Page 1
SPACEMAKER®& WALL OVEN MICROWAVES
Bigger, Brighter and Better than Ever
We bring good things to life.
Page 2
Exclusive CircuWave™1100
cooking system
New CircuWave system delivers
1100 watts of output power to provide a
more even distribution of heat, minimizing
cold spots. It's our most powerful
microwave cooking system, ever!
Quick Defrost
Convenient setting lets you thaw a pound
of ground meat up to 50% faster than our
previous models. What used to take 6 1/2
minutes now defrosts in just 3 minutes.
GE innovation,
space-saving design
With so many convenient
features and capabilities, it is
easy to see why people are making
GE Spacemaker their microwave
of choice. Ideal as a second oven,
these microwaves complete
your cooking center.
S
Since its introduction in 1979, the GE
Spacemaker microwave oven has been an
indispensable part of the American kitchen.
Today, its role is bigger than ever.
With roomy interiors and multiple baking
racks, our award-winning
microwave ovens hold up to six full-sized
plates of food. They’re not only bigger—
they’re also better.Spacemaker
microwave ovens deliver 1100 watts of
constant cooking power for even, flavorful
results. These ovens also feature improved
vortex venting, as well as brighter
interior and halogen cooktop lighting.
The Original Spacemaker
®
Before
After
2
Page 3
33
GEAppliances.com
JVM1860BF
Spacemaker microwave oven
3
Page 4
4
The JVM1490 preheats faster
than ever before with advanced
cooking technology.
Convection cooking combined
with microwave power (Fast Bake),
for cooking results up to 25%
faster than conventional ovens.
Convection cooking (Bake)
provides a browned, crisp
exterior and moist interior.
JVM1190SY Stainless steel (not shown)
JVM1190BY Black on black (not shown)
GE Profile
Spacemaker Oven
JVM1490SD Stainless steel
• 1.4 cu. ft. cavity • 900 watts* • Fast Bake • Bake • Fast Defrost • Halogen interior lighting
• Halogen cooktop lighting • Two-line scrolling display • Turntable • Easy-to-use dial control
• Bilingual display (English/Spanish)
JVM1490WD White on white (not shown)
JVM1490CD Bisque on bisque (not shown)
JVM1490BD Black on black (not shown)
GE Profile
Spacemaker Oven
JVM1190WY White on white
• 1.1 cu. ft. cavity • 825 watts* • Combination bake Hi/Lo
• Convection broil
GE Profile Spacemaker®Ovens with Convection/Microwave Cooking
These models include • Combination convection/microwave cooking • Sensor cooking controls • Multiple combination cooking levels
• SmartControl system with interactive display • Stainless steel interior • Auto/Time Defrost • Convection rack • Powerful two-speed venting
Note: bold = feature upgrade from previous model
User-friendly controls give you
access to a variety of
programmable options, and the
two-line scrolling display guides
you through the cooking process.
Not all features available on all models.
*IEC-705 Test Procedure
Page 5
GEAppliances.com
GE Profile
30" or 27"ConvectionMicrowave
Wall Oven
JEB1095SB Stainless steel
JEB1095WB White on white (not shown)
JEB1095CB Bisque on bisque (not shown)
JEB1095BB Black on black (not shown)
Convection/Microwave Wall Ovens provide a true
built-in appearance. JEB1095 will fit a 27" or 30"
cutout. A trim kit (included with all models) enables
the unit to be adapted to a 30" width. Available in
stainless steel, classic white, bisque and black.
Convection cooking produces
golden brown exteriors and
moist interiors.
GE Profile™Wall Oven with Convection/Microwave Cooking
This model includes • 1.0 cu. ft. cavity • 800 watts* • Convection cooking • Combination roast (probe) • Combination
convection/microwave cooking • Sensor cooking controls • Express Cook
Shown in 30" width
GE Profile 36" Spacemaker®Microwave Oven with Sensor Cooking
Sensor controls take the
guesswork out of cooking.
