Garmin 76 User Manual
GPSMAP® 76
chartplotting receiver
owner’s manual
© Copyright 2006 Garmin Ltd. or its subsidiaries
Garmin International, Inc.
1200 East 151st Street,
Olathe, Kansas 66062, U.S.A.
Tel. 913/397.8200 or 800/800.1020
Fax 913/397.8282
All rights reserved. Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted,
disseminated, downloaded or stored in any storage medium, for any purpose without the express prior written consent of Garmin.
Garmin hereby grants permission to download a single copy of this manual onto a hard drive or other electronic storage medium to
be viewed and to print one copy of this manual or of any revision hereto, provided that such electronic or printed copy of this manual
must contain the complete text of this copyright notice and provided further that any unauthorized commercial distribution of this
manual or any revision hereto is strictly prohibited.
Information in this document is subject to change without notice. Garmin reserves the right to change or improve its products and
to make changes in the content without obligation to notify any person or organization of such changes or improvements. Visit the
Garmin Web site (www.garmin.com) for current updates and supplemental information concerning the use and operation of this and
other Garmin products.
Garmin®, GPSMAP®, AutoLocate®, TracBack®, BlueChart®, and MapSource® are registered trademarks of Garmin Ltd. or its
subsidiaries and may not be used without the express permission of Garmin.
Industrial Estate, Romsey, SO51 9DL, U.K.
Garmin (Europe) Ltd.
Unit 5, The Quadrangle, Abbey Park
Tel. 44/0870.8501241
Fax 44/0870.8501251
Garmin Corporation
No. 68, Jangshu 2nd Road, Shijr, Taipei
County, Taiwan
Tel. 886/2.2642.9199
Fax 886/2.2642.9099
March 2006 Part Number 190-00230-00 Rev. D Printed in Taiwan
IntroductIon > About thIs MAnuAl
IntroductIon
Thank you for choosing the Garmin GPSMAP 76.
The GPSMAP 76 utilizes the proven performance of
Garmin GPS and full-featured mapping to create an
unsurpassed portable GPS receiver. Take a moment
now to compare the contents of this package with
the packing list on the box. If any pieces are missing,
contact your Garmin dealer immediately.
About This Manual
To get the most out of your new navigation system,
take time to read this manual and learn the operating
procedures for your unit in detail. This manual is
organized into the following chapters.
The Introduction chapter contains the Table of Contents
as well as GPSMAP 76 care information.
The Getting Started chapter provides information
such as an overview of unit features and how to turn
the unit on and adjust the backlight. It also contains a
simulation to help you get acquainted with your new
GPSMAP 76.
The Basic Operation chapter provides you with
information about features such as using the Find
Menu, navigating a route, and using waypoints.
There are also step-by-step directions to assist you
in these operations.
The Main Pages chapter provides detailed explanations
about each page in the GPSMAP 76 and step-by-step
directions on using the pages. The Main Menu chapter
provides detailed explanations about the Main Menu
and how to use it to congure your unit.
The Appendix contains information such as
specications, optional accessories, and maintenance
information. You can also nd warranty and FCC
information in the Appendix. Read the Safety
Information to learn how to install and use your
Garmin GPSMAP 76 safely and responsibly.
An Index is provided at the end of the manual for
reference. Simply look up the topic you wish to learn
about and read the page or pages listed.
