VBSR1070
VBSR2060
VBXR1060
VBXR2070
VJSR2070
YBXR1060
YBXR2070
YJSR2070
Washers
Owner’s Manual
Par t No. 175D1807P239 Pub. No. 39-9968 1–98 CG
Congratulations!
You Are Now Part of Our Family.
We’re proud of our quality products and we are committed to providing
dependable service. You’ll see it in this easy-to-use Owner’s Manual and you’ll hear
it in the friendly voices of our customer service department.
Best of all, you’ll experience these values each time you use your washer. That’s
important, because your new washer will be part of your family for many years. And
we hope you will be part of ours for a long time to come.
We thank you for buying our product. We appreciate your purchase, and hope you
will continue to rely on us whenever you need quality appliances for your home.
A Service Partnership.
Safety Information
. . . . . .3
Operating Instructions
Control Panels . . . . . . . . . . . . . .4, 5
Features . . . . . . . . . . . . . . . . . . . . .6
Loading and Using the Washer . . .7
Troubleshooting Tips
Before You Call For Service
. . .8–10
Customer Service
Warranty . . . . . . . . . . . . . . . . . . .15
Service Telephone
Numbers . . . . . . . . . . . .Back Cover
FOR YOUR RECORDS
Write the model and serial numbers here:
#
#
You can find them in the upper right corner on the back of
your washer.
Inside you will find many helpful hints on how to use and maintain
your washer properly. Just a little preventive care on your part can
save you a great deal of time and money over the life of your washer.
You’ll find many answers to common problems in the
Before You
Call For Service
section. If you review our chart of
Troubleshooting Tips
first, you may not need to call for service at all.
READ THIS MANUAL
IF YOU NEED SERVICE
If you do need service, you can relax knowing help is only a phone
call away. A list of toll-free customer service numbers is included in
the back section. Or you can always call the GE Answer Center® at
800.626.2000, 24 hours a day, 7 days a week.
IMPORT ANT!
Staple sales slip or cancelled check here.
Proof of the original purchase date is needed to obtain service
under the warranty.
2
Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
■Install or store where it will not be exposed to
temperatures below freezing or exposed to the weather.
■Properly ground washer to conform with all governing
codes and ordinances. Follow details in Installation
Instructions.
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire
or explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
WATER HEATER SAFETY
Under certain conditions hydrogen gas may be produced in a water heater that has not been used for two weeks
or more. Hydrogen gas can be explosive under these circumstances.
If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury by turning on
all hot water faucets and allowing them to run for several minutes. Do this before using any electrical appliance
which is connected to the hot water system. This simple procedure will allow any built-up hydrogen gas to escape.
Since the gas is flammable, do not smoke or use an open flame or appliance during this process.
PROPER INSTALLATION
This washer must be properly installed and located in
accordance with the Installation Instructions before it is
used. If you did not receive an Installation Instructions
sheet, you can receive one by calling us toll-free at the
GE Answer Center®, 800.626.2000.
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
■Keep the area underneath and around your
appliances free of combustible materials such
as lint, paper, rags, chemicals, etc.
■Close supervision is necessary if this appliance is used
by or near children. Do not allow children to play
on, with, or inside this or any other appliance.
YOUR LAUNDRY AREA
■Never reach into washer while it is moving. Wait
until the machine has completely stopped before
opening the lid.
■Do not mix chlorine bleach with ammonia or acids
such as vinegar and/or rust remover. Mixing
different chemicals can produce a toxic gas which
may cause death.
■Do not wash or dry articles that have been
cleaned in, washed in, soaked in, or spotted with
combustible or explosive substances (such as
wax, oil, paint, gasoline, degreasers, dry-cleaning
solvents, kerosene, etc.) which may ignite or
explode. Do not add these substances to the
wash water. Do not use or place these substances
around your washer or dryer during operation.
■
The laundry process can reduce the flame retardancy
of fabrics. To avoid such a result, carefully follow the
garment manufacturer’s wash and care instructions.
