Gigabyte GA-BX2000 User Manual

BX2000+

USER'S MANUAL

1. Support Suspend To RAM Function.

2. CPU Over Voltage Select (Magic Booster).

3. Support Dual BIOS and BIOS Write Protection.

4. System power on by PS/2 Mouse: First, enable this function in CMOS Setup, then you can power on the system by double clicking the right or left button of your PS/2 Mouse.

5. System power on by Keyboard: If your ATX power supply supports 300 mA 5V Stand-By current (depends on the specification of keyboards) , you can power on your system by entering password from the keyboard after setting the “Keyboard power on” password in CMOS Setup.

6. Supports 3 steps ACPI LED.

7. Modem Ring-On (COM A , B).

8. Wake-Up on LAN (The ATX power supply supports larger than 720 mA 5V Stand-By current).

Pentium II / III / Celeron Processor MAINBOARD

REV. 1.2 Second Edition

R-12-02-091220

BX2000+

The author assumes no responsibility for any errors or omissions which may appear in this document nor does it make a commitment to update the information contained herein.

Third-party brands and names are the property of their respective owners.

Sound Blaster is a registered trademark of Creative Technology Ltd in the United States and certain other countries. Sound Blaster-LINK and SB-LINK are trademarks of Creative Technology Ltd.

Dec. 20, 1999 Taipei, Taiwan

Quick Installation Guide

I. Quick Installation Guide : CPU SPEED SETUP

The system bus speed is selectable between 66 / 100 MHz. The user can select the system bus speed and change the DIP SWITCH the CPU speed for 233 - 800MHz processor.

Pentium II / III

CPU 233 / 66MHz 266 / 66MHz 300 / 66MHz OFF ON OFF ON ON OFF OFF ON 333 / 66MHz 366 / 66MHz 400 / 66MHz 433 / 66MHz 466 / 66MHz 500 / 66MHz 533 / 66MHz

* 566 / 66MHz OFF ON

350 / 100MHz 400 / 100MHz 450 / 100MHz 500 / 100MHz 550 / 100MHz 600 / 100MHz 650 / 100MHz 700 / 100MHz 750 / 100MHz 800 / 100MHz

850 / 100MHz OFF ON OFF OFF OFF OFF OFF OFF

1 2 3 4 5 6 7 8

OFF OFF ON ON ON OFF OFF ON

ON ON OFF ON ON OFF OFF ON

ON OFF OFF ON ON OFF OFF ON

OFF OFF OFF ON ON OFF OFF ON

ON ON ON OFF ON OFF OFF ON

OFF ON ON OFF ON OFF OFF ON

ON OFF ON OFF ON OFF OFF ON

OFF OFF ON OFF ON OFF OFF ON

ON ON OFF OFF ON OFF OFF ON

OFF OFF ON OFF OFF ON

OFF OFF ON ON OFF OFF OFF OFF

ON ON OFF ON OFF OFF OFF OFF

OFF ON OFF ON OFF OFF OFF OFF

ON OFF OFF ON OFF OFF OFF OFF

OFF OFF OFF ON OFF OFF OFF OFF

ON ON ON OFF OFF OFF OFF OFF

OFF ON ON OFF OFF OFF OFF OFF

ON OFF ON OFF OFF OFF OFF OFF

OFF OFF ON OFF OFF OFF OFF OFF

ON ON OFF OFF OFF OFF OFF OFF

(SW)

selection to set up

We don’t recommend you to setup your CPU ratio above 8 nth, it

doesn’t support now.

BX2000+

Main Clock Table CLK 5 6 7 8 66 MHz 152 MHz 142MHz 100 MHz OFF OFF OFF OFF

112MHz OFF OFF ON OFF 124 MHz OFF ON ON OFF 133 MHz OFF ON OFF OFF PCI Run 44.3 MHz 133 MHz ON ON ON OFF PCI Run 33.3 MHz

Note: We don’t recommend you to setup your system speed to 152,

ON OFF OFF ON ON OFF ON OFF ON ON OFF OFF

142, 112, 124 or 133MHz because these frequencies are not the

standard specifications for CPU, Chipset and most of the

peripherals. Whether your system can run under 152, 142, 112, 124

or 133MHz properly will depend on your hardware configurations:

CPU, SDRAM, Cards, etc.

Frequency Table:

FREQ. RATIO

X 3 ON OFF ON ON

DIP SWITCH (SW)

1 2 3 4

X 3.5 OFF OFF ON ON

X 4 ON ON OFF ON

X 4.5 OFF ON OFF ON

X 5 ON OFF OFF ON

X 5.5 OFF OFF OFF ON

X 6 ON ON ON OFF

X 6.5 OFF ON ON OFF

X 7 ON OFF ON OFF

X 7.5 OFF OFF ON OFF

X 8 ON ON OFF OFF

X 8.5 OFF ON OFF OFF

X 9 ON OFF OFF OFF

X 9.5 OFF OFF OFF OFF

We don’t recommend you to setup your CPU ratio above 8 nth, it

doesn’t support now.

Quick Installation Guide

BX2000+

OFF

1. Pentium II / Celeron 233 / 66 MHz FSB

Backup

BIOS

Main BIOS

440BX

CPU

Intel

PIIX4

OFF

PROMISE

2. Pentium II / Celeron 266 / 66 MHz FSB

8 7 6 5 4 3 2 1

3. Pentium II / Celeron 300 / 66 MHz FSB

8 7 6 5 4 3 2 1

4. Pentium II / Celeron 333 / 66 MHz FSB

8 7 6 5 4 3 2 1

5. Pentium II / Celeron 366 / 66MHz FSB

OFF

8 7 6 5 4 3 2 1

6. Pentium II / Celeron 400 / 66MHz FSB

8 7 6 5 4 3 2 1

7. Pentium II / Celeron 433 / 66MHz FSB

8 7 6 5 4 3 2 1

8. Pentium II / Celeron 466 / 66MHz FSB

8 7 6 5 4 3 2 1

9. Pentium II / Celeron 500 / 66MHz FSB

Quick Installation Guide

8 7 6 5 4 3 2 1

10. Pentium II / Celeron 533 / 66MHz FSB

8 7 6 5 4 3 2 1

BX2000+

OFF

11. Pentium II / Celeron 566 / 66MHz FSB (Reserve)

8 7 6 5 4 3 2 1

12. Pentium II 350 / 100 MHz FSB

8 7 6 5 4 3 2 1

13. Pentium II 400 / 100 MHz FSB

8 7 6 5 4 3 2 1

14. Pentium III 450 / 100 MHz FSB

8 7 6 5 4 3 2 1

15. Pentium III 500 / 100 MHz FSB

8 7 6 5 4 3 2 1

16. Pentium III 550 / 100 MHz FSB

8 7 6 5 4 3 2 1

17. Pentium III 600 / 100 MHz FSB

OFF

8 7 6 5 4 3 2 1

18. Pentium III 650 / 100 MHz FSB

8 7 6 5 4 3 2 1

19. Pentium III 700 / 100 MHz FSB

8 7 6 5 4 3 2 1

20. Pentium III 750 / 100 MHz FSB

8 7 6 5 4 3 2 1

21. Pentium III 800 / 100 MHz FSB

OFF

22. Pentium III 850 / 100 MHz FSB (Reserve)

8 7 6 5 4 3 2 1

Quick Installation Guide

8 7 6 5 4 3 2 1

« We don’t recommend you to setup your CPU ratio above 8 nth, it

doesn’t support now.

BX2000+

Internal Buzzer

BX2000+

II. Jumper setting :

SPK : External Speaker/ Internal Buzzer Connector

Default:

External Speak

Backup

BIOS

Main BIOS

PIN No. Function

1 VCC 2 VCC 3 Data

PIIX4

4 Data

PROMISE

CPU

Intel

440BX

RST : Reset Switch

Backup

BIOS

Main BIOS

PIN No. Function Open

Close Reset Hardware

PIIX4

Normal Operation

System

PROMISE

CPU

Intel

440BX

PW LED : Power LED Connector

BX2000+

− −

BX2000+

−

Main

Backup

BIOS

PIN No. Function

1 2

PIIX4

LED + LED − LED −

PROMISE

CPU

Intel

440BX

Quick Installation Guide

HD : IDE Hard Disk Active LED

Main

Backup

BIOS

PIN No. Function

LED +

PIIX4

LED −

PROMISE

CPU

Intel

440BX

BX2000+

IR : Infrared Connector (Optional)

Backup

BIOS

Main BIOS

PIN No. Function

IR data output 2 GND 3 IR data input 4 NC 5 VCC (+5V)

PIIX4

PROMISE

GN : Green Function Switch

PIN No. Function

Open Close Entering Green

Main

Backup

BIOS

Normal Operation

PIIX4

Mode

PROMISE

CPU

Intel

440BX

CPU

Intel

440BX

GD : Green LED

BX2000+

−

BX2000+

Backup

BIOS

Main BIOS

CPU

Intel

440BX

Quick Installation Guide

PIN No. Function

LED +

PIIX4

LED −

PROMISE

Soft Power: Soft Power Connector

PIN No. Function

Open Close Power On/Off

Main

Backup

BIOS

Normal Operation

PIIX4

PROMISE

CPU

Intel

440BX

BX2000+

ATX POWER: ATX Power Connector

Backup

BIOS

Main BIOS

Pin No. Function 3,5,7,13,1

GND 5-17 1,2,11 3.3V 4,6,19,20 VCC 10 +12V 12 -12V

PIIX4

18 -5V 8 Power Good

PROMISE

9 5V SB stand by+5V 14 PS-ON(Soft On/Off)

