Furuno fcv587 User Manual

8.4" Color LCD FISH FINDER

Model

The FCV-587 now has the ability to

The FCV-587 now has the ability to

acquire sh size and

acquire sh size and

bottom structure

bottom structure

under your boat!

under your boat!

AUTO

Auto Tuning

Auto Tuning

(Sensitivity)

(Sensitivity)

Enhanced
Sunlight Viewable

Enhanced

Sunlight Viewable

Bonded

LCD

Bonded LCD

Polarized

Friendly

Polarized

Friendly

FURUNO Digital

Filter

Bottom

Discrimination

www.furuno.com

ACCU-FISH

The FCV-587 now has the ability to

The FCV-587 now has the ability to

acquire sh size and bottom structure

acquire sh size and bottom structure

under your boat!

under your boat!

FISH SIZEFISH SIZE

BOTTOM BOTTOM

8.4" Color LCD FISH FINDER

Model

AUTO

Auto Tuning

(Sensitivity)

Bonded

LCD

Bonded LCD

FURUNO Digital

Filter

ACCU-FISH

Enhanced
Sunlight Viewable

Enhanced

Sunlight Viewable

Polarized

Friendly

Polarized Friendly

Bottom

Discrimination

Model

(

8.4"

)

Model

(

5.7"

)

▲

Equipped with Furuno’s latest technology: Bottom Discrimination Function

- Analyze bottom structure

•

Provides an at-a-glance recognition of bottom form with four types of graphical displays (Rocks/Sand/Gravel/Mud)

when connected to required thru-hull or transom mount transducer.

▲

ACCU-FISH™ - A unique sh size analyzer based on the latest digital technology

▲

White Line feature - Discriminate sh lying near the bottom

•

The top edge of the sea oor is displayed in white to clearly show bottom structures.

•

This feature helps to discriminate weeds and bottom sh distinctly.

▲

Congurable Alarm function (depth, sh echoes, etc.)

▲

Post-processing Gain Control applied to all echoes displayed on screen

▲

Share and display information on your chartplotter*

•

Furuno’s TLL (Target Lat/Lon) output allows you to interface the FCV-587 with your chartplotter

so that you can mark shing spots with various information (L/L, Depth, Water Temp, Fish size, Bottom).

* Requires connection to a chart plotter.

▲

Fast transmission rate of 3,000 PRR (Pulse Repetition Rate) per minute (at 5 m depth range)

▲

Bright 800 cd/m2 LCD gives excellent readability, even in bright sunlight

•

The LCD and the AR glass are bonded together to ensure that there’s no fogging.

•

Clear visibility even when wearing polarized sunglasses.

▲

Equipped with Furuno’s latest technology: Bottom Discrimination Function

- Analyze bottom structure

•

Provides an at-a-glance recognition of bottom form with four types of graphical displays (Rocks/Sand/Gravel/Mud)

when connected to required thru-hull or transom mount transducer.

▲

ACCU-FISH™ - A unique sh size analyzer based on the latest digital technology

▲

White Line feature - Discriminate sh lying near the bottom

•

The top edge of the sea oor is displayed in white to clearly show bottom structures.

•

This feature helps to discriminate weeds and bottom sh distinctly.

▲

Congurable Alarm function (depth, sh echoes, etc.)

▲

Post-processing Gain Control applied to all echoes displayed on screen

▲

Share and display information on your chartplotter*

•

Furuno’s TLL (Target Lat/Lon) output allows you to interface the FCV-587 with your chartplotter

so that you can mark shing spots with various information (L/L, Depth, Water Temp, Fish size, Bottom).

* Requires connection to a chart plotter.

▲

Fast transmission rate of 3,000 PRR (Pulse Repetition Rate) per minute (at 5 m depth range)

▲

Bright 800 cd/m2 LCD gives excellent readability, even in bright sunlight

•

The LCD and the AR glass are bonded together to ensure that there’s no fogging.

•

Clear visibility even when wearing polarized sunglasses.

Model

Model

(

8.4"

)

(

5.7"

)

“ACCU-FISH™” identies individual sh
with size and sh mark function

Recognizes individual or multiple sh instantaneously

ACCU-FISH™ is a revolutionary sh size assessment function of the FCV-587.
In order to assess individual sh size, the echo strength from the sh needs to be
computed and turned into sh size display on the screen. It can detect the sh size of
10 to 199 cm, in the depth of 2 to 100 m.

