GE F60 UR Series Instruction Manual

g

ISO9001:2000

Title Pa ge

GE Industrial Systems

F60 Feeder Protection System

UR Series Instruction Manual

F60 Revision: 5.5x

Manual P/N: 1601-0093-S3 (GEK-113413B)

Copyright © 2008 GE Multilin

GE Multilin

215 Anderson Avenue, Markham, Ontario
Canada L6E 1B3
Tel: [phone] Fax: [phone]
Internet: http://www.GEmultilin.com

*1601-0093-S3*

E83849

LISTED

IND.CONT. EQ.

52TL

832762A2.CDR

T

E

S

I

R

E

G

D

E

R

I

G

E

GE Multilin's Quality Management

System is registered to

ISO9001:2000
QMI # 005094

UL # A3775

N

I

M

L

I

U

T

L

g

Addendum

GE Industrial Systems

ADDENDUM

This addendum contains information that relates to the F60 Feeder Protec tion System, version 5.5x. This addendum
lists a number of information items that appear in the instruction manual GEK-113413B (revision S3) but are not
included in the current F60 operations.

The following functions and items are not yet available with the current version of the F60 relay:

• Signal sources SRC 3 to SRC 6.
Version 4.0x and higher releases of the F60 relay includes new hardware (CPU and CT/VT modules).

• The new CPU modules are specified with the following order codes: 9E, 9G, 9H, 9J, 9K, 9L, 9M, 9N, 9P, 9R, and 9S.

• The new CT/VT modules are specified with the follow ing order codes: 8F, 8G, 8H, 8J 8L, 8M, 8N, 8R.
The following table maps the relationship between the old CPU and CT/VT modules to the newer versions:

MODULE OLD NEW DESCRIPTION

CPU 9A 9E RS485 and RS485 (Modbus RTU, DNP)

9C 9G RS485 and 10Base-F (Ethernet, Modbus TCP/IP, DNP)
9D 9H RS485 and redundant 10Base-F (Ethernet, Modbus TCP/IP, DNP)

--- 9J RS485 and multi-mode ST 100Base-FX

--- 9K RS485 and multi-mode ST redundant 100Base-FX

--- 9L RS485 and single mode SC 100Base-FX

--- 9M RS485 and single mode SC redundant 100Base-FX

--- 9N RS485 and 10/100Base-T

--- 9P RS485 and single mode ST 100Base-FX

--- 9R RS485 and single mode ST redundant 100Base-FX

--- 9S RS485 and six-port managed Ethernet switch

CT/VT 8A 8F Standard 4CT/4VT

8B 8G Sensitive ground 4CT/4VT
8C 8H Standard 8CT
8D 8J Sensitive ground 8CT/8VT

-- 8L Standard 4CT/4VT with enhanced diagnostics

-- 8M Sensitive ground 4CT/4VT with enhanced diagnostics

-- 8N Standard 8CT with enhanced diagnostics

-- 8R Sensitive ground 8CT/8VT with enhanced diagnostics

The new CT/VT modules can only be used with the new CPUs (9E, 9G, 9H, 9J, 9K, 9L, 9M, 9N, 9P, 9R, and 9S), and
the old CT/VT modules can only be used with the old CPU modules (9A, 9C, 9D). To prevent any hardware mis­matches, the new CPU and CT/VT modules have blue labels and a warni ng sticker stating “Attn.: Ensure C PU and
DSP module label colors are the same!”. In the event that there is a mismatch between the CPU and CT/VT module,
the relay will not function and a

All other input/output modules are compatible with the new hardware.
With respect to the firmware, firmware versions 4.0x and higher are only compatible with the new CPU and CT/VT mod-

ules. Previous versions of the firmware (3.4x and earlier) are only compatible with the older CPU and CT/VT modules.

DSP ERROR or HARDWARE MISMATCH error will be displayed.

Table of Contents

TABLE OF CONTENTS

1. GETTING STARTED 1.1 IMPORTANT PROCEDURES

1.1.1 CAUTIONS AND WARNINGS........................................................................... 1-1

1.1.2 INSPECTION CHECKLIST................................................................................1-1

1.2 UR OVERVIEW

1.2.1 INTRODUCTION TO THE UR...........................................................................1-2

1.2.2 HARDWARE ARCHITECTURE.........................................................................1-3

1.2.3 SOFTWARE ARCHITECTURE......................................................................... .1-4

1.2.4 IMPORTANT CONCEPTS.................................................................................1-4

1.3 ENERVISTA UR SETUP SOFTWARE

1.3.1 PC REQUIREMENTS........................................................................................1-5

1.3.2 INSTALLATION..................................................................................................1-5

1.3.3 CONFIGURING THE F60 FOR SOFTWARE ACCESS ....................................1-7

1.3.4 USING THE QUICK CONNECT FEATURE.......................................................1-9

1.3.5 CONNECTING TO THE F60 RELAY...............................................................1-15

1.4 UR HARDWARE

1.4.1 MOUNTING AND WIRING.................................................... ... ........................1-16

1.4.2 COMMUNICATIONS........................................................................................1-16

1.4.3 FACEPLATE DISPLAY....................................... .... .........................................1-16

1.5 USING THE RELAY

1.5.1 FACEPLATE KEYPAD............................................................. ........................1-17

1.5.2 MENU NAVIGATION .......................................... .... ... ......................................1-17

1.5.3 MENU HIERARCHY ....................................................................... .................1-17

1.5.4 RELAY ACTIVATION.......................................................................................1-17

1.5.5 RELAY PASSWORDS.....................................................................................1-18

1.5.6 FLEXLOGIC™ CUSTOMIZATION........................................ ... .... ....................1-18

1.5.7 COMMISSIONING...........................................................................................1-19

2. PRODUCT DESCRIPTION 2.1 INTRODUCTION

2.1.1 OVERVIEW........................................................................................................2-1

2.1.2 ORDERING........................................................................................................2-2

2.1.3 REPLACEMENT MODULES ..................................... ........................................2-4

2.2 SPECIFICATIONS

2.2.1 PROTECTION ELEMENTS...............................................................................2-7

2.2.2 USER-PROGRAMMABLE ELEMENTS...........................................................2-10

2.2.3 MONITORING..................................................................................................2-11

2.2.4 METERING......................................................................................................2-11

2.2.5 INPUTS............................................................................................................2-12

2.2.6 POWER SUPPLY ............................................ ... .... .........................................2-13

2.2.7 OUTPUTS........................................................................................................2-13

2.2.8 COMMUNICATIONS........................................................................................2-15

2.2.9 INTER-RELAY COMMUNICATIONS...............................................................2-16

2.2.10 ENVIRONMENTAL ..........................................................................................2-16

2.2.11 TYPE TESTS ...................................................................................................2-17

2.2.12 PRODUCTION TESTS ....................................................................................2-17

2.2.13 APPROVALS ...................................................................................................2-17

2.2.14 MAINTENANCE ............................................................................................... 2-17

3. HARDWARE 3.1 DESCRIPTION

3.1.1 PANEL CUTOUT ...............................................................................................3-1

3.1.2 MODULE WITHDRAWAL AND INSERTION.....................................................3-5

3.1.3 REAR TERMINAL LAYOUT...............................................................................3-7

3.2 WIRING

3.2.1 TYPICAL WIRING..............................................................................................3-9

3.2.2 DIELECTRIC STRENGTH...............................................................................3-11

3.2.3 CONTROL POWER.........................................................................................3-11

3.2.4 CT/VT MODULES............................................................................................3-12

3.2.5 CONTACT INPUTS/OUTPUTS .......................................................................3-14

3.2.6 TRANSDUCER INPUTS/OUTPUTS................................................................ 3-22

GE Multilin F60 Feeder Protection System v

TABLE OF CONTENTS

3.2.7 RS232 FACEPLATE PORT..............................................................................3-23

3.2.8 CPU COMMUNICATION PORTS.....................................................................3-23

3.2.9 IRIG-B...............................................................................................................3-27

3.3 DIRECT INPUT/OUTPUT COMMUNICATIONS

3.3.1 DESCRIPTION.................................................................................................3-28

3.3.2 FIBER: LED AND ELED TRANSMITTERS......................................................3-30

3.3.3 FIBER-LASER TRANSMITTERS.....................................................................3-30

3.3.4 G.703 INTERFACE...........................................................................................3-31

3.3.5 RS422 INTERFACE ................................................. ........................................3-34

3.3.6 RS422 AND FIBER INTERFACE.....................................................................3-36

3.3.7 G.703 AND FIBER INTERFACE ......................................................................3-36

3.3.8 IEEE C37.94 INTERFACE................................................................................3-37

3.3.9 C37.94SM INTERFACE ...................................................................................3-39

3.4 MANAGED ETHERNET SWITCH MODULES

3.4.1 OVERVIEW ......................................................................................................3-41

3.4.2 MANAGED ETHERNET SWITCH MODULE HARDWARE..............................3-41

3.4.3 MANAGED SWITCH LED INDICATORS.........................................................3-42

3.4.4 CONFIGURING THE MANAGED ETHERNET SWITCH MODULE.................3-42

3.4.5 UPLOADING F60 SWITCH MODULE FIRMWARE.........................................3-44

3.4.6 ETHERNET SWITCH SELF-TEST ERRORS...................................................3-47

4. HUMAN INTERFACES 4.1 ENERVISTA UR SETUP SOFTWARE INTERFACE

4.1.1 INTRODUCTION ................................................................................................4-1

4.1.2 CREATING A SITE LIST....................................................................................4-1

4.1.3 ENERVISTA UR SETUP OVERVIEW................................................................4-1

4.1.4 ENERVISTA UR SETUP MAIN WINDOW.............................. ... .........................4-3

4.1.5 SETTINGS TEMPLATES ...................................................................................4-3

4.1.6 SECURING AND LOCKING FLEXLOGIC™ EQUATIONS................................4-8

4.1.7 SETTINGS FILE TRACEABILITY.....................................................................4-10

4.2 FACEPLATE INTERFACE

4.2.1 FACEPLATE.....................................................................................................4-13

4.2.2 LED INDICATORS............................................................................................4-14

4.2.3 CUSTOM LABELING OF LEDS.......................................................................4-17

4.2.4 DISPLAY...........................................................................................................4-23

4.2.5 BREAKER CONTROL......................................................................................4-23

4.2.6 KEYPAD ...........................................................................................................4-24

4.2.7 MENUS.............................................................................................................4-24

4.2.8 CHANGING SETTINGS ...................................................................................4-26

5. SETTINGS 5.1 OVERVIEW

5.1.1 SETTINGS MAIN MENU....................................................................................5-1

5.1.2 INTRODUCTION TO ELEMENTS......................................................................5-4

5.1.3 INTRODUCTION TO AC SOURCES..................................................................5-5

5.2 PRODUCT SETUP

5.2.1 SECURITY..........................................................................................................5-8

5.2.2 DISPLAY PROPERTIES ..................................................................................5-11

5.2.3 CLEAR RELAY RECORDS..............................................................................5-13

5.2.4 COMMUNICATIONS........................................................................................5-14

5.2.5 MODBUS USER MAP......................................................................................5-33

5.2.6 REAL TIME CLOCK .........................................................................................5-34

5.2.7 FAULT REPORTS............................................................................................5-35

5.2.8 OSCILLOGRAPHY...........................................................................................5-37

5.2.9 DATA LOGGER................................................................................................5-39

5.2.10 DEMAND ..........................................................................................................5-41

5.2.11 USER-PROGRAMMABLE LEDS .....................................................................5-42

5.2.12 USER-PROGRAMMABLE SELF-TESTS.........................................................5-45

5.2.13 CONTROL PUSHBUTTONS ............................................................................5-46

5.2.14 USER-PROGRAMMABLE PUSHBUTTONS....................................................5-47

5.2.15 FLEX STATE PARAMETERS ..........................................................................5-52

5.2.16 USER-DEFINABLE DISPLAYS........................................................................5-53

vi F60 Feeder Protection System GE Multilin

TABLE OF CONTENTS

5.2.17 DIRECT INPUTS/OUTPUTS ..................................... .... ..................................5-55

5.2.18 TELEPROTECTION.........................................................................................5-63

5.2.19 INSTALLATION ................................................................................................5-63

5.3 SYSTEM SETUP

5.3.1 AC INPUTS......................................................................................................5-65

5.3.2 POWER SYSTEM........................................................................ ... .................5-66

5.3.3 SIGNAL SOURCES.........................................................................................5-67

5.3.4 BREAKERS......................................................................................................5-70

5.3.5 DISCONNECT SWITCHES .............................................................................5-74

5.3.6 FLEXCURVES™..............................................................................................5-77

5.4 FLEXLOGIC™

5.4.1 INTRODUCTION TO FLEXLOGIC™...............................................................5-84

5.4.2 FLEXLOGIC™ RULES ........................................... .........................................5-94

5.4.3 FLEXLOGIC™ EVALUATION............................................... ...........................5-94

5.4.4 FLEXLOGIC™ EXAMPLE ...................................... .........................................5-95

5.4.5 FLEXLOGIC™ EQUATION EDITOR.............................................. .... .............5-99

5.4.6 FLEXLOGIC™ TIMERS...................................................................... ... .... ...... 5-99

5.4.7 FLEXELEMENTS™.......................................................................................5-101

5.4.8 NON-VOLATILE LATCHES........................................................................... 5-105

5.5 GROUPED ELEMENTS

5.5.1 OVERVIEW....................................................................................................5-106

5.5.2 SETTING GROUP .........................................................................................5-106

5.5.3 LOAD ENCROACHMENT..............................................................................5-107

5.5.4 PHASE CURRENT ........................................................................................5-109

5.5.5 NEUTRAL CURRENT............................................. ... .... ... .... .........................5-119

5.5.6 WATTMETRIC GROUND FAULT..................................................................5-127

5.5.7 GROUND CURRENT..................................................................................... 5-130

5.5.8 NEGATIVE-SEQUENCE CURRENT.............................................................5-132

5.5.9 BREAKER FAILURE....................................................................... .... ........... 5-138

5.5.10 VOLTAGE ELEMENTS..................................................................................5-147

5.5.11 SENSITIVE DIRECTIONAL POWER.............................................................5-155

5.6 CONTROL ELEMENTS

5.6.1 OVERVIEW....................................................................................................5-158

5.6.2 SETTING GROUPS.......................................................................................5-158

5.6.3 SELECTOR SWITCH.....................................................................................5-159

5.6.4 UNDERFREQUENCY....................................................................................5-165

5.6.5 OVERFREQUENCY ......................................................................................5-166

5.6.6 FREQUENCY RATE OF CHANGE................................................................5-167

5.6.7 SYNCHROCHECK.........................................................................................5-169

5.6.8 AUTORECLOSE............................................................................................5-173

5.6.9 DIGITAL ELEMENTS...................................................................... .... ... ........ 5-179

5.6.10 DIGITAL COUNTERS .................................. ..................................................5-182

5.6.11 MONITORING ELEMENTS ...........................................................................5-184

5.6.12 COLD LOAD PICKUP.................................................................................... 5-201

5.6.13 TRIP BUS....................................................................................................... 5-203

5.7 INPUTS/OUTPUTS

5.7.1 CONTACT INPUTS........................................................................................5-205

5.7.2 VIRTUAL INPUTS..........................................................................................5-207

5.7.3 CONTACT OUTPUTS....................................................................................5-208

5.7.4 VIRTUAL OUTPUTS......................................................................................5-210

5.7.5 REMOTE DEVICES.......................................................................................5-211

5.7.6 REMOTE INPUTS..........................................................................................5-212

5.7.7 REMOTE OUTPUTS......................................................................................5-213

5.7.8 RESETTING...................................................................................................5-214

5.7.9 DIRECT INPUTS/OUTPUTS .........................................................................5-214

5.7.10 TELEPROTECTION INPUTS/OUTPUTS ......................................................5-218

5.8 TRANSDUCER INPUTS/OUTPUTS

5.8.1 DCMA INPUTS ................................................... ...........................................5-220

5.8.2 RTD INPUTS.................................................... ... .... .......................................5-221

5.8.3 DCMA OUTPUTS ............................................... .... ... ....................................5-222

5.9 TESTING

5.9.1 TEST MODE..................................................................................................5-226

5.9.2 FORCE CONTACT INPUTS..........................................................................5-226

5.9.3 FORCE CONTACT OUTPUTS......................................................................5-227

GE Multilin F60 Feeder Protection System vii

TABLE OF CONTENTS

6. ACTUAL VALUES 6.1 OVERVIEW

6.1.1 ACTUAL VALUES MAIN MENU.........................................................................6-1

6.2 STATUS

6.2.1 CONTACT INPUTS............................................................................................6-3

6.2.2 VIRTUAL INPUTS ..............................................................................................6-3

6.2.3 REMOTE INPUTS..............................................................................................6-3

6.2.4 TELEPROTECTION INPUTS.............................................................................6-4

6.2.5 CONTACT OUTPUTS........................................................................................6-4

6.2.6 VIRTUAL OUTPUTS ..........................................................................................6-5

6.2.7 AUTORECLOSE.................................................................................................6-5

6.2.8 REMOTE DEVICES............................................................................................6-5

6.2.9 DIGITAL COUNTERS.........................................................................................6-7

6.2.10 SELECTOR SWITCHES ....................................................................................6-7

6.2.11 FLEX STATES....................................................................................................6-7

6.2.12 ETHERNET ........................................................................................................6-7

6.2.13 HI-Z STATUS.......................................... ............................................................6-8

6.2.14 DIRECT INPUTS ................................................................ ................................6-8

6.2.15 DIRECT DEVICES STATUS ....................................... .......................................6-9

6.2.16 EGD PROTOCOL STATUS...................................... ... .... ...................................6-9

6.2.17 TELEPROTECTION CHANNEL TESTS...........................................................6-10

6.2.18 INCIPIENT FAULT DETECTOR.......................................................................6-10

6.2.19 ETHERNET SWITCH .......................................................................................6-11

6.3 METERING

6.3.1 METERING CONVENTIONS ...........................................................................6-12

6.3.2 SOURCES........................................................................................................6-15

6.3.3 SENSITIVE DIRECTIONAL POWER...............................................................6-21

6.3.4 SYNCHROCHECK ...........................................................................................6-21

6.3.5 TRACKING FREQUENCY................................................................................6-21

6.3.6 FREQUENCY RATE OF CHANGE..................................................................6-22

6.3.7 FLEXELEMENTS™..........................................................................................6-22

6.3.8 IEC 61580 GOOSE ANALOG VALUES ...........................................................6-23

6.3.9 WATTMETRIC GROUND FAULT.....................................................................6-23

6.3.10 TRANSDUCER INPUTS/OUTPUTS.................................................................6-23

6.4 RECORDS

6.4.1 FAULT REPORTS............................................................................................6-24

6.4.2 EVENT RECORDS...........................................................................................6-24

6.4.3 OSCILLOGRAPHY...........................................................................................6-25

6.4.4 DATA LOGGER................................................................................................6-25

6.4.5 BREAKER MAINTENANCE ............................................... .... ... .......................6-26

6.4.6 HI-Z RECORDS............................... .... ........................................................... ..6-26

6.5 PRODUCT INFORMATION

6.5.1 MODEL INFORMATION ...................................................................................6-27

6.5.2 FIRMWARE REVISIONS................................................. ... .... ..........................6-27

7. COMMANDS AND
TARGETS

7.1 COMMANDS

7.1.1 COMMANDS MENU...........................................................................................7-1

7.1.2 VIRTUAL INPUTS ..............................................................................................7-1

7.1.3 CLEAR RECORDS.............................................................................................7-1

7.1.4 SET DATE AND TIME........................................................................................7-2

7.1.5 RELAY MAINTENANCE.....................................................................................7-2

7.2 TARGETS

7.2.1 TARGETS MENU............................ ............................................................ .......7-4

7.2.2 TARGET MESSAGES........................................................................................7-4

7.2.3 RELAY SELF-TESTS.........................................................................................7-4

8. THEORY OF OPERATION 8.1 HIGH-IMPEDANCE (HI-Z) FAULT DETECTION

8.1.1 DESCRIPTION...................................................................................................8-1

8.1.2 ENERGY ALGORITHM......................................................................................8-1

viii F60 Feeder Protection System GE Multilin

TABLE OF CONTENTS

8.1.3 RANDOMNESS ALGORITHM...........................................................................8-2

8.1.4 EXPERT ARC DETECTOR ALGORITHM......................................................... 8-2

8.1.5 SPECTRAL ANALYSIS ALGORITHM............................................................... 8-2

8.1.6 LOAD EVENT DETECTOR ALGORITHM.........................................................8-2

8.1.7 LOAD ANALYSIS ALGORITHM ........................................................................8-3

8.1.8 LOAD EXTRACTION ALGORITHM...................................................................8-3

8.1.9 ARC BURST PATTERN ANALYSIS ALGORITHM............................................8-3

8.1.10 ARCING SUSPECTED ALGORITHM.................................................... ............ 8-3

8.1.11 OVERCURRENT DISTURBANCE MONITORING............................................8-3

8.1.12 HI-Z EVEN HARMONIC RESTRAINT ALGORITHM ......................................... 8-3

8.1.13 HI-Z VOLTAGE SUPERVISION ALGORITHM ..................................................8-4

8.2 FAULT LOCATOR

8.2.1 FAULT TYPE DETERMINATION.......................................................................8-5

9. COMMISSIONING 9.1 TESTING

9.1.1 TESTING UNDERFREQUENCY AND OVERFREQUENCY ELEMENTS......... 9-1

A. FLEXANALOG

PARAMETERS

B. MODBUS

COMMUNICATIONS

A.1 PARAMETER LIST

A.1.1 FLEXANALOG LIST............................................ ...............................................A-1

B.1 MODBUS RTU PROTOCOL

B.1.1 INTRODUCTION................................................................................................B-1

B.1.2 PHYSICAL LAYER........................................... ... .... ...........................................B-1

B.1.3 DATA LINK LAYER............................................................................................B-1

B.1.4 CRC-16 ALGORITHM........................................................................................B-2

B.2 MODBUS FUNCTION CODES

B.2.1 SUPPORTED FUNCTION CODES ...................................................................B-3

B.2.2 READ ACTUAL VALUES OR SETTINGS (FUNCTION CODE 03/04H) ...........B-3

B.2.3 EXECUTE OPERATION (FUNCTION CODE 05H)...........................................B-4

B.2.4 STORE SINGLE SETTING (FUNCTION CODE 06H).......................................B-4

B.2.5 STORE MULTIPLE SETTINGS (FUNCTION CODE 10H)................................B-5

B.2.6 EXCEPTION RESPONSES.................................... ... ........................................B-5

B.3 FILE TRANSFERS

B.3.1 OBTAINING RELAY FILES VIA MODBUS........................................................B-6

B.3.2 MODBUS PASSWORD OPERATION...............................................................B-8

B.4 MEMORY MAPPING

B.4.1 MODBUS MEMORY MAP .................................................................................B-9

B.4.2 DATA FORMATS.............................................................................................B-60

C. IEC 61850

COMMUNICATIONS

C.1 OVERVIEW

C.1.1 INTRODUCTION................................................................................................C-1

C.1.2 COMMUNICATION PROFILES.........................................................................C-1

C.2 SERVER DATA ORGANIZATION

C.2.1 OVERVIEW........................................................................................................C-2

C.2.2 GGIO1: DIGITAL STATUS VALUES .................................................................C-2

C.2.3 GGIO2: DIGITAL CONTROL VALUES..............................................................C-2

C.2.4 GGIO3: DIGITAL STATUS AND ANALOG VALUES FROM RECEIVED GOOSE

DATAC-2

C.2.5 GGIO4: GENERIC ANALOG MEASURED VALUES.........................................C-2

C.2.6 MMXU: ANALOG MEASURED VALUES...........................................................C-3

C.2.7 PROTECTION AND OTHER LOGICAL NODES...............................................C-3

C.3 SERVER FEATURES AND CONFIGURATION

C.3.1 BUFFERED/UNBUFFERED REPORTING........................................................C-5

GE Multilin F60 Feeder Protection System ix

TABLE OF CONTENTS

C.3.2 FILE TRANSFER...............................................................................................C-5

C.3.3 TIMESTAMPS AND SCANNING...................................................... .... ... ..........C-5

C.3.4 LOGICAL DEVICE NAME .................................................................................C-5

C.3.5 LOCATION........................................................................................................C-5

C.3.6 LOGICAL NODE NAME PREFIXES..................................................................C-6

C.3.7 CONNECTION TIMING.....................................................................................C-6

C.3.8 NON-IEC 61850 DATA......................................................................................C-6

C.3.9 COMMUNICATION SOFTWARE UTILITIES.....................................................C-6

C.4 GENERIC SUBSTATION EVENT SERVICES: GSSE AND GOOSE

C.4.1 OVERVIEW.......................................................................................................C-7

C.4.2 GSSE CONFIGURATION..................................................................................C-7

C.4.3 FIXED GOOSE................................ ............................................................ ......C-7

C.4.4 CONFIGURABLE GOOSE................................................................................C-7

C.4.5 ETHERNET MAC ADDRESS FOR GSSE/GOOSE..........................................C-9

C.4.6 GSSE ID AND GOOSE ID SETTINGS............................................................C-10

C.5 IEC 61850 IMPLEMENTATION VIA ENERVISTA UR SETUP

C.5.1 OVERVIEW.....................................................................................................C-11

C.5.2 CONFIGURING IEC 61850 SETTIN GS.................................................. ........C-12

C.5.3 ABOUT ICD FILES..........................................................................................C-13

C.5.4 CREATING AN ICD FILE WITH ENERVISTA UR SETUP..............................C-17

C.5.5 ABOUT SCD FILES.........................................................................................C-17

C.5.6 IMPORTING AN SCD FILE WITH ENERVISTA UR SETUP..... .... ... .... ...........C-20

C.6 ACSI CONFORMANCE

C.6.1 ACSI BASIC CONFORMANCE STATEMENT ................................................C-22

C.6.2 ACSI MODELS CONFORMANCE STATEMENT............................................C-22

C.6.3 ACSI SERVICES CONFORMANCE STATEMENT.........................................C-23

C.7 LOGICAL NODES

C.7.1 LOGICAL NODES TABLE...............................................................................C-26

D. IEC 60870-5-104

COMMUNICATIONS

D.1 IEC 60870-5-104

D.1.1 INTEROPERABILITY DOCUMENT...................................................................D-1

D.1.2 IEC 60870-5-104 POINT LIST...........................................................................D-9

E. DNP COMMUNICATIONS E.1 DEVICE PROFILE DOCUMENT

E.1.1 DNP V3.00 DEVICE PROFILE..........................................................................E-1

E.1.2 IMPLEMENTATION TABLE ..............................................................................E-4

E.2 DNP POINT LISTS

E.2.1 BINARY INPUT POINTS...................................................................................E-8

E.2.2 BINARY AND CONTROL RELAY OUTPUT...................................................... E-9

E.2.3 COUNTERS.....................................................................................................E-10

E.2.4 ANALOG INPUTS............................................................................................E-11

F. MISCELLANEOUS F.1 CHANGE NOTES

F.1.1 REVISION HISTORY.............................. ...........................................................F-1

F.1.2 CHANGES TO THE F60 MANUAL....................................................................F-2

F.2 ABBREVIATIONS

F.2.1 STANDARD ABBREVIATIONS.........................................................................F-4

F.3 WARRANTY

F.3.1 GE MULTILIN WARRANTY...............................................................................F-6

INDEX

x F60 Feeder Protection System GE Multilin

1 GETTING STARTED 1.1 IMPORTANT PROCEDURES

1 GETTING STARTED 1.1IMPORTANT PROCEDURES

Please read this chapter to help guide you through the initial setup of your new relay.

1.1.1 CAUTIONS AND WARNINGS

Before attempting to install or use the relay, it is imperative that all WARNINGS and CAUTIONS
in this manual are reviewed to help prevent personal injury, equipment damage, and/or down-

WARNING

CAUTION

time.

1.1.2 INSPECTION CHECKLIST

• Open the relay packaging and inspect the unit for physical damage.

• View the rear nameplate and verify that the correct model has been ordered.

1

F60

Technical Support:
Tel: [phone]
Fax: [phone]

Feeder Management Relay

GE Multilin

http://www.GEmultilin.com

®

RATINGS:

Control Power:
Contact Inputs:
Contact Outputs:

®

®

88-300V DC @ 35W / 77-265V AC @ 35VA
300V DC Max 10mA
Standard Pilot Duty / 250V AC 7.5A
360V A Resistive / 125V DC Break
4A @ L/R = 40mS / 300W

Made in
Canada

Model:
Mods:
Wiring Diagram:
Inst. Manual:
Serial Number:
Firmware:
Mfg. Date:

- M A A B 9 7 0 0 0 0 9 9 -

F60E00HCHF8AH6AM6BP8BX7A
000
832769A3
GEK-113272
MAZB98000029
D
2005/01/05

832773A1.CDR

Figure 1–1: REAR NAMEPLATE (EXAMPLE)

• Ensure that the following items are included:

• Instruction manual

• GE EnerVista CD (includes the EnerVista UR Setup software and manuals in PDF format)

• mounting screws

• registration card (attached as the last page of the manual)

• Fill out the registration form and return to GE Multilin (include the serial number located on the rear nameplate).

• For product information, instruction manual updates, and the latest software updates, please visit the GE Multilin web­site at http://www.GEmultilin.com

.

If there is any noticeable physical damage, or any of the contents listed are missing, please contact GE
Multilin immediately.

NOTE

GE MULTILIN CONTACT INFORMATION AND CALL CENTER FOR PRODUCT SUPPORT:

GE Multilin
215 Anderson Avenue
Markham, Ontario
Canada L6E 1B3

TELEPHONE: [phone] (North America only)
FAX: [phone]
E-MAIL: [e-mail]
HOME PAGE: http://www.GEmultilin.com

GE Multilin F60 Feeder Protection System 1-1

1.2 UR OVERVIEW 1 GETTING STARTED

1.2UR OVERVIEW 1.2.1 INTRODUCTION TO THE UR

1

Historically, substation protection, control, and metering functions were performed with electromechanical e quipment. This
first generation of equipment was gradually replaced by analog electronic equipment, most of which emulated the single­function approach of their electromechanical precursors. Both of th ese technologi es required expensive cabling a nd auxil­iary equipment to produce functioning systems.

Recently, digital electronic equipment has begun to provide protectio n, control, and metering functions. Initially, this equip­ment was either single function or had very limited multi-function capability, and did not significantly reduce the cabling and
auxiliary equipment required. However, recent digital relays have become quite multi-functional, reducing cabling and aux­iliaries significantly. These devices also transfer data to central control facilities and Human Machine Interfaces using elec­tronic communications. The functions performed by these pro ducts have become so broad that many users now prefer the
term IED (Intelligent Electronic Device).

