OWNER’S MANUAL

If you need additional assistance for set-up or operating after reading owner’s manual, please call

TOLL FREE : 1-800-242-7158

Please read before using this equipment.

DVD PLAYER with VIDEO CASSETTE RECORDER

WF802

INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

LASER SAFETY

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN

THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO

NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK MECHANISM.

FCC WARNING- This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY

INSERT.

ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA

FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

–2–

1L25

IMPORTANT SAFEGUARDS

FIGURE A

EXAMPLE OF ANTENNA GROUNDING

AS PER NATIONAL ELECTRICAL CODE

ANTENNA LEAD WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

NEC – NATIONAL ELECTRICAL CODE

S2898A

1. Read Instructions - All the safety and operating instructions should be read before the appliance is operated.

2. Retain Instructions- The safety and operating instructions should be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to.

4. Follow Instructions - All operating and use instructions should be followed.

5. Cleaning - Unplug this video product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

Attachments - Do not use attachments not recommended by the video product manufacturer as they may cause hazards.

7. Water and Moisture- Do not use this video product near water, for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

Accessories - Do not place this video product on

8. an unstable cart, stand, tripod, bracket, or table. The video product may fall, causing serious injury to a child or adult, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the video product. Any mounting of the appliance should follow the manufacturer's instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

9. Ventilation - Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the video product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the video product on a bed, sofa, rug, or other similar surface. This video product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have been adhered to.

10. Power Sources - This video product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.

11. Grounding or Polarization - This video product is

equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12. Power Cord Protection - Power supply cords should be

routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

13. Outdoor Antenna Grounding - If an outside antenna or

cable system is connected to the video product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with regard to

proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14. Lightning - For added protection for this video product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the video product due to lightning and power-line surges.

15. Power Lines - An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16. Overloading - Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

17. Object and Liquid Entry - Never push objects of any kind into this video product through any openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the video product.

18. Servicing - Do not attempt to service this video product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19. Damage Requiring Service - Unplug this video product from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a. When the power-supply cord or plug is damaged. b. If liquid has been spilled, or objects have fallen into the

video product.

c. If the video product has been exposed to rain or water. d.

If the video product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the video product to its normal operation.

If the video product has been dropped or damaged in any way.

f. When the video product exhibits a distinct change in per-

formance this indicates a need for service.

20. Replacement Parts - When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.

21. Safety Check - Upon completion of any service or repairs to this video product, ask the service technician to perform safety checks to determine that the video product is in proper operating condition.

22. Heat - This video product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

–3–

1L25

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of all materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

The serial number of this product may be found on the back of the DVD/VCR player. This serial number is unique to your machine. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase

Dealer Purchase from

Dealer Address

Dealer Phone No.

Model No.

Serial No.

ABOUT COPYRIGHT

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited. This product incorporates copyright protection technology that is protected by claims of certain U.S. patents and

other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

SUPPLIED ACCESSORIES

Remote control

(NA200UD)

Two AA batteries A/V cables

(approx. 3 feet (100 cm)

long) (WPZ0102TM015)

Coaxial Cable

WPZ0901TM002

SYMBOLS USED IN THIS MANUAL

The following symbols below appear in some headings and notes in this manual, with the following meanings

VCR

: refers to playback of video cassette tapes.

DVD

: refers to playback of DVD video discs.

: refers to playback of audio CDs.

MP3

: refers to playback of MP3 discs.

