Generac 004702-0, 004703-0, 004704-0, 004705-0, 004706-0 User Manual

...
60cc O
N
QU
CT
L
G
Owner’s Manual
Air-cooled Recreational
Vehicle Generators
QUIETPACT 55, 65 and 75
• Models: 004702-0, 004703-0 004704-0, 004705-0 004706-0, & 004707-0
This manual should remain with the unit.
IETPA
POWERED BY GUARDIAN 7
55
INDUSTRIA
Generac®Power Systems, Inc.
INTRODUCTION
READ THIS MANUAL THOROUGHLY
If you do not understand any portion of this manual, contact Generac or your nearest Generac Authorized Service Dealer for starting, operating and servicing procedures.
Throughout this publication, and on tags and decals affixed to the generator, DANGER, WARNING, CAUTION and NOTE blocks are used to alert you to special instruction about a particular operation that may be hazardous if performed incorrectly or care­lessly. Observe them carefully. Their definitions are as follows:
After this heading, you can read instructions that, if not strictly complied with, will result in personal injury, including death, and property damage.
After this heading, you can read instructions that, if not strictly complied with, may result in person­al injury or property damage.
After this heading, you can read instructions that, if not strictly complied with, could result in dam­age to equipment and/or property.
NOTE:
After this heading, you can read explanatory statements that require special emphasis.
These safety warnings cannot eliminate the hazards that they indicate. Common sense and strict compli­ance with the special instructions while performing the service are essential to preventing accidents.
Four commonly used safety symbols accompany the Danger, Warning and Caution blocks. The type of information each indicates follows:
This symbol points out important safety infor­mation that, if not followed, could endanger personal safety and/or property of you and others.
This symbol points out potential explosion hazard.
This symbol points out potential fire hazard.
This symbol points out potential electrical shock hazard.
The operator (driver) is responsible for proper and safe use of the vehicle and its equipment, and the safety of all vehicle occupants. We strongly recom­mend that the operator read this manual and thor­oughly understand all instructions before using this equipment. We also strongly recommend instructing other occupants in the vehicle to properly start and operate the generator. This prepares them if they need to operate the equipment in an emergency.
CONTENTS
This manual contains pertinent owner’s information, including warranty, electrical diagrams, exploded views and lists of repair parts for generator model numbers 004702-0, 004703-0, 004704-0, 004705-0, 004706-0, and 004707-0. In addition, the latter por­tion of this manual contains information necessary for the proper installation of these generators.
OPERATION AND MAINTENANCE
It is the operator's responsibility to perform all safe­ty checks, to make sure that all maintenance for safe operation is performed promptly, and to have the equipment checked periodically by a Generac Authorized Service Dealer. Normal maintenance ser­vice and replacement of parts are the responsibility of the owner/operator and, as such, are not considered defects in materials or workmanship within the terms of the warranty. Individual operating habits and usage contribute to the need for maintenance service.
Proper maintenance and care of your generator ensure a minimum number of problems and keep operating expenses at a minimum. See your Generac Authorized Service Dealer for service aids and acces­sories.
HOW TO OBTAIN SERVICE
When your generator requires servicing or repairs, simply contact a Generac Authorized Service Dealer for assistance. Service technicians are factory-trained and are capable of handling all of your service needs.
When contacting a Generac Authorized Service Dealer or the factory about parts and service, always supply the complete model number and serial num­ber of your unit as given on its data decal, which is located on your generator.
Model No. ____________ Serial No. ______________
AUTHORIZED SERVICE
DEALER LOCATION
To locate the GENERAC AUTHORIZED SERVICE
DEALER nearest you, please call this number:
1-800-333-1322
ONLY DEALER LOCATION INFORMATION
CAN BE OBTAINED AT THIS NUMBER.
DANGER
!
Table of Contents
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
Generac®Power Systems, Inc. 1
Part I — Operating Instructions
Introduction ..................................................Inside Front Cover
Read This Manual Thoroughly ..........................................IFC
Contents ............................................................................IFC
Operation and Maintenance ..............................................IFC
How to Obtain Service ......................................................IFC
Authorized Service Dealer Locator Number ..........................IFC
Safety Rules ..................................................................................2
Section 1 – General Information ............................................4
1.1 Generator Identification ................................................4
1.2 Generator Applicability ..................................................5
1.3 Installation ....................................................................5
1.4 Safety ............................................................................5
1.5 Generator AC Connection System ..................................5
1.6 Specifications ................................................................6
1.6.1 Fuel Requirements ..............................................6
1.6.2 Engine Oil Requirements ....................................6
1.6.3 Generator Specifications......................................6
1.6.4 Engine Specifications ..........................................7
1.6.5 Emissions Compliance Period ............................7
Section 2 – Operation................................................................7
2.1 Generator Control Panel ................................................7
2.1.1 Fuel Primer..........................................................7
2.1.2 Start/Stop Switch ................................................7
2.1.3 15 Amp Fuse........................................................7
2.1.4 Line Breakers ......................................................7
2.2 Optional Remote Start/Stop Panel..................................8
2.3 Automatic Choke ..........................................................8
2.3.1 Choke Solenoid ..................................................8
2.3.2 Prechoke..............................................................8
2.4 Before Starting the Engine ............................................8
2.4.1 Installation..............................................................8
2.4.2 Engine Lubrication ................................................8
2.4.3 Fuel Supply ............................................................8
2.4.4 Cooling and Ventilating Air ....................................8
2.4.5 Engine Exhaust Gas ..............................................8
2.5 Starting the Generator ..................................................9
2.6 Stopping the Generator..................................................9
2.7 Applying Loads to Generator ........................................9
2.7.1 Letting the Engine Stabilize ................................9
2.7.2 Do Not Overload the Generator ........................10
2.8 Protection Systems ......................................................10
2.8.1 Low Oil Pressure Switch....................................10
2.8.2 High Temperature Switch ..................................10
2.8.3 Field Boost ........................................................10
2.8.4 Overvoltage Protection ......................................11
2.8.5 25-Hour Break-in Period....................................11
2.8.6 25-Hour Checkup ..............................................11
2.8.7 Operation in High Grass or Brush ....................11
Section 3 – Maintenance ........................................................11
3.1 Checking the Engine Oil Level......................................11
3.2 Changing the Engine Oil and/or Oil Filter ....................12
3.3 Maintaining the Engine Air Cleaner ............................12
3.3.1 Cleaning the Foam Precleaner............................12
3.4 Checking the Engine Spark Plug..................................13
3.5 Fuel Filter (Gasoline Only) ..........................................13
3.6 Clean Spark Arrestor ..................................................13
3.7 Cleaning the Generator ................................................14
3.8 Battery Maintenance ....................................................14
3.8.1 Weekly ..............................................................14
3.8.2 Every Six Months ..............................................14
3.9 Major Service Manual ..................................................15
3.10 Drive Belt ....................................................................15
3.11 Exercising the Generator ............................................15
3.12 Out of Service Procedure ............................................15
3.12.1 Removal From Service ....................................15
3.12.2 Return to Service ............................................15
3.13 RV Generator Service Interval......................................15
Section 4 – Notes......................................................................16
Part II — Installation Instructions ........................................17
Safety Rules................................................................................18
Section 5 — General Information..........................................20
5.1 Purpose and Scope of the Installation Instructions......20
5.2 Safety ..........................................................................20
5.3 Standards Booklets ....................................................20
5.4 Equipment Description ................................................20
5.5 Generator Engine Operating Speed..............................20
5.6 Generator AC Connection System ................................20
Major Features and Dimensions ..................................21
Section 6 — Installation ..........................................................22
6.1 Location and Support ..................................................22
6.1.1 Generator Location............................................22
6.1.2 Generator Support ............................................22
6.1.3 Suspended Mounting ........................................23
6.1.4 Generator Restraint ..........................................23
6.2 Generator Compartments ............................................23
6.2.1 Compartment Size ............................................23
6.2.2 Compartment Construction ..............................23
6.2.3 Sound Insulating Materials................................24
6.2.4 Acoustics ..........................................................25
6.2.5 Compartment Floor Cutouts..............................25
6.3 Cooling and Ventilating Air ..........................................25
6.3.1 Generator Airflow ..............................................25
6.3.2 Testing the Installation ......................................26
6.4 Gasoline Fuel System ..................................................26
6.4.1 Fuel Tank ..........................................................27
6.4.2 Generator Fuel Supply Line ..............................27
6.5 LP Gas Fuel System ....................................................27
6.5.1 LP Fuel Consumption ........................................27
6.5.2 Parts Not Included in Fuel System ....................27
6.5.3 Some Important Considerations........................28
6.5.4 Vapor Withdrawal ..............................................28
6.5.5 Primary Regulator..............................................28
6.5.6 Gaseous Carburetion ........................................28
6.5.7 Fuel Supply Lines ..............................................29
6.5.8 Excess Flow Valve ..............................................29
6.5.9 Leakage Tests ....................................................29
6.6 Exhaust System ..........................................................29
6.6.1 Mufflers and Spark Arrestors............................30
6.6.2 Exhaust System Safety ......................................30
6.7 Electrical Connections ................................................30
6.7.1 Electrical Junction Box ....................................30
6.7.2 Wiring ................................................................31
6.7.3 Generator AC Connections ................................31
6.7.4 Conduit..............................................................31
6.7.5 Isolating Different Power Sources ......................31
6.7.6 Power Supply Cord............................................31
6.7.7 Ground Fault Circuit Interrupters ....................32
6.8 Battery Installation ......................................................32
6.8.1 Recommended Battery ......................................32
6.8.2 Battery Cables ..................................................32
6.8.3 Battery Cable Connections ................................32
6.8.4 Battery Compartment ........................................32
6.9 Optional Accessories ....................................................34
6.9.1 Remote Panel Models ........................................34
Section 7 — Post Installation ................................................34
7.1 Post Installation Tests ..................................................34
7.2 Before Initial Start-up ..................................................34
7.3 Initial Start ..................................................................34
7.4 Testing Under Load......................................................35
7.5 Installation Checklist ..................................................35
Section 8 – Troubleshooting ..................................................36
8.1 Troubleshooting Guide ................................................36
Section 9 – Notes......................................................................37
Section 10 – Electrical Data ..................................................38
Section 11 – Exploded Views and Parts Lists....................40
Section 12 – Warranty ............................................................52
2 Generac®Power Systems, Inc.
Study these SAFETY RULES carefully before installing, operating or servicing this equipment. Become familiar with this manual and with the unit. The generator can operate safely, efficiently and reli­ably only if it is properly installed, operated and maintained. Many accidents are caused by failing to follow simple and fundamental rules or precautions.
Generac cannot possibly anticipate every possible circumstance that might involve a hazard. The warn­ings in this manual, and on tags and decals affixed to the unit, are, therefore, not all-inclusive. If you use a procedure, work method or operating tech­nique Generac does not specifically recommend, you must satisfy yourself that it is safe for you and others. You also must make sure the procedure, work method or operating technique that you choose does not render the generator unsafe.
Despite the safe design of this generator, operating this equipment imprudently, neglect­ing its maintenance or being careless can cause possible injury or death. Permit only responsi­ble and capable persons to operate or maintain this equipment.
Potentially lethal voltages are generated by these machines. Ensure all steps are taken to render the machine safe before attempting to work on the generator.
Parts of the generator are rotating and/or hot during operation. Exercise care near running generators.
GENERAL HAZAR
DS
• For safety reasons, Generac recommends
that the installation, initial start-up and mainte­nance of this equipment is carried out by a Generac Authorized Service Dealer.
• The generator engine releases DEADLY carbon
monoxide gas through its exhaust system. This dangerous gas, if breathed in sufficient concentra­tions, can cause unconsciousness or even death. Never operate the generator set with the vehicle inside any garage or other enclosed area. DO NOT OPERATE THE GENERATOR IF THE EXHAUST SYSTEM IS LEAKING OR HAS BEEN DAMAGED. SYMPTOMS OF CARBON MONOXIDE POISON­ING ARE (a) inability to think coherently, (b) nau­sea, (c) vomiting, (d) twitching muscles, (e) throb­bing temples, (f) dizziness, (g) headaches, (h) weakness, and (i) sleepiness. IF YOU EXPERI­ENCE ANY OF THESE SYMPTOMS, MOVE INTO FRESH AIR IMMEDIATELY. IF SYMPTOMS PER­SIST, GET MEDICAL HELP. Shut down the gener­ator and do not operate it until it has been inspect­ed and repaired.
• Never sleep in the vehicle while the genset is run-
ning unless the vehicle has a working carbon monoxide detector. The exhaust system must be installed in accordance with the genset installation manual. Make sure there is ample fresh air when operating the genset in a confined area.
• Keep hands, feet, clothing, etc., away from drive
belts, fans, and other moving or hot parts. Never remove any drive belt or fan guard while the unit is operating.
• Adequate, unobstructed flow of cooling and venti-
lating air is critical to correct generator operation and is required to expel toxic fumes and fuel vapors from the generator compartment. Without sufficient cooling airflow, the engine/generator quickly overheats, which causes serious damage to the generator. Do not alter the installation or per­mit even partial blockage of ventilation provisions, as this can seriously affect safe operation of the generator.
• When working on this equipment, remain alert at
all times. Never work on the equipment when you are physically or mentally fatigued.
• Inspect the generator regularly, and contact your
nearest Generac Authorized Service Dealer imme­diately for parts needing repair or replacement.
!!!
Safety Rules
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
SAVE THESE INSTRUCTIONS – The manufacturer suggests that these rules for safe operation be copied and posted in potential hazard areas of the recreational vehicle. Safety should be stressed to all operators and potential operators of this equipment.
!
!
The engine exhaust from this product
contains chemicals known to the state
of California to cause cancer, birth
defects or other reproductive harm.
WARNING:
This product contains or emits chemicals known to the state of California to cause
cancer, birth defects or other reproductive harm.
WARNING:
!
!
!
!
DANGER
!
Generac®Power Systems, Inc. 3
• Before performing any maintenance on the genera­tor, disconnect its battery cables to prevent acci­dental start up. Disconnect the cable from the bat­tery post indicated by a NEGATIVE, NEG or (–) first. Reconnect that cable last.
• Never use the generator or any of its parts as a step. Stepping on the unit can stress and break parts, and may result in dangerous operating con­ditions from leaking exhaust gases, fuel leakage, oil leakage, etc.
ELECTRICAL HAZARDS
• The generator covered by this manual produces dangerous electrical voltages and can cause fatal electrical shock. Avoid contact with bare wires, ter­minals, connections, etc., while the unit is running. Ensure all appropriate covers, guards and barriers are in place before operating the generator. If you must work around an operating unit, stand on an insulated, dry surface to reduce shock hazard.
• Do not handle any kind of electrical device while standing in water, while barefoot, or while hands or feet are wet. DANGEROUS ELECTRICAL SHOCK MAY RESULT.
• During installation onto the vehicle, have the gen­erator properly grounded (bonded) either by solid mounting to the vehicle frame or chassis, or by means of an approved bonding conductor. DO NOT disconnect the bonding conductor, if so equipped. DO NOT reconnect the bonding conduc­tor to any generator part that might be removed or disassembled during routine maintenance. If the grounding conductor must be replaced, use only a flexible conductor that is of No. 8 American Wire Gauge (AWG) copper wire minimum.
• In case of accident caused by electric shock, imme­diately shut down the source of electrical power. If this is not possible, attempt to free the victim from the live conductor. AVOID DIRECT CONTACT WITH THE VICTIM. Use a nonconducting imple­ment, such as a rope or board, to free the victim from the live conductor. If the victim is uncon­scious, apply first aid and get immediate medical help.
• Never wear jewelry when working on this equip­ment. Jewelry can conduct electricity resulting in electric shock, or may get caught in moving com­ponents causing injury.
FIRE HAZARDS
• For fire safety, the generator must be installed and maintained properly. Installation always must comply with applicable codes, standards, laws and regulations. Adhere strictly to local, state and national electrical and building codes. Comply with regulations the Occupational Safety and Health Administration (OSHA) has established. Also, ensure that the generator is installed in accordance with the manufacturer’s instructions and recommendations. Following proper installa­tion, do nothing that might alter a safe installation and render the unit in noncompliance with the aforementioned codes, standards, laws and regu­lations.
• Keep a fire extinguisher in the vehicle at all times. Extinguishers rated “ABC” by the National Fire Protection Association are appropriate for use on the recreational vehicle generator electrical sys­tem. Keep the extinguisher properly charged and be familiar with its use. If you have any question pertaining to fire extinguishers, consult your local fire department.
EXPLOSION HAZARDS
• Do not smoke around the generator. Wipe up any fuel or oil spills immediately. Ensure that no com­bustible materials are left in the generator com­partment, or on or near the generator, as FIRE or EXPLOSION may result. Keep the area surround­ing the generator clean and free from debris.
• Gasoline is extremely FLAMMABLE and its vapors are EXPLOSIVE. Do not permit smoking, open flame, sparks or any source of heat in the vicinity while handling gasoline. Comply with all laws gov­erning the storage and handling of gasoline.
• This generator may use liquid propane (LP) gas as a fuel. LP gas is highly EXPLOSIVE. The gas is heavier than air and tends to settle in low areas where even the slightest spark can ignite the gas and cause an explosion.
Safety Rules
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
4 Generac®Power Systems, Inc.
Section 1 – General Information
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
Please record the following information from the generator DATA DECAL or information decal.
1. Model Number ____________________ 2. Serial Number __________________
3. kW Rating__________________________ 4. Rated Voltage __________________
5. Phase ______________________________ 6. Hertz __________________________
S DO NOT PRESS START BUTTON LONGER THEN 15 SECONDS PER ATTEMPT.
(
)
QT
)
S
30
5W-30 OR 5
0
C
00
S.
T
S.
C
R
:
R
O
Y
O
:
087769
072347
1.1 GENERATOR IDENTIFICATION
REFERENCE NUMBER IDENTIFICATION
1. Generator Air Intake Screen
2. Data Plate
3. Engine Start/Stop Switch
4. 7.5 amp Fuse
5. Circuit Breaker
6. Optional Remote Panel Receptacle
7. Generator AC Output Leads
8. Starter Contactor
9. Fuel Inlet
10. Fuel Primer Switch
11. Fuel Pump (Behind access panel.)
12. Oil Filter
13. Oil Drain Plug
14. Oil Dipstick and Filler Tube
15. Air Filter (Behind access panel.)
16. Spark Plugs
17. Exhaust Outlet
18. Fuel Filter
19. LP Fuel Inlet
14
16
4
2
5
10
3
11, 15 (Behind Access Panel)
LEAN PREFILTE EVERY 100 HOUR REPLACE ELEMEN EVERY 250 HOUR
HANGE EVERY 1 HOURS. (OR ANNUALLY
1.8L/1.9
SAE VISCOSITY AE 30 OR 10W-
TARTING,
W-2
1
8
IL & OIL FILTER
IL CAPACIT
TEMPERATURE 40F AND HIGHE
17
13
12
19
7
6
9, 18
Generac®Power Systems, Inc. 5
Section 1 – General Information
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
1.2 GENERATOR APPLICABILITY
These generators have been designed and manufac­tured for supplying electrical power for recreational vehicles. You should not modify the generator or use it for any application other than for what it was designed. If there are any questions pertaining to its application, write or call the factory. Do not use the unit until you have been advised by competent authority.
For fire safety, the generator must have been properly installed in compliance with ANSI
119.2-1975/NFPA 501C-1974, “Standard for Recreational Vehicles, Part III – Installation of Electrical Systems.” The generator also must have been installed in strict compliance with the manufacturer’s detailed installation instruc­tions. After installation, do nothing that might render the unit in noncompliance with such codes, standards and instructions.
