Gigabyte GA-8SIML User Manual

MTheauthor assumes no responsibility for anyerrors oromissions that may appear in this documentnor doesthe authormake acommitment to up

date the information contained herein.

MThird-party brands and namesare the propertyof theirrespective owners.

MPlease do not removeany labelson motherboard, this mayvoid the warranty of this motherboard.

MDueto rapid changein technology, some ofthe specifications mightbe out of date beforepublication of this booklet.

oEN 55011

oEN 55013

oEN 55014

oEN 55015

oEN 55020

T EN 55022

oDIN VDE 0855

opart 10

opart 12

T CEmarking

oEN 60065

oEN 60335

Declaration of Conformity

We,Manufacturer/Importer

(full address)

G.B.T. Technology Träding GMbH

AusschlagerWeg 41,1F, 20537 Hamburg, Germany

declare that the product

( description of the apparatus, system, installation to which it refers)

Mother Board

GA-8 SIML

is in conformity with

(reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive

Limits and methods of measurement

o EN 61000-3-2*

Disturbances in supply systems cause

of radio disturbance characteristics of

T EN 60555-2

by household appliances and similar

industrial,scientific and medical (ISM



electrical equipment “Harmonics”

high frequency equipment





Limits and methods of measurement

o EN 61000-3-3*

Disturbances in supply systems cause

of radio disturbance characteristics of

T EN 60555-3

by household appliances and similar

broadcast receivers and associated

electrical equipment “Voltage fluctuations”



equipment





Limits and methods of measurement of radio disturbance characteristics of household electrical appliances, portable tools and similar electrical apparatus

Limits and methods of measurement of radio disturbance characteristics of fluorescent lamps and luminaries

Immunity from radio interference of broadcast receivers and associated equipment

Limits and methods of measurement of radio disturbance characteristics of information technology equipment

Cabled distribution systems; Equipment for receiving and/or distribution from sound and television signals

TEN 50081-1

TEN 50082-1

oEN 55081-2

oEN 55082-2

oENV 55104

oEN50091-2

Generic emission standard Part 1: Residual commercialand light industry

Genericimmunity standard Part 1: Residual commercialand light industry

Generic emission standard Part 2: Industrialenvironment

Generic emission standard Part 2: Industrialenvironment

lmmunity requirements for household appliances tools and similar apparatus

EMC requirements for uninterruptible powersystems(UPS)



(EC conformity marking)



Themanufacturer also declaresthe conformity of above mentioned product



withthe actual requiredsafety standards in accordance with LVD 73/23EEC



Safetyrequirements for mains operated

o EN 60950



electronic and related apparatus for





household and similar general use





Safety of household and similar

o EN 50091-1



electrical appliances







Manufacturer/Importer





Signature:

(S ta mp )

Date : Dec. 18, 2001

Name:





Timmy Huang

Timmy Huang

DECLARATION OF CONFORMITY

Per FCC Part 2 Sect ion 2.1077(a)

Responsible Party Name:G.B.T. INC. (U.S .A.)

Address: 17358 Railroad S treet

City of Industry, CA 91 748

Phone/Fax No:(818) 854-9338/ (818) 854-9339

hereby declares that the product

Product Name: Motherboard

Model Number:GA-8 S IML

Conforms to the follo wing specifications:

FCC Part 15, Sub part B, Sectio n 15.107(a) an d Section 15.109 (a),Class B Digital Device

Supplementary Information:

This device co mplies with part 15 of the FCC Rules . Operation is subject to t he follo wing two conditions: (1) This device may not cause harmful and (2)this device must accept any inference received, including that may cause undesired operation.

Representative Person’s Name: ERIC LU

Signature: Eric Lu

Dat e: Dec. 18,2001

GA-8SIML

P4 Titan-DDR Motherboard

USER’S MANUAL

Pentium®4 Processor Motherboard

Rev 2001 12ME-8SIML-2001

English

Table of Content



Item Checklist ..................................................................................

4

WARNING! .......................................................................................

4

Chapter 1 Introduction .......................................................................

5

Features Summary................................................................................................

5

GA-8SIML Motherboard Layout ..........................................................................

7

Chapter 2 Hardware Installation Process ............................................

8

Step 1: Install the Central Processing Unit (CPU) ...........................................

9

Step 1-1 : CPU Installation ................................................................

9

Step 1-2 : CPU Heat Sink Installation ...........................................

10

Step 2: Install memory modules .......................................................................

11

Step 3: Install expansion cards .........................................................................

