Page 1
TABLE OF CONTENTS
INTRODUCTION .............................................................................3
SYSTEM REQUIREMENT............................................................4
IPCAM SECURE300........................................................................... 4
Network:......................................................................................... 4
Recommended PC or Notebook to Access the IPCam SECURE300
....................................................................................................... 4
FEATURES AND BENEFITS......................................................6
SIMPLE TO USE ................................................................................... 6
SUPPORT VARIETY OF PLATFORMS ..................................................... 7
WEB CONFIGURATION......................................................................... 7
REMOTE UTILITY ................................................................................ 7
BROAD RANGE OF APPLICATIONS ....................................................... 8
PHYSICAL DESCRIPTION..........................................................9
FRONT PANEL...................................................................................... 9
Power LED..................................................................................10
Link LED...................................................................................... 10
REAR PANEL ..................................................................................... 11
Network Cable Connector ........................................................... 11
DC Power Connector...................................................................11
Reset Button................................................................................. 12
TOP PANEL ........................................................................................ 13
Screw Hole................................................................................... 13
BOTTOM PANEL ................................................................................ 14
Screw Hole................................................................................... 14
UNPACKING THE IPCAM SECURE300 ..............................15
CONNECTING THE IPCAM SECURE300 TO THE CAMERA STAND .....16
Page 2
HARDWARE INSTALLATION ..................................................17
1 CONNECT AN ETHERNET CABLE ..................................................... 17
2 ATTACH THE EXTERNAL POWER SUPPLY......................................... 18
SECURITY........................................................................................19
SOFTWARE INSTALLATION................................................... 21
WEB CONFIGURATION....................................................................... 21
MAIN MENU IMAGE .......................................................................... 23
SYSTEM ADMINISTRATION ................................................................ 24
SYSTEM ADMINISTRATION ................................................................ 24
System Administration – System.................................................. 24
System Administration - Image.................................................... 32
System Administration - Users..................................................... 34
System Administration – DateTime.............................................. 36
System Administration – Upload................................................. 38
System Administration – E-mail................................................... 41
System Administration - Information........................................... 43
System Administration - Tools..................................................... 44
VIEW IMAGE – ACTIVEX MODE ........................................................45
VIEW IMAGE – JAVA MODE............................................................... 47
IPCAM SECURE300 APPLICATION .....................................49
APPLICATIONS...................................................................................50
IPCAM SECURE300 APPLICATION DIAGRAMS ................................ 51
Home Applications.......................................................................51
IPVIEW SE APPLICATION.......................................................52
INSTALLATION................................................................................... 52
GETTING STARTED ....................................................................58
IPVIEW SE ........................................................................................ 58
IPView SE control panel..............................................................59
Minimize ...................................................................................... 60
Exit............................................................................................... 60
Play..............................................................................................60
1
Page 3
Scan ............................................................................................. 60
Combine....................................................................................... 60
About............................................................................................ 60
HOW TO ADD A CAMERA .................................................................. 61
Add Camera................................................................................. 61
HOW TO CHANGE CAMERA ............................................................... 66
Assign IP of New Camera............................................................ 66
HOW TO CONNECT / DISCONNECT THE IMAGE................................... 67
Connect the Image....................................................................... 67
Disconnect the Image................................................................... 70
HOW TO DELETE A CAMERA ............................................................. 71
Erase Camera.............................................................................. 71
EXTRA INFORMATION........................................................................ 72
Extra Information........................................................................ 72
HOW TO ADJUST THE PROPERTY SETTING......................................... 73
System Configure......................................................................... 73
Camera Configure....................................................................... 75
Camera Setting ............................................................................ 75
Motion Setting.............................................................................. 76
Update Firmware......................................................................... 78
HOW TO ADJUST THE RECORDING SETTING ...................................... 79
Motion Record ............................................................................. 79
Schedule Record.......................................................................... 79
Manual Record............................................................................ 79
APPENDIX .......................................................................................80
A FREQUENTLY ASKED QUESTIONS .................................................. 80
B PING YOUR IP ADDRESS............................................................... 83
C TROUBLE SHOOTING ...................................................................... 84
D TIME ZONE TABLE......................................................................... 88
E XPLUG CONTROL INSTALLATION...................................................90
F ADJUST IPCAM SECURE300 FOCUS ............................................. 94
G SPECIFICATION .............................................................................. 95
HGLOSSARY OF TERMS ..................................................................... 98
2
Page 4
1
INTRODUCTION
Thank you for the purchase of the IPCam SECURE300
connecting directly to an Ethernet or Fast Ethernet. It is different
from the conventional PC Camera, the IPCam SECURE300 is a
standalone system with built-in CPU and web-based solutions
providing a low cost solution that can transmit high quality video
images for monitoring. The IPCam SECURE300 can be
managed remotely, accessed and controlled from any
PC/Notebook over the Intranet or Internet via a web browser.
The simple installation procedures and web-based interface offers
easy integration to your network application environments
coupled with many applications such as remote monitoring for a
cost-effective solution.
3
Page 5
2
SYSTEM
REQUIREMENT
IPCam SECURE300
Network:
Local Area Network: 10Base-T Ethernet or 100Base
TX Fast Ethernet
Recommended PC or Notebook to Access the IPCam SECURE300
Web Browser:
System requirement:
CPU: Pentium II, 266 MHz or above
Memory Size: 32 MB (64 MB recommended)
VGA card resolution: 800x600 or above
• Internet Explorer 5.0 or above (ActiveX & JAVA Mode –
Image View for Windows OS and JAVA Mode – Image
View for other OS)
• Netscape 6.0 or above (JAVA Mode – Image View)
4
Page 6
IPView SE Application:
Support OS: Win 98 SE, Win 2000, Win Me, Win XP
System requirement for IPView SE:
CPU: Pentium III, 450 MHz or above
Memory Size: 128 MB (256 MB recommended)
VGA card resolution: 800x600 or above
5
Page 7
3
FEATURES AND
BENEFITS
This section describes the features and benefits of the IPCam
SECURE300
Simple To Use
The IPCam SECURE300 is a standalone system with built-in
CPU requiring no special hardware or software such as PC frame
grabber cards. The IPCam SECURE300 supports both ActiveX
mode (for Internet Explorer users) and Java mode (for Internet
Explorer and Netscape Navigator users). Therefore, all that is
required is a web browser software such as Internet Explorer 5.0
or above or Netscape 6.0 or above. Just plug and view the picture
from your IPCam SECURE300 with a valid IP Address.
6
Page 8
Support Variety of Platforms
The IPCam SECURE300 supports TCP/IP networking, SMTP email, HTTP and other Internet related protocols, and can be
utilized in a mixed operating system environment such as
Windows, Unix, and Mac. It can be integrated easily into other
www/Intranet applications.
