Gigaset AL180 Duo User Manual

Gigaset AL180

V

11.12. 11:56
INT MENU

h

1 Charge status of

the batteries
2Display keys
3Message key

Flashes: new messages

received
4Directory key
5 Control key (u)
6Talk key
7 End call key and

On/Off key
8 Ringer tone on/off

(press and hold in

idle status)
9 Keypad lock on/off

(press and hold)

10 Recall key

- Consultation call

(flash)

- Dialling pause

(press and hold)

11 Microphone
12 "Microphone off" key

The base station at a glance

AL180 base station

9

2

4

6

3

5

7

11

1

The handset at a glance

10

12

8

Display key on handset:

Pressing a key launches the function that
appears above that key in the display.

Display Function when pressed

INT

Call other registered hand­sets

¢ p. 9.

MENU

Open main/submenu
(see Menu tree

¢ p. 13).

“

Go back one menu level.

U

Scroll up/down or adjust vol­ume with u.

T

Move cursor to left/right
with u.

˜

Backspace deletes one
character at a time.

OK

Confirm menu function or
save entry.

Registration/paging key:
Search for handsets (press briefly, "Paging"

¢ p. 9)

Register handsets (press and hold

¢ p. 9).

1

2

$

ƒ

!

Safety precautions

Read this user guide and the safety precautions carefully
before use. Explain their contents and the potential haz
ards associated with using the telephone to your chil­dren.

Only use the mains unit supplied.

Fit only the recommended, rechargeable
batteries (¢ p. 11), i.e. never use a conven-
tional (non-rechargeable) battery or other bat­tery types as this could result in significant
health risks and personal injury.

The operation of medical appliances may be
affected. Be aware of the technical conditions
in

your particular environment, e.g. doctor's

surgery.
Do not hold the rear of the handset to your ear

when it is ringing. Otherwise you risk serious
and permanent damage to your hearing.
The handset may cause an unpleasant hum­ming noise in hearing aids.

Do not install the phone in a bathroom or
shower room. The handset and base station
are

not splashproof.

Do not use your phone in environments with a
potential explosion hazard, e.g. paint shops.

If you give your Gigaset to someone else, make
sure you also give them the user guide.

Please remove faulty base stations from use or
have them repaired by our service, as they could
interfere with other wireless services.

Disposal

Batteries should not be disposed of in general
household waste. Observe the local waste dis
posal regulations, details of which can be
obtained from your local authority or the dealer
you purchased the product from.
All electrical and electronic equipment must be
disposed of separately from general household
waste using the sites designated by local
authorities.
If a product displays this symbol of a crossed-out
rubbish bin, the product is subject to European
Directive 2002/96/EC.
The appropriate disposal and separate collec­tion of used equipment serve to prevent poten­tial harm to the environment and to health.
They are a precondition for the re-use and recy
cling of used electrical and electronic equip­ment.
For further information on disposing of your
used equipment, please contact your local
authority, your refuse collection service or the
dealer you purchased the product from.

Emergency numbers cannot be dialled if the keypad lock
(¢ p. 1) is activated!
Not all of the functions described in this user guide are
available in all countries.

Care

Wipe the base station, charging cradle and handset

-

with a damp cloth (do not use solvent) or an anti
static cloth.
Never use a dry cloth. This can cause static.

Contact with liquid

If the handset has come into contact with liquid:

◆ Switch off the handset and remove the bat-

tery pack immediately.

◆ Allow the liquid to drain from the handset.

◆ Pat all parts dry, then place the handset with

the battery compartment open and the keypad
facing down in a dry, warm place for at least

72

hours (not in a microwave, oven etc.).

◆ Do not switch on the handset again until it is

completely dry.

When it has fully dried out, you will normally be
able to use it again.

ECO DECT

You are helping to protect the environment with
your Gigaset

AL180.

Reduced energy consumption

Your telephone has an energy-saving adapter
plug and uses less energy.

Reduced transmission power

The transmission power of your telephone is
reduced automatically:
The handset's transmission power is reduced

-

depending on the distance to the base station.
The transmission power on the base station is
reduced to virtually zero when only one handset
is registered and the handset is in the base sta
tion.
You can reduce the transmission power of the
handset and base station even more by using
Eco Mode/Eco Mode+ (see Menu tree

¢ p. 14):

◆ Eco Mode: 80% transmission power reduc-

-

tion in standby mode and during a call (the
range of the base station is reduced).

