GASTROBACK
INSTRUCTIONS FOR USE AND RECIPES
DESIGN JUICER BASIC
Art.-Nr. 40119 DESIGN JUICER BASIC
Read all provided instructions before first usage!
Model and attachments are subject to change
Carefully read all provided instructions before you start running the appliance and pay
regard to the warnings mentioned in these instructions.
!
Contents
Introduction ......................................................................................................3
Gastroback recommends safety first ..............................................................3 – 5
Know your Design Juicer Basic ....................................................................
Assembling your Design Juicer Basic ..........................................................8 – 10
Operating your Design Juicer Basic ..........................................................10 – 11
Disassembling your Design Juicer Basic ....................................................12 – 13
Care and cleaning..........................................................................................14
Trouble shooting guide....................................................................................15
The inside information on juicing ............................................................16 – 18
Recipes..................................................................................................19 – 27
Warranty ..................................................................................................................27
6 – 7
Disposal....................................................................................................................27
Introduction
The current Interest in fresh and unprocessed food is
the reason for fresh fruit and vegetable juices to
become a favorite component of our daily food
and wellbalanced diet.
The Gastroback juicer has a special designed large
feed chute, a large pulp container and a stainless
steel micro mesh filter. It operates with a high
performance 450 watt motor which makes the
juice production easy and efficient. The elaborate
design makes the cleaning an ease.
Gastroback recommends safety first
Carefully read all instructions before operating
and save the instructions for further reference.
Do not attempt to use this appliance for any
other than the intended use, described in these
instructions. Any other use, especially misuse,
can cause severe injury or damage by electric
shock, fire or moving mechanical parts. This
instruction is an essential part of the appliance.
When passing on the appliance to a third person,
ensure to include these instructions.
Any operation, repair and technical maintenance
of the appliance or any part of it other than
described in these instructions may only be
performed at an authorised service centre.
Please contact your vendor.
Safeguards for Daily Operation
• Do not use the appliance in moving vehicles
or boats. Only use the appliance indoors.
•Store and use the appliance in a clean, frost
free environment where it is protected from
dampness, moist and immoderate and extraordinary
burden (such as: downfall, beat, overheating,
moisture in the motor block) .
• Do not use or store the appliance outdoors.
• Only use units, spare parts and supplies
which are provided and recommended by
the manufacturer. Damaged or improper units
may break in use, damage the appliance
or cause injury.
The units have a smooth surface with no grooves and
rough edges and can be cleaned easily after use.
The provided pulp container finishes with the
juice run-out and therefore eliminates any splatter
during operation.
Please read all the advice and instructions with
care and keep the manual.
Only use the appliance to process fresh food.
• Store appliance and units out of reach of children.
• Never leave children unsupervised when the
appliance or units of the appliance are in reach.
• Never let children play with the appliance or
units of the appliance. Children and invalid
people have to be supervised using the appliance.
• The work space has to be easily accessible,
solid, even, dry and of sufficient size. Do not
use the appliance in moist and wet areas.
• Operate the appliance on a well accessible,
stable, level, dry, and suitable large surface. Do
not place the appliance or any part of it on or near
hot surfaces (heater, gas burner, grill, or oven).
Do not place the appliance near the edge of the
table or counter or on inclined or wet surfaces
or where it can fall.
• Do not put any cloth or napkins underneath
the appliance to avoid endangering by fire and
electric shocks.
• Never situate the appliance close to the edge
of the working area.
• Never let water or other liquids run into the
motor block.
• Never leave the appliance unattended,
when the plug is plugged into the power
point.
• Always turn the appliance off and pull the
plug when the appliance is not in use or when
disassembling, moving or cleaning the appliance.
Always grasp the plug to disconnect the appliance
from the power outlet.
3
Gastroback recommends safety first
• Do not leave food leftovers dehumidify on
the appliance or units of the appliance. If pulp
dehumidifies on the micro mesh filter it may clog
the fine pores of the micro mesh filter thereby
lessening the effectiveness of the juicer. Remove
such dirt immediately and operate according to the
instructions ´Care and cleaning` before you
continue to proceed.
• Never clean or operate the appliance or units
of the appliance with abrasive or hard sharp-edged
items. Use a nylon brush for cleaning the filter
basket.
• Never clean the motor block in the dishwasher.
• Never use force operating the appliance to
avoid damage of the units of the appliance.
• Do not touch the small cutting blades in the
base of the stainless steel filter basket. Pay attention
not cutting yourself when handling the filter
basket.
• Always make sure the appliance is properly and
completely assembled before connecting to power
outlet and operating. The unit will not turn ‘ON’
unless properly assembled.
• Do not push products into the feed chute with
your fingers or foreign objects. Always use the
food pusher provided.
• Do not let the motor run permanently for longer
then 7 minutes to avoid overheating.
• Do not operate the appliance continuously on
heavy loads for more than 10 seconds. In this
case the appliance is overloaded or the fruit
chunks are too big. Cut the fruit in smaller pieces
and try smaller amounts at one time. To continue
juicing turn the appliance OFF and then ON
again. (None of the recipes in this book are
considered a heavy load.)
• While proceeding Do not push the food pusher
too hard down. Empty the pulp container and juice
jug in time to avoid run-over and splatter which
might causes damages to the appliance. When
proceeding hard or stringily food or if you press
the stamp down too hard the motor could stop
or slow down. In this case turn off the appliance
immediately and pull the plug to avoid overheating.
Operate according to the instructions ´Trouble
shooting guide`.
• Do not use the appliance if it is damaged or
units of the appliance are damaged. Do not use
the appliance if it does not function properly or if
it was excessively loaded. The appliance is likely damaged if the appliance or units of the
appliance show cracks, exorbitant wearing
down, alterations or leaks. It is also likely damaged
if the drive wheel of the motor block moves slowly.
Take the appliance for technical maintenance
and repair to an authorised specialised reparation
shop. Reparation and technical maintenance of
the appliance or line cord are just allowed to be
accomplished by an authorised specialist reparation
shop.
• The appliance is not suitable for mincing nuts,
chocolate or similar ingredients. The appliance
is not suitable to make minced meet or to blend
food.
