Tetra® Product Reference Guide

LineFit Light LED

LED Strip/System Power Module

Wavelength/ LEDs Lumens Lumens Consumption Dimension Maximum LED Color Per Viewing Per Module Per Foot Watts/Module** (Inches) Load Product SKU Color Temperature Module Angle (Typical) (Typical) (Typical) H x W x L Voltage (FT/Sup

95166 GEF18T12SGNHOLED Daylight 6500K 34 140 893 595 7.2/8.5 0.95 x 1.8 x 15.85 24V

94472 GEF24T12SGNHOLED Daylight 6500K 56 140 1470 735 11.5/13.5 0.95 x 1.8 x 21.81 24V 95167 GEF30T12SGNHOLED Daylight 6500K 68 140 1786 714 14.4/16.9 0.95 x 1.8 x 27.84 24V 94473 GEF36T12SGNHOLED Daylight 6500K 84 140 2205 735 17.3/20.4 0.95 x 1.8 x 33.81 24V 95168 GEF42T12SGNHOLED Daylight 6500K 96 140 2521 720 20.2/23.8 0.95 x 1.8 x 39.83 24V 94474 GEF48T12SGNHOLED Daylight 6500K 112 140 2940 735 23/27.1 0.95 x 1.8 x 45.81 24V 95169 GEF60T12SGNHOLED Daylight 6500K 140 140 3675 735 28.8/33.9 0.95 x 1.8 x 57.81 24V 94475 GEF64T12SGNHOLED Daylight 6500K 146 140 3833 719 30.2/35.5 0.95 x 1.8 x 61.83 24V 95170 GEF72T12SGNHOLED Daylight 6500K 168 140 4410 735 34.6/40.7 0.95 x 1.8 x 69.81 24V 95171 GEF84T12SGNHOLED Daylight 6500K 196 140 5145 735 40.3/47.4 0.95 x 1.8 x 81.81 24V 94476 GEF96T12SGNHOLED Daylight 6500K 224 140 5880 735 46.1/54.2 0.95 x 1.8 x 93.81 24V 95160 GEF18T12DHOLED Sign White 5400K 34 140 893 595 7.2/8.5 0.95 x 1.8 x 15.85 24V 94465 GEF24T12DHOLED Sign White 5400K 56 140 1470 735 11.5/13.5 0.95 x 1.8 x 21.81 24V 95161 GEF30T12DHOLED Sign White 5400K 68 140 1786 714 14.4/16.9 0.95 x 1.8 x 27.84 24V 94466 GEF36T12DHOLED Sign White 5400K 84 140 2205 735 17.3/20.4 0.95 x 1.8 x 33.81 24V 95162 GEF42T12DHOLED Sign White 5400K 96 140 2521 720 20.2/23.8 0.95 x 1.8 x 39.83 24V 94467 GEF48T12DHOLED Sign White 5400K 112 140 2940 735 23/27.1 0.95 x 1.8 x 45.81 24V 95163 GEF60T12DHOLED Sign White 5400K 140 140 3675 735 28.8/33.9 0.95 x 1.8 x 57.81 24V 94468 GEF64T12DHOLED Sign White 5400K 146 140 3833 719 30.2/35.5 0.95 x 1.8 x 61.83 24V 95164 GEF72T12DHOLED Sign White 5400K 168 140 4410 735 34.6/40.7 0.95 x 1.8 x 69.81 24V 95165 GEF84T12DHOLED Sign White 5400K 196 140 5145 735 40.3/47.4 0.95 x 1.8 x 81.81 24V