–4–

1L25

TABLE OF CONTENTS

■ LASER SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

■ IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . . . . . . . . . . 3

ABOUT COPYRIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

SUPPLIED ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . 4

SYMBOLS USED IN THIS MANUAL. . . . . . . . . . . . . . . . . . 4

■ FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

■ PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

■ ABOUT THE DISCS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

PLAYABLE DISCS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

DISC TYPES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

■ OPERATING CONTROLS AND FUNCTIONS. . . . . . . . . . . 9

DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

DISPLAYS DURING OPERATION . . . . . . . . . . . . . . . . . . . 12

LOADING THE BATTERIES . . . . . . . . . . . . . . . . . . . . . . . . 12

■ VIDEO/DVD SWITCHING . . . . . . . . . . . . . . . . . . . . . . . . . 13

■ HOOKUPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

DVD/VCR TO TV CONNECTION. . . . . . . . . . . . . . . . . . . . 14

SETTING THE CH3/CH4 SWITCH . . . . . . . . . . . . . . . . . . . 14

CONNECTING TO A TV . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

CONNECTING TO A TV THAT HAS AN S-VIDEO INPUT

JACK OR COMPONENT VIDEO IN JACKS. . . . . . . . . . . . 14

CONNECTING TO AN AMPLIFIER EQUIPPED WITH DIGITAL INPUT JACKS SUCH AS MD DECK OR DAT

DECK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

CONNECTING TO A DOLBY DIGITAL DECODER. . . . . . 16

CONNECTING TO AN ANALOG AUDIO. . . . . . . . . . . . . . 16

■ SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

AUTOMATIC CHANNEL SET UP. . . . . . . . . . . . . . . . . . . . 17

TO CHANGE THE ON-SCREEN LANGUAGE. . . . . . . . . . 18

CLOCK SET UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

■ PLAYBACK FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

NORMAL PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

AUTO REPEAT PLAYBACK. . . . . . . . . . . . . . . . . . . . . . . . 19

SEARCH FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

■ RECORDING FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . 20

VIEWING AND RECORDING THE SAME PROGRAM. . . 20

OTR (One Touch Recording). . . . . . . . . . . . . . . . . . . . . . . . . 20

TIMER RECORDING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

HINTS FOR TIMER RECORDING . . . . . . . . . . . . . . . . . . . 21

■ SPECIAL FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

COPYING A VIDEO TAPE. . . . . . . . . . . . . . . . . . . . . . . . . . 22

MTS (Multi-Channel Television Sound) SYSTEM . . . . . . . . 22

AUTO REWIND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

REAL TIME TAPE COUNTER. . . . . . . . . . . . . . . . . . . . . . . 23

■ PLAYING A DISC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

PLAYING A DVD VIDEO OR AN AUDIO CD . . . . . . . . . . 23

USING THE DVD MENUS . . . . . . . . . . . . . . . . . . . . . . . . . 23

USING THE TITLE MENU . . . . . . . . . . . . . . . . . . . . . . . . . 24

PAUSING PLAYBACK OR DISPLAYING A STILL

PICTURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

RESUMING PLAYBACK FROM THE POINT WHERE

PLAYBACK STOPPED . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

STEPPING THROUGH FRAMES . . . . . . . . . . . . . . . . . . . . 24

FAST FORWARD/REVERSE . . . . . . . . . . . . . . . . . . . . . . . . 25

SLOW MOTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

STARTING FROM A DESIRED TRACK . . . . . . . . . . . . . . . 25

PLAYING FROM A DESIRED TITLE OR A CHAPTER . . . 25

STARTING FROM A DESIRED TIME COUNT. . . . . . . . . . 26

MARKER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

RANDOM (Audio CD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

REPEAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

A-B REPEAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

PROGRAM (Audio CD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

ZOOM PLAYBACK (enlargement on-screen) . . . . . . . . . . . . 28

PLAYING AN MP3 DISC. . . . . . . . . . . . . . . . . . . . . . . . . . . 29

CHANGING THE ON-SCREEN DISPLAY DURING

MP3 DISC PLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

PLAYING A DESIRED TRACK FROM AN MP3 DISC . . . 30

PLAYING AN MP3 DISC RANDOMLY . . . . . . . . . . . . . . . 30

PLAYING AN MP3 DISC IN A PROGRAM. . . . . . . . . . . . . 30

■ SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

CHANGING THE AUDIO LANGUAGE OR SOUND

MODE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

CHANGING THE SUBTITLE LANGUAGE . . . . . . . . . . . . 32

CHANGING THE CAMERA ANGLE

(Multi-Angle Pictures). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

CHANGING THE ON-SCREEN DISPLAY . . . . . . . . . . . . . 33

BLACK LEVEL SETTINGS. . . . . . . . . . . . . . . . . . . . . . . . . 33

■ CHANGING THE SETUP ITEMS. . . . . . . . . . . . . . . . . . . . 34

LANGUAGE SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

DISPLAY SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

AUDIO SETTINGS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

PARENTAL LOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

■ LANGUAGE CODE LIST . . . . . . . . . . . . . . . . . . . . . . . . . . 38

■ TROUBLESHOOTING GUIDE. . . . . . . . . . . . . . . . . . . . . . 39

■ HANDLING PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . 40

DISC HANDLING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

■ SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

INDICE

■ CONTROLES DEL FUNCIONAMIENETO Y SUS FUNCIONES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

■ CAMBIO DE VCR/DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

■ CONEXIONES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

DVD/VCR A CONEXIÓN DE TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

AJUSTANDO EL CONMUTADOR CH3/CH4 CONECTANDO A UN TV CONECTADO A UN TV QUE TIENE TOMA DE ENTRADA DE S-VÍDEO o TOMAS DE ENTRADA DE VÍDEO COMPONENTE CONECTANDO A UN AMPLIFICADOR EQUIPADO CON TOMAS DE ENTRADA DIGITAL, TALES COMO PLATINA MD O PLATINA DAT CONECTANDO A UN DESCODIFICADOR DIGITALDOLBY