Important Safeguards for all Electrical
Appliances
• Always uncoil the line cord completely before
installing the appliance.
• Place the appliance close to a power point
and connect it directly without using any extension
cords to avoid additional risks of injury through
fire or voltage.
• Only install the appliance in proper form
secure grounding receptacle with adequate
electric power supply (alternating current;
230/240 V, 50 Hz) and ground fault circuit
interrupter. The maximum power consumption of the
appliance is 450 Watt. You should also install a fuse
with a release current of maximum 30mA. If
necessary ask your electrician for help.
• Never pull, rip, bend, clamp, squish or knot the
line cord. Pay attention to the line cord not
hanging of the table. Attend to nobody getting
caught in loops of the line cord or pulling the
appliance of the work space. When pulling the
plug always catch hold of the enclosure of the plug.
• Do not immerse the motor housing or power
cord in water or any other liquid. Do not pour
or drip any liquids on the motor housing or power
cord. When liquids are spilled on the motor
4
Important Safeguards for all Electrical Appliances
housing, immediately unplug the appliance and
dry the motor housing to avoid risk of electric
shock or fire. Do not attempt to operate the
appliance, when liquids are on or in the motor
housing.
Movable and sharp-edged units – risk
of injury
• The feed chute is designed exceedingly large.
Never put fingers, wooden spoons or other
foreign substance (such as hair, clothing, brushes,
cloths) into the feed chute when the appliance is
plugged into the power point.
• Always turn the appliance off, wait for the
motor to stop moving and then pull the plug
before taking off the lid of the juicer.
• Only use the provided food pusher to push
food through the feed chute.
• Never hold your face or other body parts
over the feed chute when the motor is running
because little pieces of food could be thrown out
of the feed chute.
• The blades on the base of the stainless steel
micro mesh filter and inside the feed chute are
very sharp. Pay attention when handling the
units. Only touch the stainless steel micro mesh filter
on the edge and handle with care when cleaning with
the nylon bristle brush. Only store the appliance
completely assembled. This way the blades will be
out of reach.
• Never put foreign substance or hard objects
into the feed chute. Remove all inedible parts
(such as stem, hard peeling and seeds) of the
food before putting them into the feed chute.
• The motor pursues running for a little while
after turning the appliance off. Wait until the
motor stops running completely before you
open or move the appliance.
5
Get to know your Gastroback juicer
Food pusher with cannelure:
for pushing whole fruit and vegetables down
the feed chute
Patented extra wide feed chute: You can fill in
whole fruit such as apples, carrots, tomatoes
and peeled oranges. For quick and easy juicing
of fruit and vegetables.
Juicer cover (dishwasher safe) with interlocking
safety arm: stops the juicer operating without
the juicer cover locked in place.
Large pulp container with integrated handle
(dishwasher safe)
Motor block with 450 Watt motor
On-/Off-switch
6
Stainless steel micro mesh filter basket
(dishwasher safe)
Safety arm
Customer designed juice nozzle: perfect
for mess free juicing straight into a glass
(dishwasher safe)
Rubberfeet
7
Assembling your Design Juicer Basic
Step 1:
Place the filter bowl surround on the motor block
(picture 1).
Step 2:
WARNING: Handle the units with care and do
not use any force. Pay attention to the sharp
!
blades on the stainless steel micro mesh filter
and the feed chute to avoid injury. Always
completely assemble your juicer before you
plug the plug into the power point.
1
ATTENTION: Ensure the stainless steel filter
basket is clean before assembling. Any dehumidified
!
left over food on the basket will block the fine
mesh holes. If necessary remove excess fibre
build up (from fruit or vegetables) according to
the instructions ´Care and Cleaning`.
Align the arrows on the stainless steel filter basket
with the arrows on the motor drive coupling and
push down until it clicks into place. Ensure the
stainless steel filter basket is fitted securely
inside the integrated pulp container and onto
the motor base (picture 2)
Step 3:
Place the juicer cover over the stainless steel filter
on top of the filter bowl surround (picture 3). The
feed chute has to be positioned in the middle of
the filter basket and the pulp spouting of the cover
has to face away from the interlocking safety arm.
2
3
8
Assembling your Design Juicer Basic
Step 4:
Raise the safety locking arm straight up and lock
into the two grooves on either side of the juicer
cover. The safety locking arm should now be in a
vertical position and locked into place on top of the
juicer cover (picture 4).
IMPORTANT: If the safety locking arm is not in the
right position the motor will not start moving.
4
Secure the safety arm by lifting it into the two
grooves of the cover (picture 4a).
Step 5:
Slide the food pusher down the feed chute by
aligning the groove of the food pusher with the
small protrusion on the inside of the top of the
feed chute. Continue to slide the food pusher
down the feed chute (picture 5).
4a
Food
Pusher
Groove
5
9
Assembling your Design Juicer Basic
Slide the food pusher all the way down the feed
chute (picture 5a)
Step 6:
Place the pulp container into position by tilting
the motor base slightly to the right. Insert the
container under the juicer cover on the left-hand
side ensuring it is supported by the container
support extending from under the motor base
(picture 6).
NOTE: To minimise cleaning, line the pulp container
with a plastic freezer bag to collect the pulp. Pulp can
then be used in other dishes, or as compost for the
garden or discarded.
Step 7:
Fit the custom-designed juice nozzle over the juice
spout and place a glass underneath. The juice
nozzle will prevent splatter, ensuring mess free
juicing (picture 7).
5a
6
Operating your Design Juicer Basic
WARNING: Make sure the appliance is
completely assembled and that there are nor
foreign objects in the feed chute before putting
the plug into the power point.
Never put fingers, wooden spoons or other
foreign substances (such as hair, clothing, brushes,
cloth) into the feed chute.
Always turn the appliance off and wait for the
motor to stop moving before removing the lid of
the juicer.
7
Keep the working place clean and dry. Do not
let any liquids or water run into the motor block.
Do not put any cloth or napkins underneath
the appliance to avoid endangering by fire and
voltage. In case that water or other liquids ran
into the motor block while operating turn off the
appliance immediately, pull the plug and dry
the appliance with a clean cloth. Operate
according to the instructions ´Trouble shooting
guide`
10
Operating your Design Juicer Basic
Step1:
Wash your selection of fruit and vegetables
before juicing.
