En
USER MANUAL
G Series G2
A Series A735/A835/
A1030/A1230/
W1000/W1200
E Series E840s/E1035/
E1235/E1045W/
E1055W
GE-Digital Camera
i
This symbol [crossed-out wheeled bin WEEE Annex
IV] indicates separate collection of waste electrical
and electronic equipment in the EU countries.
Please do not throw the equipment into the domestic
refuse. Please use the return and collection systems
available in your country for the disposal of this product.
Declaration of Conformity
Model Name : G2/A735/A835/A1030/A1230/W1000/
W1200/E1045W/E1055W/E840s/E1035/E1235
Trade Name : GE
Responsible Party : General Imaging Co.
Address : 2158 W.190th Street, Torrance, CA 90504, USA
Telephone Number : 1-800-730-6597
Conforms to the following Standards:
EMC : EN 55022:1998/A1:2000/A2:2003 Class B
EN 55024:1998/A1:2001/A2:2003
EN 61000-3-2:2000/A1:2001
EN 61000-3-3:1995/A1:2001
following the provision of the EMC Directive
(89/336/EEC,2004/108/EEC)
WARNING
To prevent re or shock hazard, do not expose the unit
to rain or moisture.
For customers in the U.S.A.
Tested To Comply With FCC Standards
FOR HOME OR OFFICE USE
FCC Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
For customers in Europe
"CE" mark indicates that this product complies
with the European requirements for safety,
health, environment and customer protection. "CE"
mark cameras are intended for sales in Europe.
iiii 1
SAFETY PRECAUTIONS
Camera notes:
Do not store or use the camera in the following types
of locations:
• In the rain, very humid and dusty places.
• In a place where the camera can be exposed
directly to the sunlight or subject to high
temperature, e.g. Inside a closed car in summer.
• In a place where the camera is subject to a high
magnetic eld, e.g. near motors, transformers or
magnets.
Do not place the camera on a wet surface or places
where dripping water or sand may come in contact
with the camera, which may cause irrepairable faults.
If the camera will not be used for a long period of time, we
suggest you remove the battery and the memory card.
If you carry the camera suddenly from a cold location
to a warm place, moisture may condense inside the
camera. We suggest you wait for a while before turing
on the camera.
No compensation for loss of recordings. Loss of recordings cannot be compensated for if a malfunction
of your camera or recording media, etc, makes the
playback of recordings not possible.
Battery notes:
Incorrect use of the batteries may cause them to
leak, become hot, ignite or burst. Always observe the
precautions given below.
• Do not expose the batteries to water, and take
particular care to keep the terminals dry.
• Do not heat the batteries or throw them into a re.
• Do not attempt to deform, disassemble or modify the
batteries.
• Use GE charger in the package to charge the lithium
battery only (for G and E series).
Keep the batteries out of reach of babies and small children.
In cold locations, battery performance deteriorates and
the time for which they can be used shortens markedly.
Memory card notes:
When using a new memory card, or a memory card has
been initialized by a PC, be sure to format the card with
your digital camera before using it.
To edit image data, copy the image data to the PC's hard
disk and then format memory card if upgrade the rmware.
Do not change or delete the directory names, or le
names in the memory card from your PC, as this may
make it impossible to use the card in your camera.
BEFORE YOU START
Preface
Thank you for purchasing GE digital cameras. Please
read this manual carefully and keep it in a safe place for
future reference.
Copyright
© Copyright 2008 General Imaging Company All rights
reserved.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or
translated into any language or computer language,
in any form, by any means, without the prior written
permission of General Imaging Company.
Trademarks
All trademarks mentioned in this manual are used for
identication purposes only and may be properties of
their respective owners.
Safety information
Please read the following important information carefully before using the product.
• Do not take apart or attempt to service the camera
yourself.
• Do not drop or knock the camera. Improper handling
may damage the product.
• Turn o the camera before inserting or removing the
battery and memory card.
• Use only the type of battery and charger that came
with your camera. Using other types of batteries or
chargers may damage the camera and invalidate the
warranty.
• When using Li-ion batteries in this product, ensure
that they are inserted correctly. Inserting the batteries upside down can cause damage to the camera
and possibly start a re.
• Do not touch the camera lens.
2 3
• Do not expose the camera to moisture, or extreme
temperatures. Extreme environments may shorten
the life of your camera or damage the batteries.
• Do not use or store the camera in dusty, dirty, or
sandy areas, as its components may be damaged.
• Do not expose the lens to direct sunlight for extended
periods.
• Download all pictures and remove the batteries from
the camera if you are going to store the camera for
long periods.
• Do not use abrasive cleansers, alcohol-based, or
solvent-based cleaners to clean the camera. Wipe
the camera with a slightly damp soft cloth.
About this manual
This manual provides you with instructions on how
to use your GE digital camera. Every eort has been
made to ensure that the contents of this manual are
accurate, but General Imaging Company reserves the
right to make changes without notice.
Symbols used in this manual
Throughout this manual, the following symbols are
used to help you locate information quickly and easily.
Indicates the useful information to know.
Indicates the precautions to be taken while
operating the camera.
WARNING
SAFETY PRECAUTIONS
BEFORE YOU START .............................................1
Preface ..............................................................................1
Copyright ..................................................................1
Trademarks ..............................................................1
Safety information .........................................................1
About this manual ..........................................................2
Symbols used in this manual ...............................2
CONTENTS .............................................................3
GETTING READY ...................................................7
Unpacking ........................................................................7
Camera Views : G2 ..........................................................8
: A735/A835 ....................................... 10
: A1030/A1230/W1000/W1200 ...... 12
: E1045W/E1055W ............................ 14
: E840s ................................................. 16
: E1035/E1235 ................................... 18
Charging the battery .................................................. 20
Inserting the battery .................................................. 21
Inserting an optional SD/SDHC card ....................... 24
Turning on and o ....................................................... 25
Using the Mode Dial .................................................... 26
Setting date/time and language ............................. 27
Setting the Date and Time ................................. 27
Setting the Language ......................................... 28
About the LCD screen ................................................. 29
BASIC OPERATION .............................................30
Shooting in Auto mode ............................................... 30
Using the zoom function ............................................ 30
Using the ash ............................................................. 31
Using the self-timer .................................................... 31
Using Macro mode ...................................................... 32
CONTENTS
4
Exposure compensation ............................................ 32
Advanced function menu ........................................... 33
WB (White Balance) ............................................. 33
ISO ........................................................................... 34
Quality .................................................................... 35
Size .......................................................................... 36
Color ....................................................................... 37
USING THE MODES ............................................40
LCD Screen display ...................................................... 40
Still shooting mode display ............................... 40
Video shooting mode display ............................ 42
Playback mode display ....................................... 43
Scene mode................................................................... 44
Sport ....................................................................... 44
Children .................................................................. 44
Indoor ..................................................................... 44
Leaf ......................................................................... 44
Snow ....................................................................... 45
Sunset ..................................................................... 45
Fireworks ............................................................... 45
Glass ....................................................................... 45
Museum ................................................................. 45
Landscape ............................................................. 45
Night landscape ................................................... 45
Night portrait ....................................................... 45
Return to the scene mode palette ................... 46
