Gaggenau RW466364 Specifications Sheet

Color Variants RW466364

Fully integrated, with glass door Niche width 61 cm, Niche height 213.4 cm

Included accessories

1 x connection set.

Optional accessories RA430000

Screw hole cover set. 8 pieces. RA492660

Removable shelf with oak wood frame

Installation Accessories RA420010

Door lock for RW 414 and RW 464. RA421611

Stainless steel door panel frame with handle

RA421612 Stainless steel door panel frame with handle

RA423140 Side trims, long.

RA425110 Handle bar, stainless steel, long

RA428611 Stainless steel door panel frame, handleless

RA460013 Additional side heating element 230 V. Required if appliances are installed handle to hinge or hinge to hinge. Not required if appliances are installed more than 160 mm apart from each other.

RA464611 Ventilation grille stainless steel

Characteristics Built-in / Free-standing

Built-in

Door panel options

Not possible

Height (mm)

2125

Width of the product (mm)

603

Depth of the product

608

Required niche size for installation (HxWxD)

2134.0 x 610 x 610

Net weight (kg)

167.000

Connection Rating (W)

300

Current (A)

Interior ventilator

Yes

Voltage (V)

220-240

Frequency (Hz)

50-60

Approval certificates

CE, VDE

Length electrical supply cord (cm)

300

Plug type

Gardy plug w/ earthing

Energy consumption (kWh/d) winecooler

0.47

Energy consumption per Year (kWh/a) winecooler

170.5

Total unit gross capacity (l)

441

Number of compressors

Number of independent cooling systems

Reversible Door Hinge

Yes

Interior light switch

EAN code

4242006262242

Consumption and connection features Brand

Gaggenau

Product name / Commercial code

RW466364

Product category Energy efficiency class (2010/30/EC) Energy consumption annual (kWh/

annum)

171.00

Capacity in 0.75l (bordeaux bottles)

Climate class

SN-T

Noise level (dB)

2019-01-21 Page 1

RW466364 Vario wine climate cabinet 400 series

Fully integrated, with glass door Niche width 61 cm, Niche height 213.4

TFT touch display 3 independently controllable climate zones Consistent temperatures with exact control from +5 °C to +20 °C Humidity control Stainless steel interior Fully extendable bottle trays in oak wood and solid aluminium in anthracite Bottle trays with hidden telescopic rails Warm white and glare-free LED light spots 5 preset lighting scenarios, selectable via TFT display Opening assist for door with two options:

1. Push-to-open function for integration into handleless furniture front

2. Pull-to-open function to facilitate opening the door using a handle Low-vibration operation Capacity 99 bottles

Handling

TFT touch display operation. Clear text display.

Technical Features

Dynamic cold air distribution. Automatic defrosting with defrost water evaporation. Activated charcoal air filter. UV-protection. Rest mode certified by Star-K. When rest mode is active, the appliance can only be opened using a handle. Open-door and malfunction alarm.

Features

Capacity 99 bottles (based on 0.75/l standard bottles). 12 bottle trays,

- 9 fully extendable trays

- 3 suitable for storage of Magnum bottles. Flexible interior configuration possible by adding or removing fully extendable bottle trays. Storage of up to 12 Magnum bottles with standard tray configuration (12 bottle trays). Space for max. 12 bottle trays. 2 brilliant LED light spots with warm white, glare-free light in each climate zone. 5 different lighting scenarios can be selected for individual wine presentation. Net volume 361 litres.

Consumption data

Energy consumption 171 kwh/year. Noise level 42 dB (re 1 pW).

Planning notes

Flat hinge. Door hinge right, reversible. Door opening angle of 115°, fixable at 90°. Max. door panel weight 73 kg. The mains socket needs to be planned outside the built-in niche. No transport/operation above 1.500 m sea level.

Connection

Total connected load 0.300 kW. Connecting cable 3.0 m, detachable.

RW466364 Vario wine climate cabinet 400 series

Fully integrated, with glass door Niche width 61 cm, Niche height 213.4

2019-01-21 Page 2
