advisory Msg. * ¢page 39

•

Answering Machine

¢page 46

Menu overview

¢page 38

¢page 38 ¢page 38 ¢page 38

¢page 43

Making calls

If the backlight is deactivated (¢ page 53) it is switched on by pressing any key. In this case the pressed key has no other function.

Making an external call

External calls are calls using the public telephone network.

~c Enter the number and press the

talk key.

or: c~ Press and hold the talk key c

and then enter the number.

You can cancel the dialing operation with the end call key a.

You are shown the duration of the call while the call is in progress.

Please note

Dialing with the directory (¢ page 32), call list ( ( ( keying in phone numbers.

¢ page 36), redial list ¢ page 35) and automatic redial ¢ page 35) saves you from repeatedly

Accepting a call

The handset indicates an incoming call in three ways: by ringing, by a display on the screen and by the flashing talk key c.

Accept the call by:

¤ Pressing the talk key c. ¤ Pressing the speaker key d. ¤ Gigaset S790: press the display key

§Accept§.

¤ Gigaset S795: press the display key Ô

to divert the call to the answering machine (

If the handset is in the base/charger and the Auto Answer function is activated

¢ page 54), the handset automatically

( answers the call when you remove it from the base/charger.

To deactivate the ringtone, press the display key. You can accept the call as long as it displays on the screen.

¢ page 41).

§Silence§

Ending a call

a Press the end call key.

Making calls

Ø«Ú

9725551234

Accept Silence

Gigaset S790

Gigaset S795

Ø«Ú

9725551234

Silence

Ø«Ú

9725551234

Anna Lechner

Accept Silence

Using Caller ID

Caller ID (CID) and Caller Name ID (CNID) are optional subscription services provided by your telephone service provider. These features supply incoming caller identification information that displays on your handset.

Call display with Caller ID/ Name

If the number of the caller is saved in your directory, you will see their name, and if you have assigned a caller picture (CID picture) to that caller, this will also be displayed.

Display with CID

If you have CID, then the name that is registered with your network provider for the caller's number will also be displayed. If the number of the caller is stored in your directory, the CID display is replaced by the corresponding directory entry.

1Caller's number 2Name

The display shows:

u External, if no number is transmitted. u Unavailable, if the caller has not

arranged Calling Line Identification.

Please note

The ringtone can be switched off for unknown calls (calls with Calling Line Identification (CID) blocked)

¢ page 55).

(

1 Ringtone icon or CID picture 2 Number or name of caller

The following displays in place of the number:

u External, if no number is transmitted. u Unavailable, if the caller has not

arranged Calling Line Identification.

Making calls

Using the speaker mode

In speaker mode, instead of holding the handset to your ear you can put it down, for example on the table in front of you. This allows others to participate in the call.

Activating/deactivating speaker mode

Activating while dialing

~d Enter the number and press the

speaker key.

¤ Inform your caller before you use the

speaker function so that the caller knows a third party may be listening.

Switching between earpiece and speaker mode

d Press the speaker key.

During a call and when listening to the answering machine (Gigaset S795 only), activate or deactivate speaker mode.

To place the handset in the base/charger during a call:

¤ Press and hold the speaker key d while

placing the handset in the base/charger and for a further 2 seconds.

For instructions on adjusting the speaker volume (

¢ page 54).

Switching to mute

You can deactivate the microphone in your handset during an external call.

h Press key to mute the handset.

The display shows Microphone is off. Press the key again to reactivate the microphone.

Please note

u If the telephone is muted, all keys

except the MUTE key h and the end-call key a will not work.

u A connected headset will also be

muted.

Please note

If you have a headset connected, you can switch between the headset and speaker mode.

Using the directory and lists

The options are:

u Directory u Redial list u Call lists u List of missed appointments u Answering machine list

(Gigaset S795 only)

You can create a personalised directory for your own handset. You can also send lists/ entries to other handsets (

Redial list

The redial list contains the twenty numbers last dialed with the handset (max. 32 digits). If one of the numbers is in the directory, the corresponding name displays.

Manual redial

c Press the key briefly. s Select entry. c Press the talk key again. The

number is dialed.

When a name displays, you can display the corresponding phone number by pressing the display key

Managing entries in the redial list

c Press the key briefly. s Select entry.

§Options§ Open menu.

The following functions can be selected with q:

Copy to Directory

Copy an entry to the directory (page 32).

Automatic Redial

The selected number is automatically dialed at fixed intervals (at least every 20 seconds). The speaker key flashes and "open listening" is activated.

– Party answers:

Press the talk key c. The function is ended.

– Party does not answer:

The call is terminated after approx. 30 seconds. The function is ended after pressing any key or after ten unsuccessful attempts.

Display Number (as in the directory, page 33)

Delete Entry (as in the directory, page 33)

Delete All (as in the directory, page 33)

§View§.

Using the directory and lists

All Calls

™ Frank

10/14/09, 5:40pm

š 9725551234

10/14/09, 5:32pm

™ ...15125551234

10/14/09, 5:07pm

View Options

Answering machine list (Gigaset S795 only)

You can use the answering machine list to listen to the messages that are on the answering machine.

Call lists

Prerequisite: Caller ID service subscription

(CID, page 30)

Your telephone stores various types of calls:

u Answered calls u Outgoing calls u Missed calls u Calls recorded by the answering machine

(Gigaset S795 only)

You can view each type of call separately or gain an overview of all calls. Each call record contains the last 20 numbers in its category.

When in idle status, open the call lists by selecting the menu:

List entry

New messages are displayed at the top.

Example of list entries:

§Calls§ display key or via the

u Type of entry:

– Accepted calls ( – Missed calls ( – Outgoing calls ( – Calls recorded by the answering

machine (Ã, Gigaset S795 only)

Press the talk key c to call the selected caller back.

Press the tional information, including for example the number linked to the name. If you have CID, then the name and town that is registered with your network provider for this number displays. If the name and town are not shown, it means that the caller has not requested CID or that CID has been withheld.

Select the following options:

Copy to Directory

Delete Entry

Delete All

When you quit the call lists, all entries are set to the status "old", i.e., the next time you call up the list, they will no longer be shown in bold.

§View§ display key to access addi-

§Options§ display key to select the

Copy the number to the directory.

Delete selected entry.

Delete all entries.

› )

™ )

š )

u List type (in header) u Status of entry

Bold: New entry

u Number or name of caller u Date and time of call (if set, page 15)

Using the directory and lists

œ



02 10



Messages & Calls

Calls: (3)

Missed Alarms (1)

Back OK

Opening lists with the message key

Use the message key f to open the following list selection:

u Answering machine list (Gigaset S795

only) or network mailbox, if your network provider supports this function and fast access is set for the network mailbox

¢ page 43).

(

u List of missed calls u List of missed alarms (¢ page 37)

An advisory tone sounds as soon as a new message arrives in a list. The f key flashes (it goes off when the key is pressed). In idle status, the display shows an icon for the new

message:

Icon New message...

... in the answering machine list

™



The number of new entries displays under the corresponding icon.

If calls are saved in the network mailbox, you will receive a message if the appropriate settings have been made (see your network provider user guide).

After pressing the message key f, you can see all lists containing messages and the network mailbox list.

(Gigaset S795 only) or on the network

mailbox

... in the missed calls list

... in the Missed Alarms list:

Please note

Lists containing new messages are at the top of the list and are marked in a bold font.

Select a list with q. To open, press

§OK§.

List of missed alarms

Missed (unacknowledged) appointments from the calendar (

¢ page 34) are saved in the Missed

saries ( Alarms list under the following circumstances:

u You do not accept an appointment/anni-

versary.

u The appointment/anniversary was sig-

naled during a phone call.

u The handset is deactivated at the time of

the appointment/anniversary.

u Automatic redial was activated at the

time of an appointment/anniversary

¢ page 35).

(

u Open the list by pressing the message

key f (

Each entry displays with:

u Number or name u Date and time

The most recent entry is at the head of the list.

Press the display key selected entry.

If 10 entries are already stored in the list, the next appointment reminder will delete the oldest entry.

¢ page 44) and anniver-

¢ page 37).

§Delete§, to delete the

Operating the Gigaset S795 base answering machine

•

Operating the Gigaset S795 base answering machine

You can access the answering machine via the handset, the buttons on the base

¢ page 4) or by remote operation (from

( another phone/mobile phone). You can record your own announcement message or advisory message via the handset.

Answering machine mode

You can use the answering machine in two different modes.

u In Answer & Record mode, the caller

hears the announcement and can then leave a message.

u In Answer only mode, the caller hears

your announcement but cannot leave a message.

Operating via the handset

The handset loudspeaker activates automatically if you receive an acoustic prompt

or message while operating. You can switch it off with the speaker key d.

Activating/deactivating and setting the answering machine mode

You can choose between Answer & Record, Answer only and Alternating. By using the Alternating setting, you can activate answer

and record mode for a set period of time, outside this period the caller will only hear the announcement.

§Edit§ Press the display key.

¤ You can enter data in the following fields:

Activation:

¢ Activation (μ=on)

Select On or Off to activate/deactivate the answering machine.

Mode:

Select Answer & Record, Answer only or Alternating.

If Alternating mode is selected: Record from:

Enter hours/minutes for the start of the period in 4-digit format. (The time must be set on the phone beforehand.)

Record until:

Enter hours/minutes for the end of the period in 4-digit format.

If Answer & Record is not set, Answer only mode applies.

§Save§ Press the display key.

If the messages memory is full and Activation: On has been selected, saving is interrupted and you will receive an instruction to delete old messages.

When you switch the answering machine on, the remaining memory time is announced. If the time has not yet been set, an appropriate announcement is made (set

¢ page 15). The

time the display. The LED display on the base lights up (

The phone is supplied with pre-recorded announcements for Answer & Record mode and for Announce only mode. If a personal announcement has not been recorded, the relevant pre-recorded announcement is used.

¢ page 4).

icon appears in

Recording personal announcements/ advisory messages

v ¢Ì ¢ Announcements

¢ Rec. Announcement / Rec. Advisory

Msg.

§OK§ Press the display key to start the

recording.

You hear the ready tone (short tone).

¤ Now speak your announcement (at least

3 secs.).

§End§ Press the display key to end the

recording.

Operating the Gigaset S795 base answering machine

•

Cancel recording with a or §Back§. Restart the recording with

After recording, the announcement is played back for you to check. You can rerecord the announcement with

§OK§.

Please note:

u Recording ends automatically if the max-

imum recording time of 170 seconds is exceeded or there is a break in speech for more than 2 seconds.

u If you cancel the recording, the pre-

recorded announcement is used again.

u If the answering machine's memory is

full, it will switch to Answer only mode.

¤ Delete old messages and the answer-

ing machine will automatically switch back to Answer & Record mode. Repeat recording if required.

Playing back personal announcements/ advisory messages

v ¢

¢ Play Announcement / Play Advisory

Msg.

If you have not recorded a personal announcement, the relevant pre-recorded announcement is played.

Record a new announcement while playing back the announcement:

§New§ Press the display key.

If the answering machine's memory is full, it will switch to Answer only mode.

¢ Announcements

¤ Delete old messages and the answering

machine will automatically switch back to Answer & Record mode. Repeat recording if required.

Deleting personal announcements/ advisory messages

v ¢Ì ¢ Announcements

¢ Del. Announcement / Del. Advisory

Msg.

§New§.

§Yes§ Press the display key to confirm

the prompt.

Once you have deleted your announcement, the relevant pre-recorded announcement is used again.

Please note

Deleting announcements can take some time.

Playing back messages

The date and time of each message is logged (provided this has been set, displayed during the playback. If Calling Line Identification is activated, the caller's number or name displays. If the caller's number is saved in the directory, their name displays.

Playing back new messages

New messages that have not yet been played back are indicated on the display with an icon and number:

The fkey on the handset and the display on the base will flash. The number of new messages displays on the base.

f Press the message key.

