FOREWORD

A Word to GP-150-DUAL Owners

Congratulations on your choice of the FURUNO GP-150-DUAL dual differential GPS navigation system. We are confident you will see why the FURUNO name has become synonymous with quality and reliability.

For over 50 years FURUNO Electric Company has enjoyed an enviable reputation for innovative and dependable marine electronics equipment. This dedication to excellence is furthered by our extensive global network of agents and dealers. This equipment is designed and constructed to meet the rigorous demands of the marine environment. However, no machine can perform its intended function unless operated and maintained properly. Please carefully read and follow the recommended procedures for operation and maintenance.

We would appreciate hearing from you, the end-user, about whether we are achieving our purposes.

Thank you for considering and purchasing FURUNO equipment.

Features

The GP-150-DUAL consists of two dual differential GPS navigator systems and an interface unit. Each GPS navigator consists of a display unit combining a GPS receiver and video plotter, a GPS antenna. The interface unit functions to exchange data between the GPS navigators and external equipment. A high sensitivity receiver tracks up to 12 satellites simultaneously. An 8-state Kalman filter ensures optimum accuracy in determination of vessel position, course and speed.

The main features of the GP-150-DUAL are

• Comprehensive navigation data displays

• Storage for 999 waypoints and 30 routes

• Alarms: Waypoint Arrival, Anchor Watch,

Cross track Error, Speed, Water Temperature, Depth, and Trip

• Man overboard feature records latitude and longitude coordinates at time of man overboard and provides continuous updates of range and bearing to that point.

• Menu-driven operation

• Bright 122 x 92 mm LCD with temperature

compensated tone and brilliance adjustment

• Power consumption is a low 10 W per navigator.

• Connection of autopilot (option) - steering data output to autopilot

• Digital display of water temperature and depth with connection of echo sounder having IEC 61162-1/NMEA input

• Memory stores 2,000 points of track and marks.

• 3D "Highway" display shows ship's track overlaid on intended course.

• Position may be shown in latitude and longitude or LOP (Loran or Decca).

• Navaid information (lighthouse data, lighted buoys, etc.) can be displayed by downloading database from personal computer.

• Fully meets the following regulations: IMO MSC. 112(73), IEC 61162-1 and IEC 61108-1.

Program No.

2051518-01.xx (January, 2006)

SYSTEM CONFIGURATION

GPS

ANTENNA

GPA-017S/018S/019S

GPS

ANTENNA

GPA-017S/018S/019S

DISPLAY UNIT

GP-150-DUAL

GPS/BEACON

ANTENNA

DISTRIBUTOR

MD-GB2*

INTERFACE UNIT IF-2500

GPS

ANTENNA

GPA-017S/018S/019S

DISPLAY UNIT

GP-150-DUAL

Position, waypoint, etc. (RS-422/Current loop)

Position, etc. (Current loop)

Arrival alarm

Cross track error alarm

Abnormal receiving alarm

CATEGORY OF UNITS

Unit Category

ANTENNA UNIT Exposed to weather

DISPLAY UNIT Protected from weather

* When an antenna unit is commonly used, GPS/BEACON Antenna Distributor MD-GB2 is

required.

1. OPERATIONAL OVERVIEW

1.1 Control Description

Cursor pad Shift display and cursor.

Opens/closes menu;

quits current operation.

Selects display mode.

Registers waypoints

and routes.

Inscribes mark on

the display.

Enlarges display.

Centers ship’s position/cursor

position.

Adjusts display contrast

and brilliance;

changes latitude/longitude

coordinate.

ESC

DISPLAY SEL

WPT

RTE

MARK

ZOOM IN

CENTER

TONE

NU/CU

ENT

EVENT MOB

GOTO

PLOT ON/OFF

ZOOM OUT

CURSOR ON/OFF

CLEAR

Selects display orientation; registers selections on menus.

Inscribes event mark at ship’s position; marks man overboard position.

Sets destination.

Turns recording and plotting of ship’s track on/off.

Shrinks display.

Turns cursor on/off.

Deletes waypoints and marks; clears wrong data; silences audible alarm.

POWER

Turns power on/off.

Figure 1-1 Control Panel

1-1

1. OPERATIONAL OVERVIEW

1.2 Turning On and Off the Power

The GP-150-DUAL takes about 90 seconds to find its position when turned on for the very first time. Other times it takes about 12 seconds.

Note: The GPS provides highly accurate

position information. However, position should always be checked against other aids to navigation to confirm reliability, for the safety of vessel and crew.

Turning on the power

Press the POWER key.

The unit tests the PROGRAM MEMORY, SRAM and battery for proper operation and shows the results on the display. If equipped with the internal beacon receiver, "BEACON RCVR INSTALLED" appears at the bottom of the display. After the test has been completed, the unit starts up with the last-used display mode.

PROGRAM MEMORY = OK SRAM = OK Internal Battery = OK

When turning on the power the following occurs:

12 seconds after turning on the power, accurate position (in latitude and longitude) appears on the display.

If position could not be found, "NO FIX" appears at the GPS receiving condition window. When PDOP (Position Dilution Of Precision) value exceeds 6 in the 3D mode or HDOP (Horizontal Dilution Of Precision) value exceeds 4 in the 2D mode, "DOP" appears to indicate abnormal fixing and the position indication is not updated.

When the satellite signal is being received normally, one of the indications shown in Table 1-1 appears depending on equipment setting and GPS receiver state.

Table 1-1 GPS receiver indication

Indication Meaning

2D GPS 2D

3D GPS 3D

D2D Differential 2D

D3D Differential 3D

BEACON RCVR INSTALLED DATA 3 : DATA OUTPUT

Several seconds

34° 23.456´ N 135° 45.678´ E

WGS84

2nm

later

[01]

GPS receiving

condition

D3D 100m SAFE

BRG

234°

COG

345°

RNG

123

SOG

12.3

Figure 1-2 Appearance of display when

turning on the power

W2D WAAS 2D

W3D WAAS 3D

Note 1: When PDOP value exceeds 6 in the

3D mode, the position fixing method is automatically changed to 2D.

Note 2: The "DEMO" icon appears when the

display is in the demonstration mode. To return to the normal mode, turn off the power and turn it on while pressing and holding down the

NU/CU ENT key.

Turning off the power

Press the POWER key.

The next time you turn on the power the unit starts up with the last-used display mode.

1-2

1. OPERATIONAL OVERVIEW

1.3 Adjusting Display Contrast and Brilliance

1) Press the TONE key. The display shown

in Figure 1-3 appears.

[-] [+]

Tone:

Brilliance:

MENU : Escape

Figure 1-3 Screen for adjustment of display

tone and brilliance

2) To adjust tone, press

setting and setting range (0-31) are shown to the right of "

3) To adjust brilliance, press

Current setting and setting range (0-7) are shown to the right of "

Note 1: Operate cursor pad within 10

seconds after pressing the TONE key. Otherwise, the screen for adjustment of tone and brilliance will be cleared.

Note 2: If the display is turned off with

minimum tone it will be blank at the next power up. When this occurs press the TONE key continuously to adjust tone.

17 (0~31)

7 (0~7)

or . Current

or .

1.4 Display Mode

1) Press the DISPLAY SEL key. The display shown in Figure 1-4 appears.

Select Display

Plotter 1

Plotter 2

Highway

Navigation Data

(DATUM: WGS-84)*

: Select

MENU : Escape

2) Press the DISPLAY SEL key,

Sample displays of each display mode are shown in the figures on the next several pages.

*Shows currently selected geodetic

chart datum.

Figure 1-4 Screen for selection of display

mode

or to select display mode. (When the DISPLAY SEL key is pressed, the display mode changes in sequence shown below.) Selected display mode appears.

Plotter 1 Plotter 2 Highway

Data

Navigation

1-3

1. OPERATIONAL OVERVIEW

Plotter 1 display

Plotter 2 display

Cursor position data, when cursor is on

Own ship's track

Own ship mark

34° 23.456´ N 135° 45.678´ E

WGS84

2.00 nm

Horizontal range

Course

*: For RAIM function, refer to page 8-1.

Course bar

Course width

Cursor

RAIM reliability*

Alarm range

Grid

Range from own ship to cursor

Figure 1-5 Plotter 1 display

[01]

Bearing from own ship to cursor

Bearing from own ship to destination waypoint

GPS receiving condition

Distance for RAIM reliability

D3D 100m SAFE

BRG

44°

COG

Waypoint

32°

BRG TO +

123

RNG TO +

11.5

Course over ground

Ship's position appears when cursor is off.

34° 23.456´ N 135° 45.678´ E

[01]

WGS84

2 nm

Figure 1-6 Plotter 2 display

Highway display

Bearing from own ship to destination waypoint

Position

34° 23.456´ N 135° 45.678´ E

WGS84

Course over ground

D3D 100m SAFE

BRG

34°

COG

45°

RNG

0.35

SOG

12.3

1-4

Own ship mark

North mark

Cross track error scale

Speed over ground

Range from own ship to destination waypoint

Figure 1-7 Highway display

Navigation display

1) No autopilot

Cross track error meter

Destination waypoint no.

TO;

012

0.1nm 0.1nm

ETA

Bearing scale

BRG

COG

23:45'

Estimated Time of Arrival (15th23:45)

Cross track

Cross track error scale

error indication

Bearing from own ship to destination waypoint

63°

123°

TTG

17H 45M

Time To Go (3days17hrs45min)

Waypoint

VTD

SOG

Velocity To Destination

Tr i p

distance

Speed over ground

D3D 100m SAFE

SOG

VTD

RNG

TRIP

789

12.3

10.3

123

Range from own ship to destination waypoint

1. OPERATIONAL OVERVIEW

2) Autopilot connected, automatic mode

D3D 100m

TO;

012

BRG:

63°

COG:

0.1nm 0.1nm

Auto Pilot

Auto

Auto mode

123°

Hdg

123°

Heading

Str

P 23°

P: Port S: Starboard

SAFE

SOG

12.3

VTD

10.3

RNG

123

TRIP

789

Rudder angle

Figure 1-9 Navigation display, with autopilot

connected, automatic mode

3) Autopilot connected, modes other than automatic mode (manual, nav, etc.)

D3D 100m

TO;

- - -

0.1nm 0.1nm

Auto Pilot

Man

BRG:

COG:

123°

Hdg

123°

63°

Str

P 23°

SAFE

SOG

12.3

VTD

10.3

AP CSE

123°

TRIP

789

Man: Manual mode

Figure 1-8 Navigation display,

no autopilot

Nav: Nav mode Other:---

Figure 1-10 Navigation display, autopilot

connected, modes other than

Heading

the automatic mode

Rudder angle

Autopilot-set course

1-5

1. OPERATIONAL OVERVIEW

Data display

Transmitting data

Refer to Chapter 6 for user-defined window setting. The ZOOM icon can be displayed by pressing the CURSOR ON/OFF key.

Position in latitude and

Fixing date and time*

JAN 12, 2006 23:59'59" U

POSITION

WGS84

RNG

SOG

User-defined display data #2

User-defined display window

12° 23.456' N 123° 23.456' E

31.23

12.3

User-defined display data #1

longitude or LOPs

BRG

223.4°

COG

123.4°

User-defined display data #4

User-defined display data #3

U: UTC J: JST S: Ship's time

D3D 100m SAFE

TO : 001

MARINE POINT1

: 002

MARINE POINT2

Current destination waypoint Next destination waypoint

Zoom icon

Figure 1-11 Data display mode

*: "--" appears until position is found. If fixing error occurs the time indication freezes.

1.5 Transmitting Data

The GPS navigators share the data listed below when transmitting data to each other. Any action initiated against those data is automatically repeated on the other navigator. For example, if you register waypoint 27 on one navigator it will be registered on the other navigator under the same waypoint number.

• Alarm settings, alarm buzzer

• Destination data

• Disabled satellite data

To mutually transmit data, do the following:

1) Press the MENU ESC key to display the MAIN menu.

MAIN MENU

1. DISPLAY SETUP

2. TRA CK/MARK SETUP

3. ERASE TRACK/MARK

4. ALARM SETTINGS

5. MANUAL CALCULATION

7. GPS MONITOR

8. SELF TESTS

9. SYSTEM SETTINGS

ENT: Enter MENU: Escape

Figure 1-12 MAIN menu

2) Press the 9 key to display the SYSTEM SETTINGS menu.

SYSTEM SETTINGS

1. PLOTTER SETUP

2. UNIT SETUP

3. DATA 1, 3 OUTPUT SETUP

4. DATA TRANSFER

5. DATA 4 I/O SETUP

6. GPS SETUP

7. DGPS SETUP

8. LOP SETUP

9. CLEAR MEMORY

ENT: Enter

MENU: Escape

Figure 1-13 SYSTEM SETTINGS menu

3) Press the 4 key to select DATA TRANSFER.

DAT A TRANSFER

Transmit Data All Stop Start

• Error messages

• MOB/Event mark data

• Route data

• Waypoint data

Note: This operation is necessary after

receiving waypoint data through the DATA 4 port (Page 10-14).

1-6

: Select

ENT: Enter MENU: Escape

Figure 1-14 DATA TRANSFER menu

4) Press to select All and press the NU/CU ENT key. The following message appears. Press the NU/CU ENT key to transmit, or MENU ESC to escape.

Are you sure to transmit ?

1. OPERATIONAL OVERVIEW

8) If transmission failed, transmission is stopped and the following message appears.

Failed in transmitting Try again please Press any key

ENT: Yes MENU: No

Figure 1-15

The following message appears while data

is being transmitted.

Now transmitting data

MENU: Stop

Figure 1-16

5) To stop transmitting data, press the MENU ESC key. The following display appears.

Are you sure to stop ?

ENT: Yes MENU: No

Figure 1-17

Press the NU/CU ENT key to stop. In this

case, data is partially transmitted to the other GPS navigator. You should follow "Transmsitting data" in this paragraph to transmit data again.

6) The following message appears when data was transmitted successfully.

Figure 1-19

9) Press any key to return to the DATA TRANSFER menu and select Stop. Since data will be not the same on both GPS navigator, repeat this procedure from step 4 until data is successfully transmitted.

Transmission failure during operation

Data is transmitted only once. When transmission error occurs, the following message appears.

Failed in transmitting Try "DATA TRANSFER" menu Press any key

Figure 1-20

Press any key to erase the message. Follow "Transmitting data" in this paragraph to transmit data again.

Transmitting ended successfully

Press any key

Figure 1-18

7) Press any key to escape.

1-7

1. OPERATIONAL OVERVIEW

1.6 The Interface Unit

The Interface Unit IF-2500 outputs data received from the navigators to external equipment. Operational status is shown by the LEDs on the unit. For further details, see the chapter on installation. For how to select data to output, see paragraph 8.4 Outputting Data.

Output data conventions

Since both navigators output data to the IF-2500 (through two ports on the interface) confusion would reign if it were to try to output two sets of mostly identical data. Therefore, data output is governed by the following rules:

• When both navigators are outputting data correctly, data received at the port having higher priority is output.

• When the GPS abnormal receive signal is received at the port having higher priority, data received from the other port is output.

• 30 seconds after data received at the port having higher priority becomes normal, the interface unit resumes outputting data received from that port.

• When data from both navigators is in error, data received at the port having higher priority is output.

• Arrival alarm signal or cross track error alarm is converted to a contact signal and output when received at the port having higher priority.

• When no data is received from one or both navigators, a contact signal is output.

1-8

2. DISPLAY AND TRACK

2.1 Enlarging/Shrinking the

Display

You may enlarge/shrink the display on the Plotter 1, Plotter 2 and Highway displays, with the ZOOM IN and ZOOM OUT keys. The horizontal range is available among 0.25, 0.5, 1, 2, 4, 8, 16, 32, 64, 128 and 192 nautical miles. For the Plotter 1 display the ranges are

0.36, 0.71, 1.42, 2.84, 5.69, 11.38, 22.76,

45.51, 91.02, 182.04 and 273.07 nautical

miles.

The ZOOM IN key enlarges the display and the ZOOM OUT key shrinks it. Each time a zoom key is pressed the horizontal range appears at the center of the display for about one second.

2.2 Display Orientation

Display orientation can be selected on the Plotter 1 and Plotter 2 displays, with the NU/CU ENT key. Two display orientations are available: north-up and course-up.

North-up display

In the north-up display, true north (0°) is at the top of the display. Own ship moves on the display in accordance with true speed and true motion. Land is stationary.

Course-up display

Destination set

Ship’s course is upward on the screen at the moment the course-up mode is selected and the north mark ( the display.

) appears at the left side of

Destination not set

Ship's heading or course is at the top of the display. The north mark appears at the left side of the display.

2.3 The Cursor

The cursor (+) functions to select location for a mark; erase marks; measure range and bearing, etc.

Data and cursor state

Cursor state determines what data are shown on the display.

Cursor turned on, cursor data

Cursor position is displayed in latitude and longitude or LOPs (depending on menu setting) at the top of the display. The range and bearing from own ship to the cursor appear at the right hand side of the display, when in the Plotter 1 display.

Cursor mark Cursor position in latitude and longitude

34° 23.456´ N 135° 45.678´ E

D3D 100m SAFE

BRG

234°

COG

345°

BRG TO +

123°

RNG TO +

WGS84

2.0 nm

Cursor

Bearing from own

Figure 2-1 Data displayed when the

cursor is on

11.5

Range from own ship to cursor

ship to cursor

2-1

2. DISPLAY AND TRACK

Cursor turned off

2.4 Shifting the Display

Ship's position (in latitude and longitude or LOPs), speed and course appear on the display.

Own ship mark

34° 23.456´ N 135° 45.678´ E

Own ship position in latitude and longitude

D3D 100m SAFE

BRG

234°

COG

345°

RNG

123°

SOG

12.3

Speed

Figure 2-2 Data displayed

when the cursor is turned off

Shifting the cursor

1) Press the CURSOR ON/OFF key to turn

on the cursor.

2) Press the cursor pad to shift the cursor.

The cursor moves in the direction of the arrow pressed. When the cursor reaches the edge of the display, the display shifts in the direction opposite of the arrow pressed.

Centering the cursor

Press the CENTER key.

Course

The display can be shifted on the Plotter 1 and Plotter 2 displays, with the CURSOR ON/OFF key. When own ship tracks off the display it is automatically returned to the screen center.

1) Press the CURSOR ON/OFF key to turn off the cursor.

2) Press the cursor pad continuously. The display shifts in the direction of the arrow pressed.

2.5 Centering Own Ship's

Position

1) Press the CURSOR ON/OFF key to turn off the cursor.

2) Press the CENTER key.

Note: When own ship’s position reaches an

edge of the screen, the display moves to set own ship’s position center of the display.