Fluorescent Replacements

94469 GEF96T12DHOLED Sign White 5400K 224 140 5880 735 46.1/54.2 0.95 x 1.8 x 93.81 24V 95172 GEF18T12CWHOLED Cool White 4100K 34 140 834 556 7.2/8.5 0.95 x 1.8 x 15.85 24V 94479 GEF24T12CWHOLED Cool White 4100K 56 140 1374 687 11.5/13.5 0.95 x 1.8 x 21.81 24V 95173 GEF30T12CWHOLED Cool White 4100K 68 140 1668 667 14.4/16.9 0.95 x 1.8 x 27.84 24V 94480 GEF36T12CWHOLED Cool White 4100K 84 140 2061 687 17.3/20.4 0.95 x 1.8 x 33.81 24V 95174 GEF42T12CWHOLED Cool White 4100K 96 140 2355 673 20.2/23.8 0.95 x 1.8 x 39.83 24V 94481 GEF48T12CWHOLED Cool White 4100K 112 140 2748 687 23/27.1 0.95 x 1.8 x 45.81 24V 95175 GEF60T12CWHOLED Cool White 4100K 140 140 3435 687 28.8/33.9 0.95 x 1.8 x 57.81 24V 94482 GEF64T12CWHOLED Cool White 4100K 146 140 3582 672 30.2/35.5 0.95 x 1.8 x 61.83 24V 95176 GEF72T12CWHOLED Cool White 4100K 168 140 4122 687 34.6/40.7 0.95 x 1.8 x 69.81 24V 95177 GEF84T12CWHOLED Cool White 4100K 196 140 4809 687 40.3/47.4 0.95 x 1.8 x 81.81 24V 94483 GEF96T12CWHOLED Cool White 4100K 224 140 5496 687 46.1/54.2 0.95 x 1.8 x 93.81 24V

180W: 14ft. per bank /28ft . per PS

Power Supply Loading

Product Code Description Long Description Ft per PS

94485 GEPS24-100U-GL Power Supply (24VDC/96W), Input Voltage: 108-305VAC: Damp Rated; Self-Contained, 16’ Remote or Raceway; 1 Output Bank; Class 2

94486 GEPS24-100U-NA Power Supply (24VDC/96W), Input Voltage: 108-305VAC: Damp Rated; Self-Contained, 16’ Remote or Raceway; 1 Output Bank; Class 2

94487 GEPS24-180U Power Supply (24VDC/180W), Input Voltage: 90-305VAC: Damp Rated; Self-Contained, 14’ Remote or Raceway; 2 Output Banks of 900W; Class 2

94488 GEPS24D-80U 0-10V Dimminig Power Supply (24VDC/80W), Input Voltage: 90-305VAC: Damp Rated; Self-Contained, 12’ Remote or Raceway; 1 Output Bank; Class 2

94489 GEPS24W-80 Power Supply (24VDC/80W), Input Voltage: 90-264VAC: Wet Location; 1 Output Bank; Class 2 12’

Warranty GE offers a limited system warranty of up to five (5) years System Certifications UL Recognized #E219167, UL Classified #E229508, CSA Approved, #216319, CE, C-tick, RoHS

ply

80W: 12ft., 100W: 16ft .,

GE Lighting

Tetra

LED Lighting System

Reference Chart 2014

GE Lighting • 1-888-MY-GE-LED (1 - 888 - 69 - 43 - 533) • www.gelighting.com

GE Lighting Solutions, LLC is a subsidiary of the General Electric Company. Tetra is a trademark of GE Lighting Solutions, LLC. The GE brand and logo are trademarks of the General Electric Company. © 2014 GE Lighting Solutions, LLC. Information provided is subject to change without notice. All values are design or typical values when measured under laboratory conditions.

SIGN053-061714

Tetra® LED Systems

Tetra® miniMAX MS

Tetra® miniMAX

Tetra® MAX

MiniMax MS

deep and as narrow as ½-inch wide.

Applications — huge performance in small channel letters Available Colors — white & warm white Packaging —

Tetra miniMAX delivers brilliant light in channel letters as shallow as 1.5

The patent-pending OptiLens™ promotes a wide viewing angle and superior uniformity in the smallest of channel letters.

Applications — small channel letters Available Colors — red, green, blue, white, warm white & orange Packaging — 100 ft./box

Tetra MAX is designed for the easiest possible installation and operation. This LED

system is available in a wide selection of colors and provides bright uniform light in medium sized channel letters.

Applications Available Colors Packaging

(Micro System) was created for channel letters as shallow as 1.5 inch

100 ft./box

inch.

— medium channel letters

— red, red-orange, amber, green, blue, white & warm white

— 100 ft./box

Tetra

Contour LS

Tetra® miniStrip & Tetra

miniStrip DS

Tetra® PowerStrip & Tetra

PowerStrip DS

Tetra Contour LS is our linear neon replacement system that comes pre-assembled and ready-to-install; perfect for long run border lighting applications.

