Gaggenau RB289300RU Instructions for Use

Gaggenau
User manual
RB 289
Fridge-freezer
en

Table of contents

1 Safety ............................................4
2 Preventing material damage .......9
3 Environmental protection and
saving energy...............................9
4 Installation and connection.........9
4.2 Criteria for the installation
location .....................................10
4.3 Installing the appliance ............10
4.4 Preparing the appliance for
the first time..............................11
4.5 Connecting the appliance to
the electricity supply.................11
5 Familiarising yourself with
your appliance............................12
5.1 Appliance .................................12
5.2 Control panel............................13
7.3 Switching off the appliance ......16
7.4 Setting the temperature............16
8.1 Fast cooling .............................16
8.2 Automatic Fast freezing............17
8.3 Manual Fast freezing ................17
8.4 Holiday mode ...........................17
9.1 Door alarm ...............................18
9.2 Temperature alarm ...................18
10.1 Connecting the appliance to a WLAN home network
(Wi-Fi) with WPS function .......19
10.2 Connecting the appliance to a WLAN home network (Wi-Fi) without WPS func-
tion..........................................20
10.3 Connecting the appliance
to the HomeConnect app .....20
10.4 Checking the signal
strength ..................................21
10.5 Installing updates for the
Home Connect software ........21
10.6 Resetting HomeConnect
settings ...................................22
10.7 Data protection.......................22
6.1 Extendable shelf .......................14
6.2 Fruit and vegetable con-
tainer.........................................14
6.3 Cool-fresh container .................14
6.4 Flat frozen food container ........14
6.5 Door rack..................................14
6.6 Accessories..............................14
7.1 Switching on the appliance ......15
7.2 Operating tips...........................15
2
11.1 Tips for storing food in the
refrigerator compartment .......22
11.2 Chill zones in the refriger-
ator compartment...................23
12.1 Storage times in the cool-
fresh compartment at 0°C ....23
13.1 Freezing capacity ...................24
13.2 Fully utilising the freezer
compartment volume .............24
13.3 Tips for storing food in the
freezer compartment ..............24
13.4 Tips for freezing fresh food ....24
13.5 Shelf life of frozen food at
−18°C....................................25
13.6 Defrosting methods for
frozen food .............................25
14.1 Defrosting in the refriger-
ator compartment...................25
14.2 Defrosting in the cool-fresh
compartment ..........................25
14.3 Defrosting in the freezer
compartment ..........................25
15.1 Preparing the appliance for
cleaning ..................................25
15.2 Cleaning the appliance ..........26
15.3 Removing the fittings..............26
15.4 Removing appliance com-
ponents...................................27
en
17.1 Taking the appliance out of
operation ................................33
17.2 Disposing of old appliance ....33
18.1 Product number (E-Nr.) and
production number (FD).........34
3
en Safety

1 Safety

Observe the following safety instructions.

1.1 General information

¡ Read this instruction manual carefully. ¡ Keep the instruction manual and the product information safe
for future reference or for the next owner.
¡ Do not connect the appliance if it has been damaged in transit.

1.2 Intended use

This appliance is only intended to be fully fitted in a kitchen. Only use this appliance:
¡ for chilling and freezing food and for making ice cubes. ¡ In private households and in enclosed spaces in a domestic en-
vironment.
¡ Up to an altitude of max. 2000m above sea level.

1.3 Restriction on user group

This appliance may be used by children aged 8 or over and by people who have reduced physical, sensory or mental abilities or inadequate experience and/or knowledge, provided that they are supervised or have been instructed on how to use the appliance safely and have understood the resulting dangers. Children must not play with the appliance. Cleaning and user maintenance must not be performed by chil­dren unless they are being supervised. Children above the age of three years old and younger than eight years old may load and unload the the fridge-freezer.

1.4 Safe transport

WARNING‒Risk of injury!
The high weight of the appliance may result in injury when lifted.
▶
Do not lift the appliance on your own.
4
Safety en

