Page 1
GAMING MONITOR
OSD Sidekick
Page 2
OSD Sidekick Installation Guide
Copyright
© 2018 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their
respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the
property of GIGABYTE.
Changes to the specications and features in this manual may be made
by GIGABYTE without prior notice.
No part of this manual may be reproduced, copied, translated,
transmitted, or published in any form or by any means without
GIGABYTE’s prior written permission.
For more information, check on our website at:
https://www.gigabyte.com
- 2 -
Page 3
OSD Sidekick Installation Guide
CONTENTS
SOFTWARE INSTALLATION ......................................................................................................4
Preparation..........................................................................................................................4
Installing the Software ....................................................................................................5
Uninstalling the Software ..............................................................................................7
USING THE SOFTWARE .............................................................................................................8
Launching the Software .................................................................................................8
Conguring the Settings ................................................................................................8
DISPLAY SETTING ...................................................................................................9
HOT KEY ..................................................................................................................18
GENERAL SETTING .............................................................................................. 20
ANC .......................................................................................................................... 22
ABOUT .....................................................................................................................23
- 3 -
Page 4
OSD Sidekick Installation Guide
SOFTWARE INSTALLATION
Preparation
1. Connect one end of a USB (A-Male to B-Male) cable to the USB
port of the LCD monitor and the other end to the USB port of your
computer.
2. Connect any of the following:
• One end of an HDMI cable to the HDMI port of the LCD monitor
and the other end to the HDMI port of your computer.
• One end of a DisplayPort cable to the DP port of the LCD monitor
and the other end to the DP port of your computer.
3. Plug the power cables of your computer and the LCD monitor into a
power outlet.
4. Turn on your computer and the LCD monitor.
HDMI-2DPHDMI-1
- 4 -
Page 5
OSD Sidekick Installation Guide
Installing the Software
IMPORTANT! If you have installed an older version of the software on your
computer, you have to remove the previously installed software rst before
proceeding with the following installation process. To uninstall the software,
refer to the “Uninstalling the Software” section.
1. Insert the supplied CD into your CD-ROM drive. Then from the
Windows desktop, double-click on Computer and locate the CD
drive.
2. Browse and double-click setup.exe. The setup wizard appears.
3. Click Next to continue.
- 5 -
Page 6
OSD Sidekick Installation Guide
4. Click Install to start the software installation process.
5. The software installation may take a few minutes. When the
installation is complete, click Finish to exit the setup wizard.
- 6 -
Page 7
OSD Sidekick Installation Guide
Uninstalling the Software
1. From the Windows desktop, click and select GIGABTYE.
2. Right-click on OSD_Sidekick. Then select Uninstall.
3. The Programs and Features page appears on the screen. Select
OSDSidekick from the list.
4. Right-click on OSD_Sidekick and select Uninstall. Then follow the
on-screen instructions to uninstall the software.
- 7 -
Page 8
OSD Sidekick Installation Guide
USING THE SOFTWARE
Launching the Software
IMPORTANT! Before launching the software, make sure your computer is
connected to the LCD monitor through a USB cable as described in step 1 in
“Preparation” on page 4.
After the driver installation is complete, the OSD Sidekick software
shortcut icon appears on the desktop.
Double-click the icon to launch the software.
Conguring the Settings
Using the OSD Sidekick software, you can congure the advanced
settings for the monitor.
Note:
• Most of the conguration options are similar with the OSD menu and Quick
menu that you can directly access using the Control button on the monitor.
For more information, refer to the monitor user guide.
• To make the adjustment, generally, you can do one of the following:
D Drag the slider to adjust the setting.
- 8 -
Page 9
OSD Sidekick Installation Guide
D Click the ON/OFF button to enable or disable the function.
D Click the q icon to select the available option.
• All the changes will be applied directly to the monitor.
DISPLAY SETTING
Congure the game, image, multi-picture, Dashboard, and Game Assist
related settings.