Web Configuration
Applying a standard web browser, the administrator can configure
and manage the IPCam SECURE300 directly from its own web
page via the Intranet or Internet. Up to 64 users name and
password are permitted with privilege setting controlled by the
administrator.
Remote Utility
The powerful IPView SE application assigns the administrator
with a pre-defined user ID and password, allowing the
administrator to modify the IPCam SECURE300 settings from
the remote site via Intranet or Internet. When new firmware is
available, you can also upgrade remotely over the network for
added convenience. Users are also allowed to monitor the image,
and take snapshots.
7
Page 9
Broad Range of Applications
With today’s high-speed Internet services, the IPCam
SECURE300 can provide the ideal solution for live video images
over the Intranet and Internet for remote monitoring. The IPCam
SECURE300 allows remote access from a web browser for live
image viewing and allows administrator to manage and control
the IPCam SECURE300 anywhere and any time in the world.
Apply the IPCam SECURE300 to monitor various objects and
places such as homes, offices, banks, hospitals, child-care centers,
amusement parks and other varieties of industrial and public
monitoring. The IPCam SECURE300 can also be used for
intruder detection; in addition, it can capture still images for
archiving and many more applications.
8
Page 10
4
PHYSICAL
DESCRIPTION
This section describes the externally visible features of the IPCam
SECURE300.
Front Panel
Link LED
Power LED
9
Page 11
Power LED
The Power LED is positioned on the right side of the IPCam
SECURE300’s lens while facing the IPCam SECURE300.
A steady blue light confirms that the IPCam SECURE300 is
powered on.
Link LED
The Link LED is positioned on the right side of the IPCam
SECURE300’s lens while facing the IPCam SECURE300. It is
located right of the Power LED
A steady orange light confirms that the camera has good
connection to LAN connectivity.
Dependent on the data traffic the LED will begin to flash to
indicate that the IPCam SECURE300 is receiving/sending data
from/to the network.
10
Page 12
Rear Panel
Network Cable Connector
The IPCam SECURE300’s rear panel features an RJ-45
connector for connections to 10Base-T Ethernet cabling or
100Base-TX Fast Ethernet cabling (which should be Category 5
twisted-pair cable). The port supports the NWay protocol,
allowing the IPCam SECURE300 to automatically detect or
negotiate the transmission speed of the network.
DC Power Connector
10/100 Ethernet
Network Cable
Connector
Reset
DC 5 V
Reset Button
DC Power
Connector
The DC power input connector is located on the IPCam
SECURE300’s rear panel, and is labeled DC 5V with a single
jack socket to supply power to the IPCam SECURE300. Power
will be generated when the power supply is connected to a wall
outlet.
11
Page 13
Reset Button
Reset will be initiated when the reset button is pressed once, and
Power LED begins to flash.
Factory Reset will be initiated when the reset button is pressed
continuously for three seconds or when Power LED begins to
light up. Release the reset button and the Power LED will begin
to flash, indicating the IPCam SECURE300 is changing to factory
reset. When factory reset is completed, the IPCam SECURE300
will be set to default value. The IP address will also return to the
default setting as 192.168.0.20.
12
Page 14
Top Panel
Screw Hole
Screw Hole
Located on the top panel of the IPCam SECURE300, the screw
hole is used to connect the camera stand onto the IPCam
SECURE300 by attaching the screw head on the camera stand
into the screw hole of the IPCam SECURE300.
13
Page 15
Bottom Panel
Screw Hole
Screw Hole
Located on the bottom panel of the IPCam SECURE300, the
screw hole is used to connect the camera stand onto the IPCam
SECURE300 by attaching the screw head on the camera stand
into the screw hole of the IPCam SECURE300.
14
Page 16
5
UNPACKING THE
IPCAM SECURE300
Carefully remove all items from the package. In addition to this
User’s Guide, be certain that you have:
• One IPCam SECURE300
• One Installation CD-ROM
• One Quick Installation Guide
• One DC power adapter suitable for your country’s
electric power
• One Camera Stand
• One RJ-45 Ethernet Cable
15
Page 17
Connecting the IPCam SECURE300 to the Camera Stand
The IPCam SECURE300 comes
with a camera stand (optional) with a
swivel ball screw head that can be attached
to the 's bottom
screw hole. Attach the camera stand to
the IPCam SECURE300 and station
it for your application. There are three holes
located in the base of the camera stand
allowing the IPCam SECURE300 to
be mounted on the ceiling or any wall
securely.
16
Page 18
6
HARDWARE
INSTALLATION
This section describes the Hardware installation procedure for the
IPCam SECURE300.
1 Connect an Ethernet cable
Connect an Ethernet cable to the
network cable connector located
on the IPCam SECURE300’s
rear panel, and then attach it to
the network.
10/100 Eth ernet
Reset
DC5V
17
Page 19
2 Attach the external power supply
Attach the external power
supply to the DC power input
connector located on
IPCam SECURE300’s rear panel,
and then connect it to your local
power supply.
Note:
Confirm power source is supplied
from the LED indicators label
Power on the IPCam SECURE300
Is illuminated.
10/100Ethernet
Reset
DC5V
18
Page 20
7
SECURITY
To ensure the highest security and prevent unauthorized usage of
the IPCam SECURE300 the Administrator has the exclusive
privilege to access the System Administration for settings and
control requirements to allow users the level of entry and
authorize the privileges for all users. The IPCam SECURE300
supports multi-level password protection and access to the IPCam
SECURE300 is strictly restricted to define the user who has a
"User Name" and "User Password" that is assigned by the
Administrator.
Administrator can release a public user name and password so
when remote users access the IPCam SECURE300 they will have
the right to view the image transmitted by the IPCam
SECURE300.
Note:
Since the default settings are Null String, it is highly
recommended to set the "Admin ID" and "Admin Password"
when you are the first time to use the IPCam SECURE300. Once
the ID and Password are defined, only the administrator has the
access to management the IPCam SECURE300. This procedure
should be done as soon as possible since the security features with
19
Page 21
the IPCam SECURE300 will not be enabled until the "Admin ID"
and "Admin Password" is defined.
20
Page 22
8
SOFTWARE
INSTALLATION
This section describes the Software installation procedure of the
IPCam SECURE300 for Web Configuration and IPView SE
application.
Web Configuration
The IPCam SECURE300 must be configured through its built-in
Web-based Configuration.
Extensive knowledge of LAN will be helpful in setting up the
IPCam SECURE300
From the web browser, enter the default IP address to access the
Welcome screen of the IPCam SECURE300. To configure your
IPCam SECURE300, type http://192.168.0.20 in the address box.
