Page 1
GCF23KGW
GE® Counter-Depth 22.7 Cu. Ft. Side-By-Side Refrigerator with Dispenser
Dimensions and Installation Information (in inches)
Height to top of hinge (in.) A 69-1/4
Height to top of case (in.) B 68-3/4
Case depth without door (in.) 23-7/8
C/)
c
= o
Case depth less door handle (in.) 26-3/4
E «
Oi C
> 0)
Case depth with door handle (in.) 29-3/16
O E
■q
Depth with fresh food door open 90° (in.) 45-9/16
Width (in.) G 35-3/4
Width with door open 90° inc. door handle (in.) H 40-3/4
C/)
Each side (in.)
Q)
U
Top (in.)
Q)
u
Back (in.)
fWoter hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 10-3/4" on freezer
side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 15".
Allow additional space for any necessary leveling adjustments.
1/8
1
1/2
A B
C
1
H
G
n
E
D
1 1 1 1
Top View
For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
ge.com or call GE Answer Center
800.626.2000.
®
service,
imagination at work
Listed by
Underwriters
Laboratories
Specification Revised 6/07
Total volume and shelf
area are calculated by
the Association of Home
Appliance Manufacturers'
standards.
310177
Page 2
GCF23KGW
GE® Counter-Depth 22.7 Cu. Ft. Side-By-Side Refrigerator with Dispenser
Rough-In Dimensions
Standard, New Construction
and Replacement Installation
Installation Tips to Maximize
the Built-In Look
• All wall/floor molding should be removed
prior to installation.
• Water recess on rear wall recommended to
prevent water line damage. 48" minimum
length, 1/4" diameter water line tubing
recommended.
• When possible, recess both copper water
line and electrical outlet. (See local codes)
• Front and rear leveling legs are adjustable
for the built-in look. (See owner's manual)
• If optional collar trim kit is to be used or
anticipated, see collar trim installation on
next page for different rough-in dimensions.
imagination at work
*The rough-in dimenssion i^lf ?’0-1/4" is minimum find is measLjred from the
finisstied fiieor to top eif opsnince (or th^ undsrsiids of the o\/srhsad cabiin^tss).
For lOodeis with Triro Kit: If fran'lsiisss s^eie cabinees are pianneicJ fo)r г^^зo^/s; the
rstfrigsrгrSe)r, yoru relayí neeci ton ce)níslidfsr tociciing a rpaxisnun'l o)f 1/4" (70-1/2") to
height of opening to aiiow additionai cisarancs between cabinet doors and
top of rsfrigsrator trim when cabinet doors are in open position.
Specification Revised 6/07
310177
Page 3
GCF23KGW
GE® Counter-Depth 22.7 Cu. Ft. Side-By-Side Refrigerator with Dispenser
Features and Benefits
Counter-Depth Configuration - Offers a built-in look by fitting almost completely flush with
surrounding cabinetry and blending in with décor
External Controls with Actual Temperature Display, Child Lock and Door Alarm - Eliminates the
guesswork in setting refrigerator temperatures; conveniently displayed on the dispenser
Freshness Center™ (3-pan stack) - Maximizes shelf space by utilizing three humiditycontrolled drawers
TurboCool™ Setting - "Revs up" the refrigerator, cooling it quickly after frequent door openings
Integrated Ice™ System - Frees up valuable freezer space; It tilts down, providing easy access to bulk ice
Integrated Shelf Support System - Provides strong, yet flexible support
AutoEnergy Saver - Senses freezer and fresh door openings and adjusts refrigeration operation
cycles accordingly
ClearLook™ Adjustable Gallon Door Bins - Store gallon containers with ease
Adjustable Slide-Out, Spillproof Glass Shelves - Shelves slide out, spills stay put
GE Water Filtration System - Delivers clean great-tasting water and ice through the
LightTouch! Dispenser
FrostGuard™ Technology - Protects frozen items from freezer burn by monitoring freezer door
openings and defrosting only when needed
Deluxe Quiet Design - Significantly reduces operating noise
NeverClean™ Condenser - Condenser coils are encased, so they don't require cleaning in normal
operating environments
Model GCF23KGWWW - White on white
Model GCF23KGWBB - Black on black
imagination at work
Specification Revised 6/07
310177
