Page 1
ELECTRICAL
PROFESSIONAL ICE-CRUSHER
INSTRUCTIONS FOR USE
Art.-Nr. 41311 ELECTRICAL PROFESSIONAL ICE-CRUSHER
GASTROBACK
®
Page 2
• Never pull, rip, bend, clamp, squish or
knot the line cord. Pay attention to the line
cord not hanging of the table. Attend to
nobody getting caught in loops of the line
cord or pulling the appliance of the work
space.
When pulling the plug always catch hold of
the enclosure of the plug.
• Never leave children unsupervised when the
appliance or units of the appliance are in reach.
• Never let children play with the appliance or
units of the appliance. Children and invalid
people have to be supervised using the
appliance.
• Do not use the appliance if it is damaged
or units of the appliance are damaged. Do
not use the appliance if it does not function
properly or if it was excessively loaded. The
appliance is likely damaged if the appliance
or units of the appliance show cracks,
exorbitant wearing down, alterations or leaks. It
is also likely damaged if the drive wheel of the
motorblock moves slowly or water got into
the motorblock. Take the appliance for
technical maintenance and repair to an
authorised specialised reparation shop.
• Only use units, spare parts and supplies
which are provided and recommended by
the manufacturer. Damaged or improper
units may break in use, damage the appliance
or cause injury.
• Never clean the line cord, the appliance or
parts of the appliance in the dishwasher,
poor liquids over the appliance or douse or
dip it in water or other liquids.
• The appliance is only suitable for indoor use.
• Only use the appliance for the intended purpose.
Do not use the appliance in moving vehicles or
boats. Do not use the appliance outdoors.
• The work space has to be easily accessible,
solid, even, dry and of sufficient size.
• Do not use the appliance in moist and wet
areas.
• Do not put any cloth or napkins underneath
the appliance to avoid endangering by fire and
electric shocks.
• Never situate the appliance close to the
edge of the working area.
• Never leave the appliance unattended,
when the plug is plugged into the power
outlet.
• Always turn the appliance off and pull the
plug when the appliance is not in use or
when disassembling, moving or cleaning
the appliance.
• Make sure that the appliance is turned off
before pulling the plug out of the power
outlet.
• Never put your hands, hair, cloth or other
foreign substance into the deposit slot when
the plug is in the power outlet. If the crushing
gear is blocked or the motor stops moving
while the appliance is activated debug the
arrow referring to ´Trouble shooting`.
• Never hold your face or other body parts
over the feed chute when the motor is running
because little pieces of ice could be thrown
out of the deposit slot.
3
Please read all the advice and instructions with
care and keep the manual.
The Gastroback electrical Ice-Crusher is used for
crushing water icecubes and water icepieces
which do not exceed the seize of the deposit
slot and fit through the slot without using force.
The ice is getting crushed with a crushing gear
that runs on a 100 Watt motor.
The Ice-Crusher is easy to handle and is
maintenance-free . Clean the appliance after
every use regarding to the instructions ´Care
and cleaning`.
Gastroback recommends safety first
Introduction
We at Gastroback are very safety conscious.
We design and manufacture consumer products
with the safety of you, our valued customer foremost in mind. In addition, we ask that you exercise
a degree of care when using any electrical
appliance and adhere to the following precautions.
Carefully read all instructions before operating
and save for future reference.
Important safeguards
Please read all the advice and instructions with
care and keep the manual.
• Only use the appliance as stated and only
for thus use. Any non-appropriate use and
misusage can cause damages and heavy
personal injuries through voltage, fire and
moving units.
• Only proceed the appliance as described in
the directions.
• Reparation and technical maintenance of the
appliance or line cord are just allowed to be
accomplished by an authorised specialist
reparation shop.
• Do not use or store the appliance outdoors.
• Only use units, spare parts and supplies
which are provided and recommended by
the manufacturer.
• Never situate the appliance close to a
strong heat source or a hot surface (for
example: heater, stove or grill)
• Never clean the motor block or parts of the
appliance in the dishwasher.
• Make sure the deposit slot is empty and
place the ice bucket in the right position before
you turn on the power switch (refer to
´Assembling your Gastroback Ice-Crusher`).
The processed icecubes should not contain
any foreign substance.
After use remove the leftover ice in the deposit
slot.
• Always uncoil the line cord completely before
installing the appliance.
• Place the appliance close to a power point
and connect it directly without using any
extension cords to avoid additional risks of
injury through fire or voltage.
• Only install the appliance in proper form
secure grounding receptacle with adequate
electric power supply (alternating current;
220/240 V, 50 Hz) and ground fault circuit
interrupter. The maximum power consumption
of the appliance is 100 Watt. You should also
install a fuse with a release current of maximum
30mA. If necessary ask your electrician for help.
2
Page 3
Rinse all parts of the appliance before first usage.
Operate according to the instructions ´Care and
cleaning`.
WARNING – to avoid injuries and damages of
the appliance:
• Never put your hands, hair, cloth or other
foreign substance into the deposit slot when
the plug is in the power outlet.
• Never clean the line cord, the appliance or
parts of the appliance in the dishwasher.
1. Always ensure that the Ice-Crusher is switched off
at the power outlet. Then remove the plug
from the power outlet before cleaning
and storing the appliance.
Take out the leftover ice of the deposit slot
where appropriate. Refer to ´Trouble shooting`.
Place the empty ice bucket on the drip tray.
2. When you are using only pure waterice you
can move to step 3.
5
Care and cleaning
!
Before first usage or when using ice with additives
clean the deposit slot and the crushing gear
carefully with a bottle brush.
Never clean the appliance or parts of the
appliance with abrasive and strong cleaner.