NOTE: Most fruit and vegetables such
as small apples, carrots and cucumber
will not need to be cut to size as these
!
will fit into the feed chute whole. When
juicing carrots place the tip of the carrot
into the feed chute last.
Step 2:
Ensure the juicer is correctly assembled. Ensure
the stainless steel filter is thoroughly cleaned before
each use (refer to ´Care and cleaning`). Ensure
you place a glass or jug under the spout before
commencing juicing.
Step 3:
Plug the power cord into a 230/240V power
outlet and turn the power ‘ON’. Push the
‘ON/OFF’ button to ‘ON’.
Step 4:
With the motor running, place food into the
feed chute. Using the food pusher, gently
guide food down the feed chute.
To minimise cleaning, line
the pulp container with a
plastic freezer bag to
collect the pulp.
Empty the pulp container during juicing
The pulp container can be emptied during juicing
by turning the appliance ‘Off’ at the control panel
and then carefully removing the pulp container.
Remove the pulp container by tilting the pulp
container slightly to the right and unlatch it
from under the juicer cover and the container
support extending from under the motor base.
Replace the empty pulp container into position
before continuing to juice.
NOTE: Do not use force removing the pulp
container to avoid damage to the juicer cover.
To extract the maximum amount of
juice, always push the food pusher
down slowly.
Slowly push
down the food
pusher to get the
most profitable
amount of juice
Step 5:
Juice will flow into the glass and the separated
pulp will accumulate in the integrated pulp
container.
ATTENTION: Do not allow the pulp container to
overfill as this may affect the operation of the
appliance (refer to disassembling instructions).
Reassemble machine to continue juicing.
NOTE: In case that the appliance slows down,
stumbles or stops all of a sudden turn off the
appliance immediately and pull the plug to
avoid overheating. Operate according to the
instructions ´Trouble shooting guide`.
WARNING: Never use fingers to push food
down the feed chute or to clear the feed chute.
Always use the food pusher provided.
NOTE: Pay attention not to overflow the glass
or jug.
As soon as you finished operating turn the
appliance ´OFF`. Always turn the appliance
´OFF` and pull the plug when the appliance is
not in use and you finished the operation.
Clean the appliance in accordance to the
instructions in chapter ‘Care and Cleaning`. Do
not leave any food dry on the surfaces of the
appliance or the filter basket.
11
Disassembling your Design Juicer Basic
WARNING: Always turn the appliance ‘OFF’
and pull the plug when the appliance is not in
use or when disassembling, moving or cleaning
the appliance. Never let water or other liquids
run into the motor block. Never clean the line
cord or the motor block in the dishwasher, poor
liquids over the appliance or douse or dip it in
water or other liquids.
Step 1:
Push the ‘ON/OFF’ button on the juicer to ‘OFF’
and then switch ‘OFF’ at the power outlet and
unplug. IMPORTANT: Wait for the filter basket
to stop spinning before continuing to step 2
Carefully remove the pulp container by tilting
the pulp container slightly to the right and
unlatch it from under the juicer cover and the
container support extending from under the motor
base (picture 1).
1
Step 2:
Pull the locking arm back over the grooves on
either side of the juicer cover (picture 2/3).
Move the locking arm down.
Step 3:
Lift the juicer cover off the juicer (picture 4).
2
3
4
12
Disassembling your Design Juicer Basic
Step 5:
Remove the filter bowl surround with the stainless
steel filter basket still in place. To remove the
filter bowl turn the spout to the left side. The filter
bowl surround will automatically get loose
(picture 5).
Step 6:
WARNING: The stainless steel filter basket
contains small sharp blades to cut and process
!
fruit and vegetables.
Do not touch blades when handling the filter
basket. Only touch the filter basket on the sides.
5
To remove the stainless steel filter basket from
the filter bowl surround turn the filter bowl
surround upside down (picture 6). For easy
cleaning, it is recommended to remove the filter
basket over the sink.
Step 7:
Pull the nozzle off the spout.
6
7
13
Care and Cleaning
WARNING: Always ensure that the juicer is
switched off at the power outlet. Then remove the
!
plug from the power outlet before cleaning,
dissembling and storing the appliance. Do not
immerse the motor base in water or any other
liquid. Do not use water jet to clean the motor
base. Do not clean the motor base in the dishwasher.
The centre of the filter basket and feed chute
contain small sharp blades to process fruit and
vegetables during the juicing function. Do not
touch blades when handling the filter basket or
feed chute.
ATTENTION: Abrasive and strong cleaner
damage the surface of the plastic units and
could cause discolouration. Never clean the
appliance or units with abrasive and strong cleaner.
For easier cleaning and to avoid discolouration:
Clean as you go and avoid dried on juice or
pulp residue. Immediately after each use, rinse
removable parts in hot water to remove wet pulp.
Otherwise discolouration of the plastic may occur
with strongly coloured fruit and vegetables. Allow
parts to air dry.
Never use hard or sharp-edged subjects when
using or cleaning the juicer or the stainless steel
micro mesh filter. Do not use force when using
the appliance to avoid damages. Always
assemble the appliance completely before storing.
The units are protected this way and can not get
lost.
Ensure the juicer is correctly disassembled.
Refer to ´Disassembling your Design Juicer
Basic`. Follow these instructions to clean all
surfaces of parts that come into contact with
food during normal use.
Filter bowl surround, juicer cover, stainless steel
micro mesh filter and pulp container are dishwasher
safe (top shelf only). Use a program to be
suited for glasses (low temperature). A program
with high temperature might cause discolouration
and distortion of the plastic units. Plastic units
might tarnish being frequently cleaned in the
dishwasher.
IMPORTANT: Do not clean the food pusher in
the dishwasher.
IMPORTANT: Soak the stainless steel filter basket
in hot soapy water for approximately 10 minutes
immediately after juicing is completed. If pulp
dehumidifies on the micro mesh filter it may clog
the fine pores of the micro mesh filter thereby
lessening the effectiveness of the juicer.