2.6 Stopping/Starting

Plotting and Recording of Track

The GP-150-DUAL stores 2,000 points of track and marks. When the memory becomes full the oldest track is erased to make room for the latest.

Procedure

Press the PLOT ON/OFF key to start/stop recording and plotting of track.

When plotting is resumed

2-2

"Resuming track plot" appears at the center of the display for about three seconds.

When plotting is stopped

2. DISPLAY AND TRACK

2.7 Erasing Track

"Stopping track plot" appears at the center of the display for about three seconds and "

appears at the left side of the display. ("

" does not appear on the Navigation and Data displays.)

Hold icon (appears while recording of track is stopped)

34° 23.456´ N 135° 45.678´ E

D3D 100m SAFE

BRG

234°

COG

Recording is stopped.

This portion of track does not appear on the display

Recording of track turned off

Figure 2-3 Track not plotted or

recorded when plotting is stopped

Own ship

Ship’s track while recording is stopped

345°

RNG

123

SOG

12.3

Recording of track started

The track stored in the memory and

displayed on the screen can be erased.

Note: Track cannot be restored once erased.

Be absolutely sure you want to erase track.

1) Press the MENU ESC key to show the MAIN MENU.

MAIN MENU

1. DISPLAY SETUP

2. TRACK/MARK SETUP

3. ERASE TRACK/MARK

4. ALARM SETTINGS

5. MANUAL CALCULATION

7. GPS MONITOR

8. SELF TESTS

9. SYSTEM SETTINGS

ENT: Enter MENU: Escape

Figure 2-4 MAIN menu

2) Press 3 to select ERASE TRACK/MARK.

ERASE TRACK/MARK Erase Track

Erase Mark

Track Pts. Used: Mark Pts. Used:

: Select

MENU: Escape

Yes

345/1000 Pt

123/1000 Pt

Figure 2-5 ERASE TRACK/MARK menu

3) Press

4) Press

to select Erase Track.

to select Yes. The message

shown in Figure 2-6 appears.

2-3

2. DISPLAY AND TRACK

Are you sure to erase ?

ENT: Yes MENU: No

Figure 2-6 Prompt for

erasure of track

5) Press the NU/CU ENT key.

2.8 Track Plotting Interval

The plotting interval determines both how the track will be reconstructed on the display and track storage time. A shorter interval provides more accurate reconstruction of track line, however total storage time is reduced. The plotting interval can be selected by time or distance. Plotting by distance offers the advantage that the track is not stored when the vessel is anchored.

Plotting interval by time

The setting range for plotting by time is 00 to 60 minutes.

1) Press the MENU ESC key.

2) Press 2 to display the TRACK/MARK SETUP menu.

TRACK/MARK SETUP

3) Press

4) Press

to select Track Rec.

to select Time.

5) Enter plotting interval in four digits. To enter 30 seconds, for example, press 0, 0, 3, 0.

6) Press the NU/CU ENT key.

7) Press the MENU ESC key.

Plotting interval by distance

The setting range for plotting by distance is

0.01 to 99.99 nautical miles. To plot all track,

enter 00.00.

1) Press the MENU ESC key.

2) Press 2 to display the TRACK/MARK SETUP menu.

3) Press

4) Press

5) Enter plotting interval. To enter 0.1 nautical miles, for example, press 0, 0, 1.

6) Press the NU/CU ENT key.

7) Press the MENU ESC key.

to select Track Rec.

to select Distance.

Track Rec

Mark Shape

Mark Line

Event Mark

: Select

ENT: Enter

Time

(01’00)

MENU: Escape

(00.50nm)

Dist

Figure 2-7 TRACK/MARK SETUP menu

2-4

2.9 Apportioning the Memory

The memory holds 2,000 points of track and marks and may be apportioned as you like. The default memory setting stores 1,000 points each of track and marks.

Note: All data are erased when the memory

apportion setting is changed, even when the previous value is reentered.

To store 1,500 points of track and 500 marks, for example, do the following:

1) Press the MENU ESC key.

2) Press 9 to display the SYSTEM

SETTINGS menu.

SYSTEM SETTINGS

1. PLOTTER SETUP

2. UNIT SETUP

3. DATA 1, 3 OUTPUT SETUP

4. DATA TRANSFER

5. DATA 4 I/O SETUP

6. GPS SETUP

7. DGPS SETUP

8. LOP SETUP

9. CLEAR MEMORY

ENT: Enter

Figure 2-8 SYSTEM SETTNGS menu

3) Press 1 to display the PLOTTER SETUP

menu.

PLOTTER SETUP

Memory Apportion

Bearing Ref.

Mag Variation

Calculation User defined #1

User defined #2 User defined #3 User defined #4

MENU: Escape

Trk = 1000 / 2000Pt

True

Auto

(07° W)

R.L

RNG SOG BRG

COG

Mag Man

(00° E)

G.C

2. DISPLAY AND TRACK

4) Press

to select Memory Apportion.

5) Enter amount of track to store, in four digits. To store 1,500 track points, for example, press 1, 5, 0, 0.

6) Press the NU/CU ENT key, or

or . You are asked if it is all right to erase all data.

Setting erases all data! Are you sure to change ?

ENT: Yes MENU: No

Figure 2-10

7) Press the NU/CU ENT key.

8) Press the MENU ESC key.

Note: Two display units in a system should

be set the same points for memory setting store to share waypoints data.

2.10 Bearing Reference

Ship's course and bearing to waypoint may be displayed in true or magnetic bearing. Magnetic bearing is true bearing plus (or minus) earth's magnetic deviation.

True or magnetic bearing

The default setting displays true bearings.

1) Press the MENU ESC key.

2) Press 9 to display the SYSTEM SETTINGS menu.

3) Press 1 to display the PLOTTER SETUP menu.

4) Press

5) Press

6) Press the NU/CU ENT key.

7) Press the MENU ESC key.

to select Bearing Ref.

to select True or Mag.

ENT: Enter

MENU: Escape

Figure 2-9 PLOTTER SETUP menu

2-5

2. DISPLAY AND TRACK

Magnetic variation

The location of the magnetic north pole is different from the geographical north pole. This causes a difference between the true and magnetic north direction. This difference is called magnetic variation, and varies with respect to the observation point on the earth. Magnetic variation may be entered automatically or manually.

1) Press the MENU ESC key.

2) Press 9 to display the SYSTEM SETTINGS menu.

3) Press 1 to display the PLOTTER SETUP menu.

4) Press

5) Press automatic, current variation appears in parentheses.

6) For manual entry, enter variation in two digits, referring to a nautical chart (00-99°). If the variation is 10°, for example, press 1, 0.

7) If necessary, press the

coordinate from east to west or vice versa.

8) Press the NU/CU ENT key.

9) Press the MENU ESC key.

or to select Mag Variation.

or to select Auto or Man. For

key to change

2-6

3. MARKS

3.1 Entering Marks

Marks can be inscribed on the Plotter 1 and Plotter 2 displays, in one of 12 mark shapes. Further, marks can be connected with lines.

Note: When the mark memory becomes full

no marks can be entered. When this occurs, the buzzer sounds and the message shown below appears on the display for three seconds. To enter a mark when the mark memory is full, erase unnecessary marks.

Can’t save mark Memory full

Figure 3-1

Entering marks

At own ship position

1) Press the CURSOR ON/OFF key to turn off the cursor.

2) Press the MARK key.

At cursor intersection

1) Press the CURSOR ON/OFF key to turn on the cursor.

2) Operate the cursor pad to place the cursor on the location for the mark. Select the mark shape you want, referring to paragraph 3.3.

3) Press the MARK key.

3.2 Erasing Marks

CAUTION

All marks, including event marks and the MOB mark, are erased on the ERASE MARK menu. Be absolutely sure you want to erase all marks; erased marks cannot be restored.

Erasing individual marks

1) Place the cursor on the mark to erase.

2) Press the CLEAR key.

Erasing all marks

1) Press MENU ESC and 3 to display the

ERASE TRACK/MARK menu.

ERASE TRACK/MARK

Erase Track

Erase Mark

Track Pts. Used: Mark Pts. Used: 

: Select

MENU: Escape

Figure 3-2 ERASE TRACK/MARK menu

2) Press

3) Press

Are you sure to erase ?

to select Erase Mark.

to select YES.

Yes Yes

345/1000 Pt

123/1000 Pt

ENT: Yes

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

MENU: No

Figure 3-3

3-1

3. MARKS

3.3 Mark Shape

13 mark shapes are available. Select mark shape as follows:

1) Press MENU ESC and 2 to display the

TRACK/MARK SETUP menu.

TRACK/MARK SETUP

Track Rec

Mark Shape

Mark Line

Event Mark

ENT: Enter

Time

(01’00)

: Select

MENU: Escape

Dist

(00.50nm)

3.5 Entering Event Marks

Event marks can denote any important present position. 99 event marks can be saved, and the unit automatically numbers them from 01 to 99.

Event marks are mutually entered when the navigators are sharing data.

Note 1: When the mark memory becomes

full no event marks can be entered. When this occurs, the buzzer sounds and the message shown below appears on the display for three seconds to alert you. To enter an event mark when the mark memory is full, erase unnecessary event marks.

Figure 3-4 TRACK/MARK SETUP menu

2) Press

3) Press

or to select Mark Shape.

or to select mark shape

desired.

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

The next mark entered will be inscribed in the shape selected here.

3.4 Connecting Marks

Marks can be connected with lines. Three types of connection lines are available and the "•" setting disables connection of lines.

1) Press MENU ESC and 2.

2) Press

3) Press

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

or to select Mark Line.

or to select other than "•".

Can’t save mark Memory full

Figure 3-5

Note 2: Event marks cannot be entered

when there is no position data. When this occurs, the buzzer sounds and the message shown below appears on the display for three seconds to alert you. Check that the antenna cable is tightly connected.

Can’t save event/MOB No position data

Figure 3-6

To enter an event mark;

1) Press the EVENT MOB key less than

three seconds. The position at the exact moment the key is pressed is saved as an event position.

3-2

Saved event position

34° 40.123’ N

135° 21.123’ E

Figure 3-7

To erase event marks, see "3.2 Erasing Marks".

3.6 Event Mark Shape

Event marks are available in 10 shapes.

Event mark shape is mutually changed when the navigators are sharing data.

Select event mark shape as follows.

1) Press MENU ESC and 2 to display the TRACK/MARK SETUP menu.

2) Press

3) Press

shape desired.

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

The next event mark entered will be inscribed in the shape selected here.

to select Event Mark.

to select event mark

3.7 Entering the MOB Mark

The MOB mark denotes man overboard position. To mark man overboard position, press the EVENT MOB key for more than three seconds. When the key is pressed, the position at the exact moment the key is pressed automatically becomes the destination. Further, the plotter display replaces the display in use when it is other than a plotter display.

Only one MOB mark may be entered. Each time the MOB mark is entered the previous MOB mark and its position data are written over. The MOB mark is mutually entered

3. MARKS

when the navigators are sharing data. Note: The MOB mark cannot be entered

Can’t save event/MOB No position data

Figure 3-8

1) Press the EVENT MOB key for at least three seconds.

The MOB mark ("M") is entered at the MOB position and the message shown in Figure 3-9 appears.

Saved MOB position Are you sure to change course to MOB position ? ENT: Yes MENU: No

Figure 3-9

2) Press the NU/CU ENT key. If the display in use is Highway, Navigation or Data, they are automatically replaced by the plotter display.

Note: You may cancel MOB position as

destination by pressing the MENU ESC key instead of the NU/CU ENT key at step 2. Note that the MOB mark remains on the display.

Erasing the MOB mark

See "3.2 Erasing Marks". (MOB mark cannot be erased with the cursor.) The MOB mark is mutually erased when the navigators are sharing data.

3-3

3. MARKS

This page is intentionally left blank.

3-4

4. NAVIGATION PLANNING

4.1 Entering Waypoints

In navigation terminology a waypoint is a particular location on a voyage whether it be a starting, intermediate or destination waypoint.

The GP-150-DUAL can store 999 waypoints, numbered from 001-999. Waypoints can be registered four ways:

• by cursor

• by MOB position or event position

• at own ship's position, and

• through the waypoint list.

Waypoints are mutually entered when the navigators are sharing data.

Entering waypoints by the cursor

1) Press the WPT RTE key to show the Waypoint/Route menu.

Waypoint/Route

1. Cursor

2. MOB/Event Position

3. Own ship Position

4. Waypoint List

5. Route Planning

3) Use the cursor pad to place the cursor on the location desired for the waypoint.

4) Press the NU/CU ENT key.

A window similar to the one shown in Figure 4-3 appears. The waypoint's position and date and time registered appear on the first and second lines. Waypoints are automatically given the youngest empty waypoint number and this number appears on the third line. You may, however, assign a different number. If the waypoint shares the same position with a mark, the mark's position and date and time entered are registered as waypoint data.

If the waypoint memory is full, the waypoint number line in the window is blank. In this case waypoints cannot be entered unless a waypoint is written over or erased.

30° 12.345’ N 135° 23.456’ W

AUG 12’ 03 12 : 34U

No.

123 Mark : Cmnt :

: Cursor

: Column

: Cursor

ENT: Enter

MENU: Escape

Figure 4-1 Waypoint/Route menu

2) Press 1 to select Cursor. The following display appears.

Place cursor on desired location

ENT: Enter MENU: Escape

Figure 4-2

The display changes to Plotter 2 when the Highway, Navigation or Data mode is in use.

ENT: Enter

MENU: Escape

Figure 4-3

The remaining steps show how to change waypoint number, choose mark shape and enter a comment. If you do not need to change these items, press the NU/CU ENT to register the waypoint under the number shown and the current waypoint mark shape. You may also choose the waypoint item to change by pressing

or and following

the appropriate step in this procedure.

5) Enter waypoint number, in three digits (001-999).

4-1

4. NAVIGATION PLANNING

6) Press to select waypoint mark shape. The following display appears.

: Cursor

ENT: Enter

MENU: Escape

Figure 4-4 Screen for selecting

waypoint mark shape

7) Press

or to select mark shape.

8) Press the NU/CU ENT key. The display shown in Figure 4-5 appears.

Control is returned to the last-used display mode.

When the waypoint number entered at step 5 already exists, the message shown in Figure 4-4 appears if the waypoint is part of the current destination or route or is part of a route. If you want to write over the waypoint and its data, press the NU/CU ENT key. To change waypoint number, press the MENU ESC key.

1st line Are you sure to change ?

ABCDE FGHIJ KLMNO PQRST UVWXYZ

abcde

1 2 3 4 5 6 7 8 9 0 _ # % ’ ( ) + - . / : ; < = > ?

ENT: Set

fghij

COMMENT:

: Cursor

klmno

ENTER

pqrst

uvwxyz

_ _ _ _ _ _ _ _ _ _ _ _

MENU: Escape

Figure 4-5 Screen for entry

of comment for waypoint

9) You may enter a comment, using up to 12 alphanumeric characters.

Press the cursor pad to select

alphanumeric character.

Press the NU/CU ENT key. Selected

character appears on the COMMENT line.

• To create a space, select "_".

• Numeric data can be input directly by pressing numeric keys.

• To clear wrong data, press the CLEAR

key.

Repeat steps

and

to complete

the comment.

Select ENTER and press the NU/CU

ENT key.

10) Press the NU/CU ENT key.

ENT: Yes

This wpt is GOTO This wpt is in registered route This wpt is in selected route

MENU: No

Figure 4-6

Note: If you fail to enter waypoint number,

"Enter waypoint number" appears on the display for three seconds.

4-2

Entering waypoints by MOB position/event position

4. NAVIGATION PLANNING

Entering waypoints at own ship's position

The MOB position or an event position can be registered as a waypoint. Event marks are numbered from 01 to 99; 01 is the latest event mark.

Note: You cannot register a MOB position or

event position when there are no MOB positions or event positions saved. The buzzer sounds and the message shown in Figure 4-7 appears for three seconds to alert you.

No MOB/event data in memory

Figure 4-7

1) Press the WPT/RTE key.

2) Press 2 to select MOB/Event Position. The display shown in Figure 4-8 appears.

[MOB] Displaying MOB data 34° 12.345’ N 130° 23.456’ E

[#01] Displaying event data 34° 12.345

ENT:Enter

ENT: Enter

AUG 12’ 94 19 : 25U

:Recall

’ N 130° 23.456’ E

AUG 12’ 03 19 : 25U

MENU:Escape

: Paging

MENU: Escape

Note: When there is no position data, you

cannot register a waypoint at own ship's position. The buzzer sounds and the following message appears.

No position data

Figure 4-9

1) Press the WPT/RTE key.

2) Press 3 to select Own Ship Position.

3) Follow steps 5 through 11 in "Entering waypoints by the cursor" on page 4-1.

Entering waypoints through the waypoint list

1) Press the WPT/RTE key.

2) Press 4 to display the waypoint list.

3) Press

latitude and longitude or LOP.

WAYPOINT LIST (L/L)

001

MARINE POINT

002

A POINT

003

to select position format;

34° 12.345’ N 130° 23.456’ W

AUG 12’ 03 12 : 35U

36° 12.345’ N 135° 23.456’ W

AUG 13’ 03 13 : 45U

° . ’ N ° . ’ W

Figure 4-8

3) Press

to display the MOB position or event position to register as a waypoint.

4) Press the NU/CU ENT key.

5) Follow steps 5 through 11 in "Entering waypoints by the cursor" on page 4-1.

004

ENT: Enter

° . ’ N ° . ’ W

: L/L’LOP

: Edit

MENU: Escape

Figure 4-10

4) Press

or to select waypoint

number.

5) Press

or to enter position. The display should now look something like Figure 4-11.

4-3

4. NAVIGATION PLANNING

Edit = Waypoint : 001

_ _°

_ _._ _ _’ N _ _ _°_ _._ _ _’ W

Mark : Cmnt :

ENT: Enter

: Cursor

: Column

MENU: Escape

Figure 4-11

6) Enter latitude and longitude. To enter 34°12.345' N 135°23.456' E, for example, press;

, 3, 4, 1, 2, 3, 4, 5

, 1, 3, 5, 2, 3, 4, 5, 6

To change N to S or E to W, press

7) Press

8) Press

to select mark.

9) Press the NU/CU ENT key.

10) Enter comment.

11) Press the NU/CU ENT key twice.

The waypoint list reappears. Waypoint position and date and time the waypoint was entered appear on the list.

12) To enter another waypoint through the waypoint list, repeat steps 4-11.

13) Press the MENU ESC key to finish.

4.2 Editing Waypoints

Waypoints are mutually edited when the navigators are sharing data.