◆ Eco Mode+: 100% transmission power deac-

tivation in standby mode (top left display
icon

½). Press and hold the talk key c to

check that the base station can be reached.
You will hear the ringing tone if the base sta
tion can be reached.

-

-

-

3

1

1

1

2

First steps

Check the pack contents

◆ One Gigaset AL180 base station,

◆ one mains adapter,

◆ one Gigaset AL18H handset,

◆ one phone cord,

◆ two batteries,

◆ one battery cover,

◆ one user guide.

If you have purchased a model with multiple handsets, the package should contain two
batteries, a battery cover and a charging cradle with mains adapter for each additional
handset.

Setting up the base station and charging cradle (if included)

The base station and charging cradle are designed for use in enclosed dry rooms with a
temperature range of +5

°C to +45 °C.

¤ Set up the base station at a central location on a flat, non-slip surface in your house or

apartment.

Please note

Pay attention to the range of the base station.
This is up to 300 m in unobstructed outdoor areas and up to 50 m inside buildings.
The range is reduced when Eco Mode is activated (

The phone's feet do not usually leave any marks on surfaces. However, due to the multi­tude of different varnishes and polishes used on today's furnishings, the occurrence of
marks on the surfaces cannot be completely ruled out.
You can also mount the base station and charging cradle on the wall.

Please note:

◆ Never expose the telephone to the influence of heat sources, direct sunlight or other

electrical devices.

◆ Protect your Gigaset from moisture, dust, corrosive liquids and vapours.

¢ p. 14).

Connecting the base station

¤ First connect the mains adapter 1.
¤ Then connect the telephone jack 2

and insert the cables into the cable
ducts.

Please note:

◆ The mains adapter must always be

connected, as the phone will not oper

ate without mains connection.

◆ Only use the mains adapter and phone

cord supplied. Pin connections on tel
ephone cables can vary.

-

-

4

¤ Connect the flat plug from the power supply 1.
¤ Plug the mains adapter into the plug socket 2.

If you need to disconnect the plug from the charging cradle,
press the release button 1 and disconnect the plug 2.

1

2

1

2

¤ Insert the batteries the right

way round.
The polarity is indicated in/on
the battery compartment.

¤ First insert the battery cover at

the top a.

¤ Then press the cover b until it clicks

into place.

If you need to open the battery cover,
for instance to replace the batteries,
place your fingertip in the cavity on the
casing and pull the battery cover
upwards.

a

b

Connecting the charging cradle (if included)

Setting up the handset for use

The display is protected by a plastic film.

Please remove the protective film!

Inserting the batteries and closing the battery cover

Warning

Use only the rechargeable batteries recommended by Gigaset Communications

*

GmbH

(¢ p. 11). Never use a conventional (non-rechargeable) battery or other

battery types as this could result in significant health risks and personal injury.
For

example, the batteries could explode. The phone could also malfunction or be

damaged as a result of using batteries that are not of the recommended type.

* Gigaset Communications GmbH is a trademark licensee of Siemens AG.

5

V

Registering

V

INT MENU

Before you can use the phone, you must first register the
handset to the base station.

The handset registers automatically.
Registration can take up to 5 minutes.

Do not remove the handset from the
base station during this time.

After successful registration, the idle screen is displayed.
Charge status of the batteries:

–

= e V U (flat to full)

–

= flashes: batteries almost flat

–

e V U flashes: charging

V

Put into base

MENU

¤ Place the handset with

the display facing up
in the base station.

¤ Place the handset in the base station or charging cradle for eight hours.
¤ Then remove the handset from the base station or charging cradle and

do not replace it until the batteries are completely discharged.

8 h

Placing the handset in the base station and registering

If you have purchased a model with multiple handsets, repeat the registration process
for each individual handset. Handsets are assigned the lowest available internal number
(1-4). If more than one handset is registered to the base station, the internal handset
number appears in the top left of the display, e.g. 2. If the internal numbers 1–4 are
already assigned to other devices, the number

Please note

◆ Each key press interrupts the automatic registration.

