Switching Hub

HUB-100 1.5 kg 3.31 lb

Antenna Unit for FCR-2119/2129/2819/2829/2829W

XN-20AF 39 kg 86 lb
XN-24AF 42 kg 93 lb

Antenna Unit for FCR-2139S/2839S/2839SW

SN-36AF 133 kg 293.2 lb

Monitor Unit

MU-190 8.8 kg 19.4 lb

MU-231 12.8 kg 28.2 lb

Radar Processor
Unit

RPU-013

10 kg 22 lb

Transceiver Unit for FCR-2829W

RTR-081 8.0 kg 17.6 lb

Transceiver Unit for FCR-2839SW

RTR-082 17.0 kg 37.5 lb

360 14.2" 411 16.2"

95

3.7"

498 19.6"

418 16.5"

183 7.2"

27

1.1"

350 13.8"

7

0.3"

385 15.2"
370 14.6"

25

1.0"

340 13.4"

380 15.0"

2- 7

410 16.1"

98

90

300 11.8"

468 18.4"

137 5.4"

570 22.4"

18

0.7"

XN-20AF: 2040 80.3"
XN-24AF: 2550 100.4"

4- 15

26 1.0"

4- 8

250 9.8"

12 0.5"

353 14.0"

380 15.0"

25

1.0"

325 12.8"

165 6.5"160 6.3"

200 7.9"

149 5.9"

157 6.2"

404 15.9"

6- 10

270 10.6"

88 3.5"

192 7.6"

457 18.0"

210 8.3"

210 8.3"

15

0.6"

427 16.9"

15 0.6"

510 20.1"

432 17.0"

561 22.1"

275 10.8"

378 14.9"

420 16.5"

710 28.0"

184 7.2"

421 16.6"

432 17.0"

SN-36AF: 3765 148.2"

105

4.1"

105

4.1"

8- 15

286 11.3"

250 9.8"

432 17.0"

350 13.8"

530 20.9"

110

4.3"

110

4.3"

100

3.9"

137

5.4"

270 10.63"
255 10.03"

242 9.53"

115 4.53"

162 6.38"

15 0.59"

145 5.71"

45

1.77"

47 1.85"
4-ø5
Fixing Hole

450 17.7"

110 4.3"

389 15.3"

397 15.6"

448 17.6"

489 19.3"

4-Ø18

Cutout for ush mount

471 18.5"

554 21.8"

592 23.3"

112

4.4"

484.9 19"

553 21.8"

Cutout for ush mount

Processor Unit

EC-3000

14 kg 30.9 lb

426 16.77"

396 15.59"

45 1.77"150 5.9" 150 5.9"

360 14.17"

3-ø8
Fixing hole

15 0.59"

153 6.02"

150 5.9"

Intelligent Hub

HUB-3000

1.5 kg 3.31 lb

no less than

150 5.91"

no less than

100 3.94"

42 1.65"

33

1.3"

172 6.77"

153 6.02"

133 4.06"

4-ø5
Fixing hole

324 12.76"

336 12.23"

350 13.79"

Sensor Adapter

Serial : MC-3000S 1.5 kg 3.3 lb

Analog : MC-3010A 0.8 kg 1.8 lb Digital In : MC-3020D 0.8 kg 1.76 lb Digital Out : MC-3030D 0.8 kg 1.76 lb

48 1.88"

41 1.61"

no less than 150 5.91"

100 3.94"

4-ø5
Fixing
Hole

60 2.36"

150 5.91"64 2.52"

235.5 9.25"

48 1.88"
41 1.61"

no less than 150 5.91"

100 3.94"

4-ø5
Fixing
Hole

60 2.36"

150 5.91"64 2.52"

235.5 9.25"

220 8.66"

235.5 9.27"

150 5.91"64 2.52"

no less than 150 5.91"

180 7.09"

4-ø5
Fixing
Hole

48 1.88"

41 1.61"

100 3.94"

60 2.36"

235.5 9.25"

150 5.91"64 2.51"

4-ø5
Fixing
Hole

48 1.88"

41 1.61"

no less than 150 5.91"

398 15.7"

339 13.3"32 1.26"

398 15.7"

no less than 70 2.76"

72 2.83" max.