1) Press WPT RTE and 4.

2) Press

edit.

3) Press

4) Edit the contents of the waypoint.

5) Press the NU/CU ENT key. The message shown in Figure 4-12 appears if the waypoint is currently selected as destination, is part of a route, or is in the route currently selected as destination.

to select waypoint to

1st line Are you sure to change ?

ENT: Yes

This wpt is GOTO This wpt is in registered route This wpt is in selected route

MENU: No

Figure 4-12

6) Press the NU/CU ENT key.

Enter new data, referring to "4.1 Entering Waypoints".

7) Press the MENU ESC key.

4.3 Erasing Waypoints

Waypoints are mutually erased when the navigators are sharing data.

Erasing waypoints by the cursor

1) Place the cursor on the waypoint to erase.

2) Press the CLEAR key.

4-4

Erasing waypoints through the waypoint list

1) Press WPT RTE and 4.

2) Press erase.

3) Press the CLEAR key. The message shown in Figure 4-13 appears if the waypoint is currently selected as destination, is part of a route, or is in the route currently selected as destination.

Note: All waypoint marks (as well as all

4) Press the NU/CU ENT key.

Note: To cancel erasure, press the

5) Press the MENU ESC key.

or to select waypoint to

1st line Are you sure to erase ?

ENT: Yes

This wpt is GOTO This wpt is in registered route This wpt is in selected route

MENU: No

Figure 4-13

other marks) and their data can be erased collectively by clearing the Plotter memory. For further details, see page 9-1.

MENU ESC key instead of the NU/CU ENT key. The waypoint list

appears.

4. NAVIGATION PLANNING

4.4 Entering Routes

Often a trip from one place to another involves several course changes, requiring a series of route points which you navigate to, one after another. The sequence of waypoints leading to the ultimate destination is called a route. The GP-150-DUAL can automatically advance to the next waypoint on a route, so you do not have to change the destination waypoint repeatedly.

The GP-150-DUAL can store 30 routes and each route may contain up to 30 waypoints. Routes can be registered while in the Plotter 1 or Plotter 2 display mode. Routes are mutually registered when the navigators are sharing data.

Entering routes

1) Press the WPT/RTE key.

2) Press 5 to select Route Planning. The route list appears.

ROUTE LIST

No. PTS Total Dist. TTG Remarks

ENT: Enter

Remarks Use: In use Fwd: Traverse waypoints in forward order Rvs: Traverse waypoints in reverse order

1234 . 56 nm

234 . 56 nm

*999. 99 nm

. nm

6543 . 21 nm

. nm

: Route No.

12D15H28M

2D08H35M

*9D*9H*9M

D H M

34D23H45M

D H M

: Edit

MENU: Escape

UseFwd

Figure 4-14 Route list

3) Press

to select an empty route

number.

4) Press

The route planning/waypoint list window appear as shown in Figure 4-15. The waypoint list window lists the position and data for each registered waypoint. No position or data appears for empty waypoints.

4-5

4. NAVIGATION PLANNING

ROUTE : 01 (In Use , REVERSE)

skip Distance TTG

Trial Speed : Auto Man (012.0kt)

001

002

ENT: Enter

Use: In use Fwd: Traverse waypoints in forward order Rvs: Traverse waypoints in reverse order

34° 12.345’ N 130° 23.456’ E

MARINE POINT

36° 12.345’ N 135° 23.456’ E

A POINT

↔

: RTE WPT

MENU: Escape

AUG 12’ 03 12 : 35U

AUG 13’ 03 13 : 45U

CLEAR: Delete

Route

editing

screen

Waypoint list

Figure 4-15 Route editing screen

5) If required, press

to choose Trial Speed to enter the speed by which to calculate time-to-go.

6) Press

Auto: Current average speed is used to calculate the time-to-go. Manual: Entered speed is used to calculate the time-to-go. Enter speed and press

to select Auto or Man.

Route waypoints may be registered two ways: entering waypoint number directly or

through the route editing screen. Follow

below.

Entering waypoint number directly

7) Enter waypoint number, in three digits. The cursor shifts to the "Skip" window. The procedure for skipping a waypoint is shown on page 5-4. For now, go to the next step.

8) Press

to continue. If the waypoint entered in step 7 does not exist, you are informed that the waypoint does not exist and entry is cancelled.

9) Enter other route waypoints by repeating steps 7 and 8.

10) Press MENU ESC to finish.

Using previously registered waypoints

Enter waypoints in the order they will be traversed; not by waypoint number order.

7) Press

. The reverse video on the waypoint on route planning screen disappears.

8) Press

to select waypoint

number.

9) Press the NU/CU ENT key. Selected waypoint number appears on the route editing screen. The distance and time-to-go indications to the first waypoint entered are blank.

10) To enter other route waypoints, repeat steps 8 and 9.

11) Press the MENU ESC key to finish.

Note: To return to the route editing screen,

press

4.5 Erasing Route

Waypoints

Route waypoints are mutually erased when the navigators are sharing data.

1) Press WPT RTE and 5 to display the route list.

2) Press

3) Press

4) Select the waypoint to erase.

5) Press the CLEAR key.

6) Press the NU/CU ENT key.

7) Repeat steps 2 through 4 to continue erasing waypoints.

8) Press the MENU ESC key. The route is rearranged to reflect the change.

to select route.

to display route editing screen.

4-6

4. NAVIGATION PLANNING

4.6 Replacing Route Waypoints

Route waypoints are mutually replaced when the navigators are sharing data.

1) Press WPT RTE and 5 to display the

route list.

2) Press

3) Press

4) On the route editing screen, place the

cursor on waypoint number to replace.

5) Enter new waypoint number.

6) Press the NU/CU ENT key. The message

shown in Figure 4-16 appears.

This waypoint already exists Are you sure to change ?

ENT: Yes

7) Press the NU/CU ENT key.

8) Press the MENU ESC key twice.

or to select route.

to display route editing screen.

MENU: No

Figure 4-16

4.7 Erasing Routes

Routes are mutually erased when the navigators are sharing data.

1) Press WPT RTE and 5 to display the route list.

2) Press

3) Press the CLEAR key. The display shown in Figure 4-17 appears if the route is in use.

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

1st line Are you sure to erase ?

ENT: Yes

This route is in use

to select route to erase.

MENU: No

Figure 4-17

4-7

4. NAVIGATION PLANNING

This page is intentionally left blank.

4-8

5. SETTING DESTINATION

5.1 Setting Destination

There are four ways by which you can set destination:

• By cursor

• By MOB position or event position

• By waypoint, and

• By route.

The same destination is set on both navigators when they are sharing data.

Note: Previous destination is cancelled

whenever a destination is set.

Setting destination by cursor

Using the cursor you may set a destination consisting of 30 points. When all 30 points are entered, the GP-150-DUAL automatically disables further entry.

Setting single destination

1) Press the GOTO key. The menu shown in Figure 5-2 appears.

GOTO Setting

1. Cursor

2. MOB/Event Position

3. Waypoint List

4. Route List

5. Cancel

: Cursor

ENT : Enter

Figure 5-2 GOTO setting menu

2) Press 1 to select Cursor. The display shown in Figure 5-3 appears.

Place cursor on desired location Press ENT twice to finish ENT:Enter CLR:Clear MENU:Escape

MENU : Escape

Figure 5-3

If the display in use is other than Plotter 1, the Plotter 2 display is automatically selected.

3) Place the cursor on the location desired for destination.

4) Press the NU/CU ENT key.

Note: To clear selection, press the

CLEAR key.

5) Press the NU/CU ENT key to finish.

Control is returned to the display mode in use before you set destination. A dashed line connects own ship and the destination, which is marked with a flag, as shown in Figure 5-4.

5-1

5. SETTING DESTINATION

Flag mark

Figure 5-4 Single destination set by cursor

Setting multiple destinations

1) Press GOTO and 1.

2) Place the cursor on the location desired for a waypoint.

3) Press the NU/CU ENT key.

4) Repeat steps 2 and 3 to enter other points. Waypoints are connected with a line.

5) Press the NU/CU ENT key to finish. The

route number entry display appears as shown in Figure 5-5. If no route number appears or you want to change the route number shown, go to step 6 to enter route number. To register the route under the number shown, go to step 8.

Note: For the simple route, press the CLEAR

key and then go to step 8. The simple route is not registered in the route list.

Enter route number

0 1

ENT:Enter MENU: Escape

Figure 5-5

6) Key in route number.

7) Press the NU/CU ENT key. Waypoints are marked with flags and are connected with a dashed line.

If the route number entered already exists the message shown in Figure 5-6 appears.

Overwriting ? ENT:Yes MENU:No

Figure 5-6

8) Press the NU/CU ENT key.

The waypoints do not have waypoint numbers, however you can attach waypoint numbers by doing the following.

Press WPT RTE and 5 to display the route

list.

Press

entered.

Press

Enter waypoint number, in three digits.

Press

exists the message shown in Figure 5-7 appears.

This waypoint already exists Are you sure to change ? ENT:Yes MENU:No

to select route number

. If the waypoint number already

Figure 5-7

Press the NU/CU ENT key. The waypoint

entered here replaces previously entered waypoint.

Note: To cancel replacement of

waypoint, press the MENU ESC

and

to enter other

key at step

Repeat steps

waypoint numbers.

Press the MENU ESC key twice to finish.

When destination is cancelled, dashed lines are erased but flags remain on the screen.

5-2

Setting destination by MOB position or event position

5. SETTING DESTINATION

Setting destination through waypoint list

Note: This operation cannot be performed

when there is no MOB position or event position. The buzzer sounds and the message shown in Figure 5-8 appears to alert you when there is no MOB position or event position.

No MOB/event data in memory

Figure 5-8

1) Press the GOTO key.

2) Press 2 to select MOB/Event Position. The display shown in Figure 5-9 appears.

[MOB] Displaying MOB data 34° 12.345’ N 130° 23.456’ E

[#01] Displaying event data 34° 12.345’ N 130° 23.456’ E

ENT:Enter

ENT: Enter

AUG 12’ 94 19 : 25U

:Recall

AUG 12’ 03 19 : 25U

MENU:Escape

: Paging

MENU: Escape

Figure 5-9

3) Press

to select MOB position or event position. The MOB position appears first. To select event position, press

. If selected position is within the current display range, the cursor marks the position. (The cursor does not appear on the Highway, Navigation and Data displays.)

4) Press the NU/CU ENT key. A flag appears at position selected if it is within the current display range. A dashed line connects between own ship and MOB position or event position.

When destination is cancelled, dashed lines are erased but flags remain on the screen.

Note: A waypoint must exist to set it as

destination. When a waypoint does not exist, the buzzer sounds and the message shown in Figure 5-10 appears.

No waypoint data

Figure 5-10

Destination waypoint can be set through the waypoint list two ways:

•

By entering waypoint number, and

•

By selecting waypoint by cursor

1) Press the GOTO key.

2) Press 3 to display the Waypoint List.

GOTO (Waypoint List)

Waypoint

Waypoint No.

No.

001 34° 12.345’ N 132° 23.456’ E

MARINE POINT AUG 12’ 03 12:35U 002 34° 12.345’ N 133° 12.345’ E A POINT AUG 13’ 03 13:28U 005 41° 34.567’ N 135° 23.456’ E B POINT AUG 14’ 03 09:45U

No .

Waypoint number can be entered here when this line appears in reverse video.

List

ENT:Enter

Figure 5-11 Waypoint list

Set destination by following

below.

Setting destination by waypoint no.

3) Enter waypoint number, in three digits. You can clear entry by pressing the CLEAR key.

4) Press the NU/CU ENT key.

Own ship position becomes starting point and a dashed line runs between it and the waypoint selected.

5-3

5. SETTING DESTINATION

Setting destination by selecting wpt.

3) Press

. Each press of the key alternately enables manual entry of waypoint number and selection of waypoint number by cursor (through the waypoint window).

4) Press

to select waypoint.

5) Press the NU/CU ENT key.

Own ship position becomes starting point and a dashed line runs between it and the waypoint selected.

Setting route as destination

Route number can be entered here when this line appears in reverse video.

GOTO (Route List)

Route No.

No.

PTS

02 05

: No. List

ENT:Enter

TOTAL

1234. 56nm

234. 56nm

57. 89nm

999. 99nm

6543. 21nm

FORWARD

TTG

12D15H28M

2D08H35M

0D10H28M

9D23H59M

34D23H45M

MENU:Escape

Figure 5-13 Route list

Note: Route entered must exist to set it as

destination. The buzzer sounds and the message shown in Figure 5-12 appears if you set enter a route which does not exist.

No route data

Figure 5-12

A route to set as destination may selected through the route list two ways:

•

By entering route number, and

•

By selecting route.

1) Press the GOTO key.

2) Press 4 to display the Route List. Then, follow

in the adjacent column.

By entering route number

3) Press

to select direction which to traverse the route waypoints; forward or reverse.

4) Enter route number.

5) Press the NU/CU ENT key.

Current position becomes starting point. A solid line connects between the starting point and first route waypoint and a dashed line connects all other route waypoints.

By selecting a route

3) Press

. Each press of the key alternately enables manual entry of route number and selection of route number (through the route window)

4) Press

5) Press

to select route.

to select direction in which to traverse the route waypoints; forward or reverse.

6) Press the NU/CU ENT key.

Current position becomes starting point. A solid line connects between the starting point and first route waypoint and a dashed line connects all other route waypoints.

5-4

Skipping route waypoints

You may skip route waypoints by displaying "DI" (DIsable) next to the route waypoint in the route list. Using Figure 5-14 as an example, your ship is currently heading toward waypoint 04 but is to switch course and head to waypoint 03. In this case you would want to skip waypoint 04.

Waypoint 01

Port A

Port B

Waypoint 06

1) Press WPT RTE and 5 to display the route list. Press the cursor keys to select route.

"EN" indicates waypoint is enabled. Display "DI" to skip waypoint.

ROUTE :01

skip Distance TTG

001

Trial Speed Auto Man (012.0kt)

01 0 04 EN

02 0 03 EN 345.67nm 2D 12H 34M

004

34° 12.345’ N 130° 23.456’ E MARINE POINT AUG 10’ 03 12:35U

003 36° 12.345’ N 135° 23.456’ E A POINT AUG 10’ 03 13:45U

: RTE WPT

ENT:Enter

Waypoint 02

Waypoint 03

New course

Figure 5-14

(In Use, REVERSE)

CLEAR: Delete

MENU:Escape

Waypoint 04

Waypoint 05

5. SETTING DESTINATION

2) Press

to select route waypoint

to skip.

3) Press

to shift the cursor to the

right of the waypoint number.

4) Press

to change "EN"(ENable) to

"DI"(DIsable).

5) Press the NU/CU ENT key.

To reselect the waypoint, select it on the route list and press

to change "DI" to "EN". Route waypoints are mutually skipped when the navigators are sharing data.

5.2 Cancelling Destination

Destination is cancelled at both GPS navigators when they are sharing data.

1) Press the GOTO key.

2) Press 5 to select Cancel. The message

shown in Figure 5-16 appears.

Release GOTO ?

ENT:Yes MENU:No

Figure 5-16

3) Press the NU/CU ENT key.

Note: If you are using the simple route, it will

be erased when the destination is canceled.

Figure 5-15 Route list

5-5

5. SETTING DESTINATION

5.3 Erasing Route

When flags are erased

Waypoints (flags)

Flags are erased at both GPS navigators when they are sharing data.

1) Place the cursor on the flag to erase.

2) Press the CLEAR key. The message shown in Figure 5-17 appears if the waypoint is currently selected as destination, is part of a registered route, or is part of the route currently being navigated.

1st line Are you sure to erase ? ENT:Yes MENU:No

This wpt is GOTO This wpt is in registered route This wpt is in selected route

When the origin waypoint is erased the waypoint before it becomes the origin waypoint. If there is no waypoint before the origin waypoint, current position becomes the origin waypoint.

Delete

Starting

point

Own ship

Destination waypoint

Course

Destination waypoint

Figure 5-17

3) Press the NU/CU ENT key.

Note: Flags can be erased collectively by

clearing the Plotter memory or both the Plotter memory and GPS memory. See page 9-1 for further details.

Figure 5-18 Route rearranged

after erasing flag

When a destination is erased, the waypoint which follows it becomes the destination. If there is no waypoint after the destination waypoint erased, route navigation is cancelled.

5-6

5.4 Finding Range and Bearing Between Two Points

Selecting course sailing method

The range and bearing to a destination can be calculated two ways: Great Circle or Rhumb Line. However, cross track error is calculated in rhumb line only.

Great Circle: The great circle courseline is the shortest course between two points on the surface of the earth. (Imagine stretching a piece of yarn between two points on the earth.) However, this course requires frequent change of heading to follow course faithfully.

Rhumb Line: The rhumb line courseline is the straight line drawn between two points on a nautical chart. This course does not require frequent changes of heading however it is not the shortest since it follows the earth's curvature.

1) Press MENU ESC, 9 and 1 to display the

PLOTTER SETUP menu.

PLOTTER SETUP

Memory Apportion Bearing Ref.

Mag Variation

Calculation

User defined #1 SOG User defined #2 User defined #3 RNG User defined #4 BRG

ENT:Enter

Figure 5-20 PLOTTER SETUP menu

2) Press

3) Press

or to selection Calculation.

or to select R.L (Rhumb

Line) or G.C (Great Circle).

Trk = 1000 / 2000Pt

True

Auto

(07° W)

R.L

COG

MENU:Escape

Mag Man

(00° E)

G.C

5. SETTING DESTINATION

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

Calculation procedure

You can find the range and bearing between two points by two waypoints or two latitude and longitude positions.

1) Press MENU ESC and 5. The MANUAL CALCULATION menu appears.

MANUAL CALCULATION

From

To Waypoint No. Trial speed : Auto Man

Rng: . m Brg: . ° TTG: D H M

ENT : Calculation

2) Choose two points by one of the methods below.

Latitude and longitude positions

1) Press

2) If necessary press

North latitude and to South latitude vice versa.

3) Key in latitude.

4) If necessary press

longitude to East longitude and vice versa.

5) Key in longitude.

6) Press

7) Repeat 2-5 to enter other point.

Waypoints

1) Key in first waypoint number (000-999).

(000 is reserved for own ship position.)

2) Press

3) Key in other waypoint number (000-999).

4) Press

Speed line.

5) Press

Waypoint No.

° . ’N ° . ’E

( . kt)

: Cursor

MENU : Escape

: N/S, E/W

Figure 5-19 MANUAL CALCULATION menu

to switch from

to switch from West

twice.

to shift the cursor to the Trial

to select Auto or Man. Auto

5-7

5. SETTING DESTINATION

uses ship's average speed to calculate time-to-go.