■To minimize the possibility of electric shock, unplug
this appliance from the power supply or disconnect
the washer at the household distribution panel by
removing the fuse or switching off the circuit
breaker before attempting any maintenance or
cleaning.
NOTE:
Turning the Cycle Selector knob to
an off position does
NOT
disconnect the appliance
from the power supply.
■Never attempt to operate this appliance if it is
damaged, malfunctioning, partially disassembled,
or has missing or broken parts, including a damaged
cord or plug.
WHEN USING THE WASHER USE
■Turn off water faucets to relieve pressure on hoses
and valves and to minimize leakage if a break or
rupture should occur. Check the condition of the
fill hoses; they may need replacement after 5 years.
■Before discarding a washer, or removing it from
service, remove the washer lid to prevent children
from hiding inside.
■Do not attempt to repair or replace any part of this
appliance unless specifically recommended in this
Owner’s Manual, or in published user-repair
instructions that you understand and have the skills
to carry out.
■Do not tamper with controls.
WHEN NOT IN USE
Read and follow this Safety Information carefully.
SA VE THESE INSTRUCTIONS
3
Use this
appliance
only for its
intended
purpose as
described in
this Owner’s
Manual.
About the washer control panel.
You can locate your model number on the label on the front of the washer behind the door.
Throughout this manual, features and appearance may vary from your model.
LARGE
OFF
OFF
LOAD SIZE
WASH
RINSE
COLD
COLD
WARM
COLD
SMALL
SUPER
HEAVY
NORMAL
LIGHT SOIL
EXTRA RINSE
PERM. PRESS
KNITS
DELICATES
TEMPERATURE
HOT
COLD
Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
Model VBSR1070
LARGE
OFF
OFF
LOAD SIZE
WASH
RINSE
COLD
COLD
WARM
COLD
SMALL
SUPER
HEAVY
NORMAL
LIGHT SOIL
PERM. PRESS
KNITS
DELICATES
TEMPERATURE
HOT
COLD
Model VBSR2060
MEDIUM
PERMANENT
PRESS
COTTONS
REGULAR
OFF
OFF
LOAD SIZE
WASH
RINSE
COLD
COLD
WARM
COLD
EXTRA
SMALL
EXTRA
LARGE
LIGHT SOIL
PERMANENT PRESS
KNITS
DELICATES
NORMAL
HEAVY
TEMPERATURE
HOT
COLD
Models VBXR1060 and YBXR1060
4
Control Settings
Load Size
The water level should just cover the clothes. Adjust the load size accordingly. Loosely load clothes
no higher than the top row of holes in the washer tub.
Wash/Rinse Temperature
Select the water temperature for the wash and rinse cycles. Always follow fabric manufacturer’s care
label or instructions when laundering. Follow the water temperature guide on the washer lid.
Wash Cycle
The wash cycle controls the length of the washing process. The chart below will help you match the
wash cycle setting with your clothing.
COTTONS For heavy to lightly soiled cottons, household linens, work and play clothes.
REGULAR
PERMANENT For easy care and wrinkle-resistant items.
PRESS
KNITS Specially designed for normally soiled knits.
DELICATES For lingerie and delicate fabrics with light to normal soil.
SOAK For heavily soiled clothes that need to be soaked before washing.
5
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
Models VJSR2070 and YJSR2070
MEDIUM
PERMANENT
PRESS
COTTONS
REGULAR
OFF
OFF
LOAD SIZE
WASH
RINSE
COLD
COLD
WARM
COLD
EXTRA
SMALL
EXTRA
LARGE
LIGHT SOIL
SOAK
PERMANENT PRESS
KNITS
DELICATES
NORMAL
HEAVY
TEMPERATURE
HOT
COLD
Models VBXR2070 and YBXR2070
SMALL
LOAD SIZE
LARGE
SUPER
WASH
RINSE
COLD
COLD
TEMPERATURE
WARM
COLD
HOT
COLD
COTTONS
REGULAR
SOAK
LIGHT SOIL
NORMAL
HEAVY
OFF
PERMANENT
PRESS
PERMANENT PRESS
KNITS
DELICATES
OFF
About washer features.
