Fusion NV-AM10002 Service manual

POWERPLANT

SERVICE MANUAL

AMPLIFIER MODEL

NV−AM10002

NV-AM10002 Material List

Part Number Items Q'ty Position

0 ASY-NVAM10002
1… WZ-NVAM10002

2… DIO1N4001R diode 1 D2
2… DIO1N4148R diode 8 D4~8.D10~11.D40
2… ECT016V107MDR capacitor 6 C36~39.C118.C218
2… ECT016V227MDR capacitor 1 C12
2… ECT025V107MBR capacitor 1 C5
2… ECT025V226MDR capacitor 2 C6~7
2… ECT050V100KTR capacitor 2 C103.C203
2… ECT050V101KTR capacitor 2 C109.C209

2… ECT050V104KTR capacitor 12
2… ECT050V105MDR capacitor 4 C13~14.C123.C223

2… ECT050V106MDR capacitor 2 C101.C201
2… ECT050V154KTR capacitor 1 C35

2… ECT050V220KTR capacitor 2 C104.C204
2… ECT050V221KTR capacitor 4 C102.C115.C202.C215
2… ECT050V470KTR capacitor 6 C117.C119.C121.C317.C219.C221
2… ECT050V475MBR capacitor 1 C16
2… ECT050V681KTR capacitor 1 C17
2… ECT063V103DMR capacitor 2 C113.C213
2… ECT063V104DMR capacitor 5 C8.C111.C135.C211.C235
2… ECT063V154DMR capacitor 2 C110.C210
2… ECT063V184DMR capacitor 4 C105.C125.C205.C225
2… ECT063V224DMR capacitor 4 C107~108.C207~208
2… ECT063V334DMR capacitor 2 C112.C212
2… ECT063V394DMR capacitor 2 C106.C206

C2~3.C20~24.C116.C120.C122.C216.C222C24
0

1/4

2… ECT100V104DSR capacitor 2 C124.C224
2… ECT100V473DSR capacitor 2 C10~11

2… ECT100V682DSR capacitor 1 C9
2… PCBNV100021AR PCB 1

2… RESMP121Y1000ER Resistor 13

2… RESMP121Y1001ER Resistor 21

2… RESMP121Y1002ER Resistor 29

2… RESMP121Y1003ER Resistor 1 R6
2… RESMP121Y1201ER Resistor 3 R14.R149.R249
2… RESMP121Y1202ER Resistor 1 R3
2… RESMP121Y1501ER Resistor 3 R24.R108.R208

2… RESMP121Y1502ER Resistor 9

R8.R123.R132~135.R148.R223.R232~235.R24
8

R28.R42.R52.R102.R106.R125.R128~131.R13

8.R147.R202.R206.R225.R228~231.R238.R24
7

R5.R10~11.R17~18.R20.R34.R45.R100.R103~

104.R111~112.R119.R126~127.R136~137.R15

1.R200.R203~204.R211~212.R226~227.R236~
237 .R251

R21.R121~122.R139.R159.R221~222.R239.R2
59

2… RESMP121Y1800ER Resistor 1 R1
2… RESMP121Y2002ER Resistor 2 R118.R218

NV-AM10002 Material List

Part Number Items Q'ty Position
2… RESMP121Y2004ER Resistor 1 R15
2… RESMP121Y2200ER Resistor 2 R120.R220
2… RESMP121Y2202ER Resistor 3 R16.R110.R210
2… RESMP121Y2203ER Resistor 3 R7.R166.R266
2… RESMP121Y2701ER Resistor 3 R9.R142.R242
2… RESMP121Y2703ER Resistor 1 R26
2… RESMP121Y3001ER Resistor 1 R25
2… RESMP121Y3300ER Resistor 2 R144.R244
2… RESMP121Y3600ER Resistor 2 R115.R215
2… RESMP121Y3601ER Resistor 2 R117.R217
2… RESMP121Y3902ER Resistor 3 R19.R109.R209
2… RESMP121Y4301ER Resistor 2 R143.R243
2… RESMP121Y4302ER Resistor 1 R13
2… RESMP121Y4700ER Resistor 2 R114.R214
2… RESMP121Y4701ER Resistor 4 R4.R12.R116.R216
2… RESMP121Y4702ER Resistor 3 R101.R107.R201
2… RESMP121Y47R0ER Resistor 4 R140~141.R240~241