6) If you selected Man, enter speed.

7) Press the NU/CU ENT key.

The range, bearing and time-to-go between two points appear on the display. If data entered is wrong or insufficient the buzzer sounds and the message "INCOMPLETE DATA" appears. If the data contains error, "*" and all nines appear as the calculation results.

8) Press the MENU ESC key.

5-8

6. SETTING UP VARIOUS DISPLAYS

6.1 The Data Display

The user may select what data to display in four locations on the data display.

JAN 12, 2005 23:59’59" U

POSITION

12 23.456’ N

D3D 100m SAFE

123 23.456’ E

WGS84

RNG

31.23

SOG

12.3

User-defined display data #1

User-defined display data #2

User-defined display window

BRG

COG

223.4

123.4

User-defined display data #4

User-defined display data #3

Figure 6-1 Data display

The data the user may display are;

• Altitude (ALT)*

TO : 001

MARINE POINT1

: 002

MARINE POINT2

• Trip elapsed time (TRIP TM)

• Water temperature (W.TMP)#, and

• Velocity to destination (VTD)*

• ETA to route

*ALT: Displayed only in 3D position fixing. *RT. DIST: Total distance from current

position to ultimate destination. Appears when following a registered route or a cursor-created route. *VTD: When following a route, plus or minus appears next to indication to denote which direction the route is being traversed.

# Requires external sensor.

1) Press MENU ESC, 9 and 1 to display the PLOTTER SETUP menu.

PLOTTER SETUP

Memory Apportion

Bearing Ref.

Mag Variation

Trk = 1000 / 2000Pt

True

Auto

(07° W)

Mag

Man

(00° E)

• Average course (AVR COG)

• Average speed (AVR SPD)

• Course (COG)

• Course error (dCOG)

• Cross track error (XTE)

• Depth (W.DPT)#

• ETA to waypoint (ETA)

• Range to waypoint (RNG)

• Bering to waypoint (BRG)

• Route time-to-go (RT.TTG)

• Speed (SOG)

• Time-to-go to waypoint (TTG)

• Total route distance (RT.DIST)*

• Trip distance (TRIP)

Calculation User defined #1

User defined #2

User defined #3

User defined #4

ENT:Enter

R.L

SOG

COG

RNG

BRG

MENU:Escape

G.C

Figure 6-2 PLOTTER SETUP menu

2) Press

or to select one of four of

"User defined" (#1, #2, #3, #4).

3) Press

to select data to display.

4) Press the NU/CU ENT key. To select the data to display at other user defined displays, repeat steps 2 and 3.

5) Press the MENU ESC key.

6-1

6. SETTING UP VARIOUS DISPLAYS

6.2 Position Format

For Loran LOPs

Position can be displayed in latitude and longitude, Loran C LOPs, or Decca LOPs, and the default format is latitude and longitude.

Displaying position in latitude and longitude

1) Press MENU ESC, 9 and 8 to display the LOP SETUP menu.

LOP SETUP

Pos Display Lat / Long LOP

Pos Display

LOP Display LC DE LC Chain 7980 : 23-43 ∆LOP -12.3us +0.34 us DE Chain 24:G - P ∆LOP +0.80 Lane -1.00 Lane

(RED:1 GREEN:2 PURPLE:3)

MENU : Escape

Lat / Long

: Select

ENT : Enter

: +/-

Figure 6-3 LOP SETUP menu

2) Press

3) Press

to select Pos Display.

to select Lat/Long.

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

Displaying position in LOPs

6) Press to select LC Chain.

7) Key in GRI code referring to the Loran C chain list in the Appendix. If the GRI code is 9970, for example, press 9, 9, 7, 0.

8) Key in secondary code pair referring to the Loran C chain list in the Appendix.

9) If necessary press

to choose ∆LOP to enter correction value. Key in correction value. Use

to switch from plus to

minus or vice versa.

10) Press the NU/CU ENT key.

11) Press the MENU ESC key.

For Decca LOPs

6) Press

to select DE Chain.

7) Key in Decca chain number referring to the Decca chain list in the Appendix. For the Europe chain, for example, press 0, 1.

8) Key in Decca lane pair. Red, 1; Green 2, and Purple 3.

9) If necessary press

to choose

to enter correction value. Key in correction value. Use

to switch from

plus to minus or vice versa.

10) Press the NU/CU ENT key.

11) Press the MENU ESC key.

LOP

1) Press MENU ESC, 9 and 8.

2) Press

3) Press

4) Press

5) Press

to select Pos Display.

to select LOP.

to select LOP Display.

or to select LC (Loran C) or

DE (Decca).

in the adjacent column

according to selection in step 5.

6-2

Entering waypoints using LOPs

1) Press WPT RTE and 4.

2) Press

WAYPOINT LIST (LOP, LC)

001

001 36365.2 59102.3 MARINE POINT AUG12’ 03 12 : 35U

002 36512.3 59134.5 ___ A POINT AUG13’ 03 13 : 45U

003 _ _ _ _ _ , _ _ _ _ _ _ , _ ___ _ _ _ _ _ _ _ _ _ _ _ _

004 _ _ _ _ _ , _ _ _ _ _ _ , _ ___ _ _ _ _ _ _ _ _ _ _ _ _

: L/L LOP

ENT : Enter

Figure 6-4 LOP display on the waypoint list

3) Press

number.

4) Press

like one of the displays in Figure 6-5.

to display LOPs.

MENU : Escape

to select waypoint

. Your display should look

: Edit

6. SETTING UP VARIOUS DISPLAYS

5) Key in LOP1 and LOP2, to enable calculation.

6) Press

to calculate LOPs. "Calculating" appears between parentheses during the calculation. Actual LOPs replace "Calculating" upon completion of the calculation.

If the conversion fails, the message "Failed in Conversion" appears for three seconds.

Press the CLEAR key and reenter the right LOP1 and LOP2.

7) Press or to select mark.

8) Press the NU/CU ENT key.

9) Enter comment, if desired.

10) Press the NU/CU ENT key twice. The waypoint list appears.

Edit=Waypoint : 001

LC8930 : 30 50 3 8931.2 58654.3 (34° 12.345’ Mark : Cmnt : MARINE POINT

ENT : Enter

DE : 32 (9C) RED GREEN 1 A:12.23 2H:24.35 (34° 12.345’ Mark : Cmnt : MARINE POINT

ABCDEFGHIJ fi 1, 2 ~ 9, 0

ENT : Enter

N 130° 23.456’ E)

: Cursor

Loran C LOP input screen

Edit=Waypoint : 001

N 130° 23.456’ E)

: Cursor

: Column

MENU : Escape

: Column

MENU : Escape

Decca LOP input screen

Figure 6-5 LOP input screens

6-3

6. SETTING UP VARIOUS DISPLAYS

6.3 Demo Display

The demo display provides simulated operation of this unit. Own ship tracks, at the speed selected, a figure eight course, starting from position entered. All controls are operative; you may change course, enter marks, etc.

1) While pressing and holding down NU/CU ENT, turn on the power.

DEMO SETTING

BASE POSITION

_ _°

_ _._ _ _’ N _ _ _°_ _._ _ _’ W

SPEED

00.00kt

Note: The return to the normal mode, turn off

the power and then turn it on while pressing and hold down NU/CU ENT key.

: Cursor

ENT: Enter

: Column

: N/S, E/W

Figure 6-6 DEMO SETTING menu

2) Key in latitude of initial position.

3) If necessary, press

to switch from north latitude to south latitude or vice versa.

4) Key in longitude.

5) If necessary, press

to switch from east longitude to west longitude or vice versa.

6) Press

7) Key in speed.

8) Press the NU/CU ENT key to start the demonstration mode. The plotter display appears and the demo mode begins. After the test results appear, the demo setting mode menu appears.

9) To quit the demo display, turn off the power.

All tracks, marks and data entered during the simulation are erased and default demo mode settings are restored.

6-4

7. ALARMS

7.1 Overview

There are seven alarm conditions which generate both aural and visual alarms.

When an alarm setting is violated, the buzzer sounds and the name of the alarm being violated appears on the display. The alarm icon also appears on the Plotter 1, Plotter 2 and Highway displays. This occurs on both navigators when they are sharing data.

Alarm status is output to external equipment through the DATA1 port and the DATA4 port when it outputs data in NMEA format.

34° 23.456´ N 135° 45.678´ E

Alarm message

D3D 100m SAFE

BRG

234°

COG

345°

Alarm icon

Arrival alarm Speed alarm

Press CLEAR to silence beep

RNG

123

SOG

12.3

Press CLEAR

Press CLEAR to silence beep and close window

Figure 7-1 Location of alarm

messages and alarm icon

Clearing the aural and visual alarms

Press the CLEAR key. When the navigators are sharing data, the "reset alarm signal" is transmitted to the other navigator to clear aural and visual alarms there.

Disabling an alarm

Select OFF instead of alarm name on the appropriate menu. This disables the alarm on both navigators when they are sharing data.

7.2 Arrival Alarm, Anchor Watch Alarm

Arrival alarm

The arrival alarm informs you that own ship is approaching a destination waypoint. The area that defines an arrival zone is that of a circle which you approach from the outside of the circle. The alarm will be released if own ship enters the circle.

Alarm setting

Own ship’s position

Figure 7-2 How the arrival alarm works

1) Press the MENU ESC key.

2) Press 4 to display the ALARM

SETTINGS menu.

ALARM SETTINGS 1/2

Arrival/Anchor Arr. Anc. Off Alarm Range 0.100nm XTE On Off Alarm Range 0.050nm

Ship Speed

Ship Speed In Over Off Speed Range 000.0 ~ 025.0kt Next Page

ENT : Enter

Figure 7-3 ALARM SETTINGS

3) Press

4) Press

5) Press

6) Key in alarm range (0.001-9.999 nm).

7) Press the NU/CU ENT key.

8) Press the MENU ESC key.

When own ship nears a waypoint by the range set here, the buzzer sounds and the message "Arrival alarm" appears.

Destination waypoint

: Select

MENU : Escape

: Alarm range

Over

menu, page 1/2

to select Arrival/Anchor.

to select Arr.

to select Alarm Range.

7-1

7. ALARMS

Anchor watch alarm

7.3 Cross Track Error (XTE)

The anchor watch alarm sounds to warn you that own ship is moving when it should be at rest.

Alarm

setting

Own ship’s position

Destination waypoint

: Alarm range

Figure 7-4 How the anchor

watch alarm works

Before setting the anchor watch alarm, set present position as destination waypoint, referring to chapter 5.

1) Press MENU ESC and 4.

2) Press

3) Press

4) Press

to select Arrival/Anchor.

to select Anc.

to select Alarm Range.

5) Key in alarm range (0.001-9.999 nm).

6) Press the NU/CU ENT key.

7) Press the MENU ESC key.

When own ship drifts by the range set here, the buzzer sounds and the message "Anchor alarm" appears.

Alarm

The XTE alarm warns you when own ship is off its intended course.

Starting

waypoint

Figure 7-5 How the XTE alarm works

Own ship’s position

Alarm setting

: Alarm range

1) Press MENU ESC and 4.

2) Press

3) Press

4) Press

to select XTE.

to select On.

to select Alarm Range.

5) Key in alarm range (0.001-9.999 nm).

6) Press the NU/CU ENT key.

7) Press the MENU ESC key.

When own ship strays from the intended track by the range set here, the buzzer sounds and the message "Cross track error alarm" appears.

Destination waypoint

7-2

7. ALARMS

7.4 Speed Alarm

The speed alarm sounds when ship's speed is lower or higher (or within) the alarm range set.

1) Press MENU ESC and 4.

2) Press

3) Press

In: Alarm sounds when speed is within range set.

Over: Alarm sounds when speed is higher or lower than range set.

4) Press to select Speed Range.

5) Key in low speed.

6) Key in high speed.

7) Press the NU/CU ENT key.

8) Press the MENU ESC key.

When speed is higher or lower (or within) than the speed set here, the buzzer sounds and the message "Speed alarm" appears.

or to select Ship Speed.

or to select In or Over.

7.5 Trip Alarm

The trip alarm sounds when the distance run is greater than the trip alarm setting.

1) Press MENU ESC and 4.

2) Press shown in Figure 7-6 appears.

ALARM SETTINGS 2/2

To Previous Page

Trip (CLR:Reset)

On Off Trip Range 0123.00nm Water Temp. In Over Off Temp. Range +12.0 ~ +15.0°C Depth In Over Off Depth Range 0003.0 ~ 0200.0ft WAAS/DGPS On

MENU : Escape

Figure 7-6 Alarm settings menu, page 2/2

3) Press

4) If necessary, press CLEAR to reset the trip distance and trip elapsed time.

5) Press

6) Press

7) Key in trip range.

8) Press the NU/CU ENT key.

9) Press the MENU ESC key.

When the ship's distance run is higher than the trip range set here, the buzzer sounds and the message "Trip alarm" appears.

to select Next Page. The menu

Off

: Select

ENT : Enter

+/-

or to select Trip.

or to select On.

to select Trip Range.

7-3

7. ALARMS

7.6 Water Temperature Alarm

The water temperature alarm sounds when the water temperature is higher or lower (or within) the preset temperature. This alarm requires a water temperature signal from external equipment.

1) Press MENU ESC and 4.

2) On page 2/2 of the ALARM SETTINGS

menu, press Tem p.

3) Press

4) Press

5) Key in low temperature.

6) Key in high temperature.

7) Press the NU/CU ENT key.

8) Press the MENU ESC key.

When the water temperature is higher or lower (or within) the preset value, the buzzer sounds and the message "Water temp alarm" appears.

or to select In or Over.

to select Temp. Range.

or to select Water

7.7 Depth Alarm

The depth temperature alarm sounds when the depth is higher or lower (or within) the preset depth. This alarm requires video sounder connection.

1) Press MENU ESC and 4.

2) On page 2/2 of the ALARM SETTINGS menu, press

3) Press

4) Press

5) Key in low depth.

6) Key in high depth.

7) Press the NU/CU ENT key.

8) Press the MENU ESC key.

When the depth is higher or lower (or within) the preset value, the buzzer sounds and the message "Depth alarm" appears.

or to select In or Over.

to select Depth Range.

or to select Depth.

7.8 WAAS/DGPS Alarm

The WAAS/DGPS alarm sounds when the WAAS/DGPS signal is lost. This alarm may be enabled or disabled as below.

1) Press MENU ESC and 4.

2) On page 2/2 of the ALARM SETTINGS menu, press WAAS/DGPS.

3) Press

4) Press the NU/CU/ENT key.

5) Press the MENU ESC key.

to select On, or to select off.

or to select

7-4

8. MENU SETTINGS

8.1 GPS SETUP Menu

Menu description

Fix mode

Two position fixing modes are available: 2D and 2/3D. The 2D mode provides two dimensional position fixes (latitude and longitude only) and is used when three satellites are in line of sight of the GPS receiver. The 2/3D mode switches between two and three dimension position fixing automatically depending on how many satellites (three or four) are in line of sight of the GPS receiver.

ANT Height

Enter the height of the antenna unit above sea surface (000-999 ft, 000-304 m). The default setting is 16 ft.

Disable satellite

Every GPS satellite is broadcasting abnormal satellite number(s) in the Almanac. Using this information, the GPS receiver automatically eliminates any malfunctioning satellite from the GPS satellite schedule. However, the Almanac sometimes may not contain this information. You can disable an inoperative satellite manually on the GPS SETUP menu.

GPS smoothing, position

When the DOP or receiving condition is unfavorable, the GPS fix may change greatly, even if the vessel is dead in water. This change can be reduced by smoothing the raw GPS fixes. A setting between 0 and 9 is available. The higher the setting the more smoothed the raw data, however too high a setting slows response time to change in latitude and longitude. This is especially noticeable at high ship’s speeds. "0" is the normal setting; increase the setting if the GPS fix changes greatly.

GPS smoothing, speed

During position fixing, ship’s velocity (speed and course) is directly measured by receiving GPS satellite signals. The raw velocity data may change randomly depending on receiving conditions and other factors. You can reduce this random variation by increasing the smoothing. Like with latitude and longitude smoothing, the higher the speed and course smoothing the more smoothed the raw data. If the setting is too high, however, the response to speed and course change slows. For no smoothing, enter "0." "5" is suitable for most conditions.

Speed average

Calculation of ETA and TTG, etc. is based on average ship’s speed over a given period. The default setting is one minute. Change the setting if the ETA seems wrong.

RAIM function/RAIM accuracy

RAIM (Receiver Autonomous Integrity Monitoring) is a diagnostic function which tests the accuracy of the GPS signal. To use the RAIM function, enter the range (from own ship in meters) for which you want to know position confidence, on the GPS Setup 2/2 menu. The receiver estimates position confidence using range value and detected satellite error, and displays (provided the RAIM function is active) the results as one of three levels of position confidence, at the top right-hand corner of the screen. The three levels are as follows:

SAFE: GPS signal is normal. The positioning accuracy satisfies the setting value. CAUTION: RAIM accuracy cannot be calculated. (Signals from more than five GPS satellites are necessary.) The positioning accuracy does not satisfy the setting value. UNSAFE: GPS signal is abnormal, therefore the positioning accuracy is not reliable. Note that the GP-150-DUAL does not exclude abnormal signals automatically.

8-1

8. MENU SETTINGS

SAFE: GPS signal is safe to use. CAUTION: RAIM accuracy is shorter than protected level or RAIM measurement not possible. UNSAFE: GPS signal is not safe to use.

Enter the range for which you want to know position confidence

Geodetic datum

Select the geodetic chart system you are using. WGS-84 (standard GPS chart system) and NAD 27 can be directly selected. For other charts, select "OTHER" and enter chart number referring to the geodetic chart list in the Appendix.

To output position data to ECDIS (Electronic Chart Display and Information System), turn on the power while holding down the 0 key to disable access to the Geodetic Datum menu. Then, "Cannot be changed" is shown in the Geodetic Datum menu as in Figure 8-2 on the next page. To stop outputting position data to ECDIS, turn on the power while holding down the 0 key.

Position offset

You may apply an offset to position generated by the internal GPS receiver, to compensate for difference between GPS position and chart position.

Time difference

The GPS system uses UTC time. If you would rather use local time, enter the difference in hours between local time and UTC. Use the + and - keys for times later or earlier than UTC, respectively.

Position

When executing cold start there is no satellite information in the unit’s memory, thus it may take some time to find position. To fix position faster, enter estimated position.

Setting up the GPS SETUP menu

Fix mode

1) Press MENU ESC, 9 and 6 to display the GPS SETUP menu.

