GE MDS TD220X User Manual

TD220X_manual_v8.doc Page 1 of 48 1/27/2017

GE MDS TD220X Manual

Version 8

TD220X_manual_v8.doc Page 2 of 48 1/27/2017

Table of Contents

1 Important Information ............................................................................................................ 3

1.1 Antenna Installation Warnings ........................................................................................ 3

1.2 ESD Notice ..................................................................................................................... 3

1.3 FCC Approval Notice ...................................................................................................... 3

1.4 FCC Part 15 Notice ........................................................................................................ 3

1.5 FCC Part 80 Notice ........................................................................................................ 4

1.6 Industry Canada ICES-003 and RSS-119 (Pending) ..................................................... 4

2 Introduction ........................................................................................................................... 5

3 Interfaces .............................................................................................................................. 6

3.1 Data Interface (DB-25) ................................................................................................... 6

3.2 USB ................................................................................................................................ 7

3.3 Power .............................................................................................................................. 7

3.4 Antenna Connector ......................................................................................................... 7

4 Common Setup Tasks ........................................................................................................... 8

4.1 Key the Transmitter for Test Purposes ........................................................................... 8

4.2 Prepare the Network Interface for a Radio ..................................................................... 8

4.3 Upgrade the Firmware .................................................................................................... 8

4.3.1 Introduction .............................................................................................................. 8

4.3.2 Installing TD220X Firmware by TFTP ...................................................................... 8

4.3.3 Upload Procedure .................................................................................................... 9

4.4 Set Up a GPS Base Unit ................................................................................................ 9

4.5 Set Up a PTP Base Unit ................................................................................................. 10

4.6 Set Up an OTA Mobile Unit ............................................................................................ 10

4.7 Perform Test Polling ....................................................................................................... 11

4.8 Perform Field Survey ...................................................................................................... 18

4.8.1 Set up the Base System .......................................................................................... 18

4.8.2 Set up the Mobile System ........................................................................................ 21

5 Menu Interface ...................................................................................................................... 24

5.1 Main Menu ...................................................................................................................... 26

5.2 Network Configuration Menus ........................................................................................ 27

5.3 System Configuration Menu ........................................................................................... 31

5.4 Radio Configuration Menu .............................................................................................. 32

5.5 GPS Configuration Menu ................................................................................................ 33

5.6 PTP Configuration Menu ................................................................................................ 34

5.7 Security Configuration Menu .......................................................................................... 35

5.8 Statistics/Logging Menus ................................................................................................ 36

5.9 Device Information Menus .............................................................................................. 41

5.10 Maintenance/Tools Menus ............................................................................................. 43

6 Troubleshooting .................................................................................................................... 47

7 Change Log ........................................................................................................................... 48

TD220X_manual_v8.doc Page 3 of 48 1/27/2017

1 Important Information

1.1 Antenna Installation Warnings

1. All antenna installation and servicing is to be performed by qualified technical personnel

only. When servicing the antenna, or working at distances closer than those listed below, ensure the transmitter has been disabled.

2. Depending upon the application and the gain of the antenna, the total composite power

could exceed 90 watts EIRP. For fixed/mobile configuration, the distances in the table below must be followed.

Antenna Gain vs. Minimum Safety Distance

(Based upon a 50% Duty Cycle, 0 dB Feedline Loss) Controlled Exposur e limits

Fixed/Mobile Antenna Gain

0-6 dBi

6-10 dBi

10-16.5 dBi

Minimum RF Safety Distance

1.50 meters

2.37 meters

5.01 meters

1.2 ESD Notice

To prevent malfunction or damage to this product, which may be caused by Electrostatic Discharge (ESD), the radio should be properly grounded at the time of installation. In addition, the installer or maintainer should follow proper ESD precautions, such as touching a bare metal object to dissipate body charge, prior to touching components or connecting/disconnecting cables.

1.3 FCC Approval Notice

This device is offered as a licensed transmitter per FCC Parts 80, 90 and 95. It is approved for use under the following conditions: Changes or modifications not expressly approved by the party responsible for compliance will void the user’s authority to operate the equipment.