12

Step 4: Connect ribbon cables, cabinet wires, and power supply .............

13

Step 4-1 : I/O Back Panel Introduction .........................................

13

Step 4-2 : Connectors Introduction ...............................................

15

Chapter 3 BIOS Setup ....................................................................

22

T he Main Menu (For example: BIOS Ver. :FA) ..............................................

23

Standard CMOS Features .................................................................................

25

Advanced BIOS Features ...................................................................................

28

Advanced Chipset Features ..............................................................................

31

Integrated Peripherals .......................................................................................

33

GA-8SIML Motherboard

- 2 -

Power Management Setup ................................................................................

38

PnP/PCI Configurations ......................................................................................

41

PC Health Status ..................................................................................................

43

Frequency/Voltage Control ................................................................................

45

Load Fail-Safe Defaults ......................................................................................

47

Load Optimized Defaults ....................................................................................

48

Set Supervisor/User Password ..........................................................................

49

Save & Exit Setup .................................................................................................

50

Exit Without Saving .............................................................................................

51

Chapter 4 Technical Reference ........................................................

52

Block Diagram .....................................................................................................

52

Q-Flash Introduction ...........................................................................................

53

@ BIOS Introduction ...........................................................................................

55

Easy T une III .........................................................................................................

56

Chapter 5 Appendix .......................................................................

57

English

- 3 -

Table of Content

English

Item Checklist

þThe GA-8SIML motherboard

þIDE cable x 1/ Floppy cable x 1

þCD for motherboard driver & utility (TUCD)

þGA-8SIML user’s manual

WARNING!

Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips. To protect them against damage from static electricity, you should follow some precautions whenever you work on your computer.

1.Unplug your computer when working on the inside.

2.Use a grounded wrist strap before handling computer components. If you do not have one, touch both of your hands to a safely grounded object or to a metal object, such as the power supply case.

3.Hold components by the edges and try not touch the IC chips, leads or connectors, or other components.

4.Place components on a grounded antistatic pad or on the bag that came with the components whenever the components are separated from the system.

5.Ensure that the ATX power supply is switched off before you plug in or remove the ATX power connector on the motherboard.

Installing the motherboard to the chassis…

If themotherboard has mounting holes, but they don’t line up with the holes on the base and there are no slots to attach the spacers, do not become alarmed you can still attach the spacers to the mounting holes. Just cut the bottom portion of the spacers (the spacer may be a little hard to cut off, so be careful of your hands). In this way you can still attach the motherboard to the base without worrying about short circuits. Sometimes you may need to use the plastic springs to isolate the screw from the motherboard PCB surface, because the circuit wire may be near by the hole. Be careful, don’t let the screw contact any printed circuit write or parts on the PCB that are near the fixing hole, otherwise it may damage the board or cause board malfunctioning.

GA-8SIML Motherboard

- 4 -

Chapter 1 Introduction

Features Summary

Form Factor

22.9cm x 24.3cm Micro ATX size form factor, 4 layers PCB.

CPU

Socket 478 for Intel® Micro FC-PGA2 Pentium® 4 processor



Support Intel ® Pentium ® 4 (Northwood, 0.13 m) processor



Intel Pentium®4 400MHz FSB



2nd cache depends on CPU







Chipset

SiS 650 Host/Memory controller(**)



SiS 650GX Host/Memory controller(***)



SiS 961 MuTIOL Media I/O





Memory

2 184-pin DDR DIMM sockets



Supports DDR266/200 SDRAM



Supports up to 2 un-buffer Double-sided DIMM DDR266/200



Supports up to 2GB DDR DRAM (Max)



Supports only 2.5V DDR DIMM



Supports 64bit DRAM integrity mode







I/O Control

W83697HF







Slots

1 Universal AGP slot (1X/2X/4X) device support



3 PCI slot supports 33MHz & PCI 2.2 compliant



1 CNR(Communication and Networking Riser) Slot







On-Board IDE

2 IDE bus master (UDMA33/ATA66/ATA100) IDE ports for up to 4





ATAPI devices



Supports PIO mode3,4 (UDMA 33/ATA66/ATA100) IDE & ATAPI





CD-ROM







On-Board Peripherals

1 Floppy port supports 2 FDD with 360K, 720K,1.2M, 1.44M





and 2.88M bytes.



1 Parallel port supports Normal/EPP/ECP mode



1 Serial port (COMA),1 VGA port,COMB on board



4 USB ports (Rear USB x 2,by optional cable)



1 Front Audio Connector*



1 Serial IRQ Connector**

1 IrDA connector for IR**

to be continued......

