PRECAUTIONS
Please follow these precautions:
To prevent fire or shock hazard, do not expose the unit to rain or
moisture.
To prevent electrical shock, do not open the unit. Refer to qualified
personnel for service only.
Do not use the unit continuously for more than 24 hours with camera
auto focus on. It may cause damage to the camera lens.
Be careful not to spill water or other liquids onto the unit, or allow
combustible or metallic objects to get inside the base.
Unplug the visualiser from the wall outlet when it is not being
used for a long period of time.
Clean the unit with a soft cloth lightly moistened with a mild
detergent solution.
Clean the lens carefully with an air spray or soft dry cloth to avoid
scratching it.
Rotate the camera lens cap before power the unit on.
1
2
Contents
Product Introduction ..................................................2
Parts Identification .....................................................3
Making Adjustments...................................................3
Control Panel ..............................................................7
Remote Control Instruction .......................................8
INSTALLING VISUALISER SOFTWARE ....................9
USB PORT .................................................................10
USB Image Capture ..................................................10
Specification .............................................................12
Product Introduction
Thank you for purchasing the visualiser. This visualiser comes with a new
design which is more simple, flexible, portable and with a high resolution. The
visualiser can be used to present 3D objects, texts, graphs, transparencies
2
Contents
Product Introduction ..................................................2
Parts Identification .....................................................3
Making Adjustments...................................................3
Control Panel ..............................................................7
Remote Control Instruction .......................................8
INSTALLING VISUALISER SOFTWARE ....................9
USB PORT .................................................................10
USB Image Capture ..................................................10
Specification .............................................................12
Product Introduction
Thank you for purchasing the visualiser. This visualiser comes with a new
design which is more simple, flexible, portable and with a high resolution. The
visualiser can be used to present 3D objects, texts, graphs, transparencies
and negative films. It can be connected to projector, PC and other multi-media
equipments. The visualiser is not just a equipment in corporate environment
but also a indispensable tool to academic, medical and scientific community.
Parts Identification
Making Adjustments
On the visualiser, there are six places can be adjusted.
1. Adjust Mechanical Arm
This adjustment can increase and decrease image. Hold the visualiser
3
base with one hand, carry the mechanical arm with another hand and
adjust it up and down. The mechanical arm can be moved from almost any
angle.
2. Adjust LED light
The LED light can be rotated 90 degrees. (as blow illustration)
3. Adjust Camera Box
Hole the camera box and rotate it up and down. The camera box can be
rotated 45 degrees.
(as below illustration)
4
base with one hand, carry the mechanical arm with another hand and
adjust it up and down. The mechanical arm can be moved from almost any
angle.
2. Adjust LED light
The LED light can be rotated 90 degrees. (as blow illustration)
3. Adjust Camera Box
Hole the camera box and rotate it up and down. The camera box can be
rotated 45 degrees.
(as below illustration)