PS/2 Mouse / Keyboard Connector

Main

Backup

BIOS

PS/2 Mouse

PIIX4

PS/2 Keyboard

PS/2 Mouse/ Keyboard

Pin No. Function

PROMISE

1 Data 2 NC 3 GND 4 VCC(+5V) 5 Clock 6 NC

CPU

Intel

440BX

CPU

Intel

440BX

USB : USB Port

BX2000+

Backup

BIOS

PIIX4

Main BIOS

Quick Installation Guide

6 5

PIN No. Function

1 2 USB D0-

3 4 GND

USB V0

USB D0+

440BX

USB V1

CPU

Intel

6 USB D1-

PROMISE

7 USB D1+ 8 GND

1 2

CPU FAN : CPU Cooling Fan Power Connector

Backup

BIOS

Main BIOS

CPU

PIN No. Function

Intel

440BX

GND

2 +12V

PIIX4

PROMISE

3 SENSE

BX2000+

POWER FAN : Power Fan Connector

Backup

BIOS

Main BIOS

PIN No. Function

GND

2 +12V

PIIX4

3 SENSE

PROMISE

CPU

Intel

440BX

PANEL (SYSTEM) FAN : Panel (System) Fan Connector

Backup

BIOS

Main BIOS

CPU

Intel

440BX

PIN No. Function

PIIX4

GND

2 +12V 3 SENSE

PROMISE

IDE1: For Primary IDE Port

BX2000+

Backup

BIOS

Main BIOS

PIIX4

PROMISE

IDE2: For Secondary IDE Port

Backup

BIOS

Main BIOS

CPU

Intel

440BX

CPU

Intel

440BX

Quick Installation Guide

PIIX4

PROMISE

BX2000+

ULTRA66-1: For Ultra66 Primary IDE Port

Backup

BIOS

Main BIOS

Intel

440BX

PIIX4

PROMISE

ULTRA66-2: For Ultra66 Secondary IDE Port

Backup

BIOS

Main BIOS

Intel

440BX

CPU

PIIX4

PROMISE

JP4 :ATA66 Disable / Enable

BX2000+

ATA66 Enable

BX2000+

3 2 1

Main

Backup

BIOS

PIN No. Function

1-2

ATA66 Disable

2-3

PIIX4

(Default)

PROMISE

CPU

Intel

440BX

Quick Installation Guide

FLOPPY : Floppy Port

Backup

BIOS

Main BIOS

PIIX4

PROMISE

CPU

Intel

440BX

BX2000+

COM B

COM A

BX2000+

LPT PORT / COM A / COM B

Backup

BIOS

PIIX4

Main BIOS

PROMISE

CPU

LPT PORT

Intel

440BX

JP1 : PS/2 Keyboard Power On Selection

1 2 3

Main

Backup

BIOS

PIN No. Function

1-2

2-3

PIIX4

PS/2 Keyboard Power on Enabled

PS/2 Keyboard Power on Disabled (Default)

PROMISE

CPU

Intel

440BX

J15: System After AC Back

BX2000+

Backup

BIOS

Main BIOS

PIN No. Function

Open

Close Full On

Soft Off (Default)

PIIX4

PROMISE

CPU

Intel

440BX

Quick Installation Guide

JP7: Wake On LAN

Backup

BIOS

Main BIOS

1 2

PIIX4

PIN No. Function

+5V SB

2 GND

PROMISE

Signal

CPU

Intel

440BX

BX2000+

JP8:SB-LINK Creative PCI Sound Card Support (Optional)

Backup

BIOS

Main BIOS

CPU

Intel

440BX

Signal 2 GND 3 NC 4 Signal 5 GND

PIIX4

5 6

PIN No. Function

PROMISE

6 Signal

JP11 : System Acceleration

Backup

BIOS

Main BIOS

CPU

Intel

3 2 1

440BX

PIN No. Function

PIIX4

1-2 close 2-3 close For 100MHz Normal(Default)

For 100MHz Turbo and other

PROMISE

frequencies.

JP12 : Case Open

BX2000+

Backup

BIOS

PIIX4

Main BIOS

PIN No. Function

1 2 GND

PROMISE

Signal

CPU

Intel

440BX

Quick Installation Guide

JP14 : Clear CMOS Function

Backup

BIOS

Main BIOS

1 2 3

PIN No. Function

1-2 close 2-3 close Normal (Default)

Clear CMOS

PIIX4

PROMISE

CPU

Intel

440BX

BX2000+

JP17

AGP Card, please set jumper JP17

BX2000+

STR LED Connector

JP13 / JP17 : Close STR Enable

(If you want to use STR Function, please set jumper JP13 & JP17 Closed.)

If you use INTEL i740 Chipset

/JP13 “OPEN”, because i740 not support STR Function.

Backup

BIOS

PIIX4

Main BIOS

JP13

PIN No. Function

1 2 GND

PIN No. Function

PROMISE

1 2 GND

CPU

Signal

Intel

440BX

Signal

JP16 : STR LED Connector & DIMM LED

Backup

BIOS

Main BIOS

CPU

Intel

440BX

External.

PIIX4

DRAM LED

(Indicate)

PROMISE

J18: Ring Pwr On: Internal Modem Ring Power On

BX2000+

Close for Voodoo III

Backup

BIOS

PIIX4

Main BIOS

CPU

Intel

440BX

PIN No. Function

Signal

2 GND

PROMISE

Quick Installation Guide

JP20 & JP21 : Close for Voodoo

Backup

BIOS

Main BIOS

JP20 JP21

Open

PIN No. Function

PIIX4

Open Close

Normal (Default)

PROMISE

VGA Card

CPU

Intel

440BX

BX2000+

When you add/update new device

BX2000+

4 8

JP22 : BIOS Flash ROM Write Protection

Main

Backup

BIOS

JP22

Open

PIN No. Function Open

Normal(Default)

CPU

Intel

440BX

Close Write Protection

PIIX4

, set Jumper JP22 to “Open”, thi s need to be enable to update BIOS data.

PROMISE

T3 : FPUSB

Main

Backup

BIOS

Pin No. Definition

1 VCC 2 USB D0-

3 USB D0+ 4 GND 5 VCC

PIIX4

6 USB D17 USB D1+ 8 GND

PROMISE

CPU

Intel

440BX

Quick Installation Guide

BX2000+

Danger of explosion if battery is

JP3 : Over Voltage (Magic Booster) (When JP3 set “Open”, CPU Voltage is rising 10%)

Backup

BIOS

Main BIOS

CPU

Intel

440BX

JP3

BAT1:Battery

Open

PIIX4

Main

Backup

BIOS

incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.

PIN No. Function

PROMISE

Open Close Normal (Default)

Turbo

CPU

Intel

440BX

PIIX4

PROMISE

BX2000+

III. Top Performance Test Setting:

The following performance data list is the testing results of some popular benchmark testing programs.

Users have to modify the value for each item in chipset features as follow for top performance setting.

Quick Installation Guide

These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (Different Hardware & Software configuration will result in different benchmark testing results.)

CPU Pentium III 667MHz processor

•

DRAM (128x1) MB BUFFALO SEC KOREA 928

•

KM48S8030CT-GH)

CACHE SIZE 256 KB included in CPU

•

DISPLAY Gigabyte GA-660Plus (Driver 4.00.1381.0208,4.0.0)

•

STORAGE Onboard IDE (IBM DJNA-371350)

•

Promise Ultra Driver Driver Rev 1.44 (BIOS 0728)

•

O.S. Windows NT™ 4.0 SPK5

•

DRIVER Display Driver at 1024 x 768 x 16bit colors x 75Hz.

•

Processor

Winbench99

CPU mark99

FPU Winmark99

Business Disk Winmark99

Hi-End Disk Winmark99

Business Graphics Winmark99

Hi-End Graphics Winmark99

Winstone99

Business Winstone99

Hi-End Winstone99

Intel Pentium III 667MHz

667MHz ( 100 x 6.5 )

60.4

3490

5110

11600

306 608

40.5

35.7

Suspend To RAM Installation

IV. Suspend to RAM Installation A.1 Introduce STR function:

Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state. The “state” is stored in memory (RAM) before the system goes to sleep. During STR sleep mode, your system uses only enough energy to maintain critical information and system functions, primarily the system state and the ability to recognize various “wake up” triggers or signals, respectively.

A.2 STR function Installation

Please use the following steps to complete the STR function installation.

Step-By-Step Setup Step 1:

To utilize the STR function, the system must be in Windows 98 ACPI mode.

Putting Windows 98 into ACPI mode is fairly easy.

There are two ways to accomplish this:

1. Setup with Windows 98 CD:

A. Insert the Windows 98 CD into your CD-ROM drive, select Start, and

then Run.

B. Type (without quotes)

enter key or click OK.

(In Windows 98 second edition version, all the bios version dated 12/01/99 or later are ACPI compatible. Just type" D:\Setup", the operating system will be installed as ACPI mode).

C. After setup completes, remove the CD, and reboot your system (This manual assumes that your CD-ROM device drive letter is D:).

“D:\setup /p j”

in the window provided. Hit the

BX2000+

2. Update from Windows98 APM mode:

If your Windows 98 system is in APM mode, use the following steps to update your system to ACPI mode.

1. When Windows 98 finishes loading, open the “Control Panel” in Windows 98 “My Computer” area.

2. Double click the “System” item.

Suspend To RAM Installation

3. Select the “Device Manager” tab and then the “System Devices” item.

Double click the “Plug and Play BIOS” item or select “Properties”

4. Select the “Driver” item and “Update Driver”

BX2000+

5. The “Update Device Driver Wizard” will appear.

Press the “Next” button

6. In the “Update Device Driver Wizard” window, select the “Display a list of all the drivers in a specific location, so you can select the driver you want.” Then press the “Next” button “

Suspend To RAM Installation

7. Select the “Show all hardware” item → then select the “Advance Configuration and Power Interface (ACPI) BIOS” and press the “Next” button.

8. “Update Driver Warning” will show up and ask “Are you sure you want to use this driver?” Select the “Yes” button.

BX2000+

9. “Update Device Driver Wizard” will show up again. Select the “Next” button and start copying files to the system.

10. When complete, press the “Finish” button.

11. Restart your computer. Your system will start up using the ACPI mode.

Suspend To RAM Installation

BX2000+

JP17

AGP Card, please set jumper JP17

Step 2: To use STR Function, you will need to set motherboard jumpers JP13 & JP17 closed per the figure below (i.e., put a jumper over both pins at each location).

If you use INTEL i740 Chipset

/JP13 “OPEN”, because i740 not support STR Function.

Backup

BIOS

PIIX4

Main BIOS

JP13

PIN No. Function

1 2 GND

PIN No. Function

PROMISE

1 2 GND

CPU

Signal

Intel

440BX

Signal

Step 3:

Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup. Select the item

SETUP”,

then select

“ACPI Suspend Type: Suspend to RAM”

to save the settings by pressing "ESC" and choose the

SETUP”

option.