*For PCB 1.1& 2.0 ver only **For PCB 1.0& 1.1 ver only

***For PCB 2.0 ver only

English

- 5 -

Introduction

English

Hardware Monitor

CPU/System Fan Revolution detect





CPU/System Fan Control





CPU Overheat Warning





System Voltage Detect







On-Board Sound

Sigmatel 9721 CODEC(***)





Realtek 201A CODEC(**)





Line In/Line Out/Mic In/CD In/ AUX_IN***/ SPDIF** /Game Port









On-Board

LAN

Builit in RTL8100L Chipset(**)





Builit in RTL8100BL Chipset(***)





1 RJ45 port









On-Board

VGA

Builit in SiS650 Chipset(**)





Builit in SiS650GX Chipset(***)







PS/2 Connector

PS/2 Keyboard interface and PS/2 Mouse interace









BIOS



Licensed Award BIOS, 2M bit Flash ROM (***)





Licensed AMI BIOS, 2M bit Flash ROM(**)





Additional Features

PS/2 Keyboard power on by password





PS/2 Mouse power on





STR(Suspend-To-RAM)





AC Recovery





USB KB/Mouse wake up from S3





Supports EasyTune III





Supports @BIOS









Please set the CPU host frequency in accordance with your processor’s specifications. We don’t recommend you to set the system bus frequency over the CPU’s specification because these specific bus frequencies are not the standard specifications for CPU, chipset and most of the peripherals. Whether your system can run under these specific bus frequencies properly will depend on your hardware configurations, including CPU, Chipsets,SDRAM,Cards… .etc.

*For PCB 1.1& 2.0 ver only **For PCB 1.0& 1.1 ver only

***For PCB 2.0 ver only

GA-8SIML Motherboard

- 6 -

Gigabyte GA-8SIML User Manual

GA-8SIML Motherboard Layout













CPU_FAN



DIMM_LED



KB_MS

ATX_12V





































U S B /

LAN



















COMA







SOCKET478







ATX





















VGA

LPT

















LINE OUT



CD IN

AUX IN***

SiS 650GX***/















SiS 650**













LINE IN















IN

GAME

F_AUDIO*

GA-8SIML











MIC





















SPDIF**





AGP

































RTL8100





DDR2

DDR1

IDE2

IDE1

FDD





















IR**



AC97





PCI1









CLR CMOS*** FAN





W83697HF





PCI2



SiS 961

























S_IRQ**



BATTERY











































CI

_



















SYS





BIOS

BIOS_WP***



PCI3

F_USB

F_PANEL





































COMB





Buzzer











CNR















































English

*For PCB 1.1& 2.0 ver only **For PCB 1.0& 1.1 ver only

***For PCB 2.0 ver only

- 7 -

Introduction

English

Chapter 2 Hardware Installation Process

To set up your computer, you must complete the following steps: Step 1- Install the Central Processing Unit (CPU)

Step 2- Install memory modules Step 3- Install expansion cards

Step 4- Connect ribbon cables, cabinet wires, and power supply Step 5- Setup BIOS software

Step 6- Install supporting software tools

Step1

Step4

Step 2

Step 4

Step 4

Step3

GA-8SIML Motherboard

- 8 -

Step 1: Install the Central Processing Unit (CPU)

Step1-1 : CPU Installation

Pin1 indicator

Pin1 indicator

CPU Top View

CPU Bottom View

Socket Actuation Lever

Pin1 indicator



English

1.Pull up the CPU socket lever and up to 90-degree angle.

3.Press down the CPU socket lever and finish CPU installation.

2.Locate Pin 1 in the socket and look for a (golden) cut edge on the CPU upper corner. Then insert the CPU into the socket.

MPlease make sure the CPU type is supported by the motherboard.

MIf you do not match the CPU socket Pin 1 and CPU cut edge well, it will cause improper installation. Please change the insert orientation.

- 9 -

Hardw are Installation Process

English

Step1-2 : CPU Heat Sink Installation

1. Hook one end of the cooler

2. Hook the other end of the

bracket to the CPU socket first.

cooler bracket to the CPU



socket.

MPlease use Intel approved cooling fan.

MWe recommend you to apply the thermal tape to provide better heat conduction between your CPU and heatsink.

