Gastroback 40118 User Manual
GASTROBACK
®
DESIGN
EASY JUICER
INSTRUCTIONS FOR USE
AND
INCLUDES RECIPES
Art.-Nr. 40118
Read all provided instructions before first usage!
Model and attachements are subject to change
Contents
Introduction....................................................................................................
Gastroback recommends safety first..................................................................
Movable and sharp-edged units - risk of injury...................................................
Know your Gastroback Easy Juicer...................................................................
Assembling your Gastroback Easy Juicer...........................................................
Operating your Gastroback Easy Juicer............................................................
Disassembling your Gastroback Easy Juicer.......................................................
Care and cleaning.........................................................................................
Storage.........................................................................................................
Trouble shooting guide....................................................................................
Tips on juicing................................................................................................
The inside information on juicing......................................................................
Purchasing and storage of fruit and vegetables..................................................
Preparation of fruit and vegetables...................................................................
The right technique........ ................................................................................
Getting the right blend...................... .............................................................
Using the pulp................................................................................................
Fruit and vegetable facts.................................................................................
Notes............................................................................................................
Recipes.........................................................................................................
Fresh starts....................................................................................................
Vitamin replacer............................................................................................
Liquid lunches................................................................................................
Energy fuel....................................................................................................
Spirited juices................................................................................................
Icy coolers.....................................................................................................
Fibre favourites..............................................................................................
Warranty.......................................................................................................
Disposal........................................................................................................
Notes............................................................................................................
3
3 – 5
5
6
7 – 8
9
10 – 11
11 – 12
12
13
14
14
14
14
15
15
15
16
17
18
19
20
21 – 22
22
22
23
24 – 26
26
26
27
Carefully read all provided instructions before you start running the appliance and pay
regard to the warnings mentioned in these instructions.
!
3
The current Interest in fresh and unprocessed food is
the reason for fresh fruit and vegetablejuices to
become a favorit component of our daily food
and wellbalanced diet.
The Gastroback juicer has a special designed large
feed chute, an integrated pulp container, a big juice
jug and a stainless steel micro mesh filter. It operates
with a high performance 900 watt motor which
makes the juice production easy and efficient.
The elaborate Design with the integrated pulp
container makes the cleaning an ease.
The units have a smooth surface with no grooves and
rough edges and can be cleaned easily after use.
The provided juice jug finishes with the juice
run-out and therefore eliminates any splatter
during operation. It has a volumetric capacity of
800 ml and a nice grip for easy and comfortable
handling.
Please read all the advice and instructions with
care and keep the manual.
Only use the appliance to process fresh food.
Gastroback recommends safety first
Introduction
We at Gastroback are very safety conscious.
We design and manufacture consumer products
with the safety of you, our valued customer foremost in mind. In addition, we ask that you exercise
a degree of care when using any electrical
appliance and adhere to the following precautions.
Carefully read all instructions before operating
and save for future reference.
Important safeguards for your
Gastroback Easy Juicer
Never leave the appliance unattended when in
operational mode.
• Only use the appliance as stated and only
for thus use. Any non-appropriate use and
misusage can cause damages and heavy
personal injuries through voltage, fire and
moving units.
• Only proceed the appliance as described in
the directions.
• Reparation and technical maintenance of the
appliance or line cord are just allowed to be
accomplished by an authorised specialist
reparation shop.
• Do not push products into the feed chute
with your fingers or foreign objects. Always
use the food pusher provided.
• Do not touch the small cutting blades in the
base of the stainless steel filter basket.
• Always make sure the Easy Juicer is properly
and completely assembled before connecting to
power outlet and operating. The unit will not
turn ‘ON’ unless properly assembled.
• Do not let the motor run permanently for longer
then 7 minutes to avoid overheating.
• Do not operate the Easy Juicer continuously
on heavy loads for more than 10 seconds.
None of the recipes in this book are considered
a heavy load.
• Only use the appliance indoors.
• Store and use the appliance in a clean, frost
free environment where it is protected from
dampness, moistness and immoderate and
extraordinary burden (such as: downfall,
beat, overheating, moisture in the motor
block) .
• Do not use or store the appliance outdoors.
• Store appliance and units out of reach of children
• While proceeding do not push the food
pusher too hard down. Empty the pulp container
and juice jug in time to avoid run-over and
splatter which might causes damages to the
appliance.
3
When proceeding hard or strigily food or if
you press the stamp down too hard the
motor could stop or slow down.
In this case turn off the appliance immediately
and pull the plug to avoid overheating.
Operate according to the instructions ´Trouble
shooting guide`.
• Do not leave food leftovers dehumidify on
the appliance or units of the appliance. If
pulp dehumidifies on the micro mesh filter
it may clog the fine pores of the micro mesh
filter thereby lessening the effectiveness of the
juicer. Remove such dirt immediately and operate
according to the instructions ´Care and cleaning`
before you continue to proceed.