GPS SETUP 1/2

Fix Mode 2D 2/3D ANT Height 016 ft Disable Satellite 12 GPS Smoothing

0 0 0 (0000-9999 sec) Spd 0 0 0 5 (0000-9999 sec) Speed Average 0 0 6 0 (0000-9999 sec)

To Next Page

MENU : Escape

Posn

: Select

Figure 8-1 GPS SETUP menu, page 1/2

2) Press

3) Press

to select Fix Mode.

to select fix mode

desired.

4) Press

to change other settings, or press MENU ESC to register settings and escape.

Disabling satellites

When the navigators are sharing data, satellites are disabled on both navigators.

1) Press MENU ESC, 9 and 6.

2) Press

to select Disable

satellite.

3) Key in satellite number, in two digits (01-32). Three sets of satellite numbers may be entered.

4) Press the NU/CU ENT key. If an invalid number is entered the buzzer sounds.

5) Press the MENU ESC key.

Note: To enable all disabled satellites, press

the CLEAR key at step 3. All satellite numbers on the Disable satellite line are erased.

(1-32)

ENT : Enter

8-2

GPS position smoothing

RAIM accuracy

8. MENU SETTINGS

1) Press MENU ESC, 9 and 6.

2) Press

or to select Posn.

3) Enter smoothing factor in three digits (0000-9999).

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

GPS speed smoothing

1) Press MENU ESC, 9 and 6.

2) Press

or to select Spd.

3) Enter smoothing factor in three digits (0000-9999).

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

Speed averaging

1) Press MENU ESC, 9 and 6.

2) Press

to select Speed Average.

3) Enter smoothing factor in two digits (0000-9999).

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

RAIM function

1) Press MENU ESC, 9 and 6.

2) Press

to select RAIM function on

page 2/2.

GPS SETUP 2/2

To Previous Page

RAIM Function OFF

ON RAIM Accuracy 100 m

Geodetic Datum WGS84 NAD27 OTHER (Cannot be changed) (001)

Posn Offset 0.000’ N 0.000’ E Time Diff. +00:00 Posn 38 00.000’ N 123 00.000’ W

: Select

MENU : Escape

ENT : Enter

: +/

Figure 8-2 GPS SETUP menu, page 2/2

3) Press

to turn RAIM function ON

or OFF as appropriate.

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

1) Press MENU ESC, 9 and 6.

2) Press

to select RAIM accuracy

on page 2/2.

3) Key in the range for which you want to know RAIM accuracy (1 to 999 m).

Note: Unit is meter only.

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

Geodetic datum

1) Press MENU ESC, 9 and 6.

2) Press

to select Geodetic

Datum on page 2/2.

3) Press

to select geodetic datum to use. For geodetic datum other than WGS-84 or NAD-27, select OTHER and key in chart number (001-173) referring to the geodetic chart list in the Appendix.

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

Position offset

If you do not know the type of chart you are using, GPS position may be wrong. Note the difference in position when moored to a pier and enter it on the GPS SETUP menu, to get correct position.

1) Press MENU ESC, 9 and 6.

2) Press

to select Posn Offset on

page 2/2.

3) If necessary press

to switch from north latitude to south latitude or vice versa.

4) Key in latitude correction.

5) If necessary press

to switch from east longitude to west longitude or vice versa.

6) Key in longitude correction.

7) Press the NU/CU ENT key.

8) Press the MENU ESC key.

The

icon appears when L/L offset is

applied.

8-3

8. MENU SETTINGS

Time difference

1) Press MENU ESC, 9 and 6.

2) Press

or to select Time Diff on

page 2/2.

3) Key in time difference (-14:00 to +14:00).

4) Press

to change from plus to minus

or vice versa.

5) Press the MENU ESC key.

Position

After the unit is installed you may enter position to shorten the time it takes to find position. (It takes about two minutes when there is no position data entered.)

1) Press MENU ESC, 9 and 6.

2) Press

to select Posn on page

2/2.

3) If necessary, press

to switch from north latitude to south latitude or vice versa. Key in latitude.

4) If necessary, press

to switch from east longitude to west longitude or vice versa. Key in longitude.

5) Press the NU/CU ENT key.

6) Press the MENU ESC key.

8.2 Units of Measurement

Unit of distance

Distance can be displayed in nautical mile, kilometer or statute mile as follows.

1) Press MENU ESC, 9 and 2. The UNIT SETUP menu appears.

2) Press

3) Press

to select Unit of Distance.

to select unit; nm, km or

sm.

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

Unit of depth

1) Press MENU ESC, 9 and 2.

2) Press

3) Press

to select Unit of Depth.

to select unit; meter, feet,

or fathom.

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

Unit of water temperature

1) Press MENU ESC, 9 and 2.

2) Press

3) Press

to select Unit of Temp.

to select unit; Centigrade

or Fahrenheit.

4) Press NU/CU ENT and MENU ESC.

Unit of altitude

Available only in 3D mode.

1) Press MENU ESC, 9 and 2.

2) Press

3) Press

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

to select Unit of Altitude.

to select unit.

UNIT SETUP

Unit of Distance

Unit of Depth Unit of Temp. Unit of Altitude

ENT : Enter

Figure 8-3 UNIT SETUP menu

8-4

° C

:Select

MENU : Escape

km sm

ft FA

° F

8.3 Size and Brilliance of

8. MENU SETTINGS

Waypoint mark size

Markers

The DISPLAY SETUP menu lets you select the size and brilliance of various markers.

Grid tone

The grid can be displayed in light or dark tone, or turned off.

1) Press MENU ESC and 1. The DISPLAY SETUP menu appears.

DISPLAY SETUP

Grid Course Bar

Time Mark

Waypoint Size Cursor Size

ENT : Enter

Dark Dark

Dark

Large Large

: Select

Figure 8-4 DISPLAY SETUP menu

2) Press

3) Press

to select Grid.

to select brilliance.

4) Press NU/CU ENT and MENU ESC.

Course bar tone

Light Light Light Small Small

MENU : Escape

Off Off Off

The size of the waypoint mark can be selected to large or small.

Large waypoint mark

No icon With icon

Small waypoint mark

Figure 8-5 Waypoint mark size

1) Press MENU ESC and 1.

2) Press

3) Press

to select Waypoint Size.

to select Large or Small.

4) Press NU/CU ENT and MENU ESC.

Cursor size

The size of the cursor can be selected to large or small.

Large cursor

Small cursor

The course bar can be displayed in light or dark tone, or turned off.

1) Press MENU ESC and 1.

2) Press

3) Press

to select Course Bar.

to select brilliance.

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

Time mark tone

The time mark can be displayed in light or dark tone, or turned off.

1) Press MENU ESC and 1.

2) Press

3) Press

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

to select Time Mark.

to select brilliance.

Figure 8-6 Cursor size

1) Press MENU ESC and 1.

2) Press

3) Press

to select Cursor Size.

to select Large or Small.

4) Press the NU/CU ENT key.

5) Press the MENU ESC key.

8-5

8. MENU SETTINGS

Enlarging characters

8.4 Outputting Data

The size of the indications of position or user-defined display areas can be enlarged on the Data display.

1) On the Data display, with no enlarged characters, press the CURSOR ON/OFF key to turn on the zoom icon.

2) Operate the cursor keys to select data to enlarge in the window.

3) Press the ZOOM IN key.

To switch character size from enlarged to normal, press the ZOOM OUT key at step 3.

Position

JAN 12, 2006 23:59'59" U

POSITION

WGS84

12° 23.456' N 123° 23.456' E

D3D 100m SAFE

Besides its fundamental function of displaying position, the GP-150-DUAL can also receive data and output data to external equipment, through an interface unit. Before outputting data to external equipment, first determine what data the external equipment requires. Output only necessary data to ensure data will be output correctly.

All data transmitted by marine electronics equipment are prefixed with a two-character code called a talker. The same talker must be shared by the transmitting and receiving equipment to transmit and receive data successfully. The GP-150-DUAL transmits data using the GP (GPS talker), LC (Loran) or DE (Decca) talker.

DATA 1 output setting

RNG

31.23

SOG

12.3

User-defined display window

JAN 12, 2006 23:59'59" U

N12

ZOOM

OUT

23.456'

E123

23.456'

BRG

223.4°

COG

123.4°

Zoom icon

ZOOM

D3D 100m SAFE

TO : 001

MARINE POINT1

: 002

MARINE POINT2

POSITION

WGS84

1) Press MENU ESC, 9 and 3. The DATA 1, 3 OUTPUT SETUP menu appears.

DATA 1, 3 OUTPUT SETUP

Data Fmt. V1.5 V2.0 IEC

Talker ID GP LC DE

Output Data (00-90 sec) 91%

1. AAM:00 APA:00 APB:04 BOD:00

2. BWR:00 BWW:00 GGA:00 GLL:00

3. RMB:01 RMC:01 VTG:01 WCV:00

4. WNR:00 WPL:00 XTE:00 ZDA:01

5. GNS:00 GBS:00 Rnn:00 RTE:00

DATA3. Log Pulse 400ppm

ENT : Enter

Settings shown here are default settings.

This line appears only when LOG is selected by internal jumper wires.

Figure 8-8 DATA 1 OUTPUT

200ppm

MENU : Escape

8-6

Figure 8-7 How to enlarge

indications on the data display

SETUP menu

2) Press to select Data Fmt.

3) Press

or to select NMEA 0183

(V1.5 or V2.0) or IEC 61162-1.

4) Press the NU/CU ENT key. Talker ID appears in reverse video.

5) Press

or to select GP, LC or DE.

6) Press the NU/CU ENT key.

7) Enter Tx interval for each output data sentence in line 1. Tx interval is available in 00, 01, 02, 03, 04, 05, 06, 10, 15, 20, 30, 60 and 90 (seconds).

8) Press the NU/CU ENT key.

9) Enter Tx interval for each output data sentence in lines 2 through 5. Press the NU/CU ENT key after setting each line.

For detailed information about Tx interval see the chapter on installation. However, the Tx interval settings entered by the installer of the equipment should not be changed unless absolutely necessary.

BWC and WNC are for great circle navigation and BWR and WNR are for rhumb line navigation. However, all output data are calculated by rhumb line.

When the external equipment cannot display data input from the GP-150-DUAL correctly, the rate of operation should be lowered.

For example, set a rate of operation less then 60% for the Temperature Indicator TI-20.

DATA 3 output setting

The DATA 3 connector can output IEC 61162-1/NMEA 0183 data or log pulse. For NMEA 0183, IEC 61162-1 the same data output by DATA 1 is output from DATA 3.

For log pulse, select 200 or 400 pulse per second depending on the device connected.

8. MENU SETTINGS

1) Press MENU ESC, 9 and 3.

2) Press

3) For log pulse, press

to select DATA 3 or Log Pulse.

or to select log pulse of external equipment; 200 ppm or 400 ppm.

4) Press the NU/CU ENT key twice.

Setting DATA 4 to data output

The DATA 4 port connects to a personal computer, DGPS receiver or YEOMAN equipment.

1) Press MENU ESC, 9 and 5. The DATA 4 I/O SETUP (1/2) menu appears.

DATA 4 I/O SETUP 1/2

DATA 4. Level

DATA 4. Level RS422

Data Out Com. DGPS

To Next Page

ENT : Enter

Figure 8-9 DATA 4 I/O SETUP menu (1/2)

2) Press

3) Press

to select Level.

equipment; RS232C or RS422.

4) Press the NU/CU ENT key.

5) Press

6) Press

to select To Next Page. The

DATA 4 I/O SETUP (2/2) menu appears.

RS232C

: Select

MENU : Escape

to select level of external

to select Out.

8-7

8. MENU SETTINGS

DATA 4 I/O SETUP <Out> 2/2

To Previous Page

Data Fmt. V1.5 V2.0 IEC

Talker ID GP LC DE

Output Data (00-90 sec) 100%

1. AAM:00 APA:00 APB:04 BOD:00

2. BWR:00 BWW:00 GGA:00 GLL:01

3. RMB:01 RMC:00 VTG:01 WCV:00

4. WNR:00 WPL:00 XTE:00 ZDA:01

5. GNS:00 GBS:01 Rnn:00 RTE:00

7) Press

8) Press

to select Baud Rate.

to select baud rate; 4800

bps, 9600 bps, or 19200 bps.

9) Press the NU/CU ENT key.

10) Press

11) Press

to select WPT/RTE.

to select Command. Stop, on the same line as Command, appears in reverse video.

12) Press

to select Start. The message

shown in Figure 8-12 appears.

ENT : Enter

MENU : Escape

Figure 8-10 DATA 4 I/O SETUP menu (2/2)

7) Follow "DATA 1 output setting" from step

8.5 Receiving Data from Personal Computer

Loading waypoint/route data

Waypoints and routes data can be downloaded from a personal computer, through the DATA 4 connector.

1) Press MENU ESC, 9 and 5.

2) Press

3) Press

computer; RS232C or RS422.

4) Press the NU/CU ENT key.

5) Press

6) Press

DATA 4 I/O SETUP menu appears.

to select DATA 4 Level.

or to select level of personal

or to select Com.

to select To Next Page. The

Loading erases current data and stops Route navigation Are you sure to load ? ENT: Yes MENU:No

Figure 8-12

13) Press the NU/CU ENT key. The message shown in Figure 8-13 appears.

Now loading Waypoint/Route data !

MENU:Stop

Figure 8-13

14) Operate the computer to output data. When data is loaded, the cursor shifts to Stop.

15) Press the MENU ESC key. When data is loaded successfully, The message shown in Figure 8-14 appears.

Loading ended successfully

DATA 4 I/O SETUP <Com.> 2/2

To Previous Page Baud Rate 9600 bps

Load Data WPT/RTE WPT

Command Stop Start Save Data WPT/RTE Command Stop Start

: Select

ENT : Enter

MENU : Escape

Figure 8-11 DATA 4 I/O SETUP menu (2/2)

8-8

Press any key

Figure 8-14

If data could not be loaded, the message shown in Figure 8-15 appears.

Failed in loading Invalid data Press any key

Figure 8-15

Stopping loading of data

1) Press the MENU ESC key. The message shown in Figure 8-16 appears.

Are you sure to stop ?

ENT: Yes MENU:No

Figure 8-16

2) To quit loading, press the NU/CU ENT key. The cursor shifts to Stop.

3) To start loading, select Start.

4) Press the NU/CU ENT key.

Loading waypoint data from YEOMAN equipment

1) Do steps 1 through 9 in "Loading Waypoint/route data."

2) Press

3) Press

4) Press

shown in Figure 8-17 appears.

5) Press the NU/CU ENT key. The message shown in Figure 8-18 appears.

6) Operate the YEOMAN to output data.

When data is loaded, the cursor automatically shifts to "Stop". Waypoints are loaded into empty areas. When the waypoint area becomes full, the message shown in Figure 8-19 appears.

to select WPT.

to select Command.

to select Start. The message

Are you sure to load ?

ENT: Yes MENU:No

Figure 8-17

Now loading Waypoint data !

MENU:Stop

Figure 8-18

8. MENU SETTINGS

Waypoint area is full ! Can’t load any data Press any key to stop

Figure 8-19

7) When the data is loaded, press CU/NU ENT and MENU ESC. The message

shown in Figure 8-20 appears.

The number of valid and invalid waypoints appear in the message.

Loading completed Valid waypoint : 0 Invalid waypoint : 0 Press any key

Figure 8-20

8) Press the MENU ESC key twice.

Saving data to personal computer

Waypoint and route data can be saved to a personal computer.

1) Press MENU ESC, 9 and 5.

2) Press

3) Press or RS422.

4) Press the NU/CU ENT key. "Data" appears in reverse video.

5) Press

6) Press

7) Press

8) Press 4800bps, 9600bps, or 19200bps.

9) Press Save Data line). Stop, on the same line as Command, appears in reverse video.

10) Press shown in Figure 8-21 appears.

to select Level.

to select level; RS232C

to select Com.

to select Next Page. to select Baud Rate.

to select baud rate;

to select Command (under the

to select Start. The message

Are you sure to save ?

ENT: Yes MENU:No

Figure 8-21

8-9

8. MENU SETTINGS

11) Press the NU/CU ENT key. The message shown in Figure 8-22 appears while data is being saved.

Now saving Waypoint/Route data !

MENU:Stop

Figure 8-22

12) Save data at the computer.

13) Press the MENU ESC key. When data is saved, the cursor shifts to Stop.

14) Press the MENU ESC key.

8.6 WAAS/DGPS Setting

DGPS

1) Press MENU ESC, 9 and 7 to display the WAAS/DGPS SETUP menu.

Frequency appears when "Man" is selected.

WAAS/DGPS SETUP

MODE Of

WAAS SEARCH Auto Man (GEO=134) CORRECTIONS DATA SET : 00

DGPS Station Auto Man (ID=0274)

Freq. 323.0kHz

Baud Rate 200 bps

: Select

ENT : Enter

GPS Of

MENU : Escape

Figure 8-25

This menu sets the using WAAS or when the DGPS beacon receiver GR-80 is connected. The default setting is “GPS”.

WAAS

1) Press MENU ESC, 9 and 7 to display the WAAS/DGPS SETUP menu.

WAAS/DGPS SETUP

MODE Of

WAAS SEARCH Auto Man (GEO=134)

CORRECTIONS DATA SET : 00 DGPS Station Auto Man (ID=0274)

Freq. 323.0kHz

Baud Rate 200 bps

: Select

ENT : Enter

GPS Of

MENU : Escape

Figure 8-23 WAAS/DGPS SETUP menu

2) Press

3) Press

to select DGPS Station.

or to select Auto or Man. For automatic search, the GP-150-Dual automatically search DGPS reference station. For manual search, select frequency of DGPS reference station and select the transmission rate of that.

2) Press

3) Press

4) Press

8-10

or to select WAAS or AUTO.

to select WAAS SEARCH.

or to select Auto or Man.

Reference

1) Press MENU ESC, 9 and 7 to display the DGPS SETUP menu.

2) Press

3) Press

or to select DGPS Station.

to select Man.

4) Enter four-digit ID number. You can clear an entry by the CLEAR key. If the number entered is invalid, the buzzer sounds and the message "INVALID ID" appears on the display for three seconds.

If there is no ID number, press the CLEAR key.

5) Press the NU/CU ENT key.

6) Enter frequency in four digits (283.5 kHz to 325.0 kHz).

7) Press the NU/CU ENT key. "Baud Rate" appears in reverse video.

8) Press

or to select baud rate; 25,

50, 100 or 200 bps.

9) Press the MENU ESC key.

8.7 GPS Monitor Display

8. MENU SETTINGS

Number, bearing and elevation angle of all satellites in view of the GPS receiver appear. Satellites being used in fixing position are circled with a solid line; satellites not being used in fixing position are circled with a dashed line.