Applications — border lighting and accent lighting Available Colors— red, green, blue & white & warm white Packaging — 96 ft./box

New Tetra miniStrip and miniStrip DS were designed speciﬁcally for shallow cabinet signs.

Tetra miniStrip is ideal for single-sided signs with a 3 to 6 inch can depth, while Tetra miniStrip DS is perfect for double-sided signs with a 6 to 12 inch can depth.

Applications — shallow cabinet signs Available Colors — white & warm white Packaging — Tetra miniStrip: 48 modules per box/Tetra miniStrip DS: 32 modules per box

New Tetra PowerStrip signiﬁcantly reduces maintenance and energy costs by

replacing ﬂuorescent lighting in cabinet and pylon signs. This LED system features OptiLens™, a patent-pending optical lens that eliminates striping commonly associated with ﬂuorescent lighting.

Applications — cabinet signs Available Colors — white & warm white Packaging — Tetra PowerStrip: 48 modules per box/Tetra PowerStrip DS: 32 modules per box

Tetra® PowerMAX

Tetra® Contour

Tetra PowerMAX provides powerful white light in the largest channel letter applications.

OptiLens™ allows this lighting system to produce wide uniform surface area coverage across the sign face.

Applications — large channel letters Available Colors — white & warm white Packaging — 100 ft./box

Tetra Contour is our two-part neon replacement system that can be easily heated

and formed into custom shapes and designs.

Applications — neon replacement and accent lighting Available Colors — Light Engine: red, red-orange, amber, green, blue, white & warm white

Light Guide: red, orange, yellow, lime green, green, blue & white

Packaging

Tetra Contour light guides: 96 ft./box

— Tetra Contour light engines:

96 ft./box

Tetra® EdgeStrip

LineFit

Light LED

Tetra EdgeStrip is engineered to install easily around the edge of signs with a 3 to 6 inch

can depth. Perfect for single or double-sided signs,Tetra EdgeStrip delivers money-saving advantages over T8 ﬂuorescent tubes while producing outstanding visual performance that protects end-user brand image.

Applications — shallow cabinet signs Available Colors — white & warm white Packaging — 32 modules per box

LineFit

sign into an efficient LED solution.

Applications — is the fast, simple retroﬁt for cabinet signs Available Colors — Sign White, Daylight and Cool White Packaging — 6/box

is the incredibly quick and easy way to transform a fluorescent cabinet

Tetra® Product Reference Guide

LED Strip/System Power Module

Wavelength/ LEDs Modules Lumens Lumens Consumption Dimension LED Color Per Per Viewing Per Module Per Foot Watts/Module** H x L x W Maximum Load Product Line SKU Color Temperature Module Foot Angle (Typical) (Typical) (Typical) (Inches) Voltage (FT/Power Supply)

GEMS71-1 WHITE 7100K 3 2.5 140 36 90 0.38/0.45 0.352 x 1.374 x 0.378 12V

Tetra miniMAX MS

GEMS50-1 WARM WHITE 5000K 3 2.5 140 36 90 0.38/0.45 0.352 x 1.374 x 0.378 12V GEMS41-1 WARM WHITE 4100K 3 2.5 140 28 70 0.38/0.45 0.352 x 1.374 x 0.378 12V GEMS32-1 WARM WHITE 3200K 3 2.5 140 28 70 0.38/0.45 0.352 x 1.374 x 0.378 12V GEMM71-2 WHITE 7100K 3 2.5 150 36 90 0.32/0.38 0.31 x 1.89 x 0.47 12V

Tetra miniMAX

GEMM50-2 WARM WHITE 5000K 3 2.5 150 36 90 0.32/0.38 0.31 x 1.89 x 0.47 12V

0.5” Min. Stroke Width

GEMM41-2 WARM WHITE 4100K 3 2.5 150 34 85 0.32/0.38 0.31 x 1.89 x 0.47 12V

1.5” (38mm) Min. Depth

GEMM32-2 WARM WHITE 3200K 3 2.5 150 30 75 0.32/0.38 0.31 x 1.89 x 0.47 12V GEMMRD-1 RED 625nm 3 2.5 150 11 27 0.39/0.47 0.31 x 1.89 x 0.47 12V GEMMBL-1 BLUE 467nm 3 2.5 150 8 19 0.39/0.47 0.31 x 1.89 x 0.47 12V GEMMGL-1 GREEN 530nm 3 2.5 150 24 60 0.39/0.47 0.31 x 1.89 x 0.47 12V GEMMPO-1 ORANGE 606nm 3 2.5 150 19 48 0.48/0.59 0.31 x 1.89 x 0.47 12V GEMX71-2* WHITE 7100K 3 2 150 52 105 0.46/0.54 0.31 x 0.55 x 2.56 12V GEMX50-2* WARM WHITE 5000K 3 2 150 52 105 0.46/0.54 0.31 x 0.55 x 2.56 12V