GPSMAP 76 Owner’s Manual i
IntroductIon > tAble of contents
Table of Contents
Introduction .....................................................i
About This Manual ............................................i
Care Information ..............................................iv
Getting Started ...............................................1
Unit Basics ........................................................1
Interface Keys ...................................................3
Basic Operation ............................................. 4
Turning on the GPSMAP 76 .............................4
Adjusting Backlight and Contrast .........................5
Selecting and Entering Data .................................5
Simulator Mode .................................................... 5
Initializing the GPS Receiver ...........................7
Initialization Options ............................................ 8
Creating a Waypoint .........................................9
New, Mark, and Waypoint Page Options ............ 11
Editing Waypoints............................................... 11
Creating a New Route ....................................15
Editing a Route ................................................... 17
Starting to Navigate .......................................20
Main Pages ................................................... 22
GPS Information Page ...................................23
Current GPS Receiver Status ..............................23
GPS Information Page Options Menu ................24
ii GPSMAP 76 Owner’s Manual
Map Page .........................................................25
Using Additional Map Data ................................25
Changing the Zoom Range .................................25
Map Page Options ..............................................26
Setup Map ........................................................... 27
General Tab ...................................................28
Map Tab ........................................................29
Waypoint Tab ................................................29
Point Tab ......................................................30
Marine Tab ................................................... 30
Line Tab ........................................................31
Area Tab ........................................................31
City Tab .........................................................32
Road Tab .......................................................32
Other Tab .......................................................33
Pointer Page ...................................................34
Pointer Page Options ..........................................34
Highway Page .................................................35
Highway Page Options ....................................... 36
Line Tab ........................................................36
Waypoint Tab ................................................37
Active Route/Goto Page ..................................... 37
IntroductIon > tAble of contents
Main Menu .................................................... 38
Trip Computer .................................................39
Trip Computer Options .......................................39
Tracks ..............................................................40
Track Page Options .............................................40
Track Information Page ......................................41
Points ..............................................................42
Waypoints ...........................................................42
Waypoint Options Menu .............................. 42
Points Of Interest ..........................................43
Cities ...................................................................44
Exits ....................................................................44
Exit Options ..................................................45
Addresses ............................................................ 45
Intersections ........................................................ 46
Routes .............................................................47
Routes Page Options ...........................................47
Proximity .........................................................48
Proximity Options ...............................................48
Celestial ...........................................................49
Tides....................................................................49
Sun and Moon .....................................................50
Hunt and Fish ......................................................51
MapSource and System Info .........................51
Setup Menu .....................................................52
General Tab .........................................................52
Time Tab .............................................................53
Units Tab .............................................................54
Location Tab ....................................................... 54
Interface Tab ....................................................... 57
Appendix.......................................................58
Specications .................................................58
Connecting the Power/Data ...........................59
Interfacing .......................................................59
Satellite Information .......................................60
What is WAAS? ...............................................61
What is Differential GPS (DGPS)? ................61
Map Datums ....................................................62
Navigation Terms............................................64
Messages ........................................................66
Loran TD System ............................................68
Accessories ....................................................70
FCC Compliance .............................................71
Product Registration ......................................72
Software License Agreement ........................72
Limited Warranty ............................................73
Safety Information ..........................................74
Index ............................................................. 76
GPSMAP 76 Owner’s Manual iii
IntroductIon > cAre InforMAtIon
Care Information
Cleaning the Unit
The GPSMAP 76 is constructed of high quality
materials and does not require user maintenance other
than cleaning. Clean the unit using a cloth dampened
with a mild detergent solution and then wipe dry. Avoid
chemical cleaners and solvents that may damage plastic
components.
Immersing the Unit in Water
The GPSMAP 76 is waterproof to IEC Standard 60529
IPX7. It can withstand immersion in 1 meter of water
for 30 minutes. Prolonged submersion can cause
damage to the unit. After submersion, be certain to
wipe and air dry the unit before reuse or charging.
To resolve problems that cannot be remedied using this
guide, contact Garmin Product Support in the U.S. at
800/800.1020 or Garmin Europe at 44/0870.8501241.
Storing the GPSMAP 76
Do not store the GPSMAP 76 where prolonged
exposure to temperature extremes may occur (such as
in the trunk of a car) as permanent damage may result.
