FUNAI SSF420TR User Manual

Download

OWNER’S

As an ENERGY STAR

Partner, our company has determined that this product meets the E

NERGY STAR guidelines for

energy efficiency. E

NERGY STAR

is a U.S. registered mark.

MANUAL

COLOR TV/VCR/DVD TRIPLE COMBO

SSF420TR

(20 inch)

INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

SUPPLIED ACCESSORIES

ACCESSORIES Remote Control Unit Batteries Owner’s Manual 1EMN20126

If you need additional operating assistance after reading this owner’s manual, please call

TOLL FREE : 1-800-968-3429.

Please read before using this equipment

PA RT NO. NE236UD 2 AA Batteries

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE

TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The caution marking is located on the rear of the cabinet.

IMPORTANT SAFEGUARDS

1.Read instructions-All the safety and operating instructions

should be read before the appliance is operated.

2.Retain Instructions-The safety and operating instructions should be retained for future reference.

3.Heed Warnings-All warnings on the appliance and in the operating instructions should be adhered to.

4.Follow Instructions-All operating and use instructions should be followed.

5.Cleaning-Unplug TV/VCR/DVD from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6.Attachments-Do not use attachments not recommended by the TV/VCR/DVD manufacturer as they may cause hazards.

7.Water and Moisture-Do not use this TV/VCR/DVD near water-for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8.Accessories-Do not place this TV/VCR/DVD on an unstable cart, stand, tripod, bracket, or table. The TV/VCR/DVD may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the TV/VCR/DVD. Any mounting of the appliance should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care.Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

PORTABLE CART WARNING

S3126A

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

AMEUBLES- Cet appareil ne doit être placé que sur un meuble (avec ou sans roulettes) recommandé par le fabricant. Si vous l’installez sur un meuble à roulettes, déplacez les deux ensembles avec précaution. Un arrêt brusque, l’utilisation d’une force excessive et des surfaces irrégulières risquent de déstabiliser l’ensemble et de le renverser.

9. Ventilation-Slots and openings in the cabinet and the back or bottom are provided for ventilation and to ensure reliable operation of the TV/VCR/DVD and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the TV/VCR/DVD on a bed, sofa, rug, or other similar surface. This TV/VCR/DVD should never be placed near or over a radiator or heat register. This TV/VCR/DVD should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10.Power Sources-This TV/VCR/DVD should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For TV/VCR/DVDs intended to operate from battery power, or other sources, refer to the operating instructions.

11.Grounding or Polarization-This TV/VCR/DVD is equipped with a polarized alternating-current line plug(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12.Power-Cord Protection-Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

SYMBOLE D'AVERTISSEMENT POUR

LES COMPOSANTES

APPAREIL ET MEUBLE A ROULETTES

S3126A

- 2 - EN

1B15

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE

S2898A

FIGURE A

ELECTRIC SERVICE EQUIPMENT

NEC - NATIONAL ELE CTRI CAL CO DE

GROUND

CLAMP

ANTENNA

L EAD IN WIRE

ANTENNA

DISCHARGE UNI T (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDI NG ELECTRODE SYSTEM (NEC ART 250, PART H)

13.Outdoor Antenna grounding-If an outside antenna or cable system is connected to the TV/VCR/DVD, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14.Lightning-For added protection for this TV/VCR/DVD receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV/VCR/DVD due to lightning and power-line surges.

15.Power Lines-An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16.Overloading-Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

17.Object and Liquid Entry-Never push objects of any kind into this TV/VCR/DVD through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the TV/VCR/DVD.

18.Servicing-Do not attempt to service this TV/VCR/DVD yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19.Damage Requiring Service-Unplug this TV/VCR/DVD from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a. When the power-supply cord or plug is damaged or frayed. b. If liquid has been spilled, or objects have fallen into the

TV/VCR/DVD.

c. If the TV/VCR/DVD has been exposed to rain or water. d. If the TV/VCR/DVD does not operate normally by follow-

ing the operating instructions. Adjust only those controls that are covered by the operating instructions, as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the TV/VCR/DVD to its normal operation.

e. If the TV/VCR/DVD has been dropped or damaged in any

way.

f. When the TV/VCR/DVD exhibits a distinct change in per-

formance-this indicates a need for service.

20.Replacement Parts-When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, injury to persons or other hazards.

21.Safety Check-Upon completion of any service or repairs to this TV/VCR/DVD, ask the service technician to perform routine safety checks to determine that the TV/VCR/DVD is in proper operating condition.

22.Heat-This TV/VCR/DVD product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

- 3 - EN

1B15

PRECAUTIONS

IMPORTANT COPYRIGHT INFORMATION

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

FCC WARNING- This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

LASER SAFETY

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK MECHANISM.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

CAUTION: TO PREVENT ELECTRIC SHOCK,

MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

- 4 - EN

1B15

LOCATION

For safe operation and satisfactory performance of your TV/VCR/DVD, keep the following in mind when selecting a place for its installation:

Shield it from direct sunlight and keep it away from

•

sources of intense heat. Avoid dusty or humid places.

•

Avoid places with insufficient ventilation for proper

•

heat dissipation. Do not block the ventilation holes at the top or bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.

Install unit in a horizontal position.

•

Avoid locations subject to strong vibration.

•

Do not place the TV/VCR/DVD near strong magnetic

•

fields. Avoid moving TV/VCR/DVD to locations where

•

temperature differences are extreme.

AV OID THE HAZARDS OF

ELECTRICAL SHOCK AND FIRE

Do not handle the power cord with wet hands.

•

Do not pull on the power cord when disconnecting

•

it from an AC wall outlet. Grasp it by the plug. If by accident, water is spilled on your unit, unplug

•

the power cord immediately and take the unit to a Authorized Service Center for servicing.

Do not put your fingers or objects into the

•

TV/VCR/DVD disc loading tray. Do not place anything directly on top of the unit.

•

WARNING

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place or after heating a cold room or under conditions of high humidity. If a DVD is played in a TV/VCR/ DVD which has moisture, it may damage the DVD and TV/VCR/DVD. Therefore when the condensation occurs inside the unit, turn the POWER on and allow at least 2 hours for the unit to dry out.