• Never clean or operate the appliance or units
of the appliance with abrasive or hard
sharp-edged items.
• Never clean the motor block in the dishwasher.
• Never use force operating the appliance to
avoid damage of the units of the appliance.
• The appliance is not suitable for mincing
nuts, chocolate or similar ingredients.
• The appliance is not suitable to make minced
meet or to blend food.
ATTENTION: Extra wide feed chute. Do not
push products into the feed chute with your fingers
or other foreign substances. Always use the
food pusher provided.
• Always uncoil the line cord completely before
installing the appliance.
• Place the appliance close to a power point
and connect it directly without using any
extension cords to avoid additional risks of
injury through fire or voltage.
• Only install the appliance in proper form
secure grounding receptacle with adequate
electric power supply (alternating current;
230/240 V, 50 Hz) and ground fault circuit
interrupter. The maximum power consumption
of the appliance is 900 Watt. You should also
install a fuse with a release current of maximum
30mA. If necessary ask your electrician for help.
• Never pull, rip, bend, clamp, squish or knot
the line cord. Pay attention to the line cord
not hanging of the table. Attend to nobody
getting caught in loops of the line cord or
pulling the appliance of the work space.
When pulling the plug always catch hold of
the enclosure of the plug.
• Never situate the appliance close to a strong
heat source or a hot surface (for example:
heater, stove or grill)
• Never leave children unsupervised when the
appliance or units of the appliance are in reach.
• Never let children play with the appliance or
units of the appliance. Children and invalid
people have to be supervised using the
appliance.
• Do not use the appliance if it is damaged or
units of the appliance are damaged. Do not
use the appliance if it does not function properly
or if it was excessively loaded. The appliance
is likely damaged if the appliance or units of
the appliance show cracks, exorbitant wearing
down, alterations or leaks. It is also likely damaged
if the drive wheel of the motorblock moves
slowly. Take the appliance for technical
maintenance and repair to an authorised
specialised reparation shop.
• Only use units, spare parts and supplies
which are provided and recommended by
the manufacturer. Damaged or improper
units may break in use, damage the appliance
or cause injury.
• Never let water or other liquids run into the
motorblock.
• Never clean the line cord or the motorblock
in the dishwasher, poor liquids over the
appliance or douse or dip it in water or
other liquids. In case that water or other
liquids ran into the motorblock while operating
turn off the appliance immediately, pull the
plug and dry the appliance with a clean
cloth.
• The appliance is only suitable for indoor use.
• Only use the appliance for the intended purpose.
4
5
• The feed chute is designed exceedingly large.
Never put fingers, wooden spoons or other
foreign substance (such as hair, clothing,
brushes, cloths) into the feed chute when
the appliance is plugged into the power point.
• Always turn the appliance off, wait for the
motor to stop moving and then pull the plug
before taking off the lid of the juicer.
• Only use the provided food pusher to push
food through the feed chute.
• Never hold your face or other body parts
over the feed chute when the motor is running
because little pieces of food could be thrown
out of the feed chute.
• The blades on the base of the stainless steel
micro mesh filter and inside the feed chute
are very sharp. Pay attention when handling
the units. Only touch the stainless steel micro
mesh filter on the edge and handle with care when
cleaning with the nylon bristle brush. Only store
the appliance completely assembled. This way
the blades will be out of reach.
• Never put foreign substance or hard objects
into the feed chute. Remove all
inedible parts (such as stem, hard peeling
Do not use the appliance in moving vehicles or
boats. Do not use the appliance outdoors.
• The work space has to be easily accessible,
solid, even, dry and of sufficient size.
• Do not use the appliance in moist and wet
areas.
• Do not put any cloth or napkins underneath
the appliance to avoid endangering by fire and
electric shocks.
• Never situate the appliance close to the
edge of the working area.
and seeds) of the food before putting
them into the feed chute.
• The motor pursues running for a little while
after turning the appliance off. Wait until the
motor stops running completely before you
open or move the appliance.
Movable and sharp-edged units – risk of injury
• Never leave the appliance unattended,
when the plug is plugged into the power
point.
• Always turn the appliance off and pull the
plug when the appliance is not in use or
when disassembling, moving or cleaning
the appliance.
• Make sure that the appliance is turned off
before pulling the plug out of the power
point.
Know your Gastroback Easy Juicer
6
Food pusher:
for pushing whole fruit and vegetables
down the patented wide feed chute
Juicer cover:
(dishwasher safe)
Integrated pulp container:
will collect pulp for up
to 1.5 litres of apple juice
(dishwasher safe)
High performance
900 watt motor
‘ON’ and ‘OFF’ button
800 ml dishwasher
safe juice jug
Built in froth separator lid:
ensures juice froth is
separated from juice
when poured into a
glass (if preferred)
Unique patented centrally
located feed chute
Stainless steel micro mesh
filter basket (dishwasher
safe)
Cord wrap:
cord wraps around a raised disc on the base of the Easy Juicer (not shown in picture)
Spatula:
ruler style end of brush is to assist in the
removal of pulp from the integrated pulp
container when juicing large quantities
Nylon bristle brush:
included for easy cleaning of the micro mesh filter basket
Juicer spout
7
Before first usage: Rinse all the units of the appliance that come into contact with food with water
and clean them with dishwashing detergent.