You can use your generator set to supply electrical power for operating one of the following electrical loads:
• QUIETPACT 55G & LP: 120 and/or 240 volts, sin­gle phase, 60 Hz electrical loads. These loads can require up to 5500 watts (5.5 kW) of total power, but cannot exceed 45.8 AC amperes of current at 120 volts or exceed 22.9 AC amperes at 240 volts.
• QUIETPACT 65G & LP: 120 and/or 240 volts, sin­gle phase, 60 Hz electrical loads. These loads can require up to 6500 watts (6.5 kW) of total power, but cannot exceed 54.1 AC amperes of current at 120 volts or exceed 27 AC amperes at 240 volts.
• QUIETPACT 75G & LP: 120 and/or 240 volts, sin­gle phase, 60 Hz electrical loads. These loads can require up to 7500 watts (7.5 kW) of total power, but cannot exceed 62.5 AC amperes of current at 120 volts or exceed 31.2 AC amperes at 240 volts.
Do not overload the generator. Some installa­tions may require that electrical loads be alter­nated to avoid overloading. Applying excessive­ly high electrical loads may damage the genera­tor and may shorten its life. Add up the rated watts of all electrical lighting, appliance, tool and motor loads the generator will power at one time. This total should not be greater than the wattage capacity of the generator. If an electrical device nameplate gives only volts and amps, multiply volts times amps to obtain watts (volts x amps = watts). Some electric motors require more watts of power (or amps of cur­rent) for starting than for continuous operation.
1.3 INSTALLATION
This Owner’s Manual has been prepared under the assumption that a competent, qualified technician installed the generator into a recreational vehicle. We also assume the installer complied with all applicable codes, standards and regulations pertaining to instal­lation.
An INSTALLATION MANUAL was shipped with the generator. That Manual contains manufacturer’s instructions and recommendations for installing the unit into an industrial vehicle. After installation, installers should forward the Installation Manual to Owners/Operators for their information.
Owners/Operators have the responsibility to make sure that nothing is done that might render the instal­lation unsafe or in non-compliance with applicable codes, standards and instructions.
1.4 SAFETY
Before using the generator set, carefully read GEN­ERAL SAFETY RULES inside the cover. Comply with these RULES to prevent accidents and damage to equipment and/or property. Generac suggests copy­ing and posting the GENERAL SAFETY RULES to potential operators of this equipment.
1.5 GENERATOR AC CONNECTION SYSTEM
These air-cooled generator sets are equipped with dual stator AC power windings. These two stator windings supply electrical power to customer electri­cal loads by means of a dual 2-wire connection sys­tem.
Generators may be installed to provide the following outputs:
1. 120 VAC loads only — one load with a maximum
total wattage requirement equal to the generator’s rated power output (in watts), and 120V across the generator output terminals. Figure 1.1, page 6, shows the generator lead wire connections for 120VAC ONLY.
2. 120/240 VAC loads — one load with a maximum
total wattage requirement equal to the generator’s rated power output, and 240V across the genera­tor output terminals; or two seperate loads, each with a maximum total wattage requirement equal to half of the generator’s rated power output (in watts), and 120V across the generator output ter­minals. Figure 1.2, page 6, shows the generator lead wire connections for 120/240 VAC loads. Also refer to section 2.1.4 Line Breakers for cir­cuit breaker ratings.
This procedure should be done by a Generac Authorized Service Dealer or other qualified installer.
!
DANGER
6 Generac®Power Systems, Inc.
Section 1 – General Information
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
Figure 1.1 – Connection for 120 Volts Only
Figure 1.2 - Connection for 120/240 Volts
1.6 SPECIFICATIONS
1.6.1 FUEL REQUIREMENTS (GASOLINE)
This generator is equipped with a gasoline fuel system as standard equipment. Specific installations may pro­vide either a separate fuel tank for the generator, or the generator may “share” the vehicle engine’s fuel tank.
1.6.1.1 Fuel Consumption (gph/lbs.ph)
NOTE
Some installations using a “shared” fuel tank may have a generator fuel pickup tube that is shorter than the vehicle engine’s pickup tube. Such an arrangement causes the generator engine to “run out of gas” while adequate fuel for the vehicle remains in the tank.
To reduce lead and carbon deposits use high quality UNLEADED gasoline with the generator. Leaded REGULAR grade gasoline is an acceptable substitute.
NOTE:
Using unleaded gasoline contributes to longer engine valve life by reducing lead and carbon deposits.
Generac does not recommend using any gasoline containing alcohol (such as “gasohol”). If you use any gasoline containing alcohol, it must not contain more than 10 percent ethanol, and it must be removed from the generator during storage. Do NOT use any gasoline containing methanol. If you use gasoline with alcohol, inspect more frequently for fuel leaks and other abnormalities.
1.6.2 ENGINE OIL REQUIREMENTS
Use only high quality detergent oil classified “For Service SF” and with an oil viscosity rating of SAE 10W-30 oil. Do not pour in any additives to the rec­ommended oil. Engine crankcase capacity is 1.8 liters or 1.9 quarts with oil filter change. See Section
3.2 on page 11 for oil level check and filing proce-
dures.
!
1.6.3 GENERATOR SPECIFICATIONS
SERIES QP55G QP55LP QP65G QP65LP QP75G QP75LP
Rotor RPM 3600 3600 3600 3600 3600 3600 Rotor Poles 2 2 2 2 2 2 Engine RPM 2200 2200 2571 2571 2571 2571 Rated Max. Continuous AC Output Watts* 5500 5500 6500 6500 7500 7500 Voltage* 120 120 120 120 120 120 Rated Max. Continuous Current Amps (240V) 45.8 (22.9) 45.8 (22.9) 54.1 (27.0) 54.1 (27.0) 62.5 (31.2) 62.5 (31.2) Phase 1 1 1 1 1 1 Frequency 60 Hertz 60 Hertz 60 Hertz 60 Hertz 60 Hertz 60 Hertz Battery Charging Current (Max.) 2 amps 2 amps 2 amps 2 amps 2 amps 2 amps Weight 326 lbs. 329 lbs. 328 lbs. 331 lbs. 330 lbs. 333 lbs. Length 33.7 in. 33.7 in. 33.7 in. 33.7 in. 33.7 in. 33.7 in. Width 22.2 in. 22.2 in. 22.2 in. 22.2 in. 22.2 in. 22.2 in. Height 19.6 in. 19.6 in. 19.6 in. 19.6 in. 19.6 in. 19.6 in.
* All units are reconnectable to 120 and/or 240 volts, dual voltage output. Units are not listed per RVIA/ANSI when reconnected for dual voltage output
Model 10% Load 50% Load 100% Load
QuietPact 55G 0.51 0.73 0.97 QuietPact 65G 0.51 0.76 1.07 QuietPact 75G 0.51 0.80 1.28
T1
RED
T2
WHITE
T3
BLACK
STATOR WINDINGS
CB1
CB2
GROUNDED NEUTRAL
Generac®Power Systems, Inc. 7
Section 2 – Operation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
1.6.4 ENGINE SPECIFICATIONS
Type of Engine
QUIETPACT 55/65/75 ................................................GT-760
Cooling Method ........................................................Air-cooled
Rated Horsepower
QUIETPACT 55..............................................27 at 3600 rpm
QUIETPACT 65..............................................27 at 3600 rpm
QUIETPACT 75..............................................27 at 3600 rpm
Displacement
QUIETPACT 55/65/75....................................................760cc
Compression Ratio........................................................8.6 to 1
Cylinder Block ..........................Aluminum w/Cast Iron Sleeve
Type of Governor ..............................Mechanical, Fixed Speed
Engine Governor Speed
QUIETPACT 55 ......................................................2200 rpm
QUIETPACT 65/75 ..................................................2571 rpm
Air Cleaner ........................Paper Element w/Foam Precleaner
Starter ........................................................12-volt DC Electric
Ignition System ......................Solid-state w/Flywheel Magneto
Recommended Spark Plug
Champion ..................................................................RC12YC
AC....................................................................................R45S
Fram Autolite ......................................................................65
Spark Plug Gap........................................0.030 inch (0.8 mm)
Recommended Min. Battery ............400 Cold Cranking Amps
1.6.5 EMISSIONS COMPLIANCE PERIOD
For nonhandled engines the Emissions Compliance Period referred to on the Emissions Compliance Label indicates the number of operating hours for which the engine has been shown to meet Federal emission requirements.
• For engines less than 225 cc displacement,
Category C=125 hours, B=250 hours, and A=500 hours.
• For engines of 225 cc or more, Category C=250
hours, B=500 hours, and A=1000 hours.
2.1 GENERATOR CONTROL PANEL
The following features are mounted on the generator control panel (Figure 2.1):
2.1.1 FUEL PRIMER
Before starting a cold engine (if it has not been start­ed in more than two weeks), you must press this switch for approximately ten seconds to bring fuel from the tank to the fuel pump. This rocker type switch springs back into its original position when you release it.
2.1.2 START/STOP SWITCH
To crank and start the engine, hold this switch in the START position. Release the switch when the engine starts. To stop an operating engine, press and hold the switch in the STOP position until the engine shuts off. The switch center position is the RUN position.
2.1.3 7.5 AMP FUSE
The fuse protects the engine’s DC control circuit against electrical overload. If the fuse element has melted open due to overloading, the engine cannot be cranked. If you must replace the fuse, use only an identical 7.5 amp replacement fuse.
2.1.4 LINE BREAKERS
Protects generator’s AC output circiut against overload, i.e., prevents unit from exceeding wattage/amperage capacity. The circuit breaker rat­ings are as follows:
NOTE:
If this generator has been reconnected for dual voltage AC output (120/240 volts), you can install line breakers having an amperage rating that is different than that stated above. The replacement line breakers consist of two separate breakers with a connecting piece between the breaker handles (so that both breakers will operate at the same time). If the unit is reconnected for dual voltage, it is no longer RVIA or CSA listed.
Figure 2.1 – Typical Control Panel
S
O
S
U
S
5
CO
R
C
U
C
U
S
S
.
.
.
(
)
Model Circuit Breaker 1 Circuit Breaker 2 240 Volt
QuietPact 55 30A 20A 25A 2P QuietPact 65 30A 30A 30A 2P QuietPact 75 35A 35A 35A 2P
NTROL CENTE
IF GENERATOR DOES NOT START
REMOVE AND INSPECT FUSE
SEE OWNER'S MANUAL TROUBLE SHOOTING GUIDE.
PRESS PRIME SWITCH FOR 10 SECOND
BEFORE STARTING. WHEN STARTING, DO NOT PRESS
TART BUTTON LONGER THEN 15 SECONDS PER ATTEMPT
E0580 REV. B
8 Generac®Power Systems, Inc.
Section 2 – Operation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
2.2 OPTIONAL REMOTE
START/STOP PANEL
A remote mounted Start/Stop Panel (Figure 2.2) is available that allows you to start and stop the gener­ator engine conveniently from inside the vehicle. The remote panel includes a Start/Stop switch, hourme­ter, generator run lamp and a wire harness.
Figure 2.2 — Optional Remote Panel
(Models 004057 and 004184)
2.3 AUTOMATIC CHOKE
This engine is equipped with an automatic choke that consists of two main components: a choke solenoid and prechoke.
2.3.1 CHOKE SOLENOID
During engine cranking (Start/Stop switch at START), a solid-state choke module signals the choke solenoid to activate and cycle (choke on/choke off) until the engine starts. The choke solenoid thus opens and closes the carburetor choke valve only when the engine is cranking. When the engine starts, the choke stops cycling.
2.3.2 PRECHOKE
The choke system also has a temperature-sensitive metal strip that adjusts choke valve angle according to ambient temperatures (i.e., in cold ambient tem­peratures, choke valve closes more). Once the engine starts, an element heats the temperature-sensitive strip to a normal operating condition, opening the choke valve. This may take about three minutes in cooler weather.
2.4 BEFORE STARTING THE ENGINE
NOTE:
Instructions and information in this manual assume the generator has been properly installed, connected, serviced, tested and adjusted by a qualified installation technician or installation contractor.
2.4.1 INSTALLATION
Generator installation must have been properly com­pleted so it complies with all applicable codes, stan­dards and regulations and with the manufacturer's recommendations.
2.4.2 ENGINE LUBRICATION
Have the engine crankcase properly serviced with the recommended oil before starting. Refer to Section
1.6.3 (Page 6) and Sections 3.1 and 3.2 (Page 11) for oil servicing procedures and recommendations.
Any attempt to crank or start the engine before you have properly serviced it with the recom­mended oil may result in an engine failure.
2.4.3 FUEL SUPPLY
The engine must have an adequate supply of proper fuel to operate. Before starting it, check that sufficient fuel is available.
NOTE:
Depending on the installation, the generator may have either a separate fuel tank, or it may “share” the vehicle engine’s fuel tank.
2.4.4 COOLING AND VENTILATING AIR
Air inlet and outlet openings in the generator com­partment must be open and unobstructed for contin­ued proper operation. Without sufficient cooling and ventilating airflow, the engine/generator quickly over­heats, which causes it to shut down and may damage the generator.
2.4.5 ENGINE EXHAUST GAS
Before starting the generator engine, you should be sure there is no way for exhaust gases to enter the vehicle interior and endanger people or animals. Close windows, doors and other openings in the vehi­cle that, if open, might permit exhaust gases to enter the vehicle.
!
Generac®Power Systems, Inc. 9
Section 2 – Operation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
The generator engine releases DEADLY carbon monoxide gas through its exhaust system. This dangerous gas, if breathed in sufficient concen­trations, can cause unconsciousness or even death. Never operate the generator set with the vehicle inside any garage or other enclosed area. DO NOT OPERATE THE GENERATOR IF THE EXHAUST SYSTEM IS LEAKING OR HAS BEEN DAMAGED. SYMPTOMS OF CARBON MONOX­IDE POISONING ARE (a) inability to think coher­ently, (b) nausea, (c) vomiting, (d) twitching muscles, (e) throbbing temples, (f) dizziness, (g) headaches, (h) weakness, and (i) sleepiness. IF YOU EXPERIENCE ANY OF THESE SYMPTOMS, MOVE INTO FRESH AIR IMMEDIATELY. IF SYMP­TOMS PERSIST, GET MEDICAL HELP. Shut down the generator and do not operate it until it has been inspected and repaired.
Never sleep in the vehicle while the genset is running unless the vehicle has a working carbon monoxide detector. The exhaust system must be installed in accordance with the genset installa­tion manual. Make sure there is ample fresh air when operating the genset in a confined area.
2.5 STARTING THE GENERATOR
NOTE:
Read the vehicle manufacturer’s instructions. The owner/operator should become familiar with the vehicle in which this generator is installed. Differences exist between vehicles. For example, some vehicles may use a transfer switch to isolate dockside power from the generator, while other vehicles may use an isolating receptacle. Some vehicles may be equipped with a DC converter which allows the generator to power certain DC lighting and other DC loads.
To crank and start the generator engine, proceed as follows:
1. Turn OFF electrical loads using the means pro-
vided in your vehicle (such as a main line circuit breaker or transfer switch).
NOTE:
If starting from the generator control panel, turn OFF loads by setting the generator’s main circuit breaker to the OFF (or open) position. If starting from a remote panel, turn OFF loads using the means provided in the vehicle (such as a main cir­cuit breaker). Electrical load circuits will be turned ON after the generator has started, stabi­lized and warmed up.
2. If you have not started the engine in more than two weeks, press the Fuel Pump Primer switch and hold it for about 10 seconds. However, if the engine is warm, skip Step 2.
3. To crank and start the engine, hold the start/stop switch at START. Release the switch when the engine starts.
If the engine does not start after it has been cranking for 15 seconds, release the Start/Stop switch and wait 1 minute before trying again. Holding the switch for longer than 15 seconds can damage the starter motor.
4. Let the engine run at no-load for a few minutes to stabilize and warm up.
5. Turn ON electrical loads using the means provided (such as a main circuit breaker or transfer switch).
2.6 STOPPING THE GENERATOR
1. Turn OFF all electrical loads using the means provided (such as a main circuit breaker or transfer switch).
2. Let generator run at no-load for a few minutes, to stabilize internal engine generator temperatures.
3. Place the Start/Stop switch in its STOP position. The engine will come to a complete stop.
2.7 APPLYING LOADS TO GENERATOR
When applying electrical loads to the generator, observe these guidelines:
• Before applying electrical loads, let the generator
stabilize and warm up for a minute or two.
• DO NOT overload the generator.
2.7.1 LETTING THE ENGINE STABILIZE
The generator supplies correct rated voltage only at the proper governed speed. Some electrical appli­ances may be extremely sensitive to voltage. Incorrect voltages can damage such appliances.
If electrical loads are applied at reduced operating speeds, such loads imposed on the engine when suf­ficient power is not available may shorten engine life. Never turn ON electrical loads until after the genera­tor engine has started and stabilized at no-load.
!
DANGER
!
DANGER
!
10 Generac®Power Systems, Inc.
Section 2 – Operation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
2.7.2 DO NOT OVERLOAD THE GENERATOR
You can read the rated wattage/amperage capacity of your generator on the generator data decal (see Section 1.1 on Page 4).
Applying electrical loads in excess of the unit’s rated capacity will cause the engine/generator to automati­cally shut down.
To avoid overloading, add up the wattage of all con­nected electrical lighting, appliance, tool and motor loads. This total should not be greater than the gen­erator’s rated wattage capacity.
• Most lighting, appliance, tool and motor loads indi­cate their required watts on their nameplate or data plate. For light bulbs, simply note the wattage rating of the bulb.
• If a load does not show its rated wattage, multiply that load’s rated VOLTS times AMPS to obtain WATTS.
• Induction type motors (such as those that run the vehicle’s furnace fan, refrigerator, air conditioner, etc.) need about 2-1/2 times more watts of power for starting than for running (for a few seconds during motor starting). Be sure to allow for this when connecting electrical loads to the generator. First, figure the watts needed to start electric motors in the system. To that figure, add the run­ning wattages of other items that will be operated by the generator.
• Do not apply heavy electrical loads for the first two or three hours of operation.
2.8 PROTECTION SYSTEMS
2.8.1 LOW OIL PRESSURE SWITCH
This switch (Figure 2.3) has normally closed (N.C.) contacts that are held open by engine oil pressure during cranking and operating. Should oil pressure drop below a preset level, switch contacts close, and the engine automatically shuts down. The unit should not be restarted until oil is added.
2.8.2 HIGH TEMPERATURE SWITCH
This switch (Figure 2.3), which has normally open (N.O.) contacts, is mounted near the oil filter. The contacts close if the temperature should exceed approximately 270º F (132º C) for gasoline models, and 284° F (140° C) for LP models, initiating an engine shutdown.
Figure 2.3 – Low Oil Pressure and
High Temperature Switches
2.8.3 FIELD BOOST
The Controller Circuit Board houses a field boost diode and resistor that are not part of the automatic choke circuit. These two components are part of a “field boost” circuit (Figure 2.4). During engine cranking only, a positive DC (battery) voltage is deliv­ered through a diode, resistor, brushes, slip rings, and the generator rotor. Application of this voltage to the rotor “flashes the field” whenever it is started. Flashing of the field each time the generator starts makes sure that a sufficiently strong magnetic field is available to produce “pickup” voltage in the stator windings.
