GEAppliances.com
Safety Information ........ 2–5
Operating Instructions
Countdown Display ...............7
Reversing the Door ...............6
Venting .......................... 8
Care and Cleaning ........... 9
Consumer Support
Consumer Support ......Back Cover
General Principles
of Good Practice ................11
Warranty ....................... 10
Commercial
Owner’s Manual
DCCB330
DMCD330
Dryers
Write the model and serial
numbers here:
Model # ______________
Serial # _______________
They are on the label on the front
of the dryer behind the door.
234D1581P005 49-90307-2 03-12 GE
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
For your safety, the information in this manual must be followed to minimize the risk
of fire or explosion, electric shock, or to prevent property damage, personal injury, or
death.
Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
FOR GAS DRYERS: YOU MUST POST IN A PROMINENT LOCATION
1. Instructions to follow if the user smells gas: Contact your local gas
supplier for information to be displayed.
2. Instructions concerning flammable materials as follows:
FOR YOUR SAFETY:
Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
California Safe Drinking Water and Toxic Enforcement Act
This act requires the governor of California to publish a list of substances known to the state to
cause cancer, birth defects or other reproductive harm and requires businesses to warn customers
of potential exposure to such substances.
Gas appliances can cause minor exposure to four of these substances, namely benzene, carbon
monoxide, formaldehyde and soot, caused primarily by the incomplete combustion of natural gas
or LP fuels.
Properly adjusted dryers will minimize incomplete combustion. Exposure to these substances can be
minimized further by properly venting the dryer to the outdoors.
Consumer Support Operating Instructions Safety InstructionsCare and Cleaning
2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING. GEAppliances.com
PROPER INSTALLATION
This dryer must be properly installed and located in accordance with the Installation Instructions
before it is used. If you did not receive an Installation Instructions sheet, you can receive one by
visiting
Properly ground dryer to conform with all
Install or store where it will not be exposed to
Connect to a properly rated, protected and sized
Remove all sharp packing items and dispose of
In fulfilling the specific needs of different
Any coin box or similar device added to
GEAppliances.com, or by calling 800.GE.CARES (800.432.2737).
Remove any accumulated time by manually
governing codes and ordinances. Follow details
in the Installation Instructions section.
temperatures below freezing or exposed to
the weather.
power supply circuit to avoid electrical overload.
all shipping materials properly.
commercial installations, the purchaser of this
dryer may wish to locate the coin box and controls
in any of a number of locations.
The responsibility for the proper performance
of this work lies solely with the purchaser.
It should be done by properly trained and qualified
personnel, and in accordance with
local code requirements.
the dryer, either electrically or mechanically,
should be properly grounded.
rotating timing cam in the coin box
counterclockwise until switch shuts off. Apply
a slight additional counterclockwise pressure
to further seat drive. Make certain not to turn
cam past switch shutoff position. Otherwise, one
increment of time will be gained. Switches are
off when the plastic switch actuating arm (inner)
is down and all 3 switch buttons are depressed.
Exhaust/Ducting
All dryers MUST be exhausted to the outside to
1
prevent large amounts of moisture and lint from
being blown into the room.
Use only rigid metal 4" diameter ductwork inside
2
the dryer cabinet. Use only rigid metal or flexible
metal 4" diameter ductwork for exhausting to the
outside. USE OF PLASTIC OR OTHER
COMBUSTIBLE DUCTWORK CAN CAUSE
A FIRE. PUNCTURED DUCTWORK CAN CAUSE A
FIRE IF IT COLLAPSES OR BECOMES OTHERWISE
RESTRICTED IN USE OR DURING INSTALLATION.
Follow details in the Installation Instructions section.
Safety Instructions Care and Cleaning Consumer SupportOperating Instructions
3
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
YOUR LAUNDRY AREA
Keep the area underneath and around your
appliances free of combustible materials, such
as lint, paper, rags, chemicals, gasoline and
other flammable vapors and liquids.
Close supervision is necessary if this appliance
is used by or near children. Do not allow children to
play on, with or inside this or
any other appliance.
Keep the floor around your appliances clean
and dry to reduce the possibility of slipping.
Keep area around the exhaust opening and
surrounding areas free from the accumulation
of lint, dust and dirt.
Do not obstruct the flow of ventilating air.
Do not stack or place laundry or throw rugs
against the front or back of the dryer.
WHEN USING YOUR DRYER
Never reach into the dryer while the drum is
moving. Before loading, unloading or adding
clothes, wait until the drum has completely
stopped.
Clean the lint filter before each load to prevent
lint accumulation inside the dryer or in the room.
DO NOT OPERATE THE DRYER WITHOUT THE LINT
FILTER IN PLACE.
