To our valued customers:

Gene Rich & Company has provided quality plumbing specialties to wholesalers and re-sellers since 1952. Our commitment to service and customer satisfaction remains our #1 priority.

We are therefore pleased to present our latest catalog of quality plumbing speciality products. This edition incorporates many new products and several design enhancements to help you find what you need quickly and easily. Through expanded product information and larger images, you and your customers can identify the parts you need with confidence.

This catalog is also available in electronic format online at: WWW.GENERICH.COM and ready for immediate download 24/7. The electronic version is highly cross referenced and works in concert with our website to make ordering online extremely fast and easy. Be sure to visit us online where you will always find the most current catalog and pricing or call us today to request the catalog on CD.

All Gene Rich parts have assigned UPC codes and all products are now marked with bar codes to assist with inventory accounting, shipping, receiving and pricing. We have improved our merchandising with more legible labeling and by skin-packing many items for hang-up display at your sales counter.

Please note that for identification purposes only, original manufacturer’s names may appear in the description of Gene Rich & Company replacement parts. (An asterisk * will appear next to a manufacturer’s name.) These parts are made to our standards and specifications and should not be confused with the original OEM part.

We know you have a choice when it comes to plumbing specialties and we sincerely “Thank you!” for considering Gene Rich & Company, the home of “Eager Beaver Service” for over 50 years!

We welcome your comments and suggestions to help us improve our service and value to you and we look forward to contributing to your ongoing success.

Alan Rich President

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 i

GENE RICH & COMPANY

TERMS OF SALE

EFFECTIVE AUGUST 2010

SALES POLICY

It is our policy to sell to wholesalers and resellers. Possession of this catalog does not constitute an offer to sell.

PRICES

Our prices are subject to change without notice. All orders will be invoiced at the prevailing price at the time of shipment.

PAYMENT TERMS

We accept VISA and MasterCard or open a Gene Rich credit account and take advantage of our discounted, extended payment terms, subject to credit approval. Complete the credit application in the back of this catalog and fax it toll-free with your order to: 877-535-7036.

Credit accounts in good standing will enjoy 2% 10th Prox., Net 30 day terms. Discounts will be allowed on invoices paid on or before the 10th of the month following shipment. Invoices dated after the 24th are considered next month’s billing.

Please note: Discounts only apply to merchandise. No discounts allowed on freight or labor. Unearned cash discounts will be left open as an unpaid balance to the account. Any amount past due is subject to a finance charge of 1 1/2 % per month on the past due balance in accordance with the Truth-In-Lending Act.

MINIMUM ORDER

$50.00 Net order. Orders under $50.00 net cost will be assessed a $10 handling charge.

SERVICE CHARGES

$10.00 will be charged for shipments from our warehouse to the bus terminal.

C.O.D. ORDERS

No cash discounts allowed on any C.O.D. orders.

FREIGHT TERMS

All merchandise is sold F.O.B. Fort Worth, Texas. Gene Rich & Co., Inc. selects carriers for prepaid freight. Freight will be Prepaid & Allowed on orders totaling $850.00 net value or more at one time, to one destination. No freight allowed for order under $850.00 net value under any circumstances.

To qualify for Quantity Discounts & Prepaid Freight Terms, all quantities must be shipped at one time, to one destination. NO SPLIT SHIPMENTS.

DELIVERY

We strive to ship all orders out on the same day they are received. However, we cannot be liable for any loss incurred due to delays in shipping, whatever the reason might be.

RETURNS

Returned merchandise will not be accepted and/or credited without prior approval from Gene Rich & Co. All non-defective returns must be in original, clean packaging and may be subject to a 15% handling charge. Returns should be sent to our physical address at:

2525 Ludelle Street Fort Worth, TX 76105

GUARANTEE

Our guarantee shall be limited to the replacement or credit; not to exceed the original purchase price, and shall not include any installation or labor charges of any kind. All Gene Rich & Co., Inc. merchandise is guaranteed against defects in workmanship or material for a period of one (1) year from date of purchase, excluding any diaphragm test gauges, which carry a 30 day guarantee. No credits or replacements will be issued for merchandise damaged due to improper installation or abuse. We reserve the right to determine if merchandise returned is defective, and our judgement shall be final in such matters.

TAXES

Federal, state, county or municipal taxes which we may become liable for shall be charged to and paid by the customer.

COPYRIGHT

This catalog is copyright protected. No part of this book may be reproduced in any form or by any electronic or mechanical means, including information storage and re-

trieval devices or systems, without prior written permission.

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 1

LIABILITY

Gene Rich & Co., Inc. shall not be liable for special, indirect, incidental or consequential damages, and GENE RICH & CO., INC.’s liability, whether in contract, tort, under any warranty, or otherwise, shall not exceed the price of the product or part on which such liability is based.

GENE RICH & COMPANY

TABLE OF CONTENTS

CLOSET FITTINGS

ESCUTCHEONS, FLOOR & CEILING PLATES

One Piece Shallow, Deep Bell, Deep Box | Split Sure Grip | Split Spring Type

SLIP JOINT NUTS

Chrome Plated | Die Cast & Brass

TUB & SHOWER ITEMS

PIPE NIPPLES & FITTINGS

Sharkbite Fittings & Accessories | Red Brass Nipples & Fittings | Chrome Plated Nipples & Fittings

PAGES 4 - 22

PAGES

23 - 25

PAGE 28

PAGES

29 - 48

PAGES

49 - 51

HOSE FITTINGS

Brass Swivel Hose Fittings | Brass Hose to Pipe Thread Adapters | Vacum Breaker

KITCHEN & LAVATORY SINK ITEMS

PVC TUBULAR

AIR GAPS & DISPOSAL CONNECTORS

HOSES & CLAMPS

Dishwaser & Washing Machine Drain Hoses | Garden Hoses | Murray Hose Clamps

DRYER VENTS & TUBING

Flexible & Rigid Aluminum Pipe | Vinyl Tubing | Periscope Ducts | Elbows & Couplings | Vent Hoods

PAGES

54 - 55

PAGES

55 - 69

PAGES

70 - 73

PAGE 74

PAGES

74 - 77

PAGES

78 - 81

2 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

TABLE OF CONTENTS

HANGERS & FASTENERS

PIPE REPAIR & COUPLINGS

COVER PLATES & PLUGS

Drum Trap Cover | Sewer Relief Valves | Raised Head & Countersunk Plugs Stainless Steel Cover Plates & Screws

VALVES

TOOLS

PAGES

82 - 88

PAGES

89 - 94

PAGES

94 - 96

PAGES

96 - 100

PAGES

101 - 135

ELECTRICAL

PAGES

135 - 141

RUBBER GOODS

PRODUCT NUMBER INDEX

Helps locate parts quickly when you already know the Gene Rich item number.

ALPHABETICAL INDEX

CREDIT APPLICATION

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 3

PAGES

142 - 149

PAGES

154 - 161

PAGES

162 - 172

PAGE 173

GENE RICH & COMPANY

CLOSET SCREW & BOLT COMBINATIONS

DISCOUNTED 10%

WHEN YOU BUY

1,000 or more shanks

DISCOUNTED 15%

WHEN YOU BUY

10,000 or more shanks

Deluxe Combos: Include Solid Brass Shanks, Nickel Plated BRASS Nuts and STAINLESS Steel Washers.

SNW Combos: Include

-TP: Combinations are TWIN PACKED (2 shanks, 2 nuts, 2 washers to a poly bag, with 50 bags/box)

-QN: Combinations include QUICKIE NUTS for added convieniance during installation.

-RW: For ROUND WASHERS in BOLT Combinations. (Round Washers are standard on Screw Combinations)

Nickel Plated Steel Shanks, Nickel Plated Die Cast Nuts and Nickel Plated Steel Washers.

BRASS PLATED CLOSET SCREW COMBINATIONS

CLOSET FITTINGS

Screw Combinations listed here include .042 Nickel Plated STEEL Washers. 1/4” screw combinations include 7/16” Nickel Plated Die Cast STEEL Nuts. 5/16” screw combinations include 1/2” Nickel Plated Die Cast STEEL Nuts.

BULK

Item No Shank Size Shank # Nut # Washer # Std. Pkg

10SNW 1/4 x 2-1/2 #30 #48 #75 Round 100 Ea

11SNW

14SNW 5/16 x 2-1/2 #34 #54 #75 Round 100 Ea

15SNW 5/16 x 3-1/2 #35 #54 #75 Round 100 Ea

1/4 x 3-1/2 #31 #48 #75 Round 100 Ea

TWIN PACKED (2 Shanks, 2 Nuts, 2 Washers per poly bag: 50 bags per box)

Item No Shank Size Shank # Nut # Washer # Std. Pkg

10SNW-TP 1/4 x 2-1/2 #30 #48 #75 Round 50 Pr

11SNW-TP

14SNW-TP

15SNW-TP

1/4 x 3-1/2 #31 #48 #75 Round 50 Pr

5/16 x 2-1/2 #34 #54 #75 Round 50 Pr

5/16 x 3-1/2 #35 #54 #75 Round 50 Pr

SOLID BRASS CLOSET SCREW COMBINATIONS

Screw Combinations listed here include .040 STAINLESS STEEL Washers. 1/4” screw combinations include 7/16” Nickel Plated BRASS Nuts. 5/16” screw combinations include 1/2” Heavy Nickel Plated BRASS Nuts.

BULK

Item No Shank Size Shank # Nut # Washer # Std. Pkg

12 1/4 x 2-1/2 #32 #50 #76 Round 100 Ea

13 1/4 x 3-1/2 #33 #50 #76 Round 100 Ea

16 5/16 x 2-1/2 #36 #54 #76 Round 100 Ea

17 5/16 x 3-1/2 #37 #54 #76 Round 100 Ea

TWIN PACKED (2 Shanks, 2 Nuts, 2 Washers per poly bag: 50 bags per box)

Item No Shank Size Shank # Nut # Washer # Std. Pkg

12-TP 1/4 x 2-1/2 #32 #50 #76 Round 50 Pr

12LNOW-TP

13-TP 1/4 x 3-1/2 #33 #50 #76 Round 50 Pr

16-TP 5/16 x 2-1/2 #36 #54 #76 Round 50 Pr

17-TP 5/16 x 3-1/2 #37 #54 #76 Round 50 Pr

4 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

1/4 x 2-1/2 #32 #52 #72 Oval (Lg. Nut) 50 Pr

GENE RICH & COMPANY

BRASS PLATED CLOSET BOLT COMBINATIONS

Bolt Combinations listed here include .042 Nickel Plated STEEL Washers. 1/4” bolt combinations include 7/16” Nickel Plated Die Cast STEEL Nuts. 5/16” bolt combinations include 1/2” Nickel Plated Die Cast STEEL Nuts.

BULK

Item No Shank Size Shank # Nut # Washer # Quik Nut Std. Pkg

19SNW 1/4 x 1-3/4 #39 #58 #71 Oval 100 Ea

19SNWRW

20SNW 1/4 x 2-1/4 #40 #58 #71 Oval 100 Ea

21SNW 1/4 x 3-1/2 #41 #58 #71 Oval 100 Ea

23ASNW 5/16 x 1-3/4 #43A #63 #71 Oval 100 Ea

24SNW 5/16 x 2-1/4 #44 #63 #71 Oval 100 Ea

TWIN PACKED (2 Shanks, 2 Nuts, 2 Washers per poly bag: 50 bags per box)

Item No Shank Size Shank # Nut # Washer # Quik Nut Std. Pkg

19SNW-TP 1/4 x 1-3/4 #39 #58 #71 Oval 50 Pr

20SNW-TP

20SNWQN-TP 1/4 x 2-1/4 #40 #58 #71 Oval #68 50 Pr

20SNWRW-TP

20SNWRWQNTP

21SNW-TP

21SNWRW-TP

23ASNW-TP

23ASNWQNTP 5/16 x 1-3/4 #43A #63 #71 Oval #69 50 Pr

23ASNWRWTP

23ASNWRWQNTP

24RW-TP

24SNW-TP

24SNWQN-TP 5/16 x 2-1/4 #44 #63 #71 Oval #69 50 Pr

24SNWRW-TP

1/4 x 1-3/4 #39 #58 #75 Round 100 Ea

1/4 x 2-1/4 #40 #58 #71 Oval 50 Pr

1/4 x 2-1/4 #40 #58 #75 Round 50 Pr

1/4 x 2-1/4 #40 #58 #75 Round #68 50 Pr

1/4 x 3-1/2 #41 #58 #71 Oval 50 Pr

1/4 x 3-1/2 #41 #58 #75 Round 50 Pr

5/16 x 1-3/4 #43A #63 #71 Oval 50 Pr

5/16 x 1-3/4 #43A #63 #75 Round 50 Pr

5/16 x 1-3/4 #43A #63 #75 Round #69 50 Pr

5/16 x 2-1/4 #44 #64 #76 Round 50 Pr

5/16 x 2-1/4 #44 #63 #71 Oval 50 Pr

5/16 x 2-1/4 #44 #63 #75 Round 50 Pr

DISCOUNTED 10%

WHEN YOU BUY

1,000 or more shanks

DISCOUNTED 15%

WHEN YOU BUY

10,000 or more shanks

CLOSET FITTINGS

SOLID BRASS CLOSET BOLT COMBINATIONS

Bolt Combinations listed here include .040 STAINLESS STEEL Washers. 1/4” bolt combinations include 7/16” Nickel Plated BRASS Nuts. 5/16” bolt combinations include 1/2” Heavy Nickel Plated BRASS Nuts.

BULK

Item No Shank Size Shank # Nut # Washer # Quik Nut Std. Pkg

21A 1/4 x 1-3/4 #41A #60 #72 Oval 100 Ea

22 1/4 x 2-1/4 #42 #60 #72 Oval 100 Ea

23 1/4 x 3-1/2 #43 #60 #72 Oval 100 Ea

24A 5/16 x 1-3/4 #45 #64 #72 Oval 100 Ea

26 5/16 x 2-1/4 #46 #64 #72 Oval 100 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 5

GENE RICH & COMPANY

SOLID BRASS CLOSET BOLT COMBINATIONS

(continued)

DISCOUNTED 10%

WHEN YOU BUY

1,000 or more shanks

DISCOUNTED 15%

WHEN YOU BUY

10,000 or more shanks

CLOSET FITTINGS

Bolt Combinations listed here include .040 STAINLESS STEEL Washers. 1/4” bolt combinations include 7/16” Nickel Plated BRASS Nuts. 5/16” bolt combinations include 1/2” Heavy Nickel Plated BRASS Nuts.

TWIN PACKED

Item No Shank Size Shank # Nut # Washer # Quik Nut Std. Pkg

21A-TP 1/4 x 1-3/4 #41A #60 #72 Oval 50 Pr

22-TP 1/4 x 2-1/4 #42 #60 #72 Oval 50 Pr

22QN-TP 1/4 x 2-1/4 #42 #60 #72 Oval #68 50 Pr

22RW-TP

22RW4N-TP

22RW4-TP

22RWQN-TP

22SNWRW-TP

23-TP 1/4 x 3-1/2 #43 #60 #72 Oval 50 Pr

23RW-TP

24A-TP 5/16 x 1-3/4 #45 #64 #72 Oval 50 Pr

24ARW-TP

26-TP 5/16 x 2-1/4 #46 #64 #72 Oval 50 Pr

26RW-TP

26RWQN-TP

(2 Shanks, 2 Nuts, 2 Washers per poly bag: 50 bags per box)

1/4 x 2-1/4 #42 #60 #76 Round 50 Pr

1/4 x 2-1/4 #42 #60 x4 #76 Round x 4 50 Pr

1/4 x 2-1/4 #42 #60 #76 Round x 4 #84A 50 Pr

1/4 x 2-1/4 #42 #60 #76 Round #68 50 Pr

1/4 x 2-1/4 #42 #58 #75 Round 50 Pr

1/4 x 3-1/2 #43 #60 #76 Round 50 Pr

5/16 x 1-3/4 #45 #64 #76 Round 50 Pr

5/16 x 2-1/4 #46 #64 #76 Round 50 Pr

5/16 x 2-1/4 #46 #64 #76 Round #69 50 Pr

E-Z SNAP SOLID BRASS CLOSET BOLT COMBINATIONS

Combinations include: (2) Solid BRASS Bolt Shanks (2) Captive BRASS Washers. (2) .040 STAINLESS STEEL Washers. (2) Nickel Plated BRASS Nuts.

TWIN PACKED (2 Sets per poly bag: 50 bags per box)

Item No Shank Size Shank # Nut # Washer # Std. Pkg

22EZ-TP 1/4 x 2-1/4 #42EZ #60 #76 Round 50 Pr

26EZ-TP 5/16 x 2-1/4 #46EZ #64 #76 Round 50 Pr

CLOSET SCREW SHANK

Item No Description Std. Pkg

30 1/4 x 2-1/2 Brass Plated 100 Ea

31 1/4 x 3-1/2 Brass Plated 100 Ea

32 1/4 x 2-1/2 Solid Brass 100 Ea

33 1/4 x 3-1/2 Solid Brass 100 Ea

34 5/16 x 2-1/2 Brass Plated 100 Ea

35 5/16 x 3-1/2 Brass Plated 100 Ea

36 5/16 x 2-1/2 Solid Brass 100 Ea

37 5/16 x 3-1/2 Solid Brass 100 Ea

6 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

Item No Description Std. Pkg

39 1/4 x 1-3/4 Brass Plated 100 Ea

40 1/4 x 2-1/4 Brass Plated 100 Ea

41 1/4 x 3-1/2 Brass Plated 100 Ea

41A 1/4 x 1-3/4 Solid Brass 100 Ea

42 1/4 x 2-1/4 Solid Brass 100 Ea

43 1/4 x 3-1/2 Solid Brass 100 Ea

43A 5/16 x 1-3/4 Brass Plated 100 Ea

44 5/16 x 2-1/4 Brass Plated 100 Ea

45 5/16 x 1-3/4 Solid Brass 100 Ea

46 5/16 x 2-1/4 Solid Brass 100 Ea

CLOSET SCREW CLOSED NUTS

Item No Description Std. Pkg

48 1/4 x 7/16 NP Die Cast 100 Ea

50 1/4 x 7/16 NP Brass 100 Ea

52 1/4 x 1/2 NP Brass 100 Ea

54 5/16 x 1/2 NP Brass 100 Ea

CLOSET BOLT SHANK

CLOSET FITTINGS

Item No Description Std. Pkg

58 1/4 x 7/16 NP Die Cast 100 Ea

60 1/4 x 7/16 NP Brass 100 Ea

62 1/4 x 1/2 NP Brass 100 Ea

63 5/16 x 1/2 NP Die Cast 100 Ea

64 5/16 x 1/2 NP Brass 100 Ea

• Hold Bolts in Place

Item No Description Std. Pkg

68 1/4” Plastic 100 Ea

69 5/16” Steel 100 Ea

Item No Description Std. Pkg

71 NP Steel Oval 100 Ea

72 Pol. Stainless Oval 100 Ea

75 NP Steel Round 100 Ea

76 .040 Round Stainless 100 Ea

CLOSET BOLT OPEN NUTS

QUICKIE NUTS

CLOSET WASHERS

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 7

GENE RICH & COMPANY

ADJUSTABLE TANK BOWL BOLTS

Replace broken bowls or tanks by using adjustable tank-bolts.

Two to a set for coupling one closet combination. Sliding adjustment of 2 inches allows tank with 5” holes to fit bowl with 7” holes or vice versa.

Item No Description Std. Pkg

CLOSE COUPLED TANK BOLT COMBINATIONS

79 Adjustable Brass Tank Bowl Bolts 12 Pr

#81 includes:

• Two #83 Solid Brass 5/16 x 3-1/4 Bolt Shank w/Heavy Duty Truss Head

• Four #84 Solid Brass Hex Nuts

• Four #76 Stainless Steel Round Washers

CLOSET FITTINGS

• Four #86 Black Rubber Washers #81-3S has three bolts, six nuts, six steel washers & six rubber washers

All sets are packaged in poly bags with 25 bags per box.

# of

Item No Shank Size

81 5/16 x 3-1/4 2 4 4 4 25 Set

81-3S 5/16 x 3-1/4 3 6 6 6 25 Set

Bolts

Hex Nuts

CLOSE COUPLED TANK BOLT KITS WITH GASKETS

Kit includes: • One Sponge Rubber Tank-to-Bowl Beveled Gasket

• Two #83 Solid Brass 5/16 x 3-1/4 Bolt Shank w/Heavy Duty Truss Head

• Four #84 Solid Brass Hex Nuts

• Four #76 Stainless Steel Round Washers

• Four #86 Black Rubber Washers #81C-3S has three bolts, six nuts, six steel washers & six rubber washers

Packaged in poly bags with 25 bags per box.

# of

S.S.

Washers

Rubber

Washers

Std. Pkg

Item No Shank Size # of Bolts Gasket Type Gasket # Std. Pkg

81A 5/16 x 3-1/4 2 Regular W328 25 Bag

81B 5/16 x 3-1/4 2 Heavy W329 25 Bag

81C 5/16 x 3-1/4 2 Double Seal W330 25 Bag

81C-3S 5/16 x 3-1/4 3 Double Seal W330 25 Bag

C.C. TANK BOLTS, NUTS AND WASHERS

Item No Description Std. Pkg

82 5/16” x 3” BR CC Bolt,3/4 Head 100 Ea

83 5/16 x 3-1/4 BR CC Bolt Shank 100 Ea

84 5/16 Brass Hex Nut 100 Ea

8 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

84A 1/4” Plated Steel Hex Net 100 EA

85 .040 Round Stainless Washer 100 Ea

86 C.C. Rubber Washer 100 Ea

W379 Cloth Inserted Rubber Washer 100 Ea

GENE RICH & COMPANY

• Round Caps include locking Clips

Item No Description Std. Pkg

155 Round, White Plastic, w/clip 25 Pr

156 Oval White Plastic 100 Ea

• Made of corrugated cardboard • 6” O.D. x 4” tall

WHITE PLASTIC BOLT CAPS

CLOSET BEND SPACERS

• Use around waste lines and closet bends to keep poured concrete away

• Install closet flanges with ease, no need to chip out concrete.

• Fits 3” and 4” waste lines.

Item No Description Std. Pkg

87 4” Closet Bend Spacer, 4 Layers 50 Ea

DISCOUNTED!

• Use with 4” lead pipe

Item No Description Std. Pkg

120 14 oz. BR, Brushed 25 Ea

120C Repair, For 4” Lead Pipe, 1-1/8” Collar 25 Ea

#120 #120C

WHEN YOU BUY

300 or more

BRASS CLOSET

FLOOR FLANGES

CLOSET FITTINGS

• Move the toilet closer to or farther

from the wall by 1-1/2” offset

Item No Description Std. Pkg

120B 1-1/2” Offset, 2” Deep 1 Ea

120F 1-1/2” Offset, 2” Deep, w/Lug 1 Ea

#120B #120F

• Use to raise height of existing floor flange, when necessary.

(i.e., after adding tile or hardwood flooring)

DISCOUNTED!