GE Profile
36" Spacemaker
JVM3660SF
Stainless steel
JVM3660BF
Black on black
(control panel shown)
JVM3660WF
White on white
(not shown)
JVM3660CF
Bisque on bisque
(not shown)
This model includes • 1.8 cu. ft. cavity • 1100 watts* • CircuWave
™
1100 cooking system • 36" width application • Sensor cooking controls
• Hidden vent for sleek appearance • Large 14-1/4" recessed turntable • Turntable On/Off • Bright view interior with halogen lamp • Halogen
cooktop lighting • Auto, Time and Quick Defrost • Add 30 seconds • Instant On controls • Bilingual display (English/Spanish) • Two-line
scrolling display
• Powerful three-speed plus boost 300-CFM 36" vortex venting • Removable rack • Easy mount installation
Note: bold = feature upgrade from previous model
Not all features available on all models.
*IEC-705 Test Procedure
5
Available April 2002
Page 6
6
GE Profile™and GE Spacemaker®XL1800 Microwave Ovens
Sensor controls take the
guesswork out of cooking.
Six-plate capacity with two racks
and recessed turntable, holds up
to six dinner plates or three
9" x 13" casserole dishes.
Quick Defrost lets you thaw a
pound of ground meat up to 50%
faster than our previous models.
These models include • CircuWave
™
1100 cooking system • Large 14-1/4" recessed turntable • Auto, Time and Quick Defrost • Add 30
seconds • Instant On controls
• Beeper volume control • Bilingual display (English/Spanish) • Two-line scrolling display • Big view window
• Powerful three-speed plus boost 300-CFM vortex venting • Easy mount installation • Turntable On/Off
Note: bold = feature upgrade from previous model
GE Profile
Spacemaker Sensor Oven
JVM1860BF Black on black
• 1.8 cu. ft. cavity • 1100 watts*
• Hidden vent for sleek appearance • Sensor cooking
controls
• Halogen cooktop lighting • Two racks—6-dinner-plate capacity
JVM1860WF
White on white
(control panel shown)
JVM1860SF
Stainless steel
(not shown)
JVM1861SF
Stainless steel
(not shown)
• Non-vented model
JVM1860CF
Bisque on bisque
(not shown)
GE
Spacemaker Sensor Oven
JVM1850WF White on white
• 1.8 cu. ft. cavity • 1100 watts*
• Sensor cooking controls • Removable rack,
two positions
JVM1850BF
Black on black
(control panel shown)
JVM1851BF
Black on black
(not shown)
• Non-vented model
JVM1851WF
White on white
(not shown)
• Non-vented model
JVM1850CF
Bisque on bisque
(not shown)
JVM1851CF
Bisque on bisque
(not shown)
• Non-vented model
Not all features available on all models.
*IEC-705 Test Procedure
Available April 2002
Available April 2002
Page 7
7
GEAppliances.com
GE
Spacemaker Sensor/Convenience Oven
JVM1650WB White on white
JVM1650SB
Stainless steel
(not shown)
JVM1650CB
Bisque on bisque
(not shown)
JVM1650BB
Black on black
(not shown)
Sensor controls take the
guesswork out of cooking.
This powerful 300-CFM-rated
venting system will remove smoke
and steam from your cooktop.
GE
Spacemaker Convenience Oven
JVM1840BF Black on black
• 1.8 cu. ft. cavity • 1100 watts* • Full-view cooktop lighting • Convenience cooking
controls • Removable rack
JVM1840WF
White on white
(control panel shown)
JVM1840CF
Bisque on bisque
(not shown)
Convenience cooking controls
allow you to defrost, cook or
reheat at the touch of a pad.
GE Spacemaker Microwave Oven with Sensor/Convenience Cooking
This model includes • 1.6 cu. ft. cavity • 1000 watts* • CircuWave cooking system • Sensor cooking controls • Convenience cooking
controls
• Turntable On/Off • Auto/Time Defrost • Help pad • Add 30 seconds • Full-view cooktop lighting • Removable rack • Powerful
300-CFM venting • Easy mount installation
Note: bold = feature upgrade from previous model
Not all features available on all models.