Do not wash or dry articles that have been
cleaned in, washed in, soaked in or spotted with
combustible or explosive substances (such as
wax, oil, paint, gasoline, degreasers, dry-cleaning
solvents, kerosene, etc.) which may ignite or
explode. Do not add these substances to the
wash water. Do not use or place these substances
around your washer or dryer during operation.
Any article on which you have used a cleaning
solvent or that contains flammable materials (such
as cleaning cloths, mops, towels used in beauty
salons, restaurants or barber shops, etc.) must
not be placed in or near the dryer until solvents or
flammable materials have been removed. There
are many highly flammable items used in homes
such as acetone, denatured alcohol, gasoline,
kerosene, some household cleaners, some spot
removers, turpentines,
waxes, wax removers and products containing
petroleum distillates.
The laundry process can reduce the flame
retardancy of fabrics. To avoid such a result,
carefully follow the garment manufacturer’s
Consumer Support Operating Instructions Safety InstructionsCare and Cleaning
care instructions.
Keep all laundry aids (such as detergents, bleaches,
etc.) out of the reach of children, preferably in a
locked cabinet. Observe all warnings on container
labels to avoid injury.
Never climb on or stand on the dryer top.
Do not install or store this appliance where it
will be exposed to the weather.
Do not dry articles containing rubber, plastic
or similar materials such as padded bras, tennis
shoes, galoshes, bath mats, rugs, bibs, baby
pants, plastic bags, pillows, etc. that may melt
or burn. Some rubber materials, when heated,
can under certain circumstances produce fire by
spontaneous combustion.
Do not store plastic, paper or clothing that
may
burn or melt on top of the dryer during
operation.
Garments labeled Dry Away from Heat or Do Not
Tumble Dry (such as life jackets containing Kapok)
must not be put in your dryer.
Do not dry fiberglass articles in your dryer.
Skin irritation could result from the remaining
particles that may be picked up by clothing during
subsequent dryer uses.
To minimize the possibility of electric shock,
unplug this appliance from the power supply or
disconnect the dryer at the distribution panel
by removing the fuse or switching off the circuit
breaker before attempting any maintenance or
cleaning (except the removal and cleaning of
the lint filter). NOTE: Turning the Cycle Selector
knob to an off position does NOT disconnect the
appliance from the power supply.
Do not spray any type of aerosol into, on or near
dryer at any time.
Do not place items exposed to cooking oils in your
dryer. Items contaminated with cooking oils may
contribute to a chemical reaction that could cause
a load to catch fire.
4
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING. GEAppliances.com
WHEN USING YOUR DRYER (cont.)
Never attempt to operate this appliance if it is
damaged, malfunctioning, partially disassembled,
or has missing or broken parts, including a
damaged cord or plug.
The interior of the machine and the exhaust duct
connection inside the dryer should be cleaned at
least once a year by a qualified technician. See the
Care and Cleaning section.
Do not use any type of spray cleaner when
cleaning dryer interior. Hazardous fumes or
electrical shock could occur.
If yours is a gas dryer, it is equipped with an
automatic electric ignition and does not have
a pilot light. DO NOT ATTEMPT TO LIGHT WITH
A MATCH. Burns may result from having your hand
in the vicinity of the burner when the automatic
ignition turns on.
You may wish to soften your laundered fabrics
or reduce the static electricity in them by using
a dryer-applied fabric softener or an anti-static
conditioner. We recommend you use either
a fabric softener in the wash cycle, according
to the manufacturer’s instructions for those
products, or try a dryer-added product for
which the manufacturer gives written assurance
on the package that their product can be safely
used in your dryer. Service or performance
problems caused by use of these products are
the responsibility of the manufacturers of
those products and are not covered under
the warranty to this appliance.
Safety Instructions Care and Cleaning Consumer SupportOperating Instructions
WHEN NOT USING YOUR DRYER
Grasp the plug firmly when disconnecting this
appliance to avoid damage to the cord while
pulling. Place the cord away from traffic areas
so it will not be stepped on, tripped over or
subjected to damage.
Do not attempt to repair or replace any part of
this appliance or attempt any servicing unless
specifically recommended in this Owner’s Manual
or in published user-repair instructions that you
understand and have the skills to carry out.
Before discarding a dryer, or removing it from
service, remove the dryer door to prevent children
from hiding inside.
Do not tamper with controls.
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
5
Reversing the door.
Tools needed:
Standard #2 Tape-tipped
Phillips screwdriver putty knife
Open the door and remove the filler plugs opposite the hinges. With the door
1
completely open, remove the bottom screw from each hinge on the dryer face.
Insert these screws about halfway into the TOP holes, for each hinge, on the
opposite side (where you removed the filler plugs).
Apply firm pressure to get the screw started in new holes.