1.4 FCC Part 15 Notice

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

TD220X_manual_v8.doc Page 4 of 48 1/27/2017

1.5 FCC Part 80 Notice

For FCC Part 80, the Effective Radiated Power (ERP) must be less than or equal to 4 Watts for mobile use and 20 Watts for fixed use. This can be accomplished by adjusting the output power of the radio and selecting an antenna with appropriate gain. Consult the following table for assistance in setting the output power and selecting an antenna to maintain compliance. The table provides examples, however other combinations can be used.

Radio Power Setting

ERP

Maximum Antenna Gain

2 W

4 W

3 dBd (5.2 dBi)

4 W

0 dBd (2.2 dBi)

2 W

20 W

10dBd (12.2 dBi)

10 W

20 W

3 dBd (5.2 dBi)

20 W

0 dBd (2.2 dBi)

1.6 Industry Canada ICES-003 and RSS-119 (Pending)

This Class A digital apparatus complies with Canadian ICES-003 and with RSS-119. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

TD220X_manual_v8.doc Page 5 of 48 1/27/2017

2 Introduction

The GE MDS TD220X is a 25-Watt 220 MHz GMSK data radio intended for bridging messages over the air between locomotives and wayside devices. The data interface is Ethernet and uses the UDP/IP-based Simple Timeslot/Frequency/Power Protocol (STFP), defined elsewhere. STFP is capable of supporting various payload protocols.

A time division channel access method is used by the TD220X for wireless communication. Each second is divided into 8 133-byte time slots. The radio further defines a multi-second epoch to allow the effective number of time slots to be scaled according to system design. Radios must be configured with the same epoch size.

Precise synchronization of timing amongst radios is necessary for operation. Each radio can be configured to use one of three timing sources: GPS, Precision Time Protocol (PTP), and over-the-air (OTA). While system design can be flexible, a base radio installation typically uses either GPS or PTP timing and a mobile radio typically uses OTA to synchronize to the wireless transmissions of a base radio. Radios configured for GPS timing must be connected to an external GPS unit to receive NMEA sentence information and the PPS signal. Radios configured for PTP timing will interact with a PTP Grandmaster Clock over the Ethernet port using IEEE 1588 (PTPv2). Radios configured for OTA timing use messages received wirelessly in the first time slot of each second to maintain timing.

With its time slot definition and variable epoch size, the TD220X provides a generic TDMA implementation that can be used by an external Communication Manager (CM) to support a variety of TDMA schemes. A CM is responsible for making decisions regarding timeslot, frequency, power, and payload organization. The TD220X is responsible for requesting data from a CM for upcoming timeslots, forwarding messages received wirelessly to a CM, and wirelessly transmitting messages received from a CM using the specified timeslot, frequency, and power. All communication between the TD220X and a CM is done using STFP.

TD220X_manual_v8.doc Page 6 of 48 1/27/2017

3 Interfaces

3.1 Data Interface (DB-25)

The Data Interface has several ports integrated into one connector: Ethernet, COM1 and COM2 Serial Ports, and GPS signaling. Note that COM3 is connected internally and therefore not available on pins labeled with “COM3.”

DB-25 Pin

Signal

Direction WRT MDS Equipment

Notes

COM3_DCD

Input

Reserved

COM2_TXD

Input

GPS NMEA Data Expected

COM2_RXD

Output

COM2_RTS

Input

COM2_CTS

Output

COM3_TXD

Output

Reserved

GND

Input/Output

COM2_DCD

Output

COM3_CTS

Input

Reserved

COM3_RTS

Output

Reserved

COM3_DTR

Output

Reserved

COM3_RXD

Input

Reserved

GND

Input/Output

ETH_TX_H

Output

ETH_TX_L

Output

ETH_RX_H

Input

ETH_RX_L

Input

EXT_KEY

Output

Reserved

EXT_DET

Input

Reserved

COM2_DTR

Input

ALARM_OUT

Output

Reserved

GPS_PPS_L

Input

Not Connected

GPS_PPS_H

Input

TTL level 1PPS signal input. 0 to 5 VDC nominal.