Ans. Machine:

Select and press

If there are new messages, playback then begins with the first new message. After the last new message, you will hear the end tone and an announcement stating how much recording time remains.

If the message has been saved with the date and time, you will hear an appropriate announcement before playback begins.

Playing back old messages

You can listen to old messages if there are no more new messages. Begin playback as described under "Playing back new messages".

¢ page 15) and

§OK§.

Operating the Gigaset S795 base answering machine

After the entry time and date have been played back (after approx. 3 seconds) a new message assumes the status "old".

Stopping and controlling playback

During message playback: 2 Pause playback. Press 2

again to resume.

§Options§ Open menu.

Pause Select and press §OK§.

To c o ntinue sel ect Continue and press

t or

Go to the start of the current message. Press twice to go back to the previous message.

s or 3

Skip to next message. Press twice to skip ahead two messages.

If playback is interrupted for over a minute, the answering machine returns to idle status.

§OK§.

Marking a message as "new"

A previously played back "old" message displays as a "new" message again.

During message playback: * Press the star key.

or:

§Options§ Open menu.

Mark as New

Select and press

An announcement informs you of the message's new status.

Playback of the current message is cancelled. Playback of next message starts, if applicable.

The f key on the handset flashes.

§OK§.

Copying a phone number from a message to the directory

During playback or pause:

§Options§ ¢Copy to Directory

¤ Complete the entry (¢ page 34).

Deleting messages

You can either delete all old messages together or individually.

Deleting all old messages

During playback or pause:

§Options§ ¢Delete Old List

§OK§ Press the display key to confirm

the prompt.

§Yes§ Press the display key to confirm

the prompt.

Deleting individual old messages

During playback or pause:

§Delete§ Press the display key.

Picking up a call from the answering machine

You can pick up a call while the answering machine is recording or is being operated via remote operation:

§Accept§

c/

Press the talk or display key.

Recording stops and you can speak to the caller.

If two seconds of the call have already been recorded when you pick it up, the call displays as a new message. The f key on the handset flashes.

You can answer the call, even if it is not signaled on the handset.

Operating the Gigaset S795 base answering machine

•

Diverting an external call to the answering machine

You can divert an incoming external call to the answering machine, even if it is deactivated.

Prerequisite: Sufficient memory space is available on the answering machine.

An external call is signaled on the handset:

Ô Select display key.

The answering machine starts immediately in Answer & Record mode and records the call. The set time for ring delay ( is ignored.

¢ page 41)

Activating/deactivating two-way record

You can record an external call with the answering machine.

¤ Inform the caller that the call is being

recorded.

§Options§ Open menu.

Two-way Record

Select and press

Two-way record is indicated on the display by an advisory text and is added to the answering machine list as a new message.

§End§ Press the display key to stop

two-way record.

The maximum recording time depends on the memory available on the answering machine. If the memory is full, you will hear an end tone, the recording is aborted, and the call recorded up to that point is listed in the answering machine list as a new message.

§OK§.

Permanently activating/deactivating call screening

v ¢

¢ Handset / Base (³=on)

§Change§ Select display key to activate/

Call screening can be simultaneously activated on the base and handset.

¢ Call Screening

deactivate the function.

Deactivating call screening for the current recording

You can deactivate the function for your own handset during the recording.

§Silence§ Press the display key.

Setting the recording

parameters

The answering machine has already been preset at the factory. Individual settings can be adjusted using the handset.

¢ Recordings

¤ You can enter data in the following fields:

Length:

Select maximum recording time 1 min., 2 min., 3 min. or Maximum.

Quality:

Select Long Play or High recording quality. If the quality is higher, the maximum recording time is reduced.

Ring Delay:

Select when the answering machine should accept a call:

Immediately, after 10 sec., 18 sec., 30 sec. or Auto.

§Save§ Press the display key.

Activating/deactivating

call screening

While a message is recording, you can screen calls via the base loudspeaker and registered handsets.

Information about ring delay

In Auto mode, the following applies for ring delay:

u If there are no new messages, the answer-

ing machine answers a call after 18 seconds.

u If there are new messages, the answering

machine answers a call after 10 seconds.

Operating the Gigaset S795 base answering machine

•

When operating remotely (¢page 42), you can tell after approx. 15 seconds that there are no new messages (otherwise the answering machine would have already accepted your call). There are no call charges if you hang up now.

Changing the language for voice prompt and pre-recorded announcement

v Open the main menu. *#Q5#2

Enter digits and press

§OK§ To set En g l i sh.

 §OK§ To set Fr e nch.

2 §OK§ To set Sp ani s h .

Resetting fast access for the answering machine using key 1

By default, key  has been assigned for fast access to the integrated answering machine. However, if you have set the network mailbox for fast access ( you can reset this setting.

Answering Machine

Once you have selected the answering machine, press and hold key . You are connected directly.

The setting for fast access applies to all registered handsets.

¢ Set Key 1

Select and press

¢ page 43),

§OK§.

Operating when on the move (remote operation)

You can check and activate your answering machine from any other telephone (hotel, pay phone etc.),.

Prerequisites:

u You have set a system PIN other than

¢ page 58).

0000 (

u The phone you are using for remote oper-

ation has tone dialing (DTMF), i.e., you hear different tones when you press the keys. Alternatively, you can use a code transmitter (available from your mobile phone retailer).

Calling the answering machine and playing back messages

~ Dial your own number. 9~ When you hear your announce-

ment, press 9 and enter the system PIN.

You are informed whether any new messages have been recorded. The messages are now played back. You can now operate the answering machine with the keypad.

The following keys are used for operation: A To return to the start of the cur-

rent message. Press twice to go back to the previous message.

B Stop playback. Press again to

resume.

3 Go to the next message. 0 Delete current message.

Activating the answering machine

¤ Phone home and let the phone ring until

you hear: "Please enter PIN".

Your answering machine is activated. It tells you how much memory time is left.

The messages are now played back.

The answering machine cannot be deactivated remotely.

Enter system PIN.

Using the network mailbox

•

Using the network mailbox

The network mailbox is your network provider's answering machine within the network. You cannot use the network mailbox unless you have requested it from your network provider.

Configuring fast access for the network mailbox

With fast access, you can dial the network mailbox or the integrated answering machine (Gigaset S795 only) directly.

Gigaset S790: Fast access is preset for the network mailbox. You only need to enter the number of the network mailbox.

Gigaset S795: The integrated answering machine is preset for fast access. You can configure the network mailbox instead. Ask your network provider about this.

Configuring fast access for the network mailbox and entering the network mailbox number

Gigaset S790:

v ¢Ì ¢ Set Key 1

Network Mailbox

Select and press

Ø Select= selected).

(

Gigaset S795:

v ¢Ì ¢ Network Mailbox

To c o ntinue: ~ Enter the number for the net-

work mailbox.

§Save§ Press the display key.

The setting for fast access applies to all Gigaset S79H handsets.

§Network Mailbox§

Calling the network mailbox

 Press and hold. You are con-

nected straight to the network mailbox.

d Press speaker key d if

required. You will hear the network mailbox announcement.

Viewing the network mailbox message

When a message is recorded, you receive a call from the network mailbox. If you have requested Calling Line Identification, the network mailbox number displays. If you accept the call, the new messages are played back. If you do not accept the call, the network mailbox number is saved in the missed call list and the message key flashes

¢ page 37).

(

Please note

Enter the network mailbox phone number into your directory along with the designation "Network mailbox"; the display and the call list will then show this designation.

ECO DECT

Oct 2009

Back Options

Mo Tu We Th Fr Sa Su

01 02 03 04

05 06 07 08 09 10 11

12 13 14 15 16 17 18

19 20 21 22 23 24 25

26 27 28 29 30 31

ECO DECT

You are helping to protect the environment with your Gigaset S790/S795.

Reducing energy consumption

By using a power-saving adapter plug, your telephone consumes less power.

Reducing radiation

The radiation from your telephone is reduced automatically:

u Handset: The closer the handset is to the

base, the lower the radiation.

u Base station: The radiation is reduced to

virtually zero when only one handset is registered and the handset is placed in the base.

You can reduce the radiation from the handset and base even more by using Eco Mode:

u Eco Mode

Reduces the radiation of the base station and handset by 80% - whether you are making a call or not. Eco Mode reduces the range of the base station by approx. 50%. Using Eco Mode always makes sense when a reduced range is sufficient.

Status displays

Display icon

Signal strength:

ÐiÑÒ

(flashes)

| Ð white Eco Mode deactivated Ð green Eco Mode activated

– good to poor – no signal

Please note

Activating Eco Mode reduces the range of the base.

Setting an appointment (calendar)

You can use your handset to remind yourself of up to 30 appointments. Anniversaries

¢ page 34) entered in the directory are

( automatically recorded in the calendar.

Saving an appointment.

Prerequisite: The date and time have

already been set (

v ¢Í ¢ Calendar

¢ page 15).

Activate/deactivate Eco Mode

v ¢Ï ¢ Eco Mode ¢ Eco Mode

§Change§ Press the display key (³ =on).

u The current day is selected (highlighted

in white).

u Days on which appointments have

already been saved are highlighted in white.

r/q Select the required day in the

graphical calendar.

Setting an appointment (calendar)

ØáÚ

Meeting

11/03/09 9:38am

Off

The selected day is highlighted in white. The current day is no longer highlighted.

w Press the center of the control

key.

u If appointments have already been

entered, this will open the list of saved appointments on that day. Select <New Entry> data input window.

u If no appointments have been entered,

the data input window will open immediately to add the new appointment.

¢ §OK§ to open the

¤ You can enter data in the following fields:

Activation:

Select On or Off.

Date:

Enter day/month/year in 8-digit format.

Time:

Enter hours/minutes in 4-digit format, then select AM/PM.

Tex t :

Enter text (max. of 16 characters). The text appears as the appointment name in the list and displays on the screen during the appointment reminder. If you do not enter any text, only the date and time of the appointment are displayed.

Signal:

Select the reminder type.

§Save§ Press the display key.

Please note

If you have already saved thirty appointments, you will have to first delete an existing appointment before adding a new one.

Signaling appointments and anniversaries

An appointment reminder is signaled in idle status for 60 seconds with the selected ringtone at the volume that has been set for internal calls ( reminder call, you can permanently change the volume by pressing the side keys ø (louder) or ÷ (quieter).

¢ page 55). During the

The name displays for anniversaries, while the entered text displays for appointments along with the date and time.

You can either deactivate or answer an appointment reminder:

§§Off§§ Press the display key to deacti-

vate the appointment reminder.

Please note

During a call, the appointment reminder is signaled by a short tone.

Managing appointments

v ¢Í ¢ Calendar

Editing individual appointments

r/q Select a day in the graphical cal-

endar and press the control key w. (Days on which appointments have already been saved are highlighted in white in the calendar).

q Select appointment for the day.

You have the following options:

§§View§§ Press the display key and edit or

confirm the entry.

§Options§ Open the menu for editing,

deleting and activating/deactivating.

Deleting all appointments for one day

§Options ¢Delete all Appoints. ¢ §OK§

Confirm the security prompt with §Yes§. All appointments are deleted.

Setting the alarm clock

Displaying missed appointments, anniversaries

Missed appointments/anniversaries

¢ page 34) are displayed in the Missed

( Alarms list if:

u You do not accept an appointment/anni-

versary.

u The appointment/anniversary was sig-

naled during a phone call.

u The handset is deactivated at the time of

the appointment/anniversary.

u Automatic redial was activated at the

time of an appointment/anniversary

¢ page 35).

(

The icon n and the number of new entries are shown in the display. The most recent entry is at the head of the list.

Open the list by pressing the message key

¢ page 37) or via the menu:

f( v ¢Í ¢ Missed Alarms

Select appointment/anniversary. Information about the appointment/anniversary displays. A missed appointment displays with the appointment name and a missed anniversary displays with the last name and first name. The date and time will also be given.