Loosen top screw from each hinge on the dryer face halfway. With one hand
2
holding the top of the door and the other hand holding the bottom, remove the
door from the dryer by lifting it UP and OUT.
Rotate the door 180°. Insert it on the opposite side of the opening by moving the
3
door IN and DOWN until the top hinge and the bottom hinge are resting on the
top screws inserted in step 1.
Remove the remaining screws from the side of the opening from which
4
the door was removed. With these screws, secure each hinge at the bottom.
Tighten the two top screws of each hinge. Reinsert the plastic plugs on
the side from which the door was removed.
Consumer Support Operating Instructions Safety InstructionsCare and Cleaning
6
Countdown display. (DMCD models only) GEAppliances.com
The countdown display shows the remaining operating time as well as the current drying cycle.
The display board is configured for a 45-minute dry time at the factory to correspond with
the 45-minute timer cam pre-installed in the coin box. If the timer cam is modified for another
operating duration, the dip switches on the display board should be set as follows:
Safety Instructions Care and Cleaning Consumer SupportOperating Instructions
DRYING TIME (minutes) 1 2
45 1 1
60 1 0
90 0 1
120 0 0
NOTE: This display does not accumulate time. See the following examples of display possibilities.
DIP SWITCH SETTING (min)
45 1 45 to 0, then blank
45 2 45 to 1, then 1 for next 45 min.,
then 0 and blank
120 1 99 for 21 minutes, then 98 to 0,
then blank
COIN SLIDE ACTUATIONS DISPLAY READING (min)
DIP SWITCH NUMBERS
7
Venting the dryer.
For the best drying performance, the dryer needs to be properly vented. The dryer will use more energy
and run longer if it is not vented to the below specifications. Carefully follow the details on Exhausting in
the Installation Instructions.
Use only rigid metal 4" diameter ductwork inside the dryer cabinet. Use only rigid metal or
flexible metal 4" diameter ductwork for exhausting to the outside.
Do not use plastic or other combustible ductwork.
Use the shortest length possible.
Do not crush, kink or collapse the duct.
Avoid resting the duct on sharp objects.
Venting must conform to local building codes.
Correct
Venting
Incorrect
Venting
Consumer Support Operating Instructions Safety InstructionsCare and Cleaning
8
Care and cleaning. GEAppliances.com
Care and Cleaning of the Dryer
Safety Instructions Care and Cleaning Consumer SupportOperating Instructions
The Exterior: Wipe or dust any spills or washing
compounds with a damp cloth. Dryer control
panel and finishes may be damaged by some
laundry pretreatment soil and stain remover
products. Apply these products away from the dryer.
The fabric may then be washed and dried normally.
Damage to your dryer caused by these products is
not covered by your warranty.
The Lint Filter: Clean the lint
filter before each use. Moisten
your fingers and reach into
the filter opening. Run your
fingers across the filter. Have
a qualified technician vacuum
the lint from the dryer once a
year.
The Exhaust Duct: Inspect and clean the exhaust
ducting at least once a year to prevent clogging.
A partially clogged exhaust can lengthen the
drying time.
Follow these steps:
Turn off electrical supply by disconnecting the
1
plug from the wall socket.
Disconnect the duct from the dryer.
2
Vacuum the duct with the hose attachment and
3
reconnect the duct.
The Exhaust Hood: Check from the outside that the
flaps of the hood move freely when operating. Make
sure that there is no wildlife (birds, insects, etc.) nesting
inside the duct or hood.
9
GE Commercial Dryer Warranty.
Coin-Operated Model DMCD330 Only
All warranty service provided by our Factory Service Centers,
General Electric Commercial Laundry Distributors or an authorized
Customer Care
®
technician. To get customer support, on-line, visit us
at gecommerciallaundry.com, or call 800.GE.CARES (800.432.2737).
Please have serial number and model number availa ble when calling
Staple your receipt here.
Proof of the original purchase
date is needed to obtain
service under the warranty.
for service.
For The Period Of: We Will Replace:
90 Days Any part of the dryer (except the coin system*) which fails due to a defect in materials
From the date of the or workmanship. During this limited 90-day warranty, GE will also provide, free of charge,
original purchase all labor and related service to replace the defective part.
Three Years Any part of the dryer which fails due to a defect in materials or workmanship. During this
From the date of the limited three-year warranty, you will be responsible for any labor and related service costs.
original purchase
Fourth through The dryer drum, if it should fail due to a defect in materials or workmanship, and the cabinet
Fifth Year side panels, base and cover, if they should fail due to rust-through. During this limited additional
From the date of the two-year warranty, you will be responsible for any labor and related service costs.
original purchase
What Is Not Covered:
*Coin System (including the coin drop meter, coin slide
mechanism, coin vault and locks) is covered under a
separate manufacturer’s warranty. See insert for details.