*IEC-705 Test Procedure
Available April 2002
Page 8
GE
Spacemaker Convenience Oven
JVM1440WD White on white
• 1.4 cu. ft. oven cavity • 950 watts* • CircuWave cooking system
• Turntable On/Off • Removable rack
JVM1440BD
Black on black
(not shown)
8
These models include • SmartControl System with interactive display • Convenience cooking controls • Delay Start • Reminder
• Auto/Time Defrost • Express Cook • Add 30 seconds • Instant On controls • Timer On/Off • Full-view cooktop lighting • Easy mount
installation • Powerful 300-CFM exhaust fan
Note: bold = feature upgrade from previous model
GE Spacemaker®Microwave Ovens
GE
Spacemaker Convenience Oven
JVM1640WB White on white
• 1.6 cu. ft. oven cavity • 1000 watts* • CircuWave
™
cooking system
• Turntable On/Off • Beeper volume control • Removable rack
JVM1640AB
Almond on almond
(not shown)
JVM1640BB
Black on black
(not shown)
Auto Defrost option automatically
sets time and power level for
fast defrosting.
Convenience cooking controls
allow you to defrost, cook or
reheat at the touch of a pad.
Add 30 seconds extends
cooking time without the
hassle of reprogramming.
This powerful 300-CFM-rated
venting system will remove smoke
and steam from your cooktop.
Not all features available on all models.
*IEC-705 Test Procedure
Page 9
9
GEAppliances.com
Spacemaker Convection/Microwave Ovens
Filler Panel Kit
See below for part numbers.
When replacing a 36" or 42" range hood, this kit fills
in the additional width to provide a custom built-in
appearance. For installation between cabinets only;
not for end-of-cabinet installation. Each kit contains
two 3"-wide filler panels. Two kits
are needed for a 42" opening.
Recirculating
Charcoal Filter Kit
See below for part numbers.
To be used when the
Spacemaker microwave
oven
cannot be vented
to the outside. (Included with
non-vented models.)
JX22SS—Stainless Steel Decorative Panel Kit
When replacing a Hi/Low range with a Spacemaker
microwave/convection oven or Spacemaker over a
range model, this panel kit fills in the area between
the microwave and range left by the Hi/Low model.
Optional Accessories (Available at additional cost)
Dimensions
(in inches)
Ventilation Options
The Spacemaker convection/microwave and Spacemaker microwave ovens are designed for adaptation to the following three
types of ventilation:
Outside Exhaust (Vertical—as shown above)
Outside Exhaust (Horizontal)
Recirculating (Non-vented ductless—see Filter Kit Drawing, order JX81, JX81A or JX81B)
Requires 120V grounded outlet. Electrical receptacle must be located in cabinet above Spacemaker microwave/convection and
Spacemaker microwave ovens. No additional wiring, venting or cabinet rebuilding necessary in many cases. Complete detailed,
easy-to-follow installation instructions and convenient full-size templates are packed with product.
Important: When installing these ovens over a range, allow minimum of 2" from bottom of microwave oven to top of range
backguard to allow for removal of light covers.
66" MIN.
Mounting
height
from
floor
30"
MIN.
width
required
Exhaust outlet
connects to
3-1/4" X 10" duct
H (rear)
105°
Door open
D
H
12"
MAX.
24-1/2
Recirculating Filler Decorative
Model Charcoal Filter Kit Panel Kit Panel Kit
JVM1190SY JX81 JX41 JX22SS
JVM1190WY JX81 JX40WH JX22SS
JVM1190BY JX81 JX41 JX22SS