Tetra MAX

GEMX41-2* WARM WHITE 4100K 3 2 150 47 95 0.46/0.54 0.31 x 0.55 x 2.56 12V

0.75” Min. Stroke Width

GEMX32-2* WARM WHITE 3200K 3 2 150 43 86 0.46/0.54 0.31 x 0.55 x 2.56 12V

4” (102mm) Min. Depth

GEMXRD-1* RED 625nm 3 2 150 14 27 0.48/0.59 0.31 x 0.55 x 2.56 12V

>12” (304.8mm) Letter Height

GEMXBL-1* BLUE 467nm 3 2 150 10 20 0.48/0.59 0.31 x 0.55 x 2.56 12V GEMXGL-1* GREEN 530nm 3 2 150 30 60 0.48/0.59 0.31 x 0.55 x 2.56 12V

Channel LettersBorder Lighting

GEMXPO-1* ORANGE 606nm 3 2 150 13 25 0.36/0.44 0.31 x 0.55 x 2.56 12V GEMXRC-1* RED-ORANGE 616nm 3 2 150 12 23 0.29/0.36 0.31 x 0.55 x 2.56 12V GEMXYG-1* AMBER 589nm 3 2 150 16 21 0.54/0.66 0.31 x 0.55 x 2.56 12V GEMXH71-2* WHITE 7100K 3 2 150 82 165 0.72/0.85 0.31 x 0.55 x 2.56 12V GEMXH50-2* WARM WHITE 5000K 3 2 150 82 165 0.72/0.85 0.31 x 0.55 x 2.56 12V GEMXH41-2* WARM WHITE 4100K 3 2 150 75 150 0.72/0.86 0.31 x 0.55 x 2.56 12V GEMXH32-2* WARM WHITE 3200K 3 2 150 68 136 0.72/0.86 0.31 x 0.55 x 2.56 12V GEMXHRD-1* RED 625nm 4 2 150 16 31 0.41/0.49 0.24 x 0.55 x 3.06 12V GEPM71-2* WHITE 7100K 3 1.5 150 133 200 1.32/1.50 0.31 x 0.71 x 3.94 12V

Tetra PowerMAX

GEPM50-2* WARM WHITE 5000K 3 1.5 150 133 200 1.32/1.50 0.31 x 0.71 x 3.94 12V

1.25” Min. Stroke Width 4” (102mm) Min. Depth

GEPM41-2* WARM WHITE 4100K 3 1.5 150 120 180 1.32/1.50 0.31 x 0.71 x 3.94 12V

>=36” (914.4mm) Letter Height

GEPM32-2* WARM WHITE 3200K 3 1.5 150 109 164 1.32/1.50 0.31 x 0.71 x 3.94 12V GEXNRD-1** RED 625nm 115/330 55 1.52/1.79 0.48 x 0.40 x 16.0 24V

Tetra Contour

GEXNRC-1** RED/ORANGE 618nm 115/330 85 2.27/2.67 0.48 x 0.40 x 16.0 24V

Border & Accent Lighting

GEXNYG-1** AMBER 589nm 115/330 60 2.27/2.67 0.48 x 0.40 x 16.0 24V

15mm neon replacement

GEXNGL-1** GREEN 532nm 115/330 120 1.52/1.79 0.48 x 0.40 x 16.0 24V GEXNBL-1** BLUE 467nm 115/330 30 1.52/1.79 0.48 x 0.40 x 16.0 24V GEXN32-1** WARM WHITE 3200K 115/330 130 3.17/3.73 0.48 x 0.40 x 16.0 24V GEXN65-1** WHITE 6500K 115/330 140 3.17/3.73 0.48 x 0.40 x 16.0 24V GEXNLRD-1 RED/RED 625nm 115/330 55 1.30/1.53 0.48 x 0.40 x 8.0 24V