◆ If automatic registration does not work, the handset will have to be registered

manually

◆ Only place the handset in the base station or charging cradle that is intended for

it.

(¢ p. 9).

4 will be overwritten.

Initial charging and discharging of the batteries

The correct charge level can only be displayed if the batteries are first fully charged and
discharged.

6

V

11.12. 11:56
INT MENU

Please note

◆ After the first battery charge and discharge you may replace your handset in the

base station or charging cradle after every call.

◆ Always repeat the charging and discharging procedure if you remove the batteries

from the handset and reinsert them.

◆ The batteries may warm up during charging. This is not dangerous.

◆ After a while, the charge capacity of the batteries will decrease for technical rea-

sons.

Setting the date and time

Set the date and time so that the correct date and time can be assigned to incoming calls,
and so that the alarm can be used.

MENU ¢ Settings ¢ OK ¢ Date/Time ¢ OK
¢ Date: ¢ ~ (enter the day, month and year in 6-digit format) ¢ OK
¢ Time: ¢ ~ (enter hours and minutes in 4-digit format) ¢ OK (display message: Saved)
¢ a (press and hold to return to idle status)

Please note

When entering the time and date, you can move the position of an entry to the left
or right by pressing the control button up or down.

Display in idle status

Once the phone is registered and the time set, the idle dis­play is shown as in this example.

Activating/deactivating the handset

Press and hold the a key to activate or deactivate the hand­set.
If you place a deactivated handset in the base station or
charging cradle, it will automatically activate.

Your phone is now ready for use.

If you have any questions about using your phone, please read the tips on troubleshooting
("

Questions and answers" ¢ p. 11) or contact our Customer Care team ¢ p. 12.

7

Making calls

Making external calls and ending calls

External calls are calls using the public telephone
network.

~

(Enter the phone number) ¢c.

The phone number is dialled. (Or you can first
press and hold
number.) During the call you can adjust the ear
piece volume using t and set the volume with u.

End the call/cancel dialling:

Press the end call key a.
You can automatically insert a network provider
dialling code before any phone number
(see

Menu tree "Preselection" ¢ p. 14).

c [dial tone] and then enter the

-

Accepting a call

The handset indicates an incoming call by ringing
and by a display on the screen.

Press the talk key c to accept the call.
When Auto Answer is activated (see Menu tree

¢ p. 14), simply remove the handset from the

base station/charging cradle.
In idle status, use t to activate the menu for set­ting the call volume and use u to set the volume.

Calling Line Identification

When you get a call, the caller's number will be dis­played on your handset; the caller's name will be
displayed if it is stored in the directory.

Preconditions:

1 You have asked your network provider for the

caller's number (
handset screen.

2 The caller has asked the network provider for

his number to be identified (CLI).

®

requested Calling Line Identification,
appears if the caller has withheld CLI, and

able appears if CLI has not been requested.

appears in the display if you have not

Muting

You can mute your handset when making external
calls. Your caller can no longer hear you.
Press the "Microphone off" key m during the call to
activate/deactivate the function.

CLIP) to be displayed on your

Withheld

Unavail-

Using the directory and lists

Directory

To open the directory: press h.
You ca n s ave up to 40 phone numbers
(max.

32 digits) with corresponding names

(max.

14 characters). Enter letters/characters

¢ p. 11.

Saving the first number in the directory

h ¢ New Entry? ¢ OK

¢ ~ (enter number) ¢ OK
¢ ~ (enter number) ¢ OK

Storing a number in the directory

h ¢ MENU ¢ New Entry ¢ OK

¢ ~ (enter number) ¢ OK
¢ ~ (enter number) ¢ OK

Selecting a directory entry

Open the directory with h. You hav e th e fo ll owi ng
options:

◆ Use u to scroll through the entries until the

required name is selected.

◆ Enter the first character of the name and scroll

to the entry with

Dialling with the directory

h ¢ u (select entry) ¢ c

Using other functions

h ¢ u (select entry) ¢ MENU

The following functions can be selected with u:

New Entry
Show Number
Use Number

Edit Entry
Delete Entry
Send Entry

Delete List
Send List

Shortcut

u, if required.

Save new phone number.

Display the phone number.

Edit or add to the number.
Then

dial or use other functions

with

MENU.