Figure 2.4 – Field Boost Circuit
Generac®Power Systems, Inc. 11
Section 3 – Maintenance
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
2.8.4 OVERVOLTAGE PROTECTION
A solid-state voltage regulator (Figure 2.5) controls the generator’s AC output voltage. This regulator sup­plies an excitation current to the rotor. By regulating the rotor’s excitation current, the strength of its mag­netic field is regulated and, in turn, the voltage deliv­ered to connected electrical loads is controlled. When the AC frequency is 60 Hertz, voltage is regulated at 115 volts.
Figure 2.5 – Solid State Voltage Regulator
The voltage regulator also incorporates a “voltage surge protection circuit.” This circuit prevents trou­blesome surges in the generator AC output voltage. Voltage surge is a common cause of damage to elec­tronic equipment.
2.8.5 25-HOUR BREAK-IN PERIOD
The first 25 hours of operation is the break-in period for the generator. Properly breaking in the generator is essential to minimize fuel consumption and pro­vide maximum engine performance. During this 25­hour break-in period, follow this procedure:
• Run the unit at varying electrical loads to help seat the engine piston rings properly.
• Check the engine oil level frequently. Add oil if needed. It is normal for the generator engine to consume more oil than is normal until the piston rings have properly seated.
• For the 75-hour operation following the break-in period, avoid light electrical loads. Load the generator at 50 percent (or more) of its rated wattage capacity. Repeated light loads during these 75 hours can cause improper seating of engine pis­ton rings, resulting in blowby and high oil con­sumption.
• After operating the unit for 25 hours, complete the tasks recommended under Section 2.8.6.
2.8.6 25-HOUR CHECK-UP
After the 25-hour break-in period, contact a Generac Authorized Service Dealer for the following mainte­nance. (The vehicle owner is responsible for any
charges relating to normal unit maintenance.)
• Change the engine crankcase oil and oil filter.
• Check all fluid levels.
• Inspect the cooling and ventilation openings.
• Check the engine ignition system.
• Inspect the entire electrical system.
• Inspect the engine exhaust system.
2.8.7 OPERATION IN HIGH GRASS OR BRUSH
Never operate the generator while the vehicle is parked over high grass, weeds, brush, leaves or any other combustible substance. Such materials can ignite and burn from the heat of the exhaust system. The generator exhaust system becomes extremely hot dur­ing operation and remains hot for a long time after it has shut down.
3.1 CHECKING THE ENGINE OIL LEVEL
For oil capacities and requirements, see “Engine Oil Requirements,” Section 1.6.2 (Page 6). Check the engine crankcase oil level at least every eight hours of operation, or before you use it. To check the engine oil level, proceed as follows (see Figure 3.1):
1. Be sure the generator is as level as possible.
2. Remove the dipstick and wipe it dry with a clean,
lint-free cloth.
3. Install and tighten the dipstick cap; then, remove
it again. The oil level should be at the dipstick “Full” mark.
4. If necessary, remove the oil fill cap on the rocker
cover and slowly add oil until it reaches the dip­stick “Full” mark. DO NOT FILL ABOVE THE “FULL” MARK.
Never operate the engine with the oil level below the “Add” mark on the dipstick. Doing this could damage the engine.
5. Install and tighten the oil fill cap and the dipstick
before operating the engine.
!
12 Generac®Power Systems, Inc.
Section 3 – Maintenance
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
3.2 CHANGING THE ENGINE OIL AND/OR OIL FILTER
• Change the engine oil after the first 25 hours of
operation (after the 25-hour break-in period, see Section 2.8.5, Page 10). Thereafter, change the oil every 100 operating hours. Change the oil more frequently if operating consistently under heavy load or at high ambient temperatures.
• Change the engine oil filter after the first 25 hours
of operation, and every 100 operating hours there­after.
To change the oil and/or oil filter, proceed as follows:
1. Run the engine until it is thoroughly warmed up
(at least five minutes) then shut OFF the engine.
2. With the engine still warm from running, remove
the oil drain plug (Figure 3.1). Drain the oil into a suitable container.
Figure 3.1 — Oil Dipstick/Fill Tube and
Location of Oil Drain Plug
3. After the oil has drained, replace the oil drain
plug. (If only changing the oil, go to step 7.)
4. With the oil drained, remove the old oil filter by
turning it counterclockwise (Figure 3.2).
5. Apply a light coating of clean engine oil to the gas-
ket of the new filter.
6. Screw the new filter on by hand until its gasket
lightly contacts the oil filter adapter. Then, tight­en the filter an additional 3/4 to one turn.
7. Remove the dipstick and fill crankcase with the
proper type and amount of recommended oil (see Section 1.6.2, Page 6). The engine crankcase can hold about 1.8 liters or 1.9 quarts with oil filter change. DO NOT FILL ABOVE THE “FULL” MARK.
8. Install and tighten the dipstick before operating
the engine.
9. Start the engine and check for leaks.
Figure 3.2 — Engine Oil Filter
NOTE:
Check the oil level and fill to the “FULL” mark after checking for leaks. The filter will retain some oil.
3.3 MAINTAINING THE ENGINE AIR CLEANER
3.3.1 CLEANING THE FOAM PRECLEANER
Clean and re-oil the foam precleaner every three months or every 25 hours of operation, whichever occurs first. Service the foam precleaner more fre­quently if operating the generator in extremely dusty or dirty conditions. Use the following procedure (Figure 3.3):
1. Turn the knob counterclockwise to loosen.
2. Remove the cover, foam precleaner and paper fil-
ter.
3. Remove the foam precleaner from the cover.
4. Wash the foam precleaner in liquid detergent and
water.
5. Wrap the foam precleaner in a clean cloth and
gently squeeze it dry.
6. Saturate the foam precleaner in clean engine oil.
Gently squeeze it in a clean cloth to remove excess oil and to distribute oil (DO NOT TWIST).
7. Install the foam precleaner into the cover, fol-
lowed by the paper filter. Tabs at edges of paper filter must lock into slots on cover.
8. Install the cover, foam precleaner and paper filter.
9. Replace knob to retain the filter in place.
Oil Dipstick
Oil Drain Hose
Section 3 – Maintenance
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
Figure 3.3 – Engine Air Cleaner
3.4 CHECKING THE ENGINE SPARK PLUG
Clean the spark plug and reset the spark plug gap every 100 hours of operation.
1. Clean the area around the base of the spark plug
to keep dirt and debris out of the engine. Clean by scraping or washing using a wire brush and com­mercial solvent. Do not blast the spark plug to clean.
2. Remove the spark plug and check the condition.
Replace the spark plug if worn or if reuse is ques­tionable.
3. Check the spark plug gap using a wire feeler
gauge. Adjust the gap to 0.030 inch (0.76 mm) by carefully bending the ground electrode (Figure 3.4).
Figure 3.4 – Setting the Spark Plug Gap
Sparking can occur if the wire terminal does not fit firmly on the spark plug terminal end. If necessary, re-form the wire terminal to obtain a tight fit.
3.5 FUEL FILTER (GASOLINE ONLY)
Remove and replace the fuel filter (Figure 3.5) once each year or every 400 hours of operation, whichever comes first.
Figure 3.5 – Fuel Filter
3.6 CLEAN SPARK ARRESTOR
The engine exhaust muffler has a spark arrestor screen. Inspect and clean the screen every 50 hours of operation or once each year, whichever comes first.
NOTE:
If you use your generator on any forest-covered, brush-covered or grass-covered unimproved land, it must equipped with a spark arrestor. The spark arrestor must be maintained in good condition by the owner/operator.
Clean and inspect the spark arrestor as follows:
• Remove the screen retaining bracket by removing the screw.
• Slide the spark arrestor screen out from the tail pipe.
• Inspect screen and replace if torn, perforated or otherwise damaged. DO NOT USE a defective screen. If screen is not damaged, clean it with com­mercial solvent.
• Replace the screen and the retaining bracket.
Figure 3.6 - Spark Arrestor
g
ut
O
S
A
at
g
ut
t
Generac®Power Systems, Inc. 13
TO FUEL PUMP
CUSTOMER FUEL CONNECTION
FUEL FILTER
P/N 0E0907
P/N 0D5133A
P/N 0D5133
P/N 045764
Fl
ffset
Compartmen
Win N
Win N
TAILPIPE
!
RETAINER
SPARK ARRRESTOR SCREEN
RETAINING SCREW
14 Generac®Power Systems, Inc.
3.7 CLEANING THE GENERATOR
Keep the generator set as clean and dry as possible. Protect the unit against excessive dust, dirt, corrosive vapors, road splash, etc. Permitting dirt and mois­ture to accumulate on generator windings will have an adverse effect on the insulation resistance of those windings.
When moisture is allowed to remain in contact with windings, some of the moisture will be retained in voids and cracks in the insulation. This causes a reduced insulation resistance and will eventually cause problems. Dirt will make the problem worse, since dirt tends to hold moisture in contact with windings. Salt (as from sea air) also will worsen the problem since it tends to absorb moisture from the air. Salt and moisture, when combined, form a good electrical conductor.
Do NOT use a forceful spray of water to clean the generator. Water will enter the generator interior and cause problems, and may also cont­aminate the generator fuel system.
3.8 BATTERY MAINTENANCE
All lead-acid batteries will discharge when not in use. The generator battery should be inspected as follows:
3.8.1 WEEKLY
• Inspect the battery posts and cables for tightness and corrosion. Tighten and clean as necessary.
• Check the battery fluid level of unsealed batteries and, if necessary, fill with Distilled Water Only. Do not use tap water in batteries.
3.8.2 EVERY SIX MONTHS
• Have the state of charge and condition checked. This should be done with an automotive-type bat­tery hydrometer.
NOTE:
Servicing of the battery is to be performed or supervised by personnel knowledgeable of batter­ies and the required precautions. Keep unautho­rized personnel away from batteries.
Damage will result if the battery connections are made in reverse.
Do not dispose of the battery in a fire. The battery is capable of exploding. Storage batter­ies give off explosive hydrogen gas. This gas can form an explosive mixture around the bat­tery for several hours after charging. The slightest spark can ignite the gas and cause an explosion. Such an explosion can shatter the battery and cause blindness or other injury. Any area that houses a storage battery must be properly ventilated. Do not allow smoking, open flame, sparks, or any spark producing tools or equipment near the battery. Discharge static electricity from your body before touch­ing the battery by first touching a grounded metal surface.
A battery presents a risk of electrical shock and high short circuit current. The following precautions are to be observed when working on batteries:
• Remove watches, rings or other metal objects;
• Use tools with insulated handles;
• Wear rubber gloves and boots;
• Do not lay tools or metal parts on top of the battery;
• Disconnect any charging source prior to connecting or disconnecting battery terminals; and
• Do not use any jumper cables or booster battery to crank and start the generator engine. If any battery has discharged, remove it for recharging.
Do not open or mutilate the battery. Released electrolyte has been known to be harmful to the skin and eyes, and to be toxic.
The electrolyte is a dilute sulfuric acid that is harmful to the skin and eyes. It is electrically conductive and corrosive. The following procedures are to be observed:
• Wear full eye protection and protective clothing;
• Where electrolyte contacts the skin, wash it off immediately with water;
• Where electrolyte contacts the eyes, flush thoroughly and immediately with water and seek medical attention; and
• Spilled electrolyte is to be washed down with an acid neutralizing agent. A common practice is to use a solution of 1 pound (500 grams) bicarbonate of soda to 1 gallon (4 liters) or water. The bicar­bonate of soda solution is to be added until the evidence of reaction (foaming) has ceased. The resulting liquid is to be flushed with water and the area dried.
!
!
!
Section 3 – Maintenance
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
DANGER
Generac®Power Systems, Inc. 15
3.9 MAJOR SERVICE MANUAL
To obtain a service manual for your generator, con­tact your nearest Generac Authorized Service Dealer. Make sure to identify your MODEL NUMBER and SERIES. Manuals can be obtained from the internet website (www.generac.com) or a service dealer.
3.10 DRIVE BELT
The engine drives the generator rotor by means of a pulley and drive belt arrangement. Drive belt tension was properly adjusted before the unit was shipped from the factory. If you suspect that drive belt tension is incorrect, contact a Generac Authorized Service Dealer.
3.11 EXERCISING THE GENERATOR
Generac recommends that you start and operate the generator at least once every seven days. Let the unit run for at least 30 minutes to “exercise” the engine.
3.12 OUT OF SERVICE PROCEDURE
3.12.1 REMOVAL FROM SERVICE
If you cannot exercise the generator every seven days, and it is to be out of service longer than 30 days, pre­pare the generator for storage as follows:
1. Start the engine and let it warm up.
2. Close the fuel shutoff valve in the fuel supply line and allow the unit to shut down.
3. While the engine is still warm from running, drain the oil completely. Refill the crankcase with SAE 5W-30 oil having API classification “For Service SF.”
4. Attach a tag to the engine indicating the viscosity and classification of the oil in the crankcase.
5. Remove the spark plug and pour two or three tablespoons of clean, fresh engine oil into the spark plug threaded openings. Reinstall and tighten the spark plug.
6. Remove the battery and store it in a cool, dry room on a wooden board. Never store the battery on any concrete or earthen floor.
7. Clean and wipe the entire generator.
3.12.2 RETURN TO SERVICE
To return the unit to service after storage, proceed as follows:
1. Check the tag on the engine for oil viscosity and classification. Verify that the correct recommend­ed oil is used in the engine (see Section 1.5.4, Page 6). If necessary, drain and refill with the proper oil.
2. Check the state of the battery. Fill all cells of unsealed batteries to the proper level with distilled water. DO NOT USE TAP WATER IN THE BAT­TERY. Recharge the battery to 100 percent state of charge, or, if defective, replace the battery.
3. Clean and wipe the entire generator.
4. Reconnect the battery. Observe battery polarity. Damage may occur if the battery is connected incorrectly.
5. Turn OFF all electrical loads. Add fuel if neces­sary and then start the engine.
6. Allow the unit to warm up thoroughly.
7. Apply electrical loads to at least 50 percent of the unit’s rated wattage capacity.
8. When the engine is thoroughly warmed up, shut it down.
9. Your generator is now ready for service.
3.13 RV GENERATOR SERVICE
INTERVAL
QUIETPACT 55/65/75:
50 Hours ................................Clean Spark Arrestor
1st 50 Hours,
then every 500 Hours................Adjust Valve Lash
100 Hours..........................Change Engine Oil/Filter
100 Hours ..................................Clean Air Pre-filter
100 Hours ................................Inspect Spark Plugs
250 Hours ............Replace Paper Air Filter Element
400 Hours ..................................Replace Fuel Filter
500 Hours................................Replace Spark Plugs
Section 3 – Maintenance
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
16 Generac®Power Systems, Inc.
Section 4 – Notes
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
PART II –
INSTALLATION
INSTRUCTIONS
ONLY QUALIFIED ELECTRICIANS OR CONTRACTORS
SHOULD ATTEMPT INSTALLATION!!
DANGER
18 Generac®Power Systems, Inc.
Safety Rules
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
NOTICE TO INSTALLER
These Installation Instructions have been published by Generac to aid in the installation of the products described in this manual. Generac assumes that installation personnel are familiar with the proce­dures for installing such products, or similar prod­ucts that Generac manufactures. Generac also assumes that personnel have been trained in the rec­ommended installation procedures for these prod­ucts and that such training includes (a) use of com­mon hand tools, (b) use of special Generac tools, and (c) use of any tools and/or equipment from other sup­pliers.
Generac cannot possibly know of and advise the recreational vehicle trade of all conceivable methods, procedures or techniques by which to perform an installation. Nor can Generac anticipate every possi­ble hazard that might result from each installation method, procedure or technique. Generac has not undertaken any such wide evaluation. Therefore, people who use a method, procedure or technique that Generac does not specifically recommend must first completely satisfy themselves that their safety, the safety of the vehicle's occupants and the product's safety is not endangered by the method, procedure or technique selected.
Information, illustrations, specifications, etc., con­tained in these Installation Instructions are based on the latest information available at the time of publi­cation. Every effort has been expended to be sure that such data is both accurate and current. However, the manufacturer reserves the right to change, alter or otherwise improve this product at any time without prior notice.
Despite the safe design of this generator, operating this equipment imprudently, neglecting its maintenance or being careless can cause possible injury or death. Permit only responsible and capable persons to operate or maintain this equipment.
Potentially lethal voltages are generated by these machines. Ensure all steps are taken to render the machine safe before attempting to work on the generator.
Parts of the generator are rotating and/or hot during operation. Exercise care near running generators.
GENERAL HA
ZARDS
• For safety reasons, Generac recommends
that the installation, initial start-up and mainte­nance of this equipment is carried out by a Generac Authorized Service Dealer.
• The generator engine releases DEADLY carbon
monoxide gas through its exhaust system. This dangerous gas, if breathed in sufficient concentra­tions, can cause unconsciousness or even death. Never operate the generator set with the vehicle inside any garage or other enclosed area. DO NOT OPERATE THE GENERATOR IF THE EXHAUST SYSTEM IS LEAKING OR HAS BEEN DAMAGED. SYMPTOMS OF CARBON MONOXIDE POISON­ING ARE (a) inability to think coherently, (b) nau­sea, (c) vomiting, (d) twitching muscles, (e) throb­bing temples, (f) dizziness, (g) headaches, (h) weakness, and (i) sleepiness. IF YOU EXPERI­ENCE ANY OF THESE SYMPTOMS, MOVE INTO FRESH AIR IMMEDIATELY. IF SYMPTOMS PER­SIST, GET MEDICAL HELP. Shut down the gener­ator and do not operate it until it has been inspect­ed and repaired.
• Never sleep in the vehicle while the genset is run-
ning unless the vehicle has a working carbon monoxide detector. The exhaust system must be installed in accordance with the genset installation manual. Make sure there is ample fresh air when operating the genset in a confined area.
• Keep hands, feet, clothing, etc., away from drive
belts, fans, and other moving or hot parts. Never remove any drive belt or fan guard while the unit is operating.
• Adequate, unobstructed flow of cooling and venti-
lating air is critical to correct generator operation and is required to expel toxic fumes and fuel vapors from the generator compartment. Without sufficient cooling airflow, the engine/generator quickly overheats, which causes serious damage to the generator. Do not alter the installation or per­mit even partial blockage of ventilation provisions, as this can seriously affect safe operation of the generator.
• When working on this equipment, remain alert at
all times. Never work on the equipment when you are physically or mentally fatigued.
• Before performing any maintenance on the genera-
tor, disconnect its battery cables to prevent acci­dental start up. Disconnect the cable from the bat­tery post indicated by a NEGATIVE, NEG or (–) first. Reconnect that cable last.
!!!
DANGER: For fire safety, installation of a generator into a recreational vehicle must comply strictly with article 551, NFPA 70; ANSI C1-1975; AND, ANSI A119.2-1975/NFPA 501C “Standard for Recreational Vehicles” (Part 3, “Installation of Electrical Systems”). In addition, installation must comply with the manufacturer’s instructions and recommendations.
!
DANGER
!
Generac®Power Systems, Inc. 19
Safety Rules
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
• Never use the generator or any of its parts as a step. Stepping on the unit can stress and break parts, and may result in dangerous operating con­ditions from leaking exhaust gases, fuel leakage, oil leakage, etc.
• Never insert any tool or other object through open­ings in the generator interior, even if the unit is not running. You might seriously injure yourself or damage the equipment.
ELECTRICAL HAZAR
DS
• The generator covered by this manual produces dangerous electrical voltages and can cause fatal electrical shock. Avoid contact with bare wires, ter­minals, connections, etc., while the unit is running. Ensure all appropriate covers, guards and barriers are in place before operating the generator. If you must work around an operating unit, stand on an insulated, dry surface to reduce shock hazard.