CONECTANDO A UN AUDIO ANALÓGICO

■

PREPARACIÓN

PREPARACIÓN DE CANAL AUTOMÁTICA PREPARACIÓN DE RELOJ

■ REPRODUCCIÓN DE UN DISCO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

REPRODUCIENDO UN DVD, VIDEO O UN CD AUDIO

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

. . . 46

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

–5–

. 46

1L25

FEATURES

DVD

¡Dolby Digital sound

Mode

This player can handle Dolby Digital surround sound with 5.1 channels when connected to a Dolby Digital decoder.

¡Still/fast/slow/step playback

Various playback modes are available including still pictures, fast forward/reverse, slow motion and step frames.

¡Random playback for audio CD and MP3

This player can shuffle the order of tracks to play them in random order.

¡Program playback for audio CD and MP3

You can program the order of tracks to play them in any desired order.

¡DVD menus in a desired language

You can display DVD menus in the desired language, if available on the DVD.

¡Screen saver/Auto power-off functions

The screen saver program starts when there is no input from the player for five minutes in the stop mode. When the screen saver program has been activated for 30 minutes, the screen saver is automatically turned off.

¡Subtitles in a desired language

You can select the desired language for the subtitle display, if that language is available on the disc.

¡Selecting a camera angle

You can select the desired camera angle, if the disc contains sequences recorded from different angles.

¡Choices for audio language and sound mode

You can select the desired audio language and sound mode, if different languages and modes are available on the disc.

¡Parental lock

You can set the control level to limit playback of discs which may not be suitable for children.

¡Automatic detection of discs

This player automatically detects if the loaded disc is DVD, audio CD or MP3 on disc.

¡Playing an MP3 disc

You can enjoy MP3 files which are recorded on CDR/RW.

¡Direct Search

You can search for the desired title, chapter, and track with the Number buttons during playback or in stop mode.

¡On-screen display

Information about the current operation can be displayed on the TV screen, allowing you to confirm the currently active functions (such as program playback), on the TV screen using the remote control.

¡Search

Chapter search

: Search for a chapter designated by user is

possible.

Title search: Search for a title designated by user is pos-

sible.

Track search: Search for a track designated by user is

possible.

Time search: Search for a time designated by user is

possible.

¡Repeat

Chapter: Repeated playback of the chapter of the

disc being played is possible.

Title: Repeated playback of the title of the disc

being played is possible.

Track: Repeated playback of the track of the disc

being played is possible.

Disc

(audio CD)

: Repeated playback of the entire disc being

(MP3) played is possible.

A-B: Playback of the section between A and B

(designated by user) is possible.

Album: Repeated playback of the album of the

MP3 disc being played is possible.

¡Zoom

A ×2 and ×4 magnified screen can be displayed.

¡Marker

A part designated by user can be called back.

¡Resume Play

User can resume playback from the part at which the play was stopped even if the power is turned off.

¡Dimmer

Brightness of the display can be varied.

¡Bit rate indication ¡DRC (Dynamic range control)

You can control the range of sound volume.

–6–

1L25

VCR

Mode

Hardware specifications

¡Auto Head Cleaner ¡4 Head HiFi Stereo ¡Bilingual on-screen menu display selectable in

English, French, or Spanish

¡181 channel capability PLL frequency synthesiz-

er tuner with direct station call

(A cable converter box may be necessary to view scrambled cable channels.)

Automatic functions

¡Auto power on system

Automatically turns the DVD/VCR on when you insert the cassette.

¡Digital Auto Tracking (DTR)

PRECAUTIONS

Playback

¡S-VHS Quasi Playback (SQPB)

(Allows you to view a tape recorded in S-VHS format.)

¡Auto Repeat ¡2 Step Picture Search Operation ¡Index Search ¡Time Search

Recording

¡1 Year, 7 events (including Daily and Weekly Timer

Recording)

¡OTR (One Touch Recording)

INSTALLATION LOCATION

For safety and optimum performance of your DVD/VCR:

• Install the DVD/VCR in a horizontal and stable position. Do not place anything directly on top of the DVD/VCR. Do not place the DVD/VCR directly on top of the TV.