21
Page 23
The number is the default IP address of your IPCam SECURE300.
Then, press [Enter]
.
Note:
The PC’s IP address must correspond with the IPCam
SECURE300’s IP address in the same segment for the two
devices to communicate. Therefore, if your PC’s IP address
doesn’t not correspond with the IPCam SECURE300’s IP
address, you MUST modify your PC’s IP address at first.
22
Page 24
Main Menu Image
After the default IP address is entered from the browser, the
IPCam SECURE300 Welcome screen will appear with a still
image. There will be three options to choose from to set-up and
view your IPCam SECURE300, including:
z View Image – ActiveX Mode
z View Image – Java Mode
z System Administration
23
Page 25
System Administration
Click “System Administration” from the Welcome screen to
access the settings required for the IPCam SECURE300.
There will be several options in the System menu bar to choose
from to set your IPCam SECURE300, including:
z System
z Image
z Users
z Date Time
z Upload
z E-mail
z Information
z Tools
System Administration
System Administration – System
The System menu contains commands for settings that are
required for inputting key details to set-up the IPCam
SECURE300 for operation.
Click "System" in the system administration menu bar, and the
System screen will appear as illustrated below:
24
Page 26
25
Page 27
Click “Home” to
return to Welcome
Screen
26
Page 28
Camera Name:
This field is used to enter a descriptive name for the device.
The default setting for the Camera Name is CS-xxxxxx, where
xxxxxx is the last six digit of the MAC Address. The maximum
length is 32 (Printable ASCII).
Location:
This field is used to enter a descriptive name for the location used
by the IPCam SECURE300.
Admin:
This field is used to enter the Administrator ID along with the
password to access the System Administration settings. Be sure
to enter the password twice to confirm the details once in the
Admin Password field and again in the Confirm Password field.
The default setting for Admin is blank space (Null String), and
you need to key in the Admin ID with a maximum length of 12
(Printable ASCII) characters and enter the Admin Password with
a maximum length of 8 (Printable ASCII) characters.
It is highly recommended to set the Admin ID and Admin
Password as soon as possible to enable security option for the
IPCam SECURE300 to function.
IP Assignment:
Access to the IPCam SECURE300 is done through assigning a proper
IP address. Please make sure to use a vacant IP address when you
assign the IP address for the IPCam SECURE300. This will prevent
errors from occurring if the IP address is overlapped.
Important Information
27
Page 29
There are two options to select from the IP Assignment:
Manually Assign or Assign Automatically Using.
Manually Assign
You can click “Manually Assign” and directly enter the IP
address.
The default settings are as follows:
• Default IP – 192.168.0.20
• Subnet Mask – 255.255.255.0
• Default Gateway – 0.0.0.0
Assign Automatically Using
If your network is using RARP, BOOTP or DHCP server, you
can click “Assign Automatically Using” and then click
“RARP”, “BOOTP” or “DHCP”. Under this setting the IPCam
SECURE300 will automatically assign an IP address from RARP,
BOOTP or DHCP server. Every time when the camera starts up,
please make sure that the DHCP server is set to assign a static IP
address to your camera.
If your application requires direct connection from an ADSL
modem through the IPCam SECURE300’s RJ-45 LAN port, and
you also have an ISP PPPoE account, click “PPPoE” option and
enter the Service Name, User ID and Password into the respective
fields. The IPCam SECURE300 will get an IP address from the
ISP as starting up.
28
Page 30
DNS IP Address:
DNS (Domain Name System) server is an Internet service that
translates domain names into IP addresses. Enter at least one
DNS IP Address.
Dynamic DNS:
The Dynamic DNS service allows you to alias a dynamic IP
address to a static hostname in any of the domains, allowing your
computer to be more easily accessed from various locations on
the Internet.
LED Control:
The LED control allows user to setup the LED illumination as
desired. This feature provides the flexibility when surveillance
activity is ON.
There are three options as follows:
z Normal –
Power - Steady On of the LED indicator.
Link - Steady On of the LED indicator. When
LAN activity is present the LED indicator will
flash steadily.
z OFF –
Power - LED indicator is off
Link – LED indicator is off
z Dummy –
Power - Steady On of the LED indicator.
Link -
random flashing.
Steady On of the LED indicator with
The default setting for the LED control is at Normal. When you
have configured the LED control, the correct illumination will be
set after 1 minute.
29
Page 31
Note:
This function is built-in to the LED indicators to add extra
capabilities. The three options allow the Administrator to
configure and camouflage the illumination for the LED indicator
to falsify the monitoring status. In Normal Mode, the LED
indicator functions normally. Under Off Mode, the LED
indicators are both off; however, it is still monitoring the activity.
In Dummy Mode, the LED indicators operate in monitoring
condition but monitoring activity is off or on.
Loading ActiveX From:
This field is used to specify the location of Xplug Control
(ActiveX) plug-in program. Enter the information as required
in .ocx format, for example:
http://www.<your company>.com/xplug.ocx, where <your
company> must be replaced with your company’s DNS server.
Or it can be installed from the CD come with the IPCam
SECURE300.
Open Second Port:
The Web Server field allows settings to open a second port for the
IPCam SECURE300. This will permit users IP Sharing
Gateways to support multiple IPCam SECURE300s. By default,
Port 80 is always opened for the IPCam SECURE300 Web Server
access. Select “Yes” and input the second port value.
For example: If you have 5 IPCam SECURE300 to be installed,
each with an IP address from
192.168.0.101
192.168.0.102
192.168.0.103
192.168.0.104
30
Page 32
192.168.0.105
You can open the second port for each IPCam SECURE300 from
port 81 to Port 85 as illustrated below:
IPCam SECURE300 1 – IP 192.168.0.101, second web port 81
IPCam SECURE300 2 – IP 192.168.0.102, second web port 82
IPCam SECURE300 3 – IP 192.168.0.103, second web port 83
IPCam SECURE300 4 – IP 192.168.0.104, second web port 84
IPCam SECURE300 5 – IP 192.168.0.105, second web port 85
You also need to setup your DSL gateway for Port Mapping.
Port 81 map to 192.168.0.101
Port 82 map to 192.168.0.102
Port 83 map to 192.168.0.103
Port 84 map to 192.168.0.104
Port 85 map to 192.168.0.105
The Transfer Image field allows settings to open a second port for
the IPCam SECURE300 to transfer images. The default Port
8481 is open image transfer and you can define a second port
similar to the above.
Save/Cancel:
After making sure all settings in the System are correct, click the
“Save” button to store the settings for the IPCam SECURE300.
You can alternatively click the “Cancel” button to restore all
settings to the values last saved to or retrieved from the IPCam
SECURE300.