“POWER MANAGEMENT

. Remember

“SAVE & EXIT

Congratulation! You have completed the installation and now can use the STR function.

BX2000+

A.3 How to put your system into STR mode?

There are two ways to accomplish this:

1. Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down”

B. Choose the “Stand by” item and press “OK”

Suspend To RAM Installation

2. Define the system ”power on” button to initiate STR sleep mode:

A. Double click “My Computer” and then “Control Panel”

B. Double click the “ Power Management” item.

BX2000+

C. Select the “Advanced” tab and “Standby” mode in Power Buttons.

Step 4:

Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the

“Power on” button..

A.4 How to recover from the STR sleep mode?

There are six ways to “wake up” the system:

1. Press the “Power On” button

2. Use the “Keyboard Power On” function.

3. Use the “Mouse Power On” function

4. Use the “Resume by Alarm” function

5. Use the “Modem Ring On” function

6. Use the “Wake On LAN” function.

Suspend To RAM Installation

BX2000+

STR LED Connector

A.5 Notices & Limitations:

1. In order for STR to function properly, several hardware and software

requirements must be satisfied: A. Your ATX power supply must comply with the ATX 2.01 specification

(provide more than 720 mA 5V Stand-By current). B. Your SDRAM must be PC-100 compliant.

2. Jumper JP16 is provided to connect to the STR LED in your system chassis. [Your chassis may not provide this feature.] The STR LED will be illuminated when your system is in STR sleep mode.

Backup

BIOS

Main BIOS

PIIX4

DRAM LED

(Indicate)

PROMISE

CPU

Intel

440BX

External.

3. The following is a listing of popular peripherals which have been successfully tested, on an individual basis, to function correctly in an STR environment. NOTE: All combinations of these peripherals have NOT been tested and therefore we do not warrant any particular combination.

A. VGA Card:

(1) AGP: Winfast L2300 Driver Ver.: 7-1-1998 (2) AGP: ATi 3D RAGE Pro AGP 2X Driver Ver.: 535 (3) AGP: ATi RAGE TURBO AGP Driver Ver.: 535 (4) AGP: GA-600 Driver Ver.: win95.342

BX2000+

B. VGA +Sound Card:

(1) AGP: Winfast L2300 Driver Ver.: 7-1-998 Sound: Creative PCI64 Driver Ver.: 3-18-1998 (2) AGP: ATi 3D RAGE Pro x2 Driver Ver.: 535 Sound: Creative PCI64 Driver Ver.: 3-18-1998 (3) AGP: ATi RAGE TURBO AGP Driver Ver.:535 Sound: Creative PCI64 Driver Ver.: 3-18-1998 (4) AGP: GA-600 Driver Ver.: win95.342 Sound: Creative PCI64 Driver Ver.: 3-18-1998

C. VGA + LAN Card:

AGP Card: Winfast L2300 Driver Ver.: 7-1-1998 ATi 3D RAGE Pro AGP 2X Driver Ver.: 535 ATi RAGE TURBO AGP Driver Ver.: 535 GA-600 Driver Ver.: win95.342

LAN Card: Intel E100B(82557) Driver Ver.: WIn98 embedded Intel PILA8461(82558B) Driver Ver.: WIn98 embedded Intel PILA8465(82558) Driver Ver.: WIn98 embedded SMC9432TX Driver Ver.: WIn98 embedded SMC EtherPower Driver Ver.: WIn98 embedded D-Link DFE-500TX Driver Ver.: WIn98 embedded D-Link DE-530CT Driver Ver.: WIn98 embedded D-Link DE-220P Driver Ver.: WIn98 embedded 3COM 3C900 Driver Ver.: 10-29-1998 3COM 3C905B-TX Driver Ver.: 10-29-1998 3COM 3C905 Driver Ver.: 10-29-1998 Digital LM-P100TX Driver Ver.: WIn98 embedded Digital DE500-BA Driver Ver.: WIn98 embedded Adaptec ANA-6911/TX Driver Ver.: WIn98 embedded

Suspend To RAM Installation

D. VGA +Sound+LAN Card:

(1)AGP: Winfast L2300 Driver Ver.: 7-1-1998 Sound: Creative PCI64 Driver Ver.: 3-18-1998 LAN: Intel PILA8461(82558B) Driver Ver.: WIn98 embedded

(2) AGP: Winfast L2300 Driver Ver.: 7-1-1998 Sound: Creative PCI64 Driver Ver.: 3-18-1998 LAN: Intel PILA8465(82558) Driver Ver.: WIn98 embedded

(3)AGP: Winfast L2300 Driver Ver.: 7-1-1998 Sound: Creative PCI64 Driver Ver.: 3-18-1998 Lan: 3COM 3C905B-TX Driver Ver.: 10-29-1998

(4)AGP: ATi 3D RAGE Pro AGP 2X Driver Ver.: 535 Sound: Creative PCI64 Driver Ver.: 3-18-1998 LAN: Intel PILA8461(82558B) Driver Ver.: WIn98 embedded

(5) AGP: ATi 3D RAGE Pro AGP 2X Driver Ver.: 535 Sound: Creative PCI64 Driver Ver.: 3-18-1998 LAN: Intel PILA8465(82558) Driver Ver.: WIn98 embedded

(6)AGP: ATi 3D RAGE Pro AGP 2X Driver Ver.: 535 Sound: Creative PCI64 Driver Ver.: 3-18-1998 LAN: 3COM 3C905B-TX Driver Ver.: 10-29-1998

(7)AGP: ATi RAGE TURBO AGP Driver Ver.: 535 Sound: Creative PCI64 Driver Ver.: 3-18-1998 LAN: Intel PILA8461(82558B) Driver Ver.: WIn98 embedded

(8)AGP: ATi RAGE TURBO AGP Driver Ver.: 535 Sound: Creative PCI64 Driver Ver.: 3-18-1998 LAN: Intel PILA8465(82558) Driver Ver.: WIn98 embedded

(9)AGP: ATi RAGE TURBO AGP Driver Ver.: 535

Sound: Creative PCI64 Driver Ver.: 3-18-1998 LAN: 3COM 3C905B-TX Driver Ver.: 10-29-1998

BX2000+

E. SDRAM:

(1) SDRAM: Apacer (AM2V168A1T8) 32MB (2) SDRAM: Trandscend (MITSUBISHI M5M4V16S30BTP –10) 32MB (3) SDRAM: BUFFALO(NEC D4516821AG5-A10-75F) 32MB (4) SDRAM: HYUNDAI (HYUNDIA 7V75A400 DTFG-10P) 32MB (5) SDRAM: ATP (SEC KM48S2020CT-G8 ) 32MB (6) SDRAM: CRUCIAL (MICRON MT48LC2M8A-8) 32MB (7) SDRAM: BUFFALO (FUJITSU 81F16822D-102LFN M00) 32MB (8) SDRAM: UMAX (MITSUBISHI M5M4V16S30DTP –8) 32MB (9) SDRAM: UMAX (MITSUBISHI M5M4V16S30BTP –10) 32MB (10) SDRAM: ARMAS (NEC D4564841G5-A10) 64MB (11) SDRAM: SAMSUNG (SEC KM48S8030CT-GA) 64MB (12) SDRAM: BUFFALO (MICRON MT48LC2M8A1-8) 64MB (13) SDRAM: ADTEC (MITSUBISH M5M4V64S30ATP-8) 128MB

(14) SDRAM: (NEC D4564441G5-A10-9JF) 256MB F. Power Supply:

Vender Model Spec. (1). HIGH POWER HPC-250G1 REV:A0-01 (5VSB 1A)

(2). PC WINNER ST-235ATX (5VSB 1.5A) (3). Enhance ATX-725B (5VSB 1A) (4). Enhance ATX-723B (5VSB 1A) (5). Sseasanic SS-200FS (5VSB 1A) (6). SPI FSP-235-60GT (5VSB 0.8A ) (7). ETASIS EPR-2305 (5VSB 0.8A) (8). DVE DSP-ATX-230 (5VSB 0.75A)

4. Limitation List: a. Don’t get into STR mode right away when the system just resume

from STR mode, Please wait a few seconds to let the system

completely restore the last status’s data. b. SCSI HD devices are not supported for STR function for now on. c. If you use a ZIP of external connector type, please modify the item

“Parallel Port Mode” of “INTEGRATED PERIPHERALS” in your

BIOS setting to “ECP or ECP+EPP” mode.

Suspend To RAM Installation

d. If your PS/2 Mouse fails in “Mouse Power On” function, please

contact your vendor and update your Mouse Driver.

Introduce Dual BIOS

V. Introduce Dual BIOS

A. What is Dual BIOS Technology?

Dual BIOS means that there are two system BIOS (ROM) on the

motherboard, one is the Main BIOS and the other is Backup BIOS. Under the normal circumstances, the system works on the Main BIOS. If the Main BIOS is corrupted or damaged, the Backup BIOS can take over while the system is powered on. This means that your PC will still be able to run stably as if nothing has happened in your BIOS.

B. How to use Dual BIOS?

a. Boot Screen

Intel 440BX AGPSet BIOS for XXX Vx.x Check System Health ok , Vcore =2.00V Pentium III-MMX CPU at 600MHz <CPU ID:0652 Patch ID:0014> Memory Test :16384K OK

Award Plug and Play BIOS Extension Vx.x Copyright (C ) 1998, Award software, Inc.

Press F1 to enter Dual BIOS Utility

Press DEL to enter SETUP 03/29/1999-I440BX-8671-2A69KG0EC- 00

BX2000+

b. Dual BIOS Utility

Dual BIOS Utility V6.60.g.01K

Wide Range Protection :Disabled Halt On BIOS Defects :Disabled Auto Recovery :Enabled Boot From :Main BIOS

BIOS Recovery :Main to Backup

F3: Load Default F5:Start BIOS Recovery F7: Save And Restart F9:Exit Without Saving

Use <Space> key to toggle setup

c. Dual BIOS Item explanation:

Wide Range Protection: Disabled(Default), Enabled

Status 1:

If any failure (ex. Update ESCD failure, checksum error or reset…)

occurs in the Main BIOS , just before the Operating System is loaded and after the power is on, and that the Wide Range Protection is set to “Enable”, the PC will boot from Backup BIOS automatical ly.