(The CPU cooling fan might stick to the CPU due to the hardening of the thermal paste. During this condition if you try to remove the cooling fan, you might pull the processor out of the CPU socket alone with the cooling fan, and might damage the processor. To avoid this from happening, we suggest you to either use thermal tape instead of thermal paste, or remove the cooling fan with extreme caution.)

MMake sure the CPU fan power cable is plugged in to the CPU fan connector, this completes the installation.

MPlease refer to CPU heat sink user’s manual for more detail installation procedure.

GA-8SIML Motherboard

- 10 -

Step 2: Install memory modules

The motherboard has 2 dual inline memory module (DIMM) sockets . The BIOS w ill automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot

.The DIMM module can only fit in one direction due to the notch. Memory size can vary between sockets.

Total Memory Sizes With Unbuffered DDR DIMM

Dev ices used on DIMM

1 DIMM x 64 / x 72

2

DIMMs x 64 / x 72









64

Mbit (2Mx 8x 4 banks)

128 MBy tes

256 MBy tes

64

Mbit (1Mx 16x 4 banks)

32 MBy tes

64 MBy tes

128

Mbit(4Mx 8x 4 banks)

256 MBy tes

512 MBy tes

128

Mbit(2Mx 16x 4 banks)

64 MBy tes

128 MBy tes

256

Mbit(8Mx 8x 4 banks)

512 MBy tes

1

GBy tes

256

Mbit(4Mx 16x 4 banks)

128 MBy tes

256 MBy tes

512

Mbit(16Mx 8x 4 banks)

1 GBy tes

2

GBy tes

512

Mbit(8Mx 16x 4 banks)

256 MBy tes

512 MBy tes

DDR

1.The DIMM slot has a notch, so the

DIMMmemory module can only fit in one direction.

2.Insert the DIMM memory module verticallyinto the DIMM slot. Then push it down.

3.Close the plastic clip at both edges of theDIMM slots to lock the DIMM module.

Reverse the installation steps when you wish to remove the DIMM module.

MPlease note that the DIMM module can only fit in one direction due to the one notches. Wrong orientation will cause improper installation. Please change the insert orientation.

English

- 11 -

Hardw are Installation Process

English

DDR Introduction

Established on the existing SDRAM industry infrastructure, DDR (Double Data Rate) memory is a high performance and cost-effective solution that allows easy adoption for memory vendors, OEMs and system integrators.

DDR memory is a sensible evolutionary solution for the PC industry that builds on the existing SDRAM infrastructure, yet makes awesome advances in solving the system performance bottleneck by doubling the memory bandwidth. DDR SDRAM w ill offer a superior solution and migration path from existing S DRAM designs due to its availability, pricing and overall market support. PC2100 DDR memory (DDR266) doubles the data rate through reading and writing at both the rising and falling edge of the clock, achieving data bandwidth 2X greater than PC133 when running with the same DRAM clock frequency . With peak bandwidth of 2.1GB per second, DDR memory enables system OEMs to build high performance and low latency DRAM subsystems that are suitable for servers, workstations, highend PC 's and v alue desktop SM A sy stems. With a core voltage of only 2.5 Volts compared to conventional SDRAM's 3.3 volts, DDR memory is a compelling solution for small form factor desktops and notebook applications.

Step 3: Install expansion cards

1.Read the related expansion card’s instruction document before install the expansion card into the computer.

2.Remove your computer’s chassis cover, necessary screws and slot bracket from the computer.

3.Press the expansion card firmly into expansion slot in motherboard.

4.Be sure the metal contacts on the card are indeed seated in the slot.

5.Replace the screw to secure the slot bracket of the expansion card.

6.Replace your computer’s chassis cover.

7.Power on the computer, if necessary, setup BIOS utility of expansion card from BIOS.

8.Install related driver from the operating system.



Please carefully pull out the small white-



drawable bar at the end of the AGP slot when



you try to install/ Uninstall the AGP card.



Please align the AGP card to the onboard



AGP slot and press firmly down on the slot .

AGP Card

Make sure your AGP card is locked by the



small whitedrawable bar.

GA-8SIML Motherboard

- 12 -

Step 4: Connect ribbon cables, cabinet wires, and power supply

Step4-1:I/O Back Panel Introduction

v

w

u



x

y

u PS/2 Keyboard and PS/2 Mouse Connector

PS/2 Mouse Connector (6 pin Female)

PS/2 Keyboard Connector (6 pin Female)

v USB & LAN Connector

LAN

USB 0

USB 1

ØThis connector supports standard PS/2 keyboard and PS/2 mouse.