Panorama mode .......................................................... 47
Image stabilization mode .......................................... 48
Face detection.............................................................. 50
Smile detection ............................................................50
Blink detection ............................................................. 50
PLAYBACK ...........................................................53
Viewing photos and videos ....................................... 53
Editing video ......................................................... 55
5
Thumbnail view ............................................................ 56
Using zoom playback (for still pictures only) ......... 57
Using the delete button ............................................. 58
USING THE MENUS ............................................59
Still menu ...................................................................... 59
AF mode (Auto-Focus mode) .............................. 60
AF-assist beam ..................................................... 60
Expo Metering (Exposure Metering).. ............... 60
Cont.Shot (Continuous shot) .............................. 61
Grid ......................................................................... 61
Quick Review ........................................................ 62
Digital Zoom .......................................................... 62
Histogram .............................................................. 63
Slow shutter .......................................................... 63
Blink detection ..................................................... 64
Date Imprint.......................................................... 64
Movie menu .................................................................. 65
Expo Metering (Exposure Metering).. ............... 66
Playback menu............................................................. 67
Protect .................................................................... 67
Delete ..................................................................... 68
DPOF (Digital Print Order Format) ................... 69
Info. Box (Information Box) ................................ 70
Trim ......................................................................... 70
Resize...................................................................... 71
Rotate ..................................................................... 71
Slide show .............................................................. 72
Red-eye removal .................................................. 73
Setup menu ................................................................... 74
Format Memory.................................................... 74
Beep ........................................................................ 75
LCD Brightness ..................................................... 76
Power Saver .......................................................... 76
Date/Time .............................................................. 77
World time ............................................................. 77
66 7
File Numbering ..................................................... 77
Language ............................................................... 78
Video system ......................................................... 78
Copy to Card (Copy internal
memory to memory card) .................................. 79
Reset Settings ....................................................... 79
FW Ver. (Firmware version)................................ 80
CONNECTIONS ...................................................81
Connecting to a TV ...................................................... 81
Connecting to a PC ...................................................... 81
Setting the USB mode ......................................... 82
Transferring les to your PC .............................. 82
Connecting to a PictBridge compatible printer .... 85
Setting the USB mode ......................................... 85
Connecting the camera and priter .................. 86
Using the PictBridge menu ........................................ 87
Print with date ...................................................... 87
Print without date ............................................... 88
Print index ............................................................. 89
Print DPOF ............................................................. 90
Exit .......................................................................... 90
Appendices .........................................................91
Specications:
G2 ................................................................... 91
A735/A835.................................................... 95
A1030/A1230/W1000/W1200 .................. 99
E1045W/E1055W ...................................... 103
E840s/E1035/E1235 ................................. 107
Error messages .......................................................... 112
Troubleshooting ........................................................ 114
GETTING READY
Your package should contain the camera model you purchased along with the following items. If anything is missing
or appears to be damaged, please contact your vendor. (The accessories will vary based on model purchased and are
noted below.)
Unpacking
Rechargeable Lithiumion battery (except
A735/A835 A1030/A1230/
W1000/W1200)
Battery charger (except
A735/A835/A1030/
A1230/W1000/W1200)
USB cable AV cable
CD-ROM
User Manual
User Ma
n
ual
Quick start guide
Warranty card
Wrist strap
AA-size alkaline
batteries X2 (A735/A835/
A1030/A1230/W1000/
W1200only)
8 9
Front View
Camera views : G2
Back View
Right View
1 2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Top View
Left View
1 Mic 13 Self-timer / Down button
2 Flash 14 Flash mode / Left button
3 Lens 15 Func / ok button
4 AF assist beam / Timer indicator 16 Speaker
5 LCD screen 17 Zoom scroll wheel
6 Status LED 18 Shutter button
7 Mode dial 19 Power button
8 Face detection AF button 20 Memory card / Battery compartment
9 Menu button 21 Tripod mount point
10 Erase button 22 USB / AV port
11 Exposure compensation / Up button 23 Wrist strap mount
12 Macro mode / Right button
Bottom View
19
17
18
20 21
22
23
10 11
Front View
Camera views : A735/A835
Back View
Right View
1 2
3
4
5
8
7
6
9
10
11
12
13
14
15
16
Top View
Left View
1 Flash 13 Self-timer / Down button
2 Lens 14 Func / ok button
3 Mic 15 Flash mode / Left button
4 AF assist beam / Timer indicator 16 USB / AV port
5 Status LED 17 Power button
6 LCD screen 18 Shutter button
7 Face detection AF button 19 Mode dial
8 T&W button 20 Speaker
9 Menu button 21 Tripod mount point
10 Erase button 22 Memory card / Battery compartment
11 Exposure compensation / Up button 23 Wrist strap mount
12 Macro mode / Right button
Bottom View
17
18
19
20
21
22
23
12 13
Front View
Camera views : A1030/A1230/W1000/W1200
Back View
Right View
1 2
3
4
megapixel
12.1
6
7
5
8
9
11
12
13
14
10
15
Top View
Left View
Bottom View
1 AF assist beam / Timer indicator 13 Self-timer / Down button
2 Flash 14 Flash mode / Left button
3 Lens 15 USB / AV port
4 Mic 16 Power button
5 LCD screen 17 Status LED
6 Face detection AF button 18 Shutter button
7 Zoom scroll wheel 19 Mode dial
8 Menu button 20 Tripod mount point
9 Erase button 21 Speaker
10 Func / ok button 22 Memory card / Battery compartment
11 Exposure compensation / Up button 23 Wrist strap mount
12 Macro mode / Right button
17
18
19
16
20
21
22
23
14 15
Front View
Camera views : E1045W/E1055W
Back View
Right
View
1
2
3 4
5 6 7
8
9
10
11
12
13
14
15
Top View
Left View
Bottom View
1 Flash 13 Self-timer / Down button
2 Mic 14 Flash mode / Left button
3 AF assist beam / Timer indicator 15 Func / ok button
4 Lens 16 Shutter button
5 LCD screen 17 Zoom scroll wheel
6 Status LED 18 Power button
7 Mode dial 19 Memory card / Battery compartment
8 Face detection AF button 20 Speaker
9 Menu button 21 Tripod mount point
10 Erase button 22 USB / AV port
11 Exposure compensation / Up button 23 Wrist strap mount
12 Macro mode / Right button
16 17 18
19 20 21
22
23
16 17
Front View
Camera views : E840s
Back View
Right View
1 2
3
4
5
7
6
8
9
10
11
12
13
14
15
16
Top View
Left View
Bottom View
1 Mic 13 Self-timer / Down button
2 Flash 14 Flash mode / Left button
3 AF assist beam / Timer indicator 15 Func / ok button
4 Lens 16 Speaker
5 LCD screen 17 Power button
6 Face detection AF button 18 Shutter button
7 Status LED 19 Zoom scroll wheel
8 Mode dial 20 Tripod mount point
9 Menu button 21 USB/ AV port
10 Erase button 22 Memory card / Battery compartment
11 Exposure compensation / Up button 23 Wrist strap mount
12 Macro mode / Right button
19
17
18
20 21
22
23
18 19
Front View
Camera views : E1035/E1235
Back View
Right View
megapix el
10.1
1 2
3
4
5
7
6
8
9
10
11
12
13
14
15
Top View
Left View
Bottom View
1 Flash 13 Self-timer / Down button
2 AF assist beam / Timer indicator 14 Func / ok button
3 Lens 15 Flash mode / Left button
4 Mic 16 Power button
5 LCD screen 17 Shutter button
6 Face detection AF button 18 Zoom scroll wheel
7 Status LED 19 Speaker
8 Mode dial 20 Tripod mount point
9 Menu button 21 USB / AV port
10 Erase button 22 Memory card / Battery compartment
11 Exposure compensation / Up button 23 Wrist strap mount
12 Macro mode/ Right button
W
T
16
17
18
19
20 21
22
23
20 21
1. Place the battery into the charger as shown.
2. Plug one end of the connecting cable into the charger
base.
3. Plug the other end of the connecting cable into a wall
outlet.
Charging the battery (except A735/A835/A1030/A1230/W1000/W1200)
Leave the battery to charge until the charger light
goes green.
(To maximize battery life, the rst charge should
be at least 4 hours)
Throughout the rest of the manual, the following
illustrations show theE1035 model as an
example.