§Delete§ Delete appointment.

If 10 entries are already stored in the list, the next appointment reminder will delete the oldest entry.

Setting the alarm clock

Prerequisite: The date and time have

already been set (

Activating/deactivating and setting the alarm clock

v ¢á ¢ Alarm Clock

¤ You can enter data in the following fields:

Activation:

Select On or Off.

Time:

Enter the wake-up time in 4-digit format, then select AM/PM.

Occurrence:

Select Daily or Monday-Friday.

Volu me:

Set the volume (1–6). You can choose between five volumes (1–5; e.g., volume 3 = Š) and the "crescendo" ringtone (6; volume increases with each ring = ‡).

Melody:

Select melody.

§Save§ Press the display key.

In idle status, the ¼ icon and wake-up time are displayed.

A wake-up call is signaled on the display and with the selected ringtone ( wake-up call sounds for 60 seconds. If no key is pressed, the wake-up call is repeated twice at five minute intervals and then switched off.

While the wake-up call sounds, you can permanently change the volume by pressing the side keys ø (louder) or ÷ (quieter).

During a call, the wake-up call is only signaled by a short tone.

¢ page 15).

¢ page 3). The

Using multiple handsets

Deactivating the wake-up call/ repeating after a pause (snooze mode)

Prerequisite: A wake-up call is sounding.

§Off§ Press the display key. The wake-

up call is deactivated.

§Snooze§ Press the display key or any key.

The wake-up call is deactivated and then repeated after 5 minutes. After the second repetition the wake-up call is deactivated completely.

Using multiple handsets

Registering handsets

You can register up to six handsets to your base.

A Gigaset S79H handset can be registered on up to four bases.

Manually registering a Gigaset S79H to a Gigaset S790/ S795

You must activate manual registration of the handset on both the handset (1) and the base (2).

When the registration process has completed successfully, the handset returns to idle status. The handset's internal number is shown in the display e.g., INT 1. If not, repeat the procedure. .

1) On the handset

The handset is not registered to a base.

§Register§ Press the display key.

The handset is already registered to a base:

v ¢Ï ¢ Registration

¢ Register Handset

If the handset is already registered to four bases:

s Select base, e.g., Base 3 and

§OK§.

press

~ If required, enter the system

PIN for the base and press

A message appears stating that the handset is searching for a base that is ready for registration.

§OK§.

2) On the base

Within 60 seconds press and hold the registration/paging key on the base

¢ page 4) (approx. 3 seconds).

(

Registering other handsets

You can register other Gigaset handsets and handsets for other devices with GAP functionality as follows. .

1) On the handset

¤ Start to register the handset as

described in its user guide.

2) On the base

Press and hold the registration/paging key on the base (

¢ page 4) (approx. 3 sec.).

Using multiple handsets

De-registering handsets

You can de-register any other registered handset from any registered Gigaset S79H handset.

¢ De-reg. Handset

s Select the internal subscriber

~ Enter the current system PIN

§Yes§ Press the display key.

¢ Registration

you wish to de-register and

§OK§.

press (The handset you are currently using is highlighted with <).

and press

§Save§.

Locating a handset ("Paging")

You can locate your handset using the base.

¤ Briefly press the registration/paging key

on the base (

¢ page 4).

¤ All handsets will ring simultaneously

("paging"), even if the ringtones are deactivated.

Ending paging

¤ Briefly press the registration/paging key

on the base or press the talk key c on the handset.

Changing the base

If your handset is registered to more than one base, you can set it to a particular base or to the base that has the best reception (Best Base).

v s Select one of the registered

¢ Registration ¢Select Base

bases or Best Base and press

§Select§.

Making internal calls

Internal calls to other handsets registered on the same base are free.

Calling a specific handset

u Initiate internal call. ~ Enter the number of the hand-

set.

or:

u Initiate internal call. s Select handset. c Press the talk key.

Calling all handsets ("group call")

u Press and hold.

or:

u Initiate internal call. * Press the star key.

Call All Select c Press the talk key.

All handsets are called.

Ending a call

a Press the end call key.

Transferring a call to another handset

You can transfer an external call to another handset (connect).

u Open the list of handsets.

The external participant hears music on hold, if activated

¢ page 58).

(

s Select a handset or Call All and

§OK§.

press

When the internal participant answers:

¤ If necessary, announce the external call.

a Press the end call key.

The external call is transferred to the other handset.

Using multiple handsets

•

If the internal participant does not answer or the line is busy, press the display key return to the external call.

When transferring a call, you can also press the end call key a before the internal participant answers.

Then, if the internal participant does not answer or the line is busy, the call will automatically return to you.

§End§ to

Internal consultation/conference calls

When you are conducting an external call, you can call an internal participant at the same time for consultation or hold a conference call between all 3 participants.

You are conducting an external call: u Open the list of handsets.

The external participant hears music on hold, if activated

¢ page 58).

(

s Select handset and press §OK§.

The internal participant is called.

If the participant picks up, you can either:

§End§ Press the display key.

You are reconnected with the external participant.

or:

§Conference§ Press the display key.

All 3 participants are connected with each other.

Please note

u If only two handsets are registered,

the other handset is called immediately by pressing the u key.

u Pressing and holding the u key calls

all handsets immediately.

Ending a conference call

a Press the end call key.

If an internal participant presses the end call key a, the other handset remains connected to the external participant.

Accepting/rejecting call waiting

If you receive an external call during an internal call, you will hear the call waiting

tone (short tone). With Calling Line Identification, the caller's number or name will appear in the display.

Ending an internal call, accepting an external call

§Accept§ Press the display key.

The internal call is ended. You are connected to the external caller.

Rejecting the external call

§Reject§ Press the display key.

The call waiting tone is turned off. You remain connected to the internal participant. The ringtone can still be heard on other registered handsets.

Listening in to an external call

Prerequisite: The Listening In function must

be activated.

You are conducting an external call. An internal participant can listen in on this call and take part in the conversation. All the participants are made aware of additional listeners by a signal tone.

Activating/deactivating

listening in

v ¢Ï ¢ Tel e ph ony ¢Listening In

Press §Change§ to activate/deactivate the function (³ =on).

Internal listening in

The line is engaged with an external call. Your screen displays information to that effect. To listen in to the external call.

c Press and hold the talk key.

You can listen in to the call. All participants hear a signal tone. During this time, this handset displays the Conference message and it is not possible to dial another number from this handset.

Using a handset as a room monitor

Ending listening in

a Press the end call key.

All participants hear a signal tone.

If the first internal participant presses the end call key a, the handset that has "listened in" remains connected to the external participant.

Changing the name of a handset

The names "INT 1", "INT 2" etc. are assigned automatically on registration. You can change these names. The name must be no more than 10 characters. The changed name displays in every handset's list.

u Open the list of handsets. Your

own handset is indicated by

s Select handset.

§Options§ Open menu.

Rename

~ Enter name.

§Save§ Press the display key.

Changing a handset's internal number

A handset is automatically assigned the lowest free number when it is registered. If all slots are occupied, number 6 is overwritten if this handset is in idle status. You can change the internal number of all registered handsets (1–6).

u Open the list of handsets. Your

own handset is indicated by

§Options§ Open menu.

Assign Handset No.

Select and press

r Select number. Only numbers

that have not been assigned are displayed.

§Save§ Press the display key to save the

input.

§OK§.

Using a handset as a room monitor

If the room monitor is activated, a previously saved destination number is called as soon as a set noise level is reached. You can save an internal or external number in your handset as the destination number. All of the handset keys are deactivated, with the exception of the display keys.

The room monitor call to an external number is terminated after approximately 90 seconds. The room monitor call to an internal number (handset) is terminated after approximately 3 minutes (depending on the base). When the room monitor is activated, all keys are locked except the end call key. The handset's speaker is muted.

When the room monitor is activated, incoming calls to the handset are indicated with- out a ringtone and are only shown on the screen. The display and keypad are not illuminated and advisory tones are also turned off.

If you accept an incoming call, the room monitor is suspended for the duration of the call, but the function remains activated.

If you deactivate then reactivate the handset, the room monitor remains activated.

Using a handset as a room monitor

i Ã V

07:15 am

INT 1 Oct 22

Room Monitor

9725551234

Off Options

Warning!

u Always check the operation of the

room monitor before use. For example, test its sensitivity. Check the connection if you are diverting the room monitor to an external number.

u When the function is switched on, the

handset's operating time is considerably reduced. If necessary, place the handset in the base/charger. This ensures that the battery does not run down.

u Ideally the handset should be posi-

tioned 1 to 2 metres away from the baby. The microphone must be directed towards the baby.

u The connection to which the room

monitor is diverted must not be blocked by an activated answering machine.

Activating the room monitor and entering the destination number

v ¢ É ¢ Room Monitor

¤ You can enter data in the following fields:

Activation:

Select On to activate.

Alarm to:

Select Internal or External. External number: Select the number

from the directory (press display key or enter it manually.

Internal number: Select display key

§Change§ ¢. Select handset or Call All to

call all registered handsets In idle status, the destination number or

the internal destination number displays.

Sensitivity:

Select noise level sensitivity (Low or High).

¤ Press §Save§ to save the settings.

¢ §OK§.

ö)

When the room monitor function is activated, the idle display appears as shown below:

Changing the set destination number

v ¢ É ¢ Room Monitor

¤ Enter and save number as described in

"Activating the room monitor and entering the destination number"

¢ page 51).

(

Cancel/deactivate room monitor

Press the end call key a to cancel the call when the room monitor is activated.

In idle status, press the display key deactivate room monitor mode.

§Off§ to

Deactivating the room monitor remotely

Prerequisites: The phone must support tone

dialing and the room monitor should be set for an external destination number.

¤ Accept the call from the room monitor

and press keys 9 ;.

The room monitor function will deactivate after the call ends. There are no further room monitor calls. The other room monitor settings on the handset (e.g., no ringtone) will remain activated until you press the display

§Off§ on the handset.

key

To reactivate the room function with the same phone number:

¤ Turn on the activation again and save

§Save§ (¢page 51).

with

Handset settings

Your handset is preconfigured, but you can change the settings to suit your individual requirements.

Quick access to numbers and functions

You can assign a number from the directory to each of the digit keys Q and 2to O.

The left and right display keys have a default function. You can change the assignment

¢ page 52).

(

The number is then dialed or the function started by simply pressing a key.

Assigning digit keys

Prerequisite: You have not yet assigned a

number to the digit key.

¤ Press and hold the digit key

Press the digit key briefly and press the display key

The directory opens.

¤ Select an entry and press §OK§.

The entry is saved to the corresponding digit key.

Please note

If you delete or edit the entry in the directory at a later date, this will not affect the assignment to the number key.

§QuickDial§.

Selecting numbers/changing an assignment

Prerequisite: The digit key already has a

number assigned to it.

When the handset is in idle status

¤ Press and hold the digit key:

The number is dialed immediately.

¤ Briefly press the digit key.

Press the display key with the number/ name (abbreviated if necessary) to select the number or press the display key the assignment or to delete the assignment.

§Change§ to change

Changing display key assignments

¤ Press and hold the left or right side of the

display key.

The list of possible key assignments is opened. The following can be selected:

Room Monitor

Assign menu for setting and activating the room monitor to a key (

Alarm Clock

Assign menu for setting and activating the alarm clock to a key (

Calendar

Display graphical calendar (

Redial

Display the redial list.

More Functions...

More features are available:

Call Lists

Display call lists (

INT

Internal calls (

¢ page 48).

¢ page 50).

¢ page 46).

¢ page 44).

¢ page 36).

¤ Select an entry and press §OK§.

Handset settings

•

Changing the display language

You can view the display texts in different languages.

The current language is indicated by a Ø. s Select language and

If you accidentally choose a language you do not understand:

v ¢Ï ¢ s ¢ s ¢ s

s Select the correct language and

¢ Language

§Select§.

press

Press keys in sequence and confirm by selecting

press the right display key.