• Do not handle any kind of electrical device while standing in water, while barefoot, or while hands or feet are wet. DANGEROUS ELECTRICAL SHOCK MAY RESULT.
• During installation onto the vehicle, properly ground (bond) the generator either by solid mount­ing to the vehicle frame or chassis, or by means of an approved bonding conductor. DO NOT connect the bonding conductor to any generator part that might be removed or disassembled during routine maintenance. If the grounding conductor must be replaced, use only a flexible conductor that is of No. 8 American Wire Gauge (AWG) copper wire minimum.
• If the vehicle electrical circuits can be powered by any other source of electricity (such as a “dockside” power receptacle), there must be no possibility of connecting the different power sources to the vehi­cle circuits at the same time. The dockside (utility) power source must be positively isolated from the vehicle circuits whenever the generator is operating. Failure to isolate the vehicle circuits from the dock­side power supply when the generator is running may result in damage to the generator or serious injury or death to dockside (utility) power workers due to backfeed of electrical energy.
• In case of accident caused by electric shock, imme­diately shut down the source of electrical power. If this is not possible, attempt to free the victim from the live conductor. AVOID DIRECT CONTACT WITH THE VICTIM. Use a nonconducting implement, such as a rope or board, to free the victim from the live conductor. If the victim is unconscious, apply first aid and get immediate medical help.
• Never wear jewelry when working on this equip­ment. Jewelry can conduct electricity resulting in electric shock, or may get caught in moving com­ponents causing injury.
FIRE HAZARDS
• For fire safety, the generator must be installed and maintained properly. Installation always must comply with applicable codes, standards, laws and regulations. Adhere strictly to local, state and national electrical and building codes. Comply with regulations the Occupational Safety and Health Administration (OSHA) has established. Also, ensure that the generator is installed in accordance with the manufacturer’s instructions and recommendations. Following proper installa­tion, do nothing that might alter a safe installation and render the unit in noncompliance with the aforementioned codes, standards, laws and regu­lations.
• Keep a fire extinguisher in the vehicle at all times. Extinguishers rated “ABC” by the National Fire Protection Association are appropriate for use on the recreational vehicle generator electrical system. Keep the extinguisher properly charged and be familiar with its use. If you have any question per­taining to fire extinguishers, consult your local fire department.
EXPLOSION HAZARDS
• Do not smoke around the generator. Wipe up any fuel or oil spills immediately. Ensure that no com­bustible materials are left in the generator com­partment, or on or near the generator, as FIRE or EXPLOSION may result. Keep the area surround­ing the generator clean and free from debris.
• Gasoline is extremely FLAMMABLE and its vapors are EXPLOSIVE. Do not permit smoking, open flame, sparks or any source of heat in the vicinity while handling gasoline. Comply with all laws gov­erning the storage and handling of gasoline.
• Fuel lines must be properly installed and fastened, and free of leaks. There must be no possibility of gasoline vapors entering the vehi­cle interior.
• You are required to install an approved, flexible, nonconductive fuel line between the generator fuel connection point and rigid fuel lines.
• If the generator is equipped with a liquid propane (LP) gas fuel system, install the unit so it complies with all codes, standards and regulations pertain­ing to such systems. LP gas is highly explosive. The gas tends to settle in low areas where even the slightest spark can ignite it and cause an explo­sion. Do not allow gas vapors to enter the vehicle.
20 Generac®Power Systems, Inc.
5.1 PURPOSE AND SCOPE OF THE INSTALLATION INSTRUCTIONS
These Installation Instructions have been prepared especially for the purpose of familiarizing installers and owners of the applicable equipment with the product's installation requirements. Give serious consideration to all information and instructions in the manual, both for safety and for continued reliable operation of the equipment.
Because of the different recreational vehicle models and the variations between the models, it would be extremely difficult, if not impractical, to provide detailed instructions for every possible installation. For that reason, instructions and illustrations in this manual are general in nature. Illustrations are not intended to serve as detailed installation blueprints.
The installation should comply strictly with all applicable codes, standards and regulations pertain­ing to the installation and use of this product. If any portion of this manual appears to be in conflict with such codes, standards or regulations, the applicable codes, standards or regulations must take prece­dence over the manual.
5.2 SAFETY
Before handling, installing, operating or servicing this equipment, carefully read the “Notice to Installer” and “Safety Rules” on Pages 18 and 19. Comply with all safety rules to prevent death, personal injury or damage to equipment and/or property. Stress safety to all installers, operators and service technicians who work on this equipment.
5.3 STANDARDS BOOKLETS
Installation, use and servicing of this equipment should comply strictly with published standards, as well as the manufacturer's recommendations. The following standards booklets (latest revision) are available from the sources indicated:
1. NFPA Standard 501C, “Standard for Recreational
Vehicles,” available from the National Fire Protection Association, Batterymarch Park, Quincy, MA 02269.
2. NFPA 70, “NFPA Handbook of the National
Electric Code,” available same as Item 1.
3. ANSI C1-1975 and ANSI 119.2-1975, available
from the American National Standards Institute, 1430 Broadway, New York, NY 10018.
4. ANSI A119.2/NFPA 501C, available from the
Recreational Vehicle Association, 1896 Preston White Drive, Reston, VA 22090.
5. California Administrative Code, Title 25, avail-
able from the State of California, Documents Section, P.O. Box 1015, North Highlands, CA
95660.
6. CSA Electrical Bulletin 946, available from the Canadian Standards Association, Housing and Constructions Materials Section, 178 Rexdale Boulevard, Rexdale, Ontario, Canada, M9W 1R3.
5.4 EQUIPMENT DESCRIPTION
Instructions and information in this section pertain to Generac air-cooled generators. These generators are designed specifically for installing in recreational vehicles. They operate 120-volt, single-phase, 60­Hertz, AC electrical loads.
5.5 GENERATOR ENGINE
OPERATING SPEED
The generator’s revolving field (rotor) is driven by a single-cylinder, four-cycle engine through a pulley and drive belt arrangement. The generator supplies 120 volts AC at 60 Hertz when the rotor is operating at 3,600 rpm.The drive belt arrangement allows the engine to operate at a lower speed than the rotor.
5.6 GENERATOR AC
CONNECTION SYSTEM
These air-cooled generator sets are equipped with dual stator AC power windings. These two stator windings supply electrical power to customer electrical loads by means of a dual 2-wire connection system.
Generators may be installed to provide the following outputs:
1) 120 VAC loads only — one load with a maximum
total wattage requirement equal to the generator’s rated power output (in watts), and 120V across the generator output terminals. (See Fig. 5.1 below)
2) 120/240 VAC loads — one load with a maximum
total wattage requirement equal to the generator’s rated power output, and 240 V across the generator output terminals; or two seperate loads, each with a maximum total wattage requirement equal to half of the generator’s rated power output (in watts), and 120 V across the generator output terminals. (See Fig.
5.3 on page 22)
Figure 5.1 – Connection for 120 Volts Only
Section 5 – General Information
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
Generac®Power Systems, Inc. 21
Figure 5.2 - Major Features and Dimensions (Drawing No. 0E1058-A)
Section 5 – General Information
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
5
5
5 6
5
8
9 6
8 6
8
6
9 6
8 0
5
8
0
3
US
6
U
S
)
O
C
O SS
C
O
S
O
O
O
O
O
OO
CC
SS
O
Q
S
US
OU
S
C
O
O
S
UC
O
S
Q
GU
60cc
O
US
. ALL N
TLET
TI
T
TR B
F ANY
AND EXHA
UIRED FOR COOLING.
LEAR
N TI
NNE
7
EL FILTER
.7 1
.
.4
R F
E
R A
UIRED MAINTENANCE
NT D
LL RE
R
21.2
P
M T
IEW FR
.2
.
. 2
.4
T BE KEPT
TE: ALL AIR INTAKE
PEN AREA IS RE
4
R
EL INLET
T
TE PANEL
NNE
EM
TRIAL
ND
HVI V-TWIN
ARDIAN 7
WERED BY
UIETPACT
ARNE
C OUTPUT
4.1
.2
.2 2
44.
EL INLET
.
7
NT R
T
WELDN
8 PLACES
.
"-1
4
74.7
.
YP.
.
. 2
.
4.
4
.4
N
T
T AIR
XHA
ATI
.
.2 1
.2 2
7.4
22 Generac®Power Systems, Inc.
Figure 5.3 - Connection for 120/240 Volts
• The AC connection system on all air-cooled PRIMEPACT series generators uses a GROUNDED neutral.
• A separate green ground wire is connected to the recreational vehicle’s junction box.
• Loads connected across T1 (Red) to T2 (White), and T3 (Black) to T2 (White), must not exceed rat­ings for your specific generator (see Section 1.6.3).
NOTE:
Do NOT connect loads in excess of circuit breaker ratings.
6.1 LOCATION AND SUPPORT
6.1.1 GENERATOR LOCATION
The most desirable location for the generator set is between the vehicle's main frame members. However, this is seldom possible. Most units must be installed on the side of the vehicle and are difficult to reinforce.
Many recreational vehicles have been factory equipped with an area for the generator set. Some vehicles may even have a generator compartment provided by the vehicle manufacturer.
Plan the generator location based on the following:
• The generator set must be installed on a frame­work that is part of the recreational vehicle, as out­lined in Section 6.1.2.
• The location must provide an access opening that is large enough to permit generator removal (unless the generator is to be removed from under­neath the supporting framework).
• The location must provide easy access to frequent­ly serviced components, such as filters, oil drains, spark plugs and other common maintenance parts.
• The location must provide sufficient room to allow minimum clearances as outlined in Section 6.2. If sound insulation is to be used on the compartment walls and ceiling, the minimum recommended applies to the space between the generator and such insulation.
• The location must provide adequate cooling and ventilating airflow for the generator without a great deal of work and expense.
6.1.2 GENERATOR SUPPORT
The generator must be securely attached to a metal framework that has been made part of the vehicle frame structure by bolting or welding. The metal framework on which the generator will rest and which will restrain the generator set should consist of at least two horizontal beams. These beams should consist of (a) 1-1/2-inch square, 11-gauge steel tubing OR (b) 1-1/2-inch, 11-gauge angle iron. A typical sup­porting frame with horizontal support tubing, is shown in Figure 6.1.
The generator can be installed so that it sits on top of the horizontal support tubing if the vehicle design permits. Another method is to suspend the generator below the horizontal support tubing by means of suit­able, structurally sound metal framework. The fol­lowing general rules apply:
• Vehicle construction MUST be capable of support­ing the weight of the generator.
• Whether the generator is mounted above the hori­zontal support tubing or suspended below the tub­ing, the supporting frame used must be structural­ly sound.
• If the generator cannot be bolted directly to the supporting frame or support tubing, consider using additional tubing, angle brackets or other supports to give the supporting frame sufficient strength.
Figure 6.1 – Typical Horizontal Support Frame
Section 6 – Installation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
T1
RED
T2
WHITE
T3
BLACK
STATOR WINDINGS
CB1
CB2
GROUNDED NEUTRAL
Generac®Power Systems, Inc. 23
6.1.3 SUSPENDED MOUNTING
If you are going to suspend the generator below the horizontal support tubing, the suspension method you use with the vehicle frame members must (a) be able to support the weight of the generator AND (b) provide sufficient restraint for the generator. One typ­ical suspended mounting system is shown in Figure
6.2. The location of a suspended mounting system must be carefully planned, keeping the following gen­eral rules in mind:
• Protect the generator against road splash and debris. Baffles or splash guards may be required to protect certain areas of the generator. To make sure the gen­erator is adequately protected, road test the installa­tion through mud, water and slush.
Figure 6.2 – Typical Suspended Mounting System
• The installer must make certain that the selected location will permit adequate cooling and ventilat­ing airflow to be supplied.
6.1.4 GENERATOR RESTRAINT
Use four 3/8"-16 hardened steel bolts (Grade 5) to fas­ten the generator to the supporting frame or the sup­port tubing. These bolts must pass through (a) the gen­erator mounting base, (b) the compartment floor (if a compartment is used) and (c) the supporting frame­work (Figure 6.3). All bolts must be long enough so that when tight, at least three threads are visible past the retaining lock nuts. Refer to Section 6.2 for the location of the generator mounting holes.
Figure 6.3 – Typical Generator Restraint
6.2 GENERATOR COMPARTMENTS
Whether the generator set is being installed inside a compartment specifically manufactured to house a gen­erator or inside a compartment that the installer con­structs, the compartment MUST meet certain specifi­cations as outlined in the following sections:
6.2.1 COMPARTMENT SIZE
Plan the compartment size carefully. Provide a mini­mum clearance of 1/2 inch (13 mm) on the front and top, 1 inch (25 mm) on the sides, and 1/2 inch (13 mm) from the back for air circulation AFTER the compartment has been lined with metal and sound insulation (Figure 6.4).
NOTE:
Refer to “Figure 5.2 – Major Features and Dimensions” on Page 21.
Figure 6.4 – Clearances
6.2.2 COMPARTMENT CONSTRUCTION
• The generator compartment should be either con­structed of, or lined with, 26-gauge galvanized steel.
NOTE:
Aluminum is NOT an acceptable alternative to galvanized steel due to aluminum’s low melting point.
• If the compartment is lined with galvanized steel, it may be constructed of any material. Generac rec­ommends that the compartment be constructed of 1/2-inch thick plywood (not strandboard), with the floor made of a double thickness of 1/2-inch ply­wood with the grain of the wood at cross section for added strength (Figure 6.5).
60cc O
CT
L
G
Section 6 – Installation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
IETPA
55
POWERED BY GUARDIAN 7
HVI V-TWIN
INDUSTRIA
Plywood
Compartment
Insulation
1/2" Clearance on Top
1/2"
in Front
1" Each Side
1" Clearance
in Back
24 Generac®Power Systems, Inc.
Figure 6.5 – Typical Compartment Construction
• If constructing a compartment, line the exterior (underside) of the compartment floor with 26­gauge galvanized steel.
• All seams, splices and joints of the compartment walls (unless vapor tight by design) should be caulked to prevent poisonous, flammable or explo­sive vapors from entering the vehicle interior.
NOTE:
Caulking must be done so that the caulking mate­rial will stay in place permanently. Pressing such materials as putty tape onto joints and seams is not acceptable. A high quality silicone rubber base sealant is recommended.
• Holes and openings made in the compartment walls to allow for the passage of electrical conduit, conductors, hoses, cables, etc., into the vehicle liv­ing area must be sealed vapor tight with silicone rubber base sealant.
• If flexible metal conduit is used, it must be sealed internally at the end where it terminates inside the compartment’s electrical junction box.
NOTE:
Flexible metal conduit, due to its unique con­struction, is NOT vapor tight along its entire length.
• Seams and joints of the galvanized steel (whether used as a liner or for the compartment itself) must be lapped and mechanically secured. Such seams may be manufactured, welded, bolted, riveted or screwed. Manufactured lock seams are shown in Figure 6.6. Installer constructed compartments typically utilize a standard lap joint.
Figure 6.6 – Types of Lock Seams
• After the compartment has been metal lined and vapor sealed, line the compartment interior walls and ceiling with an approved, nonflammable sound insulating material. See Section 6.2.3.
Do not install any flammable material directly above or around the compartment. Heat, transferred through the compartment structure, may be sufficient to ignite, char or discolor seat cushions, fiberboard and other flammable materials. You may need to use approved nonflammable insulating materials in high temperature areas.
6.2.3 SOUND INSULATING MATERIALS
Once installers have determined that a compartment is properly constructed and metal lined, they can add acoustical material. This may include additional sealant or insulating material, to reflect noise away from the vehicle interior.
Sound insulating materials should be of a nonflam­mable type. One excellent insulating material is a 1­inch (25 mm) thick fiberglass having a 2-pound den­sity. When fiberglass is used, its coated side should face toward the compartment interior.
Do not install sound insulation or any absorbent material on the compartment floor interior. Such materials will become soaked with combustible or explosive vapors and liq­uids and will become a fire hazard.
Using a combination of sound insulating materials can often reduce noise more effectively than a single material. For example, a sheet of lead or visco-elastic material, along with a layer of other acoustical mate­rial, is more effective than when a single material is used.
Section 6 – Installation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
DANGER
DANGER
Generac®Power Systems, Inc. 25
Section 6 – Installation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
6.2.4 ACOUSTICS
For additional noise abatement, the installer may wish to consider the following:
• Using special sound insulating materials.
• Construction of a special noise abatement com­partment.
NOTE:
Any method used to reduce noise must not adversely affect the flow of cooling and ventilating air into or out of the compartment.
In addition to the effective use of sound insulating materials, construction of a special noise abatement compartment might be considered to reduce noise levels. Such a compartment might be constructed as follows (Figure 6.7):
• Use 5/8-inch thick or 3/4-inch thick plywood in the compartment.
• Construct the compartment floor of a double thick­ness of 5/8-inch or 3/4-inch plywood.
• Line the compartment interior walls and floor, as well as the underside of the floor, with 26-gauge galvanized steel.
• Vapor seal all compartment seams and joints.
• Over the galvanized steel lining, install a combina­tion of acoustical materials as mentioned in Section 6.2.3.
To prevent fire or explosion, do not install any insulation or other absorbent materials on the interior or underside of the compartment floor.
• Seal all compartment door edges to prevent noise leakage around the door perimeter.
• Line the compartment door interior (except for air openings) with suitable, fireproof sound insulation (such as 1-inch (25 mm) thick fiberglass with a 2­pound density).
Figure 6.7 – Typical Noise Abatement
6.2.5 COMPARTMENT FLOOR CUTOUTS
You must provide openings in the generator compart­ment for the following items (Figure 6.8, Page 26):
• Engine exhaust and cooling air outlets
• Generator cooling air inlet
• Four holes for passage of generator mounting bolts. See Section 6.1.4 (Page 23).
Fuel lines and exhaust piping must not pene­trate into the vehicle living area.
6.3 COOLING AND VENTILATING AIR
It is absolutely essential that an adequate flow of air for cooling, ventilating and engine combustion be supplied to the generator set. Without sufficient air­flow, the engine/generator quickly overheats. Such overheating can cause serious operating difficulties and also may cause fire and personal injury. The installer must make sure that sufficient air is avail­able to the generator for cooling, ventilating and com­bustion. The installer also must provide for a path for exhausting the cooling air to the exterior of a com­partment, if so equipped.
Never use discharged cooling air for heating or permit such air to enter the vehicle interior. This air contains deadly carbon monoxide gas and other poisonous, flammable or explosive gases.
6.3.1 GENERATOR AIRFLOW
Engine operation drives cooling fans for the two-stage cooling air system. A pressure fan draws cooling air into the top of the generator (Figure 6.9). This airflow cools the engine/generator and electronic compo­nents. The second part of the cooling system, a suc­tion fan, draws air that is heated from a hot engine into a collector pan at the base of the unit. This heat­ed air (although cooler than exhaust muffler) is then deflected out the bottom toward the ground.
Figure 6.9 – Airflow Through Engine/Generator
e
T
L
A
DANGER
DANGER
!
DANGER
ARDI
by Generac Power Syst
UIETPAC
INDUSTRIA
26 Generac®Power Systems, Inc.
6.3.2 TESTING THE INSTALLATION
Generac recommends testing the installation to be sure adequate cooling airflow is available to the unit before placing the unit into service. If the unit shows signs of overheating, you will need to enlarge the air openings. Never place a unit into service until absolutely certain that cooling and ventilation is ade­quate.
NOTE:
You must test the installation, especially if you bring in air from below the generator set.