COM1_RXD

Input

Console

COM1_TXD

Output

Console

The DB-25 connector is female, and the orientation of the connector as looking into the front panel of the unit is as shown below.

12 11 10 9 8 7 6 5 4 3 2 1

24 23 22 21 20 19 18 17 16 15 14

TD220X_manual_v8.doc Page 7 of 48 1/27/2017

3.2 USB

The radio provides a USB Port conforming to version 1.1 of the USB standard. This port is provided for features such as logging STFP messages to text files on a memory stick. Consult GE MDS for information on this feature. The pinout for this connector is given in the table below.

Signal Name

Description

PC_USB_+5V

+5 VDC

USBD-

USB Data Minus

USBD+

USB Data Plus

GROUND

Ground

3.3 Power

The power connector is a screw-secured 2-pin connector.

Signal Name

Direction with respect to MDS Equipment

Description

1 (L)

PWR

Input

13.8 VDC input, 7 Amps maximum.

2 (R)

GROUND

Input

Power return.

The pin orientation as looking into the connector is shown below.

Consult the following table to determine how much current is required for receiving or transmitting vs. input voltage and RF power output.

Voltage (V)

RF Power Out (W)

Duty Cycle (%)

Current Required (A)

Thermal Dissipation (W)

0 (RX)

0.3

TBSL

12 2 100

TBSL

13.8

0 (RX)

0.3

TBSL

13.8

100

1.2

13.8

3.2

13.8

5.5

3.4 Antenna Connector

The Antenna Connector is a type N female connector with 50-Ohm characteristic impedance.

TD220X_manual_v8.doc Page 8 of 48 1/27/2017

4 Common Setup Tasks

Note: For accessing the COM1 console, use a serial terminal emulator program such as HyperTerminal or Putty. The default settings are: baud rate 19200, no parity, 8 data bits, and 1 stop bit. The pins for this port are listed in section 3.1.

4.1 Key the Transmitter for Test Purposes

1. Log in to the radio on its COM1 console using a serial terminal emulator program.

2. Go to the Radio Configuration menu.

3. Select the frequency for the test transmission.

4. Select the RF Output Power to use. Note that power levels greater than 2 Watts will

timeout after a 5-second period by default. Ensure ventilation with supplemental forced airflow if longer durations are desired.

5. Select the Force TX Key menu option.

6. When finished, deselect the Force TX Key menu option.

4.2 Prepare the Network Interface for a Radio

Each radio is assigned an IP Address, a Netmask, and a Gateway IP Address. The IP Address and Netmask should be chosen carefully. The radio will network directly with other equipment with IP Addresses that are on a common Subnet. IP Addresses that begin with the same numerical IP address bits where the Netmask is one will be on the same Subnet. For example, if the IP Address is

10.4.100.1 and the Netmask is 255.255.0.0, the radio will attempt direct Ethernet communication with any node whose IP Address begins with 10.4. If a message is bound for a node outside of the

10.4 network, it will be sent to the Gateway IP address instead so that it can be placed from the radio’s subnet onto another subnet.

1. Log in to the radio on its COM1 console using a serial terminal emulator program.

2. Go to the IP Configuration menu.

3. Set the IP address of the radio, plus the Netmask and Gateway.

4. Go to the Maintenance/Tools Menu and select the Ping Utility.

5. Enter the IP address of a known node on the network.

6. Execute the Ping and observe the results. If the network interface is working properly, Ping

responses should be received.

4.3 Upgrade the Firmware

4.3.1 Introduction

From time-to-time MDS will offer upgrades to the TD220X firmware. Uploading new firmware into the radio does not require that the radio be taken off-line until you want to operate the radio from the new firmware image. You must use the TD220X’s embedded Menu System for all firmware activities, including uploading firmware from a TFTP server. The Menu System can be accessed in one of two ways:

 Terminal-Emulator—Use a terminal emulator program on your PC, such as HyperTerminal

or Putty, connected directly to the TD220X COM1 port via a serial cable.

 Telnet—Text-based access to the Menu System through a network connection.