§OK§.

Setting the display

Setting the screensaver/slide show

When in idle state, a picture or a slide show (all the pictures are displayed one after the other) from the Screensaver folder of the Resource Directory ( time can be displayed as a screensaver. This will replace the idle state display.

The screensaver is not displayed in certain situations, e.g., during a call or if the handset is de-registered.

If a screensaver is activated, the Screensaver menu option is marked with μ.

¢ Display + Keypad

¢ page 56) or the

¢ Screensaver

The current setting displays.

¤ You can enter data in the following fields:

Activation:

Select On (screensaver displays) or Off (no screensaver).

Selection:

Select screensaver or

§View§ Press the display key. The active

screensaver displays.

s Select screensaver and press

§OK§.

§Save§ Press the display key.

Briefly press the end call key a to return to the idle display.

Please note

If the analogue clock has been set as the screensaver, the second hand is shown only when the handset is in the base.

Setting large font

You can increase the font size of print and symbols in call lists and in the directory to improve readability. Only one entry is shown at a time on the display instead of several entries and names are abbreviated if necessary.

¢ Large Font

§Change§ Press display key (³=on).

¢ Display + Keypad

Setting the colour scheme

You can set the display to be shown in various colour combinations.

¢ Color Schemes

Select Color Scheme (1 to 5) and press §OK§.

¢ Display + Keypad

Setting the display backlight

Depending on whether or not the handset is in the base/charger, you can activate or deactivate the backlight. If it is activated, the display is permanently dimmed. If the backlight is deactivated it is switched on by pressing any key. In this case the pressed key has no other function.

¢ Display Backlight

The current setting displays.

¢ Display + Keypad

¤ You can enter data in the following fields:

In Charger

Select On or Off.

Out of Charger

Handset settings

•

Select On or Off.

Please note

With the On setting, the standby time of the handset can be significantly reduced.

§Save§ Press the display key.

Setting keypad illumination

The brightness of the keypad illumination can be set to one of five levels.

¢ Keypad Illumination

The current setting is displayed.

¢ Display + Keypad

¤ You can enter data in the following fields:

Brightness:

Select 1 (darkest) to 5 (brightest).

§Save§ Press the display key.

Activating/deactivating auto answer

If you activate this function, when you receive a call you can simply lift the handset out of the base/charger without having to press the talk key c.

§Change§ Press display key (³=on).

Changing the speaker/ earpiece volume

You can set the speaker volume for speaker mode and the earpiece volume to five different levels.

During a conversation via the earpiece or in speaker mode:

ø/ ÷ Press the side key to call up the

¢ Te le ph on y ¢ Auto Answer

Handset Volume menu.

Change the volume by pressing

ø (louder) or ÷ (quieter).

t Press the control key to call up

the Handset Volume menu. Set the earpiece or speaker volume by pressing r.

The setting will automatically be saved after approximately 3 seconds, if not then press the display key

If t is assigned to another function:

§Options§ Open menu.

Volu me Select and press §OK§.

Configure setting (see above).

§Save§.

Please note

u The settings for the earpiece also

apply to a connected headset.

u You can also set the call volume using

the menu (

¢ page 26).

Setting a handsfree profile

In idle state, you can set various handsfree profiles to optimally adapt your phone to your environment.

Profile 1

The optimum setting for most connections and set as default.

Profile 2

Optimum volume in handsfree mode. However, this means that the par ticipants cannot speak at the same time as the person speaking is given preferential transmission (making two-way conversations difficult).

Profile 3

Optimises two-way conversations, both callers can hear each other, even if they talk at the same time.

Profile 4

Optimised for special connections. If the default setting (profile 1) does not provide optimum sound, please give this a try.

¢ Audio Settings

¢ Handsfree Profiles

Select handsfree profile (1 to 4) and press

§Select§.

Handset settings

•

Changing ringtones

u Volume:

You can choose between five volumes (1– 5; e.g., volume 3 = Š) and the "crescendo" ringtone (6; volume increases with each ring = ‡).

u Ringtones:

You can select a ringtone from a list of pre-loaded melodies.

You can select various ringtones, melodies or any sound from the Resource Directory (

You can set different ringtones for the following functions:

u Intrnl Calls u Ext. Calls

Setting volume/melodies

In idle status:

v ¢Ï ¢ Audio Settings

¢ Ringtones(Handset) ¢ Volume/

Melodies

r Setting volume/melodies for

s Scroll to the next line. r Setting volumes/melodies for

§Save§ Press the display key to save the

While the phone is ringing, you can permanently change the volume by pressing the side keys ø (louder) or ÷ (quieter).

Additionally for external calls:

You can specify a time period when you do not want the telephone to ring, e.g., during the night.

¢ Ringtones(Handset) ¢ Time Control

Time Control:

Select On or Off.

¢ page 56).

internal calls and anniversaries.

external calls.

setting.

¢ Audio Settings

If the time control is activated:

Suspend ring from:

Enter the start of the period in 4-digit format.

Suspend ring until:

Enter the end of the period in 4-digit format.

Please note

During this period, you will continue to receive calls from numbers to which you have assigned a personalized melody in the directory (VIP).

Activating/deactivating the ringtone for unknown calls.

You can set your phone not to ring for calls where Calling Line Identification has been withheld. The call will only be signaled on the display.

In idle status:

¢ Ringtones(Handset) ¢Anon. Calls

Silent

Press function (³= on).

¢ Audio Settings

§Change§ to activate or deactivate the

Activating/deactivating the ringtone

You can deactivate the ringtone on your handset before you answer a call or when the handset is in idle status; the ringtone can be deactivated permanently or just for the current call. The ringtone cannot be re-activated while an external call is in progress.

Deactivating the ringtone permanently

* Press and hold the star key.

The ó icon appears in the display.

Reactivating the ringtone

* Press and hold the star key.

Handset settings

Deactivating the ringtone for the current call

§Silence§ Press the display key.

Activating/deactivating the alert tone

In place of the ringtone, you can activate an alert tone. When you receive a call, you will hear a short tone ("Beep") instead of the ringtone.

* Press and hold the star key and

within 3 seconds:

§Beep§ Press the display key. A call will

now be signaled by one short alert tone.

appears in the display.

Resource Directory

The resource directory on the handset manages sounds, which you can use as ringtones, and pictures, which you can use as caller pictures or as screensavers. Prerequi- site: Caller ID service subscription (CID). The resource directory can manage the following media types:

Typ e Fo rmat

Sound

Ringtones Internal

Monophonic Internal

Polyphonic Internal

Imported sounds WMA, MP3, WAV

Picture – Caller picture – Screensaver

Various mono and polyphonic sounds and pictures are preconfigured on your handset.

You can listen to the available sounds and view the pictures.

You can download pictures and sounds from

¢ page 63). If there is not enough

a PC ( memory available, you must first delete one or more pictures or sounds.

BMP, JPG, GIF 128 x 86 pixels 128 x 160 pixels

Playing back sounds/viewing caller pictures

v ¢ · ¢ Screensavers / Caller

Pictures / Sounds (select entry)

Pictures:

§View§ Press the display key. The

selected picture displays. Switch between pictures using the q key.

If you have saved a picture in an invalid file format, you will see an error message after selecting the entry.

Sounds:

The selected sound is played back immediately. Switch between the sounds using the q key.

You can set the volume during playback.

§Options§ Open menu.

Volu me Select and press §OK§.

r Set volume.

§Save§ Press the display key.

Deleting/renaming a picture/ sound

You have selected an entry.

§Options§ Open menu.

If a picture/sound cannot be deleted (¯), these options are not available. You can select the following functions:

Delete Entry

The selected entry is deleted.

Rename

Change the name (max. 16 characters) and press the new name.

§Save§. The entry is stored with

Checking the memory

You can check how much memory is available for screensavers and caller pictures.

¢ · ¢ Capacity

Handset settings

•

Area Codes

International code:

011- 1

Local access code:

1-972

Save

•

advisory tones

Your handset uses advisory tones to tell you about different activities and statuses. The following advisory tones can be activated/ deactivated independently of each other:

u Key tone: every key press is confirmed. u Acknowledge tones:

– Confirmation tone (ascending tone

– Error tone (descending tone

– Menu end tone: when scrolling to the

u Battery low beep: the battery needs

charging.

In idle status:

¢ Advisory Tones

¤ You can enter data in the following fields:

Key Tones:

Select On or Off.

Confirmation:

Select On or Off.

Battery:

Select On or Off.

§Save§ Press the display key.

area codes

To transfer phone numbers via USB phone from your outlook (e.g., in vCards), it is essential that your area code (international and local area code) is saved on the phone.

Some of these numbers are already preset.

Check that the preset area code is correct.

¤ You can enter data in the following fields:

q Select/change input field.

Activating/deactivating

sequence): at the end of an entry/setting and when a new entry arrives in the answering machine list or call list

sequence): when you make an incorrect entry

end of a menu

¢ Audio Settings

Setting long-distance and

¢ Te le ph on y ¢ Area Codes

r Navigate to the input field.

Ñ If necessary, delete number:

press the display key.

~ Enter number.

§Save§ Press the display key.

Example:

Note:

If a long distance number is recorded in a vCard without the national access code "1" ( i. e., 312 -555-1212 instead of 1-312-555-

1212), please add the "1" in front of the telephone number before transferring the number to the S79H handset via USB.

Restoring the handset

default settings

You can reset individual settings and changes that you have made.

When you perform a reset, the settings listed below are automatically retained.

u Registration to the base u Date and time u Entries in the calendar u Entries in the directory, the call lists and

the content of the resource directory

§Yes§ Press the display key.

¢ System ¢ Handset Reset

Setting the base

•

Setting the base

The base settings are changed using a registered Gigaset S79H handset.

Changing the Gigaset S795 base ringtones

u Volume:

You can choose between five volumes (1– 5; e.g., volume 3 = Š) and the "crescendo" ringtone (6; volume increases with each ring = ‡).

u Ringtones:

You can select a ringtone from a list of pre-loaded melodies.

In idle status:

¢ Ringtones (Base)

¤ You can enter data in the following fields:

r Set volume. s Scroll to the next line. r Set melody.

§Save§ Press the display key to save the

music on hold

¢ Audio Settings

setting.

Activating/deactivating

Changing the system PIN

You can change the 4-digit system PIN set on the base (default setting: 0000) to a 4-digit PIN known only by you.

Gigaset S795: Setting a system PIN facilitates remote operation of the answering machine

¢ page 42).

(

v ¢Ï ¢ System ¢ System PIN ~ Enter the current system PIN

and press

~ Enter your new system PIN and

press

§OK§.

Resetting the system PIN

If you have forgotten your system PIN, you can reset the base to the original code 0000:

1. Disconnect the power cable from the base.

2. Hold down the registration/paging key on the base while reconnecting the power cable to the base.

3. Hold down the key for at least 5 seconds.

4. The base has now been reset and the system PIN set to 0000.

Please note

All handsets are de-registered and must be re-registered. All settings are reset to the factory settings.

v ¢Ï ¢ Audio Settings

¢ Music on Hold

Press §Change§ to activate or deactivate the music on hold (³ = on).

Protecting against unauthorized access

Protect the system settings of the base with a PIN known only to yourself. The system PIN must be entered when, for example, registering/de-registering a handset to/from the base or when restoring the default settings.

Resetting the base to the

factory settings

When the settings are restored:

u Date and time are retained u Handsets are still registered u Eco Mode is activated deactivated, u The system PIN is not reset.

v ¢Ï ¢ System ¢ Base Reset ~ Enter the system PIN and

§OK§.

press

§Yes§ Press the display key.

Connecting the base to the PABX

•

Connecting the base to the PABX

The following settings are only necessary if your PABX requires them; see the PABX user guide.

Dialing modes and recall

The current setting is indicated by Ø.