• Shield it from direct sunlight and keep it away from sources of intense heat. Avoid dusty or humid places. Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes on the sides of the DVD/VCR. Avoid locations subject to strong vibration or strong magnetic fields.

AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE

• Do not handle the power cord with wet hands.

• Do not pull on the power cord when disconnecting it

from AC wall outlet. Grasp it by the plug.

• If, by accident, water is spilled on your DVD/VCR, unplug the power cord immediately and take the unit to our Authorized Service Center for servicing.

• Do not put your fingers or objects into the DVD/VCR cassette holder.

MOISTURE CONDENSATION WARNING

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, or after heating a cold room or under conditions of high humidity. Do not use the DVD/VCR at least for 2 hours until its inside is dry.

–7–

1L25

ABOUT THE DISCS

DVD

Video

12 cm

Approx. 4 h

(single-sided)

Approx. 80 min

(single-sided)

8 cm

Logo

Maximum

Playback Time

ContentsDisc Type

Sound

and

Pictures

Disc Size

74 min

Approx. 8 h

(double-sided)

Approx. 160 min

(double-sided)

12 cm

20 min

8 cm

(singles)

Audio

Sound

Example

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1 Chapter 2Chapter 3 Chapter 4

Example

Track 1 Track 2 Track 3 Track 4 Track 5 Track 6

Example

Album 1 Album 2

Track 1 Track 2 Track 1 Track 2Track 3 Track 4

PLAYABLE DISCS

The following discs can be played back on this DVD/VCR.

This player conforms to the NTSC color system. You cannot play discs recorded in other color systems such as PAL or SECAM.

¡Some discs include region codes as shown below.

¡The number inside the symbol refers to a region of the

world, and a disc encoded in a specific region format can only be played back on DVD/VCR with the same region code.

The following discs cannot be played back on this DVD/VCR.

DVD with region codes other than 1 or ALL.

DVD-ROM

DVD-RAM (Never attempt to play back, otherwise a malfunction may result.)

CD-ROM

VSD

CDV (Only plays back the audio part.)

CD-G (Only plays back the sound.)

CD-R/CD-RW (Only plays back discs on which audio CD or MP3 are recorded.)

CD-I (Never attempt to play back, otherwise a malfunction may result.)

SACD

Photo CD (Never attempt to play back, otherwise a malfunction may result.)

Video CD (Never attempt to play back, otherwise a malfunction may result.)

Any other discs without compatibility indications

DISC TYPES

[

]

DVD

Data on a DVD is divided into sections called "titles", and then into subsections called "chapters", each of which is given a title or chapter number. Playback conditions are preset on some DVD video discs, and these playback conditions take priority over user operations on this player. If a function you selected does not run as desired, refer to the manual accompanying the disc.

[

AUDIO CD

Data on an audio CD is divided into sections called “tracks”, each of which is given a track number.

[

MP3

Data on an MP3 is divided into sections called "albums", and then into subsections called "tracks", each of which is given an album or track number.

–8–

]

1L25

OPERATING CONTROLS AND FUNCTIONS

OPEN/CLOSE

STOP SKIP/REV PLAY FWD/SKIP

STOP/EJECT

REW PLAY F.FWD REC/OTR

POWER

VIDEO

AUDIO

TIMER

SET

VCR/TV

CST.IN

CHANNEL

OUTPUT

1 2 3 64 87 9

242322212019181716

1113

12510

DVD OPERATION VCR OPERATION

FRONT PANEL

REMOTE CONTROL

POWER

SPEED AUDIO

123

456

789

010

DVD VCR

DISPLAY

+100

SKIP/CH.

VCR/TV

SLOW

PAUSE

35 37 39

36 38

RECORD

SETUP

SUBTITLE

ZOOMMODE

ANGLE

PLAY

STOP

ENTER

MODE

REPEAT

RETURNTITLE

CLEAR/

C.RESET

A-B

1. Disc loading tray

2. DVD OUTPUT Light (Green) [page 13]

This light appears when the DVD output mode is selected. You can only watch DVDs when the green DVD OUTPUT Light is on. To make the green DVD OUTPUT light come on, press the DVD button on the remote control or the OUTPUT button on the front panel.

3. VCR OUTPUT Light (Green) [page 13]

This light appears when the VCR output mode is selected. You can only watch tapes when the green VCR OUTPUT light is on. To make the green VCR OUTPUT light come on, the VCR button on the remote control or the OUTPUT button on the front panel.