Edit selected entry.

Delete selected entry.

Send a single entry to another
handset

(¢ p. 8).

Delete all directory entries.

Send the complete list to
another handset

For shortcuts, assign the cur­rent entry to a key.

(¢ p. 8).

8

CallsList 01+02

Using shortcut keys

You can assign directory entries to the keys 0 and
2–9:

h ¢ u (select entry) ¢ MENU ¢ Shortcut ¢ OK

¢ ~ (press the key you want to assign the entry to)

To dia l, press and hold the required shortcut key.

Sending the directory to another handset

Preconditions:

◆ The sending and receiving handsets must both

be registered to the same base station.

◆ The other handset and the base station can

send and receive directory entries.

h ¢ u (select entry) ¢ MENU ¢ Send Entry /

Send List ¢ OK ¢ ~ (enter the internal number
of the receiving handset) ¢ OK

Last number redial list

This list contains the ten last dialled numbers.

Dialling from the last number redial list
c (press briefly) ¢ u (select entry) ¢ c

Managing entries in the last number redial list
c (press briefly) ¢ u (select entry) ¢ MENU

You can select the following settings:

Use Number

Copy to Dir.
Delete Entry

Delete List

Calls list/network mailbox list

An advisory tone sounds and the message key
flashes as soon as a new entry appears in the calls

list/answer machine list. A message appears in the
display.
When you press the f key, all the lists are dis­played. If only one list contains new messages, this
will be opened automatically.

Please note:

If calls are saved in the network mailbox, you will
receive a message if the appropriate settings have
been made (depending on your network pro
vider).

Edit or add to the number.
Then

dial or use other functions

with

MENU.

Copy an entry to the directory.

Delete selected entry.

Delete all entries.

-

Calls list
Precondition: CLIP (¢ p. 7)

Depending on the type of list set, the calls list con­tains (¢ p. 14)

◆ answered calls

◆ missed calls

Depending on the type of list set, all numbers of
the last 25 incoming calls are saved or just the
missed calls are saved.
The calls list is displayed as follows:

Number of new entries + number of old, read entries

Open the calls list

f ¢ CallsList 01+02 ¢ OK

The last incoming call is displayed.
If necessary, use u to select another entry.

Using other functions

u (select entry) ¢ MENU

The following functions can be selected with u:

Delete Entry
Copy to Dir.
Date/Time
Status

Delete List

Delete current entry.

Copy an entry to the directory.

Call date and time (if set).

New Call: new missed call.
Old Call: entry already read.
Answ.: call taken.

Warning! All old and new
entries will be deleted.

Calling back a caller from the calls list

f ¢ CallsList 01+02 ¢ OK ¢ u (select entry)

¢ c

Assigning key 1 for fast access to the network mailbox

Simply press and hold key 1 on the handset and
you will be connected directly to the network mail
box.

See Menu tree ¢ p. 13.

-

9

Locating a handset ("paging")

You can locate your handset using the base station.

◆ Briefly press the registration/paging key on the

base station

◆ All handsets will ring simultaneously ("pag-

ing"), even if the ringer tones are deactivated.

End paging: briefly press the register/paging key
on the base station
a handset.

(¢ p. 1).

(¢ p. 1) or the talk key c on

Registering handsets

You can register up to four handsets on your base
station (Gigaset

Please note:
Each additional handset must be registered on

the base station in order for it to work properly!

For automatic registration of handsets to
Gigaset

AL18H) recommended).

AL180, see ¢ p. 5.

Manual registration of handsets to Gigaset AL180

1. On the handset: MENU ¢ Settings ¢ OK

¢ Handset ¢ OK ¢ Register HS ¢ Enter the sys-

tem PIN of the base station (default is 0000) ¢ OK.

Registering flashes in the display.

2. On the base station: within 60 sec. of entering
the system PIN, press and hold the registration/
paging key

Registration takes approx. 1 minute.

(¢ p. 1) (min. 3 sec.).

De-registering handsets

Handsets can only be de-registered by resetting
the base station to its default settings. This will
also reset every other setting

If you have only registered handsets for other GAP­compatible devices, these can only be de-regis
tered with a hardware reset ¢ p. 10.

¢ p. 10.