NOTE: Not all features are available on all washer models.
Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
Liquid Bleach Dispenser (on some models)
The dispenser dilutes liquid chlorine bleach before it reaches into your wash load.
Check clothing care labels for special instructions.
Measure liquid bleach carefully, following instructions on the bottle.
■
Never pour undiluted liquid chlorine bleach directly onto clothes or into the wash basket.
■
Do not pour powdered bleach into bleach dispenser.
Before starting the washer, pour measured amount of bleach directly into bleach
dispenser. Avoid splashing or over-filling dispenser. If you prefer to use powdered
bleach, add it into the wash basket with your detergent.
■
Do not mix chlorine bleach with ammonia or acids such as vinegar and/or rust remover. Mixing can
produce a toxic gas which may cause death.
3
2
1
The Agitator Cap or Fabric Softener Dispenser (depending on model)
The agitator cap
fits into the top of the
agitator. If it accidentally comes off, simply
put it back on.
The fabric softener dispenser
automatically
releases liquid fabric softener at the proper
time during the cycle.
Do not stop the washer during the first
spin. This will cause the dispenser to
empty too soon.
To use, follow these steps:
Make sure dispenser is securely attached
to agitator.
Use only liquid fabric softener. Pour
into dispenser, using amount
recommended on package.
Never pour fabric softener directly on
clothes. It may stain them.
Add water to dispenser until it reaches
the maximum fill line.
3
2
1
Do not pour anything into the agitator if
the agitator cap or dispenser is removed.
Cleaning the Fabric Softener Dispenser (on some models)
Remove the dispenser from the top of the agitator.
Separate the dispenser cup from the cover by grasping the top and pushing down on
the inside of the cup with your fingers. Dispenser cup will pop free from the cover.
To clean the dispenser, soak both the dispenser cup and the dispenser cover in the
following solution:
■
1 US gallon (3.8 liters) warm water
■
1/4 cup (60 ml) heavy duty liquid detergent
■
1 cup (240 ml) bleach
If necessary, loosen build-up with a clean, soft cloth after soaking. Do not use a stiff
brush; you may roughen the surface of the dispenser.
Rinse and reassemble dispenser. Place dispenser back on the agitator.
5
4
3
2
1
Separate for cleaning.
6
Loading and using the washer.
Always follow fabric manufacturer’s care label when laundering.
7
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
Sorting Wash Loads
Proper Use of Detergent
Add detergent and start the washer before adding
clothes so that the detergent can work effectively.
Follow the detergent package directions. Using too
little detergent is a common cause of laundry
problems.
Use more detergent if you have hard water, large
loads, greasy or oily soils or lower water
temperature.
Care and Cleaning of the Washer
Wash Basket:
Leave the lid open after washing to
allow moisture to evaporate. If you want to clean the
basket use a clean soft cloth dampened with liquid
detergent, then rinse. (Do not use harsh or gritty
cleaners.)
Fill Hoses:
Hoses connecting washer to faucet should
be replaced every 5 years.
Lint Filter:
The lint filter is located under the agitator.
It is self-cleaning and requires no maintenance.
Exterior:
Immediately wipe off any spills. Wipe with
damp cloth. Try not to hit surface with sharp objects.
Moving and Storage:
Ask the service technician to
remove water from drain pump and hoses. Do not
store the washer where it will be exposed to the
weather. Call the GE Answer Center®, 800.626.2000
for information on how to keep the tub stationary
when moving the washer.
Long Vacations:
Be sure water supply is shut off at
faucets. Drain all water from hoses if weather will be
below freezing.
Loading the Washer
Load dry items loosely, no higher than the top
row of holes in the washer tub. When loading wet
items make sure you set the load/water level high
enough to allow the items to move freely. Water
level should just cover the clothes. To add items
after washer has started, push in Cycle knob and
submerge additional items next to the agitator.
Close the lid and pull Cycle knob out to restart.
■
Do not wrap large items like sheets around the
agitator.