10 to 20

0.39" to 0.79"
388 15.3"

180 7.09"

180 7.09"

170 6.69"

55 2.17"

216 8.50"

38 1.50"

Control Unit

RCU-025 3.1 kg 6.84 lb

Trackball Control Unit

RCU-026 1.5 kg 3.31 lb

Models: FCR-21x9 (with 19" LCD) / FCR-28x9 (with 23.1" LCD

)

120 4.72"

180 7.09"

no less than

70 2.76"

Max 70

2.76"

170 6.69"

120 4.72"

110 4.33"

180 7.09"

with an optional pedestal

FURUNO integrates advanced signal processing
technology with a user-friendly interface, providing
reliable situation awareness, and navigation safety

FURUNO integrates advanced signal processing
technology with a user-friendly interface, providing
reliable situation awareness, and navigation safety

▲

Multifunction display capability, featuring Chart Radar, ECDIS,
conning information display and Alert Management System*

▲

New user interface delivers straightforward operation

▲

Instantaneous redraw, scrolling and zoom in/out delivered by FURUNO’s
advanced drawing engine, making redraw latency a thing of the past

*Multifunction display capability is to be implemented as software update after the

product release in autumn 2012. (Option)

▲

Complies with the following IMO and IEC regulations:

▲

Interface with Jeppesen Dynamic Licensing service

▲

High-resolution LCD presents clear radar/chart images

• IMO Resolution A.278(VIII) • IMO Resolution A.694(17)

• IMO Resolution A.817(19) • IMO Resolution A.820(19)

• IMO Resolution A.823(19) • IMO Resolution MSC.191(79)

• IMO Resolution MSC.192(79) • IMO Resolution MSC.232(82)

• IEC60945 Ed. 4.0 • IEC61162-1 Ed. 4.0 • IEC61162-2 Ed. 1.0

• IEC61174 Ed. 3.0 • IEC61993-2 Ed. 1.0 • IEC62288 Ed. 1.0

• IEC62388 Ed. 1.0

ECDIS

Conning Information Display

Radar (Chart OFF

)

Radar (Chart ON

)

FURUNO’s new user interface delivers straightforward ope ration

FURUNO’s new user interface delivers straightforward ope ration

Unique & smart operation tool – “Status bar” and “InstantAccess bar”

The user interface of the Chart Radar centers on carefully organized operational tools: Status bar and InstantAccess bar.
These operational tools deliver straightforward, task-based operation by which the operator can quickly perform a
certain task needed without having to go deeper into an intricate menu tree.

Status bar contains information about
the operating status, i.e., MFD operating
mode, main tasks assigned to each
MFD operating mode.

InstantAccess bar contains all the tasks
(functions/actions) corresponding to the
operation mode currently selected so
that quick access to necessary
functions/actions can be made.

Status bar

InstantAccess bar

A toggle button alternately selects one
of two functions assigned to the button.
The background color of a toggle button
is light blue when the button's function
is enabled.

Rain/Sea clutter and gain are set
with the slider bars. Slider bars
can be controlled by the use of
trackball controller.

Toggle button Drop-down menu Slider bar

on buttons in the Status bar and InstantAccess
bar indicate that there are hidden options of
actions/tasks to be performed in the sub-layer,
which can be initiated by left-clicking the buttons.
This way, the operator can quickly gain access to
the related tasks.

Stress-free operation with the well-designed
control unit

Stress-free operation with the well-designed
control unit

trackball: to move the cursor and select an object

left-click: to perform/conrm the action related the selected object

right-click: to display context menu while a cursor is on the display area,
and to cancel action done on the selected object

scrollwheel: to select menu items

EBL key and encoder

InstantAccess Knob

VRM key and encoder

1

1
2

3

4

2

3

EBL/VRM

EBL/VRM can be set just by pressing the
buttons and rotating the encoder.

InstantAccess Knob

Rotating and pressing InstantAccess Knob leads you
easily to the items in InstantAccess bar.

PC-liked operation

All operations can be controlled with the trackball.

