GE UVW9484SP Specification
UVW9484SP
30" models require a 30"-wide opening
20-1/8"
12-1/4"
13-13/16"
29-7/8"
27-1/2"
to 51"
2-3/4"
48" Designer Wall Mount Hood w/Dimmable LED Lighting
DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)
INS TA LLATI O N IN F O RMATI O N:
Before installing, consult Use & Care/installation instructions
packed with product for current dimensional data.
OPTIONAL ACCESSORIES
CX8DC9SPSS - 8 (ft.) High Ceiling Duct Cover Kit
CX10DC9SPSS - 10 (ft.) High Ceiling Duct Cover Kit
CX12DC9SPSS - 12 (ft.) High Ceiling Duct Cover Kit
AMP RATING
120V TBD
12"
47-15/16"
18"
24" Min
36" Max
For answers to your Monogram, GE Café™, GE Profile™ or GE Appliances
product questions, visit our website at geappliances.com or call
GE Answer Center® Service, 800.626.2000.
47-15/16"25"
Listed by
Underwriters
Laboratories
Speci fication Revised 6/21
UVW9484SP
48" Designer Wall Mount Hood w/Dimmable LED Lighting
FEATURES AND BENEFITS
1220 CFM Vertical Exhaust – With 1220 CFM of power in a vertical
exhaust configuration, you can quickly and easily remove smoke,
grease, odors and moisture from the air.
LED Hood Lighting – Get a bright view of your cooktop as you
prepare your favorite meals with LED lighting in this range hood.
Removable, Dishwasher-Safe Baffle Filters – The baffle filters in
this range hood are removable and dishwasher-safe, making cleaning
easier than ever.
Variable Speed Fan Control – This variable speed, high performance
exhaust system pulls smoke and vapors out of the kitchen without
making loud noise, so you can cook and talk without disruptions.
Baff le Filters – The baffle filters in this range hood trap more grease
and require less frequent cleaning than standard filters.
Heat Sensor – This temperature sensor range hood will automatically
turn on if the heat sensor detects high temperatures, preventing
damage by reducing heat.
ADA Compliant – This ADA compliant range hood can be operated
with a mobile device, eliminating reaching and improving safety for
users of all abilities.
Model UVW9484SPSS – Stainless steel
Speci fication Revised 6/21