WHEN YOU BUY

300 or more

CLOSET FLANGE EXTENDER

BRASS OFFSET

CLOSET FLANGES

• Stackable, sturdy PVC construction

Item No Description Std. Pkg

120X 1/2” PVC 6 Ea

SPANNER FLANGE

• Use to repair broken closet flanges

Item No Description Std. Pkg

121 Spanner Flange 12 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 9

GENE RICH & COMPANY

TANK BOWL GASKETS

#88 #89 #90

C.P. BRASS FLUSH OFFSET

CLOSET FITTINGS

FLUSH ELBOW

HEAVY TYPE AMBER WAX

Meets government specifications #HHC 536A

Individually Boxed - Full Cartons Only

Item No Description Std. Pkg

88 Heavy Wax Gasket Only 48 Ea

89 w/ 4” Plastic Flange 24 Ea

90 w/Tappered Flange 4”-3” 24 Ea

POLISHED CHROME PLATED BRASS

Complete with Slip Nuts & Washers

Item No Description Std. Pkg

2398 1-1/2”Offset, 2 x 6 1 Ea

POLISHED CHROME PLATED BRASS

Complete with Slip Nuts & Washers

REPAIR FLUSH ELBOW

TOILET PAPER ROLLER

Item No Description Std. Pkg

123 2” x 4” x 6” CP BR Flush Elbow 1 Ea

124 2” x 5” x 7” CP BR Flush Elbow 1 Ea

125 2” x 6” x 8” CP BR Flush Elbow 1 Ea

POLISHED CHROME PLATED BRASS

Complete with Slip Nuts & Washers

Item No Description Std. Pkg

125R 2” x 6” x 8” CP BR Repair Flush Elbow 1 Ea

• Tension Spring

Item No Description Std. Pkg

149 White Plastic Toilet Paper Roller 12 Ea

• White Polystyrene

C.P. BRASS SEAT HINGE

10 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

• Polished Chrome Plated Brass

• Standard pattern

• Complete with plated screws, and all required nuts & washers

Item No Description Std. Pkg

150 CP Brass Seat Hinge 1 Ea

GENE RICH & COMPANY

Replaces virtually any China toilet tank

UNIVERSAL REPLACEMENT TANK

• High Impact Plastic Lid (Vandal proof model includes locking bolts)

• Universal Tank-To-Bowl Adapter Kit w/gaskets & close coupled bolt sets

• Ballcock Kit complete with Float Rod & Ball

• Flush Valve Kit complete with Flapper

• Flush Handle Lever

Item No Description Std. Pkg

TK-1 IMPACTO Tank Replacement Kit 1 Ea

TK-1L Tank Replacement w/Insuliner 1 Ea

TK-1LVP Tank Repl w/Liner & Vandal Proof

1 Ea

BRASS CLOSET SPUDS AND BRASS URINAL SPUDS

Complete with brass locknut, friction ring and flanged rubber washer

Flanged

Item No Size Description

126 1” x 3/4” Urinal Spud W363 W545 139M 25 Ea

127 1-1/4” x 1-1/4” Closet Spud W364 W544 139A 25 Ea

128 1-1/4” x 3/4” Urinal Spud W373 W544 139L 25 Ea

129 1-1/2” x 1-1/2” Closet Spud W365 W543 139C 25 Ea

129A 1-1/2” x 1-1/4” Closet Spud W372 W544 139B 25 Ea

130 2” x 2” Closet Spud W366 W540 139G 25 Ea

134 2” x 1-1/2” Closet Spud W371 W541 139H 25 Ea

135 2” x 1-1/4” Closet Spud W370 W542 139J 25 Ea

Washer

Friction

Ring

Brass

Locknut Std. Pkg

CLOSET FITTINGS

Item No Description Std. Pkg

136 2” x 2” 25 Ea

137 1-1/2” (fits Jr. Basket Strainers) 25 Ea

138 1-1/4” 25 Ea

432 1/2” Die Cast Zinc Locknut 25 Ea

434 3-3/8” for Basket Strainers 12 Ea

Item No Description Std. Pkg

139A 1-1/4” x 1-1/4” 25 Ea

139B 1-1/2” x 1-1/4” 25 Ea

139C 1-1/2” x 1-1/2” 25 Ea

139F 2” x 2” Round 25 Ea

139G 2” x 2” Hex Pattern 25 Ea

139H 2” x 1-1/2” (for Jr. Basket Strainers) 25 Ea

139J 2” x 1-1/4” 25 Ea

139K 3-3/8” (for Basket Strainer) 25 Ea

139L 1-1/4” x 3/4” (for Urinal Spud) 25 Ea

139M 1” x 3/4” (for Urinal Spud) 25 Ea

139P Ballcock Locknut 25 Ea

139R Ballcock Slipnut 25 Ea

139T DT Ballcock Coupling Nut 25 Ea

DIE CAST LOCKNUTS

BRASS LOCKNUTS

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 11

GENE RICH & COMPANY

BRASS LIFT WIRES

Item No Description Std. Pkg

91 8-1/2” Upper 25 Ea

96 5-1/2” Lower 25 Ea

BRASS CLOSET REFILL TUBES

Item No Description Std. Pkg

107 1/4” x 9” 25 Ea

CLOSET FITTINGS

BRASS OVERFLOW TUBES

Item No Description Std. Pkg

109 1” OD x 10-1/2” 25 Ea

110

Full .116 Diameter

Order in packs of 25 or 100

1” x 1-1/8” x 10-1/2” 25 Ea

BRASS GUIDE ARMS

#112 #113

DOUGLAS FLUSH VALVES

• Brass Body

• Plastic Overflow Tube

• With Nuts, Washers and Guide

#140

#140PL

• Plastic Overflow Tube

• Flapper Tank Ball

• With Nuts, Washers and Guide Order in packs of 10 or 50

1” Adjustable Arm

Item No Description Std. Pkg

112 Adjustable 50 Ea

113

Item No Description Std. Pkg

140 Douglas Flush Valve 25 Ea

Duncan Bronze 50 Ea

• Plastic Body, Non-corrosive ABS

Item No Description Std. Pkg

140PL Plastic 10 Ea

#141

12 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

• Brass Overflow Tube

• With Nuts, Washers and Guide

Item No Description Std. Pkg

141 Brass, Import 2 Ea

• Brass Body

GENE RICH & COMPANY

UNIVERSAL OEM STYLE FLAPPER

• Universal Replacement Flapper for Hoov-R-Line*/Coast* Styles

• 3 Way Adapter

• Over 80% OEM Toilets Use This Style and Material

• No-Cut Strap AND Stainless Steel Chain are included

Item No Description Std. Pkg

B03 3-Way Black Flapper:Hoover/Coast 12 Ea

MAINTENANCE TRADE STYLE FLAPPER

• Universal Replacement Flapper for Seal Master/Korky/Korky Plus

• Most Popular Maintenance Trade Design

• Chemical Resistant Material Meets OEM Specifications

• Big Buford* Oversized Seal Surface Even Works On A/S* Actuating Unit

• Stainless Steel Chain Included

Item No Description Std. Pkg

B04 2-Way Red Flapper:Sealmaster/Korky 12 Ea

CLOSET FITTINGS

COAST* OEM FLAPPER

• Stainless Steel Chain Included

Item No Description Std. Pkg

B05 Blue Vinyl Flapper w/Chain, Coast OEM 12 Ea

• Siliconized Construction

• Rated #1 Material, Southern California Municipal Test**

• Resists chemicals and toilet tank cleaners

• Stainless Steel Chain Included

Item No Description Std. Pkg

B07 Crane* Flapper w/Foam Float, SS Chn 1 Ea

• Eljer* original unit with rigid arms

• Foam Cone

• Stainless Steel Beaded Chain Included

Item No Description Std. Pkg

B08 Eljer* Plastic Flapper w/Foam Flt, Chain 1 Ea

• High Grade Vinyl Construction

• White Plastic Construction

CRANE* STYLE FLAPPER

ELJER* STYLE FLAPPER

• Fits Old Style Kohler*

KOHLER* STYLE BIG BULB FLAPPER

• Stainless Steel Chain Included

Item No Description Std. Pkg

B09 Kohler* Big Bulb Flapper w/SS Chain 1 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 13

GENE RICH & COMPANY

KOHLER* STYLE LONG ARM FLAPPER

• Siliconized Construction

• Resists chemicals and toilet tank cleaners

• Stainless Steel Chain Included

• Fits: Rialto, Rosario, Rocjelle, Pillow Talk, San Martina, San Raphael

Item No Description Std. Pkg

B10 Kohler* Long Arm Flapper, w/Chain 1 Ea

KOHLER* STYLE T-BACK FLAPPER

CLOSET FITTINGS

• Siliconized Construction

• Resists chemicals and toilet tank cleaners

• Stainless Steel Chain Included

• Fits: Kelly Graphos, Rialto, Rosario, San Raphael, Santa Rosa

Item No Description Std. Pkg

B11 Kohler* T-Back Rialto Flapper, w/Chain 1 Ea

KOHLER* STYLE SHARKTOP FLAPPER

• Siliconized Construction

• Resists chemicals and toilet tank cleaners

• Stainless Steel Chain Included

• Fits: Citizen, Gabrielle, Revival, Rialto, San Raphael, Santa Rosa

Item No Description Std. Pkg

B12 Kohler* Sharkfin Flapper, w/Chain 1 Ea

JUMBO TOTO* STYLE FLAPPERS

• Siliconized Construction

• Resists chemicals and toilet tank cleaners

• Stainless Steel Chain Included

• Blue: Power Gravity

• Red: G-Max

• Winner of the 2003 BMPMA Award

Item No Description Std. Pkg

B14B Jumbo Toto Flapper, Blue (powr gravity) 1 Ea

B14R Jumbo Toto Flapper, Red (G-Max) 1 Ea

14 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

CENTERLINE ADJUSTABLE FLAPPER

Fits virtually all 1.6 tank flush valves

• Quick Release Thumb Screw with Integral Ball Joint allows the

• seal disc to tilt and telescope for perfect alignment every time! Disc can extend 5/8” and tilt up to 30°

• Fully adjustable timing float provides 1 to 4.5 G.P.F.

• Chemical Resistant

• Individually carded

•

Item No Description Std. Pkg

B15 Centerline Adjustable Flapper 12 Ea

Universal design fits most 1.6 gallon toilets

• Adjustable sealing ball for precise water control

• Easily change the flush volume with just a twist

• Saves up to 50% more water when used in convential toilets

• Chemical resistant chlorazone® body

• Individually carded in cartons of 12

•

Item No Description Std. Pkg

B16 Korky 1.6 Adjustable Flapper 12 Ea

Universal replacement flapper prefered by plumbers since 1954

• Assures a positive seal

• Eliminates lift wire misalignment

• Chemical resistant

• Individually carded for easy display

•

Item No Description Std. Pkg

B54 Black Original 12 Ea

ORIGINAL KORKY PLUS FLAPPER

Universal replacement flapper

• Premium quality chlorazone® construction

• Withstands chloramine and tank cleaners

• 5- year Guarantee

• Individually carded for easy display

•

KORKY 1.6 FLAPPER

by Lavelle

CLOSET FITTINGS

ORIGINAL KORKY FLAPPER

by Lavelle

Item No Description Std. Pkg

B60 Red Korky Plus 12 Ea

KOHLER FLUSH BALL REPLACEMENT

Fits specific Kohler two-piece toilets

• Premium red Chlorazone® rubber resists chlorine

• Replaces Kohler p/n 49114

• Individually carded for easy display

•

Item No Description Std. Pkg

B58 Kohler Flush Ball replacement 12 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 15

by Lavelle

TANK BALLS

GENE RICH & COMPANY

• Tank Balls are boxed to protect shape

#B50

#B51 #B52

CLOSET FITTINGS

DISC SEAT FLAPPERS

#B73 #B74

#B75

• Eljer* Tank Ball for use with Eljer* Touch Flush

• Tri-Seal Tank Ball exerts internal pressure for positive seal

• For small tilt flush valves

• Long rib pattern with smaller O.D.

• All discs are shipped in a plastic case to protect the seat’s shape

• Fit-All Tank Ball is designed to adapt to all types of valve seats

Item No Description Std. Pkg

B50 Fit-All Tank Ball 12 Ea

B51 Eljer* Tank Ball for Touch Flush 12 Ea

B52 Tri-Seal Tank Ball 12 Ea

Item No Description Std. Pkg

B73 Am. Std.* Disc Seat Flapper, Snap-On 25 Ea

B74 Am. Std.* Disc Seat Flapper, Screw-On 25 Ea

B75 Am. Std.* Disc Seat Flapper, Combo 25 Ea

AMERICAN STANDARD* ACUATOR ACCESSORIES

• Chain Kit for all actuator units (Am. Std.* #8321-07)

• Includes Chain, Grommet and Clip

#B79

Item No Description Std. Pkg

B79 Am. Std.* Chain Kit w/Gommet & Clip 10 Ea

AMERICAN STANDARD* FLAPPERS

• Actuator Replacement Kits complete with disc, chain, grommet and clip

• #B82 includes a generic Old Style Black, Low Profile Actuator

#B82

#B84

Use to replace OEM #5 (33642-07)

• #B84 includes a generic Old Style Black, High Profile Actuator Use to replace OEM #6 (72880-07)

Item No Description Std. Pkg

B82 Am. Std.* #5 Low, Black, Actuating Unit 5 Ea

B84 Am. Std.* #6 High, Black, Actuating Unit 5 Ea

16 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

• Chrome Plated Hollow Handle

• 8” Brass Arm

• Metal Spud and Nut

• Individually Boxed

Item No Description Std. Pkg

119 CP Tank Lever, Zinc Spud & Nut 25 Ea

119WPN CP Tank Lever, Plastic Spud & Nut

• Chrome Plated Handle

• Right Hand Threaded - Nut tightens clockwise

• For right hand mount and some handicapped toilets

• 8” Brass Arm

• Plastic Spud and Nut • Individually Boxed

Item No Description Std. Pkg

119-RH CP Br Right Hand Tank Lever 1 Ea

• Chrome Plated Handle

• 8” Brass Arm

• Plastic Spud and Nut

ECONOMY FIT ALL

TOILET TANK TRIP LEVER

DISCOUNTED!

WHEN YOU BUY

100 or more

1 EA

RIGHT HAND

TOILET TANK TRIP LEVER

CLOSET FITTINGS

HEAVY DUTY FIT ALL

TOILET TANK TRIP LEVER

• Individually Boxed

Item No Description Std. Pkg

119-HD Heavy Duty CP Br Tank Lever 1 Ea

• 8” Brass Arm

• Plastic Spud and Nut

• Individually Boxed

Item No Description Std. Pkg

119-AB Antique Brass Tank Lever 1 Ea

• 8” Brass Arm

• Plastic Spud and Nut

• Individually Boxed

• Antique Brass Handle

• Polished Brass Handle

DISCOUNTED!

WHEN YOU BUY

100 or more

ANTIQUE BRASS FIT ALL

TOILET TANK TRIP LEVER

POLISHED BRASS FIT ALL

TOILET TANK TRIP LEVER

Item No Description Std. Pkg

119-PB Polished Brass Tank Lever 1 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 17

GENE RICH & COMPANY

AMERICAN STANDARD* TOILET TANK TRIP LEVERS

AMERICAN STANDARD*

CLOSET FITTINGS

TOILET TANK TRIP LEVER

SHORT ARM TOILET TANK TRIP LEVER

• Chrome Plated Handle

• 5 ½” Brass Arm

• Plastic Spud and Nut

• Individually Bagged w/Hang-up Headers

• 4 ½” Plastic Arm

• Plastic Spud and Nut

• Individually Bagged w/Hang-up Headers

• 4 ½” Brass Arm

Item No Description Std. Pkg

119-MA C.P. Tank Lever, 5-1/2” Arm 1 Ea

• Chrome Plated Plastic Handle

Item No Description Std. Pkg

119-PAS Plastic 4” Tank Lever-Am.Stnd. 1 Ea

• Chrome Plated Handle

• Plastic Spud and Nut

• Individually Boxed

Item No Description Std. Pkg

119-SA C.P. Tank Lever, 4-1/2” Arm 1 Ea

ELJER* SIDE MOUNT TRIP LEVER

• Chrome Plated Handle

• 9” Brass Arm

• Plastic Spud and Nut

• Individually Bagged w/Hang-up Headers

Item No Description Std. Pkg

119-SM CP Tank Lever,Eljer Side Mount 1 Ea

TANK LEVER NUTS

Item No Description Std. Pkg

119-PN Tank Lever Nut - Plastic 10 Ea

119-ZN Tank Lever Nut - Zinc

10 Ea

18 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

Plastic Floats available in 25 Packs and 100 Packs Only

•

Item No Description Std. Pkg

142 4” x 5” Copper 100 Ea

142-12 4” x 5” Copper 12 Ea

143 4” x 5” Plastic 25 Ea

Order in packs of 25 or 100

• BRASS FLOAT RODS

Item No Size Std. Pkg

100 1/4 x 8” 25 Ea

101 1/4 x 9” 25 Ea

102 1/4 x 10” 25 Ea

103 1/4 x 12” 25 Ea

GENUINE COASTMASTER BALLCOCKS

FLOAT BALLS

1/4” - 20 Threads

CLOSET FITTINGS

DISCOUNTED

5% for 72 10% for 144

15% for 504

#2302 & #2303

#2301

All Delrin construction

• Easy to install

• Quiet, Reliable operation

• Brass screws

• Includes: 8” Brass Float Rod

• Vinyl filler tube Locknut, Coupling nut & all washers Individually bagged

• Code approved Anti-Siphon design

•

(#2302 & #2303 only)

Item No Size Type Std. Pkg

2301 8” Regular 24 Ea

2302 12” Anti-Siphon 24 Ea

2303 10” Anti-Siphon 24 Ea

COASTMASTER TOP ASSEMBLIES COAST BALLCOCK REPAIR KIT

Genuine Coastmaster

• Replacement parts

Brass Screws

•

Individually bagged

#2316

Item No Description Std. Pkg

2316 Top Assy. for #2301 1 Ea

2318 Top Assy. for #2302 & 2303 1 Ea

•

#2318

Item No Description Std. Pkg

2100 Ballcock Repair Kit 25 Ea

Genuine Coastmaster

• Replacement parts

Brass Screws

•

Individually bagged

•

HELICAL SPRING REFILL CLIPS

All Brass Spring

•

Refill tube holder slides

• onto overflow tube

Item No Description Std. Pkg

2309 Helical Spring for Ballcock 24 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 19

Item No Description Std. Pkg

2310 Refill Clip For Ballcocks 25 Ea

Plastic construction

•

Use to hold refill tube

• in place

GENE RICH & COMPANY

COASTMASTER LO-BOY FILL VALVE MANSFIELD* STYLE BALLCOCK

Fits many one piece toilets

•

Meets all codes

•

Non-metallic materials

•

Includes float rod and all

• necessary installation parts

All Brass construction

•

Compound lever

•

Refill tube included

•

Float rod included

•

Item No Description Std. Pkg

2304 Coastmaster Lo-Boy Fill Valve 24 Ea

CLOSET FITTINGS

KORKY® QUIETFILL® Proven quietest! ANTI-SIPHON FILL VALVE

Fits all two-piece toilets:

•

All brands, all sizes. Fits most one-piece toilets. Innovative twist-lock action for water level adjustment.

Quietest fill valve available:

•

Laboratory test prove the Korky® QuietFill® is 2 to 3 times quieter than other fill valves.

Anti-siphon design, code approved.

•

Efficient compact design:

•

Internal float makes installation easy. Assures precise water control.

Five-year guarantee

•

Item No Description Std. Pkg

2330 Korky QuietFill Toilet Fill Valve 1 Ea

Item No Description Std. Pkg

2307IMP Elevated Brass Ballcock 1 Ea

FLUIDMASTER® ANTI-SIPHON #1 Best Selling Fill Valve in the World! FILL VALVE

Fits most standard tanks including 1.6 gpf models.

• Anti-siphon, code approved.

• Won’t contaminate fresh water supply. Height adjustable from 9” - 14”.

• “Signals” leaks or water waste by automatically turning on/off during

• periods of non-use. Turn-and-lock cap for easy seal replacement - no tools needed.

• Water level adjusts easily for ideal flush.

• Corrosion-resistant materials withstand harsh water & constant use.

• Easy to install, no special tools required.

•

Item No Description Std. Pkg

FM-400A Fluidmaster Toilet Tank Fill Valve 1 Ea

BALLCOCK NUTS Die Cast Ballcock Nuts

20 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

•

Item No Description Std. Pkg

145 Die Cast Coupling Nut, 11/16” Hole 50 Ea

146 Die Cast Zinc Ballcock Locknut 25 Ea

GENE RICH & COMPANY

BRAIDED STAINLESS STEEL

• Specially formulated NSF and FDA approved PVC compound

• Reinforced with tightly knit external stainless steel braiding

• A quality alternative to inner braided PVC water supply connectors

• Improved reliability and flexibility that resists kinking

• Plastic Nut at ballcock connection

• Brass coupling at the stop

• Solid brass inserts

• Operating temperture range: 30° F - 180° F

• Maximum pressure range: 1,800 psi @ 70° F 1,250 psi @ 180° F

• UPC Approved and Certified to ANSI / NSF 61

CLOSET SUPPLIES

WITH PLASTIC NUT

Item No Description Std. Pkg

653SF 9” - 1/2 ips, 7/8 BC 6 Ea

653SH 12” - 1/2 ips, 7/8 BC 6 Ea

653SL 20” - 1/2 ips, 7/8 BC 6 Ea

653SM 9” - 3/8 comp, 7/8 BC 6 Ea

653SR 12” - 3/8 comp, 7/8 BC 6 Ea

653SR-16 16” - 3/8 comp, 7/8 BC 6 Ea

653SS 20” - 3/8 comp, 7/8 BC 6 Ea

653SU 9” - 1/2 comp, 7/8 BC 6 Ea

653SW 12” - 1/2 comp, 7/8 BC 6 Ea

653SX 20” - 1/2 comp, 7/8 BC 6 Ea

1

/2” ips x 7/8” ips

1

/2” comp x 7/8” ips

3

/8” comp x 7/8” ips

BRAIDED STAINLESS STEEL

• Specially formulated NSF and FDA approved PVC compound

• Reinforced with tightly knit external stainless steel braiding

• A quality alternative to inner braided PVC water supply connectors

• Improved reliability and flexibility that resists kinking

• All Brass Nuts, Couplings and Inserts

• Operating temperture range: 30° F - 180° F

• Maximum pressure range: 1,800 psi @ 70° F 1,250 psi @ 180° F

CLOSET SUPPLIES

WITH BRASS NUT

CLOSET FITTINGS

• UPC Approved and Certified to ANSI / NSF 61

Item No Description Std. Pkg

653SFB 9” - 1/2 ips, 7/8 BR BC 6 Ea

653SHB 12” - 1/2 ips, 7/8 BR BC 6 Ea

653SLB 20” - 1/2 ips, 7/8 BR BC 6 Ea

653SMB 9” - 3/8 comp, 7/8 BR BC 6 Ea

653SRB 12” - 3/8 comp, 7/8 BR BC 6 Ea

653SRB-16 16” - 3/8 comp, 7/8 BR BC 6 Ea

653SSB 20” - 3/8 comp, 7/8 BR BC 6 Ea

653SUB 9” - 1/2 comp, 7/8 BR BC 6 Ea

653SWB 12” - 1/2 comp, 7/8 BR BC 6 Ea

653SXB 20” - 1/2 comp, 7/8 BR BC 6 Ea

1

/2” ips x 7/8” ips

1

/2” comp x 7/8” ips

3

/8” comp x 7/8” ips

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 21

GENE RICH & COMPANY

BRAIDED STAINLESS STEEL LAVATORY SUPPLIES

CLOSET FITTINGS

1

/2” ips x 1/2” ips

1

/2” comp x 1/2” ips

3

/8” comp x 1/2” ips

FLARE ADAPTORS

• Specially formulated NSF and FDA approved PVC compound

• Reinforced with tightly knit external stainless steel braiding

• A quality alternative to inner braided PVC water supply connectors

• Improved reliability and flexibility that resists kinking

• All Brass Nuts, Couplings and Inserts

• Operating temperture range: 30° F - 180° F

• Maximum pressure range: 1,800 psi @ 70° F 1,250 psi @ 180° F

• UPC Approved and Certified to ANSI / NSF 61

Item No Description Std. Pkg

652SF 12” - 1/2 ips, 1/2 ips 6 Ea

652SH 20” - 1/2 ips, 1/2 ips 6 Ea

652SL 12” - 3/8 comp, 1/2 ips 6 Ea

652SL-16 16” - 3/8 comp, 1/2 ips 6 Ea

652SM 20” - 3/8 comp, 1/2 ips 6 Ea

652SR 12” - 1/2 comp, 1/2 ips 6 Ea

652SS 20” - 1/2 comp, 1/2 ips 6 Ea

• Chrome Plated Brass Adaptor with Plastic Washer

• Convert Flare connections to Compression connections

• Replacement Plastic Washers are available

PEX LAVATORY SUPPLY TUBES

PEX CLOSET SUPPLY TUBES

Item No Description Std. Pkg

654A 3/8 Comp x 3/8 Flare, CP 12 Ea

654B 3/8 Comp x 1/2 Flare, CP 12 Ea

654A-W Plastic Washer for #654A Adaptor 12 Ea

654B-W Plastic Washer for #654B Adaptor 12 Ea

Cross linked polyethylene (PEX)

• ASTM F876/877, NSF 61, IAPMO listed

• Rated for 100 psi at 180° F

•

Item No Description Std. Pkg

652PX-12 3/8” x 12” PEX Lavatory Supply Tube 10 Ea

652PX-15 3/8” x 15” PEX Lavatory Supply Tube 10 Ea

652PX-20 3/8” x 20” PEX Lavatory Supply Tube 10 Ea

652PX-30 3/8” x 30” PEX Lavatory Supply Tube 10 Ea

652PX-36 3/8” x 36” PEX Lavatory Supply Tube 10 Ea

Cross linked polyethylene (PEX)