Contextual menu

The context menu that containing all
the available actions related to the
selected icon or area, hence providing
quick access to tasks required.

VRM

EBL

4

1

2

3

4

Navigation sensors can be directly interfaced with the processor’s 8 serial I/0 ports.
Sensor adapters are required under the following conditions:

• the sensor data is to be shared amongst multiple networked Chart Radar and ECDIS systems,

• the number of sensors interfaced is more than the number of the ports the processor has (8 serial I/O ports, 1 digital IN and 6 digital OUT), and/or

• the networked sensors include analog sensors.

In order to integrate onboard sensors into the navigation network, the sensor adapter may be interfaced with the switching hub
HUB-100 from which distribution of the sensor data throughout the network is possible. Alternatively, multiple sensor adapters
may be interfaced via Ethernet to integrate onboard sensors for use in the shipboard network.

▲

Ease of installation and maintenance thanks to simplied cabling in the sensor-to-Chart Radar/ECDIS
interface delivered by common sensor adapter

Sensor Adapter acts as central medium to gather all the sensor data and collectively feed it to all FCR-2xx9 Chart Radar and FMD-3200/3300 ECDIS in the
system. Since sensor adapter can be extended to cover all the sensors within the system, individual cablings in the sensor-to-Chart Radar/ECDIS interface can
be greatly reduced.

Model:

FAR-2xx7

System diagram
for the current
Radar

Model:

FCR-2xx9

System diagram
for the new
Chart Radar

HUB3000

Gyro 1 Gyro 2GPS 1 GPS 2HCS Speed log

Anemometer

Nav. E.S. AIS

Sensor AdapterSensor Adapter

HUB100 HUB100

HUB100

HUB100

LAN Adapter

B Adapter

Gyro 1 Gyro 2GPS 1 GPS 2HCS Speed log

Anemometer

Nav. E.S. AIS

B Adapter

LAN Adapter

HUB100

FURUNO’s new user interface delivers straightforward ope ration

FURUNO’s new user interface delivers straightforward ope ration

Unique & smart operation tool – “Status bar” and “InstantAccess bar”

The user interface of the Chart Radar centers on carefully organized operational tools: Status bar and InstantAccess bar.
These operational tools deliver straightforward, task-based operation by which the operator can quickly perform a
certain task needed without having to go deeper into an intricate menu tree.

Status bar contains information about
the operating status, i.e., MFD operating
mode, main tasks assigned to each
MFD operating mode.

InstantAccess bar contains all the tasks
(functions/actions) corresponding to the
operation mode currently selected so
that quick access to necessary
functions/actions can be made.

Status bar

InstantAccess bar

A toggle button alternately selects one
of two functions assigned to the button.
The background color of a toggle button
is light blue when the button's function
is enabled.

Rain/Sea clutter and gain are set
with the slider bars. Slider bars
can be controlled by the use of
trackball controller.

Toggle button Drop-down menu Slider bar

on buttons in the Status bar and InstantAccess
bar indicate that there are hidden options of
actions/tasks to be performed in the sub-layer,
which can be initiated by left-clicking the buttons.
This way, the operator can quickly gain access to
the related tasks.

1

MFD operating mode selector4Preset picture selector

6

Rain/Sea clutter reducer

7

Gain adjuster

3

Antenna selector

5

IMO chart database selector
(base, standard or all)

2

Stand-by and transmit

1

Click to select the radar pulse length

2

Click to tune the radar receiver manually

3

Click to activate/deactivate and choose the level
(1/2/3) of the interference rejecter

4

Click to activate/deactivate and choose the level
(1/2/3) of the echo stretch

5

Click to activate/deactivate and choose the level
(1/2/3) of the echo averaging

6

Click to erase everything but radar echoes
temporarily

7

Click to reset the ship’s position in Course-Up and
True Motion modes

11

Click to set the AIS information (navigation
status, ETA, destination, draught, etc.)