-

Using several handsets

Making internal calls

Internal calls are free calls to other handsets that
are registered to the same base station.

To make a call to other handsets, press

◆ INT ¢ ~ (1...4, enter internal number of the

handset)

◆ INT ¢ star key P ¢ OK, all handsets are

called.
When a participant answers you can speak to
them. To end the call, press

¢ OK, the handset is called or

a.

Internal consultation call/connecting a call

You are in conversation with an external partici­pant. Press the INT key and call one or all handsets.
The external participant hears the hold music.

◆ Before the internal participant has answered,

press the end call key
the participant who answers the call.

◆ After the internal participant has answered,

you can talk to him. Press the end call key
the call is diverted, or press the display key
you are reconnected to the external participant.

a; the call is diverted to

a;

;

Listening in to an external call

You are conducting an external call. An internal
participant can listen in on this call and take part in
the conversation (conference).

Precondition: The Listening in function must be
activated.

Activating/deactivating listening in

MENU ¢ Settings ¢ OK ¢ Base ¢ OK
¢ Listening in ¢ OK (‰ = on)

Internal listening in (conference)

You want to listen in to an existing external call.
Briefly press and hold the c key. You can listen in

to the call. All participants hear a signal tone.
To e nd : press the end call key a. All participants

hear a signal tone.
If the first internal participant presses the end call
key

a, the handset that has "listened in" remains

connected to the external participant.

Setting the alarm clock

Activating/deactivating the alarm clock

MENU ¢ Alarm Clock ¢ OK ¢ Activation

¢ OK (‰ = on)

When activated:

¢ Set the wake-up time ¢ OK

When the alarm clock rings, press any key to switch
it off for 24
wake-up icon
wake-up time will be displayed instead of the date.

Setting the wake-up time

MENU ¢ Alarm Clock ¢ OK ¢ Wake-up time ¢ OK

Enter the wake-up time in hours and minutes, then
press

hours. If the alarm clock is set, the

9 will appear on the screen and the

OK.

10

Phone settings

For details on how to make audio settings, see
Menu tree
For details on how to set the system PIN on the
base station, see the Menu tree

¢ p. 13.

¢ p. 14.

Changing the display language

MENU ¢ Settings ¢ OK ¢ Handset ¢ OK

¢ Language ¢ OK ¢ select the language ¢ OK

The current language is indicated by ‰.

If you accidentally choose a language you do not
understand:

MENU ¢ 4 2 1 (press the keys one after the other)

Select the correct language with u and press OK.

Resetting the handset

You can reset individual settings and changes that
you have made. Entries in the directory, the calls
list and the handset's registration to the base sta
tion will be retained.

MENU ¢ Settings ¢ OK ¢ Handset ¢ OK
¢ Reset Handset ¢ OK

Cancel the reset with a.

Restoring the base station to the factory settings

When restoring factory settings:

◆ All handsets are de-registered

◆ Individual settings are reset

◆ All lists are deleted

◆ The system PIN is reset to the original code

0000

Only the date and time are retained.

Software reset

MENU ¢ Settings ¢ OK ¢ Base ¢ OK
¢ Base Reset ¢ OK

Hardware reset

Disconnect the power cord from the base station.
Hold down the registration/paging key
on the base station while reconnecting the power
cable to the base station. Release the key after
approximately 5 seconds.

Repeater mode

(¢ p. 1)

Operating the base station on the PABX

The following settings are only necessary when
your PABX requires them, see the user guide for
your PABX.
When entering the digits, enter them slowly one
after the other.

Changing the dialling mode

MENU ¢ 4 I O 1 1 ¢ The number for the set dial-

ling mode flashes: 0 = touch tone dialling (DTMF);
1 = dial pulsing (DP) ¢ enter number ¢OK.

Setting recall

MENU ¢ 4 I O 1 2 ¢ The number for the current

recall flashes

3 = 400 ms; 4 = 250 ms; 5 = 300 ms; 6 = 600 ms;
7 = 800 ms ¢ enter number ¢ OK.

Changing pause after line seizure

­You can set the length of the pause inserted
between pressing the talk key
phone number.

MENU ¢ 4 I O 1 O ¢ The number for the current
pause length flashes: 1 = 1 sec.; 2 = 3 sec.; 3 = 7 sec.