User information, such as waypoints and routes are
retained in the unit’s memory without the need for
external power. It is always a good practice to back
up important user data by manually recording it or
downloading it to a PC (transferring it to MapSource).
iv GPSMAP 76 Owner’s Manual
Unit Basics
Internal Antenna
Interface keys
180 x 240 Four-Level
Gray, Backlight Display
GettInG stArted > unIt bAsIcs
GettInG Started
External Antenna
Connection
Battery Compartment
External Data/
Auxilary
Power Port
GPSMAP 76 Owner’s Manual 1
GettInG stArted > unIt bAsIcs
To Install the batteries:
1. Remove the Battery Cover
by turning the D-ring 1/4 turn
counter clockwise and pulling
the cover loose.
2. Check the battery polarity with
the molded diagram in the
battery compartment and install
the batteries inserting the end
toward the spring rst.
3. Re-install the Battery Cover by
aligning the back cover
with the Unit and turning the
D-ring clockwise.
Remove the batteries from your GPSMAP 76 when you do not
expect to use the unit for several months. Be sure to observe the
proper polarity when inserting the batteries. Follow the battery
manufacturer’s instructions on the proper care and handling of
the batteries.
To install the Lanyard:
1. Place the loop of the Lanyard
through the slot at the bottom of
the unit.
2. Route the strap through the loop
and pull tight.
2 GPSMAP 76 Owner’s Manual
GettInG stArted > InterfAce Keys
Interface Keys
IN/OUT Zoom Keys
• From the Map page, press to zoom
in or out
• From any other page, press to scroll
up or down a list
NAV/MOB Key
• Press and release at any time to view
the Find Menu page
• Press and hold for MOB
POWER Key
• Press and hold to turn unit On/Off
• Press and release to adjust
backlighting
QUIT Key
• Press and release to cancel data entry
or exit a page
ROCKER Key
• Move Up/Down or Right/Left to
move through lists, highlight elds,
on-screen buttons, icons, enter data or
move the map panning arrow
PAGE Key
• Press to cycle through the main pages
• Press when using the on-screen
keyboard to close
• Press to end an operation in progress
and return to the main page.
MENU Key
• Press and release to view options for
a page
• Press twice to view the Main Menu
ENTER/MARK Key
• Press and release to enter highlighted
options, data, or conrm on-screen
messages
• Press and release at any time to mark
your current location as a waypoint
GPSMAP 76 Owner’s Manual 3
bAsIc operAtIon > turnInG on the GpsMAp 76
BaSIc operatIon
Turning on the GPSMAP 76
When the GPSMAP 76 is turned on, the Welcome
page is displayed, followed by the Information and
Warning pages. Acknowledge each of these pages by
pressing the PAGE key. The GPS Information page
is now displayed. The unit must now collect satellite
data and establish its present position. To ensure proper
initialization, the GPSMAP 76 is shipped from the
factory in AutoLocate mode, which allows the receiver
to “nd itself” anywhere in the world. Before you turn
on the unit to start initialization, be sure the antenna
has a clear and unobstructed view of the sky to receive
satellite signals.
To turn On and Off the GPSMAP 76:
1. Press and hold the red POWER key. When the
unit powers on, a tone sounds and the Warning
and Information pages are displayed.
2. To acknowledge that you have read and
understand the Information and Warning pages,
press PAGE. You will now see the Satellite
Information page.
3. To turn off the GPSMAP 76, press and hold the
red POWER key again.
4 GPSMAP 76 Owner’s Manual
bAsIc operAtIon > turnInG on the GpsMAp 76
Adjusting Backlight and Contrast
You may want to adjust the backlight/contrast to see
the display better.
Simulator Mode
The Simulator Mode is great for practicing with the
unit while inside and satellite signals are not available.
When the GPSMAP 76 is in Simulator Mode, the GPS
To adjust the backlight/contrast level:
1. Press and quickly release the POWER key.
2. Press the ROCKER key UP to increase
the brightness or DOWN to decrease the
brightness.
3. Press the ROCKER key RIGHT to increase the
contrast or LEFT to decrease the contrast
3. Press ENTER or QUIT to close the Backlight/
Contrast adjustment window.
receiver is turned off, conserving battery power. The
unit cannot be used for actual navigation.