(G2, A735, A835, A1030, A1230, W1000, W1200,
E1045W, E1055W, E840s, E1235 operate
similarly.)
1
2
Inserting the battery
1. Open the battery compartment. 2. Insert the battery while observing the correct
polarity. Use the side of battery to press down
the stopper as shown, allowing the battery to be
inserted properly.
22
3. Close the battery compartment.
Battery capacity decreases with usage.
1. Open the battery compartment.
Inserting the battery
(A735/A835/A1030/
A1230/W1000/W1200)
23
2. Insert the battery while observing the correct
polarity. Use the side of battery to press down the
stopper as shown, allowing the battery to be inserted
properly.
3. Close the battery compartment.
+
-
-
+
24 2524 25
Inserting an optional SD/SDHC card
1. Open the battery compartment. 2. Insert an optional SD/SDHC card into the memory
card slot as shown.
Optional SD/SDHC cards are not included. The use
of 64MB to 4GB memory cards from recognized
manufacturers such as SanDisk, Panasonic and
Toshiba is recommended for reliable data storage.
To remove the SD/SDHC card, open the battery compartment and gently push the card to release it. Pull
the card carefully.
Turning on and o
Press the Power button to turn the camera on. To turn
o the camera, press the Power button again.
W
T
Power button
When turned on, the camera will enter the mode according to the mode dial setting. You can also turn the
mode dial to change the modes after the camera is
turned on.
3. Close the battery compartment.
26 27
Using the Mode Dial
The GE camera provides a convenient mode dial that allows you to switch between dierent modes with ease. All the
available modes are listed as follows.
Mode Name Icon Description
Auto
Switch to take still pictures. (The camera uses the default programmed automatic
settings.)
Playback Switch to view the pictures/videos stored in the memory card and internal memory.
Movie Switch to record videos.
Image Stabilization
Switch to use Image Stabilization when taking still pictures.
Scene
Switch to use a preset scene mode for taking still pictures. There are 12 scenes in
total.
Portrait Switch to portrait mode when taking close-up portrait photos.
Panorama
Switch to capture a sequence of shots and stitch them together into a panoramic
photo.
Manual
Switch to take still pictures in manual mode, where many camera settings can be
congured. (Recommended for advanced users only)
Setting date/time and language
To set the language, date, and time, the following
settings need to be congured in the
Setup
menu.
• Date / Time
• Display language
To access the
Setup
menu, do the following:
1. Press
Power
to turn the camera on.
2. Press the
button and use
Up/Down/Left/
Right
to select the
Setup
menu.
Setting the Date and Time
1. Use the
Up/Down
to select
Date/Time
. Then press
the
Right
to enter the setting.
2828 29
2. Press the
Left/Right
to highlight each eld and use
the
Up/Down
to adjust the value.
3. Press the
button to conrm the setting.
Setting the Language
1. Use the
Up/Down
to select
Language
. Then press
the
Right
to enter the setting.
2. Use the navigation buttons to select the desired
language.
3. Press the
button to conrm the setting.
The Set date/time and language screen will
automatically appear when the camera is turned
on the rst time.
If the LCD monitor is damaged, take particular care
with the liquid crystal in the monitor. If any of the
following situations arise, take the urgent action
indicated.
• If liquid crystal comes in contact with your skin, wipe
the area with a cloth and then wash thoroughly with
soap and running water.
• If liquid crystal gets into your eye, ush the aected
eye with clean water for at least 15 minutes and
then seek medical assistance.
• If liquid crystal is swallowed, ush your mouth
thoroughly with water. Drink large quantities of
water and induce vomiting. Then seek medical
assistance.
About the LCD screen
When you turn the camera on, various icons are shown
on the LCD screen to indicate the current camera settings and status. To learn more about the displayed
icons, see “LCD Screen display” on page 40.
LCD Screen notes:
Extremely high-precision technology had been used to
manufacture the LCD screen so that most of the pixels
are operational for use. However, there may be some
minute points (black, white, red, blue or green) that
constantly appear on the LCD screen. These points are
normal in the manufacturing process and the recording
is not aected in any way.
30 3130 31
Shooting in Auto mode
Auto mode is the easiest mode to take photos. While
operating in this mode, the camera automatically
optimizes your photos for best results.
To start shooting, do the following:
1. Set the mode dial to
Auto mode ( ).
2. Press
Power to turn the camera on.
3. Compose your picture on the LCD screen and press
the shutter button halfway to focus on the subject.
4. When the subject is in focus, the green colored focus
frame appears on the center of the LCD screen.
5. Press
Shutter fully to capture the image.
Using the zoom function
BASIC OPERATION
Your camera is equipped with two types of zoom:
optical zoom and digital zoom. Use the Zoom scroll
wheel on the top of the camera to zoom in or out on
your subject while taking pictures.
Zoom Scroll wheel
W
T
W T
_
Zoom indicator
(See “Digital
Zoom“ on page
62)
When the optical zoom factor reaches its maximum
value, it stops momentarily. Keep the (Tele) zoom
button depressed and zoom will switch over to digital
zoom automatically.
Using the ash
There are six ash modes. Press the Left/Flash to
cycle through the following ash modes.
• Auto ash
Camera ash res automatically based on
existing light conditions.
• Red-eye reduction ash
The camera res a brief ash before the picture is taken to reduce red-eye eects.
• Forced ash
Flash always res.
• Flash o
Flash is turned o.
• Slow Synchro
This allows you to take pictures of people at
night that clearly show both your subjects and
the night time backdrop.
• Red-Eye Reduction+Slow Synchro
Use this mode for slow synchro shots with
red-eye reduction.
Using the self-timer/Multiple shots
To enable the self-timer function, press the Down/
Self-timer to select 2-second timer delay, 10-second
timer delay, or a continuous shot.
• 2-second timer delay
A single picture is shot 2 seconds after the
shutter button is pressed.
• 10-second timer delay
A single picture is shot 10 seconds after the
shutter button is pressed.
• Continuous shot
Pictures are shot continuously when the shutter button is pressed based on the Continuous
Shot settings in the menu. (See “Continuous
Shot” on page 61).
32 3332 33
Using Macro mode
In Macro mode, you can capture tiny details of the
subject at a very close range. Press the Right/Mac-
ro to take close-up shots.
• Macro
Select this to focus on subjects 5cm from the
lens.
Exposure compensation
The exposure compensation allows you to adjust the
background brightness to produce the best result of
photos. To change the exposure values, do the following:
1. When taking a picture, press the Up/Exposure button
to activate the set exposure screen.
2. Use the Left/Right to adjust the exposure value for
the picture. The range is from EV -2.0 to EV+2.0 (steps
of 0.3).
Advanced function menu (quick menu setup)
WB (White Balance)
The white balance allows the user to adjust the color
temperature under dierent light source to ensure faithful color reproduction.
(The WB setting is only available when the camera is in
the Manual mode).
To set the white balance, do the following:
1. Press the
button to enter the Function menu.
Make sure the WB function is selected.
2. Use Up/Down navigation buttons to select
the setting you want. The following options are
available:
• Auto
• Daylight
• Cloudy
• Fluorescent
• Fluorescent CWF
• Incandescent
• Manual WB adjustment (press the menu
button to set)
3. Use the
Left/Right buttons to select other options,
or press the button once to conrm your
selection and exit the current menu.
34
ISO
The ISO function allows you to set the camera sensor
sensitivity to light. To improve the performance in
darker environments, a higher ISO value is required.
On the other hand, a lower ISO value is needed when in
bright conditions.
(The ISO setting is only available when the camera is in
the Manual mode).
To set the ISO value, do the following:
1. Press the
button to enter the Function menu.
2. Use the
Left/Right navigation buttons to
highlight the ISO function.