Tetra Contour LS

GEXNLGL-1 GREEN/GREEN 532nm 115/330 120 1.73/2.03 0.48 x 0.40 x 8.0 24V

Straight Border Lighting

GEXNLBL-1 BLUE/BLUE 467nm 115/330 30 1.73/2.03 0.48 x 0.40 x 8.0 24V

15mm neon replacement

GEXNL65-1 WHITE 6500K 115/330 140 3.17/3.73 0.48 x 0.40 x 8.0 24V GEXNL32-1 WARM WHITE 3200K 115/330 130 3.17/3.73 0.48 x 0.40 x 8.0 24V

20W: 16ft. (40 Modules), 60W: 48ft . (120 Modules), 180W: 48ft. (120 Modules) per bank / 144ft. (360 Modules) per PS

20W: 26ft. (52 Modules), 60W: 80ft . (160 Modules), 180W: 80ft. (160 Modules) per bank / 240ft. (480 Modules) per PS

20W: 33ft. (66 Modules), 60W: 100ft . (200 Modules), 180W: 100ft. (200 Modules) per bank / 300ft. (600 Modules) per PS

20W: 17ft. (34 Modules), 60W: 53ft . (106 Modules), 180W: 53ft. (106 Modules) per bank / 159ft. (318 Modules) per PS

20W: 23ft. (46 Modules), 60W: 71ft . (142 Modules), 180W: 71ft. (142 Modules) per bank / 213ft. (426 Modules) per PS

20W: 20ft. (50 Modules), 60W: 60ft . (150 Modules)

180W: 60ft. (150 Modules) per bank / 180ft . (450 Modules) per PS

20W: 22ft. (56 Modules), 60W: 68ft . (170 Modules)

180W: 68ft. (170 Modules) per bank / 204ft . (510 Modules) per PS

20W: 20ft. (50 Modules), 60W: 60ft . (150 Modules)

180W: 60ft. (150 Modules) per bank / 180ft . (450 Modules) per PS

20W: 21ft. (42 Modules), 60W: 64ft . (128 Modules)

180W: 64ft. (128 Modules) per bank / 192ft . (384Modules) per PS

20W: 20ft. (40 Modules), 60W: 60ft . (120 Modules)

180W: 60ft. (120 Modules) per bank / 180ft . (360 Modules) per PS

20W: 13ft. (26 Modules), 60W: 40ft . (80 Modules)

180W: 40ft. (80 Modules) per bank / 120ft . (240 Modules) per PS

20W: 9ft. (14 Modules), 60W: 28ft . (42 Modules)

180W: 28ft. (42 Modules) per bank/84ft . (126 Modules) per PS

20W: 12ft, 80W: 50ft , 100W: 59ft, 180W: 55ft per bank

20W: 8ft, 80W:33ft , 100W: 40ft, 180W: 37ft per bank

20W: 12ft, 80W: 50ft , 100W: 59ft, 180W: 55ft per bank

20W: 6ft. (216 LEDs), 80W: 24ft . (864 LEDs), 100W: 29ft. (1044 LEDs),

180W: 27ft. (972 LEDs) per bank /54ft . (1944 LEDs) per PS

20W: 14ft, 80W: 58ft , 100W: 69ft, 180W: 65ft. per bank

20W: 11ft, 80W: 44ft , 100W: 52ft, 180W: 48ft per bank

20W: 6ft. (216 LEDs), 80W: 24ft . (864 LEDs), 100W: 29ft. (1044 LEDs),

180W: 27ft. (972 LEDs) per bank /54ft . (1944 LEDs) per PS

Warranty GE offers a limited system warranty of up to five (5) years System Certifications UL/cUL Recognized #E219167, UL/cUL Classified #E229508, IP66 rated: separate enclosure required,

damp location rated. Product is compliant with material restriction requirements of RoHS.