6.4 GASOLINE FUEL SYSTEM
Gasoline is highly flammable, and its vapors are explosive. Comply with all codes, standards and regulations pertaining to gasoline fuel systems used in recreational vehicle generators. Properly install and maintain the fuel system and keep it entirely free of leaks. Gasoline vapors must not enter the vehicle interior.
The installation of a gasoline fuel system (Figure
6.14) for a recreational vehicle generator set must
comply with applicable codes, standards and regula­tions. The entire fuel system must be completely free of leaks. There must be no possibility of gasoline vapors entering the vehicle interior.
Figure 6.14 – Generator Fuel System
Section 6 – Installation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
Figure 6.8 — Compartment Floor Cutout
5
7
5
2
2
69
8
9
2
2
8
6
5
9
2
4
2
1
R
UST
S
)
T
T
4
Q
.
HOT AI
EXHA
25.
4
16.
26.
70.
.
4
74.
21.
44.
.
"-16 WELDNUT
8 PLACES
4
FRON
233.
FUEL INLE
126.
4.
.
195.
4.
NOTE: ALL AIR INTAKES AND EXHAUST OUTLETS MUST BE KEPT CLEAR OF ANY OBSTRUCTIONS. ALL OPEN AREA IS RE
DANGER
UIRED FOR COOLING
Fuel Pump (Behind Access Cover)
Fuel Filter (Side of Unit)
Fuel Line
Generac®Power Systems, Inc. 27
Factory installed generator fuel system components include (a) fuel filter, (b) 12-volt DC electric pump, (c) engine carburetor, and (d) interconnecting lines and fittings. Connect a fuel supply line to the fuel filter inlet. Use a flexible length of approved fuel hose between the fuel filter inlet connection and rigid fuel lines.
6.4.1 FUEL TANK
Either the generator must share the vehicle engine's fuel tank, or you must install a separate fuel tank for the generator set. All fuel tanks installed on the vehi­cle must be constructed, installed and restrained so they comply with applicable codes, standards and regulations.
If the generator is to share the vehicle engine's tank, separate fuel pickup tubes are required for the engine and the generator. Generac recommends that you make the fuel pickup tube 2 to 3 inches (51 to 76 mm) shorter than the vehicle engine's pickup tube. This prevents the generator from depleting the entire fuel supply during prolonged generator operating periods.
Do NOT tee the generator fuel supply line into the vehicle engine fuel supply line. If this is done, the generator will be starved of fuel when both engines are operating at the same time. Also, while the vehicle engine is not run­ning, generator operation may drain the vehi­cle engine supply line, making it difficult to start the vehicle engine.
6.4.2 GENERATOR FUEL SUPPLY LINE
6.4.2.1 Rigid Fuel Lines
Those lines used to supply fuel from a tank to the generator must comply with applicable codes, stan­dards and regulations. The following general rules apply to rigid fuel lines:
• Rigid lines should be of annealed, seamless, drawn aluminum or steel.
• Lines and fittings must comply with SAE J512F, “Standard Automotive Fittings,” or with ANSI B126.26 (latest edition).
• Route the fuel line so that at least 2 inches (51 mm) of clearance is maintained between the line and any exhaust system parts.
• Do not attach electrical wiring to fuel lines. Route the wiring so it cannot come into contact with any fuel line.
• Route fuel lines so if they leak, fuel does not drip onto any electrical or exhaust system parts.
• Use nonferrous metal straps without sharp edges to secure fuel lines.
6.4.2.2 Flexible Fuel Line
Use an approved flexible length of fuel hose between the generator fuel inlet connection and rigid fuel lines. This prevents breaking of the line caused by vibration, shifting, settling or movement. The follow­ing rules apply:
• The flexible hose must comply with SAE J30B, “Standard for Fuel and Oil Hose.” It must be approved for use with gasoline.
• The hose should be at least 6 inches (152 mm) longer than is needed to prevent the hose from rupturing if the generator shifts or settles.
6.5 LP GAS FUEL SYSTEM
LP gas is highly EXPLOSIVE. The gas is heavier than air and tends to settle in low areas. Even the slightest spark can ignite it and cause and explosion. Only competent, qualified people should be allowed to install, test, adjust or ser­vice an LP gas fuel system. Install the optional fuel system in compliance with applicable codes, standards and regulations. After the installation, do not do anything that might ren­der the system in noncompliance with applica­ble codes and standards.
The LP powered range of generators are fitted with a nonadjustable, factory set system. These systems are tamper-proof to meet 1997 California Air Resources Board requirements for engine emission.
6.5.1 LP FUEL CONSUMPTION (lb./hour)
6.5.2 PARTS NOT INCLUDED IN FUEL SYSTEM
The propane fuel system does NOT include such items as (a) gas tank, (b) gas piping, (c) fittings, (d) valves, and (e) primary regulator, used to store the gaseous fuel and deliver it to the gaseous fuel sole­noid (Figure 2.15, Page 29).
Use only approved components in the fuel sup­ply system. All components must be properly installed in accordance with applicable codes. Improper installation or use of unauthorized components may result in fire or an explosion. Follow approved methods to test the system for leaks. No leakage is permitted. Do not allow fuel vapors to enter the vehicle interior.
!
Section 6 – Installation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
Model Idle 50% Load 100% Load
Quietpact 55LP 2.34 3.96 5.07 Quietpact 65LP 2.34 4.20 6.50 Quietpact 75LP 2.34 4.44 8.75
DANGER
DANGER
28 Generac®Power Systems, Inc.
Figure 6.15 – Typical Propane Gas Fuel System
6.5.3 SOME IMPORTANT CONSIDERATIONS
When installing an LP gas system, consider seriously the following items:
• All fittings, lines, hoses and clamps must be tight and free of leaks. Apply a pipe sealant to threads when assembling threaded connections. This reduces the possibility of leakage.
• Test the entire fuel system for leaks using approved test methods.
• Optimum gas pressure at the inlet to the gaseous fuel solenoid valve and secondary regulator is 11 inches water column.
• The installer’s fuel supply connection point is at the gaseous fuel solenoid valve. This is a 3/4-inch (female) connection. Provide a suitable 3/4-inch NPT (male) connector to attach to the fuel supply line.
• Use a length of approved flexible fuel hose between the gaseous fuel solenoid valve and rigid gas pip­ing. The flexible line should be at least 6 inches longer than necessary.
6.5.4 VAPOR WITHDRAWAL
LP gas is stored in pressure tanks as a liquid. The gas systems used with these generators were designed only for vapor withdrawal type systems. Vapor withdrawal systems use the gas vapors that form above the liquid fuel in the tank. Do NOT attempt to use the generator with any liquid with­drawal type system.
6.5.5 PRIMARY REGULATOR
Gas pressure delivered to the solenoid valve must be properly regulated by means of a primary gas regula­tor. Mount the primary regulator at the gas tank out­let or in the supply line from the gas tank. The fol­lowing rules apply:
• For best results, the primary regulator supplies gaseous fuel to the secondary regulator at 11 inch­es water column. Do NOT exceed 14 inches water column.
• The installer must be sure the primary regulator is rated at sufficient gas flow to operate the generator plus all other gas appliances in the circuit.
NOTE:
Recommended MINIMUM gas flow rate for all air­cooled PRIMEPACT series generators is 67 cubic feet per hour.
If an existing primary gas regulator does not have a sufficient flow capacity for the generator and other gas appliances in the circuit, (a) install a pri­mary regulator with adequate flow rate, or (b) install a separate regulator only and rated at least 67 cubic feet per hour. The inlet side of any pri­mary regulator that supplies the generator must connect directly to a gas pressure tank. Do NOT tee the generator line into a gas circuit feeding other areas.
6.5.6 GASEOUS CARBURETION
LP gas vapors should be supplied to the secondary regulator inlet at about 11 inches water column (pos­itive pressure). The engine pistons draw air in during the intake stroke (Figure 6.16). This air passes through a carburetor venturi, which creates a low pressure that is proportional to the quantity of air being pumped. The low pressure from the carburetor venturi acts on the regulator diaphragm to pull the diaphragm toward the source of low pressure. A lever attached to the diaphragm opens a valve to permit gas glow through the carburetor.
Figure 6.16 – LP Gas Carburetion Diagram
Section 6 – Installation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
Generac®Power Systems, Inc. 29
The greater the airflow through the carburetor ven­turi, the lower the pressure at the venturi throat. The lower the pressure at the venturi throat, the greater the diaphragm movement, and the greater the move­ment of the regulator valve. The more the regulator valve opens, the greater the gas flow that is propor­tional to airflow through the generator.
The following facts about the secondary regulator must be emphasized:
• The regulator must be sensitive to venturi throat pressure changes throughout the operating range.
• The regulator must be properly adjusted so it will stop the flow of gas when the engine is not running (no air flow through the carburetor).
• The slightest airflow (and vacuum in the venturi throat) should move the regulator valve off its seat and permit gas to flow.
6.5.7 FUEL SUPPLY LINES
• LP gas lines must be accessible, but protected against possible damage.
• Do NOT connect electrical wiring to any LP gas fuel line or run wiring alongside the lines.
• Route gas lines away from hot engine exhausts.
• Retain gas lines with metal clamps that do not have sharp edges.
• Install an approved length of flexible hose between the gaseous fuel solenoid valve and rigid fuel sup­ply lines. The flexible line must be nonmetallic, nonorganic and nonconductive. It must be approved for use with LP gas.
Gaseous fuel lines between the tank and the secondary regulator are under a positive pres­sure (about 11 inches water column). Gas pres­sure at the outlet side of the secondary regula­tor, however, is a negative pressure and can draw flame inside a line or fitting and cause an explosion.
6.5.8 EXCESS FLOW VALVE
LP gas tanks should have an excess flow valve, according to NFPA 501C, Paragraph 3-4.4. This valve and the gas lines must be carefully sized so the valve will close when a fuel line is severed or broken. Consult the Natural-LP Gas Association for informa­tion and limitations of excess flow valves.
Manual shutoff valves on the supply tank and else­where in the system must be fully open when operat­ing the generator. The excess flow valve functions properly only if all valves are fully open.
6.5.9 LEAKAGE TESTS
Do not place the generator into service until you have properly tested the gas system for leaks. To test the system, you need a separate source of 12 volts DC to open the gaseous fuel solenoid valve.
The leak test must comply fully with NFPA, Paragraph 318. All connections, hoses, valve regula­tors, fittings, and other fuel system parts must be tested under gas or air pressure of not less than 90 psi (620 kPa), while using soap and water or an equivalent solution to check for leaks. Other approved methods of testing for leaks may be used, if appropriate. DO NOT USE ANY FLAME TO TEST FOR LEAKS.
6.6 EXHAUST SYSTEM
The generator exhaust system must be safely and properly installed. Only approved mufflers and other exhaust system parts must be used. A properly installed exhaust system must be vapor tight, quiet and completely safe.
The generator engine gives off DEADLY carbon monoxide gas through its exhaust system. This dangerous gas, if breathed in sufficient concen­trations, can cause unconsciousness or even death. Never operate the generator set with the vehicle inside any garage or other enclosed area. DO NOT OPERATE THE GENERATOR IF THE EXHAUST SYSTEM IS LEAKING OR HAS BEEN DAMAGED. SYMPTOMS OF CARBON MONOX­IDE POISONING ARE (a) inability to think coher­ently; (b) vomiting; (c) twitching muscles; (d) throbbing temples; (e) dizziness; (f) headaches; (g) weakness; and (h) sleepiness. IF YOU FEEL ANY OF THESE SYMPTOMS, MOVE INTO FRESH AIR IMMEDIATELY. IF SYMPTOMS PERSIST, GET MEDICAL HELP. Do not operate the generator until its exhaust system has been inspected and properly repaired.
Never tee the generator engine exhaust pipe into the vehicle engine exhaust piping. This causes excessive back pressure on the genera­tor engine. Also, water from one engine can damage the other engine.
!
Section 6 – Installation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
DANGER
DANGER
!
30 Generac®Power Systems, Inc.
6.6.1 MUFFLERS AND SPARK ARRESTORS
This muffler meets code and standard requirements of the U.S. Forest Service. Use only mufflers and parts approved by Generac. Any person(s) installing an unapproved muffler, or an unapproved exhaust system part, or modifying an exhaust system in any way that might cause a hazard, is liable for any dam­age, injury or warranty expense that might be caused by such unapproved installation or modification.
Failure to provide and maintain a spark arrestor may be in violation of the law. If this generator is used on any forest covered, brush covered or grass covered unimproved land, you must provide a spark arrestor. The vehicle owner or operator must maintain this device in good condition. In the state of California, the preceding is required by law (Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands.
When installing/replacing the tailpipe or spark arrestor components, verify that the tailpipe has a hole to securely fasten the spark arrestor compo­nents (see Figure 6.17). Use only Generac supplied hardware. Substitution of parts may cause damage to the screen or a loose fit to the tailpipe.
Figure 6.17 — Spark Arrestor Installation
6.6.2 EXHAUST SYSTEM SAFETY
• Maintain a clearance of at least 3 inches (76 mm) between exhaust system parts and any com­bustible material (such as wood, felt, cotton, organic fibers or other like material). If you cannot maintain the 3-inch (76 mm) clearance, locate, insulate or shield the exhaust part(s) so that the temperature of any combustible material is not raised more than 117° F (65° C) above the ambient air temperature.
• Extend the exhaust system at least 1 inch (25 mm) past the outer edge of the vehicle. Do not terminate the exhaust system under the vehicle.
• Terminate the exhaust tailpipe such that exhaust gases will not be drawn back into the generator compartment and recirculated.
• If there is any possibility of the tailpipe or muffler being damaged, protect these damage-prone areas by means of a protective device (such as a skid bar).
• Install the generator exhaust system according to safe automotive practices.
• Use enough exhaust system hangers to prevent any part of the system from being dislocated.
• Use exhaust system parts recommended by Generac. Using unapproved exhaust mufflers and exhaust system parts is the responsibility of the person(s) installing such unauthorized parts.
• Do not terminate the exhaust system under any opening, window or vent that can be opened or is not permanently sealed from the vehicle interior.
• Exhaust piping must be large enough to prevent excessive back pressure on the generator engine.
• Never tee the generator engine exhaust pipe into the vehicle engine exhaust piping. This causes excessive back pressure on the generator engine. Also, water from one engine can damage the other engine.
• Plan exhaust system installation carefully. Comply with all applicable codes, standards and regula­tions.
6.7 ELECTRICAL CONNECTIONS
Be sure to read Section 5.6 on Page 20.
The following general rules apply to electrical con­nections in a recreational vehicle:
• Qualified electricians who are familiar with applic­able codes, standards and regulations should install electrical wiring.
• The wiring should comply with codes, standards and regulations. The National Electrical Code (NFPA 70), and state and local codes apply.
• Switches and circuit breakers should be of a type approved for use in recreational vehicles and must be mounted and installed to prevent damage from road shock.
• Wiring must be of adequate size, have approved insulative qualities and be properly supported.
• Conduit and wire openings into the generator com­partment (if used) must be vapor-sealed to prevent entry of flammable, explosive or poisonous gases into the vehicle.
6.7.1 ELECTRICAL JUNCTION BOX
Install an approved, square electrical junction box with a blank cover on the interior or exterior wall of the area you plan to install the generator (NOT on the generator). Route the generator's AC output leads into this junction box through approved flexible con­duit. This is the point of first termination for genera­tor AC output leads.
]
[]
[]
Section 6 – Installation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
24 [0.95"
Generac®Power Systems, Inc. 31
6.7.2 WIRING
• Wiring should be of stranded copper to reduce the chance that vibration may cause breakage.
• Wire gauge size should be large enough to handle at least 115 percent of the installed generator's rated maximum current.
• If neutral conductors are used, they must be the same size as other leg wires.
• Route power supply conductors from generator AC output leads T1 (red), T2 (white), T3 (black) and the green ground wire through approved flexible conduit to the electrical junction box on the com­partment wall.
• If flexible metal conduit is used between the gener­ator and the compartment junction box, the con­duit end that terminates the compartment junction box must be vapor-sealed. Flexible metal conduit is NOT vapor tight along its entire length.
• From the junction box, route power supply wires through approved conduit to either (a) double­pole, double-throw transfer switch, or (b) approved isolation receptacle. Connecting to a transfer switch or isolation receptacle must pre­vent vehicle electrical circuits from being connect­ed to two different power supplies at the same time (such as generator and dockside power).
• Conductors must be rated 221° F (105° C) or must be of a larger conductor size.
6.7.3 GENERATOR AC CONNECTIONS
Generator AC output leads T1 (red), T2 (white) and T3 (black) come out of the generator as shown in Figure 6.18. Leads T1 (red) and T3 (black) are “hot,” while T2 (white) is the grounded neutral lead. There is also a green lead that connects to ground in the junction box of the recreational vehicle.
Figure 6.18 – Generator AC Output Leads
Line T1 (red) to T2 (white) is protected against over­load by a circuit breaker (CB1). Use this line-to-neu­tral connection separately to operate 120-volt, single­phase, 60 Hertz, AC loads. Line T3 (black) to T2 (white) also is protected against overload by a circuit breaker (CB2). Use this line-to-neutral connection separately to operate similar loads. However, be sure the total unit load does not exceed the maximum rat­ing of the generator. The neutral line (T2, white) on all units is a grounded neutral.
Do NOT connect electrical loads in excess of any circuit breaker rating or you will develop problems with circuit breaker tripping, which causes a loss of AC output. Also, do NOT exceed the generator's rated wattage capacity. Add the watts or amperes of all lighting, appli­ance, tool and motor loads the generator will operate at one time. This total should be less than the unit's rated wattage/amperage capaci­ty.
6.7.4 CONDUIT
Route the connections between the generator and the junction box through approved, flexible conduit. The following general rules apply:
• Cut wiring to the required length and allow extra wire for junction box connections.
• Carefully prepare conduit ends to prevent sharp edges from cutting through wiring insulation.
• Route conduit so it does not interfere with genera­tor movement.
• If you use metallic conduit, vapor seal the end of the conduit where it enters the junction box. Do this because flexible metallic conduit is not vapor­proof along its entire length.
6.7.5 ISOLATING DIFFERENT POWER SOURCES
Connections from the junction box must terminate in a double-pole, double-throw transfer switch (Figure
6.19, Page 33). An alternate method for isolating dif­ferent power sources is by using an isolating recepta­cle (Figure 6.20, Page 33). Whichever method you use, you must be certain that both power sources are NOT connected at the same time.
6.7.6 POWER SUPPLY CORD
The power supply cord must comply with all applic­able codes, standards and regulations. It must be large enough to handle the full amperage to which it will be subjected. (See page 33 for illustration.)
Section 6 – Installation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
T3 T2 T1
Green (Ground)
32 Generac®Power Systems, Inc.
Section 6 – Installation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
6.7.7 GROUND FAULT CIRCUIT INTERRUPTERS
The National Electrical Code (NFPA 70, article 551) requires that you install ground fault circuit inter­rupters (GFCIs) on all external and some internal electrical receptacles. Contact your manufacturer or dealer for recommendations.
6.8 BATTERY INSTALLATION
6.8.1 RECOMMENDED BATTERY
Install a battery that meets the following require­ments:
• The battery must be a 12-volt, automotive type storage battery.
• For prevailing ambient temperatures above 32° F (0° C), use a battery rated 70 amp-hours and capa­ble of delivering 400 cold-cranking amperes.
• For prevailing ambient temperatures below 32° F (0° C), use a battery rated 95 amp-hours and capa­ble of delivering 400 cold-cranking amperes.
NOTE:
If the battery is to be used to power other vehicle accessories, as well as start the generator, you may need a battery with a larger capacity.
