GBC Prostyle+ Instruction Manual

Prostyle+

Instruction Manual

H

F

I

D

A

E

G

C

B

J

Lights and Icons Explained

Introduction

Thank you for choosing this shredder from GBC. We are sure
it will serve you well, but please take a little time to read these
instructions to ensure you get the best out of your machine.

Safety First

t Please store this instruction manual in a safe place for future

reference.

t Please pay close attention to the safety symbols on the top of

the shredder and operate the machine accordingly.

t If the shredder needs cleaning, unplug the unit from the

power socket and use a damp cloth. NB. Do not use any
cleaning products to clean the unit.

t Do not position the unit near to an object that radiates heat.

t Do not place the unit in a damp environment.

t Take care not to splash any liquid onto the machine.

t Return the product and proof of purchase with receipt to the

store at which it was purchased if…

- The power cable or plug is broken.

- The machine malfunctions because liquid was accidentally
spilt onto the machine.

- The shredder doesn’t operate despite following the
guidelines in the manual.

t Make sure the power cable isn’t a trip hazard.

t Please ensure the power supply is compatible with the

requirements of the machine (230V~50Hz).

t To avoid risk of injury, do not open the machine’s casing to

attempt DIY repair. Any attempted repair by an unqualified
person will invalidate the warranty.

DO NOT attempt to repair shredder yourself.

KEEP OUT OF REACH OF CHILDREN.

LEDs

Auto Cool Down
Colour of LED Blue Red

Power On/Off Switch

Auto Mode light

Forward Mode light

Reverse Mode light

Cool Down Indicator light light
Sleep Mode

Description of product parts

On/off button (at rear of machine)

Important safety symbols

Paper and credit card entry slot

CD entry slot

Auto button

Reverse button

Continuous forward function

Pull out bin with viewing window

Cool down (red light)

CD Bin (not shown)

A

B

C

D

E

F

G

H

I

J

Shredder Control Panel

ReverseForwardAuto

Safety First

This means you should be careful because long hair can
become entangled in the cutting head.

This means don’t reach into the feed opening of the
cutting head.

This means be careful of ties and other loose clothing
which could become entangled in the cutting head.

This means keep children away from shredder.

This means be careful of loose jewelry which could
become entangeld in the cutting head.

This means no aerosols.

This means machine is cooling down.

Cutting Type

Shred Size

Security Class

Sheet Capacity (one pass)

Entry Width

Product Dimensions

Rated Voltage/Frequency

Rated Current

GBC ProStyle+

Confetti Cut

4 x 35mm

DIN S3

12 sheets (80 gsm)

230mm

H405 x W225 x D420mm

230V~50Hz

1.8 amps

Specifications

Bin Capacity

18 litres

Duty Cycle

3 mins ON / 40 minutes OFF

3

Preparation before use

How to use the shredder correctly:

Take care not to insert fingers, ties or other objects into the

entry slot of the shredder.

We recommend to remove staples and paperclips, avoid

laminating materials, plastic bags etc. from being passed
through the shredder. This will prevent damage to the
cutters.

Do not shred wet paper as it can tangle in the cutters.

Do not shred more than the stated sheet capacity in one

pass.

Do not shred continuously for more than 3 minutes at a

time. Running the unit for too long may make the motor
overheat. If the motor over heats, allow it to cool down for at
least 40 minutes before resuming use.

Do not use the reverse

(

)

function if it’s not necessary.

Over use of the reverse (

)

function can result in
shredded paper becoming jammed in the entry slot, which
will adversely affect the performance of the shredder.

Rare Occasions of Jamming

In the unlikely event of the shredder jamming, use the reverse
function to unblock the shredder (see Reverse function section).

Alternating between the reverse and continuous forward
functions will help unblock the feed area.

Over Heating

If this product is used continuously for long periods of time the
shredder may overheat. If this occurs the thermometer symbol
on the indicator panel will illuminate.

When the shredder is ready to be used again the thermometer
symbol will not illuminate.

Bin Full

Empty or compress the shredded paper when it reaches the
bottom of the viewing window. This will avoid paper spilling
over or difficulty in removing the bin when it is too full. Over
filling the bin may cause the bin to jam.

Once the bin is empty, replace correctly or the shredder will not
function.

Lubrication of the Shredder

Only use Rexel Oil Sheets (2101948 & 2101949) to lubricate.
ACCO Brands accepts no liability for product performance or
safety when other types or brands of lubricants are used on any
part(s) of this machine.

Reverse Function

Should you wish to reverse the shredding direction whilst

shredding a document, a reverse button (f) has been fitted
for your convenience.

By pressing the reverse button the shredding cutters will

change direction allowing the retrieval of the document
being shredded.

The reverse function will only run whilst the button is being

pressed. When the reverse button has been released the
shredder will revert to Auto mode.

CD and Credit Card Shredding

Insert CD to be shredded into the feed area (d).

A separate CD tray is provided to collect the shredded CD

shards. Ensure that this is correctly mounted onto the bin
before shredding CDs or credit cards. CD and credit card
shards should be disposed of separately to paper.

Empty the CD tray after 8 credit cards or CD’s to avoid

waste spilling over into the paper waste bin. Remove the CD
tray before recommencing to shred paper.

Operation

After unpacking the product, pull out the shredder bin and

remove the CD shard tray and store externally. Reposition
the CD shard tray when you shred CD’s to separate waste
for recycling.

Connect shredder to mains supply.

Ensure the on/off button on the back of the machine is in

the on position (a).

To commence shredding, press the central Auto button (e).

This sets the shredder into auto mode. The standby symbol
will illuminate blue.

Insert paper (or credit card) to be shredded into the feed

area (c).

If the shredder is left in auto mode for more than 2 minutes

without being used, the shredder will automatically turn
back to standby mode in order to save power.

The shredder will automatically ‘wake up’ from sleep mode

when paper is inserted into the shredder mouth. There is no
need to press the Auto button (e).

4

Certificate of Warranty

(For use in Singapore only)

Model :
Serial No. :
Validity : 1 year from date of purchase

IMPORTANT: Certificate of Warranty must be produced together with proof of

purchase (e.g. sales invoice, receipts, etc) when your equipment requires our
service. All services provided after warranty period will be chargeable.

Terms and conditions

ACCO Brands Asia hereby certify that all machines of whatever designs are free
from any defects in materials and in workmanship under normal use and service for
twelve (12) months from date of purchase. Should any defects occur within the
aforesaid period, ACCO Brands Asia shall at their absolute discretion, effect repairs
or replacement of any part of the said machine free of costs.

1. This warranty shall not be transferable, negotiable or assignable to any third
party.

2. This warranty shall be considered VOID under the following circumstances:

a. The serial number of the machine has been altered or removed.
b. The machine has been subjected to misuse, accident, and negligence.
c. The machine has not been installed, maintained or operated in

accordance with the instructions given in the instruction manual.

d. The machine has undergone repairs, adjustments or corrections made to

it by unauthorised person.

e. The machine has been dismantled by unauthorised person.

3. This warranty is applicable only in Singapore.

4. This warranty shall exclude all faults/defects caused by natural wear and tear.

5. This warranty shall exclude all other warranties & guarantees, expressed or
implied other than mentioned above.

6. No notices will be given on expiry of this warranty. ACCO Brands Asia reserves
the rights to amend or modify the terms and conditions of this warranty without
giving any prior notice.