Using the cleaning brush,
hold the filter basket under
running water and brush
from the inside of the basket
to the outer rim. Avoid
touching the small sharp blades in the centre of
the filter basket. After cleaning the filter basket,
hold it up towards a light to ensure the fine mesh
holes are not blocked. If the holes are blocked,
soak the filter basket in hot water with 10%
lemon juice to loosen the blocked holes.
Alternatively, wash the filter basket in the dishwasher.
NOTE: Alternatively you can soak the filter
basket in hot water with dental prosthesis
detergent. Rinse thoroughly with clear water
and he provided nylon brush.
IMPORTANT: Do not soak the stainless steel
filter basket in bleach. Always treat the filter
basket with care as it can be easily damaged.
NOTE: To minimise cleaning, line the pulp
container with a plastic freezer bag to collect the
pulp. Pulp can then be used in other dishes (see
recipes), or as compost for the garden or discarded.
Wipe the motor base with a damp cloth. Ensure
of no water intrusion into the inside of the motor block.
Allow parts to air dry or thoroughly dry them
with a clean cloth. Always assemble the appliance
completely before storing (regard ´Assembling
the appliance`). The units are protected this way
and can not get lost. Keep all parts out of reach
of children.
IMPORTANT: Do not clean the nozzle in the
dishwasher to avoid damage to the plastic.
WARNING: Please store the juicer in a frost-free,
clean and dry location where it is out of reach of
children and is protected against excessively loads
(such as down-fall, voltage, heat, humidity). Never
lay heavy or hard objects on top of the appliance.
14
Trouble Shooting Guide
Possible problem Easy solution
Machine will not work when
switched ´ON´
Motor appears to stall when
juicing
Excess pulp building up in
the micro mesh filter basket
Pulp too wet and reduced
extracted juice
Juice leaks between the rim
of the juicer and the cover
of the filter
Bowl surround juice sprays
out from spout
Juicer makes loud noise
when turned on
The safety locking arm may not be correctly engaged in the vertical operating
position with the locking arm located into the two grooves on either side of the
juicer cover (regard ´Assembling the appliance)`.
Wet pulp can build up under the cover if the juicing action is too vigorous. Try
slower juicing action by pushing the food pusher down more slowly. Clean the
integrated pulp container, the stainless steel filter basket and the juicer cover
(regard ´Clear blockage`).
Stop the juicing process. Remove the juicer cover, scrape off pulp. Assemble and
begin juicing again. Try alternating (soft and hard) vegetable and fruit varieties.
Try a slower juicing action by pushing the food pusher down more slowly.
Remove stainless steel filter basket and thoroughly clean mesh walls with the nylon
brush. Rinse the stainless steel filter basket under hot water. If the fine mesh holes
are blocked, soak the stainless steel filter basket in a solution of hot water with
10% lemon juice to unblock the holes or wash in the dishwasher. This will
remove excess fibre build up (from fruit or vegetables) which could be inhibiting
the juice flow.
Try a slower juicing action by pushing the food pusher down more slowly. Fruit
and vegetables with a high water content (tomatoes and watermelon) should be
juiced on low speed.
Try a slower juicing action by pushing the food pusher down more slowly.
Filer basket is not properly snapped into position. Turn the On/OFF button to
OFF. Turn the power OFF. Disassemble the Design Juicer Basic (refer to ´disassembling`).
Assemble (refer to ´assembling`).
No juice coming out while
juicing
Check that the spout is not blocked with pulp. Refer to ´Care and Cleaning`.
TToo cclleeaarr bblloocckkaaggee
When juicing hard or stringily fruit or vegetables, or if you push down the food pusher too fast or with too
much pressure or the juicing action is too vigorous, wet pulp can build up under the juicer cover or
the motor appears to stall when juicing. Wet pulp would block the fine mashes of the filter basket. Try slower
juicing action by pushing the food pusher down more slowly. Follow Disassembling and Cleaning instructions
and clean the filter bowl surround, the stainless steel filter basket and the juicer cover.
11..
Turn the appliance off, wait for the motor to stop moving and pull the plug.
22..
Disassemble the appliance according to the instructions.
WWAARRNNIINNGG::
33..
Remove residue of food on the filter basket with a small wooden or plastic spoon.
44..
Assemble the appliance according to the instructions and continue juicing.
55..
If another blockage occurs clean the appliance according to the instruction ´Care and Cleaning`.
To avoid further blockage:
• When juicing hard or stringily fruit or vegetables choose a high speed.
• Remove very hard and stringily elements such as stalks and stems.
• Try slower juicing action by pushing the food pusher down more slowly.
• Avoid overloading pulp in the pulp container. The pulp has to be able to fall easily and unhindered
into the pulp container.
• Try other fruit and vegetables.
Do not touch blades when handling the filter basket.
15
Tips on juicing
The inside information on juicing
Although juice drinks are usually developed
with flavour, texture and aroma at the forefront,
the health benefits certainly add to the pleasurable taste experience.
95% of the nutrient content of fruit and vegetables
is found in the juice. Liquids extracted from fresh
fruit and vegetables form an important part of a
wellbalanced diet. Fresh fruit and vegetable
juices are an easy to make source of vitamins
and minerals.
Juices are rapidly absorbed into the blood stream
therefore being the quickest way in which the
body can digest nutrients. When you make your
own juices, you have complete control over
what you include in them. You select the ingredients
and decide if you need to use sugar, salt or
other flavouring agents. Freshly extracted juices
should be consumed just after they have been
made to avoid a loss of vitamin content.
Purchasing and storage of fruit and vegetables
• Always wash fruit and vegetables before
juicing.
• Always use fresh fruit and vegetables for
juicing.
• To save money and obtain fresher produce,
purchase fruit or vegetables that are in season.
• Keep your fruit and vegetables ready for
juicing by washing them before storing.
• Most fruits and hardier type vegetables can
be stored at room temperature. The more
delicate and perishable items such as tomatoes,
berries, leafy greens, celery, cucumber
and herbs should be stored in the refrigerator
until required.
Preparation of fruit and vegetables
• If using fruit with hard or inedible skins
such as mangoes, guava, melons or pineapple,
always peel before juicing.
• Citrus fruit can be juiced in the juicer if
peeled first.