Status 2:

If the ROM BIOS on peripherals cards(ex. SCSI Cards, LAN Cards,..)

emits signals to request restart of the system after the user make any alteration on it, the boot up BIOS will not be changed to the Backup BIOS.

Introduce Dual BIOS

Halt On BIOS Defects : Disabled(Default), Enabled

If the BIOS occurs a checksum error or the Main BIOS occurs a WIDE RANGE PROTECTION error and Halt On BIOS Defects set to Enable, the PC will show messages on the boot screen, and the system will pause and wait for the user’s instruction.

If Auto Recovery :

Disabled Enabled

, it will show

<or the other key to Auto

Recover.>

Auto Recovery : Enabled(Default), Disabled

When one of the Main BIOS or Backup BIOS occurs checksum failure,

the working BIOS will automatically recover the BIOS of checksum failure.

(In the Power Management Setup of the BIOS Setting, if ACPI Suspend Type is set to Suspend to RAM, the Auto Recovery will be set to Enable automatically.)

(If you want to enter the BIOS setting, please press

“Del”

key when the

boot screen appears.)

Boot From : Main BIOS(Default), Backup BIOS

Status 1:

The user can set to boot from main BIOS or Backup BIOS.

Status 2:

If one of the main BIOS or the Backup BIOS fails, this item

Main BIOS(Default)”

will become gray and will not be changed by user.

“Boot From :

BIOS Recovery : Main to Backup

Auto recovery message:

BIOS Recovery: Main to Backup

The means that the Main BIOS works normally and could automatically

recover the Backup BIOS.

BIOS Recovery: Backup to Main

The means that the Backup BIOS works normally and could automatically recover the Main BIOS.

(This auto recovery utility is set by system automatically and can’t be changed by user.)

BX2000+

DualBIOS

GIGABYTE Technology is pleased to introduce DualBIOS technology, a hot spare for your system BIOS. This newest “Value- added” feature, in a long series of innovations from GIGABYTE, is available on GA-BX2000+ motherboard. Future GIGABYTE motherboards will also incorporate this innovation.

Technology FAQ

What’s DualBIOSTM?

On GIGABYTE motherboards with DualBIOS there are physically two BIOS chips. For simplicity we’l l call one your “Main BIOS” and the other we’l l call your “Backup” BIOS (your “hot spare”). If your Main BIOS fails, the Backup BIOS almost automatically takes over on your next system boot. Almost automatically and with virtually zero down time! Whether the problem is a failure in flashing your BIOS or a virus or a catastrophic failure of the Main BIOS chip, the result is the same - the Backup BIOS backs you up, almost automatically.

Introduce Dual BIOS

I. Q: What is DualBIOSTM technology? Answer:

DualBIOS technology is a patented technology from Giga-Byte Technology. The concept of this technology is based on the redundancy and fault tolerance theory. DualBIOSTM technology simply means there are two system BIOSes (ROM) integrated onto the motherboard. One is a main BIOS, and the other is a backup BIOS. The mainboard will operate normally with the main BIOS, however, if the main BIOS is corrupt or damaged for various reasons, the backup BIOS will be automatically used when the system powered-On. Your PC will operate as before the main BIOS was damaged, and is completely transparent to the user.

II. Q: Why does anyone need a motherboard with DualBIOSTM technology? Answer:

In today’s systems there are more and more BIOS failures. The most common reasons are virus attacks, BIOS upgrade failures, and/or deterioration of the BIOS (ROM) chip itself.

1. New computer viruses are being found that attack and destroy the system BIOS. They may corrupt your BIOS code, causing your PC to be unstable or even not boot normally.

2. BIOS data will be corrupted if a power loss/surge occurs, or if a user resets the system, or if the power button is pressed during the process of performing a system BIOS upgrade.

3. If a user mistakenly updates their mainboard with the incorrect BIOS file, then the system may not be able to boot correctly. This may cause the PC system hang in operation or during boot.

4. A flash ROM's life cycle is limited according to electronic characteristics. The modern PC utilizes the Plug and Play BIOS, and is updated regularly. If a user changes peripherals often, there is a slight chance of damage to the flash ROM.

With Giga-Byte Technology’s patented DualBIOSTM technology you can reduce the possibility of hangs during system boot up, and/or loss BIOS data due to above reasons. This new technology will eliminate valuable system down time and costly repair bills cause by BIOS failures.

BX2000+

III. Q: How does DualBIOSTM technology work? Answer:

1. DualBIOSTM technology provides a wide range of protection during the boot

up procedure. It protects your BIOS during system POST, ESCD update, and even all the way to PNP detection/assignment.

2. DualBIOSTM provides automatic recovery for the BIOS. When the first BIOS

used during boot up does not complete or if a BIOS checksum error occurs, boot-up is still possible. In the DualBIOSTM utility, the "Auto Recovery" option will guarantee that if either the main BIOS or backup BIOS is corrupted, the DualBIOSTM technology will use the good BIOS and correct the wrong BIOS automatically.

3. DualBIOSTM provides manual recovery for the BIOS. DualBIOSTM

technology contains a built-in flash utility, which can flash your system BIOS from backup to main and/or visa versa. There is no need for an OS-dependent flash utility program.

4. DualBIOSTM contains a one-way flash utility. The built-in one-way flash

utility will ensure that the corrupt BIOS is not mistaken as the good BIOS during recovery and that the correct BIOS (main vs. backup) will be flashed. This will prevent the good BIOS from being flashed.

IV. Q: Who Needs DualBIOSTM technology? Answer:

1. Every user should have DualBIOSTM technology due to the advancement of

computer viruses. Everyday, there are new BIOS-type viruses discovered that will destroy your system BIOS. Most commercial products on the market do not have solutions to guard against this type of virus intrusion. The DualBIOSTM technology will provide a state-of-the-art solution to protect your PC: Case I.) Vicious computer viruses may wipe out your entire system BIOS. With a conventional single system BIOS PC, the PC will not be functional until it is sent for repairs. Case II.) If the "Auto Recovery" option is enabled in the DualBIOSTM utility, and if a virus corrupts your system BIOS, the backup BIOS will automatically reboot the system and correct the main BIOS. Case III.) A user may override booting from the main system BIOS. The DualBIOSTM utility may be entered to manually change the boot sequence to

boot from the backup BIOS.

Introduce Dual BIOS

BX2000+

2. During or after a BIOS upgrade, if DualBIOSTM detects that the main BIOS is corrupt, the backup BIOS will take over the boot-up process automatically. Moreover, it will verify the main and backup BIOS checksums when booting-up. DualBIOSTM technology examines the checksum of the main and backup BIOS while the system is powered on to guarantee your BIOS operates properly.

3. Power Users will have the advantage of having two BIOS versions on their mainboard. The benefit is being able to select either version BIOS to suit the performance system needs.

4. Flexibility for high-end desktop PCs and workstation/servers. In the DualBIOSTM utility, the option can be set, "Halt On When BIOS Defects," to be enabled to halt your system with a warning message that the main BIOS has been corrupted. Most workstation/servers require constant operation to guarantee services have not been interrupted. In this situation, the "Halt On When BIOS Defects" message may be disabled to avoid system pauses during normal booting. Another advantage you gain from Giga-Byte’s DualBIOSTM technology is the ability to upgrade from dual 2 Mbit BIOS to dual 4 Mbit BIOS in the future if extra BIOS storage is need.

BX2000+

TABLE OF CONTENTS

1. INTRODUCTION

1.1. PREFACE.......................................................................................................1-1

1.2. KEY FEATHERS............................................................................................1-1

1.3. PERFORMANCE LIST...................................................................................1-2

1.4. BLOCK DIAGRAM..........................................................................................1-3

1.5. INTRODUCE THE PENTIUM II / III PROCESSORS.................................1-4

1.6. WHAT IS AGP?..............................................................................................1-5

2. SPECIFICATION

2.1. HARDWARE ..................................................................................................2-1

2.2. SOFTWARE...................................................................................................2-2

2.3. ENVIRONMENT.............................................................................................2-2

3. HARDWARE INSTALLATION

3.1. UNPACKING..................................................................................................3-1

3.2. MAINBOARD LAYOUT..................................................................................3-2

3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS...........................3-2

3.4. DRAM INSTALLATION..................................................................................3-7

3.5. CPU SPEED SETUP......................................................................................3-7

3.6. CMOS RTC & ISA CFG CMOS RAM............................................................3-8

3.7. SPEAKER CONNECTOR INSTALLATION...................................................3-9

3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION.................3-9

3.9. POWER LED CONNECTOR INSTALLATION..............................................3-9

3.10. IDE & ATAPI DEVICE INSTALLATION.......................................................3-9

Table of Contents

3.11. PERIPHERAL DEVICE INSTALLATION.....................................................3-9

3.12. KEYBOARD & PS/2 MOUSE INSTALLATION............................................3-9

4. BIOS CONFIGURATION

4.1. ENTERING SETUP........................................................................................4-1

4.2. CONTROL KEYS ...........................................................................................4-1

4.3. GETTING HELP.............................................................................................4-2

4.3.1. Main Menu .....................................................................................4-2

4.3.2. Status Page Setup Menu / Option Page Setup Menu..........................4-2

4.4. THE MAIN MENU...........................................................................................4-2

4.5. STANDARD CMOS SETUP MENU...............................................................4-4

4.6. BIOS FEATURES SETUP .............................................................................4-8

4.7. CHIPSET FEATURES SETUP......................................................................4-13

4.8. POWER MANAGEMENT SETUP.................................................................4-17

4.9. PNP/PCI CONFIGURATION........................................................................4-22

4.10. LOAD BIOS DEFAULTS..............................................................................4-24

4.11. LOAD PERFORMANCE DEFAULTS ..........................................................4-25

4.12. INTEGRATED PERIPHERALS....................................................................4-26

4.13. SPUERVISOR PASSOWORD/USER PASSWORD ..................................4-31

4.14. IDE HDD AUTO DETECTION.....................................................................4-32

4.15. SAVE & EXIT SETUP ..................................................................................4-33

4.16. EXIT WITHOUT SAVING ............................................................................4-34

Appendix A: Ultra66 Driver Install Produce..................................................A-1

BX2000+

1. INTRODUCTION

1.1. PREFACE

Welcome to use the

BX2000+

motherboard. It is a Pentium II / III / Celeron Processor based PC / AT compatible system with AGP / PCI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want.