• ASTM F876/877, NSF 61, IAPMO listed

• Rated for 100 psi at 180° F

•

Item No Description Std. Pkg

653PX-12 3/8” x 12” PEX Toliet Supply Tube 10 Ea

653PX-15 3/8” x 15” PEX Toliet Supply Tube 10 Ea

653PX-20 3/8” x 20” PEX Toliet Supply Tube 10 Ea

22 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

• Sure Grip Escutcheons

• Full Packages Only

Item No Size Hole I.D. Flange OD Std. Pkg

160 3/8” IPS 11/16” 2-1/2” 25 Ea

161 1/2” IPS 27/32” 2-1/2” 25 Ea

162 3/4” IPS 1-1/16” 2-1/2” 25 Ea

163 1” IPS 1-3/8” 2-3/4” 25 Ea

164 1-1/4” IPS 1-11/16” 3” 25 Ea

165 1-1/2” IPS 1-15/16” 3-1/2” 25 Ea

165SOD 1-1/2” IPS 1-15/16” 3” 25 Ea

166 2” IPS 2-3/8” 3-1/2” 25 Ea

Item No Size CWT Size Flange OD Std. Pkg

167 3/8” OD 2-1/2” 25 Ea

167A 1/2” OD 3/8” CWT 2-1/2” 25 Ea

168 5/8” OD 1/2” CWT 2-1/2” 25 Ea

168A 3/4” OD 2-1/2” 25 Ea

169 7/8” OD 3/4” CWT 2-1/2” 25 Ea

170 1-1/4” OD 2-3/4” 25 Ea

170A 1-1/8” OD 1” CWT 2-1/2” 25 Ea

171 1-3/8” OD 1-1/4” CWT 2-3/4” 25 Ea

172 1-1/2” OD 2-3/4” 25 Ea

172A 1-5/8” OD 1-1/2” CWT 3” 25 Ea

173 1-3/4” OD 3-1/2” 25 Ea

174 2” OD 3-1/2” 25 Ea

CHROME PLATED STEEL

SHALLOW ESCUTCHEONS

DISCOUNTED

5% for 500

10% for 1,000

ESCUTCHEONS

• Sure Grip Escutcheons

• Full Packages Only

Item No Size Hole I.D. Flange OD Height Std. Pkg

200 3/8” IPS 11/16” 2-3/8” 1-1/8” 25 Ea

201 1/2” IPS 27/32” 2-3/8” 1-1/8” 25 Ea

202 3/4” IPS 1-1/16” 2-3/8” 1-1/8” 25 Ea

203 1” IPS 1-3/8” 3” 1-1/2” 25 Ea

204 1-1/4” IPS 1-11/16” 3” 1-1/4” 25 Ea

205 1-1/2” IPS 1-15/16” 3” 1-1/4” 25 Ea

Item No Size CWT Size Flange OD Height Std. Pkg

207 3/8” OD 2-3/8” 1-1/8” 25 Ea

208 7/16” OD 2-3/8” 1-1/8” 25 Ea

209 1/2” OD 3/8” CWT 2-3/8” 1-1/8” 25 Ea

210 9/16” OD 2-3/8” 1-1/8” 25 Ea

211

212 1-1/4” OD 3” 1-3/8” 25 Ea

213 1-1/2” OD 3” 1-3/8” 25 Ea

5/8” OD 1/2” CWT 2-3/8” 1-1/8” 25 Ea

CHROME PLATED STEEL

DEEP BELL ESCUTCHEONS

DISCOUNTED

5% for 500

10% for 1,000

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 23

GENE RICH & COMPANY

PLASTIC DEEP BELL ESCUTCHEONS

• Sure Grip Escutcheons

• Full Packages Only

PLASTIC, POLISHED BRASS FINISH

PLASTIC, WHITE

ESCUTCHEONS

DEEP BOX ESCUTCHEONS

• Sure Grip, STEEL Escutcheons

• Full Packages Only

CHROME PLATED STEEL

DISCOUNTED

5% for 500

10% for 1,000

Item No Size CWT Size Flange OD Height Std. Pkg

7940PB 5/8” OD 1/2” CWT 2-1/4” 1-1/8” 12 Ea

7945PB 1-1/4” OD 3” 1-5/8” 12 Ea

7946PB 1-1/2” OD 3” 1-5/8” 12 Ea

Item No Size CWT Size Flange OD Height Std. Pkg

7940W 5/8” OD 1/2” CWT 2-1/4” 1-1/8” 12 Ea

7945W 1-1/4” OD 3” 1-5/8” 12 Ea

7946W 1-1/2” OD 3” 1-5/8” 12 Ea

DISCOUNTED

5% for 500

10% for 1,000

Item No Size Hole I.D. Flange OD Height Std. Pkg

214 1-1/4” IPS 1-11/16” 3” 1-1/2” 25 Ea

215 1-1/2” IPS 1-15/16” 3” 1-1/2” 25 Ea

216 1-1/4” OD 1-1/4” 3” 1-1/2” 25 Ea

218 1-1/2” OD 1-1/2” 3” 1-1/2” 25 Ea

219 2” OD 2” 3” 1-3/4” 25 Ea

• Full Packages Only

PLASTIC, POLISHED BRASS FINISH

Item No Size CWT Size Flange OD Height Std. Pkg

7948PB 1-1/4” OD 3” 1-5/8” 12 Ea

7949PB 1-1/2” OD 3” 1-5/8” 12 Ea

• Sure Grip, PLASTIC Escutcheons

24 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

• Full Packages Only

PLASTIC, WHITE

Item No Size CWT Size Flange OD Height Std. Pkg

7948W 1-1/4” OD 3” 2-5/8” 12 Ea

7949W 1-1/2” OD 3” 2-5/8” 12 Ea

• Sure Grip, PLASTIC Escutcheons

GENE RICH & COMPANY

• Heavy Gauge Steel Plates • Full Packages Only

FLOOR

• Tempered steel springs hold the plate to the ceiling

• Plates are copper plated before the nickel finish and chrome is applied

Item No Size Hole I.D. Flange OD Std. Pkg

249 1/4” IPS 5/8” 2-1/4” 12 Ea

250 3/8” IPS 3/4” 2-1/4” 12 Ea

251 1/2” IPS 7/8” 2-1/2” 12 Ea

252 3/4” IPS 1-1/8” 2-3/4” 12 Ea

253 1” IPS 1-3/8” 3-1/4” 12 Ea

254 1-1/4” IPS 1-3/4” 3-1/2” 12 Ea

255 1-1/2” IPS 2-1/16” 3-7/8” 12 Ea

256 2” IPS 2-1/2” 4-1/2” 12 Ea

257 2-1/2” IPS 2-15/16” 5-3/8” 12 Ea

258 3” IPS 3-9/16” 5-7/8” 12 Ea

259 3-1/2” IPS 4-1/8” 6-5/8” 12 Ea

260 4” IPS 4-9/16” 7-1/8” 12 Ea

260A 5” IPS 5-5/8” 9” 12 Ea

260B 6” IPS 6-13/16” 10” 12 Ea

260C 8” IPS 8-15/16” 13-1/4” 12 Ea

260F 10” IPS 11” 16-1/4” 12 Ea

260H 12” IPS 12 Ea

CHROME PLATED STEEL

AND CEILING PLATES

WITH SPRINGS

ESCUTCHEONS

DISCOUNTED

5% for 72

10% for 144

Item No Size Hole I.D. Flange OD Std. Pkg

261 3/8” CWT 1/2” 2-1/8” 12 Ea

262 1/2” CWT 5/8” 2-3/8” 12 Ea

263 3/4” CWT 7/8” 2-3/8“ 12 Ea

264 1” CWT 1-1/8” 3“ 12 Ea

265 1-1/4” CWT 1-3/8” 3-1/4“ 12 Ea

266 1-1/2” CWT 1-5/8” 3-1/4“ 12 Ea

267 2” CWT 2-1/8” 4“ 12 Ea

267A 2-1/2” CWT 2-5/8” 4-7/8“ 12 Ea

268 3” CWT 3-1/8” 5-1/8“ 12 Ea

268A 3-1/2” CWT 12 Ea

269 (Discontinued) 4” CWT Use 3-1/2” IPS (#259)

269A 4-1/2” CWT 12 Ea

270A 5” CWT 12 Ea

270B 6” CWT 6-1/8” 9-1/2“ 12 Ea

270C 8” CWT 8-1/8” 12-1/2“ 12 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 25

GENE RICH & COMPANY

CHROME PLATED STEEL

FLOOR

AND CEILING PLATES

SURE GRIP STYLE

DISCOUNTED

5% for 72

10% for 144

ESCUTCHEONS

• Light Gauge Steel Plates • Full Packages Only

• Plates are copper plated before the nickel finish and chrome is applied.

Item No Size Hole I.D. Flange OD Std. Pkg

272 3/8” IPS 11/16” 2-3/4” 12 Ea

273 1/2” IPS 7/8” 2-3/4” 12 Ea

274 3/4” IPS 1-1/8” 2-3/4” 12 Ea

275 1” IPS 1-3/8” 3-1/2” 12 Ea

276 1-1/4” IPS 1-3/4” 3-1/2” 12 Ea

277 1-1/2” IPS 2” 3-1/2” 12 Ea

278 2” IPS 2-7/8” 4-1/4” 12 Ea

Item No Size Hole I.D. Flange OD Std. Pkg

280 1/2” CWT 5/8” 2-3/4” 12 Ea

281 3/4” CWT 7/8” 2-3/4” 12 Ea

282 1” CWT 1-1/8” 2-3/4” 12 Ea

283 1-1/4” CWT 1-3/8” 3-1/2” 12 Ea

284 1-1/2” CWT 1-5/8” 3-1/2” 12 Ea

CHROME PLATED PLASTIC

FLOOR

AND CEILING PLATES

• Non-Corrosive • Non-Breakable

• 100% Rust Proof • Full Packages Only

• One Piece • Split Ring

Item No Size Hole I.D. Flange OD Std. Pkg

7900 1/2” IPS 0.827” 2.787” 12 Ea

7901 3/4” IPS 1.037” 2.997” 12 Ea

7902 1” IPS 1.298” 3.210” 12 Ea

7903 1-1/4” IPS 1.640” 3.580” 12 Ea

7904 1-1/2” IPS 1.900” 3.900” 12 Ea

7905 2” IPS 2.380” 4.450” 12 Ea

7906 2-1/2” IPS 2.900” 5.280” 12 Ea

7907 3” IPS 3.535” 5.925” 12 Ea

7908 4” IPS 4.575” 6.935” 12 Ea

7909 5” IPS 5.655” 8.655” 6 Ea

7910 6” IPS 6.740” 9.820” 6 Ea

7911

Item No Size Hole I.D. Flange OD Std. Pkg

7924 1/2” CWT 0.612” 2.572” 12 Ea

7925 3/4” CWT 1.037” 2.997” 12 Ea

7926 1” CWT 1.298” 3.210” 12 Ea

7927 1-1/4” CWT 1.361” 3.308” 12 Ea

7928 1-1/2” CWT 1.900” 3.900” 12 Ea

7929 2” CWT 2.105” 4.205” 12 Ea

8” IPS 8.790” 13.010” 6 Ea

26 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

• One Piece • Split Ring

• Non-Corrosive • Non-Breakable

• 100% Rust Proof • Full Packages Only

Item No Size Hole I.D. Flange OD Std. Pkg

7899PB 3/8” IPS 0.688” 2.500” 12 Ea

7900PB 1/2” IPS 0.827” 2.787” 12 Ea

7901PB 3/4” IPS 1.037” 2.997” 12 Ea

7902PB 1” IPS 1.298” 3.210” 12 Ea

7903PB 1-1/4” IPS 1.640” 3.580” 12 Ea

7904PB 1-1/2” IPS 1.900” 3.900” 12 Ea

7905PB 2” IPS 2.380” 4.450” 12 Ea

Item No Size Hole I.D. Flange OD Std. Pkg

7924PB 1/2” CWT 0.612” 2.572” 12 Ea

7925PB 3/4” CWT 1.037” 2.997” 12 Ea

7926PB 1” CWT 1.298” 3.210” 12 Ea

7927PB 1-1/4” CWT 1.361” 3.308” 12 Ea

7928PB 1-1/2” CWT 1.900” 3.900” 12 Ea

7929PB 2” CWT 2.105” 4.205” 12 Ea

Item No Size Hole I.D. Flange OD Std. Pkg

7938PB 1-1/4” OD 1.250” 3.500” 12 Ea

7939PB 1-1/2” OD 1.500” 3.500” 12 Ea

POLISHED BRASS PLASTIC

FLOOR

AND CEILING PLATES

ESCUTCHEONS

• One Piece • Split Ring

• Non-Corrosive • Non-Breakable

• 100% Rust Proof • Full Packages Only

Item No Size Hole I.D. Flange OD Std. Pkg

7899W 3/8” IPS 0.688” 2.500” 12 Ea

7900W 1/2” IPS 0.827” 2.787” 12 Ea

7901W 3/4” IPS 1.037” 2.997” 12 Ea

7902W 1” IPS 1.298” 3.210” 12 Ea

7903W 1-1/4” IPS 1.640” 3.580” 12 Ea

7904W 1-1/2” IPS 1.900” 3.900” 12 Ea

7905W 2” IPS 2.380” 4.450” 12 Ea

Item No Size Hole I.D. Flange OD Std. Pkg

7924W 1/2” CWT 0.612” 2.572” 12 Ea

7925W 3/4” CWT 1.037” 2.997” 12 Ea

7926W 1” CWT 1.298” 3.210” 12 Ea

7927W 1-1/4” CWT 1.361” 3.308” 12 Ea

7928W 1-1/2” CWT 1.900” 3.900” 12 Ea

7929W 2” CWT 2.105” 4.205” 12 Ea

Item No Size Hole I.D. Flange OD Std. Pkg

7938W 1-1/4” OD 1.250” 3.500” 12 Ea

7939W 1-1/2” OD 1.500” 3.500” 12 Ea

FLOOR

WHITE PLASTIC

AND CEILING PLATES

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 27

GENE RICH & COMPANY

DIE CAST LAVATORY COUPLING NUTS

• Polished Chrome Plated Finish

• B and D packs include Rubber Cone Washers

DISCOUNTED

5% for 500

10% for 1,000

IPS x OD Item No Item No Item No Item No Item No

1

/2” x3/8” 300-A 300-B 300-C 300-D 300-E

1

/2” x7/16” 301-A 301-B 301-C 301-D 301-E

1

/2” x1/2” 302-A 302-B 302-C 302-D 302-E

DIE CAST SLIP JOINT NUTS

SLIP JOINT NUTS

1

/2” x9/16” 303-A 303-B 303-C 303-D 303-E

3

/4” x1/2” 305-A 305-B 305-C 305-D 305-E

3

/4” x9/16” 306-A 306-B 306-C 306-D 306-E

DISCOUNTED

5% for 500

• B and D packs include Square Cut Rubber Washers

10% for 1,000

IPS x OD Item No Item No Item No Item No Item No

1 1/4” x 1 1/4” 309-A 309-B 309-C 309-D 309-E

1 1/2” x 1 1/2” 310-A 310-B 310-C 310-D 310-E

1 1/2” x 1 3/8” 311-A 311-B 311-C 311-D 311-E

1 1/2” x 1 1/4” 312-A 312-B 312-C 312-D 312-E

2” x 2” 313-A 313-B 313-C 313-D 313-E

2” x 1 1/2” 315-A 315-B 315-C 315-D 315-E

SIZES

A-Pack

12 to Pkg

Nuts Only

B-Pack

12 to Pkg

w/Washers

C-Pack

25 to Ctn

Nuts Only

• Polished Chrome Plated Finish

A-Pack

12 to Pkg

Nuts Only

B-Pack

12 to Pkg

w/Washers

C-Pack

25 to Ctn

Nuts Only

D-Pack

25 to Ctn

w/Washers

D-Pack

25 to Ctn

w/Washers

E-Pack

250 to Ctn

Nuts Only

E-Pack

250 to Ctn

Nuts Only

SOLID BRASS SLIP JOINT NUTS

SPLIT THREADED COUPLING NUTS

• Polished Chrome Plated Finish

DISCOUNTED

5% for 500

• B and D packs include Square Cut Rubber Washers

10% for 1,000

A-Pack

12 to Pkg

SIZES

IPS x OD Item No Item No Item No Item No Item No

1 1/4” x 1 1/4” 329-A 329-B 329-C 329-D 329-E

1 1/2” x 1 1/2” 330-A 330-B 330-C 330-D 330-E

1 1/2” x 1 1/4” 332-A 332-B 332-C 332-D 332-E

2” x 2” 333-A 333-B 333-C 333-D 333-E

Nuts Only

B-Pack

12 to Pkg

w/Washers

C-Pack

25 to Ctn

Nuts Only

D-Pack

25 to Ctn

w/Washers

• Replaces broken nuts fast and easy

• Patented “Split” design means no pipes to take apart

• For use with plastic or metal pipes.

Item No Description Std. Pkg

320 1-1/4” PVC 12 Ea

321 1-1/2” PVC 12 Ea

28 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

E-Pack

250 to Ctn

Nuts Only

GENE RICH & COMPANY

STAINLESS STEEL

• Made in U.S.A.

DISCOUNTED

5% for 50

• Bright Satin Finish

10% for 100

• Corrosion Resistant

• 18 gauge (.049) 304 Stainless Tubing

• 14 gauge (.078) 304 Stainless Flanges

• All grab bars are supplied with 6 #10 2” Stainless Screws

• Conforms to A.D.A. and ASTM requirements

• Polybagged with complete step-by-step instructions

• Packed 5 Grab Bars per carton

1

/4” O.D. GRAB BARS

EXPOSED MOUNT CONCEALED MOUNT SIZE

Item No Item No O.D. x Length

604-12 605-12 1 1/4” x 12”

604-16 605-16 1 1/4” x 16”

604-18 605-18 1 1/4” x 18”

604-24 605-24 1 1/4” x 24”

604-30 605-30 1 1/4” x 30”

604-36 605-36 1 1/4” x 36”

604-42 605-42 1 1/4” x 42”

604-48 605-48 1 1/4” x 48”

SAFETY

GRAB BARS

TUB & SHOWER

Exposed Mount

1

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 29

1

/2” O.D. GRAB BARS

EXPOSED MOUNT CONCEALED MOUNT SIZE

Item No Item No O.D. x Length

606-12 607-12 1 1/2” x 12”

606-16 607-16 1 1/2” x 16”

606-18 607-18 1 1/2” x 18”

606-24 607-24 1 1/2” x 24”

606-30 607-30 1 1/2” x 30”

606-36 607-36 1 1/2” x 36”

606-42 607-42 1 1/2” x 42”

606-48 607-48 1 1/2” x 48”

GENE RICH & COMPANY

SHOWER CURTAIN PINS

• Easy Clip Style

• Sturdy Nickel Plated Steel Construction

• Use to hang shower curtains, banners, stained glass displays & more

SHOWER ROD FLANGES

JUMBO FLANGES

TUB & SHOWER

Item No Description Std. Pkg

600 NP Steel 100 Ea

• Wall mount screws included

• Poly bagged in pairs

Item No Description Std. Pkg

610 CP Steel, with Set Screw 1 Pr

610LSS CP Steel, Sure Grip Style 1 Pr

• Chrome Plated Die Cast Flanges

• For 1” O.D. Curtain Rods

• All screws included

• Poly bagged in pairs

Item No Description Std. Pkg

612 CP DC Jumbo 1 Pr

612PB Pol. BR DC Jumbo 1 Pr

• Chrome Plated Steel Flanges

ADJUSTABLE SHOWER ROD HOLDERS

#622 #623 #623PB

RUBBER ROD HOLDER PADS

• “EXPAN-TITE” Shower Rod Holders

• For use with 15/16” and 1” OD rods

• Installs quickly . . . easily . . . securely . . . without screws

Item No Description Std. Pkg

622 Polished Aluminum 50 Ea

623 Chrome Plated Plastic 200 Ea

623PB Polished Brass Plated Plastic 12 Ea

• Rubber Replacement Pads

• for Adjustable Rod Holders

Item No Description Std. Pkg

624 Rubber Pads for Rod Holders 25 Ea

5% for 500

10% for 1,000

DISCOUNTED

30 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

• 1” O.D. & 0.025” wall

• Individually wrapped

• Full Carton Quantities Only

Item No Description Std. Pkg

630A 5’ CP Aluminum Curtain Rod 50 Ea

630A-6 5’ CP Aluminum Curtain Rod 6 Ea

630PB 5’ Polished Brass Curtain Rod 6 Ea

633A 6’ CP Aluminum Curtain Rod 50 Ea

633A-6 6’ CP Aluminum Curtain Rod 6 Ea

633PB 6’ Polished Brass Curtain Rod 6 Ea

• 1” O.D. & 0.025” wall

• Rods are individually wrapped and boxed together with holders

• Full Carton Quantities Only

Item No Description Std. Pkg

631A 5’ CP Rod, with #610 CP Steel Holders 50 Ea

631A-6 5’ CP Rod, with #610 CP Steel Holders 6 Ea

631B 5’ CP Rod, with #622 Pol Alum Holders 50 Ea

631B-6 5’ CP Rod, with #622 Pol Alum Holders 6 Ea

631C 5’ CP Rod, with #623 CP Plastic Holders 50 Ea

631C-6 5’ CP Rod, with #623 CP Plastic Holders 6 Ea

DISCOUNTED

5% for 500

10% for 1,000

ALUMINUM SHOWER RODS

DISCOUNTED

5% for 500

10% for 1,000

ALUMINUM SHOWER RODS

W

ITH HOLDERS

TUB & SHOWER

ALUMINUM

CORNER CURTAIN ROD

• 1” O.D. & 0.025” wall

• Jumbo Flanges Included

• Individually Boxed

Item No Description Std. Pkg

27”

625 1” OD x 5’ w/Flanges 1 Ea

52”

ALUMINUM ROD

• All parts are Chrome Plated Steel

• Complete with threaded support rod, ring, flange and screws

Item No Description Std. Pkg

617 24” 1 Ea

618 30” 1 Ea

CEILING SUPPORTS

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 31

GENE RICH & COMPANY

ADD-A-SHOWERS

#685 #686 #687

65” Height 49-1/2” Height 61-1/4” Height CP Bathcock Diverter 3/4” IPS CP Diverter Spout CP Bathcock Diverter w/3-3/8” Center w/3-3/8” Center with 1/2” Bushing 27” x 42” Aluminum Curtain Ring Connection is at the Wall-end 10” Wall Support & 36” Ceiling Support (For spout only, see #640-I pg 38) Set screws allow supports to be cut to the desired length. Only the flange end is threaded

TUB & SHOWER

#687CBC

67-1/4” Height with Code Pattern Bathcock All other specs same as #687

ADD-A-SHOWER CURTAIN RING ONLY

Add-A-Showers feature:

• 3/8” CP Brass Risers with CP Brass Coupling Nut

• All Parts are Chrome Plated

• All brackets, support rods and screws are included

• Individually boxed with installation instructions

• Includes one 24”, 12” and 6” CP support rod

• Two CP Flanges, Four CP Screws, one CP Tee Fitting

• Shower Heads with Max Flow Rate of 2.5 GPM @ 80 psi

Item No Description Std. Pkg

685 w/ Bathcock Diverter Spout 1 Ea

686 w/ Tub Diverter Spout 1 Ea

687 w/ Bathcock Diverter & 27” x 42” Ring 1 Ea

687CBC w/Code Bathcock & Curtain Ring 1 Ea

• Aluminum Curtain Ring is 27” x 42”

27” x 42”

32 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

Item No Description Std. Pkg

687RO 27” x 42” Ring Only 6 Ea

GENE RICH & COMPANY

• Chrome Plated Brass with Brass Locknuts

• 3 3/8” Center and 3/4” threaded inlets

• Replaceable stem and seat

Item No Description Std. Pkg

684 Leg Tub Bathcock (Slip “O” Connection) 1 Ea

• Chrome Plated Brass with Brass Locknuts

• 3 3/8” Center and 3/4” threaded inlets

• 6” Goose Neck Spout

• Meets anti-siphon codes

Item No Description Std. Pkg

684GN CP BR, w/gooseneck 1 Ea

CHROME PLATED BRASS

BATHCOCK

GOOSE NECK

CODE BATHCOCK

• Chrome Plated Brass Bathcock with Brass Locknuts

• 3 3/8” Center and 3/4” threaded inlets

• 6” CP Brass Riser between bathcock and diverter spout

• 3/8” female ips riser fitting

• Meets anti-siphon codes

Item No Description Std. Pkg

684CBC Code Pattern Bathcock Diverter 1 Ea

• 3 3/8” Center and 3/4” threaded inlets

• 3/8” female IPS riser fitting

Item No Description Std. Pkg

689 Bathcock Diverter with 3/8” Riser Fitting 1 Ea

• Chrome Plated Brass Coupling Elbows

• Chrome Plated Brass Bathcock with Brass Locknuts

CODE PATTERN

BATHCOCK DIVERTER

TUB & SHOWER

BATHCOCK DIVERTER

BATHCOCK TAILPIECE

• 3/4” bath cock threads x 1/2” male ips

• Sold in pairs

Item No Description Std. Pkg

3028 NP Brass 6 Pr

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 33

GENE RICH & COMPANY

SHOWERALLS

• 1/2” IPS female connector

• Positioning bar/mount included

• Ideal for heavy outdoor duty

• Handy addition in the bath or kitchen

Item No Description Std. Pkg

700-1 w/71” Vinyl Hose 1 Ea

700-2 w/60” CP Brass Flexible Hose 1 Ea

SHOWERALL

Model ‘A’

• Kit comes with 5 adapters to cover virtually all installations.

• For a leg tub where the spout is mounted on the tub

Item No Description Std. Pkg

700A For Tub Mounted Spouts 1 Ea

TUB & SHOWER

SHOWERALL

Model ‘B’

• Spout IS included in this kit.

• For a wall mounted spout as illustrated

Item No Description Std. Pkg

700B For Wall Mounted Spouts 1 Ea

SHOWERALL

Model ‘C’

• For a shower or tub with a plunger type valve.