31
Page 33
System Administration - Image
Image menu in the system administration contains commands to
provide the settings for the images captured by the IPCam
SECURE300.
Click “Image” in the system administration menu bar and the
Image screen will appear as illustrated below:
Click “Home” to
Video Resolution:
Select the desired video resolution format ranging from 320x240
(default) to 640x480
Compression Rate:
Select the desired compression rate with five levels from very low
to very high. Higher video compression rate will generate more
compact file size with less video quality and vise-versa. The
default setting is Medium.
32
Page 34
Frame Rate:
Select the frame rate desired with default setting at Auto for
optimal frame rate.
Brightness Control:
Adjust the brightness level with default setting at 64.
Contrast Control:
Adjust the contrast level with default setting at 64.
Saturation Control:
Adjust the saturation with default setting at 64.
Light Frequency:
Adjust the light frequency to suit your area of operation from the
options either 50 Hz or 60 Hz (default).
Note:
50 Hz and 60 Hz variants are available to accommodate the
different light frequency found in USA (60 Hz) and Europe (50
Hz) for the IPCam SECURE300 to ensure better image quality.
Save/Cancel:
After making sure all settings in the Image are correct, click the
“Save” button to store the settings for the IPCam SECURE300.
You can alternatively click the “Cancel” button to restore all
settings to the values last saved to or retrieved from the IPCam
SECURE300.
33
Page 35
System Administration - Users
The User options menu contains commands to allow the system
administrator to assign legal users who are permitted to monitor
the IPCam SECURE300 from the remote site.
Click “Users” in the system administration menu bar and the
Users screen will appear as illustrated below:
Click “Home” to
return to Welcome
Add User:
User Name:
Enter the user name in this field.
A maximum of 64 users names are allowed, however each users
name must be different. Each user name can be used as a group
given the password for example, if the User Name is “Guest” and
the User Password is “Guest” anyone can access the IPCam
SECURE300 with these details used as a group of users under the
User Name Guest. The maximum length for the User Name is 12
(Printable ASCII).
User Password:
Enter the user’s password assigned by the administrator. The
maximum password length is 8 (Printable ASCII).
Screen
34
Page 36
Delete User:
Select the user you wish to delete from the pull down menu and
click the “delete” button.
Once the administrator has configured the IPCam
SECURE300 Users, any user will be asked to enter a login
password to access the video image from the IPCam
SECURE300. The password dialog box is illustrated below.
Important Information
192.168.0.20
35
Page 37
System Administration – DateTime
The DateTime menu contains commands for setting the IPCam
SECURE300's time and date requirements to provide correct
information to users who might be thousands of miles away in the
remote site. There are two options to select from the DateTime
menu bar either Synchronized with Time Server or Set Manually.
Click “DateTime” in the system administration menu bar and the
DateTime screen will appear as illustrated below:
Click “Home” to
return to Welcome
Screen
DateTime:
Select “Synchronized with Time Server” and the time will be
based on GMT setting. The time will be synchronized every 10
minutes. This is also the default setting for the IPCam
SECURE300.
IP Address:
Enter the IP Address of the Time Server in this field.
36
Page 38
Protocol:
Two options of NTP or Time are available for your selection to
link with the Time Server. The default setting is NTP.
TimeZone:
The system administrator must select the time zone for the region.
Please refer to the appendix for the time zone selection table.
To set the Date Time manually, select “Set Manually” and the
system administrator must enter the Date and Time in the
respective field manually.
Note:
When you select Set Manually, every time when the IPCam
SECURE300 is powered off and on, you must re-enter the details
once again due to time lost.
Save/Cancel:
After making sure all settings in the DateTime are correct, click
the “Save” button to store the settings for the IPCam
SECURE300. You can alternatively click the “Cancel” button to
restore all settings to the values last saved to or retrieved from the
IPCam SECURE300.
37
Page 39
System Administration – Upload
The Upload menu contains the commands for FTP server, time
schedule and manual operation settings.
Click “Upload” in the system administration menu bar, and the
Upload screen will appear as below:
Click “Home” to
return to Home Screen
38
Page 40
There are three options to proceed in the Upload screen, including
FTP Server, Time Schedule and Manual Operation.
FTP Server:
There are six basic settings for your FTP server.
• Host Address: The IP Address of the target FTP server.
• Port Number: The standard port number for the FTP
server is Port 21, and it’s also the default setting. If the
FTP server uses a specific port, please confirm the IT
manager.
• User Name: Enter the user name in this field.
• Password: Enter the user password in this field to login
the FTP server.
• Directory Path: Enter an existing folder name in this
field, and the images will be uploaded to the given folder.
• Passive Mode: This function depends on your FTP
server. Please check with your IT manager if the FTP
server uses passive mode. The default setting is ‘No’.
Time Schedule:
Select “Upload image to FTP server” and enter the relevant
information, such as the schedule, image frequency and base file
name.
• Schedule: You can 1.) Choose Always to always upload
the images to FTP server, or 2.) Set the Schedule to
39
Page 41
manage the uploading task. In the Schedule option, you
can set the Day and Time Period option.
• Image Frequency: There are two ways to set the image
frequency: 1.) Set Auto/1/2/3 frames per second, or 2.)
Set the time in seconds for every frame.
• Base File Name: Enter the file name to make sure that
the images could be saved as the base file name.
• File: Since you may not upload only one image to the
FTP server, you can choose the filing rule, including
Overwrite, Date/Time Suffix, and set up the Sequence
Number.
Manual Operation: When you click the upload “Image” button
in view image screen, it will start to upload the image. The
setting refers to “Base File Name” and “File” information above.
Save/Cancel:
After making sure all settings in the System are correct, click the
“Save” button to store the settings for the IPCam SECURE300.
You can alternatively click the “Cancel” button to restore all
settings to the latest saved values or retrieve the settings from
IPCam SECURE300.
40
Page 42
System Administration – E-mail
The E-mail menu contains the commands for E-mail account,
time schedule and manual operation settings.
Click “E-mail” in the system administration menu bar, and the
setting screen will appear as below:
Click “Home” to
return to Home Screen
Enter the relevant information, such as the SMPT Server Address,
Sender e-mail Address, Receiver e-mail Address, User Name and
Password.
Then active sending e-mail by selecting “Enable e-mail Image”
in enter “Time schedule” or “Manual Operation”.
41
Page 43
• SMTP (Simple Mail Transfer Protocol) is a protocol for
sending e-mail messages between servers you need to
input the mail server address in this field.
• Sender e-mail is the e-mail address of the user who will
send the e-mail.
• Receiver e-mail is the e-mail address of the user who
will receive the e-mail.
• User Name: Enter the user name in this field.