Selecting and Entering Data
As we progress through this Owner’s Manual you will
often be directed to press a specied Interface key or
highlight a eld. When you are directed to press a key,
you should press, then release the key. If the key needs
to be held down for a period of time, the instructions
will tell you. The position of the highlight is controlled
by the ROCKER key. When a eld is highlighted, a
dark strip encompasses the eld.
NOTE: Do not try to navigate in Simulator Mode.
While in the Simulator Mode, the GPS receiver is
turned off. Any Satellite Signal Strength Indicators
displayed are only simulations and do not indicate
the strength of actual satellite signals.
GPS Information Page
Menu
GPSMAP 76 Owner’s Manual 5
bAsIc operAtIon > turnInG on the GpsMAp 76
To put the GPSMAP 76 in Simulator Mode:
1. With the GPS Information page displayed, press
the MENU key.
2. Using the ROCKER key, highlight Start
Simulator then press the ENTER key.
When the Simulator Mode is active, the message
“Simulating GPS” is displayed along the top of the
GPS Information page.
To turn off the simulator:
1. With the GPS Information page displayed, press
the MENU key.
2. Select Stop Simulator then press ENTER.
To simulate movement, press PAGE until the pointer
page is displayed. Press the ROCKER key LEFT or
RIGHT changes the Track. Press the ROCKER key
RIGHT until your Track has changed about 40°. This
simulates the direction change to the right. The Pointer
should now be pointed toward the left of the display
indicating that you need to turn to the left to head
toward the waypoint.
Press the ROCKER key to the LEFT, simulating a left
turn, until the Pointer is realigned with the vertical line
in the Compass Ring indicating the GPS is on track to
the destination.
6 GPSMAP 76 Owner’s Manual
bAsIc operAtIon > InItIAlIzInG the Gps receIver
Initializing the GPS Receiver
The GPSMAP 76 needs to be initialized the rst time
Initializing the GPS Receiver:
1. With fresh batteries installed, take the unit
the unit is used, if it has been stored several months,
or if it has been moved over 600 miles. The Almanac
2. Turn the unit on and hold it in front of you with
within unit stores each satellite’s orbital data that is
supplied in the satellite signals. The GPSMAP 76 uses
the Almanac to know which satellites to search for
and automatically updates each time the unit aquires
3. The initialization process is automatic. It should
satellites. If you do not use your GPS for several
months or move the unit over 600 miles between
uses, the Almanac can become “cold” and the orbital
information is no longer valid. Your unit may have
trouble locking on to satellite signals using a “cold”
Almanac. If the unit is unable to receive enough
satellite signals to determine its location and update the
Almanac, it displays an options menu.
outside for a clear 360° view of the sky.
the top of the unit tilted upward. Follow the
screen prompts, pressing PAGE to display the
GPS Information page.
take the GPSMAP 76 no longer than ve
minutes to acquire enough satellite signals to
become operational. When the unit is able to
navigate, it displays either 2D GPS Location or
3D GPS Location in the Receiver Status eld.
GPSMAP 76 Owner’s Manual 7
bAsIc operAtIon > InItIAlIzInG the Gps receIver
Initialization Options
If the GPSMAP 76 is unable to determine its location,
an options menu is displayed. Select the appropriate
option to help the unit acquire satellites. Highlight the
option and then press ENTER to select.
Start Simulator—is used for practicing with the unit
while inside and satellite signals are not available.
When you select Simulator, the GPS receiver is turned
Stored w/o Batteries—is used when the date stored
in the unit may be incorrect due to storage without
batteries. To check the date, highlight Stored w/o
Batteries and verify the date displayed. If the date is
incorrect, select Stored w/o Batteries to search
for satellites.
Continue Acquiring—is used when in an area where
the satellite signals are being temporarily blocked.
off saving battery power.
New Location—is used when you have moved the unit
over 600 miles and are having trouble locking onto
satellite signals.