1.5 Safe installation

WARNING‒Risk of electric shock!
Improper installation is dangerous.
▶
Connect and operate the appliance only in accordance with the specifications on the rating plate.
▶
Connect the appliance to a power supply with alternating cur­rent only via a properly installed socket with earthing.
▶
The protective conductor system of the domestic electrical in­stallation must be properly installed.
▶
Never equip the appliance with an external switching device, e.g. a timer or remote control.
▶
When the appliance is installed, the mains plug of the power cord must be freely accessible. If free access is not possible, an all-pole isolating switch must be installed in the permanent elec­trical installation according to the installation regulations.
▶
When installing the appliance, check that the power cable is not trapped or damaged.
If the insulation of the power cord is damaged, this is dangerous.
▶
Never let the power cord come into contact with heat sources.
WARNING‒Risk of explosion!
If the appliance's ventilation openings are sealed, a leak in the re­frigeration circuit may result in a flammable mixture of gas and air.
▶
Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
WARNING‒Risk of fire!
It is dangerous to use an extended power cord and non-approved adapters.
▶
Do not use extension cables or multiple socket strips.
▶
If the power cord is too short, contact Customer Service.
▶
Only use adapters approved by the manufacturer. Portable multiple socket strips or portable power supply units may overheat and cause a fire.
▶
Do not place portable multiple socket strips or power supply
units on the back of the appliance.
5
en Safety

1.6 Safe use

WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric shock.
▶
Only use the appliance in enclosed spaces.
▶
Never expose the appliance to intense heat or humidity.
▶
Do not use steam- or high-pressure cleaners to clean the appli-
ance.
WARNING‒Risk of suffocation!
Children may put packaging material over their heads or wrap themselves up in it and suffocate.
▶
Keep packaging material away from children.
▶
Do not let children play with packaging material. Children may breathe in or swallow small parts, causing them to suffocate.
▶
Keep small parts away from children.
▶
Do not let children play with small parts.
WARNING‒Risk of explosion!
Mechanical devices or other devices may damage the refrigera­tion circuit; flammable refrigerant may escape and explode.
▶
To accelerate the defrosting process, do not use any other
mechanical devices or devices other than those recommended
by the manufacturer. Products which contain flammable propellants and explosive sub­stances may explode, e.g. spray cans.
▶
Do not store products which contain flammable propellants (e.g.
spray cans) or explosive substances in the appliance.
WARNING‒Risk of fire!
Electrical devices within the appliance may cause a fire, e.g. heat­ers or electric ice makers.
▶
Do not operate electrical devices within the appliance.
6
Safety en
WARNING‒Risk of injury!
Containers that contain carbonated drinks may burst.
▶
Do not store containers that contain carbonated drinks in the
cool-fresh compartment.
▶
Do not store containers that contain carbonated drinks in the
freezer compartment. Injury to the eyes caused by escaping flammable refrigerant and hazardous gases.
▶
Do not damage the tubes of the refrigerant circuit or the insula-
tion.
WARNING‒Risk of cold burns!
Contact with frozen food and cold surfaces may cause burns by refrigeration.
▶
Never put frozen food straight from the freezer compartment
into your mouth.
▶
Avoid prolonged contact of the skin with frozen food, ice and
surfaces in the freezer compartment.
CAUTION‒Risk of harm to health!
To prevent food from being contaminated, you must observe the following instructions.
▶
If the door is open for an extended period of time, this may lead
to a considerable temperature increase in the compartments of
the appliance.
▶
Regularly clean the surfaces that may come into contact with
food and accessible drain systems.
▶
Store raw meat and fish in suitable containers in the refrigerator
so that they do not touch or drip on other food.
▶
If the fridge/freezer is empty for an extended period of time,
switch off the appliance, defrost it, clean it and leave the door
open to prevent the formation of mould. Metal or metal-style parts in the appliance may contain aluminium. If acidic food comes into contact with aluminium in the appliance, aluminium foil ions may pass into the food.
▶
Do not consume soiled food.
7
en Safety

1.7 Damaged appliance

WARNING‒Risk of electric shock!
If the appliance or the power cord is damaged, this is dangerous.
▶
Never operate a damaged appliance.
▶
Never pull on the power cord to unplug the appliance. Always
unplug the appliance at the mains.
▶
If the appliance or the power cord is damaged, immediately un-
plug the power cord or switch off the fuse in the fuse box.
▶
Call customer services. →Page34 Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be carried out by trained
specialist staff.
▶
Only use genuine spare parts when repairing the appliance.
▶
If the power cord of this appliance is damaged, it must be re-
placed by the manufacturer, the manufacturer's Customer Ser-
vice or a similarly qualified person in order to prevent any risk.
WARNING‒Risk of fire!
If the tubes are damaged, flammable refrigerant and harmful gases may escape and ignite.
▶
Keep naked flames and ignition sources away from the appli-
ance.
▶
Ventilate the room.
▶
Switch off the appliance. →Page16
▶
Unplug the appliance from the mains or switch off the circuit
breaker in the fuse box.
▶
Call after-sales service. →Page34
8
Preventing material damage en

Preventing material damage

2 Preventing material
damage
Preventing material damage
ATTENTION!
Using the base, runners or appliance doors as a seat surface or climbing surface may damage the appliance.
▶
Do not stand or support yourself
on the base, runners or doors. Contamination with oil or fat may cause plastic parts and door seals to become porous.
▶
Keep plastic parts and door seals
free of oil and grease. Metal or metal-style parts in the appli­ance may contain aluminium. Alu­minium reacts when it comes into contact with acidic foods.
▶
Do not store unpackaged food in
the appliance.

