PACKING LIST FOR 1934C/NT
Box 1 - 1934C/NT Display Wt: 25 lbs. Dim: 19" x 14" x 14"
Part No.
1 RDP149/NT 10.4: Navnet VX2 Displa
2 100-323-600 White Plastic Facia Cover 1
3 008-524-700 Mounting Bracket 1
4 008-523-650 Mounting Knob 2
5 000-549-013 Fuse FGBO 7
6 000-549-014 Fuse FGBO 15
7 100-292-140 3A, 5A, 7A Fuse Label 1 sub CP03-22701
8 100-292-770 Cutout Template Sheet 1 "
9 100-323-900 Flush Mnt. Gasket GAS-KET-104 1 "
10 000-802-081 Tapping Screw M5 x 20 4 "
11 000-804-742 Washerhead Screw M4 x 20 6 "
12 000-809-171 Nylon Cable Tie 120mm 1 "
13 OSE-354-30Z Operator's Guide 1
14 IME-354-30Z Installation Manual 1
15 OME-354-30Z Operator's Manual 1
16 000-154-025 Power Cable Assembl
Description Quantity Yes Remarks
1 CMAP configuration
3 sub SP03-14001
3"
1
Tech
Date
RDP149/NT
Box 2 - Gearbox Wt: 50 lbs. Dim: 18" x 21" x 18"
Part No.
1 RSB0070-064 Gearbox w/RTR064 4KW X'CVR 1
2 Reducer Grommet 1 inside gearbox
3 300-130-020 Corrosion Proof Mat 1
4 000-515-332 Plastic Cap 4
5 000-863-112 Hex Nut M12 4
6 000-864-132 Flat Washer M12 4
7 000-864-263 Spring Washer M12 4
8 000-862-191 Hex Bolt M12 x 60 4
9 000-863-109 Hex Nut M6 1
10 000-864-129 Flat Washer M6 3
11 000-864-260 Spring Washer M6 1
12 000-862-180 Hex Bolt M6 x 25 1
13 000-141-084 EMI Core RFC-13 3
14 000-566-000 Grounding Cable 340mm 1
Description Quantity Yes Remarks
RSB0070-064
REV 4/11
Page 1 of 2
For Internal Use Only
Serial No.4323 Checked By:
PACKING LIST FOR 1934C/NT
Box 3 - Antenna Wt: 13 lbs. Dim: 9" x 11" x 44"
Part No.
1 XN10A/3.5 3.5' Curved Face Antenna 1
2 000-851-313 80mm "O" Ring 1
3 000-854-118 "3 Bond" Adhesive 1
4 000-862-151 Hex Bolt M8 x 30 4
5 000-854-130 M8 Flat Washer 4
6 000-864-262 M8 Spring Washer 4
Box 4 - Cable Wt: 10 lbs. Dim: 16" x 17" x 15"
Part No.
1 000-140-435 15M IC Cable with Connectors 1 20, 30M available
Description Quantity Yes Remarks
Description Quantity Yes Remarks
Tech
Date
XN10A/3.5
000-140-435
REV 4/11
Page 2 of 2