SYMBOLS USED IN THIS MANUAL

The following symbols below appear in some headings and notes in this manual, with the following meanings

TV/VCR

: Description refers to TV/VCR operation (in the

TV/VCR mode).

DVD-V

: Description refers to playback of DVD video discs

(in the DVD mode).

: Description refers to playback of audio CDs

(in the DVD mode).

QUICK

: Description refers to the items to be set by the

QUICK mode (in the DVD mode).

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

The serial number of this product may be found on the back of the unit. No other TV/VCR/DVD has the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase Dealer Purchase from Dealer Address Dealer Phone No. Model No. Serial No.

- 5 - EN

1C29

TABLE OF CONTENTS

C IMPORTANT SAFEGUARDS . . . . .2

C PRECAUTIONS . . . . . . . . . . . . . . . .4

LOCATION . . . . . . . . . . . . . . . . . . .5

AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE .5

WARNING . . . . . . . . . . . . . . . . . . . .5

SYMBOLS USED IN THIS

MANUAL . . . . . . . . . . . . . . . . . . . . .5

C TABLE OF CONTENTS . . . . . . . . . .6

C FEATURES . . . . . . . . . . . . . . . . . . . .7

C OPERATING CONTROLS AND

FUNCTIONS . . . . . . . . . . . . . . . . . . .9

C PREPARATION FOR USE . . . . . . .11

ANTENNA/CABLE

CONNECTION . . . . . . . . . . . . . . . .11

CONNECTING TO EXTERNAL

INPUT JACKS . . . . . . . . . . . . . . . .12

INSTALLING THE BATTERIES . .12

EXTERNAL INPUT MODE . . . . . .12

CONNECTING TO A STEREO RECEIVER EQUIPPED WITH

DIGITAL INPUT JACKS . . . . . . . .13

CONNECTING TO RECEIVER WITH A DOLBY DIGITAL

DECODER (for DVD) . . . . . . . . . .14

TV/VCR SECTION

C SET UP FOR USE . . . . . . . . . . . . .15

SELECTING THE LANGUAGE . .15 CLOCK SET UP

(AUTO / MANUAL) . . . . . . . . . . . .15

DAYLIGHT-SAVING TIME . . . . . .17

CHANNEL SET UP . . . . . . . . . . . .18

DELETING (OR ADDING)