This manual also explains how to install the motherboard for operation, and how to set up your CMOS CONFIGURATION with BIOS SETUP program.

1.2. KEY FEATURES

Intel Pentium II / III / Celeron Processor based PC / AT compatible main

board.

Slot 1 supports Pentium II / III / Celeron processor running at 233-800

MHz.

Intel 440BX chipset, Supports AGP / SDRAM / Ultra DMA/33 IDE /

Keyboard and PS/2 Mouse Power On / ACPI features.

Supports 4xDIMMs using 3.3V SDRAM DIMM module.



Supports Intel LDCM

Supports 8 MB – 1GB SDRAM memory on board.

Supports ECC or Non-ECC type DRAM module.

1xAGP slot, 6xPCI Bus slots, 1xISA Bus slots.

Supports 2 channels Ultra DMA/33 IDE ports for 4 IDE Devices.

Promise Chipset supports 2 channels Ultra DMA66/33 IDE Port for 4 IDE

Device.

Supports 2xCOM (16550), 1xLPT (EPP / ECP), 1x Floppy port.

Supports 4xUSB ports (Front Panel USBx2, Back Panel USBx2), 1xPS/2

Mouse & 1xPS/2 Keyboard.

Licensed AWARD BIOS, 2M bits FLASH ROM.

Support

Support Suspend To RAM Function.

Support

Dual BIOS

CPU Over Voltage Select (Magic Booster

Network Manageability.

BIOS Write Protection

and

1-1

30.5 cm x 19.5 cm ATX SIZE form factor, 4 layers PCB.

Introduction

1-2

BX2000+

1.3. PERFORMANCE LIST

The following performance data list is the testing results of some popular benchmark testing programs.

CPU Pentium III 667MHz processor

•

DRAM (128x1) MB BUFFALO SEC KOREA 928

•

KM48S8030CT-GH)

CACHE SIZE 256 KB included in CPU

•

DISPLAY Gigabyte GA-660Plus (Driver 4.00.1381.0208,4.0.0)

•

STORAGE Onboard IDE (IBM DJNA-371350)

•

Promise Ultra Driver Driver Rev 1.44 (BIOS 0728)

•

O.S. Windows NT™ 4.0 SPK5

•

DRIVER Display Driver at 1024 x 768 x 16bit colors x 75Hz.

•

Processor

Winbench99

CPU mark99

FPU Winmark99

Business Disk Winmark99

Hi-End Disk Winmark99

Business Graphics Winmark99

Hi-End Graphics Winmark99

Winstone99

Business Winstone99

Hi-End Winstone99

Intel Pentium III 667MHz

667MHz ( 100 x 6.5 )

60.4 3490 5110

11600

306 608

40.5

35.7

1-3

1.4. BLOCK DIAGRAM

Bus

Introduction

AGP

Ultra DMA/33

IDE Ports

AGP Bus

66MHz

IDE Bus

Promise

SLOT 1

Host Bus

INTEL

82443BX

CHIPSET

PCI Bus

PIIX4

82371EB

CHIPSET

100 MHz

33MHz

66 /

100 MHz

33 MHz

33 MHz 48 MHz

14.318MHz

USB Bus

14.318MHz

66 /

100 MHz

ICS 9248-63 /

9279-01

FPUSB

3.3V SDRAM

DIMM Sockets

33 MHz 24MHz

BPUSB

COM Ports

Ultra DMA66/33

IDE Ports

ISA

1-4

I/O

CHIPSET

ITE 8671

LPT Port

Floppy Port

Keyboard

PS/2 Mouse

BX2000+

1.5. INTRODUCE THE Pentium II / III Processors

Figure 1: Universal Retention Mechanism & attach Mount

Figure 2:OEM Pentium II Processor

1-5

Introduction

Figure 3: OEM Pentium III Processor

1.6 What is AGP?

The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory.

The AGP port can be used either as fast PCI port (32-bits at 66MHz vs.32-Bits at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and side band addressing. When the 2x-data rate is used the port can transmit data at 533MB/sec (66.6*2*4). The read-queue can be used to pipeline reads – removing the effects of the reads-latency. Side band addressing can be used to transmit the data address on a separate line in order to speed up the transaction.

1-6

2. SPECIFICATION

2.1. HARDWARE

CPU

•

PROTECTION

•

SPEED

•

DRAM MEMORY

•

CACHE MEMORY

•

I/O BUS SLOTS

•

−

Pentium II/III/Celeron processor 233 – 800 MHz.

−

242 pins 66 / 100MHz slot1 on board.

−

Supports

(

−

Speaker Alarm when detect "CPU FAN Failure" or

−

Automatically slow down CPU speed when "CPU

−

Intel LDCM supported.

−

H/W monitor power status (±5V, ±12V, VGTL,5VSB,

CPU voltage & CMOS battery voltage).(Optional)

−

66/100 MHz system speed.

−

66 MHz AGP bus speed. (2X mode 133MHz)

−

33 MHz PCI-Bus speed.

−

8 MHz AT bus speed.

−

4 banks 168 pins DIMM module sockets on board.

−

Use 8 / 16 / 32 / 64 / 128 / 256 MB DIMM module

−

8 ~ 1GB SDRAM.

−

Supports 3.3V SDRAM.

−

Supports ECC or Non-ECC type DRAM.

−

Supports

−

32 KB L1 cache memory included in CPU.

−

L2 cache memory included in CPU

−

Supports DIB speed mode for L2 Cache.

−

6 33MHz Master / Slave PCI-BUS.

−

1 8MHz 16 bits ISA BUS.

−

1 66MHz / 133MHz AGP bus.

CPU Over Voltage Select

Magic Booster

“CPU Overheat”.

Overheat".

DRAM.

Suspend To RAM

(depends on CPU type)

Specification

Function.

2-1

BX2000+

IDE PORTS

•

I/O PORTS

•

GREEN FUNCTION

•

BIOS

•

DIMENSION

•

2.2. SOFTWARE

•

DRIVER

•

BIOS

•

O.S.

−

2 Ultra DMA/33 Bus Master IDE channels onboard.

(Using IRQ14,15)

−

Support Mode 3,4 IDE & ATAPI CD – ROM.

−

Promise Chipset supports 2 Channels Ultra

DMA66/33 IDE Port for 4 IDE device.

−

Supports 2 16550 COM ports.

−

Supports 1 SPP/EPP/ECP LPT port.

−

Supports 1 Floppy port.

−

Supports 4 USB ports.

−

Supports PS/2 Mouse & PS/2 Keyboard.

−

Suspend mode support.

−

Green switch & ACPI LED support.

−

IDE & Display power down support.

−

Monitor all IRQ / DMA / Display / I/O events.

−

2M bits FLASH ROM.

−

Support

−

Supports Plug & Play, DMI , ACPI Function.

−

ATX Form Factor, 4 layers PCB.

−

IUCD.

−

Licensed AWARD BIOS.

−

AT CMOS Setup, BIOS / Chipset Setup, Green

Setup, Hard Disk Utility included.

−

Operation with MS-DOS, Windows95,

Dual BIOS

BIOS Write Protection

and

Windows98, WINDOWS NT™, OS/2, NOVELL and SCO UNIX.

2.3. ENVIRONMENT

•

Ambient Temp.

• Relative Hum.

•

Altitude

•

Vibration

•

Electricity

−

0°C to +50°C (Operating). 0 to +85% (Operating). 0 to 10,000 feet (Operating). 0 to 1,000 Hz.

4.9 V to 5.2 V. (Max. 20A current at 5V.)

2-2

Hardware Installation

3. HARDWARE INSTALLATION

3.1. UNPACKING

The main board package should contain the following:

BX2000+

• The

•

The Universal Retention Mechanism & Attach Mount

•

USER’S MANUAL for main board.

• Cable set for DMA66/33 device, Floppy device.

•

CD for main board Utility.

The main board contains sensitive electric components, which can be easily damaged by static electricity, so the main board should be left in its original packing until it is installed.

Unpacking and installation should be done on a grounded anti-static mat. The operator should be wearing an anti static wristband, grounded at the same point as the anti-static mat.

main board.

Inspect the main board carton for obvious damage. Shipping and handling may cause damage to your board. Be sure there are no shipping and handling damages on the board before proceeding.

After opening the main board carton, extract the system board and place it only on a grounded anti-static surface component side up. Again inspect the board for damage. Press down on all of the socket IC's to make sure that they are properly seated. Do this only on with the board placed on a firm flat surface.

DO NOT APPLY POWER TO THE BOARD IF IT HAS BEEN DAMAGED.

3-1

BX2000+

ATX PWR

AGP

PCI 1

PCI 2

PCI 3

PCI 4

PCI 5

PCI 6

ISA 1

3.2. MAINBOARD LAYOUT

Backup

BIOS

JP8

System

BAT

(Panel)

FAN

BZ1

J15

JP14

JP22

JP12

Main

BIOS

JP7

JP18

PIIX4

PROMISE

JP9

Figure 3.1Ø

JP11

Bank 3 Bank 2 Bank 1 Bank 0

JP4

COMA

JP17

IDE2 IDE1

Ultra66-2

COMB

LPT

CPU

Intel

440BX

JP1

JP3

Power FAN

LED1

3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS

I/O Ports Connector

USB USB port.

PS/2 For PS/2 Keyboard / Mouse port. IDE 1 For Primary IDE port. IDE 2 For Secondary IDE port.

Ultra66-1 For Ultra DMA66 Primary IDE port. Ultra66-2 For Ultra DMA66 Secondary IDE port.

Floppy For Floppy port COM B For Serial port2 (COM B).[Support External Modem Ring On] COM A For Serial port1 (COM A).[Support External Modem Ring On]

LPT For LPT port. ATX

POWER

Slot 1

For Pentium

CPU FAN : CPU Cooling FAN Power Connector

For ATX Power Connector.