Operate according to the instructions ´Care and
cleaning´.
WARNING:
Handle the units with care and do not use any
force. Pay attention to the sharp blades on the
stainless steel micro mesh filter and the feed chute
to avoid injury. Always completely assemble your
juicer before you plug the plug into the power
point.
Step1:
Place the motor base on a flat, dry surface such
as a bench top. Ensure that the motor base is
switched ‘OFF’ at the power outlet and the
power cord is unplugged.
Step 2:
Place the integrated pulp container on top of the
motor base. Locate the integrated pulp container
so that the spout fits through the hole on the front
of the motor base (Picture 1).
Step 3:
Align the arrows on the stainless steel filter basket
with the arrows on the motor drive coupling and
push down until it clicks into place. Ensure the
stainless steel filter basket is fitted securely inside
the integrated pulp container and onto the motor
base (Picture 2).
Step 4:
Place the juicer cover over the stainless steel filter
and integrated pulp container. The humps of the
rim of the juicer cover should align with the small
plastic wings on the integrated pulp container.
Lower into position. The juicing cover can be
positioned in either of the plastic wings on the
integrated pulp container. (Picture 3).
1
2
3
!
Assembling your Gastroback Easy Juicer
Step 5:
Raise the safety locking arm up and lock into the
two grooves on either side of the juicer cover. The
safety locking arm should now be in a vertical
position and locked into place on top of the juicer
cover (Picture 1 and 2).
Step 6:
Slide the food pusher down the feed chute by
aligning one of the grooves in the food pusher
with the small protrusion on the inside of the top
of the feed chute. Continue to slide the food
pusher down the feed chute (Picture 3).
Step 7:
Place the juice jug provided sideways under the
spout of the Easy Juicer. A graphic on the lid
shows where the juicer spout is to be placed.
Note the jug is designed to clip in under the
spout to give it a positive location. A glass
could also be used to collect the juice, but using
the jug and lid is recommended to avoid any
splatter.
1
2
4
8
Assembling your Gastroback Easy Juicer
3
Food
Pusher
Groove
Small protrusion inside feed tube.
WARNING: Make sure the appliance is com-
pletely assembled and that there are nor foreign
objects in the feed chute before putting the plug
into the power point.
Never put fingers, wooden spoons or other for-
eign substances (such as hair, clothing, brushes,
cloth) into the feed chute.
Always turn the appliance off and wait for the
motor to stop moving before removing the lid of
the juicer.
Keep the working place clean and dry. Do not
let any liquids or water run into the motorblock
Do not put any cloth or napkins underneath
the appliance to avoid endangering by fire and
voltage. In case that water or other liquids ran
into the motorblock while operating turn off the
appliance immediately, pull the plug and dry
the appliance with a clean cloth. Operate
according to the instructions ´Trouble shooting
guide`
Step1:
Wash your selection of fruit and vegetables
before juicing.
NOTE: Most fruit and vegetables such
as small apples, carrots and cucumber
will not need to be cut to size as these
will fit into the feed chute whole. When
juicing carrots place the tip of the carrot
into the feed chute last.
Step 2:
Ensure the Easy Juicer is correctly assembled.
Ensure the stainless steel filter is thoroughly cleaned
before each use (refer to ´Care and cleaning`).
Ensure you place the juice jug with lid fitted (or
glass) under spout before commencing juicing.
Step 3:
Plug the power cord into a 230/240V power
outlet and turn the power ‘ON’. Push the
‘ON/OFF’ button to ‘ON’.
Step 4:
With the motor running, place food into the
9
Operating your Gastroback Easy Juicer
!
!
!
!
feed chute. Using the food pusher, gently
guide food down the feed chute. To extract the
maximum amount of juice, always push the
food pusher down slowly.
NOTE: In case that the appliance slows down,
stumbles or stops all of a sudden turn off the
appliance immediately and pull the plug to
avoid overheating. Operate according to the
instructions ´Trouble shooting guide`.
WARNING: Never use fingers to push food
down the feed chute or to clear the feed chute.
Always use the food pusher provided.
Step 5:
Juice will flow into the juice jug and the separated
pulp will accumulate in the integrated pulp
container.
NOTE: When the integrated pulp container is
full of pulp, it must be emptied before continuing
to juice. (Refer to disassembling instructions).
Reassemble machine to continue juicing.
Slowly push
down the food
pusher to get the
most profitable
amount of juice
!
Loading...