4. CASSETTE COMPARTMENT

5. REC/OTR Light [page 20]

Lights up during recording.

6. TIMER SET Light [page 20]

This light glows when the DVD/VCR is in standby mode or off for a timer recording or during a OneTouch Recording. It flashes if the TIMER SET button is pressed for a timer recording, but there is no

tape in the DVD/VCR. It flashes when all timer recordings or One-Touch Recordings are finished.

7. POWER Button [page 17]

Press to turn the power on and off.

8. POWER Light

Lights up when the power is on.

9. VIDEO In Jack

Connect a video cable coming from the video out jack of a camcorder, another VCR, or a video source (laser disc player, camcorder, etc.) here.

10. AUDIO In Jacks

Connect audio cables coming from the audio out jacks of a camcorder, another VCR, or an audio source here.

11. TIMER SET Button [page 21]

Press to put the DVD/VCR into standby mode for a timer recording.

12. CST IN Light [page 19]

Lights up when a cassette is in the DVD/VCR.

13. VCR/TV Light [page 17]

Lights up when the DVD/VCR is in the VCR position, and goes off when it is in the TV position.

14. CHANNEL Buttons [page 17]

In VCR mode, press to change TV channels on the DVD/VCR; press to adjust the tracking during normal or slow motion playback; press to remove vertical jitter in a Still picture.

15. REC/OTR Button (VCR) [page 20]

Press once to start a recording. Press repeatedly to start a One-Touch Recording.

16. F.FWD Button (VCR) [page 17]

Press to rapidly advance the tape, or view the picture rapidly in forward during playback. (Forward Search). When setting program (For example:setting clock or timer program), press to determine your selection and proceed to the next step you want to input. Press to determine the setting modes from the on screen menu. Press to add or delete channel numbers during channel preset.

17. PLAY Button (VCR) [page 17]

Press to begin playback. Press to enter digits when setting program (For example: setting clock or timer program). Press to select the setting modes from the on screen menu.

18. REW Button (VCR) [page 18]

–

9 –

1L25

example: setting clock or timer program). Press to add or delete channel numbers during channel preset.

19.

STOP/EJECT Button (VCR) [

page 21

]

●EJECT Button

Press to remove the tape from the VCR.

● STOP Button

Press to stop the tape motion. Press to enter digits when setting program (For example:setting clock or timer program). Press to select the setting modes from the on screen menu.

20. OUTPUT Button [page 13]

Press to select DVD mode or VCR mode.

●

You can switch the output mode either by pressing the OUTPUT button on the front panel, or by pressing the DVD or the VCR button on the remote control. However,

if you press the OUTPUT button on the front panel first, you need to re-select the corresponding mode by pressing the DVD or the VCR button on the remote control.

21.

FWD/SKIP Button (DVD) [page 25]

Plays back from the beginning of the next chapter or track. Hold down to fast forward playback.

22. PLAY Button (DVD) [page 23]

Press to begin playback.

23. SKIP/REV Button (DVD) [page 25]

Plays back from the beginning of the current chapter or track. Hold down to fast reverse playback.

24. STOP Button (DVD) [page 23]

Stops operation of the disc.

25. OPEN/CLOSE Button [page 23]

Press to insert discs into or remove them from the tray.

26. Display, Remote Sensor Window

27. SPEED Button [page 20]

Press to select the VCR’s recording speed (SP or SLP)

28. POWER Button

Press to turn the power on and off.

29. Number Buttons

● DVD mode [page 25]

Press to directly select a Track (Audio CD) for playback. Press to program Tracks (Audio CD) for playback.

● VCR mode [page 17]

Press to select TV channels on the DVD/VCR. To select channels, enter channel numbers as a two-digit number for the quickest results. For example, to select channel 6, press 0 then 6.

+100 Button:

If you want to select channels 100 and above, press this button first, then press the last two digits. For example, to select channel 125, press +100 button first, then press 2 and 5.

30. DISPLAY Button

● DVD mode [page 29]

Press to access or remove the display screen during DVD or Audio CD playback.

● VCR mode [page 22]

Press to access or remove the VCR’s on-screen sta- tus display.

31. DVD Button [page 13]

Press to select DVD mode for the remote control.

● You can switch the OUTPUT mode either by

pressing the OUTPUT button on the front panel, or by pressing the DVD or the VCR button on the remote control. However,

if you press the OUTPUT

button on the front panel first, you need to re-

select the corresponding mode by pressing the DVD or the VCR button on the remote control.

32.

h Button

● DVD mode

Press to view the DVD picture in fast reverse motion or to reverse playback of an Audio CD.

