GE RM24974 User Manual [en, es]

RM24974

ediuG-SRediuG-HC

REPLAY

DVR

SETUP

LCR

CLEAR

Universal Remote Instruction Manual

Control Remoto Universal Manual de Instrucciones

Table of Contents

Introduction ..................................................................................... 3

Setup .................................................................................................. 3

Battery Installation ...............................................................3

Battery Saver ........................................................................... 3

Code Saver ............................................................................... 3

Code Setup ............................................................................... 3

Button Functions ................................................................... 4

Audio Functions ..................................................................... 6

AM/FM Tuner, Home Theater and

Surround Sound Feature ...................................................7

DVR Operation ....................................................................... 8

Direct Code Entry................................................................... 9

Code Search ...........................................................................10

Using Your Remote ....................................................................11

Code Identiﬁcation .............................................................11

Controlling Devices with Power On and Off ............12

Controlling Combo Devices ............................................12

VCR/DVD/DVR Punch-Through .....................................12

Volume/Mute Control and Punch-Through .............13

All Volume/Mute Control to any one Mode .............13

Setting any Mode for its own Volume/Mute ...........14

Troubleshooting ..........................................................................15

Congratulations on your purchase of a 7 function Universal Remote Control. This remote is one of the most easy to use remote controls available today. Now juggling multiple remote controls is a thing of the past! Your Universal Remote controls up to seven devices, including the most popular brands of TV, VCR, DVD, CBL, and SAT. It is easy to use, easy to program, and it gives you total control—at the touch of your ﬁngertips!

Note: Some functions from your original remote may not be controlled by this remote. Use the original remote, if available, to control such functions. Sometimes buttons other than described in these instructions may actually perform the function. For example, the CHAN and VOL buttons might be used to navigate through menu choices. We recommend you experiment with the remote to identify if such situations pertain to your equipment.

Setup

Battery Installation

1. On the back of the remote, push down on the tab and lift the cover off.

2. Match the batteries to the + and - marks inside the battery case, then insert 2 AAA Alkaline batteries.

3. Press the battery cover back into place.

Battery Saver

Your remote automatically turns off if the buttons are depressed more than 30 seconds. This will save your batteries should your remote get stuck in a place where the buttons remain depressed (e.g., between the sofa cushions).

Code Saver

You will have up to 10 minutes to change the batteries in your remote without losing codes you have programmed. However, do not press any buttons until batteries are installed in the remote. If buttons are pressed without batteries in the remote, all codes will be lost.

Code Setup

The SETUP button is used to setup the remote. You can either setup the remote using the code tables (on separate sheet), or you can search through the library of codes until you ﬁnd a code that works for your product. Please refer to “ Code Search” on page 10 for more information on using the code search feature to learn how to search through the library of codes for your products. NOTE: You can store any kind of code under any mode (except TV). I.E. you can store a VCR code under the CBL button, or a Cable code under the DVD button, etc. However, you can only store TV codes under the TV button.

SETU P

Button Functions

Some buttons on the remote might have functions that are referred to by different names on the device you are controlling. E.G. LCR may be called RECALL, or ENTER may be called DISPLAY. These differences depend on the brand and model of your product. Also, this remote can only operate features that exist on your product. E.G., your product must have LCR/Recall ability for the LCR button to operate this feature.

GUIDE displays satellite or cable on-screen

TV, VCR, etc. Selects product to be operated.

program guide.

MENU-PROG Brings up the main menu. If you are ready in the menu system, press SELECT to select a highlighted choice. Use the arrow buttons to move through the menu selections.

MUTE Turns off the TV sound while the picture remains.

VOLUME UP/DOWN

Changes the volume level of the product, normally the TV.

Red Indicator Lights when any button is pressed.

ediuG-SRediuG-HC

CLEAR

SETUP Used for setup.

0-9

Enter numbers for direct channel selection. Some products require ENTER to be pressed after channel selection.

ENTER For some TV models, used after direct channel number entry to immediately change to the selected channel.

REPLAY Replays the last 8 seconds of a program.

PAGE UP/DOWN TiVo Thumbs controls.

TUP

DVR

REPLAY

Button Functions, cont.

ON•OFF Turns

product On or Off.

SETUP

DVR

Navigation buttons and

SELECT used to move

through on-screen menuing

and guides. With some DBS

models the DISP button

should be used to select the

highlighted item. Use the

navigation buttons to move

the highlighted choice up,

down, left, or right .

ediuG-SRediuG-HC

CLEAR

RS Guide, Plays your

CLEAR Removes the on

screen display to return

LCR

to normal viewing.

LCR, Last Channel/ Recall

AM/FM Selects AM or FM

CHANNEL Up/Down

Changes the channels

TRACK +/- controls DVD/CD

track selection i.e. DVD/CD

Track Skip Up/Down (in DVD

TV/VCR/DVR Operates the

same as the TV/VCR TV/DVD,

or antenna keys on your

recorded shows.

on your tuner.

and CD modes).

original remotes.

REPL AY

ADVANCE Catches up to your

Live Broadcast.

RECORD, PLAY, STOP, REW, FF, PAUSE VCR control buttons operate your VCR even when the remote is set to operate the TV. Also operates DVD Scan -/+. Note the VCR keys also control DVD when in DVD Mode.

Note: The REC button must be pressed TWICE to record from your VCR. For some brands of VCRs, you might need to press the REC button once, then press it again for three seconds.