It is obvious to station designers that the amount of cabling and auxiliary equipment installed in stations can be even further
reduced, to 20% to 70% of the levels common in 1990, to achieve large cost r eductions. This requires placing eve n more
functions within the IEDs.

Users of power equipment are also interested in reducing cost by improving power quality and pe rsonnel productivity, and
as always, in increasing system reliability and efficiency. These objectives are realized through software which is used to
perform functions at both the station and supervisory levels. The use of these systems is growing rapidly.

High speed communications are required to meet the data tr ansfer rates required by moder n automatic control and moni­toring systems. In the near future, very high speed communications will be required to perform protection signaling with a
performance target response time for a command signal between two IEDs, from transmission to reception, of less than 3
milliseconds. This has been established by the IEC 61850 standard.

IEDs with the capabilities outlined above will also provide significantly more power system data than is presently available,
enhance operations and maintenance, and permit the use of adaptive system configuration for protection and control sys­tems. This new generation of equipment must also be easily incorporated into automation systems, at both the station and
enterprise levels. The GE Multilin Universal Relay (UR) has been developed to meet these goals.

1-2 F60 Feeder Protection System GE Multilin

1 GETTING STARTED 1.2 UR OVERVIEW

1.2.2 HARDWARE ARCHITECTURE

a) UR BASIC DESIGN

The UR is a digital-based device containing a central processing unit (CPU) that handles multiple types of input and output
signals. The UR can communicate over a local area network (LAN ) with an operator interface, a programming device, or
another UR device.

Input Elements

Contact Inputs Contact Outputs

Virtual Inputs

Analog Inputs

CT Inputs

VT Inputs

Remote Inputs

Direct Inputs

Input

Status

Table

Protective Elements

CPU Module Output Elements

Logic Gates

Pickup
Dropout
Operate

Output

Status

Table

Virtual Outputs

Analog Outputs

Remote Outputs

-DNA

-USER

Direct Outputs

LAN

Programming

Device

Figure 1–2: UR CONCEPT BLOCK DIAGRAM

The CPU module contains firmware that provides protection elements in the form of logic algorithms, as well a s program­mable logic gates, timers, and latches for control features.

Input elements accept a variety of analog or digital signals from the field. The UR isolates an d converts these signals into
logic signals used by the relay.

Output elements convert and isolate the logic signals generated by the relay into digital or analog signals that can be used
to control field devices.

Operator
Interface

827822A2.CDR

1

b) UR SIGNAL TYPES

The contact inpu t s and output s are digital signals associated with connections to hard-wired contacts. Both ‘wet’ and ‘dry’
contacts are supported.

The vi rtual inputs and outputs are digital signals associated with UR-series internal logic signals. Virtual inputs include
signals generated by the local user interface. The virtual outputs are outputs of FlexLogic™ equation s used to customize
the device. Virtual outputs can also serve as virtual inputs to FlexLogic™ equations.

The analog inputs and outputs are signals that are associated with transducers, such as Resistance Temperature Detec-
tors (RTDs).

The CT and VT inputs refer to analog current transformer and voltage transformer signals used to monitor AC power lines.
The UR-series relays support 1 A and 5 A CTs.

The remote inputs and outputs provide a means of sharing digi tal point state information between remote UR-series
devices. The remote outputs interface to the remote inputs of other UR-series devices. Remote outputs are FlexLogic™
operands inserted into IEC 61850 GSSE and GOOSE messages.

The direct inputs and outputs provide a means of sharing digital point states between a number of UR-series IEDs over a
dedicated fiber (single or multimode), RS422, or G.703 interface. No switching equipment is required as the IEDs are con­nected directly in a ring or redundant (dual) ring configuration. This featu re is optimized for speed and intended for pilot­aided schemes, distributed logic applications, or the extension of the input/output capabilities of a single relay chassis.

GE Multilin F60 Feeder Protection System 1-3

1.2 UR OVERVIEW 1 GETTING STARTED

c) UR SCAN OPERATION

The UR-series devices operate in a cyclic scan fashion. The dev ice reads the inputs into an input status table, solves the

1

logic program (FlexLogic™ equation), and then sets each output to the appropriate state in an output status table. Any
resulting task execution is priority interrupt-driven.

Read Inputs

Protection elements
serviced by sub-scan

Protective Elements

Solve Logic

PKP
DPO
OP

Set Outputs

827823A1.CDR

Figure 1–3: UR-SERIES SCAN OPERATION

1.2.3 SOFTWARE ARCHITECTURE

The firmware (software embedded in the relay) is designed in functional modules wh ich can be installed in any relay as
required. This is achieved with object-oriented design and programming (OOD/OOP) techniques.

Object-oriented techniques involve the use of objects and classes. An object is defined as “a logical entity that contains
both data and code that manipulates that data”. A class is the generalized form of similar objects. By using this concept,
one can create a protection class with the protection elements as objects of the class, such as time overcurrent, instanta­neous overcurrent, current differential, undervoltage, overvoltage, underfrequency, and distance. These objects represent
completely self-contained software modules. The same object-class concept can be used for metering, input/output control,
hmi, communications, or any functional entity in the system.

Employing OOD/OOP in the software architecture of the F60 achieves the same features as the hardware architecture:
modularity, scalability, and flexibility. The application software for any UR-series device (for example, feeder protection,
transformer protection, distance protection) is constructed by co mb in i ng o b j ects from the various functionality classes. Th i s
results in a common look and feel across the entire family of UR-series platform-based applications.

1.2.4 IMPORTANT CONCEPTS

As described above, the architecture of the UR-series relays differ from previous devices. To achieve a general understand­ing of this device, some sections of Chapter 5 are quite helpful. The most important functions of the relay are contained in
“elements”. A description of the UR-series elements can be found in the Introduction to elements section in chapter 5.
Examples of simple elements, and some of the organization of this manual, can be found in the Control elements section of
chapter 5. An explanation of the use of inputs from CT s and VTs is in the Introduction to AC sources section in chapter 5. A
description of how digital signals are used and routed within the relay is contained in the Introduction to FlexLogic™ section
in chapter 5.

1-4 F60 Feeder Protection System GE Multilin

1 GETTING STARTED 1.3 ENERVISTA UR SETUP SOFTWARE

1.3ENERVISTA UR SETUP SOFTWARE 1.3.1 PC REQUIREMENTS

The faceplate keypad and display or the EnerVista UR Setup software interface can be used to communicate with the relay .
The EnerVista UR Setup software interface is the preferred method to edit settings and view actual values because the PC
monitor can display more information in a simple comprehensible format.

The following minimum requirements must be met for the EnerVista UR Setup software to properly operate on a PC.

• Pentium class or higher processor (Pentium II 300 MHz or higher recommended)

• Windows 95, 98, 98SE, ME, NT 4.0 (Service Pack 4 or higher), 2000, XP

• Internet Explorer 4.0 or higher

• 128 MB of RAM (256 MB recommended)

• 200 MB of available space on system drive and 200 MB of available space on installation drive

• Video capable of displaying 800 x 600 or higher in high-color mode (16-bit color)

• RS232 and/or Ethernet port for communications to the relay

The following qualified modems have been tested to be compliant with the F60 and the EnerVista UR Setup software.

• US Robotics external 56K FaxModem 5686

• US Robotics external Sportster 56K X2

• PCTEL 2304WT V.92 MDC internal modem

1.3.2 INSTALLATION

After ensuring the minimum requirements for using EnerVista UR Setup are met (see previous section), use the following
procedure to install the EnerVista UR Setup from the enclosed GE EnerVista CD.

1. Insert the GE EnerVista CD into your CD-ROM drive.

2. Click the Install Now button and follow the installation instructions to install the no-charge EnerVista software.

3. When installation is complete, start the EnerVista Launchpad application.

4. Click the IED Setup section of the Launch Pad window.

1

GE Multilin F60 Feeder Protection System 1-5

1.3 ENERVISTA UR SETUP SOFTWARE 1 GETTING STARTED

5. In the EnerVista Launch Pad window, click the Add Product button and select the “F60 Feeder Protection System”

1

from the Install Software window as shown below. Select the “Web” option to ensure the most recent software release,
or select “CD” if you do not have a web connection, then click the Add Now button to list software items for the F60.

6. EnerVista Launchpad will obtain the software from the Web or CD and automatically start the installation program.

7. Select the complete path, including the new directory name, where the EnerVista UR Setup will be installed.

8. Click on Next to begin the installation. The files will be installed in the directory indicated and the installation program
will automatically create icons and add EnerVista UR Setup to the Windows start menu.

9. Click Finish to end the installation. The UR-series device will be added to the list of installed IEDs in the EnerVista
Launchpad window, as shown below.

1-6 F60 Feeder Protection System GE Multilin

1 GETTING STARTED 1.3 ENERVISTA UR SETUP SOFTWARE

1.3.3 CONFIGURING THE F60 FOR SOFTWARE ACCESS

a) OVERVIEW

The user can connect remotely to the F60 through the rear RS485 port or the rear Ethernet port with a PC running the
EnerVista UR Setup software. The F60 can also be accessed locally with a laptop computer through the front panel RS232
port or the rear Ethernet port using the Quick Connect feature.

• To configure the F60 for remote access via the rear RS485 port(s), refer to the Configuring Serial Communications

section.

• To configure the F60 for remote access via the rear Ethernet port, refer to the Configuring Ethernet Communicati ons

section. An Ethernet module must be specified at the time of ordering.

• To configure the F60 for local access with a laptop through either the front RS232 port or rear Ethernet port, refer to the

Using the Quick Connect Feature section. An Ethernet module must be specified at the time of ordering for Ethernet
communications.

b) CONFIGURING SERIAL COMMUNICATIONS

Before starting, verify that the serial cable is properly connected to the RS485 terminals on the back of the device. T he
faceplate RS232 port is intended for local use and is not described in this section; see the Using the Quick Connect Feature
section for details on configuring the RS232 port.

A GE Multilin F485 converter (or compatible RS232-to-RS485 converter) is wi ll be required. Refer to th e F485 instruction
manual for additional details.

1. Verify that the latest version of the EnerVista UR Setup software is installed (available from the GE EnerVista CD or

online from http://www.GEmultilin.com

2. Select the “UR” device from the EnerVista Launchpad to start EnerVista UR Setup.

3. Click the Device Setup button to open the Device Setup window and click the Add Site button to define a new site.

4. Enter the desired site name in the “Site Name” field. If desired, a short description of site can also be entere d along

with the display order of devices defined for the site. In this example, we will use “Location 1” a s the site name. Click
the OK button when complete.

5. The new site will appear in the upper-left list in the EnerVista UR Setup window. Click the Device Setup button then

select the new site to re-open the Device Setup window.

6. Click the Add Device button to define the new device.

7. Enter the desired name in the “Device Name” field and a description (optional) of the site.

). See the Software Installation section for installation details.

1

GE Multilin F60 Feeder Protection System 1-7

1.3 ENERVISTA UR SETUP SOFTWARE 1 GETTING STARTED

8. Select “Serial” from the Interface drop-down list. This will display a numbe r of interface parameters that must be
entered for proper serial communications.

1

Figure 1–4: CONFIGURING SERIAL COMMUNICATIONS

9. Enter the relay slave address, COM port, baud rate, and parity settings from the

MUNICATIONS ÖØ SERIAL PORTS menu in their respective fields.

10. Click the Read Order Code button to connect to the F60 device and upload the order code. If an communications error
occurs, ensure that the EnerVista UR Setup serial communications values entered in the previous step correspond to
the relay setting values.

11. Click “OK” when the relay order code has been received. The new device will be added to the Site List window (or
Online window) located in the top left corner of the main EnerVista UR Setup window.

The Site Device has now been configured for RS232 communications. Proceed to the Connecting to th e F60 section to
begin communications.

c) CONFIGURING ETHERNET COMMUNICATIONS

Before starting, verify that the Ethernet network cable is properly connected to the Ethernet port on the back of the relay. To
setup the relay for Ethernet communications, it will be necessary to define a Site, then add the relay as a Device at that site.

1. Verify that the latest version of the EnerVista UR Setup software is installed (available from the GE EnerVista CD or
online from http://www.GEmultilin.com

2. Select the “UR” device from the EnerVista Launchpad to start EnerVista UR Setup.

3. Click the Device Setup button to open the Device Setup window, then click the Add Site button to define a new site.

4. Enter the desired site name in the “Site Name” field. If desired, a short description of site can also be entered along
with the display order of devices defined for the site. In this example, we will use “Location 2” a s the site name. Click
the OK button when complete.

5. The new site will appear in the upper-left list in the EnerVista UR Setup window. Click the Device Setup button then
select the new site to re-open the Device Setup window.

6. Click the Add Device button to define the new device.

7. Enter the desired name in the “Device Name” field and a description (optional) of the site.

). See the Software Installation section for installation details.

SETTINGS Ö PRODUCT SETUP ÖØ COM-

1-8 F60 Feeder Protection System GE Multilin

1 GETTING STARTED 1.3 ENERVISTA UR SETUP SOFTWARE

8. Select “Ethernet” from the Interface drop-down list. This will display a number of interface parameters that must be

entered for proper Ethernet functionality.

1

Figure 1–5: CONFIGURING ETHERNET COMMUNICATIONS

9. Enter the relay IP address specified in the

ADDRESS) in the “IP Address” field.

10. Enter the relay sl ave address and Modbus port address values fro m the respective settings in the SETTINGS Ö PROD-

UCT SETUP ÖØ COMMUNICATIONS ÖØ MODBUS PROTOCOL menu.

1 1. Click the Read Order Code button to connect to the F60 device and upload the order code. If an communications error

occurs, ensure that the three EnerVista UR Setup values entered in the previous steps correspond to the relay setting
values.

12. Click OK when the relay order code has been received. The new device will be added to the Site List window (or

Online window) located in the top left corner of the main EnerVista UR Setup window.

The Site Device has now been configured for Ethernet communications. Proceed to the Connecting to the F60 section to
begin communications.

a) USING QUICK CONNECT VIA THE FRONT PANEL RS232 PORT

Before starting, verify that the serial cable is properly connected from the laptop computer to the front panel RS232 port
with a straight-through 9-pin to 9-pin RS232 cable.

1. Verify that the latest version of the EnerVista UR Setup software is installed (available from the GE EnerVista CD or

online from http://www.GEmultilin.com

2. Select the “UR” device from the EnerVista Launchpad to start EnerVista UR Setup.

SETTINGS Ö P RODUCT SETUP ÖØ COMMUNICATIONS ÖØ NETWORK Ö IP

1.3.4 USING THE QUICK CONNECT FEATURE

). See the Software Installation section for installation details.

GE Multilin F60 Feeder Protection System 1-9

1.3 ENERVISTA UR SETUP SOFTWARE 1 GETTING STARTED

3. Click the Quick Connect button to open the Quick Connect dialog box.

1

4. Select the Serial interface and the correct COM Port, then click Connect.

5. The EnerVista UR Setup software will create a site named “Quick Connect” with a corresponding device also named
“Quick Connect” and display them on the upper-left corner of the screen. Expand the sections to vie w data directly
from the F60 device.

Each time the EnerVista UR Setup software is initialized, click the Quick Connect button to establish direct communica­tions to the F60. This ensures that configuration of the EnerVista UR Setup software matches the F60 model number.

b) USING QUICK CONNECT VIA THE REAR ETHERNET PORTS

To use the Quick Connect feature to access the F60 from a laptop through Ethern et, first assign an IP ad dress to the relay
from the front panel keyboard.

1. Press the MENU key until the SETTINGS menu is displayed.

2. Navigate to the

3. Enter an IP address of “1.1.1.1” and select the ENTER key to save the value.

4. In the same menu, select the

5. Enter a subnet IP address of “255.0.0.0” and press the ENTER key to save the value.

Next, use an Ethernet cross-over cable to connect the laptop to the rear Ethernet port. The pinout for an Ethernet cross­over cable is shown below.

Now, assign the laptop computer an IP address compatible with the relay’s IP address.

SETTINGS Ö PRODUCT SETUP ÖØ COMMUNICATIONS ÖØ NETWORK Ö IP ADDRESS setting.

SUBNET IP MASK setting.

5

4

3

2

1

6

7

8

END 1 END 2
Pin Wire color Diagram Pin Wire color Diagram

1 White/orange 1 White/green
2 Orange 2 Green

3 White/green 3 White/orange
4 Blue 4 Blue
5 White/blue 5 White/blue
6 Green 6 Orange
7 White/brown 7 White/brown
8 Brown 8 Brown

Figure 1–6: ETHERNET CROSS-OVER CABLE PIN LAYOUT

842799A1.CDR

1-10 F60 Feeder Protection System GE Multilin

1 GETTING STARTED 1.3 ENERVISTA UR SETUP SOFTWARE

1. From the Windows desktop, right-click the My Network Places icon an d select Properties to open the network con-

nections window.

2. Right-click the Local Area Connection icon and select Properties.

1

3. Select the Internet Protocol (TCP/IP) item from the list provided and click the Properties button.

4. Click on the “Use the following IP address” box.

GE Multilin F60 Feeder Protection System 1-11

1.3 ENERVISTA UR SETUP SOFTWARE 1 GETTING STARTED

5. Enter an IP address with the first three numbers the same as the IP address of the F60 relay and the last number dif­ferent (in this example, 1.1.1.2).

1

6. Enter a subnet mask equal to the one set in the F60 (in this example, 255.0.0.0).

7. Click OK to save the values.

Before continuing, it will be necessary to test the Ethernet connection.

1. Open a Windows console window by selecting Start > Run from the Windows Start menu and typing “cmd”.

2. Type the following command:

C:\WINNT>ping 1.1.1.1

3. If the connection is successful, the system will return four replies as follows:

Pinging 1.1.1.1 with 32 bytes of data:
Reply from 1.1.1.1: bytes=32 time<10ms TTL=255

Reply from 1.1.1.1: bytes=32 time<10ms TTL=255
Reply from 1.1.1.1: bytes=32 time<10ms TTL=255
Reply from 1.1.1.1: bytes=32 time<10ms TTL=255

Ping statistics for 1.1.1.1:

Packets: Sent = 4, Received = 4, Lost = 0 (0% loss),

Approximate round trip time in milli-sec ond s:

Minimum = 0ms, Maximum = 0ms, Average = 0 ms

4. Note that the values for time and TTL will vary depending on local network configuration.

If the following sequence of messages appears when entering the C:\WINNT>ping 1.1.1.1 command:

Pinging 1.1.1.1 with 32 bytes of data:
Request timed out.

Request timed out.
Request timed out.
Request timed out.

Ping statistics for 1.1.1.1:

Packets: Sent = 4, Received = 0, Lost = 4 (100% loss),

Approximate round trip time in milli-sec ond s:

Minimum = 0ms, Maximum = 0ms, Average = 0 ms

Pinging 1.1.1.1 with 32 bytes of data:

Verify the physical connection between the F60 and the laptop computer, and double-check the programmed IP address in
the PRODUCT SETUP ÖØ COMMUNICATIONS ÖØ NETWORK Ö IP ADDRESS setting, then repeat step 2 in the above procedure.

If the following sequence of messages appears when entering the C:\WINNT>ping 1.1.1.1 command:

Pinging 1.1.1.1 with 32 bytes of data:
Hardware error.

Hardware error.
Hardware error.
Hardware error.

Ping statistics for 1.1.1.1:

Packets: Sent = 4, Received = 0, Lost = 4 (100% loss),

Approximate round trip time in milli-sec ond s:

Minimum = 0ms, Maximum = 0ms, Average = 0 ms

Pinging 1.1.1.1 with 32 bytes of data:

Verify the physical connection between the F60 and the laptop computer, and double-check the programmed IP address in

PRODUCT SETUP ÖØ COMMUNICATIONS ÖØ NETWORK Ö IP ADDRESS setting, then repeat step 2 in the above procedure.

the
If the following sequence of messages appears when entering the

C:\WINNT>ping 1.1.1.1 command:

1-12 F60 Feeder Protection System GE Multilin

1 GETTING STARTED 1.3 ENERVISTA UR SETUP SOFTWARE

Pinging 1.1.1.1 with 32 bytes of data:
Destination host unreachable.

Destination host unreachable.
Destination host unreachable.
Destination host unreachable.

Ping statistics for 1.1.1.1:

Packets: Sent = 4, Received = 0, Lost = 4 (100% loss),

Approximate round trip time in milli-sec ond s:

Minimum = 0ms, Maximum = 0ms, Average = 0 ms

Pinging 1.1.1.1 with 32 bytes of data:

Verify the IP address is programmed in the local PC by entering the ipconfig command in the command window.

C:\WINNT>ipconfig
Windows 2000 IP Configuration
Ethernet adapter <F4FE223E-5EB6-4 BF B-9 E3 4-1 BD 7B E7F 59 FF> :

Connection-specific DNS suffix. . :

IP Address. . . . . . . . . . . . : 0.0.0.0

Subnet Mask . . . . . . . . . . . : 0.0.0.0

Default Gateway . . . . . . . . . :

Ethernet adapter Local Area Connection:

Connection-specific DNS suffix . :

IP Address. . . . . . . . . . . . : 1.1.1.2

Subnet Mask . . . . . . . . . . . : 255.0.0.0

Default Gateway . . . . . . . . . :

C:\WINNT>

It may be necessary to restart the laptop for the change in IP address to take effect (Windows 98 or NT).
Before using the Quick Connect feature through the Ethernet port, i t is necessary to di sable any configu red proxy settings

in Internet Explorer.

1. Start the Internet Explorer software.

2. Select the Tools > Internet Options menu item and click on Connections tab.

3. Click on the LAN Settings button to open the following window.

1

4. Ensure that the “Use a proxy server for your LAN” box is not checked.
If this computer is used to connect to the Internet, re-enable any proxy server settings after the laptop has been d iscon-

nected from the F60 relay.

1. Verify that the latest version of the EnerVista UR Setup software is installed (available from the GE enerVista CD or

online from http://www.GEmultilin.com). See the Software Installation section for installation details.

2. Start the Internet Explorer software.

GE Multilin F60 Feeder Protection System 1-13

1.3 ENERVISTA UR SETUP SOFTWARE 1 GETTING STARTED

3. Select the “UR” device from the EnerVista Launchpad to start EnerVista UR Setup.

4. Click the Quick Connect button to open the Quick Connect dialog box.

1

5. Select the Ethernet interface and enter the IP address assigned to the F60, then click Connect.

6. The EnerVista UR Setup software will create a site named “Quick Connect” with a corresponding device also named
“Quick Connect” and display them on the upper-left corner of the screen. Expand the sections to vie w data directly
from the F60 device.

Each time the EnerVista UR Setup software is initialized, click the Quick Connect button to establish direct communica­tions to the F60. This ensures that configuration of the EnerVista UR Setup software matches the F60 model number.

When direct communications with the F60 via Ethernet is complete, make the following changes:

1. From the Windows desktop, right-click the My Network Places icon an d select Properties to open the network con­nections window.

2. Right-click the Local Area Connection icon and select the Properties item.

3. Select the Internet Protocol (TCP/IP) item from the list provided and click the Properties button.

4. Set the computer to “Obtain a relay address automatically” as shown below.

If this computer is used to connect to the Internet, re-enable any proxy server settings after the laptop has been discon­nected from the F60 relay.

AUTOMATIC DISCOVERY OF ETHERNET DEVICES

The EnerVista UR Setup software can automatically discover and communicate to all UR-series IEDs located on an Ether­net network.

Using the Quick Connect feature, a single click of the mouse will trigger the software to automatically detect any UR-series
relays located on the network. The EnerVista UR Setup software will then proceed to configure all settin gs and orde r code
options in the Device Setup menu, for the purpose of communicating to mu ltiple relays. This feature allows the user to
identify and interrogate, in seconds, all UR-series devices in a particular location.

1-14 F60 Feeder Protection System GE Multilin

1 GETTING STARTED 1.3 ENERVISTA UR SETUP SOFTWARE

1.3.5 CONNECTING TO THE F60 RELAY

1. Open the Display Properties window through the Site List tree as shown below:

Quick action hot links

Expand the site list by double-clicking
or selecting the +/– box.

Communications status indicators:

Green = OK
Red = No communications
UR icon = report is open

1

842743A3.CDR

2. The Display Properties window will open with a status indicator on the lower left of the EnerVista UR Setup window.

3. If the status indicator is red, verify that the Ethernet network cable is properly connected to the Eth ernet port on the

back of the relay and that the relay has been properly setup for communications (steps A and B earlier).
If a relay icon appears in place of the status indicator, than a report (such as an oscillography or event record) is open.

Close the report to re-display the green status indicator.

4. The Display Properties settings can now be edited, printed, or changed according to user specifications.

Refer to chapter 4 in this manual and the EnerVista UR Setup Help File for more information about the
using the EnerVista UR Setup software interface.

NOTE

QUICK ACTION HOT LINKS

The EnerVista UR Setup software has several new quick action buttons that provide users with instant access to several
functions that are often performed when using F60 relays. From the online window, users can select which relay to interro­gate from a pull-down window, then click on the button for the action they wish to perform. The following quick action func­tions are available:

• View the F60 event record.

• View the last recorded oscillography record.

• View the status of all F60 inputs and outputs.

• View all of the F60 metering values.

• View the F60 protection summary.

GE Multilin F60 Feeder Protection System 1-15

1.4 UR HARDWARE 1 GETTING STARTED

1.4UR HARDWARE 1.4.1 MOUNTING AND WIRING

1

Please refer to Chapter 3: Hardware for detailed mounting and wiring instructions. Review all WARNINGS and CAUTIONS
carefully.

1.4.2 COMMUNICATIONS

The EnerVista UR Setup software communicates to the relay via the faceplate RS232 port or the rear panel RS485 / Ether­net ports. To communicate via the faceplate RS232 port, a standard straight-through serial cable is used. The DB-9 male
end is connected to the relay and the DB-9 or DB-25 female end is connected to the PC COM1 or COM2 port as described
in the CPU communications ports section of chapter 3.

Figure 1–7: RELAY COMMUNICATIONS OPTIONS

To communicate through the F60 rear RS485 port from a PC RS232 port, the GE Multilin RS232/RS485 converter box is
required. This device (catalog number F485) connects to the computer using a “straight-through” serial cable. A shield ed
twisted-pair (20, 22, or 24 AWG) connects the F485 converter to the F60 rear communications port. The converter termi­nals (+, –, GND) are connected to the F60 communicatio n module (+, –, COM) terminals. Refer to the CPU communica-
tions ports section in chapter 3 for option details. The line should be terminated wi th an R-C network (that is, 12 0 Ω, 1 nF)
as described in the chapter 3.

1.4.3 FACEPLATE DISPLAY

All messages are displayed on a 2 × 20 backlit liquid crystal display (LCD) to ma ke them visible under poor l ighting condi­tions. Messages are descriptive and should not re quire the aid of an instruction manual for decip hering. While the keypad
and display are not actively being used, th e display will default to user-defined messages. Any high priority event driven
message will automatically override the default message and appear on the display.

1-16 F60 Feeder Protection System GE Multilin

1 GETTING STARTED 1.5 USING THE RELAY

1.5USING THE RELAY 1.5.1 FACEPLATE KEYPAD

Display messages are organized into pages under the following headings: actual values, settings, comma nds, and targets.
The MENU key navigates through these pages. Each heading page is broken down further into logical subgroups.

The MESSAGE keys navigate through the subgroups. The VALUE keys scroll increment or decrement numerical setting
values when in programming mode. These keys also scroll through alphanumeric valu es in the text edit mode. Alterna­tively, values may also be entered with the numeric keypad.

The decimal key initiates and advance to the next character in text edit mode or enters a decimal point. The HELP key may
be pressed at any time for context sensitive help messages. The ENTER key stores altered setting values.

1.5.2 MENU NAVIGATION

Press the MENU key to select the desired header display page (top-level menu). The header title appears momentarily fol­lowed by a header display page menu item. Each press of the MENU key advances through the following mai n heading
pages:

• Actual values.

• Settings.

• Commands.

• Targets.

• User displays (when enabled).

1.5.3 MENU HIERARCHY

The setting and actual value messages are arranged hierarchically. The header display pages are indicated by double
scroll bar characters (), while sub-header pages are indicated by single scroll bar characters (). The header display
pages represent the highest level of the hierarchy and the sub-header display pages fall below this leve l. The MESSAGE
UP and DOWN keys move within a group of headers, sub-headers, setting values, or actual values. Continua lly pressing
the MESSAGE RIGHT key from a header display displays specific information for the header category. Conversely, contin­ually pressing the MESSAGE LEFT key from a setting value or actual value display returns to the header display.

1

HIGHEST LEVEL LOWEST LEVEL (SETTING VALUE)

 SETTINGS
 PRODUCT SETUP

 SETTINGS
 SYSTEM SETUP

The relay is defaulted to the “Not Programme d” state when it leaves the factory. This safeguards against the installation of
a relay whose settings have not been entered. When powered up successfu lly, the Trouble LED will be on and the In Ser­vice LED off. The relay in the “Not Programmed” state will block signaling of any output relay. These conditions will remain
until the relay is explicitly put in the “Programmed” state.

Select the menu message

RELAY SETTINGS:
Not Programmed

SETTINGS Ö PRODUCT SETUP ÖØ INST ALLATION Ö RELAY SETTINGS

 PASSWORD
 SECURITY

ACCESS LEVEL:
Restricted

1.5.4 RELAY ACTIVATION

GE Multilin F60 Feeder Protection System 1-17

1.5 USING THE RELAY 1 GETTING STARTED

To put the relay in the “Programmed” state, press either of the VALUE keys once and then press ENTER. The faceplate
Trouble LED will turn off and the In Service LED will turn on. The settings for the relay can be programmed manually (refer

1

to Chapter 5) via the faceplate keypad or remotely (refer to the EnerVista UR Setup help file) via the Ene rVista UR Setup
software interface.

1.5.5 RELAY PASSWORDS

It is recommended that passwords be set up for each security level and assigned to specific personnel. There are two user
password security access levels, COMMAND and SETTING:

1. COMMAND

The COMMAND access level restricts the user from making any settings changes, but allows the user to perform the fol­lowing operations:

• operate breakers via faceplate keypad

• change state of virtual inputs

• clear event records

• clear oscillography records

• operate user-programmable pushbuttons

2. SETTING

The SETTING access level allows the user to make any changes to any of the setting values.

Refer to the Changing Settings section in Chapter 4 for co mplete instructions on setting u p security level
passwords.

NOTE

1.5.6 FLEXLOGIC™ CUSTOMIZATION

FlexLogic™ equation editing is required for setting up user-defined logic for customizing the relay operations. See the Flex­Logic™ section in Chapter 5 for additional details.

1-18 F60 Feeder Protection System GE Multilin

1 GETTING STARTED 1.5 USING THE RELAY

1.5.7 COMMISSIONING

The F60 requires a minimum amount of maintenance when it is commissioned into service. Since the F60 is a microproces­sor-based relay, its characteristics do not change over time. As such, no further functional tests are required.