2/4

2… RESMP121Y4R70ER Resistor 8 R153.R155.R157~158.R253.R255.R257~258

2… RESMP121Y5103ER Resistor 2 R113.R213
2… RESMP121Y5601ER Resistor 1 R29
2… RESMP121Y5602ER Resistor 1 R207
2… RESMP121Y6800ER Resistor 4 R30~31.R160.R260
2… RESMP121Y6801ER Resistor 2 R48~49
2… RESMP121Y7501ER Resistor 2 R105.R205
2… RESMP251Y1000ER Resistor 6 R2.R22~23.R32~33.R57
2… RESMP251Y1002ER Resistor 2 R40~41
2… TRA2N4401R Triode 1 Q1
2… TRA2N4403R Triode 2 Q2.Q4
2… TRA2SB647R Transistor 3 Q15.Q110.Q210
2… TRA2SD667R Transistor 3 Q16.Q109.Q209

2… TRAA06R Triode 8

2… TRAA56R Triode 8 Q5~6.Q103.Q105~106.Q203.Q205~206
2… WIR060R6R Jumper 3 J41.J52.J69

2… WIR100R8R Jumper 20

Q102.Q104.Q108.Q113.Q202.Q204.Q208.Q21
3

J7.J37~38.J44.J47.J49.J67~68.J70~71.J73.J91~

94.J166.J168~169.J211.J215

2… WIR12R50R8R Jumper 14

2… WIR150R8R Jumper 16

2… WIR17R50R8R Jumper 18

2… WIR200R8R Jumper 15

2… WIR220R8R Jumper 15
2… WIR240R8R Jumper 8 J10~11.J140.J95~96.J161~163

2… WIR7R50R8R Jumper 7 J24~25.J40.J45.J51.J64.J167

J1~2.J18.J21.J48.J60~61.J63.J77~79.J83.J97~9
8

J15~17.J19.J26.J34.J36.J43.J54.J72.J186.J188.
J210.J213~214.J222

J3.J39.J42.J46.J58~59.J66.J74~76.J80~81.J84~
89

J35.J121.J141.J155~160.J164~165.J207~209.J
212

J4~6.J8~9.J12~14.J20.J22~23.J82.J90.J120.J15
4

NV-AM10002 Material List

Part Number Items Q'ty Position
2… ZD1N5239BR diode 1 ZD1
2… ZD1N5241BR diode 1 ZD2
2… ZD1N5245BR diode 2 ZD3~4

1… WS-NVAM10002

2… DIO1N5402R diode 1 D1
2… DIOFMG22RR diode 1 D13
2… DIOFMG22SR diode 1 D12
2… ECT025B228MER capacitor 3 C1.C4.C15
2… ECT050B338MDR capacitor 2 C18~19
2… ERT154K01R varistor 1 RT1
2… FAN34002RR pipe 1

FUS1JK202R Fuse holder 1 FUSE

2…
2… ICBA4558D8PR IC 1 IC2
2… ICBA4558S8PR IC 7 IC101~103.IC104~107
2… ICKIA494PR IC 1 IC3
2… ICPC17K1R IC 1 IC1
2… IND3U1R2P5R Inductor 1 L1
2… LEDRGR302R LED 1 LED
2… MOSIRFZ44NR Mosfet 6 Q3.Q7~8.Q11.Q20~21
2… RCAJU4RWAR RCA 1 RCA1

3/4

2… RESCEM502NR10KR resistor 8 R145~146.R154.R156.R245~246.R254.R256

2… RESMO102P220JR resistor 1 R38
2… RESMO102P221JR resistor 2 R46~47
2… RESMO102P4R7JR resistor 2 R152.R252
2… ST3DOWHI001R Terminal 1 CON1
2… ST4DOWHI001R Terminal 1 CON2
2… SW12P3T06002R Slide switch 1 SW101
2… TRA2SA1694R Transistor 4 Q112.Q121.Q212.Q221
2… TRA2SC4467R Transistor 4 Q111.Q122.Q211.Q222
2… TRA2SC945R Transistor 2 Q101.Q201
2… TRAA06R Triode 2 Q107.Q207
2… TRR38619002R transformer 1 TR-1
2… VRRB50302J1503R VR 1 VR101
2… VRRB50304J1502R VR 1 VR102
2… VRRB50306J15R VR 2 VR104~105
2… VRRC50302J15R VR 1 VR103
2… W020671002R copper wire 2
2… W051P2207001R ground wire 1 GND

1… E-NVAM10002

2… FUS0430R032VR fuse 2

1… A-NVAM10002

2… BRA01023501R Green Bar 2 Inside heatsink
2… BRA01320001R Green Bar 2 Inside heatsink
2… BRA01323501R Green Bar 2 Inside heatsink
2… BRA0300102R bar 1
2… BRA0420102R bar 4
2… BRA0450202R bar 2