Audio Button Descriptions

Press the AUDIO device button to enable the AUDIO MODE. Audio functions are indicated by the blue button descriptions. CD, TAPE, TUNER, TV, VIDEO Used to directly select the device you want to control. (Works in AUDIO mode). AM/FM Lets you select the AM/FM band on your audio receiver. FUNCTION Toggles the different audio input devices. The number buttons also select the function labels below the buttons when in AUDIO mode. DELAY-, ON, DELAY+ Increases or decreases the delay between the surround and main speakers when the receiver is in surround sound mode.

ON•OFF, SURR. MODE Toggles the surround modes on

and off. SURR MODE toggles through the receiver’s various surround sound mode settings.

Operating Audio Functions

Note: Not all functions work for all brands.

Turning on the Receiver or Mini-System

Point the remote control at the receiver and press the AUDIO button. The receiver should turn on. In some cases you might need to press the AUDIO button and then the

ON•OFF button to turn the system on.

Selecting a device Input

Device inputs such as CD Player or Tape Deck may be selected depending on the features of your receiver or minisystem. Input selection may be made either by pressing the labeled number function, or by pressing the FUNCTION button to toggle through the inputs available on your system.

Using the number buttons to change audio inputs

To select a device, press the number button (1-6) that corresponds to the device you want to operate (CD, TAPE, TUNER, TV, or VIDEO).

Using the function buttons to change audio devices

To select a device, press the FUNCTION button until the input you want to operate appears on your system.

Audio Functions, cont.

Operating a CD player or Tape Deck

Use the Play, Forward, Reverse, Record, Stop, and Pause buttons for CD Players and Tape Decks. In some case the Preset buttons (CHAN+/CHAN-) may change tracks on CD Players.

AM/FM Tuner Functions

1. Press the AUDIO button.

2. Press the TUNER (3) button.

3. Press the AM/FM button to toggle between AM and FM.

4. Use the preset (CHAN+ or CHAN- buttons to move up and down channel presets.

Home Theater Systems

With GE receivers, a second press of the TV button turns the receiver on.

1. Turn the TV on.

2. Press the AUDIO button.

3. Select the audio input either by using the labeled number buttons, or the FUNCTION button.

4. Press the VOL+ or VOL- buttons to control volume.

NOTE: The volume buttons may operate both the TV and the receiver volume at the same time. If this presents a problem, it may be resolved by disabling the TV speakers by going into the TV menu.

Surround Sound Feature

The surround sound feature may be turned ON/OFF by pressing the SURR ON•OFF button.

1. Press the SURR MODE button until the desired mode is found.

2. Press DELAY+ or DELAY- to achieve the desired delay affect.

DVR Operation

For TiVo products the following buttons apply:

T-CENTRAL Accesses TiVo Central. GUIDE Switches between live TV and program guide. REPLAY Replays the last 8 seconds of a program. ADVANCE Catches you up to the live broadcast, or

advances viewing to the end of a recorded program.

TV/VCR/DVD Accesses live TV. OK Selects on-screen options. SLOW Plays a program in slow speed. THUMBS UP/DOWN (PAGE UP/DOWN) To set TiVo

“Thumbs” ratings. FORWARD, REVERSE To move forward or backward in segments. PAUSE To pause live or recorded programs.

For ReplayTV products the following buttons apply:

CH GUIDE Channel guide: Shows TV program listings. RS GUIDE Recorded shows guide: Plays your recorded

shows.

M Menu button: Accesses ReplayTV main menu. PAGE UP/DOWN Moves up or down pages in Replay-

TV guides and menus.

REPLAY Replays the last 7 seconds of a program. ADVANCE Catches you up to the live broadcast. OK Selects on-screen options. TV/VCR/DVD Switches between ReplayTV and TV

tuners. FORWARD, REVERSE To move forward or backward in segments. PAUSE To pause live or recorded programs.

Direct Code Entry

1. Press and hold the SETUP button until the

SETU P

red indicator stays on, then release the SETUP button.

2. Press and release the desired device button (TV, VCR, etc.). The red indicator blinks, then stays lit.

3. Enter the 3 digit code from the code tables (on separate sheet). Note: after a valid code entry, the red indicator turns off. For an invalid code, the red indicator ﬂashes.

4. With your device on, press

ON•OFF. If the device turns off, no further programming is required. Note: If some buttons do not operate your equipment, try one of the other codes for your brand.

Write your codes down here for easy reference later.

Type Type stored Code TV TV DVR VCR CBL/SAT DVD AUDIO AUX

Code Search

If your device does not respond after you have tried all the codes for your brand, or if your brand is not listed, try searching for your code by following these steps.

1. Manually turn on the device (TV, VCR, etc.) to be controlled.

2. Press and hold the red indicator stays on, then release the

SETUP button until the

SETU P

SETUP button.

3. Press and quickly release the desired device button (TV, VCR, etc.). The red indicator blinks off once.

4. Press the

ON•OFF button repeatedly (up to 300 times) until the device to be controlled turns off. The red indicator blinks off with each button press.

5. Press and release ENTER to install the code.

Most users will store VCR codes under the VCR button, Cable codes under CABLE, etc. If (for example) you want to store a VCR code under CABLE, ﬁrst follow the procedure for Direct Code Entry (previous page) and press CABLE in step 2 of Direct Code Entry, then enter ANY VCR code in step 3 of Direct Code Entry. Then follow the steps above for Code Search.

Note: Code Search starts from the currently stored three digit number under that mode. Sometimes the ﬁrst code that “works” with your device may only allow limited functionality (e.g. the MENU button might not work). There may be a code that performs more functions. Continue the code search process until the best code is found.