Item No Description Std. Pkg

700C For Plunger Type Valves 1 Ea

SHOWERALL

Model ‘D’

• 1/2” IPS female connector

34 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

• 79” chrome plated brass flexible hose

Item No Description Std. Pkg

700D For 1/2” pipe thread connection 1 Ea

GENE RICH & COMPANY

DIE CAST

TUB SPOUTS

#640 #640-A #640-B #640-C #640PB #640PB-B

• 5 3/16” Length • Spouts are individually boxed

Chrome Plated

• Allen Key included with #640-B & #640PB-B

Item No Size Feature Finish Connect @ Std. Pkg

640 1/2” IP DC Chrome Nose 1 Ea

640-A 3/4” IP DC Chrome Nose 1 Ea

640-B 1/2” CWT DC Slide Connect Chrome Wall 1 Ea

640-C 3/4” IP DC w/1/2” Bushing Chrome Wall 1 Ea

Polished Brass Plated

640PB 1/2” IP DC Pol Brass Nose 1 Ea

640PB-B 1/2” CWT DC Slide Connect Pol Brass Wall 1 Ea

CAST BRASS

• Chrome Plated Heavy Duty Cast Brass

• 5” Length

• Spouts are individually boxed

Item No Size Feature Finish Connect @ Std. Pkg

641-IMP 1/2” IPS BR Cast Brass Chrome Wall 1 Ea

Chrome Plated

TUB SPOUT

LONG TUB SPOUTS

Chrome Plated Die Cast Zinc

#640-D1 #640-D2 #640PB-D2 #640-D1

• One Piece Design

• These longer spout designs accomodate larger tubs

•

Chrome Plated Cast Brass #640-D2

• Spouts are individually boxed

3

/4” x 1/2” Brass Bushing is included with -D2 spouts

TUB & SHOWER

Item No Size Feature Finish Connect @ Std. Pkg

640-D1 1/2” IPS DC 7” (1pc) Chrome Nose 1 Ea

640-D2 3/4” IPS BR 8.5” w/1/2 Bshg Chrome Wall 1 Ea

Polished Brass Plated

640PB-D2 3/4” IP Cast BR 8.5” w/1/2 Bshg Pol Brass Wall 1 Ea

Cast Brass #640PB-D2

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 35

GENE RICH & COMPANY

UNIVERSAL CONNECT ADJUSTABLE TUB SPOUT

3/4” IPS 1/2” IPS 5/8” OD Tube Reducer Bushing Adjustable Sleeve Slip-fit Bushing Adjustable Adapter O-Ring Allen Key

Spout Housing

• 5 1/4” Length

• Chrome plated die cast zinc

• Spouts are individually boxed

• Universal design replaces 3 spouts

• Allen Key is included with each spout

• Fits

• Slip-Fits on

1

/2” or 3/4” IPS pipe nipples

5

/8” OD tube, 1/2” nominal size copper pipe

• Patent Pending design provides Quick & Easy Leak-Free Installations

• Telescoping Adjustable Sleeve provides extra one inch to adjustment range

TUB & SHOWER

UNIVERSAL CONNECT ADJUSTABLE DIVERTER SPOUT

Item No Size Feature Finish Connect @ Std. Pkg

640-BC 1/2, 3/4 IP+5/8 od universal spout Chrome Wall 1 Ea

3/4” IPS 1/2” IPS 5/8” OD Tube Reducer Bushing Adjustable Sleeve Slip-fit Bushing Adjustable Adapter O-Ring Allen Key

• 5 1/4” Length

Spout Housing

• Chrome plated die cast zinc

• Spouts are individually boxed

• Universal design replaces 3 diverters

• Allen Key is included with each spout

• Fits

• Slip-Fits on

1

/2” or 3/4” IPS pipe nipples

5

/8” OD tube, 1/2” nominal size copper pipe

• Patent Pending design provides Quick & Easy Leak-Free Installations

• Telescoping Adjustable Sleeve provides extra one inch to adjustment range

Item No Size Feature Finish Connect @ Std. Pkg

640-KF 1/2, 3/4 IP+5/8 od univ. diverter Chrome Wall 1 Ea

36 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

DIE CAST, REAR LIFT

DIVERTER SPOUTS

• Die Cast Zinc

• Rear Lift Diverter

• 5

•

Chrome Plated

• Individually boxed

Item No Size Feature Finish Connect @ Std. Pkg

640-F 3/4 IP DC w/1/2” Bushing Chrome Wall 1 Ea

640PB-F 3/4” IP DC w/1/2” Bushing Pol Brass Wall 1 Ea

Polished Brass Plated

3

/16” Length

3

/4” x 1/2” Bushing is included

• Chrome Plated Cast Brass

DIVERTER SPOUTS

CAST BRASS

• Rear Lift Diverter • 5” Length

•

• Individually boxed

Item No Size Feature Finish Connect @ Std. Pkg

643-IMP 3/4” IP Cast BR Rear Lift Div Chrome Wall 1 Ea

643A-IMP 3/4” IP Cast BR w/1/2” Bushing Chrome Wall 1 Ea

3

/4” x 1/2” Bushing is included with #643A-IMP

DIE CAST, FRONT LIFT

DIVERTER SPOUTS

#640-J #640-K #640-L #640PB-J #640PB-K #640PB-L

• Front Lift Diverter • 5

Chrome Plated

• Die Cast Zinc • Individually boxed

• Allen Key included with #640-K & #640PB-K

•

3

/4” x 1/2” Bushing is included with #640-L & #640PB-L

3

/16” Length

TUB & SHOWER

Item No Size Feature Finish Connect @ Std. Pkg

640-J 1/2 IP DC Front Lift Div Chrome Nose 1 Ea

640-K 1/2 CWT DC Slide Connect Chrome Wall 1 Ea

640-L 3/4” IP DC w/1/2” Bushing Chrome Wall 1 Ea

Polished Brass Plated

640PB-J 1/2” IP DC Front Lift Div Pol Brass Nose 1 Ea

640PB-K 1/2” CWT DC Slide Connect Pol Brass Wall 1 Ea

640PB-L 3/4” IP DC w/1/2” Bushing Pol Brass Wall 1 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 37

GENE RICH & COMPANY

DIVERTER SPOUTS

FOR HAND HELD SHOWERS

Chrome Plated #640-G #640-H #640PB-G #640PB-H

1

/2” Male Hose Fitting for Hand Held Shower Connection

3

/16” Spout Length

3

/4” x 1/2” Bushing is included

Polished Brass Plated

•

• Rear Lift Diverter

• Die Cast Zinc

• 5

•

• Spouts are individually boxed

Chrome Plated

Item No Size Feature Finish Connect @ Std. Pkg

640-G 3/4” & 1/2” IP DC 1/2 top hose ftg Chrome Wall 1 Ea

TUB & SHOWER

Polished Brass Plated

640-H 3/4” & 1/2” IP DC 1/2 btm hse ftg Chrome Wall 1 Ea

640PB-G 3/4” & 1/2” IP DC 1/2 top hose ftg Pol Brass Wall 1 Ea

640PB-H 3/4” & 1/2” IP DC 1/2 btm hse ftg Pol Brass Wall 1 Ea

DIVERTER SPOUT

FOR ADD-A-SHOWERS

• Die Cast Zinc

• Rear Lift Diverter

Chrome Plated Die Cast Zinc

•

• 5

•

• Spouts are individually boxed

• Replacement spout for #686 Add-A-Shower (page 32)

3

/8” Female Riser Fitting

3

/16” Spout Length

3

/4” x 1/2” Bushing is included

Item No Size Feature Finish Connect @ Std. Pkg

640-I 3/4 IP DC 3/8 fem riser ftg Chrome Wall 1 Ea

38 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

LONG DIVERTER SPOUTS

Chrome Plated Die Cast Zinc

#640-M1 #640-M2 #640PB-M2 #640-M1

• One Piece Design

• These longer spout designs accomodate larger tubs

•

Chrome Plated Cast Brass

• Spouts are individually boxed

#640-M2

Item No Size Feature Finish Connect @ Std. Pkg

640-M1 3/4” IP Cast BR w/1/2” Bushing

640-M2 3/4” IP Cast BR w/1/2” Bushing

640PB-M2 3/4” IP DC w/1/2” Bushing

Polished Brass Plated Cast Brass #640PB-M2

3

/4” x 1/2” Brass Bushing is included with -M2 spouts

Chrome Nose 1 Ea

7”, 1pc Divrtr

Chrome Wall 1 Ea

8.5”, 1pc Divrtr

Pol Brass Wall 1 Ea

8.5”, 1pc Divrtr

• Highly Polished Finish

• Extend tub and diverter spouts to accomodate larger tubs

• Useful for whirlpools and roman tubs

• Individually boxed

Item No Size Material Finish Std. Pkg

640-X 3” Die Cast Zinc Chrome Plated 1 Ea

640PB-X 3” Die Cast Zinc Polished Brass 1 Ea

• Solid Brass

•

3

/4” FIP x 1/2” FIP

• For use with Diverter Spouts

Item No Description Std. Pkg

644-IMP Brass Twin Elbow 12 Ea

• Solid Brass

•

3

/4” MIP x 1/2” FIP

TUB AND DIVERTER

SPOUT EXTENDERS

BRASS TWIN ELBOW

FACE BUSHING

TUB & SHOWER

Item No Description Std. Pkg

648 3/4” x 1/2” Brass Face Bushing 25 Ea

`

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 39

VOLUME CONTROL SHOWER HEAD

GENE RICH & COMPANY

• Chrome Plated Brass Body •

• Volume Flow Control • Brass Ball Joint

• 2” CP Die Cast Face • Four Spray Nozzles

Item No Description Std. Pkg

667 2” Face, 1/2” IPS CP Adustable 1 Ea

1

/2” FIP threads

ADJUSTABLE SHOWER HEADS

#668 #668-HD

WATER SAVER SHOWER HEADS

TUB & SHOWER

#670 #670W

#672

CLOG RESISTANT SHOWER HEAD

• Chrome Plated Brass Body • Brass Ball Joint

• Adjustable Spray •

1

/2” FIP threads

• CP Brass Face • Individually boxed

Item No Description Std. Pkg

668 1-3/4” Face, 1/2” IPS CP BR Adjustable 1 Ea

668-HD 2-1/4” Face, 1/2” IPS CP BR Adjustable 1 Ea

• 2.5 GPM @ 80 PSI •

• 1

Item No Description Std. Pkg

670 1-3/4” Face, Chrome Plated Plastic 1 Ea

670W 1-3/4” Face, White Plastic 1 Ea

672 1-3/4” Face, Chrome Plated BRASS 1 Ea

3

/4” White Plastic Face • Individually boxed

1

/2” FIP threads

• Clog Resistant Rubber Tips • Screen Insert

• Chrome Plated Brass Body • Brass Ball Joint

• 2.5 GPM @ 80 PSI •

• 2” Face (2

1

/2” Head) • Individually boxed

1

/2” FIP threads

Item No Description Std. Pkg

673A CP Br Shower Head, clog resistant 1 Ea

DELUXE RAIN SHOWER 8” SHOWER HEAD

• Clog Resistant Rubber Tips

• Chrome Plated Brass Body • Brass Ball Joint

• 2.5 GPM @ 80 PSI •

• 8” Rain Shower Face • Individually boxed

40 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

Item No Description Std. Pkg

673R 8” CP Br Rainshower Shower Head 1 Ea

1

/2” FIP threads

GENE RICH & COMPANY

SHOWER DIVERTER VALVE

•

1

/2” FIP x 1/2” MIP x 1/2” MIP

• Installs between arm and shower head

• Allows use of a hand held shower or shower head

Item No Description Std. Pkg

682B Push-Pull CP Br Shower Diverter Valve 5 Ea

•

1

/2” MIP x 1/2” FIP • Individually boxed

• Restricts water flow (but is not a shut-off valve)

WATER VOLUME

FLOW CONTROLS

• Push Button Control allows 2.45 GPM @ 80 PSI

Item No Description Std. Pkg

683 Push Button 2.45 GPM Flow Control 12 Ea

683H Shower Control Valve 20 Ea

#683 #683H

• Chrome Plated Brass

•

1

/2” MIP threads • 45 degree bend

SHOWER ARMS

Item No Description Std. Pkg

690 6” CP Brass Shower Arm 12 Ea

691 8” CP Brass Shower Arm 12 Ea

• Chrome Plated Brass

• Adds 8” or 10” to the height of the shower head

•

Item No Description Std. Pkg

692A 8” ‘S’ Style Shower Arm 1 Ea

692B 10” ‘S’ Style Shower Arm 1 Ea

• Chrome Plated Brass •

1

/2” MIP threads (shower head & flange is not included)

1

/2” IP threads

• Locking wing nut adjustment

• Raise or lower shower head by up to 10”

Item No Description Std. Pkg

693 10” Adjustable 1 Ea

‘S’ PATTERN

SHOWER ARMS

ADJUSTABLE SHOWER ARM

TUB & SHOWER

SHOWER ARM FLANGES

• Chrome Plated

Item No Description Std. Pkg

694 Sure Grip style (2-1/4” OD) 25 Ea

695 Flange w/set screw (2-1/2” OD) 25 Ea

#694 #695

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 41

GENE RICH & COMPANY

BRASS SHOWER ARM ELBOW

• Securely mounts a shower arm or tub spout nipple

to a fiberglass shower stall

• Brass locknuts secure the elbow to the fiberglass wall

• Requires a 1

1

/32” hole through the fiberglass

• Use with copper, iron pipe or compression fittings

• Outlet end:

• Inlet end: 1/2” female sweat or 1/2” NPS (for IP)

1

/2” FIP

DISCOUNTED

5% for 60 or more

Item No Description Std. Pkg

696 Fiberglass Shower Arm Ell 12 Ea

OFFSET BATH SUPPLIES

Double Offset Single Offset

•

• Chrome Plated Brass • Includes nuts, washers & escutcheons

#650 #651

9

/16” OD annealed tube • One pair per box

Item No Description Std. Pkg

650 Double Offset 25 Pr

650P Trim for Offset Bath Supply 1 Ea

651 Single Offset 25 Pr

TUB & SHOWER

OVERFLOW PLATE

WITH TRIP LEVER

• Spring assembly holds trip lever position secure

• 3

• Die Cast Steel with Chrome or Polished Brass Finish

1

/4” diameter plate • Square handle trip lever

• 2” bolt hole centers • Individually boxed

Item No Description Std. Pkg

639 Chrome Pltd Trip Ovrflw Plate w/screws 1 Ea

639A Chrome Pltd Trip Overflow Plate Only 12 Ea

639PB Pol BR Pltd Trip Overflw Plate w/screws 1 Ea

639A-PB Pol BR Pltd Trip Overflow Plate Only 12 Ea

639S 1-3/4” Chrome Plated Steel Screws 100 Ea

639S-PB 2-1/4” Pol. Brass Plated Steel Screws 100 Ea

SQUARE OVERFLOW PLATE

42 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

• Polished Stainless Steel

• 2

Item No Description Std. Pkg

3005 Square, 1 Hole Tub Overflow Plate 25 Ea

7

/8” Square

GENE RICH & COMPANY

• Chrome Plated Die Cast Zinc

• 3

1

/4” diameter plate • Order screws separately

• #3006 features 2” bolt hole centers

Item No Description Std. Pkg

3006 CP, 2 Hole, Round 25 Ea

#3006 #3006A

3006A CP, 1 Hole, Round 25 Ea

OVERFLOW PLATES

CP ABS ROUND

CP ROUND

• Chrome Plated ABS Plastic

• 3

1

/4” diameter plate

• Steel bracket and chrome plated steel screw included

Item No Description Std. Pkg

3007 ABS Fit-all Face Plate Assy. 1 EA

OVERFLOW PLATE

WITH SCREW AND BRACKET

POLISHED BRASS PLATED

• Polished Brass Plated Die Cast Zinc

• 3

1

/4” diameter plate

ROUND OVERFLOW PLATE

WITH SCREWS

• 2” bolt hole centers • Screws included

Item No Description Std. Pkg

3008 PVD 2 Hole Overflow Plate+Scrw 20 Ea

• Brass

• 22 Gauge tube

• Price Pfister* style

Item No Description Std. Pkg

637 1-3/8” Waste & Overflow Shoe 12 Ea

638 1-1/2” Waste & Overflow Shoe 12 Ea

• Polished Stainless Steel

• Price Pfister* style

TUB & SHOWER

WASTE AND OVERFLOW

SHOES

WASTE AND OVERFLOW

SHOE STRAINERS

Item No Description Std. Pkg

638S Waste & Overflow Strainer Only 12 Ea

638SG Waste & Overflow Strainer w/Grid 12 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 43

GENE RICH & COMPANY

BEADED CHAIN

AND COUPLINGS

#C38

#C55

‘B’ ‘A’

#C58 #C59

RUBBER BATH STOPPERS

• Nickel Plated Brass

• #10 Size,

Item No Description Std. Pkg

C36 11” NP `B` #10 Bead Chain 12 Ea

C37 11” NP `A` #10 Bead Chain 12 Ea

C38 15” NP `B` #10 Bead Chain 12 Ea

C39 15” NP `A` #10 Bead Chain 12 Ea

Item No Description Std. Pkg

C55 #10 Bead Chain (100’ Reel) 1 Ea

Item No Description Std. Pkg

C58 NP `B` Bead Chain Coupling 100 Ea

C59 NP `A` Bead Chain Coupling 100 Ea

3

/16”

• White Hollow Rubber • Rustproof Ring

• Full Cartons Only

TUB & SHOWER

#S100 - #S108

#4320

FLIP-IT STOPPERS

Tub Stoppers

Chrome Antique Polished Brass Brass

Lavatory Stoppers

Item No Description Std. Pkg

S100 1” 12 Ea

S101 1-1/8” 12 Ea

S102 1-1/4” 12 Ea

S103 1-3/8” 12 Ea

S104 1-1/2” 12 Ea

S105 1-5/8” 12 Ea

S106 1-3/4” 12 Ea

S107 1-7/8” 12 Ea

S108 2” 12 Ea

4320 1-1/2 - 2” Fit-All Tub Stopper 12 Ea

• Flip the lever to easily open and close the stopper

• Easy installation, no tools needed

• Assorted o-rings are included to fit most drains

• Delrin and ABS consturction

• Available in Chrome, Antique Brass and Polished Brass Finishes

Item No Description Std. Pkg

635F-CP Tub Stopper, Chrome Pltd 1 Ea

635F-AB Tub Stopper, Antique BR 1 Ea

635F-PB Tub Stopper, Polished BR 1 Ea

635FJ-CP Lav Stopper, Chrome Pltd 1 Ea

635FJ-AB Lav Stopper, Antique BR 1 Ea

635FJ-PB Lav Stopper, Polished BR 1 Ea

44 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

• Solid Brass Bushing

• Adapts a 1

Item No Description Std. Pkg

636A 1-1/2MIP x 1-1/4FIP BR Adaptor 20 Ea

1

/4” bath drain to fit a 11/2” waste connection

ADAPTOR BUSHING

BATH DRAIN

BATH DRAIN & OVERFLOW TRIM KITS

All kits contain: 1 Two Hole Round Overflow Plate

#636KL

2 Chrome or Brass Plated Steel Screws Series

1 11/4” Bath Drain (with 2 3/4” od flange) 1 11/2” MIP x 11/4” FIP Brass Adaptor

Item No Material Type Finish Std. Pkg

636KLB Die Cast Lift Drain Kit Polished Brass 1 Ea

636KLC Die Cast Lift Drain Kit Chrome Plated 1 Ea

636KLBB Brass Lift Drain Kit Polished Brass 1 Ea

636KLCB Brass Lift Drain Kit Chrome Plated 1 Ea

#636KT

636KTB Die Cast Popup Drain Kit Polished Brass 1 Ea

Series

636KTC Die Cast Popup Drain Kit Chrome Plated 1 Ea

636KTBB Brass Popup Drain Kit Polished Brass 1 Ea

636KTCB Brass Popup Drain Kit Chrome Plated 1 Ea

• Rubber gasket included • 2 3/4” OD Flange • Individually Boxed

LIFT-N-TURN

BATH DRAINS

Item No Material Size Type Finish Std. Pkg

636LB1 Die Cast 1-1/4” Lift+Turn Polished Brass 1 Ea

636LC1 Die Cast 1-1/4” Lift+Turn Chrome Plated 1 Ea

636LB2 Die Cast 1-1/2” Lift+Turn Polished Brass 1 Ea

636LC2 Die Cast 1-1/2” Lift+Turn Chrome Plated 1 Ea

636LB1B Brass 1-1/4” Lift+Turn Polished Brass 1 Ea

636LC1B Brass 1-1/4” Lift+Turn Chrome Plated 1 Ea

636LB2B Brass 1-1/2” Lift+Turn Polished Brass 1 Ea

#636L Series

636LC2B Brass 1-1/2” Lift+Turn Chrome Plated 1 Ea

• Rubber gasket included • 2 3/4” OD Flange • Individually Boxed

TOE TOUCH POP-UP

BATH DRAINS

Item No Material Size Type Finish Std. Pkg

636TB1 Die Cast 1-1/4” PopUp Polished Brass 1 Ea

636TC1 Die Cast 1-1/4” PopUp Chrome Plated 1 Ea

636TB2 Die Cast 1-1/2” PopUp Polished Brass 1 Ea

636TC2 Die Cast 1-1/2” PopUp Chrome Plated 1 Ea

636TB1B Brass 1-1/4” PopUp Polished Brass 1 Ea

636TC1B Brass 1-1/4” PopUp Chrome Plated 1 Ea

636TB2B Brass 1-1/2” PopUp Polished Brass 1 Ea

#636T Series

636TC2B Brass 1-1/2” PopUp Chrome Plated 1 Ea

TUB & SHOWER

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 45

GENE RICH & COMPANY

BRASS FEMALE IRON PIPE SHOWER DRAINS

ZINC FEMALE IRON PIPE SHOWER DRAINS

• Cast Bass Body

• 4

• Slotted Strainer Grid

Item No Description Std. Pkg

654IMP 1-1/2” IPS Brass Drain 1 Ea

655IMP 2” IPS Brass Drain 1 Ea

• Chrome Plated Zinc Body

• 4

• Slotted Strainer Grid

Item No Description Std. Pkg

656 1-1/2” IPS CP Zinc Drain 1 Ea

657 2” IPS CP Zinc Drain 1 Ea

1

/4“ O.D. Stainless Steel Strainer

1

/4“ O.D. Stainless Steel Strainer

BRASS CAULK SHOWER DRAIN

TUB & SHOWER

ASSEMBLED CAST IRON

SHOWER

AND FLOOR DRAINS

• Chrome Plated Brass Body

• 4

1

/4“ O.D. Stainless Steel Strainer

• 2” Caulk

• Add a #660-G gasket to convert to no-caulk

Item No Description Std. Pkg

666 2” Caulk CP Brass Drain 1 Ea

• 2” IPS Brass Spud

• 4“ O.D. Stainless Steel Round Strainer

• Tongue and groove cast iron bolt down clamping ring

• Weep holes on top and bottom for secondary drainage

• Add a #660-G gasket to #659 to convert unit to no-caulk

46 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

Item No Description Std. Pkg

658 2” IPS 1 Ea

659 2” Caulk 1 Ea

GENE RICH & COMPANY

• Fits over 2” or inside 3” schedule 40 DWV pipe

• 2” IPS PVC Spud

• 4“ O.D. Stainless Steel Round Strainer

• Tongue and groove PVC bolt down clamping ring

• Clamping ring has weep holes for secondary drainage

Item No Description Std. Pkg

662PVC PVC Drain for 2”OD & 3”ID Pipe 1 Ea

SHOWER

ASSEMBLED PVC

AND FLOOR DRAIN

SHOWER DRAIN

• Convert 2” caulk drains to no-caulk

Item No Description Std. Pkg

660-G Shower Drain Connector Gasket 1 Ea

BRASS SHOWER STALL DRAINS

CONNECTOR GASKET

• Fits 2” Schedule 40 plastic or cast iron pipe

• Designed for prefab shower stalls

• 4

• Includes locknut, rubber washer, & fiber washer

#660

• Add a #660-G gasket to convert to no-caulk

1

/4“ O.D. Snap-in Stainless Steel Strainer

• Individually boxed

Item No Description Std. Pkg

660 2” Caulk, BR, less gasket 1 Ea

#661

661 2” IPS BR 1 Ea

NO CAULK

TUB & SHOWER

• Fits 2” Schedule 40 plastic or cast iron pipe

SHOWER DRAINS

• Designed for prefab shower stalls

• 4

#663PVC #663ABS

• Includes: Locknut, rubber washer, fiber washer,

compression gasket & wrench for tightening the gasket

• Individually boxed

Item No Description Std. Pkg

663ABS 2” No Caulk ABS Shower Drain 1 Ea

663BR 2” No Caulk BRASS (140NC) 1 Ea

#663BR

663PVC 2” No Caulk PVC (101PNC) 1 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 47

1

/4“ O.D. Snap-in Stainless Steel Strainer

GENE RICH & COMPANY

SHOWER PAN LINER

SHOWER PAN LINER CEMENT

•

Orange 40 mil flexible PVC sheet No underlayment required, may be glued directly to drain for a positive seal Meets FHA, HUD requirements for shower pans & ASTM D-4551

Item No Mil Width Length Sq. Ft. Std. Pkg

PL4405 40 4 Ft. x 50 Ft. 200 1 Roll

PL4504 40 5 Ft. x 40 Ft. 200 1 Roll

PL4605 40 6 Ft. x 50 Ft. 300 1 Roll

PL4410 40 4 Ft. x 100 Ft. 400 1 Roll

PL4510 40 5 Ft. x 100 Ft. 500 1 Roll

PL4610 40 6 Ft. x 100 Ft. 600 1 Roll

PVC Solvent

•

Dauber included

•

For joining seams of vinyl shower pan liner

•

Item No Description Std. Pkg

PLC660 Shower Pan Liner Cement 1 Ea

PLASTIC WATER HEATER PAN For use with electric water heaters

Meets Southern building codes

•

TUB & SHOWER

Hi-impact styrene

•

Predrilled drain hole

•

1” x 1 1/2” PVC Drain

•

2 1/2” Deep

•

Item No O.D. I.D. Std. Pkg

WHP20 20-1/2” 20” 3 Ea

WHP22 24-1/8” 22” 3 Ea

WHP24 25-1/2” 24” 3 Ea

WHP26 27-3/4” 26” 3 Ea

ALUMINUM WATER HEATER PAN For use with gas water heaters

One piece construction

•

Predrilled drain hole

•

1” x 1 1/2” PVC Drain

•

2 1/8” Deep

•

Item No O.D. I.D. Std. Pkg

WHA20 22” 20” 3 Ea

WHA22 24” 22” 3 Ea

WHA24 25-1/2” 24” 3 Ea

WHA26 28” 26” 3 Ea

WHA30 32” 30” 3 Ea

WATER HEATER STAND

Durable galvanized steel

•

Easy screw and nut assembly

•

Item No Water Htr Size Wt Limit Dimensions Std. Pkg

WHS21 30-65 Gal 650 lbs 21” x 21” x 18” H 1 Ea

WHS24 75-100 Gal 1300 lbs 24” x 24” x 18” H 1 Ea

48 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

SHARKBITE® CONNECTION SYSTEM

STRAIGHT COUPLING REDUCING COUPLING

Fits OD controlled copper, CPVC or PEX pipe

• Push-fittings, no soldering, clamps, unions or glue required.