CHANNEL(S) . . . . . . . . . . . . . . . . .18

C TV OPERATION . . . . . . . . . . . . . . .19

WATCHING A TV PROGRAM . . .19

DEGAUSSING . . . . . . . . . . . . . . . .19

PICTURE CONTROL . . . . . . . . . . .19

CLOSED CAPTION SYSTEM . . . .20

V-CHIP SET UP . . . . . . . . . . . . . . .21

C MTS(Multi-Channel Television

sound)SYSTEM . . . . . . . . . . . . . . . .23

CHECKING THE SELECTED

MTS MODE . . . . . . . . . . . . . . . . . .23

MTS RECORDING/MONITOR

MODE . . . . . . . . . . . . . . . . . . . . . .23

SELECTING THE MTS SYSTEM .24

C VIDEO CASSETTE . . . . . . . . . . . . .25

C PLAYBACK . . . . . . . . . . . . . . . . . . .26

NORMAL PLAYBACK . . . . . . . . .26

TRACKING ADJUSTMENT . . . . .26

SLOW MOTION . . . . . . . . . . . . . .26

STILL PICTURE . . . . . . . . . . . . . .26

VERTICAL HOLD CONTROL . . .26

C SPECIAL PLAYBACK . . . . . . . . . .27

RENTAL PLAYBACK . . . . . . . . . .27

AUTO REPEAT PLAYBACK . . . . .27

C SEARCH . . . . . . . . . . . . . . . . . . . . .28

ZERO RETURN . . . . . . . . . . . . . . .28

PICTURE SEARCH . . . . . . . . . . . .28

TIME SEARCH . . . . . . . . . . . . . . .28

INDEX SEARCH . . . . . . . . . . . . . .29

C SPECIAL FEATURES . . . . . . . . . .29

REAL TIME TAPE COUNTER . . .29

AUTO REWIND-EJECT . . . . . . . .29

C RECORDING . . . . . . . . . . . . . . . . .30

NORMAL RECORDING . . . . . . . .30

SKIPPING UNWANTED SCENES

DURING RECORDING . . . . . . . . .30

OTR (One Touch Recording) . . . . . .31

COPYING A VIDEO CASSETTE (Requires a VCR or camcorder) . . .31

C TIMER . . . . . . . . . . . . . . . . . . . . . .32

AUTOMATIC

TIMER RECORDING . . . . . . . . . .32

TIMER PROGRAM EXTENSION .33 HINTS FOR AUTOMATIC TIMER

RECORDING . . . . . . . . . . . . . . . . .34

AUTO RETURN . . . . . . . . . . . . . . .34

SLEEP TIMER . . . . . . . . . . . . . . . .34

C ON SCREEN DISPLAY . . . . . . . . .35

C CABLE CHANNEL

DESIGNATIONS . . . . . . . . . . . . . .35

DVD SECTION

C ABOUT THE DISCS . . . . . . . . . . . .36

PLAYABLE DISCS . . . . . . . . . . . .36

DISC TYPES . . . . . . . . . . . . . . . . .36

C PLAYING A DISC . . . . . . . . . . . . . .37

BASIC PLAYBACK . . . . . . . . . . . .37

GENERAL FEATURES . . . . . . . . .37

DISC MENU . . . . . . . . . . . . . . . . .37

TITLE MENU . . . . . . . . . . . . . . . . .37

RESUME . . . . . . . . . . . . . . . . . . . .38

PAUSE . . . . . . . . . . . . . . . . . . . . . .38

STEP BY STEP PLAYBACK . . . . .38

FAST FORWARD/REVERSE

SEARCH . . . . . . . . . . . . . . . . . . . .38

SLOW FORWARD / SLOW

REVERSE . . . . . . . . . . . . . . . . . . . .38

C SEARCH FUNCTION . . . . . . . . . . .39

TRACK SEARCH . . . . . . . . . . . . .39

TITLE / CHAPTER SEARCH . . . .39

TIME SEARCH . . . . . . . . . . . . . . .39

MARKER SETUP SCREEN . . . . . .39

SPECIAL PLAYBACK FUNCTION . . .40

REPEAT . . . . . . . . . . . . . . . . . . . . .40

PROGRAM . . . . . . . . . . . . . . . . . . .40

RANDOM PLAYBACK . . . . . . . . .40

C CHANGING THE SETTINGS . . . .41

SUBTITLE LANGUAGE . . . . . . . .41

AUDIO LANGUAGE . . . . . . . . . . .41

STEREO SOUND MODE . . . . . . . .41

CAMERA ANGLE . . . . . . . . . . . . .41

BLACK LEVEL SETTING . . . . . . .41

VIRTUAL SURROUND . . . . . . . . .41

THE ON-SCREEN INFORMATION . . .42

C CHANGING THE DVD SETUP

ITEMS . . . . . . . . . . . . . . . . . . . . . . .43

LANGUAGE SETTING . . . . . . . . .43

DISPLAY SETTING . . . . . . . . . . . .44

AUDIO SETTINGS . . . . . . . . . . . .44

PARENTAL CONTROL . . . . . . . . .45

INITIARIZE . . . . . . . . . . . . . . . . . .45

C TROUBLESHOOTING GUIDE . . .46

C MAINTENANCE . . . . . . . . . . . . . . .49

DISC HANDLING . . . . . . . . . . . . .49

C SPECIFICATIONS . . . . . . . . . . . . .50

C ESPAÑOL . . . . . . . . . . . . . . . . . . . .51

C WARRANTY . . . . . . . . . . .Back Cover

- 6 - EN

1C29

FEATURES

TV/VCR Mode

Hi-Fi system

•

system offers you excellent sound quality with a dynamic range of 80dB, frequency response from 20Hz to 20kHz, and 0.005% wow and flutter.

Rotary 4-head Record/Playback System–Four head

•

ensure excellent picture quality and special effects playback.

Index Search–

•

Slow Motion–View recorded program at slower

•

than normal speed.

Infrared remote control

•

Trilingual on screen TV/VCR setup display

•

selectable in English, Spanish or French Real time counter–This shows the elapsed recording

•

or playback time in hours, minutes and seconds. “–” indication will appear when the tape is rewound further than the tape counter position “0:00:00”.

181 channel capability PLL frequency synthesiz-

•

er tuner–

scrambled cable channels.)

Auto Clock Setting–Allows you to set the clock

•

function from a PBS (Public Broadcast Station).

Closed caption system–You may view specially

•

labeled (cc) TV programs, movies, news, prerecorded tapes, etc. with either a dialogue caption or text display added to the program.

Auto power on and off system–Automatically

•

turns on the TV/VCR/DVD when you insert the cassette, turns off after auto-rewind and ejects when the beginning of the tape is reached.

Auto rewind when the end of a tape is

•

reached–

timer recording.

Smooth mode change–Changing between

•

TV/VCR mode and DVD mode is easy.

–The Hi-Fi stereo recording/playback

Fast-forwards to start of next recording.

The

(A converter may be necessary to view

This function doesn’t occur when using

2 Step picture search operation–You can view a

•

video program at a high speed or super high speed in either a forward or reverse direction in LP and SLP mode. For SP mode only high speed.

Three different playback tape speeds : SP/LP/SLP

•

Two different recording tape speeds : SP/SLP

•

Auto Head Cleaner–Automatically cleans video

•

heads as you insert or remove a cassette.

Zero Return–The tape returns to counter of

•

0:00:00 by rewinding or fast forwarding.

Still–“Freeze” the picture at any time, for close

•

viewing of a particular scene.

Digital Auto Tracking (DTR)–Automatically

•

adjusts the tracking for each tape you play.

Rental play mode–Improves playback picture

•

quality from worn tapes, such as rental tapes.

Auto repeat–Allows you to repeat the playing of a

•

tape indefinitely without pressing the PLAY button.

Time search–Lets you set the TV/VCR/DVD to

•

advance the tape by entering the desired playback time you want to skip.

OTR (One Touch Recording)–Instant timed

•

recording from 30 to 480 minutes is possible at the push of the REC/OTR button.

1 Year, 8 events (including Daily and Weekly

•

Timer Recording)–

record up to 8 programs at different times on different channels up to 1 year in advance. The Daily timer allows recordings to be made of daily broadcasts and the Weekly timer allows recording to be made once a week up to the end of the tape.

Auto return–After timer recording is finished, the

•

TV/VCR/DVD can return to the beginning of the recording.

Sleep timer–Allows you to have the

•

automatically turn off at a desired time.

Timer Program Extension–Allows you to shift the

•

time schedule for automatic timer recording.

V-CHIP–Enables parents to prevent their children

•

from watching inappropriate material on TV.

The built-in timer allows you to

TV/VCR/DVD

- 7 - EN

1C29

DVD Mode

¡Dolby Digital sound

This TV/VCR/DVD can output a Dolby Digital surround signal from the coaxial digital audio output jack.

¡Still/fast/slow/step playback

Various playback modes are available including still pictures, fast forward/reverse, slow motion and frame by frame.

¡Random playback for audio CD

This TV/VCR/DVD can shuffle the order of tracks to play them in random order.

¡Program playback for audio CD

You can program the order of tracks to play them in any desired order.

¡DVD menus in a desired language

You can display DVD menus in a desired language, if available on a DVD.

¡Screen saver/Auto power-off functions

The screen saver program starts when there is no input from the TV/VCR/DVD for 5 minutes in the stop mode. for 15 minutes, the power automatically turns off.

¡Subtitles in a desired language

You can select a desired language for the display subtitles, if that language is available on a disc.

¡Selecting a camera angle

You can select the desired camera angle, if a disc contains sequences recorded from different angles.

¡Choices for audio language and sound mode

You can select the desired audio language and sound mode, if different languages and modes are available on a disc.

¡Parental lock

You can set the control level to limit playback of discs which may not be suitable for children.