6.8.2 BATTERY CABLES
Using battery cables that are too long or too small in diameter may cause a drop in voltage, which causes starting problems. For the best cold weather starting, the voltage drop between battery terminals and the generator connection point should not exceed 0.12 volts per 100 amperes of cranking current.
PRIMEPACT generators are rated at about 100 DC amperes of cranking current.
Select battery cables based on (a) cable length and (b) prevailing ambient temperatures. Generally, the longer the cable and the colder the weather, the larg­er the cable size must be, as shown in the chart.
6.8.3 BATTERY CABLE CONNECTIONS
1. Connect the battery cable from the battery post or terminal indicated by a POSITIVE, POS or (+) to the lug on the starter contactor (Figure 6.21).
NOTE:
Check to be sure the battery cable boot for the starter cable has been installed.
2. Connect the battery cable from the battery post indicated by a NEGATIVE, NEG or (-) to the frame ground connection (Figure 6.21).
3. Connect cables so the connectors are clean and tight.
Figure 6.21 – Connecting Battery Cables
6.8.4 BATTERY COMPARTMENT
Install the generator battery in its own, vented com­partment. Place the battery compartment away from any source of heat, sparks or flame.
Provide ventilation openings in the battery compart­ment. The minimum size of openings should be 2 square inches at the top of the compartment. Mount the battery on a strong, rigid supporting structure, where leaks and spills of battery fluid will not cause damage.
CABLE LENGTH
in Feet (meters) CABLE SIZE
0 to 10 (0 to 3) 2*
11 to 15 (3.4 to 4.5) 0
16 to 20 (4.5 to 6) 000
*For warm weather, use No. 2 cable up to 20 feet.
Positive Cable
Negative Cable
+
Battery
Chassis Ground
Generac®Power Systems, Inc. 33
Section 6 – Installation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
Figure 6.18 — Transfer Switch Isolation Method
N
G
Figure 6.19 — Installation With Isolation Receptacle
60cc O
N
G
IETPACT55
POWERED BY GUARDIAN 760cc OHVI V-TWI
IETPACT55
POWERED BY GUARDIAN 7
HVI V-TWI
34 Generac®Power Systems, Inc.
6.9 OPTIONAL ACCESSORIES
A plug-in receptacle (Figure 6.22) is provided on the generator set, above the muffler enclosure. Use this receptacle to connect an optional remote-mounted start/stop panel to the generator. Installation of such a panel will permit you to start and stop the genera­tor engine from any convenient location inside the vehicle.
Figure 6.22 – Remote Panel Plug-in Receptacle
6.9.1 REMOTE PANEL MODELS
The remote panels mount a rocker type start/stop switch, a “Generator Run” advisory lamp and an hourmeter. The hourmeter should be used in con­junction with the maintenance operations found in Part I of this manual.
• Model 004057 includes the remote panel and a 10 foot long, 4 wire harness.
• Model 004184 includes the remote panel and a 30 foot long, 4 wire harness.
7.1 POST INSTALLATION TESTS
The air-cooled generator set was factory tested and adjusted. You should not be required to adjust the unit any further except under special circumstances.
Do not make any unnecessary adjustments. Factory settings are correct for most applica­tions. When making adjustments, however, be careful to avoid overspeeding the engine.
7.2 BEFORE INITIAL START-UP
Before starting, complete the following:
1. Check the engine crankcase oil level and, if nec­essary, fill to the dipstick “FULL” mark (cross­hatched area) with the recommended oil. Do not fill above the FULL mark.
2. Check the fuel supply. Gas fuel lines must have been properly purged and leak tested in accor­dance with applicable fuel codes. All fuel shutoff valves in the fuel supply lines must be open.
If a liquid propane (LP) gas fuel system has been installed, it must be properly tested for leaks before operating the system in compli­ance with ANSI A119.2/NFPA 501C. No leakage is permitted. You must be sure no gasoline fuel vapors enter the vehicle interior.
7.3 INITIAL START
When you are absolutely certain that the unit has been properly installed and prepared for use, start the engine as follows:
1. Turn off all electrical loads. Do this by setting the generator’s main circuit breakers to their “OFF” (or open) position.
2. Refer to Part I, Section 2.5, “Starting the Generator” (Page 8), for cranking and starting instructions. The engine may require more cranking for initial starting since the fuel lines have to be primed (use of the primer switch will shorten this time).
3. Let the engine warm up for about five minutes to allow internal temperatures to stabilize.
4. Carefully inspect the engine/generator for fuel, oil and exhaust system leaks. Before proceeding to the next step, correct any leakage immediately.
5. When all tests and adjustments at no-load are completed, apply electrical loads and check for proper operation under load. See Section 7.4. Run the unit at least 30 minutes with loads applied.
6. Turn off all electrical loads by setting the genera­tor’s main circuit breakers to their “OFF” (or open) position.
7. Let the unit run at no-load for a few minutes to stabilize internal engine/-generator temperatures. Then, shut down the engine.
NOTE:
The generator set was thoroughly tested and adjusted at the factory before shipping. No addi­tional adjustment should be necessary. Only qual­ified service technicians who have been trained should perform adjustments outlined in this man­ual.
!
12.00"
Section 7 – Post Installation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
6 5 4 3 2 1
WIRE
No.
14 15 17 18
14A P/N: 0D9099-B
0
14A
15
18
14
17
0
WIRE
COLOR WHITE
RED ORANGE YELLOW
BROWN
BLUE
12.00"
LENGTH (mm)
12.0 (305)
12.0 (305)
12.0 (305)
12.0 (305)
12.0 (305)
12.0 (305)
14A
15
18
14
17
0
FUNCTION
GROUND
ENGINE RUN SIGNAL
12 VDC
START STOP PRIME
!
DANGER
Generac®Power Systems, Inc. 35
7.4 TESTING UNDER LOAD
Apply electrical loads equal to about 75 to 100 per­cent of the unit's rated wattage/amperage capacity.
Let the unit run at least 30 minutes with load applied. During this part of the test, check that the unit is not running excessively hot and that adequate cooling airflow is available. You must not allow the unit to overheat during prolonged operation.
NOTE:
The generator engine is equipped with a high tem­perature switch. The switch has normally open (N.O.) contacts. When the engine temperature is too high, switch contacts close, and the engine shuts down automatically.
GENERAC RECOMMENDS THAT YOU TEST THE GENERATOR FOR ADEQUATE COOLING.
7.5 INSTALLATION CHECKLIST
LOCATION AND SUPPORT
Generator is properly located.Generator is properly supported.Generator is properly restrained.
GENERATOR COMPARTMENT
Compartment construction is proper.Holes/Openings are vapor-sealed.Compartment size is correct.Compartment is vapor-sealed.Sound insulation is correct.Floor cutouts are properly completed.
COOLING AND VENTILATING AIR
Airflow is adequate.Air inlet opening is correct.Compensate for restrictions.Check that installation has been tested.
GASOLINE FUEL SYSTEM
Fuel tank complies with all applicable codes.Fuel system is properly installed and checked
for leaks.
OPTIONAL LP GAS FUEL SYSTEM
Fuel system is properly installed and checked
for leaks.
Pressure at regulator inlet is correct.Rated flow of primary regulator is correct.All parts are properly installed.Fuel system is properly tested/adjusted.
EXHAUST SYSTEM
Exhaust system complies with all applicable
codes.
Exhaust system is properly and safely installed.
ELECTRICAL CONNECTIONS
Connections comply with local code requirements
and all National Electrical Codes.
Junction box is properly installed.Wiring meets all standards.All connections are correct.Conduit is properly installed and sealed.Generator is properly bonded to the vehicle.
BATTERY INSTALLATION
Recommended battery is installed.Recommended cables are installed.Cables are clean and tight.Cables are connected properly.Proper ventilation is provided.Terminals are coated with anti-corrosion grease,
and terminal covers are positioned.
OPTIONAL ACCESSORIES
Check that remote start/stop panels (if used) are
installed properly.
Check that hourmeter kit (if used) is installed
properly.
Check that any other options and accessories (if
used) are installed properly.
POST INSTALLATION TESTS
Check that all tests are completed properly.
Section 7 – Post Installation
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
DATE OF INSTALLATION ____________________________________________________
NAME OF INSTALLER ______________________________________________________
SIGNATURE OF INSTALLER ________________________________________________
36 Generac®Power Systems, Inc.
Section 8 – Troubleshooting
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
8.1 TROUBLESHOOTING GUIDE
PROBLEM CAUSE CORRECTION
Engine won’t crank. 1. 7.5 amp fuse blown. 1. Replace blown fuse.
2. Loose, or corroded or defective 2. Tighten, clean or replace, battery cable(s). as necessary.
3. Battery is discharged or defective. 3. Recharge or replace battery.
4. Defective Start/Stop switch. 4. Replace switch.
5. Defective starter contactor. 5. Replace starter contactor.
6. Defective starter motor. 6. Replace starter motor.
7. Defective Engine Control Board 7. Contact an authorized service dealer.
Engine cranks, won't start. 1. Out of fuel. 1. Refill fuel tank.
2. Fuel shutoff valve is closed. 2. Open fuel shutoff valve(s).
3. Fuel pump not operating. 3. Repair or replace pump.
4. Automatic choke not operating properly. 4. Repair, replace or adjust.
5. Engine is flooded. 5. Wait 5-10 minutes;try again.
6. Fuel filter is clogged. 6. Replace filter if clogged.
7. Engine spark plugs defective. 7. Clean, regap or replace as needed.
8. Bad ignition magneto on engine. 8. Replace if defective.
9. Bad carburetor. 9. Adjust, repair or replace.
10. Dirty air cleaner. 10. Clean or replace as needed.
Engine starts hard, runs rough. 1. Dirty engine air cleaner. 1. Clean or replace as needed.
2. Automatic choke is sticking. 2. Free choke linkage as needed.
3. Defective spark plugs. 3. Clean, regap or replace.
4. Defective ignition magneto. 4. Replace it if defective.
Engine starts, then shuts down. 1. Engine oil level is low. 1. Add oil as needed.
2. Bad low oil pressure switch. 2. Replace, if bad.
3. Defective high temp switch. 3. Replace, if bad.
4. Water in fuel. 4. Drain fuel tank and refill.
5. Defective remote harness. 5. Disconnect remote harness. Contact
authorised service facility.
No AC output voltage. 1. Main breaker(s) open. 1. Close main breaker(s).
2. Transfer switch (if so equipped) is 2. Reset transfer switch. set to wrong position.
3. Failure in vehicle electrical system. 3. See vehicle manual.
4. Generator component failure. 4. Contact an authorized service facility.
Generac®Power Systems, Inc. 37
Section 9 – Notes
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
38 Generac®Power Systems, Inc.
Section 10 — Electrical Data
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators V-Twin – Drawing No. 0E1057-B
G
C
CUSTO
3
S
S
5
9
6
8
5
O
O
)
(
)
)
)
)
)
)
)
)
)
)
)
M
R
R - BATTERY CHARGE RECTIFIER
B1 - CIRCUIT BREAKER, 30A (QP55 & QP65 MODELS
CIRCUIT BREAKER, 35A (QP75 MODEL
B2 - CIRCUIT BREAKER, 20A (QP55 MODEL
CIRCUIT BREAKER, 30A (QP65 MODEL
B3 - CIRCUIT BREAKER, 2.5A (QP55 MODEL
CIRCUIT BREAKER, 3.0A
H - CHOKE HEATER (GASOLINE MODELS ONLY 1 - FUSE, 7.5A
P - FUEL PUMP-OR-LPG SHUT OFF VALVE
- FUEL SOLENOID
T - TERMINAL, GROUND M - METER, HOUR (OPTIONAL TO - SWITCH, HIGH TEMP. OIL (CLOSES ON HIGH TEMP.
M1 - IGNITION MAGNETO - #1 CYL. M2 - IGNITION MAGNETO - #2 CYL.
1 - LIGHT, RUN (OPTIONAL OP - SWITCH, LOW OIL PRESSURE (CLOSES ON LOW PRESSURE
1 - RESISTOR, 1 OHM 25W
- STARTER CONTACTOR
R - STARTER CONTACTOR RELAY
W1 - SWITCH, START/STOP
W2 - SWITCH FUEL PRIMER
P1 - SPARK PLUG #1 CYL. P2 - SPARK PLUG #2 CYL. C - TERMINAL, CONN. 4-TAB
CONNECTOR
QP65 & QP75 MODELS
EUTRAL CONNECTION Y
EGEND
REEN
MER
W2
H
B
R
2
1-4 1­1­1-7
A A
P2
B
1­1-
T
P
EMOTE
1-1
I
WN R
6
N
M
N
2
LECTRONI
LTAGE
K
EGULATOR
1
B1
EMOTE PANEL
OPTIONAL
EL
B2
N
B
LACK
PE WINDIN
F
20V 20A - QP55 20V 30A - QP65 20V 35A - QP75
20V 30A - QP55 & QP65 20V 35A - QP75
LACK
Generac®Power Systems, Inc. 39
Section 10 — Electrical Data
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
V-Twin – Drawing No. 0E1057-B
3
5
CUSTO
PPLIED BY
O
CUSTO
S
CUSTO
C
S
G
S
S
MER
M
A
1-1
B
A
H
NN. 2
PPLIED BY
MER
1
2
W2
LECTRONI
LTAGE
EGULATOR
TATOR
2 1
LOSEST TO BEARIN
F
K
T
F
I
W1
B1
B
F
N
I
T
1
EMOTE
NNECTOR
3
A
LOP
T
A
A
P1
B2
LACK
LACK
REEN
TOMER
CONNECTION
EUTRAL CONNECTION Y
MER
40 Generac®Power Systems, Inc.
0
3
5
6
0
8
9
3
2
5
6
8
5
0
3
6
8
9
6
A
.
Section 11 — Exploded Views and Parts Lists
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators Base & Pulley – Drawing No. 0E1323-A
"
1
1
1
1
2
2
"
1
1
2
1
1
2
2
2
4
4
2
4
4
1
TO CARB
"
4
" "
Generac®Power Systems, Inc. 41
Section 11 — Exploded Views and Parts Lists
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
Base & Pulley – Drawing No. 0E1323-A
ITEM PART NO. QTY. DESCRIPTION
1 0E0196 1 FRAME, 760 ENGINE 2 022129 12 WASHER LOCK M8-5/16 3 022145 15 WASHER FLAT 5/16-M8 ZINC 4 022259 6 NUT HEX 5/16-18 STEEL 5 0C7758 4 VIB MNT 1.5 X 1.38 X 5/16-18 6 0C3168 1 WASHER LOCK SPECIAL 5/16 7 0C2417 1 EARTH STRAP 8 077603 2 SCREW HHC 5/16-18 X 3.5 SPC
9 0E0588 1 SPACER, SAFETY BOLT .375 I.D. 10 029451 1.5 FT. TAPE ELEC UL FOAM 1/8 X ½ 11 0D8912 1 DUCT, AIR OUT 12 0E0571 2 GASKET,AIR OUT DUCT 13 0D8911 1 BRACKET, MUFFLER SUPPORT 14 043107 7 SCREW HHC M8-1.25 X 25 G8.8 15 0D9021 1 MUFFLER, GTV760 RV 16 096289 1 CLAMP, EXHAUST 1.25" 17 0D8940 1 MANIFOLD, EXHAUST 18 070006 4 WASHER LOCK M8 SS 19 070008 4 WASHER FLAT M8 SS 20 040976 4 SCREW SHC M8-1.25 X 20 G12.9 21 056893 6 SCREW CRIMPTITE 10-24 X ½ 22 023897 6 WASHER FLAT #10 ZINC 23 0E1078 2 GASKET, EXH BASE, GTV760 RV 24 0C4138 2 GASKET,EXHAUST PORT 25 043116 3 SCREW HHC M6-1.0 X 12 G8.8 (5.5 KW
ONLY)
26 022097 4 WASHER LOCK M6-1/4 (5.5 KW ONLY)
022097 1 WASHER LOCK M6-1/4 (6.5 & 7.5 KW
ONLY)
27 022473 3 WASHER FLAT 1/4-M6 ZINC (5.5 KW
ONLY) 28 0C1751 1 FAN NYLON 7" DIA (5.5 KW ONLY) 29 0C1753B 1 PULLEY, ALTERNATOR 2200 RPM (5.5 KW
ONLY)
073106B 1 PULLEY, ALTERNATOR 2500 RPM (6.5 &
7.5 KW ONLY)
30 075224A 1 PULLEY, ENGINE 2100 RPM (5.5 KW
ONLY)
075224B 1 PULLEY, ENGINE 2500 RPM (6.5 & 7.5 KW
ONLY)
ITEM PART NO. QTY. DESCRIPTION
31 0E0586 1 GASKET, BOTTOM AIR OUT QPRV 32 0D7176 4 WASHER SELF LOCKING 1"DIA 12GA 33 0E1334 1 SCREEN, BOTTOM AIR OUT 34 0D8824 1 TRAY, V-TWIN RV 35 081105 2 NUT FLG 5/16-18 LOCK 36 073118 1 SCREW HHC 3/8-24 X 2-1/4 G8 37 046526 1 WASHER LOCK M10 38 022131 1 WASHER FLAT 3/8-M10 ZINC 39 0C2824 7 SCREW TAP-R #10-32 X 9/1 40 0E1077 1 BLOWER HOUSING GTV760 RV 41 042633 1 SCREW HHC 3/8-24 X 1 G5 42 022237 1 WASHER LOCK 3/8 43 049451 1 WASHER FLAT .406ID X 1.62OD 44 0C1441 1 SET,BLOWER HOUSING GASKET 45 0C1112 1 BELT,V-RIB 4LX42.5" 46 023484E 1 BUSHING SNAP (GASOLINE ONLY)
0E1534 1 PLUG PLASTIC 0.687" (LP ONLY) 47 0D7530 1 STUD, M6-1.0 OFFSET 48 0D9723 1 ELEMENT AIR FILTER 49 0D4511 1 PRECLEANER,AIR GTH990 GASOLINE 50 0D8981 2 FILTER GASKET RV (GASOLINE ONLY)
0D8981 1 FILTER GASKET RV (LP ONLY) 51 0D8451 1 WASHER FLAT .281"ID X 1.25"OD 52 087680 2 NUT WING M6-1.0 53 0D3700 3 NUT FLANGE M6-1.0 NYLOK (GASOLINE
ONLY)
0D3700 1 NUT FLANGE M6-1.0 NYLOK (LP ONLY) 54 087769 1 FILTER FUEL 1/8P-5/16H (GASOLINE
ONLY)
55 0E0570 1 ASSEMBLY,NON SHTOFF FUEL PUMP
(GASOLINE ONLY)
56 0D9919 1 ASSEMBLY, RV V-TWIN FUEL LINE
(GASOLINE ONLY)
57 0E1330 1 GROMMET, 38.1 DIA. CROSS SLIT
(GASOLINE ONLY)
0E1534A 1 PLUG PLASTIC 1.50" (LP ONLY) 58 0A1658 1 WASHER LOCK SPECIAL 1/4" 59 0D5133 1 SCREEN, SPARK ARRESTOR 60 0D5133A 1 RETAINER, SPARK ARREST SCREEN 61 045764 1 SCREW HHTT M4-0.7 X 8 BP