Changing the dialing mode

The following dialing modes can be selected:

u Ton e d i aling (DT MF) u Pulse dialing (PD).

v ¢Ï ¢ Te le ph on y ¢ Dialing Mode s Select dialing mode and press

§Select§ (Ø = selected).

Setting recall

Your phone is preset at the factory for operation on the main connection. For operation on a PABX, you may have to change this value. Please refer to the user guide for your PA BX .

v s Select recall and

¢ Te le ph on y ¢ Flash

§Select§

press

Ø = set value). Possible values

( are: 80 ms, 100 ms, 120 ms, 180 ms, 250 ms, 300 ms, 400 ms, 600 ms, 800 ms.

Setting pauses

Changing the pause after line seizure

You can change the length of the pause that is inserted between pressing the talk key c and sending the number.

v Open the main menu. *#Q5#L

Press keys.

~ Enter number for the length of

the pause (1 = 1 sec.; 2 = 3 secs.; 3 = 7 secs.) and press

§OK§.

Change pause after recall key

You can change the length of the pause if your PABX requires this (refer to the user guide for your PABX).

v Open the main menu. *#Q5#2

Press keys.

~ Enter a number for the length of

the pause (1 =800ms; 2 =1600ms; 3 = 3200 ms) and

§OK§.

press

Switching temporarily to tone dialing (DTMF)

If your PABX still operates with pulse dialing (PD), but you need tone dialing for a connection (e.g., to listen to the network mailbox), you must switch to tone dialing for the call.

Prerequisite: You are conducting a call or have already dialed an external number.

* Press the star key.

After the call ends, pulse dialing is automatically activated again.

Troubleshooting

If you have any questions about the use of your telephone, you can contact us at any time at www.gigaset.com/customercare

The table below contains a list of common problems and possible solutions.

The display is blank.

1. The handset is not switched on.

¥ Press and hold the end call key a.

2. The battery is empty.

¥ Charge the battery or replace it

(

¢page 12).

Not all menu items are displayed.

The menu display is restricted (standard mode).

¥ Activate extended menu display (expert

mode

No Base flashes on the display.

1. The handset is outside the range of the base.

) (¢page 26).

•

¥ Move the handset closer to the base.

2. The base's range is reduced because Eco Mode is activated.

¥ Deactivate Eco Mode (¢ page 44) or

reduce the distance between the handset and the base.

3. The base is not switched on.

¥ Check the base power adapter

(

¢page 10).

Please registerhandset flashes on the display.

Handset has not been registered with the base or has been deregistered.

¥ Register the handset (¢page 47).

Handset does not ring.

1. The ringtone is deactivated.

¥ Activate the ringtone (¢page 55).

2. The phone only rings if the phone number has been transferred.

¥ Switch on the ringtone for unknown calls

(

¢page 55).

You cannot hear a ringtone/dialing tone from the fixed line network.

The phone cord supplied has not been used or has been replaced by a new cord with the wrong pin connections.

¥ Please always use the phone cord supplied or

ensure that the pin connections are correct when purchasing from a retailer (

¢page 10).

Error tone sounds after system PIN prompt.

You have entered the wrong system PIN.

¥ Reset the system PIN to 0000 (¢page 58).

Forgotten the system PIN.

¥ Reset the system PIN to 0000 (¢page 58).

The other party cannot hear you. You have pressed the mute button h. The

handset is "muted".

¥ Reactivate the microphone (¢ page 31).

The number of the caller is not displayed despite CID.

Calling Line Identification is not enabled (CID).

¥ The caller should ask the network provider to

enable Calling Line Identification (CID).

You hear an error tone when keying an input (a descending tone sequence).

Action has failed/invalid input.

¥ Repeat the operation.

Watch the display and refer to the user guide if necessary.

You cannot listen to messages on the network mailbox.

Your PABX is set for pulse dialing.

¥ Set your PABX to tone dialing.

Appendix

Gigaset S795 only:

No time is specified for a message in the call list.

Date and time have not been set.

¥ Set the date and time (¢ page 15).

The answering machine announces "PIN is incorrect" during remote operation.

1. You have entered the wrong system PIN.

¥ Enter the system PIN again.

2. The system PIN is still set to 0000.

¥ Set the system PIN to something other

than 0000 (

The answering machine is not recording any messages/has switched over to answer only.

Its memory is full.

¢page 58).

¥ Delete old messages. ¥ Play back new messages and delete.

Exclusion of liability

Some displays may contain pixels (picture elements), which remain activated or deactivated. As a pixel is made up of three sub-pixels (red, green, blue), it is possible that pixel colours may vary.

This is completely normal and does not indicate an error.

Appendix

Caring for your telephone

¤ Wipe the device with a damp cloth or an

antistatic cloth. Do not use solvent or a

microfiber cloth.

¤ Impairments in the high-gloss finish can

be carefully removed using display polishes for mobile phones.

Never use a dry cloth as this can cause static.

Contact with liquid

If the device comes into contact with liquid:

1. Unplug the power supply and/or re-

move the battery from the handset immediately.

2. Allow the liquid to drain from the device.

3. Pat all parts dry. Place the device (handset with the battery compartment open and the keypad facing down) in a dry, warm place for at least 72 hours (not in a microwave, oven etc.).

4. Do not switch on the device again until

it is completely dry.

When it has fully dried out, you will normally be able to use it again.

Appendix

1unused 2unused 3a 4b 5unused 6unused

3 2 1

4 5 6

Specifications

Batteries

Technology:

Nickel-metal-hydride (NiMH)

Size: AAA (Micro, HR03) Voltage: 1.2 V

Capacity: 550 - 1000 mAh

The handset is supplied with nickel-metal hydride UL-approved AAA batteries.

Handset operating times/charging times

This telephone can charge batteries up to a capacity of 1000 mAh. The use of special high-performance batteries or batteries with high capacities is not recommended for cordless phones.

The operating time of your telephone depends on the capacity and age of the batteries and the way they are used. (All times are maximum possible times).

Capacity (mAh) approx.

550 700 800 1000

Standby time (hours)*

Talktime (hours) 11121417

Operating time for

1.5 hrs of calls per day (hours)**

Charging time in base (hours)

Charging time in charger (hours)

* without/with display backlight ** without display backlight (Setting the display backlight

140/ 50165/ 58185/ 67230/

85 95 110 135

7.5 8.5 10 12

6.5 7.5 8.5 10.5

¢page 53)

Base power consumption

In standby mode: Gigaset S790: approx. 1.1 watt Gigaset S795: approx. 1.2 watt

During the conversation: Gigaset S790: approx. 1.0 watt Gigaset S795: approx. 1.1 watt

General specifications

DECT standard Is supported

GAP standard Is supported

No. of channels 60 duplex channels

Radio frequency range 1880–1900 MHz

Duplex method Time multiplex,

Channel grid 1728 kHz

Bit rate 1152 kbit/s

Modulation GFSK

Language code 32 kbit/s

Transmission power 10 mW, average power

Range Up to 984 feet outdoors,

Base power supply 120 V ~/60 Hz

Environmental conditions in operation

Dialing mode DTMF (tone dialing)/

10 ms frame length

per channel

up to 165 feet indoors

+41°F to +113°F, 20% to 75% relative humidity

PD (pulse dialing)

Pin connections on the telephone jack

Due to the constant progression in battery development, the list of recommended batteries in the FAQ section of the Gigaset Customer Care pages is regularly updated.

Additional functions via the PC interface

Writing and editing text

The following rules apply when writing text:

u Each key between Q and O is

assigned several letters and characters.

u Control the cursor with uvts.

Press and hold u or v to move the cur- sor word by word.

u Characters are inserted at the cursor posi-

tion.

u Press the star key

table of special characters. Select the required character and press the display

§Insert§ to insert the character at the

key cursor position.

u Press and hold Q to O to enter dig-

its.

u Press display key Ñ to delete the char-

acter to the left of the cursor. Press and hold to delete the word to the left of the

cursor.

u The first letter of the name of directory

entries is automatically capitalised, followed by lower case letters.

Setting upper/lower case or digits

Repeatedly press the pound key # to change the text input mode.

123 Writing digits

Abc Upper case *

abc Lower case

* First letter in capitals, all others in lower case

The active mode is indicated at the bottom right of the screen.

to display the

¤ Briefly press the key several times in suc-

cession to select the required letter/character.

Standard characters

1x 2x 3x 4x 5x 6x 7x 8x 9x 10x



2 3 4 5 L M N O Q

1) Space

2) Line break

abc2дбавгз def3лйик gh i4ïíìî

jkl5

mno6цсутфх

pqr s 7ß

tuv 8üúùû

wx y z 9 яэжше

.,?!0

Additional functions via the PC interface

To enable your handset to communicate with the PC, the "Gigaset QuickSync" program must be installed on your PC (free to download at www.gigaset.com/gigasets790

After installing "Gigaset QuickSync", c o nnect the handset to your computer using a USB data cable (

¢ page 18).

Please note

Please connect your handset directly to the PC; do not connect via a USB hub.

Writing names

¤ Enter the individual letters/characters by

pressing the corresponding key.

The characters assigned to the key are shown in a selection line at the bottom left of the screen. The selected character is highlighted.

Transferring data

Start the "Gigaset QuickSync" program. You can now:

u Synchronise your handset directory with

Outlook. (period)

u Download caller pictures (.bmp, .jpg, .gif)

from the computer to the handset. (period)

Additional functions via the PC interface

u Download pictures (.bmp, .jpg, .gif) as a

screensaver from the computer to the handset.

u Download sounds (ringtones) from the

computer to the handset.

During the transfer of data between handset and PC, you will see Data transferin progress on the display. During this time the keypad is disabled, and incoming calls will be ignored.

Completing a firmware update

¤ Connect you phone to your PC using a

USB data cable (

¢ page 18).

¤ Start the "Gigaset QuickSync" program

on your PC.

¤ Establish a connection to your handset. ¤ Select [Settings] ¢[Device proper-

ties]to open the [Device properties] tab.

¤ Click on [Firmware update].

This launches the firmware update.

The update process can take up to 10 minutes (not including the download time). Do

not interrupt the process or remove the USB data cable.

The data is initially loaded from the update server on the Internet. The amount of time required depends on the speed of your Internet connection.

The display on your phone is switched off and the message key f and the talk key c start flashing.

When the update is complete, your phone will automatically restart.

Procedure in case of an error

If the update procedure fails or your phone does not work properly following the update, repeat the update procedure as follows:

¤ Close the "Gigaset QuickSync" program

on the PC.

¤ Remove the USB data cable from the tel-

ephone.

¤ Remove the battery (¢page 12).

¤ Replace the battery. ¤ Complete the firmware update as

described.

If the update procedure fails several times or you can no longer connect to the PC, proceed as follows (emergency update):

¤ Close the "Gigaset QuickSync" program

on the PC.

¤ Remove the USB data cable from the tel-

ephone.

¤ Remove the battery (¢ page 12). ¤ Press and hold keys 4 and L with

the index and middle finger.

¤ Replace the battery. ¤ Release keys 4 and L. The message

key f and the talk key c will flash alternately.

¤ Complete the firmware update as

described.

Please note

Personal pictures and sounds that you have loaded to your handset should always be saved on your PC as they will be deleted during an emergency

update.

FCC / ACTA Information

Industry Canada Certification

Operation is subject to the following two conditions (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

NOTICE: The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network, protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.

Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas

NOTE: Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate. This product meets the applicable Industry Canada technical specifications.

The Ringer Equivalence Number is an indication of the maximum number of devices allowed to be connected to a telephone interface. The termination of an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all devices does not exceed five.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

FCC / ACTA Information

Warning: Changes or modifications to this unit

not expressly approved by Gigaset Communications USA LLC could void the FCC authority to operate the equipment. This includes the addition of any external antenna device. This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the bottom of the base station is a label that contains, among other information, a product identifier in the format US:AAAEQ##TXXXX. If requested, this number must be provided to the telephone company.

