Controls on top
Left-hinged only
CM 470 712
Stainless steel-backed full glass front
Width 24" (60 cm)
Included accessories
1 assembly screws
1 scoop
1 water hardness test strip
1 milk container (insulated) 17 oz
(0.5 liters)
1 connection hose for milk frother
1 milk tube
1 bean container with lid
Optional accessories
(order as spare parts):
Part No. 17000705
Water filter
Part No. 00311819
Descaling tablets
Part No. 00311769
Cleaning tablets
Part No. 00636455
Door hinge restrictor
(92° opening angle)
Part No. 11005967
Stainless steel milk container
Part No. 11015223
Bean container with lid
400 series plumbed, fully automatic
espresso machine
CM 470
– Handleless door / automatic door
opening
– Fixed inlet and outlet water
connection
– Continuous flow heater means no
waiting time and constant brewing
temperature
– Aroma brewing technology for a full
aroma
– Single portion cleaning
– TFT touch display
– Centralized controls for easy use and
intuitive operation
– One-touch operation
– Personalization function
– Seven light settings
– Electronic fill level control for milk,
water and coffee to ensure a perfect
result
Type of beverage
Ristretto / 2 x Ristretto.
Espresso / 2 x Espresso.
Espresso Macchiato / 2 x Espresso
Macchiato.
Coffee / 2 x Coffee.
Americano / 2 x Americano.
Caffe Latte / 2 x Caffe Latte.
Latte Macchiato / 2 x Latte Macchiato.
Cappuccino / 2 x Cappuccino.
Flat White / 2 x Flat White.
Milk froth / 2 x Milk froth.
Warm milk / 2 x Warm milk.
Hot water / 2 x Hot water.
Operation
Automatic door opening to the left.
Rotary knobs and TFT touch display
operation.
Clear text display in 44 languages.
Personalization function, option to save
8 individualized beverages.
4 beverage size settings from small to
extra large; can be individually adjusted
to match the size of the cup.
8 coffee strength levels from very mild to
extra strong.
3 coffee temperature levels.
10 hot water temperature levels.
4 coffee-milk ratio levels.
Adjustable grinding level.
Height-adjustable coffee dispenser
2 ¾" - 5 ⅞".
Easy access to water tank, milk and
coffee bean container behind the door.
Features
Maintenance-free grinding unit with
ceramic discs.
Separate drawer for second ground
coffee type.
Water pump with 275 psi (19 bar)
pressure.
Double grinding and brewing cycles for
extra intensity for single beverage order.
For double beverage order, two grinding
and brewing cycles.
Beverage dispenser with integrated milk
system.
Insulated stainless steel milk container
for up to 17 oz. ( 0.5 liters).
Integrated LED lighting.
Removable 1.1 lbs. (0.5 kg) bean
container with aroma lid, allows for an
effortless exchange of different types of
coffee beans.
Automatic adjustment of ground coffee
quantity.
Removable 81 oz. (2.4 liter) water tank.
Drain connection: ¾"
67" long (1.7 m) rubber outlet hose
included
Drain size: 1 ½" diameter minimum.
Vacuum break recommended.
Ensure a 6" minimum drop to connect to
the drain line to ensure proper drainage.
Rating
Total rating: 1,600 W.
Total Amps: 10 A
120 V / 60 H
Connecting cable 39" with three-prong
plug (NEMA 5-15P).
Plan for a LAN cable or connect via WiFi.
Electronic water filter exchange indicator.
Electronic fill level control for drip tray
and container for coffee residue.
Home network integration for digital
services (Home Connect) either via cable
connection LAN (recommended) or
wireless via WiFi.
The use of the Home Connect
functionality depends on the Home
Connect services, which are not available
in every country. For further information
please check: home-connect.com.
Safety
Child lock.
Aqua stop.
Cleaning
Fully automatic rinse program when
machine is turned on/off.
Automatic steam cleaning of the milk
system after every beverage.
Automatic cleaning and descaling
program.
Emptying program to prepare the
appliance for holiday or transportation.
Removable brewing unit.
Coffee residue container and drip tray
dishwasher-safe.
Beverage dispenser dishwasher-safe.
Planning notes
Ideal installation height 3.1 ft - 4.8 ft.
(top edge of bottom cut-out).
The front of the appliance extends 1 ⅞"
from the furniture cavity.
When installing in a corner a side
clearance is required.
Door opening angle approx. 110°
(delivery status) - mounting distance to
the wall has to be at least 13 ¾".
Door opening angle approx. 155° mounting distance to the wall has to be
at least 25 ⁹⁄₁₆".
Door opening angle approx. 92° mounting distance to the wall has
to be at least 3 ¹⁵⁄₁₆" (spare part No.
00636455).
Installation directly above WS461
(5 ⅜" tall) high warming drawer in 23 ¼"
standard cut-out.
At no point may the outlet hose be
positioned higher than the bottom edge
of the appliance. The outlet hose must
also be at least 5 ⅞" lower than the
appliance outlet (see drawing "drainage
connection").
If necessary, the transformer can be
placed in an adjacent cabinet. Note that
the length of the power cable between
the transformer and appliance is 23 ½"
(600 mm).
If the appliance is placed too far from the
main siphon, the drain system has to be
adjusted on-site (building installation).
The water connection (1) for the inlet
hose must always be accessible and not
located directly behind the appliance.
The connection of the outlet hose to the
siphon (2) must not be directly behind
the appliance and should be accessible.
Water connection: ¾" inner diameter,
1" outer diameter (cold water only)
65" long (1.65 m) aqua stop inlet hose
included.
www.gaggenau.com/us
Revised: June 2021
7"
distance from the wall is only 4" (100).
(175)
3
min. 1
/8"
(min. 35)
min. 23
depth including transformer
1
/2" (min. 597)
View from rear
21
15
(558)
/16"
min. 18
(min. 458)
1
Top View
3
/4"
(19)
3
/4"+1/16"
17
+2
(450
)
1
22
1
/16"
/16"+5/16"
+8
)
(560
1
/8"
(3)
23
(590)
1
/2"
17
(347)
7
/8"
1
(47)
15
/16"
17
(455)
1
/4"
(4) Water outlet
(5) Cold-water connection
54 6
3
/8"
9
(238)
6"
(152)
1
(44)
9
7
/16"
2
1
/16"
(65)
3
/4"
13
/16"
(20)
(36)
(6) Electric terminal box
2
Transformer
1
/2" (622)
24
flush
Drainage connection
insert
1" (25)
reveal
cleats
1" (25)
reveal
cleats
depth
22" (558)
24" (610)
Left corner installation
≥ 13¾"
(350)
If using the 92° door hinge restrictor (spare part no. 00636455), the minimum
Numbers indicated
inside parenthesis ( ) = mm
110°
≥ 6"
(≥ 152)
www.gaggenau.com/us
Revised: June 2021