Firmware images are provided free-of-charge on the MDS Web site at:

http://supportcentral.ge.com/products/sup_products.asp?prod_id=181796

4.3.2 Installing TD220X Firmware by TFTP

To use this function the user will need:

TD220X_manual_v8.doc Page 9 of 48 1/27/2017

 A PC with a TFTP server running.  The IP address of the PC running the TFTP server.

If you do not know your computer’s address on a Windows PC, you can use the RUN function from the Start menu and enter winipcfg or ipcfg to determine your local PC’s IP address. The IP address of the radio can be found on the Starting Information Screen. (See Page 24.) A TFTP server can be found on the MDS web site at:

http://supportcentral.ge.com/products/sup_products.asp?prod_id=181796

4.3.3 Upload Procedure

To upload a new firmware file (tdx-krmd-X_Y_Z.mpk) into the TD220X unit use the following procedure:

1. Launch a TFTP server on a PC connected either directly or via a LAN to the Ethernet port

(LAN) of the radio. On the Options tab, set the outgoing path to the directory containing the firmware image file.

2. Connect to the radio’s Menu System by whichever means is convenient: Telnet via the LAN

or Terminal emulator via the COM1 port.

3. Go to the Reprogramming Menu.

(Starting Menu->Main Menu>Maintenance Menu>Reprogramming Menu)

4. Fill in the information for the: o TFTP Host Address – IP Address of the server (host computer) running the TFTP

server.

o Retrieve File – Name of the file (tdx-krmd-X.Y.Z.mpk) to be pulled from the TFTP

server holding the firmware file.

5. Pull the firmware file through the TFTP server into the TD220X radio.

(Note: the uploaded firmware image file replaces the “Inactive Image” file and

be automatically verified.)

6. Reboot the TD220X radio.

7. Test the radio for normal operation.

8. End of procedure.

4.4 Set Up a GPS Base Unit

1. If not already done, complete steps from 4.2 above.

2. Connect the RS-232 NMEA serial data output from the GPS receiver to the Base Radio via

the radio’s COM2 port. Drive serial data into the radio on DB-25 pin 2.

3. Connect the GPS’s PPS output to the Base Radio. Drive TTL into the radio on DB-25 pin 23.

4. Log in to the radio.

5. Go to the GPS Configuration menu.

6. Verify that the GPS NMEA Baud Rate and PPS Polarity match the connected GPS.

7. Go to the System Configuration menu.

8. Set the timing source to GPS and reboot if necessary.

9. Set the STFP radio ID. Set to 64 (decimal) to match the configuration in the tests below.

10. Set the IP Port on which the base will receive STFP messages from the Communication

Manager.

11. Set the IP Address of the Communication Manager to which timing markers and messages

received from mobiles should be sent.

12. Set the epoch size to match the same value configured on the neighboring radios and

reboot if necessary.

13. Set the STFP slot delay as necessary. This number, multiplied by 125ms, represents the slot

delay allowed from when a timing marker is sent to the Communication Manager to when a data message must be received from the Communication Manager. For most cases the default value of 2 should suffice.

14. Go to the Maintenance/Tools menu.

15. Verify the Ethernet Link using the Ping utility.

TD220X_manual_v8.doc Page 10 of 48 1/27/2017

16. Begin sending UDP data.

17. Verify the TX LED illuminates and the radio begins transmitting over the air.

4.5 Set Up a PTP Base Unit

1. If not already done, complete steps from 4.2 above.

2. Install and configure a PTP Grandmaster Clock. The clock must be connected to the base

through the Ethernet Link. The base also communicates with the Communication Manager using the Ethernet Link; therefore an external switch or router may be required.

3. Log in to the radio.

4. Go to the PTP Configuration menu.

5. Set the IP Port on which the base will receive PTP messages from the Grandmaster Clock.

6. Set the IP Address of the Grandmaster Clock.

7. Set the IP Port of the Grandmaster Clock.

8. Go to the System Configuration menu.

9. Set the timing source to PTP and reboot if necessary.

10. Set the STFP radio ID. Set to 64 (decimal) to match the configuration in the tests below.

11. Set the IP Port on which the base will receive STFP messages from the Communication

Manager.