II / III / Celeron Processor installed

Pin No. Function

1 GND. 2 +12V

Floppy

Ultra66-1

USB

JP20 JP21

CPU FAN

JP16

PS/2

JP13

3-2

Hardware Installation

3 SENSE

POWER FAN : POWER FAN Power Connector

Pin No. Function

1 GND. 2 +12V 3 SENSE

PANEL(SYSTEM) FAN: PANEL(SYSTEM) FAN Power Connector

Pin No. Function

1 GND. 2 +12V 3 SENSE

J15 : System After Ac Back

Pin No. Function

Open Soft Off (Default)

Close Full On

JP1 : PS/2 Keyboard Power On Selection

Pin No. Function 1-2 close PS/2 Enabled Keyboard power on. 2-3 close PS/2 Disabled Keyboard power on.(Default)

JP11 : System Acceleration 1-2 close For 100MHz Turbo and other frequencies 2-3 close For 100MHz Normal (Default)

JP7 : Wake on LAN Connector

Pin No. Function

1 +5VSB 2 GND 3 CTRL-Signal

JP12 : Case Open

Pin No. Function

1 Signal 2 GND

3-3

BX2000+

JP18 SB-LINK : For PCI Sound Card Connector (Optional)

Pin No. Function

1 Signal 2 GND 3 NC 4 Signal 5 GND 6 Signal

JP9 IR: INFRARED Connector (Optional)

Pin No. Function

1 IR DATA OUTPUT 2 GND 3 IR DATA INPUT 4 NC 5 VCC (+5V)

JP14 : CLEAR CMOS

Pin No. Function 1-2 close Clear CMOS 2-3 close Normal (Default)

JP13 / JP17 :Close STR Enable

Pin No. Function

1 Signal 2 GND

JP8 Ring Pwr On : Internal Modem Ring Power On.

Pin No. Function

1 Signal 2 GND

JP20 & JP21 : Close for Voodoo

Pin No. Function

Open Normal (Default)

Close Close for Voodoo III VGA Card.

JP3 : Over Voltage (Magic Booster)

Pin No. Function

3-4

Open Turbo.

Close Normal (Default)

JP4 : ATA66 Disable / Enable

Pin No. Function 1-2 close Disabled 2-3 close Enabled (Default)

JP22 : BIOS Flash ROM Write Protection

Pin No. Function

Open Normal (Default)

Close Write Protection

T3 : FPUSB

Pin No. Function

1 VCC 2 USB D03 USB D0+ 4 GND 5 VCC 6 USB D17 USB D1+ 8 GND

T4 : 2*11PIN Jumper

G−

1 G+

P+P−P

SPKR

−

H+

H−

Hardware Installation

PW : Soft Power Connector

Open: Normal Operation

Short: Power On/Off

RE : Reset Switch

3-5

BX2000+

Open: Normal Operation

Short: For Hardware Reset System

3-6

P+P−P−: Power LED

−

PIN 1 : LED anode (+)

PIN 2 : LED cathode (−) PIN 3 : LED cathode (−)

SPKR : External Speaker Connector

PIN 1 : VCC (+)

PIN 2 : VCC PIN 3 : Data

PIN 4 : Data (−)

H+H−: IDE Hard Disk Active LED

PIN 1: LED anode (+)

PIN 2: LED cathode (−)

GN: Green Function Switch

Open : Normal operation

Short : Entering Green Mode

G−G+: Green LED

PIN 1 : LED anode (+)

PIN 2 : LED cathode (−)

Hardware Installation

3-7

BX2000+

3.4. DRAM INSTALLATION

The main board can be installed with 8 / 16 / 32 / 64 / 128 / 256 MB 168 pins DIMM module DRAM, and the DRAM speed must be 67~100 MHz for SDRAM when system bus speed is set to 66MHz. When system bus speed is set to 100MHz, 100MHz SDRAM is required. The DRAM memory system on main board consists of bank 0, 1, 2 & bank 3.

Since 168 pins DIMM module is 64 bits width, therefore 1 piece of DIMM module may match a 64 bits system. The total memory size is 8 MB ~1GB SDRAM. The DRAM installation position refer to Figure 3.1, and notice the Pin 1 of DIMM module must match with the Pin 1 of DIMM socket. Insert the DRAM DIMM module into the DIMM socket at Vertical angle. If there is a wrong direction of Pin 1, the DRAM DIMM module could not be inserted into socket completely.

3.5. CPU SPEED SETUP

The system bus speed can be set to 66 / 100MHz form the DIP SWITCH (SW). The user can change the DIP SWITCH selection to set up the CPU speed for different processors.

Pentium II / III

CPU 233 / 66MHz 266 / 66MHz 300 / 66MHz 333 / 66MHz 366 / 66MHz 400 / 66MHz 433 / 66MHz 466 / 66MHz 500 / 66MHz 533 / 66MHz

* 566 / 66MHz

350 / 100MHz 400 / 100MHz 450 / 100MHz OFF ON OFF ON OFF OFF OFF OFF 500 / 100MHz 550 / 100MHz

1 2 3 4 5 6 7 8

OFF OFF ON ON ON OFF OFF ON

ON ON OFF ON ON OFF OFF ON

OFF ON OFF ON ON OFF OFF ON

ON OFF OFF ON ON OFF OFF ON

OFF OFF OFF ON ON OFF OFF ON

ON ON ON OFF ON OFF OFF ON

OFF ON ON OFF ON OFF OFF ON

ON OFF ON OFF ON OFF OFF ON

OFF OFF ON OFF ON OFF OFF ON

ON ON OFF OFF ON OFF OFF ON

OFF ON OFF OFF ON OFF OFF ON OFF OFF ON ON OFF OFF OFF OFF

ON ON OFF ON OFF OFF OFF OFF

ON OFF OFF ON OFF OFF OFF OFF

OFF OFF OFF ON OFF OFF OFF OFF

3-8

Hardware Installation

600 / 100MHz 650 / 100MHz 700 / 100MHz 750 / 100MHz 800 / 100MHz

* 850 / 100MHz

We don’t rec ommend you to setup your CPU ratio above 8 nth, it

ON ON ON OFF OFF OFF OFF OFF

OFF ON ON OFF OFF OFF OFF OFF

ON OFF ON OFF OFF OFF OFF OFF

OFF OFF ON OFF OFF OFF OFF OFF

ON ON OFF OFF OFF OFF OFF OFF

OFF ON OFF OFF OFF OFF OFF OFF

doesn’t support now.

Main Clock Table CLK 5 6 7 8 66 MHz 152 MHz

142MHz 100 MHz 112MHz OFF OFF ON OFF 124 MHz OFF ON ON OFF 133 MHz OFF ON OFF OFF PCI Run 44.3 MHz 133 MHz ON ON ON OFF PCI Run 33.3 MHz

The CPU is a sensitive electric component and it can be easily

ON OFF OFF ON ON OFF ON OFF ON ON OFF OFF

OFF OFF OFF OFF

damaged by static electricity, so users must keep it away from metal surface when the CPU is installed onto main board.

3.6. CMOS RTC & ISA CFG CMOS RAM

There're RTC & CMOS RAM on board; they have a power supply from external battery to keep the DATA inviolate & effective. The RTC is a REAL-TIME CLOCK device, which provides the DATE & TIME to system. The CMOS RAM is used for keeping the information of system configuration, so the system can automatically boot OS every time. Since the lifetime of internal battery is 5 years, the user can change a new Battery to replace old one after it cannot work.

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the

manufacturer.

Dispose of used batteries according to the manufacturer’s instructions.

3-9

BX2000+

3.7. SPEAKER CONNECTOR INSTALLATION

There is a speaker in AT system for sound purpose. The 4 - Pins connector

SPKR

is used to connect speaker. Anode connects +, Cathode connects −.

3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION

The RESET switch on panel provides users with HARDWARE RESET function. The system will do a cold start after the RESET switch is pushed and released by user. The RESET switch is a 2 PIN connector and should be installed to

RST

on main board.

3.9. POWER LED CONNECTOR INSTALLATION

System has Power LED lamp on the panel of case. The Power LED will light on off or flash to indicate which step on the system. The connector should be connected to

PWR

of main board in correct direction.

3.10. IDE & ATAPI DEVICE INSTALLATION

There are two-Enhanced PCI IDE ports ( ATAPI standard SPEC. Any one IDE port can connected to two ATAPI devices (IDE Hard Disk, CD-ROM & Tape Driver), so total four ATAPI devices can exist in a system. The

is the active LED port for ATAPI devices.

IDE1, IDE2

) on board, which following

3.11. PERIPHERAL DEVICE INSTALLATION

After the I/O device installation and jumpers setup, the main board can be mounted into the case and fixed by screw. To complete the main board installation, the peripheral device could be installed now. The basic system needs a display interface card. If the PCI - Bus device is to be installed in the system, any one of four PCI - Bus slots can be used.

3.12. KEYBOARD & PS/2 MOUSE INSTALLATION

The main board supports PS/2 Mouse. The BIOS will auto detect whether the PS/2 Mouse is installed or not & assign IRQ12 for PS/2 Mouse port if it is installed. After installing the peripheral device, the user should check everything again, and prepare to power-on the system.

3-10

Hardware Installation

3-11

BX2000+

4.BIOS CONFIGURATION

Award's BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS SRAM so that it retains the Setup information when the power is turned off.

4.1. ENTERING SETUP

Power ON the computer and press <Del> immediately will allow you to enter Setup. If the message disappears before you respond and you still wish to enter Setup, restart the system to try again by turning it OFF then ON or pressing the "RESET" bottom on the system case. You may also restart by simultaneously press <Ctrl>, <Alt>, and <Del> keys.

4.2. CONTROL KEYS

Up arrow Move to previous item Down arrow Move to next item Left arrow Move to the item in the left hand Right arrow Move to the item in the right hand Esc key Main Menu - Quit and not save changes into CMOS

Status Page Setup Menu and Option Page Setup Menu -

Exit current page and return to Main Menu PgUp key Increase the numeric value or make changes PgDn key Decrease the numeric value or make changes F1 key General help, only for Status Page Setup Menu and Option

Page Setup Menu F2 key Change color from total 16 colors F3 key Reserved F4 key Reserved F5 key Restore the previous CMOS value from CMOS, only for

Option Page Setup Menu F6 key Load the default CMOS value from BIOS default table, only

for Option Page Setup Menu F7 key Load the default F8 key Reserved F9 key Reserved F10 key Save all the CMOS changes, only for Main Menu

4-1

BIOS Configuration

4.3. GETTING HELP

4.3.1. Main Menu

The on-line description of the highlighted setup function is displayed at the bottom of the screen.