Satellite distribution

Jan 21 2006 23:59’59" U

:BEACON RCVR MONITOR

MENU:Escape

Satellite number with circle is used for positioning.

Fixing date and time

Receive signal level

(When signal level is more than 35, it is used for positioning.)

*: This indication appears in the WAAS mode.

SATELLITES MONITOR

W3D 100m SAFE

SV (PRN)

01 12

31 16 18 19

134

DOP:1.5

DOP value

GPS fix state

SNR

Three GPS monitor displays provide GPS information:

• Satellite monitor which shows position of

GPS satellites

• DGPS INTEGRITY STATUS which

displays DGPS beacon station information

• DGPS beacon station message monitor

which displays messages received from beacon stations

To display the GPS monitor displays;

1) Press MENU ESC, 7.

2) Press

you want to view.

3) Press the MENU ESC key to escape.

to choose the GPS monitor

Jan 21 2006 23:59’59" U

DGPS INTEGRITY STATUS

:STATION MESSAGE

MENU:Escape

DGPS data and DGPS

station receiving condition

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

NAME:

ID: _ _ _ _ Bit Rate: _ _ _ bps

Sig Strength: _ _ dB

DGPS DATA: Good BEACON STATION:

DGPS INTEGRITY STATUS

Press [ ].

D3D 100m SAFE

Health: _ Freq: _ _ _ . _ kHz SNR: _ _ dB

Good

DGPS station

data

8-11

8. MENU SETTINGS

Press [ ].

Jan 21 2006 23:59’59" U

Message:

STATION IS OPERATING.

:SATELLITES MONITOR

MENU:Escape

STATION MESSAGE

Press [ ].

Return to SATELLITES MONITOR

Figure 8-26 GPS monitor displays

D3D 100m SAFE

8-12

9. MAINTENANCE & TROUBLESHOOTING

9.1 Clearing the Memory

The GP-150-DUAL has two memories: GPS memory and plotter memory.

Clearing the plotter memory

The plotter memory holds plotted track and mark data. When you clear the plotter memory, all tracks and marks are cleared and all corresponding defaults settings are restored.

1) Press MENU ESC, 9 and 9 to display the

CLEAR MEMORY menu.

CLEAR MEMORY

Clear Plotter No Yes

Clear GPS

Clear GPS No Yes Clear All No Yes

Clearing the GPS memory

The GPS memory stores GPS information, including the Almanac. When you clear the GPS memory, all GPS information is erased.

1) Press MENU ESC, 9 and 9 to display the

CLEAR MEMORY menu.

2) Press

3) Press message appears.

4) Press the [NU/CU ENT] key.

or to select Clear GPS.

to select Yes. The following

Setting for cold start Are you sure to clear ? ENT:Yes MENU:No

Figure 9-3

Clearing GPS and plotter memories

: Select

MENU : Escape

Figure 9-1 CLEAR MEMORY menu

2) Press

3) Press message appears.

4) Press the NU/CU ENT key.

to select Clear Plotter.

to select Yes. The following

Clear tracks and marks Are you sure to clear ? ENT:Yes MENU:No

Figure 9-2

To clear both GPS and plotter memories;

1) Press MENU ESC, 9 and 9 to display the

CLEAR MEMORY menu.

2) Press

3) Press shown in Figure 9-4 appears.

4) Press the NU/CU ENT key.

Note: The equipment may lock after

to select Clear All.

to select Yes. The message

Setting for default Are you sure to clear ? ENT:Yes MENU:No

Figure 9-4

clearing the GPS and plotter memories. Reapply power to the equipment to restore normal operation.

9-1

9. MAINTENANCE & TROUBLESHOOTING

9.2 Preventive Maintenance

Battery

Regular maintenance is necessary to maintain performance. Check the items mentioned below monthly to keep the equipment in good working order.

Antenna unit

Check fixing bolts for tightness.

Antenna cable

Check connector for tightness, rust, damage and water leaks.

Power cable

Check for tight connection.

Ground terminal

Check for rust and tight connection.

Fuse

The 2A fuse (Type: FGBO-A 2A AC125V, Code No.: 000-549-062) in the power cable protects the unit from overvoltage and equipment fault. If the fuse blows, find out the cause before replacing the fuse. If the fuse blows after replacement, request service.

A battery installed on the NP board inside the display unit preserves date when the power is turned off. The life of the battery is about three years. When the battery voltage is low “NG” appears on the start-up display. When this happens, contact your dealer to request replacement of the battery.

Type Code Number

Lithium Battery

CR2450-F2ST2L 000-144-941

9.3 Error Messages

Error messages appear on the display to alert you to possible trouble.

GPS error

When the GPS signal is suddenly lost and position cannot be calculated within one second the message shown in Figure 9-5 appears.

GPS No fix

Figure 9-5 GPS error message

WARNING

Use only a 2A fuse in the power cable.

Use of different fuses may cause fire.

9-2

This message may appear when there is an interfering object between the satellite and GPS receiver (for example, mast) or the antenna cable is disconnected.

Press the CLEAR key to silence the buzzer. If the CLEAR key is not pressed, several beeps sound every three minutes.

Error message disappears automatically when normal operation is restored.

DOP error

9. MAINTENANCE & TROUBLESHOOTING

Self test error message

When PDOP value exceeds 6 in the 3D mode, or HDOP value exceeds 4 in the 2D mode, this error occurs and the following message appears.

DOP Error

Figure 9-6 DOP error message

Press the CLEAR key to silence the buzzer. If the CLEAR key is not pressed, several beeps sound every three minutes.

Error message disappears automatically when normal operation is restored.

DGPS error

If the self test (conducted when turning on the power) finds equipment error, the message shown in Figure 9-8 appears.

GPS No fix GPS SEFTTEST error XX

Figure 9-8 Self test error message

If the self test error message appears, consult your dealer for advice.

When the DGPS alarm is active and DGPS data contains errors or the DGPS beacon station is experiencing transmitting problems, the message shown in Figure 9-7 appears. Normal operation is restored when DGPS signal is acquired.

DGPS Error

Figure 9-7 DGPS error message

Refer to DGPS INTEGRITY STATUS in “8.7 Display GPS Monitor Displays” to confirm DGPS Beacon station status.

9-3

9. MAINTENANCE & TROUBLESHOOTING

9.4 Troubleshooting

The table which follows provides troubleshooting procedures which you can follow to restore normal operation. If normal operation cannot be restored, ask your dealer for advice.

Table 9-1 Troubleshooting table

If… Then…

you cannot turn on the power

position cannot be fixed

position is wrong

position sometimes cannot be fixed

data cannot be transmitted to external equipment

• check power connector for tight connection.

• check if ship’s main is off.

• check for blown fuse.

• check antenna cable for tight connection and water leakage.

• check if functional satellite has been disabled:

MENU ESC, 9, 6

• Check if correct geodetic chart is entered: MENU ESC, 9, 6

• apply position correction to GPS position: MENU ESC, 9, 6

• DOP figure may be too small. Enter larger figure; 20 is the

usual setting.

• check if data format is correct:

MENU ESC, 9, 3 (9, 4 or 9, 5) See the chapter on installation for further details.

• tx interval may be set to “0”. Select proper interval.

MENU ESC, 9, 3 (9, 4 or 9, 5) See chapter on installation for further details.

9-4

• check appropriate settings on external equipment.

• check connections:

GP-150-DUAL TXD-H ↔ RXD-H TXD-C ↔ RXD-C

Ext. equipment

9.5 Diagnostic Tests

Memory and I/O port test

1) Press MENU ESC and 8 to display the SELF TESTS menu.

SELF TESTS

1. Memory, I/O Port Test

2. Keyboard Test

3. Test Pattern

4. Automatic T esting

DGPS PROGRAM No. 08501820XX GPS PROGRAM No. 48505640XX NAV PROGRAM No. 2051520-01.XX BOOT PROGRAM No. 2051521-01.XX

:Cursor

ENT:Enter

Figure 9-9 Diagnostic TESTS menu

Note: Program version No. shown as "xx" is

a field which denotes minor changes and is subject to change under responsibility of the manufacturer.

2) Press 1.

MENU:Escape

9. MAINTENANCE & TROUBLESHOOTING

OK appears to the right of GPS and

BEACON when they are normal; NG and 16 hexadecimal figure appear when an abnormality is found.

Whenever NG or 16 hexadecimal figure

appears contact your dealer for advice.

DATA 1 PORT, DATA 2 PORT and DATA

4 PORT show results of communication interface test. A special test connector is required to test those ports. NG appears as the results of the self test when there is no test connector attached.

4) Press the MENU ESC key to escape.

Keyboard test

1) Press MENU ESC, 8 and 2 to display the KEYBOARD TEST screen.

KEYBOARD TEST

MEMORY, I/O PORT TEST

PROGRAM MEMORY SRAM Internal Battery DATA 1 PORT DATA 2 PORT DATA 4 PORT GPS BEACON

MENU:Escape

OK OK OK

NG NG

NG OK OK

Figure 9-10 MEMORY, I/O PORT

TEST display

3) When testing is finished, press the MENU ESC key to escape and return to the SELF TESTS menu. (Testing continues if the key is not pressed.)

OK appears to the right of PROGRAM,

SRAM and Internal Battery when those devices are normal; NG (No Good) appears when an abnormality is found.

Press CLEAR 3 times to escape

Figure 9-11 KEYBOARD TEST screen

2) Press each key one by one. A key's corresponding location on the screen lights in reverse video if the key is normal.

3) To quit the keyboard test, press the CLEAR key three times. Control is returned to the SELF TESTS menu.

4) Press the MENU ESC key.

9-5

9. MAINTENANCE & TROUBLESHOOTING

Display test

Automatic testing

1) Press MENU ESC, 8 and 3 to display the test pattern screens.

2) To change the test pattern, press the NU/CU ENT key. Each time the key is pressed one of the patterns shown in Figure 9-12 appears.

TEST PATTERN

ENT:Pattern MENU:Escape

This feature conducts all self tests continuously.

1) Press MENU ESC, 8 and 4. Self tests are conducted continuously in the order of memory, I/O test, keyboard test and test pattern.

2) To stop testing, press the MENU ESC key.

3) Press the MENU ESC key.

9.6 Interface Unit IF-2500

Fuse replacement

If the fuse blows, find the cause of the problem before replacing it. Do not use a fuse rated more than 0.5A, since it may cause more serious damage to the equipment.

Self test 1

Figure 9-12 Test patterns 1 and 2

3) Press the MENU ESC key.

The unit performs an internal self-check in the following sequence each time power is turned on.

1) LEDs CR7 to CR10 blink twice every 2 seconds.

2) ROM and RAM are tested.

3) LED CR normal operation. If an error is detected during the test, the corresponding LED is turned on.

•

6 blinks every second for

When CR7 is on, ROM is defective.

When CR8 is on, RAM is defective.

9-6

GPS ANTENNA GPA-017S GPA-018S GPA-019S

GP-150 GP-150

INTERFACE UNIT

TNC-J-3 TNC-P-3

8D-FB-CV *30m*

N-J-3

N-P-8DFB

TNC-PS-3D-15 *15m*

N-J-3

N-P-8DFB

8D-FB-CV *50m*

N-J-3

N-P-8DFB

N-J-3

N-P-8DFB

8D-FB-CV *30m*

N-J-3

N-P-8DFB

TNCP-NJ

8D-FB-CV *50m*

N-J-3

N-P-8DFB

TNCP-NJ

TNC-J-3 TNC-P-3

8D-FB-CV *30m*

N-J-3

N-P-8DFB

TNC-PS-3D-15 *15m*

N-J-3

N-P-8DFB

8D-FB-CV *50m*

N-P-8DFB

N-J-3

N-P-8DFB

8D-FB-CV *30m*

N-J-3

N-P-8DFB

TNCP-NJ

8D-FB-CV *50m*

N-J-3

N-P-8DFB

TNCP-NJ

N-J-3

NJ-TP-3DXV-1

12-24 VDC

10. INSTALLATION

10.1 General

The figure below shows the system configuration of the GP-150-DUAL. For MD-GB2 connection, see the interconnection diagram attached at back of this manual.

1) #: MJ-A2SPF004-030 *3m*

2) Cable type is CO-SPEVV-SB-C 2P or equivalent, unless noted otherwise.

3) *1: Interface Unit IF-1422 is required if cable length is more than 30 m.

Figure 10-1 System Configuration

10-1

10. INSTALLATION

10.2 Display Unit

The display unit can be installed using either of four methods as shown below. Refer to the outline drawing page D-1, D-2, and D-3.

• Locate the unit away from exhaust pipes and vents.

• The mounting location should be well ventilated.

• Mount the unit where shock and vibration are minimal.

• Keep the display unit away from electromagnetic field generating equipment

such as motor, generator.

• Allow sufficient maintenance space and a sufficient slack in cables for maintenance and repair.

Table Top and Overhead Mounting

TABLE TOP OVERHEAD

Figure 10-2 Display unit mounting methods

Flush mounting type F

An optional flush mount kit type F is required. For details, see outline drawing page D-3. (Name: Flush Mount Kit F, Type: OP20-25, Code No.: 004-393-280)

Name Type Code No. Qty

Self-tapping screw 5X20 000-802-840 4

Hex. bolt M6X12 SUS304 000-862-127 2

Spring washer M6 SUS304 000-864-260 2

Cosmetic panel 20-013-1121 100-234-240 1

10-2

Flush mounting type S

An optional flush mount kit type S is required. (Name: Flush Mount Kit S, Type: OP20-24, Code No.: 004-393-000)

Name Type Code No. Qty

Wing bolt M4X30 YBSC2 000-804-799 4

Hex. bolt M6X12 SUS304 000-862-127 2

Wing nut M4 YBCS2 000-863-306 4

Spring washer M6 SUS304 000-864-260 2

Flush mount metal 20-013-1111 100-234-230 2

1. Prepare a cutout in the mounting location whose dimensions are 242 (W) X 152 (H) mm.

2. Insert the unit to the cutout.

3. Attach two flush mount metals to the unit with two hex bolts (M6X12) and two spring washers.

4. Screw four wing bolts to wing nut.

5. Fasten the unit with four wing bolts assembled at step 4, and then tighten nuts.

10-3

10. INSTALLATION

10.3 Antenna Unit

Mounting

Install the antenna unit referring to the installation diagram on page D-4. When selecting a mounting location for the antenna unit, keep in mind the following points.

• Select a location out of the radar beam. The radar beam will obstruct or prevent reception of the GPS satellite signal.

• Be sure the location offers a clean line-of-sight to satellite. Objects within line-of-sight to a satellite, for example, a mast or funnel, block reception and cause prolonged acquiring time or interruption of position fix.

• Mount the unit as high as possible. Mounting the antenna as high as possible keeps it free of water spray, which can interrupt or prevent reception of GPS satellite signal, if water spray is frozen.

• The antenna unit GPA-018S must be grounded. Connect ground wire of

1.25 sq or larger (local supply) between the antenna unit and a stainless steel screw fastened to the mast.

• The antenna unit GPA-018S must be taped. See next page.

• The antenna unit should be fixed to the mast as below.

Coat here with silicone sealant to prevent breakage of the cable by vibration.

Wrap the vinyl sheet to prevent the breakage of the cable, and then fix it with a hose clamp.

10-4

Taping antenna unit GPA-018S

After inserting the whip antenna to the antenna base of GPA-018S, tape the antenna base and whip antenna with self-vulcanizing tape and vinyl tape to reinforce the whip antenna.

1. Wrap the antenna junction point with butyl rubber tape No. 15 (NITTO SINKO COOP.) or the equivalent.

How to wrap

1) Pull the tape to be about two times in length and wind it up, overlapping by

1/2 the width of the tape.

2) Wrap from bottom to top, i.e., from right to left as in the picture below.

10. INSTALLATION

Whip antenna

Butyl rubber tape

Base

Antenna

3) Wrap the tape from the base to a point about 60 mm, and then back to the

base.

Keep tension on edge of tape, using finger to hold tape. Then, squeeze

edges of tape with thumb and index finger.

Wrap approx. 60 mm

2. Completely cover the butyl rubber tape with white vinyl tape, wrapping from the base to the last wind of butyl rubber tape and then back to the base.

How to wrap

1) Being careful not to pull the tape too tightly, wind tape, overlaping by

approx. 1/3 of tape width.

2) Squeeze edges of tape with thumb and index finger.

White vinyl tape

10-5

10. INSTALLATION

Extending antenna cable length

The standard cable is 15m long. 30m and 50m long extension cable sets are optionally available.

Extension cable line-up

Fabricate the end of antenna cable and attach the coaxial connector. Details are shown on the next page.

GPA-019S

20cm

Antenna Unit

GPA-018S GPA-017S

Conversion Cable Assy.

Antenna Cable

1 m

For CP20-01700, CP20-01710

TNCP-NJ

For CP20-02700, CP20-02710

30 m or 50 m 1 m

Antenna Cable

30 m or 50 m

Cable length

30 m

50 m

Fabricate locally. (See the next page.)

Conversion Cable Assy.

Fabricate locally. (See the next page.)

Necessary parts

1 m

CP20-01700 CP20-02700 CP20-01710 CP20-02710

: Connector

Code no.

004-372-110 004-381-160 004-372-120 004-381-170

To display unit

Extension Cable Line-up



Waterproofing the connector Wrap connector with vulcanizing tape and then vinyl tape. Bind the tape end with cable-tie.

How to waterproof the connector of the antenna cable

10-6

How to attach the N-P-8DFB connector

Outer Sheath

Armor

Inner Sheath Shield

10. INSTALLATION

Remove outer sheath and armor by the dimensions shown left. Expose inner sheath and shield by the dimensions shown left.

Cover with heat-shrink tubing and heat.

Clamp Nut

Gasket (reddish brown)

Trim shield here.

Insulator

Clamp

Aluminum Foil

Cut off insulator and core by 10mm.

Twist shield end.

Slip on clamp nut, gasket and clamp as shown left.

Fold back shield over clamp and trim.

Cut aluminum foil at four places, 90° from one another.

Fold back aluminum foil onto shield and trim.

Trim aluminum tape foil here.

Clamp Nut

Solder through the hole.

Shell

Expose the insulator by 1mm.

Expose the core by 5mm.

Slip the pin onto the conductor. Solder them together through the hole on the pin.

Insert the shell into the pin. Screw the clamp nut into the shell. (Tighten by turning the clamp nut. Do not tighten by turning the shell.)

10-7

10. INSTALLATION

10.4 Wiring

The figure below shows the connection of cables on rear of display unit.