When you select New Location, another menu is
displayed. This menu contains the options Automatic
or Use Map. If you select Automatic, the unit switches
to the AutoLocate mode and begin searching for
satellites. This process may take longer to acquire
satellites. Use Map utilizes the pointer on the Map
page to select your approximate location. Then the unit
continues to acquire satellites normally.
When initializing the receiver or trying to
receive satellite signals, orient the GPSMAP
76 so the top of the unit points toward the
sky. If the unit is held with the top of the unit
pointed toward the horizon, satellite reception
may be severly degraded.
8 GPSMAP 76 Owner’s Manual
Creating a Waypoint
The term Waypoint may be new to you, but is
frequently used when discussing navigation. A
Waypoint is a position stored in the unit’s memory
used for direct navigation or to build a Route.
bAsIc operAtIon > creAtInG A WAypoInt
The unit has to be turned on and receiving at least
three satellites (or simulating navigation) to mark
a waypoint. There are three methods for creating
waypoints in the GPSMAP 76. You can press the
Delete
Waypoint
Goto
Waypoint
Show Waypoint
on Map
Conrm Changes
and Exit Page
ENTER/MARK key while at a location, create a
waypoint on the Map page, or enter coordinates for
a waypoint manually.
Creating a waypoint on the Map Page—Using the
ROCKER key, move the Map Pointer to the desired
location on the Map page and press ENTER. If the
Creating a waypoint using the ENTER/MARK
key—Press and hold ENTER/MARK key until
the Mark Waypoint page is displayed. At this point,
you can edit the waypoint name, symbol, date/time,
elevation, and depth. Highlight the OK button and
press ENTER to save the waypoint.
GPSMAP 76 Owner’s Manual 9
Map Pointer is not on a map feature or road, the New
Waypoint page is displayed. You can edit the waypoint
name, symbol, date/time, elevation, and depth.
See page 11 for information on editing waypoints.
Highlight the OK button and press ENTER to save
the waypoint.
bAsIc operAtIon > creAtInG A WAypoInt
Creating a waypoint manually using existing
coordinates—Press and hold ENTER/MARK
until the Mark Waypoint page is displayed. The unit
captures its current location. Highlight the Location
eld, press ENTER, and change the coordinates to
the new location using the ROCKER. Press ENTER
to conrm the change. At this point, you can edit the
waypoint name, symbol, date/time, elevation, and
depth. Highlight the OK button and press ENTER to
save the waypoint.
Highlight the Distance eld and press Enter. Use the
ROCKER to adjust the distance from the selected
location that the new waypoint is to be marked. Press
ENTER. Repeat the process to adjust the bearing.
When you have adjusted all elements of the projected
location, highlight Save and press Enter.
Make any other desired changes to the new waypoint
data such as name, symbol, and date. Highlight OK
and then press ENTER.
Creating a waypoint by projecting its location—
A waypoint may also be created by “projecting” the
distance and bearing from a specic location to a new
location. Create a waypoint using your favorite method
previously discussed. Press MENU to open the New
Waypoint Page Options menu, highlight Project
Location, and press ENTER. Highlight the From
eld and press Enter to open the Find menu. Select
the point from which you wish to project your new
waypoint just as you would select a waypoint or point
of interest.
10 GPSMAP 76 Owner’s Manual
bAsIc operAtIon > creAtInG A WAypoInt
New, Mark, and Waypoint Page Options
The New Waypoint page has a secondary menu
containing three options: Average Location, Project
Location, and Append to Route. Access this menu
by pressing the MENU key when the New, Mark, or
Waypoint page is displayed.
Average Location—collects and averages location
readings. The Location, Estimated Accuracy, Elevation,
and Measurement Count are displayed on the Average
Location page. When you are ready to save the
waypoint, highlight the Save button and press ENTER.
Project Location—projects a waypoint from a
specied location.
Append To Route—shows the available routes or
a New Route selection is displayed. If you select an
existing route, the waypoint is added to the end of the
route. If you select New Route, a new route is created
and the waypoint is added to the route.