• All fruits with pits, hard seeds or stones such
as nectarine, peaches, mangoes, apricots,
plums and cherries must be pitted before
juicing.
• A small amount of lemon juice can be
added to apple juice to prohibit browning.
NOTE:
Your juicer makes invigorating, frothy orange
juice. Simply peel the oranges and juice.(It is
best to refrigerate oranges before juicing).
16
The right technique
When juicing a variety of ingredients with varying
textures start with the softer textured ingredients
then change to for harder texture ingredients. If
you are juicing herbs, sprouts or leafy green
vegetables either wrap then together to form a
bundle or juice them in the middle of a combination
of ingredients to obtain the best extraction.
If juicing herbs or leafy green vegetables on
their own, the juice yield will be low due to the
nature of centrifugal juicing, it is advised to
juice them as with a combination of other fruit
and vegetables.
Getting the right blend
It is easy to create great tasting juice. If you
have been making your own vegetable and fruit
juices, then you know how simple it is to invent
new combinations. Taste, colour, texture and
ingredient preferences are a personal thing. Just
think of some of your favourite flavours and
foods – would they work well together or would
All fruit and vegetables produce different
amounts of liquids. This varies within the same
group i.e. one batch of tomatoes can produce
more juice than another batch. Since juice
recipes are not exact, the precise quantities of
any juice are not crucial to the success of a particular mixture.
NOTE:
To extract the maximum amount of juice always
push the food pusher down slowly.
they clash. Some strong flavours could over
power the more subtle flavours of others. It is
however, a good rule of thumb to combine starchy,
pulpy ingredients with those high in moisture.
Using the pulp
The remaining pulp left after juicing fruit or vegetables is mostly fibre and cellulose which, like
the juice, contains vital nutrients necessary for
the daily diet and can be used in many ways.
However, like the juice, pulp should be used
that day to avoid loss of vitamins.
Some of the uses of pulp are to bulk out rissoles,
thicken casseroles or soups or in the case of
fruit, simply placed in a bowl topped with
meringue and baked for a simple dessert. Quite
apart from the consumption use, pulp is great
used in the garden for compost.
NOTE:
When using the pulp, there may be some pieces
of fruit or vegetables remaining. These should
be removed before using the pulp in any recipes.
17
Fruit and vegetable facts
Fruit and vegetables
Apples
Apricots
Beetroot
Broccoli
Brussels Sprouts
Cabbage
Carrots
Cauliflower
Celery
Cucumber
Fennel
Kiwi Fruit
Mangoes
Melons including
Watermelon
nectarine
Oranges
Peaches
Pears
Pineapples
Plums
Tomatoes
Best season
to buy
Autumn/Winter
Summer
Winter
Autumn/Winter
Autumn/Winter
Winter
Winter
Autumn/Winter
Autumn/Winter
Summer
Winter/Spring
Winter/Spring
Summer
Summer/Autumn
Summer
Autumn/Winter
Spring
Summer
Autumn
Summer
Summer
Summer
Storage
Vented plastic bags in refrigerator
Unwrapped in crisper of refrigerator
Cut off tops, then refrigerate unwrapped
Plastic Bag in refrigerator
Unwrapped in crisper of refrigerator
Wrap, trimmed in the refrigerator
Uncovered in refrigerator
Remove outer leaves, store in Plastic bag in
refrigerator
Refrigerate in plastic bag
Crisper in refrigerator
Crisper in refrigerator
Crisper in refrigerator
Refrigerated
Crisper in refrigerator
Crisper in refrigerator
cool and dry place for 1 week, transfer to
refrigerator keep longer
Refrigerate uncovered
Refrigerate uncovered
Refrigerate uncovered
Refrigerate uncovered
Uncovered in crisper of refrigerator
Nutritional value
High in Dietary Fibre and Vitamin C
High in Dietary Fibre, Contains Potassium
Good source Folate and Dietary Fibre,
Vitamin C and Potassium
Vitamin C, Folate, B2, B5, E, B6 and
Dietary Fibre
Vitamin C, B2, B5, E, Folate and Dietary
Fibre
Vitamin C, Folate, Potassium, B6 and
Dietary Fibre
Vitamin A, C, B6 and Dietary Fibre
Vitamin C, B5, B6, Folate, Vitamin K and
Potassium
Vitamin C and Potassium
Vitamin C
Vitamin C and Dietary Fibre
Vitamin C and Potassium
Vitamin A, C, B1, B6 and Potassium
Vitamin C, Folate, Dietary Fibre and
Vitamin A
Vitamin C, B3, Potassium and Dietary Fibre
Vitamin C 35 mg/100 g
Vitamin C, B3, Potassium and Dietary Fibre
Dietary Fibre
Vitamin C
Dietary Fibre
Vitamin C, Dietary Fibre, Vitamin E, Folate
and Vitamin A
Kilojoule/calories count
200g Apple=300 Kj (72 cals)
30g Apricot=85 Kj (20 cals)
160g Beetroot
=190Kj (45 cals)
100g Broccoli
=195Kj (23 cals)
100g Brussels Sprouts
=110Kj (26 cals)
100g Cabbage
=110Kj (26 cals)
120 g Carrots
=125 Kj (30 cals)
100 g Cauliflower
=55 Kj (13 cals)
80g Celery= 55 Kj (7cals)
280g Cucumber
=120 Kj (29 cals)
300g Fennel=145 Kj (35cals)
100 g Kiwi Fruit
=100 Kj (40 cals)
240 g Mango
=200 Kj (48 cals)
200 g Melon
=210 Kj (50 cals)
80 g nectarine
=355 Kj (85 cals)
150g Orange
=160Kj (38 cals)
150g Peach
=205Kj (49 cals)
150 g Pears=250 Kj (60 cals)
150 g Pineapple
=245 Kj (59 cals)
70 g Plums=110 Kj (26 cals)
100g Tomatoes
= 90Kj (22 cals)
18
Recipes
19
Fresh starts
Apple-Carrot-Celery-Juice
You may alter the amounts of either the carrots
or apple to make the juice sweeter or savoury
to suit your taste buds:
Makes 2 cups:
4 small Granny Smith apples
3 medium sized carrots, trimmed
4 sticks celery
Process apples, carrots and celery through
juicer. Mix well and serve immediately.