Parts of the appliance are made of plastic
which can warp in hot water and could discolour,
get cloudy or scratched using abrasive or
strong cleaner. Dip the bottle brush in warm
water with a little dishwashing detergent and
carefully clean the appliance through the
disposal slot. Do not use any force. Rinse the
bottle brush with clear water and repeat the
procedure.
3. Rinse the deposit slot carefully with a little bit
of water.
4. Take out the ice bucket and empty it. Moisten
a clean, soft cloth with warm soapy water and
wipe the outside of the appliance and of the
ice bucket.
5. Dry the appliance and parts of the appliance.
Put the ice bucket afterwards back onto the
drip tray.
4
Know your Gastroback Professional Ice-Crusher
Ice bucket
ATTENTION: Stop pouring icecubes into the
deposit slot when the ice bucket is almost full
of the crushed ice to prevent blocking up the
crushing gear. Remove the ice bucket to serve
ice and put it back to operate again.
Drip gird and drip tray are made up of
stainless steel. They are moveable for
cleaning. Take out the drip tray to wash
when water or the crushed ice collects
on it.
Deposit slot
ATTENTION:
Icecubes must not exceed 30 x 30 x 30 mm
in size.
‘ON’ and ‘OFF’ switch
ON - I
OFF - 0
!
!
Assembling your Gastroback Ice-Crusher
1. Place the Ice-Crusher on a flat, dry surface
such as a bench top and prepare the Ice-Crusher
for use.
2. Place the drip grid on the drip tray. Slide the
units on the base of the appliance until they
are in the right position and finish off with the
front of the appliance.
3. Place the ice bucket in the intended space.
4. Put the plug into the power point.
Page 4
7
Trouble shooting
!
ATTENTION: While turning over the appliance
pay attention that no water will run into the
downside of the Ice-Crusher.
If needed dry the appliance before turning it
over. Joggle the icecubes carefully out of the
deposit slot.
3. Place the Ice-Crusher upright on the bench
top, dry if needed and place the ice bucket
onto the drip tray.
4. Plug the plug into the power outlet and turn
the appliance ´ON`.
The motor should be running again.
Otherwise please take the appliance for
repair to an authorised specialised reparation
shop.
When overloading the deposit slot or the
icecubes get filled into the deposit slot while
the motor is not running, the crushing gear can
blockup or the motor stops moving while
appliance is activated. Operate according to
following instructions:
1. Turn ´OFF` the appliance immediately and
pull the plug out of the power outlet.
2. Remove the leftover ice out of the deposit
slot. Operate according to following
instructions:
WARNING – To avoid injuries:
Never put your hands, hair, cloth or other
foreign substance into the deposit slot when
the plug is in the power point. Take out the
ice bucket. Turn the appliance over a bucket
or the sink to empty it.
!
Waste disposal
If necessary get information of the regional waste
management enterprise.
The appliance has to be deposed by the definition of
the regional waste disposal of electricalscrap.
Warranty
inappropriate treatment, over loading or installation
mistakes.
The warranty claim expires if there is any technical
interference of a third party without an written
agreement.
The purchaser has to present the sales slip in
assertion-of-claims and has to bear all charges of
costs and risk of the transport.
We guarantee that all our products are free of
defects at the time of purchase.
Any demonstrable manufacturing or material
defects will be to the exclusion of any further claim
and within 2 years after purchasing the appliance
free of charge repaired or substituted.
There is no warranty claim of the purchaser if the
damage or defect of the appliance is caused by
Before first usage: Rinse all parts of the
appliance. Operate according to the instructions
´Care and cleaning`.
Operating your Professional
Ice-Crusher
While operating the appliance condensed or
melt water could build up. Place a dry cloth
ready to dry off running down water.
WARNING – To avoid injuries caused by voltage:
Do not let any liquids or water run underneath
the motorblock and do not put any cloth or
napkins underneath the appliance to avoid
endangering by fire and voltage.
Place the motor base on a flat, dry surface such
as a bench top and prepare yourself for usage:
1. Make sure that there is no foreign substance
in the deposit slot.
2. Place the ice bucket on the drip tray.
3. Put the plug into the power outlet.
4. Push the ‘ON/OFF’ button to ‘I’.
ATTENTION: Only fill ice into the deposit slot
when the motor is operating and do not overfill
the deposit slot.
5. Start filling the ice into the deposit slot.
Never use force when filling the icecubes into
the deposit slot and watch out that no foreign
substance gets into the deposit slot.
WARNING: Never hold your face or other
body parts over the feed chute when the motor is
running because little pieces of ice could be
thrown out of the deposit slot.
6
Operating your Gastroback Professional Ice-Crusher
!
!
!
Never put foreign substance into the deposit
slot when the plug is in the power outlet to avoid
injuries caused by moving units of the appliance`s
crushing gear.
Empty the ice bucket the latest when it is filled
up to 3/4.
6. Turn ´Off` the appliance.
7. Take out the ice bucket.
ATTENTION: After 10 minutes of usage turn
´OFF` the motor for 10 minutes to allow the
motor to cool down to avoid overheating of the
motor.
After usage
8. When you are finished with the crushing of
the ice turn ´OFF` the appliance and unplug
the plug.
9. Empty the ice bucket and the deposit slot.
WARNING: If needed follow to the instructions
´Trouble shooting`.
10.Clean and dry the appliance according to
the instructions ´Care and cleaning`.
Storage
Always clean and dry the appliance before storing.
Place the ice bucket into the drip tray. Operate
according to the instructions ´Care and cleaning`.
Please store the juicer in a frost-free, clean and
dry location where it is out of reach of children
!
!
Page 5
GASTROBACK GmbH
Gewerbestraße 29
D-21279 Hollenstedt/Germany
http://www.gastroback.de
E-Mail: [email protected]
Loading...