: 0 = 80 ms; 1 = 100 ms; 2 = 120 ms;

c and sending the

¢ enter number ¢ OK.

Changing the pause after the recall key

MENU ¢ 4 I O 1 4 ¢ The number for the current

pause length flashes: 1 = 800 ms; 2 = 1600 ms;
3 = 3200 ms ¢ enter number ¢ OK.

With a repeater you can increase the range of your
base station. You will need to activate repeater
mode

(¢ p. 14). Repeater mode and Eco mode or

Eco mode+ (¢ p. 1) cancel each other out.

11

1)

Appendix

Entering letters/characters

Press the relevant key the number of times indi­cated.
Briefly press the hash key # to switch from
"Abc" to "123" mode, from "123" to "abc"mode and
from "abc" to "Abc" mode.

Standard characters

1x 2x 3x 4x 5x 6x 7x 8x 9x 10x 11x 12x13x 14x

1 £ $ ¥ ¤

1

a b c 2 ä á à â ã ç

2

d e f 3 ë é è ê

I

g h i 4 ï í ì î

4

j k l 5

5

m n o 6 ö ñ ó ò ô õ

L

p q r s 7 ß

M

t u v 8 ü ú ù û

N

w x y z 9 ÿ ý æ ø å

O

. , ? ! 0 + - : ¿ ¡ " ’ ; _

Q

* / ( ) < = > %

P

Abc

123

-->

-->

# @ \ & §

#

1) Space

Specifications

Recommended batteries

Technology: Nickel-metal-hydride (NiMH)
Size: AAA (Micro, HR03)
Voltage: 1.2 V
Capacity: 400–800 mAh

We recommend the following types of battery:

◆ GP 550/700 mAh

◆ Yuasa Phone 700/800 mAh

◆ Peacebay 550/650 mAh

(Valid at the time of going to press)
The handset is supplied with recommended batter­ies.

Base station power consumption

In standby mode
– Handset in base station
– Handset outside base station

During a call approx. 1.5 W

General specifications

DECT standard is supported
GAP standard is supported
Range up to 300 m outdoors

Base station power supply 230 V ~/50 Hz
Environmental conditions

in

123

operation

abc

approx. 1.3 W
approx. 1.3 W

up to 50 m indoors

+5 °C to +45 °C, 20% to
75%

elative humidity

Questions and answers

If you have any queries about the use of your tele­phone, visit our website at
www.gigaset.com/customercare
for 24-hour support. The table below contains a lis t
of common problems and possible solutions.

Problem Cause Solution

Nothing
appears in
the

display.

No wireless
connection
to

the base

station,

Base

flashes

in the display.

You cannot
hear a ringer/
dialling tone
from the fixed
line network.

Error tone
sounds after
system PIN
prompt.

PIN forgotten.

The handset is not
switched on.

The batteries are
flat.

The handset is
outside the range
of the base sta
tion.
The handset is not
registered.
The base station is
not turned on.

The phone cord
supplied has not
been used or has
been replaced by
a new cord with
the wrong jack
connections.

The system PIN
you have entered
is incorrect.

Press the end call
key a for approx.

5

seconds or place

the handset in the
base station.
Charge or replace the
batteries.

Move the handset
closer to the base
station.

-

Register the handset

¢ p. 9.

Check the mains con­nector on the base
station

¢ p. 3.

Please always use the
phone cord supplied
or ensure that the
pin

connections are
correct when purchas
ing from a retailer:
3-4 assignment of
telephone leads/
EURO

CTR37.

Reset the system PIN
to the default 0000

¢ p. 10.

All handsets are
de-registered. All
settings are reset.
All lists are deleted.

Authorisation

This device is intended for analogue phone lines in
your network.

Country-specific requirements have been taken
into consideration.

We, Gigaset Communications GmbH, declare that
this device meets the essential requirements and
other relevant regulations laid down in Directive
1999/5/EC.
A copy of the 1999/5/EC Declaration of Conformity
is available at this Internet address:
www.gigaset.com/docs.

-

12

Abu Dhabi. . . . . . . . . . . . .97 12 62 23 800

Argentina . . . . . . . . . . . . . 0800-888-9878

Australia . . . . . . . . . . . . . . . .1300 665 366

Austria .05 17 07 50 04 (0,065 Euro/Min.)