12

Click to open the AIS message menu window from
which the operators can handle AIS messages,
i.e., sending, viewing and deleting messages

13

Click to select a
color palette
(color and
brilliance set of the screen
presentation) to match the
ambient lighting conditions

14

Click to summon display brilliance
level adjustment window where the
brilliance level can be adjusted either
manually (by gauge) or automatically
(by clicking the automatic brilliance
adjustment button, next to the
brilliance gauge). (for FURUNO
monitor)

15

Click to enter Man Overboard mark on
the chart

16

Click to take a screenshot

17

Click to undo the past actions

8

Click to show/hide the radar map

9

Click to show/hide the chart

10

Click to congure presentation settings

Status bar

InstantAccess bar

6 7 81 2 3 4 5

The FCR-2xx9 offers several picture preset
options for specic navigating requirements:

•

Control of what objects and text to show on the chart.

•

Temporarily hides the chart symbols (depth contours, navigation buoys, etc.) and
shows only the coast line.

•

Temporarily puts the chart symbols on the top layer

8

User prole management

The FCR-2xx9 can store 10 sets of custom
settings for some items i.e., display brilliance,
color presentation, etc. User prole function
allows individual users to quickly set the
equipment according to their preferences.

•

OCEAN (Optimum setting for long range detection using a range scale of
6 nm or larger)

•

CANAL (Optimum setting for operating in a canal)

•

BERTHING (Optimum setting for berthing)

•

CONGESTION (Optimum setting for short range navigation using a range
scale of 1.5 nm or less)

•

ROUGH SEA (Optimum setting for operation in rough seas)

•

HARD RAIN (Optimum setting for rough weather or heavy rain)

Also, 2 user-programmable presets are provided (labeled CUSTOM1/2)

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

Stress-free operation with the well-designed
control unit

Stress-free operation with the well-designed
control unit

trackball: to move the cursor and select an object

left-click: to perform/conrm the action related the selected object

right-click: to display context menu while a cursor is on the display area,
and to cancel action done on the selected object

scrollwheel: to select menu items

EBL key and encoder

InstantAccess Knob

VRM key and encoder

1

1
2

3

4

2

3

EBL/VRM

EBL/VRM can be set just by pressing the
buttons and rotating the encoder.

InstantAccess Knob

Rotating and pressing InstantAccess Knob leads you
easily to the items in InstantAccess bar.

PC-liked operation

All operations can be controlled with the trackball.

Contextual menu

The context menu that containing all
the available actions related to the
selected icon or area, hence providing
quick access to tasks required.

VRM

EBL

4

1

2

3

4

Target trails

The target trails can be displayed in the
form of synthetic afterglow. Trail time and
the trail plotting interval can be selected.
The trails are useful for showing own ship
movement and other ship tracks.

Automatic acquisition zone

User can set an automatic acquisition
zone anywhere in the radar echo area.
When a target enters an acquisition
zone, the buzzer sounds and the alert
message appears in the Alert box.
Further, the AIS display is automatically
turned on if it is off.

Radar map

A radar map is a layer consisting of marks
and lines that can be produced and
overlaid onto the radar display. It is
intended for indicating safety-related areas
and objects. 10 radar maps can be made
and each map can have a total of 4,000
lines and symbols. The map data can be
saved to facilitate repeated use on a routine
navigation area. The user can create a
radar map on-real time while using the
radar for navigation or at leisure time at
anchor or while the radar is not being used.

Automatically acquired targets

TT information

AIS information

AIS target

The chart radar can track the
movement of up to 100 radar
targets and display up to 1,000
AIS targets.

TT (ARPA)/AIS

Radar Mode

ECDIS mode can be selected from
the MFD operating mode selector
at the Status bar.
In ECDIS mode, the operators can
generate and edit route plans.
Also, ship’s behavior can be
monitored in relations to the
planned route. The detailed
parameters set for each waypoint
within the route can be viewed in
the route information window.

ECDIS Mode

Route MonitoringRoute Planning

System Fail
Power Fail

ACK IN

VDR

DVI-RGB Cable

100-230 VAC 1ø, 50-60 Hz

Control Unit

RCU-025

or

Trackball Control Unit

RCU-026

USB Keyboard

USB Mouse

INTERCONNECTION DIAGRAMINTERCONNECTION DIAGRAMSPECIFICATIONSSPECIFICATIONS

100 VAC

1ø, 50-60 Hz

200/380 VAC, 3ø, 50 Hz
220/440 VAC, 3ø, 60 Hz

200/380 VAC, 3ø, 50 Hz
220/440 VAC, 3ø, 60 Hz

* Up to 8 EC-3000 Processor Units can be
interfaced through single HUB-3000.