¡Automatic detection of discs

This TV/VCR/DVD automatically detects if the loaded disc is DVD or audio CD on disc.

When the screen saver program is activated

¡On-screen display

Information about the current operation can be displayed on a TV screen, allowing you to confirm the currently active functions (such as program playback), on the TV screen using the remote control.

¡Search

Chapter search / Title search / Track search / Time search

¡Repeat

Chapter / Title / Track / All / A-B

¡Marker

Allows the user to return to a specific location on a DVD disc.

¡Resume Play

User can resume to playback from the specific location to which the play was stopped.

¡Virtual Surround (for DVD, CD only)

Creates a surround sound effect.

¡Bit rate indication ¡DRC (Dynamic range control)

You can limit the range of volume.

NOTE:

We do not recommend the use of universal remote controls. Not all of the functions may be controlled with

•

a universal remote control. If you decide to use a universal remote control with this TV/VCR/DVD, please be aware that the code num-

ber given may not operate this TV/VCR/DVD. In this case, please call the manufacturer of the universal remote control.

- 8 - EN

1C29

OPERATING CONTROLS AND FUNCTIONS

REC/OTRTR

SELECT

WER

- TV/VCR/DVD FRONT PANEL - [Fig.1]

DVD buttons TV/VCR buttons

POPOWER

12 4 5 6 107 1514983 3 411 12 13 212019181716

STOP F.FWDREWREC/O

OPEN/CLOSE

SELECT

CHANNELVOLUME

TV/VCRDVD

STOP

PLAYSKIPSKIP PLAY

HEADPHONE

EJECT

AUDIO RL

VIDEO

+100

ENTER

REPEATSEARCH MODE

[Fig. 2]

CH.

VOL.

MUTEV.SURR

DISC

RETURNTITLESETUP

ANGLESUBTITLEAUDIO

45 44

43 42

3 (DVD)

15 (TV/VCR)

5 41

40 39

38 37

36 35

- REMOTE CONTROL -

POWER PICTURE SELECTSLEEP

24 25

123

456

789

PAUSE

SPEED C.RESET

(DVD) 3

(TV/VCR) 14

RECORD

DISPLAY

27 28

29 30

CLEAR

MODE

31 32

1.POWER Button

[TV/VCR P.15 / DVD P.37]

0 +10

PLAY

STOP

Press to turn the power on and off.

2.VOLUME (VOL.) X/Y Buttons

Press to control the volume level for the TV/VCR/DVD.

3.SKIP Buttons (for DVD)

Press once to skip chapters or tracks to a desired

[P.38]

point. Press and hold to change forward or reverse playback speed.

4.PLAY Button

[TV/VCR P.26 / DVD P.37]

Starts playback of the disc or video tape.

5.STOP Button

[TV/VCR P.26 / DVD P.37]

Stops operation of the disc. (or front panel) Stops operation of the disc or tape contents.

(remote control)

6.OPEN/CLOSE Button

[DVD P.37]

Press to insert a disc into or remove from the tray.

7.Disc loading tray

8.DVD Indicator

Illuminates during DVD mode.

9.SELECT Button

Press to change to TV/VCR mode, external input mode or DVD mode.

10.TV/VCR Indicator

Illuminates during TV/VCR mode.

11. CHANNEL (CH.) K/L Buttons

Press to select memorized channel.

12. Recording Indicator

Flashes during recording. Lights up in the Standby mode for Timer Recording.

13. REC/OTR Button (Front Panel)

[TV/VCR P.31]

Press to start manual recording. Press repeatedly to begin One Touch Recording.

RECORD Button (Remote Control)

Press to begin manual recording.

14. REW Button (for TV/VCR)

[TV/VCR P.28]

Press to rewind the tape, or to view the picture rapidly in reverse during playback mode. (Rewind Search)

15. F.FWD Button (for TV/VCR)

[TV/VCR P.28]

Press to rapidly advance the tape, or to view the picture rapidly in forward during playback mode. (Forward Search)

16. STOP/EJECT Button

[TV/VCR P.25, 31]

Press to stop the tape motion. Press in the Stop mode to remove tape from the TV/VCR/DVD.

17. Remote sensor window

18. HEADPHONE Jack

To connect headphone (not supplied) for personal listening.

19. VIDEO input Jack

Connect to the video output jack of a video camera, VCR, video game system.

- 9 - EN

[TV/VCR P.30]

1C29

ANT.

AUDIO OUT

COAXIAL

- TV/VCR/DVD REAR PANEL - [Fig.3]

20. AUDIO L/R input Jacks

Connect to the audio output jacks of a video camera, VCR, video game system.

21. Cassette compartment

22. PICTURE Button

Press to adjust the picture.

23. Number Buttons

TV/VCR Mode:

[P.18]

Press two digits to directly access the desired channel. Remember to press a “0” before a single digit channel.

+100 Button–

Press to select cable channels which are equal or greater than number 100.

DVD Mode:

[P.39]

Press to enter the desired number.

+10 Button–

Press to enter the desired numbers which are equal or greater than number 10.

24. PAUSE Button

[TV/VCR P.26 / DVD P.38]

Pauses the disc or tape movement.

25. SPEED Button

[TV/VCR P.30]

Press to choose the desired recording speed: SP/SLP.

26. C.RESET Button

[TV/VCR P.28]

Press to reset counter to 0:00:00. Press to cancel a setting of timer program. (See page 33.)

27. DISPLAY Button

TV/VCR Mode:

[P.23]

Display the counter or the current channel number and current time on the TV screen.

DVD Mode:

[P.42]

Displays the current status on the TV screen for checking purposes.

28. SETUP Button

[TV/VCR P.15] [DVD P.43-45]

Press to enter or exit the TV menu or DVD setup mode.

29. TITLE Button

[DVD P.37]

Displays the title menu.

30. CLEAR Button

[DVD P.39]

Resets a setting.

31. MODE Button

[DVD P.40]

Activates program playback or random playback mode.

32. SEARCH MODE Button

[DVD P.39]

Press to locate a desired point on a DVD disc.