Furthermore, the F60 performs a number of continual self-tests and takes the necessary action in case of any major errors
(see the Relay Self-tests section in chapter 7 for details). However, it is recommended that F60 maintenance be scheduled
with other system maintenance. This maintenance may involve the in-service, out-of-service, or unscheduled maintenance.

In-service maintenance:

1. Visual verification of the analog values integrity such as voltage and current (in comparison to other devices on the cor-

responding system).

2. Visual verification of active alarms, relay display messages, and LED indications.

3. LED test.

4. Visual inspection for any damage, corrosion, dust, or loose wires.

5. Event recorder file download with further events analysis.
Out-of-service maintenance:

1. Check wiring connections for firmness.

2. Analog values (currents, voltages, RTDs, analog inputs) injection test and metering accuracy verification. Calibrated

test equipment is required.

3. Protection elements setting verification (analog values injection or visual verification of setting file entries against relay

settings schedule).

4. Contact inputs and outputs verification. This test can be conducted by direct change of state forcing or as part of the

system functional testing.

5. Visual inspection for any damage, corrosion, or dust.

6. Event recorder file download with further events analysis.

7. LED Test and pushbutton continuity check.
Unscheduled maintenance such as during a disturbance causing system interruption:

1. View the event recorder and oscillography or fault report for correct operation of inputs, outputs, and elements.
If it is concluded that the relay or one of its modules is of concern, contact GE Multilin for prompt service.

1

GE Multilin F60 Feeder Protection System 1-19

1

1.5 USING THE RELAY 1 GETTING STARTED

1-20 F60 Feeder Protection System GE Multilin

2 PRODUCT DESCRIPTION 2.1 INTRODUCTION

2 PRODUCT DESCRIPTION 2.1INTRODUCTION 2.1.1 OVERVIEW

The F60 Feeder Protection System is a microprocessor based relay designed for feeder protection.
Overvoltage and undervoltage protection, overfrequency and underfrequency protection, breaker failure protection, direc-

tional current supervision, fault diagnostics, RTU, and programmable logic functions are provided. This relay also provides
phase, neutral, ground and negative sequence, instantaneous and time overcurrent pr otection. The time overcurrent func­tion provides multiple curve shapes or FlexCurves™ for optimum co-ord ination. Automatic reclosing, synchrocheck, and
line fault locator features are also provided. When equipped with a type 8Z CT/VT module, an element for detecting high
impedance faults is provided.

Voltage, current, and power metering is built into the relay as a standard feature. Current parameters are available as total
waveform RMS magnitude, or as fundamental frequency only RMS magnitude and angle (phasor).

Diagnostic features include a sequence of records capable of storing 1024 ti me-tagged events. The internal cl ock used for
time-tagging can be synchronized with an IRIG-B signal o r via the SNTP protocol over the Ethernet port. This precise time
stamping allows the sequence of events to be determined throughout the system. Events can also be programmed (via
FlexLogic™ equations) to trigger oscillography data capture which may be set to record the measured parameters before
and after the event for viewing on a personal computer (PC). These tools significantly reduce troubleshooting time and sim­plify report generation in the event of a system fault.

A faceplate RS232 port may be used to connect to a PC for the programming of settings and the monitoring of actual val­ues. A variety of communications modules are available. Two rear RS485 ports allow independent access by operating and
engineering staff. All serial ports use the Modbus

®

RTU protocol. The RS485 ports may be connected to system computers
with baud rates up to 115.2 kbps. The RS232 port has a fixed baud rate of 19.2 kbps. Optional communications modules
include a 10Base-F Ethernet interface which can be used to provide fast, reliable communications in noisy environments.
Another option provides two 10Base-F fiber optic ports for redundancy. The Ethernet port supports IEC 61850, Modbus
TCP, and TFTP protocols, and allows access to the relay via any standard web browser (F60 web pages). The IEC 60870­5-104 protocol is supported on the Ethernet port. DNP 3.0 and IEC 60870-5-104 cannot be enabled at the same time.

The F60 IEDs use flash memory technology which allows fi eld upgra ding as new features are added. T he follo wing single
line diagram illustrates the relay functionality using ANSI (American National Standards Institute) device numbers.

2

®

/

Table 2–1: ANSI DEVICE NUMBERS AND FUNCTIONS

DEVICE
NUMBER

25 (2) Synchrocheck 51P Phase time overcurrent
27P (2) Phase undervoltage 51_2 Negative-sequence time overcurrent
27X Auxiliary undervoltage 52 AC circuit breaker
32 Sensitive directional power 59N Neutral overvoltage
32N Wattmetric zero-sequence directional 59P Phase overvoltage
50BF/50NBF Breaker failure 59X Auxiliary overvoltage
50DD Disturbance detector 59_2 Negative-sequence overvoltage
50G Ground instantaneous overcurrent 67N Neutral directional overcurrent
50N Neutral instantaneous overcurrent 67P Phase directional
50P Phase instantaneous overcurrent 67_2 Negative-sequence directional overcurrent
50_2 Negative-sequence instantaneous overcurrent 79 Automatic recloser
51G Ground time overcurrent 81O Overfrequency
51N Neutral time overcurrent 81U Underfrequency

FUNCTION DEVICE

NUMBER

FUNCTION

GE Multilin F60 Feeder Protection System 2-1

2.1 INTRODUCTION 2 PRODUCT DESCRIPTION

R

52

79

CLOSE TRIP

Monitoring

2

50_2

50P

22 222 22222

F60 Feeder Management Relay

Table 2–2: OTHER DEVICE FUNCTIONS

FUNCTION FUNCTION FUNCTION

Breaker arcing current (I
Breaker control (2) Event recorder Non-volatile selector switch
Breaker flashover Fault detector and fault report Oscillography
Breaker restrike Fault locator Setting groups (6)
Cold load pickup (2) FlexElements™ (8) Time synchronization over SNTP
Contact inputs (up to 96) FlexLogic™ equations Transducer inputs and outputs
Contact outputs (up to 64) High impeda nce fault detection (Hi-Z) User-definable displays
Control pushbuttons IEC 61850 communications (optional) User-programmable LEDs
Data logger Incipient cable fault detection User-programmable pushbuttons
Demand Load encroachment User-programmable self-tests
Digital counters (8) Metering: current, voltage, power, PF,
Digital elements (48) Virtual outputs (96)
Direct inputs and outputs (32) Modbus user map VT fuse failure

2

t) Disconnect switches (8) Non-volatile latches

51_2

50BF

51P/V

67P

67_2

FlexElement

50G

2

32 50N 51N

TM

51G

Figure 2–1: SINGLE LINE DIAGRAM

energy, frequency, harmonics, THD

81U

6

50NBF

32N

67N/G

22

METERING

2

Transducer

Inputs

27X

59X

2

81O

4

27P

2

59P

1

59N

1

59_2

1

25

2

832727AD.CDR

Virtual inputs (64)

2.1.2 ORDERING

The F60 is available as a 19-inch rack horizontal mount unit or a reduced size (¾) vertical mount unit, and consists of the
following modules: CPU, faceplate, power supply, CPU, CTs and VTs, digital input and outputs, transducer inputs and out­puts, and inter-relay communications. Each of these modules can be supplied in a number of configurations specified at the
time of ordering. The information required to completely specify the relay is provided in the following tables (see chapter 3
for full details of relay modules).

Order codes are subject to change without notice. Refer to the GE Multilin ordering page at

http://www.GEindustrial.com/multilin/order.htm

NOTE

for the latest details concerning F60 ordering options.

The order codes for the horizontal mount units are shown below.

2-2 F60 Feeder Protection System GE Multilin

2 PRODUCT DESCRIPTION 2.1 INTRODUCTION

Table 2–3: F60 ORDER CODES (HORIZONTAL UNITS)

BASE UNIT F60 | | | | | | | | | | | Base Unit
CPU E | | | | | | | | | | RS485 and RS485

SOFTWARE 00 | | | | | | | | | No Software Options

MOUNT/COATING H | | | | | | | | Horizontal (19” rack)
FACEPLATE/ DISPLAY C | | | | | | | English display

POWER SUPPLY
(redundant supply must
be same type as main supply)

CT/VT MODULES 8F | | | | | Standard 4CT/4VT

DIGITAL INPUTS/OUTPUTS XX XX XX XX XX No Module

TRANSDUCER
INPUTS/OUTPUTS
(select a maximum of 3 per unit)

INTER-RELAY
COMMUNICATIONS
(select a maximum of 1 per unit)

F60 - * ** - * * * - F ** - H ** - M ** - P ** - U ** - W/X ** Full Size Horizontal Mount

G | | | | | | | | | | RS485 and multi-mode ST 10Base-F
H | | | | | | | | | | RS485 and multi-mode ST redundant 10Base-F
J | | | | | | | | | | RS485 and multi-mode ST 100Base-FX
K | | | | | | | | | | RS485 and multi-mode ST redundant 100Base-FX
L | | | | | | | | | | RS485 and single mode SC 100Base-FX
M | | | | | | | | | | RS485 and single mode SC redundant 100Base-FX
N | | | | | | | | | | RS485 and 10/100Base-T
P | | | | | | | | | | RS485 and single mode ST 100Base-FX
R | | | | | | | | | | RS485 and single mode ST redundant 100Base-FX
S | | | | | | | | | | RS485 and six-port managed Ethernet switch

01 | | | | | | | | | Ethernet Global Data (EGD); not available for Type E CPUs
03 | | | | | | | | | IEC 61850; not available for Type E CPUs
04 | | | | | | | | | Ethernet Global Data (EGD) and IEC 61850; not available for Type E CPUs

A | | | | | | | | Horizontal (19” rack) with harsh environmental coating

D | | | | | | | French display
R | | | | | | | Russian display
A | | | | | | | Chinese display
P | | | | | | | English display with 4 small and 12 large programmable pushbuttons
G | | | | | | | French display with 4 small and 12 large programmable pushbuttons
S | | | | | | | Russian display with 4 small and 12 large programmable pushbuttons
B | | | | | | | Chinese display with 4 small and 12 large programmable pushbuttons
K | | | | | | | Enhanced front panel with English display
M | | | | | | | Enhanced front panel with French display
Q | | | | | | | Enhanced front panel with Russian display
U | | | | | | | Enhanced front panel with Chinese display
L | | | | | | | Enhanced front panel with English display and user-programmable pushbuttons
N | | | | | | | Enhanced front panel with French display and user-programmable pushbuttons
T | | | | | | | Enhanced front panel with Russian display and user-programmable pushbuttons
V | | | | | | | Enhanced front panel with Chinese display and user-programmable pushbuttons

H | | | | | | 125 / 250 V AC/DC power supply
H | | | | | RH 125 / 250 V AC/DC with redundant 125 / 250 V AC/DC power supply
L | | | | | | 24 to 48 V (DC only) power supply
L | | | | | RL 24 to 48 V (DC only) with redundant 24 to 48 V DC power supply

8G | | | | | Sensitive Ground 4CT/4VT
8H | | | | | Standard 8CT
8J | | | | | Sensitive Ground 8CT
8L | | | | | Standard 4CT/4VT with enhanced diagnostics
8M | | | | | Sensitive Ground 4CT/4VT with enhanced diagnostics
8N | | | | | Standard 8CT with enhanced diagnostics
8R | | | | | Sensitive Ground 8CT with enhanced diagnostics

| 8Z | | | Hi-Z 4CT (required for high-impedance fault detection element)

4A 4A 4A 4A 4A 4 Solid-State (no monitoring) MOSFET outputs
4B 4B 4B 4B 4B 4 Solid-State (voltage with optional current) MOSFET outputs
4C 4C 4C 4C 4C 4 Solid-State (current with optional voltage) MOSFET outputs
4D 4D 4D 4D 4D 16 digital inputs with Auto-Burnishing
4L 4L 4L 4L 4L 14 Form-A (no monitoring) Latching outputs
67 67 67 67 67 8 Form-A (no monitoring) outputs
6A 6A 6A 6A 6A 2 Form-A (voltage with optional current) and 2 Form-C outputs, 8 digital inputs
6B 6B 6B 6B 6B 2 Form-A (voltage with optional current) and 4 Form-C outputs, 4 digital inputs
6C 6C 6C 6C 6C 8 Form-C outputs
6D 6D 6D 6D 6D 16 digital inputs
6E 6E 6E 6E 6E 4 Form-C outputs, 8 digital inputs
6F 6F 6F 6F 6F 8 Fast Form-C outputs
6G 6G 6G 6G 6G 4 Form-A (voltage with optional current) outputs, 8 digital inputs
6H 6H 6H 6H 6H 6 Form-A (voltage with optional current) outputs, 4 digital inputs
6K 6K 6K 6K 6K 4 Form-C and 4 Fast Form-C outputs
6L 6L 6L 6L 6L 2 Form-A (current with optional voltage) and 2 Form-C outputs, 8 digital inputs
6M 6M 6M 6M 6M 2 Form-A (current with optional voltage) and 4 Form-C outputs, 4 digital inputs
6N 6N 6N 6N 6N 4 Form-A (current with optional voltage) outputs, 8 digital inputs
6P 6P 6P 6P 6P 6 Form-A (current with optional voltage) outputs, 4 digital inputs
6R 6R 6R 6R 6R 2 Form-A (no monitoring) and 2 Form-C outputs, 8 digital inputs
6S 6S 6S 6S 6S 2 Form-A (no monitoring) and 4 Form-C outputs, 4 digital inputs
6T 6T 6T 6T 6T 4 Form-A (no monitoring) outputs, 8 digital inputs
6U 6U 6U 6U 6U 6 Form-A (no monitoring) outputs, 4 digital inputs
5A 5A 5A 5A 5A 4 dcmA inputs, 4 dcmA outputs (only one 5A module is allowed)
5C 5C 5C 5C 5C 8 RTD inputs
5D 5D 5D 5D 5D 4 RTD inputs, 4 dcmA outputs (only one 5D module is allowed)
5E 5E 5E 5E 5E 4 RTD inputs, 4 dcmA inputs
5F 5F 5F 5F 5F 8 dcmA inputs

2A 2A C37.94SM, 1300nm single-mode, ELED, 1 channel single-mode
2B 2B C37.94SM, 1300nm single-mode, ELED, 2 channel single-mode
2E 2E Bi-phase, single channel

2F 2F Bi-phase, dual channel
2G 2G IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 1 Channel
2H 2H IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 2 Channels

| 2S Six-port managed Ethernet switch with high voltage power supply (110 to 250 V DC / 100 to 240 V AC)

| 2T Six-port managed Ethernet switch with low voltage power supply (48 V DC)
72 72 1550 nm, single-mode, LASER, 1 Channel
73 73 1550 nm, single-mode, LASER, 2 Channel
74 74 Channel 1 - RS422; Channel 2 - 1550 nm, single-mode, LASER
75 75 Channel 1 - G.703; Channel 2 - 1550 nm, Single-mode LASER
76 76 IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 1 Channel
77 77 IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 2 Channels

7A 7A 820 nm, multi-mode, LED, 1 Channel
7B 7B 1300 nm, multi-mode, LED, 1 Channel
7C 7C 1300 nm, single-mode, ELED, 1 Channel
7D 7D 1300 nm, single-mode, LASER, 1 Channel
7E 7E Channel 1 - G.703; Channel 2 - 820 nm, multi-mode

7F 7F Channel 1 - G.703; Channel 2 - 1300 nm, multi-mode

7G 7G Channel 1 - G.703; Channel 2 - 1300 nm, single-mode ELED
7H 7H 820 nm, multi-mode, LED, 2 Channels

7I 7I 1300 nm, multi-mode, LED, 2 Channels

7J 7J 1300 nm, single-mode, ELED, 2 Channels

7K 7K 1300 nm, single-mode, LASER, 2 Channels

7L 7L Channel 1 - RS422; Channel 2 - 820 nm, multi-mode, LED

7M 7M Channel 1 - RS422; Channel 2 - 1300 nm, multi-mode, LED
7N 7N Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, ELED
7P 7P Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, LASER
7Q 7Q Channel 1 - G.703; Channel 2 - 1300 nm, single-mode LASER
7R 7R G.703, 1 Channel
7S 7S G.703, 2 Channels

7T 7T RS422, 1 Channel

7W 7W RS422, 2 Channels

2

GE Multilin F60 Feeder Protection System 2-3

2.1 INTRODUCTION 2 PRODUCT DESCRIPTION

The order codes for the reduced size vertical mount units are shown below.

Table 2–4: F60 ORDER CODES (REDUCED SIZE VERTICAL UNITS)

BASE UNIT F60 | | | | | | | | | Base Unit
CPU E | | | | | | | | RS485 and RS485

2

SOFTWARE 00 | | | | | | | No Software Options

MOUNT/COATING V | | | | | | Vertical (3/4 rack)
FACEPLATE/ DISPLAY C | | | | | English display

POWER SUPPLY H | | | | 125 / 250 V AC/DC power supply
CT/VT MODULES 8F | | | Standard 4CT/4VT

DIGITAL INPUTS/OUTPUTS XX XX XX No Module

TRANSDUCER
INPUTS/OUTPUTS
(select a maximum of 3 per unit)

INTER-RELAY
COMMUNICATIONS
(select a maximum of 1 per unit)
For the last module, slot P is used for digital and transducer
input/output modules; slot R is used for inter-relay
communications modules.

F60 - * ** - * * * - F ** - H ** - M ** - P/R ** Reduced Size Vertical Mount (see note regarding P/R slot below)

G | | | | | | | | RS485 and multi-mode ST 10Base-F
H | | | | | | | | RS485 and multi-mode ST redundant 10Base-F
J | | | | | | | | RS485 and multi-mode ST 100Base-FX
K | | | | | | | | RS485 and multi-mode ST redundant 100Base-FX
L | | | | | | | | RS485 and single mode SC 100Base-FX
M | | | | | | | | RS485 and single mode SC redundant 100Base-FX
N | | | | | | | | RS485 and 10/100Base-T
P | | | | | | | | RS485 and single mode ST 100Base-FX
R | | | | | | | | RS485 and single mode ST redundant 100Base-FX

01 | | | | | | | Ethernet Global Data (EGD); not available for Type E CPUs
03 | | | | | | | IEC 61850; not available for Type E CPUs
04 | | | | | | | Ethernet Global Data (EGD) and IEC 61850; not available for Type E CPUs

B | | | | | | Vertical (3/4 rack) with harsh environmental coating

D | | | | | French display
R | | | | | Russian display
A | | | | | Chinese display
K | | | | | Enhanced front panel with English display
M | | | | | Enhanced front panel with French display
Q | | | | | Enhanced front panel with Russian display
U | | | | | Enhanced front panel with Chinese display
L | | | | | Enhanced front panel with English display and user-programmable pushbuttons
N | | | | | Enhanced front panel with French display and user-programmable pushbuttons
T | | | | | Enhanced front panel with Russian display and user-programmable pushbuttons
V | | | | | Enhanced front panel with Chinese display and user-programmable pushbuttons

L | | | | 24 to 48 V (DC only) power supply

8G | | | Sensitive Ground 4CT/4VT
8H | | | Standard 8CT
8J | | | Sensitive Ground 8CT
8L | | | Standard 4CT/4VT with enhanced diagnostics
8M | | | Sensitive Ground 4CT/4VT with enhanced diagnostics
8N | | | Standard 8CT with enhanced diagnostics
8R | | | Sensitive Ground 8CT with enhanced diagnostics

| 8Z | Hi-Z 4CT (required for high-impedance fault detection element)

4A 4A 4A 4 Solid-State (no monitoring) MOSFET outputs
4B 4B 4B 4 Solid-State (voltage with optional current) MOSFET outputs
4C 4C 4C 4 Solid-State (current with optional voltage) MOSFET outputs
4D 4D 4D 16 digital inputs with Auto-Burnishing
4L 4L 4L 14 Form-A (no monitoring) Latching outputs
67 67 67 8 Form-A (no monitoring) outputs
6A 6A 6A 2 Form-A (voltage with optional current) and 2 Form-C outputs, 8 digital inputs
6B 6B 6B 2 Form-A (voltage with optional current) and 4 Form-C outputs, 4 digital inputs
6C 6C 6C 8 Form-C outputs
6D 6D 6D 16 digital inputs
6E 6E 6E 4 Form-C outputs, 8 digital inputs
6F 6F 6F 8 Fast Form-C outputs
6G 6G 6G 4 Form-A (voltage with optional current) outputs, 8 digital inputs
6H 6H 6H 6 Form-A (voltage with optional current) outputs, 4 digital inputs
6K 6K 6K 4 Form-C and 4 Fast Form-C outputs
6L 6L 6L 2 Form-A (current with optional voltage) and 2 Form-C outputs, 8 digital inputs

6M 6M 6M 2 Form-A (current with optional voltage) and 4 Form-C outputs, 4 digital inputs

6N 6N 6N 4 Form-A (current with optional voltage) outputs, 8 digital inputs
6P 6P 6P 6 Form-A (current with optional voltage) outputs, 4 digital inputs
6R 6R 6R 2 Form-A (no monitoring) and 2 Form-C outputs, 8 digital inputs
6S 6S 6S 2 Form-A (no monitoring) and 4 Form-C outputs, 4 digital inputs
6T 6T 6T 4 Form-A (no monitoring) outputs, 8 digital inputs
6U 6U 6U 6 Form-A (no monitoring) outputs, 4 digital inputs
5A 5A 5A 4 dcmA inputs, 4 dcmA outputs (only one 5A module is allowed)
5C 5C 5C 8 RTD inputs
5D 5D 5D 4 RTD inputs, 4 dcmA outputs (only one 5D module is allowed)
5E 5E 5E 4 RTD inputs, 4 dcmA inputs
5F 5F 5F 8 dcmA inputs

2A C37.94SM, 1300nm single-mode, ELED, 1 channel single-mode
2B C37.94SM, 1300nm single-mode, ELED, 2 channel single-mode
2E Bi-phase, single channel

2F Bi-phase, dual channel
2G IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 1 Channel
2H IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 2 Channels
72 1550 nm, single-mode, LASER, 1 Channel
73 1550 nm, single-mode, LASER, 2 Channel
74 Channel 1 - RS422; Channel 2 - 1550 nm, single-mode, LASER
75 Channel 1 - G.703; Channel 2 - 1550 nm, Single-mode LASER
76 IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 1 Channel
77 IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 2 Channels
7A 820 nm, multi-mode, LED, 1 Channel
7B 1300 nm, multi-mode, LED, 1 Channel
7C 1300 nm, single-mode, ELED, 1 Channel
7D 1300 nm, single-mode, LASER, 1 Channel
7E Channel 1 - G.703; Channel 2 - 820 nm, multi-mode
7F Channel 1 - G.703; Channel 2 - 1300 nm, multi-mode
7G Channel 1 - G.703; Channel 2 - 1300 nm, single-mode ELED
7H 820 nm, multi-mode, LED, 2 Channels

7I 1300 nm, multi-mode, LED, 2 Channels
7J 1300 nm, single-mode, ELED, 2 Channels
7K 1300 nm, single-mode, LASER, 2 Channels
7L Channel 1 - RS422; Channel 2 - 820 nm, multi-mode, LED
7M Channel 1 - RS422; Channel 2 - 1300 nm, multi-mode, LED
7N Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, ELED
7P Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, LASER
7Q Channel 1 - G.703; Channel 2 - 1300 nm, single-mode LASER
7R G.703, 1 Channel
7S G.703, 2 Channels
7T RS422, 1 Channel
7W RS422, 2 Channels

2.1.3 REPLACEMENT MODULES

Replacement modules can be ordered separately as shown be low. When ordering a replacement CPU module or face­plate, please provide the serial number of your existing unit.

2-4 F60 Feeder Protection System GE Multilin

2 PRODUCT DESCRIPTION 2.1 INTRODUCTION

Not all replacement modules may be applicable to the F60 relay. Only the modules specified in the order codes are
available as replacement modules.

NOTE

Replacement module codes are subject to change without notice. Re fer to the GE Multilin orde ring page at http://

www.GEindustrial.com/multilin/order.htm for the latest details concerning F60 ordering options.

NOTE

The replacement module order codes for the ho rizontal mount units are shown below.

Table 2–5: ORDER CODES FOR REPLACEMENT MODULES, HORIZONTAL UNITS

POWER SUPPLY
(redundant supply only available in horizontal units;
must be same type as main supply)

CPU | 9E | RS485 and RS485 (Modbus RTU, DNP 3.0)

FACEPLATE/DISPLAY | 3C | Horizontal faceplate with keypad and English display

DIGITAL INPUTS AND OUTPUTS | 4A | 4 Solid-State (no monitoring) MOSFET outputs

CT/VT
MODULES
(NOT AVAILABLE FOR THE C30)

INTER-RELAY COMMUNICATIONS | 2A | C37.94SM, 1300nm single-mode, ELED, 1 channel single-mode

TRANSDUCER
INPUTS/OUTPUTS

UR - ** - *

| 1H | 125 / 250 V AC/DC
| 1L | 24 to 48 V (DC only)
| RH | redundant 125 / 250 V AC/DC
| RH | redundant 24 to 48 V (DC only)

| 9G | RS485 and 10Base-F (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9H | RS485 and Redundant 10Base-F (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9J | RS485 and multi-mode ST 100Base-FX (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9K | RS485 and multi-mode ST redundant 100Base-FX (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9L | RS485 and single mode SC 100Base-FX (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9M | RS485 and single mode SC redundant 100Base-FX (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9N | RS485 and 10/100Base-T (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9P | RS485 and single mode ST 100Base-FX (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9R | RS485 and single mode ST redundant 100Base-FX (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9S | RS485 and six-port managed Ethernet switch

| 3D | Horizontal faceplate with keypad and French display
| 3R | Horizontal faceplate with keypad and Russian display
| 3A | Horizontal faceplate with keypad and Chinese display
| 3P | Horizontal faceplate with keypad, user-programmable pushbuttons, and English display
| 3G | Horizontal faceplate with keypad, user-programmable pushbuttons, and French display
| 3S | Horizontal faceplate with keypad, user-programmable pushbuttons, and Russian display
| 3B | Horizontal faceplate with keypad, user-programmable pushbuttons, and Chinese display
| 3K | Enhanced front panel with English display
| 3M | Enhanced front panel with French display
| 3Q | Enhanced front panel with Russian display
| 3U | Enhanced front panel with Chinese display
| 3L | Enhanced front panel with English display and user-programmable pushbuttons
| 3N | Enhanced front panel with French display and user-programmable pushbuttons
| 3T | Enhanced front panel with Russian display and user-programmable pushbuttons
| 3V | Enhanced front panel with Chinese display and user-programmable pushbuttons

| 4B | 4 Solid-State (voltage with optional current) MOSFET outputs
| 4C | 4 Solid-State (current with optional voltage) MOSFET outputs
| 4D | 16 digital inputs with Auto-Burnishing
| 4L | 14 Form-A (no monitoring) Latching outputs
| 67 | 8 Form-A (no monitoring) outputs
| 6A | 2 Form-A (voltage with optional current) and 2 Form-C outputs, 8 digital inputs
| 6B | 2 Form-A (voltage with optional current) and 4 Form-C outputs, 4 digital inputs
| 6C | 8 Form-C outputs
| 6D | 16 digital inputs
| 6E | 4 Form-C outputs, 8 digital inputs
| 6F | 8 Fast Form-C outputs
| 6G | 4 Form-A (voltage with optional current) outputs, 8 digital inputs
| 6H | 6 Form-A (voltage with optional current) outputs, 4 digital inputs
| 6K | 4 Form-C and 4 Fast Form-C outputs
| 6L | 2 Form-A (current with optional voltage) and 2 Form-C outputs, 8 digital inputs
| 6M | 2 Form-A (current with optional voltage) and 4 Form-C outputs, 4 digital inputs
| 6N | 4 Form-A (current with optional voltage) outputs, 8 digital inputs
| 6P | 6 Form-A (current with optional voltage) outputs, 4 digital inputs
| 6R | 2 Form-A (no monitoring) and 2 Form-C outputs, 8 digital inputs
| 6S | 2 Form-A (no monitoring) and 4 Form-C outputs, 4 digital inputs
| 6T | 4 Form-A (no monitoring) outputs, 8 digital inputs
| 6U | 6 Form-A (no monitoring) outputs, 4 digital inputs
| 8F | Standard 4CT/4VT
| 8G | Sensitive Ground 4CT/4VT
| 8H | Standard 8CT
| 8J | Sensitive Ground 8CT
| 8L | Standard 4CT/4VT with enhanced diagnostics
| 8M | Sensitive Ground 4CT/4VT with enhanced diagnostics
| 8N | Standard 8CT with enhanced diagnostics
| 8R | Sensitive Ground 8CT with enhanced diagnostics
| 8Z | HI-Z 4CT

| 2B | C37.94SM, 1300nm single-mode, ELED, 2 channel single-mode
| 2E | Bi-phase, single channel
| 2F | Bi-phase, dual channel
| 2G | IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 1 Channel
| 2H | IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 2 Channels
| 2S | Six-port managed Ethernet switch with high voltage power supply (110 to 250 V DC / 100 to 240 V AC)
| 2T | Six-port managed Ethernet switch with low voltage power supply (48 V DC)
| 72 | 1550 nm, single-mode, LASER, 1 Channel
| 73 | 1550 nm, single-mode, LASER, 2 Channel
| 74 | Channel 1 - RS422; Channel 2 - 1550 nm, single-mode, LASER
| 75 | Channel 1 - G.703; Channel 2 - 1550 nm, Single-mode LASER
| 76 | IEEE C37.94, 820 nm, multimode, LED, 1 Channel
| 77 | IEEE C37.94, 820 nm, multimode, LED, 2 Channels
| 7A | 820 nm, multi-mode, LED, 1 Channel
| 7B | 1300 nm, multi-mode, LED, 1 Channel
| 7C | 1300 nm, single-mode, ELED, 1 Channel
| 7D | 1300 nm, single-mode, LASER, 1 Channel
| 7E | Channel 1 - G.703; Channel 2 - 820 nm, multi-mode
| 7F | Channel 1 - G.703; Channel 2 - 1300 nm, multi-mode
| 7G | Channel 1 - G.703; Channel 2 - 1300 nm, single-mode ELED
| 7H | 820 nm, multi-mode, LED, 2 Channels
| 7I | 1300 nm, multi-mode, LED, 2 Channels
| 7J | 1300 nm, single-mode, ELED, 2 Channels
| 7K | 1300 nm, single-mode, LASER, 2 Channels
| 7L | Channel 1 - RS422; Channel 2 - 820 nm, multi-mode, LED
| 7M | Channel 1 - RS422; Channel 2 - 1300 nm, multi-mode, LED
| 7N | Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, ELED
| 7P | Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, LASER
| 7Q | Channel 1 - G.703; Channel 2 - 1300 nm, single-mode LASER
| 7R | G.703, 1 Channel
| 7S | G.703, 2 Channels
| 7T | RS422, 1 Channel
| 7W | RS422, 2 Channels
| 5A | 4 dcmA inputs, 4 dcmA outputs (only one 5A module is allowed)
| 5C | 8 RTD inputs
| 5D | 4 RTD inputs, 4 dcmA outputs (only one 5D module is allowed)
| 5E | 4 dcmA inputs, 4 RTD inputs
| 5F | 8 dcmA inputs

2

GE Multilin F60 Feeder Protection System 2-5

2.1 INTRODUCTION 2 PRODUCT DESCRIPTION

The replacement module order codes for the reduced-size vertical mount units are shown below.

