SD-5200 MANUAL

5/2 WATT RF DATA RADIO

IMPORTANT NOTICE!

FCC RF Exposure Compliance requirements for Occupational Use:

• This device must be restricted to work related operations in an occupational / controlled RF exposure

environment.

• Transmitting duty factor may not exceed 50%.

• All qualified users must have the knowledge to control their own, passengers and bystanders’RF

exposure to comply with the General Population / Controlled MPE limit and requirements.

• The antenna used for this transmitter must be installed to provide a separation distance of at least 32cm

from all persons and must not exceed an antenna gain of 0 dDd.

IMPORTANT NOTICE!

This radio can only be programmed to frequency by qualified, approved technicians using a separate PC

software and cable package. Only authorized technicians can contact Tekk to purchase this programming

software product.

CH.1 PRODUCT INTRODUCTION

SD-5200, This RF Data Radio is designed to operate in the frequency range is 450MHz~ 470MHz. Inside of SD-5200 is

installed microprocessor and SD-5200 is operated by PLL type. RF power is 2watt and 5watt. Bandwidth is 12.5khz or

25khz

SD-5200 features

-. PLL SYNTHESIZER type

-. set parameter with PC program

-. RF power : 2 Watt, 5Watt

-. band width : 12.5/25kHz

-. light weight

-. PC downloading

-. Power : DC 10V

2. SD-5200 outward view
Data Radio (SD-5200)

3. D-SUB Connector PIN Specification

PIN NO PIN Specification Remark

1 DC+12V 9V~15V
2 GND

3 PTT “Low" Active
4 DATA INPUT
5 DATA OUTPUT
6 S_I/O( PC Program) Programming
7 GND
8 RSSI Receive Signal Strength Indicator
9 S.Q(CD) Carrier Detect

4. CON2 PIN Specification (PCB Connector)

PIN NO PIN Specification

1 RSSI Receive Signal Strength Indicator
2 GND
3 S_I/O PC Program PIN

Remark

5. CON3 PIN Specification (PCB Connector)

PIN NO PIN Specification Remark

1 S.Q (C.D)
2 DATA INPUT

3 DATA OUTPUT
4 PTT
5 DC+12V

6 GND

6. CON4 PIN Specification (PCB Connector)

PIN NO PIN Specification Remark

1 RESET
2 DC+5V
3 S_CLOCK
4 S_DATA
5 GND

used

for modifying

MPU Program

CH2. SPECIFICATIONS

1. Specification

Spurious and Harmonic

Operating Mode
Frequency Range
Frequency Stability
Programmable Channels
Channel Spacing
Dimensions
Weight
Power Source
Current Drain(maximum)

Sensitivity
Squelch Sensitiviy
Selectivity

Rejection
Intermodulation
FM Hum and Noise
Maximum Frequency Spread
Audio Output Power
Audio Distortion
Audio Response
IF Frequencies
Input Impedance

GENERAL

Conventional (nontrunked) only
450~470MHz
± 2.5PPM(- 30 to +60?)
1 Channel
Dual Channel Spacing 12.5/25kHz
30mm(H)×60mm(W)×95mm(L)
360g
DC 9~15V
Transmit mode - 1.8A

RECEIVER

.35uV 12 dB SINAD
.25uV 10dB SINAD

-60dB (12.5KHz)

-60dB (25KHz)

-60dB

-60dB

-34dB(12.5KHz), -40dB(25KHz)
UHF = 20MHz
460mW across an 8-ohm load
Less than 5% at rated output
± 2dB from characteristic from 20~3000Hz

21.4MHz and 455kHz
50 ohms

TRANSMITTER

RF Power Output
Spurious and Harmonic

FM Hum and Noise
Audio Distortion
Audio Frequency Response
Maximum Channel Spread
Output Impedance

2 Watt or 5 Watt

-60

-34dB(12.5KHz), -40dB(25KHz)
5% maximum with 1kHz modulation
± 2dB from characteristic from 20~3000Hz
UHF = 20MHz
50 ohms

CH. 3 SD- 5200 circuit

1. SD-5200 circuit

SD-5200 circuit is composed of RF and MPU. (RF determines communication quality and performance. MPU controls

terminal performance.) RF is composed of TX and RX. TX is composed of synthesizer (Synthesizer generates TX

frequency.), VCO, Data ALC (Automatic Level Control), Power Drive, final amplification and antenna switch.
