USER INSTRUCTIONS FOR GET
PORTABLE 12k BTU AIR CONDITIONER
MODEL No. GPACU12HR
CONTENTS
Introduction
Safety Notes
Identification of parts
Installation instructions
Operation instructions
Maintenance
Troubleshooting
Introduction
Thank you for choosing this portable air conditioner to provide you and your family with all
of the “Home Comfort” requirements for your home, or office. The appliance can be moved
from room to room within your home and set-up in just minutes.
It is a multi-functional room air exchanging, air-processing appliance, designed to offer you
the functions of: Air Conditioning, Dehumidifying, Heating and Independent Fan.
This manual will provide you with valuable information necessary for the proper care and
maintenance for your new appliance. Read these instructions fully before operating the
unit and retain them for future reference. If properly maintained your appliance will give
you many years of trouble free operation.
SAFETY NOTES
1. Do not connect to any AC socket outlet that is damaged.
2. Do not use in the following locations:Next to a source of fire.
An area where oil is likely to splash.
An area exposed to direct sunlight.
An area where water is likely to splash
Near a bath, shower or a swimming pool
In a greenhouse
3. Never insert your finger or any foreign objects into the air outlet. Take special care to warn children
of these dangers.
4. Always store the unit upright in order to maintain the compressor in a proper working condition. If
not, leave the unit upright for at least 24 hours before operating.
5. Always unplug the unit before cleaning.
6. Do not cover the unit.
7. If the supply cord of this appliance becomes damaged, it must be replaced by a qualified engineer.
8. This appliance is fitted with an approved BS 1363 13A 3 pin plug and a 13A BS 1362 fuse. In the
event of either requiring replacement ensure that equivalent rated and approved components are
used. See plug replacement details below.
9. IMPORTANT:
ensure that the air replacement is sufficient for both the unit used as an air conditioner and the fuel
burning appliance
If the plug is damaged and requires replacement, follow the wiring instructions supplied with the new plug.
1. The green and yellow wire must be
connected to the terminal marked with
the letter E or the earth symbol.
2. The blue wire must be connected to
the terminal marked with the letter N.
3. The brown wire must be connected
to the terminal marked with the letter L.
4. A 13 amp plug to BS 1363 must be
fitted with a 13 Amp fuse to BS 1362.
If this unit is sited in a room containing a fuel burning appliance, the installer must
PLUG REPLACEMENT
For your safety and protection, this unit is earthed through the power cord plug when plugged into a
matching earthed wall socket. If you are not sure whether the wall sockets in your home are properly
earthed, consult a qualified electrician. Do not use plug adaptors or extension cords with this unit.