ØBefore you connect your device(s) into USB connector(s), please make sure your device(s) such as USB keyboard,mouse, scanner, zip, speaker..etc. Have astandard USB interface. Also make sure yourOS (Win 95with USB supplement, Win98, Windows 2000, Windows ME, Win NT with SP 6) supports USB controller. If your OS does not support USB controller, please contact OS vendor for possible patch or driver upgrade. For more information please contact your OS or device(s) vendors.

English

- 13 -

Hardw are Installation Process

English

w Parallel Port , Serial Port and VGA Port (LPT/COMA/VGA)

Parallel Port (25 pin Female)

COMA

VGA

Serial Port

VGA Port

(9 pin Male)

(15 pin Female)

ØThis connector supports 1 standard COM port ,1 Parallel port and 1 VGA port. Device like printercan be connected to Parallel port ; mouse and modem etc can be connected to Serial ports.

x Game /MIDI Ports

Joystick/ MIDI (15 pin Female)

y Audio Connectors

































































































Line Out





MIC In

























Line In

ØThis connector supports joystick, MIDI keyboard and other relate audio devices.

ØAfter install onboard audio driver, you may connect speaker to Line Out jack, micro phone to MIC Injack. Device like CD-ROM , walkman etc can be connected to Line-In jack.

GA-8SIML Motherboard

- 14 -

Step 4-2 : Connectors Introduction







A



B













C

S







D









R







E

Q









P







F









G

O







H

N















M

L

K

J

I

A)

ATX_12V

K)

F_USB

B)

CPU_FAN

L)

BATTERY

C)

ATX

M)

COMB

D)

IDE1/IDE2

N)

BIOS_WP***

E)

FLOPPY

O)

S_IRQ**









F)

IR**

P)

SPDIF**

G)

CLR_CMOS***

Q)

F_AUDIO *

H)

SYS_FAN

R)

CD_IN

I)

CI

S)

AUX_IN***

J)

F_PANEL













*For PCB 1.1& 2.0 ver only **For PCB 1.0& 1.1 ver only

***For PCB 2.0 ver only

English

- 15 -

Hardw are Installation Process

English

A) ATX_12V

( +12V Power Connector)

ØThis connector (ATX +12V) suppliesthe CPU







operation voltage (Vcore).



3

4

If this " ATX+ 12V connector" is not connected,



system cannot boot.

+12V



+12V





GND



GND





1

2



B ) CPU_FAN (CPU FAN Connector)

Sense +12V/Control GND

1

ØPlease note, a proper installation of the CPU cooler is essential to prevent the CPU from running under abnormal condition or damaged by overheating.The CPU fan connector supports Max . current up to 600 mA.

H ) SYS_FAN (System FAN Connector)



Sense

1

+12V/Control

GND

I) CI (CASE OPEN)

Signal

GND

1

ØThis 2 pin connector allows your system to enable or disable the system alarm if the sys tem case begin remove.

GA-8SIML Motherboard

- 16 -

E ) FDD (Floppy Connector)

1

D ) IDE1/ IDE2 (IDE1/IDE2 Connector)

1

1

IDE1

IDE2

ØImportant Notice:

Please connect first harddisk to IDE1 and connect CDROM to IDE2.

Q) F_AUDIO (Front Audio Connector)* Ø

MIC

1

GND



Front Audio (R)



Rear Audio (R)

Front Audio (L)



Rear Audio (L)

GND





*For PCB 1.1& 2.0 ver only **For PCB 1.0& 1.1 ver only

***For PCB 2.0 ver only

If you want to use "Front Audio" connector, you must move 3-4,5-6 Jumper. In order to utilize thefront audio header, yourchassis must have front audio connector. Also please make sure thepin assigment on the cable is the same as the pin assigment on the MB header. To find out if the chassis you are buying support front audio connector, please contact your dealer.

English

- 17 -

Hardw are Installation Process

English

R) CD_IN (CD Audio Line In)



CD-R



GND

1

CD-L



S) AUX_IN ( AUX In Connector)***



AUX-R

1

GND

AUX-L

P)SPDIF**







Ø The SPDIF output is capable of providing







digital audio to external speakers or com

VCC



1

pressed AC3 data to an external Dolby



Digital Decoder. Use this feature only when



SPDIF Out









GND





your stereo system has digital output





function.