Environmental protection and saving energy

3 Environmental protec-
tion and saving energy
Environmental protection and saving energy

3.1 Disposing of packaging

The packaging materials are environ­mentally compatible and can be re­cycled.
▶
Sort the individual components by
type and dispose of them separ-
ately.

3.2 Saving energy

If you follow these instructions, your appliance will use less power.

Selecting the installation location

¡ Keep the appliance out of direct
sunlight.
¡ Install the appliance as far away as
possible from heating elements,
cookers and other heat sources:
– Maintain a 30mm clearance to
electric or gas cookers.
– Maintain a 300mm clearance to
oil or solid-fuel cookers.
¡ Use a niche depth of 560mm. ¡ Never cover or block the exterior
ventilation grilles.

Saving energy during use

Note:The arrangement of the fittings
does not affect the energy consump­tion of the appliance.
¡ Open the appliance only briefly. ¡ Never cover or block the interior
ventilation openings or the exterior ventilation grilles.
¡ Transport purchased food in a
cool bag and place in the appli­ance quickly.
¡ Allow warm food and drinks to
cool down before storing them.
¡ Thaw frozen food in the refrigerator
compartment to utilise the low tem­perature of the food.
¡ Always leave some space between
the food and to the back panel.
¡ Open the freezer compartment
door only briefly and then close it properly.

Installation and connection

4 Installation and con-
nection
Installation and connection
You can find out where and how best to install your appliance here. You will also learn how to connect your appliance to the power supply.

4.1 Scope of delivery

After unpacking all parts, check for any transport damage and for com­pleteness of delivery. If you have any complaints, contact your dealer or our after-sales service →Page34.
9
en Installation and connection
5
The delivery consists of the following:
¡ Built-in appliance ¡ Equipment and accessories
1
¡ Installation material ¡ Installation instructions ¡ User manual ¡ Customer service directory ¡ Warranty enclosure
2
¡ Energy label ¡ Information on energy consump-
tion and noises
¡ Information about HomeConnect
4.2 Criteria for the installation
location
WARNING
Risk of explosion!
If the appliance is in a space that is too small, a leak in the refrigeration circuit may result in a flammable mix­ture of gas and air.
▶
Only install the appliance in a
space with a volume of at least
1m3 per 8g refrigerant. The
volume of refrigerant is indicated
on the rating plate. →"Appliance",
Fig. 1 /5, Page13
The weight of the appliance ex works may be up to 75kg depending on the model. The subfloor must be sufficiently stable to bear the weight of the appli­ance.

Permitted room temperature

The permitted room temperature de­pends on the appliance's climate class. The climate class can be found on the rating plate. →"Appliance", Fig.
1 /
, Page13
Climate class
Permitted room tem­perature
SN 10°C to 32°C N 16°C to 32°C ST 16°C to 38°C T 16°C to 43°C
The appliance is fully functional within the permitted room temperature. If an appliance with climate class SN is operated at colder room temperat­ures, the appliance will not be dam­aged up to a room temperature of 5°C.

Niche dimensions

Observe the niche dimensions if you install your appliance in the niche. If this is not the case, problems may occur when installing the appliance.
Niche depth
Install the appliance in the recom­mended niche depth of 560mm. If the niche depth is smaller, the en­ergy consumption increases slightly. The niche depth must be a minimum 550mm.
Niche width
An inside niche width of at least 560mm is required for the appli­ance.

Side-by-side installation

If you want to install two appliances side by side, you must maintain a distance of at least 150mm between the appliances.

4.3 Installing the appliance

▶
Install the appliance in accordance with the enclosed installation in­structions.
1
Depending on the appliance specifications
2
Not in all countries
10
4.4 Preparing the appliance
for the first time
1. Remove the informative material.
2. Remove the protective foil and
transit bolts, e.g. remove the ad-
hesive strips and carton.
3. Clean the appliance for the first
time. →Page26
4.5 Connecting the appliance
to the electricity supply
1. Insert the mains plug of the appli-
ance's power cable in a socket
nearby.
The connection data of the appli-
ance can be found on the rating
plate. →"Appliance", Fig. 1 /5,
Page13
2. Check the mains plug is inserted
properly.
a The appliance is now ready for
use.
Installation and connection en
11
Loading...
+ 25 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