42 Generac®Power Systems, Inc.
R
D
E
ROUND T
O
L
0
0
5
6
3
8
0
3
6
8
9
3
8
6
0
Section 11 — Exploded Views and Parts Lists
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators Enclosure – Drawing No. 0E1011-B
NT. PANE
ROUN
TO ENGIN
2
2
2
ARTE
2
4
"
4
4
4
"
1
1
1
4
1
2
1
2
Generac®Power Systems, Inc. 43
ITEM PART NO. QTY. DESCRIPTION
1 0D8827 1 PANEL, ENCLOSURE ROOF 2 0A7215 22 SCREW SW 1/4-20X5/8 N WA JS500 3 029451 11.5 FT. TAPE ELEC UL FOAM 1/8 X 1/2" 4 0D8825 1 PANEL, SIDE AND BACK ENCLOSURE 5 0D3700 14 NUT FLANGE M6-1.0 NYLOK (GASOLINE ONLY)
0D3700 17 NUT FLANGE M6-1.0 NYLOK (LP ONLY) 6 090388 8 SCREW HHTT M6-1.0 X 12 YC 7 0D8979 1 PANEL, AIR IN DUCT BASE 8 0D8960 1 PANEL, CUSTOMER CONNECTION 9 023484D 1 BUSHING SNAP SB-875-11
10 0E0594 1 COVER, RV AIR CLEANER BOX 11 064113 1 STUD WINGNUT M6-1.0 X 20MM NY 12 0E0575 1 FOAM SEALING STRIP 1" X 12FT 13 0D8980 1 PANEL, AIR IN DUCT BACK 14 0E1376 1 BAFFLE, V-TWIN RV SHORT 15 0E1377 1 BAFFLE, V-TWIN RV LONG 16 0D8628 3.5 FOAM, AIR OUT COMPARTMENT 17 0D8910 1 PANEL, MUFFLER SHIELD 18 0D8826 1 PANEL, ENCLOSURE SIDE 19 0D9162 1 PANEL, FRONT & SIDE ENCLOSURE 20 0C5644 2 SLIDE LATCH,FLUSH 21 0D8828 1 PANEL, ENCLOSURE DOOR 22 0E0585 1 FOAM PANEL, DOOR 1/2"THK QP RV 23 0E1486 1 HARNESS, AC OUTPUT (5.5, 6.5, & 7.5 KW ONLY)
0E1774 1 HARNESS, AC OUTPUT (5.0 & 7.0 KW-50 Hz ONLY)
24 0D9099 1 CUST. CONN.4KW RV REMOTE 25 074908 4 SCREW HHTT M5-0.8 X 10 BP 26 022473 1 WASHER FLAT 1/4-M6 ZINC 27 022097 1 WASHER LOCK M6-1/4 28 022507 1 SCREW HHC 1/4-20 X 1/2 G5 29 0742600149 1 WIRE ASM.BATT.(NEG.) QP RV 30 0C7968 4 NUT HEX JAM 3/8-16 BRASS 31 022237 2 WASHER LOCK 3/8 32 0C7423 1 STUD 3/8-16 X 2-1/4 BRASS 33 0742600151 1 GND WIRE C/PNL TO STUD V-T RV 34 0A4456 1 WASHER LOCK SPECIAL 3/8 35 0D8502 1 NEUTRAL CONNETCTOR UL 36 0E0593 1 STUD, 1/4-20 TO 5/16-18 37 0742600148 1 WIRE ASM BATT. (POS.) QP RV 38 022129 2 WASHER LOCK M8-5/16 (GASOLINE ONLY)
022129 4 WASHER LOCK M8-5/16 (LP ONLY)
39 022259 2 NUT HEX 5/16-18 STEEL 40 045756 8 SCREW HHTT M6-1.0 X 10 YC 41 0A2115 1 WASHER NYLON .250 42 029451A 6.5 FT. TAPE, 1/2" X 1/16" CLOSED CELL 43 0E1534A 1 PLUG PLASTIC 1.50" (GASOLINE ONLY) 44 0A5606 1 ELBOW 90DEG 3/8X3/4 (LP ONLY) 45 0E1528 1 BRACKET, LP REGULATOR MOUNTING (LP ONLY) 46 0A1495 2 SCREW HHTT M4-0.7 X 10 BP (LP ONLY) 47 042907 2 SCREW HHC M8-1.25 X 16 G8.8 (LP ONLY) 48 022145 1 WASHER FLAT 5/16-M8 ZINC (GASOLINE ONLY)
022145 3 WASHER FLAT 5/16-M8 ZINC (LP ONLY)
49 0D8979A 1 PANEL, AIR IN DUCT
Section 11 — Exploded Views and Parts Lists
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
Enclosure – Drawing No. 0E1011-B
44 Generac®Power Systems, Inc.
5
8
8
0
3
6
8
9
9
0
3
6
8
9
0
5
01
04
03
05
06
07
06
P
OR
08
6
3
0
09
C"
Section 11 — Exploded Views and Parts Lists
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators Sheet Metal – Drawing No. 0E1012-B
1
11
TO L REGULAT
"
1
1
1
11511
1
"
7
7
1
1
1
"
1
"
11
1
4
4
1
2
2 2
"
4
4
3
4
4
1
2
2
Generac®Power Systems, Inc. 45
ITEM PART NO. QTY. DESCRIPTION
1 045756 15 SCREW HHTT M6-1.0 X 10 YC 2 0D1131 1 GUARD,FAN 12KW HSB 3 0C3022G 1 HOUSING, BLOWER V-TWIN RV 4 0C9763 4 NUT,GROMMET 1/4 PLUG 5 0D9782 1 HOSE, BREATHER 6 0C3034 1 NUT HEX M24-2.0 G8 YEL CHR 7 0C3033 1 WASHER,BELLEVILLE 25MM BOLT 8 051754 2 SCREW HHC M8-1.25 X 12 G8.8
9 0A5992 2 WASHER SHAKEPROOF INT M8 SS 10 0C3032 1 PLATE, FAN GV-990 11 0C3031 1 FAN NYLON GV-990 12 0C3725A 1 FLYWHEEL ASSY GT-990 13 0C3016A 1 PLATE,BACKING GT990 W/OIL COOL 14 023484F 1 BUSHING SNAP SB-1000-12 15 0D9679A 1 WRAP, CRANKCASE GTV760 RV SPCC 16 0D9708 1 GT760 VERTICAL SHAFT RV ENGINE 17 0D9681A 1 WRAP, CYL 1 GTV760 RV SPCC 18 056893 13 SCREW CRIMPTITE 10-24 X ½ 19 072347 2 SPARK PLUG 20 0E0998 1 CLAMP VINYL 9.5 O.D. TUBE 21 0D8384 1 TUBE, OIL DRAIN & CHECK 22 043790A 1 BARBED EL 90 3/8NPT X 3/8 VS 23 0D3083 1 ASSEMBLY, OIL DRAIN HOSE 24 0E0361A 1 OIL DRAIN / DIPSTICK TUBE VTW 25 0E0393 1 ASSEMBLY, CAP & DIP STICK 26 0C2824 2 SCREW TAP-R #10-32 X 9/16 (GASOLINE
ONLY)
0C2824 1 SCREW TAP-R #10-32 X 9/16 (LP ONLY) 27 065852 1 SPRING CLIP HOLDER .37-.62 28 075246 4 SCREW HHTT 3/8-16 X 1-1/4 CZ 29 0A4456 1 WASHER LOCK SPECIAL 3/8 30 0A2311 2 SCREW SWAGE 1/4-20 X 1 Z/YC 31 070185 1 FILTER, OIL D 69X64 LG 32 0A8584 1 SWITCH OIL PRESSURE HOBBS 33 0A5360 1 SUPPORT OIL FLTR,FLARE 34 043182 2 WASHER LOCK M3 35 0C1085 2 SCREW PPHM M3-0.5 X 8 36 0E1497 1 SWITCH, OIL HIGH TEMP (GASOLINE
ONLY)
075281 1 SWITCH, OIL HIGH TEMP (LP ONLY) 37 0D9399 1 ASSEMBLY, GOVERNOR LEVER 38 0D9513 1 SPRING, GOV.(5.5 KW & 5.0 KW-50HZ
ONLY)
0E1498 1 SPRING, GOV.(6.5/7.5 KW & 7.0 KW-50HZ
ONLY) 39 0D1366 2 BUSHING, GOVERNOR ROD 40 0D9395 1 ROD, GOVERNOR 41 077075 1 BOOT CHOKE SOLENOID (GASOLINE
ONLY) 42 0A7094 2 RHMS 4-40 X 1/4 SEMS (GASOLINE ONLY) 43 0D8590 1 ASSY, BI-METAL/HEATER (GASOLINE ONLY) 44 0D8591 1 SOLENOID, CHOKE (GASOLINE ONLY) 45 045770 1 SCREW HHC M5-0.8 X 10 G8.8 46 049226 1 WASHER LOCK M5 47 051713 1 WASHER FLAT M5 48 0D9402 1 LINKAGE, CHOKE SOLENOID/BELLCRNK
(GASOLINE ONLY) 49 077091 1 COTTER PIN (GASOLINE ONLY) 50 082025 1 NUT LOCK HEX M5-0.8 SS NYL INS 51 0E1247 1 ASSEMBLY, GOV. ADJUSTMENT 52 055173 2 SCREW HHC M8-1.25 X 20 G10.9 53 022129 2 WASHER LOCK M8-5/16 54 022145 2 WASHER FLAT 5/16-M8 ZINC 55 0D9403 1 LINKAGE CHOKE BELLCRANK/CARB 56 0E1246 1 ASSEMBLY, CHOKE BRACKET (GASOLINE
ONLY)
ITEM PART NO. QTY. DESCRIPTION
0D9400 1 BRACKET, CHOKE (LP ONLY) 57 0A7095 2 RHMS 4-40 X 5/16SEMS 58 0D9404 1 SPRING, CHOKE RETURN 59 0D9801A 1 WRAP, VALLEY UPPER SPCC 60 0C3018A 1 WRAPPER,UPR #1 W/ M8 WELD NUT 61 0D9680A 1 WRAP, VALLEY GTV760 RV SPCC 62 0D1143A 1 WRAPPER,UPR #2 W/ M8 WELD NUT 63 0C3053 1 ASSY GROUND WIRE GV990 64 085011 1 INSULATOR ASM IGN 65 0D9852 2 ASSY,IGNITION COIL GT760 RV 66 022097 8 WASHER LOCK M6-1/4 67 092079 4 SCREW HHTT M6-1.0 X 25 BP 68 0C1546 1 O-RING 59.92 X 66.98 X 3.53MM 69 0C1547 1 O-RING 21.89 X 27.13 X 2.62MM 70 082774 1 KEY, WOODRFF 4 X 19D 71 0A5358 1 ADPTR OIL PAD, FLARE 72 0D9312 1 TUBE, ENGINE OIL RETURN 73 0D9314 1 TUBE, ENGINE OIL OUT 74 0C1557 1 O-RING 20.35 X 23.91 X 1.78MM 75 0A9028 1 BOLT, OIL ADAPTOR 76 0D9682A 1 WRAP, CYL 2 GTV760 RV SPCC 77 0D9270 1 INTAKE TUBE 1.25" X 20 GA 78 048031A 2 HOSE CLMP-BAND 1 5/8 79 0D9269 1 BOOT, INTAKE AIRBOX 80 0E0142 1 BOOT, CARB ADAPTOR 81 078643B 2 BOLT,CARB MOUNT M6 X 1.0 -85LG 82 0D9219 1 ADAPTER, AIR INTAKE CARB 83 0E0573 1 GASKET,CARB TO ADAPTOR 84 0D8807 1 CARBURETOR, GT-760 (GASOLINE ONLY)
0E1217 1 CARBURETOR, GT-760 (LP ONLY) 85 0E0572 1 GASKET,CARB TO INTAKE MANIFOLD 86 0C3043 2 GASKET INTAKE PORT GT990 87 0D8836 1 MANIFOLD, INTAKE 760 RV 88 049821 4 SCREW SHC M8-1.25 X 30 G12.9 89 070008 4 WASHER FLAT M8 SS 90 070006 4 WASHER LOCK M8 SS 91 035461A 2 BARBED STR 1/4NPT X 3/8 W/VS 92 040173 4 CLAMP HOSE #5.5 .62 - .62 93 0C9806 2 HOSE,3/8"IDX6"L 300F 94 0C3026 1 COOLER, OIL GV-990 95 0D9683A 1 DUCT, OIL CLR GTV760 RV SPCC 96 0C9764 4 PLASTITE,1/4-15 X ¾ 97 036933 1 SCREW PPHM #10-32 X 3/8 98 0E0246 1 SCREW HHTT #4-40 X ¼ 99 0D9394 1 PLATE, THROTTLE
100 022152 1 WASHER LOCK #10 101 022158 1 NUT HEX #10-32 STEEL 102 043116 2 SCREW HHC M6-1.0 X 12 G8.8 103 049811 4 WASHER FLAT M6 104 047411 2 SCREW HHC M6-1.0 X 16 G8.8 105 066849B 2 SCREW HHTT M5-0.8 X 8 BP 106 057822 2 CLAMP HOSE #8 .53 - 1.00 (LP ONLY) 107 074994 2.25 FT. HOSE 1\2 ID (LP ONLY) 108 075476 1 SCREW PPHM M4-0.7 X 16 (GASOLINE
ONLY)
109 082121A 1 CLIP-J VINYL COAT .375 ID (GASOLINE
ONLY) 110 038150 1 WASHER FLAT #8 (GASOLINE ONLY) 111 022264 1 WASHER LOCK #8 (GASOLINE ONLY) 112 051715 1 NUT HEX M4-0.7 G8 YC (GASOLINE ONLY) 113 0D6029 2 SCREW HHTT M6-1.0 X 16 YC 114 055934D 1 CLAMP VINYL 1.06 X .406 (LP ONLY) 115 022473 1 WASHER FLAT 1/4-M6 (LP ONLY) 116 090388 1 SCREW HHTT M6-1.0 X 12 (LP ONLY)
Section 11 — Exploded Views and Parts Lists
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
Sheet Metal – Drawing No. 0E1012-B
46 Generac®Power Systems, Inc.
0
3
5
6
8
9
0
3
5
6
0
3
6
9
Section 11 — Exploded Views and Parts Lists
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators Control Panel – Drawing No. 0E1013-A
1
1
4
2
4
4
2
1
1
4
1
1
2
2
Generac®Power Systems, Inc. 47
ITEM PART NO. QTY. DESCRIPTION
1 0C2375 2 SCREW HHC M8-1.25 X 90 G8.8 2 022145 2 WASHER FLAT 5/16-M8 ZINC 3 029459 2 TENSION SPRING 4 075215 2 WASHER, SPRING CENTER 5 052858 6 NUT LOCK FL M8-1.25 6 047411 7 SCREW HHC M6-1.0 X 16 G8.8 7 022097 13 WASHER LOCK M6-1/4 8 022473 10 WASHER FLAT 1/4-M6 ZINC
9 080925 8 WASHER NYLON .404 10 0D9921 4 STANDOFF, 1/2" HEX 11 066849 2 SCREW HHTT M5-0.8 X 16 12 066386 1 ASSY, BRUSH HOLDER 13 0C9674 1 BEARING CARRIER, UP 14 0E0363H 1 STATOR ASSEMBLY (5.5 KW ONLY)
0E0364H 1 STATOR ASSEMBLY (6.5 KW ONLY)
0E0362H 1 STATOR ASSEMBLY (7.5 KW ONLY) 15 073159 1 BEARING BALL 16 077005H 1 ROTOR ASSEMBLY (5.5 KW ONLY)
077004H 1 ROTOR ASSEMBLY (6.5 KW ONLY)
073163H 1 ROTOR ASSEMBLY (7.5 KW ONLY) 17 031971 1 BEARING 18 077006 4 STUD,RV STATOR D/C 19 0C9675 1 BEARING CARRIER, LOW 20 0A5351 1 NYLON SLIDE 21 073146 2 SLIDE, NYLON 22 0C1878 2 SUPPORT, SLIDE 23 075242 4 SPRING, GEN.MOUNT 24 075237 4 WASHER, SPRING CENTER 25 090145 1 CIRCUIT BREAKER 30 X 1 (5.5 & 6.5 KW
ONLY)
0E1529 1 CIRCUIT BREAKER 35 X 1 (7.5 KW ONLY) 26 090144 1 CIRCUIT BREAKER 20 X 1 (5.5 KW ONLY)
090145 1 CIRCUIT BREAKER 30 X 1 (6.5 KW ONLY)
0E1529 1 CIRCUIT BREAKER 35 X 1 (7.5 KW ONLY) 27 025105 4 SCREW RHM 6-32 X 1/4 SIMS 28 0A9611 1 FUSE 7.5 AMP 29 032300 1 HOLDER FUSE 30 092113 1 SWITCH SPDT ON-MOM-ON 31 087798 1 SWITCH 6A SPDT 32 055440 2 SCREW HHC M5-0.8 X 25 G8.8 33 0D9377 1 PANEL, TOP CONTROL
ITEM PART NO. QTY. DESCRIPTION
34 054502 1 CIRCUIT BREAKER 3 X 1 35 031879 4 WASHER FLAT #4 ZINC 36 043182 4 WASHER LOCK M3 37 051714 4 NUT HEX M3-0.5 G8 YEL CHR 38 092234 1 ASSY POTTED RV CNTL 39 049226 5 WASHER LOCK M5 40 051716 3 NUT HEX M5-0.8 G8 YEL CHR 41 023484R 2 BUSHING SNAP 42 0D3700 1 NUT FLANGE M6-1.0 NYLOK 43 0D9378 1 PANEL, BOTTOM CONTROL 44 052619 1 SCREW HHC M5-0.8 X 20 G8.8 45 075476 2 SCREW PPHM M4-0.7 X 16 46 065795 1 RECTIFIER-BATTERY CHARGE 47 0C2174 1 RELAY 12V 25A SPST 48 092120 4 NUT LOCK TRIC M6 X 1.0 Y/ZNC 49 049721 2 SCREW HHC M6-1.0 X 35 G8.8 BLK 50 0A1658 2 WASHER LOCK SPECIAL 1/4" 51 074260-146 1 WIRE ASM GRD STD CONN. 52 049813 4 NUT HEX M6 X 1.0 G8 YEL CHR 53 023484D 1 BUSHING SNAP 54 074260-151 1 GROUND WIRE C/PNL TO STUD V-T RV 55 084867 1 RUBBER U-CHANNEL 56 043181 2 SCREW PHM M3-0.5 X 10MM 57 075210A 1 BLOCK 1 POSITION 58 022264 2 WASHER LOCK #8-M4 59 051715 2 NUT HEX M4-0.7 G8 YEL CHR 60 0C7605 2 SCREW HHC M5-0.8 X 60 G8.8 61 083049 1 ASY POTTED REG W/FIN 62 089047 2 SPACER .25 X .43 X .55 ST/ZNC 63 075234 1 RESISTOR WW LUG 1R 5% 25W 64 0A2053 1 SCREW HHC M6-1.0 X 65 G8.8 65 058000K 2 NUT TRIC M5 X .8 66 0D8941 1 COMPARTMENT, AIR BOX 67 029451A 2.3 FT. TAPE, 1/2" X 1/16" CLOSED CELL 68 0E0583 1 WIRE HARNESS, QP RV (GASOLINE
ONLY)(NOT SHOWN)
0E1812 1 WIRE HARNESS, QP RV (LP ONLY) (NOT
SHOWN)
69 0E1375 1 WIRE ASS'Y STARTER TO C/PNL (NOT
SHOWN)
