GV-3D People Counter V2 August 24, 2017
- 1 -
GV-3D People Counter V2
Introduction
The GV-3D People Counter V2 can count and analyze the number of people passing by the designated area at high precision counting
accuracy. With its Power over Ethernet and user-friendly interface, the counter is simple to use and easy to install. You can look up
neatly compiled people counting data in chart analysis with the support of GV-Web Report Lite, its built-in Web interface. In addition
to its sleek and stylish design, the counter also supports the I/O devices and GV-GPS Receiver for accessing people counting data
remotely.
Features
• High precision counting accuracy
• Counts the number of people (In and Out)
• Lightweight with sleek design
• Digital I/O (1 Input/1 Output)
• PoE (IEEE 802.3af)
• Low power consumption
• Built-in micro SD card slot (SD/SDHC/SDXC/UHS-I, Class 10) for local storage
• GPS positioning (optional GV-GPS Receiver and GV-Web Report software required)
• GV-Web Report Lite :Built-in Web interface to look up people counting data and charts
• Support for data compiling and chart analysis on the optional GV-Web Report software
* No SD/SDHC card slot & local storage function for Argentina.
Page 2
GV-3D People Counter V2 August 24, 2017
- 2 -
Dimensions
Overview
Bottom View
Rear View
Specifications
Page 3
GV-3D People Counter V2 August 24, 2017
- 3 -
External Interface
Ethernet
RJ45, 10/100 Ethernet (PoE Only)
Local Storage
Micro SD card slot (SD/SDHC/SDXC/UHS-I, Class 10)
Terminal Block
Input
1 Sensor Input
Output
GPS
UART
Power Over Ethernet
PoE Standard
PoE (IEEE 802.3af Power over Ethernet / PD)
PoE Power Supply Type
End-Span and Mid-Span
PoE Power Output
Per Port 48V DC, 350 mA, Max. 15.4 watts
General Information
Diagonal
92°
Horizontal
74°
Vertical
55°
Counting Accuracy
Up to 98%
Weather Resistance
Indoor only
Operating Temperature
0 °C ~ 40 °C (32 °F ~ 104 °F )
Operating Humidity
20 % ~ 80 % (with no condensation)
Operating Distance
1.8 ~ 4 m (5.91 ~ 13.12 ft.)
Power Source
PoE (IEEE 802.3af) Only
Max. Power Consumption
6.24 W
Dimensions (W x H x D)
150 x 48.5 x 37.5 mm (5.9 x 1.9 x 1.47 in)
Net Weight
200 g (0.44 lb)
Regulatory
CE, FCC, RCM compliant
Supported Browser
Microsoft Internet Explorer 10 or above
GV-VMS
GV-Web Report
GV-3D People Counter V2 V1.00
V16.10.3.0 or later
V2.2.6.0 or later
Name
Details
from up to 1000 units of GV-3D People Counter V2s. Compatible version: V2.2.6.0 or later.
GV-POE Switch is available in various models with different numbers and types of ports.
Angle of View
1 Alarm Output
Language English, Traditional Chinese, Simplified Chinese, Russian, French
Compatible Firmware and Software Versions
Note: All specifications are subject to change without notice.
Options for 3D People Counter V2
Receive the GPS signals for 3D People Counter positioning.
GV-GPS Receiver
GV-Web Report
Through a Web browser, the GV-Web Report keeps track of and analyzes the people counting results
The GV-PA191 is a Power over Ethernet (PoE) adapter designed to provide power to the IP device
through a single Ethernet cable.
GV-PA191
GV-POE Switch
The GV-POE Switch is designed to provide power along with network connection for IP devices. The
Page 4
GV-3D People Counter V2 August 24, 2017
- 4 -
Packing List
1. GV-3D People Counter V2
2. SDHC Micro SD card (8 GB)
3. Ceiling Mount Kit
4. Wall Mount Kit
5. Installation Sticker x 2 (Wall mount / Ceiling mount)
6. Screw x 4
7. Anchor x 2
8. Documents Download Guide
9. Warranty Card