Higher ISO pictures will naturally have more
noise than lower ISO pictures.
3. Use the Up/Down navigation buttons to select the
desired ISO value from Auto, 64, 80,100, 200,
400, 800, or 1600.
4. Press the
button to conrm your setting.
5. Use the Left/Right buttons to select other options,
or press the button once to conrm your selection and exit the current menu.
35
Quality
The quality setting adjusts the compression ratio of the
images. Higher quality settings give better photos, but
will take up more memory space.
To set the image quality, do the following:
1. Press the
button to enter the Function menu.
2. Use the
Left/Right navigation buttons to highlight
the Quality function.
3. Use the Up/Down navigation buttons to select a
desired setting. Three options are available.
• : Best quality (Standard compression)
• : Fine quality (High compression)
• : Normal quality (Maximum compression)
4. Press the
button to conrm your setting.
5. The number of available shots remaining is displayed
on the LCD.
6. Use the Left/Right buttons to select other options, or
press the button once to conrm your selection
and exit the current menu.
36
Size
The size setting refers to the image resolution in pixels.
A higher image resolution allows you to print that image
in larger sizes without degrading the image.
To set the image size, do the following:
1. Press the
button to enter the Function menu.
2. Use the
Left/Right navigation buttons to highlight
the Size function.
3. Use the Up/Down navigation buttons to select a
resolution.
4. Press the
button to conrm your setting.
5. The number of available shots is displayed on the
screen.
The bigger the number of recorded pixels is, the
better the image quality becomes. As the number
of recorded pixels becomes smaller, you will be
able to record more frames on a memory card.
Please refer to page 38 for a list of image sizes
that are available to the various GE digital camera
models.
37
Color
The color setting allows you to add artistic eects
directly when taking shots. You can try dierent color
tones to alter the mood of your pictures.
(The Color setting is only available when the camera is in
the Manual mode).
To set the image color, do the following:
1. Press the
button to enter the Function menu.
2. Use the
Left/Right navigation buttons to highlight
the Color function.
3. Use
Up/Down
to select an option. The following
options are available:
• Auto
• Black & White
• Sepia
• Vivid
4. Press the
button to conrm your setting.
38
• Size settings in shooting mode. (•: available)
Icon
File size
(Pixels)
Model name :
G2 A735 A835 A1030/
W1000
A1230/
W1200
E840s E1035 E1235
E1045W E1055W
0.3M:
640×480
• • • • • • • • • •
1M:
1024×768
• • • • • • • •
2M:
1600×1200
• • • • • • • •
3M:
2048×1536
• • • • • • • • • •
5M:
2560×1920
• • • • • • •
5M(16:9):
3072×1728
•
6M:
2816×2112
• •
6M(3:2):
3072×2048
•
6M(16:9):
3264×1836
• • •
39
Icon
File size
(Pixels)
Model name :
G2
A735 A835 A1030/
W1000
A1230/
W1200
E840s E1035 E1235 E1045W E1055W
7M:
3072×2304
•
7M(3:2):
3264×2176
• • •
7M(16:9):
3648×2052
• • • •
8M:
3264×2448
• • • • •
9M(3:2):
3648×2432
• • • •
9M(16:9):
4032×2268
• •
10M:
3648×2736
• • • •
10M(3:2):
4032×2688
• •
12M:
4032×3024
• •
40 41
LCD Screen display
USING THE MODES
Still shooting mode display
Mode:
10
1
13 14 15 16 17
9
11
12
2 3 4 5 6 7 8
19
18
20
1. Shooting mode icon
Auto Manual
Panorama
Portrait
Scene
Image Stabilization
2. Scene icon (only available for
Scene mode)
Sport
Fireworks
Children
Glass
Indoor
Museum
Leaf
Landscape
Snow
Night landscape
Sunset
Night portrait
3. Light metering method
Spot AE
Center-Weight
Ai AE
4. EV indicator
5. Self-timer indicator
2-second self-timer
10-second self-timer
Continuous shot
6. Macro mode indicator
Macro mode
7. Flash mode indicator
Auto ash
Red-eye reduction ash
Forced ash
Flash o
Slow Synchro
Red-Eye Reduction+Slow Synchro
8. Battery status
9. Face detection “on” indicator
10. Remaining number of photos that can be taken.
11. Focus frame
12. Zoom indicator
13. White balance (only available for
Manual mode)
14. ISO (only available for
Manual mode)
15. Image quality
16. Image size
17. Image color (only available for
Manual mode)
18. Slow shutter warning indicator
19.
Memory card/internal memory indicator
20. EV adjustment slider
42
Video shooting mode display
Mode :
1
11 12
7
9
13
8
10
2 3 4 5 6
1. Shooting mode icon
2. Light metering method
Spot AE
Center-Weight
Ai AE
3. EV indicator
4. Self-timer indicator
10-second self-timer
5. Macro mode indicator
Macro mode
6. Battery status
7. Movie recording “on” indicator
8. Remaining time for videos that can be taken.
9. Focus frame
10. Zoom indicator
11. Video resolution
12. Video quality
13. Memory card/built-in memory indicator
For best movie results, the use of SD cards is
recommended. Movie recordings using internal
memory are subject to quality degradations.
While movie recording is in progress, optical zoom
will stay xed, but up to 1.5X digital zoom will
remain available.
43
Playback mode display
Mode:
10
9
1 2 3 4 5 6 7 8
12
13
14
15
11
18 17 16
1. Playback mode icon
2. DPOF le icon
3. File protection icon
4. Audio le icon
5. Video le icon
6. Memory card/internal
memory indicator
7. Picture ID
8. Battery status
9.
Photo audio status
(Press the shutter button to
record sound)
(Press the shutter button to
play sound)
10.
Recording date and time
11.
Histogram
12.
Aperture value
13.
Shutter speed
14.
Exposure value
15.
Memory capacity
(current picture/total
picture number)
16.
ISO value
17.
WB
18.
Image size
44 45
In Scene mode, you can select from a total of 12 scene
types to match your needs. You just need to select the
right scene for the occasion and the camera will automatically adjust to the optimal settings for you.
To enter the scene mode, turn the mode dial to Scene
mode. The scene mode palette appears.
Use Up/Down/Left/Right to select a scene, and
press the button.
Sport
For shooting fast-moving objects. Bring lively pictures
to life.
Children
Suitable for photographing children and pets. The
ash shuts o automatically in order not to disturb the
subject being photographed.
Indoor
For shooting people indoors. Clearly show background
and atmosphere.
Leaf
For shooting plants. Vivid reproduction of green.
Snow
Suitable for snowy landscape. Camera automatically
adjusts and corrects exposure value (EV).
Scene mode (SCN)
Sunset
For shooting sunsets. Vivid reproduction of red and
yellow.
Fireworks
For shooting at night and reworks. Shutterspeed is
slower than normal.(Use of tripod is recommended)
Glass
Suitable for photographing objects behind glass or
window.
Museum
For shooting in museums or places where ash is not
allowed.
Landscape
For shooting landscapes. Vivid reproduction of green
and blue.
Night landscape
For shooting night scenes. Use of tripod is recommended.
Night portrait
For shooting portraits with night scenes as background.
46 47
Panorama mode
Returning to the Scene selection menu
1. In Scene mode, press the button to activate
the main function menu.
2. Select the “SCENE” menu option and then press the
button to return to the to Scene selection menu.
The main function menu also allows you congure image
quality and image size. Please refer to the "Advanced
Functions Menu" section on pages 33 for detailed
instructions.
Panorama mode allows you create a panoramic picture.
The camera will to automatically compose a panoramic
picture using the individual shots that you take.
Follow these steps to create a panoramic picture:
1. Set the mode dial to
Panorama mode ( ).
