RM24977
Universal Remote
Instruction Manual
Table of Contents
Setup
Setup .................................................................... 3
Battery Installation ........................................... 3
Battery Saver ................................................... 3
Code Saver ...................................................... 3
Code Setup ...................................................... 3
Button Functions .................................................. 4
DVD Functions ................................................ 6
SAT Functions ................................................. 7
Sleep Function................................................. 7
Code Entry ........................................................... 8
Direct Code Entry ............................................ 8
Code Search .................................................... 9
Using Your Remote ............................................. 10
Code Identification ......................................... 10
Controlling Devices with Power On and Off ..... 11
Controlling Combo Devices ............................. 11
VCR/DVD/DVR Punch-Through ...................... 11
Volume/Mute Control and Punch-Through ...... 12
All Volume/Mute Control to any one Mode ..... 12
Setting any Mode for its own Volume/Mute .... 13
Troubleshooting .................................................. 14
Congratulations on your purchase of the RM24977
Universal Remote Control. The RM24977 is one of
the most easy to use remote controls available
today. With the RM24977, juggling multiple remote
controls is a thing of the past! Your RM24977
controls up to four devices, including the most
popular brands of TV, VCR, DVD, CBL, SAT, and
audio equipment.
Note: Some functions from your original remote may
not be controlled by this remote. Use the original
remote, if available, to control such functions.
Sometimes buttons other than described in these
instructions may actually perform the function. For
example, the CHAN and VOL buttons might be
used to navigate through menu choices. We
recommend you experiment with the remote to
identify if such situations pertain to your equipment.
The RM24977 is easy to use, easy to program, and
it gives you total control—at the touch of your
fingertips!
Battery Installation
1. On the back of the remote, push down on the
tab and lift the cover off.
2. Match the batteries to the + and - marks inside
the battery case, then insert 2 AAA Alkaline
batteries.
3. Press the battery cover back into place.
Battery Saver
Your remote automatically turns off if the buttons
are depressed more than 30 seconds. This will save
your batteries should your remote get stuck in a
place where the buttons remain depressed (e.g.,
between the sofa cushions).
Code Saver
You will have up to 10 minutes to change the
batteries in your remote without losing codes you
have programmed. However, do not press any
buttons until batteries are installed in the remote. If
buttons are pressed without batteries in the remote,
all codes will be lost.
Code Setup
The CODE SEARCH button is used to setup the
remote. You can either setup the remote using the
code tables (on separate sheet), or you can search
through the library of codes until you find a code
that works for your product. Please refer to “Pro-
gramming with Code Search” page 9 for more
information on using the code search feature to
learn how to search through the library of codes for
your products. NOTE: You can store any kind of
code under any mode (except TV). I.E. you can
store a VCR code under the CABLE button, or a
DVD code under the VCR button, etc. However, you
can only store TV codes under the TV button.
32
Button Functions
Button Functions, cont.
Some buttons on the remote might have functions that
are referred to by different names on the device you are
controlling. E.G. PREV.CH may be called RECALL, or
ENTER may be called DISPLAY. These differences
depend on the brand and model of your product. Also,
this remote can only operate features that exist on your
product. E.G., your product must have PREV.CH ability
for the PREV.CH button to operate this feature.
TV, VCR, etc.
Selects product
to be operated.
CODE SEARCH
For setup.
MUTE Turns off the
TV sound while the
picture remains.
PREV.CH Returns to
the previously selected
channel, or DVD repeat
toggle. REPEAT performs
DVD players “A-B Repeat”
(or RPT A.B) function for
repeat play of current
Chapter or Track.
CC (SUBTITLE)
TV Closed
Caption (if your
TV has this
feature) or DVD
Subtitle toggle.
GUIDE displays satellite
or cable on-screen
program guide.
ENTER
For some TV models,
used after direct channel
number entry to immediately change to the
selected channel.
RECORD, PLAY, STOP, REW, FF, PAUSE VCR
control buttons operate your VCR even when the
remote is set to operate the TV. Also operates
DVD Scan -/+. Note the VCR keys also control
DVD when in DVD Mode.
ON-OFF Turns
product On or Off.
Red Indicator
Lights when any
button is pressed.
CHANNEL Up/Down
Changes the channels.
SKIP +/- controls DVD/CD
track selection i.e. DVD/CD
Track Skip Up/Down (in
DVD and CD modes).
INPUT
For some TVs, press repeatedly to
select from available viewing sources
(antenna, cable box, VCR, etc.).
Note: The REC button must be pressed TWICE to
record from your VCR. For some brands of VCRs, you
might need to press the REC button once, then press it
again for three seconds.
pressed after channel selection.
(red indicator stays on).
INFO button brings up DVD
Display or Control Menu for
Chapter/Track/Title number,
Time remaining/elapsed,
system information, etc.
Menu Press and release Shift
then Menu to display the menu
on the TV. The red LED is on
continuously to indicate the
remote is in Menu mode, VOL
UP/DOWN keys operate as
cursor right/left, CH+/- keys
operate as cursor up/down,
and Mute operates as OK.
Press Sleep/Exit key to exit
TITLE Brings up the DVD
Enter numbers for direct
channel selection. Some
products require ENTER to be
Shift Press and
release to access
buttons labeled in red
Press again to exit
Shift mode.
VOLUME UP/DOWN
Changes the volume
level of the product,
normally the TV.
OK Selects menu
items for the device
you are controlling.
Menu.
Title Menu screen.
NUMBERS
54