• Password: Enter the user password in this field to login
receiver’s mail server
Time Schedule:
To set schedule to send e-mail.
“Interval”: Define time interval between two images sent.
Manual Operation:
When you chick the E-mail image button in view image screen, it
will start to e-mail image.
“Interval”: To define time interval between two images sent.
Save/Cancel:
After making sure all settings in the System are correct, click the
“Save” button to store the settings for the Wireless IPCam
SECURE300. You can alternatively click the “Cancel” button to
restore all settings to the values last saved to or retrieved from the
Wireless IPCam SECURE300.
42
Page 44
System Administration - Information
The Information menu contains commands for displaying
information about the IPCam SECURE300.
Click “Information” in the system administration menu bar and
the Information screen will appear as illustrated below:
Click “Home” to
return to Welcome
Screen
The Information table provides detailed information of the IPCam
SECURE300, such as the Model Name, Firmware Version, Mac
Address, and IP Address.
43
Page 45
System Administration - Tools
The Tools menu contains commands for restarting the IPCam
SECURE300.
Click “Tools” in the system administration menu bar and the
Tools screen will appear as illustrated below:
Click “Home” to
return to Welcome
Reset:
The Reset command restarts the IPCam SECURE300 just like
turning the device off and on and saved settings are retained. The
Reset panel contains the message “Do you really want to reset
this device?” and a YES button. If you do not want to reset the
IPCam SECURE300, exit the panel without clicking YES;
otherwise, click the “YES” button and the reset process will
initiate.
Factory Reset:
A factory reset restarts the IPCam SECURE300 and returns all of
its settings to their default values. The Factory Reset panel
contains the message “Do you really want to factory reset this
device?” and a YES button. If you do not want to carry out a
factory reset command, exit the panel without clicking YES;
otherwise, click the “YES” button and factory reset will be
initiated.
44
Screen
Page 46
Note:
The Network must be reconfigured after a Factory Reset.
Once the configuration is completed, click “Home” to return to
the Welcome screen and select the desired Viewing Image either
through ActiveX Mode or Java Mode as described in the next
section.
Then, position the IPCam SECURE300 to the desired location
appropriately for your purpose. Followed by adjustment of the
IPCam SECURE300 focus, done manually by turning the lens
clockwise or anti-clockwise to the desire image quality. Please
refer to the appendix for detailed information regarding Adjust
IPCam SECURE300 Focus and Replacing the Lens.
View Image – ActiveX Mode
To view video images from the browser, click “View Image –
ActiveX Mode” from the welcome screen to access the video
images from Internet Explorer as illustrated below:
Camera Name*
Date Time***
Click “Home” to
return to Welcome
Screen
45
Page 47
Camera Name* - The Camera name will be display when the
Camera Name field is entered in the Web Configuration setting
under “System”
Date/Time***- The date/time of the video server will show the
date and time that come from time server or you set manually.
Note:
Please refer to the appendix on how to install ActiveX.
1. Install to the Web Server
2. Install to your Local PC
In the View Image – ActiveX Mode, you are allowed upload
image and E-mail image options. Just click the desired selection
“ON” or “OFF” to utilize the options for each of the functions.
Note 1:
Administrator has the authority to set the email image functions
through the setting in the “E-mail” of System Administration
menu bar.
Note 2:
The Administrator has the authority to allow the users to set the
image upload functions through the setting in the “Upload” of
System Administration menu bar.
46
Page 48
View Image – Java Mode
Click “View Image – Java Mode” from the Welcome screen to
access the video images from the Internet Explorer or Netscape
browser as illustrated below:
Camera Name*
Date/Time***
Click “Home” to
return to Welcome
Screen
Camera Name* - The Camera name will be display when the
Camera Name field is entered in the Web Configuration setting
under “System”
Date/Time***- The date/time of the IPCam SECURE300 will
show the date and time that come from time server or you set
manually.
In the View Image – ActiveX Mode, you are allowed upload
image and E-mail image options. Just click the desired selection
“ON” or “OFF” to utilize the options for each of the functions.
47
Page 49
Note 1:
Administrator has the authority to set the email image functions
through the setting in the “E-mail” of System Administration
menu bar.
Note 2:
The Administrator has the authority to allow the users to set up
the image upload functions through the setting in the “Upload” of
System Administration menu bar.
48
Page 50
9
IPCAM SECURE300
APPLICATION
The IPCam SECURE300 can be applied in wide variety of
applications. With the built-in CPU, it can work as a standalone
system that provides a web-based solution transmitting high
quality video images and sounds for monitoring purposes. It can
be managed remotely, accessed and controlled from any PC
desktop over the Intranet or Internet via a web browser. With the
easy installation procedure, real-time live images will be available.
In addition, once the IPCam SECURE300 is installed coupled
with the IPView SE application, you can further expand the scope
of the IPCam SECURE300.
The following section will provide the typical applications for the
IPCam SECURE300 along with the IPView SE application, and
also includes some basic knowledge to assist in the installation
and configuration of the IPCam SECURE300.
49
Page 51
Applications
• Monitoring of local and remote places and objects such as
construction sites, hospitals, amusement parks, schools
and day-care centers through the use of a web browser.
• Capture single frame images from the IPView SE
application.
• Configure the camera to upload image or send-mail
messages with a single frame image.
50
Page 52
IPCam SECURE300 Application Diagrams
Home Applications
51
Page 53
10
IPVIEW SE
APPLICATION
Installation
Insert the CD-ROM into the CD-ROM drive to initiate the autorun program. Once completed, a menu screen will appear as
below:
52
Page 54
To install the IPView SE application click the "IPView SE"
button to activate the installation procedure for the application
program.
Once executed, you will be asked to select the desired language.
Select the language you want and click “OK” to continue.
53
Page 55
The Welcome screen will appear as below. Click the “Next”
button.
The License Agreement window will appear as below. Read the
details carefully and click the “Yes” button.
54
Page 56
In the following window, you may click “Next” to accept the
recommended destination location or click “Browse” to select
another location. After specifying the desired destination location,
click “Next”.
The following window allows you to select the folder where the
IPView SE application will be located, click “Next” to continue.
55
Page 57
Please wait until one of the following two dialog boxes to appear.
If the system has to restart, select “Yes, I want to restart my
computer now” and click the “Finish” button to complete the
installation procedure.
Otherwise, you may simply click the “Finish” button to complete
the installation procedure
56
Page 58
After successfully installing the IPView SE, the application
program for the IPCam SECURE300 is automatically installed to
\Programs\Files directory.
To start running the IPView SE, click Start -> Programs ->
IPView SE -> IPView SE.
Once login, the IPView SE application is executed and the
interface of IPView SE will appear in the default List View
format as bellow:
57
Page 59
11
GETTING STARTED
This section describes the operation of the IPView SE application
with detailed procedures for using the application.