Service trips to your place of business to teach you how
to use the product.
Improper installation, delivery or maintenance.
Replacement of fuses or resetting of circuit breakers at
place of business.
Damage to the product caused by accident, fire, floods or
acts of God.
Incidental or consequential damage caused by possible
defects with this appliance.
Failure of the product if it is abused, misused, or used
for other than the intended purpose.
Damage caused after delivery.
Replacement of the light bulb.
Any and all implied warranties of merchantability and
fitness for a particular purpose.
Product not accessible to provide required service.
Defects or damage due to operation in freezing
temperatures.
Products which are not defective or broken, or which are
working as described in the Owner’s Manual.
E;CLUSION OF IMPLIED WARRANTIES³Your sole and exclusive remedy is product repair as provided in
this Limited Warranty. Any implied warranties, including the implied warranties of merchantability or
fitness for a particular purpose, are limited to one year or the shortest period allowed by law.
This warranty is extended to the original purchaser and any succeeding owner for products purchased for
commercial use within the USA. If the product is located in an area where service by a GE Authorized Servicer
is not available, you may be responsible for a trip charge or you may be required to bring the product to an
Authorized GE Service location for service. In Alaska, the warranty excludes the cost of shipping to your
place of business.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know
what your legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Consumer Support Operating Instructions Safety InstructionsCare and Cleaning
10
Warrantor: General Electric Company. Louisville, KY 40225
AUTOMATIC DRYER
COMMERCIAL APPLICATION
GENERAL ELECTRIC DRYERS
GENERAL PRINCIPLES OF GOOD PRACTICE
(COIN-OPERATED MODELS ONLY)
In fulfilling the specific needs of different commercial installations, the purchaser of this
General Electric automatic dryer may wish to locate the coin box and controls in any of
a number of locations. The responsibility for the proper performance of this work lies solely
with the purchaser. It should be done by properly trained and qualified personnel, and in
accordance with local code requirements.
In addition, General Electric Company assumes no responsibility or liability whatsoever to the
purchaser for any patent infringement expenses, either in the form of damages or legal costs,
where the alleged infringement is based on a patent claim including one or more components
added by the purchaser (i.e., not supplied by General Electric Company with the purchased
dryer).
Set forth below are some general principles which should be followed by persons installing the
coin box and controls in the desired location. This listing is not all-inclusive, and is
only intended to serve as a general guide. These principles are intended to supplement,
not modify, the Installation Instructions which accompany the automatic dryer.
1. Any component added to the automatic dryer, either electrically or mechanically,
should be properly grounded.
2. All current-carrying metal parts should be isolated from possible contact by the user.
3. All wiring should be properly protected from sharp edges, burrs, moving parts and other
agencies which might cause abrasion of the insulation on the conductors.
4. All electrical connections should be mechanically secure, and should provide adequate
and reliable electrical contact under conditions, such as vibration, to which they may be
subjected.
5. All electrical components, wires and terminals should be of proper electrical rating for the
specific application.
6. All insulating materials should remain effective under the specific conditions to which they
will be exposed (e.g., humidity, temperature, etc.).
7. The installation should not be incompatible with the electrical circuit within the automatic
dryer nor in any manner interfere with either the safety devices or the sequence of
operations of the cycle which are engineered into the appliance.
8. Uninsulated current-carrying metal parts should have adequate and ensured permanence of
spacing from other parts.
11
Consumer Support.
GE Appliances Website GEAppliances.com
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day,
any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals,
order parts or even schedule service on-line.
Schedule Service GEAppliances.com
Expert GE repair service is only one step away from your door. Get on-line and schedule your service at
your convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal business
hours.
Real Life Design Studio GEAppliances.com
GE supports the Universal Design concept³products, services and environments that can be used by
people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and
mental abilities and impairments. For details of GE’s Universal Design applications, including kitchen design
ideas for people with disabilities, check out our Website today. For the hearing impaired, please call 800.TDD.
GEAC (800.833.4322).
Extended Warranties GEAppliances.com
Purchase a GE extended warranty and learn about special discounts that are available while your warranty
is still in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours.
GE Consumer Home Services will still be there after your warranty expires.
Parts and Accessories GEAppliances.com
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or
by phone at 800.626.2002 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.
Contact Us GEAppliances.com
If you are not satisfied with the service you receive from GE, contact us on our Website with all the details
including your phone number, or write to: General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
Register Your Appliance GEAppliances.com
Register your new appliance on-line³at your convenience! Timely product registration will allow for enhanced
communication and prompt service under the terms of your warranty, should the need arise.
You may also mail in the pre-printed registration card included in the packing material.
Printed in Canada
Loading...