• Certified to 200 PSI and 200°F

• Certified to IGC 188 • IAPMO listed

• Certified to ANSI/NSF-61 • Compact, DZR brass body

• Meets UPC, IPC and cUPC requirements

•

Item No Size Std. Pkg

U008 1/2” x 1/2” 12 Ea

U016 3/4” x 3/4” 12 Ea

U020 1” x 1” 6 Ea

Item No Size Std. Pkg

U058 3/4” x 1/2” 12 Ea

U060 1” x 3/4” 6 Ea

STRAIGHT CONNECTOR REDUCING CONNECTOR

Item No Size Std. Pkg

U072 1/2” x 1/2” FNPT 12 Ea

U088 3/4” x 3/4” FNPT 6 Ea

U094 1” x 1” FNPT 6 Ea

U120 1/2” x 1/2” MNPT 12 Ea

U134 3/4” x 3/4” MNPT 12 Ea

U140 1” x 1” MNPT 6 Ea

Item No Size Std. Pkg

U068 1/2” x 3/4” FNPT 6 Ea

U116

U142 1” x 3/4” MNPT 6 Ea

1/2” x 3/4” MNPT 6 Ea

TEE REDUCING TEE

Item No Size Std. Pkg

U362 1/2” x 1/2” x 1/2” 12 Ea

U370 3/4” x 3/4” x 3/4” 12 Ea

U374 1” x 1” x 1” 6 Ea

U412 3/4” x 3/4” x 1/2” 12 Ea

U444 3/4” x 1/2” x 3/4” 12 Ea

U454 3/4” x 1/2” x 1/2” 12 Ea

U416 1” x 1” x 3/4” 6 Ea

PIPE NIPPLES & FITTINGS

ELBOW DROP EAR ELBOW

Item No Size Std. Pkg

U248 1/2” x 1/2” 12 Ea

U256 3/4” x 3/4” 12 Ea

U274 3/4” x 1/2” 6 Ea

U260 1” x 1” 6 Ea

U280 1/2” x 1/2” MNPT 6 Ea

U308 1/2” x 1/2” FNPT 6 Ea

DISCONNECT CLIPS

Item No Size Std. Pkg

U710 1/2” 1 Ea

U712 3/4” 1 Ea

U714 1” 1 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 49

Disassembly is quick and easy

Item No Size Std. Pkg

U249 1/2” x 1/2” 6 Ea

U334 1/2” x 1/2” FNPT 6 Ea

HY-EAR ELBOW

Item No Size Std. Pkg

U335 1/2” x 1/2” FNPT 6 Ea

END STOP

Item No Size Std. Pkg

U514 1/2” 12 Ea

U518 3/4” 6 Ea

U520 1” 6 Ea

RED BRASS NIPPLES

GENE RICH & COMPANY

• Manufactured in accordance with ASTM B-687

• All sizes are packed 12 pieces per carton

• Larger diameters and longer lengths are also available by special order

Item No Size

2446A 1/8” x Close

2446B 1/8” x 1-1/2”

2446C 1/8” x 2”

2446D 1/8” x 2-1/2”

2446E 1/8” x 3”

2446F 1/8” x 3-1/2”

2446G 1/8” x 4”

2446H 1/8” x 4-1/2”

2446J 1/8” x 5”

2446K 1/8” x 5-1/2”

2446L 1/8” x 6”

Item No Size

2448A 1/4” x Close

2448B 1/4” x 1-1/2”

2448C 1/4” x 2”

2448D 1/4” x 2-1/2”

2448E 1/4” x 3”

2448F 1/4” x 3-1/2”

2448G 1/4” x 4”

2448H 1/4” x 4-1/2”

2448J 1/4” x 5”

2448K 1/4” x 5-1/2”

2448L 1/4” x 6”

PIPE NIPPLES & FITTINGS

Item No Size

2456A 1” x Close

2456C 1” x 2”

2456D 1” x 2-1/2”

2456E 1” x 3”

2456F 1” x 3-1/2”

2456G 1” x 4”

2456H 1” x 4-1/2”

2456J 1” x 5”

2456K 1” x 5-1/2”

2456L 1” x 6”

Item No Size

2450A 3/8” x Close

2450B 3/8” x 1-1/2”

2450C 3/8” x 2”

2450D 3/8” x 2-1/2”

2450E 3/8” x 3”

2450F 3/8” x 3-1/2”

2450G 3/8” x 4”

2450H 3/8” x 4-1/2”

2450J 3/8” x 5”

2450K 3/8” x 5-1/2”

2450L 3/8” x 6”

Item No Size

2458A 1-1/4 x Close

2458C 1-1/4 x 2”

2458D 1-1/4 x 2-1/2”

2458E 1-1/4 x 3”

2458F 1-1/4 x 3-1/2”

2458G 1-1/4 x 4”

2458H 1-1/4 x 4-1/2”

2458J 1-1/4 x 5”

2458K 1-1/4 x 5-1/2”

2458L 1-1/4 x 6”

Item No Size

2452A 1/2” x Close

2452B 1/2” x 1-1/2”

2452C 1/2” x 2”

2452D 1/2” x 2-1/2”

2452E 1/2” x 3”

2452F 1/2” x 3-1/2”

2452G 1/2” x 4”

2452H 1/2” x 4-1/2”

2452J 1/2” x 5”

2452K 1/2” x 5-1/2”

2452L 1/2” x 6”

Item No Size

2460A 1-1/2 x Close

2460C 1-1/2 x 2”

2460D 1-1/2 x 2-1/2”

2460E 1-1/2 x 3”

2460F 1-1/2 x 3-1/2”

2460G 1-1/2 x 4”

2460H 1-1/2 x 4-1/2”

2460J 1-1/2 x 5”

2460K 1-1/2 x 5-1/2”

2460L 1-1/2 x 6”

Item No Size

2454A 3/4” x Close

2454B 3/4” x 1-1/2”

2454C 3/4” x 2”

2454D 3/4” x 2-1/2”

2454E 3/4” x 3”

2454F 3/4” x 3-1/2”

2454G 3/4” x 4”

2454H 3/4” x 4-1/2”

2454J 3/4” x 5”

2454K 3/4” x 5-1/2”

2454L 3/4” x 6”

Item No Size

2462A 2” x Close

2462D 2” x 2-1/2”

2462E 2” x 3”

2462F 2” x 3-1/2”

2462G 2” x 4”

2462H 2” x 4-1/2”

2462J 2” x 5”

2462K 2” x 5-1/2”

2462L 2” x 6”

50 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

RED BRASS 45° STREET ELBOWS

Item No Size

2513B 3/8”

2514B 1/2”

2515B 3/4”

RED BRASS 90° STREET ELBOWS

Item No Size

2517B 3/8”

2518B 1/2”

2519B 3/4”

RED BRASS TEES

Item No Size

2521B 3/8” x 3/8” x 3/8”

2522B 1/2” x 1/2” x 1/2”

2523B 3/4” x 3/4” x 3/4”

2524B 1/2” x 1/2” x 3/8”

2525B 3/4” x 3/4” x 1/2”

RED BRASS 45° ELBOWS

Item No Size

2527B 3/8”

2528B 1/2”

2529B 3/4”

RED BRASS 90° ELBOWS

Item No Size

2506B 3/8”

2507B 1/2”

2508B 3/4”

2510B 1/2x3/8 Reducer

2511B

3/4x1/2 Reducer

RED BRASS COUPLINGS

Item No Size

2531B 3/8”

2532B 1/2”

2533B 3/4”

RED BRASS BUSHINGS

Item No Size

2534B 1/4” x 1/8”

2535B 1/2” x 3/8”

2536B 1/2” x 1/4”

2538B 3/4” x 1/2”

RED BRASS FLANGES

Item No Size

2545B 1/2”

2546B 3/4”

RED BRASS CAPS

Item No Size

2553B 3/8”

2554B 1/2”

2555B 3/4”

RED BRASS REDUCER COUPLINGS

Item No Size

2548B 1/2” x 3/8”

2550B 3/8” x 1/4”

2551B 3/4” x 1/2”

RED BRASS PLUGS

Item No Size

2540B 3/8”, Solid

2541B 1/2”, Solid

2542B 3/4”, Solid

RED BRASS UNIONS

Item No Size

2557B 3/8”

2558B 1/2”

2559B 3/4”

PIPE NIPPLES & FITTINGS

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 51

CHROME PLATED BRASS NIPPLES

GENE RICH & COMPANY

• Manufactured in accordance with ASTM B-687

• All sizes are packed 12 pieces per carton

• Larger diameters and longer lengths are also available by special order

Item No Size

2470 3/8” x Close

2471 3/8” x Short

2472 3/8” x 2”

2473 3/8” x 2-1/2”

2474 3/8” x 3”

2475 3/8” x 3-1/2”

2476 3/8” x 4”

2477 3/8” x 4-1/2”

2478 3/8” x 5”

2479 3/8” x 5-1/2”

2480 3/8” x 6”

CHROME PLATED BRASS

45° ELBOWS

12 pieces per carton

•

Item No Size

2482 1/2” x Close

2483 1/2” x Short

2484 1/2” x 2”

2485 1/2” x 2-1/2”

2486 1/2” x 3”

2487 1/2” x 3-1/2”

2488 1/2” x 4”

2489 1/2” x 4-1/2”

2490 1/2” x 5”

2491 1/2” x 5-1/2”

2492 1/2” x 6”

Item No Size

2495 3/4” x Short

2496 3/4” x 2”

2497 3/4” x 2-1/2”

2498 3/4” x 3”

2499 3/4” x 3-1/2”

2500 3/4” x 4”

2501 3/4” x 4-1/2”

2502 3/4” x 5”

2503 3/4” x 5-1/2”

2504 3/4” x 6”

CHROME PLATED BRASS

45° STREET ELBOWS

12 pieces per carton

•

Item No Size

PIPE NIPPLES & FITTINGS

CHROME PLATED BRASS

90° ELBOWS

52 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

2527 3/8”

2528 1/2”

2529 3/4”

12 pieces per carton

•

Item No Size

2506 3/8”

2507 1/2”

2508 3/4”

2510 1/2x3/8 Reducer

2511

3/4x1/2 Reducer

CHROME PLATED BRASS

90° STREET ELBOWS

Item No Size

2513 3/8”

2514 1/2”

2515 3/4”

12 pieces per carton

•

Item No Size

2517 3/8”

2518 1/2”

2519 3/4”

GENE RICH & COMPANY

CHROME PLATED

•

Item No Size

2521 3/8” x 3/8” x 3/8”

2522 1/2” x 1/2” x 1/2”

2523 3/4” x 3/4” x 3/4”

2524 1/2” x 1/2” x 3/8”

2525 3/4” x 3/4” x 1/2”

CHROME PLATED

BRASS BUSHINGS

•

Item No Size

2535 1/2” x 3/8”

2536 1/2” x 1/4”

2538 3/4” x 1/2”

BRASS TEES

12 pieces per carton

CHROME PLATED

BRASS COUPLINGS

Item No Size

2531 3/8”

2532 1/2”

2533 3/4”

CHROME PLATED BRASS

REDUCER COUPLINGS

Item No Size

2548 1/2” x 3/8”

2550 3/8” x 1/4”

2551 3/4” x 1/2”

12 pieces per carton

•

12 pieces per carton

•

Item No Size

2553 3/8”

2554 1/2”

2555 3/4”

CHROME PLATED

BRASS CAPS

12 pieces per carton

•

CHROME PLATED HOLLOW

•

Item No Size

2540 3/8”, Hollow

2541 1/2”, Hollow

2542 3/4”, Hollow

CHROME PLATED

•

Item No Size

2557 3/8”

2558 1/2”

2559 3/4”

BRASS PLUGS

12 pieces per carton

PIPE NIPPLES & FITTINGS

BRASS UNIONS

12 pieces per carton

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 53

GENE RICH & COMPANY

BRASS HOSE FITTINGS

• All sizes are packed 12 pieces per carton

SWIVEL GARDEN HOSE FITTINGS

#701 #702 & #703

Female Pipe to Female Hose

Item No Size

701 1/2 FPT x 3/4 FHT, Swivel

702 3/4 FPT x 3/4 FHT, Swivel

Female Hose to Female Hose

Item No Size

703 3/4 FHT x 3/4 FHT, Swivel

MALE HOSE FITTINGS

Female Pipe to Male Hose

HOSE WYE

Item No Size

710 3/4 FHT x 3/4 MHT x 3/4 MHT

HOSE CAP

Item No Size

712 3/4” FHT Hose Cap

FEMALE HOSE FITTINGS

Female Pipe to Female Hose

#704 #707

Item No Size

704 1/2 FPT x 3/4 MHT

707 3/4 FPT x 3/4 MHT

DUAL Male/Female Pipe to Male Hose

HOSE FITTINGS

Item No Size

705 1/2 FPT x 3/4 MPT x 3/4 MHT

Male Pipe to Male Hose

Item No Size

706 1/2 MPT x 3/4 MHT

Item No Size

709 3/4 FPT x 3/4 FHT

DUAL Male/Female Pipe to Female Hose

Item No Size

708 1/2 FPT x 3/4 MPT x 3/4 FHT

Male Pipe to Female Hose

Item No Size

705A 1/2 MPT x 3/4 FHT

54 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

•

3

/4” FHT x 3/4” MHT

• Breakaway set screw deters unauthorized removal

• Specially designed to prevent sillcock freezing.

Just remove the hose and push the white plastic tripping stem to one side to drain out collected water.

• Individually boxed

Item No Description Std. Pkg

711 Back Flow Preventer 12 Ea

• 1

1

/4” x 5” Two Piece Wrot

• 20 Gauge Polished Chrome Plated Tailpiece

• Complete with Stainless Steel Chain and Rubber Stopper

• Mack washer and fiber washer

• Individually boxed

Item No Description Std. Pkg

679 2pc w/Chain, stopper & tailpiece 1 Ea

BRASS BACKFLOW

PREVENTER

5” WROT 2 PIECE

P.O. PLUG

• 1

1

/4” x 7” One Piece Brass

• 17 Gauge Polished Chrome Plated Tailpiece

• With Vandalproof 19 Hole CP Brass Grid

• Mack washer, fiber washer and brass locknut

• Individually boxed

Item No Description Std. Pkg

680 Cast Br, w/grid & tailpiece 1 Ea

• Chrome Plated Brass Drain & Pop-Up Assembly

• 20 Gauge Chrome Plated Brass Tailpiece

• Chrome Plated Brass Lift Rod

• Mack washer, fiber washer and brass locknut

• Individually boxed

COMMERCIAL GRID STYLE

LAVATORY DRAIN

CHROME PLATED

POP-UP WASTE

KITCHEN & LAVATORY SINK ITEMS

Item No Description Std. Pkg

524 CP Brass 1 Ea

526 CP ABS 1 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 55

GENE RICH & COMPANY

LOTION DISPENSERS

FAUCET HOLE COVERS

#573 #571 #575

FAUCET ROSETTE

• All Brass Pump

• 7 oz. lotion bottle

• Individually boxed

Item No Description Std. Pkg

488 Chrome Finish 1 Ea

489 Polished Brass Finish 1 Ea

490 White Enamel Finish 1 Ea

• Stainless Steel

• Carton Quantities only

Item No Description Std. Pkg

571 1-3/4” OD, CP 25 Ea

573 2” OD, CP with washer 25 Ea

575 1-1/2” OD, NP Snap-In Cover 25 Ea

• Zinc Plated Steel

• Carton Quantities only

Item No Description Std. Pkg

#580 #581

BASIN FAUCET

580 Deep Pattern 25 Ea

581 Flat Pattern 25 Ea

• Chrome Plated Brass

• Replaceable seat and stem

• Meets NSF standard 61.9

• Hot and Cold buttons included

• Includes rosette, washer, locknut, cone washer and coupling nut

Item No Description Std. Pkg

677 CP Brass 2 Ea

SELF-CLOSING BASIN FAUCETS

KITCHEN & LAVATORY SINK ITEMS

• Chrome Plated Brass

• Replaceable stem, cam and spring mechanism

• Includes rosette, washer, locknut, cone washer and coupling nut

#677SC

#677SC-HD

56 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

Item No Description Std. Pkg

677SC Self-Closing Basin Faucet 1 Ea

677SC-HD Self-Closing Basin Faucet, Heavy 1 Ea

GENE RICH & COMPANY

• Chrome Plated Heavy Brass

•

• Spring Action Cross Handle

• Individually boxed

Item No Description Std. Pkg

676SC Self-Closing Stop 1 Ea

1

/2” FIP x 1/2” FIP

SELF-CLOSING

STOP VALVE

• Chrome Plated Heavy Brass

•

1

/2” FIP x 1/2” FIP

• Spring Action Lever Handle

• Includes stainless steel pull chain with rings to

hold valve open hands-free

• Individually boxed

Item No Description Std. Pkg

676SCL Self-Closing Shower Valve w/Ch 1 Ea

• Chrome Plated Brass

•

3

/8” FIP connection

• Lead free, meets NSF standard 61.9

• Stainless steel cartridge

• Individually boxed

SELF-CLOSING

SHOWER VALVE

PUSH BUTTON

FOUNTAIN

BUBBLER

Item No Description Std. Pkg

678BTN Push-Button Fountain Bubbler 1 Ea

SELF-CLOSING

FOUNTAIN BUBBLER

• Chrome Plated Heavy Brass

•

• Spring Action Cross Handle

• Individually boxed

Item No Description Std. Pkg

678SC Self-Closing Fountain Bubbler 1 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 57

1

/2” FIP

KITCHEN & LAVATORY SINK ITEMS

GENE RICH & COMPANY

WALL SINK FAUCETS

• Chrome Plated Cast Brass

• Standard 8” Centers

• CP Soap Dish

KITCHEN DECK FAUCET

• Chrome Plated Cast Brass

• Standard 8” Centers

• CP Cast Brass Spout

• Renewable Seats

KITCHEN DECK FAUCET

WITH GOOSENECK SPOUT

• Chrome Plated Cast Brass

• Standard 8” Centers

Item No Description Std. Pkg

506 Wall Sink, 6” Spout 1 Ea

508 Wall Sink, 8” Spout 1 Ea

512 Wall Sink, 12” Spout 1 Ea

Item No Description Std. Pkg

514 CP Deck, Cast BR Spout 1 Ea

BAR SINK FAUCET

KITCHEN & LAVATORY SINK ITEMS

LAVATORY FAUCET

• 8” CP Brass Gooseneck Spout

• Renewable Seats

Item No Description Std. Pkg

516 CP Deck, Gooseneck Spout 1 Ea

• Chrome Plated Cast Brass

• 4” Centers - Fits all standard bar sinks

• 10” High CP Brass Spout

• Clear Acrylic Handles

• Max flow rate of 2.0 GPM @ 60 psi

• 1/2” IPS connections

Item No Description Std. Pkg

518 4” CP Brass Bar Sink 1 Ea

• Chrome Plated Cast Brass

• Standard 4” Centers

• Clear Acrylic Handles

• Renewable Seats

Item No Description Std. Pkg

58 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

520 4” CP BR Lav, Less Popup 1 Ea

522 4” CP BR Lav, With Popup 1 Ea

GENE RICH & COMPANY

GENERIC DELTA REPLACEMENT PARTS

Item No Description

Repair Kit For

SINGLE CHROME HANDLE FAUCETS

2 Large O Rings, 2 Small O Rings

2 Old Style Seats with springs

DL1

DL2

DL25

DL61

1 Cam, 1 Packing, 1 Wrench

Repair Kit For

CRYSTAL HANDLE FAUCETS

(Except Scald-Guard)

2 Old Style Seats with springs

1 Cam, 1 Packing, 1 Wrench

Repair Kit For

SINGLE HANDLE FAUCETS

2 Large O Rings, 2 Small O Rings

Repair Kit For

CHROME HANDLE FAUCETS

1 Cam & 1 Packing

Item No Description

STEM UNIT

For

ALL DELTA* TWO HANDLE FAUCETS

DL1740

SINGLE CHROME HANDLE FAUCET

DL3614

DL3616

Hang-up Header/Bag

Repair Kit for

2 Large O Rings, 2 Small O Rings

2 New Style Seats with springs

1 Cam, 1 Packing, 1 Wrench

Repair Kit for

CRYSTAL HANDLE FAUCETS

(Except Scald-Guard)

2 New Style Seats with springs

1 Cam, 1 Packing, 1 Wrench

ALL DELTA/DELEX FAUCETS

BRASS

DL70B DL70P

DL134

DL188

BRASS

DL212B DL212P

BRASS and PLASTIC BALLS

for

CHROME HANDLE FAUCETS

2 Large O Rings, 2 Small O Rings

PLASTIC

Brass Ball-Delta Chrome Faucet

Plastic Ball-Delta Chrme Fauct

ALL FAUCETS

2 Old Style Seats with springs

Repair Kit For

CRYSTAL HANDLE FAUCETS

(Except Scald-Guard)

1 Cam & 1 Packing

BRASS and PLASTIC BALLS

for

CRYSTAL HANDLE FAUCETS

2 Large O Rings, 2 Small O Rings

PLASTIC

Brass Ball-Delta Crystl Faucet

Plastic Ball-Delta Crystl Handle

DL4993

DL6000

DL1805

DL1806

DL3426

DL3427

2 New Style Seats with springs

ALL FAUCETS

2 Old Style Seats with springs

2 New Style Seats with springs

OLD STYLE SEAT

100 per Box

NEW STYLE SEAT

100 per Box

OLD STYLE SPRING

100 per Box

NEW STYLE SPRING

100 per Box

KITCHEN & LAVATORY SINK ITEMS

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 59

Left Hand Right Hand

closes closes

counter-clockwise clockwise

GENE RICH & COMPANY

FAUCET STEM ASSEMBLIES

As a general rule, a valve stem which closes to the right (clockwise) will be your hot right hand threaded stem. If the valve stem closes to the left (counter-clockwise) it will be your cold left hand threaded stem. Not every stem follows this guideline. Exceptions include the Acorn, Chicago, Crane Dial-Ease and other brands of stems which do not close downward against a seat. These style stems close upwards against a seat surface. Faucets with round or square handles almost always close to the right (clockwise) on hot and cold sides. For replacement stems, order the right hand thread in this case.

AMERICAN STANDARD* - Aquaseal

Item No Stem Std. Pkg

540AST-01L Left hand 1 Ea

540AST-01R

Right hand 1 Ea

CENTRAL BRASS*

Item No Stem Std. Pkg

540CEN-01L Left hand 1 Ea

540CEN-01R Right hand 1 Ea

CRANE* - Dial Ease

Item No Stem Std. Pkg

540CRA-04L Left hand 1 Ea

540CRA-04R Right hand 1 Ea

ELJER* - Lusterline

Item No Stem Std. Pkg

540ELJ-01L Left hand 1 Ea

540ELJ-01R Right hand 1 Ea

INDIANNA BRASS*

Item No Stem Std. Pkg

540IND-02L Left hand 1 Ea

540IND-02R Right hand 1 Ea

KOHLER* - Valvet

Item No Stem Std. Pkg

540KOH-04L Left hand 1 Ea

540KOH-04R Right hand 1 Ea

PRICE PFISTER*

Item No Stem Std. Pkg

540PPF-02R Right hand 1 Ea

SAYCO* - Spaceage

Item No Stem Std. Pkg

540SAY-01L Left hand 1 Ea

540SAY-01R

Right hand 1 Ea

STERLING*

Item No Stem Std. Pkg

540STG-01L Left hand 1 Ea

540STG-01R Right hand 1 Ea

KITCHEN & LAVATORY SINK ITEMS

GERBER*

Item No Stem Std. Pkg

540GER-01L Left hand 1 Ea

540GER-01R Right hand 1 Ea

UNION BRASS*

Item No Stem Std. Pkg

540GOP-01L Left hand 1 Ea

540GOP-01R Right hand 1 Ea

60 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

• Decorative Acrylic Crystal Handles

• Hot and Cold buttons & screws included

Item No Description Std. Pkg

550RPT Delta* Crystal 2-Handle, Tub/Shower 5 Pr

550RS Delta* Crystal Single Handle 5 Ea

550RSO Delta* Crystl Single Offset Handle 5 Ea

FAUCET HANDLES FOR

DELTA* / PEERLESS*

FAUCET HANDLES FOR

• Chrome Plated Canopy handles (CPC)

• Decorative Acrylic Crystal Handles (RPD)

#551CPC

• Hot and Cold buttons & screws included

Item No Description Std. Pkg

#551RPD

551CPC Delex/P* 2 Handle Chrome Canopy 5 Pr

551RPD Delex/P*, Crystal, 2 Handle 5 Pr

• Teardrop handle replaces both Teardrop and Round handles

• Hot and Cold buttons & screws included

DELEX* / PEERLESS*

FAUCET HANDLES FOR

MOEN*

Item No Description Std. Pkg

552RF Moen* Round Crystal, Flush 5 Ea

552RR Moen* Round Crystal, Recess 5 Ea

552TF Moen* Teardrop, Crystal,Flush 5 Ea

#552R #552T

552TR Moen* Teardrop, Crystal,Recess 5 Ea

• Screws included

• Individually bagged

FAUCET HANDLES FOR

MIXET*

• Use the Clear Inner handle with the Chrome outer handle

Item No Description Std. Pkg

554NL Mixet* Inner Handle, Clear 5 Ea

554NS Mixet* Inner Handle, Smoke 5 Ea

554TC Mixet* Outer Handle, Chrome 5 Ea

554TL Mixet* Outer Handle, Clear 5 Ea

554TS Mixet* Outer Handle, Smoke 5 Ea

FAUCET HANDLES FOR

• Decorative Acrylic Crystal Handles

• Hot and Cold buttons & screws included

PRICE PFISTER*

KITCHEN & LAVATORY SINK ITEMS

Item No Description Std. Pkg

#556RL #556WS

556RL Pfister* Large Crystal Handle, Pair 5 Pr

556WL Pfister* Large Windsor Crystal, Single 5 Ea

556WS Pfister* Small Windsor Crystal, Pair 5 Pr

#556WL

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 61

GENE RICH & COMPANY

LEVER HANDLES

CROSS HANDLES

• Chrome Plated economy handles

• Fit-All Indexed Lever style

• Allen wrench & Set screws included

Item No Description Std. Pkg

698 Regular CP Fit-All, w/wrench 6 Pr

• Chrome Plated heavy duty handles

• Fit-All Indexed Lever style

• Patented “Twin-Grip” design

Item No Description Std. Pkg

820 CP Vise Grip Indexed 1 Pr

• Chrome Plated economy handles

• Fit-All Indexed Cross style

• Allen wrench & Set screws included

Item No Description Std. Pkg

699 Regular CP Fit-All, w/wrench 6 Pr

• Chrome Plated heavy duty handles

• Fit-All Indexed Cross style

HEAVY DUTY FAUCET HANDLES

• Patented “Twin-Grip” design

Item No Description Std. Pkg

822 CP Vise Grip Indexed 1 Pr

• Indexed Lucite Faucet Handle Replacements

• Patented “Twin-Grip” design

Item No Description Std. Pkg

825 Two Valve Lucite Lav. Handles 1 Pr

HOSE BIBB HANDLES

KITCHEN & LAVATORY SINK ITEMS

826 Three Valve Shower Set,Lucite 1 St

• Hose Bibb Handle Replacements

Item No Description Std. Pkg

1426A Round Tee, 12-Knurl, Zinc 24 Ea

1426B Oval Wheel, 5/16” Sq. Hole, Zinc 24 Ea

1426C Open Wheel, 5/16” Sq. Hole, Zinc 24 Ea

1426D Open Wheel, 12-Knurl, Zinc 24 Ea

FAUCET HANDLE PULLER

62 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

• Tempered Steel • Removes any type of faucet handle.

• Adjustable guide sets pulling arms to securely grip the handle.

• Turning the cross bar exerts pulling pressure to remove the handle.