* Max and PowerMax products can be deposited in the trash **Tetra Contour power consumption is measured by the foot

Tetra® Product Reference Guide

LED Strip/System Power Module

Wavelength/ LEDs Modules Lumens Lumens Consumption Dimension LED Color Per Per Viewing Per Module Per Foot Watts/Module** H x W x L Maximum Load Product Line SKU Color Temperature Module Foot Angle (Typical) (Typical) (Typical) (Inches) Voltage (FT/Power Supply)

Tetra miniStrip

GEWWBSP3-50K WARM WHITE 5000K 3 1 140 96 96 1.10/1.29 0.51 x 1.10 x 7.87 12V GEWWBSP3-41K WARM WHITE 4100K 3 1 140 72 96 1.10/1.29 0.51 x 1.10 x 7.87 12V

3” (76mm) Min. Depth

GEWWBSP3 WARM WHITE 3200K 3 1 140 72 96 1.10/1.29 0.51 x 1.10 x 7.87 12V GEBSH71-1 WHITE 7100K 3 1 140 120 110 1.49/1.75 0.51 x 1.10 x 7.87 12V GEBSH50-1 WARM WHITE 5000K 3 1 140 120 110 1.49/1.75 0.51 x 1.10 x 7.87 12V GEBSH41-1 WARM WHITE 4100K 3 1 140 90 90 1.49/1.75 0.51 x 1.10 x 7.87 12V GEBSH32-1 WARM WHITE 3200K 3 1 140 90 90 1.49/1.75 0.51 x 1.10 x 7.87 12V

Tetra miniStrip DS

GEWWBDP6-50K WARM WHITE 5000K 6 1 140 192 192 2.20/2.59 0.59 x 1.10 x 7.87 24V

6” (152mm) Min. Depth

GEWWBDP6-41K WARM WHITE 4100K 6 1 140 144 192 2.20/2.59 0.59 x 1.10 x 7.87 24V GEWWBDP6 WARM WHITE 3200K 6 1 140 144 192 2.20/2.59 0.59 x 1.10 x 7.87 24V GEBDH71-1 WHITE 7100K 6 1 140 240 220 2.98/3.50 0.59 x 1.10 x 7.87 24V GEBDH50-1 WARM WHITE 5000K 6 1 140 240 220 2.98/3.50 0.59 x 1.10 x 7.87 24V GEBDH41-1 WARM WHITE 4100K 6 1 140 180 180 2.98/3.50 0.59 x 1.10 x 7.87 24V GEBDH32-1 WARM WHITE 3200K 6 1 140 180 180 2.98/3.50 0.59 x 1.10 x 7.87 24V

Tetra PowerStrip

GESS50-1 WARM WHITE 5000K 5 1 140 280 280 2.4/2.82 0.45 x 1.14 x 9.20 12V

5” (127mm) Min. Depth

GESS41-1 WARM WHITE 4100K 5 1 140 210 210 2.4/2.82 0.45 x 1.14 x 9.20 12V GESS32-1 WARM WHITE 3200K 5 1 140 210 210 2.4/2.82 0.45 x 1.14 x 9.20 12V GESSH71-1 WHITE 7100K 8 1 140 360 360 3.63/4.15 0.47 x 1.12 x 9.92 12V GESSH50-1 WARM WHITE 5000K 8 1 140 360 360 3.63/4.15 0.47 x 1.12 x 9.92 12V GESSH41-1 WARM WHITE 4100K 8 1 140 260 260 3.63/4.15 0.47 x 1.12 x 9.92 12V

Cabinet Signs

GEDS71-1 WHITE 7100K 10 1 140 560 560 4.8/5.64 0.45 x 1.34 x 9.20 24V

Tetra PowerStrip DS

GEDS50-1 WARM WHITE 5000K 10 1 140 560 560 4.8/5.64 0.45 x 1.34 x 9.20 24V

5” (127mm) Min.

GEDS41-1 WARM WHITE 4100K 10 1 140 420 420 4.8/5.64 0.45 x 1.34 x 9.20 24V

Depth From Face

GESDS32-1 WARM WHITE 3200K 10 1 140 420 420 4.8/5.64 0.45 x 1.34 x 9.20 24V GEDSH71-1 WHITE 7100K 16 1 140 720 720 6.55/7.14 0.55 x 1.32 x 8.98 24V GEDSH50-1 WARM WHITE 5000K 16 1 140 720 720 6.55/7.14 0.55 x 1.32 x 8.98 24V GEDSH41-1 WARM WHITE 4100K 16 1 140 520 520 6.55/7.14 0.55 x 1.32 x 8.98 24V GEDSH32-1 WARM WHITE 3200K 16 1 140 520 520 6.55/7.14 0.55 x 1.32 x 8.98 24V GEWHBIP2 WHITE 7100K 2 1.5 23 x 100 200 200 2.40/2.74 0.83 x 1.30 x 5.91 24V