A p lu g an d j ack us ed to c on nec t t hi s eq ui pme nt to the premises wiring and telephone network must comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. See installation instructions for details.

The REN is used to determine the number of devices that may be connected to a telephone line. Excessive RENs on a telephone line may result in the devices not ringing in response to an incoming call. In most but not all areas, the sum of RENs should not exceed five (5.0). To be cer tain of the number of devices that may be connected to a line, as determined by the total RENs, contact the local telephone company. For products approved after July 23, 2001, the REN for this product is part of the product identifier that has the format US:AAAEQ##TXXXX. The digits represented by ## are the REN without a decimal point (e.g., 03 is a REN of 0.3). For earlier products, the REN is separately shown on the label. A copy of the supplier's Declaration of Conformity (SDoC) is available at this Internet address: www.gigaset.com/docs.

If this equipment causes harm to the telephone network, the telephone company will notify you advance, that temporary discontinuance of service may be required. But if advance notice isn’t practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary.

The telephone company may make changes in its facilities, equipment, operations or procedures that could affect the operation of the equipment. If this happens the telephone company will provide advance notice in order for you to make necessary modifications to maintain uninterrupted service. If you experience trouble with this telephone system, disconnect it from the network

FCC / ACTA Information

until the problem has been corrected or until you are sure that the equipment is not malfunctioning.

If trouble is experienced with this equipment, for repair or warranty information, please contact Support at 1-866 247-8758. If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved. This equipment is of a type that is not intended to be repaired by the Customer (user).

This telephone system may not be used on coin service provided by the telephone company. Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service commission or corporation commission for information. Privacy of communications may not be ensured when using this phone. If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this equipment does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualified installer.

This telephone system equipment has been tested and found to comply with the limits for Class B digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. These limits are designed to provide reasonable protection against harmful interference in a residential installation. Some cordless telephones operate at frequencies that may cause interference to nearby T V’s and VCR’s; to minimize or prevent such interference, the system base should not be placed near or on top of a TV or VCR; and, if interference is experienced, moving the base farther away from the TV or VCR will often reduce or eliminate the interference.

However, there is no guarantee that interference will not occur in a particular installation. If this telephone system does cause harmful interference to radio or television reception, which can be determined by turning the system off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the base station and receiver.

3. Connect the base station into an outlet on a circuit different from that to which the receiver is connected.

4. Consult the dealer or an experienced radio TV technician for help.

Notice for Direct Inward Dialing ("DID")

ALLOWING THIS EQUIPMENT TO BE OPERATED IN SUCH A MANNER AS TO NOT PROVIDE FOR PROPER ANSWER SUPERVISION IS A VIOLATION OF PART 68 OF THE FCC‘S RULES.

Notice to Hearing Aid Wearers:

This phone system is compatible with inductively coupled hearing aids.

Power Outage:

In the event of a power outage, your cordless telephone will not operate. The cordless telephone requires electricity for operation. You should have a telephone that does not require electricity available for use during power outages.

Notice:

The installation of the base unit should allow at least 8 inches between the base and persons to be in compliance with FCC RF exposure guidelines.

For body worn operation, the portable part (handset) has been tested and meets FCC RF exposure guidelines. Use with an accessory that contains metal parts may not ensure compliance with FCC RF exposure guidelines.

Notice to telephone company service: If you need service from your telephone company, please provide them with the information – Facility interface Code (FIC)

– Service Order Code (SOC) – Universal Service Order Code (USOC) as indicated on the label on the bottom side of the

base station.

Safety precautions

Before using your telephone equipment, basic safety instructions should always be followed to reduce the risk of fire, electric shock and injury to persons.

1. Read and understand all instructions.

2. Follow all warnings and instruc tions ma rked on the product.

3. Unplug this product from the wall telephone jack and power outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use damp cloth for cleaning.

4. Do not use this product near water, for example, near a bathtub, wash bowl, kitchen sink, or laundry tub, in a wet basement or near a swimming pool.

FCC / ACTA Information

5. Place this product securely on a stable surface. Serious damage and/or injury may result if the unit falls.

6. Slots or openings in the cabinet and the back and bottom are provided for ventilation, to protect it from overheating. These openings must not be blocked or covered. This product should never be placed near or over a radiator or heat register, or in a place where proper ventilation is not provided.

7. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of AC line power to your home, consult your dealer or local power company.

8. Do not place objects on the power cord. Install the unit where no one can step or trip on the cord.

9. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock.

10. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out parts that could result in the risk of fire or electric shock. Never spill liquid of any kind on this product.

11. To reduce the risk of electric shock or burns, do not disassemble this product. Take it to a qualified service center when service is required. Opening or removing covers may expose you to dangerous voltages, dangerous electrical current or other risks. Incorrect reassembly can cause electric shock when the appliance is subsequently used.

12. Unplug the product from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a.) When the power cord is damaged or frayed. b.) If liquid has been spilled into the product. c.) If the product has been exposed to rain or water. d.) If the product does not operate normally by follow

ing the operating instructions. Adjust only those controls instructions because improper adjustment of other controls may result in damage and may require extensive work by a qualified technician to restore the product to normal operation. e.) If the product has been dropped or physically has been damaged. f.) If the product exhibits a distinct change in performance.

13. Avoid using a telephone (other than a cordless type) during a thunderstorm. There may be a remote risk of electrical shock from lightning. Therefore we suggest a surge arrestor.

14. Do not use the telephone to report a gas leak in the vicinity of the leak.

that are covered by the operating

15. Emergency/911 numbers may not be dialed if the keypad is locked.

16. Minimum No. 26 AWG telecommunication line cord must be used with this phone.

BATTERY SAFETY PRECAUTIONS

To reduce the risk of fire, injury or electric shock, and to properly dispose of batteries, please read and understand the following instructions. CONTAINS NICKEL METAL HYDRIDE BATTERY. BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY. DO NOT DISPOSE OF IN MUNICIPAL WASTE.

1. Only use the batteries specified for use with this product.

2. DO NOT USE NICKEL CADMIUM OR LITHIUM BATTERIES, or mix batteries ofdifferent sizes or from different manufacturers in this product. DO NOT USE NONRECHARGEABLE BATTERIES.

3. Do not dispose of the batteries in a fire; the cells may explode. Do not expose batteries to water. Check with local codes for special disposal instructions.

4. Do not open or mutilate the batteries. Released electrolyte is corrosive and may cause damage to the eyes or skin. The electrolyte may be toxic if swallowed.

5. Exercise care in handling the batteries in order not to short the batteries with conducting materials such as rings, bracelets, and keys. The batteries or conducting material may overheat and cause burns or fire.

6. Charge the batteries provided with, or identified for use with, this product only in accordance with the instructions and limitations specified in the user’s manual. Do not attempt to charge the batteries with any means other than that specified in the users manual.

7. Periodically clean the charge contacts on both the charger and handset.

FCC / ACTA Information

Customer Care Warranty for Cordless Products

product operation information, or for problem resolution, call:

Service (Customer Care)

To obtain Customer Care Warranty service,

Toll Free:

1-866 247-8758

End-user limited warranty

This product is covered by a one year limited warranty. Any repair replacement or warranty ser vice, and all questions about this product should be directed to: 1-866 247-8758.

This limited, non-transferable warranty is provided to the original buyer/end-consumer ("you") for systems, handsets and accessories (collectively, "Product") provided by Gigaset Communications USA LLC or Gigaset Communications Canada Inc. (collectively "Gigaset NAM"). Gigaset NAM warrants to you that at the date of purchase, the Product is free of defects in workmanship and materials and the software included in the Product will perform in substantial compliance to its program specifications.

1. WARRANTY PERIOD

The Product warranty period is one (1) year from the original date of purchase by you. Proof of purchase (e.g., sales slip or invoice) must be provided with any Product returned during the warranty period. Batteries supplied with the Products are warranted to be free from defects at the time of purchase only.

2. EXCLUSIVE REMEDY

Gigaset NAM's entire liability and your exclusive remedy if the Product is defective in materials or workmanship during the warranty period and is returned shall be that the Product will be repaired or replaced as set forth in Section 4 below. Reconditioned replacement components, parts or materials may be used in the replacement or repair. Data in the memory of the Product may be lost during repair.

3. THIS LIMITED WARRANTY DOES NOT

COVER AND IS VOID WITH RESPECT TO THE FOLLOWING:

– Cosmetic damage, physical damage to the sur-

face of the Product, including, without limitation, breakage, cracks, dents, scratches or adhesive marks on the LCD screen or outside casing of the Product.

– Products which have been repaired, main-

tained or modified (including the antenna) by anyone other than Gigaset NAM or a Gigaset NAM-approved repair facility, or that have

been improperly installed. – Cost of installation, removal or reinstallation. – Damage due to any telephone, electronic,

hardware or software program, network, Inter-

net or computer malfunctions, failures, or diffi-

culties of any kind, including without limita-

tion, server failure or incomplete, incorrect,

garbled or delayed computer transmissions. – Equipment and components not manufac-

tured, supplied or authorized by Gigaset NAM. – Modification of the Product's components, or

operation of the Product in an unsuitable envi-

ronment or in a manner for which it is not

intended, including but not limited to failures

or defects caused by misuse, abuse, accidents,

physical damage, abnormal operation,

improper handling or storage, neglect, altera-

tions, unauthorized installation, removal or

repairs, failure to follow instructions, problems

caused by the carrier's network coverage,

exposure to fire, water or excessive moisture or

dampness, floods, or extreme changes in cli-

mate or temperature, acts of Go d, riots, acts of

terrorism, spills of food or liquids, viruses or

other software flaws introduced into the Prod-

uct or other acts which are not the fault of

Gigaset NAM and which the Product is not

specified to tolerate, including damage caused

by mishandling or blown fuses. – Products which have had warranty stickers,

electronic serial number and/or serial number

label removed, altered, rendered illegible or

fraudulently applied to other equipment. – Signal reception problems (unless caused by

defect in material or workmanship in the Prod-

uct). – Products operated outside published maxi-

mum ratings. – Performance of the Products when used in

combination with other products or equip-

ment not manufactured, supplied or author-

ized by Gigaset NAM. – Consumables (such as batteries and fuses).

FCC / ACTA Information

– Payments for labor or service to representa-

tives or service centers not authorized to per-

form product maintenance by Gigaset NAM. – Loss of data. – Testing and examination discloses that the

alleged defect or malfunction in the Product

does not exist. This warranty does not cover customer education, instruction, installation or removal, set up adjustments, problems related to service(s) provided by a carrier or other service provider, and/or signal reception problems. Gigaset NAM shall not be responsible for software, firmware, information, or memory data contained in, stored on, or integrated with any Products returned for repair, whether under warranty or not. This warranty is valid only in the country in which it is purchased (i.e., the United States of America or Canada respectively, but not both).

USE WITH ACCESSORIES NOT SUPPLIED BY GIGASET NAM OR NOT OTHERWISE EXPRESSLY AUTHORIZED BY GIGASET NAM MAY VOID WAR RAN TY.

4. WARRANTY CLAIM PROCEDURE

All warranty claims must be made by notifying Gigaset NAM prior to the expiration of the warranty period. Gigaset NAM's obligation to provide warranty support shall not extend past the end of the warranty period, except that any product repaired or replaced during the warranty period shall continue to be warranted for the balance of such warranty period or thirty (30) days, whichever is greater.

Support service will be provided for you by accessing the toll free customer service number:

1-866 247-8758

5. LIMITATION OF WARRANTY

Gigaset NAM makes no warranty or representation that the software in the Products will meet your requirements or will work in combination with any hardware or applications software products provided by third parties, that the operation of the software will be uninterrupted or error free, or that all defects in the software products will be corrected.