Table 2–6: ORDER CODES FOR REPLACEMENT MODULES, VERTICAL UNITS

POWER SUPPLY | 1H | 125 / 250 V AC/DC
CPU | 9E | RS485 and RS485 (Modbus RTU, DNP 3.0)

2

FACEPLATE/DISPLAY | 3F | Vertical faceplate with keypad and English display

DIGITAL
INPUTS/OUTPUTS

CT/VT
MODULES
(NOT AVAILABLE FOR THE C30)

INTER-RELAY COMMUNICATIONS | 2A | C37.94SM, 1300nm single-mode, ELED, 1 channel single-mode

TRANSDUCER
INPUTS/OUTPUTS

UR - ** - *

| 1L | 24 to 48 V (DC only)
| 9G | RS485 and 10Base-F (Ethernet, Modbus TCP/IP, DNP 3.0)

| 9H | RS485 and Redundant 10Base-F (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9J | RS485 and multi-mode ST 100Base-FX (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9K | RS485 and multi-mode ST redundant 100Base-FX (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9L | RS485 and single mode SC 100Base-FX (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9M | RS485 and single mode SC redundant 100Base-FX (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9N | RS485 and 10/100Base-T (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9P | RS485 and single mode ST 100Base-FX (Ethernet, Modbus TCP/IP, DNP 3.0)
| 9R | RS485 and single mode ST redundant 100Base-FX (Ethernet, Modbus TCP/IP, DNP 3.0)

| 3D | Vertical faceplate with keypad and French display
| 3R | Vertical faceplate with keypad and Russian display
| 3K | Vertical faceplate with keypad and Chinese display
| 3K | Enhanced front panel with English display
| 3M | Enhanced front panel with French display
| 3Q | Enhanced front panel with Russian display
| 3U | Enhanced front panel with Chinese display
| 3L | Enhanced front panel with English display and user-programmable pushbuttons
| 3N | Enhanced front panel with French display and user-programmable pushbuttons
| 3T | Enhanced front panel with Russian display and user-programmable pushbuttons
| 3V | Enhanced front panel with Chinese display and user-programmable pushbuttons
| 4A | 4 Solid-State (no monitoring) MOSFET outputs
| 4B | 4 Solid-State (voltage with optional current) MOSFET outputs
| 4C | 4 Solid-State (current with optional voltage) MOSFET outputs
| 4D | 16 digital inputs with Auto-Burnishing
| 4L | 14 Form-A (no monitoring) Latching outputs
| 67 | 8 Form-A (no monitoring) outputs
| 6A | 2 Form-A (voltage with optional current) and 2 Form-C outputs, 8 digital inputs
| 6B | 2 Form-A (voltage with optional current) and 4 Form-C outputs, 4 digital inputs
| 6C | 8 Form-C outputs
| 6D | 16 digital inputs
| 6E | 4 Form-C outputs, 8 digital inputs
| 6F | 8 Fast Form-C outputs
| 6G | 4 Form-A (voltage with optional current) outputs, 8 digital inputs
| 6H | 6 Form-A (voltage with optional current) outputs, 4 digital inputs
| 6K | 4 Form-C and 4 Fast Form-C outputs
| 6L | 2 Form-A (current with optional voltage) and 2 Form-C outputs, 8 digital inputs
| 6M | 2 Form-A (current with optional voltage) and 4 Form-C outputs, 4 digital inputs
| 6N | 4 Form-A (current with optional voltage) outputs, 8 digital inputs
| 6P | 6 Form-A (current with optional voltage) outputs, 4 digital inputs
| 6R | 2 Form-A (no monitoring) and 2 Form-C outputs, 8 digital inputs
| 6S | 2 Form-A (no monitoring) and 4 Form-C outputs, 4 digital inputs
| 6T | 4 Form-A (no monitoring) outputs, 8 digital inputs
| 6U | 6 Form-A (no monitoring) outputs, 4 digital inputs
| 8F | Standard 4CT/4VT
| 8G | Sensitive Ground 4CT/4VT
| 8H | Standard 8CT
| 8J | Sensitive Ground 8CT
| 8L | Standard 4CT/4VT with enhanced diagnostics
| 8M | Sensitive Ground 4CT/4VT with enhanced diagnostics
| 8N | Standard 8CT with enhanced diagnostics
| 8R | Sensitive Ground 8CT with enhanced diagnostics
| 8Z | HI-Z 4CT

| 2B | C37.94SM, 1300nm single-mode, ELED, 2 channel single-mode
| 2E | Bi-phase, single channel
| 2F | Bi-phase, dual channel
| 2G | IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 1 Channel
| 2H | IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 2 Channels
| 72 | 1550 nm, single-mode, LASER, 1 Channel
| 73 | 1550 nm, single-mode, LASER, 2 Channel
| 74 | Channel 1 - RS422; Channel 2 - 1550 nm, single-mode, LASER
| 75 | Channel 1 - G.703; Channel 2 - 1550 nm, Single-mode LASER
| 76 | IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 1 Channel
| 77 | IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 2 Channels
| 7A | 820 nm, multi-mode, LED, 1 Channel
| 7B | 1300 nm, multi-mode, LED, 1 Channel
| 7C | 1300 nm, single-mode, ELED, 1 Channel
| 7D | 1300 nm, single-mode, LASER, 1 Channel
| 7E | Channel 1 - G.703; Channel 2 - 820 nm, multi-mode
| 7F | Channel 1 - G.703; Channel 2 - 1300 nm, multi-mode
| 7G | Channel 1 - G.703; Channel 2 - 1300 nm, single-mode ELED
| 7H | 820 nm, multi-mode, LED, 2 Channels
| 7I | 1300 nm, multi-mode, LED, 2 Channels
| 7J | 1300 nm, single-mode, ELED, 2 Channels
| 7K | 1300 nm, single-mode, LASER, 2 Channels
| 7L | Channel 1 - RS422; Channel 2 - 820 nm, multi-mode, LED
| 7M | Channel 1 - RS422; Channel 2 - 1300 nm, multi-mode, LED
| 7N | Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, ELED
| 7P | Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, LASER
| 7Q | Channel 1 - G.703; Channel 2 - 1300 nm, single-mode LASER
| 7R | G.703, 1 Channel
| 7S | G.703, 2 Channels
| 7T | RS422, 1 Channel
| 7W | RS422, 2 Channels
| 5A | 4 dcmA inputs, 4 dcmA outputs (only one 5A module is allowed)
| 5C | 8 RTD inputs
| 5D | 4 RTD inputs, 4 dcmA outputs (only one 5D module is allowed)
| 5E | 4 dcmA inputs, 4 RTD inputs
| 5F | 8 dcmA inputs

2-6 F60 Feeder Protection System GE Multilin

2 PRODUCT DESCRIPTION 2.2 SPECIFICATIONS

2.2SPECIFICATIONSSPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE

2.2.1 PROTECTION ELEMENTS

The operating times below include the activation time of a trip rated form-A output contact unless otherwise indi­cated. FlexLogic™ operands of a given element are 4 ms faster. This should be taken into account when using

NOTE

FlexLogic™ to interconnect with other protection or control elements of the relay, building FlexLogic™ equations, or
interfacing with other IEDs or power system devices via communications or different output contacts.

PHASE/NEUTRAL/GROUND TOC

Current: Phasor or RMS
Pickup level: 0.000 to 30.000 pu in steps of 0.001
Dropout level: 97% to 98% of pickup
Level accuracy:

for 0.1 to 2.0 × CT: ±0.5% of reading or ±0.4% of rated

for > 2.0 × CT: ±1.5% of reading > 2.0 × CT rating

Curve shapes: IEEE Moderately/Very/Extremely

Curve multiplier: Time Dial = 0.00 to 600.00 in steps of

Reset type: Instantaneous/Timed (per IEEE)
Timing accuracy: Operate at > 1.03 × actual pickup

(whichever is greater)

Inverse; IEC (and BS) A/B/C and Short
Inverse; GE IAC Inverse, Short/Very/
Extremely Inverse; I
(programmable); Definite Time (0.01 s
base curve)

0.01

±3.5% of operate time or ±½ cycle
(whichever is greater)

2

t; FlexCurves™

PHASE/NEUTRAL/GROUND IOC

Pickup level: 0.000 to 30.000 pu in steps of 0.001
Dropout level: 97 to 98% of pickup
Level accuracy:

0.1 to 2.0 × CT rating: ±0.5% of reading or ±0.4% of rated
(whichever is greater)

> 2.0 × CT rating ±1.5% of reading
Overreach: <2%
Pickup delay: 0.00 to 600.00 s in steps of 0.01
Reset delay: 0.00 to 600.00 s in steps of 0.01
Operate time: <16 ms at 3 × pickup at 60 Hz

(Phase/Ground IOC)
<20 ms at 3 × pickup at 60 Hz
(Neutral IOC)

Timing accuracy: Operate at 1.5 × pickup

±3% or ±4 ms (whichever is greater)

NEGATIVE SEQUENCE TOC

Pickup level: 0.000 to 30.000 pu in steps of 0.001
Dropout level: 97% to 98% of pickup
Level accuracy: ±0.5% of reading or ±0.4% of rated

Curve shapes: IEEE Moderately/Very/Extremely

Curve multiplier (Time dial): 0.00 to 600.00 in steps of 0.01
Reset type: Instantaneous/Timed (per IEEE) and Lin-

Timing accuracy: Operate at > 1.03 × actual pickup

(whichever is greater)
from 0.1 to 2.0 x CT rating
±1.5% of reading > 2.0 x CT rating

Inverse; IEC (and BS) A/B/C and Short
Inverse; GE IAC Inverse, Short/Very/
Extremely Inverse; I
(programmable); Definite Time (0.01 s
base curve)

ear

±3.5% of operate time or ±½ cycle
(whichever is greater)

2

t; FlexCurves™

NEGATIVE SEQUENCE IOC

Pickup level: 0.000 to 30.000 pu in steps of 0.001
Dropout level: 97 to 98% of pickup
Level accuracy:

Overreach: < 2%
Pickup delay: 0.00 to 600.00 s in steps of 0.01
Reset delay: 0.00 to 600.00 s in steps of 0.01
Operate time: < 20 ms at 3 × pickup at 60 Hz
Timing accuracy: Operate at 1.5 × pickup

0.1 to 2.0 × CT rating: ±0.5% of read-

ing or ±0.4% of rated

(whichever is greater)

> 2.0 × CT rating: ±1.5% of reading

±3% or ±4 ms (whichever is greater)

PHASE DIRECTIONAL OVERCURRENT

Relay connection: 90° (quadrature)
Quadrature voltage:

ABC phase seq.: phase A (V

), phase C (VAB)

B (V

CA

ACB phase seq.: phase A (V

), phase C (VBA)

B (V

AC

Polarizing voltage threshold: 0.000 to 3.000 pu in steps of 0.001
Current sensitivity threshold: 0.05 pu
Characteristic angle: 0 to 359
Angle accuracy: ±2°
Operation time (FlexLogic™ operands):

° in steps of 1

Tripping (reverse load, forward fault):<

12 ms, typically

Blocking (forward load, reverse fault):<

8 ms, typically

BC

CB

2

), phase

), phase

GE Multilin F60 Feeder Protection System 2-7

2.2 SPECIFICATIONS 2 PRODUCT DESCRIPTION

NEUTRAL DIRECTIONAL OVERCURRENT

Directionality: Co-existing forward and reverse
Polarizing: Voltage, Current, Dual
Polarizing voltage: V_0 or VX
Polarizing current: IG
Operating current: I_0
Level sensing: 3 × (|I_0| – K × |I_1|), IG
Restraint, K: 0.000 to 0.500 in steps of 0.001

2

Characteristic angle: –90 to 90° in steps of 1
Limit angle: 40 to 90° in steps of 1, independent for

forward and reverse
Angle accuracy: ±2°
Offset impedance: 0.00 to 250.00 Ω in steps of 0.01
Pickup level: 0.002 to 30.000 pu in steps of 0.01
Dropout level: 97 to 98%
Operation time: < 16 ms at 3 × pickup at 60 Hz

NEGATIVE SEQUENCE DIRECTIONAL OC

Directionality: Co-existing forward and reverse
Polarizing: Voltage
Polarizing voltage: V_2
Operating current: I_2
Level sensing:

Zero-sequence:|I_0| – K × |I_1|

Negative-sequence:|I_2| – K × |I_1|
Restraint, K: 0.000 to 0.500 in steps of 0.001
Characteristic angle: 0 to 90° in steps of 1
Limit angle: 40 to 90° in steps of 1, independent for

Angle accuracy: ±2°
Offset impedance: 0.00 to 250.00 Ω in steps of 0.01
Pickup level: 0.015 to 30.000 pu in steps of 0.01
Dropout level: 97 to 98%
Operation time: < 16 ms at 3 × pickup at 60 Hz

forward and reverse

WATTMETRIC ZERO-SEQUENCE DIRECTIONAL

Measured power: zero-sequence
Number of elements: 2
Characteristic angle: 0 to 360° in steps of 1
Minimum power: 0.001 to 1.200 pu in steps of 0.001
Pickup level accuracy: ±1% or ±0.0025 pu, whichever is greater
Hysteresis: 3% or 0.001 pu, whichever is greater
Pickup delay: definite time (0 to 600.00 s in steps of

Inverse time multiplier: 0.01 to 2.00 s in steps of 0.01
Time accuracy: ±3% or ±20 ms, whichever is greater
Operate time: <30 ms at 60 Hz

0.01), inverse time, or FlexCurve

SENSITIVE DIRECTIONAL POWER

Measured power: 3-phase, true RMS
Number of stages: 2
Characteristic angle: 0 to 359° in steps of 1
Calibration angle: 0.00 to 0.95° in steps of 0.05
Minimum power: –1.200 to 1.200 pu in steps of 0.001
Pickup level accuracy: ±1% or ±0.001 pu, whichever is greater
Hysteresis: 2% or 0.001 pu, whichever is greater
Pickup delay: 0 to 600.00 s in steps of 0.01
Time accuracy: ±3% or ±4 ms, whichever is greater
Operate time: 50 ms

PHASE UNDERVOLTAGE

Voltage: Phasor only
Pickup level: 0.000 to 3.000 pu in steps of 0.001
Dropout level: 102 to 103% of pickup
Level accuracy: ±0.5% of reading from 10 to 208 V
Curve shapes: GE IAV Inverse;

Definite Time (0.1s base curve)

Curve multiplier: Time dial = 0.00 to 600.00 in steps of

0.01

Timing accuracy: Operate at < 0.90 × pickup

±3.5% of operate time or ±4 ms (which­ever is greater)

AUXILIARY UNDERVOLTAGE

Pickup level: 0.000 to 3.000 pu in steps of 0.001
Dropout level: 102 to 103% of pickup
Level accuracy: ±0.5% of reading from 10 to 208 V
Curve shapes: GE IAV Inverse, Definite Time
Curve multiplier: Time Dial = 0 to 600.00 in steps of 0.01
Timing accuracy: ±3% of operate time or ±4 ms

(whichever is greater)

PHASE OVERVOLTAGE

Voltage: Phasor only
Pickup level: 0.000 to 3.000 pu in steps of 0.001
Dropout level: 97 to 98% of pickup
Level accuracy: ±0.5% of reading from 10 to 208 V
Pickup delay: 0.00 to 600.00 in steps of 0.01 s
Operate time: < 30 ms at 1.10 × pickup at 60 Hz
Timing accuracy: ±3% or ±4 ms (whichever is greater)

NEUTRAL OVERVOLTAGE

Pickup level: 0.000 to 3.000 pu in steps of 0.001
Dropout level: 97 to 98% of pickup
Level accuracy: ±0.5% of reading from 10 to 208 V
Pickup delay: 0.00 to 600.00 s in steps of 0.01 (definite

time) or user-defined curve
Reset delay: 0.00 to 600.00 s in steps of 0.01
Timing accuracy: ±3% or ±20 ms (whichever is greater)
Operate time: < 30 ms at 1.10 × pickup at 60 Hz

2-8 F60 Feeder Protection System GE Multilin

2 PRODUCT DESCRIPTION 2.2 SPECIFICATIONS

AUXILIARY OVERVOLTAGE

Pickup level: 0.000 to 3.000 pu in steps of 0.001
Dropout level: 97 to 98% of pickup
Level accuracy: ±0.5% of reading from 10 to 208 V
Pickup delay: 0 to 600.00 s in steps of 0.01
Reset delay: 0 to 600.00 s in steps of 0.01
Timing accuracy: ±3% of operate time or ±4 ms

(whichever is greater)

Operate time: < 30 ms at 1.10 × pickup at 60 Hz

NEGATIVE SEQUENCE OVERVOLTAGE

Pickup level: 0.000 to 1.250 pu in steps of 0.001
Dropout level: 97 to 98% of pickup
Level accuracy: ±0.5% of reading from 10 to 208 V
Pickup delay: 0 to 600.00 s in steps of 0.01
Reset delay: 0 to 600.00 s in steps of 0.01
Time accuracy: ±3% or ±20 ms, whichever is greater
Operate time: < 30 ms at 1.10 × pickup at 60 Hz

UNDERFREQUENCY

Minimum signal: 0.10 to 1.25 pu in steps of 0.01
Pickup level: 20.00 to 65.00 Hz in steps of 0.01
Dropout level: pickup + 0.03 Hz
Level accuracy: ±0.001 Hz
Time delay: 0 to 65.535 s in steps of 0.001
Timer accuracy: ±3% or 4 ms, whichever is greater
Operate time: typically 4 cycles at 0.1 Hz/s change

typically 3.5 cycles at 0.3 Hz/s change
typically 3 cycles at 0.5 Hz/s change

OVERFREQUENCY

Pickup level: 20.00 to 65.00 Hz in steps of 0.01
Dropout level: pickup – 0.03 Hz
Level accuracy: ±0.001 Hz
Time delay: 0 to 65.535 s in steps of 0.001
Timer accuracy: ±3% or 4 ms, whichever is greater
Operate time: typically 4 cycles at 0.1 Hz/s change

typically 3.5 cycles at 0.3 Hz/s change
typically 3 cycles at 0.5 Hz/s change

RATE OF CHANGE OF FREQUENCY

df/dt trend: increasing, decreasing, bi-directional
df/dt pickup level: 0.10 to 15.00 Hz/s in steps of 0.01
df/dt dropout level: 96% of pickup
df/dt level accuracy: 80 mHz/s or 3.5%, whichever is greater
Overvoltage supv.: 0.100 to 3.000 pu in steps of 0.001
Overcurrent supv.: 0.000 to 30.000 pu in steps of 0.001
Pickup delay: 0 to 65.535 s in steps of 0.001
Reset delay: 0 to 65.535 s in steps of 0.001
Time accuracy: ±3% or ±4 ms, whichever is greater
95% settling time for df/dt: < 24 cycles
Operate time: 12 cycles at 2 × pickup

8 cycles at 3 × pickup
5 cycles at 5 × pickup

BREAKER FAILURE

Mode: 1-pole, 3-pole
Current supervision: phase, neutral current
Current supv. pickup: 0.001 to 30.000 pu in steps of 0.001
Current supv. dropout: 97 to 98% of pickup
Current supv. accuracy:

0.1 to 2.0 × CT rating: ±0.75% of reading or ±2% of rated
(whichever is greater)

above 2 × CT rating: ±2.5% of reading

BREAKER ARCING CURRENT

Principle: accumulates breaker duty (I2t) and mea-

sures fault duration

Initiation: programmable per phase from any Flex-

Compensation for auxiliary relays: 0 to 65.535 s in steps of 0.001
Alarm threshold: 0 to 50000 kA2-cycle in steps of 1
Fault duration accuracy: 0.25 of a power cycle
Availability: 1 per CT bank with a minimum of 2

Logic™ operand

BREAKER FLASHOVER

Operating quantity: phase current, voltage and voltage differ-

Pickup level voltage: 0 to 1.500 pu in steps of 0.001
Dropout level voltage: 97 to 98% of pickup
Pickup level current: 0 to 1.500 pu in steps of 0.001
Dropout level current: 97 to 98% of pickup
Level accuracy: ±0.5% or ±0.1% of rated, whichever is

Pickup delay: 0 to 65.535 s in steps of 0.001
Time accuracy: ±3% or ±42 ms, whichever is greater
Operate time: <42ms at 1.10 × pickup at 60 Hz

ence

greater

BREAKER RESTRIKE

Principle: detection of high-frequency overcurrent

Availability: one per CT/VT module (not including 8Z

Pickup level: 0.1 to 2.00 pu in steps of 0.01
Reset delay: 0.000 to 65.535 s in steps of 0.001

condition ¼ cycle after breaker opens

modules)

INCIPIENT CABLE FAULT DETECTION

Principle: detection of ½ cycle or less overcurrent

condition during normal load

Availability: two per CT/VT module (not including 8Z

modules)

Pickup level: 0.1 to 10.00 pu in steps of 0.01
Reset delay: 0.000 to 65.535 s in steps of 0.001
Operating mode: number of counts, counts per time win-

dow

SYNCHROCHECK

Max voltage difference: 0 to 400000 V in steps of 1
Max angle difference: 0 to 100
Max freq. difference: 0.00 to 2.00 Hz in steps of 0.01
Hysteresis for max. freq. diff.: 0.00 to 0.10 Hz in steps of 0.01
Dead source function: None, LV1 & DV2, DV1 & LV2, DV1 or

° in steps of 1

DV2, DV1 xor DV2, DV1 & DV2
(L = Live, D = Dead)

2

GE Multilin F60 Feeder Protection System 2-9

2.2 SPECIFICATIONS 2 PRODUCT DESCRIPTION

AUTORECLOSURE

Single breaker applications, 3-pole tripping schemes
Up to 4 reclose attempts before lockout
Independent dead time setting before each shot
Possibility of changing protection settings after each shot with

FlexLogic™

2

FLEXLOGIC™

Programming language: Reverse Polish Notation with graphical

visualization (keypad programmable)
Lines of code: 512
Internal variables: 64
Supported operations: NOT, XOR, OR (2 to 16 inputs), AND (2

to 16 inputs), NOR (2 to 16 inputs),

NAND (2 to 16 inputs), latch (reset-domi-

nant), edge detectors, timers
Inputs: any logical variable, contact, or virtual

input
Number of timers: 32
Pickup delay: 0 to 60000 (ms, sec., min.) in steps of 1
Dropout delay: 0 to 60000 (ms, sec., min.) in steps of 1

FLEXCURVES™

Number: 4 (A through D)
Reset points: 40 (0 through 1 of pickup)
Operate points: 80 (1 through 20 of pickup)
Time delay: 0 to 65535 ms in steps of 1

FLEX STATES

Number: up to 256 logical variables grouped

under 16 Modbus addresses
Programmability: any logical variable, contact, or virtual

input

FLEXELEMENTS™

Number of elements: 8
Operating signal: any analog actual value, or two values in

differential mode
Operating signal mode: signed or absolute value
Operating mode: level, delta
Comparator direction: over, under
Pickup Level: –90.000 to 90.000 pu in steps of 0.001
Hysteresis: 0.1 to 50.0% in steps of 0.1
Delta dt: 20 ms to 60 days
Pickup & dropout delay: 0.000 to 65.535 s in steps of 0.001

LOAD ENCROACHMENT

Responds to: Positive-sequence quantities
Minimum voltage: 0.000 to 3.000 pu in steps of 0.001
Reach (sec. Ω): 0.02 to 250.00 Ω in steps of 0.01
Impedance accuracy: ±5%
Angle: 5 to 50° in steps of 1
Angle accuracy: ±2°
Pickup delay: 0 to 65.535 s in steps of 0.001
Reset delay: 0 to 65.535 s in steps of 0.001
Time accuracy: ±3% or ±4 ms, whichever is greater
Operate time: < 30 ms at 60 Hz

TRIP BUS (TRIP WITHOUT FLEXLOGIC™)

Number of elements: 6
Number of inputs: 16
Operate time: <2 ms at 60Hz
Time accuracy: ±3% or 10 ms, whichever is greater

2.2.2 USER-PROGRAMMABLE ELEMENTS

NON-VOLATILE LATCHES

Type: set-dominant or reset-dominant
Number: 16 (individually programmed)
Output: stored in non-volatile memory
Execution sequence: as input prior to protection, control, and

FlexLogic™

USER-PROGRAMMABLE LEDs

Number: 48 plus trip and alarm
Programmability: from any logical variable, contact, or vir-

tual input

Reset mode: self-reset or latched

LED TEST

Initiation: from any digital input or user-program-

mable condition
Number of tests: 3, interruptible at any time
Duration of full test: approximately 3 minutes
Test sequence 1: all LEDs on
Test sequence 2: all LEDs off, one LED at a time on for 1 s
Test sequence 3: all LEDs on, one LED at a time off for 1 s

USER-DEFINABLE DISPLAYS

Number of displays: 16
Lines of display: 2 × 20 alphanumeric characters
Parameters: up to 5, any Modbus register addresses
Invoking and scrolling: keypad, or any user-programmable con-

dition, including pushbuttons

CONTROL PUSHBUTTONS

Number of pushbuttons: 7
Operation: drive FlexLogic™ operands

2-10 F60 Feeder Protection System GE Multilin

2 PRODUCT DESCRIPTION 2.2 SPECIFICATIONS

USER-PROGRAMMABLE PUSHBUTTONS (OPTIONAL)

Number of pushbuttons: 12 (standard faceplate);

16 (enhanced faceplate)
Mode: self-reset, latched
Display message: 2 lines of 20 characters each
Drop-out timer: 0.00 to 60.00 s in steps of 0.05
Autoreset timer: 0.2 to 600.0 s in steps of 0.1
Hold timer: 0.0 to 10.0 s in steps of 0.1

OSCILLOGRAPHY

Maximum records: 64
Sampling rate: 64 samples per power cycle
Triggers: any element pickup, dropout, or operate;

digital input change of state; digital out-

put change of state; FlexLogic™ equa-

tion
Data: AC input channels; element state; digital

input state; digital output state
Data storage: in non-volatile memory

EVENT RECORDER

Capacity: 1024 events
Time-tag: to 1 microsecond
Triggers: any element pickup, dropout, or operate;

digital input change of state; digital out-

put change of state; self-test events
Data storage: in non-volatile memory

DATA LOGGER

Number of channels: 1 to 16
Parameters: any available analog actual value
Sampling rate: 15 to 3600000 ms in steps of 1
Trigger: any FlexLogic™ operand
Mode: continuous or triggered
Storage capacity: (NN is dependent on memory)

1-second rate:

01 channel for NN days

16 channels for NN days

↓

60-minute rate:

01 channel for NN days
16 channels for NN days

SELECTOR SWITCH

Number of elements: 2
Upper position limit: 1 to 7 in steps of 1
Selecting mode: time-out or acknowledge
Time-out timer: 3.0 to 60.0 s in steps of 0.1
Control inputs: step-up and 3-bit
Power-up mode: restore from non-volatile memory or syn-

chronize to a 3-bit control input or synch/
restore mode

2.2.3 MONITORING

FAULT LOCATOR

Method: single-ended
Voltage source: wye-connected VTs, delta-connected

VT s and neutral voltage, delta-connected
VT s and zero-sequence current (approxi­mation)

Maximum accuracy if: fault resistance is zero or fault currents

from all line terminals are in phase
Relay accuracy: ±1.5% (V > 10 V, I > 0.1 pu)
Worst-case accuracy:

+ user data

VT

%error

+ user data

CT

%error

Z

Line%error

METHOD
RELAY ACCURACY

+ user data

+ see chapter 8

%error

+ (1.5%)

%error

HI-Z

Detections: Arc Suspected, Arc Detected, Downed

Conductor, Phase Identification

2

2.2.4 METERING

RMS CURRENT: PHASE, NEUTRAL, AND GROUND

Accuracy at

0.1 to 2.0 × CT rating: ±0.25% of reading or ±0.1% of rated
(whichever is greater)

> 2.0 × CT rating: ±1.0% of reading

RMS VOLTAGE

Accuracy: ±0.5% of reading from 10 to 208 V

REAL POWER (WATTS)

Accuracy: ±1.0% of reading at

–0.8 < PF ≤ –1.0 and 0.8 < PF ≤ 1.0

REACTIVE POWER (VARS)

Accuracy: ±1.0% of reading at –0.2 ≤ PF ≤ 0.2

APPARENT POWER (VA)

Accuracy: ±1.0% of reading

WATT-HOURS (POSITIVE AND NEGATIVE)

Accuracy: ±2.0% of reading
Range: ±0 to 1 × 10
Parameters: three-phase only
Update rate: 50 ms

6

MWh

GE Multilin F60 Feeder Protection System 2-11

2.2 SPECIFICATIONS 2 PRODUCT DESCRIPTION

VAR-HOURS (POSITIVE AND NEGATIVE)

Accuracy: ±2.0% of reading
Range: ±0 to 1 × 10
Parameters: three-phase only
Update rate: 50 ms

6

Mvarh

CURRENT HARMONICS

Harmonics: 2nd to 25th harmonic: per phase, dis-

2

played as a % of f
quency phasor)
THD: per phase, displayed as a % of f

Accuracy:

HARMONICS: 1. f

THD: 1. f1 > 0.4pu: (0.25% + 0.035% / harmonic) of

> 0.4pu: (0.20% + 0.035% / harmonic) of

1

reading or 0.15% of 100%, whichever is
greater

< 0.4pu: as above plus %error of f

2. f

1

reading or 0.20% of 100%, whichever is
greater

< 0.4pu: as above plus %error of f

2. f

1

(fundamental fre-

1

VO LTAGE HARMONICS

Harmonics: 2nd to 25th harmonic: per phase, dis-

played as a % of f
quency phasor)
THD: per phase, displayed as a % of f

Accuracy:

HARMONICS: 1. f

1

THD: 1. f1 > 0.4pu: (0.25% + 0.035% / harmonic) of

> 0.4pu: (0.20% + 0.035% / harmonic) of

1

reading or 0.15% of 100%, whichever is
greater

< 0.4pu: as above plus %error of f

2. f

1

reading or 0.20% of 100%, whichever is
greater

< 0.4pu: as above plus %error of f

2. f

1

(fundamental fre-

1

1

1

1

FREQUENCY

1

1

Accuracy at

V = 0.8 to 1.2 pu: ±0.001 Hz (when voltage signal is used

for frequency measurement)
I = 0.1 to 0.25 pu: ±0.05 Hz
I > 0.25 pu: ±0.001 Hz (when current signal is used

for frequency measurement)

DEMAND

Measurements: Phases A, B, and C present and maxi-

mum measured currents

3-Phase Power (P, Q, and S) present

and maximum measured currents

Accuracy: ±2.0%

AC CURRENT

CT rated primary: 1 to 50000 A
CT rated secondary: 1 A or 5 A by connection
Nominal frequency: 20 to 65 Hz
Relay burden: < 0.2 VA at rated secondary
Conversion range:

Standard CT: 0.02 to 46 × CT rating RMS symmetrical
Sensitive Ground CT module:

0.002 to 4.6 × CT rating RMS symmetrical

HI-Z CT module: 0.002 to 4.6 × CT rating RMS symmetri-

cal

Current withstand: 20 ms at 250 times rated

1 sec. at 100 times rated
continuous at 3 times rated

AC VOLTAGE

VT rated secondary: 50.0 to 240.0 V
VT ratio: 1.00 to 24000.00
Nominal frequency: 20 to 65 Hz
Relay burden: < 0.25 VA at 120 V
Conversion range: 1 to 275 V
Voltage withstand: continuous at 260 V to neutral

1 min./hr at 420 V to neutral

2.2.5 INPUTS

CONTACT INPUTS

Dry contacts: 1000 Ω maximum
Wet contacts: 300 V DC maximum
Selectable thresholds: 17 V, 33 V, 84 V, 166 V
Tolerance: ±10%
Contacts per common return: 4
Recognition time: < 1 ms
Debounce time: 0.0 to 16.0 ms in steps of 0.5
Continuous current draw:3 mA (when energized)

CONTACT INPUTS WITH AUTO-BURNISHING

Dry contacts: 1000 Ω maximum
Wet contacts: 300 V DC maximum
Selectable thresholds: 17 V, 33 V, 84 V, 166 V
Tolerance: ±10%
Contacts per common return: 2
Recognition time: < 1 ms
Debounce time: 0.0 to 16.0 ms in steps of 0.5
Continuous current draw:3 mA (when energized)
Auto-burnish impulse current: 50 to 70 mA
Duration of auto-burnish impulse: 25 to 50 ms

DCMA INPUTS

Current input (mA DC): 0 to –1, 0 to +1, –1 to +1, 0 to 5, 0 to 10,

0 to 20, 4 to 20 (programmable)

Input impedance: 379 Ω ±10%
Conversion range: –1 to + 20 mA DC
Accuracy: ±0.2% of full scale
Type: Passive

2-12 F60 Feeder Protection System GE Multilin

2 PRODUCT DESCRIPTION 2.2 SPECIFICATIONS

RTD INPUTS

Types (3-wire): 100 Ω Platinum, 100 & 120 Ω Nickel, 10

Ω Copper

Sensing current: 5 mA
Range: –50 to +250°C
Accuracy: ±2°C
Isolation: 36 V pk-pk

IRIG-B INPUT

Amplitude modulation: 1 to 10 V pk-pk
DC shift: TTL
Input impedance: 22 kΩ
Isolation: 2 kV

REMOTE INPUTS (IEC 61850 GSSE/GOOSE)

Number of input points: 32, configured from 64 incoming bit pairs
Number of remote devices:16
Default states on loss of comms.: On, Off, Latest/Off, Latest/On

DIRECT INPUTS

Number of input points: 32
No. of remote devices: 16
Default states on loss of comms.: On, Off, Latest/Off, Latest/On
Ring configuration: Yes, No
Data rate: 64 or 128 kbps
CRC: 32-bit
CRC alarm:

Responding to: Rate of messages failing the CRC
Monitoring message count: 10 to 10000 in steps of 1
Alarm threshold: 1 to 1000 in steps of 1

Unreturned message alarm:

Responding to: Rate of unreturned messages in the ring

configuration
Monitoring message count: 10 to 10000 in steps of 1
Alarm threshold: 1 to 1000 in steps of 1

TELEPROTECTION

Number of input points: 16
No. of remote devices: 3
Default states on loss of comms.: On, Off, Latest/Off, Latest/On
Ring configuration: No
Data rate: 64 or 128 kbps
CRC: 32-bit

2.2.6 POWER SUPPLY

2

LOW RANGE

Nominal DC voltage: 24 to 48 V
Min/max DC voltage: 20 / 60 V
Voltage loss hold-up: 20 ms duration at nominal
NOTE: Low range is DC only.