2. Use the Left/Right buttons to specify the direction
of picture taking, and then in 2 seconds the
panoramic sequence will commence automatically.
3. Compose your rst view on the LCD screen and
press the shutter button.
4. The frame record icon will display under the focus
frame to indicate the number of photos you have
taken.
5. Using the same steps for the rst shot, take the
second and the third shots. Compose your shots so
that the edges of the pictures overlap. The numeric
indicators on the LCD inform you which shot is being
taken.
6. The camera will then stitch the pictures into a
panorama automatically.
7. Turn the mode dial to playback mode to view the
panoramic picture.
For best results the use of a tripod is recommended.
While in panorama mode, press the button to
save images and exit panorama shooting. Press
the button to discard images and exit.
48 49
Image Stabilization mode
The stabilizer function is used for less blur picture
caused by hand shake under a dark environment, the
camera would increase the ISO level under the mode to
have a higher shutter speed.
This function may not help to take a clear picture
of a fast moving target, such as a car passing by,
etc.
This function may not help to stabilize photos if
you are in a moving vehicle (car, boat, etc.). It is
best used when taking normal shots.
The Image Stabilization mode combats the eect of
hand shake and allows you to take pictures that would
otherwise be blurred.
1. Switch the mode dial to ( ) mode.
2. Press
Shutter
halfway to focus on the subject.
3. Press
Shutter
fully to capture the image.
Increasing the ISO level may cause heavier noise on
the photo.
Use of a tripod is always best to get the clearest picture.
50 51
The Face Detection mode will detect faces of persons in
a photo so that the faces will be as clear as possible.
1. While in photography mode, press the
button to
activate Face Detection. The indicator appears
on the LCD.
2. Hold the camera securely, and point the camera
towards the subject to start the face detection
process. When the camera detects a face, a white
rectangular frame will be drawn around the face.
(Note: For best results, the face of the subject
should be relatively large on the LCD screen, and the
subject should be facing the camera as front on as
possible.)
3. Press
Shutter
halfway to focus on the subject.
4. Press
Shutter
fully to capture the image.
5. Press the
button again to deactivate face
detection.
Face Detection
Smile Detection
With the camera's new "smile detection"feature, which
automatically detects and captures a person smiling,
you'll never miss a smile.
1. While in shooting mode, press the
button
repeatedly until appears on the LCD. This icon
indicates that the camera is in Smile Detection mode.
2. Point the camera at the subject until the subject's
face is detected and bracketed by a square box. Press
the shutter button all the way down and release the
shutter button. The camera will now 'wait' for the
subject to smile.
3. When the subject smiles, the camera will automatically
release the shutter and capture the photo.
4. To disable the automatic shutter release, press the
shutter again .
Note:
• A face must be detected by the camera in order for
smile detection to function correctly.
• For optimal detection results, the subject should be
framed to occupy most of the screen space.
52 5352 53
Blink Detection
The Blink Detection feature is on by default, and after
taking each photo, a warning message will pop up if a
blink had been detected in the photo.
1. In photography modes, press the button
to
enter the Photo menu.
2. Use the Up/Down navigation buttons to select "Blink
detection" setting.
3. Use the Right navigation buttons to enter the
submenu, and select "On" option.
4. Press the button
to conrm the setting and exit
the menu.
5. The "Blink detection" indicator appears on the LCD.
6. Press the shutter button fully to capture the image, if
someone's eyes blink, the camera will automatically
show blink detection warning message.
Note:
• For optimal results, the subject should be framed to
occupy most of the screen space.
Viewing photos and videos
PLAYBACK
To view the captured photos and video clips on the LCD
screen:
1. Turn your camera to
Playback mode. The last
recorded photo or video clip is displayed.
2. Use the
Left/Right navigation buttons to scroll
through the photos or video clips stored in the
internal memory or memory card.
3. To play a selected video clip, press the
button to
enter the movie playback mode.
4. Use the
Left/Right navigation buttons to select
a program button and press the button to
conrm the selection. The function of each button is
described in the following.
1 2 3 4 5 6 7
1 Exit 5 Previous frame
2 Play 6 Next frame
3 Slow motion 7 Edit Movie
4 First frame
54
During the video playback, an operation guide appears
on the screen. You can use the navigation pad to perform the functions accordingly.
During the video playback, you can use the
Up/Down
navigation buttons to adjust the volume of playback.
During the slow motion playback, you can use the
Left/Right
navigation buttons to adjust the speed of
playback.
Volume will be muted when using the slow
motion playback.
55
Editing video
Press the Edit program button to enter the following screen and use the buttons on the left side to edit
the playback. Use the Up/Down navigation buttons to
select a button.
1. Select the button and use the Left/Right
navigation buttons to specify the new beginning of
the playback.
2. Select the
button and use the Left/Right
navigation buttons to specify the new end of the
playback.
3. To save the le, select the
button and press
the button.
4. Use the
Up/Down navigation buttons to select an
option.
• New le: Save as a new le.
•
Back: Do not save the le and return to the Edit
screen.
5. Press the
button to conrm your setting.
56 5756 57
To exit the Edit screen, select the button and
press the button.
Edited video must be at least 1 second long .
With sucient battery and at least 1GB available
memory, up to 30 minutes of footage can be
recorded per movie.
Thumbnail view
When in Playback mode, move the zoom scroll wheel
to the Wide position ( ) once to display the thumbnail of photos and video clips on the screen.
1. Use the zoom scroll wheel to switch between the
2x2, 3x3, and 4x4 thumbnail display.
2. Use
Up/Down/Left/Right to select a photo or
video clip to view.
If the indicator appears on the LCD, then a
movie le is currently being displayed.
Press the button to restore a preview icon to
its original image size.
Using zoom playback (for still pictures only)
The zoom scroll wheel can also be used during playback. This allows you to magnify photos up to 8X.
1. Turn your camera to
Playback mode.
2. Use the
Left/Right navigation buttons to select a
photo to magnify.
3. Move the zoom scroll wheel to the Tele position
( ) once.
4. Use the zoom scroll wheel to zoom in and out. The
zoom indicator and pan box appear on the screen.
5. Use the navigation buttons to pan across the image.
6. Press the
button to return the image to its
original scale.
Movie images cannot be enlarged.
58 5958 59
Using the Delete button
The camera is equipped with a quick Delete button
for you to delete photos or videoclips without
entering the Playback menu.
To delete a photo or video:
1. Turn your camera to
Playback mode.
2. Use the navigation buttons to select the photo/
video clip you want to delete.
3. Press the
button. The Delete screen appears.
4. Press the Up/Down navigation buttons to select
Yes or No. Then press the button to conrm.
Erased photos/video clips cannot be recovered.
Please refer to page 68 for instructions on the
delete menu options.
The indicator appears if the picture has a
sound le attached. You can choose to delete
the attached sound le alone or to delete both
the picture and the sound le.
Still menu
USING THE MENUS
Mode :
In still shooting modes, press the button to enter
the Still menu.
To congure the settings:
1. In the Still menu, press the
Up/Down button to
switch between the page numbers of the function
menu, and press the Right button to enter the
function menu option.
2. Switch between various functions with the
Up/
Down button.
3. Press the
Right button to enter the sub-menu.
4. Select an option with the
Up/Down navigational
button.
5. Press the
button to conrm the setting and exit
the menu.
Refer to the following sections for more detailed information on each setting.
60
AF mode (Auto-Focus mode)
Use this setting to control the auto-focus mechanism
while taking pictures.
Two options are available:
•
Single-AF: The focus frame appears on the center
of the LCD screen to focus on the subject.
•
Multi-AF: The camera automatically focuses the
subject in a wide area to nd the focus point.
AF-assist beam
Use this setting to aid focus in dark conditions. Select
On to turn on the AF assist beam, or Off to disable the
function.