12. Set the IP Address of the Communication Manager to which timing markers and messages

received from mobiles should be sent.

13. Set the IP Port of the Communication Manager to which timing markers and messages

received from mobiles should be sent.

14. Set the epoch size to match the same value configured on the neighboring radios and

reboot if necessary.

15. Set the STFP slot delay as necessary. This number, multiplied by 125ms, represents the slot

16. Go to the Maintenance/Tools menu.

17. Verify the Ethernet Link using the Ping utility.

18. Begin sending UDP data.

19. Verify the TX LED illuminates and the radio begins transmitting over the air.

4.6 Set Up an OTA Mobile Unit

1. If not already done, complete steps from 4.2 above.

2. Log in to the radio.

3. Go to the System Configuration menu.

4. Set the timing source to OTA and reboot if necessary.

5. Set the STFP radio ID to 0 to match the configurations in the tests below.

6. Set the IP Port on which the mobile will receive STFP messages from the Communication

Manager.

7. Set the IP Address of the Communication Manager to which timing markers and messages

received from bases should be sent.

8. Set the IP Port of the Communication Manager to which timing markers and messages

received from bases should be sent.

9. Set the epoch size to match the same value configured on the neighboring radios and

reboot if necessary.

10. Set the STFP slot delay as necessary. This number, multiplied by 125ms, represents the slot

11. Go to the Maintenance/Tools menu.

12. Verify the Ethernet Link using the Ping utility.

TD220X_manual_v8.doc Page 11 of 48 1/27/2017

13. Ensure at least one base is present in the neighborhood of this radio so that it can detect

beacons and synchronize timing.

14. Begin sending UDP data from a polling program.

15. Verify the TX LED illuminates and the radio begins transmitting over the air.

4.7 Perform Test Polling

1. Set up the Base and Mobile as above.

2. Connect as shown in the following diagram. Note: this is for bench testing only, i.e. not for

sensitivity testing. Sensitivity testing requires complete RF isolation or mixed operation to prevent the leakage path from being the dominant RF path between units. For bench testing, use attenuation so that the signal level at every unit that is participating is around –70 to –50 dBm.

Test Polling Setup

TD220X Base

Set for 2 Watts

TD220X mobile

Set for 2 Watts

Ethernet Switch

30 dB / 50W 30 dB / 50W

Test PC

13.8 VDC < 5 Amps 13.8 VDC < 5 Amps

Radio

COM1 to PC

Serial Port

Radio COM1 to PC Serial Port

TD220X_manual_v8.doc Page 12 of 48 1/27/2017

3. Configure the Base as follows:

System Configuration Menu

-==========================================================================-

A) Timing Source GPS

B) STFP Radio ID 64

C) STFP Receive Port 53000 D) STFP Transmit Address x.x.x.x (Note: Use IP address of Poller PC) E) STFP Transmit Port 50000

F) STFP Epoch Size 6 sec G) STFP Slot Delay 2 H) STFP Send OTA Beacon enabled

I) Timing Signal Timeout 60 Seconds

Select a letter to configure an item, <ESC> for the prev menu

Radio Configuration Menu

-==========================================================================-

A) Transmit Frequency 219.000000 MHz

B) Transmit Frequency 219.000000 MHz

C) Output Power 2 W

D) Enable External PA enabled

E) Max Message Age 60 sec

F) Force Tx Key Normal

TX Key Timeout 5 sec

Select a letter to configure an item, <ESC> for the prev menu

4. Reboot the Base

TD220X_manual_v8.doc Page 13 of 48 1/27/2017

5. Configure the Mobile as follows:

System Configuration Menu

-==========================================================================-

A) Timing Source OTA

B) STFP Radio ID 0

C) STFP Receive Port 53000 D) STFP Transmit Address x.x.x.x (Note: Use IP address of Poller PC) E) STFP Transmit Port 50011