Item No Description Std. Pkg

6760 Faucet Handle Puller 5 Ea

GENE RICH & COMPANY

MIRROR ACRYLIC COVERUPS

#830 #831 #832 #833 BEFORE

• Conceals damaged tiles • No tools required - Use silicone caulk

Item No # of Holes Hole ID Width Height Thick Std. Pkg

830 One 1-3/4” 3.5” 3.5” 1/8” 1 Ea

831 One 5” 14” 8” 1/8” 1 Ea

832 Two 1-3/4” 14” 6” 1/8” 1 Ea

AFTER

833 Three 1-3/4” 14” 6” 1/8” 1 Ea

NON-SLOTTED FAUCET AERATORS

• Chrome Plated Brass

Female

• Meets ANSI A-112.18M

Threads #460FR #461FR

Individually

Male Threads #462FR #464FR

Dual Threads #463FR #463N22-6

bagged

10 per Box 6 per Tube

460FR 460N22-6 55/64” - 27 Female 2.2

461FR 461N22-6 3/4” - 27 Female 2.2

462FR 462N22-6 15/16” - 27 Male 2.2

464FR 464N22-6 13/16” - 27 Male 2.2

463FR 463N22-6

Thread

Size

Female 55/64” - 27

Male 15/16” - 27

Thread

Type

Dual 2.2

GPMItem No Item No

SLOTTED SPRINGFLO AERATORS

• Genuine Springflo Brand (#38D)

• Chrome Plated Brass • Meets ANSI A-112.18M

• 27 Threads per inch

• Counter display contains 144 aerators: 24 tubes of 6 each

Item No Threads GPM Pcs/Tube Std. Pkg

463S22-6 Springflo Dual 15/16”m, 55/64”f 2.2 6 1 Tb

463S22-144 Springflo Dual 15/16”m, 55/64”f 2.2 6 x 24 tubes 1 Ctn

SWIVEL

• Meets ANSI A-112.18M • Individually bagged

• #466FR switches from stream to spray with just a pull

Item No Threads GPM Std. Pkg

465FR Dual 15/16”m, 55/64”f Swivel 2.2 10 Ea

466FR Dual 15/16”m, 55/64”f Double Swivel/Spray 2.2 10 Ea

#466FR #465FR

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 63

AERATORS

KITCHEN & LAVATORY SINK ITEMS

GENE RICH & COMPANY

RINSING SPRAY HEADS

DISCOUNTED!

5% for 72 pcs

#468 #468IMP

#477 #477CP #477IMP #477CP-IMP

10% for 144+ pcs

HOSE GUIDES

DISCOUNTED!

5% for 72 pcs

10% for 144+ pcs

• Improved rinsing sprays.

• Attaches to existing hose to replace any automatic on-off (thumb-control) sink spray.

• Individually boxed

Item No Description Std. Pkg

468 White Spray Head - Rinse Quik 1 Ea

468IMP White Spray Head 1 Ea

477 Black Spray Head - Rinse Quik 1 Ea

477IMP Black Spray Head 1 Ea

477CP Chrome Plated Spray Head - Rinse Quik 1 Ea

477CP-IMP Chrome Plated Spray Head 1 Ea

• For deck- or ledge-mount installations.

• New, high quality plastic core prevents excessive hose wear, lengthens hose life.

• Chrome plated, 2” OD raised escutcheon prevents

water from running into under-sink area.

#469 #486 #469IMP #486IMP

RINSING SPRAY HEAD & HOSE ASSEMBLY

DISCOUNTED!

5% for 72 pcs

KITCHEN & LAVATORY SINK ITEMS

#475 #475CP #475IMP #475CP-IMP

10% for 144+ pcs

Item No Description Std. Pkg

469 White Hose Guide - Rinse Quik 1 Ea

469IMP White Hose Guide 1 Ea

486 Black Hose Guide - Rinse Quik 1 Ea

486IMP Black Hose Guide 1 Ea

• Improved rinsing spray with 4-foot hose to replace any automatic on-off (thumb-control) spray and hose on any

ledge- or deck-mount faucet.

• #475-series include a unversal hose Coupling.

• #476 includes a

Item No Description Std. Pkg

475 Black Spray & Hose, w/univ.cplg - Rinse Quik 1 Ea

475IMP Black Spray & Hose, w/univ.cplg 1 Ea

476 Black Spray & Hose w/1/4”f Ftg - Rinse Quik 1 Ea

475CP Chrome Plated Spray & Hose - Rinse Quik 1 Ea

475CP-IMP Chrome Plated Spray & Hose 1 Ea

1

/4” IP Union nut.

64 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

• Fits All Major Brands including: American Standard, Briggs, Central Brass, Chicago Faucet, Delta, Gerber, Kohler, Moen,

4 FOOT HOSE FOR

RINSING SPRAYS

Peerless and Price Pfister.

• This hose length is for use when the faucet is mounted on the ledge or deck of the sink.

• Universal coupling at faucet end of hose.

Fits any faucet ever made for use with automatic spays.

• Spray end of hose fits any automatic on-off rinsing spray head.

• #479 is the genuine RINSE QUIK MR-4 OEM replacement hose,

#479

packaged in a hang up bag.

• The generic #479IMP includes a black spray head lower assembly,

with washers and lock ring, all packaged in a hang up box.

Item No Description Std. Pkg

479 4’ Hose for Spray - Rinse Quik 1 Ea

479IMP 4’ Hose for Spray 1 Ea

#479IMP

• #480 is the same as #479, except the faucet end of hose is

fitted with a 1/4” female pipe thread union nut.

• Genuine RINSE QUIK MR-4C OEM replacement hose,

packaged in a hang up bag.

Item No Description Std. Pkg

#480

480 4’ Hose w/1/4” Union Nut - Rinse Quik 1 Ea

• This hose length is for use when the faucet is mounted on

30 INCH HOSE

the wall above the sink.

• Genuine RINSE QUIK MR-30 OEM replacement hose

• Includes universal coupling, washers and lock ring.

Item No Description Std. Pkg

485 30” Hose for Spray Heads - Rinse Quik 1 Ea

#485

•

Item No Description Std. Pkg

3474 Universal Brass Hose Coupling 12 Ea

#3474

1

/8” FIP x 1/4” FIP

• Replaces automatic on-off shampoo sprays supplied with bath and lavatory spouts, beauty or barber shop basins.

UNIVERSAL BRASS HOSE COUPLING

RINSE QUIK

SHAMPOO SPRAY HEAD

• Squeeze and release to turn on and off. Interchangeable with

any thumb-controlled (automatic on-off) sink rinsing spray.

KITCHEN & LAVATORY SINK ITEMS

• Genuine RINSE QUIK MR-421 OEM replacement

Item No Description Std. Pkg

487 Shampoo Spray Head - Rinse Quik 1 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 65

GENE RICH & COMPANY

JUNIOR DUO DEEP BASKET STRAINER

• For 2” and 2

• Chrome Plated Brass

JUNIOR DUO STRAINERS

#442

#442A #442B

Item No Description Std. Pkg

441 2-1/2 Deep Duplex Strainer 1 Ea

441B Replacement Basket for #441 1 Ea

• Stainless steel body

• Fits 1

3

/4” bar sinks

• Complete with washers and 1

• Includes chrome plated flat grid, crumb cup with post or

a 1 3/4” rubber stopper.

Item No Description Std. Pkg

442 Stainless Duplex Strainer 1 Ea

442A w/Crumb Cup 1 Ea

442B w/1-3/4”stopper 1 Ea

1

/2” deep outlets and bar sinks

1

/2” die cast locknut

JUNIOR DUO STRAINER CRUMB CUP

• 1

#414

#415 #416

JUNIOR DUO STRAINER GRID ONLY

KITCHEN & LAVATORY SINK ITEMS

OLD STYLE SINK STRAINER

• For use with #442 series junior strainers

• Available with or without a post,

or with post and rubber stopper.

Item No Description Std. Pkg

414 Crumb Cup with post & stopper 1 Ea

415 Crumb Cup with post 12 Ea

416 Crumb Cup without post 12 Ea

• 1

• Replacement for #442 series junior duo strainers

Item No Description Std. Pkg

417 For #442 Jr Strainer 12 Ea

• Polished Stainless Steel

• 4

• Screw holes measure 3

1

/2” stainless steel baskets

7

/8” polished aluminum grid

1

/2” diameter

7

/8” center-to-center.

66 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

Item No Description Std. Pkg

420 Old Style S.S. Sink Strainer 12 Ea

GENE RICH & COMPANY

• 4 1/2” Stainless steel body fits a 3 1/2” opening

• 2 3/4” polished stainless steel grid

Complete with: 4

3 3/8” die cast strainer locknut (#434) 1 1/2” pvc flanged washer (#W381) 1 1/2” die cast locknut (#310)

Item No Description Std. Pkg

443 Wide Flange Stainless Grid Strainer 1 Ea

• 4 1/2” Stainless steel body fits a 3 1/2” opening

• Lift-N-Turn stainless crumb cup with rubber stopper

Complete with: 4

3 3/8” die cast strainer locknut (#434) 1 1/2” pvc flanged washer (#W381) 1 1/2” die cast locknut (#310)

Item No Description Std. Pkg

444 S.S., w/cup 1 Ea

3

/8” od x 3 3/8” id fiber & rubber (#W389) washers

3

/8” od x 3 3/8” id fiber & rubber (#W389) washers

WIDE FLANGE GRID STRAINER

• Stainless steel

• Drop post with neoprene stopper

DUO BASKET STRAINER

REPLACEMENT BASKETS

• Fits most basket strainers.

Item No Description Std. Pkg

446 Stainless Steel 25 Ea

448 Imp. Drop Post S.S. 25 Ea

BASKET STRAINER

WASHERS AND LOCKNUTS

#310 #W381

Item No Size Description Std. Pkg

137 1-1/2” Die Cast Locknut for Jr. Basket 25 Ea

310 1-1/2” Chrome Plated Zinc Slip Nut 25 Ea

#434

434 3-3/8” Die Cast Sink Strainer Locknut 12 Ea

W381 1-1/2” PVC Flanged Washer 100 Ea

W389 4-3/8”od x 3-3/8” id Rubber Duo Strainer Washer 25 Ea

#W389 #W390

W390 4-3/8”od x 3-3/8” id Plastic Duo Strainer Washer 25 Ea

• Vinyl construction • 4” O.D. Stopper

• White plastic lift • Flanged to fit 3” and 3

Item No Description Std. Pkg

#4325

4325 Garbage Disposer Stopper 10 Ea

1

/4”

SINK STOPPER

KITCHEN & LAVATORY SINK ITEMS

• Snap-fit reinforced ring • Fits all disposal brands

Item No Description Std. Pkg

4326 Disposal Splash Guard 12 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 67

DISPOSAL SPLASH GUARD

GENE RICH & COMPANY

WASTE DISPOSER TEE

WITH BAFFLE

WASTE TEE

• Brass construction, satin finish

• 1 1/2” slip joint inlets

• 1 1/2” fine thread outlet

• Complete with nuts and washers

Item No Description Std. Pkg

3390 Waste Disposer Tee & Baffle 25 Ea

• Brass construction, satin finish

1

• 1

• 1 1/2” fine thread outlet

• Complete with nuts and washers

Item No Description Std. Pkg

3392 1-1/2” Brass Waste Tee 25 Ea

• Brass construction, chrome plated finish

• 1 1/2” slip joint connections all the way around

• Complete with nuts and washers

Item No Description Std. Pkg

3397 1-1/2” 3 Way Repair Tee 25 Ea

/2” slip joint inlets

90° WASTE ELBOW

45° WASTE ELBOW

KITCHEN & LAVATORY SINK ITEMS

WASTE EXTENSION COUPLING

• Brass construction, polished chrome plated finish

• Slip joint inlet and outlet

• Complete with nuts and washers

Item No Description Std. Pkg

3405 1-1/2” x 90° Waste Elbow 25 Ea

3406 1-1/4” x 90° Waste Elbow 25 Ea

• Brass construction, polished chrome plated finish

• Slip joint inlet and outlet

• Complete with nuts and washers

Item No Description Std. Pkg

3409 1-1/2” x 45° Waste Elbow 25 Ea

3410 1-1/4” x 45° Waste Elbow 25 Ea

• Brass construction, polished chrome plated finish

• Slip joint connection on both ends

• Complete with nuts and washers

Item No Description Std. Pkg

3412 1-1/2” x 1-1/2” Extension Coupling 25 Ea

3414 1-1/4” x 1-1/4” Extension Coupling 25 Ea

68 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

• Brass body, brass ferrule and brass nut

• MIP connectors are combination female sweat

MALE IRON PIPE x SWEAT

Item No Size Std. Pkg

3500 1-1/4” MIP x 1-1/4” OD 12 Ea

Male

3501 1-1/2” MIP x 1-1/2” OD 12 Ea

3502 1-1/2” MIP x 1-1/4” OD 12 Ea

FEMALE IRON PIPE x SWEAT

Item No Size Std. Pkg

3503 1-1/4” FIP x 1-1/4” OD 12 Ea

3504 1-1/2” FIP x 1-1/2” OD 12 Ea

3505 1-1/2” FIP x 1-1/4” OD 12 Ea

Female

BRASS WASTE CONNECTORS

BRASS WASTE CONNECTOR

• All brass replacement compression rings

COMPRESSION RING

Item No Size Std. Pkg

3509 1-1/4” 12 Ea

3510 1-1/2” 12 Ea

Fit vitreous china, steel or cast iron lavatories

•

1” Chrome Plated Tips

•

2” Tall Hex Escutcheon with set screw

• allows for 1 ½” of adjustability

Assembled range: 28 ½” - 30” (#3103)

•

32 ½” - 34” (#3104)

Boxed in pairs only

•

Item No Size Std. Pkg

3103 27” High 1 Pr

3104 31” High 1 Pr

CHROME PLATED

LAVATORY LEGS

KITCHEN & LAVATORY SINK ITEMS

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 69

PVC P TRAPS

#7501

GENE RICH & COMPANY

• Meets ASTM F-409 • Individually bagged

• Includes: One (#7755) 1 1/2” PVC J Bend One (#7760) 1 1/2” PVC Quarter Bend Two (#7605) 1 1/2” PVC Slip Nuts

Two (#7615) 1 1/2” PVC Beveled Slip Joint Washers

Two (#7620) 1 1/2” x 1 1/4” PVC Beveled Slip Joint Washers

#7503

PVC REPAIR P TRAP

PVC S TRAP

20”

• #7503 includes : One (#7570) 1 1/2” x sweat Adaptor for Schedule 40

and : One more (#7605) 1

Item No Description Std. Pkg

7501 1-1/2” PVC P Trap 25 Ea

7503 1-1/2” PVC P Trap, w/Sch.40 Adaptor 25 Ea

• Meets ASTM F-409 • Individually bagged

• Includes: One (#7755) 1 1/2” PVC J Bend One (#7800) 1 1/2” PVC 90° Repair Elbow Two (#7605) 1 1/2” PVC Slip Nuts

Two (#7615) 1 1/2” PVC Beveled Slip Joint Washers

Two (#7620) 1 1/2” x 1 1/4” PVC Beveled Slip Joint Washers

Item No Description Std. Pkg

7505 1-1/2” PVC Repair P Trap 25 Ea

• Meets ASTM F-409 • Individually bagged

• Includes: One (#7830) 1 1/2” PVC Floor Tube with Captive Nut One (#7755) 1 1/2” PVC J Bend Two (#7605) 1 1/2” PVC Slip Nuts

Two (#7615) 1 1/2” PVC Beveled Slip Joint Washers

Two (#7620) 1 1/2” x 1 1/4” PVC Beveled Slip Joint Washers

1

/2” PVC Slip Nut

Item No Description Std. Pkg

7510 1-1/2” PVC S Trap 12 Ea

PVC J BENDS

PVC TUBULAR

#7515

#7520

70 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

• Meets ASTM F-409 • Individually bagged

• Includes: One (#7755) 1 Two (#7605) 1 1/2” PVC Slip Nuts Two (#7615) 1 1/2” PVC Beveled Slip Joint Washers Two (#7620) 1 1/2” x 1 1/4” PVC Beveled Slip Joint Washers

• #7520 includes : One 1 1/2” Hi-Line Nipple (#7805)

: One (#W381) 1

and : One more (#7605) 1 1/2” PVC Slip Nut

Item No Description Std. Pkg

7515 1-1/2” PVC J Bend 25 Ea

7520 1-1/2” PVC J Bend w/Hi-line nipple 25 Ea

1

/2” PVC J Bend

1

/2” PVC Flanged Washer

GENE RICH & COMPANY

• Meets ASTM F-409 • Individually bagged

CONTINUOUS WASTE

• Includes: One (#7680)11/2” PVC CENTER Outlet slip joint baffle tailpiece Two (#7805) 1 1/2” PVC Hi-Line Nipples Two (#7810) 1 1/2” x 7” PVC Waste Arms Six (#7605) 1 1/2” PVC Slip Nuts Four (#7615) 1 1/2” PVC Beveled Slip Joint Washers Two (#7620) 1 1/2” x 1 1/4” PVC Beveled Slip Joint Washers Two (#W381) 1 1/2” PVC Flanged Washers

Item No Description Std. Pkg

7525 1-1/2” Center Outlet Continuous Waste 25 Ea

PVC CENTER OUTLET

• Meets ASTM F-409 • Individually bagged

• Includes: One (#7675) 11/2” PVC END Outlet slip joint baffle tailpiece Two (#7805) 1 1/2” PVC Hi-Line Nipples One (#7820) 1 1/2” x 15” PVC Waste Arm Five (#7605) 1 1/2” PVC Slip Nuts Three(#7615)1 1/2” PVC Beveled Slip Joint Washers Two (#7620) 1 1/2” x 1 1/4” PVC Beveled Slip Joint Washers Two (#W381) 1 1/2” PVC Flanged Washers

Item No Description Std. Pkg

7530 1-1/2” End Outlet Continuous Waste 25 Ea

PVC END OUTLET

CONTINUOUS WASTE

PVC WASTE REPAIR FITTINGS

• Meets ASTM F-409

• Individually bagged

#7550 #7555

Item No Description Std. Pkg

7550 1-1/2” PVC Universal Slip Joint Coupler 25 Ea

7555 1-1/2” PVC Universal 45° SJ Coupler 25 Ea

7560 1-1/2” PVC Universal 90° SJ Coupler 25 Ea

7565 1-1/2” PVC Universal Tee SJ Coupler 25 Ea

#7560 #7565

• Meets ASTM F-409 • Individually bagged

1

• Includes: One (#7780) 1 One (#7605) 1 1/2” PVC Slip Nut One (#7615) 1 1/2” PVC Beveled Slip Joint Washer One (#7620) 1 1/2” x 1 1/4” PVC Beveled Slip Joint Washer

Item No Description Std. Pkg

7570 1-1/2” PVC Adaptor for Schdl 40 pipe 25 Ea

/2” x Sched 40 PVC Adaptor

1 1/2“ PVC WASTE ADAPTOR

FOR SCHEDULE 40 PIPE

90° PVC ELBOW

• Meets ASTM F-409

• Individually bagged

WITH CAPTIVE NUT

PVC TUBULAR

Item No Description Std. Pkg

7575 90° Sink Trap Elbow w/Nut 25 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 71

GENE RICH & COMPANY

PVC SLIP JOINT NUTS and WASHERS

• ANSI/NSF Standard 14 (NSF-dwv)

• White PVC • Full cartons only

Item No Description Std. Pkg

7605 1-1/2” PVC Slip Joint Nut 100 Ea

7614 1-1/4” PVC Beveled Slip Joint Washer 100 Ea

7615 1-1/2” PVC Beveled Slip Joint Washer 100 Ea

7620 1-1/2” x 1-1/4” Beveled Slip Jnt Washer 100 Ea

PVC FLANGED TAILPIECES

• Meets ASTM F-409

Item No Description Std. Pkg

PVC BAFFLE TAILPIECES

7650 1-1/2” x 4” PVC Flanged Tailpiece 25 Ea

7655 1-1/2” x 6” PVC Flanged Tailpiece 25 Ea

7660 1-1/2” x 8” PVC Flanged Tailpiece 25 Ea

7665 1-1/2” x 12” PVC Flanged Tailpiece 25 Ea

7670 1-1/2” x 16” PVC Double Flngd Tailpce 25 Ea

• Meets ASTM F-409

• Includes: One 1 1/2” PVC Slip Joint Baffle Tailpiece Two (#7605) 1 1/2” PVC Slip Nuts Two (#7615) 1 1/2” PVC Beveled Slip Joint Washers

Item No Description Std. Pkg

7675 1-1/2” PVC End Outlet SJ Baffle 25 Ea

#7675 #7680

PVC BRANCH TAILPIECES

#7685 #7695 #7690 #7700

7680 1-1/2” PVC Center Outlet SJ Baffle 25 Ea

• Meets ASTM F-409

• Includes: One 1 One (#7605) 1 1/2” PVC Slip Nuts One (#7615) 1 1/2” PVC Beveled Slip Joint Washers

Item No Description Std. Pkg

7685 1-1/2” PVC Slip 1/2” Branch Tailpiece 25 Ea

7690 1-1/2” PVC Slip 3/4 Branch Tailpiece 25 Ea

7695 1-1/2” PVC Hi-Line 1/2 Branch Tailpce 25 Ea

7700 1-1/2” PVC Hi-Line 3/4 Branch Tailpce 25 Ea

PVC SOLVENT WELD EXTENSION TUBES

PVC TUBULAR

#7715 #7720 #7725 #7730

• Meets ASTM F-409

• ANSI/NSF Standard 14 (NSF-tubular)

Item No Description Std. Pkg

7715 1-1/2” x 6” Solvent Weld Ext. Tube 25 Ea

7720 1-1/2” x 8” Solvent Weld Ext. Tube 25 Ea

7725 1-1/2” x 12” Solvent Weld Ext. Tube 25 Ea

7730 1-1/2” x 16” Double Conn Solv Weld 25 Ea

1

/2” PVC Slip Joint Branch Tailpiece

72 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

PVC SLIP JOINT EXTENSION TUBES

• Meets ASTM F-409

• ANSI/NSF Standard 14 (NSF-tubular)

Item No Description Std. Pkg

7735 1-1/2” x 6” SJ 25 Ea

7740 1-1/2” x 8” SJ 25 Ea

#7735

7745 1-1/2” x 12” SJ 25 Ea

#7740 #7745 #7750

7750 1-1/2” x 16” Double Conn SJ 25 Ea

• Meets ASTM F-409

Item No Description Std. Pkg

7805 1-1/2” 25 Ea

• Meets ASTM F-409

1

• Includes 1

Item No Description Std. Pkg

7810 1-1/2” x 7” PVC Waste Arm 25 Ea

7815 1-1/2” x 9-1/2” PVC Waste Arm 25 Ea

7820 1-1/2” x 15” PVC Waste Arm 25 Ea

7825 1-1/2” x 20” PVC Waste Arm 25 Ea

/2” PVC Nut (#7605) and Washer (#7615)

PVC WASTE ARMS

FLEXI-DRAIN PRODUCTS

• Bends to shape and offsets up to 2”. • For use with all metal or plastic drain systems

• May be used with all metal or plastic drain systems. • Use only with flanged metal floor or wall tube.

• Will not deteriorate and is unaffected by strong drain cleaning chemicals.

PVC HI LINE NIPPLE

FLEXI-DRAIN J BEND

• Combo Trap Bend

• May be used with all metal or plastic drain systems.

#7850 #7851

FLEXI-DRAIN EXTENSIONS

• Slip joint x Sweat connections

• Offsets up to 2”

• Use 9” for bathroom traps

• Use 12” for kitchen traps

Item No Description Std. Pkg

7850 1-1/2” x 1-1/4” 25 Ea

7851 1-1/2” x 1-1/4” w/Adaptor 25 Ea

FLEXI-DRAIN CONNECTOR

• NO TOOLS NEEDED

• Eliminate extra fittings

• Corrosion resistant

Elbow/Coupling

Item No Description Std. Pkg

7852 1-1/2” Coupler/Elbow 25 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 73

Item No Description Std. Pkg

7853 1-1/4” x 9”, w/nuts/washers 25 Ea

7854 1-1/2” x 12” w/nuts/washers 25 Ea

FLEXI-DRAIN FLANGED TAILPIECE

• Use with Center or End outlet continuous wastes.

• Offsets up to 2” for mis-aligned traps.

Item No Description Std. Pkg

7855 1 1/2” x 12” w/Nuts/washers 25 Ea

PVC TUBULAR

GENE RICH & COMPANY

PROVENT

DISCOUNTED!

When you buy

50 pcs or more

DISHWASHER AIR GAP

DISCOUNTED!

When you buy

50 pcs or more

• Automatic anti-siphon trap vent for use as secondary venting in manufactured housing and RV’s

• Quickly vents kitchen & bathroom sinks, showers, tubs and washing machines

• Black ABS with 1 1/2” MPT

• Tested to NSF-24 • Made in USA

• Easy to install - Just hand tighten, no thread seal required

• Install only in accessible locations with free flow of air

• Must be located at least 60” above trap arm

• Water closet must have main stack to outside

Item No Description Std. Pkg

7868 Pro Vent - Ventmaster II 12 Ea

• Interupts siphoning in drain lines to prevent sewage backflow

• White polypropylene body

• Chrome plated ABS top

• UPC approved

DISHWASER DISPOSAL CONNECTOR KITS

#DD5KIMP

#DD10K

DISHWASHER DRAIN HOSES

Item No Description Std. Pkg

7870 Chrome Plated 12 Ea

• DD5KIMP includes 4 screw-down clamps

• DD10K includes 2 worm gear clamps

• Individually bagged

Item No Description Std. Pkg

DD5KIMP 4 Clamp Dishwasher/Disposal Conn Kit 200 Ea

DD10K 2 Clamp Dishwasher/Disposal Conn Kit 100 Ea

• Meets specifications for reinforced drain hoses on portable and permanent dishwashers.

• Can be used for drain discharges that require additional strength

• 40 lb working pressure at 70° F

• 5/8” ID connects dishwasher pump to airgap inlet or dishwasher tailpiece

• 7/8” ID connects airgap outlet to branch tailpiece or disposal

Item No I.D. O.D. Length W/P @ 70° F Std. Pkg

DISHWASHER CONNECTORS

74 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

A218 7/8” 1-3/16” 50’ 40 1 Ea

A220 5/8” 7/8” 50’ 40 1 Ea

GENE RICH & COMPANY

• Heavy duty hose is manufactured to withstand chemicals discharged through the drain side of the washing machine.

• 90° elbow to fit tight areas

• Expanded end steps down to fit 1 1/4”, 1 1/8” and 1”

Item No Description Std. Pkg

A195 1” I.D. x 6 Ft. Drain Hose w/Alum. Hook 5 Ea

• Facilitates mixing of hot and cold water into the washing machine.