HIGH RANGE

Nominal DC voltage: 125 to 250 V
Min/max DC voltage: 88 / 300 V
Nominal AC voltage: 100 to 240 V at 50/60 Hz
Min/max AC voltage: 88 / 265 V at 25 to 100 Hz
Voltage loss hold-up: 200 ms duration at nominal

FORM-A RELAY

Make and carry for 0.2 s:30 A as per ANSI C37.90
Carry continuous: 6 A
Break (DC inductive, L/R = 40 ms):

VOLT AGE CURRENT

24 V 1 A

48 V 0.5 A
125 V 0.3 A
250 V 0.2 A

Operate time: < 4 ms
Contact material: silver alloy

ALL RANGES

Volt withstand: 2 × Highest Nominal Voltage for 10 ms
Power consumption: typical = 15 to 20 W/VA

maximum = 50 W/VA
contact factory for exact order code con­sumption

INTERNAL FUSE

RATINGS

Low range power supply: 8 A / 250 V
High range power supply: 4 A / 250 V

INTERRUPTING CAPACITY

AC: 100 000 A RMS symmetrical
DC: 10 000 A

2.2.7 OUTPUTS

LATCHING RELAY

Make and carry for 0.2 s:30 A as per ANSI C37.90
Carry continuous: 6 A
Break at L/R of 40 ms: 0.25 A DC max.
Operate time: < 4 ms
Contact material: silver alloy
Control: separate operate and reset inputs
Control mode: operate-dominant or reset-dominant

FORM-A VOLTAGE MONITOR

Applicable voltage: approx. 15 to 250 V DC
Trickle current: approx. 1 to 2.5 mA

FORM-A CURRENT MONITOR

Threshold current: approx. 80 to 100 mA

GE Multilin F60 Feeder Protection System 2-13

2.2 SPECIFICATIONS 2 PRODUCT DESCRIPTION

FORM-C AND CRITICAL FAILURE RELAY

Make and carry for 0.2 s:30 A as per ANSI C37.90
Carry continuous: 8 A
Break (DC inductive, L/R = 40 ms):

VOLT AGE CURRENT

24 V 1 A
48 V 0.5 A

2

125 V 0.3 A
250 V 0.2 A

Operate time: < 8 ms
Contact material: silver alloy

FAST FORM-C RELAY

Make and carry: 0.1 A max. (resistive load)
Minimum load impedance:

INPUT

VOLTAGE

250 V DC 20 KΩ 50 KΩ
120 V DC 5 KΩ 2 KΩ

48 V DC 2 KΩ 2 KΩ
24 V DC 2 KΩ 2 KΩ

Note: values for 24 V and 48 V are the same due to a
required 95% voltage drop across th e load impedance.

2 W RESISTOR 1 W RESISTOR

IMPEDANCE

Operate time: < 0.6 ms
Internal Limiting Resistor: 100 Ω, 2 W

SOLID-STATE OUTPUT RELAY

Operate and release time: <100 μs
Maximum voltage: 265 V DC
Maximum continuous current: 5 A at 45°C; 4 A at 65°C
Make and carry:

for 0.2 s: 30 A as per ANSI C37.90
for 0.03 s 300 A

Breaking capacity:

UL508 Utility

Operations/
interval

Break
capability
(0 to 250 V
DC)

5000 ops /

1s-On, 9s-Off

1000 ops /

0.5 s-On, 0.5 s-Off

3.2 A

L/R = 10 ms

1.6 A

L/R = 20 ms

0.8 A

L/R = 40 ms

application

(autoreclose

scheme)

5ops/

0.2 s-On,

0.2 s-Off
within 1

minute

10 A

L/R = 40 ms

Industrial

application

10000 ops /

0.2 s-On,
30 s-Off

10 A

L/R = 40 ms

IRIG-B OUTPUT

Amplitude: 10 V peak-peak RS485 level
Maximum load: 100 ohms
Time delay: 1 ms for AM input

40 μs for DC-shift input

Isolation: 2 kV

CONTROL POWER EXTERNAL OUTPUT
(FOR DRY CONTACT INPUT)

Capacity: 100 mA DC at 48 V DC
Isolation: ±300 Vpk

REMOTE OUTPUTS (IEC 61850 GSSE/GOOSE)

Standard output points: 32
User output points: 32

DIRECT OUTPUTS

Output points: 32

DCMA OUTPUTS

Range: –1 to 1 mA, 0 to 1 mA, 4 to 20 mA
Max. load resistance: 12 kΩ for –1 to 1 mA range

12 kΩ for 0 to 1 mA range
600 Ω for 4 to 20 mA range

Accuracy: ±0.75% of full-scale for 0 to 1 mA range

±0.5% of full-scale for –1 to 1 mA range

±0.75% of full-scale for 0 to 20 mA range
99% Settling time to a step change: 100 ms
Isolation: 1.5 kV
Driving signal: any FlexAnalog quantity
Upper and lower limit for the driving signal: –90 to 90 pu in steps of

0.001

ETHERNET SWITCH (HIGH VOLTAGE, TYPE 2S)

Nominal DC voltage: 110 to 240 V DC
Minimum DC voltage: 88 V DC
Maximum DC voltage: 300 V DC
Input Current: 0.9 A DC maximum
Nominal AC voltage: 100 to 240 V AC, 0.26 to 0.16 A/26 to 39

VA at 50/60 Hz
Minimum AC voltage: 85 V AC, 0.31 A/22 VA at 50/60 Hz
Maximum AC voltage: 265 V AC, 0.16 A/42 VA at 50/60 Hz
Internal fuse: 3 A / 350 V AC, Ceramic, Axial SLO

BLO;
Manufacturer: Conquer; Part number:
SCD-A 003

ETHERNET SWITCH (LOW VOLTAGE, TYPE 2T)

Nominal voltage: 48 V DC, 0.31 A/15 W
Minimum voltage: 30 V DC, 0.43 A/16 W
Maximum voltage: 60 V DC
Internal fuse: 5 A / 350 V AC, Ceramic, Axial SLO

BLO;
Manufacturer: Conquer; Part number:
SCD-A 005

2-14 F60 Feeder Protection System GE Multilin

2 PRODUCT DESCRIPTION 2.2 SPECIFICATIONS

2.2.8 COMMUNICATIONS

RS232

Front port: 19.2 kbps, Modbus® RTU

RS485

1 or 2 rear ports: Up to 115 kbps, Modbus® RTU, isolated

Typical distance: 1200 m
Isolation: 2 kV

together at 36 Vpk

ETHERNET (FIBER)

PARAMETER FIBER TYPE

10MB MULTI-

MODE

Wavelength 820 nm 1310 nm 1310 nm
Connector ST ST SC
Transmit power –20 dBm –20 dBm –15 dBm
Receiver sensitivity –30 dBm –30 dBm –30 dBm
Power budget 10 dB 10 dB 15 dB
Maximum input

power
Typical distance 1.65 km 2 km 15 km
Duplex full/half full/half full/half
Redundancy yes yes yes

1. UR-2S and UR-2T only support 100 Mb multimode

–7.6 dBm –14 dBm –7 dBm

100MB MULTI-

MODE

1

100MB SINGLE-

MODE

ETHERNET (10/100 MB TWISTED PAIR)

Modes: 10 MB, 10/100 MB (auto-detect)
Connector: RJ45
SNTP clock synchronization error: <10 ms (typical)

ETHERNET SWITCH FIBER OPTIC PORTS

Maximum fiber segment length calculation:
The maximum fiber segment length between two adjacent

switches or between a switch and a device is calculated as fol­lows. First, calculate the optical power budget (OPB) of each
device using the manufacturer’s data sheets.

OPB P

where OPB = optical power budget, P
and P

= receiver sensitivity.

R

The worst case optical power budget (OPB
lated by taking the lower of the two calculated power budgets, sub-

–=

TMIN()PRMIN()

= transmitter output power,

T

WORST

) is then calcu-

tracting 1 dB for LED aging, and then subtracting the total insertion
loss. The total insertion loss is calculated by multiplying the num­ber of connectors in each single fiber path by 0.5 dB. For example,
with a single fiber cable between the two devices, there will be a
minimum of two connections in either transmit or receive fiber
paths for a total insertion loss of 1db for either direction:

Total insertion loss number of connectors 0.5 dB×=

2 0.5 dB×= 1.0 dB=

The worst-case optical power budget between two type 2T or 2S
modules using a single fiber cable is:

OPB

WORST

OPB 1 dB (LED aging)– total insertion loss–=

10dB 1dB– 1dB– 8dB=

To calculate the maximum fiber length, divide the worst-case opti­cal power budget by the cable attenuation per unit distance speci­fied in the manufacturer data sheets. For example, typical
attenuation for 62.5/125 μm glass fiber optic cable is approxi-
mately 2.8 dB per km. In our example, this would result in the fol­lowing maximum fiber length:

Maximum fiber length

OPB

=

-------------------------------------------------------

cable loss (in dB/km)

8 dB

---------------------------= 2.8km=

2.8 dB/km

WORST

(in dB)

The customer must use the attenuation specified within the manu­facturer data sheets for accurate calculation of the maximum fiber
length.

ETHERNET SWITCH 10/100BASE-T PORTS

Connector type: RJ45
MAXIMUM 10 MBPS ETHERNET SEGMENT LENGTHS

Unshielded twisted pair: 100 m (328 ft.)
Shielded twisted pair: 150 m (492 ft.)

MAXIMUM STANDARD FAST ETHERNET SEGMENT LENGTHS

10Base-T (CAT 3, 4, 5 UTP): 100 m (328 ft.)
100Base-TX (CAT 5 UTP):100 m (328 ft.)
Shielded twisted pair: 150 m (492 ft.)

2

GE Multilin F60 Feeder Protection System 2-15

2.2 SPECIFICATIONS 2 PRODUCT DESCRIPTION

2.2.9 INTER-RELAY COMMUNICATIONS

SHIELDED TWISTED-PAIR INTERFACE OPTIONS

INTERFACE TYPE TYPICAL DISTANCE

RS422 1200 m
G.703 100 m

2

RS422 distance is based on transmitter power

NOTE

and does not take into consideration the clock
source provided by the user.

LINK POWER BUDGET

EMITTER,
FIBER TYPE

820 nm LED,
Multimode

1300 nm LED,
Multimode

1300 nm ELED,
Singlemode

1300 nm Laser,
Singlemode

1550 nm Laser,
Singlemode

TRANSMIT

POWER

–20 dBm –30 dBm 10 dB

–21 dBm –30 dBm 9 dB

–23 dBm –32 dBm 9 dB

–1 dBm –30 dBm 29 dB

+5 dBm –30 dBm 35 dB

RECEIVED

SENSITIVITY

These power budgets are calculated from the

NOTE

manufacturer’s worst-case transmitter power
and worst case receiver sensitivity.

The power budgets for the 1300nm ELED are cal-

NOTE

culated from the manufacturer's transmitter
power and receiver sensitivity at ambient temper­ature. At extreme temperatures these values will
deviate based on component tolerance. On aver­age, the output power will decrease as the tem­perature is increased by a factor 1dB / 5°C.

MAXIMUM OPTICAL INPUT POWER

EMITTER, FIBER TYPE MAX. OPTICAL

820 nm LED, Multimode –7.6 dBm
1300 nm LED, Multimode –11 dBm
1300 nm ELED, Singlemode –14 dBm
1300 nm Laser, Singlemode –14 dBm
1550 nm Laser, Singlemode –14 dBm

INPUT POWER

POWER

BUDGET

T YPICAL LINK DISTANCE

EMITTER TYPE CABLE

820 nm LED,
multimode

1300 nm LED,
multimode

1300 nm ELED,
single mode

1300 nm Laser,
single mode

1550 nm Laser,
single-mode

TYPE

62.5/125 μm ST 1.65 km

62.5/125 μm ST 3.8 km

9/125 μm ST 11.4 km

9/125 μm ST 64 km

9/125 μm ST 105 km

CONNECTOR

TYPE

TYPICAL

DISTANCE

Typical distances listed are based on the fol­lowing assumptions for system loss. As

NOTE

actual losses will vary from one installation to
another, the distance covered by your system
may vary.

CONNECTOR LOSSES (TOTAL OF BOTH ENDS)

ST connector 2 dB

FIBER LOSSES

820 nm multimode 3 dB/km
1300 nm multimode 1 dB/km
1300 nm singlemode 0.35 dB/km
1550 nm singlemode 0.25 dB/km
Splice losses: One splice every 2 km,

at 0.05 dB loss per splice.

SYSTEM MARGIN

3 dB additional loss added to calculations to compensate for
all other losses.

Compensated difference in transmitting and receiving (channel
asymmetry) channel delays using GPS satellite clock: 10 ms

2.2.10 ENVIRONMENTAL

AMBIENT TEMPERATURES

Storage: –40 to 80°C

OPERATING TEMPERATURES

Cold: IEC 60068-2-1, 16 h at –40°C
Dry Heat: IEC 60068-2-2, 16 h at +85°C

The LCD contrast may be impaired at temperatures less
than –20°C.

NOTE

OTHER

Humidity (non-condensing): IEC 60068-2-30, 95%, Variant 1, 6

days
Altitude: Up to 2000 m
Installation Category: II

2-16 F60 Feeder Protection System GE Multilin

2 PRODUCT DESCRIPTION 2.2 SPECIFICATIONS

2.2.11 TYPE TESTS

Electrical fast transient: ANSI/IEEE C37.90.1

IEC 61000-4-4
IEC 60255-22-4

Oscillatory transient: ANSI/IEEE C37.90.1

IEC 61000-4-12
Insulation resistance: IEC 60255-5
Dielectric strength: IEC 60255-6

ANSI/IEEE C37.90
Electrostatic discharge: EN 61000-4-2
Surge immunity: EN 61000-4-5
RFI susceptibility: ANSI/IEEE C37.90.2

IEC 61000-4-3

IEC 60255-22-3

Ontario Hydro C-5047-77

THERMAL

Products go through an environmental test based upon an

Accepted Quality Level (AQL) sampling process.

APPROVALS

UL Listed for the USA and Canada
CE:

LVD 73/23/EEC: IEC 1010-1
EMC 81/336/EEC: EN 50081-2, EN 50082-2

Conducted RFI: IEC 61000-4-6
Voltage dips/interruptions/variations:

IEC 61000-4-11
IEC 60255-11

Power frequency magnetic field immunity:

IEC 61000-4-8
Pulse magnetic field immunity: IEC 61000-4-9
Vibration test (sinusoidal): IEC 60255-21-1
Shock and bump: IEC 60255-21-2
Seismic: IEC 60255-21-3

IEEE C37.98
Cold: IEC 60028-2-1, 16 h at –40°C
Dry heat: IEC 60028-2-2, 16 h at 85°C

Type test report available upon request.

NOTE

2.2.12 PRODUCTION TESTS

2.2.13 APPROVALS

2

MOUNTING

Attach mounting brackets using 20 inch-pounds (±2 inch-pounds)
of torque.

2.2.14 MAINTENANCE

CLEANING

Normally, cleaning is not required; but for situations where dust
has accumulated on the faceplate display, a dry cloth can be used.

Units that are stored in a de-energized state should be
powered up once per year, for one hour continuously, to

NOTE

avoid deterioration of electrolytic capacitors.

GE Multilin F60 Feeder Protection System 2-17

2

2.2 SPECIFICATIONS 2 PRODUCT DESCRIPTION

2-18 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.1 DESCRIPTION

3 HARDWARE 3.1DESCRIPTION 3.1.1 PANEL CUTOUT

a) HORIZONTAL UNITS

The F60 Feeder Protection System is available as a 19-inch rack horizontal mount unit with a removable faceplate. The
faceplate can be specified as either standard or enhanced at the time of ordering. The en hanced faceplate contains addi­tional user-programmable pushbuttons and LED indicators.

The modular design allows the relay to be easily upgraded or repaired by a qualified service person . The faceplate is
hinged to allow easy access to the removable modules, and is itself removable to allow mounting on doors with limited rear
depth. There is also a removable dust cover that fits over the faceplate, which must be removed when attempting to access
the keypad or RS232 communications port.

The case dimensions are shown below, along with panel cutout details for panel mounting. When planning the location of
your panel cutout, ensure that provision is made for the faceplate to swing open without interference to or from adjacent
equipment.

The relay must be mounted such that the faceplate sits semi-flush with the panel or switchgear door, allowing the operator
access to the keypad and the RS232 communications port. The relay is secured to the panel with the use of four screws
supplied with the relay.

11.016”

[279,81 mm]

9.687”

[246,05 mm]

3

6.995”

[177,67 mm]

17.56”

[446,02 mm]

19.040”

[483,62 mm]

Figure 3–1: F60 HORIZONTAL DIMENSIONS (ENHANCED PANEL)

[189,48 mm]

6.960”
[176,78 mm]

842807A1.CDR

7.460”

GE Multilin F60 Feeder Protection System 3-1

3

3.1 DESCRIPTION 3 HARDWARE

18.370”

[466,60 mm]

0.280”
[7,11 mm]

4.000”

[101,60 mm]

842808A1.CDR

Typ.x4

CUT-OUT

17.750”

[450,85 mm]

Figure 3–2: F60 HORIZONTAL MOUNTING (ENHANCED PANEL)

Figure 3–3: F60 HORIZONTAL MOUNTING AND DIMENSIONS (STANDARD PANEL)

b) VERTICAL UNITS

The F60 Feeder Protection System is available as a reduced size (¾) vertical mount unit, with a removable fa cepla te. The
modular design allows the relay to be easily upgraded or repaired by a qualified service person. The fa cepla te i s hinged to
allow easy access to the removable modules, and is itself removable to allow mou nting on doors with limited rear depth.
There is also a removable dust cover that fits over the faceplate, which must be removed when attempting to access the
keypad or RS232 communications port.

The case dimensions are shown below, along with panel cutout details for panel mounting. When planning the location of
your panel cutout, ensure that provision is made for the faceplate to swing open without interference to or from adjacent
equipment.

The relay must be mounted such that the faceplate sits semi-flush with the panel or switchgear do or, allowing the operator
access to the keypad and the RS232 communications port. The relay is secured to the panel with the use of four screws
supplied with the relay.

3-2 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.1 DESCRIPTION

e

URSERIES

URSERIES

3

Figure 3–4: F60 VERTICAL MOUNTING AND DIMENSIONS

GE Multilin F60 Feeder Protection System 3-3

3

3.1 DESCRIPTION 3 HARDWARE

Figure 3–5: F60 VERTICAL SIDE MOUNTING INSTALLATION

3-4 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.1 DESCRIPTION

3

Figure 3–6: F60 VERTICAL SIDE MOUNTING REAR DIMENSIONS

3.1.2 MODULE WITHDRAWAL AND INSERTION

Module withdrawal and insertion may only be performed when control power has been removed from the

WARNING

WARNING

The relay, being modular in design, allows for the withdrawal and insertion of modules. Modules must only be replaced with
like modules in their original factory configured slots.

The enhanced faceplate can be opened to the left, once the thumb screw has been removed, as shown below. This allows
for easy accessibility of the modules for withdrawal. The new wide-angle hinge assembly in the enhanced front panel opens
completely and allows easy access to all modules in the F60.

unit. Inserting an incorrect module type into a slot may result in personal injury, damage to the unit or con­nected equipment, or undesired operation!

Proper electrostatic discharge protection (for example, a static strap) must be used when coming in con­tact with modules while the relay is energized!

GE Multilin F60 Feeder Protection System 3-5

3.1 DESCRIPTION 3 HARDWARE

842812A1.CDR

3

The standard faceplate can be opened to the left, once the sliding latch on the right side has been pushed up, as shown
below. This allows for easy accessibility of the modules for withdrawal.

Figure 3–7: UR MODULE WITHDRAWAL AND INSERTION (ENHANCED FACEPLATE)

Figure 3–8: UR MODULE WITHDRAWAL AND INSERTION (STANDARD FACEPLATE)

To properly remove a module, the ejector/inserter clips, located at the top and bottom of each module, must be pull ed
simultaneously. Before performing this action, control power must be removed from the relay. Record the original loca­tion of the module to ensure that the same or replacement module is inserted into the correct slot. Modules with current
input provide automatic shorting of external CT circuits.

To properly insert a module, ensure that the correct module typ e is inserted into the correct slot position. The ejector/
inserter clips located at the top and at the bottom of each module must be in the disengaged position as the modu le is
smoothly inserted into the slot. Once the clips have cleared the raised edge of the chassis, engage the clips simultaneously.
When the clips have locked into position, the module will be fully inserted.

All CPU modules except the 9E are equipped with 10/100Base-T or 100Base-F Ether net connectors. These con­nectors must be individually disconnected from the module before it can be removed from the chassis.

3-6 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.1 DESCRIPTION

The 4.0x release of the F60 relay includes new hardware modules.The new CPU modules are specified with codes
9E and higher. The new CT/VT modules are specified with the codes 8F and higher.

NOTE

The new CT/VT modules can only be used with new CPUs; similarly, old CT/VT modules can only be used with old
CPUs. To prevent hardware mismatches, the new modules have blue labels and a warning sticker stating “Attn.:
Ensure CPU and DSP module label colors are the same!”. In the event that there is a misma tch between the
CPU and CT/VT module, the relay will not function and a

DSP ERROR or HARDWARE MISMATCH error will be dis-

played.
All other input and output modules are compatible with the new hardwa re. Firmware versions 4.0x and higher are

only compatible with the new hardware modules. Previous versions of the firmware (3.4x and earlier) are only com­patible with the older hardware modules.

3.1.3 REAR TERMINAL LAYOUT

Model:

Feeder Management Relay

F60

Technical Support:
Tel: [phone]

XWVU TS PNML KJ H DGF BR

Tx1

Rx1

Tx1

Tx2

Rx2

Tx2

Fax: [phone]

GE Multilin

http://www.GEIndustrial.com/Multilin

RATINGS:

®

Control Power:

88-300V DC @ 35W / 77-265V AC @ 35VA

Contact Inputs:

300V DC Max 10mA
Standard Pilot Duty / 250V AC 7.5A

Contact Outputs:

360V A Resistive / 125V DC Break
4A @ L/R = 40mS / 300W

®

®

abc abc

Made in
Canada

F60H00HCHF8FH6AM6BP8BX7A
000

Mods:

ZZZZZZ

Wiring Diagram:

D

Inst. Manual:

MAZB98000029

Serial Number:

D

Firmware:

1998/01/05

Mfg. Date:

- M A A B 9 7 0 0 0 0 9 9 -

abc

b

b

a

1

1

2

2

3

3

4

4

IN

OUT

Tx1

CH1

Rx1

CH1

Tx
Rx

CH2

Tx2

CH2

Rx2

a

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

3

Optional
Ethernet

switch

Optional

direct

input/output

module

Optional

HI-Z CT or

contact

input/output

module

Optional

contact

input/output

module

CT/VT

module

CPU module

(Ethernet not

available when

ordered with

Ethernet switch)

Power
supply

module

832768A3.CDR

Figure 3–9: REAR TERMINAL VIEW

Do not touch any rear terminals while the relay is energized!

WARNING

The relay follows a convention with respect to terminal number assign ments which are three characters long assigned in
order by module slot position, row number, and column letter. Two-slot wide modules take their slot designation from the
first slot position (nearest to CPU module) which is indicated by an arrow marker on the terminal block. See the following
figure for an example of rear terminal assignments.

GE Multilin F60 Feeder Protection System 3-7

3

3.1 DESCRIPTION 3 HARDWARE

Figure 3–10: EXAMPLE OF MODULES IN F AND H SLOTS

3-8 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.2 WIRING

52

I

V

I

V

3.2WIRING 3.2.1 TYPICAL WIRING

TYPICAL CONFIGURATION

THE AC SIGNAL PATH IS CONFIGURABLE

This diagram is based on the following order code:

F60-E00-HCH-F8F-H6B-M6K-P6C-U6D-W6A

This diagram provides an example of how the device
is wired, not specifically how to wire the device. Please
refer to the Instruction Manual for additional details on
wiring based on various configurations.