● VCR mode

Press to rewind the tape, or to view the picture rapidly in reverse during the playback mode (Rewind Search). Press to cancel a setting of timer program. Press to correct digits when setting program (For example: setting clock or timer program). Press to add or delete channel numbers during channel preset.

33. STOP Button

● DVD mode

Press to stop the disc motion.

● VCR mode

Press to stop the tape motion. Press to enter digits when setting program (For example: setting clock or timer program). Press to select the setting modes from the on screen menu.

34. RECORD Button

Press to start a recording.

35. MENU Button

● DVD mode [page 23]

Press to display the menu of the Disc.

● VCR mode [page 17]

Press to access the VCR menu.

36. TITLE Button [page 24]

37. SETUP Button [page 34]

Press to enter the setup mode.

38. ZOOM Button [page 28]

Enlarges part of a DVD-reproduced image.

39. MODE Button [pages 19]

Activates program playback or random playback mode when playing CDs or MP3. Sets Black level.

40. SUBTITLE Button [page 32]

Press to select the desired subtitle language.

41. ANGLE Button [page 32]

Press to change the camera angle to see the sequence being played back from a different angle.

42. REPEAT Button [page 27]

Repeats playback of the current disc, title, chapter or track.

43. A-B REPEAT Button [page 27]

Repeats playback of a selected section.

44. SEARCH MODE Button

● DVD mode [page 25]

Press to access or remove the Search display, which allows you to go directly to a specific Title/Chapter/Track/Time.

● VCR mode [page 19]

Press to perform a Time Search or an Index Search.

45. CLEAR/C.RESET Button

● DVD mode [page 26]

Press to reset the setting.

● VCR mode [page 18]

Press to reset the counter. Press to exit from the MENU screen.

46. RETURN Button

Returns to the previous operation.

47. Arrow Buttons

Use when making settings while watching the display on a TV screen.

48. ENTER Button

–10–

1L25

Press to accept a setting.

ANT - IN

DVD/VCR

OUT

DVD/VCR

AUDIO OUT

COAXIAL

S-VIDEO

OUT

DIGITAL AUDIO OUT PCM / BITSTREAM

AUDO

VIDEO

CH3 CH4

ANT - OUT

666564 63

5857 59

49. g Button

● DVD mode

Press to fast forward the Disc. Press the Pause button, then press the FWD button to begin slow motion playback. Press the FWD button repeatedly to change the forward speed of slow motion.

● VCR mode

Press to rapidly advance the tape, or view the picture rapidly in forward during playback (Forward Search). When setting program (For example: setting clock or timer program), press to determine your selection and proceed to the next step you want to input. Press to determine the setting modes from the on screen menu. Press to add or delete channel numbers during channel preset.

50. PLAY Button

● DVD mode

Press to begin playback.

● VCR mode

Press to begin playback. Press to enter digits when setting program (For example: setting clock or timer program). Press to select the setting modes from the on screen menu.

51. VCR Button [page 13]

Press to select VCR mode for the remote control.

● You can switch the OUTPUT mode either by

pressing the OUTPUT button on the front panel, or by pressing the DVD or the VCR button on the remote control. However,

if you press the OUTPUT button on the front panel first, you need to reselect the corresponding mode by pressing the DVD or the VCR button on the remote control.

52.

PAUSE Button

● DVD mode [page 24]

Press to pause Disc playback. Press repeatedly to advance the DVD picture step by step (or one frame at a time).

● VCR mode [page 19]

While recording, press to temporarily stop the recording (pause). Press a second time to resume normal recording. You can not pause a One-Touch Recording. Or, press during tape playback to freeze the picture. Press to advance the picture one

frame at a time during still mode.

53. SLOW Button [page 19]

During tape playback, press to view the video tape in slow motion. Press again to resume normal playback. This button does not affect DVD playback.

54. VCR/TV Button [page 21]

Use to select VCR or TV position. If the VCR/TV light appears on the front of the DVD/VCR, it is in VCR position (in either VCR or DVD mode). If the VCR/TV light doesn’t appear on the front of the DVD/VCR, it is in TV position.

● VCR Position

When the green VCR OUTPUT light appears on the front of the DVD/VCR, use the VCR to watch a tape, watch a TV program while recording it, or watch a TV broadcast using the CHANNEL or the Number buttons to change channels at the DVD/VCR. When the green DVD OUTPUT light appears on the front of the DVD/VCR, use the DVD/VCR to view Disc playback or menus.

