Garmin 760 Quick Start Manual

Quick Start Manual

®

nüvi

760

for Volvo® cars

personal travel assistant

WARNING: See the Important Safety and Product Information guide in the product box for product warnings
and other important information.

What’s in the Box?

nüvi GPS device.

USB cable to connect the nüvi to your computer.

Your nüvi connects to your computer as a mass

Headphone/audio

storage device.

AC adapter cable to receive power from a wall
outlet.

Carrying case to protect your nüvi from
scratches and accidental screen taps.

Quick Start Manual.

Ways to Charge Your nüvi

Use the vehicle mount.

•

Use the USB cable.

•

Use the AC adapter cable.

•

Mini-USB connector

Power key:

slide to the left to turn the unit on/off;

slide to the right to lock the screen

out jack

SD card slot

Microphone

GPS antenna

Serial number

External antenna connector

Speaker

2

WARNING: This product contains a non-user-replaceable lithium-ion battery. See the Important Safety and
Product Information guide in the product box for important battery safety information.

Step 1: Mount the nüvi

1. Flip the cradle open, toward the windshield.

2. Fit the bottom of your nüvi
into the cradle.

3. Tilt the nüvi back until it
snaps into place.

Your unit should turn on
automatically if it is in place
and your vehicle is running.

To remove the unit from the cradle, pull up the
release button on the back of the cradle and tilt
the unit towards you and remove it.

Step 2: Congure the nüvi

To turn on your nüvi, slide the Power key to
the left. Follow the on-screen instructions.

Step 3: Acquire Satellites

Go outdoors to an open area, out of garages, and
away from tall buildings. Stop your vehicle, and
turn on the nüvi. Acquiring satellite signals may
take a few minutes.

The bars indicate GPS satellite
strength. When one bar is green, the nüvi has
acquired satellite signals. Now you can select a
destination and navigate to it.

Step 4: Use the nüvi

A

B
C

D

E

F

G

H

I

A

B

E F

G

GPS satellite strength.

Bluetooth® technology status.

Battery status.

Current time; touch to change time

settings.

Touch to nd a destination.

Touch to view the map.

Touch to make a call when connected to

a compatible mobile phone.

Touch to adjust the volume.

Touch to use the tools such as media

players, settings, and Help.

C

D

H

I

3