6. LIMITATION ON REMEDIES; NO

CONSEQUENTIAL OR OTHER DAMAGES

Your exclusive remedy for any breach of this limited warranty is as set forth above. Except for any refund elected by Gigaset NAM, YOU ARE NOT

ENTITLED TO ANY DAMAGES, INCLUDING BUT NOT LIMITED TO CONSEQUENTIAL DAMAGES,

if the Product does not meet the limited warranty , and, to the maximum extent allowed by applicable law, even if any remedy fails of its essential purpose. The terms below ("Exclusion of Incidental, Consequential and Certain Other Damages") are also incorporated into this limited warranty . Some states/jurisdictions/provinces do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This limited warranty gives you specific legal rights. You may have others which vary from state/jurisdiction/province to state/jurisdiction/province.

7. DISCLAIMER OF WARRANTIES

GIGASET NAM AND ITS SUPPLIERS PROVIDE THE PRODUCT AND SUPPORT SERVICES (IF ANY) AS IS AND WITH ALL FAULTS. THE LIMITED WARRANTY IS IN LIEU OF ANY OTHER EXPRESS WARRANTIES (IF ANY) CREATED BY ANY DOCUMENTATION OR PACKAGING EXCEPT FOR THE LIMITED WARRANTY, AND TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW IS IN LIEU OF ANY IMPLIED OR STATUTORY WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, OF ACCURACY OR COMPLETENESS OR RESPONSES, OF RESULTS, OF WORKMANLIKE EFFORT, OF LACK OF VIRUSES AND OF LACK OF NEGLIGENCE, ALL WITH REGARD TO THE PRODUCT, AND THE PROVISION OF OR FAILURE TO PROVIDE SUPPORT SERVICES. ALSO, THERE IS NO WARRANTY OR CONDITION OF TITLE, QUIET ENJOYMENT, QUIET POSSESSION, OR CORRESPONDENCE TO DESCRIPTION OR NONINFRINGEMENT WITH REGARD TO THE PRODUCT. Some states/jurisdictions/provinces do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above exclusions or limitations may not apply to you. If an implied warranty or condition is created by your state/ province and federal or state/provincial law prohibits disclaimer of it, you also have an implied warranty or condition, BUT ONLY AS TO DEFECTS DISCOVERED DURING THE PERIOD OF THIS LIMITED WARRANTY (ONE YEAR). AS TO ANY DEFEC TS DISCOVERED AFTER THE ONE YEAR PERIOD, THERE IS NO WARRANTY OR CONDITION OF ANY KIND. This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state/province to province. In no event shall Gigaset NAM's liability exceed the cost of repairing or replacing defective Products as provided herein, and any such liabilities will terminate upon expiration of the warranty period.

FCC / ACTA Information

Any supplements or updates to the Product or the software in the Product, including without limitatio n, an y (if any ) sof twar e fixe s or u pgrad es or bug fixes provided to you after the expiration of the one year limited warranty period are not covered by any warranty or condition, express, implied or statutory.

8. EXCLUSION OF INCIDENTAL,

CONSEQUENTIAL AND CERTAIN OTHER DAMAGES

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL GIGASET NAM, SELLER OR THEIR SUPPLIERS BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING, BUT NOT LIMITED TO, DAMAGES FOR LOSS OF PROFITS OR CONFIDENTIAL OR OTHER INFORMATION, FOR BUSINESS INTERRUPTION, FOR PERSONAL INJURY, FOR LOSS OF PRIVACY, FOR FAILURE TO MEET ANY DUTY INCLUDING OF GOOD FAITH OR OF REASONABLE CARE, FOR NEGLIGENCE, AND FOR ANY OTHER PECUNIARY OR OTHER LOSS WHATSOEVER) ARISING OUT OF OR IN ANY WAY RELATED TO THE USE OF OR INABILITY TO USE THE PRODUCT, THE PROVISION OF OR FAILURE TO PROVIDE SUPPORT SERVICES, OR OTHERWISE UNDER OR IN CONNECTION WITH ANY PROVISION OF THIS LIMITED WARRANTY, EVEN IN THE EVENT OF THE FAULT, TORT (INCLUDING NEGLIGENCE), STRICT LIABILITY, BREACH OF CONTRACT OR BREACH OF WARRANTY OF GIGASET NAM OR SELLER OR ANY SUPPLIER, AND EVEN IF GIGASET NAM OR SELLER OR ANY SUPPLIER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REPAIR OR REPLACEMENT, AS PROVIDED UNDER THE WARRANTY, IS YOUR SOLE AND EXCLUSIVE REMEDY FOR BREACH OF THE LIMITED WARRANTY.

9. LIMITATION OF LIABILITY AND

REMEDIES

NOTWITHSTANDING ANY DAMAGES THAT YOU MIGHT INCUR FOR ANY REASON WHATSOEVER (INCLUDING, WITHOUT LIMITATION, ALL DAMAGES REFERENCED ABOVE AND ALL DIRECT OR GENERAL DAMAGES), THE ENTIRE LIABILITY OF GIGASET NAM, SELLER AND ANY OF THEIR SUPPLIERS UNDER ANY PROVISION OF THIS LIMITED WARRANTY AND YOUR EXCLUSIVE REMEDY FOR ALL OF THE FOREGOING (EXCEPT FOR ANY REMEDY OF REPAIR OR REPLACEMENT ELECTED BY GIGASET NAM OR SELLER OR SUPPLIER WITH RESPECT TO ANY BREACH OF THE LIMITED WARRANTY) SHALL BE LIMITED TO THE GREATER OF THE AMOUNT ACTUALLY PAID BY YOU FOR THE PRODUCT OR FIVE DOLLARS ($5.00 USD/CAN). THE FOREGOING LIMITATIONS, EXCLUSIONS AND DISCLAIMERS SHALL APPLY TO THE MAXIMUM

EXTENT PERMITTED BY APPLICABLE LAW, EVEN IF ANY REMEDY FAILS ITS ESSENTIAL PURPOSE.

10. GOVERNING LAW

If this Product was purchased in the United States of America this limited warranty will be governed by the laws of Texas, and exclude the United Nations Convention on Contracts for the International Sale of Goods. If this Product was purchased in Canada this limited warranty will be governed by the laws of the Province of Ontario and the federal laws of Canada applicable therein, and exclude the United Nations Convention on Contracts for the International Sale of Goods.

If you want to learn more about Gigaset Service or for Support on your Gigaset phone, visit our web site at http://www.gigaset.com or please call 1-866 247-8758.

Issued by Gigaset Communications GmbH Frankenstr. 2a, D-46395 Bocholt Manufactured by Gigaset Communications GmbH under trademark license of Siemens AG.

reserved. Product attributes subject to change.

We reserve the right, to make changes without notice in equipment design and/or components. Part Number: A31008-M2121-R301-2-3S19

Accessories

Gigaset handsets

ADD MORE GIGASET HANDSETS TO YOUR CORDLESS TELEPHONE SYSTEM.

Gigaset S79H handset

u Illuminated graphic colour display (65k colours) u Illuminated keypad u Speaker mode u Polyphonic ringtones u Directory for approx. 500 entries u Caller picture u PC interface, e.g., for managing directory entries, ringtones

and screensavers

u Headset socket u Room monitor

www.gigaset.com/gigasets79h

All accessories and batteries are available from your phone retailer.

Use only original accessories. This will avoid possible health risks and personal injury, and also ensure that all the relevant regulations are complied with.

Mounting the base on the wall (Gigaset S790 only)

Approx. 5.5

41 mm

Approx. 4

21 mm

Mounting the base on the wall (Gigaset S790 only)

Mounting the charger on the wall

Index

Access protection . . . . . . . . . . . . . . . . . . . . . 58

Accessories Acknowledge tones Activating

advisory tones answering machine answering machine

appointment handset keypad lock listening in ring delay room monitor

two-way record Advisory tones Alarm clock Alert tone Anniversary

deactivating

missed

saving in the directory Announcement (answering machine) Answering machine

activating/deactivating

deleting messages

playing back messages

recording a personal

remote operation

scrolling back

scrolling forward Answering machine list Answering machine, see also

Appointment Appointment/anniversary

display missed Appointments

activating/deactivating

deleting

managing Area codes

extra codes

. . . . . . . . . . . . . . . . . . . . . . . . . . . 71

. . . . . . . . . . . . . . . . . . . 57

. . . . . . . . . . . . . . . . . . . . . . 57

. . . . . . . . . . . . . . . . . 38

(remote operation)

. . . . . . . . . . . . . . 42

. . . . . . . . . . . . . . . . . . . . . . . 44

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

. . . . . . . . . . . . . . . . . . . . . . . . 23

. . . . . . . . . . . . . . . . . . . . . . . . . 49

. . . . . . . . . . . . . . . . . . . . . . . . . . 54

. . . . . . . . . . . . . . . . . . . . . . 51

. . . . . . . . . . . . . . . . . . . . . 41

. . . . . . . . . . . . . . . . . . . . . . . . 57

. . . . . . . . . . . . . . . . . . . . . . . . . . . 46

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

. . . . . . . . . . . . . . . . . . . . . . . . . . . 34

. . . . . . . . . . . . . . . . . . . . . . . . 35

. . . . . . . . . . . . . . . . . . . . . . . . . . 37, 46

. . . . . . . . . . . . . . . 34

. . . . . . . . . . . . . . 38

. . . . . . . . . . . . . . . . . . 40

. . . . . . . . . . . . . . 39

announcement/advisory message

. . . . . . . . . . . . . . . . . . . . . . . 38

. . . . . . . . . . . . . . . . . . . 42

. . . . . . . . . . . . . . . . . . . . . . . 40

. . . . . . . . . . . . . . . . . . . . 40

. . . . . . . . . . . . . 36, 37

Network mailbox

. . . . . . . . . . . . . . . . . . . . . . . . . 44

. . . . . . . . . . . . . . . . . . . . . . 46

. . . . . . . . . . . . . . 45

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

. . . . . . . . . . . . . . . . . . . . . . . . . . 45

. . . . . . . . . . . . . . . . . . . . . . . . . 17

. . . 39

local area code

setting own area code Assigning a number key Automatic

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

redial

ring delay

. . . . . . . . . . . . . . . . . . . . . . 17

. . . . . . . . . . . . . . . 57

. . . . . . . . . . . . . . . 52

. . . . . . . . . . . . . . . . . . . . . . . 29, 54

Backlight

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

keypad Base

changing

connecting

connecting to PABX

restoring to factory settings

setting ringtone

setting up

settings

system PIN Battery

charging

display

icon

inserting

tone Best base Birthday, see Anniversary

. . . . . . . . . . . . . . . . . . . . . . . . . . . 48

. . . . . . . . . . . . . . . . . . . . . . . . . 10

. . . . . . . . . . . . . . . . . 59

. . . . . . . . . . 58

. . . . . . . . . . . . . . . . . . . . 58

. . . . . . . . . . . . . . . . . . . . . . . . . . 10

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

. . . . . . . . . . . . . . . . . . . . . . . . . 58

. . . . . . . . . . . . . . . . . . . . . . . 2, 3, 14

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2, 3

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2, 3

. . . . . . . . . . . . . . . . . . . . . . . . . . . 12

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Call

accepting

connect participant

ending

external

internal

picking up from answering machine

transferring (connecting)

two-way record Call duration Call lists Call screening during recording Call waiting

internal call Caller ID Caller Picture Calling

external

internal Caring for your telephone

. . . . . . . . . . . . . . . . . . . . . . . . . . 29

. . . . . . . . . . . . . . . . . 49

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

. . 40

. . . . . . . . . 48, 50

. . . . . . . . . . . . . . . . . . . . . 41

. . . . . . . . . . . . . . . . . . . . . . . . . . 29

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

. . . . . . . . 41

. . . . . . . . . . . . . . . . . . . . . . . . . 49

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

. . . . . . . . . . . . . . . . . . . . . . 32, 56

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

. . . . . . . . . . . . . . 61

Index

Changing

destination number (room monitor) dialing mode display language earpiece volume internal number of a handset name of a handset pauses ringtone speaker volume