■
Do not wash fabrics containing flammable
materials (waxes, cleaning fluids, etc.).
■
Agitation will not start with the lid up.
Colors
Whites
Lights
Darks
Soil
Heavy
Normal
Light
Fabric
Delicates
Easy Care
Sturdy Cottons
Lint
Lint Producers
Lint Collectors
Problem Possible Causes What To Do
Washer won’t operate
Washer is unplugged • Make sure cord is plugged securely into a working outlet.
Water supply is turned off • Turn both hot and cold faucets fully on.
Controls are not set • Check controls and make sure Cycle knob is pulled out
properly to ONposition.
Lid is open • Close lid and pull Cycle knob out to
ON
position.
Circuit breaker/fuse is • Check house circuit breakers/fuses. Replace fuses or
tripped/blown reset breaker. Washer should have separate outlet.
Water temperature
Control is not set properly • Check water temperature control and adjust.
is incorrect
Water supply is turned off • Turn both hot and cold faucets fully on and make sure
or improperly connected hoses are connected to correct faucets.
Water valve screens are • Turn off the water source and remove the water
stopped up connection hoses from the upper back of the washer.
Use a brush or toothpick to clean the screens in the
machine. Reconnect the hoses and turn the water
back on.
House water heater is • Make sure house water heater is delivering water
not set properly at 120°F.–140°F.(48°C.–60°C.).
Water won’t drain
Drain hose is kinked or • Straighten drain hose and make sure washer is not
improperly connected sitting on it.
• Top of drain outlet should be less than 8 ft. above floor.
Water leaks
Fill hoses or drain hose is • Make sure hose connections are tight at faucets and
improperly connected make sure end of drain hose is correctly inserted in
and secured to drain facility.
Household drain may • Check household plumbing. You may need
be clogged to call a plumber.
Constant water pressure • Tighten hoses at the faucets and turn the water off
to the fill hoses at the after each use.
water source
• Check condition of the fill hoses; they may need
replacement after 5 years.
Washer is noisy
Washer is uneven • Make sure washer is level and firm to the floor.
Washer load is • Push the Cycle knob in to stop the washer, open the
unbalanced lid and redistribute the load evenly. Close the lid
and restart.
Washer pauses in cycle
The washer normally pauses
between washing steps
Clothes too wet
Incorrect cycle selected • Make sure the cycle selected matches the load
you are washing.
Before you call for service…
8
Troubleshooting Tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.
Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
Problem Possible Causes What To Do
Lint or residue on
Washing too long • Separate lint producers from lint collectors.
clothes
Detergent not dissolving • Add detergent as wash basket fills with water, before you
load clothes.
• Try a liquid detergent.
• Use warmer water temperature.
Overloading • Load clothes no higher than the top row of holes in the
washer tub.
• Make sure load size selector matches clothes load size.
Incorrect use of fabric • Check fabric softener package for instructions and follow
softener directions for using dispenser.
Colored spots
Incorrect use of fabric • Check fabric softener package for instructions and follow
softener directions for using dispenser.
• Pretreat stain and rewash.
Dye transfer • Sort whites or lightly colored items from dark colors.
Wrinkling
Improper sorting • Avoid mixing heavy items (like work clothes) with
light items (like blouses).
• Try a fabric softener.
Overloading or • Load your washer so clothes have enough room
incorrect water level to move freely.
Incorrect wash and • Match Cycle selection to the type of fabric you are
dry cycles washing (especially for easy care loads).
Repeated washing in • Wash in warm or cold water with plenty of detergent.
water that is too hot
T oo many suds
Type of detergent • Switch to a lower sudsing detergent brand and
follow instructions on package.
Very soft water • Try less detergent.
Snags, holes, tears, rips
Pins, snaps, hooks, sharp • Fasten snaps, hooks, buttons, and zippers.
or excessive wear
buttons, belt buckles,
• Remove loose items like pins, objects in pockets
zippers, and sharp objects
and sharp buttons.
left in pockets
• Turn knits (which snag easily) inside out.
Undiluted chlorine bleach • Check bleach package instructions for proper amount.