● TV Position

Use to watch TV (changing channels at the TV) or watch one program while recording another.

55. SKIP/CH. Buttons

● DVD mode

Press to skip Chapters or Tracks.

● VCR mode

Press to change TV channels on the DVD/VCR.

56. AUDIO Button [page 31]

Press to select a desired audio language or sound mode.

57. AC Power Cord

Notes

¡To use the remote control to operate the DVD/VCR

and its features, press the DVD button on the remote control before pressing other DVD buttons. Verify that the green DVD OUTPUT Light is on.

¡To use the remote control to operate the VCR and its

features, press the VCR button on the remote control before pressing other VCR buttons. Verify that the green VCR OUTPUT Light is on.

REAR VIEW

Connect to a standard AC outlet to supply power to the DVD/VCR.

58. AUDIO IN Jacks

–11–

Connect audio cables coming from the audio out jacks of a camcorder, another VCR, or an audio source here.

59. DVD/VCR AUDIO OUT Jacks

1L25

Lit when the inserted disc is being played back.

Lights up when a CD is inserted on the tray.

Lights up when a DVD is inserted into the tray.

Lights up when the inserted disc comes to a pause.

Lit when the A-B repeat function is on.

Lit when the repeat function is on.

Displays how long the current title or track has been playing. When a chapter or track is switched, the number of the new title, chapter or track is displayed.

Power on

No disc inserted

Tray open

Tray closed

Loading the Disc

Power off

Connect the supplied audio cables here and to the Audio In jacks of a television or other audio equipment.

60. COAXIAL Jack

Connect an optional coaxial digital audio cable here and to the Coaxial Digital Audio In jack of a decoder or audio receiver.

61. S-VIDEO OUT Jack

Connect an optional S-Video cable here and to the S-Video In jack of a television.

62. DVD/VCR VIDEO OUT Jack

Connect the yellow video cable (supplied) here and to the TV’s Video In jack.

63. VIDEO IN Jack

Connect a cable coming from the video out jack of a camcorder, another VCR, or an audio-visual source (laser disc player, video disc player, etc.) here.

64. CH3/CH4 Switch

Set to channel 3 or 4 to use your TV with your DVD/VCR.

65. ANT-IN (Antenna In) Jack

Connect your antenna, Cable Box, or Direct Broadcast System.

66. ANT-OUT (Antenna Out) Jack

Use the supplied RF coaxial cable to connect this jack to the ANTENNA IN Jack on your TV.

Notes

¡The S-VIDEO OUT jack, COAXIAL jack, and

OPTICAL jack are only useful in DVD mode.

DISPLAY

DISPLAYS DURING

OPERATION

LOADING THE BATTERIES

1. Open the battery compartment cover.

2. Insert two AA batteries, with each one oriented correctly.

3. Close the cover.

Notes

¡Do not mix alkaline and manganese batteries. ¡Do not mix old and new batteries.

–12–

1L25

VCR/DVD SWITCHING

STOP/EJECT

REW

OUTPUT

Since this product comprises VCR and DVD players, it is necessary to select the correct output mode.

SWITCHING TO VCR MODE

Press the VCR button on the remote control.

(Verify that the VCR OUTPUT Light is lit.)

SWITCHING TO DVD MODE

Press the DVD button on the remote control.

(Verify that the DVD OUTPUT Light is lit.)

Notes

¡Pressing only the OUTPUT button on the front panel does not switch the mode of the remote control. You

always need to select the correct mode on the remote control too.

POWER

OPEN/CLOSE

OUTPUT

DVD OPERATION VCR OPERATION

STOP SKIP/REV PLAY FWD/SKIP

STOP/EJECT

CHANNEL

TIMER

SET

VCR/TV

REW PLAY F.FWD REC/OTR

CST.IN

DVD OUTPUT Light

VCR OUTPUT Light

VIDEO

AUDIO

DVD button

VCR button

SPEED AUDIO

POWER

123

456

789

+100

010

DVD VCR

DISPLAY

PLAY

SKIP/CH.