Antenna Unit

CAUTION

Ground the receiver to prevent loss of sensitivity and mutual interference.

GPA-019S

20cm

GPA-018S GPA-017S

IF-2500

GP-150-DUAL

Rear of Display Unit

DATA 1

ANT

DATA 2

DATA 3

DATA 4

–

Black Red

Ground terminal

Flat washer

Crimp-on lug

Spring washer

INPUT 12-24 VDC

Flat washer

Wing bolt

Ground

Grounding

The display unit contains several CPUs. While they are operating, they radiate noise, which can interfere with other radio equipment. Ground the unit as follows to prevent it.

• The grounding wire should be 1.25sq or larger.

• The grounding wire should be as short as possible.

10-8

FUSE 2A

Connection of cables on display unit

10.5 Initial Settings

The GP-150-DUAL can output navigation information to external equipment through the Interface Unit IF-2500. For example, it can output position data to a radar or echo sounder for display on their screen.

Before selecting data to output, confirm what data the external equipment requires. Output necessary data only. Outputting unnecessary data can cause receiving problems at the external equipment.

Talker

All data transmitted by marine electronics equipment is prefixed with a two-character code which tells external equipment what equipment is transmitting data. This two-character code is called the “talker.” The GP-150-DUAL contains the talkers GP, LC and DE.

Data format and data output availability

10. INSTALLATION

The type of data which can be transmitted depends on format. Output data sentence of IEC 61162-1 and NMEA 0183 Ver. 1.5/Ver. 2.0.

AAM: Waypoint arrival alarm APB: Autopilot sentence B

magnitude of cross track error, direction to steer, arrival alarm, bearing to waypoint

("Heading to steer to destination waypoint data" not used) BOD: Bearing-origin to destination BWC: Bearing and distance to waypoint-great circle BWR: Bearing and distance to waypoint-rhumb line BWW: Bearing-waypoint to waypoint DTM: Datum reference GGA: Global positioning system (GPS) fix data

time of fix, latitude, longitude, quality indicator, number of satellites

in use, DOP, altitude, geoidal separation ("age of dgps data" and "differential reference station ID" not used) GLL: Geographic position-latitude/longitude

10-9

10. INSTALLATION

GNS: GNSS fix data GPS: GPS satellite fault detection RMB: Recommended minimum navigation information. Cross-track error,

RMC: Recommended minimum specific GPS/TRANSIT data. UTC of

RTE: Routes VTG: Course over ground and ground speed WCV: Waypoint closure velocity WNC: Distance-waypoint to waypoint-great circle WPL: Waypoint location XTE: Cross-track error, measured ZDA: Time and data

Also, the following NMEA 0183 Ver. 1.5 sentences are output

APA: Autopilot sentence "A". Magnitude of cross-track error, direction to

WNR: Distance-waypoint to waypoint-rhumb line

Note: BWC, BWR, GGA, GLL, RMB, RMC or WPL is required to output DTM.

Input data sentence of NMEA 0183 Ver. 1.5/2.0 Checksum is checked if attached, and if any error is found, the sentence becomes invalid. Talker ID is not distinguished. DBT: Depth below transducer

DPT: Depth

MTW: Water temperature

direction to steer, origin and destination waypoint latitude and longitude, range and bearing of destination waypoint, destination closing velocity, arrival alarm.

position fix, latitude and longitude, ground speed and course, data, magnetic variation

steer, arrival alarm, bearing origin to destination.

$--DBT, 1234.5 f, 1234.5, M, 1234.5 F*12<CR><LF> a b c d e f g a, b: Water depth, feet c, d: Water depth, m e, f: Water depth, fathoms g: Checksum

$--DPT, 1234.5 1234.5, 1234.5*23<CR><LF>, a b c a: Water depth relative to the transducer, meters b: Offset from transducer, meters

… not used

c: Checksum

$--MTW, 23.4, C*34<CR><LF> a b c a: Temperature: degrees, C c: Checksum

10-10

TLL: Target latitude and longitude

$--TLL, 00, 3445.678, N, 13521.234, E, abcd, 121530, T a b c d d f g h R*A5<CR><LF> a: Target number

… not used

b, c: Latitude d, e: Longitude f: Target name g: UTC

… not used

h: Target status i: Reference target

… not used

j: Checksum

FURUNO proprietary sentences

AGFPA: Autopilot information from FURUNO autopilot

10. INSTALLATION

Port Input Output

DATA1 NMEA 0183

Ver. 1.5/2.0

AGFPA, DBT, DPT, MTW, TTL

IEC 61162-1/NMEA 0183 Ver.

1.5/2.0

AAM, APA, APB, BOD, BWC, BWR, BWW, GGA, GLL, GNS, RMB, RMC, VTG, WCV< WNC, WNR, WPL, XTE, ZDA, GBS, Rnn, RTE

LOG PULSE DATA3 External MOB

Same as for DATA1.

General data DATA4 DGPS or general data (selected through menu)

IEC 61162-1/NMEA 0183 Ver.

1.5/2.0

AAM, APA, APB, BOD, BWC,

BWR, BWW, GGA, GLL, GNS,

RMB, RMC, VTG, WCV< WNC,

WNR, WPL, XTE, ZDA, GBS,

Rnn, RTE

Note: BWC, BWR, GGA, GLL, RMB, RMC or WPL is required to output DTM.

10-11

10. INSTALLATION

General data

1) Input of lighthouse/buoy information: Floppy disk stored lighthouse/buoy information is supplied from PC connected to DATA4 port.

2) Input of waypoint data: Connect YEOMAN to DATA4 port

3) Input and output of waypoint/route data

TX Rate of operation

The TX rate or operation is the percentage of data output in one second, and it appears on the screen. If short intervals are assigned to many sentences, the rate of operation increases as illustrated below.

TX TX TX

TX rate of operation: Low

TX rate of operation: High

Note 1: When outputting data without rest intervals between data, TX rate of

operation is 100%. In this case, wrong data may be shown on the receiver because it cannot recognize intervals between data. Thus, do not output unnecessary data or set TX interval to large value so that TX rate of operation becomes small.

Note 2: When the external equipment cannot display correct data input from the

GP-150, the rate of operation should be lowered. For example, set a rate of operation less than 60 % for the Temperature Indicator TI-20.

10-12

DATA1 output setting

1) Press MENU ESC, 9 and 3 keys to show the DATA1, 3 OUTPUT SETUP menu.

10. INSTALLATION

DATA 1, 3 OUTPUT SETUP

Data Fmt. V1.5 IEC

Talker ID GP LC DE

Output Data (00-90 sec) 82%

1. AAM:00 APA:00 APB:04 BOD:00

2. BWC:00 BWW:00 GGA:01 GLL:01

3. RMB:01 RMC:00 VTG:01 WCV:00

4. VDR:00 WPL:00 XTE:00 ZDA:01

5. GNS:00 GBS:01 Rnn:00 RTE:00

DATA3. Log Pulse

ENT : Enter

This line appears only when LOG is selected by internal jumper blocks.

Settings shown above are default settings.

V2.0

200ppm

MENU : Escape

400ppm

TX rate of operation

DATA1, 3 OUTPUT SETUP menu

2) Press

3) Press

to select DATA FMT.

or to select V1.5, V2.0 or IEC.

4) Press the CU/NU ENT key. Talker ID appears in reverse video.

5) Press

or to select GP, LC or DE.

6) Press the CU/NU ENT key.

7) Enter TX interval for each output data sentence in line 1. TX interval is available in 00, 01, 02, 03, 04, 05, 06, 10. 15, 20. 30, 60 and 90 msec.

8) Press the MENU ENT key.

9) Enter TX interval for each output data sentence in lines 2 through 5. Press the CU/NUENT key after setting each line.

In great circle calculation, BWC and WNC are output but BWR and WNR are not. In rhumb line navigation, BWR and WNR are output but BWC and WNC are not. The total data output are shown by percentage on the third line.

For best results the total output should be less than 90%; lengthen the Tx interval of less important data to make the total output less than 90%.

10-13

10. INSTALLATION

DATA 3 output setting

The DATA 3 can output NMEA 0183 (V1.5/V2.0) /IEC 61162-1 data or log pulse depending on jumper block setting on the NAV board. For NMEA 0183 (V1.5/V2.0) /IEC 61162-1, the same signal of DATA 1 is output from DATA 3.

Selection of NMEA0183 or log pulse

Output data

NP board

JP3 #1-2 #2-3

JP4 #1-2 #2-3

JP10 #1-2 #2-3

Rate of log pulse output

150 mA Max. 50 VDC

Procedure for setting of log pulse rate

1) Press ESC MENU, 9 and 3.

2) Press

3) Press 400ppm.

4) Press the CU/NU ENT key.

5) Press the MENU ESC key.

to select DATA 3. Log Pulse.

or to select log pulse for external equipment; 200ppm or

NMEA 0183 (V1.5/ V2.0)/IEC 61162-1

(Default Setting)

Log pulse

10-14

Setting DATA 4 to Data Output

1) Press MENU ESC, 9 and 5 to show the DATA4 I/O SETUP menu.

DATA 4 I/O SETUP 1/2

DATA 4. Level RS232C RS422

To Next Page

ENT : Enter MENU : Escape

Appears only when external DGPS receiver is used.

10. INSTALLATION

Data Out Com. DGPS

: Select

DATA4 I/O SETUP menu

2) Press

3) Press

to select DATA 4. Level.

or to select level of external equipment; RS-23C or RS422.

4) Press the CU/NU ENT key.

5) Press

6) Press

or to select Out.

to go to the next page to show the DATA I/O SETUP <Out> menu.

DATA 4 I/O SETUP <Out> 2/2

To Previous Page

Data Fmt. V1.5 V2.0 IEC

Talker ID GP LC DE

Output Data (00-90 sec) 98%

1. AAM:00 APA:00 APB:04 BOD:00

2. BWR:00 BWW:00 GGA:00 GLL:01

3. RMB:01 RMC:00 VTG:01 WCV:00

4. WNR:00 WPL:00 XTE:00 ZDA:01

5. GNS:00 GBS:01 Rnn:00 RTE:00

ENT : Enter

MENU : Escape

DATA4 I/O SETUP <Out> menu

7) Follow "DATA 1 output setting" from step 2.

10-15

10. INSTALLATION

Setting DATA 4 to "COM." (general data)

Waypoint data can be received from a personal computer, through the DATA 4 port. Note that the data transmitting operation should be done after receiving data using DATA 4 port. For details, see page 1-6.

1) Press MENU ESC, 9 and 5.

2) Press

3) Press

4) Press the CU/NU ENT key.

5) Press

6) Press appears.

7) Press

8) Press

9) Press the CU/NU ENT key.

10) Press

11) Press in reverse video.

12) Press

to select Level.

or to select level of personal computer; RS232C or RS422.

or to select Com.

to select To Next Page. The DATA 4 I/O SETUP <Com.> menu

Loading erases current data Are you sure to load?

ENT: Yes MENU: No

I/O SETUP <Com.> menu

to select Baud Rate.

or to select baud rate; 4800bps, 9600bps, or 19200bps.

to select WPT/RTE. to select Command. Stop, on the same line as Command, appears

to select Start. The message shown in below appears.

Now loading WPT/RTE data !

MENU: Stop

13) Press the CU/NU ENT key. The message shown in below appears while data is being loaded.

Are you sure to stop ?

ENT: Yes MENU: No

14) Output data from the computer. When data is loaded, the cursor shifts to Stop.

15) Press the ESC key.

10-16

Setting DATA 4 to DGPS

An external DGPS receiver can be connected to the DATA 4 port. Follow the procedure below to setup the GP-150-DUAL according to the specifications of the DGPS receiver.

1) Press MENU ESC, 9 and 5.

2) Press

3) Press

4) Press the CU/NU ENT key.

5) Press

6) Press

to select Level.

or to select level; RS232C or RS422.

to select DGPS.

to select To Next Page.

DATA 4 I/O SETUP <DGPS> 2/2

To Previous Page

First Bit

Parity Stop Bit Baud Rate

MSB LSB EVEN ODD NONE 12 4800 9600

10. INSTALLATION

: Select

ENT: Enter MENU: Escape

I/O SETUP <DGPS> 2/2 menu

7) Press S or T to select First Bit.

8) Press W or X to select first bit; MSB or LSB.

9) Press

10) Press

11) Press

12) Press

13) Press

14) Press

to select Parity.

to select parity bit; EVEN, ODD or NONE.

to select Stop Bit.

to select stop bit; 1 or 2.

to select Baud Rate.

or to select baud rate; 4800 or 9600.

15) Press the CU/NU ENT key.

16) Press the MENU ESC key.

10-17

10. INSTALLATION

10.6 Interface Unit IF-2500

Specifications

Input port 2 ports for NMEA 0183 data Output port 6 ports for either of NMEA 0183 or RS-422 data 3 ports for alarm signal Power supply 10 to 35 VDC Power consumption 2.2 W maximum Color 2.5G5/1.5 Newtone no. 5 Ambient temperature -15°C to +55°C Humidity Relative humidity 95% at +40°C Waterproofing None

Installation

Mounting considersations

The installation site is important for proper operation and continued performance. Select it keeping the following points in mind. The unit is not waterproof; locate it away from water spray. Select a clean and cool place. Select a place where shock,vibration and electrical noise are minimal. Leave sufficient space at the sides and rear of the unit for maintenance and service.

Mounting

The unit can be mounted on a bulkhead, overhead or tabletop. Secure the unit to mounting location with woodscrews. For added support, use nuts, bolts and washers instead of woodscrews.

• All dimensions in millimeters.

• For added support, use nuts, bolts and washers instead of woodscrews.

• Leave sufficient space at the sides and rear of the unit for maintenance and servicing.

10-18

Interface unit mounting

Cable fabrication

1) Remove the outer sheath, armor, and shield as illustrated.

2) Remove the insulation of cores 3 mm.

3) Cut and solder unused cores to the shield.

10. INSTALLATION

4) Solder a ground wire to the shield.

5) Dress the shield and the outer sheath with heat shrink tube, leaving 30 mm of shield and outer sheath exposed.

6) Heat the heat shrink tube.

7) Remove the insulation of NH connector (supplied) 3 mm.

8) Heat the heat shrink tube.

How to fabricate the signal cable

10-19

10. INSTALLATION

Grounding

To prevent electrical shock and mutual interference, run a ground wire between the earth terminal on the unit and ship’s superstructure.

Cabling schedules

The signal cable should be a twisted-pair, double-screened cable. Ground the signal cable at the cable clamp.

Connections

Power supply

J1 (24 VDC)

Pin no. Designation

#1 +

#2 -

Input signal (NMEA)

The signal from GPS navigator is connected to J2 and J3. Data being fed to J2 has higher priority than J3.

Pin no. Designation Pin no. Designation

#3 RD1-H #3 RD2-H

#4 RD1-C #4 RD2-C

#6 GND #6 GND

Output signal (RS-422 or NMEA)

J4, J5, J6, J7, J8, J9

Pin no. RS-422 NMEA

J2 J3

10-20

#1 TD-B TD-H

#2 TD-A TD-C

#4* GND GND

*#5 for J9

10. INSTALLATION

Output signal (contact closure signal)

J10 (Arrival alarm) J11 J12

Pin no. Designation Pin no. Designation Pin no. Designation

#1 Alarm out 1 (H) #1 Alarm out 2 (H) #1 Alarm out 3 (H) #2 Alarm out 1 (C) #2 Alarm out 2 (C) #2 Alarm out 3 (C)

Selection of output data format

The output data format is selectable by changing a jumper block; A for RS-422 and B for NMEA. For example, to select NMEA for J4, change the jumper block from A to B on J401 and J402. Do the same on J5 thru J9.

No. Jumper Pin no. Jumper No. Jumper

J4 J401/J402 (A) J5 J501/J502 (A) J6 J601/J602 (A) J7 J701/J702 (A) J8 J801/J802 (A) J9 J901/J902 (B)

Default jumper setting is shown in parenthesis.

Self test 2

The test requires an external loop to check I/O. Follow the steps below to carry out the test.

1) Set the #4 segment of DIP switch S1 to the ON position.

2) Temporarily disconnect input and output connectors J2 and J4.

3) Solder a jumper block between J2 and J4; #3 and #4 of J2 are connected to #1 and #2 of J4, respectively.

Jumper block consists of XH-6 pin and 4 pin connectors with two short wires as below.

XH, 6 pin #3 - - - #1 #4 - - - #2

4) Change the jumper block between J2 and J5; J2/J6, J2/J7, J2/J8, J2/J9, J3/J4, J3/J5, J3/J6, J2/J7, J2/J8, J2/J9.

XH, 4 pin

10-21

10. INSTALLATION

LED status

The LEDs light according to equipment status as follows: CR2: Lights when receiving NMEA data from J2. CR3: Lights when sending NMEA data from J3. CR4: Lights when sending NMEA data from J4 to J9. CR6: Blinks every second. CR7: Lights when ROM error is detected, or no signal at J2 for 300 ms. CR8: Lights when RAM error is detected, or no signal at J3 for 300 ms. CR9: Lights when SIO error is detected, or NMEA data is input at J2. CR10: Lights when NMEA data is input at J2.

From left #2, #3, #4, #6 thru #10

Location of LEDs

10.7 GPS/BEACON Antenna Distributor MD-GB2

Specification

Transmission frequency GPS : 1575.42MHz

Beacon : 283.5〜325.0kHz

Loss GPS : 4dB

Beacon : 3dB Power supply to antenna One line fed from two distribution lines Connector type TNC

Ambient temperature -15 to +55℃ Humidity 95％ or less

Waterproofing None

Note: Furuno GPS Receivers are designed, considering 10dB antenna cable

loss. Because this distributor loses 4dB, shorten antenna cables so that loss is 6dB or less. Refer to the following formula for calculation of loss.

8D-FB cable: 0.165dB/m 3D-2V cable: 0.65 dB/m

For the mounting, see the outline drawing at the back of this manual.