• Never add undiluted bleach to wash or allow clothes
to come in contact with undiluted bleach.
Chemicals like hair bleach • Rinse items that may have chemicals on them before
or dye, permanent wave washing.
solution
9
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
Problem Possible Causes What To Do
Pilling
Result of normal wear on • While this is not caused by the washer, you
poly-cotton blends and can slow the pilling process by washing
fuzzy fabrics garments inside out.
Grayed or yellowed
Not enough detergent • Use more detergent (especially with larger loads).
clothes
Hard water • Use a water conditioner like Calgon brand or install
a water softener.
Water is not hot enough • Make sure water heater is delivering water at
120°F.–140°F. (48°C.–60°C.).
Washer is overloaded • Select load size to match clothes load.
Detergent is not • Add detergent as wash basket fills with water before
dissolving you load clothes.
Dye transfer • Sort clothes by color. If fabric label states
wash
separately,
unstable dyes may be indicated.
Before you call for service…
10
Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
Notes
11
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
Notes
12
Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
13
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
Notes
14
Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
Washer Warranty
15
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
All warranty service provided by our Factory Service Centers or an authorized Customer Care
®
technician. For service, call 800-GE-CARES.
For The Period Of: We Will Replace, At No Charge To You:
One Year Any part
of the washer which fails due to a defect in materials or workmanship. During this
From the date of the full one-yearwarranty,
we will also provide,
free of charge,
all labor and in-home service to replace
original purchase
the defective part.
Five Years The transmission,
if it should fail due to a defect in materials or workmanship. During this
From the date of the five-year limited warranty,
you will be responsible for any labor or in-home service costs.
original purchase
Twenty Years The washer basket,
if it should fail due to a defect in materials or workmanship. During this
From the date of the twenty-year limited warranty,
you will be responsible for any labor or in-home service costs.
original purchase
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA. In Alaska, the
warranty excludes the cost of shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state. To know what your legal rights are, consult your local or state consumer affairs office or
your state’s Attorney General.
■Service trips to your home to teach you how to use
the product.
■Improper installation.
■Failure of the product if it is abused, misused, or used for
other than the intended purpose or used commercially.
■Replacement of house fuses or resetting of circuit
breakers.
■Damage to the product caused by accident, fire, floods or
acts of God.
■Incidental or consequential damage to personal property
caused by possible defects with this appliance.
What Is Not Covered:
Warrantor: General Electric Company. Louisville, KY 40225
Customer Service Troubleshooting Tips
Operating Instructions
Safety Instructions
Installation Instructions
Customer Service Troubleshooting Tips
Installation Instructions
Safety Instructions
Operating Instructions
Customer Service Troubleshooting Tips
Installation Instructions
Safety Instructions
Operating Instructions
Printed in Louisville, KY
16
Service Telephone Numbers.
GE Answer Center
®
800.626.2000
The GE Answer Center® is open 24 hours a day, 7 days a week.
In-Home Repair Service
800-GE-CARES (800-432-2737)
Expert GE repair service is only a phone call away.
Special Needs Service
800.626.2000
800-TDD-GEAC (800-833-4322)
GE offers, free of charge, a brochure to assist in planning a barrier-free kitchen for persons
with limited mobility.
Service Contracts
800-626-2224
Purchase a GE service contract while your warranty is still in effect and you’ll receive a
substantial discount. GE Consumer Service will still be there after your warranty expires.
Parts and Accessories
800-626-2002
Individuals qualified to service their own appliances can have parts or accessories sent directly
to their homes (VISA, MasterCard and Discover cards are accepted).
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since
improper servicing may cause unsafe operation.
Service Satisfaction
If you are not satisfied with the service you receive from GE:
First,
contact the people who serviced your appliance.
Next,
if you are still not pleased, write all the details—including your phone number—to:
Manager, Consumer Relations
GE Appliances
Appliance Park
Louisville, KY 40225
Finally,
if your problem is still not resolved, write:
Major Appliance Consumer Action Program
20 North Wacker Drive
Chicago, IL 60606
Loading...