Expo Metering (Exposure Metering)
Use this setting to select an area for the exposure to be
obtained.
Three options are available:
• Spot AE (Spot Auto Exposure)
• Center-Weight
• AiAE (Articial Intelligence AE)
61
Cont. Shot (Continuous shot)
Use this setting to perform continuous shooting. Once
in this mode, you must continuously hold the shutter
button to use this function.
Four options are available:
•
Off: Capture a single shot only.
•
3 shot: Capture up to 3 consecutive pictures.
•
Last 3 shots: Capture pictures continuously
until the shutter button is released but only the
last 3 shots are recorded.
•
Time-Lapse : Automatically capture pictures in at
predened intervals.
The ash is designed not to work in this mode in order
to enable quick succession of shots.
To activate this mode, the camera must have the
self-timer for multiple shots already turned on (as
described on page 31)
Grid
Use this setting to turn on or o the framing grids when
taking photos. This may help you position the subject in
your composition.
62
Quick Review
This setting refers to the quick photo review immediately after taking a picture. The picture stays on the LCD
screen for an adjustable period of time.
Four options are available:
•
Off
• 1
sec
• 2
sec
• 3
sec
Digital Zoom
Use this setting to enable or disable the digital zoom
function. When disabled, only the optical zoom is
enabled.
63
Digital Zoom indicator
• Off: gray color.
• On: reddish color.
Histogram
The histogram is used for checking the exposure while
taking pictures. Use this setting to enable or disable the
histogram display on the LCD screen.
• Off
• On
Slow Shutter
In Slow shutter mode, the shutter will remain open as
long as the shutter button is pressed. This gives you
complete control over the duration of exposure. (The
slow shutter mode is available only in manual
mode.
•
Manual
: To set a long exposure time between
2~30 sec.
The use of tripod is recommended for prolonged
exposure.
6464 65
Date Imprint
Include a date/time stamp in the photo image.
•
Off
:
•
Date
•
Date and time
Blink Detection
The Blink Detection feature is on by default, and after
taking each photo, a warning message will pop up if a
blink had been detected in the photo.
•
Off
:
• On
Movie menu
Mode :
In movie shooting mode, press the button to enter
the Movie menu.
To congure the settings:
1. In the Short Movie Shot menu, press the
Up/Down
button to switch between the page numbers of the
function menu, and press the Right button to enter
the function menu option.
2. Switch between various functions with the
Up/
Down button.
3. Press the
Right button to enter the sub-menu.
4. Press the
button to conrm the setting and exit
the menu.
Refer to the following sections for more detailed information on each setting.
6666 67
Expo Metering (Exposure Metering)
Set metering mode for various lighting conditions.
Three options are available:
• Spot metering
• Center-weighted average metering
• Articialintelligenceautomaticexpo
-
sure (Ai AE)
Playback menu
Mode :
In playback mode, press the button to enter the
Playback menu.
Please refer to the following sections for detailed
instructions on the various menu options.
Protect
To prevent pictures or videos being erased accidentally,
you can use this setting to lock one or all les.
To protect/unprotect a picture or video:
1. Switch to playback mode using the mode dial. Use
the Left/Right buttons to locate and display the
photo or movie that you want to protect.
2. Select the
Protect setting from the Playback
menu as described previously.
68
3. Use the Up/Down navigation buttons to select
One to protect this picture/video, or select All to
protect all pictures/videos in the internal memory
or memory card. Then press the Right navigation
button.
4. Use the
button to select Yes to lock the
displayed picture/video or Unlock to unlock it, and
use the Up/Down navigation buttons to select
Back to return to the Playback menu.
5. A key (
) icon will appear on the top of the screen
to indicate that the picture/video is protected.
6. Select
reset to cancel protection for all les that
have been placed in the protected mode.
Delete
There are three ways to delete les: (please note that a
le cannot be recovered once it is deleted.)
• Delete One:
1. On the Delete menu, select
Delete One and then
press the Right button.
2. Using the
Left/Right buttons, locate the photo or
movie le to be deleted. Select Yes (to delete le)
or No (to return to the previous menu) using the
Up/Down buttons, then press the button to
conrm.
69
• Delete All:
1. On the Delete menu, select
Delete All and then
press the Right button.
2. Using the
Left/Right buttons, select Yes (to delete
all les) or No (to cancel and return to the previous
menu).
The “ ” indicator means a le is protected. File
protection must be removed rst before a le can
be deleted.
Deleting les will cause DPOF settings to be reset.
DPOF (Digital Print Order Format)
DPOF allows you to record your selection of pictures
that you would like to print, and will save your selection
in the memory card, so that you can simply hand your
memory card to a photo kiosk without having to tell
them in person which photos you would like to print.
70
Info. Box (Information Box)
Use this setting to enable or disable the text display for
taking pictures. The following information will be displayed on the screen: histogram display, aperture value,
shutter speed, exposure value, image size, image quality,
and ISO value. (Please refer to page 40 for information
on the menu options shown.
Trim
The trim setting allows you select an area of the photo
you want to keep and then save it as a new photo.
To trim a picture:
1. Select the
Trim setting from the Playback menu
as described previously.
2. Using the
Left/Right buttons, locate the photo
that you want to crop and have it displayed on the
LCD.
3. Use the zoom scroll wheel and navigation buttons to
adjust the trimming box to t the location and size
of the new picture.
71
4. Press the
Shutter
button to save what you see on
the LCD screen as a new picture, or the button to
cancel and return to the
Playback
menu.
Resize
This setting allows you to resize picture to a specied
resolution, and save it as a new picture.
1. Select the
Resize
setting from the
Playback
menu
as described previously.
2. Use the
Left/Right
navigation buttons to select a
picture to resize.
3. Use the
Up/Down
navigation buttons to select
a resolution (
1024X768
or
640X480
) to resize
the image or
back
to cancel and return to the
Playback
menu.
4. Press the
button to conrm the setting.
Resizing an image creates a new le that contains
the image in the size you select. The le with the
original image also remains in memory.
If the message “The image cannot be edited.”
appears, it means that the current image cannot
be resized.
Rotate
You can use this setting to change the picture orientation of the picture.
1. Select the
Rotate setting from the Playback
menu as described previously.
2. Use the
Left/Right navigation buttons to select a
picture to rotate.
3. Use the Up/Down navigation buttons to select the
72
direction for rotation or Back to cancel and return
to the Playback menu.
4. Press the button to conrm the setting.
The rotated image will be saved as a new le, and
the original image will remain intact in memory.
Slide show
This setting allows you to view all the stored pictures as
a slideshow.
1. Select the
Slide show
setting from the
Playback
menu as described previously.
2. Use the
Up/Down
navigation buttons to select
Eect, Interval time, or Repeat and use the
Left/
Right
navigation buttons to adjust the setting.
3. Use the Up/Down navigation buttons to select
Start to run the slideshow or Cancel to return to
the Playback menu.
4. Press the
button to conrm the setting.
73
Red-eye removal
Use this setting to remove red-eye eect in your
photos.
1. Select the
Red-eye removal
setting from the
Playback
menu as described previously.
2. Use the
Left/Right
navigation buttons to select
the image for which red-eye will be removed.
3. Use the
Up/Down
navigation buttons to select
Yes
to x the selected image or
back
to cancel
and return to the
Playback
menu.
4. Press the button to conrm the setting.
For best results, the face of the subject should
be relatively large on the LCD screen, the subject
should be facing the camera as front on as
possible, and the red eyes should be as large as
possible.
74 75
Setup menu
Mode :
The Setup menu is available in all modes. Press the
button in any modes, then use the navigation but-
tons to select the Setup menu.
To congure the settings:
1. In the Setting menu, press the
Up/Down button to
switch between the page numbers of the function
menu, and press the Right button to enter the
Setting menu option.