Bahrain . . . . . . . . . . . . . . . 97 31 73 11 173

Belgium . . . . . . . . . . . . . . . . 0 78 15 66 79

Bosnia Herzegovina . . . . . . . . 033 276 649

Brazil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Grande Capitais e Regiões Metropolitanas:

. . . . . . . . . . . . . . . . . . . . . . . . . 4003 3020

. . . . . . . . . . . . . . . . . .R$ 0,14 (US$ 0,069)

Demais localidades: . . . . . 0800 888 3020

. . . . . . . . . . . . . . . . . .R$ 0,20 (US$ 0,098)

Bulgaria. . . . . . . . . . . . . . . . . 02 873 94 88

Canada . . . . . . . . . . . . . . . . .866 247 8758

China . . . . 0 21 400 670 6007 (RMB 0.11)

Croatia . . . . . . . . 016 10 53 81 (0,23 Kun)

Czech Republic . . . . . . . . . . . . 233 032 727

Denmark . . . . . . . . . . . . . . . . . 35 25 86 00

Dubai . . . . . . . . . . . . . . . . 97 14 39 69 944

Egypt. . . . . . . . . . . . . . . . . . . 202 7623441

Finland . . . . . . . . . . . . . . . . 09 23 11 34 25

France. . . 01 56 38 42 00 (Appel national)

Germany. . . . . . . . . . . . . . .01805 333 222

(0,14 Euro/Min. aus dem Festnetz der Deut­schen Telekom. Für Anrufe aus den Mobil­funknetzen können abweichende Preise
gelten)

Greece . . . . . . 801 1000 500 (0,026 Euro)

Hungary . . . . . . . . . 06 14 71 24 44 (27 Ft)

India . . . . . . . . . . . . . . .Please refer to your

. . . . . . . . . . . . . . . . . . .local warranty card

Ireland . . . . . . . . . . . . . . . .18 50 77 72 77

Israel . . . . . . . . . . . . . . . . . . 1 700 700 727

Italy. . . . . . . . . . . . . . . . . . . . 199.15.11.15

Jordan . . . . . . . . . . .00962 6 5625460/1/2

Kuwait . . . . . . . . . . . . . . . 00965-2464993

Latvia . . . . . . . . . . . . . . . . . . . . . 7 50 11 18

Lebanon. . . . . . . . . . . . . . 00961-1236110

Luxembourg . . . . . . . . . . . 40 66 61 56 40

Malaysia. . . . . . . . . . . . . . . .603 77124304

Malta . . . . . . . . . . . . . . [phone]

Mexico . . . . . . . . . . . . . .01 80 07 11 00 03

Netherlands

. . . . . . . . .0900-3333102 (0,25 Euro/min.)

New Zealand . . . . . . . . . . . 08 00 27 43 63

Norway . . . . . . . . . . . . . . . . . . 22 70 84 00

Oman. . . . . . . . . . . . . . . . 96 82 47 09 281

Poland . . . . . . . . . . . . . . . . .0 801 140 160

Portugal. . . . . . . . . . . . (351) 808 781 223

Romania . . . . . . . . . . . . +4.021.529.7114.

Russia. . . . . . . . . . . . . . . 8 [phone]

Serbia. . . . . . . . . . . . . . . . . . 0800 222 111

Singapore . . . . . . . . . . . . . . . . 62 27 11 18

Slovak Republic

. . . . . . . . . . . . . 02 59 68 22 66 (4,428 sk)

Slovenija . . . . . . . . . . . . . . . 0 14 74 63 36

South Africa. . . . . . . . . . . . 08 60 10 11 57

Spain . . . . . . . . . . . . . . . . . . . . 902 103935

Sweden . . . . . . . . . . . . . . . . . 08 750 99 11

Switzerland

. . . . . . . . . . 0848 212 000 (0,08 SFr./Min.)