33. AUDIO Button

[DVD P.41]

Press to select a desired audio language or sound mode.

34. SUBTITLE Button

[DVD P.41]

Press to select a desired subtitle language.

35. REPEAT Button

[DVD P.40]

Repeats playback of the current disc, title, chapter or track.

36. ANGLE Button (DVD mode)

[DVD P.41]

Press to change the camera angle to see the sequence being played back from a different angle (if available).

37. A-B REPEAT Button

[DVD P.40]

Repeats playback of a selected section.

38. RETURN Button

[TV/VCR P.33] [DVD P.39]

Returns to the previous operation in the DVD setup mode.

39. ENTER Button

[TV/VCR P.15] [DVD P.37]

Press to accept a setting.

40. Arrow Buttons

TV/VCR Mode:

[P.15]

Press to select a setting mode from the menu on the TV screen. Press to select or adjust from a particular menu.

DVD Mode:

[P.37]

Use when making settings while watching the display on a TV screen.

41. DISC MENU Button

[DVD P.37]

Displays the menus in the DVD.

42. V. SURR (VIRTUAL SURROUND) Button

[DVD P.41]

Sets virtual surround on/off (DVD and CD sound only).

43. MUTE Button

Mutes the sound. Press it again to resume sound.

44. SLEEP Button

Sets the Sleep Timer.

45. SELECT Button

[TV/VCR P.34]

[TV/VCR P.15] [DVD P.37]

Press to switch TV/VCR and DVD mode. You can see the mode (TV/VCR or DVD) on the front panel indicator.

- 10 - EN

1C29

ANT.

AUDIO OUT COAXIAL

ANT.

OUT

46. ANT. in Jack

Connect to an antenna, cable system or satellite system.

47. Power cord

Connect to a standard AC outlet (120V/60Hz).

NOTE: Remove the power cord from the hook to

avoid breaking a wire before you connect to a standard AC outlet.

PREPARATION FOR USE

ANTENNA/CABLE CONNECTION

48. COAXIAL digital audio out Jack

Connect to the digital input of an external Audio receiver.

NOTE: Only DVD and CD audio will be output

from this jack.

Satellite Box or Cable Box (Not supplied)

From Cable System or Satellite Dish

75-ohm From Cable System

Coaxial

Cable

(Not sup-

plied)

75-ohm Coaxial Cable (Not

supplied)

VHF/UHF SEPARATE ANTENNAS

In some areas it will be necessary to use an outdoor antenna.

CABLE WITHOUT CONVERTER/ DESCRAMBLER BOX

Use this connection if your cable system connects directly to your TV/VCR/DVD without a converter box.

By using this connection you can:

1) Use the TV/VCR/DVD remote to select channels.

2) Program one or more unscrambled channels for Automatic Timer Recording.

NOTE: This TV/VCR/DVD will ONLY record and view the same channel.

VHF/UHF Antenna (Not supplied)

VHF Antenna (Not supplied)

UHF Antenna (Not supplied)

VHF/UHF Combiner (Not supplied)

[Fig. 4]

Flat twin-lead cable

CABLE WITH CONVERTER/ DESCRAMBLER BOX OR SATELLITE BOX

If your cable service supplies you with a converter box or if you use a satellite system, you can use the basic connection shown in the illustration.

By using this connection you can also record scrambled channels. However, channel selection must be made with the converter box or satellite box. This means that channels cannot be changed using the TV/VCR/DVD Remote Control. Unattended timer recording is limited to one channel at a time.

Antenna/Cable Connections Continued on the Next Page.

- 11 - EN

1C29

TO RECORD A SCRAMBLED/UNSCRAM-

VIDEO AUDIO RL

HEADPHONE

BLED CHANNEL

1. Set the TV/VCR/DVD channel selector to the output channel of the Cable Converter Box or Satellite Box. (Ex. CH3)

2.Select the channel to record on your Cable

Converter Box or Satellite Box.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

INSTALLING THE BATTERIES

1)Open the battery compartment cover by pressing the cover on the remote unit in the direction of the arrow.

2)Insert 2 “AA” penlight batteries into the battery compartment in the direction indicated by the polarity (+/-) markings.

3)Replace the cover.

EXTERNAL INPUT MODE

CONNECTING TO EXTERNAL

INPUT JACKS

When you watch a program recorded on another source (VCR, video camera or video game), use the audio/video input jacks on the front of the TV/VCR/DVD.

Connect the audio/video output jacks of another source to the AUDIO L/R and VIDEO jacks of this TV/VCR/DVD.

Then press the CHANNEL button “AUX” appears on the screen.

NOTE:

When you connect a monaural VCR (another

•

source) to this TV/VCR/DVD, connect the Audio output jack of the monaural VCR (another source) to the AUDIO L jack of this TV/VCR/DVD. The audio will output in both L and R channel equally.

To the audio output jacks

[Another source]

K or L until

When using an external input signal (another VCR, video camera or video game), connect the player’s audio/video output cables to the AUDIO L/R IN/ VIDEO IN jacks

AUX

of your TV/VCR/DVD. Then press the CHANNEL button K or L until “AUX” appears on the screen.

To the video output jack

etc.

Audio/Video cable (not supplied)

[Front of the TV/VCR/DVD]

[Fig. 5]

- 12 - EN

1C29

CONNECTING TO A STEREO RECEIVER EQUIPPED WITH

ANT.

AUDIO OUT

COAXIAL

Receiver equipped with digital

input jacks

To COAXIAL DIGITAL AUDIO INPUT jack

DIGITAL AUDIO OUT COAXIAL NOTE: DVD, CD audio only

DIGITAL INPUT JACKS

Use an audio coaxial digital cable available at retail stores for the audio connection.

[Fig. 6]

NOTES:

A 5.1 channel Dolby Digital surround format cannot be recorded as digital sound.

•

Be sure to turn off the power to all components in the system before connecting them together.

•

Refer to the Owner's Manuals for the components to be connected to the TV/VCR/DVD.

•

Set Dolby Digital to OFF for audio output in the setup mode when using this digital audio connection.

•

Playing a DVD using incorrect settings may generate noise distortion and may also damage the speakers.