Dashboard
Game AssistPIP/PBPGaming & Picture
Picture Mode
Crosshair
Conguring the Picture Mode Proles
By default, there are 10 preset Picture Mode proles. These proles
cannot be deleted. However, you can still do the following:
- 9 -
Page 10
OSD Sidekick Installation Guide
D Click to add an additional prole or import other prole.
√ To add an additional prole, select Add Prole.
Note: Make sure to congure the necessary Gaming & Picture settings
before creating a new prole.
√ To import other prole from the specied folder, select Import
Prole.
Browse the location and select the prole le to import. Then
click OK to import the le.
Note: The default Prole folder is located at the OSDsidekick installation
path.
- 10 -
Page 11
OSD Sidekick Installation Guide
D Click to export a prole to the specied folder.
Browse the location and enter the le name. Then click OK to export
the le.
Note: The default Prole folder is located at the OSDsidekick installation
path.
D Click to rename the prole name.
D Click to reset the preset Picture Mode prole to its default
settings.
Note: The customized prole settings cannot be reset.
D Click to delete the customized prole.
Note: The user dened Picture Mode applies to the monitor Custom 3.
- 11 -
Page 12
OSD Sidekick Installation Guide
D Click to link the prole with an application.
Select the application (*.exe) you want to link and click OK.
When you open that application, the display setting will
automatically change to the prole you linked.
- 12 -
Page 13
OSD Sidekick Installation Guide
Customizing the Crosshair Cursor
Set the CROSSHAIR setting to ON to activate the function. Then select
one of the rectangular grids (marked in the illustration below) and click
.
Select the desired color and line thinkness. Then draw a new crosshair
cursor.
Once complete, click Save. The new crosshair cursor will appear on the
screen.
- 13 -
Page 14
OSD Sidekick Installation Guide
Exporting/Importing the Crosshair Cursor
D Click Export to export the Crosshair le to the specied folder.
Browse the location and enter the le name. Then click OK to export
the le.
Note: The default Crosshair folder is located at the OSDsidekick installation
path.
D Click Import to import the Crosshair le from the specied folder.
Browse the location and select the Crosshair le to import. Then click
OK to import the le.
Note: The default Crosshair folder is located at the OSDsidekick installation
path.
- 14 -
Page 15
OSD Sidekick Installation Guide
Customizing the PIP/PBP Settings
Set the Picture-in-Picture (PIP)/ Picture-by-Picture (PBP) setting
to ON to activate the function. Select any of the following items to
congure the PIP/PBP settings:
D Click PBP to display the screen image from two sources side by side.
D Click PIP to display the screen image from the main source on the
full screen and the second source in a sub window.
D In PBP/PIP SOURCE, click the q icon to select the main source.
D If you have selected the PIP layout, in PIP SIZE, click the q icon to
set the sub window size to Large, Medium, or Small.
D If you have selected the PIP layout, in PIP LOCATION, click the q
icon to set the sub window location to Left-Top, Right-Top, Left-
Bottom, or Right-Bottom.
D Click PBP DISPLAY SWITCH to switch the main source and sub source,
regardless the screen layout.
D Click PBP AUDIO SWITCH to switch the audio source, regardless the
screen layout.
- 15 -
Page 16
OSD Sidekick Installation Guide
Customizing the Dashboard Information
Set the DASHBOARD setting to ON to activate the function. Then
congure the following settings:
D In LOCATION, click the q icon to set the location of the options on
the screen to Up or Down.
Note: The DASHBOARD location on the right side or on the left side of the
screen depends on the Game Assist location setting. For example, if the
Game Assist items are on the left side of the screen, then the DASHBOARD
items are on the right side of the screen and vice versa.
D Click SETTINGS and check the desired option(s) to be shown on the
screen.
Note: Uncheck the option to hide it from the screen.
- 16 -
Page 17
OSD Sidekick Installation Guide
Customizing the Game Assist Settings
Congure the following Game Assist settings:
D Set the REFRESH RATE setting to ON to enable displaying the
refresh rate.