Taiwan. . . . . . . . . . . . . . . . 02 23 96 10 06

Thailand. . . . . . . . . . . . . . . . . 02 722 1118

Turkey . . . . . . . . . . . . . . . .0216 459 98 59

Ukraine . . . . . . . . . . . .+380-44-451-71-72

United Arab Emirates . . . . . 0 43 66 03 86

United Kingdom . . . . . . .0 84 53 67 08 12

USA . . . . . . . . . . . . . . . . . 1-866 247-8758

. . . . . . . . . . . . . . . . . . . . . . . . . . . (toll free)

Service (Customer Care)

You can get assistance easily when you have technical questions or questions about how to use your device
by using our online support service on the Internet at:

www.gigaset.com/customercare
This site can be accessed at any time wherever you are. It will give you 24/7 support for all our products. It

also a list of FAQs and answers plus user guides for you to download. You will also find frequently asked
questions and answers in the Questions and Answers section of this user guide in the appendix.

If the device needs to be repaired, please contact one of our Customer Care Centers:

Please have your record of purchase ready when calling.
Replacement or repair services are not offered in countries where our product is not sold by

authorised dealers.

Menu tree

13

Your phone has an extensive range of features.
These are offered in the form of menus.
To select a function while the phone is in idle sta-
tus, press MENU (open menu), use the t and

v keys to scroll to the function you require and

press

OK to confirm.

As an alternative to selecting functions using the

t and v buttons, you can also enter the digit

combination that is in front of the function in the
menu tree.
For setting the time and date, for example:

MENU ¢ 4 1 ¢ OK

To return to idle status: press and hold the

a key.

1 Alarm Clock

1-1 Activation Activating/deactivating the alarm clock

1-2 Wake-up time Input format: HHMM

2 Audio Settings

2-1 Handset Volume Can be set to one of 3 levels

2-2 Ringer Volume 5 levels + "crescendo" available

2-3 Ringer Melody 2-3-1 External Calls 10 ringer tones available for external calls

2-3-2 Internal Calls 10 ringer tones available for internal calls

2-3-3 Alarm Clock 10 ringer tones available for alarm clock

2-4 Advis. Tones During a conversation

2-5 Battery Low 2-5-1 Off Warning tone to indicate

2-5-2 On always

2-5-3 During Call only during a call

3 Voice Mail

3-1 Set Key 1

(all devices)

3-1-1 Netw. Mailbx Assign key 1 with network mailbox and enter the network mailbox

battery is almost flat:

number (in idle status, press and hold key
Netw. Mailbx: your network provider's answer machine; must be
requested separately. The network mailbox list can be displayed if
your network provider supports this function and if key
assigned with the network mailbox.

never

1 to dial).

1 has been

14

4 Settings

4-1 Date/Time Enter date (DDMMYY format), then time (HHMM format)
4-2 Handset 4-2-1 Language Set the display language ¢ p. 10

4-2-2 Auto Answer Automatically activate/deactivate auto answer ¢ p. 7
4-2-3 Register HS Manually register the handset ¢ p. 9
4-2-4 Reset Handset Reset the handset ¢ p. 10

4-3 Base 4-3-2 Call list type 4-3-2-1 Missed Calls ¢ p. 8

4-3-2-2 All Calls ¢ p. 8

4-3-3 System PIN Change system PIN (default is 0000)
4-3-4 Base Reset Restore factory settings ¢ p. 10
4-3-5 Additional 4-3-5-1 Repeater Activating/deactivating ¢ p. 10

4-3-5-2 Eco Mode+ Activating/deactivating ¢ p. 2
4-3-5-3 Eco Mode Activating/deactivating ¢ p. 2

4-3-6 Listening in Activate/deactivate the function ¢ p. 9

4-3-7 Preselection 4-3-7-1 Presel. Number Network provider dialling code,

4-3-7-2 With Preselect First digits of the dialling codes,

4-3-7-3 Without Presel First digits of dialling codes, should

should be inserted automatically
before the dialled phone number.

should be dialled with preselection.

be dialled without preselection.

15

16

Issued by
Gigaset Communications GmbH
Schlavenhorst 66
D-46395 Bocholt
Gigaset Communications GmbH is a trademark
licensee of Siemens AG

© Gigaset Communications GmbH 2008
All rights reserved. Subject to availability.
Rights of modification reserved.
www.gigaset.com

A31008- M2003- R201- 1- 9W19

This user guide is made from 100% recycled paper.

Version: 30.10.2008
