Gaggenau DVP221100 Specifications Sheet

Color Variants
DVP221100

Glass front in Gaggenau Anthracite
Width 60 cm, Height 14 cm

DVP221110
Glass front in Gaggenau Metallic
Width 60 cm, Height 14 cm

Optional accessories
BA080670

Vacuuming bags, small, 180 mm x 280
mm, 100 pcs.

BA080680
Vacuuming bags, large, 240 mm x 350
mm, 100 pcs.

Characteristics
Color / Material
Alternative colors available
Net weight (kg)

32.455

Gross weight (kg)

35.00

Specification of product image


EAN code

4242006260255

Consumption and connection features
Dimensions of the product (mm)
Dimensions of the packed product

(HxWxD) (mm)

230 x 655 x 665

2018-12-04
Page 1

DVP221100
Vacuuming drawer 200 series

Glass front in Gaggenau Anthracite
Width 60 cm, Height 14 cm

Integrable in 14 cm high niche
Hygienic stainless steel vacuuming
chamber, applicable height up to 80
mm
3 vacuuming levels for vacuuming in
the chamber, max. 99%
3 vacuuming levels for vacuuming
outside the chamber, max. 90%
Automatic connection recognition for
vacuuming outside the chamber
Flush installation
Handleless drawer
Push-to-open system

Application

Vacuuming for sous-vide cooking.
Vacuuming for fast marinating and
flavouring.
Vacuuming for extended storage.
Vacuuming of vacuuming containers
outside the chamber.
Vacuuming of liquids in bottles outside
the chamber.

Handling

Touch key operation.

Features

Net volume 7 litres.
Capacity load max. 10 kg.
Maximum size of vacuuming bags W
240 mm x L 350 mm.
3 heat-sealing levels for different
strengths of bag material.
Sealing bar, non-stick coating,
removable.
Safety glass cover, opens automatically
after vacuuming.
Raised vacuuming platform, 44 mm,
deployable.
Utility space in vacuuming chamber, W
210 mm x L 275 mm.
Membrane for avoiding reflow of liquids
during vacuuming outside the chamber.
Drying programme for vacuuming
pump.
Warning function.

Planning notes

Necessary lateral gap between
appliance front and furniture panel of
min. 5 mm.
The panel surface of the appliance
extends 21 mm from the furniture
cavity.
Installation of BS/BM/CM directly
above DV in 59 cm niche without
intermediate floor.
Built-in under worktop or in single
niche.
The socket can be planned behind the
appliance.

Connection

Total connected load 0.32 kW.
Connecting cable 1.5 m with plug.

DVP221100
Vacuuming drawer 200 series

Glass front in Gaggenau Anthracite
Width 60 cm, Height 14 cm

2018-12-04
Page 2