F) STFP Epoch Size 6 sec G) STFP Slot Delay 2 H) STFP Send OTA Beacon disabled

I) Timing Signal Timeout 60 Seconds

Select a letter to configure an item, <ESC> for the prev menu

Radio Configuration Menu

-==========================================================================-

A) Transmit Frequency 219.000000 MHz

B) Transmit Frequency 219.000000 MHz

C) Output Power 2 W

D) Enable External PA enabled

E) Max Message Age 60 sec

F) Force Tx Key Normal

TX Key Timeout 5 sec

Select a letter to configure an item, <ESC> for the prev menu

6. Reboot the Mobile

7. Obtain the TD220X Poller (TD220X_Poller.exe) from GE MDS.

8. In the Poller directory, create or modify the TD220X poller data configuration file

(TD220X_Poller.parms) as shown below.

TD220X_manual_v8.doc Page 14 of 48 1/27/2017

set ::TXparms { { 0 "Type" 8 "00" "RW" } { 1 "Ver" 8 "09" "RW" } { 2 "Radio ID" 32 "00000040" "RW" } { 3 "Radio Cfg Tag" 8 "00" "RW" } { 4 "Timeslot" ts "07" "RW" } { 5 "TX Freq MHz" 32 "30323139" "RW" } { 6 "TX Freq kHz" 24 "303030" "RW" } { 7 "TX Freq Hz" 24 "303030" "RW" } { 8 "RX Freq MHz" 32 "30323139" "RW" } { 9 "RX Freq kHz" 24 "303030" "RW" } { 10 "RX Freq Hz" 24 "303030" "RW" } { 11 "TX Power" 8 "02" "RW" } { 12 "Length" l4 "00000000" "RO" } { 13 "Seq No" sn "00" "RW" } { 14 "Data" nt "123456789012345678901234567890123456789012345678901234567890123456789012345678 9012345678901234567890123456789012345" "RW" } { 15 "CRC32" ck "00000000" "RO" } } set ::RXparms { { 0 "Type" 8 "00" "RW" } { 1 "Ver" 8 "09" "RW" } { 2 "Radio ID" 32 "00000000" "RW" } { 4 "Timeslot" ts "07" "RW" } { 5 "TX Freq MHz" 32 "30323139" "RW" } { 6 "TX Freq kHz" 24 "303030" "RW" } { 7 "TX Freq Hz" 24 "303030" "RW" } { 8 "RX Freq MHz" 32 "30323139" "RW" } { 9 "RX Freq kHz" 24 "303030" "RW" } { 10 "RX Freq Hz" 24 "303030" "RW" } { 11 "RSSI" rs "-120" "RW" } { 12 "Length" l4 "00000000" "RO" } { 13 "Seq No" sn "00" "RW" } { 14 "Data" nt "123456789012345678901234567890123456789012345678901234567890123456789012345678 9012345678901234567890123456789012345" "RW" } { 15 "CRC32" ck "00000000" "RO" } } set ::ERparms { { 0 "Type" 8 "00" "RW" } { 1 "Ver" 8 "00" "RW" } { 2 "Radio ID" 32 "00000000" "RW" } { 4 "Timeslot" ts "07" "RW" } { 5 "TX Freq MHz" 32 "30323139" "RW" } { 6 "TX Freq kHz" 24 "303030" "RW" } { 7 "TX Freq Hz" 24 "303030" "RW" } { 8 "RX Freq MHz" 32 "30323139" "RW" } { 9 "RX Freq kHz" 24 "303030" "RW" } { 10 "RX Freq Hz" 24 "303030" "RW" } { 11 "RSSI" rs "-120" "RW" } { 12 "CRC32" ck "00000000" "RO" } }

TD220X_manual_v8.doc Page 15 of 48 1/27/2017

9. Set up the Poller as shown below, where 10.4.144.100 is replaced with the IP address of

your base radio. Note: Set GPS Serial Port to None to prevent the utility opening a serial port.

10. Click Start Polling and observe the message counts and sequence number increment. The

test will show 100% success if all messages sent to the base radio were transmitted over the air, received by the mobile radio, and forwarded back to the Poller.

+ 33 hidden pages

GE MDS TD220X User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