Editing Waypoints
You can edit waypoints at the time they are created or
at a later date. There are six items that can be changed:
the symbol, name, location, date/time, elevation, and
depth. You also have the option to show the waypoint
name on the Map page.
Editing a Saved Waypoint—Press the MENU key
twice to display the Main Menu. Highlight Points
and press ENTER, highlight Waypoints and press
ENTER again. Select the desired waypoint from the
list and press ENTER to display the Waypoint page.
When nished, highlight the OK button and press
ENTER to accept the changes. See page 42 for more
information on the waypoint list.
Selecting a Symbol—Highlight the symbol eld and
press ENTER. Use the ROCKER key to select a
symbol from the list and press ENTER. The selected
symbol is now displayed at the waypoint location on
the Map page.
GPSMAP 76 Owner’s Manual 11
bAsIc operAtIon > creAtInG A WAypoInt
Changing the Name—Highlight the name eld
and press ENTER. Use the ROCKER key to scroll
through the alpha-numeric list and make a selection.
Press the ROCKER to the right to move the next
placeholder. When nished, press ENTER to accept
the changes.
Changing the Location, Date/Time, Elevation, or
Depth—Highlight the desired eld and press ENTER.
Use the ROCKER key to scroll through the numeric
list until the desired number is displayed. Press
the ROCKER key to the right to move to the next
character. When nished, press ENTER to accept
the changes.
Symbol
Date
Elevation
Show
Name
Name
Location
Depth
Show Name on Maps—Activating this option displays
the waypoint name on the Map page. Highlight the box
and press ENTER to check/uncheck the box.
These are the same steps that you use to ENTER
names and change numbers and select options in all of
the elds in the GPSMAP 76.
• If you press and hold the
ROCKER key while
scrolling through the alpha-numeric list, it
increases scrolling speed.
• You can scroll through the alpha-numeric list in
either direction.
• Do not press the
ENTER key until you have
nished entering the data. Remember, use the
ROCKER key to move to the next placeholder.
12 GPSMAP 76 Owner’s Manual
bAsIc operAtIon > creAtInG A WAypoInt
We have already created a waypoint with the ENTER
key. Let’s create another waypoint on the Map page
using the Map Pointer.
Press the PAGE key until the Map page is displayed.
Press the IN key several times until the Zoom Range
in the lower left corner of the Map page reads .5 mi
or lower. The current GPS location is indicated by the
triangle in the center of the map. Press the ROCKER
key any direction to display the Map Pointer.
Using the ROCKER key, you can pan the Map Pointer
around the map. As you move around the map, the
direction and distance from the Map Pointer to the
current GPS location is displayed at the top of the map.
With the Map Pointer at a location on the map about
one mile from your current location and not on a road
or map feature, press ENTER. The location of the
Map Pointer is captured and the New Waypoint page
is displayed. Change the waypoint name and store the
waypoint in memory by highlighting OK, then pressing
ENTER. Press the QUIT key to hide the Map Pointer
and center the map on the current GPS location.
Bearing and Distance from
Pointer to current GPS location.
Map Pointer
GPSMAP 76 Owner’s Manual 13
bAsIc operAtIon > creAtInG A WAypoInt
To go to a waypoint:
1. Press the NAV key.
2. Highlight Go To Point and press ENTER.
3. Highlight Waypoints and press ENTER.
4. Highlight the desired waypoint and press
ENTER.
5. Highlight the Goto Button and press ENTER.
movement, press the ROCKER key up one time. This
sets a speed of 10 miles per hour. If you continue to
press or hold the ROCKER key, the speed increases in
10 mph increments.
The Pointer page displays a Pointer and Compass
Ring. The Pointer always point toward your destination
(Bearing) while the Compass Ring reects the direction
that you are traveling (Track). When you are headed
directly toward your destination, the Pointer is pointing
toward the top of the display, aligned with the vertical
line on the Compass Ring. If you are no longer heading
toward your destination, the Pointer turns away from
the top of the display to point toward your destination.
