GE GEWADRGDG755 Specs
GTD75GCPL/GCSL
GE® 7.4 Cu. Ft. Capacity Aluminized Alloy Drum Gas Dryer With HE Sensor Dry
DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)
EXHAUST OPTION: When viewed from the front
of the unit, exhaust 3-way via rear, left and bottom.
Dryer is shipped exhausted to the rear. Alternate
exhausting knockouts are supplied.
GAS: An individual, properly-grounded branch circuit,
with a three-prong grounding-type receptacle, protected
by a 15 or 20 amp circuit breaker or a time-delay fuse is
required.
GAS DRYER ELECTRIC RATING: 120V, 60Hz, 6A
GAS (BTU/HR): 22,000. Factory-equipped for
natural gas. Tested for LP gas. LP gas supply requires
a conversion kit. Check installation instructions for
correct kit and have a qualified gas technician install a
conversion kit. See dryer ducting information for proper
installation.
NOTE: Dryer wall outlet must be located within 36" of
service cord entry and accessible when dryer is mounted
in position.
INS TA LLATI O N IN F O RMATI O N: For complete
information, see installation instructions packed with
your dryer.
SPECIAL INSTALLATION REQUIREMENTS
ALCOVE OR CLOSET INSTALLATION:
- If your dryer is approved for installation in an alcove or closet, it will be stated on a
label on the dryer back.
- The dryer MUST be exhausted to the outside.
- Minimum clearances between dryer cabinet and adjacent walls or other surfaces
are: 0" either side; 1" front, top and rear
- Closet doors must be louvered or otherwise ventilated and must contain a
minimum of 60 sq. in. of open area equally distributed. If this closet contains
both a washer and a dryer, doors must contain a minimum of 120 sq. in. of
open area equally distributed.
- No other fuel-burning appliance shall be installed in the same closet with a
ga s d r yer.
BATHROOM OR BEDROOM INSTALLATION:
- The dryer MUST be exhausted to the outdoors.
- The installation must conform with the local codes, or in the absence of local
codes, with the National Electric Code and National Fuel Gas Code, ANSI
Z223 for gas dryers.
MINIMUM CLEARANCES OTHER THAN ALCOVE OR CLOSET
INS TA LLATI O N:
- Minimum clearances to combustible surfaces are: 0" both sides; 1" rear
DRYER EXHAUSTING INFORMATION :
- Use metal duct only, vertical and horizontal ducting.
For answers to your Monogram, GE Café™ Series, GE Profile™ Series or
GE Appliances product questions, visit our website at geappliances.com
or call GE Answer Center® Service, 800.626.2000.
Speci fication Created 5/17
GTD75GCPL/GCSL
22 1/2"
30 1/2"
27"
3 1/2"
1 3/4"
3 1/4"
8"
40 1/2"
48"
27"
5"
Power Cord 4 1/2"
11 3/4"
Side View Rear View
5
Back View
Power
Cord Hole
4-1/2
GE® 7.4 Cu. Ft. Capacity Aluminized Alloy Drum Gas Dryer With HE Sensor Dry
DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)
POWER CORD LOCATIONS
For answers to your Monogram, GE Café™ Series, GE Profile™ Series or
GE Appliances product questions, visit our website at geappliances.com
or call GE Answer Center® Service, 800.626.2000.
Speci fication Created 5/17