• 3/8” I.D. Hose

• Two 3/4” FHT inlet connections

• One 3/4” MHT connection at the Wye

Item No Description Std. Pkg

A182 3/8” ID `Y’ Mixer Hose w/3/4” Ftgs 10 Ea

• 3/4” FHT connections

• Burst pressure rating of 800 PSI

• Individually bagged with washers

BLACK DRAIN HOSE

WITH ALUMINUM HOOK

“Y” WATER MIXER HOSE

HOSES & CLAMPS

WASHING MACHINE

HOSES

Item No Description Std. Pkg

A183 3/8” ID x 4 Ft. 10 Ea

A184 3/8” ID x 5 Ft. 10 Ea

A185 3/8” ID x 6 Ft. 10 Ea

A186 1/2” ID x 4 Ft. 10 Ea

A187 1/2” ID x 5 Ft. 10 Ea

A188 1/2” ID x 6 Ft. 10 Ea

A189 3/8” ID x 4 Ft. with 90° elbow 10 Ea

#A189 & #A190

A190 3/8” ID x 5 Ft. with 90° elbow 10 Ea

• 3/8” I.D. Hose

• Heavy duty brass 3/4” FHT connections

• Max Temp: 180° F • Max PSI: 2800

Item No Description Std. Pkg

A183S 3/8” ID x 4 Ft. 10 Ea

A184S 3/8” ID x 5 Ft. 10 Ea

A185S 3/8” ID x 6 Ft. 10 Ea

STAINLESS STEEL BRAIDED

WASHING MACHINE HOSE

REINFORCED GARDEN HOSE

•

5

/8” I.D. x 50 Ft. Reinforced Garden Hose

• Brass 3/4” MHT x 3/4” FHT ABS Easy-grip Fitting

Item No Description Std. Pkg

A222 5/8” ID x 50 Ft 5 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 75

GENE RICH & COMPANY

MURRAY GOLD SEAL ® STAINLESS STEEL HOSE CLAMPS

“H” Series

with Zinc Plated Carbon Steel Screw

“H-SS” Series

with “400” Series Stainless Steel Screw

HOSES & CLAMPS

All sizes are packaged 10 per box

DISCOUNTED

5% for 1,000

10% for 2,000

Band and housing are 200/300 series stainless steel. Screw is

5

/16” slotted hex head, heat treated carbon steel, double plated with zinc plus trivalent chromate for long lasting protection. Good generalpurpose clamp. (THIS IS THE ONE WITH THE “GOLD SCREW”)

Rated Ultimate Torque: 50 in.-lbs. min. (5.6Nm)

Recommended Installation

Torque:

30-40 in.-lbs. (3.4-4.5 Nm)

Clamp Series

H H-SS

H6 H6SS .44 .78 7/16 25/32 11 20

H8 H8SS .44 .91 7/16 29/32 11 23

H10 H10SS .56 1.06 9/16 1-1/16 14 27

H12 H12SS .69 1.25 11/16 1-1/4 18 32

H16 H16SS .75 1.50 3/4 1-1/2 19 38

H20 H20SS .81 1.75 13/16 1-3/4 21 44

H24 H24SS 1.06 2.00 1-1/16 2 27 51

H28 H28SS 1.31 2.25 1-5/16 2-1/4 33 57

H32 H32SS 1.56 2.50 1-9/16 2-1/2 40 64

H36 H36SS 1.81 2.75 1-13/16 2-3/4 46 70

H40 H40SS 2.06 3.00 2-1/16 3 52 76

H44 H44SS 2.31 3.25 2-5/16 3-1/4 59 83

H48 H48SS 2.56 3.50 2-9/16 3-1/2 65 89

H52 H52SS 2.81 3.75 2-13/16 3-3/4 71 95

H56 H56SS 3.06 4.00 3-1/16 4 78 102

H60 H60SS 3.31 4.25 3-5/16 4-1/4 84 108

H64 H64SS 3.56 4.50 3-9/16 4-1/2 90 114

H72 H72SS 4.06 5.00 4-1/16 5 103 127

H80 H80SS 4.56 5.50 4-9/16 5-1/2 116 140

H88 H88SS 5.06 6.00 5-1/16 6 129 152

H96 H96SS 5.56 6.50 5-9/16 6-1/2 141 165

H104 H104SS 6.06 7.00 6-1/16 7 154 178

H116 H116SS

Decimals Inches Millimeters

Min Max Min Max Min Max

6.50 7.75 6-1/2 7-3/4 165 197

Band and housing are 200/300 series stainless steel. Screw is 5/16” slotted hex head, heat treated 400 series stainless steel. The high cor rosion resistance of this all stainless steel band, housing and screw makes this the perfect clamp for numerous industrial installations.

Rated Ultimate Torque: 60 in.-lbs. min. (6.8Nm)

Recommended Installation

Torque:

35-40 in.-lbs. (3.96-4.52 Nm)

“A” Diameter Range

-

* GOLD SEAL and MINI-CLAMPS are registered trademarks of Murray Corporation

76 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

MURRAY STAINLESS STEEL

“MM-SS” Series

with “400” Series Stainless Steel Screw

Band and housing are 300 series stainless steel. Screw is

1

/4” slotted hex head, heat treated 400 series stainless steel. Lightweight, low profile, compact design allows ease of installation in restricted applications.

MINI-CLAMPS ®

10 per box

Clamp Series

MM-SS

MM4SS .25 .63 1/4 5/8 6 16

MM5SS .31 .91 5/16 29/32 8 23

Rated Ultimate Torque: 20 in.-lbs. min. (2.3Nm)

Recommended Installation

Torque:

12-15 in.-lbs. (1.4-1.7 Nm)

“A” Diameter Range

Decimals Inches Millimeters

Min Max Min Max Min Max

HOSE CLAMP

A COMPLETE CLAMP DEPARTMENT IN LESS THAN ONE SQUARE FOOT. IT’S ONLY SIX INCHES DEEP!

H900SS-

”400” Series

Stainless

Clamps to fit any hose, pipe or tubing, from 1/4” to 2 1/2” O.D.

Use for compressing, fastening, clamping and repairing.

No. Clamps on

Merchandiser

10 MM4 MM4SS

20 H8 H8SS

20 H12 H12SS

10 H16 H16SS

30 H20 H20SS

10 H32 H32SS

H900-Carbon

Screw

COUNTER-TOP

DISPLAYS

HOSES & CLAMPS

GOLD SEAL CLAMPS

CLAMP MERCHANDISER now available, offering choice of clamps in all stainless steel with a carbon steel screw or 400 series stainless steel screw.

Item No Description Std. Pkg

H900 w/100 H-Series Clamps 1 Ea

H900SS w/100 HSS-Series Clamps 1 Ea

H900WR Wire Rack Only 1 Ea

* GOLD SEAL and MINI-CLAMPS are registered trademarks of Murray Corporation

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 77

GENE RICH & COMPANY

FLEXIBLE ALUMINUM PIPE

WITH ONE CRIMPED END

• Full Cartons Only

One Crimped End One Plain, Untreated End

FLEXIBLE ALUMINUM PIPE

WITH TWO PLAIN ENDS

• Full Cartons Only

DRYER VENTS & TUBING

Two Plain, Untreated Ends

Item No Size Ctn. Qty.

774-308 3” x 8’ 10 Ea

774-308B 3” x 8’ 63 EA

774-408 4” x 8’ 12 Ea

774-408B 4” x 8’ 40 EA

774-508B 5” x 8’ 32 EA

774-608B 6” x 8’ 18 EA

774-708B 7” x 8’ 15 EA

774-808B 8” x 8’ 10 EA

773-908B 9” x 8’ 8 EA

773-A08B 10” x 8’ 4 EA

Item No Size Ctn. Qty.

775-308 3” x 8’ 10 Ea

775-320 3” x 20’ 20 Ea

775-408 4” x 8’ 12 Ea

775-420 4” x 20’ 12 Ea

RIGID ALUMINUM PIPE

FLEXIBLE VINYL VENT HOSE

• Nemco AP series

• One crimped end, one plain end

• Snap-together assembly

• Ships nested

• Steel Wire Support

• 1” Pitch

• Useful as bathroom fan venting. Check your local codes.

* Individually boxed * Individually boxed

Item No Size Ctn. Qty.

776-32 3” x 2’ 25 Ea

776-42 4” x 2’ 25 Ea

Item No Size Ctn. Qty.

785 4” x 5’ 12 Ea

786 4” x 8’ 12 Ea

787 4” x 20’ 5 Ea

788 4” x 50’ 4 Ea

78 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 79

GENERAL PERISCOPE SPECIFICATIONS

PERISCOPES

• Allows dryer to sit 2 1/2” from the wall

• 2” x 6” Rigid metal construction

ERISCOPE

• One 4” male snap-lock fitting

• One 4” collar for dryer connection

• Sections can be reversed for airflow

0-18” PERISCOPE

18-29” P

the same or apart (NOT on 0-18”)

2.5” dryer to wall

• Use where outlets overlap

Rotates to any position

Adjusts from 0-18”

or are very close

• Baffles help direct airflow in 3-18” situations

0-18” Length

Ends are shown trimmed.

2.5” dryer to wall Periscope openings can be on the same Periscope fittings can or opposite sides rotate to any position

18-29” Length

• Sections are not reversible

• Draw band female collar

• Reaches side of most dryers

• Two piece assembly

• Beveled ends

• Draw band female collar

29-50” PERISCOPE

0-18” PERISCOPE

Item No Pkgd Ctn Qty

777-P18 Ind. Bxd 4 Ea

18-29” PERISCOPE

DRYER VENTS & TUBING

Item No Pkgd Ctn Qty

777-P29 Ind. Bxd 4 Ea

2.5” dryer to wall Periscope openings Periscope fittings can can be on the same rotate to any position or opposite sides

• Reaches top of most dryers

• Four piece assembly

29-50” Length

• Beveled ends

• Draw band female collar

• Four telescoping sections

• One male snap-lock fitting

• One female snap-lock collar

• Mounting strap included

Designed to fit between the studs inside a wall carrying the exhaust air up through the top plate to an attic or floor space. Use 4” aluminum pipe to complete the run to the outside.

Also used in basements directly on the wall behind the dryer. Installation instructions included.

• 2” x 6” rigid metal

• Fittings sold separately

Slide into and over 18-29”, 29-50” and 29-74” sections to lengthen. We recommend using aluminum tape to secure the sections when extending to their maximum length.

29-50” PERISCOPE

Item No Pkgd Ctn Qty

777-P50 Ind. Bxd 4 Ea

29-74” PERISCOPE

Item No Pkgd Ctn Qty

777-P74 Ind. Bxd 3 Ea

23” AND 43” EXTENSION PIECES

Item No Size Description Pkgd Ctn Qty

777-X23 23” Extension Bulk 8 Ea

777-X43 43” Extension Bulk 8 Ea

777-SA 2” x 6” Scissor Adptr Bulk 5 Ea

GENE RICH & COMPANY

ALUMINUM

ELBOWS

CLOSE ADJUSTABLE

• Turns 90° within 4.5” • Turns 90° within 6”

• One male rotating snap-lock fitting • One crimped end

• One female rotating snap-lock fitting • 4-piece sectional adjustability

• Best choice for 90° turns from the dryer • Nemco AE series

Item No Size Ctn Qty

778-C4 4” 24 Ea

ALUMINUM ALUMINUM

DRYER VENTS & TUBING

DUCT EXTENSION COUPLING COLLAR

• Designed to connect pieces of plain-end or crimped pipe. • Extends a wall pipe which does not extend even past the wall.

Item No Size Ctn Qty

779-A3 3” 12 Ea

779-A4 4” 12 Ea

PLASTIC STEEL STEEL CLAMPS CLAMPS TENSION

• Patented polymeric stretch plastic • Phillips/hex head screw • “Spring” clamps

• Slotted Steel Screw & Nut • 4” Min I.D. 3.90”, Max 4.25” • No tools required

Item No Size Ctn Qty

778-A3 3” 12 Ea

778-A4 4” 12 Ea

Item No Size Ctn Qty

779-XA4 4” Dia x 3” 100 Ea

Item No Size Ctn Qty

783-P4 4” 100 Ea

Item No Size Ctn Qty

783-S3 3” 100 Ea

783-S4 4” 100 Ea

Item No Size Ctn Qty

783-T4 4” 100 Ea

SPACE SAVING ELBOWS AND PERISCOPES

Dryer 6” from wall Dryer 6” from wall Dryer 4.5” Dryer 2.5” with with a from wall from wall Flexible Pipe Standard with a with a

Alone Adjustable Close Elbow Periscope Elbow

80 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 81

• Fully assembled, riveted 11 1/2” aluminum tailpipe

METAL VENT HOODS

• Back plate included • Back-draft flapper

Item No Description Pkgd Ctn Qty

780 4” Standard Aluminum Vent Hood Bulk 12 Ea

780-40 4” Standard Aluminum Vent Hood Bulk 40 Ea

781 4” Standard Aluminum Vent Hood Ind. Bxd 1 Ea

Standard (Nemco VH Series)

Item No Description Pkgd Ctn Qty

780-WM3 3” Wide Mouth Aluminum Vent Hood Bulk 12 Ea

780-WM4 4” Wide Mouth Aluminum Vent Hood Bulk 40 Ea

780G-WM4 4” Wide Mouth Galvanized Vent Hood Bulk 12 Ea

Wide Mouth (Nemco WVH Series)

Item No Description Pkgd Ctn Qty

780ESC-I 4” Inside Flange Plate Bulk 1 Ea

780ESC-O 4” Outside Flange Plate Bulk 1 Ea

• Fully assembled, riveted 10 1/2” aluminum tailpipe

PLASTIC VENT HOODS

• Louvered faceplates have 4 louvers

• Back plate included • Back-draft flapper

DRYER VENTS & TUBING

Item No Description Pkgd Ctn Qty

780-WP4 4” Wide Mouth White Plastc Vent Hood Bulk 40 Ea

Wide Mouth (Nemco PVH Series)

Item No Description Pkgd Ctn Qty

780-LW3 3” Louvered White Plastic Vent Hood Bulk 12 Ea

780-LW4 4” Louvered White Plastic Vent Hood

780-LW4B 4” Louvered White Plastic Vent Hood

Louvered (Nemco LO Series)

• (1) Flexible Aluminum Pipe w/plain ends

• (1) Vent Hood (Wide Mouth Metal or Louvered Plastic)

• (2) Metal Clamps

Item No Description Pkgd Ctn Qty

782-AL45 4” x 5’ Alum Duct w/Plastic Louvr Hood Ind. Bxd 4 Ea

#782-AL Series

782-AL48 4” x 8’ Alum Duct w/Plastic Louvr Hood Ind. Bxd 4 Ea

782-AW45 4” x 5’ Alum Duct w/Wide Metal Hood

782-AW48 4” x 8’ Alum Duct w/Wide Metal Hood

#782-AW Series

• (1) Vinyl Vent Hose

• (1) Vent Hood (Std. Metal or Louvered Plastic)

Bulk 12 Ea

Bulk 60 Ea

DRYER VENT HOOD KITS

Ind. Bxd 4 Ea

Bulk 4 Ea

COOL AIR VENT KITS

• (2) Plastic Clamps

Item No Description Pkgd Ctn Qty

#782-VL Series

782-VL45 4” x 5’ Vinyl Duct w/Plastic Louvr Hood Ind. Bxd 4 Ea

(Nemco LO Series)

782-VL48 4” x 8’ Vinyl Duct w/Plastic Louvr Hood Ind. Bxd 4 Ea

#782-VS Series

782-VS45 4” x 5’ Vinyl Duct w/Std Metal Hood Ind. Bxd 1 Ea

(Nemco EK Series)

GENE RICH & COMPANY

STOVE PIPE COLLAR

FIXTURE HANGERS

ZINC PLATED STEEL FIXTURE HANGER

1

2

/2”

HANGERS & FASTENERS

1

3

For 10” Cast Iron Fixtures

10”

1

2

/4”

15”

1

/2”

THREE NOTCH HANGER

Accomodates mounting

1

5

/2”

2”

1

/2”

Fits most cast iron fixtures.

• Enameled Steel

• 3” I.D. x 9 1/2” O.D.

Item No Description Std. Pkg

590 Stove Pipe Collar 12 Ea

Item No Std. Pkg

451 12 Ea

7

Zinc Plated Steel

in 3 directions.

Item No Std. Pkg

452 12 Ea

1

/2”

BATHTUB HANGER

1

/4”

3

/4”

3

/4”

May be used on studding,

furring strip or walls.

1

/4”

Item No Std. Pkg

454 100 Ea

CAST IRON

FIXTURE HANGER

1

3

/2”

Item No Std. Pkg

455 24 Ea

ADJUSTABLE

Zinc Plated Steel

STEEL FIXTURE HANGER

For vitreous china fixtures

1

2

/8”

Item No Std. Pkg

453 12 Ea

1

3

/4”

GALVANIZED STEEL HANGER IRON

PLASTIC HANGER TAPE

3

1

/4”

1

3

/4”

LAVATORY HANGER

3

1

/4”

1”

7”

7” Zinc Plated Steel

2”

Item No Std. Pkg

456 12 Ea

• Hanger iron is 3/4” wide with 1/4” and 3/16” alternating holes for bolts or nails Holes are spaced 1/2” apart, center to center.

• All gauges and lengths are sold in Coils Only.

Item No Size Gauge Coils/ Ctn Feet / Ctn

1120 3/4 x 10’ 20 Heavy 50 500 Ft

1124

1128

1129

3/4 x 10’ 24 Medium 50 500 Ft

3/4 x 10’ 28 Light 100 1000 Ft

3/4 x 100’ 28 Light 10 1000 Ft

• 1/8” diameter holes every 3/4”

• 125 lb. ultimate load ASTM A-370-77

• Cut with scissors or utility knife

• Flexible, non-conductive polypropylene

Item No Size Thickness Std. Pkg

1133 3/4” x 100 Ft 0.050 1 Rl

82 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

COPPER PLATED PIPE HOOKS

Item No Size Length Ctn Qty

1500 5/8” O.D. (1/2” Nom) 6” 50 Ea

• 10 Gauge

1513 7/8” O.D. (3/4” Nom) 6” 50 Ea

• Full Cartons Only

1514 7/8” O.D. (3/4” Nom) 8” 50 Ea

1/2” IPS

• 10 Gauge Steel

• All sizes are 50 pcs/carton

Length

• Full Cartons Only

Item No

4” 1501 1504

6” 1502 1505 1509

8” 1503 1506 1510

10” 1507 1511

12” 1508

3/4” IPS Item No

1” IPS

Item No

COPPER PLATED STEEL “J” HOOKS

Item No IPS Nominal Ctn Qty

• Full Cartons Only

1530 3/8” 1/2” 100 Ea

1531 1/2” 3/4” 100 Ea

1532 3/4” 1” 100 Ea

Item No IPS Size Ctn Qty

1537B 1/4” 100 Ea

1537F 3/8” 100 Ea

1537H 1/2” 100 Ea

1537J 3/4” 100 Ea

Item No IPS Size Ctn Qty

1537K 1” 100 Ea

1537L 1-1/4” 100 Ea

1537M 1-1/2” 50 Ea

1537R 2” 50 Ea

STEEL PIPE HOOKS

GALVANIZED 1 HOLE

PIPE STRAP

HANGERS & FASTENERS

• Full Cartons Only

Item No IPS Size Ctn Qty

1539 1/4” 100 Ea

1540 3/8” 100 Ea

1541 1/2” 100 Ea

1542 3/4” 100 Ea

1543 1” 100 Ea

1544 1-1/4” 50 Ea

Item No IPS Size Ctn Qty

1545 1-1/2” 50 Ea

1546 2” 50 Ea

1546A 2-1/2” 25 Ea

1546F 3” 25 Ea

1546H 4” 25 Ea

1546L 6” 25 Ea

GALVANIZED 2 HOLE

PIPE STRAP

• Full Cartons Only COPPER PLATED SOLID COPPER

Item No CWT Size Ctn Qty

1560 3/8” 100 Ea

1561 1/2” 100 Ea

1562 3/4” 100 Ea

1563 1” 100 Ea

1564B 2” 100 Ea

Item No CWT Size Ctn Qty

1565 1/2” 100 Ea

1566 3/4” 100 Ea

1566-100 1” 100 Ea

1566-125 1-1/4” 100 Ea

1566-150 1-1/2” 100 Ea

1566-200 2” 100 Ea

COPPER 2 HOLE

PIPE STRAP

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 83

DWV

GENE RICH & COMPANY

PIPE HANGER

ADJUSTABLE CLEVIS HANGER

RISER CLAMP

HANGERS & FASTENERS

• Galvanized Steel

• Alternating screw and nail holes

• 250 lb. max load rating

• Carbon steel with galvanized finish • 650° F Max. Temp.

• Recommended for the suspension of non-insulated, stationary pipe lines

• Yoke is on the outside of the lower U-strap so the yoke cannot slide toward the center of the bolt, thus bending of the bolt is minimized.

Item No Size Std. Pkg

1515A 1/2” 25 Ea

1515B 3/4” 25 Ea

1515C 1” 25 Ea

1515D 1-1/4” 25 Ea

1515E 1-1/2” 25 Ea

• Carbon steel with galvanized finish • 650° F Max. Temp.

• For support and steadying of steel pipe risers either insulated or bare, cast iron pipe, or conduit

Item No Size Std. Pkg

1533 1-1/2” 50 Ea

1534 2” 50 Ea

1535 3” 50 Ea

1536 4” 50 Ea

Item No Size Std. Pkg

1515F 2” 25 Ea

1515G 2-1/2” 25 Ea

1515H 3” 25 Ea

1515J 4” 25 Ea

Item No Size Std. Pkg

1520D 1-1/4” 25 Ea

1520E 1-1/2” 25 Ea

1520F 2” 25 Ea

1520G 2-1/2” 25 Ea

SPLIT RING COPPER TUBE HANGER

• Copper plated malleable iron.

• For suspension of non-insulated copper tubing pipe lines

HANGER FLANGE

• 7 gauge low carbon steel • Galvanized or Copper Clad finish

• Provides a means for attaching hanger rods to wood beams or ceilings.

Item No Description Std. Pkg

1525A Galvanized, 3/8” BT 50 Ea

1525B Copper Clad, 3/8”BT 50 Ea

Item No Size Std. Pkg

1520H 3” 25 Ea

1520J 4” 25 Ea

1520K 5” 15 Ea

1520L 6” 10 Ea

Item No Size Std. Pkg

1524A 1/2” 50 Ea

1524B 3/4” 50 Ea

1524C 1” 50 Ea

1524D 1-1/4” 25 Ea

1524E 1-1/2” 25 Ea

1524F 2” 25 Ea

84 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

• Universal/Reversible (double rod hole) for top or bottom mounting.

• Structural attachment (with infinite adjustment) to top or bottom of metal beams, purlins, channel or angle iron to support hanger rod.

• Set screw must be tightened onto the sloped side of the I-Beam, channel or angle iron flange and torqued to 60 inch pounds.

• Set screw and locknut supplied are hardened steel.

• Conforms with federal specification WW-H-171 (Type 23)

Max. Recom.

Rod

Item No

1527A 3/8” 3/4” 4 500 250 50 Ea

• Plain carbon steel

Item No Diameter Threads/In Length Material Std. Pkg

2225A 1/4” 20 6 Ft. Steel 50 Ea

2225B 3/8” 16 6 Ft. Steel 25 Ea

2225C 1/2” 13 6 Ft. Steel 12 Ea

Size

Throat

Size

Max

Pipe Size

Load (lbs)

Std. PkgTop Bottom

TOP BEAM CLAMP

ALL THREADED

STEEL HANGER ROD

• Plain carbon steel

• Full cartons only

Item No I.D. O.D. Fits Bolt Std. Pkg

2226A 5/16” 5/8” 1/4” 100 Ea

2226B 7/16” 13/16” 3/8” 100 Ea

2226C 9/16” 1-1/16” 1/2” 100 Ea

• Plain carbon steel

• Full cartons only

Item No Size Threads/In Std. Pkg

2227B 3/8” 16 100 Ea

2227C 1/2” 13 100 Ea

• Sold Brass

HANGERS & FASTENERS

FLAT WASHER

HEX NUT

ALL THREADED

BRASS ROD

Item No Diameter Threads/In Length Material Std. Pkg

2228 1/4” 20 12” Brass 1 Ea

2230 1/4” 20 24” Brass 1 Ea

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 85

STEEL F.H.A.

GENE RICH & COMPANY

NAIL PLATES

#1548

#1552

GALVANIZED STEEL F.H.A.

STUD GUARDS

• F.H.A. 16 Gauge steel plate

• Six nail holes

• Full cartons only

Item No Width Length Std. Pkg

1547 1-1/2” 6” 100 Ea

1548 1-1/2” 8” 100 Ea

1549 1-1/2” 12” 100 Ea

1550 1-1/2” 18” 25 Ea

1551 1-1/2” 24” 25 Ea

1552 3” 8” 100 Ea

• F.H.A. Self-Nailing stud protector

• 20 Gauge galvanized steel

• Full cartons only

HANGERS & FASTENERS

SLOTTED HEX HEAD SHEET METAL SCREWS

Item No Width Length Std. Pkg

1553 1-1/2” 6” 100 Ea

1554 1-1/2” 8” 100 Ea

1555 1-1/2” 12” 100 Ea

1556 1-1/2” 18” 25 Ea

1557 1-1/2” 24” 25 Ea

• Zinc Plated Steel

• Full cartons only

• These sheet metal screws have a Type A point.

• They are thread forming screws for use in thin metals 0.015 - 0.050 thick.

• Use with drilled, punched or nested holes in sheet metal, resin impregnated plywood, asbestos combinations, among others.

• These screws can be driven with a 1/4” hex drive.

Item No Size Std. Pkg

729-3 #6 x 5/8” 100 Ea

729-9 #8 x 1/2” 100 Ea

729-12 #8 x 1” 100 Ea

729-15 #10 x 3/4” 100 Ea

729-17 #12 x 1” 100 Ea

86 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

• Zinc Plated Steel • Full cartons only

• Excellent resistance to pull out. • All screws have a sharp point.