Option or connectable equipment

Model

FCR-2119
FCR-2129
FCR-2819
FCR-2829
FCR-2829W
FCR-2139S
FCR-2839S
FCR-2839SW

Output Power (Transceiver)

X band 12 kW (RTR-078A)
X band 25 kW (RTR-079A)
X band 12 kW (RTR-078A)
X band 25 kW (RTR-079A)
X band 25 kW (RTR-081A)

S band 30 kW (RTR-080)
S band 30 kW (RTR-080)
S band 30 kW (RTR-082)

Antenna Length (Antenna Unit)

6.5 ft (XN-20AF)
8 ft (XN-24AF)

12 ft (SN-36AF)

Rotation (Gear Box)

24 rpm (RSB-103)

21 / 26 rpm (RSB-104/105)

24 rpm (RSB-096)
42 rpm (RSB-097)

21 / 26 rpm (RSB-098/099)
45 rpm (RSB-100/101/102)

Monitor Unit

19.0" SXGA (MU-190)

23.1" UXGA (MU-231)

23.1" UXGA (MU-231)

19.0" SXGA (MU-190)

23.1" UXGA (MU-231)

23.1" UXGA (MU-231)

Antenna

XN-20AF (6.5 ft)
XN-24AF (8 ft)

Transceiver
RTR-078A (12 kw)
RTR-079A (25 kw)

Performance Monitor
PM-31

Antenna

XN-20AF (6.5 ft)
XN-24AF (8 ft)

Antenna

SN-36AF (12 ft)

Antenna

SN-36AF (12 ft)

Gear Box

RSB-096 (24 rpm)
RSB-097 (42 rpm)

Gear Box

RSB-103 (24 rpm)

Gear Box

RSB-098/99 (21/26 rpm)
RSB-100/101/102 (45 rpm)

Gear Box

RSB-104/105 (21/26 rpm)

FCR-2119/2129/2819/2829 FCR-2829W FCR-2139S/2839S FCR-2839SW

Note:

1. Length of LAN cable is 50 m (max.)

2. Cable between Sensor Adapter components
should be no longer than 6 m.

Performance Monitor
PM-31

Performance Monitor
PM-51

Performance Monitor
PM-51

RTR-081A
Transceiver Unit

Transceiver
RTR-080(30 kW)

RTR-082
Transceiver Unit

PSU-007
Power Supply Unit

100-115/220-230 VAC

1ø, 50-60 Hz

100-115/220-230 VAC

1ø, 50-60 Hz

100-230 VAC
1ø, 50-60 Hz

100-230 VAC

24 VDC

Gyro Converter

GC-10

RPU-013

Radar Processor

Unit

Processor Unit EC-3000 for ECDIS and Chart Radar*

EC-3000

Processor Unit

DVI cable

RS-485

MU-190: 5/10 m (max.)
MU-231: 5 m (max.)

MU-190: 10 m (max.)
MU-231: 5 m (max.)
for Brill control

MU-190
19"

GYRO COMPASS

SUB DISPLAY

A-D CONVERTER

Intelligent Hub

HUB-3000

8 ports

Switching Hub

HUB-100

Sensor Adapter

Serial MC-3000S (8 ports)

Analog MC-3010A (3 ports)

Digital IN/OUT

MC-3020D/3030D

(8 ports each)

Navigation Sensors

Gyrocompass
AIS
GPS
NAVTEX
Wind Indicator
Echo Sounder
Speed Log
Water Temp. Sensor
etc.