2. Switch between various functions with the
Up/
Down button.
3. Press the
Right button to enter the sub-menu.
Refer to the following sections for more detailed information on each setting.
Format Memory
Please note: formatting enables you to delete all
contents in the memory card and built-in memory,
including protected photo and movie les.
To use this setting:
1. Select the
Format Memory setting from the
Setup menu as described previously.
2. Use the
Left/Right navigation buttons to select
Yes or No, and press the button to conrm.
3. The current media is formatted.
Beep
Use this setting to adjust the volume of beep when
buttons are pressed and change the tones for shutter,
buttons, self-timer, and power-on/power-o.
To change this setting:
1. Select the
Beep setting from the Setup menu as
described previously.
2. Use the
Up/Down navigation buttons to switch
between volume, shutter tone, key tone, self-timer
tone, and power tone elds.
3. Use the Left/Right navigation buttons to adjust
the volume and change each tone style. Then press
the button to conrm.
LCD Brightness
Use this setting to adjust the brightness of your LCD
screen.
1. Select the
LCD Brightness setting from the
Setup menu as described previously.
2. Use the
Up/Down buttons to select to Auto or
Manual brightness adjustment, and then press
to conrm your election.
76
3. For manual adjustment, use the Left/Right buttons
to adjust the brightness.
Power Saver
This setting allows you to save power and get the
maximum possible running time for your battery. Follow
the steps below to turn o the LCD screen and camera
automatically after a period of inactivity.
1. Select the
Power Save setting from the Setup
menu as described previously.
2. Use the
Up/Down navigation buttons to switch
between LCD power and Camera power elds.
3. Use the Left/Right navigation buttons to specify
the idle period before automatic power-o. The level
bars correspond to the following idle periods.
• LCD o:
30 seconds, 1 minute, 2 minutes, and Always on.
• Camera o:
3 minutes, 5 minutes, 10 minutes, and Always on.
4. Press the
button to conrm.
77
Date/Time
See “Setting the Date and Time“ section on page 27.
World time
The world time setting is a useful function on your overseas trips. This feature enables you to display the local
time on the LCD screen while you are overseas.
1. Select the
World time setting from the Setup
menu as described previously. The world time screen
appears.
2. Use the
Up/Down navigation buttons to switch
between the hometown ( ) and travel destination
( ) elds.
3. Use the
Left/Right navigation buttons to select a
city close to the desired time zone. Then press the
button to conrm.
File Numbering
After capturing photos or videos, the camera will auto-
matically save the le with a numeric sux.
78
Select this
setting:
Serial number is derived and assigned
to a new le as follows:
Continue
whether the number should continue
on from the last photo you have taken
Reset
reset the counter to 1 and save les in
a new folder in the memory card.
Language
See “Setting the Language“ section on page 28.
Video system
Use this setting to determine your video system in the
current area.
1. Select the
Video system setting from the Setup
menu as described previously.
2. Use the
Up/Down navigation buttons to select
NTSC or PAL. Then press the button to
conrm.
The video output signal can be switched to NTSC or
PAL to accommodate dierent regional standards. The
appropriate setting will vary between regions.
NTSC :
USA, Canada, Taiwan, Japan, etc.
PAL :
Europe, Asia (excluding Taiwan), Oceania, etc.
Note :
The TV output will not display properly if an
incorrect video system is selected.
79
Copy to Card (Copy internal memory to
memory card)
Use this setting to copy the les stored in the internal
memory to the memory card.
1. Select the
Copy to memory card setting from the
Setup menu as described previously.
2. Use the
Up/Down navigation buttons to select Yes
or No. Then press the button to conrm.
Reset Settings
Use this setting to restore the camera to its default
settings.
1. Select the
Reset setting from the Setup menu as
described previously.
2. Use the
Up/Down navigation buttons to select
Yes or No. Then press the button to conrm.
8080 81
FW Ver. (Firmware version)
Use this setting to view the current camera rmware
version.
1. Select the
FW Ver.
setting from the
Setup
menu as
described previously.
2. If SD card contains a new version of rmware, please
upgrade accordingly as necessary.
CONNECTIONS
Connecting to a TV
You can connect your camera to your television,
computer, or printer to view picture you have taken.
By using the AV cable, you can view the captured images
on a TV. Follow the steps below to connect the supplied
AV cable to a TV.
1. Choose
[NTSC] or [PAL] to match your TV video
standard (see page 79) and then turn o the camera.
2. Connect one end of the AV cable to the USB/AV OUT
port on your camera.
3. Connect the plugs on the other end of the cable to
the audio and video input ports on the TV.
4. Turn on the camera and the TV on.
Audio
Video
Make sure that both the camera and TV are
turned o before connecting the AV cable.
Use a fully charged battery to prevent the
camera from turning o unexpectedly while
connected.
82 83
Connecting to a PC
Use the USB cable and ArcSoft software (CD-ROM)
supplied with your camera to copy (transfer) pictures to
a computer.
Setting the USB mode
Since the camera’s USB port can be set to connect with
either a PC or a Printer, the following steps will allow
you to ensure that the camera is correctly congured to
connect with a PC.
1. Press the
button and use the
Up/Down
navigation buttons to select
USB Connect
, and
then press the Right navigation button.
2. Use the
Up/Down
navigation buttons to select PC.
3. Press the
button to conrm the setting.
TransferringlestoyourPC
The computer will automatically detect the camera as a
removable drive. Double-click My
Computer
icon on
the desktop to locate the removable drive and to copy
the folders and les in the drive to a directory on your
PC as you would copy any typical folder or le.
If the USB option is set to [PC]
:
Turn the camera o and disconnect the USB cable.
If the USB option is set to [PC (PTP) ] :
Remove the camera from the system as described below
before turning the camera o and disconnecting the USB
cable.
Window XP Home Edition/XP Professional
Click the [Safely Remove Hardware] icon in the
taskbar and select [Safely remove USB Mass Storage
Device] from the menu displayed.
By using the USB cable, you can transfer the captured
photos and videos to a PC. Follow the steps below to
connect the camera to a PC.
1. Start a computer to which ArcSoft software has been
installed.
2. Make sure both the camera and PC are turned on.
3. Connect one end of the supplied USB cable to the
USB/AV OUT port on your camera.
4. Connect the other end of the cable to an available
USB port on your PC.
5. Disconnect the camera once transfer is completed.
8484 85
Window 2000 Professional
Click the [Unplug or Eject Hardware] icon in the
taskbar and select [Stop USB Mass Storage Device]
from the menu displayed.
Macintosh
Drag the untitled icon to the Trash. ("Untitled")
Connecting to a PictBridge compatible printer
PictBridge allows printing images from a
memory card in a digital camera directly
to a printer, regardless of brand. To nd
out if a printer is PictBridge compatible,
simply look for the PictBridge logo on the packaging or
check the manual for specications.With the PictBridge
function on your camera, you can print the captured
photos directly with a PictBridge compatible printer using the supplied USB cable, without the need for a PC.
Setting the USB mode
Since the camera’s USB port can be set to connect with
either a PC or a Printer, the following steps will allow
you to ensure that the camera is correctly congured to
connect with a Printer.
1. Press the
button and use Up/Down to select
USB Connect, and then press the Right navigation
button.
2. Use
Up/Down to select Printer.
3. Press the
button to conrm the setting.
Every time the camera is powered o, the USB
Mode will automatically revert back to PC mode.
8686 87
Connecting the camera and printer.
1. Make sure both the camera and printer are turned
on.
2. Connect one end of the supplied USB cable to the USB
port on your camera.
3. Connect the other end of the cable to the USB port on
the printer.
If the camera is not connected to a PictBridge
compatible printer, the following error message
appears on the LCD screen.
