7 5/16"
D225034
Lemora™
Single Handle Lavatory Faucet
SPECIFICATIONS
Features/Benets
• 1.2 gpm (4.5 L/min) Max Flow @ 60 psi with Laminar Water Stream
• Alternative Flow Rates Available with Spray Water Stream
• 1.0 gpm (3.8 L/min) When Used with DA613074N Aerator
• 0.5 gpm (1.9 L/min) When Used with DA613075N Aerator
• 5 1/16" Spout Height, 5 7/16" Spout Reach
• Ceramic Disc Cartridge
• Includes Metal Touch-Down Drain Assembly
• Single Hole Mount
• Optional Deck Plate, DA607568, Sold Separately
• Temperature Indicators Included on Faucet Body
Available Color/Finishes Mount Type Standards & Certications
Chrome
Please see gerberonline.com or current
price list for available finishes.
Finish is defined by additional suffix.
4"
(186mm)
5 7/16"
(138mm)
1 7/8"
(47.5mm)
2 1/2"max
(63.5mm)max
Ø
1 1/8"
- Ø 1 1/2"
(Ø 29mm - Ø 38mm) Hole Size
9/16-24UNEF-2B
45° 45°
8 3/4"
(220mm)
Ø
(Ø
1/2"min
1 1/2"~2 1/4"
(38.1~57mm)
1 1/4"
31.75mm)
5 1/16"
4 1/8"
(129mm)
12.7mm(min)
3°
(105mm)
Ø
(Ø
Ø
(Ø
M40X1.5
25°
1 15/16"
(48.5mm)
2 1/8"
54mm)
1 9/16"Max
40mm)
3"
(76mm)
1"
(24.8mm)
8 3/16"
(208mm)
25"
(635.5mm)
Submittal Information:
Name:
Location:
Replacement parts, call : /
Les pièces de rechange, appellez : /
Partes de reemplazo, llame : US
US www.gerberonline.com or CA www.gerberonline.ca
Contractor:
Contact #:
1-888-328-2383 /
CA
1-800-487-8372
05/20