- 13 - EN

1C29

ANT.

AUDIO OUT COAXIAL

Front speaker

(left)

Center

speaker

Front speaker

(right)

Surround

speaker

(left)

Surround

speaker

(right)

Subwoofer

DIGITAL AUDIO OUT COAXIAL

To COAXIAL DIGITAL AUDIO INPUT jack

Receiver with Dolby

Digital decoder

CONNECTING TO RECEIVER WITH A DOLBY DIGITAL DECODER

(for DVD)

If using this TV/VCR/DVD to play a DVD disc in a 5.1 channel Dolby Digital surround format, the TV/VCR/DVD outputs a DOLBY DIGITAL Data stream from its COAXIAL digital audio out jack. By hooking the TV/VCR/DVD up to a Dolby Digital decoder, you can enjoy a more convincing, realistic surround sound as enjoyed in movie theaters.

Use audio coaxial digital cables available at retail stores for the audio connection.

[Fig. 7]

NOTES:

Be sure to turn off the power to all components in the system before connecting them together.

•

Refer to the Owner's Manuals for the components to be connected to the TV/VCR/DVD.

•

If connected to a receiver with a Dolby Digital decoder, set DOLBY DIGITAL to ON for audio output in

•

the setup mode. (See page 44 to set DOLBY DIGITAL to ON.) Unless connected to a receiver with a Dolby Digital decoder, set DOLBY DIGITAL to OFF for audio out-

•

put in the setup mode. Playing a DVD using incorrect settings may generate noise distortion and may also damage the speakers.

Manufactured under license from Dolby Laboratories.“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

- 14 - EN

1C29

SET UP FOR USE

TV/VCR SECTION

SELECTING THE LANGUAGE

TV/VCR

1 Plug in the TV/VCR/DVD power cord

Plug the TV/VCR/DVD power cord into a standard AC outlet.

NOTE:

If any digits appear in the corner of the

•

screen, press the POWER button without unplugging the power cord.

Make sure ...

Press the SELECT button to select TV/ VCR mode

•

or make sure TV/ VCR lights on. Press the POWER button to turn on the

•

TV/VCR/DVD.

2 Select “LANGUAGE”

Press the SETUP button on the remote control.

Press the Arrow button

K or L to

point to “LANGUAGE”. NOTE: This function effects only

the language on the screen menu and not the audio source.

3 Select “ENGLISH”, “ESPAÑOL” or “FRANÇAIS”

Select “ENGLISH”, “ESPAÑOL”= Spanish or “FRANÇAIS”= French using the ENTER button.

4 Exit the Language mode

Press the SETUP button on the remote control to return to TV mode.

NOTE: If for some reason the menu is in Spanish or French, press the SETUP button on the remote control, press the Arrow button “IDIOMA [ESPAÑOL]” or “LANGAGE [FRANÇAIS]”, then press the ENTER button, then press the SETUP button on the remote control.

K or L to point to

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP

B LANGUAGE [ENGLISH]

CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

CLOCK SET UP

(AUTO / MANUAL)

TV/VCR

The TV/VCR/DVD clock must be set correctly before VCR timer recording is possible. It is suggested that the clock be set manually when first setting up the TV/VCR/DVD, then set the auto clock setting to [ON] which will periodically correct the setting if necessary.

NOTE: If you cannot receive a station with time signals, auto clock setting cannot be performed. Use manual setting only.

MANUAL CLOCK SETTING

Make sure ...

The TV/VCR/DVD is turned on.

•

In the example below, the clock is to be set to:

DATE May 6th, 2004 SETTING TIME 5:40PM

1 Select “SETTING CLOCK”

Press the SETUP button on the remote control.

Press the Arrow button

K or L to point to “SETTING CLOCK”. Then press the ENTER button.

2 Select “MANUAL CLOCK SET”

Press the Arrow button K or L to point to “MANUAL CLOCK SET”. Then press the ENTER button.

3 Select the month

Press the Arrow button K or L until your desired month appears.

(Example: May Then press the Arrow button

(Or press the Arrow button s to go back one step.)

→ 05)

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH SEARCH AUTO CLOCK CH [ 02 ]

B MANUAL CLOCK SET

D.S.T. [OFF]

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / – – – – – – – – –

HOUR MINUTE

– – : – – – –

4 Select the day

Press the Arrow button K or L until your desired day appears.

(Example: 6th Then press the Arrow button

→ 06)

- 15 - EN

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 – – – – – – –

HOUR MINUTE

– – : – – – –

1C29

5 Select the year

Press the Arrow button K or L until your desired year appears.

(Example: 2004) Then press the Arrow button

6 Select the hour

Press the Arrow button K or L until your desired hour appears.

(Example: 5, PM) Then press the Arrow button

7 Select the minute

Press the Arrow button K or L until the desired minute appears.

(Example: 40)

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 THU 2 0 0 4

HOUR MINUTE

– – : – – – –

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 THU 2 0 0 4

HOUR MINUTE

0 5 : – – PM

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 THU 2 0 0 4

HOUR MINUTE

0 5 : 4 0 PM

AUTOMATIC CLOCK SETTING

Make sure ...

The TV/VCR/DVD is turned on.

•

Confirm the TV/VCR/DVD is receiving a RF

•

(Radio Frequency) signal from either an antenna or cable system connection using the ANT. terminal on the rear of the TV/VCR/DVD.

NOTE:

If a cable converter box is being used, make sure it

•

is powered on. You must use the TV/VCR/DVD remote control to

•

perform the clock setting procedure. If the TV/VCR/DVD is connected directly to a

•

cable converter box or satellite box, the local PBS station must be selected on the cable box itself and the TV/VCR/DVD must be set to the output channel of the cable converter box or satellite box (usually channel 3 or 4), to be able to set up or correct the clock automatically.

8 Start the clock

5:40 PM

Press the SETUP button on the remote control.

Although seconds are not displayed, they begin counting from 00 when you press the SETUP button on the remote control. Use this feature to synchronize the clock with the correct time.

NOTE:

When unplugging the AC cord or if there is a power failure for more than 3 seconds, you may have to reset the clock.