To get headed toward your destination again, turn
until the Pointer is realigned with the vertical line in
the Compass Ring and pointed toward the top of
the display.
The GPSMAP 76 is now navigating to the waypoint.
For a GPS to navigate, it has to be moving. Fortunately,
you can simulate movement in the GPSMAP 76. Press
Note: Remember that while the GPS is very
reliable, you should always have a backup means
of navigation.
the PAGE key until the Pointer Page is displayed.
Along the top of the Pointer page there are several data
elds, one of which is the Speed eld. To simulate
14 GPSMAP 76 Owner’s Manual
bAsIc operAtIon > creAtInG A neW route
Creating a New Route
There are several methods to create a route. Press
MENU twice and select Routes. Highlight the New
button on the Routes page and press ENTER. A blank
Route page is displayed. Press MENU to display the
Create Route Options. Place the points in the route in
the order that you wish to navigate.
If you place the Map Pointer on a Map Feature, such
as a road, park, or intersection, the GPSMAP 76 stores
that location only to the route using the feature name
as a reference. These points are not stored in the User
Waypoint List. To save a Map Feature Point as a User
Waypoint, highlight the point in the route and press
ENTER. The Information page is now displayed. Press
MENU and select Save as Waypoint.
Use Map—displays the Map page with the Map
Pointer active. You can now point at any location or
point on the map and enter it into the route.
When using the map to create a route, you can select
an existing User Waypoint/Map Feature, or you can
create a new waypoint. New waypoints are created
if you place the Map Pointer on a location that is not
a Map Feature. A new waypoint is stored in the User
Waypoint List and can be edited as any other User
Waypoint. When placing a new waypoint in a route,
you have to press ENTER to create the waypoint,
ENTER to save the waypoint, and ENTER a nal
time to insert it into the route.
New Route Menu
GPSMAP 76 Owner’s Manual 15
bAsIc operAtIon > creAtInG A neW route
Add Waypoint—displays the Points Menu (see page
42 for information on the Points Menu). Highlighting
the dashed line in the waypoint eld on the Route
page and pressing ENTER it is the same as making
this selection. Use the Points Menu to display an
Information page, highlight the OK Button, and press
ENTER.
Using a combination of the Map Page and
Route Page—enables you to create a route using a
combination of the methods described above. Start
with a blank Route page. Enter a waypoint manually
or press the MENU key and select Use Map. You can
select Use Map at any time while creating a route.
Press QUIT to display the Route page after you have
nished using the map. You can continue entering
waypoints manually.
Naming the Route—automatically names the route
using the rst and last waypoint names as a reference.
To change the Route Name, highlight the Name eld,
press ENTER, and use the ROCKER key to scroll
through the alphanumeric list and enter the new name.
Press ENTER to accept the changes.
New Route Menu
16 GPSMAP 76 Owner’s Manual
bAsIc operAtIon > creAtInG A neW route
Editing a Route
The Route page has a secondary menu containing
Inserting a New waypoint—There are two methods
that can be used to insert a new waypoint into a route.
seven options: Use Map, Insert Waypoint, Remove
Waypoint, Reverse Route, Plan Route, Delete the
Route, and Start Navigation. To display the Route Edit
Options, select the Route page and press MENU.
Use Map—displays the Map page with the Route Line
active and the Map Pointer located on the waypoint
previously highlighted on the Route page.
Review Route Waypoint—displays the waypoint
information. To review information on a route
waypoint, place the Map Pointer on the waypoint
then press ENTER. This displays an options menu.
Highlight Review and press ENTER.
1. Highlight and select Use Map. Place the Map
Pointer on the route leg that you want to insert
the new point into. When the solid line turns to
a small dashed line, press ENTER. The Map
Pointer now displays “Ins” under it. Move the
Map Pointer, dragging the Route Line to the
new location, then press ENTER. If the new
location is a Map Feature, the point is inserted
in the leg. If the location is not on a Map
Feature, the New Waypoint page is displayed.