A

C

B

OPEN DELTA
VT CONNECTION (ABC)

POSITIVE WATTS

6a

6c

7a

5a

5c

F

F

VA

VA

7c

F

F

F

F

VC

VB

VC

VB

6a

6c

7a

7c

8a

5a

5c

F

F

F

F

VB

VA

VB

VA

8c

F

F

F

F

VX

VC

VX

VC

(5 Amp CT)

CONNECTION
AS REQUIRED

4a

1c

1a

1b

F

F

IA

IA5

2c

2a

2b

F

IA1

3a

F

F

F

F

IB

IB5

IB1

IC5

4b

3c

3b

F

IC

4c

F

F

F

F

IG

IG5

IG1

IC1

VOLTAGE AND

CURRENT SUPERVISION

3

Ground at

Remote
Device

Co-axial * - For IRIG-B Input

only use one
terminal as input

( DC ONLY)

AC or DC

DC

Shielded

twisted pairs

Co-axial *

Co-axial

Co-axial

VOLTAGE INPUTS

No. 10AWG

Minimum

MODULES MUST BE

GROUNDED IF

TERMINAL IS

PROVIDED

H7a

H7c
H8a
H8c

H7b

H8b

W5a

W5c
W6a
W6c

W5b

W7a

W7c
W8a
W8c

W7b

W8b

U1a

U1c
U2a

U2c

U1b
U3a

U3c
U4a
U4c
U3b

U5a

U5c
U6a
U6c

U5b

U7a

U7c
U8a
U8c

U7b

U8b

B1b
B1a
B2b
B3a
B3b
B5b

B6b
B6a
B8a
B8b

D1b
D2b
D3b
D1a
D2a
D3a
D4b
D4a

GROUND BUS

VOLTAGE INPUTS

CONTACTINPUT H7a
CONTACTINPUT H7c
CONTACTINPUT H8a
CONTACTINPUT H8c

COMMON H7b

SURGE

GE Consumer & Industrial

Multilin

FEEDER MANAGEMENT RELAY

F60

CONTACTINPUT W5a
CONTACTINPUT W5c
CONTACTINPUT W6a
CONTACTINPUT W6c

COMMON W5b

CONTACTINPUT W7a
CONTACTINPUT W7c
CONTACTINPUT W8a
CONTACTINPUT W8c

COMMON W7b

SURGE

CONTACTINPUT U1a
CONTACTINPUT U1c
CONTACTINPUT U2a
CONTACTINPUT U2c

COMMON U1b

CONTACTINPUT U3a
CONTACTINPUT U3c
CONTACTINPUT U4a
CONTACTINPUT U4c

COMMON U3b

CONTACTINPUT U5a
CONTACTINPUT U5c
CONTACTINPUT U6a
CONTACTINPUT U6c

COMMON U5b

CONTACTINPUT U7a
CONTACTINPUT U7c
CONTACTINPUT U8a
CONTACTINPUT U8c

COMMON U7b

SURGE

CRITICAL

FAILURE

48 VDC
OUTPUT

HI

CONTROL

LO

POWER

SURGE

FILTER

RS485
COM 1

COM

RS485
COM 2

COM

IRIG-B

Input

BNC

IRIG-B

BNC

Output

6

6

Inputs/

Inputs/

outputs

outputs

*

*

* Optional

CURRENT INPUTS

8F/8G

DIGITALINPUTS/OUTPUTS

DIGITALINPUTS/OUTPUTS

6D

DIGITALINPUTS/OUTPUTS

1

CONTACTSSHOWN

WITH NO

CONTROL POWER

POWER SUPPLY

9E

CPU

MODULE ARRANGEMENT

N

MXLWKVBHTD

6

6

Inputs/

Inputs/

outputs

outputs

*

*

(Rear view)

RS-232

DB-9

(front)

JU

Inputs/
outputs

6

6B

H1

H2

H3

H4

H5

H6

6A

W1

W2

W3

W4

6C

P1

P2

P3

P4

P5

P6

P7

P8

DIGITALINPUTS/OUTPUTS

6K

M1

M2

M3

M4

M5

M6

M7

M8

DIGITALINPUTS/OUTPUTS

832769A4.CDR

GSP FR

8

CPU

CT/VT

H1a
H1b

H1c

H2a
H2b

H2c

H3a
H3b

H3c

H4a
H4b

H4c

H5a
H5b

H5c

H6a
H6b

H6c

I

W1a
W1b

V

W1c

I

W2a
W2b

V

W2c
W3a
W3b
W3c
W4a
W4b

W4c

P1a

P1b

P1c
P2a
P2b
P2c
P3a
P3b
P3c
P4a
P4b

P4c

P5a
P5b
P5c

P6a

P6b
P6c
P7a
P7b

P7c

P8a

P8b

P8c

M1a

M1b

M1c
M2a
M2b
M2c
M3a
M3b
M3c
M4a
M4b

M4c

M5a
M5b
M5c

M6a

M6b
M6c
M7a
M7b

M7c

M8a

M8b

M8c

1

9

Power
Supply

TC

1

VOLTAGE SUPERVISION

TC

2

UR COMPUTER

8

1

1

3

22

TXD RXD

33

RXD TXD

SGND SGND

CONNECTOR

2

44

20

55

7

66

6

77

4
5

88
99

22

9PIN

25 PIN
CONNECTOR

Figure 3–11: TYPICAL WIRING DIAGRAM

GE Multilin F60 Feeder Protection System 3-9

3.2 WIRING 3 HARDWARE

52

TYPICAL CONFIGURATION

THE AC SIGNAL PATH IS CONFIGURABLE

This diagram is based on the following order code:

3

F60-H00-HCH-F8F-H6B-M8Z-P6C-UXX-WXX

This diagram provides an example of how the device
is wired, not specifically how to wire the device. Please
refer to the Instruction Manual for additional details on
wiring based on various configurations.

AS REQUIRED

CONNECTION

(5 Amp CT)

POSITIVE WATTS

OPEN DELTA

C
B

VT CONNECTION (ABC)

6C

M8c

M8b

M8a

M7c

GE Consumer & Industrial

Multilin

FEEDER MANAGEMENT RELAY

F60

M7b

M7a

M6c

M6b

M6a

M5c

M5b

M5a

M4c

M4b

M4a

M3c

M3b

M3a

M2c

M2b

M2a

M1c

M1b

M1a

F4c

F4b

F4a

F3c

F3b

F3a

F2c

F2b

F2a

F1c

F1b

F1a

F8c

F8a

F7c

F7a

F6c

F6a

F5c

F5a

F7c

F7a

F6c

F6a

F5c

F5a

8Z

IG1

IG

IG5

IC1

IC

IC5

IB1

CURRENT INPUTS NOTUSED

IB

IB5

IA1

IA

IA5

IG1

IG

IG5

IC1

IC

IC5

IB1

CURRENT INPUTS

IB

IB5

IA1

8F/8G

IA

IA5

VX

VX

VC

VC

VB

VOLTAGE INPUTS

VB

VA

VA

VC

VC

VB

VB

VOLTAGE INPUTS

VA

VA

Digital
inputs/
outputs

* Optional

8

6

Digital
inputs/
outputs

CONTACTSSHOWN

WITH NO

CONTROL POWER

MODULE ARRANGEMENT

6
Digital
inputs/
outputs

RS-232

DB-9

(front)

JU

N

MXLWKVBHTD

8

6
Digital
inputs/

CT

outputs

(Rear view)

GSP FR

8

CT/VT

6B

DIGITALINPUTS/OUTPUTS

DIGITALINPUTS/OUTPUTS

H1

H2

H3

H4

H5

H6

CONTACTINPUT H7a
CONTACTINPUT H7c
CONTACTINPUT H8a
CONTACTINPUT H8c

COMMON H7b

SURGE

1

CRITICAL

CONTROL

POWER SUPPLY

NORMAL

9H

COM

ALTERNATE

1

RS485

COM 2

IRIG-B
Input

IRIG-B

Output

CPU

832770A3.CDR

9

CPU

P1

P2

P3

P4

P5

P6

P7

P8

FAILURE

48 VDC
OUTPUT

POWER

SURGE

FILTER

V

V

Power

Supply

P1a

P1b

P1c
P2a
P2b
P2c
P3a
P3b
P3c
P4a
P4b

P4c

P5a
P5b

UR COMPUTER

P5c

P6a

TXD RXD

P6b

RXD TXD

P6c
P7a

SGND SGND

P7b

P7c

P8a

P8b

P8c

CONNECTOR

I

H1a
H1b

H1c

I

H2a
H2b

H2c

H3a
H3b

H3c

H4a
H4b

H4c

H5a
H5b

H5c

H6a
H6b

H6c

H7a

H7c

H8a

H8c

H7b

H8b

B1b
B1a
B2b
B3a
B3b

HI

B5b

LO

B6b
B6a
B8a
B8b

10BaseFL

Tx1

Rx1

10BaseFL

Tx2

Rx2

10BaseT

D1a
D2a

com

D3a
D4b
D4a

BNC

BNC

No. 10AWG

minimum

1

MODULES MUST BE

GROUNDED IF
TERMINAL IS

PROVIDED

8

1

1

3

22
33

2

44

20

55

7

66

6

77

4
5

88
99

22

9PIN

DC

AC or DC

Shielded

twisted pairs

Co-axial *

Co-axial

Co-axial

GROUND BUS

25 PIN
CONNECTOR

( DC ONLY)

Co-axial * - For IRIG-B Input

only use one
terminal as input

*

Ground at

Remote
Device

Fibre
Optic

A

Figure 3–12: TYPICAL WIRING DIAGRAM WITH HIGH-IMPEDANCE DETECTION

3-10 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.2 WIRING

3.2.2 DIELECTRIC STRENGTH

The dielectric strength of the UR-series module hardware is shown in the following table:

Table 3–1: DIELECTRIC STRENGTH OF UR-SERIES MODULE HARDWARE

MODULE

TYPE

1 Power supply High (+); Low (+); (–) Chassis 2000 V AC for 1 minute
1 Power supply 48 V DC (+) and (–) Chassis 2000 V AC for 1 minute
1 Power supply Relay terminals Chassis 2000 V AC for 1 minute
2 Reserved N/A N/A N/A
3 Reserved N/A N/A N/A
4 Reserved N/A N/A N/A
5 Analog inputs/outputs All except 8b Chassis < 50 V DC
6 Digital inputs/outputs All Chassis 2000 V AC for 1 minute

7
8 CT/VT All Chassis 2000 V AC for 1 minute

9 CPU All Chassis 2000 V AC for 1 minute

MODULE FUNCTION TERMINALS DIELECTRIC STRENGTH

FROM TO

G.703 All except 2b, 3a, 7b, 8a Chassis 2000 V AC for 1 minute

RS422 All except 6a, 7b, 8a Chassis < 50 V DC

(AC)

Filter networks and transient protection clamps are used in the hardware to prevent damage caused b y high peak voltage
transients, radio frequency interference (RFI), and electromagnetic i nterference (EMI). These protective components can
be damaged by application of the ANSI/IEEE C37.90 specified test voltage for a period longer than the specified one min­ute.

3

3.2.3 CONTROL POWER

CONTROL POWER SUPPLIED TO THE RELAY MUST BE CONNECTED TO THE MA TCHING POWER SUPPLY
RANGE OF THE RELAY. IF THE VOLTAGE IS APPLIED TO THE WRONG TERMINALS, DAMAGE MAY

CAUTION

OCCUR!
The F60 relay, like almost all electronic relays, contains electrolytic capacitors. These capacitors are well

known to be subject to deterioration over ti me if voltage is not applied periodically. Deterioration can be

NOTE

avoided by powering the relays up once a year.

The power supply module can be ordered for two possible voltage ranges, with o r withou t a re dun dant power op tio n. Each
range has a dedicated input connection for proper operation. The ra nges are as shown below (see the Technical specifica-
tions section of chapter 2 for additional details):

• Low (LO) range: 24 to 48 V (DC only) nominal.

• High (HI) range: 125 to 250 V nominal.
The power supply module provides power to the relay and supplies power for dry contact input connections.
The power supply module provides 48 V DC power for dry contact input connections and a critical failure relay (see the

Typical wiring diagram earlier). The critical failure relay is a form-C devic e that will be energized once control power is
applied and the relay has successfully booted up with no critical self-test failures. If on-going self-test diagnostic checks
detect a critical failure (see the Self-test errors section in chapter 7) or control power is lost, the relay will de-energize.

For high reliability systems, the F60 has a redundant option in which two F60 power su pplies are placed in parallel on the
bus. If one of the power supplies become faulted, the second power supply will assume the full load of the relay without any
interruptions. Each power supply has a green LED on the front of the module to indicate it is functional. The critical fail relay
of the module will also indicate a faulted power supply.

GE Multilin F60 Feeder Protection System 3-11

3.2 WIRING 3 HARDWARE

An LED on the front of the control power module shows the status of the power supply:

LED INDICATION POWER SUPPLY

CONTINUOUS ON OK
ON / OFF CYCLING Failure
OFF Failure

AC or DC

Heavy copper conductor

or braided wire

NOTE:
14 gauge stranded
wire with suitable
disconnect devices
is recommended.

AC or DC

3

Switchgear
ground bus

B8b B8a B6a B6b B5b

FILTER

SURGE

–

CONTROL

+

LOW

POWER

HIGH

+

UR-series

protection system

Figure 3–13: CONTROL POWER CONNECTION

A CT/VT module may have voltage inputs on channels 1 through 4 inclusive, or channels 5 through 8 inclusive. Channels 1
and 5 are intended for connection to phase A, and are labeled as such in the relay. Likewise, channels 2 and 6 are intended
for connection to phase B, and channels 3 and 7 are intended for connection to phase C.

Channels 4 and 8 are intended for connection to a single-phase source. For voltage inputs, these channel are labelled as
auxiliary voltage (VX). For current inputs, these channels are intended for connection to a CT between system neutral and
ground, and are labelled as ground current (IG).

Verify that the connection made to the relay nominal current of 1 A or 5 A matches th e seco n dary r ating of

CAUTION

the connected CTs. Unmatched CTs may result in equipment damage or inadequate protection.

+

ETHERNET SWITCH

GND

OPTIONAL

827759AA.CDR

—

3.2.4 CT/VT MODULES

CT/VT modules may be ordered with a standard ground current input that is the same as the phase current input. Each AC
current input has an isolating transformer and an automatic shorting me chanism that shorts the input when the mo dule is
withdrawn from the chassis. There are no internal ground connections on the current inputs. Current transformers with 1 to
50000 A primaries and 1 A or 5 A secondaries may be used.

CT/VT modules with a sensitive ground input are also available. The g round CT input of the sensitive ground modules is
ten times more sensitive than the ground CT input of standard CT/VT modules. However, the phase CT inputs and phase
VT inputs are the same as those of regular CT/VT modules.

The above modules are available with enhanced diagnostics. These modules can automatically detect CT/VT hardware
failure and take the relay out of service.

CT connections for both ABC and ACB phase rotations are identical as shown in the Typical wiring diagram.
The exact placement of a zero-sequence core balance CT to detect ground fault current is shown below. Twisted-pair

cabling on the zero-sequence CT is recommended.

3-12 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.2 WIRING

UNSHIELDED CABLE

Source

ABCN G

LOAD

Ground connection to neutral
must be on the source side

Ground
outside CT

SHIELDED CABLE

Source

AB C

LOAD

Stress cone

shields

To ground;
must be on
load side

996630A5

Figure 3–14: ZERO-SEQUENCE CORE BALANCE CT INSTALLATION

The phase voltage channels are used for most metering and protecti on purposes. The auxiliary voltage channel is used as
input for the synchrocheck and volts-per-hertz features.

Substitute the tilde “~” symbol with the slot position of the module in the following figure.

3

1a

1b

1c

2a

2b

2c

3a

3b

3c

4a

4b

4c

5a

5c

6a

6c

7a

7c

8a

~

~

~

~

~

~

~

~

~

~

~

~

~

~

~

~

IA

IA5

2a

1c

1b

1a

~

~

~

IA5

1a

~

IA5

~

IA

IA1

IB5

1b

1c

2a

~

~

~

IA

IA1

IB5

IB

IA1

IB5

Current inputs

3a

2c

2b

~

~

~

IB

IB1

IC5

2b

2c

3a

~

~

~

IB

IB1

IC5

Current inputs Not used

8Z module (used for high-impedance fault detection)

IC

IB1

IC5

8F and 8G modules (4 CTs and 4 VTs)

3c

3b

4a

~

~

~

IC

IC1

IG5

8H and 8J modules (8 CTs)

3b

3c

4a

~

~

~

IC

IC1

IG5

IG

IC1

IG5

4c

4b

5a

~

~

~

IG

IG1

IA5

Current inputs

4b

4c

~

~

IG

IG1

IG1

5b

~

IA

VA

VA

6a

5c

~

~

IA1

IB5

~

VB

VB

VC

Voltage inputs

7a

6c

6b

~

~

~

IB

IB1

IC5

8c

~

~

~

VX

VC

VX

8b

8a

~

~

IG

IG5

842769A1.CDR

IG1

8c

~

7c

7b

~

~

IC

IC1

Figure 3–15: CT/VT MODULE WIRING

GE Multilin F60 Feeder Protection System 3-13

3.2 WIRING 3 HARDWARE

52

A relay configured for high impedance fault detection element includes two CT/VT modules: one type 8F, 8G, 8H, or 8J
module and one type 8Z module. For correct operation of the high impedance fault detection element, the ground current
terminals of the two CT modules must be connected to a ground current source, either a zero-sequence CT (see the Typi-
cal wiring diagram with high impedance fault detection earlier in this chap ter) or, if a zero-sequence CT is not available, to
the neutral conductor of the phase CT s (see diagram below).

POSITIVE WATTS

(5 Amp CT)

A
B
C

3

MMMMMMMMMMMMMMMMMMMMMMM

F

FFFFFFFFFFF

5a5c6a

VA

VA

7a

6c

VB

VC

VB

VOLTAGE INPUTS

8c

8a

7c

1a

IA5

VX

VX

VC

1b

IA

8F / 8G

FFFFFFF
2b

2c

1c

2a

IB5

IA1

IB1

IB

CURRENT INPUTS

4b

4a

3c

3b

3a

IG5

IC5

IC1

IG

IC

Figure 3–16: TYPICAL 8Z MODULE WIRING WITH PHASE CTS

Every digital input/output module has 24 terminal connections. T hey are arranged as three terminals per row, with eight
rows in total. A given row of three terminals may be used for the outputs of one relay. For example, for form-C relay outputs,
the terminals connect to the normally open (NO), normally closed (NC), and common contacts of the relay. For a form-A
output, there are options of using current or voltage detection for feature supervision, dep ending on the module ordered.
The terminal configuration for contact inputs is different for the two applications.

The digital inputs are grouped with a common return. The F60 has two versions of grouping: four inputs per common return
and two inputs per common return. When a digital input/output module is ordered, four inputs per common is used. The four
inputs per common allows for high-density inputs in combination with outputs, with a compromise of four inputs sharing one
common. If the inputs must be isolated per row, then two inputs per common return should be selected (4D module).

The tables and diagrams on the following pages illustrate the module type s (6A, etc.) and contact arrangements that may
be ordered for the relay. Since an entire row is used for a single contact output, the name is assigned using the module slot
position and row number. However, since there are two contact inputs per row, these names are assigned by mod ule slot
position, row number, and column position.

Some form-A / solid-state relay outputs include circuits to monitor the DC voltage across the output contact when it is open,
and the DC current through the output contact when it is closed. Each of the monitors contains a level detector whose ou t­put is set to logic “On = 1” when the current in the circuit is above the threshold setting. The voltage monitor is set to “On =
1” when the current is above about 1 to 2.5 mA, and the current monitor is set to “On = 1” when the current exceeds about
80 to 100 mA. The voltage monitor is intended to check the health of the overall trip circuit, and th e current mon itor can be
used to seal-in the output contact until an external contact has interrupted current flow.

Block diagrams are shown below for form-A and form-A / solid-state relay outputs with optional voltage monitor, optional
current monitor, and with no monitoring

M

F
4c

1a

IG1

IA5

2b

1b

1c

2a

IB5

IA1

IA

CURRENT INPUTS NOT USED

3b

3a

2c

3c

IC5

IC1

IB1

IC

IB

5a

4b

4a

4c

IG5

IG1

IG

8Z

5b

6b

6a

7a

6c

5c

832752A3.CDR

3.2.5 CONTACT INPUTS/OUTPUTS

7b

8b

7c

8c

8a

3-14 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.2 WIRING

If Idc 80mA, Cont Op xxx Ion

³

a) Voltage with optional

current monitoring

b) Current with optional

voltage monitoring

~#a

I

V

If Idc 1mA, Cont Op xxx Von

~#b

otherwise Cont Op xxx Voff

~#c

³

+

Load

-

Voltage monitoring only

~#a

V

I

If Idc 80mA, Cont Op xxx Ion

~#b

otherwise Cont Op xxx Ioff

~#c

³

+

Load

-

Current monitoring only Both voltage and current monitoring

~#a

I

V

Both voltage and current monitoring

V

I

(external jumper a-b is required)

otherwise Cont Op xxx Ioff

~#a

If Idc 1mA, Cont Op xxx Von
otherwise Cont Op xxx Voff

~#b

~#c

If Idc 80mA, Cont Op xxx Ion
otherwise Cont Op xxx Ioff

~#a

If Idc 1mA, Cont Op xxx Von
otherwise Cont Op xxx Voff

~#b

~#c

³

³

³

+

Load

-

+

Load

-

3

c) No monitoring

a) Voltage with optional

current monitoring

V

b) Current with optional

voltage monitoring

~#b

~#c

+

Load

-

827821A6.CDR

Figure 3–17: FORM-A CONTACT FUNCTIONS

If Idc 80mA ,

³ Cont Op ## Ion

otherwise

~#a

I

~#b

V

~#c

³ Cont Op ## Von

If Idc 1mA ,

Cont Op ## Voff

otherwise

-

Load

+

Voltage monitoring only

~#a

If Idc 80mA ,

~#b

I

~#c

³ Cont Op ## Ion

otherwise

Cont Op ## Ioff

-

Load

+

V

Current monitoring only Both voltage and current monitoring

~#a

~#a

I

~#b

V

~#c

Both voltage and current monitoring

~#a

~#b

I

~#c

(external jumper a-b is required)

Cont Op ## Ioff

³ Cont Op ## Von

If Idc 1mA ,

Cont Op ## Voff

otherwise

If Idc 80mA ,

³ Cont Op ## Ion

otherwise

Cont Op ## Ioff

³ Cont Op ## Von

If Idc 1mA ,

Cont Op ## Voff

otherwise

-

Load

+

-

Load

+

827862A2.CDR

c) No monitoring

~#b

~#c

-

Load

+

Figure 3–18: FORM-A AND SOLID STATE CONTACT FUNCTIONS

The operation of voltage and current monitors is reflected with the co rresponding FlexLo gic™ operands (

CONT OP # VOFF, CONT OP # ION, and CONT OP # IOFF) which can be used in protection, control and alarm logic. The typical

CONT OP # VON,

application of the voltage monitor is breaker trip circuit integrity monitoring; a typical application of the current monitor is
seal-in of the control command.

GE Multilin F60 Feeder Protection System 3-15

3.2 WIRING 3 HARDWARE

Refer to the Digital elements section of chapter 5 for an example of how form-A and solid-state relay contacts can be
applied for breaker trip circuit integrity monitoring.

Relay contacts must be considered unsafe to touch when the unit is energized! If the relay contacts need to
be used for low voltage accessible applications, it is the customer’s responsibility to ensure proper insula-

WARNING

tion levels!
USE OF FORM-A AND SOLID-STATE RELAY OUTPUTS IN HIGH IMPEDANCE CIRCUITS

For form-A and solid-state relay output contacts internally equipped with a voltage measuring cIrcuit across the

NOTE

contact, the circuit has an impedance that can cause a problem when used in conjunction with external high input
impedance monitoring equipment such as modern relay test set trigger circuits. These monitoring circuits may con­tinue to read the form-A contact as being closed after it has closed and subsequently opened, w hen measured as
an impedance.

The solution to this problem is to use the voltage measuring trigger input of the relay test set, and connect the form-

3

A contact through a voltage-dropping resistor to a DC voltage source. If the 48 V DC output of the power supply is
used as a source, a 500 Ω, 10 W resisto r is appropriate. In this configuration , the voltage across either the fo rm-A
contact or the resistor can be used to monitor the state of the output.

Wherever a tilde “~” symbol appears, substitute with the slot position of the mo dule; wherever a number
sign "#" appears, substitute the contact number

NOTE

When current monitoring is used to seal-in the form-A and solid-state relay contact outputs, the Flex­Logic™ operand driving the contact output should be given a reset delay o f 10 ms to prevent damage of

NOTE

the output contact (in situations when the element initiating the contact output is bouncing, at values in the
region of the pickup value).

Table 3–2: DIGITAL INPUT/OUTPUT MODULE ASSIGNMENTS

~6A MODULE ~6B MODULE ~6C MODULE ~6D MODULE

TERMINAL

ASSIGNMENT

~1 Form-A ~1 Form-A ~1 Form-C ~1a, ~1c 2 Inputs
~2 Form-A ~2 Form-A ~2 Form-C ~2a, ~2c 2 Inputs
~3 Form-C ~3 Form-C ~3 Form-C ~3a, ~3c 2 Inputs

~4 Form-C ~4 Form-C ~4 Form-C ~4a, ~4c 2 Inputs
~5a, ~5c 2 Inputs ~5 Form-C ~5 Form-C ~5a, ~5c 2 Inputs
~6a, ~6c 2 Inputs ~6 Form-C ~6 Form-C ~6a, ~6c 2 Inputs
~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs ~7 Form-C ~7a, ~7c 2 Inputs
~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs ~8 Form-C ~8a, ~8c 2 Inputs

TERMINAL

ASSIGNMENT

~1Form-C ~1 Fast Form-C ~1Form-A ~1Form-A

~2Form-C ~2 Fast Form-C ~2Form-A ~2Form-A

~3Form-C ~3 Fast Form-C ~3Form-A ~3Form-A

~4Form-C ~4 Fast Form-C ~4Form-A ~4Form-A
~5a, ~5c 2 Inputs ~5 Fast Form-C ~5a, ~5
~6a, ~6c 2 Inputs ~6 Fast Form-C ~6a, ~6c 2 Inputs ~6 Form-A
~7a, ~7c 2 Inputs ~7 Fast Form-C ~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs
~8a, ~8c 2 Inputs ~8 Fast Form-C ~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs

OUTPUT OR

INPUT

~6E MODULE ~ 6F MODULE ~6G MODULE ~6H MODULE

OUTPUT OR

INPUT

TERMINAL

ASSIGNMENT

TERMINAL

ASSIGNMENT

OUTPUT OR

INPUT

OUTPUT TERMINAL

TERMINAL

ASSIGNMENT

ASSIGNMENT

OUTPUT TERMINAL

OUTPUT OR

INPUT

c 2 Inputs ~5 Form-A

ASSIGNMENT

TERMINAL

ASSIGNMENT

OUTPUT

OUTPUT OR

INPUT

3-16 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.2 WIRING

~6K MODULE ~6L MODULE ~6M MODULE ~6N MODULE

TERMINAL

ASSIGNMENT

~1 Form-C ~1Form-A ~1Form-A ~1Form-A
~2 Form-C ~2Form-A ~2Form-A ~2Form-A
~3 Form-C ~3Form-C ~3Form-C ~3Form-A
~4 Form-C ~4Form-C ~4Form-C ~4Form-A
~5 Fast Form-C ~5a, ~5c 2 Inputs ~5Form-C ~5a, ~5c 2 Inputs
~6 Fast Form-C ~6a, ~6c 2 Inputs ~6Form-C ~6a, ~6c 2 Inputs
~7 Fast Form-C ~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs
~8 Fast Form-C ~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs

~6P MODULE ~6R MODULE ~6S MODULE ~6T MODULE

TERMINAL

ASSIGNMENT

~1 Form-A ~1Form-A ~1Form-A ~1Form-A
~2 Form-A ~2Form-A ~2Form-A ~2Form-A
~3 Form-A ~3Form-C ~3Form-C ~3Form-A
~4 Form-A ~4Form-C ~4Form-C ~4Form-A
~5 Form-A ~5a, ~5c 2 Inputs ~5Form-C ~5a, ~5c 2 Inputs
~6 Form-A ~6a, ~6c 2 Inputs ~6Form-C ~6a, ~6c 2 Inputs

~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs
~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs

OUTPUT TERMINAL

OUTPUT OR

INPUT

ASSIGNMENT

TERMINAL

ASSIGNMENT

OUTPUT OR

INPUT

OUTPUT OR

INPUT

TERMINAL

ASSIGNMENT

TERMINAL

ASSIGNMENT

OUTPUT OR

INPUT

OUTPUT OR

INPUT

TERMINAL

ASSIGNMENT

TERMINAL

ASSIGNMENT

OUTPUT OR

INPUT

OUTPUT OR

INPUT

3

~6U MODULE ~67 MODULE ~4A MODULE ~4B MODULE

TERMINAL

ASSIGNMENT

~1 Form-A ~1Form-A ~1Not Used ~1Not Used
~2 Form-A ~2Form-A ~2 Solid-State ~2 Solid-State
~3 Form-A ~3Form-A ~3Not Used ~3Not Used
~4 Form-A ~4Form-A ~4 Solid-State ~4 Solid-State
~5 Form-A ~5Form-A ~5Not Used ~5Not Used
~6 Form-A ~6Form-A ~6 Solid-State ~6 Solid-State

~7a, ~7c 2 Inputs ~7Form-A ~7Not Used ~7Not Used
~8a, ~8c 2 Inputs ~8Form-A ~8 Solid-State ~8 Solid-State

TERMINAL

ASSIGNMENT

~1 Not Used ~1a, ~1c 2 Inputs ~1 2 Out puts
~2 Solid-State ~2a, ~2c 2 Inputs ~2 2 Outputs
~3 Not Used ~3a, ~3c 2 Inputs ~3 2 Out puts
~4 Solid-State ~4a, ~4c 2 Inputs ~4 2 Outputs
~5 Not Used ~5a, ~5c 2 Inputs ~5 2 Out puts
~6 Solid-State ~6a, ~6c 2 Inputs ~6 2 Outputs
~7 Not Used ~7a, ~7c 2 Inputs ~7 2 Outputs
~8 Solid-State ~8a, ~8c 2 Inputs ~8Not Used

OUTPUT OR

INPUT

~4C MODULE ~4D MODULE ~4L MODULE

OUTPUT TERMINAL

TERMINAL

ASSIGNMENT

ASSIGNMENT

OUTPUT TERMINAL

OUTPUT TERMINAL

ASSIGNMENT

ASSIGNMENT

OUTPUT TERMINAL

OUTPUT

ASSIGNMENT

OUTPUT

GE Multilin F60 Feeder Protection System 3-17

3

3.2 WIRING 3 HARDWARE

842762A2.CDR

Figure 3–19: DIGITAL INPUT/OUTPUT MODULE WIRING (1 of 2)

3-18 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.2 WIRING

3

Figure 3–20: DIGITAL INPUT/OUTPUT MODULE WIRING (2 of 2)

CORRECT POLARITY MUST BE OBSERVED FOR ALL CONTACT INPUT AND SOLID STATE OUTPUT CON-

CAUTION

GE Multilin F60 Feeder Protection System 3-19

NECTIONS FOR PROPER FUNCTIONALITY.

3.2 WIRING 3 HARDWARE

NOT

CONTACT INPUTS:

A dry contact has one side connected to terminal B3b. This is the positive 48 V DC voltage rail supplied by the p ower sup­ply module. The other side of the dry contact is co nnected to the required contact input terminal. Each contact input group
has its own common (negative) terminal which must be connected to the DC negative terminal (B3a) of the power supply
module. When a dry contact closes, a current of 1 to 3 mA will flow through the associated circuit.

A wet contact has one side connected to the positive terminal of an external DC power supply. The other side of this contact
is connected to the required contact input terminal. If a wet contact is used, then the negative side of the external source
must be connected to the relay common (negative) terminal of each contact group. The maximum external source vol tage
for this arrangement is 300 V DC.

The voltage threshold at which each group of four contact inputs will detect a closed contact input is programmable as
17 V DC for 24 V sources, 33 V DC for 48 V sources, 84 V DC for 110 to 125 V sources, and 166 V DC for 250 V sources.

3

DIGITAL I/O 6B

+

7a

~
~7c
~

8a

~

8c

~

7b

~

8b

1bB
1a

B

2b

B

3a -

B

3b +

B

5b HI+

B

6b LO+

B

6a

B

8a

B

8b

B

CONTACT IN 7a

+

CONTACT IN 7c

+

CONTACT IN 8a

+

CONTACT IN 8c

-

COMMON 7b

CRITICAL

FAILURE

OUTPUT

CONTROL

-

SURGE

48 VDC

POWER

SURGE
FILTER

~
~
~
~
~

24-250V

POWER SUPPLY 1

(Wet)(Dry)

DIGITAL I/O 6B
~

7a

~

7c

~

8a

~

8c

~

7b

~

8b

+

CONTACT IN 7a

+

CONTACT IN 7c

+

CONTACT IN 8a

+

CONTACT IN 8c

-

COMMON 7b

SURGE

827741A4.CDR

~
~
~
~
~

Figure 3–21: DRY AND WET CONTACT INPUT CONNECTIONS

Wherever a tilde “~” symbol appears, substitute with the slot position of the module.