4.3.2. Status Page Setup Menu / Option Page Setup Menu

Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window press <Esc>.

4.4. THE MAIN MENU

Once you enter Award BIOS CMOS Setup Utility, the Main Menu (Figure 4.1) will appear on the screen. The Main M enu allow s you to select from nine setup functions and two exit choices. Use arrow keys to select among the items and press <Enter> to accept or enter the sub-menu.

Figure 4.1: Main Menu

• Standard CMOS setup

This setup page includes all the items in standard compatible BIOS.

• BIOS features setup

This setup page includes all the items of Award special enhanced features.

4-2

BX2000+

•

Chipset features setup

This setup page includes all the items of chipset special features.

• Power management setup

This setup page includes all the items of Green function features.

• PNP/PCI configuration

This setup page includes all the configurations of PCI & PnP ISA resources.

• Load BIOS defaults

BIOS Defaults indicates the most appropriate value of the system parameters that the system would be in safe configuration.

• Load Performance defaults

Performance Defaults indicates the value of the system parameters that the system would be in the best performance configuration.

• Integrated peripherals

This setup page includes all onboard peripherals.

• Supervisor password

Change, set, or disable password. It allows you to limit access to the system and Setup, or just to Setup.

• User password

Change, set, or disable password. It allows you to limit access to the system.

• IDE HDD auto detection

Automatically configure hard disk parameters.

• Save & exit setup

Save CMOS value settings to CMOS and exit setup.

• Exit without saving

Abandon all CMOS value changes and exit setup.

4-3

BIOS Configuration

4.5. STANDARD CMOS SETUP MENU

The items in Standard CMOS Setup Menu (Figure 4.2) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item.

Figure 4.2: Standard CMOS Setup Menu

• Date

The date format is <week>, <month> <date> <year>.

week The week, from Sun to Sat, determined by the BIOS and is

display-only month The month, Jan. through Dec. date The date, from 1 to 31 (or the maximum allowed in the month) year The year, from 1994 through 2079

• Time

The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00.

4-4

BX2000+

•

Primary HDDs / Secondary HDDs

The category identifies the types of hard disk from drive C to F that has been installed in the computer. There are two types: auto type, and user definable type. User type is user-definable; Auto type which will automatically detect HDD type.

Note that the specifications of your drive must match with the drive table. The hard disk will not work properly if you enter improper information for this category.

If you select User Type, related information will be asked to enter to the following items. Enter the information directly from the key board and press <Enter>. Such information should be provided in the documentation form your hard disk vendor or the system manufacturer.

CYLS. Number of cylinders HEADS number of heads PRECOMP write precomp LANDZONE Landing zone SECTORS number of sectors

If a hard disk has not been installed select NONE and press <Enter>.

• Drive A type / Drive B type

The category identifies the types of floppy disk drive A or drive B that has been installed in the computer.

None No floppy drive installed 360K, 5.25 in. 5.25 inch PC-type standard drive; 360K byte capacity.

1.2M, 5.25 in. 5.25 inch AT-type high-density drive; 1.2M byte

capacity (3.5 inch when 3 Mode is Enabled).

720K, 3.5 in. 3.5 inch double-sided drive; 720K byte capacity

1.44M, 3.5 in. 3.5 inch double-sided drive; 1.44M byte capacity.

2.88M, 3.5 in. 3.5 inch double-sided drive; 2.88M byte capacity.

4-5

BIOS Configuration

•

Floppy 3 Mode Support (for Japan Area)

Disabled Normal Floppy Drive. Drive A Drive A is 3 mode Floppy Drive. Drive B Drive B is 3 mode Floppy Drive. Both Drive A & B are 3 mode Floppy Drives.

• Video

The category detects the type of adapter used for the primary system monitor that must match your video display card and monitor. Although secondary monitors are supported, you do not have to select the type in setup.

EGA/VGA Enhanced Graphics Adapter/Video Graphics Array. For

EGA, VGA, SVGA, or PGA monitor adapters CGA 40 Color Graphics Adapter, power up in 40 column mode CGA 80 Color Graphics Adapter, power up in 80 column mode MONO Monochrome adapter, includes high resolution

monochrome adapters

• Halt on

The category determines whether the computer will stop if an error is detected during power up.

NO Errors The system boot will not stop for any error that may

be detected

All Errors W henever the BIOS detects a non-fatal error the

system will be stopped and you will be prompted

All, But Keyboard The system boot will not stop for a keyboard error;

it will stop for all other errors

All, But Diskette The system boot will not stop for a disk error; it will

stop for all other errors

All, But Disk/Key The system boot will not stop for a keyboard or disk

error; it will stop for all other errors

4-6

BX2000+

•

Memory

The category is display-only which is determined by POST (Power On Self Test) of the BIOS.

Base Memory

The POST of the BIOS will determine the amount of base (or conventional) memory installed in the system.

The value of the base memory is typically 512 K for sy stems with 512 K memory installed on the motherboard, or 640 K for systems with 640 K or more memory installed on the motherboard.

Extended Memory

The BIOS determines how much extended memory is present during the POST.

This is the amount of memory located above 1 MB in the CPU's memory address map.

Expanded Memory

Expanded Memory in memory defined by the Lotus/Intel/Microsoft (LIM) standard as EMS.

Many standard DOS applications can not utilize memory above 640 K; the Expanded Memory Specification (EMS) swaps memory, which not utilized by DOS with a section, or frame, so these applications, can access all of the system memory.

Memory can be swapped by EMS is usually 64 K within 1 MB or memory above 1 MB, depends on the chipset design.

Expanded memory device driver is required to use memory as Expanded Memory.

Other Memory

This refers to the memory located in the 640 K to 1024 K address space. This is memory that can be used for different applications.

DOS uses this area to load device drivers to keep as much base memory free for application programs. Most use for this area is Shadow RAM.

4-7

BIOS Configuration

4.6. BIOS FEATURES SETUP

Figure 4.3: BIOS Features Setup

✲ System will detect automatically and show up when you install the Pentium III

processor.

• Virus Warning

If it is set to enable, the category will flash on the screen w hen there is any attempt to write to the boot sector or partition table of the hard disk drive. The system will halt and the warning message w ill appear in the mean time. You can run anti-virus program to locate the problem.

Default value is Disabled.

Enabled Activate automatically when the system boots up causing a

warning message to appear when anything attempts to access the boot sector or hard disk partition table

Disabled No warning message to appear when anything attempts to

access the boot sector or hard disk partition table

4-8

BX2000+

•

CPU Internal Cache / External Cache

These two categories speed up memory access. However, it depends on CPU / chipset design. The default value is Enabled.

Enabled Enable cache Disabled Disable cache

• CPU L2 Cache ECC Checking

The default value is Disabled.

Enabled Enable CPU L2 Cache ECC Checking Disabled Disable CPU L2 Cache ECC Checking

• Processor Number Feature

This item will show up when you install the Pentium III processor.

The default value is Enabled.

Enabled Pentium III Processor Number Feature. Disabled Disable this function

• Quick Power On Self Test

This category speeds up Power On Self Test (POST) after you power on the computer. If it is set to Enable, BIOS will shorten or skip some check items during POST.

The default value is Enabled.

Enabled Enable quick POST Disabled Normal POST

• CPU Update Data

The default value is Enabled.

Enabled Enable CPU Update Data Disabled Normal CPU Update Data

4-9

BIOS Configuration

•

Boot From LAN First

The default value is Enabled.

Auto Enable Boot From LAN First Function Enabled Enable Boot From LAN First Function Disabled Disable Boot From LAN First Function

☞You can set “Auto” or “Enabled” to boot from LAN first.

• Boot Sequence

This category determines which drive computer searches first for the disk operating system (i.e., DOS). Default value is A, C, SCSI.

X1, X2, X3

☞If you have the IDE device connected to the board as well as ATA66 device at the same time. In order to boot from ATA66 device, you must set “Boot Sequence : U66, A, C”.

System will first search for X1 disk drive then X 2 disk drive and then X3 disk drive.

• Swap Floppy Drive

The default value is Disabled.

Enabled Floppy A & B will be swapped under DOS Disabled Floppy A & B will be normal definition

• VGA Boot From

The default value is AGP.

AGP VGA Boot From AGP PCI VGA Boot From PCI

• Boot Up Floppy Seek

During POST, BIOS will determine the floppy disk driv e installed is 40 or 80 tracks. 360 K type is 40 tracks 720 K, 1.2 M and 1.44 M are all 80 tracks. The default value is Enabled.

Enabled BIOS searches for floppy disk drive to determine it is 40 or

Disabled BIOS will not search for the type of floppy disk driv e by track

80 tracks. Note that BIOS can not tell from 720 K, 1.2 M or

1.44 M drive type as they are all 80 tracks number. Note that there will not be any warning message if

the drive installed is 360 K

4-10

BX2000+

•

Boot Up NumLock Status

The default value is On.

On Keypad is number keys Off Keypad is arrow keys

• Typematic Rate Setting

The default value is Disabled.

Enabled Enable Keyboard Typematic rate setting. Disabled Disable Keyboard Typematic rate setting.

• Typematic Rate (Chars / Sec)

The default value is 6.

6-30 Set the maximum Typematic rate from 6 chars. Per second

to 30 chars. Per second.

• Typematic Delay (Msec)

The default value is 250.

250-1000 Set the time delay from first key to repeat the same key in

to computer.

• Security Option

This category allows you to limit access to the system and Setup, or just to Setup. The default value is Setup.

System The system can not boot and can not access to Setup page

will be denied if the correct password is not entered at the prompt

Setup The system will boot, but access to Setup will be denied if

the correct password is not entered at the prompt

0 To disable security, select PASSWORD SETTING at Main Menu and

then you will be asked to enter password. Do not type anything and just press <Enter>, it will disable security. Once the security is disabled, the system will boot and you can enter Setup page freely.

4-11

•

PCI/VGA Palette Snoop

The default value is Disabled.

Enabled For h a v i n g V i deo C ard on ISA Bus and VGA Card on PCI Bus. Disabled For VGA Card only.

• Assign IRQ For VGA

The default value is Enabled.