IPView SE
IPView SE is responsible for the management of preview,
configuration, and searching of each camera.
It is designed with a user-friendly interface for ease of control and
navigation requirements as illustrated below.
58
Page 60
IPView SE control panel
Add Camera System Config
Minimize
Exit
Play
Scan
About
Combine
59
Page 61
Minimize
To minimize the control panel.
Exit
To close IPView SE.
Play
To play back the recorded file.
Scan
To display for each camera one by one.
Combine
To combine all display windows in one.
About
To display the information of IPView SE.
60
Page 62
How to Add a Camera
Add Camera
Add Camera
To add a new camera, click the Add Camera button. An Add
Camera dialog box will appear as illustrated below.
61
Page 63
You must select the camera and click the “Add” button to add a
new camera.
You can select the “Input IP” button, an Input IP dialog box
will appear as illustrated below.
Enter the IP Address of the camera in the specified field and click
the “Add” icon to add a new camera.
Note:
1. If you want to add a camera through the Internet, you must key
in a physical IP Address.
2. When the camera is installed behind Gateway and the Open
Second Port of camera/Port Forwarding of Gateway function is
enabled, the Gateway IP address has to be entered with the Port
Number as below:
62
Page 64
3. At the same time, the Gateway IP address can be replaced by
URL as below:
4. If you forget the IP Address that you want to add, a dialog box
will appear to notify you of the error.
If you are unsure of the IP Address of the camera, you can click
the “Browse” button, the Browse Camera dialog box will appear
with a blank screen as illustrated below.
63
Page 65
You must select the camera and click the “Add” button to add a
new camera.
If the Login Camera dialog box appears, make sure to enter the
correct User Name and Password and click the “OK” button.
Then, the camera will be added into IPView SE in list format. If
the User Name and Password is entered incorrectly, the camera
will not be added into IPView SE.
The above dialog box will appear only if administrator has
already set up the User Name and Password in the Web
Configuration setting.
If you forget to highlight the camera you want to add, a dialog
box will appear to notify you of the error.
Make sure to save any changes you have made to keep the
information updated.
64
Page 66
Note 2:
You are allowed to add only one camera at a time.
When the user add the IPCam SECURE300, four icons will
appear, including: “Assign IP to Camera”, “Connect/Disconnect”,
“Erase”, “Extra Information”
Camera Config
Assign IP to Camera
Connect / Disconnect
Erase
Manual record
Extra Information
Motion record
Schedule record
65
Page 67
How to Change Camera
Assign IP of New Camera
To change camera, click the “Assign IP of Camera” button. An
Assign IP of Camera dialog box will appear as illustrated below.
You must select the camera and click the “Add” button to add a
new camera.
66
Page 68
How to Connect / Disconnect the Image
Connect the Image
Click the “Connect/Disconnect” button and the preview screen
will appear with the video image.
Note:
When a new camera is added, it IS connected. You can see the
image right away. If you click the “Connect/ Disconnect” button,
it will be in disconnecting, also, no image showed.
Minimize
Click to minimize the display screen of the IPCam
SECURE300.
67
Page 69
Maximize
Click to maximize the display screen of the IPCam
SECURE300.
Close
Click to close the display screen of the IPCam
SECURE300.
Always on top
Click to have the display screen always appear on the top
of the window.
Wake up control panel
Click to open the control panel again when it is closed.
Color setting
Click to adjust color of the image.
View list
Click to check the event list of the IPCam SECURE300.
Snapshot
Click to snapshot a picture from the IPCam SECURE300.
Rotate image
68
Page 70
Click to rotate the image of the IPCam SECURE300.
69
Page 71
Disconnect the Image
Click the “Connect / Disconnect” button, the camera will be
disconnected.
70
Page 72
How to Delete a Camera
Erase Camera
To delete a camera, you must select the camera to delete from the
IPView SE control
button.
After deleting the camera, the IPView SE control
appear as below.
panel. Then, click the “Erase Camera”
panel will
71
Page 73
Extra Information
Extra Information
The screen displays the camera’s information.
72
Page 74
How to Adjust the Property Setting
System Configure
From the control panel, select the button and the dialog box will
appear as shown below.
Log Storage:
1. Single HDD Reserve Space
This option permits reserved HDD space from 500 MB to
1000 MB.
2. Split Recording File
From this option, you can adjust the file size for recording
the video images (the default setting is 10MB). If the
recorded video files reach the file size, video images will be
recorded into another file automatically.
73
Page 75
By File Size - permits recording by file size from 10 MB to
50 MB.
3. Storage List
This option is used to define the path to save image files.
The software will create a camera name folder as the
“Storage List” which is allowed to create up to 16 File Path.
Recycle:
When you enabled this function, it will recycle the HDD space
once the disk space is less than the size defined. The size defined
can be from 200 MB to 50000 MB.
Proxy Server:
Select this option to enable the Proxy Server support.
Camera Scan Delay:
It allows you to display for each camera one by one. The time
interval for each camera can be from 1 Sec. to 20 Sec.
74
Page 76
Camera Configure
Click the “Camera Config” button and it will active the Camera
Setting, Motion Setting and Update Firmware buttons.
Camera Setting
Motion Setting
Update Firmware
Camera Setting
Please refer to the “Web Configuration” section.
75
Page 77
Motion Setting
You can adjust the sensitivity level and choose the Invoke Alarm
options to work with motion detection function.
Besides the Alarm Beep, Send Email can be enabled when motion
detected.
The user can define the time interval to Send E-mail.
76
Page 78
Mail Server: Mail Server IP or name.
Mail From: E-Mail Address of sender.
Mail To: E-Mail Address of receiver.
Subject: Can be any information to high light the message.
User Name: Enter the user name in this field.
Password: Enter the user password in this field to login
receiver’s mail server
Interval Time: The time interval to send next E-Mail the unit is
by second.
77
Page 79
Update Firmware
Enter the File Path and click the “Update” button, the firmware
will be updated automatically.
If you are unsure of the File path, you can click the “Browse”
button, the Browse dialog box will appear as illustrated below.
During firmware update process, please make sure no interruptions will occur
as it might possibly cause serious damage to the IPCam SECURE300
Warning
78
Page 80
How to Adjust the Recording Setting
There are three ways to start recording image - Motion Record,
Schedule Record & Manual Record.
Motion Record
This option allows the camera to trigger recording by motion
detected. You can adjust the sensitivity level and choose the
warning options when motion is detected from motion setting.
Schedule Record
This option allows the camera to trigger recording as schedule
defined. The schedule is set by date or week day.
Manual Record
This option allows the camera to trigger recording manually.