Tomato-Carrot-Celery-Lime-Juice
Makes 3 cups:
2 medium tomatoes
1 large carrot, trimmed
2 celery stalks, trimmed
1 lime, peeled
Process tomatoes, carrot, celery and lime
through juicer. Serve immediately.
Carrot-Beetroot-Orange-Juice
Makes 2 cups:
2 medium carrots, trimmed
3 medium beetroot, trimmed
4 oranges, peeled
Process carrots, beetroot and oranges through
juicer. Serve immediately.
Apple-Peach-Grapefruit-Juice
Makes 2 cups
1 small Delicious apple
2 large peaches, halved and seeds removed
2 grapefruits, peeled
Process apple, peaches and grapefruit through
juicer. Serve immediately.
Pineapple-Peach-Pear-Juice
Makes 3 cups
1/2 small pineapple, peeled and halved
2 peaches, halved and seeds removed
2 small ripe pears
Process pineapple, peaches and pears through
juicer. Serve immediately.
Apple-Pear-Strawberry-Juice
Makes 3 cups:
1 small Granny Smith apple
3 small ripe pears
1 cup strawberries, trimmed
Process apple, pears and strawberries through
juicer. Serve immediately.
Rockmelon-Mint-Mango-Juice
Makes 2 cups:
1/2 small rockmelon, peeled, seeded
and halved
3 sprigs fresh mint leaves
1 mango, halved, seeded and peeled
Process rockmelon, mint and mango through
juicer. Serve immediately.
Tomato-Cucumber-Parsley-Carrot-Juice
Makes 3 cups:
3 medium tomatoes
1 large cucumber
1 large bunch fresh parsley
3 medium carrots, trimmed
Process tomatoes, cucumber, parsley and carrots through juicer. Serve immediately.
Kumera-Celery-Ginger-Orange-Juice
Makes 3 cups:
4 sticks celery, trimmed
1 small kumera (sweet potato), peeled and halved
2.5 cm piece fresh ginger
4 oranges, peeled
1. Process celery, kumera, ginger and oranges
through juicer. Serve immediately.
Parsnip-Celery-Pear Juice
Makes 3 Cups:
2 parsnips, trimmed
4 sticks celery, trimmed
4 medium pears, stalks removed
Process parsnips, celery and pears through
juicer. Serve immediately.
20
Vitamin replacer
Tomato-Carrot-Red Capsicum-Juice
Makes 3 cups:
2 small red capsicum
3 medium tomatoes
3 carrots, trimmed
4 sprigs parsley
Trim base of capsicum and remove seeds.
Process tomatoes, carrots, parsley and capsicum through juicer. Serve immediately.
Blackberry-Pear-Grapefruit-Juice
Makes 3 cups:
250g blackberries
3 ripe pears
2 grapefruits, peeled
Process blackberries, pears and grapefruit
through juicer. Serve immediately.
Beetroot-Apple-Celery-Juice
Makes 2 cups:
4 medium sized beetroot, trimmed
2 medium Granny Smith apples
4 sticks celery
Process beetroot, apples and celery through
juicer. Serve immediately.
Cucumber-Celery-Fennel-Bean Sprout-Juice
Makes 3 cups:
1 large cucumber
3 sticks celery
1 bulb fennel, trimmed
2 cups bean sprouts
Process cucumber, celery, fennel and bean
sprouts through juicer. Serve immediately.
Frothie orange juice
Makes 8-10 cups:
Process oranges through juicer. Serve immediately. (Best to refrigerate oranges before juicing)
21
Liquid lunches
Fresh vegetable soup with noodles
Serves 4
1 small tomato
1 small onion, peeled and trimmed
2 carrots
1 green capsicum, base removed and seeded
1 tablespoon butter
1 tablespoon wholemeal flour
375ml vegetable stock
425g canned baked beans
1 packet 2 Minute Noodles
Freshly ground black pepper
Process tomato, onion, carrots and green pepper
through juicer. Melt butter in a large saucepan
over a medium heat. Stir in flour, cook for one
minute, stirring constantly.
Stir in the extracted juice, vegetable stock and
baked beans. Bring to the boil, then reduce
heat and allow to simmer for 10 minutes. Add
noodles, cook for 2 minutes or until noodles are
tender. Pour into 4 soup bowls, sprinkle with
black pepper to taste and serve immediately.
Pasta with provencal style sauce
Serves 4:
4 tomatoes
2 sprigs fresh parsley
1 stick celery
2 large cloves garlic
1 small onion, peeled and trimmed
1 red capsicum, base removed and seeded
1 tablespoon tomato paste
1/2 cup red wine
2 teaspoons dried oregano
500g cooked pasta
3 tablespoons grated Parmesan cheese
Process tomatoes, parsley, celery, garlic, onion
and red capsicum. Blend tomato paste with red
wine, stir in the extracted juice. Pour into a saucepan
and cook over medium heat for 3-4 minutes.
Add pasta and toss to coat pasta well. Divide
mixture between 4 serving bowls. Sprinkle with
oregano and Parmesan cheese. Serve immediately.
Gazpacho
Serves 4:
4 medium tomatoes
4 sprigs fresh parsley
1 large clove garlic, peeled
1 small onion, peeled and trimmed
2 carrots
2 stalks celery
1 red capsicum, base removed and seeded
1 lebanese cucumber
2 tablespoons red wine vinegar
freshly ground black pepper
1 cup crushed ice
3 tablespoons chopped fresh basil
Process tomatoes, parsley, garlic, onion, carrots,
celery, red capsicum and cucumber through
juicer.
Stir in vinegar and black pepper. Arrange ice in
four soup bowls. Pour in extracted juice, sprinkle
with basil and serve immediately.
Mango, rockmelon and orange yogurt drink
Serves 4:
1 mango, halved, peeled and seeded
1/2 small rockmelon, peeled, seeded and
cut into two equal portions
5 oranges, peeled
3 tablespoons natural yogurt
Process mango, rockmelon and oranges
through juicer. Pour into a large bowl whisk in
yogurt. Serve immediately.
22
Energy fuel
Grape, kiwi fruit and berry booster
Grapes contain potassium and iron, providing
a great pick-me-up after a strenuous day.