JVM1490SD JX81A JX41 JX22SS
JVM1490WD JX81A JX40WH JX22SS
JVM1490CD JX81A JX40CT JX22SS
JVM1490BD JX81A JX41 JX22SS
JVM1440WD JX81A JX46WH JX22SS
JVM1440BD JX81A JX46BL JX22SS
JVM1640WB JX81A JX48WH JX22SS
JVM1640AB JX81A JX48AL JX22SS
JVM1640BB JX81A JX48BL JX22SS
JVM1650SB JX81A JX48 JX22SS
JVM1650WB JX81A JX48WH JX22SS
JVM1650CB JX81A JX48 JX22SS
JVM1650BB JX81A JX48BL JX22SS
JVM1840WF JX81B JX52WH JX22SS
JVM1840CF JX81B JX52CT JX22SS
JVM1840BF JX81B JX52BL JX22SS
JVM1850WF JX81B JX52WH JX22SS
JVM1850CF JX81B JX52CT JX22SS
JVM1850BF JX81B JX52BL JX22SS
JVM1860SF JX81B JX52BL JX22SS
JVM1860WF JX81B JX52WH JX22SS
JVM1860CF JX81B JX52CT JX22SS
JVM1860BF JX81B JX52BL JX22SS
JVM3660SF JX81B – –
JVM3660WF JX81B ––
JVM3660CF JX81B ––
JVM3660BF JX81B ––
JVM1490SD
JVM1490WD
JVM1190SY
JVM1490CD JVM1190WY
JVM1490BD JVM1190BY
Capacity
Oven cavity (cu. ft.) 1.4 1.1
Features
Watts (IEC-705 test procedure) 900 825
Controls Membrane/Dial Electronic Touch
SmartControl system
w/interactive display ●●
Electronic scrolling digital display
w/clock and AM/PM 2 Lines 1 Line
Variable scroll speed ●●
Help pad ●●
Concurrent programming ●●
Display On/Off ●●
Bilingual display (English/Spanish) ●
Cavity lighting Halogen Incandescent
Cooktop lighting Halogen Incandescent
Sensor controls
Chicken,
Cook Fish, Potato
Beverage ●●
Popcorn ●●
Reheat ●●
Vegetables (canned/fresh/frozen) ●●
Convection controls ●●
Convection broil Hi/Lo
Convection bake/ Fast Bake ● / ●● / –
Combination roast ●
Chicken,
Sensor combination Fish, Potato
Combination bake Hi/Lo
Express Cook (1-6 minutes) ●●
Instant On controls ●●
Time cook I & II I & II
Add 30 seconds ●●
Temp cook ●●
Auto/Time Defrost ● / ●● / ●
Fast Defrost ●
Power levels 10 10
Delay start ●
Programmable night light ●●
Timer On/Off ●●
Reminder ●
Variable beeper volume control ●●
Cooking complete reminder ●●
Child lockout ●●
Two-speed venting ●●
Appearance
Stainless steel
White on white Stainless steel
Bisque on bisque White on white
Color appearance Black on black Black on black
Black
White Black
Bisque White
Case color Black Black
Designer-style handle ●●
Weights & Dimensions
WxHxD–JVM1490 Cavity 21-3/32 x 8-7/32 x 14-3/32
(in inches) Exterior 29-7/8 x 15-21/32 x 15-7/8
WxHxD–JVM1190 Cavity 18 x 8-1/16x 12-1/2
(in inches) Exterior 29-15/16 x 15-1/8x 14-1/4
Approx. shipping weight (lbs.) 98 98
Power/Ratings
2450 Frequency (MHz) ●●
Electrical input @ 120V Watts 1800 1300
Amperage 15 12.5
Accessories
Convection rack/ Broil pan ● / – ● / ●
Warranty
Full one-year in home warranty* ●●
Limited nine-year magnetron
warranty* (10 years total) ●●
*See written warranty for details.
This information is not intended to be used for installing unit
described. Before installing, consult installation instructions
packed with product/kit for current dimensional data.
GE Profile
™
19
30
3/8"
depth
Listed by
Underwriters
Laboratories
R
Model D H H (rear)
JVM1490 15-7/8 15-21/32 16-19/32
JVM1190 14-1/4 15-1/8 15-1/2
Page 10
10
Spacemaker®Microwave Ovens
JVM1850WF
JVM1860SF JVM1851WF*
JVM3660SF JVM1861SF*
JVM1850CF JVM1650SB
JVM3660WF JVM1860WF
JVM1851CF* JVM1840WF JVM1650WB JVM1640WB
JVM3660CF JVM1860CF
JVM1850BF JVM1840CF JVM1650CB JVM1640AB JVM1440WD
JVM3660BF JVM1860BF JVM1851BF* JVM1840BF JVM1650BB JVM1640BB JVM1440BD
Capacity
Oven cavity (cu. ft.) 1.8 1.8 1.8 1.8 1.6 1.6 1.4
Features