Displaying sh marks

The sh mark can be utilized to display on individual sh echoes when detected.
It helps beginners to identify the sh targets on the display for a more fun shing experience.
Fish mark is selectable from two types of sh
symbol, circle and square. The sh symbol, displayed
in two different sizes (Large: over 50 cm, Small: 10
to 49 cm), is a great help for anglers to identify sh
targets. Circle and square indentify targets without
hiding sh echo.

Displaying sh size or sh depth

Activating the ACCU-FISH™ from the menu, FSV-587 displays sh size on the individual
sh echo. When the ACCU-FISH™ is used concurrently with sh marks, it greatly helps
anglers to identify sh targets on the display. You may also select and display the target
depth instead of sh size, which helps to see how far the sh is from the boat.

In some instances, sh size indicated on the FCV-587 may differ from its actual size.
Please read the operation manual carefully before using this feature.

Striped

Solid

Circle

Square

Circles and sh size are displayed on top of
the sh echoes. When in dual frequencies
mode, you can set the mark to be displayed
either individually or on both windows.

Bottom Discrimination feature

The FCV-587’s Bottom Discrimination feature enables the sh nder to indicate if the major
component of the bottom is rocks, gravel, sand, mud.
The Bottom Discrimination feature provides you with valuable information that helps you
locate rich shing grounds, and boost your catch of the day.

Please keep the following in mind when using the Bottom Discrimination Sounder:

1) Use at a depth of 5 m - 100 m.

2) Use transducer in transom mount or thru-hull mount.

3) Set the transducer parallel to the bottom of the craft.

4) To show a consistent display of the actual bottom, set the range display
of the sh nder screen to “auto”.

5) Enter the ship’s draft value.

6) Use a ship speed of 10 kn or less.

7)

In some instances, bottom component indicated on the FCV-587 may
differ from its actual bottom structure.
Please read the operation manual

carefully

before using this feature.

Graphic mode

The standard graphic display mode shows the most
probable bottom composition by graphic or four colors.

Probability mode

The probability display mode shows the most
probable bottom composition in graph form.

Rocks
Gravel

Sand
Mud

Rocks
Gravel
Sand
Mud

White Line function distinguishes sh from bottom

The white line function helps you distinguish bottom sh from the bottom by changing the strongest
signal color to white. This function is not only useful discriminating bottom sh but is also valuable
for judging sh school density. The setting range is 0%-100%,
in intervals of 1%. The higher the value the thicker the line.

Field Test

Screenshot from sh reef in lake:

Many sh marks appear on the screen in the thick weed bed.
The white line function helps to distinguish between the sea
bottom, weeds and the actual sh.

Post-Processing Gain Control

With conventional gain controls, changes are made for new
echoes only when a change in the gain setting is applied.
With the FCV-587’s Post-Processing Gain Control, changes
in the gain setting are applied to new echoes as well as all
of the echoes already on the screen. Because the changes
are applied to both new and existing returns, you will be
able to quickly and easily nd the right gain setting for your
conditions.

Gain: 4Gain: 2

Bright LCD for excellent viewability in sunlight

Bright 800 cd/m2 LCD gives excellent readability even in bright sunlight.

FCV-587 has a LCD screen which does not "black out" when
wearing polarized sunglasses at certain angles, providing no
loss of visibility while shing.

ViewableBlack out

Conventional

FCV-587

Conventional FCV-587

Gain: 4 Gain: 2

Conventional gain setting

Fish Alarm function

When sh echoes come in the area which you set above the bottom, beeps sound and the alarm icon ashes
at the top right corner of the screen. Furthermore, an integrated alarm setting is also available that can be set
by every and each condition, including water depth, target depth, water temp, bottom type, etc.

Swivel mounting bracket to adjust
the angle of the display unit

The gimbal mount allows the display unit to swivel around
when desktop mounted. You can adjust the angle of the display
to get the optimum viewing angle.

SPECIFICATIONS OF

GENERAL

Frequency 50 and 200 kHz
Output Power 600 W/1 kW*

DISPLAY

Display Type 8.4" color LCD
Effective Display Area 128.2 (W) x 170.9 (H) mm
Pixel Number 640 x 480 (VGA)
Display Single frequency (50 or 200 kHz),

Basic Range 2-1200 m*

Alarm Bottom, Fish (Normal), ACCU-FISH™,

Language English, French, Spanish, German,

Range Phasing up to 1200 m
Expansion Range Bottom-lock expansion: 2-10 m
Sectional expansion: 2-1200 m
Picture Advance Speed 8 steps: stop, 1/16, 1/8, 1/4, 1/2,

Pulselength & PRR 0.04-5.0 ms, Max 3,000 pulse/min
Interface (Input) BWC, GGA, GLL, GNS, HDG,