Enabled Assign a specific IRQ for VGA

Disabled No IRQ is assigned for VGA

• OS Select For DRAM>64MB

The default value is Non-OS2.

Non-OS2 Using non-OS2 operating system. OS2 Using OS2 operating system and DRAM>64MB.

HDD S.M.A.R.T. Capability

•

The default value is Disabled.

Enable Enable HDD S.M.A.R.T. Capability Disable Disable HDD S.M.A.R.T. Capability

BIOS Configuration

• Report No FDD For WIN 95

The default value is No.

No Assign IRQ6 For FDD. Yes FDD Detect IRQ6 Automatically.

• Video BIOS Shadow

It determines whether video BIOS is able to copy to RAM, however, it is optional from chipset design. Video Shadow will increase the video speed. The default value is Enabled.

Enabled Video shadow is enabled Disabled Video shadow is disabled

4-12

BX2000+

4.7. CHIPSET FEATURES SETUP

Figure 4.4: Chipset Features Setup

• Reset Case Open Status (Optional)

• Case Opened (Optional)

If the case is closed, “Case Opened” will show “No”. If the case have been opened, “Case Opened” will show “Yes” . If you want to reset “Case Opened” value, set “Reset Case Open Status” to “Enabled” and restart your computer.

• Slow Down CPU Duty Cycle (Optional)

The default value is Normal.

Normal Normal Operation

12.5%~75.0% Monitor CPU Temp. will cause system slow down CPU Duty Cycle to 12.5%~75.0%.

4-13

BIOS Configuration

•

Shutdown Temp. (°C / °F) (Optional)

(This function will be effective only for the operating systems that support

ACPI Function.)

The default value is 75°C / 167°F

Disabled Normal Operation

60°C / 140°F Monitor CPU Temp. at 60°C / 140°F, if Temp. > 60°C /

140°F system will automatically power off .

65°C / 149°F Monitor CPU Temp. at 65°C / 149°F, if Temp. > 65°C /

149°F system will automatically power off .

70°C / 158°F Monitor CPU Temp. at 70°C / 158°F, if Temp. > 70°C /

158°F system will automatically power off .

75°C / 167°F Monitor CPU Temp. at 75°C / 167°F, if Temp. > 75°C /

167°F system will automatically power off .

• Temp. Select (°C / °F) (Optional)

The default value is 70°C /158°F

60°C / 140°F Monitor CPU Temp. at 60°C / 140°F 65°C / 149°F Monitor CPU Temp. at 65°C / 149°F 70°C / 158°F Monitor CPU Temp. at 70°C / 158°F 75°C / 167°F Monitor CPU Temp. at 75°C / 167°F

• Temperature Alarm (Optional)

The default value is No

No When CPU Temp. overheat, then system won’t alarm.

Yes W hen CPU Temp. overheat, then system will alarm.

• Current Temp. (Optional)

Detect Temp. automatically.

4-14

BX2000+

•

Fan Fail Alarm (Optional)

CPU/POWER/PANEL

No Fan Fail Alarm Function Disabled.

Yes Fan Fail Alarm Function Enabled.

• Current FAN Speed (RPM) (Optional)

Detect Fan speed status automatically.

• Current Voltage (v) VCORE / VGTL/ VCC3 / ±12V / ±5V / VBAT / 5VSB

(Optional)

Detect system’s voltage status automatically.

• EDO CASx# MA Wait State

The default value is 1

1 Set EDO CASx# MA Wait State to 1. 2 Set EDO CASx# MA Wait State to 2.

• EDO RASx# Wait State

The default value is 1

1 Set EDO RASx# Wait State to 1. 2 Set EDO RASx# Wait State to 2.

• SDRAM CAS latency Time

The default value is Auto

3 For 67 / 83 MHz SDRAM DIMM module. 2 For 100 MHz SDRAM DIMM module.

Auto CAS latency time will be set automatically if you hav e SPD

on SDRAM

4-15

•

DRAM Data Integrity Mode

This value will depend on the DRAM type.

Non-ECC For 64bit standard type DIMM module. ECC For 72bit ECC type DIMM module.

• BIOS Flash Protection

The default value is Disabled.

Enabled BIOS Flash Write Protection.

Disabled Normal.

• System BIOS Cacheable

The default value is Enabled.

Enabled Enable System BIOS Cacheable.

Disabled Disable System BIOS Cacheable.

• Video BIOS Cacheable

The default value is Enabled.

Enabled Enable video BIOS Cacheable.

Disabled Disable video BIOS Cacheable.

BIOS Configuration

• Video RAM Cacheable

The default value is Disabled.

Disabled Disable this function.

Enabled Enable this function to get better VGA performance; while

some brands of VGA must be disabled this function (e.g.ET4000W32P).

• 16 Bit I/O Recovery Time

The default value is 1.

1-4 Set 16 Bit I/O recovery time from 1 to 4.

NA None.

4-16

BX2000+

•

Memory Hole At 15M-16M

The default value is Disabled.

Disabled Normal Setting. Enabled Set Address=15~16MB remap to ISA BUS.

• Delayed Transaction

The default value is Disabled.

Disabled Normal operation.

Enabled For slow speed ISA device in system.

• Clock Spread Spectrum

The default value is Disabled.

Disabled Disabled this function

Enabled Enabled Clock Spread Spectrum

4.8. POWER MANAGEMENT SETUP

Figure 4.5: Power Management Setup

✲ These two items will show up when “Resume by Alarm” is Enabled.

4-17

•

Power Management

The default value is Enabled.

Enabled Enable Green function. Disabled Disable Green function.

• PM Control by APM

BIOS Configuration

The default value is Yes.

Yes Enable software APM function. No Disable software APM function.

• Video off Method

The default value is DPMS.

V/H SYNC + Blank Blank Screen DPMS

BIOS will turn off V/H-SYNC when gets into Green mode for Green monitor power saving. BIOS will only black monitor when gets into Green mode. BIOS will use DPMS Standard to control VGA card. (The Green type VGA card will turn of V/H-SYNC automatically.)

• Suspend Mode

The default value is Disabled.

Disabled Disable Suspend Mode. 1 min - 1 Hour Setup the timer to enter Suspend Mode.

• HDD Power Down

The default value is Disabled.

Disable Disable HDD Power Down mode function. 1-15 mins. Enable HDD Power Down mode between 1 to 15 mins.

4-18

BX2000+

•

VGA Active Monitor

The default value is Disabled.

Disabled Disable monitor VGA activity. Enabled Enable monitor VGA activity.

• Soft-off by PWR-BTTN

The default value is Instant-Off.

Instant-off Soft switch ON/OFF for POWER ON/OFF Delay 4 Sec. Soft switch ON 4sec. for POWER OFF.

• System After AC Back

The default value is Soft-Off.

Memory This function depends on computer status Soft-Off Set System Soft-Off Status. Full-On Set System Full-On Status.

• Power LED in Suspend

The default value is Blinking.

Blinking Set Power LED in Suspend at Blinking mode. On Set Power LED in Suspend at On mode. Off/Dual Set Power LED in Suspend at Off/Dual mode.

• CPUFAN Off In Suspend

The default value is Enabled.

Disabled Disable this function. Enabled Stop CPU FAN when entering Suspend mode.

• PME Event Wakeup

The default value is Disabled.

Disabled Disable PME Event Wakeup. Enabled Enable PME Event W akeup.

4-19

•

ModemRingOn / WakeOnLan

The default value is Enabled.

Disabled Disable these functions. Enabled Enable these functions.

• ACPI Suspend Type

The default value is Power On Suspend.

Power On Suspend Suspend to RAM

Set ACPI Suspend Type is Power On Suspend. Set ACPI Suspend Type is Suspend to RAM.

• Resume by Alarm

The default value is Disabled.

Disabled Disable this function. Enabled Enable alarm function to POWER ON system.

If the “Resume by Alarm” is Enabled.

Date ( of Month) Alarm : 0~31 Time ( hh: mm: ss) Alarm : (0~23) : (0~59) : (0~59)

BIOS Configuration

• IRQ [3-7,9-15] , NMI

The default value is Enabled.

Disabled Disable this function. Enabled Enable monitor IRQ [3-7,9-15] for Green event.

• Primary IDE 0/1

The default value is Disabled.

Disabled Disable this function. Enabled Enable monitor Primary IDE 0/1 for Green event.

4-20

BX2000+

•

Secondary IDE 0/1

The default value is Disabled.

Disabled Disable this function. Enabled Enable monitor Secondary IDE 0/1 for Green event.

• Floppy Disk

The default value is Enabled.

Disabled Disable this function. Enabled Enable monitor Floppy Disk for Green event.

• Serial Port

The default value is Enabled.

Disabled Disable this function. Enabled Enable monitor Serial Port for Green event.

• Parallel Port

The default value is Disabled.

Disabled Disable this function. Enabled Enable monitor Parallel Port for Green event.

4-21

BIOS Configuration

4.9. PNP/PCI CONFIGURATION

Figure 4.6: PCI Slot Configuration

✲ This item will show up when “Used MEM base addr” has been set.

• PNP OS Installed

The default value is No.

Yes Enable PNP OS Installed function. No Disable PNP OS Installed function.

• Resources Controlled by

The default value is Manual.

Manual User can set the PnP resource (I/O Address, IRQ & DMA

channels) used by legacy ISA DEVICE.

Auto BIOS automatically use these PnP rescuers.

• Reset Configuration Data

The default value is Disabled. Disabled Disable this function.

Enabled Enable clear PnP information in ESCD.

4-22

BX2000+

•

IRQ (3,4,5,7,9,10,11,12,14,15), DMA(0,1,3,5,6,7) assigned to

The default value is "Legacy ISA" or "PCI/ISA PnP". Legacy ISA The resource is used by Legacy ISA device.

PCI/ISA PnP

The resource is used by PCI/ISA PnP device (PCI or ISA).

• Used MEM base addr.

The default value is N/A.

N/A Disable the MEM. block using.

C800 ~ DC00 Select the MEM. block starting address.

• Used MEM Length

The default value is 8K. 8K ~ 64K Select the MEM. block size.

• Assign IRQ For USB

The default value is Enabled.

Enabled Assign a specific IRQ for USB

Disabled No IRQ is assigned for USB

4-23

Gigabyte GA-BX2000 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