Contact outputs may be ordered as form-a or form-C. The form-A contacts may be connected for external circuit supervi­sion. These contacts are provided with voltage and current monitoring circuits used to detect the loss of DC voltage in the
circuit, and the presence of DC current flowing through the contacts when the form-A contact closes. If enabled, the current
monitoring can be used as a seal-in signal to ensure that the form-A contact does not attempt to break the energized induc­tive coil circuit and weld the output contacts.

There is no provision in the relay to detect a DC ground fau lt on 48 V DC control power external output. We
recommend using an external DC supply.

E

3-20 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.2 WIRING

USE OF CONTACT INPUTS WITH AUTO-BURNISHING:

The contact inputs sense a change of the state of the external device contact based on the measured current. When exter­nal devices are located in a harsh industrial environment (either outdoor or indoor), their contacts can be exposed to vari­ous types of contamination. Normally, there is a thin film of insulating sulfidation, oxidation, or contaminates on the surface
of the contacts, sometimes making it difficult or impossible to detect a change of the state. This film must be removed to
establish circuit continuity – an impulse of higher than normal current can accomplish this.

The contact inputs with auto-burnish create a high current impulse when the threshold is reached to burn off this oxidation
layer as a maintenance to the contacts. Afterwards the contact input current is reduced to a steady-state current. The
impulse will have a 5 second delay after a contact input changes state.

current

50 to 70 mA

3 mA

time

3

25 to 50 ms

842749A1.CDR

Figure 3–22: CURRENT THROUGH CONTACT INPUTS WITH AUTO-BURNISHING

Regular contact inputs limit current to less than 3 mA to reduce station battery burden. In contrast, contact inputs with auto­burnishing allow currents up to 50 to 70 mA at the first instance when the change of state was sensed. Then, within 25 to
50 ms, this current is slowly reduced to 3 mA as indicated above. The 50 to 70 mA peak current burns any film on the con­tacts, allowing for proper sensing of state changes. If the external device contact is bouncing, the auto-burnishing starts
when external device contact bouncing is over.

Another important difference between the auto-burnishing input module and the regular input modules is that only two con­tact inputs have common ground, as opposed to four contact inputs sharing one common ground (refe r to the Digital Input/
Output Module Wiring diagrams). This is beneficial when connecting c ontact inputs to separate voltage sources. Conse­quently, the threshold voltage setting is also defined per group of two contact inputs.

The auto-burnish feature can be disabled or enabled usi ng the DIP switches found on each daughter card. Th ere is a DIP
switch for each contact, for a total of 16 inputs.

CONTACT INPUT 1 AUTO-BURNISH = OFF

CONTACT INPUT 1 AUTO-BURNISH
CONTACT INPUT 2 AUTO-BURNISH

CONTACT INPUT 1 AUTO-BURNISH
CONTACT INPUT 2 AUTO-BURNISH

= OFFCONTACT INPUT 2 AUTO-BURNISH

= ON
= OFF

= OFF
= ON

CONTACT INPUT 1 AUTO-BURNISH
CONTACT INPUT 2 AUTO-BURNISH

842751A1.CDR

= ON
= ON

Figure 3–23: AUTO-BURNISH DIP SWITCHES

The auto-burnish circuitry has an internal fuse for safety purposes. During re gular maintenance, the auto-burnish
functionality can be checked using an oscilloscope.

GE Multilin F60 Feeder Protection System 3-21

3.2 WIRING 3 HARDWARE

NOT

3.2.6 TRANSDUCER INPUTS/OUTPUTS

Transducer input modules can receive input signals from external dcmA output transducers (dcmA In) or resistance tem­perature detectors (RTD). Hardware and software is provided to receive signals from these external transducers and con­vert these signals into a digital format for use as required.

Transducer output modules provide DC current outputs in several standard dcmA ranges. Software is provided to configure
virtually any analog quantity used in the relay to drive the analog outputs.

Every transducer input/output module has a total of 24 terminal connections. These connections are arranged as three ter­minals per row with a total of eight rows. A given row may be used for either inputs or outputs, with terminals in column "a"
having positive polarity and terminals in column "c" having negative po larity. Since an entire row is used for a single input/
output channel, the name of the channel is assigned using the module slot position and row number.

Each module also requires that a connection from an extern al ground bus be made to terminal 8b. The current outputs
require a twisted-pair shielded cable, where the shield is grounded a t one end only. The figure below illustrates the trans-

3

ducer module types (5A, 5C, 5D, 5E, and 5F) and channel arrangements that may be ordered for the relay.

Wherever a tilde “~” symbol appears, substitute with the slot position of the module.

E

Figure 3–24: TRANSDUCER INPUT/OUTPUT MODULE WIRING

3-22 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.2 WIRING

3.2.7 RS232 FACEPLATE PORT

A 9-pin RS232C serial port is located on the F60 faceplate for programming with a personal computer. All that is required to
use this interface is a personal computer running the EnerVista UR Setup software provided with the rel ay. Cabling for the
RS232 port is shown in the following figure for both 9-pin and 25-pin connectors.

The baud rate for this port is fixed at 19200 bps.

NOTE

3

Figure 3–25: RS232 FACEPLATE PORT CONNECTION

3.2.8 CPU COMMUNICATION PORTS

a) OPTIONS

In addition to the faceplate RS232 port, the F60 provides two additional communication ports or a managed six-port Ether­net switch, depending on the installed CPU module.

The CPU modules do not require a surge ground connection.

NOTE

Table 3–3: CPU MODULE COMMUNICATIONS

CPU TYPE COM1 COM2

9E RS485 RS485
9G 10Base-F and 10Base-T RS485
9H Redundant 10Base-F RS485
9J 100Base-FX RS485
9K Redundant 100Base-FX RS485
9L 100Base-FX RS485
9M Redundant 100Base-FX RS485
9N 10/100Base-T RS485
9P 100Base-FX RS485
9R Redundant 100Base-FX RS485
9S Ethernet switch module with two 10/100Base-T and four 100Base-FX ports RS485

GE Multilin F60 Feeder Protection System 3-23

3.2 WIRING 3 HARDWARE

3

Ground at

remote

device

Ground at

remote
device

Ground at

remote

device

Ground at

remote

device

MM fiber

optic cable

MM fiber

optic cable

MM fiber

optic cable

Shielded twisted-pairs

Co-axial cable

Co-axial cable

Shielded twisted-pairs

Co-axial cable

Co-axial cable

Shielded
twisted-pairs

Co-axial cable

Co-axial cable

Co-axial cable

Co-axial cable

SM fiber

+

D1b
D2b
D3b
D1a
D2a
D3a
D4b
D4a

Tx1

10Base-FL

Rx1

10Base-T

D1a
D2a
D3a
D4b
D4a

Tx1

10Base-FL

Rx1

Tx2

10Base-F

Rx2

10Base-T

D1a
D2a
D3a
D4b
D4a

Tx1

100Base-FL

Rx1

D1a
D2a
D3a
D4b
D4a

—

COMMON

+

—

COMMON

+

—

BNC

BNC

+

—

COMMON

+

—

BNC

BNC

+

—

COMMON

+

—

BNC

BNC

+

—

COMMON

+

—

BNC

BNC

RS485
COM1

RS485
COM2

IRIG-B

input

IRIG-B output

NORMAL

RS485
COM2

IRIG-B

input

IRIG-B output

NORMAL

ALTERNATE

RS485
COM2

IRIG-B

input

IRIG-B output

COM1NORMAL

RS485
COM2

IRIG-B

input

IRIG-B output

COM1

COM1

CPU 9E

CPU 9G

9H

CPU

9J

CPU

Ground at

remote

device

Ground at

remote

device

Ground at

remote

device

Ground at

remote

device

optic cable

SM fiber optic cable

SM fiber

optic cable

Co-axial cable

Co-axial cable

Shielded twisted-pairs

Co-axial cable

Co-axial cable

Shielded
twisted-pairs

Co-axial cable

Co-axial cable

Shielded twisted-pairs

Co-axial cable

Co-axial cable

D1a
D2a
D3a
D4b
D4a

D1a
D2a
D3a
D4b
D4a

D1a
D2a
D3a
D4b
D4a

Tx1

Rx1

D1a
D2a
D3a
D4b
D4a

100Base-FL

+
—

COMMON

+
—

BNC

BNC

100Base-FL

100Base-F

+
—

COMMON

+
—

BNC

BNC

10/100Base-T

+
—

COMMON

+
—

BNC

BNC

100Base-FL

10/100Base-T

+
—

COMMON

+
—

BNC

BNC

RS485

COM2

IRIG-B

input

IRIG-B output

NORMAL

ALTERNATE

RS485

COM2

IRIG-B

input

IRIG-B output

NORMAL

RS485

COM2

IRIG-B

input

IRIG-B output

NORMAL

RS485

COM2

IRIG-B

input

IRIG-B output

COM1NORMAL

COM1

COM1

COM1

9L

CPU

9M

CPU

9N

CPU

9P

CPU

Tx1

Rx1

Tx2

Rx2

D1a
D2a
D3a
D4b
D4a

100Base-FL

100Base-F

10/100Base-T

+
—

COMMON

+
—

BNC

BNC

NORMAL

ALTERNATE

RS485

COM2

IRIG-B

input

IRIG-B output

842765A5.CDR

9R

COM1

CPU

Ground at

remote

device

MM fiber optic cable

MM fiber optic cable

MM fiber optic cable

MM fiber optic cable

MM fiber optic cable

100Base-T cable

100Base-T cable

110 to 250 V DC
100 to 240 V AC

Shielded twisted-pairs

Co-axial cable

Co-axial cable

+
–

Tx1

Tx2

Tx1

Tx2

Tx1

Tx1

D1a
D2a
D3a
D4b
D4a

W1a
W2b
W1a

100Base-FL

Rx1

100Base-F

Rx2

COMMON

BNC

BNC

100Base-FX

Rx1

100Base-FX

Rx2

100Base-FX

Rx1

100Base-FX

Rx1

10/100Base-T

10/100Base-T

GROUND

+

—

+

—

+

—

NORMAL

ALTERNATE

RS485
COM2

IRIG-B

input

IRIG-B output

Fiber
ports

Copper

ports

Power supply

COM1

SM fiber optic cable

Shielded
twisted-pairs

Ground at

remote

device

Co-axial cable

CPU 9K

Co-axial cable

CPU 9S

Figure 3–26: CPU MODULE COMMUNICATIONS WIRING

3-24 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.2 WIRING

b) RS485 PORTS

RS485 data transmission and reception are accomplished over a single twisted pair with transmit and receive data alternat­ing over the same two wires. Through the use of these ports, continuous monitoring and control from a remote computer,
SCADA system or PLC is possible.

To minimize errors from noise, the use of shielded twisted pair wire is recommended. Correct polarity must also be
observed. For instance, the relays must be connected with all RS485 “+” terminals connected togeth er, and all RS485 “–”
terminals connected together. The COM terminal should be connected to the common wire inside th e shield, when pro­vided. To avoid loop currents, the shield should be grounded at one point only. Each relay should also be daisy chained to
the next one in the link. A maximum of 32 relays can be connected in this manner without exceeding driver capability. For
larger systems, additional serial channels must be added. It is also possible to use commercially available repeaters to
increase the number of relays on a single channel to more than 32. Star or stub connections should be avoided entirely.

Lightning strikes and ground surge currents can cause large mo mentary voltage differences between remote ends of the
communication link. For this reason, surge protection devices are internally provided at both communi cation ports. An iso­lated power supply with an optocoupled data interface also acts to reduce noise coupling. To ensure maximum reliability, all
equipment should have similar transient protection devices installed.

Both ends of the RS485 circuit should also be terminated with an impedance as shown below.

3

Figure 3–27: RS485 SERIAL CONNECTION

GE Multilin F60 Feeder Protection System 3-25

3.2 WIRING 3 HARDWARE

c) 10BASE-FL AND 100BASE-FX FIBER OPTIC PORTS

ENSURE THE DUST COVERS ARE INSTALLED WHEN THE FIBER IS NOT IN USE. DIRTY OR SCRATCHED

CAUTION

CAUTION

The fiber optic communication ports allow for fast and efficient communications between relays at 10Mbps or 100 Mbps.
Optical fiber may be connected to the relay supporting a wavelength of 820 nm in multi-mode or 1310 nm in multi-mode
and single-mode. The 10 Mbps rate is available for CPU modules 9G and 9H; 100Mbps is available for modules 9H, 9J, 9K,
9L, 9M, 9N, 9P, and 9R. The 9H, 9K, 9M, and 9R modules have a second pair of identical optical fiber transmitter and
receiver for redundancy.

The optical fiber sizes supported include 50/125 µm, 62.5/125 µm and 100/140 µm for 10 Mbps. The fiber optic port is
designed such that the response times will not vary for any core that is 100 µm or less in di ameter, 62.5 µm for 100 Mbps.

3

For optical power budgeting, splices are required every 1 km for the transmitter/receiver pair. When splicing optical fibers,
the diameter and numerical aperture of each fiber must be the same. In order to engage or disengage the ST type connec­tor, only a quarter turn of the coupling is required.

CONNECTORS CAN LEAD TO HIGH LOSSES ON A FIBER LINK.
OBSERVING ANY FIBER TRANSMITTER OUTPUT MAY CAUSE INJURY TO THE EYE.

3-26 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.2 WIRING

3.2.9 IRIG-B

IRIG-B is a standard time code format that allows stamping of events to be synchronized among conne cted device s within
1 millisecond. The IRIG time code formats are serial, width-modulated codes which can be either DC level shifted or ampli­tude modulated (AM). Third party equipment is available for generating the IRIG-B signal ; this equipment may u se a GPS
satellite system to obtain the time reference so that devices at different geographic locations can also be synchronized.

GPS CONNECTION
OPTIONAL

GENERATOR

(DC SHIFT OR

AMPLITUDE MODULATED

SIGNAL CAN BE USED)

IRIG-B

TIME CODE

GPS SATELLITE SYSTEM

RG58/59 COAXIAL CABLE

+

-

TO OTHER DEVICES

(DC-SHIFT ONLY)

RELAY

IRIG-B(+)

4B

IRIG-B(-)

4A

BNC (IN)

BNC (OUT)

RECEIVER

REPEATER

827756A5.CDR

Figure 3–28: IRIG-B CONNECTION

The IRIG-B repeater provides an amplified DC-shift IRIG-B signal to other equipment. By using o ne IRIG-B serial connec­tion, several UR-series relays can be synchronized. The IRIG-B repeater has a bypass function to maintain the time signal
even when a relay in the series is powered down.

3

Figure 3–29: IRIG-B REPEATER

Using an amplitude modulated receiver will cause errors up to 1 ms in event time-stamping.

NOTE

GE Multilin F60 Feeder Protection System 3-27

3.3 DIRECT INPUT/OUTPUT COMMUNICATIONS 3 HARDWARE

3.3DIRECT INPUT/OUTPUT COMMUNICATIONS 3.3.1 DESCRIPTION

The F60 direct inputs and outputs feature makes use of the type 7 series of communications modules. These mod ules are
also used by the L90 Line Differential Relay for inter-relay communications. The direct input and output feature uses the
communications channels provided by these modules to exchange digital state information between relays. This feature is
available on all UR-series relay models except for the L90 Line Differential relay.

The communications channels are normally connected in a ring configuration as shown below. The transmitter of one mod­ule is connected to the receiver of the next module. The transmitter of this second module is then connected to the receiver
of the next module in the ring. This is continued to form a communications ring. The figure below illustrates a ring of four
UR-series relays with the following connections: UR1-Tx to UR2-Rx, UR2-Tx to UR3-Rx, UR3-Tx to UR4-Rx, and UR 4-Tx
to UR1-Rx. A maximum of sixteen (16) UR-series relays can be connected in a single ring

Tx

Rx

Tx

Rx

Tx

Rx

Tx

Rx

842006A1.CDR

3

UR #1

UR #2

UR #3

UR #4

Figure 3–30: DIRECT INPUT AND OUTPUT SINGLE CHANNEL CONNECTION

The interconnection for dual-channel Type 7 communications modules is shown below. Two channel modules allow for a
redundant ring configuration. That is, two rings can be created to provide an additional independent data path. The required
connections are: UR1-Tx1 to UR2-Rx1, UR2-Tx1 to UR3-Rx1, UR3-Tx1 to UR4-Rx1, and UR4-Tx1 to UR1-Rx1 for the first
ring; and UR1-Tx2 to UR4-Rx2, UR4-Tx2 to UR3-Rx2, UR3-Tx2 to UR2-Rx2, and UR 2-Tx2 to UR1-Rx2 for the second
ring.

Tx1

UR #1

UR #2

Rx1

Tx2

Rx2

Tx1

Rx1

Tx2

Rx2

Tx1

UR #3

UR #4

Rx1

Tx2

Rx2

Tx1

Rx1

Tx2

Rx2

842007A1.CDR

Figure 3–31: DIRECT INPUT AND OUTPUT DUAL CHANNEL CONNECTION

The following diagram shows the connection for three UR-se ries relays using two indepe ndent communication channels.
UR1 and UR3 have single type 7 communication modules; UR2 has a dual-channel module. The two communication chan­nels can be of different types, depending on the Type 7 modules used. To allow the direct input and output data to cross-
over from channel 1 to channel 2 on UR2, the

DIRECT I/O CHANNEL CROSSOVER setting should be “Enabled” on UR2. This

forces UR2 to forward messages received on Rx1 out Tx2, and messages received on Rx2 out Tx1.

3-28 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.3 DIRECT INPUT/OUTPUT COMMUNICATIONS

Tx1

Rx1

Tx2

Rx2

Tx

Rx

Channel #1

Channel #2

Tx

Rx

842013A1.CDR

UR #1

UR #2

UR #3

Figure 3–32: DIRECT INPUT AND OUTPUT SINGLE/DUAL CHANNEL COMBINATION CONNECTION

The interconnection requirements are described in further detail in this secti on for each specific variation of type 7 commu­nications module. These modules are listed in the following table. All fiber modules use ST type connectors.

Not all the direct input and output communications modules may be app licable to the F60 rel ay. Only the modules
specified in the order codes are available as direct input and output communications modules.

NOTE

Table 3–4: CHANNEL COMMUNICATION OPTIONS (Sheet 1 of 2)

MODULE SPECIFICATION

2A C37.94SM, 1300 nm, single-mode, ELED, 1 channel single-mode
2B C37.94SM, 1300 nm, single-mode, ELED, 2 channel single-mode
2E Bi-phase, 1 channel
2F Bi-phase, 2 channel
2G IEEE C37.94, 820 nm, 128 kbps, multi-mode, LED, 1 channel
2H IEEE C37.94, 820 nm, 128 kbps, multi-mode, LED, 2 channels
2S Six-port managed Ethernet switch with high voltage power supply
2T Six-port managed Ethernet switch with low voltage power supply
72 1550 nm, single-mode, laser, 1 channel
73 1550 nm, single-mode, laser, 2 channels
74 Channel 1 - RS422; channel 2 - 1550 nm, single-mode, laser
75 Channel 1 - G.703; channel 2 - 1550 nm, single-mode, laser
76 IEEE C37.94, 820 nm, 64 kbps, multi-mode, LED, 1 channel
77 IEEE C37.94, 820 nm, 64 kbps, multi-mode, LED, 2 channels
7A 820 nm, multi-mode, LED, 1 channel
7B 1300 nm, multi-mode, LED, 1 channel
7C 1300 nm, single-mode, ELED, 1 channel
7D 1300 nm, single-mode, laser, 1 channel
7E Channel 1: G.703, Channel 2: 820 nm, multi-mode
7F Channel 1: G.703, Channel 2: 1300 nm, multi-mode
7G Channel 1: G.703, Channel 2: 1300 nm, single-mode ELED
7H 820 nm, multi-mode, LED, 2 channels
7I 1300 nm, multi-mode, LED, 2 channels
7J 1300 nm, single-mode, ELED, 2 channels
7K 1300 nm, single-mode, LASER, 2 channels
7L Channel 1: RS422, channel: 820 nm, multi-mode, LED
7M Channel 1: RS422, channel 2: 1300 nm, multi-mode, LED

3

GE Multilin F60 Feeder Protection System 3-29

3.3 DIRECT INPUT/OUTPUT COMMUNICATIONS 3 HARDWARE

Table 3–4: CHANNEL COMMUNICATION OPTIONS (Sheet 2 of 2)

MODULE SPECIFICATION

7N Channel 1: RS422, channel 2: 1300 nm, single-mode, ELED
7P Channel 1: RS422, channel 2: 1300 nm, single-mode, laser
7Q Channel 1: G.703, channel 2: 1300 nm, single-mode, laser
7R G.703, 1 channel
7S G.703, 2 channels
7T RS422, 1 channel
7V RS422, 2 channels, 2 clock inputs
7W RS422, 2 channels

OBSERVING ANY FIBER TRANSMITTER OUTPUT MAY CAUSE INJURY TO THE EYE.

3

CAUTION

3.3.2 FIBER: LED AND ELED TRANSMITTERS

The following figure shows the configuration for the 7A, 7B, 7C, 7H, 7I, and 7J fiber-only modules.

Module: 7A / 7B / 7C 7H / 7I / 7J

Connection Location: Slot X Slot X

RX1 RX1

TX1 TX1

RX2

TX2

1 Channel 2 Channels

831719A2.CDR

Figure 3–33: LED AND ELED FIBER MODULES

3.3.3 FIBER-LASER TRANSMITTERS

The following figure shows the configuration for the 72, 73, 7D, and 7K fiber-laser module.

Module:

Connection Location:

72/ 7D
Slot X

TX1 TX1

RX1 RX1

73/ 7K
Slot X

TX2

RX2

1 Channel 2 Channels

831720A3.CDR

Figure 3–34: LASER FIBER MODULES

When using a laser Interface, attenuators may be necessary to ensure that you do not exceed the maxi­mum optical input power to the receiver.

WARNING

3-30 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.3 DIRECT INPUT/OUTPUT COMMUNICATIONS

3.3.4 G.703 INTERFACE

a) DESCRIPTION

The following figure shows the 64K ITU G.703 co-directional interface configuration.

The G.703 module is fixed at 64 kbps. The

SETTINGS Ö PRODUCT SETUP ÖØ DIRECT I/O ÖØ DIRECT I/O DATA RATE

setting is not applicable to this module.

AWG 24 twisted shielded pair is recommended for external connections, with the shield grounded only at one end. Con­necting the shield to pin X1a or X6a grounds the shield since these pins are internally connected to ground. Thus, if pin X1a
or X6a is used, do not ground at the other end. This interface module is protected by surge suppression devices.

7R

G.703

channel 1

Surge

G.703

channel 2

Inter-relay communications

Surge

Shield

Tx –

Rx –

Tx +

Rx +

Shield

Tx –

Rx –

Tx +

Rx +

1a

X

1b

X

2a

X

2b

X

3a

X

3b

X

6a

X

6b

X

7a

X

7b

X

8a

X

8b

X

842773A1.CDR

Figure 3–35: G.703 INTERFACE CONFIGURATION

The following figure shows the typical pin interconnectio n between two G.703 interfaces. For the actual physical arrange­ment of these pins, see the Rear terminal assignments section earlier in this chapter. All pin interconnections are to be
maintained for a connection to a multiplexer.

7R

G.703

CHANNEL 1

SURGE

G.703

CHANNEL 2

COMM.

SURGE

Shld.

Tx -

Rx -

Tx +

Rx +

Shld.

Tx -

Rx -

Tx +

Rx +

1a

X

1b

X

2a

X

2b

X

3a

X

3b

X

6a

X

6b

X

7a

X

7b

X

8a

X

8b

X

Shld.

1a

X

Tx -

1b

X

Rx -

2a

X

Tx +

2b

X

3a

Rx +

X

3b

X

Shld.

6a

X

6b

X

Rx -

7a

X

Tx +

7b

X

Rx +

8a

X

8b

X

Tx -

G.703

CHANNEL 1

SURGE

G.703

CHANNEL 2

SURGE

831727A2.CDR

7R

COMM.

Figure 3–36: TYPICAL PIN INTERCONNECTION BETWEEN TWO G.703 INTERFACES

Pin nomenclature may differ from one manufacturer to another. Therefore, it is not uncommon to see pin­outs numbered TxA, TxB, RxA and RxB. In such cases, it can be assumed that “A” is equivalent to “+” and

NOTE

“B” is equivalent to “–”.

3

b) G.703 SELECTION SWITCH PROCEDURES

1. Remove the G.703 module (7R or 7S). The ejector/inserter clips located at the top and at the botto m of each module,
must be pulled simultaneously in order to release the module for removal. Before performing this action, control
power must be removed from the relay. The original location of the module should be recorded to help ensure that
the same or replacement module is inserted into the correct slot.

2. Remove the module cover screw.

3. Remove the top cover by sliding it towards the rear and then lift it upwards.

4. Set the timing selection switches (channel 1, channel 2) to the desired timing modes.

5. Replace the top cover and the cover screw.

GE Multilin F60 Feeder Protection System 3-31

3.3 DIRECT INPUT/OUTPUT COMMUNICATIONS 3 HARDWARE

6. Re-insert the G.703 module. Take care to ensure that the correct module type is inserted into the correct slot position.
The ejector/inserter clips located at the top and at the bottom of ea ch module must be in the disengaged position as
the module is smoothly inserted into the slot. Once the clips have cleared the raised edge of the chassis, engage the
clips simultaneously. When the clips have locked into position, the module will be fully inserted.

3

Figure 3–37: G.703 TIMING SELECTION SWITCH SETTING

Table 3–5: G.703 TIMING SELECTIONS

SWITCHES FUNCTION

S1 OFF → octet timing disabled

S5 and S6 S5 = OFF and S6 = OFF → loop timing mode

c) G.703 OCTET TIMING

If octet timing is enabled (on), this 8 kHz signal will be asserted during the violation of bit 8 (LSB) necessary for connecting
to higher order systems. When F60s are connected back to back, octet timing should be disabled (off).

d) G.703 TIMING MODES

There are two timing modes for the G.703 module: internal timing mode and loop timing mode (default).

• Internal Timing Mode: The system clock is generated internally. Therefore, the G.703 timing selection should be in
the internal timing mode for back-to-back (UR-to-UR) conn ections. For back-to-back connections, set for octet timing
(S1 = OFF) and timing mode to internal timing (S5 = ON and S6 = OFF).

• Loop Timing Mode: The system clock is derived from the received line signal. Therefore, the G.703 timing selection
should be in loop timing mode for connections to higher order systems. For connection to a higher order system (UR­to-multiplexer, factory defaults), set to octet timing (S1 = ON) and set timing mode to loop timing (S5 = OFF and S6 =
OFF).

ON → octet timing 8 kHz

S5 = ON and S6 = OFF → internal timing mode
S5 = OFF and S6 = ON → minimum remote loopback mode
S5 = ON and S6 = ON → dual loopback mode

3-32 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.3 DIRECT INPUT/OUTPUT COMMUNICATIONS

The switch settings for the internal and loop timing modes are shown below:

842752A1.CDR

e) G.703 TEST MODES

In minimum remote loopback mode, the multiplexer is enabled to return the data from the external interface without any
processing to assist in diagnosing G.703 line-side problems irrespective of clock rate. Data enters from the G.703 inputs,
passes through the data stabilization latch which also restores the proper signal polarity, passes through the multiplexer
and then returns to the transmitter. The differential received data is processed and passed to the G.703 transmitter module
after which point the data is discarded. The G.703 receiver module is fully functional and continues to process data and
passes it to the differential Manchester transmitter module. Since timing is returned as it is received, the timing sour ce is
expected to be from the G.703 line side of the interface.

3

DMR

DMX

G7X

G7R

DMR = Differential Manchester Receiver
DMX = Differential Manchester Transmitter
G7X = G.703 Transmitter
G7R = G.703 Receiver

842774A1.CDR

Figure 3–38: G.703 MINIMUM REMOTE LOOPBACK MODE

In dual loopback mode, the multiplexers are active and the function s of the circuit are divide d into two with each receiver/
transmitter pair linked together to deconstruct and then reconstruct their re spective signals. Differential Manchester data
enters the Differential Manchester receiver module and then is returned to the differential Manchester transmitter module.
Likewise, G.703 data enters the G.703 receiver module and is passed through to the G.703 transmitter module to be
returned as G.703 data. Because of the complete split in the communicatio ns path and because, in each case, the clocks
are extracted and reconstructed with the outgoing data, in this mode there must be two independent sources of timing. One
source lies on the G.703 line side of the interface while the other lies on the differential Manchester side of the interface.

DMR

G7X

DMR = Differential Manchester Receiver
DMX = Differential Manchester Transmitter
G7X = G.703 Transmitter
G7R = G.703 Receiver

DMX

G7R

842775A1.CDR

Figure 3–39: G.703 DUAL LOOPBACK MODE

GE Multilin F60 Feeder Protection System 3-33

3.3 DIRECT INPUT/OUTPUT COMMUNICATIONS 3 HARDWARE

3.3.5 RS422 INTERFACE

a) DESCRIPTION

There are two RS422 inter-relay communications modules avai lable: singl e-chan nel RS4 22 (module 7T ) and dual -ch ann el
RS422 (module 7W). The modules can be configured to run at 64 kbps or 128 kbps. AWG 24 twisted shielded pair cable is
recommended for external connections. These modules are protected by optically-isolated surge suppression devices.

The shield pins (6a and 7b) are internally connected to the ground pin (8a). Proper shi eld termination is as follows:

• Site 1: Terminate shield to pins 6a or 7b or bo th.

• Site 2: Terminate shield to COM pin 2b.

The clock terminating impedance should match the impedance of the line.

3

Single-channel RS422 module

Tx –

3b

~

Rx –

3a

~

Tx +

2a

~

Rx +

4b

~

Shield

6a

~

7a

~

8b

~

COM

2b

~

8a

~

~ indicates the slot position

RS422

Clock

Surge

Dual-channel RS422 module

3b

~

3a

~

2a

~

4b

~

6a

~

5b

~

5a

~

4a

Inter-relay comms. 7T

~

6b

~

7b

~

7a

~

8b

~

2b

~

8a

~

Tx –

Rx –

Tx +

Rx +

Shield

Tx –

Rx –

Tx +

Rx +

Shield

COM

RS422

channel 1

RS422

channel 2

Clock

Surge

Inter-relay communications 7W

842776A3.CDR

Figure 3–40: RS422 INTERFACE CONNECTIONS

The following figure shows the typical pin interconnection between two single-channel RS422 interfaces installed in slot W.
All pin interconnections are to be maintained for a connection to a multiplexer.