D Set the GAMING TIMER setting to ON to enable displaying the
gaming timer.
- Select either COUNT UP or COUNT DOWN the timer.
- Click the q icon to set the countdown time.
D Set the GAMING COUNTER setting to ON to enable displaying the
gaming counter.
D In LOCATION, click the q icon to set the gaming counter location on
the screen to Left Top, Left Center, Left Bottom, Right Top, Right
Center, or Right Bottom.
- 17 -
Page 18
OSD Sidekick Installation Guide
HOT KEY
Manage the keyboard shortcut to access a particular function which
you are using frequently.
Note: By default, the assigned hot keys appears on the right panel.
Assigning a Hot Key
On the left panel, scroll down to select the function you want to assign
a hot key to.
Note: A function hot key consists of one or more modier keys (Alt, Shift, Ctrl)
plus a symbol.
- 18 -
Page 19
OSD Sidekick Installation Guide
Editing a Hot Key
To edit a hot key, do as follows:
1. Select the function on the left panel and assign a new hot key:
a) Click on one or more modier key(s): ALT , SHIFT, and/or CTRL.
b) Click on the symbol eld and enter any desired symbol.
2. Click ADD.
Modier keys Symbol eld
The hot key of the function appears on the right panel as illustrated
below:
Note: If a function has been set to a hot key, the item in the left eld will be
displayed in gray. To reassign the hot key, you have delete rst the current hot
key. To delete, refer to the “Deleting a Hot Key” section below.
Deleting a Hot Key
On the right panel, select the hot key you want to delete and click .
- 19 -
Page 20
OSD Sidekick Installation Guide
GENERAL SETTING
Congure the display screen, system, and hot keys (for the Control
button) related settings.
Display & System
RGB Controller
Hot Keys for
Control button
Changing the Hot Key for the Control Button
On the right panel (QUICK SWITCH), you can change the preset hot key
function for the Control button.
Select the key position ( / / /( ) and click the q icon. Then
select the desired option.
- 20 -
Page 21
OSD Sidekick Installation Guide
Conguring the LED Pattern
On the RGB CONTROLLER, click SETTING. The RGB FUSION software
opens.
Select the desired LED color and adjust its respective Speed and
Brightness settings.
Note: For more information, refer to the documentation that is included with
the RGB FUSION software.
- 21 -
Page 22
OSD Sidekick Installation Guide
ANC
With the Active Noise-Cancelling (ANC) function, it helps to reduce the
unwanted ambient sounds when you are using the headphones or
microphones.
Conguring the Noise-Cancelling Setting
On the Noise-Cancelling level option, select the desired setting.
Specifying the Microphone Position
On the right panel (Position), set the microphone position based on its
actual placement to ensure the best sound quality.
- 22 -
Page 23
OSD Sidekick Installation Guide
ABOUT
View the current rmware and software version and give you options to
update the latest version.
IMPORTANT! During the rmware updating process, do not turn o the
monitor. Any interruption may cause the device to malfunction.
Updating the Software Automatically
Click LIVE UPDATE to check and automatically update software when a
new version is available.
Set the Auto Update setting to ON to allow the system to check
for software updates and display a message when a new update is
available every time you open the app.
Note: Checking and updating software automatically requires Internet connection.
- 23 -
Page 24
OSD Sidekick Installation Guide
Updating the Firmware Manually
Note: Updating rmware manually does not require Internet connection.
1. Click DOWNLOAD. Then download the latest rmware from
GIGABYTE web site and save the le on your computer.
2. Click BROWSE. Then select for the rmware le (*.bin) and click OK.
3. The rmware le is displayed on the eld. Click UPDATE to update
the rmware to the latest version.
4. Wait until the updating process is complete. Once the process is
complete, a “Success” message appears on the screen. Then click OK
to close the message window.
- 24 -
Loading...