TO CHANGE CLOCK SETTING

If you want to change the clock,

1)Follow steps [1] to [2].

2)Select where you want to change using the Arrow button

3)Enter correct numbers using the Arrow button or L.

4)Press the SETUP button on the remote control to start the clock.

PLEASE NOTE:

If there is no local PBS (Public Broadcast Station) in your area or on your cable system, select “AUTO CLOCK” and press the ENTER button to turn [OFF] this function. Then you can manually adjust the clock.

1 Select “SETTING CLOCK”

Press the SETUP button on the remote control. Press the Arrow button K or L to select “SETTING CLOCK”. Press the ENTER button to enter “SETTING CLOCK” menu.

2 Set “AUTO CLOCK” to [ON]

Press the Arrow button B until “AUTO CLOCK [ON]” appears.

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– SETTING CLOCK –

B AUTO CLOCK [ON]

AUTO CLOCK CH SEARCH AUTO CLOCK CH [ 02 ] MANUAL CLOCK SET D.S.T. [OFF]

3 Begin “AUTO CLOCK CH SEARCH”

Press the Arrow button L to select “AUTO CLOCK CH SEARCH”. Press the ENTER button.

The TV/VCR/DVD is now

•

searching for the station which contains the auto clock signal. The search for a signal may take up to 20 seconds per channel. “_ _” appears at the lower left of

•

the screen when the search has ended.

Auto Clock station(s)- write

•

down the number(s) that appear on the screen. These are the auto clock station(s) in your area. It is (they are) necessary in step [4] on the next page.

If no number(s) appear on the TV screen, there are

•

no stations in your area which contain the Auto Clock signal. Auto Clock Setting is not possible. Please use Manual Clock Setting on page 15.

Press the SETUP button to exit the screen.

– SETTING CLOCK –

AUTO CLOCK [ON]

B AUTO CLOCK CH SEARCH

AUTO CLOCK CH [ 02 ] MANUAL CLOCK SET D.S.T. [OFF]

– AUTO CLOCK CH SEARCH –

08 10 13

_ _

- 16 - EN

1C29

NOTE: During Auto Clock CH Search, the picture may be distorted, this is normal.

4 Enter the channel number that contains the

Automatic Clock Setting Signal

Press the SETUP button on the remote control.

Press the Arrow button

K or L to

select “SETTING CLOCK”. Press the ENTER button to enter

“SETTING CLOCK” menu. Press the Arrow button

L to select

“AUTO CLOCK CH”. Press the ENTER button or the

Arrow button

s or B until you

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH SEARCH

B AUTO CLOCK CH [ 45]

MANUAL CLOCK SET D.S.T. [OFF]

locate Auto Clock Set station number. See step [3] on page 16.

Press the SETUP button to exit the screen.

5 Turn off the TV/VCR/DVD

Once the TV/VCR/DVD is turned off , it will periodically check and set the correct date and time.

DAYLIGHT-SAVING TIME

TV/VCR

Select this feature and the TV/VCR/DVD’s clock automatically will advance one hour in April, then reverse one hour in October.

When Daylight-Saving Time is ON, the clock will change automatically as follows:

First Sunday of April : At 2 AM the clock imme-

•

diately changes to 3 AM. Any timer programming you have set to occur between 2 AM and 3 AM will not record.

Last Sunday of October : At 2 AM the clock

•

immediately changes to 1 AM.

Make sure ...

Press the POWER button to turn on the TV/VCR/DVD.

•

1 Select “SETTING CLOCK”

Press the SETUP button on the remote control.

Press the Arrow button

K or L to

point to “SETTING CLOCK”. Then press the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

2 Set “D.S.T.” (Daylight-Saving Time) to [ON]

Press the Arrow button K or L to point to “D.S.T.”.

Then press the ENTER button until [ON] appears.

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH SEARCH AUTO CLOCK CH [ 02 ] MANUAL CLOCK SET

B D.S.T. [ON]

3 Exit the Daylight-Saving Time mode

Press the SETUP button on the remote control to return to TV mode.

TO CANCEL THE DAYLIGHT-SAVING TIME

Repeat steps [1] to [2], select [OFF] using the ENTER button.

- 17 - EN

1C29

CHANNEL SET UP

TV/VCR

You can program the tuner to preset all the channels you receive in your area.

NOTE: Channel memory programming is NOT needed when connected to a cable box or satellite box. Just select the TV/VCR/DVD channel to the output channel of the cable box or satellite box (Ex CH3), then select the channel to be viewed on the Cable Box or Satellite Box.

Make sure ...

Press the POWER button to turn on the TV/VCR/DVD.

•

DELETING (OR ADDING)

CHANNEL(S)

TV/VCR

The channels you no longer receive or seldom watch can be deleted from the memory. (Of course, you can add the deleted channel into the memory again.)

1 Select “CHANNEL SET UP”

Press the SETUP button on the remote control.

Press the Arrow button

K or L to

point to “CHANNEL SET UP”. Then press the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK

B CHANNEL SET UP

USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

1 Select “CHANNEL SET UP”

Press the SETUP button on the remote control.

Press the Arrow button

K or L to

point to “CHANNEL SET UP”. Then press the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK

B CHANNEL SET UP

USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

2 Begin auto ch programming

Press the Arrow button K or L to point to “AUTO CH PROGRAMMING”.

Then press the ENTER button. The tuner scans and memorizes all

the active channels in your area.

– CHANNEL SET UP –

ADD / DELETE CH (CATV)

B AUTO CH PROGRAMMING

3 After scanning

The tuner stops on the lowest memorized channel.

When AUTO CH PROGRAMMING is activated

•

where there is no TV signal input, “NO TV SIGNALS” will appear on the display after the completion of the channel scanning.

The TV/VCR/DVD may memorize TV channels as

•

CATV channels if reception conditions are poor. If this happens, check the antenna connections and try the AUTO CH PROGRAMMING action again, or wait until reception conditions are better and then try it again.

2 Select “ADD/DELETE CH”

Press the Arrow button K or L to point to “ADD/DELETE CH”.

– CHANNEL SET UP –

B ADD / DELETE CH (CATV)

AUTO CH PROGRAMMING

Press the ENTER button.