Watts (IEC-705 test procedure) 1100 1100 1100 1100 1000 1000 950
Electronic touch controls ●●●●●●●
SmartControl system w/interactive display ●●●●●●●
Scrolling display 2 Line 2 Line 2 Line 2 Line 1 Line 1 Line 1 Line
Clock and AM/PM pad ●●●●●●●
Variable scroll speed ●●●●●●●
Help pad ●●●●●●●
Concurrent programming ●●●●●●●
Display On/Off ●●●●●●●
Bilingual display (English/Spanish) ●●●●
Sensor controls Beverage ●●● ●
Chicken ●●
Fish ●●
Meats ●●
Popcorn ●●● ●
Potatoes ●●● ●
Reheat ●●● ●
Vegetables ●●● ●
Custom pads ●●●●
Convenience Beverage ●●●
controls
Cook
●●●
Popcorn ●●●
Reheat ●●●
Snacks ●●
Express cook (1-6 min.) ●●●●●●●
Instant On controls ●●●●●●●
Time cook I & II I & II I & II I & II I & II I & II I & II
Add 30 seconds ●●●●●●●
Auto/Time Defrost ● / ●● / ●● / ●● / ●● / ●● / ●● / ●
Quick Defrost ●●●●
Power levels 10 10 10 10 10 10 10
Delay Start ●●●●●●●
Reminder ●●●●●●
CircuWave™ cooking system 1100 1100 1100 1100 ●●●
Rack(s) 1 2 1 1 1 1 1
Turntable Recessed Recessed Recessed Recessed ●●●
Turntable On/Off ●●●●●●●
Halogen interior lighting ●●●
Halogen cooktop lighting ●●
Full-view cooktop lighting ●●●●●●●
Night light ●●●●●●●
Programmable night light ●●●●●
Timer On/Off ●●●●●●●
Beeper volume control ●●●●●●
Cooking complete reminder ●●●●●●●
Child lockout ●●●●●●●
300-CFM exhaust fan 3-Speed plus Boost 3-Speed plus Boost 3-Speed plus Boost 3-Speed plus Boost 2-Speed 2-Speed 2-Speed
Easy mount installation ●●●●●●●
Appearance
Color appearance** SS/WW/CC/BB SS/WW/CC/BB WW/CC/BB WW/CC/BB SS/WW/CC/BB WW/AA/BB WW/BB
Black/White/ Black/White/ White/ White/ Black/White/
Case color Bisque/Black Bisque/Black Bisque/Black Bisque/Black Bisque/Black White/Almond/Black White/Black
Designer-style handle ●●●●●●●
Big view window Bright view Bright view ●● ●●●
Weights & Dimensions
WxHxD
Cavity 21-29/32 x 9-1/2 x 14-19/32 20-1/4 x 9-9/32 x 14-13/32 †††
(in inches) Exterior ††† 29-7/8 x 16-15/32 (rear) x 15-1/16 †††
Approx. shipping weight (lbs.) 69 67 68 68 67 67 67
Power/Ratings
2450 Frequency (MHz) ●●●●●●●
Electrical input
Watts 1480 1480 1480 1480 1480 1480 1480
@ 120V Amperage 15 15 15 15 15 15 15
Warranty
Full one-year in-home warranty‡ ●●●●●●●
Limited nine-year magnetron
warranty‡ (10 years total) ●●●●●●●
*Non-vented model.
**SS = Stainless steel, WW = White on white, CC = Bisque, AA = Almond on almond, BB = Black on black.
†Exterior dimensions: depth excludes handle.
††Model JVM3660—Exterior: 35-7/8 x 16-13/32 (rear) x 15.
†††Model JVM1440—Cavity: 19-5/16 x 9-5/16 x 13-3/16 Exterior: 29-7/8 x 16-1/2 (rear) x 14-15/16.
‡See warranty for details.
NOTE: Convenience popcorn pad designed for use with 3 package sizes—3.5, 3.0 and 1.75 oz.
GE Profile
™
GE
This information is not intended to be used for installing unit described. Before installing,
consult installation instructions packed with product/kit for current dimensional data.
Dimensions (in inches)
All models except JVM3660.
JVM3660 requires 36"
minimum width.
66" MIN.
21-3/4"
Door open
Mounting
height
from floor
12"
MAX.
15-3/4
30" MIN.
width required
15
16-1/2
Exhaust outlet
connects to
3-1/4" X 10" duct
Page 11
11
GEAppliances.com
This information is not intended to be used for installing unit
described. Before installing, consult installation instructions
packed with product/kit for current dimensional data.
17-1/2"
36" Min.