MU-231

23.1"

Monitor Unit

GENERAL

Minimum range
Range discrimination
Bearing accuracy
Presentation modes

22 m
26 m
±1°
Head-up, Head-up TB, Course-up, North-up, True Motion
(sea or ground stabilization in True Motion)

ANTENNA UNIT

Radiator Type
Beamwidth and Sidelobe

Slotted waveguide array

RADAR PROCESSOR UNIT

PROCESSOR UNIT

Chart Materials

Data Presentation
Own Ship

Target Data

(TT: ARPA, AIS)

Position Calculation

Navigation Planning
Navigation Recording
Route Monitoring
User Chart
Notes Data
MOB (Man Overboard)

IMO/IHO S57 edition-3 ENC vectorized material
(IHO S-63 ENC data protection scheme),
C-MAP and CM-93/3 vectorized materials

Own ship's mark and numeral position in lat/lon,
speed and course
Range, bearing, speed, course, CPA/TCPA, BCR/BCT
Target information from AIS (waypoint, ship's hull and status)
Navigation by result from external position sensor
Dead reckoning with gyro and log data from gyro, log,
and position sensors to be fed to mathmatical filter to
generate highly accurate position and speed
Planning by rhumb line, great circle
Latest 12 hours of navigation data to be recorded
Off-track display, waypoint arrival alarm, shallow depth alarm
User chart creation and display
Create and display notes data
Position, and other data at time of man overboard are
recorded MOB mark is displayed on the screen

INTERFACE

DVI

LAN
USB
COM

Serial I/O

Digital IN
Contact Closure

3 ports, DVI-I Ver 1.1
(Video signal from DVI No. 1 and DVI No. 2 is identical)
3 ports, Ethernet 1000 Base-T

(1port for Radar sensor only)
4 ports, USB 2.0 type-A
2 ports, RS-485 for brilliance control
8 ports, IEC61162-1/2 (2 ports), IEC61162-1 (6 ports)
Sentences: AAM, ABK, ABM, ACK, ALR, BBM, BWC, BWR,
DBT, DPT, DTM, ETL, GBS, GGA, GLL, GNS, HDT, MTW,
MWD, MWV, OSD, RMB, RMC, ROT, RSD, RTE, THS,
TTM, VBW, VDM, VDO, VHW, VTG, WPL, ZDA
1 port, ACK signal input
6 ports: 1 port for system fail, 1 port for power fail,
2 ports for normal close, and 2 ports for nomal open

Radiator Type
Length
Beamwidth (H)
Beamwidth (W)
Frequency
Sidelobe (within ±10°)
Sidelobe (outside ±10°)

XN-20AF

6.5 ft

1.23°
20°

-28 dB

-32 dB

XN-24AF

8 ft

0.95°
20°

-28 dB

-32 dB

X band: 9410±30 MHz

SN-36AF

12 ft

1.8°
25°

S band: 3050±30 MHz

-24 dB

-30 dB

MONITOR UNIT

Monitor Unit
Display Type
Resolution

MU-190

19" color LCD

SXGA(1280×1024 pixels

)

MU-231

23.1" color LCD

UXGA(1600×1200 pixels

)

Pulselength, Pulse Repetition Rate (PRR) and Range scale

*500 Hz on 96/120 NM range
**2200Hz on TT range = 32 NM

Pulselength (μs)
PRR (Hz approx.)
Range scale (NM)

0.07

3000**

0.125/0.25/

0.5/0.75/1/

1.5/2

0.15

3000**

0.5/0.75/

1/1.5/2/3/4

0.3

1500

0.75/1/1.5/
2/3/4/6/8

0.5

1000

3/4/6/8/

12/16/24

0.7

1000

3/4/6/8/
12/16/24

1.2

600*

6/8/12/16/
24/32/48/

96/120

Range scales (NM)
Ring intervals (NM)
Number of Rings

0.125

0.025
5

6
1
6

4
1
4

3

0.5
6

2

0.5
4

1.5

0.25
6

1

0.25
4

0.75

0.25
3

0.5

0.1
5

0.25

0.05
5

Range Scales and Ring Intervals

1, 2, 4, 8, 16, 32, 72, 120 NM cannot be selected on IMO radar.