• Threads cover about 2/3 or more of the screw length.

• Flat heads provide a flush surface in countersunk holes, head angle is 82°.

• Length is measured from top of head to point.

Item No Size Std. Pkg

730 #12 x 1” 100 Ea

731 #12 x 1-1/4” 100 Ea

732 #12 x 1-1/2” 100 Ea

733 #12 x 2” 100 Ea

734 #12 x 2-1/2” 100 Ea

Item No Size Std. Pkg

730P #12 x 1” 100 Ea

731P #12 x 1-1/4” 100 Ea

732P #12 x 1-1/2” 100 Ea

733P #12 x 2” 100 Ea

734P #12 x 2-1/2” 100 Ea

Item No Size Std. Pkg

735 #14 x 1-1/4” 100 Ea

736 #14 x 1-1/2” 100 Ea

737 #14 x 2” 100 Ea

738 #14 x 2-1/2” 100 Ea

739 #14 x 3” 100 Ea

Item No Size Std. Pkg

735P #14 x 1-1/4” 100 Ea

736P #14 x 1-1/2” 100 Ea

737P #14 x 2” 100 Ea

738P #14 x 2-1/2” 100 Ea

739P #14 x 3” 100 Ea

FLAT HEAD

WOOD SCREWS

SLOTTED

PHILLIPS

• Zinc Plated Steel • Full cartons only

• These sheet metal screws have a Type A point.

Item No Size Std. Pkg

740 #6 x 3/8” 100 Ea

741 #6 x 1/2” 100 Ea

742 #7 x 3/8” 100 Ea

743 #7 x 1/2” 100 Ea

744 #7 x 3/4” 100 Ea

745 #8 x 1/2” 100 Ea

746 #8 x 3/4” 100 Ea

• Zinc Plated Steel • Full cartons only

• Head protrudes above the material surface.

• Length is measured from under the head.

• Square nut included with each bolt

Item No Size Std. Pkg

747 3/16” x 1” 100 Ea

748 3/16” x 1-1/2” 100 Ea

749 3/16” x 2” 100 Ea

• They are thread forming screws for use in thin metals 0.015 - 0.050 thick.

• Use with drilled, punched or nested holes in sheet metal, resin impregnated plywood, asbestos combinations, among others.

Item No Size Std. Pkg

750 1/4” x 3/4” 100 Ea

751 1/4” x 1” 100 Ea

752 1/4” x 1-1/4” 100 Ea

753 1/4” x 1-1/2” 100 Ea

754 1/4” x 2” 100 Ea

HANGERS & FASTENERS

SLOTTED PAN HEAD

TAPPING SCREWS

SLOTTED

ROUND HEAD

STOVE BOLTS

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 87

GENE RICH & COMPANY

TOGGLE BOLTS

CAULK-IN ANCHORS

(LEAD EXPANSION SLEEVE)

CONICAL PLASTIC ANCHOR

HANGERS & FASTENERS

• Zinc Plated Steel bolt and wings

• Full cartons only

• Spring-action snaps wings open to spread load out over a greater surface than other anchors.

• Requires a predrilled hole.

• Also known as machine-screw anchors, these anchors can be used in concrete, brick and other solid masonry.

• Anchor consists of a threaded zinc-alloy cone and a lead sleeve. The cone is chamfered at the top to ease screw starting.

• Setting tool included

• Full cartons only

• Use in tile, plaster and brick. • Withstands temperature changes

• Will cold-flow under pressure to fill cavaties

• Screws Not included.

• Full cartons only

Item No Size Std. Pkg

755 1/8” x 3” 50 Ea

756 1/8” x 4” 50 Ea

757 3/16” x 3” 50 Ea

758 3/16” x 4” 50 Ea

759 1/4” x 3” 50 Ea

760 1/4” x 4” 50 Ea

Item No Size Std. Pkg

1708 1/4-20 100 Ea

Item No Size Std. Pkg

1720A 1/4” x 1” 100 Ea

RIBBED POLYETHYLENE ANCHOR KITS

#1722

Pan Head Screws

#1723

Hex Head Screws

STEEL GRIP ANCHORS

• Use in drywall, concrete, wood, tile, plaster and brick.

P

AN HEAD KIT CONTAINS:

• 100 Phillips/Slotted #10 x 1” Pan Head Sheet Metal Screws

• 100 #10-12 x 1” Red Ribbed Plastic Anchors

• One 1/4” drill bit , slow masonry, carbide tip, black finish

Item No Description Std. Pkg

1722 Pan Head Combo Anchor Kit w/Drill Bit 1 Ea

HEX HEAD KIT CONTAINS:

• 100 Phillips/Slotted #10 x 1” Hex Head Sheet Metal Screws

• 100 #10-12 x 1” Blue Ribbed Plastic Anchors

• One 1/4” drill bit , slow masonry, carbide tip, black finish

• One 5/16” magnetic nut driver

Item No Description Std. Pkg

1723 Hex Head Combo Anchor Kit w/Bit & Driver 1 Ea

• Insert these expandable anchors in drywall and other hollow walls and ceilings and drive the machine screw. The anchor fingers expand to grip behind the surface.

• Anchors are made of zinc plated steel.

Screw

Item No

1760 1/8” 1-5/8” 1/2” 5/16” 100 Ea

1762 1/8” 2-1/8” 1/2” 5/16” 100 Ea

Head

Dia.

Hole

Size Std. PkgSize Length

88 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

• Band: Type #304 Stainless Steel

• Lugs: Malleable Iron - Electro Galvanized with Dichromate Finish

• Bolts: Carbon Steel - Electro Galvanized with Dichromate Finish

• Nuts: Carbon Steel - Electro Galvanized with Dichromate Finish

• Washers: SAE Flat Washer - Meets ASTM-F844

• Gasket: Neoprene (Chloroprene) All purpose indoor/outdoor synthetic rubber. Resistant to most chemicals, oils, weather, etc.

• Temperature Range: -50° F to +240° F

• Pressure Rating: 150 psi (Based on city water pressure)

Item No Size Std. Pkg

1299 3/8” x 3” 24 Ea

1301 1/2” x 3” 24 Ea

1305 3/4” x 3” 24 Ea

1309 1” x 3” 24 Ea

1313 1-1/4” x 3” 16 Ea

1317 1-1/2” x 3” 16 Ea

1321 2” x 3” 16 Ea

1323 2-1/2” x 3” 16 Ea

1325 3” x 3” 16 Ea

IItem No Size Std. Pkg

1300 3/8” x 6” 12 Ea

1302 1/2” x 6” 12 Ea

1306 3/4” x 6” 12 Ea

1310 1” x 6” 12 Ea

1314 1-1/4” x 6” 8 Ea

1318 1-1/2” x 6” 8 Ea

1322 2” x 6” 8 Ea

1324 2-1/2” x 6” 8 Ea

1326 3” x 6” 8 Ea

1329 4” x 6” 4 Ea

STAINLESS STEEL

PIPE REPAIR CLAMPS

3” (One bolt)

6” (Two bolt)

ECONOMY STAINLESS STEEL

• Type #301 Stainless Steel bands, won’t rust

• Plated malleable Iron lugs insure uniform pressure

• High content neoprene gasket won’t deteriorate, gives positive seal

• Will not collapse schedule 40 PVC pipe

• Sizes fit IPS pipe

Item No Size Std. Pkg

1299IMP 3/8” x 3” 24 Ea

1301IMP 1/2” x 3” 24 Ea

1305IMP 3/4” x 3” 24 Ea

1309IMP 1” x 3” 24 Ea

1313IMP 1-1/4” x 3” 16 Ea

1317IMP 1-1/2” x 3” 16 Ea

1321IMP 2 x 3” 16 Ea

1325IMP 3” x 3” 16 Ea

Item No IP Size Std. Pkg

1330 1/2” 1 Ea

1331 3/4” 1 Ea

1332 1” 1 Ea

1333 1-1/4” 1 Ea

1334 1-1/2” 1 Ea

1335 2” 1 Ea

Item No Size Std. Pkg

1302IMP 1/2” x 6” 12 Ea

1306IMP 3/4” x 6” 12 Ea

1310IMP 1” x 6” 12 Ea

1314IMP 1-1/4” x 6” 8 Ea

1318IMP 1-1/2” x 6” 8 Ea

1322IMP 2” x 6” 8 Ea

1326IMP 3” x 6” 8 Ea

1329IMP 4” x 6” 4 Ea

• With neoprene rubber gasket

• Schedule 40 pipe sizes

• Allows a lasting positive seal on all leaking pipes

• Individually bagged

PIPE REPAIR CLAMPS

PIPE REPAIR & COUPLINGS

3” (One bolt)

6” (Two bolt)

HINGED

PIPE REPAIR

CLAMPS

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 89

GENE RICH & COMPANY

NO HUB COUPLINGS

DISCOUNTED

5% for 500

#T1194TW

No-Hub Torque Wrench

See page 116

• Stainless Steel Band & Shield

• Stainless Steel Screws

• Neoprene Gaskets

• Manufactured to specifications:

ASTM C-564 (neoprene gaskets) ASTM C-1277-97 CISPI 310-97, IAPMO Approved

10% for 1,000

COMPRESSION TEE - MALLEABLE IRON

• Galvanized for corrosion protection • EPDM gaskets

• Fits both IPS and Schedule 40 pipe • Max 125 psi @ 120° F

Item No Size Std. Pkg

1360A 1-1/2” 100 Ea

1360B 2” 100 Ea

1360C 3” 100 Ea

1360D 4” 100 Ea

1360E 5” 20 Ea

1360F 6” 20 Ea

1360G 8” 10 Ea

1360H 10” 8 Ea

Item No Size Std. Pkg

1361A 2” x 1-1/2” 100 Ea

1361B 3” x 2” 100 Ea

1361C 4” x 3” 100 Ea

• Metal friction ring

• Compression tees must be restrained on both ends

COMPRESSION TEE - BRONZE

PIPE REPAIR & COUPLINGS

• Bronze coated brass • Max 125 psi @ 180° F

• For galvanzied pipe and copper tubing • EPDM gaskets

• Compression tees must be restrained on both ends

COMPRESSION COUPLING GASKET

• EPDM (Ethylene Propylene Diene Monomer) gasket

• Excellent resistance to UV rays and ozone.

• Good resistance to Anti-freeze, Synthetic Detergents, Acetone, Boric acid, Ethanol, Formaldehyde, Mercury, Potassium Sulfate, Silver Nitrate, Steam (up to 212° Fahrenheit), Saccharin.

Item No CTS IPS Branch Std. Pkg

1336 1/2” 3/8” 1/2” FIP 1 Ea

1337 3/4” 1/2” 3/4” FIP 1 Ea

Item No CTS IPS Branch Std. Pkg

1380 1/2” 3/8” 1/2” FIP 1 Ea

1381 3/4” 1/2” 1/2” FIP 1 Ea

1384 1” 3/4” 3/4” FIP 1 Ea

Item No Replacement Gasket Std. Pkg

1390BR-G For 3/8” IPS Bronze Coupling 1 Ea

90 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

1391BR-G For 1/2” IPS Bronze Coupling 1 Ea

1392BR-G For 3/4” IPS Bronze Coupling 1 Ea

1391IMP-G For 1/2” IPS Galvanized Coupling 1 Ea

1392IMP-G For 3/4” IPS Galvanized Coupling 1 Ea

GENE RICH & COMPANY

SHORT PATTERN

Item No IPS CTS Length Std. Pkg

1390SBR 3/8” 1/2” 3” 12 Ea

1391SBR 1/2” 3/4” 3” 12 Ea

1392SBR 3/4” 1” 3” 12 Ea

1393SBR 1” 1-1/4” 3” 12 Ea

• Bronze coated brass

LONG PATTERN

Item No IPS CTS Length Std. Pkg

1390BR 3/8” 1/2” 5” 12 Ea

1391BR 1/2” 3/4” 5” 12 Ea

1392BR 3/4” 1” 5” 12 Ea

1393BR 1” 1-1/4” 5” 12 Ea

1394BR 1-1/4” 1-1/2” 5” 12 Ea

1395BR 1-1/2” 5” 12 Ea

1396BR 2” 5” 12 Ea

1397BR 2” 5” 12 Ea

• Max 125 psi @ 180° F

• EPDM gaskets

• For galvanzied pipe and copper tubing

• Galvanized for corrosion protection

• Max 125 psi @ 120° F

BRASS

COMPRESSION COUPLING

GALVANIZED MALLEABLE IRON

COMPRESSION COUPLING

• EPDM gaskets • Metal friction ring

• Fits both IPS and Schedule 40 pipe

Item No IPS Length Std. Pkg

1391GAL 1/2” 4-1/4” 10 Ea

1392GAL 3/4” 4-1/2” 10 Ea

1393GAL 1” 4-3/4” 10 Ea

Item No IPS Length Std. Pkg

1394GAL 1-1/4” 5” 10 Ea

1395GAL 1-1/2” 5-1/8” 5 Ea

1396GAL 2” 5-1/2” 5 Ea

• For use on cold water lines only PVC COMPRESSION COUPLING

• EPDM gaskets • Max 150 psi @ 73° F

• Fits both IPS and Schedule 40 pipe

Item No IPS Length Std. Pkg

1391PVC 1/2” 4” 10 Ea

1392PVC 3/4” 4-1/4” 10 Ea

1393PVC 1” 4-1/2” 10 Ea

• Pressure rated to Schedule 40 tolerances

• Telecoping expansion coupling with 2” - 31/2” adjustment

Item No IPS Length Std. Pkg

1394PVC 1-1/4” 5” 10 Ea

1395PVC 1-1/2” 5-1/2” 5 Ea

1396PVC 2” 6” 5 Ea

COMPRESSION COUPLING

PVC TELESCOPING

PIPE REPAIR & COUPLINGS

• Non-leading permanent seals are ensured by a 1500 psi-rated O-ring.

Item No IPS Length Std Pkg

1391TPVC 1/2” 6 1/4” - 8 5/16” 30 Ea

1392TPVC

1393TPVC

3/4” 6 1/2” - 8 7/8” 24 Ea

1” 7 1/2” - 10 3/16” 18 Ea

Item No IPS Length Std Pkg

1394TPVC 1-1/4” 8 3/4” - 11 1/4” 12 Ea

1395TPVC

1396TPVC

1-1/2” 9 1/2” - 12 1/2” 12 Ea

2” 9 3/4” - 13” 8 Ea

(EXPANSION COUPLING)

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 91

GENE RICH & COMPANY

FLANGE CONNECTION BOLT SETS

NON-ASBESTOS FLANGE GASKET

Full Face

PIPE REPAIR & COUPLINGS

Ring Gasket

• Bolts meet ASTM A-307 Grade A

• Nuts meet ASTM A-563 Grade A

Item No Bolt Size Bolts/Set Fits Flange Std. Pkg

1398B20 5/8” x 2-1/4” 4 2” 1 St

1398B30 5/8” x 2-1/2” 4 2-1/2” & 3” 1 St

1398B40 5/8” x 3” 8 4” 1 St

1398B60 3/4” x 3-1/4” 8 6” 1 St

FULL FACE GASKETS

Item No Size Style Std. Pkg

1398F20 2” Full Face 1 Ea

• Non-Asbestos specification compliance:

ASTM F152, F36A, D1170-P1141A, F104-F002120 M6, ANSI B16.21

• 1/16” Thick

• 150 Lbs

1398F25 2-1/2” Full Face 1 Ea

1398F30 3” Full Face 1 Ea

1398F40 4” Full Face 1 Ea

1398F60 6” Full Face 1 Ea

RING GASKETS

Item No Size Style Std. Pkg

1398R20 2” Ring 1 Ea

1398R25 2-1/2” Ring 1 Ea

1398R30 3” Ring 1 Ea

1398R40 4” Ring 1 Ea

1398R60 6” Ring 1 Ea

RED RUBBER FLANGE GASKET

• Rubber gaskets meet:

Full Face

Ring Gasket

92 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

ASTM D-1330 Grade II

• 1/16” Thick

• 150 Lbs

FULL FACE GASKETS

Item No Size Style Std. Pkg

1398F20R 2” Full Face 1 Ea

1398F25R 2-1/2” Full Face 1 Ea

1398F30R 3” Full Face 1 Ea

1398F40R 4” Full Face 1 Ea

1398F60R 6” Full Face 1 Ea

RING GASKETS

Item No Size Style Std. Pkg

1398R20R 2” Ring 1 Ea

1398R25R 2-1/2” Ring 1 Ea

1398R30R 3” Ring 1 Ea

1398R40R 4” Ring 1 Ea

1398R60R 6” Ring 1 Ea

GENE RICH & COMPANY

• Non-Asbestos Gasket specification compliance: ASTM F152, F36A, D1170-P1141A, F104-F002120 M6, ANSI B16.21

• 1/16” Thick • 150 Lbs

• Bolts meet ASTM A-307 Grade A

• Nuts meet ASTM A-563 Grade A

FULL FACE GASKET KITS

Item No Size Gasket Bolts/Set Bolt Size Std. Pkg

1399F20R 2” Full Face 4 5/8” x 2-1/4” 1 Kit

1399F25R 2-1/2” Full Face 4 5/8” x 2-1/2” 1 Kit

1399F30R 3” Full Face 4 5/8” x 2-1/2” 1 Kit

1399F40R 4” Full Face 8 5/8” x 3” 1 Kit

1399F60R 6” Full Face 8 3/4” x 3-1/4” 1 Kit

RING GASKET KITS

Item No Size Gasket Bolts/Set Bolt Size Std. Pkg

1399R20 2” Ring 4 5/8” x 2-1/4” 1 Kit

1399R25 2-1/2” Ring 4 5/8” x 2-1/2” 1 Kit

1399R30 3” Ring 4 5/8” x 2-1/2” 1 Kit

1399R40 4” Ring 8 5/8” x 3” 1 Kit

1399R60 6” Ring 8 3/4” x 3-1/4” 1 Kit

NON-ASBESTOS

FLANGE CONNECTION KITS

#1399F40

#1399R30

• Red Rubber Gaskets meet ASTM D-1330 Grade II

• 1/16” Thick • 150 Lbs

• Bolts meet ASTM A-307 Grade A

• Nuts meet ASTM A-563 Grade A

FULL FACE GASKET KITS

Item No Size Gasket Bolts/Set Bolt Size Std. Pkg

1399F20R 2” Full Face 4 5/8” x 2-1/4” 1 Kit

1399F25R 2-1/2” Full Face 4 5/8” x 2-1/2” 1 Kit

1399F30R 3” Full Face 4 5/8” x 2-1/2” 1 Kit

1399F40R 4” Full Face 8 5/8” x 3” 1 Kit

1399F60R 6” Full Face 8 3/4” x 3-1/4” 1 Kit

RING GASKET KITS

Item No Size Gasket Bolts/Set Bolt Size Std. Pkg

1399R20R 2” Ring 4 5/8” x 2-1/4” 1 Kit

1399R25R 2-1/2” Ring 4 5/8” x 2-1/2” 1 Kit

1399R30R 3” Ring 4 5/8” x 2-1/2” 1 Kit

1399R40R 4” Ring 8 5/8” x 3” 1 Kit

1399R60R 6” Ring 8 3/4” x 3-1/4” 1 Kit

RED RUBBER

FLANGE CONNECTION KITS

PIPE REPAIR & COUPLINGS

#1399F30R

#1399R40R

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 93

GENE RICH & COMPANY

DIELECTRIC UNION

FEMALE IPS X SWEAT

DIELECTRIC UNION

FEMALE IPS X FEMALE IPS

• Prevent electrolysis or galvanic action when connecting dissimilar metals

• Zinc plated forged steel body with female IPS threads

• Brass sweat connection for copper piping

• ABS fiber sleeve separates steel and brass components.

• Max temperature 210° F

• Max pressure: 125 psi

• Cadmium plated malleable iron body with female IPS threads.

• Nylon dielectric element is permanently molded to the union body.

• Recommended for water, oil & gas.

• Max temperature 210

• Max pressure: 125 psi

° F

Copper IPS

1/2” 1/2” 1566A 1566A-W 1 Ea

1/2” 3/4” 1567 1567-W 1 Ea

3/4” 3/4” 1568 1568-W 1 Ea

1” 1” 1569 1569-W 1 Ea

1-1/4” 1-1/4” 1573 1573-W 1 Ea

1-1/2” 1-1/2” 1574 1574-W 1 Ea

2” 2” 1576 1576-W 1 Ea

Item No IPS IPS Std. Pkg

1591 1/2” 1/2” 12 Ea

1592 3/4” 3/4” 12 Ea

1593 1” 1” 6 Ea

1594 1-1/4” 1-1/4” 6 Ea

1595 1-1/2” 1-1/2” 6 Ea

1596 2” 2” 4 Ea

Complete

Union

Item No

Washer

Only

Item No

Std. Pkg

DIELECTRIC COUPLING

PIPE REPAIR & COUPLINGS

DRUM TRAP COVER

• Provides dielectric protection from corrosion between dissimilar metal piping.

• Inner dielectric element is a threaded thermosetting plastic laminate.

• Cadmium plated steel body

• Recommended for use with fresh water and petroleum products.

• Do not use with salt water.

• Max temperature 210° F

• Max pressure: 125 psi

• Flanged, 3” chrome plated die cast

• Gasket is included

Item No Description Std. Pkg

1663 Chrome Plated Drum Trap Cover 6 Ea

Item No FIPT Std. Pkg

1578 1/2” 12 Ea

1579 3/4” 12 Ea

1580 1” 12 Ea

1581 1-1/4” 6 Ea

1582 1-1/2” 6 Ea

1583 2” 6 Ea

1584 2-1/2” 1 Ea

1585 3” 1 Ea

94 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

GENE RICH & COMPANY

• Eliminate costly damage due to sewage back-up.

• Provide a visible warning that sewage is backing up.

• For use in outside clean-outs

• Fit cast iron or plastic pipe

• Spring keeps valve closed to prevent sewer gases from escaping but easily opens to relieve pressure during a sewage backup.

• Sets include: 1 - Brass cleanout plug, countersunk, tapped 1 - Polished stainless steel cover plate, 24 gauge 1 - 1/4”-20 x 4” machine screw, plated, flat head, slotted

Item No Size Std. Pkg

1665A 1-1/2” 10 Ea

1665B 2” 10 Ea

1665C 2-1/2” 10 Ea

1665D 3” 10 Ea

1665E 3-1/2” 10 Ea

1665F 4” 10 Ea

EXTENSION COVER SETS

Item No Plug Size Plate Size Screw Size Std. Pkg

1666 1-1/2” 3” 1/4” x 4” 1 Set

1666A 1-1/2” 4” 1/4” x 4” 1 Set

1667 2” 3” 1/4” x 4” 1 Set

1667A 2” 4” 1/4” x 4” 1 Set

1668 3” 5” 1/4” x 4” 1 Set

1668A 3” 6” 1/4” x 4” 1 Set

1669A 4” 8” 1/4” x 4” 1 Set

SEWER RELIEF VALVES

Item No Size Std. Pkg

1675 1-1/2” 6 Ea

• Cast Brass

• Countersunk

• Tapped for a 1/4”-20 screw

• Polished to a mirror finish

• 24 gauge stainless steel

• Punched for a 1/4” screw

• Bright zinc plated steel

• Slotted flat head

• 1/4” diameter, 20 threads/inch

• Full thread

1676 2” 6 Ea

1676A 2-1/2” 6

1677 3” 6 Ea

1678 3-1/2” 6 Ea

1679 4” 6 Ea

Item No Size Std. Pkg

1680 3” 50 Ea

1681 4” 25 Ea

1682 5” 25 Ea

1683 6” 25 Ea

1684 8” 25 Ea

1684A 10” 10 Ea

Item No Size Std. Pkg

1694 1/4-20 x 4” 50 Ea

1696 1/4-20 x 6” 50 Ea

TAPPED BRASS

COUNTERSUNK PLUG

(F

OR EXTENSION COVER)

STAINLESS STEEL

COVER PLATES

EXTENSION COVER

MACHINE SCREWS

COVER PLATES & PLUGS

PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036 95

GENE RICH & COMPANY

SOUTHERN CODE BRASS CLEANOUT PLUGS

RAISED HEAD

Item No Size Std. Pkg

1686 1-1/4” 1 Ea

1687 1-1/2” 1 Ea

1688 2” 1 Ea

1689 2-1/2” 1 Ea

1690 3” 1 Ea

1691 3-1/2” 1 Ea

1692 4” 1 Ea

1692A 5” 1 Ea

1692B 6” 1 Ea

1692F 8” 1 Ea

10” RECTANGULAR PLASTIC METER BOX

• For burial of water line valves, sprinkler valves, meters, etc.

• Plastic drop-in lid with snap-in lock tab.

Countersunk Wrench

on Pg 120

COUNTERSUNK

Item No Size Std. Pkg

1693A 1-1/2” 1 Ea

1693F 2” 1 Ea

1693L 2-1/2” 1 Ea

1693M 3” 1 Ea

1693R 3-1/2” 1 Ea

1693T 4” 1 Ea

1693V 5” 1 Ea

1693W 6” 1 Ea

1693X 8” 1 Ea

12” RECTANGULAR PLASTIC METER BOX

COVER PLATES & PLUGS

WITH READER LID

ROUND PLASTIC VALVE

BOX

• 10” D x 12-3/4” W x 19” L at base

• 9-3/4” W x 15” L at top

• One 3” x 4” pipe slot

• For burial of water line valves, sprinkler valves, meters, etc.

• Black drop-in plastic lid cover with snap-in lock tab.

• Hinged reading lid is 4-1/2” x 7-1/2”

• 12” D x 16” W x 21-1/2” L at base

• 10-1/2” W x 16” L at top

• One 3” x 4” pipe slot

• For burial of water line valves or sprinkler valves.

• Snap-in green lid

Item No Std. Pkg

1240 1 Ea

Item No Std. Pkg

1242 1 Ea

• Black lower body

• Use 6” plastic or iron pipe to extend to any depth

• 9” D x 8” W

• One 2-1/2” x 2-1/2” pipe slot

96 PHONE 800-433-7605 WWW.GENERICH.COM TOLL FREE FAX 877-535-7036

Item No Std. Pkg

1244 1 Ea