Press ENTER to save the new waypoint, then
ENTER again to insert the new waypoint in the
route.
2. Place the Map Pointer over a location that is not
a Map Feature, then press ENTER. The New
Waypoint page is displayed. Press ENTER to
save the new waypoint. Place the Map Pointer
over the route leg that you want to insert the
waypoint into, then press ENTER.
GPSMAP 76 Owner’s Manual 17
bAsIc operAtIon > creAtInG A neW route
Remove a Point or Waypoint—by placing the Map
Pointer over the point or waypoint you want to remove
and press ENTER. An options menu is displayed.
Highlight Remove then press ENTER. The point or
waypoint is removed and the Map Pointer moves to the
next point in the route.
Move a Waypoint—Only User Waypoints can be
moved. To move a waypoint, place the Map Pointer
on the waypoint and press ENTER. This displays an
options menu. Highlight Move, then press ENTER.
Place the Map Pointer at the desired new location and
press ENTER to move the waypoint.
Insert Waypoint—displays the Points Menu (see page
42 for more information on the Points Menu). Select a
point from the menu to insert into the route. The new
point is inserted into the route above the waypoint
highlighted on the Route page.
Remove Waypoint—removes the waypoint that
is highlighted on the Route page. With a waypoint
highlighted, press MENU. Highlight Yes and press
ENTER to remove the waypoint.
Reverse Route—reverses the direction of the route
placing the last waypoint at the top of the list.
Next Point in Route—moves the Map Pointer to
the next point in the route, place the Map Pointer on
a route point or waypoint and press ENTER. This
displays an options menu. Highlight Next, press
ENTER, and the Map Pointer moves to the next point
or waypoint in the route.
18 GPSMAP 76 Owner’s Manual
Plan Route—plans a route with a Speed, Fuel Flow,
Depart Time, and Depart Date. Fuel Flow is measured
in “units per hour.” Please consult your vehicle’s
Owner’s Manual for performance specications.
The Active Route page and Route page display tripplanning information for each leg or the entire route.
Available information includes Course, ETA, Fuel to
point, Leg Fuel, Leg Time, Sunrise & Sunset at point
location, Time to Point, and Leg Distance. To show
a specic eld, with the Active Route or Route page
displayed, press the ROCKER key right or left to
cycle through the elds.
Delete Route—removes the selected route from the
Routes page.
bAsIc operAtIon > creAtInG A neW route
Plan Route Option
GPSMAP 76 Owner’s Manual 19
bAsIc operAtIon > stArtInG to nAvIGAte
DESTINATION
START
Current
Track 45°
Starting to Navigate
With the unit on and displaying 3D GPS Location on
the GPS Information page, mark a waypoint at your
current location. Name this waypoint HOME, assign
the Residence Symbol, and store the waypoint.
Before starting to navigate, let’s clear the Track Log.
The Track Log is the bread crumb trail left on the Map
page and Highway page.
Bearing 000°
from START to
DESTINATION
To clear the Track Log:
1. Press MENU twice to display the Main Menu.
2. Highlight TRACKS then press the ENTER key.
3. Highlight CLEAR, then press ENTER.
4. Highlight the YES button then press ENTER.
Bearing 340° from current location
to DESTINATION
The GPS provides a straight line, direct navigation
course to your destination. Since it is not always
possible to follow a straight line from start to nish,
as you move, the Pointer always points toward your
destination and the Compass Ring always shows
your current track.
4. Press PAGE until the Map page is displayed.
Begin walking holding the GPSMAP 76 in front of
you with the top of the unit pointed toward the sky. As
you move, you see that the unit leaves a bread crumb
trail on the map indicating where you have been. Walk
at least a two minutes in one direction and then make
either a right or left turn. Continue walking in this new
20 GPSMAP 76 Owner’s Manual
direction for approximately another two minutes.