27" or 30"
Cabinet
25-1/4"
26-3/4"
18-5/8"
Locate electrical outlet on
back wall 17" min. outside
and 19" min. inside cutout.
16-3/8"
Excluding
Handle
18"
29-3/4"
with side trim
18-5/8"
Listed by
Underwriters
Laboratories
Cutout and Dimensional Information (in inches)
45-1/4"
to top
surface
of plywood
base
25-1/4
24
25-1/4
27
1-7/8"
MIN.
15-5/8"
MIN.
27-1/2"
MIN.
17-1/2
24-3/16
29-1/4
18-5/8
26-3/4
26-3/4
16-3/8"
excluding
handle
R
27" single oven installation
30" single oven installation
Convection/Microwave Wall Ovens
JEB1095WB
JEB1095SB JEB1095CB JEB1095BB
Capacity
Oven cavity (cu. ft.) 1.0 1.0 1.0
Features
Watts (IEC-705 test procedure) 800 800 800
Electronic touch controls ●●●
Electronic digital display w/clock ●●●
Sensor controls
Beverage ●●●
Cook ●●●
Popcorn ●●●
Reheat ●●●
Convection cook ●●●
Combination cook ●●●
Combination roast (probe) ●●●
Express cook ●●●
Instant On controls ●●●
Time cook I & II I & II I & II
Add 30 seconds ●●●
Temp Cook/Hold (probe) ●●●
Auto Defrost ●●●
Time Defrost ●●●
Power levels 10 10 10
Delay/Start reminder ●●●
Minute pad ●●●
Program cooking 5-Stage 5-Stage 5-Stage
Kitchen timer 99-M./99-S. Digital 99-M./99-S. Digital 99-M./99-S. Digital
Variable beeper volume ●●●
Cooking complete reminder ●●●
Appearance
Color appearance* SS WW/CC BB
Case color Black White/Bisque Black
Designer-style handle ●●●
Weights & Dimensions
Cavity 18x 8-3/16x 11-1/2
WxHxD
(in inches) Exterior† 26-3/4x18-5/8 x16-3/8
Approx. shipping weight (lbs.) 84 84 84
Power/Ratings
2450 Frequency (MHz) ●●●
Watts 1450 1450 1450
Electrical input @ 120V Amperage 13.0 13.0 13.0
Accessories
Deluxe cookbook ●●●
Wire oven rack ●●●
30" trim kit (included) ●●●
Warranty
Full one-year in-home warranty** ●●●
Limited nine-year magnetron
warranty** (10 years total) ●●●
*SS = Stainless steel, WW = White on white, CC = Bisque, BB = Black on black.
**See written warranty for details.
†Exterior dimensions: depth excludes handle.
GE Profile
™
Page 12
GE has a policy of continuous improvement of
its products and reserves the right to change
materials and specifications without notice.
© 2002 General Electric Company
Pub. No. 4-S401 PC32198
GE Appliances
General Electric Company
Louisville, Kentucky 40225
GEAppliances.com
GE Profile™Convection/
Microwave Wall Ovens
Offering a true built-in look, these
ovens bring added space and visual
appeal to the kitchen. Our wall
oven is designed to fit 27" or 30"
installations.
Microwave Ovens
These ovens offer tremendous
flexibility, with a variety of color,
size and feature options. There’s a
GE countertop microwave for
every kitchen: Build them into a
wall, hang them from a cabinet or
set them on a shelf.
Spacemaker®Over-The-Range
Microwave Ovens
These ovens complete the cooking
center and make the most of
consumers’ time and kitchen space.
Powerful venting and lighting
systems are integrated into the
base of each oven, eliminating the
need for a range hood.
GE has a microwave for every kitchen.
GE Appliances on the Web
GEAppliances.com
Everything you want to know about GE appliances.
The GE Answer Center
®
800.626.2000
Questions? Call anytime.
GE Genuine Parts
800.626.2002
Accessories to enhance, upgrade or fix it.
GE Appliance Service
800.432.2737
(800.GE.CARES)
Product service at your convenience.
Industry-leading service support from—
GE is the appliance brand most often mentioned
among the brands rated as offering the best products
and services in America.
*
*Source:
Louis Harris Poll – 2000
America’s
#
1
Preferred
Appliance
Brand
Loading...