Figure 3–41: TYPICAL PIN INTERCONNECTION BETWEEN TWO RS422 INTERFACES

b) TWO-CHANNEL APPLICATION VIA MULTIPLEXERS

The RS422 interface may be used for single channel or two channel applic ations over SONET/SDH or multiplexed sys­tems. When used in single-channel applications, the RS422 interface links to highe r order systems in a typical fashion
observing transmit (Tx), receive (Rx), and send timing (ST) connections. However, when used in two-channel applications,
certain criteria must be followed since there is one clock input for the two RS422 channels. The system will function cor­rectly if the following connections are observed and your data module has a terminal timing feature. Terminal timing is a
common feature to most synchronous data units that allows the module to accept timing from an external source. Using the
terminal timing feature, two channel applications can be achieved if th ese connections are follow ed: The send timing out­puts from the multiplexer (data module 1), will connect to the clock inputs of the UR–RS422 interface in the u sual fashion.
In addition, the send timing outputs of data module 1 will also be paralleled to the terminal timing inputs of data module 2.
By using this configuration, the timing for both data modules and both UR–RS422 cha nnels will be derived from a single
clock source. As a result, data sampling for both of the UR–RS422 channels will be synchronized via the send timing leads
on data module 1 as shown below. If the terminal timing feature is not available or this type of connection is not desired, the
G.703 interface is a viable option that does not impose timing restrictions.

3-34 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.3 DIRECT INPUT/OUTPUT COMMUNICATIONS

Data module 1

Signal name

SD(A) - Send data

SD(B) - Send data

RD(A) - Received data

RD(B) - Received data
RS(A) - Request to send (RTS)

RS(B) - Request to send (RTS)

RT(A) - Receive timing

RT(B) - Receive timing

CS(A) - Clear To send

CS(B) - Clear To send

Local loopback

Remote loopback

Signal ground

ST(A) - Send timing

ST(B) - Send timing

Data module 2

Signal name

TT(A) - Terminal timing

TT(B) - Terminal timing

SD(A) - Send data

SD(B) - Send data

RD(A) - Received data

RD(B) - Received data
RS(A) - Request to send (RTS)

RS(B) - Request to send (RTS)

CS(A) - Clear To send

CS(B) - Clear To send

Local loopback

Remote loopback

Signal ground

ST(A) - Send timing

ST(B) - Send timing

831022A3.CDR

7W

INTER-RELAY COMMUNICATIONS

RS422

CHANNEL 1

CLOCK

RS422

CHANNEL 2

SURGE

Tx1(+)

Tx1(-)

Rx1(+)

Rx1(-)

Shld.

Tx2(+)

Tx2(-)

Rx2(+)

Rx2(-)

Shld.

com

2a

W
W

3b

W

4b

W

3a

W

6a

+

7a

W

–

8b

W
W

4a

W

5b

W

6b

W

5a
7b

W

2b

W

8a

W

Figure 3–42: TIMING CONFIGURATION FOR RS422 TWO-CHANNEL, 3-TERMINAL APPLICATION

Data module 1 provides timing to the F60 RS422 interface via the ST(A) and ST(B) outputs. Data module 1 also provi des
timing to data module 2 TT(A) and TT(B) inputs via the ST(A) and AT(B) outputs. The dat a module pin numbers have been
omitted in the figure above since they may vary depending on the manufacturer.

3

c) TRANSMIT TIMING

The RS422 interface accepts one clock input for transmit timing. It is important that the rising edge of the 64 kHz transmit
timing clock of the multiplexer interface is sampling the data in the center of the transmit data window. Therefore, it is impor­tant to confirm clock and data transitions to ensure proper system operation. For example, the foll owing figure shows the
positive edge of the Tx clock in the center of the Tx data bit.

Tx Clock

Tx Data

Figure 3–43: CLOCK AND DATA TRANSITIONS

d) RECEIVE TIMING

The RS422 interface utilizes NRZI-MARK modulation code and; therefore, does not rely on an Rx clock to reca pture data.
NRZI-MARK is an edge-type, invertible, self-clocking code.

GE Multilin F60 Feeder Protection System 3-35

3.3 DIRECT INPUT/OUTPUT COMMUNICATIONS 3 HARDWARE

To recover the Rx clock from the data-stream, an integrated DPLL (digital phase lock loop) circuit is utilized. The DPLL is
driven by an internal clock, which is 16-times over-sampled, and uses this clock along with the data-stream to generate a
data clock that can be used as the SCC (serial communication controller) receive clock.

3.3.6 RS422 AND FIBER INTERFACE

The following figure shows the combined RS422 plus Fiber interface configuration at 64K baud. The 7L, 7M, 7N, 7P , and 74
modules are used in two-terminal with a redundant channel or three-te rminal configurations where channe l 1 is employed
via the RS422 interface (possibly with a multiplexer) and channel 2 via direct fiber.

AWG 24 twisted shielded pair is recommended for external RS422 connections and the shield should be grounded only at
one end. For the direct fiber channel, power budget issues should be addressed properly.

When using a LASER Interface, attenuators may b e nec essary to ens ure th at you do not e xce ed max imum

3

WARNING

optical input power to the receiver.

~
~
~
~
~
~
~
~

~

1a

1b

2b

2a

3a

3b

4b

6a

Tx2

8a

COM

Tx1 +

Rx1 –

Tx1 –

Rx1 +

Shield

Rx2

Clock

(channel 1)

RS422

channel 1

Fiber

channel 2

Surge

Inter-relay comms. 7L, 7M, 7N, 7P, 74

842777A1.CDR

Figure 3–44: RS422 AND FIBER INTERFACE CONNECTION

Connections shown above are for multiplexers configured as DCE (data communications equipment) units.

3.3.7 G.703 AND FIBER INTERFACE

The figure below shows the combined G.703 plus fiber interface configuration at 64 kbps. The 7E, 7F, 7G, 7Q, and 75 mod­ules are used in configurations where channel 1 is employed via the G.703 interface (possibly with a multiplexer) and chan­nel 2 via direct fiber. A WG 24 twisted shielded pair is recommended for external G.703 connections connecting the shield to
pin 1a at one end only. For the direct fiber channel, power budget issues should be addressed properly. See previous sec­tions for additional details on the G.703 and fiber interfaces.

When using a laser Interface, attenuators may be necessary to ensure that you do not exceed the maxi­mum optical input power to the receiver.

WARNING

Shield

1a

~

Tx –

1b

~
~
~
~
~

2a

2b

3a

3b

Tx2

Rx –

Tx +

Rx +

Rx2

G.703

channel 1

Surge

Fiber

channel 2

842778A1.CDR

7Q,75

7E, 7F, 7G,

Inter-relay

communications

Figure 3–45: G.703 AND FIBER INTERFACE CONNECTION

3-36 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.3 DIRECT INPUT/OUTPUT COMMUNICATIONS

8

3.3.8 IEEE C37.94 INTERFACE

The UR-series IEEE C37.94 communication modules (modules types 2G, 2H, 76, and 77) are designed to interface with
IEEE C37.94 compliant digital multiplexers or an IEEE C37.94 compliant interface converter for use with direct input and
output applications for firmware revisions 3.30 and higher. The IEEE C37.94 standard defines a point-to-point optical link
for synchronous data between a multiplexer and a teleprotection device. This data is typically 64 kbps, but the standard
provides for speeds up to 64n kbps, where n = 1, 2,…, 12. The UR-series C37.94 communication modul es are either
64 kbps (with n fixed at 1) for 128 kbps (with n fixed at 2). The frame is a valid International Telecommunications Union
(ITU-T) recommended G.704 pattern from the standpoint of framing and data rate. The frame is 256 bits and is repeated at
a frame rate of 8000 Hz, with a resultant bit rate of 2048 kbps.

The specifications for the module are as follows:.

• IEEE standard: C37.94 for 1 × 64 kbps optical fiber interface (for 2G and 2H modules) or C37.94 for 2 × 64 kbps optical

fiber interface (for 76 and 77 modules).

• Fiber optic cable type: 50 mm or 62.5 mm core diameter optical fiber.

• Fiber optic mode: multi-mode.

• Fiber optic cable length: up to 2 km.

• Fiber optic connector: type ST.

• Wavelength: 830 ±40 nm.

• Connection: as per all fiber optic connections, a Tx to Rx connection is required.
The UR-series C37.94 communication module can be connected di rectl y to any compliant digital multiplexe r that supports

the IEEE C37.94 standard as shown below.

3

The UR-series C37.94 communication module can be connected to the electrical interface (G.703, RS422, or X.21) of a
non-compliant digital multiplexer via an optical-to-electrical interface converter that su pports the IEEE C37.94 standard, as
shown below.

The UR-series C37.94 communication module has six (6) switches that are used to set the clock configuration. The func­tions of these control switches is shown below.

42753A1.CDR

GE Multilin F60 Feeder Protection System 3-37

3.3 DIRECT INPUT/OUTPUT COMMUNICATIONS 3 HARDWARE

For the internal timing mode, the system clock is generated internally. therefore, the timing switch selection should be inter­nal timing for relay 1 and loop timed for relay 2. There must be only one timing source configured.

For the looped timing mode, the system clock is derived from the received line signal. Therefore, the timing selecti on
should be in loop timing mode for connections to higher order systems.

The IEEE C37.94 communications module cover removal procedure is as follows:

1. Remove the IEEE C37.94 module (type 2G, 2H, 76, or 77 module):
The ejector/inserter clips located at the top and at the bottom of each module, must be pul led simultaneously in order

to release the module for removal. Before performing this action, control power must be removed from the relay.
The original location of the module should be recorded to help ensure that the same or replacement module is inserted
into the correct slot.

2. Remove the module cover screw.

3. Remove the top cover by sliding it towards the rear and then lift it upwards.

3

4. Set the timing selection switches (channel 1, channel 2) to the desired timing modes (see description above).

5. Replace the top cover and the cover screw.

6. Re-insert the IEEE C37.94 module. Take care to ensure that the correct module type is inserted into the correct slot
position. The ejector/inserter clips located at the top and at the bottom of each module must be in the disengaged posi­tion as the module is smoothly inserted into the slot. Once the clips have cleared the raised edge of the chassis,
engage the clips simultaneously. When the clips have locked into position, the module will be fully inserted.

Figure 3–46: IEEE C37.94 TIMING SELECTION SWITCH SETTING

3-38 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.3 DIRECT INPUT/OUTPUT COMMUNICATIONS

3.3.9 C37.94SM INTERFACE

The UR-series C37.94SM communication modules (2A and 2B) are designed to interface with modified IEEE C37.94 com­pliant digital multiplexers or IEEE C37.94 compliant interface converters that have been converted from 820 nm multi-mode
fiber optics to 1300 nm ELED single-mode fiber optics. The IEEE C37.94 standard defines a point-to-point optical link for
synchronous data between a multiplexer and a teleprotection dev ice. This data is typically 64 kbps, but the standard pro­vides for speeds up to 64n kbps, where n = 1, 2,…, 12. The UR-series C37.94SM communication module is 64 kbps only
with n fixed at 1. The frame is a valid Internationa l Telecommunications Union (ITU-T) recommended G.704 pattern from
the standpoint of framing and data rate. The frame is 256 bits and is repeated at a frame rate of 8000 Hz, with a resultant bit
rate of 2048 kbps.

The specifications for the module are as follows:

• Emulated IEEE standard: emulates C37.94 for 1 × 64 kbps optical fiber interface (modules set to n = 1 or 64 kbps).

• Fiber optic cable type: 9/125 μm core diameter optical fiber.

• Fiber optic mode: single-mode, ELED compatible with HP HFBR-1315T transmitter and HP HFBR-2316T receiver.

• Fiber optic cable length: up to 10 km.

• Fiber optic connector: type ST.

• Wavelength: 1300 ±40 nm.

• Connection: as per all fiber optic connections, a Tx to Rx connection is required.
The UR-series C37.94SM communication module can be connected directly to any complia nt digital multiplexer that sup-

ports C37.94SM as shown below.

3

It can also can be connected directly to any other UR-series relay with a C37.94SM module as shown below.

The UR-series C37.94SM communication module has six (6) switches that are used to set the clock configuration. The
functions of these control switches is shown below.

842753A1.CDR

For the internal timing mode, the system clock is generated internally. Therefore, the timing switch selection should be
internal timing for relay 1 and loop timed for relay 2. There must be only one timing source configured.

GE Multilin F60 Feeder Protection System 3-39

3.3 DIRECT INPUT/OUTPUT COMMUNICATIONS 3 HARDWARE

For the looped timing mode, the system clock is derived from the received line signal. Therefore, the timing selecti on
should be in loop timing mode for connections to higher order systems.

The C37.94SM communications module cover removal procedure is as follows:

1. Remove the C37.94SM module (modules 2A or 2B):
The ejector/inserter clips located at the top and at the bottom of each module, must be pul led simultaneously in order

to release the module for removal. Before performing this action, control power must be removed from the relay.
The original location of the module should be recorded to help ensure that the same or replacement module is inserted
into the correct slot.

2. Remove the module cover screw.

3. Remove the top cover by sliding it towards the rear and then lift it upwards.

4. Set the timing selection switches (channel 1, channel 2) to the desired timing modes (see description above).

3

5. Replace the top cover and the cover screw.

6. Re-insert the C37.94SM module. Take care to ensure that the correct module type is inserted into the correct slot
position. The ejector/inserter clips located at the top and at the bottom of each module must be in the disengaged posi­tion as the module is smoothly inserted into the slot. Once the clips have cleared the raised edge of the chassis,
engage the clips simultaneously. When the clips have locked into position, the module will be fully inserted.

Figure 3–47: C37.94SM TIMING SELECTION SWITCH SETTING

3-40 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.4 MANAGED ETHERNET SWITCH MODULES

3.4MANAGED ETHERNET SWITCH MODULES 3.4.1 OVERVIEW

The type 2S and 2T embedded managed switch modules are supported by UR-series relays containing type 9S CPU mod­ules with revisions 5.5x and higher. The modules communicate to the F60 through an internal Ethernet port (referred to as
the UR port or port 7) and provide an additional six external Ethernet ports: two 10/100Base-T ports and four multimode ST
100Base-FX ports.

The Ethernet switch module should be powered up before or at the same time as the F60. Otherwise, the switch
module will not be detected on power up and the

NOTE

issued.

EQUIPMENT MISMATCH: ORDERCODE XXX self-test warning will be

3.4.2 MANAGED ETHERNET SWITCH MODULE HARDWARE

The type 2S and 2T managed Ethernet switch modules provide two 10/100Base-T and four multimode ST 100Base-FX
external Ethernet ports accessible through the rear of the module. In addition , a serial console port is accessible from the
front of the module (requires the front panel faceplate to be open).

The pin assignment for the console port signals is shown in the following table.

Table 3–6: CONSOLE PORT PIN ASSIGNMENT

PIN SIGNAL DESCRIPTION

1 CD Carrier detect (not used)
2 RXD Receive data (input)
3 TXD Transmit data (output)
4 N/A Not used
5 GND Signal ground
6 to 9 N/A Not used

Two 10/100Base-T
ports

3

Four 100Base-FX
multimode ports
with ST connectors

RS232

console port

FRONT VIEW

REAR VIEW

Independent power
supply. Options:

2S: high-voltage
2T: low-voltage

842867A2.CDR

Figure 3–48: MANAGED ETHERNET SWITCHES HARDWARE

GE Multilin F60 Feeder Protection System 3-41

3.4 MANAGED ETHERNET SWITCH MODULES 3 HARDWARE

3.4.3 MANAGED SWITCH LED INDICATORS

The 10/100Base-T and 100Base-FX ports have LED indicators to indicate the port status.
The 10/100Base-T ports have three LEDs to indicate connection speed, duplex mode, and link activity. The 100Base-FX

ports have one LED to indicate linkup and activity.

Connection speed indicator (OFF = 10 Mbps; ON = 100 Mbps)
Link indicator (ON = link active; FLASHING = activity)

Duplex mode indicator (OFF = half-duplex; ON = full-duplex)

3

Link indicator (ON = link active; FLASHING = activity)

842868A2.CDR

Figure 3–49: ETHERNET SWITCH LED INDICATORS

3.4.4 CONFIGURING THE MANAGED ETHERNET SWITCH MODULE

A suitable IP/gateway and subnet mask must be assigned to both the switch and the UR relay for correct operation. The
Switch has been shipped with a default IP address of 192.168.1.2 and a subnet mask of 255.255.255.0. Consu lt your net­work administrator to determine if the default IP address, subnet mask or default gateway needs to be modified.

Do not connect to network while configuring the switch module.

CAUTION

a) CONFIGURING THE SWITCH MODULE IP SETTINGS

In our example configuration of both the Switch’s IP address and subnet mask must b e changed to 3.94.247.229 and

255.255.252.0 respectively. The IP address, subnet mask and default gateway can be configured using either EnerVista

UR Setup software, the Switch’s Secure Web Management (SWM), or through the console port using CLI.

1. Select the Settings > Product Setup > Communications > Ethernet Switch > Configure IP menu item to open the
Ethernet switch configuration window.

3-42 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.4 MANAGED ETHERNET SWITCH MODULES

2. Enter “3.94.247.229” in the IP Address field and “255.255.252.0” in the Subnet Mask field, then click OK.

The software will send the new settings to the F60 and prompt as follows when complete.

3. Cycle power to the F60 and switch module to activate the new settings.

b) SAVING THE ETHERNET SWITCH SETTINGS TO A SETTINGS FILE

The F60 allows the settings information for the Ethernet switch module to be saved loca lly as a settings file. This file con­tains the advanced configuration details for the switch not contained within the standard F60 settings file.

This feature allows the switch module settings to be saved local ly before performing firmware upgrades. Saving settings
files is also highly recommended before making any change to the module configuration or creating new setting files.

The following procedure describes how to save local settings files for the Ethernet switch module.

1. Select the desired device from site tree in the online window.

2. Select the Settings > Product Setup > Communications > Ethernet Switch > Ethernet Switch Settings File >

Retreive Settings File item from the device settings tree.
The system will request the name and destination path for the settings file.

3

3. Enter an appropriate folder and file name and click Save.
All settings files will be saved as text files and the corresponding file extension automatically assi gned.

c) UPLOADING ETHERNET SWITCH SETTINGS FILES TO THE MODULE

The following procedure describes how to upload local settings files to the Ethernet switch module. It is highly recom­mended that the current settings are saved to a settings file before uploading a new settings file.

It is highly recommended to place the switch offline while transferring setting files to the switch. When transferring
settings files from one switch to another, the user must reconfigure the IP address.

NOTE

1. Select the desired device from site tree in the online window.

2. Select the Settings > Product Setup > Communications > Ethernet Switch > Ethernet Switch Settings File >

Transfer Settings File item from the device settings tree.

GE Multilin F60 Feeder Protection System 3-43

3.4 MANAGED ETHERNET SWITCH MODULES 3 HARDWARE

The system will request the name and destination path for the settings file.

3

3. Navigate to the folder containing the Ethernet switch settings file, select the file, then click Open.

The settings file will be transferred to the Ethernet switch and the settings uploaded to the device.

3.4.5 UPLOADING F60 SWITCH MODULE FIRMWARE

a) DESCRIPTION

This section describes the process for upgrading firmware on a UR-2S or UR-2T switch module.
There are several ways of updating firmware on a switch module:

• Using the EnerVista UR Set u p software.

• Serially using the F60 switch module console port.

• Using FTP or TFTP through the F60 switch module console port.

It is highly recommended to use the EnerVista UR Setup software to upgrade firmware on a F60 switch module.

Firmware upgrades using the serial port, TFTP, and FTP are described in detail in the switch module manual.

NOTE

b) SELECTING THE PROPER SWITCH FIRMWARE VERSION

The latest switch module firmware is available as a download from the GE Multilin web site. Use the following procedure to
determine the version of firmware currently installed on your switch

1. Log into the switch using the EnerVista web interface.

The default switch login ID is “manager” and the default password is “manager”.

NOTE

3-44 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.4 MANAGED ETHERNET SWITCH MODULES

The firmware version installed on the switch will appear on the lower left corner of the screen.

3

Version: 2.1 beta

2. Using the EnerVista UR Setup program, select the Settings > Product Setup > Communications > Ethernet Swi tch

> Firmware Upload menu item.

The following popup screen will appear warning that the settings will be lost when the firmware is upgraded.

It is highly recommended that you save the switch settings before upgrading the firmware.

NOTE

3. After saving the settings file, proceed with the firmware upload by selecting Yes to the above warning.

Another window will open, asking you to point to the location of the firmware file to be uploaded.

842869A1.CDR

GE Multilin F60 Feeder Protection System 3-45

3.4 MANAGED ETHERNET SWITCH MODULES 3 HARDWARE

4. Select the firmware file to be loaded on to the Switch, and select the Open option.

3

The following window will pop up, indicating that the firmware file transfer is in progress.

If the firmware load was successful, the following window will appear:

Note

The switch will automatically reboot after a successful firmware file transfer.

NOTE

5. Once the firmware has been successfully uploaded to the switch module, load the settings file using the procedure
described earlier.

3-46 F60 Feeder Protection System GE Multilin

3 HARDWARE 3.4 MANAGED ETHERNET SWITCH MODULES

3.4.6 ETHERNET SWITCH SELF-TEST ERRORS

The following table provides details about Ethernet module self-test errors.
Be sure to enable the

ETHERNET SWITCH FAIL setting in the PRODUCT SETUP ÖØ USER-PROGRAMMABLE SELF-TESTS menu

and the relevant PORT 1 EVENTS through PORT 6 EVENTS settings under the PRODUCT SETUP ÖØ COMMUNICATIONS ÖØ ETH-

ERNET SWITCH menu.

Table 3–7: ETHERNET SWITCH SELF-TEST ERRORS

ACTIVATION SETTING (SET
AS ENABLED)

ETHERNET SWITCH FAIL ETHERNET MODULE

PORT 1 EVENTS to PORT 6
EVENTS

No setting required; the F60
will read the state of a general
purpose input/output port on
the main CPU upon power-up
and create the error if there is a
conflict between the input/
output state and the order
code.

EVENT NAME EVENT CAUSE POSSIBLE CAUSES

OFFLINE

ETHERNET PORT 1
OFFLINE to ETHERNET
PORT 6 OFFLINE

EQUIPMENT
MISMATCH: Card XXX
Missing

No response has been
received from the Ethernet
module after five successive
polling attempts.

An active Ethernet port has
returned a FAILED status.

The F60 has not detected the
presence of the Ethernet
switch via the bus board.

• Loss of switch power.

• IP/gateway/subnet.

• Incompatibility between the CPU and
the switch module.

• UR port (port 7) configured incorrectly
or blocked

• Switch IP address assigned to another
device in the same network.

• Ethernet connection broken.

• An inactive port’s events have been
enabled.

The F60 failed to see the switch module
on power-up, because switch won’t
power up or is still powering up. To clear
the fault, cycle power to the F60.

3

GE Multilin F60 Feeder Protection System 3-47

3

3.4 MANAGED ETHERNET SWITCH MODULES 3 HARDWARE

3-48 F60 Feeder Protection System GE Multilin

4 HUMAN INTERFACES 4.1 ENERVISTA UR SETUP SOFTWARE INTERFACE

4 HUMAN INTERFACES 4.1ENERVISTA UR SETUP SOFTWARE INTERFACE 4.1.1 INTRODUCTION

The EnerVista UR Setup software provides a graphical user interface (GUI) as one of two human interfaces to a UR device.
The alternate human interface is implemented via the device’s faceplate keypad and display (refer to the Faceplate inter-
face section in this chapter).

The EnerVista UR Setup software provides a single facility to configure, monitor, maintain, and trouble-shoot the operation
of relay functions, connected over local or wide area communication networks. It can be used while disconnected (off-line)
or connected ( on-line) to a UR device. In off-line mode, settings files can be created for eventual downloading to the
device. In on-line mode, you can communicate with the device in real-time.

The EnerVista UR Setup software, provided with every F60 relay, can be run from any computer supporting Microsoft

®

95, 98, NT, 2000, ME, and XP. This chapter provides a summary of the basic EnerVista UR Setup software interface

dows
features. The EnerVista UR Setup Help File provides details for getting started and using the EnerVista UR Setup software
interface.

4.1.2 CREATING A SITE LIST

To start using the EnerVista UR Setup software, a site definition and device definition must first be created. See the EnerV­ista UR Setup Help File or refer to the Connecting EnerVista UR Setup with the F60 section in Chapter 1 for details.

4.1.3 ENERVISTA UR SETUP OVERVIEW

a) ENGAGING A DEVICE

The EnerVista UR Setup software may be used in on-line mode (relay connected) to directly communicate with the F60
relay. Communicating relays are organized and grouped by communication interfaces and into sites. Sites may contain any
number of relays selected from the UR-series of relays.

Win-

4

b) USING SETTINGS FILES

The EnerVista UR Setup software interface supports three ways of handling changes to relay settings:

• In off-line mode (relay disconnected) to create or edit relay settings files for later download to communicating relays.

• While connected to a communicating relay to directly modify any relay settin gs via relay data view windows, and then
save the settings to the relay.

• You can create/edit settings files and then write them to the relay while the interface is connected to the relay.

Settings files are organized on the basis of file names assigned by the user. A settings file contains data pertaining to the
following types of relay settings:

• Device definition

• Product setup

• System setup

• FlexLogic™

• Grouped elements

• Control elements

• Inputs/outputs

• Testing

Factory default values are supplied and can be restored after any changes.

c) CREATING AND EDITING FLEXLOGIC™

You can create or edit a FlexLogic™ equation in order to customize the relay. You can subsequently view the automatically
generated logic diagram.

GE Multilin F60 Feeder Protection System 4-1

4.1 ENERVISTA UR SETUP SOFTWARE INTERFACE 4 HUMAN INTERFACES

d) VIEWING ACTUAL VALUES

You can view real-time relay data such as input/output status and measured parameters.

e) VIEWING TRIGGERED EVENTS

While the interface is in either on-line or off-line mode, you can view and analyze data generated by tri ggered specified
parameters, via one of the following:

• Event Recorder facility: The event recorder captures contextual da ta associated with the last 1024 events, listed in
chronological order from most recent to oldest.

• Oscillography facility: The oscillography waveform traces and digital states are used to provide a visual display of
power system and relay operation data captured during specific triggered events.

f) FILE SUPPORT

• Execution: Any EnerVista UR Setup file which is double clicked or opened will launch the application, or provide focus
to the already opened application. If the file was a settings file (has a URS extension) which had been removed from
the Settings List tree menu, it will be added back to the Settings List tree menu.

• Drag and Drop: The Site List and Settings List control bar windows are each mutually a drag source and a drop target
for device-order-code-compatible files or individual menu items. Also, the Settings List control bar window and any

4

Windows Explorer directory folder are each mutually a file drag source and drop target.
New files which are dropped into the Settings List window are added to the tree which is automatically sorted alphabet-

ically with respect to settings file names. Files or individual menu items which are dropped in the selected device menu
in the Site List window will automatically be sent to the on-line communicating device.

g) FIRMWARE UPGRADES

The firmware of a F60 device can be upgraded, locally or remotely, via the EnerVista UR Setup software. The correspond­ing instructions are provided by the EnerVista UR Setup Help file under the topic “Upgrading Firmware”.

Modbus addresses assigned to firmware modules, features, settings, and corresponding data items (i.e. default
values, minimum/maximum values, data type, and item size) may change slightly from version to versio n of firm-

NOTE

ware. The addresses are rearranged when new features are added or existing features are enha nced or modified.

EEPROM DATA ERROR message displayed after upgrading/downgrading the firmware is a resettable, self-test

The
message intended to inform users that the Modbus addresses have changed with the upgraded firmware. This
message does not signal any problems when appearing after firmware upgrades.

4-2 F60 Feeder Protection System GE Multilin

4 HUMAN INTERFACES 4.1 ENERVISTA UR SETUP SOFTWARE INTERFACE

4.1.4 ENERVISTA UR SETUP MAIN WINDOW

The EnerVista UR Setup software main window supports the following primary display components:

1. Title bar which shows the pathname of the active data view.

2. Main window menu bar.

3. Main window tool bar.

4. Site list control bar window.

5. Settings list control bar window.

6. Device data view windows, with common tool bar.

7. Settings file data view windows, with common tool bar.

8. Workspace area with data view tabs.

9. Status bar.

10. Quick action hot links.

10

2

1

6

7

4

3

4

5

9

Figure 4–1: ENERVISTA UR SETUP SOFTWARE MAIN WINDOW

Extended EnerVista UR Setup Features

Setting file templates simplify the configuration and commissioning of multiple relays that protect similar assets. An exam­ple of this is a substation that has ten similar feeders protected by ten UR-series F60 relays.

GE Multilin F60 Feeder Protection System 4-3

8

4.1.5 SETTINGS TEMPLATES

842786A2.CDR

4.1 ENERVISTA UR SETUP SOFTWARE INTERFACE 4 HUMAN INTERFACES

In these situations, typically 90% or greater of the settings are identical betwe en all devices. The te mplates feature allows
engineers to configure and test these common settings, then lock them so they are not available to users. For example,
these locked down settings can be hidden from view for field engineers, allowing them to quickly identify an d concentrate
on the specific settings.

The remaining settings (typically 10% or less) can be specified as editable and be made available to field engineers install­ing the devices. These will be settings such as protection element pickup values and CT and VT ratios.

The settings template mode allows the user to define which setting s will be visible in EnerVista UR Setup. Settings tem­plates can be applied to both settings files (settings file templates) and online devices (online settings templates). The func­tionality is identical for both purposes.

The settings template feature requires that both the EnerVista UR Setup software and the F60 firmware are at ver­sions 5.40 or higher.

NOTE

a) ENABLING THE SETTINGS TEMPLATE

The settings file template feature is disabled by default. The following procedure describes how to enable the settings tem­plate for UR-series settings files.

1. Select a settings file from the offline window of the EnerVista UR Setup main screen.

2. Right-click on the selected device or settings file and select the Template Mode > Create Template option.

4

The settings file template is now enabled and the file tree displayed in light blue. The settings file is now in template editing
mode.

Alternatively, the settings template can also be applied to online settings. The following procedure describes this process.

1. Select an installed device from the online window of the EnerVista UR Setup main screen.

2. Right-click on the selected device and select the Template Mode > Create Template option.

The software will prompt for a template password. This password is required to use the template feature and must be
at least four characters in length.

3. Enter and re-enter the new password, then click OK to continue.

The online settings template is now enabled. The device is now in template editing mode.

b) EDITING THE SETTINGS TEMPLATE

The settings template editing feature allows the user to specify which settings are available for viewing and modification in
EnerVista UR Setup. By default, all settings except the FlexLogic™ equation editor settings are locked.

1. Select an installed device or a settings file from the tree menu on the left of the EnerV i sta UR Setup main screen.

2. Select the Template Mode > Edit Template option to place the device in template editing mode.

3. Enter the template password then click OK.

4. Open the relevant settings windows that contain settings to be specified as viewable.

4-4 F60 Feeder Protection System GE Multilin