The above error message would also appear if the
USB mode were set incorrectly, in which case you
should disconnect the USB cable, check the USB
mode settings, ensure that the Printer is turned
on, and then try connecting the USB cable again.
After setting the USB mode to Printer, the PictBridge
menu appears.
Use the Up/Down navigation buttons to select a menu
item, and press the Right navigation button to enter.
Refer to the following sections for more detailed information on each setting.
Print with date
If you have set the date and time of your camera, the
date record would be saved with the photos you take.
You can print the photos with date by following the
steps below.
1. Select
Print with date from the PictBridge
menu. The following screen appears.
2. Use the Left/Right navigation buttons to scroll
through the photos.
Using the PictBridge menu
88
3. Use the Up/Down navigation buttons to select the
number of prints for the current displayed photo.
4. Press the
button and the following screen
appears.
5. Select Yes to conrm printing, or No to cancel.
Then press the button.
Print without date
Use this setting to print the photos without dates on
them.
1. Select
Print without date from the PictBridge
menu. The following screen appears.
2. Use the Left/Right navigation buttons to scroll
through the images.
3. Use the
Up/Down navigation buttons to select the
number of prints for the current displayed image.
4. Press the
button and the following screen
appears.
89
5. Select Yes to conrm printing, or No to cancel. Then
press the button.
Print index
You can use this setting to print all indexes to show all
the photos currently in your camera.
1. Select
Print index from the PictBridge menu.
The following screen appears.
2. Select Yes to conrm the printing, or No to cancel.
Then press the button.
9090 91
Print DPOF (Digital Print Order Format)
To use DPOF printing, you must make the selection of
photos for printing using the DPOF settings before hand.
See “
DPOF
” section on page 70.
1. Select
Print DPOF
from the
PictBridge
menu. The
following screen appears.
2. Select Yes to conrm the printing, or No to cancel.
Then press the button.
Exit
To exit the PictBridge menu, select Exit. The “Remove USB cable” message will be displayed.
Disconnect the USB cable from the camera and printer.
Specications : G2
Appendices
"Design and specications are subject to change without notice."
Eective Image Sensor Pixels 8.0 Megapixels
Image Sensor 8.31 Megapixels [1/2.35” Charge Coupled Device (CCD)]
Lens
Focal Length F = 6.75mm (Wide) ~ 27mm (Tele)
[35mm lm equivalent] [38mm (Wide) ~ 152mm (Tele)]
F number F3.5 (Wide) ~ F5.15 (Tele)
Lens Construction 14 elements in 11 groups
Optical Zoom 4X
Focusing Range Normal: 60cm ~∞ ; (Tele) 80cm ~ ∞, Macro: (Wide) 6cm ~ ∞
Anti-Handshake Electronic Image Stabilization
Digital Zoom 4.5X digital zoom (Combined Zoom: 18X)
Number of
Recording
Pixels
Still Image
8MP, 7MP (3:2), 6MP(16:9),5MP,3MP, 2MP, 1MP, 0.3MP
Movie 640x480pixels: 30fps/15fps, 320x240pixels: 30fps/15fps
92
Image Compression Best, Fine, Normal
DCF, DPOF (Ver1.1) Support Yes
File Format
Still Image Exif 2.2 (JPEG)
Movie Image Compression: MPEG4, Audio: G.711 [Monaural]
Audio WAVE [Monaural] (Max 60 seconds)
Shooting Modes
Auto, Manual, Image Stabilization, Movie, Scene (Sport, Children,
Indoor, Leaf, Snow, Sunset, Fireworks, Glass, Museum, Landscape,
Night Landscape, Night Portrait), Panorama, Portrait
Smile Detection Yes
Blink Detection Yes
Face-Detection Yes
Red-eye Removal Yes
Panorama Stitching Yes
LCD Display
2.7 inch LTPS (low-temperature polycrystalline silicon) TFT color LCD
(230,400 pixels)
ISO Sensitivity Auto, ISO 64/100/200/400/800/1600
93
AF Method
Single AF, Multi-AF (TTL 9-point), Face-Detection, AF Assist Light (On/
O)
Light Metering Method
Articial Intelligence AE (Ai AE), Center-weighted Average, Spot (Fixed
to center of frame)
Exposure Control Method ProgramAE (AE-lock available)
Exposure Compensation ±2 EV in 1/3 steps
Shutter Speed 4 ~ 1/2000 second (Manual 30 seconds)
Continuous Shooting Approx. 1.8 fps (Large/Fine mode)
Playback Modes
Single Photo, Index (4/9/16 thumbnails), Slide Show, Movie (SlowMotion possible), Zoom (Approx. 2X~8X), Audio , Histogram Display
White Balance Control
Auto (AWB), Daylight, Cloudy, Fluorescent , Fluorescent CWF,
Incandescent, Manual
Internal Flash (Shooting Range)
Auto/Red-Eye Reduction/Forced Flash/No Flash/Slow Synchro/RedEye Reduction+Slow Synchro
Gno. 5.9 (ISO 100)
(Shooting Range) Wide: Approx. 0.3m~3.3m / Tele: Approx. 0.3m~2.7m
(ISO 400)
9494 95
Recording Media
Internal Memory: 26MB
SD Card/SDHC Card (Up to 4GB support)
Other Features PictBridge, Exif Print Support, Multi-language Support (23 languages)
Jacks USB2.0/AV-OUT (Integrated Proprietary Connector)
Power Rechargeable Lithium-ion Battery GB-20, 3.7V 750mAh
Battery Charger
Input Voltage : AC 100 to 240V, 50/60Hz, 100mA
Output Voltage : DC 4.2V, 500mA"
Shooting Capability (Battery Performance) Approx. 200 shots (based on CIPA standards)
Operation Environment Temperature: 0~40oC, Humidity: 0~90%
Dimensions (W x H x D) 91mm x 60mm x 18mm
Mass Approx. 120g (Body only)
Eective Image Sensor Pixels 7.07 /8.0 Megapixels
Image Sensor 7.40 /8.5 Megapixels [1/2.5” (CCD)]
Lens
Focal Length F = 6.1mm (Wide) ~ 18.3mm (Tele)
[35mm lm equivalent] [36mm (Wide) ~ 108mm (Tele)]
F number F2.8 (Wide) ~ F4.8 (Tele)
Lens Construction 7 elements in 6 groups
Optical Zoom 3X
Focusing Range Normal: 60cm ~∞, Macro: (Wide) 5cm ~ ∞; (Tele) 40cm ~ ∞
Anti-Handshake Electronic Image Stabilization
Digital Zoom 4.5X digital zoom (Combined Zoom: 13.5X)
Specications : A735/A835
Appendices
"Design and specications are subject to change without notice."
96
Number of
Recording
Pixels
Still Image
A735:
7MP, (3:2)6MP, (16:9)5MP, 3MP, 2MP, 1MP, 0.3MP
A835:
8MP, (3:2)7MP, (16:9)6MP, 5MP, 3MP, 2MP, 1MP, 0.3MP
Movie 640x480pixels: 30fps/15fps, 320x240pixels: 30fps/15fps
Image Compression Best, Fine, Normal
DCF, DPOF (Ver1.1) Support Yes
File
Format
Still Image Exif 2.21 (JPEG)
Movie Quick Time Motion JPEG, Audio: G.711 [Monaural]
Audio WAVE [Monaural] (Max 60 seconds)
Shooting Modes
Auto, Manual, Image Stabilization, Scene (Sport, Children, Indoor, Leaf,
Snow, Sunset, Fireworks, Glass, Museum, Landscape, Night Landscape,
Night Portrait), Panorama, Portrait
Smile Detection Yes
Blink Detection Yes
Face-Detection Yes
Red-eye Removal Yes
Loading...