(Output) DBS, DBT, DPT, MTW*, RMB*,

ENVIRONMENT

Temperature -15°C to +55°C
Waterproong IP56

POWER SUPPLY 12-24 VDC, 1.1-0.5A
EQUIPMENT LIST

Standard

1. Display Unit CV-587

2. Installation Materials and Standard Spare Parts

Option

1. Speed/Temperature Sensor
ST-02MSB (Bronze, thru-hull), ST-02PSB (Plastic, thru-hull),
T42 (Bronze, thru-hull), T80 (Stainless-steel, transom),

2. Connector Kit for Connection of Temperature Sensor or
Speed & Temperature Sensor

3. Matching Box MB-1100 (For 1 kW output with some transducers)

4. NMEA+Power Cable

*Matching Box MB-1100 required

Dual-frequency, Zoom, Nav data,
A-scope, Marker zoom, Bottom zoom,
Bottom-lock, Bottom Discrimination,
ACCU-FISH™

*m, ft, fm, HR, pb can be selected in the menu

Fish (B/L), Bottom Discrimination, Fish
Level, Temperature, Speed, Arrival and
Battery

Italian, Portuguese, Greek, Polish,
Danish, Swedish, Norwegian, Finnish,
Chinese, Japanese, Thai, Vietnamese,
Indonesian, Burmese

1, 2, 4

HDT, MDA, MTW, MWV, RMA, RMB,
RMC, VHW, VTG, XTE, ZDA

VHW*, TLL* by key operation

* External data required.

Transducers (Specify when ordering)

600 W
520-5PSD (Plastic, thru-hull), 520-5MSD (Bronze, thru-hull),
525-5PWD (Plastic, transom), 525STID-MSD (Bronze, thru-hull,
with a speed/temp sensor), 525STID-PWD (Plastic, transom,
with a speed/temp sensor)
1 kW
50 kHz: 50B-6, 50B-6B
200 kHz: 200B-5S
50/200 kHz dual-frequency: 50/200-1T, 50/200-12M,
526TID-HDD

DISPLAY UNIT

Bracket Mount

2.3 kg 5.1 lb

Flush Mount

1.6 kg 3.5 lb

R135

233 9.2"

233 9.2"

4-ø6

233 9.2"

142 5.6"

60˚

233 9.2"

54 2.1"

60˚

110 4.3"

57 2.2"

70

2.8"

52

2.0"

270 10.6"

ø127

110 4.3"
158 6.2"

54 2.1"

282 11"

152 6.0"

4-ø4.5

66 2.6"

94.5 3.7"

173 6.8"

140 5.5"

Cutout for flush mount

90˚

INTERCONNECTION DIAGRAM

GPS
Navigator

GPS
Plotter

MB-1100

Option

12-24 VDC Transducer

(600 W)

NMEA0183

NMEA0183

Matching Box

Transducers (1kW)

Beware of similar products

All brand and product names are registered trademarks,
trademarks or service marks of their respective holders.

FURUNO ELECTRIC CO., LTD.

Nishinomiya, Hyogo, Japan
www.furuno.com

FURUNO U.S.A., INC.

Camas, Washington, U.S.A.
www.furunousa.com

FURUNO (UK) LIMITED

Havant, Hampshire, U.K.
www.furuno.co.uk

FURUNO FRANCE S.A.S.

Bordeaux-Mérignac, France
www.furuno.fr

FURUNO ITALIA S.R.L.

Gatteo Mare, Italy
www.furuno.it

FURUNO ESPAÑA S.A.

Madrid, Spain
www.furuno.es

FURUNO DANMARK A/S

Hvidovre, Denmark
www.furuno.dk

FURUNO NORGE A/S

Ålesund, Norway
www.furuno.no

FURUNO SVERIGE AB

Västra Frölunda, Sweden
www.furuno.se

FURUNO FINLAND OY

Espoo, Finland
www.furuno.

FURUNO POLSKA Sp. Z o.o.

Gdynia, Poland
www.furuno.pl

FURUNO EURUS LLC

St. Petersburg, Russian Federation
www.furuno.com.ru

SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE

PLEASE READ MANUAL BEFORE USING THE UNIT

RICO (PTE) LTD

Singapore
www.rico.com.sg

FURUNO DEUTSCHLAND GmbH

Rellingen, Germany
www.furuno.de

FURUNO HELLAS S.A.

Piraeus, Greece
www.furuno.gr

FURUNO (CYPRUS) LTD

Limassol, Cyprus
www.furuno.com.cy

FURUNO SHANGHAI CO., LTD.

Shanghai, China
www.furuno.com/cn

14113SS Printed in Japan

Catalogue No. E-410b
