Gasmate GRHS User Manual

RANGEHOOD
WALL MOUNTED SMALL
Model No. GRHS
Important: Retain these instructions for future use.
03470 07/16
WARRANTY TERMS & CONDITIONS
This warranty is not transferable to a subsequent purchaser if the product is sold by the original purchaser during the warranty period.
If a warranty fault appears within the warranty period, S.G.A. reserves the right to replace or repair the product.
In the event that S.G.A. chooses to replace the product, this original warranty will expire at the original date.
If the product includes various accessories or components, only the defective accessory or component will be replaced or repaired.
S.G.A. Reserves the right to replace defective parts of the product with parts and components of similar quality, grade and composition where an identical part or component is not available.
Products presented for repair may be replaced by refurbished products of the same type rather than being repaired. Refurbished parts may be used to repair the products.
To make a warranty claim, first contact S.G.A’s Customer Service Line on the contact number below.
The purchase receipt for this product is to be retained and must be presented if making claim under the terms of this S.G.A. warranty.
Warranty repairs are free of charge, provided the product is delivered to our Service Department at 33-35 Lionel Road, Mt Waverley, Victoria, 3149 or to one of our Authorised Service Agents.
If a warranty fault is found the freight cost will be credited to the owner. If no fault is found the product will be returned and any costs associated with the service will be charged to the owner.
Products sent freight forward will not be accepted. In most cases the defective accessory or component only will need to be returned. The product or part of the product being returned must be adequately protected in a box.
S.G.A. will not be responsible for any in-transit loss or damage.
This warranty does not apply to any defect, deterioration, loss, injury or damage occasioned by or as a result of misuse or abuse, negligent handling or storage, normal wear and tear or if the product has not been installed and used in accordance with S.G.A.’s instructions, recommendations and specifications or if the product has been subjected to abnormal conditions. The warranty does not apply to blockages caused by insects or living organisms, as well as non-operating butterfly baffles or incorrectly installed ducts.
The warranty is void if there is evidence of the product being tampered with by unauthorised persons. The warranty does not extend to installation or disconnection costs.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. The benefits of this warranty are in addition to any rights and remedies imposed by Australian State and Federal legislation that cannot be excluded.
Product Approved For Outdoor Use Only
For warranty claims, service, spare parts or products information in Australia, please call SITRO GROUP AUSTRALIA Pty Ltd on the Customer Service Line 1300 174 876.
A receipt or proof of purchase is required and must be kept for your records.
CONTACT DETAILS
Sitro Group Australia Pty Ltd 33-35 Lionel Road, Mt. Waverley Victoria 3149, Australia Tel (+613) 9543 9533 Fax (+613) 9543 9839 sales@sitro.com.au
For any queries or assistance call
Customer Service
Australia Only
1300 174 876
Hours of operation:
Monday to Friday 8am - 5pm EST
Do not return to place of purchase.
2 32 2
Read all instructions before installing and operating this Rangehood.
This Rangehood is designed for use above an outdoor domestic gas (propane/natural) barbecue.
WHAT IS AN OUTDOOR AREA
An outdoor area is an open-air situation that is not obstructed by buildings, structures etc, facilitating correct combustion and allowing products of combustion to be readily dispersed to atmosphere.
An alfresco area, veranda or balcony (large area) is considered outdoors when it is an open-air situation with natural ventilation. This ensures stagnant areas do not form, as these prevent the products of combustion from being rapidly dispersed by wind and natural convection. In the unlikely event of a gas leak occurring, a well-ventilated area will allow escaping gases to rapidly disperse.
Parallel Walls Right Angle Walls
The following situations are considered to provide the natural ventilation required for an outdoor domestic barbecue or patio heater to be used:
• Four open sides with a roof or overhead cover.
• Four enclosed sides (walls) without a roof or overhead cover.
• Two parallel walls or two walls at right angles to each other with a roof or overhead cover.
• Three walls, with the one open side being at least 25 per cent of the total perimeter and the remaining three walls having an area of 30 per cent or more of unrestricted opening, with a roof or overhead cover.
30% or more in total of
the remaining wall area
is open and unrestricted
Open side at least 25% of total wall area
Electrical Data IMPORTANT SAFETY RULES
This rangehood is fitted with a sealed electrical connection plug that is compatible with the mains power supply for Australia / New Zealand and meets the requirements of Australian Standards. This rangehood must be connected to a supply voltage that is equal to that stated on the rating label. If the mains power connection plug or power cord becomes damaged it must be replaced with a complete assembly that is identical to the original, and this must be replaced by an authorised service centre. Always follow the Australian / New Zealand requirements for connection to the mains supply. If in doubt always consult a qualified electrician.
INSTALLATION - OUTDOOR USE ONLY
BALCONIES & VERANDAS
An outdoor barbecue or rangehood may be installed and used on a balcony or veranda if, by location and use, it will not cause a hazard and the manufacturer’s instructions allow for such use. It may also be necessary to consult local building laws before installing or using a gas barbecue on a balcony or veranda.
A balcony or veranda shallow in depth and with a roof and three enclosed sides is considered an acceptable area if the following applies:
• the depth of the balcony or veranda is smaller than or equal to its height; and
• the open face width is at least twice the depth.
Examples of these situations:
• A balcony with an open construction balustrade (more than 75 per cent free open area). Measure the distance from floor to roof ‘H’.
• The maximum allowable depth ‘D’ is the same as ‘H’ and the minimum width ‘W’ is twice ‘D’.
• A balustrade is enclosed or has less than 75 per cent free open area. Measure from the top of the balustrade to the roof ‘Ha’. The maximum allowable depth ‘D’ is the same as ‘Ha’ and the minimum width ‘W’ is twice ‘D’.
IMPORTANT
It is recommended that access doors or windows to the balcony or veranda be closed while the barbecue is in use. If unsure always consult with your local building authority and local gas authority.
SPECIFICATIONS
395 - 400mm
395 - 400mm
60mm
110mm
50mm
600mm
720mm
330mm
1200mm
4 54 4