Makes 6 cups:
500g green seedless grapes, stems removed
2 kiwi fruit, peeled
250g strawberries, hulled
500ml skim milk
2 tablespoons powdered protein drink mix
1/2 cup crushed ice
Process grapes, kiwi fruit and strawberries
through juicer. Mix in milk, protein drink mix
and crushed ice. Serve immediately.
Beetroot, carrot and orange quencher
8 carrots
2 small beetroot, trimmed
1/4 cup fresh mint leaves
4 oranges, peeled
Process carrots, beetroot, mint leaves and
oranges through juicer. Serve immediately.
Apricot, apple and pear sparkle
Makes 4 cups
4 large apricots, halved and seeded
4 small red apples
3 medium pears
250ml sparkling mineral water
1/2 cup crushed ice
Process apricots, apples and pears through
juicer. Stir in mineral water and ice. Serve
immediately.
Spirited juices
Coconut pineapple colada
Makes 4 cups:
1/2 coconut, peeled and halved
1/2 large pineapple, peeled and quartered
3 tablespoons Malibu liqueur
500ml soda water
1 cup crushed ice
Process coconut and pineapple through juicer.
Stir in liqueur and soda water. Scoop ice into 4
tall glasses, pour over juice mixture, mix well to
combine. Serve immediately.
Bloody Mary
Makes 4 cups
4 medium tomatoes
2 sticks celery
1 large red capsicum, base removed
and seeded
1/3 cup Vodka
1 cup crushed ice
Process tomatoes, celery and red capsicum
through juicer. Stir in Vodka. Scoop ice into 4
glasses, pour over tomato mixture, mix well to
combine. Serve immediately.
Honeydew dream
Makes 4 cups:
1 honeydew melon, peeled, seeded
and quartered
3 tablespoons Midori liqueur
500ml soda water
1 cup crushed ice
Process honeydew melon through juicer. Stir in
liqueur and soda water. Scoop ice into 4 tall
glasses, pour over melon mixture, mix well to
combine. Serve immediately.
Peach and mint julep
Makes 4 cups:
6 peaches, halved and seeded
1/2 cup fresh mint leaves
2 tablespoons Creme de Menthe
2 teaspoons sugar
1/2 cup crushed ice
500ml mineral water
Process peaches and mint leaves through
juicer. Stir in Creme de Menthe and sugar.
Scoop ice into 4 glasses, pour over peach mixture, mix well to combine. Serve immediately.
23
Icy Coolers
Sparkling pear and apricot cooler
Makes 4 cups:
4 large apricots, halved and seeded
3 large pears
250 ml mineral water
1 cup crushed ice
Process apricots and pears through juicer.
Scoop ice into 4 tall glasses. Divide extracted
juice between the glasses. Top with mineral
water, stir well to blend. Serve immediately.
Rockmelon, strawberry and passion crush
Makes 4 cups:
1/2 rockmelon, peeled, seeded and divided
into 2 equal portions
250g strawberries, hulled
pulp of 2 passion fruit
1 cup crushed ice
Process rockmelon and strawberries through
juicer. Stir in passion fruit pulp. Scoop ice into 4
glasses, pour over juice, mix well to combine. Serve
immediately.
Tomato, nectarine, passionfruit and mint icer
Makes 4 cups:
6 tomatoes
2 nectarine
1/2 cup fresh mint leaves
pulp of 4 passion fruit
1 cup crushed ice
Process tomatoes, nectarine and mint leaves
through juicer. Stir in passionfruit pulp.
Scoop ice into 4 glasses, pour over juice, mix
well to combine. Serve immediately.
Cucumber, pineapple and coriander ice
Makes 4 cups:
1/2 small pineapple, peeled and halved
2 cucumber
1/2 cup fresh coriander leaves
1 cup crushed ice
Process pineapple, cucumber and coriander
through juicer. Scoop ice into 4 glasses, pour over
juice, mix well to combine. Serve immediately.
Tropical blend
Makes 4 cups
2 mangoes, halved, seeded and peeled
3 kiwi fruit, peeled
1/2 small pineapple, peeled and halved
1/2 cup fresh mint leaves
1 cup crushed ice
Process mangoes, kiwi fruit, pineapple and mint
through juicer. Scoop ice into 4 glasses, pour over
juice, mix well to combine. Serve immediately.
Pear, radish and celery crush
Makes 4 cups:
3 medium pears
4 radishes, trimmed
3 sticks celery
1 cup crushed ice
Process pears, radishes and celery through
juicer. Scoop ice into 4 glasses, pour over juice,
mix well to combine. Serve immediately.
24
Fibre favourites
Rather than waste the fibre from the fruit and
vegetables that have been juiced, the following
recipes have been developed using the left over pulp.
Carrot, pumpkin and feta flan
Serves 6:
8 sheets filo pastry
60g butter, melted
1 leek finely sliced
1 cup pumpkin pulp
1 cup carrot pulp
250g feta cheese, crumbled
3 eggs
1 egg white
1/2 cup milk
2 tablespoons orange rind
3 tablespoons chopped fresh parsley
Layer the sheets of pastry, brushing between
each sheet with butter. Lift pastry into a 25cm
flan tin, press over base and side. Trim pastry
edge to about 1.5cm higher than side of tin.
Combine leek, pumpkin, carrot, feta cheese,
eggs, egg white, milk, orange rind and parsley.
Pour into pastry case and bake at 180°C for
25-30 minutes or until golden and set.
Vegetable and bacon soup
Serves 4:
3 teaspoons butter
1 onion, finely chopped
1 ham bone
350g beetroot pulp, strained and
juice reserved
50g potato pulp, strained and juice reserved
50g carrot pulp, strained and juice reserved
100g tomato pulp, strained and juice reserved
50g cabbage pulp, strained and juice reserved
reserved juices and enough water to
make up 2 litres
4 bacon rasher, chopped
1 tablespoon lemon juice
1/2 cup sour cream
Melt butter in a large saucepan, cook onion
over a medium heat for 2-3 minutes or until golden.