system PIN Changing the system PIN Character set Charge status display Colour scheme Conference

internal Confirmation tone Connecting the headset Connecting, base to PABX Consultation call

internal Control key Correcting incorrect entries Customer Care

. . . . . . . . . . . . . . . . . . . . . . . 59

. . . . . . . . . . . . . . . . . . . . 53

. . . . . . . . . . . . . . . . . . . . 54

. . . . . . . . 50

. . . . . . . . . . . . . . . . . . 50

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

. . . . . . . . . . . . . . . . . . . . . . . . . 55, 58

. . . . . . . . . . . . . . . . . . . . . 54

. . . . . . . . . . . . . . . . . . . . . . . . . 58

. . . . . . . . . . . . . . 58

. . . . . . . . . . . . . . . . . . . . . . . . . 63

. . . . . . . . . . . . . . . . . 2, 3

. . . . . . . . . . . . . . . . . . . . . . . . 53

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

. . . . . . . . . . . . . . . . . . . . . 57

. . . . . . . . . . . . . . . 18

. . . . . . . . . . . . . . 59

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

. . . . . . . . . . . . . . . . . . . . . . . . . 2, 20

. . . . . . . . . . . . 21

. . . . . . . . . . . . . . . . . . . . . . . . 68

Deactivating

advisory tones

answering machine

appointment

handset

keypad lock

listening in

ring delay

room monitor

two-way record Delete key Deleting

announcement for answer

machine characters message

De-registering (handset) Destination number (room monitor) Dialing

using quick dial using the directory

Dialing mode Directory

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

. . . . . . . . . . . . . . . . . . . . . . 57

. . . . . . . . . . . . . . . . . 38

. . . . . . . . . . . . . . . . . . . . . . . 44

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

. . . . . . . . . . . . . . . . . . . . . . . . 23

. . . . . . . . . . . . . . . . . . . . . . . . . 49

. . . . . . . . . . . . . . . . . . . . . . . . . . 54

. . . . . . . . . . . . . . . . . . . . . . 51

. . . . . . . . . . . . . . . . . . . . . 41

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

. . . . . . . . . . . . . . . . . . . . . . . 39

. . . . . . . . . . . . . . . . . . . . . . . . . . 21

. . . . . . . . . . . . . . . . . . . . . . . . . . . 40

. . . . . . . . . . . . . . . 48

. . . . . . . . . . . . . . . . . . 34, 52

. . . . . . . . . . . . . . . . . . 33

. . . . . . . . . . . . . . . . . . . . . . . . . 59

. . 51

. . . . 51

copying number from text . . . . . . . . . . . 34

managing entries opening order of entries saving anniversary saving entry sending entry/list to handset using to enter numbers

Display

backlight changing display language colour scheme directory memory in idle status memory (resource directory) missed anniversaries missed

network mailbox message number (Caller ID/Name) screensaver setting slide show

Display keys

assigning

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

appointments/anniversaries

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

. . . . . . . . . . . . . . . . . . . 33

. . . . . . . . . . . . . . . . . . . . . 33

. . . . . . . . . . . . . . . . . . 34

. . . . . . . . . . . . . . . . . . . . . . . . 32

. . . . . . . . . 34

. . . . . . . . . . . . . . 34

. . . . . . . . . . . . . . . . . . . . . . . . . . . 53

. . . . . . . . . . 53

. . . . . . . . . . . . . . . . . . . . . . 53

. . . . . . . . . . . . . . . . . . . 33

. . . . . . . . . . . . . . . . . . . . . 16, 23

. . . . . . . . . 56

. . . . . . . . . . . . . . . . 37

. . . . . 46

. . . . . . . . . . . 43

. . . . . . . . . . . . 30

. . . . . . . . . . . . . . . . . . . . . . . . . 53

. . . . . . . . . . . . . . . . . . . . . . . . . . 53

. . . . . . . . . . . . . . . . . . . . . . . . 2, 21

. . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Earpiece volume . . . . . . . . . . . . . . . . . . . . . . 54

ECO DECT Eco mode E-mail address

copying from

End call key Ending, call Entry

selecting from directory Error tone Expert mode External call

forwarding to ans. mach. Extra codes

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

the directory

. . . . . . . . . . . . . . . . . . . 34

. . . . . . . . . . . . . . . . . . . . . . . . . 2, 29

. . . . . . . . . . . . . . . . . . . . . . . . . . . 29

. . . . . . . . . . . . . 33

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

. . . . . . . . . . . . . . . . . . . . . . . 26, 60

. . . . . . . . . . . . 41

. . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Fast access

answering machine

network mailbox Firmware update Flash key

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

. . . . . . . . . . . . . . . . . 42

. . . . . . . . . . . . . . . . . . . . 43

. . . . . . . . . . . . . . . . . . . . . . 64

Index

Group call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Handset

activating/deactivating advisory tones changing internal number changing name changing the number changing to a different base changing to best reception colour scheme contact with liquid de-registering display backlight display language earpiece volume idle status keypad backlight large font

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

list locating muting

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

paging registering registering to a different base restoring to factory settings screensaver set up for use

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

setting speaker volume transferring a call using multiple

using room monitor Handset mode Handset operating time

in room monitor mode Handsfree

set profile Handsfree profile Headset socket Hearing aids

. . . . . . . . . . . . . . . . . . . . . . 57

. . . . . . . . . . . . . . . . . . . . . . 53

. . . . . . . . . . . . . . . . . . . 47, 48

. . . . . . . . . . . . . . . . . . . . . . . . . . 23

. . . . . . . . . . . . . . . . . . . . . . . . . . . 53

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

. . . . . . . . . . . . . . . . . . . . . . . . . 47

. . . . . . . . . . . . . . . . . . . . . . . . . 53

. . . . . . . . . . . . . . . . . . . . . . . 12

. . . . . . . . . . . . . . . . . . . . . . 47

. . . . . . . . . . . . . . . . . . . . . . . . 31

. . . . . . . . . . . . . . . . . . . . . . . . . . 54

. . . . . . . . . . . . . . . . . . . . . . 54

. . . . . . . . . . . . . . . . . . . . . . . . 18

. . . . . . . . . . . . . . . . . . . . . . . . . . . .8

. . . . . . . . . . . . . . 23

. . . . . . . . . . . 50

. . . . . . . . . . . . . . . . . . . . . 50

. . . . . . . . . . . . . . . 50

. . . . . . . . . 48

. . . . . . . . . . 48

. . . . . . . . . . . . . . . . . . 61

. . . . . . . . . . . . . . . . . . . . 53

. . . . . . . . . . . . . . . . . . . . 54

. . . . . . . . . . . . . . . . . . . 54

. . . . . . . . 48

. . . . . . . . . . 57

. . . . . . . . . . . . . . . . . . . . . 54

. . . . . . . . . . . . . . . . . . . 48

. . . . . . . . . . . . . . . . . 50

. . . . . . . . . . . . . . 51

Icon

alarm clock

answering machine

. . . . . . . . . . . . . . . . . . . . . . . . . 46

. . . . . . . . . . . . . . 38, 41

for new messages keypad lock new message

ringtone Idle status (display) Idle status, returning to Incorrect entries (correction) Industry Canada Certification Installing, base Internal

conference

consulting

listening in

making calls Internal call

call waiting

. . . . . . . . . . . . . . . . . . . . . . . . . . . 55

. . . . . . . . . . . . . . . . . . . . . . . . . . . 48

. . . . . . . . . . . . . . . . . . . 37

. . . . . . . . . . . . . . . . . . . . . . . . 23

. . . . . . . . . . . . . . . . . . . . . . . 39

. . . . . . . . . . . . . . . . . 16, 23

. . . . . . . . . . . . . . . . 23

. . . . . . . . . . . 21

. . . . . . . . . . 65

. . . . . . . . . . . . . . . . . . . . . . . . 10

. . . . . . . . . . . . . . . . . . . . . . . . . 49

. . . . . . . . . . . . . . . . . . . . . . . . . . 49

. . . . . . . . . . . . . . . . . . . . . . . . . 49

. . . . . . . . . . . . . . . . . . . . . . . . 48

. . . . . . . . . . . . . . . . . . . . . . . . . 49

Key

assigning to a function or

number Key 1 (fast access) Keypad backlight Keypad lock Keys

control key delete key display keys end call key fast access flash key message key mute key on/off key pound key quick dial side keys speaker key star key talk key

. . . . . . . . . . . . . . . . . . . . . . . . 52

. . . . . . . . . . . . . . . . . . . 2, 42

. . . . . . . . . . . . . . . . . . . . . 54

. . . . . . . . . . . . . . . . . . . . . . . . . . 23

. . . . . . . . . . . . . . . . . . . . . . . 2, 20

. . . . . . . . . . . . . . . . . . . . . . . . . . 21

. . . . . . . . . . . . . . . . . . . . . . 2, 21

. . . . . . . . . . . . . . . . . . . . . . . 2, 29

. . . . . . . . . . . . . . . . . . . . . . . . 2, 42

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

. . . . . . . . . . . . . . . . . . . . . . . . . .2

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

. . . . . . . . . . . . . . . . . . . . . . . . . . . .2

. . . . . . . . . . . . . . . . . . . . . . . . . . 23

. . . . . . . . . . . . . . . . . . . . . . . . . . . 34

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

. . . . . . . . . . . . . . . . . . . . . . . . . . .2

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

. . . . . . . . . . . . . . . . . . . . . . . . . . 2, 29

Language, display. . . . . . . . . . . . . . . . . . . . . 53

Large font List

answering machine call lists handsets missed calls

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

. . . . . . . . . . . . . . 36, 37

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

. . . . . . . . . . . . . . . . . . . . . . . . . . . 20

. . . . . . . . . . . . . . . . . . . . . . . . 36

Index

network mailbox . . . . . . . . . . . . . . . . . . . . 37

Listening in to a call Local area code Locating, handset Lock

activating/deactivating keypad lock

. . . . . . . . . . . . . . . . . . . 49

. . . . . . . . . . . . . . . . . . . . . . . 17

. . . . . . . . . . . . . . . . . . . . . 48

Making calls

accepting a call external

internal Manual redial Medical equipment Memory

Gigaset S790, S795 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

The handset at a glance

Display symbols

The base at a glance

Contents

Safety precautions

First steps

Checking the package contents

Setting up the base and charger (if included)

Connecting the base

Connecting the charger (if included)

Setting up the handset

Setting the date and time

Setting up area codes

Connecting the headset

Connecting the USB data cable

What would you like to do next?

Using the phone

Control key

Display keys

Keys on the keypad

Side keys

Correcting incorrect entries

Using the menus

Activating/deactivating the handset

Activating/deactivating the keypad lock

Using this guide

Menu overview

Making calls

Making an external call

Accepting a call

Ending a call

Using Caller ID

Using the speaker mode

Switching to mute

Using the directory and lists

Directory

Redial list

Answering machine list (Gigaset S795 only)

Call lists

Opening lists with the message key

List of missed alarms

Operating the Gigaset S795 base answering machine

Operating via the handset

Resetting fast access for the answering machine using key 1

Operating when on the move (remote operation)

Using the network mailbox

Configuring fast access for the network mailbox

Viewing the network mailbox message

ECO DECT

Setting an appointment (calendar)

Setting the alarm clock

Displaying missed appointments, anniversaries

Using multiple handsets

Registering handsets

De-registering handsets

Locating a handset ("Paging")

Changing the base

Making internal calls

Listening in to an external call

Using a handset as a room monitor

Changing the name of a handset

Changing a handset's internal number

Handset settings

Quick access to numbers and functions

Changing the display language

Setting the display

Setting keypad illumination

Activating/deactivating auto answer

Changing the speaker/ earpiece volume

Setting a handsfree profile

Changing ringtones

Resource Directory

Setting the base

Changing the Gigaset S795 base ringtones

Protecting against unauthorized access

Connecting the base to the PABX
