RM24965
Universal Remote
Instruction Manual
TV
MENU
SLEEP
SAT
DVD CB L
AUX
VCR
OK
EXIT LAS T
GUIDE
INFO
TITLE
23
5
46
78
ENTER
SCAN-
RECORD
9
TV/VCR
INPUT
0
PLAY SCAN+
STOP
PAU SE
Table of Contents
Setup
Setup .................................................................... 3
Battery Installation ........................................... 3
Battery Saver ................................................... 3
Code Saver ...................................................... 3
Code Setup ...................................................... 3
Button Functions .................................................. 4
DVD Functions ................................................ 6
SAT Functions ................................................. 6
Code Entry ........................................................... 7
Direct Code Entry ............................................ 7
Code Search .................................................... 8
Using Your Remote ............................................... 9
Code Identification ........................................... 9
Controlling Devices with Power On and Off .... 10
Controlling Combo Devices ............................ 10
VCR/DVD/DVR Punch-Through ..................... 10
Volume/Mute Control and Punch-Through ....... 11
All Volume/Mute Control to any one Mode ......11
Setting any Mode for its own Volume/Mute .... 12
Sleep ............................................................. 13
Troubleshooting .................................................. 14
Congratulations on your purchase of the RM24965
Universal Remote Control. The RM24965 is one of
the most easy to use remote controls available
today. With the RM24965, juggling multiple remote
controls is a thing of the past! Your RM24965
controls up to seven devices, including the most
popular brands of TV, VCR, DVD, SAT, CBL, and
audio equipment.
Note: Some functions from your original remote may
not be controlled by this remote. Use the original
remote, if available, to control such functions.
Sometimes buttons other than described in these
instructions may actually perform the function. For
example, the CHAN and VOL buttons might be
used to navigate through menu choices. We
recommend you experiment with the remote to
identify if such situations pertain to your equipment.
The RM24965 is easy to use, easy to program, and
it gives you total control—at the touch of your
fingertips!
Battery Installation
1. On the back of the remote, push down on the
tab and lift the cover off.
2. Match the batteries to the + and - marks inside
the battery case, then insert 2 AAA Alkaline
batteries.
3. Press the battery cover back into place.
Battery Saver
Your remote automatically turns off if the buttons
are depressed more than 30 seconds. This will save
your batteries should your remote get stuck in a
place where the buttons remain depressed (e.g.,
between the sofa cushions).
Code Saver
You will have up to 10 minutes to change the
batteries in your remote without losing codes you
have programmed. However, do not press any
buttons until batteries are installed in the remote. If
buttons are pressed without batteries in the remote,
all codes will be lost.
Code Setup
The CODE SEARCH button is used to setup the
remote. You can either setup the remote using the
code for your brand of product, from the code tables
(on separate sheet), or you can search through the
library of codes until you find a code that works for
your product. Please refer to “Programming with
Code Search” page 9 for more information on using
the code search feature to learn how to search
through the library of codes for your products.
NOTE: You can store any kind of code under any
mode (except TV). I.E. you can store a VCR code
under the CABLE button, or a DVD code under the
VCR button, etc. However, you can only store TV
codes under the TV button.
32
Button Functions
Button Functions, cont.
Some buttons on the remote might have functions that
are referred to by different names on the device you are
controlling. E.G. LAST may be called RECALL, or
ENTER may be called DISPLAY. These differences
depend on the brand and model of your product. Also,
this remote can only operate features that exist on your
product. E.G., your product must have LAST ability for
the LAST button to operate this feature.
TV, VCR, etc.
Selects product
to be operated.
MUTE Turns off the
TV sound while the
picture remains.
VOLUME UP/DOWN
Changes the volume
level of the product,
normally the TV.
EXIT Exit On-Screen Menus
and/or Return to previous
On-Screen selection.
MENU
Selects the on-screen menu.
SLEEP enables the
remote to turn off your
TV after a period of 1
to 99 minutes.
ENTER
For some TV models,
used after direct
channel number
entry to immediately
change to the
selected channel.
RECORD, PLAY, STOP,
REW, FF, PAUSE VCR
control buttons operate
your VCR even when the
remote is set to operate the
TV. Also operates DVD
Scan -/+. Note the VCR
keys also control DVD
when in DVD Mode.
Red Indicator
Lights when any
button is pressed.
ON-OFF Turns
product On or
Off.
GUIDE displays satellite or
cable on-screen program
INFO button brings up DVD
number, Time remaining/
elapsed indication, system
channel selection. Some
products require ENTER
For some TVs, press repeat-
edly to select from available
viewing sources (antenna,
Note: The REC button must be pressed TWICE to
record from your VCR. For some brands of VCRs, you
might need to press the REC button once, then press it
again for three seconds.
CODE SEARCH
For setup.
CHANNEL Up/Down
Changes the channels
SKIP +/- controls DVD/
CD track selection i.e.
DVD/CD Track Skip Up/
Down (in DVD and CD
modes).
OK Selects menu
items for the device
you are controlling.
LAST Returns to
the previously selected
channel,
guide.
Display or Control Menu
for Chapter/Track/Title
information, etc.
NUMBERS
Enter numbers for direct
to be pressed after
channel selection.
TV/VCR/INPUT
cable box, VCR, etc.).
54