Add ham bone to pan, stir in beetroot pulp,
potato pulp, carrot pulp, tomato pulp, cabbage
pulp, reserved juices and water, bacon and
lemon juice. Bring to the boil, reduce heat and
simmer for 30-40 minutes. Remove ham bone,
discard bone, finely chop meat and return to the
pan. Serve topped with sour cream.
Parsnip, herb and polenta hot cakes
Serves 6:
2 cups parsnip pulp, strained
1/4 cup milk
2 eggs, separated
1/4 cup polenta (corn meal)
1/4 cup self-raising flour
1 teaspoon chopped fresh thyme
1 teaspoon chopped fresh rosemary
1 teaspoon cajun seasoning
1 small red capsicum, finely chopped
1 tablespoon oil
Combine parsnip pulp, milk, egg yolks, self-raising
flour, polenta, thyme, rosemary, cajun seasoning
and red capsicum in a large mixing bowl. Beat
egg whites until soft peaks form, fold into parsnip
mixture. Heat oil in a large frying pan, drop
spoonfuls of mixture into pan. Cook for about 1
minute on each side or until golden. Serve
immediately.
Berry and white chocolate mousse
Serves 6
200g white chocolate
200g strawberry pulp
200g raspberry pulp
3 teaspoons gelatin dissolved in
3 tablespoons hot water
3 egg yolks
300ml carton thickened cream
1/4 cup icing sugar
2 tablespoons Grand Marnier
Melt chocolate over hot water, cool, being careful
not to let it set. Combine strawberry pulp and
raspberry pulp, set aside. Combine chocolate,
gelatin mixture and egg yolks, whisk until pale
and glossy. Beat cream until soft peaks form,
fold through chocolate mixture with berry pulp
and Grand Marnier. Pour into a wetted 5 cup
capacity mould. Refrigerate several hours or
overnight.
25
Fibre favourites
Family meat loaf
Serves 4-6
500g lean beef mince
500g sausage mince
2 onions, finely chopped
1/2 cup carrot pulp, strained
1/2 cup potato pulp, strained
2 teaspoons curry powder
1 teaspoon ground cumin
1 tablespoon chopped fresh parsley
1 egg, lightly beaten
1/2 cup evaporated milk
1/2 cup beef stock
Freshly ground black pepper
2 tablespoons slivered almonds
Tomato glaze
1/2 cup beef stock
4 tablespoons tomato sauce
1 teaspoon instant coffee powder
3 tablespoons Worcestershire sauce
11/2 tablespoons vinegar
11/2 tablespoons lemon juice
3 tablespoons brown sugar
1/4 cup butter
Place beef, sausage mince, onions, carrot pulp,
potato pulp, curry powder, cumin, parsley, egg,
evaporated milk, stock and black pepper in a
bowl, mix to combine. Press mixture into a lightly
greased 11cm x 21cm loaf pan. Pour glaze
over meat loaf, sprinkle with almonds and
bake, basting often with glaze, for 40 minutes.
To make glaze, place stock, tomato sauce, coffee
powder, Worcestershire sauce, vinegar, lemon
juice, sugar and butter in a saucepan and bring
to the boil over a medium heat. Reduce heat
and simmer, stirring frequently, for 8-10 minutes
or until glaze reduces and thickens slightly.
Serves 8:
30g butter
1 small onion, finely chopped
41/2 cups carrot, apple and celery
pulp, strained
(see juice recipe on page R3)
250g cottage cheese
2 tablespoons chopped fresh mint
1 egg, beaten
12 sheets filo pastry
60g butter, melted extra
1 cup grated fresh Parmesan cheese
Melt butter in a saucepan, add onion, cook for
2-3 minutes, or until soft, seasoning to taste.
Combine onion, carrot, apple and celery pulp,
cottage cheese, mint and egg in a bowl. Mix
well. Cut filo sheets in half, place 3 sheets on
bench, cover remaining pastry with greaseproof
paper, then a damp cloth to prevent drying. Brush
1 sheet of pastry with extra butter, sprinkle with
Parmesan cheese, top with another sheet of pastry,
brush with butter, sprinkle with more cheese.
Repeat with last sheet of pastry. Place tablespoons
of carrot mixture on one end of pastry, fold in
sides and roll up like a swiss roll. Repeat with
remaining pastry and pulp mixture. Place on a
greased oven tray and bake at 200°C for
20-25 minutes or until golden.
Carrot, apple and celery strudels
26
Fibre favourites
Carrot cake
Serves 16
13/4 cups plain flour
2 teaspoons baking powder
1/2 teaspoon nutmeg
1/2 teaspoon cinnamon
1/2 teaspoon cardamom
1/2 cup peanuts, chopped
1/2 cup sultana
1/2 cup brown sugar, firmly packed
11/2 cups carrot pulp
1/2 cup oil
2 eggs, lightly beaten
1/4 cup sour cream
Warranty
We guarantee that all our products are free of
defects at the time of purchase.
Grease and line a 25cm x 15cm loaf pan. Sift
flour and baking powder into a large mixing
bowl, add nutmeg, cinnamon, cardamom,
peanuts, sultana, brown sugar and carrot pulp,
stir to combine. Add eggs, oil and sour cream.
Beat with electric mixer, using medium speed
until all ingredients are well blended. Pour into
loaf pan. Bake at 180°C for 1 hour or until cake
is cooked when tested with a skewer. Remove
from oven, stand in cake pan for 5 minutes
before inverting out onto a wire cake rack.
inappropriate treatment, over loading or installation
mistakes.
Any demonstrable manufacturing or material
defects will be to the exclusion of any further claim
and within 2 years after purchasing the appliance
free of charge repaired or substituted.
There is no Warranty claim of the purchaser if the
damage or defect of the appliance is caused by
Waste disposal
The appliance has to be deposed by the definition of
the regional waste disposal of electricalscrap.
If necessary get information of the regional waste
management enterprise.
The Warranty claim expires if there is any technical
interference of a third party without an written
agreement.
The purchaser has to present the sales slip in
assertion-of-claims and has to bear all charges of
costs and risk of the transport.
27
Gewerbestraße 20 • D-21279 Hollenstedt/Germany
http://www.gastroback.de • E-Mail: info@gastroback.de
GASTROBACK GmbH
Loading...