O) S_IRQ **

(For special design, for example: PCMCIA add on card)

GND

Signal

1

*For PCB 1.1& 2.0 ver only **For PCB 1.0& 1.1 ver only **For PCB 2.0 ver only

GA-8SIML Motherboard

- 18 -

C ) ATX (ATX Power)

+12V

5V SB (Stand by +5V)

Power Good GND VCC GND

VCC

GND 3.3V 3.3V

20

VCC

VCC

-5V

ØAC power cord should only be connected to your power supply unit after ATX power cable and other related devices are firmly connected to the mainboard.

GND

GND

GND

PS-ON(SoftOn/Off)

GND

-12V

3.3V 1

J) F_USB (Front USB Connector)

GND

USB 3+ USB 3- Power

1

Power USB 2- USB 2+

GND

ØBe careful with the polarity of the front panel USB connector. Check the pin assignment while you connect the front panel USB cable. Please contact your nearest dealer for optional front panel USB cable.

F)IR **





Ø Be careful with the polarity of the IR

1

VCC(+5V)

connectorwhile you connect the IR. Please

contact you nearest dealer for optional IR



IR Data Input



device.



GND











IR Data

Output



English

*For PCB 1.1& 2.0 ver only **For PCB 1.0& 1.1 ver only **For PCB 2.0 ver only

- 19 -

Hardw are Installation Process

English

N) BIOS_WP***

(BIOS Write Protection)

2-3 close: Normal 1

1-2 close: Write Protection 1

ØPlease note, To flash/upgrade BIOS on this MB BIOS_WP must be set to 2-3 close. We recommend BIOS_WP to be set to "1-2 close", whenever user does not need to flash/upgrade the BIOS.

G) CLR_CMOS***

(Clear CMOS)

1

2-3 close: Normal

1

1-2 close: Clear CMOS

M) COM B

NC

NCTSB-

NDSRB-

NDTRB-

NSINB

1

NRIB-

NRTSB-

GND

NSOUTB

NDCDB-

ØYou may clear the CMOS data to its default values by this jumper.

*For PCB 1.1& 2.0 ver only **For PCB 1.0& 1.1 ver only **For PCB 2.0 ver only

GA-8SIML Motherboard

- 20 -

J) F_PANEL (2x7 pins jumper)

HD-

SPK-





SPK+

RST+

RST-

2







1



14











1











13

1













HD+

PDY -

PDG -

PD+

PW PW+ -



HD (IDE Hard Disk Active LED)

Pin 1: LED anode(+)



Pin 2: LED cathode(-)





SPK (Speaker Connector)

Pin 1: VCC(+)



Pin 2- Pin 3: NC



Pin 4: Data(-)





RST (Reset Switch)

Open: Normal Operation



Close: Reset Hardware System





PD+/PD_G-/PD_Y-(Power LED)

Pin 1: LED anode(+)



Pin 2: LED cathode(-)



Pin 3: LED cathode(-)





PW (Soft Power Connector)

Open: Normal Operation



Close: Power On/Off





ØPlease connect the power LED, PC speaker, reset switch and power switch etc of your chassis front panel to the F_PANEL connector according to the pin assignment above.

L) Battery

CAUTION

v Danger of explosion if battery is incorrectly

+

replaced.

v Replace only with the same or equivalent type recommended by the manufacturer.

v Dispose of used batteries according to the manufacturer’s instructions.

English

- 21 -

Hardw are Installation Process

English

Chapter 3 BIOS Setup

BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery -backed CMOS RAM so that it retains the Setup information when the power is turned off.

ENTERING SETUP

Power ON the computer and press <Del> immediately will allow you to enter Setup.

CONTROL KEYS

<á>

Move to previous item

<â>

Move to next item





<ß>

Move to the item in the left hand





<à>

Move to the item in the right hand





<Esc>

Main Menu - Quit and not save changes into CMOS Status Page Setup Menu and



Option Page Setup Menu - Exit current page and return to Main Menu





<+/PgUp>

Increase the numeric value or make changes





<-/PgDn>

Decrease the numeric value or make changes





<F1>

General help, only for Status Page Setup Menu and Option Page Setup Menu





<F2>

Reserved





<F3>

Reserved





<F4>

Reserved





<F5>

Restore the previous CMOS value from CMOS, only for Option Page Setup Menu





<F6>

Load the file-safe default CMOS value from BIOS default table





<F7>

Load the Optimized Defaults





<F8>

Dual BIOS/Q-Flash function





<F9>

Reserved





<F10>

Save all the CMOS changes, only for Main Menu





GA-8SIML Motherboard

- 22 -

Loading...
+ 57 hidden pages