79
Page 81
APPENDIX
A Frequently Asked Questions
IPCam SECURE300 Features
Q: What is an IPCam SECURE300?
A: The IPCam SECURE300 is a standalone system connecting
directly to an Ethernet or Fast Ethernet network. It is different
from the conventional PC Camera, the IPCam SECURE300 is an
all-in-one system with built-in CPU and web-based solutions
providing a low cost solution that can transmit high quality video
images for monitoring. The IPCam SECURE300 can be
managed remotely, accessed and controlled from any
PC/Notebook over the Intranet or Internet via a web browser.
Q: What is the maximum number of users that can be allowed to
access the IPCam SECURE300 simultaneously?
A: Maximum number of users that can log onto the IPCam
SECURE300 at the same time is 64. Please keep in mind the
overall performance of the transmission speed will slow down
when many users are logged on.
80
Page 82
Q: What algorithm is used to compress the digital image?
A: The IPCam SECURE300 utilizes the JPEG image
compression technology providing high quality images for users.
JPEG is adopted since it is a standard for image compression and
can be applied to various web browser and application software
without the need to install extra software.
IPCam SECURE300 Installation
Q: Can the IPCam SECURE300 be used out-doors?
A: The IPCam SECURE300 is not weatherproof. It needs to be
equipped with a weatherproof case to be used outdoors and it is
not recommended.
Q: What network cabling is required for the IPCam SECURE300?
A: The IPCam SECURE300 uses Category 5 UTP cable
allowing 10 Base-T and 100 Base-T networking.
Q: Can the IPCam SECURE300 be setup as a PC-cam on the
computer?
A: No, the IPCam SECURE300 is an IPCam SECURE300 used
only on Ethernet and Fast Ethernet network and supported by
transmission.
Q: Can the IPCam SECURE300 be connected on the network if
it consists of only private IP addresses?
A: The IPCam SECURE300 can be connected to LAN with
private IP addresses.
Q: Can the IPCam SECURE300 be installed and work if a
firewall exists on the network?
81
Page 83
A: If a firewall exists on the network, port 80 is open for
ordinary data communication. However, since the IPCam
SECURE300 transmits image data, the default port 8481 is also
required. Therefore, it is necessary to open port 8481 of the
network for remote users to access the IPCam SECURE300.
82
Page 84
B PING Your IP Address
The PING (Packet Internet Groper) command can determine
whether a specific IP address is accessible by sending a packet to
the specific address and waiting for a reply. It can also provide a
very useful tool to confirm if the IP address conflicts with the
IPCam SECURE300 over the network.
Follow the step-by-step procedure below to utilize the PING
command. However, you must disconnect the IPCam
SECURE300 from the network first.
Start a DOS window.
Type ping x.x.x.x, where x.x.x.x is the IP address of the IPCam
SECURE300.
The succeeding replies as illustrated below will provide useful
explanation to the cause of the problem with the IPCam
SECURE300 IP address.
83
Page 85
C Trouble Shooting
Q: I cannot access the IPCam SECURE300 from a web browser.
A1: The possible cause might be the IP Address for the IPCam
SECURE300 is already being used by another device. To correct
the possible problem, you need to first disconnect the IPCam
SECURE300 from the network. Then run the PING utility
(follow the instructions in Appendix B - PING Your IP Address).
A2: Another possible reason is the IP Address is located on a
different subnet. To fix the problem, run the PING utility (follow
the instructions in Appendix B - PING Your IP Address). If the
utility returns “no response” or similar, the finding is probably
correct, then you should proceed as follows:-
In Windows 95/98/2000 and Windows NT, double check the IP
Address of the IPCam SECURE300 is within the same subnet as
your workstation.
Click “Start”, “Setting”, “Control Panel”, and the “Network” icon.
Select TCP/IP from the “Network” dialog box and from the
“TCP/IP Properties” dialog box click “Specify an IP address”.
If the IPCam SECURE300 is situated on a different subnet than
your workstation, you will not be able to set the IP address from
this workstation. To verify make sure the first 3 sections of the IP
address of the IPCam SECURE300 corresponds to the first 3
sections of the workstation. Therefore the IP address of the
IPCam SECURE300 must be set from a workstation on the same
subnet.
84
Page 86
A3: Other possible problems might be due to the network cable.
Try replacing your network cable. Test the network interface of
the product by connecting a local computer to the unit, utilizing a
standard Crossover (hub to hub) Cable. If the problem is not
solved the IPCam SECURE300 might be faulty.
Q: Why does the Power LED not light up constantly?
A: The power supply used might be at fault. Confirm that you
are using the provided power supply DC 5V for the IPCam
SECURE300 and verify that the power supply is well connected.
Q: Why does the Link LED not light up properly?
A1: There might be a problem with the network cable. To
confirm that the cables are working, PING the address of a know
device on the network. If the cabling is OK and your network is
reachable, you should receive a reply similar to the following
(…bytes = 32 time = 2 ms).
A2: The network device utilized by the IPCam SECURE300 is
not functioning properly such as hubs or switches. Confirm the
power for the devices are well connected and functioning.
Q: Why does the IPCam SECURE300 work locally but not
externally?
A1: Might be caused from the firewall protection. Need to check
the Internet firewall with your system administrator.
A2: The default router setting might be a possible reason. Need
to double check if the configuration of the default router settings
is required.
85
Page 87
Q: Why does a series of broad vertical white line appears
through out the image?
A: A likely issue is that the CMOS sensor becomes overloaded
when the light source is too bright such as direct exposure to
sunlight or halogen light. You need to reposition the IPCam
SECURE300 into a more shaded area immediately as this will
damage the CMOS sensor.
Q: There is bad focus on the IPCam SECURE300, what should
be done?
A1: The focus might not be correctly adjusted for the line of
sight. You need to adjust the IPCam SECURE300 focus
manually as described in Adjust IPCam SECURE300 Focus.
A2: There is no adaptor fitted with your C-type lens. If you have
previously changed the supplied CS-type lens, you may have
unintentionally installed a C-type lens without fitting the adaptor
first.
Q: Noisy images occur how can I solve the problem?
A1: The video images might be noisy if the IPCam SECURE300
is used is a very low light environment. To solve this issue you
need more lighting.
A2: There might be transmission interference make sure there
are no other devices on the network that will affect the
transmission.
Q: There is poor image quality, how can I improve the image?
A1: A probable cause might be the incorrect display properties
configuration for your desktop. You need to open the Display
86
Page 88
Properties on your desktop and configure your display to show at
least 65’000 colors for example at least 16-bit.
Note:
Applying only 16 or 256 colors on your computer will produce
dithering artifacts in the image.