Tetra EdgeStrip

GEWWBIP2-50K WARM WHITE 5000K 2 1.5 23 x 100 200 200 2.40/2.74 0.83 x 1.30 x 5.91 24V

3” (76mm) Min. Depth

GEWWBIP2-41K WARM WHITE 4100K 2 1.5 23 x 100 150 150 2.40/2.74 0.83 x 1.30 x 5.91 24V GEWWBIP2 WARM WHITE 3200K 2 1.5 23 x 100 150 150 2.40/2.74 0.83 x 1.30 x 5.91 24V GEBIH71-1 WHITE 7100K 2 1.5 23 x 100 410 410 5.40/6.17 0.87 x 1.69 x 5.91 24V GEBIH50-1 WARM WHITE 5000K 2 1.5 23 x 100 410 410 5.40/6.17 0.87 x 1.69 x 5.91 24V GEBIH41-1 WARM WHITE 4100K 2 1.5 23 x 100 330 330 5.40/6.17 0.87 x 1.69 x 5.91 24V GEBIH32-1 WARM WHITE 3200K 2 1.5 23 x 100 330 330 5.40/6.17 0.87 x 1.69 x 5.91 24V

GEWHBSP3 WHITE 7100K 3 1 140 96 96 1.10/1.29 0.51 x 1.10 x 7.87 12V

GEWHBDP6 WHITE 7100K 6 1 140 192 192 2.20/2.59 0.59 x 1.10 x 7.87 24V

GESS71-1 WHITE 7100K 5 1 140 280 280 2.4/2.82 0.45 x 1.14 x 9.20 12V

GESSH32-1 WARM WHITE 3200K 8 1 140 260 260 3.63/4.15 0.47 x 1.12 x 9.92 12V

20W: 17ft. (17 Modules), 60W: 53ft . (53 Modules)

180W: 53ft. (53 Modules) per bank /159ft . (159 Modules) per PS

20W: 12ft. (12 Modules), 60W: 38ft . (38 Modules)

180W: 38ft. (38 Modules) per bank /114ft . (114 Modules) per PS

20W: 8ft. (8 Modules), 80W: 31ft . (31 Modules), 100W: 39ft. (39 Modules)

180W: 35ft. (35 Modules) per bank /70ft . (70 Modules) per PS

20W: 6ft. (6 Modules), 80W: 24ft . (24 Modules), 100W: 30ft. (30 Modules)

180W: 27ft. (27 Modules) per bank /54ft . (54 Modules) per PS

20W: 6ft. (6Modules), 60W: 20ft . (20 Modules)

180W: 20.0ft. (20 Modules) per bank / 60ft . (60 Modules) per PS

20W: 5ft. (5 Modules), 60W: 16ft . (16 Modules)

180W: 16ft. (16 Modules) per bank / 48ft . (48 Modules) per PS

20W: 3ft. (3 Modules), 80W: 14ft . (14 Modules)

100W: 16ft. (16 Modules), 180W: 15ft . (15 Modules) per bank / 30ft. (30 Modules) per PS

20W: 3ft. (3 Modules), 80W: 12ft . (12 Modules)

100W: 13ft. (13 Modules), 180W: 13ft . (13 Modules) per bank /26ft. (26 Modules) per PS

20W: 4.7ft. (7 Modules), 80W: 20ft . (30 Modules)

100W: 24ft. (36 Modules), 180W: 22ft . (33 Modules) per bank / 44ft. (66 Modules) per PS

20W: 2ft. (3 Modules), 80W: 9.3ft . (14 Modules)

100W: 11.3ft. (17 Modules), 180W: 10.7ft . (16 Modules) per bank / 21.4ft. (32 Modules) per PS

Warranty GE offers a limited system warranty of up to five (5) years System Certifications UL/cUL Recognized #E219167, UL/cUL Classified #E229508, IP66 rated: separate enclosure required,

damp location rated. Product is compliant with material restriction requirements of RoHS.