Section 11 — Exploded Views and Parts Lists
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
Control Panel – Drawing No. 0E1013-A
48 Generac®Power Systems, Inc.
Section 11 — Exploded Views and Parts Lists
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators 760 V-Twin Engine – Drawing No. 0E1014-B
8
5
6
7
3
9
0
3
0
9
8
6
8
9
5A
5B
5A
3
6
5
1
1
1
1
1
1
1
2
2
4
4
2
2
4
4
4
2
4
2
4
Generac®Power Systems, Inc. 49
ITEM PART NO. QTY. DESCRIPTION
1 0C5730A 1 ASSEMBLY, CRANKCASE RV 2 0C3008 1 SEAL, 38 I.D.CRANKCASE 3 090388 6 SCREW, HHTT M6-1.0 X 12mm 4 0C5372 1 ASSEMBLY, BREATHER 5 0C3005 1 GASKET, BREATHER COVER 6 0C3003 3 SEPARATOR, OIL BREATHER 7 0D8067A 1 ASSEMBLY, HEAD #1 8 0C2981C 1 COVER, ROCKER
9 071983 4 RETAINER, PISTON PIN 20 10 0C5848 2 PISTON, HC 11 021533 2 SET, PISTON RING 90mm 12 071980 2 PIN , PISTON D20 13 0D4041 1 ASSEMBLY, CAMSHAFT & GEAR 14 0C2983 1 SHAFT, GOVERNOR
15A 0C2985A 2 ROLLER BEARING, GOVERNOR PLATE 15B 0C2985B 1 ROLLER BEARING, GOVERNOR
16 0D4042 1 ASSEMBLY, GOVERNOR GEAR 17 0A7811 1 SPOOL, GOVERNOR MACHINED 18 0C2977 1 GASKET, CRANK CASE 19 0C5943 1 SEAL, OIL PASSAGE 20 0D4122A 1 ASSEMBLY, CRANKSHAFT 21 0D3961 2 ASSEMBLY, CONNECTING ROD 22 0C2978 2 GASKET, HEAD 23 093873 3 WASHER, LOCK RIB M6 24 021374 3 SCREW, SHC M6-1.0 X 30mm 25 0C2994 1 SCREEN, OIL PICKUP 26 0C2997 1 COVER, GEROTOR 27 0C2995 1 GEROTOR, INNER 28 0C2996 1 GEROTOR, OUTER 29 0C3011 2 COVER, OIL RELIEF 30 0C3009 2 SPRING, OIL RELIEF 31 0C3010 2 BALL, 1/2D OIL RELIEF 32 050873A 1 1/4" NPT PIPE PLUG
ITEM PART NO. QTY. DESCRIPTION
33 0C2991 2 E-RING, GOVERNOR ARM 34 0D1667A 1 ARM, GOVERNOR 35 0C2988 1 THRUST W ASHER, GOVERNOR 36 0C2992 1 BUSHING, GOVERNOR LOWER 37 0C5732 1 ASSEMBLY, SUMP WITH SLEEVE 38 0C2993 1 SEAL, GOVERNOR SHAFT 39 0C3007 1 SEAL, 42 I.D.CRANKSHAFT 40 0D9756 1 CONNECTOR, 3/8NPT TO INVTD FLR
3/8OD 41 0C3006 10 SCREW, HHFC M10-1.5 X 55mm 42 0C8566 8 SCREW HHFC M6-1.0 X 20mm 43 0C2982 1 COVER, ROCKER WITH OIL FILL 44 093064 1 ASSEMBLY, OIL FILL CAP 45 0C2979 2 GASKET, VALVE COVER 46 086515 8 KEEPER, VALVE SPRING 47 0D2274 4 RETAINER, VALVE SPRING 48 0D3867 4 SPRING, VALVE 49 078672 2 SEAL, VALVE STEM D7 50 0C5371 4 WASHER, VALVE SPRING 51 0D5326 4 NUT, JAM ROCKER ARM 52 0D5354 4 PIVOT, ROCKER ARM 53 0D5313 4 ROCKER ARM 54 0D6023 4 STUD, ROCKER ARM M8-1.0 x 57mm 55 0D6024 2 PLATE, PUSH ROD GUIDE 56 0C2976 12 SCREW HHFC M8-1.25 X 65mm 57 0D8067B 1 ASSEMBLY, HEAD #2 58 0C2229 2 VALVE, INTAKE 59 086516 2 VALVE, EXHAUST 60 0D9853D 4 PUSHROD 147 61 083897 4 TAPPET, SOLID 62 0C3017 1 STARTER, V-TWIN ENGINE 63 022129 2 WASHER LOCK M8 64 061906 2 SCREW, HHC M8-1.25 X 85mm
Section 11 — Exploded Views and Parts Lists
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
760 V-Twin Engine – Drawing No. 0E1014-B
50 Generac®Power Systems, Inc.
0
3
5
9
3
4
5
6
6
8
0
Section 11 — Exploded Views and Parts Lists
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators LP Regulator – Drawing No. 0E1530
1
1
1
1
1
1
2
2
2
2
2
Generac®Power Systems, Inc. 51
ITEM PART NO. QTY. DESCRIPTION
1 0D5694 1 CASTING, TWIN REGULATOR HOUSING 2 075475 4 SCREW PPHM M4-0.7 X 10 3 022264 4 WASHER LOCK #8-M4 4 043180 4 WASHER FLAT M4 5 0C5765 1 SOLENOID, TWIN REGULA T OR 6 0C6070 1 SPRING-SOLENOID PLUNGER 7 0C4680 1 PLUNGER LP REG. ASSY 8 0C4647 1 GASKET, SOLENOID
9 0C4643 1 INLET, TWIN REGULATOR NO HOLE 10 0D3973 1 PLUG, EXPANSION 16MM TWINREG 11 0C6606 1 BARBED STR 1/2 X 1/2NPT W/VS 12 026073 2 PLUG STD PIPE 1/8 STEEL SQ HD 13 0D3308 2 WASHER FLAT 3.2MM ID X 10MM OD 14 070728 2 SCREW PFILHM M3-0.5 X 5 15 0C5764 1 SPRING, REGULATOR 45N/M 32MM 16 0C4643A 1 INLET, TWIN REG 11.11 DIA. 17 0C6066 1 SEAL, INLET REGULATOR 18 0C5968 1 SUPPORT, INLET SEAL 19 0C5759 1 PIN, PIVOT ARM 20 0C5761 1 LEVER, REGULATOR 21 0C6069 1 GASKET, DIAPHRAGM 22 0C6731 1 RIVET .118 X .125 ALUMINUM 23 0C6067 1 SUPPORT, DIAPHRAGM 24 0C4706 1 DIAPHRAGM, TWIN REGULAT OR 25 0C6068 1 CAP, DIAPHRAGM SUPPORT 26 0C5762 1 COVER,TWIN REGULATOR 27 045764 8 SCREW HHTT M4-0.7 X 8 BP
Section 11 — Exploded Views and Parts Lists
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
LP Regulator – Drawing No. 0E1530
52 Generac®Power Systems, Inc.
Section 12 – Warranty
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
CALIFORNIA AND FEDERAL EMISSION CONTROL WARRANTY STATEMENT
YOUR WARRANTY RIGHTS AND OBLIGATIONS
The California Air Resources Board (CARB) and the United States Environmental Protection Agency (EPA), together with Generac Power Systems, Inc. (Generac), are pleased to explain the Emission Control System Warranty on your new engine.* New utility, and lawn and garden equipment engines must be designed, built and equipped to meet stringent anti-smog stan­dards for the state of California and the federal government. Generac will warrant the emission control system on your engine for the periods of time listed below provided there has been no abuse, neglect, unapproved modification or improp­er maintenance of your engine.
Your emission control system may include parts such as the carburetor, ignition and exhaust systems. Generac will repair your engine at no cost to you for diagnosis, replacement parts and labor, should a warrantable condition occur.
MANUFACTURER’S EMISSION CONTROL SYSTEM WARRANTY COVERAGE:
Emissions control systems on 1997 and later model year engines are warranted for two years as hereinafter noted. If, dur­ing such warranty period, any emission-related component or system on your engine is found to be defective in materials or workmanship, repairs or replacement will be performed by a Generac Authorized Warranty Service Facility.
PURCHASER’S/OWNER’S WARRANTY RESPONSIBILITIES:
As the engine purchaser/owner, you are responsible for the completion of all required maintenance as listed in your factory supplied Owner’s Manual. For warranty purposes, Generac recommends that you retain all receipts covering maintenance on your engine. However, Generac cannot deny warranty solely because of the lack of receipts or for your failure to ensure the completion of all scheduled maintenance.
As the engine purchaser/owner, you should, however, be aware that Generac may deny any and/or all warranty coverage or responsibility if your engine, or a part/component thereof, has failed due to abuse, neglect, improper maintenance or unap­proved modifications, or the use of counterfeit and/or ‘grey market’ parts not made, supplied or approved by Generac.
You are responsible for presenting your engine to a Generac Authorized Warranty Service Facility as soon as a prob­lem occurs. The warranty repairs should be completed in a reasonable amount of time, not to exceed 30 days.
Warranty service can be arranged by contacting either your selling dealer or a Generac Authorized Warranty Service Facility. To locate the Generac Authorized Warranty Service Facility nearest you, call our toll-free number:
1-800-333-1322
IMPORTANT NOTE: This warranty statement explains your rights and obligations under the Emission Control System Warranty (ECS Warranty), which is provided to you by Generac pursuant to California and federal law. See also the “Generac Limited Warranties for Generac Power Systems, Inc.,” which is enclosed herewith on a separate sheet, also provided to you by Generac. The ECS Warranty applies only to the emission control system of your new engine. If there is any conflict in terms between the ECS Warranty and the Generac Warranty, the ECS Warranty shall apply except in circumstances where the Generac Warranty may provide a longer warranty period. Both the ECS Warranty and the Generac Warranty describe important rights and obligations with respect to your new engine.
Warranty service can be performed only by a Generac Authorized Warranty Service Facility. When requesting warranty ser­vice, evidence must be presented showing the date of the sale to the original purchaser/owner. The purchaser/owner shall be responsible for any expenses or other charges incurred for service calls and/or transportation of the product to/from the inspection or repair facilities. The purchaser/owner also shall be responsible for any and/or all damages or losses incurred while the engine is being transported/shipped for inspection or warranty repairs.
If you have any questions regarding your warranty rights and responsibilities, you should contact Generac at the fol­lowing address:
ATTENTION WARRANTY DEPARTMENT
GENERAC POWER SYSTEMS, INC.
P.O. BOX 297
WHITEWATER, WI 53190
Part 1
Generac®Power Systems, Inc. 53
Section 12 – Warranty
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
EMISSION CONTROL SYSTEM WARRANTY
Emission Control System Warranty (ECS Warranty) for 1997 and later model year engines:
(a) Applicability: This warranty shall apply to 1997 and later model year engines. The ECS Warranty Period shall begin on
the date the new engine or equipment is purchased by/delivered to its original, end-use purchaser/owner and shall contin­ue for 24 consecutive months thereafter.
(b) General Emissions Warranty Coverage: Generac warrants to the original, end-use purchaser/owner of the new engine or
equipment, and to each subsequent purchaser/owner, that each of its engines is ...
(1) Designed, built and equipped so as to conform with all applicable regulations adopted by the EPA and CARB pursuant
to their respective authority, and
(2) Free from defects in materials and workmanship which, at any time during the ECS Warranty Period, may cause a war-
ranted emissions-related part to fail to be identical in all material respects to the part as described in the engine manu­facturer’s application for certification.
(c) The ECS Warranty only pertains to emissions-related parts on your engine, as follows:
(1) Any warranted, emissions-related parts that are not scheduled for replacement as required maintenance in the Owner’s
Manual shall be warranted for the ECS Warranty Period. If any such part fails during the ECS Warranty Period, it shall be repaired or replaced by Generac according to Subsection (4) below. Any such part repaired or replaced under the ECS Warranty shall be warranted for the remainder of the ECS Warranty Period.
(2) Any warranted, emissions-related part that is scheduled only for regular inspection as specified in the Owner’s Manual
shall be warranted for the ECS Warranty Period. A statement in such written instructions to the effect of “repair or replace as necessary” shall not reduce the ECS Warranty Period. Any such part repaired or replaced under the ECS Warranty shall be warranted for the remainder of the ECS Warranty Period.
(3) Any warranted, emissions-related part that is scheduled for replacement as required maintenance in the Owner’s
Manual shall be warranted for the period of time prior to the first scheduled replacement point for that part. If the part fails prior to the first scheduled replacement, the part shall be repaired or replaced by Generac according to Subsection (4) below. Any such emissions-related part repaired or replaced under the ECS Warranty shall be warranted for the remainder of the ECS Warranty Period prior to the first scheduled replacement point for such emissions-related part.
(4) Repair or replacement of any warranted, emissions-related part under this ECS Warranty shall be performed at no
charge to the owner at a Generac Authorized Warranty Service Facility.
(5) When the engine is inspected by a Generac Authorized Warranty Service Facility, the owner shall not be held responsi-
ble for diagnostic costs if the repair is deemed warrantable.
(6) Generac shall be liable for damages to other original engine components or approved modifications proximately caused
by a failure under warranty of any emission-related part covered by the ECS Warranty.
(7) Throughout the ECS Warranty Period, Generac shall maintain a supply of warranted emission-related parts sufficient
to meet the expected demand for such emission-related parts.
(8) Any Generac authorized and approved emission-related replacement part may be used in the performance of any ECS
Warranty maintenance or repairs and will be provided without charge to the purchaser/owner. Such use shall not reduce Generac’s ECS Warranty obligations.
(9) Unapproved, add-on, modified, counterfeit and/or ‘grey market’ parts may not be used to modify or repair a Generac
engine. Such use voids this ECS Warranty and shall be sufficient grounds for disallowing an ECS Warranty claim. Generac shall not be held liable hereunder for failures of any warranted parts of a Generac engine caused by the use of such an unapproved, add-on, modified, counterfeit and/or ‘grey market’ part.
EMISSION RELATED PARTS INCLUDE THE FOLLOWING:
*Generac engine types covered by this warranty statement include the following:
1) Utility
2) Lawn and Garden Equipment
3) Recreational Vehicle (RV) Generator
4) Industrial Mobile (IM) Generator
Part 2
1) Fuel Metering System:
1.1) Gasoline carburetor assembly and its internal components (if so equipped).
a) Fuel filter (if so equipped) b) Carburetor gaskets c) Fuel pump (if so equipped)
1.2) LPG carburetion assembly and its internal components (if so equipped).
a) Fuel controller (if so equipped) b) Mixer and its gaskets (if so equipped) c) Carburetor and its gaskets (if so equipped) d) Primary gas regulator (if so equipped) e) LP liquid vaporizer (if so equipped)
2) Air Induction System including: a) Intake pipe/manifold b) Air cleaner
3) Ignition System including: a) Spark plug b) Ignition module
4) Catalytic Muffler Assembly (if so equipped) including: a) Muffler gasket b) Exhaust manifold
5) Crankcase Breather Assembly including: a) Breather connection tube
Part No. 0E1015 Revision B (08/30/02) Printed in U.S.A.
Section 12 – Warranty
QUIETPACT 55, 65, and 75 Recreational Vehicle Generators
GENERAC POWER SYSTEMS’ THREE-YEAR LIMITED WARRANTY
FOR RECREATIONAL VEHICLE GENERATORS
NOTE: ALL UNITS MUST BE INSTALLED BY GENERAC POWER SYSTEMS AUTHORIZED SERVICE FACILITIES.
For a period of 3 (three) years or 2,000 (two thousand) hours of operation from the date of original sale, whichever occurs first, Generac Power Systems, Inc. (Generac) will, at its option, repair or replace any part which, upon examination, inspec­tion and testing by Generac or a Generac Authorized Warranty Service Facility, is found to be defective under normal use and service, in accordance with the warranty schedule set forth below. Any equipment that the purchaser/owner claims to be defective must be returned to and examined by the nearest Generac Authorized Warranty Service Facility. All trans­portation costs under the warranty, including return to the factory, are to be borne and prepaid by the purchaser/owner. This warranty applies only to Generac generators sold and rated for “Recreational Vehicle” (RV) applications, as Generac has defined Recreational Vehicle generator applications. This warranty is effective only upon Generac’s receipt, from the original purchaser/owner, of a completed Warranty Registration Card. This card is the only valid registration identification and must be presented at time of request for warranty service. Claims will not be accepted without presentation of the Warranty Registration Card. The factory recommends exercising the unit one half-hour every season.
WARRANTY SCHEDULE – COMMERCIAL APPLICATIONS
YEAR ONE – 100% (one hundred percent) coverage on part(s), labor, removal and reinstallation listed:
• Engine – All components
• Alternator – All components
WARRANTY SCHEDULE – CONSUMER/PERSONAL APPLICATIONS
YEARS ONE AND TWO – 100% (one hundred percent) coverage on part(s), labor, removal and reinstallation listed:
• Engine – All components
• Alternator – All components YEAR
THREE – 100% (one hundred percent) only on selected part(s) and labor listed (Any labor and part(s) not listed, and
removal and reinstallation are the owner’s responsibility):
Rotor, Stator, Computer Control Board, (if applicable with regard to the generator) Cylinder Block, Cylinder Head, Crankshaft,
Piston(s), Valve, Valve Lifter(s), Intake and Exhaust Manifolds
Generac RV generators manufactured prior to December 31, 1997, DO NOT have a transferable warranty. Generac RV gen­erators manufactured after January 1, 1998, have a transferable warranty to the second owner ONLY for the remainder of the three-year limited warranty. Proof-of-purchase is required and must be presented to a Generac Authorized Warranty Service Facility prior to the performance of any warranty service.
All warranty expense allowances are subject to the conditions defined in Generac’s
SUPER SE
RRVV
ICE INFORMATION MANUAL.
THIS WARRANTY SHALL NOT APPLY TO THE FOLLOWING:
• Generac Guardian generators that utilize non-Generac replacement parts.
• Costs of normal maintenance, adjustments, installation and start-up.
• Failures caused by any contaminated fuels, oils, coolants or lack of proper fluid amounts.
• Failures due, but not limited, to normal wear and tear, accident, misuse, abuse, negligence or improper installation. As with all mechanical devices, the Generac engines need periodic part(s) service and replacement to perform well. This warranty will not cover repair when normal use has exhausted the life of a part(s) or engine.
• Failures caused by any external cause or act of God, such as collision, theft, vandalism, riot or wars, nuclear holocaust, fire, freezing, lightning, earthquake, windstorm, hail, volcanic eruption, water or flood, tornado or hurricane.
• Damage related to rodent infestation.
• Products that are modified or altered in a manner not authorized by Generac in writing.
• Any incidental, consequential or indirect damages caused by defects in materials or workmanship, or any delay in repair or replacement of the defective part(s).
• Failure due to misapplication.
• Telephone, cellular phone, facsimile, internet access or other communication expenses.
• Living or travel expenses of person(s) performing service, except as specifically included within the terms of a specific unit warranty period.
• Expenses related to "customer instruction" or troubleshooting where no manufacturing defect is found.
• Rental equipment used while warranty repairs are being performed.
• Overnight freight costs for replacement part(s).
• Overtime labor.
• Starting batteries, fuses, light bulbs and engine fluids.
THIS WARRANTY IS IN PLACE OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED. SPECIFICALLY, GENERAC MAKES NO OTHER WARRANTIES AS TO THE MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
GENERAC'S ONLY LIABILITY SHALL BE THE REPAIR OR REPLACEMENT OF PART(S) AS STATED ABOVE. IN NO EVENT SHALL GENERAC BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF SUCH DAMAGES ARE A DIRECT RESULT OF GENERAC'S NEGLIGENCE. Some states do not allow the exclusion or limitation of incidental or conse­quential damages, so the above limitation may not apply to you. This warranty gives you specific legal rights. You also have other rights from state to state.