10-22

APPENDIX

Menu Tree

Main menu

MENU ESC

1. DISPLAY SETUP

2. TRACK/MARK SETUP

3. ERASE TRACK/MARK

4. ALARM SETTINGS

Arrival/Anchor (Arr., Anc., Off)

XTE (On, Off)

Ship Speed (In, Over, Off)

Trip (CLR:Reset) (On, Off)

Water Temp. (In, Over, Off)

Depth (In, Over, Off)

WAAS/DGPS (On, Off)

Grid (Dark, Light, Off) Course Bar (Dark, Light, Off) Time Mark (Dark, Light, Off) Waypoint Size (Large, Small) Cursor Size (Large, Small)

Track Rec (Time, Dist) Mark Shape (

Mark Line ( Event Mark (

Erase Track (No, Yes) Erase Mark (No, Yes)

Alarm Range (0.500 nm)

Alarm Range (0.250 nm)

Speed Range (011.0 - 015.0 kt)

Trip Range (0100.00 nm)

Temp. Range (+11.0 - +15.0 °C)

Depth Range (0011.0 - 0015.0 ft)

,,,

) )

)

5. MANUAL CALCULATION

7. GPS MONITOR

8. SELF TESTS

From To Trial Speed (Auto, Man)

(010.0 kt)

SATELLITES MONITOR BEACON RCVR MONITOR STATION MESSAGE

1. Memory, I/O Port Test

2. Keyboard Test

3. Test Pattern

4. Automatic T esting

P-1

APPENDEX

9. SYSTEM SETTINGS

1. PLOTTER SETUP

2. UNIT SETUP

3. DATA1, 3 OUTPUT SETUP

Memory Apportion (Trk: 1000/2000 Pt) Bearing Ref. (True, Mag) Mag Variation (Auto, Man)

Calculation (RL, GC) User defined #1 W RNG X

Unit of Distance (nm, km, sm)

Unit of Depth (m, ft, FA) Unit of Temp. (°C, °F) Unit of Altitude (m, ft)

(07°W) (00°E)

SOG, COG, RNG, BRG, #2 W SOG X #3 W BRG X #4 W COG X

Data Fmt. (V1.5, V2.0, IEC) Talker ID (GP, LC, DE) Output Data

AAM: 00, APA: 00, APB: 01, BOD: 00, BWR: 00, BWW: 00, GGA: 01, GLL: 00, RMB: 01, RMC: 01, VTG: 01, WCV:00, WNR: 00, WPL: 00, XTE: 00, ZDA: 01, GNS: 00, GBS: 00, Rnn: 00, RTE: 00

W. TMP, W. DPT, XTE, dCOG,

AVR SOG, AVR COG, TTG, ETA,

TRIP, TRIP TM, RT. DIST, RT. TTG,

RT. ETA, ALT, VTD

4. DATA TRANSFER

5. DATA4 I/O SETUP

ALL (Stop, Start)

Data4. Level (RS232C, RS422) Data (Out, Com., DGPS) Data Fmt. (V1.5, V2.0, IEC) Talker ID (GP, LC, DE)

Output Data

AAM: 00, APA: 00, APB: 04, BOD: 00, BWR: 00, BWW: 00, GGA: 00, GLL: 01, RMB: 01, RMC: 00, VTG: 01, WCV:00, WNR: 00, WPL: 00, XTE: 00, ZDA: 01, GNS: 00, GBS: 01, Rnn: 00, RTE: 00

AP-2

6. GPS SETUP

7. WAAS/DGPS SETUP

Fix Mode (2D, 2/3D)

ANT Height (016 ft, 000 - 999 ft) Disable Satellite (1 - 32)

GPS Smoothing

Speed Average (0060, 0000 - 9999 sec) RAIM Function (Off, On)

RAIM Accuracy (100, 1 - 999)

Geodetic Datum (WGS84, NAD27, OTHER)

Posn Offset (0.000’N, 0.000’W)

Time Diff. (+00:00)

Posn (38°00.000’N, 123°00.000’W)

Posn (0000, 0000 - 9999 sec) Spd (0005, 0000 - 9999 sec)

(001)

MODE (GPS, WAAS, INT BEACON*, EXT BEACON*, AUTO)

WAAS SEARCH (Auto, Man)

CORRECTIONS DATA SET (00)

DGPS Station (Auto, Man (ID: 0274))

Freq. (323.0 kHz)

Baud Rate (25, 50, 100, 150, 200 bps)

8. LOP SETUP

9. CLEAR MEMORY

Pos Display (Lat/Long, LOP)

LOP Display (LC, DE)

LC Chain (7980: 23 - 43)

ULOP (+00.0 µs +00.0 µs)

DE Chain (24: G - P)

ULOP (+0.00 Lane, +0.00 Lane)

Clear Plotter (No, Yes) Clear GPS (No, Yes) Clear All (No, Yes)

*: One is displayed according to kind of beacon receiver used.

P-3

APPENDEX

World Time Standards

AP-4

Geodetic Chart List

001: WGS84 002: WGS72 003: TOKYO : 004: NORTH AMERICAN 1927 : Mean Value (CONUS) 005: EUROPEAN 1950 : Mean Value 006: AUSTRALIAN GEODETIC 1984 : Australia & Tasmania 007: ADINDAN : 008: : Ethiopia 009: : Mali 010: : Senegal 011 : Sudan 012: AFG : Somalia 013: AIN EL ABD 1970 : Bahrain Is. 014: ANNA 1 ASTRO 1965 : Cocos Is. 015: ARC 1950 : Mean Value 016: : Botswana 017: : Lesotho 018: : Malawi 019: : Swaziland 020: : Zaire 021: : Zambia 022: : Zimbabwe 023: ARC 1960 : 024: : Kenya 025: : Tanzania 026: ASCENSION IS. 1958 : Ascension Is. 027: ASTRO BEACON “E” : Iwo Jima Is. 028: ASTRO B4 SOR. ATOLL : Tern Is. 029: ASTRO POS 71/4 : St. Helena Is. 030: ASTRONOMIC STATION 1952 : Marcus Is. 031: AUSTRALIAN GEODETIC 1966 : Australia & Tasmania 032: BELLEVUE (IGN) : Efate & Erromango Islands 033: BERMUDA 1957 : Bermuda Islands 034: BOGOTA OBSERVATORY : Columbia 035: GAUPO INCHAUSPE : Argentina 036: CANTON IS. 1966 : Phoenix Islands 037: CAPE : South Africa 038: CAPE CANAVERAL : 039: CARTHAGE : Tunisia 040: CHATHAM 1971 : Chatham Is. (New Zealand) 041: CHUA ASTRO : Paraguay 042: CORREGO ALEGRE : Brazil 043: DJAKARTA (BATAVIA) : Sumatra Is. (Indonesia) 044: DOS 1968 : Gizo Is. (New Georgia Is.) 045: EASTER IS. 1967 : Easter Is. 046: EUROPEAN 1950 (Cont’d) : Western Europe 047: : Cyprus 048: : Egypt 049: : 050: : 051: : Greece 052 : Iran 053: : Italy, Sardinia 054: : Italy, Sicily 055: : Norway & Finland 056: : Portugal & Spain 057: EUROPEAN 1979 : Mean Value 058: GANDAJIKA BASE : Republic of Maldives 059: GEODETIC DATUM 1949 : New Zealand 060: GUAM 1963 : Guam Is. 061: GUX 1 ASTRO : Guadalcanal Is. 062: HJORSEY 1955 : Iceland 063: HONG KONG 1363 : Hong Kong 064: INDIAN : Thailand & Vietnam 065: : Bangladesh, India & Nepal 066: IRELAND 1965 : Ireland 067: ISTS 073 ASTRO 1969 : Diego Garcia 068: JOHNSTON IS. 1961 : Johnston Is. 069: KANDAWALA : Sri Lanka 070: KERGUELEN IS. : Kerguelen Is. 071: KERTAU 1948 : West Malaysia & Singapore 072: LA REUNION : Mascarene Is. 073: L. C. 5 ASTRO : Cayman Brac Is. 074: LIBERIA 1964 : Liberia 075: LUZON : 076: : Mindanao Is. 077: MAHE 1971 : Mahe Is. 078: MARCO ASTRO : Salvage Islands 079: MASSAWA : Eritrea (Ethiopia) 080: MERCHICH : Morocco 081: MIDWAY ASTRO 1961 : Midway Is. 082: MINNA : Nigeria 083: NAHRWAN : Masirah Is. (0man) 084: : United Arab Emirates 085: : Saudi Arabia 086: NAMIBIA : Namibia 087: MAPARIMA, BWI : Trinidad & Tobago 088: NORTH AMERICAN 1927 : Western United States 089: : Eastern United States 090: : Alaska 091: : 092: : Bahamas, San Salvador Is. 093: : 094: : Alberta & British Columbia

Mean Value (Japan, Korea & Okinawa)

Mean Value (Ethiopia & Sudan)

Mean Value (Kenya & Tanzania)

Mean Value (Florida & Bahama Islands)

England, Scotland, Channel & Shetland Islands England, Ireland, Scotland, & Shetland Islands

Philippines (excl. Mindanao Is.)

Bahamas (excl. San Salvador Is.)

Canada (incl. Newfoundland Is.)

095: : East Canada 096: : Manitoba & Ontario 097: : 098: : Yukon 099: : Canal Zone 100: : Caribbean 101: : Central America 102: : Cuba 103: : Greenland 104: : Mexico 105: NORTH AMERICAN 1983 : Alaska 106: : Canada 107: : CONUS 108: : Mexico, Central America 109: OBSERVATORIO 1966 : 110: OLD EGYPTIAN 1930 : Egypt 111: OLD HAWAIIAN : Mean Value 112: : Hawaii 113: : Kauai 114: : Maui 115: : Oahu 116: OMAN : Oman 117: ORDNANCE SURVEY OF GREAT BRITAIN 1936: Mean Value 118: : England 119: : England, Isle of Man & Wales 120: : Scotland, & Shetland Islands 121: : Wales 122: PICO DE LAS NIVIES : Canary Islands 123: PITCAIRN ASTRO 1967 : Pitcairn Is. 124: PROVISIONAL SOUTH CHILEAN 1963: South Chile (near 53°S) 125: PROVISIONAL SOUTH AMERICAN 1956: Mean Value 126: : Bolivia 127: : 128: : 129: : Columbia 130: : Ecuador 131: : Guyana 132: : Peru 133: : Venezuela 134: PUERTO RICO : Puerto Rico & Virgin Islands 135: QATAR NATIONAL : Qatar 136: QORNOQ : South Greenland 137: ROME 1940 : Sardinia Islands 138: SANTA BRAZ : 139: SANTO (DOS) : Espirito Santo Is. 140: SAPPER HILL 1943 : East Falkland Is. 141: SOUTH AMERICAN 1969 : Mean Value 142: : Argentina 143: : Bolivia 144: : Brazil 145: : Chile 146: : Columbia 147: : Ecuador 148: : Guyana 149: : Paraguay 150: : Peru 151: : Trinidad & Tobago 152: : Venezuela 153: SOUTH ASIA : Singapore 154: SOUTHEAST BASE : 155: SOUTHWEST BASE : 156: TIMBALAI 1948 : 157: TOKYO : Japan 158: : Korea 159: : Okinawa 160: TRISTAN ASTRO 1968 : Tristan da Cunha 161: VITI LEVU 1916 : Viti Levu Is. (Fiji Islands) 162: WAKE-ENIWETOK 1960 : Marshall Islands 163: ZANDERIJ : Surinam 164: BUKIT RIMPAH : 165: CAMP AREA ASTRO : 166: G. SEGARA : Kalimantan Is. (Indonesia) 167: HERAT NORTH : Afghanistan 168: HU-TZU-SHAN : Taiwan 169:

TANANARIVE OBSERVATORY 1925 : Madagascar 170: YACARE : Uruguay 171: RT-90 : Sweden 172: Pulkovo 1942 : Russia 173: Finish KKJ : Finland

Northwest Territories & Saskatchewan

Corvo & Flores Islands (Azores)

Chile-Northern Chile (near 19°S) Chile-Southern Chile (near 43°S)

Sao Maguel, Santa Maria Islands (Azores)

Porto Santo & Madeira Islands Faial, Graciosa, Pico, Sao Jorge, & Terceira Is. Brunei & East Malaysia (Sarawak & Sadah)

Bangka & Belitung Islands (Indonesia) Camp Mcmurdo Area, Antarctica

P-5

APPENDEX

Loran C Chains

niahCIRG1S2S3S4S5S

cificaPlartneC09941192------

tsaoCtsaEnaidanaC0395115283----

)aeroK(noiLodnammoC0795111324----

tsaoCtseWnaidanaC099511721

aibarAiduaShtuoS071711629325--

aeSrodarbaL03971162------

aissuRnretsaE059711036416--

aksalAfofluG0697116244----

aeSnaigewroN079711626406--

ASUt

saehtuoS089711323495--

aeSnaenarretideM0997119274----

aissuRnretseW000811520556--

ASUlartneChtroN0928117224----

aibarAiduaShtroN0998115204659

sekaLtaerG079811824495--

ASUlartneChtuoS01691152042556

ASUtsaoCtseW0499117204----

ASUtsaehtroN069911529345--

)dlo(cificaPtsewhtroN079

911035518--

4----

cidnalecI08991103------

cificaPhtroN0999119234----

zeuS19940142

ecnarF,dnalgnE04982103

cificaPtsewhtroN039811030507

dnuofweN07271152

yasseL13760193

ØB10071172

tlyS99471162

edjE7009013283

tsaoCtsaEdnal

htroNaibarAaiduaS038811529365

htuoSaibarAaiduaS030711527355

AP-6

Decca Chains

APPENDEX

Chain No.

Chain Chain

code

01 South Baltic 0A Europe 34 Kanto 8C Japan

02 Vestlandet 0E " 35 Shikoku 4C "

03 Southwest British 1B " 36 Hokuriku 2C "

04 Northumbrian 2A " 37 Kita Kyushu 7C "

05 Holland 2E " 38 Namaqualand 4A Southern Africa

06 North British 3B " 39 Cape 6A "

07 Lofoten 3E " 40 Eastern Province 8A "

08 3F " 41 South West Africa 9C "

09 North Baltic 4B " 42 Natal 10C "

10 North West 4C " 43 Dampier 8E Australia

11 Trondelag 4E " 44 Port Headland 4A "

12 English 5B " 45 Anticosti 9C Northern Africa

13 North Bothnian 5F " 46 East Newfoundland 2C "

14 Southern Spanish 6A " 47 Cabot Strait 6B "

15 North Scottish 6C " 48 Nova Scotia 7C "

16 Gulf of Finland 6E "

17 Danish 7B "

18 Irish 7D "

19 Finnmark 7E "

20 French 8B "

21 South Bothnian 8C "

22 Hebridean 8E "

23 Frisian Islands 9B "

24 Helgeland 9E "

25 Skagerrak 10B "

26 North Persian Gulf 5C Persian Gulf & India

27 South Persian Gulf 1C "

28 Bombay 7B "

29 Calcutta 8B "

30 Bangladesh 6C "

31 Saliyah 2F "

32 Hokkaido 9C Japan

33 Tohoku 6C "

Location Chain

no.

Chain Chain

code

Location

P-7

APPENDEX

Parts List

This equipment contains complex modules in which fault diagnosis and repair down to component level are not practical (IMO A.694(17)/8.3.1). Only some discrete components are used. FURUNO Electric Co., Ltd. believes identifying these components is of no value for shipboard maintenance; therefore, they are not listed in the manual. Major modules can be located on the parts location photos on the next page.

F U R U N O

ELECTRICAL PARTS LIST

SYMBOL TYPE

DISPLAY UNIT GP-150

PRINTED CIRCUIT BOARD

20P8148, PNL 004-401-410 20P8192, NP 004-401-960

ASSEMBLY

20S0395, GN-8096 000-150-957-12 08S0334, GR-7000A (option) 000-143-249

LCD

20S0394, EW50379FDW 000-151-235

Model GP-150-DUAL Unit

DISPLAY UNIT GP-150-DUAL

Sep-05 Blk.No.

Code No.

AP-8

Parts Location

Display unit

APPENDEX

GR-7000A (Option) (08S0334)

GN-8096 (20S0395)

NP Board (20P8192)

LCD EW50379FDW

PNL Board (20P8148)

P-9

APPENDEX

Interface Documentation

"DATA1" Port

IEC 61162-1/NMEA 0183 Ver. 1.5 Output

• Output Schematic Diagram (Talker)

DATA 1

TD-A

TD-B

• Output Drive Capability

Max. 10mA

NMEA 0183 Input

DATA 1

RD-H

RD-C

20P8192

MJ-A6SRMD

20P8192

MJ-A6SRMD

FL4

FL7

FL6

FL5

R182 100

JP1

R123 390

CR15 1SS272

PC-400

U26

U25 SN75ALS172

+3.3V

R130

2.2K

AP-10

Furuno GP-150-DUAL User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

IMPORTANT NOTICE

TABLE OF CONTENTS

FOREWORD

A Word to GP-150-DUAL Owners

Features

Program No.

SYSTEM CONFIGURATION

1. OPERATIONAL OVERVIEW

1.1 Control Description

1.2 Turning On and Off the Power

1.3 Adjusting Display Contrast and Brilliance

1.4 Display Mode

1.5 Transmitting Data

1.6 The Interface Unit

2. DISPLAY AND TRACK

2.2 Display Orientation

2.3 The Cursor

2.4 Shifting the Display

2.7 Erasing Track

2.8 Track Plotting Interval

2.9 Apportioning the Memory

3. MARKS

3.1 Entering Marks

3.2 Erasing Marks

3.3 Mark Shape

3.5 Entering Event Marks

3.4 Connecting Marks

3.6 Event Mark Shape

3.7 Entering the MOB Mark

4. NAVIGATION PLANNING

4.1 Entering Waypoints

4.2 Editing Waypoints

4.3 Erasing Waypoints

4.4 Entering Routes

4.6 Replacing Route Waypoints

4.7 Erasing Routes

5. SETTING DESTINATION

5.1 Setting Destination

5.2 Cancelling Destination

5.4 Finding Range and Bearing Between Two Points

6. SETTING UP VARIOUS DISPLAYS

6.1 The Data Display

6.2 Position Format

6.3 Demo Display

7. ALARMS

7.1 Overview

7.2 Arrival Alarm, Anchor Watch Alarm

7.4 Speed Alarm

7.5 Trip Alarm

7.6 Water Temperature Alarm

7.7 Depth Alarm

7.8 WAAS/DGPS Alarm

8. MENU SETTINGS

8.1 GPS SETUP Menu

8.2 Units of Measurement

8.4 Outputting Data

8.5 Receiving Data from Personal Computer

8.6 WAAS/DGPS Setting

8.7 GPS Monitor Display

9. MAINTENANCE & TROUBLESHOOTING

9.1 Clearing the Memory

9.2 Preventive Maintenance

9.3 Error Messages

9.4 Troubleshooting

9.5 Diagnostic Tests

9.6 Interface Unit IF-2500

10. INSTALLATION

10.1 General

10.2 Display Unit

10.3 Antenna Unit

10.4 Wiring

10.5 Initial Settings

10.6 Interface Unit IF-2500

10.7 GPS/BEACON Antenna Distributor MD-GB2

APPENDIX

Menu Tree