A2: The configuration on the IPCam SECURE300 image display
is incorrect. Through the Web Configuration Image section you
need to adjust the image related parameter for improve images
such as brightness, contrast, hue and light frequency. Please refer
to the Web Configuration section for detail information.
Q: There are no images available through the web browser?
A: The ActiveX might be disabled. If you are viewing the
images from Internet Explorer make sure ActiveX has been
enabled in the Internet Options menu. Alternatively, you can use
the Java Applet for viewing the required images.
87
Page 89
D Time Zone Table
88
Page 90
89
Page 91
E Xplug Control Installation
Installation To Web Server
It is highly recommended to install the Xplug Control
application to the Web Server for IE 5.0. It must be
installed to a Public Domain with Fixed IP address.
1. Installation:
Copy the “xplug.ocx” file to any WEB Server table.
2. Setting (Configuration):
From the Web Configuration menu select “System” and
under the “Loading ActiveX From” input web server
location
(
http://www.web server location.com/).
Once the settings are completed, the user now is able to access the
IPCam SECURE300 from the web browser by selecting the
image view – ActiveX mode.
Important Information
90
Page 92
Installation To Local PC
Insert the CD-ROM into the CD-ROM drive to initiate the autorun program. Once completed, a menu screen will appear as
below:
To install Xplug Control, click the "Xplug Control" button to
activate the installation procedure for the plug-in program.
91
Page 93
The Welcome screen will appear. Click the “Next” button to
proceed with the installation.
The License Agreement prompt will appear as below. Read the
details carefully and click the “Yes” button to continue with the
installation procedure.
92
Page 94
Click the “Finish” button to complete Setup of the Xplug Control
Utility program for the IPCam SECURE300.
93
Page 95
F Adjust IPCam SECURE300 Focus
To adjust the focus of the lens, you need to turn the lens slowly in
either clockwise or anti-clockwise direction until the desired
image appears. DO NOT over turn the lens in either of the
directions as it will be out of focus.
Note:
You can further adjust the Wireless IPCam SECURE300's image
quality through System Administration – Image of Web
Configuration. Please refer to Web Configuration section for
further details.
Direct exposure to sunlight may cause permanent damage to the
CMOS sensor. Therefore do not expose the IPCam SECURE300’s
lens directly to sunlight. When operation is required in glaring
light environment, it is recommended to use an iris lens.
The IPCam SECURE300 is designed for indoor usage and if your
application requires prolong exposure to sunlight, a sun visor is
recommended to protect the IPCam SECURE300.
Warning
94
Page 96
G Specification
Video Specification
Resolution: 640 x 480 pixel
Sensor: color CMOS sensor
Gain control: Automatic
Exposure: Automatic
White Balance: Automatic
Shutter: Electronics 1/60 ~ 1/15000 sec
Minimum Illumination: 2.5 lux@f1.4, 3000K color
Focal Length: 6.0 mm
Aperture: F=1.8
Signal/ Noise ratio 57dB
Focus Extent: 20 cm - ∞
Lens mounting: Fixed board lens
Image (Video Setting)
Image compression: JPEG
Frame rate: 20fps@SIF, 6fps@VGA
Compression Rate selection: Auto
Frame rate setting: 1, 5, 7, 15, 20, auto (depends on the
video format)
Video resolution: 320x240, 640x480
Brightness control: Range 1- 128
Contrast control : Range 1- 128
Saturation control : Yes
95
Page 97
Hardware Interface
LAN Connector: One RJ-45 port to connect to
10/100Mbps Ethernet, auto-sensed
LED Indicator: Power LED (Green)
Link LED (Yellow)
Note:
LED three mode setting can be changed by software. (Normal / Off /
Dummy)
Power Supply: DC 5V, switching type
Power Communication: 2.75 Watt (550mA x 5V)
Communication Support
Communication: 10/100Mbps Ethernet only
Communication protocol: HTTP, FTP, TCP/IP, UDP, ARP,
ICMP, BOOTP, RARP, DHCP,
PPPoE
Browser Support
System requirement:
CPU: Pentium II, 266 MHz or above
Memory Size: 32 MB (64 MB recommended)
VGA card resolution: 800x600 or above
• Internet Explorer 5.0 or above
• Netscape 6.0 or above
Note:
ActiveX Mode –View Image supports Internet Explorer under Windows
OS.
IPView SE Application
Support OS: Win 98 SE, Win 2000, Win Me, Win XP
System requirement for IPView:
CPU: Pentium III, 450 MHz or above
Memory Size: 128 MB (256 MB recommended)
VGA card resolution: 800x600 or above
96
Page 98
Operating environment
Operating temperature: 5°C ~ 50°C
Storage temperature: -25°C ~ 50°C
Humidity: 5% ~ 95% non-condensing
EMI
FCC, CE
97
Page 99
HGlossary of Terms
b
NUMBERS
10BASE-T
100BASE-TX
802.11b
A
Access point
Applet
ASCII
ARP
10BASE-T is Ethernet over UTP Category III,IV, or V unshielded
twisted-pair media.
The two-pair twisted-media implementation of 100BASE-T is
called 100BASE-TX.
An IEEE standard for wireless local area networks. It offers
transmissions speeds at up to 11 Mbps in the 2.4-GHz band.
It is the hardware interface between a wireless LAN and a wired
LAN. The access point attaches to the wired LAN through an
Ethernet connection.
Applets are small Java programs that can be embedded in an
HTML page. The rule at the moment is that an applet can only
make an Internet connection to the computer form that the applet
was sent.
American Standard Code For Information Interchange, it is the
standard method for encoding characters as 8binary numbers, allowing a maximum of 256 characters.
Address Resolution Protocol. ARP is a protocol that resides at the
it sequences of
98
Page 100
p
AVI
B
BOOTP
C
Communication
Connection
D
DHCP
TCP/IP Internet layer that delivers data on the same network by
translating an IP address to a physical address.
Audio Video Interleave, it is a Windows platform audio and video
file type, a common format for small movies and videos.
Bootstrap Protocol is an Internet protocol that can automatically
configure a network device in a diskless workstation to give its
own IP address.
Communication has four components: sender, receiver, message,
and medium. In networks, devices and application tasks and
rocesses communicate messages to each other over media. They
represent the sender and receivers. The data they send is the
message. The cabling or transmission method they use is the
medium.
In networking, two devices establish a connection to communicate
with each other.
Dynamic Host Configuration Protocol was developed by
Microsoft a
devices on a
have a different IP address every time it connects to the network.
In some systems, the device's IP address can even change while it
is still connected. DHCP also supports a mix of static and dynamic
IP addresses. This simplifies the task for network administrators
protocol for assigning dynamic IP addresses to
network. With dynamic addressing, a device can
99
Loading...