VCR/TV

SLOW

PAUSE

OUTPUT button

–13–

RECORD

SETUP

SUBTITLE

ZOOMMODE

ANGLE

STOP

ENTER

MODE

REPEAT

RETURNTITLE

CLEAR/

C.RESET

A-B

1L25

ANT - IN

DVD/VCR

OUT

DVD/VCR

AUDIO OUT

COAXIAL

S-VIDEO

OUT

DIGITAL AUDIO OUT PCM / BITSTREAM

AUDO

VIDEO

CH3 CH4

ANT - OUT

To S-VIDEO OUT jackTo S-VIDEO INPUT jack

To Right (red) and Left (white)

AUDIO OUT jacksAUDIO INPUT jacks

A/V-compatible or

wide screen TV

ANT - IN

DVD/VCR

OUT

DVD/VCR

AUDIO OUT

COAXIAL

S-VIDEO

OUT

DIGITAL AUDIO OUT PCM / BITSTREAM

AUDO

VIDEO

CH3 CH4

ANT - OUT

A/V-compatible or

wide screen TV

To VIDEO OUT jack

To VIDEO INPUT jack

To Right (red) and Left (white)

Antenna/Cable signal

To ANT. IN

of TV

AUDIO INPUT jacks

AUDIO OUT jacks

ANT - IN

CH3 CH4

ANT - OUT

[VHF/UHF combination antenna]

[Back of the DVD/VCR]

OUT

[Cable box or satellite box]

[Indoor antenna]

[Back of the

UHF/VHF combination TV]

UHF/VHF

Coaxial cable

(supplied)

From Cable or Satellite Company

HOOKUPS

DVD/VCR TO TV CONNECTION

1. Disconnect the AC power cord of the TV from the AC outlet.

2. Disconnect the antenna or cable from the TV.

3. Connect the antenna or cable to the ANT-IN jack of the DVD/VCR.

4. Connect the DVD/VCR to the TV using the coaxial cable.

5. Plug the AC power cords of the DVD/VCR and TV into the AC outlets.

If your TV does not have A/V terminals:

When the DVD/VCR is in the VCR Playback mode or when the DVD/VCR is in the VCR mode, your TV will receive signals from the DVD/VCR on either channel 3 or channel 4. To use the DVD/VCR with your TV, set the selector switch to CH3 or CH4 (which is located in the back of your DVD/VCR), whichever is not used for normal broadcasts in your area. Then set your TV to the same channel.

SETTING THE CH3/CH4

SWITCH

ANT - IN

ANT - OUT

CH4

CH3

[Back of the DVD/VCR]

CH3 CH4

Note to CATV system installer

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground should be connected to the grounding system of the building, as close to the point of cable entry as practical.

CONNECTING TO A TV

Notes

¡Connect the DVD/VCR directly to a TV. If the A/V cables are connected to a VCR, pictures may be

distorted due to the copy protection system.

CONNECTING TO A TV THAT HAS AN

S-VIDEO INPUT JACK OR COMPONENT VIDEO IN JACKS

FOR TVs WITH S-VIDEO INPUT JACK

Use an S-Video cable (commercially available) in place of the yellow video cable to enjoy higher quality pictures. The S-Video connection only supplies video (picture) in the DVD mode of the DVD/VCR. Therefore, in order to use the VCR features or view TV channels on the DVD/VCR, you still need to either connect the RF coaxial cable between the ANT-OUT jack of the DVD/VCR and the TV’s Antenna In jack, or connect the yellow video cable as described earlier (Fig.1). To connect the supplied RF coaxial cable, see “DVD/VCR TO TV CONNECTION” above.

–14–

[Fig. 1]

[Fig. 2]

1L25

CONNECTING TO AN AMPLIFIER EQUIPPED WITH DIGITAL

Amplifier equipped with digital

input jacks, MD deck,

DAT deck, etc.

ANT - IN

DVD/VCR

OUT

DVD/VCR

AUDIO OUT

COAXIAL

S-VIDEO

OUT

DIGITAL AUDIO OUT PCM / BITSTREAM

AUDO

VIDEO

CH3 CH4

ANT - OUT

To COAXIAL DIGITAL AUDIO INPUT jack

To COAXIAL DIGITAL AUDIO OUT jack

INPUT JACKS SUCH AS MD DECK OR DAT DECK

Use an audio coaxial digital cables (not included) for the audio connections. Connecting to an amplifier equipped with digital input jacks such as MD Deck or DAT Deck.

[Fig. 4]

Notes

¡The audio source on a disc in the 5.1 channel Dolby Digital surround format cannot be recorded as digital

sound by an MD or DAT deck.

¡Be sure to turn off the power to all components in the system before connecting another component. ¡Refer to the Owner’s Manuals for the components to be connected to the DVD/VCR. ¡Set Dolby Digital to off for audio output in the setup mode. Playing a DVD disc using incorrect settings may

generate noise distortion, and may also damage the speakers. (See page 36 to set Dolby Digital to on)

–15–

1L25

+ 34 hidden pages
