Geemarc iLoop Plus User Manual
Neck Loop
Boucle Magnétique
Induktionsschleife
English P1
Français P8
Deutsch P15
1
1. GENERAL
The mobile iLoopTM+ inductive loopset is for
people with hearing aids.
When you use the iLoop
TM
+, you can speak
directly to the caller by the microphone
inside the system. So, the device works as
a wireless system. Compatible with
products equipped with a standard 3.5mm
coaxial microphone, headset socket &
with most cellular like iPhone, Blackberry,
Samsung etc, and DECT....in some
instances you may need to purchase an
adaptor in case the product does not have
a suitable headset socket.
NOTE: Don't forget to switch your hearing
aid to T mode.
GENERAL
2
NOTE:
● OFF: LED is off
● ON: LED is Green
● Low battery: LED is Red
● Battery Charging: LED is Blue
GENERAL
Microphone
Charging,
ON/OFF, low
battery indicator
Loop
ON/OFF
button
Level knob adjustment
Charging USB
socket
Plug for the telephone
connection (Φ3.5mm)
3
2. POWER SUPPLY / CONNECTING
The unit needs 2pcs AAA size 1.2V
rechargeable NiMH batteries for correct
functioning. The batteries must be charged
for about 7 hours before use.
- Open the battery compartment door.
- Insert the batteries supplied with the unit,
making sure the polarity is according to
the diagram inside the battery
compartment.
- To charge the batteries connect the
supplied USB cable to the USB socket of
the unit and then onto a USB power
supply. The blue LED will light up.
- Continue charging until the LED switches
OFF.
- Disconnect the USB cable after the
charging is complete.
- Connect the audio plug of the unit to the
microphone/headphone socket of your
telephone. Your iLoop
TM
+ is now ready for
use.
POWER SUPPLY / CONNECTING
4
NOTE:
● Always disconnect the plug of the
iLoop
TM
+ from the telephone before
installing the batteries.
● Check that the microphone/headphone
socket is compatible with the 3 contact
plug (speaker, mic, common).
● Do not dispose off batteries in household
rubbish. Pay attention to the battery
regulations regarding battery disposal.
POWER SUPPLY / CONNECTING
5
3. MAKING / RECEIVING CALLS
- Place the loop around your neck.
- Switch your hearing aid to T mode.
- Press the ON/OFF button. You are ready
to speak through your iLoop
TM
+.
- The Green LED will turn ON.
- During the call you can adjust the volume
of your device by using the volume control
knob located at the bottom of the iLoop
TM
+.
The iLoop
TM
+ will be automatically turned
OFF at the end of the call or after a few
minutes of silence. It will also turn ON
automatically when there is an Incoming
call or if the person at the other end speaks
after a long pause.
NOTE: Voltages presented to the
Telecomminications network are classified
TNV-3 according to EN60950 standard.
NOTE: When the batteries are discharged,
the Red LED will light up. Charge the
batteries immediately to avoid damage to
the unit or the batteries.
MAKING / RECEIVING CALLS
6
4. GUARANTEE
From the moment your Geemarc product is
purchased, Geemarc guarantee it for the period
of one year. During this time, all repairs or
replacements (at our option) are free of
charge.Should you experience a problem then
contact our helpline or visit our website at
www.geemarc.com
. The guarantee does not
cover accidents, negligence or breakages to
any parts. The product must not be tampered
with or taken apart by anyone who is not an
authorised Geemarc representative. The
Geemarc guarantee in no way limits your legal
rights.
IMPORTANT: YOUR RECEIPT IS PART OF YOUR
GUARANTEE AND MUST BE RETAINED AND
PRODUCED IN THE EVENT OF A WARRANTY CLAIM.
DECLARATION : Geemarc Telecom SA
hereby declares that this product is in
compliance with the essential requirements and
other relevant provisions of the Radio
and Telecommunications Terminal
Equipment Directive 1999/5/EEC.
The declaration of conformity may be consulted at
www.geemarc.com
GUARANTEE
The guarantee applies to the
United Kingdom only.
7
5. RECYCLING DIRECTIVES
Recycling directives: The WEEE (Waste
Electrical and Electronic Equipment) Directive
has been put in place so that products at the
end of life are recycled in the best way.
When this product is out of order, please do not
put it in your domestic waste bin. Please use
one of the following disposal options:
- Remove the batteries and deposit them in an
appropriate WEEE skip. Deposit the product
in an appropriate WEEE skip.
- Or hand the old product to the retailer. If you
purchase a new one, they should accept it.
Thus if you respect these instructions
you ensure human health
andenvironmental protection.
For product support and help visit our website
at www.geemarc.com
Telephone: +44 (0)1707 384438
or Fax +44 (0)1707 832529
RECYCLING DIRECTIVES