Range scales (NM)
Ring intervals (NM)
Number of Rings

8
2
4

120

20

6

96
16

6

72
12

6

48

8
6

32

8
4

24
4
6

16

4
4

12

2
6

Model

FCR-2139S(-BB)
FCR-2839S

3.0A

3.0A

1.5A

1.5A

3.5A-3.5A-3.5A

-

Antenna voltage input (100 kn)

200 VAC,
ø3, 50 Hz,
220 VAC,
ø3, 60 Hz

380 VAC,
ø3, 50 Hz,
440 VAC,
ø3, 60 Hz

220 VAC,
ø3, 50 Hz,
(HSC)

220 VAC,
ø3, 60 Hz,
(HSC)

440 VAC,
ø3, 60 Hz,
(HSC)

1 port, Ethernet 100 Base-TX
8 ports, IEC 61162-1/2 (4 ports), IEC 61162-1 (4 ports)
1 port for system fail, normal close or normal open
3 ports/per unit, -10 to +10V/0 to 10 V, 4 to 20 mA selectable
8 ports/per unit, normal close or open, selectable
8 ports/per unit, normal close or open, selectable

SENSOR ADAPTER

Control and Serial Input
LAN
Serial
Contact Closure
Analog Input
Digital IN
Digital Output

-15°C to +55°C

-25°C to +55°C (storage +70°C)
93 % or less at 40°C

IP22

IPX0
IP20 (IP22: option)
IPX0
IP22
IPX6
IEC 60945 Ed.4

ENVIRONMENTAL CONDITIONS

Ambient Temperature
Monitor/processor/transceiver/
control/power supply unit
Antenna unit
Relative Humidity
Degree of protection
Monitor unit
Processor unit
RPU-013
EC-3000
Transceiver/power supply unit
Control unit
Antenna unit
Vibration

EQUIPMENT LIST

Standard

Monitor Unit
Radar Processor Unit
Processor Unit
Control Unit
Control Unit
Trackball Control Unit
Antenna Radiator
Transceiver
Gear Box

Power Supply Unit for S-band (FCR-2139S/2839S)
Cable between Radar Processor and Antenna Unit
LAN Cable between Radar Processor Unit and
Processor Unit
Power Switch Cable between Radar Processor Unit
and Processor Unit
Standard Spare Parts and Installation Materials

MU-190/MU-231
RPU-013
EC-3000

RCU-025
RCU-026
XN-20AF/XN-24AF/SN-36AF
RTR-078A/079A/080/081A/082
RSB-096/097/098/099/100/101/
102/103/104/105
PSU-007

Option

Performance Monitor for X-band/S-band
Sensor Adapter
Gyro interface
Slave Radar Cable
Switching Hub for sensor network
Intelligent Hub for interswitch network
Installation Materials

PM-31/51
MC-3000S/3010A/3020D/3030D
GC-10
RW-4864
HUB-100
HUB-3000

1unit
1unit
1unit
1unit
1unit*
1unit*
1unit
1unit
1unit

1unit
1 pc

1 pc

1 pc
1 set

S-band: 200/220/380/440 VAC, 4 phase, 50/60 HzAntenna unit

24 VDC, 1.4 ASensor Adapter

POWER SUPPLY

Monitor unit
MU-231
MU-190
Processor unit
RPU-013

EC-3000

100-230 VAC; 1.0-0.6 A, 1 phase, 50/60 Hz
100-230 VAC; 0.7-0.4 A, 1 phase, 50/60 Hz

FCR-2119(-BB)/2819:
100-115 VAC: 2.6 A (3.0 A), 220-230 VAC: 1.6 A (1.7 A)
FCR-2129(-BB)/2829:
100-115 VAC: 3.0 A (3.4 A), 220-230 VAC: 1.8 A (1.9 A)
( ): Value for 42 rpm antenna unit
FCR-2829W:
100-115 VAC: 3.2 A, 220-230 VAC: 1.6 A
FCR-2139S(-BB)/2839S/2839SW:
100-115 VAC: 3.0 A, 220-230 VAC: 1.5 A
100-115/220-230 VAC, 1 phase, 50/60 Hz

* Specify when ordering

Target Tracking (TT)
Acquisition
Auto tracking
Tracking

100 targets in 0.1-24(32) NM (Auto or Manual)
All acquired targets
5/10 points on all targets