3 Enter the desired channel number

Press the Arrow button K or L until your desired channel number appears. (You can also use the number buttons or the CHANNEL

ADD / DELETE

K or L button to enter it) (Example: CH8)

You must precede single-digit channel numbers

•

with a zero (Example: 02 ... 09). When selecting cable channels which are higher

•

than 99, press the +100 button first, then press the last two digits. (Example: to select channel 125, first press the +100 button then press “2” and “5”).

4 Delete (or add) it from (or into) memory

Press the ENTER button. The channel number changes to light red. The channel is deleted from memory.

To delete another channel, repeat steps [3] to [4].

•

If you press the ENTER button again, the channel

•

is memorized again.

Added channel: Light blue. Deleted channel: Light red.

5 Exit the channel setup mode

Press the SETUP button on the remote control to return to TV mode.

NOTE: To confirm that channel(s) has been deleted or added, press the CHANNEL

- 18 - EN

K or L button.

1C29

TV OPERATION

to decrease brightness

to decrease contrast

to pale to brilliant

to green

to clear

to purple

to soft

to increase brightness

to increase contrast

BRIGHT

CONTRAST

COLOR

TINT

SHAPNESS

Arrow Button { Arrow Button B

WATCHING A TV PROGRAM

TV/VCR

1 Turn on the TV/VCR/DVD

Press the POWER button to turn on the TV/VCR/DVD.

2 Select the channel number

Press the CHANNEL button K or L to select your desired channel number or press the number on the remote control.

Note for using the Number button on the remote control:

¡You must precede single-digit channel numbers

with a zero (For example: 02, 03, 04 and so on).

¡When selecting cable channels which are higher

than 99, press +100 first, then press the last two digits. (Example: to select channel 125, first press “+100” then press “2” and “5”).

Remember: If the TV/VCR/DVD is connected to a cable box or satellite box, the TV/VCR/DVD must be on CH3 or CH4, then the channel to be viewed must be selected on the cable box or satellite box.

3 Adjust sound

Press the VOLUME button XXor to adjust the volume.

VOLUME 20

C C C C C C C C C C C C

PICTURE CONTROL

TV/VCR

The TV/VCR/DVD’s picture controls – BRIGHT, CONTRAST, COLOR, TINT and SHARPNESS –

are preset to factory specifications. Although they are usually the best, you may need to make some further adjustments to your preference.

NOTES:

Procedures must be followed within 5 seconds or

•

the Picture Control mode will be cancelled. When setting the Picture Control, the Game mode

•

will be cancelled.

Make sure ...

TV/VCR/DVD power must be turned on.

•

1 Select “PICTURE CONTROL”

Press the PICTURE button on the remote control.

2 Select item you want to adjust

Press the Arrow button K or L until desired control is displayed.

BRIGHT CONTRAST COLOR TINT SHARPNESS

BRIGHT

PP PP PP PP PP PP PP CC PP PP PP PP PP PP PP

–

NOTES:

If you press the CHANNEL button K or L in the

•

DVD mode, you can change the TV channels. Even if you turn off the TV/VCR/DVD in the

DVD mode, when you turn it on again, it will go into the TV/VCR mode.

DEGAUSSING

This television has a degaussing circuit that will clear up color errors on the TV screen that are caused by any excess magnetism which happens to get too close to the TV. This circuit is designed to operate once when the set is first plugged in. If minor color errors are seen in some locations on the screen, please unplug the TV for approximately 15 minutes. When the TV is plugged back in, the degaussing circuit will operate once to clear them up. Repeat this procedure any time the TV screen is accidentally magnetized, or when the TV is moved or relocated.

TV/VCR

3 Adjust the picture control

Press the Arrow button s or B to adjust to your desired level.

If there is a power failure of any kind, the

•

TV/VCR/DVD will retain its memory for this feature.

- 19 - EN

1C29

CLOSED CAPTION SYSTEM

TV/VCR

You can view specially labeled (cc) TV programs, movies, news and pre-recorded tapes with either a dialogue caption or text display.

CAPTION mode: By choosing the caption mode, you

can watch dramas, movies and news while captioning the dialogues and the contents of news.

TEXT mode: By choosing the text mode, you can

watch half screen text information if you want.

1-2: You may get these captions or text information

by selecting either “1” or “2”. Caption “2” is used, usually for a second language if available.

NOTE:

Not all programs are broadcast with closed captions. Your TV/VCR/DVD is designed to provide error free closed captions from high quality antenna, cable and VCR signals. Conversely, poor quality signals are likely to result in caption errors or no captions at all. Common signal conditions which may cause captions errors are listed below:

Automobile ignition noise

•

Electric motor brush noise

•

Weak snowy reception on TV screen

•

Multiplex signal reception displaying picture

•

ghosts or airplane flutter. Playback of poorly recorded or worn VCR tapes.

•

NOTE:

If the TV/VCR/DVD displays a black box on the TV screen, this means that the TV/VCR/DVD is set to the TEXT mode. To clear screen, select [CAPTION1], [CAPTION2] or [OFF].

Make sure ...

TV/VCR/DVD’s power must be turned on.

•

1 Select “CAPTION”

Press the SETUP button on the remote control.

Press the Arrow button point to “CAPTION”.

K or L to

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [OFF]

ZERO RETURN TIME SEARCH INDEX SEARCH

2 Select your desired caption menu

Press the ENTER button until your desired caption menu appears.

([CAPTION1], [CAPTION2], [TEXT1] or [TEXT2])

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [CAPTION1]

ZERO RETURN TIME SEARCH INDEX SEARCH

3 Exit the caption setting mode

Press the SETUP button on the remote control to return to TV mode.

TO CANCEL THE CLOSED CAPTION SYSTEM

Repeat steps [1] to [2], select [OFF] using the ENTER button. Press the SETUP button on the remote control to return to TV mode.

WHEN THE CLOSED CAPTION MODE IS ON

The On-Screen Display will disappear after 5 seconds.

It will also disappear when the MUTE button is

•

pressed or when the PAUSE button is pressed while recording.

If there is a power failure of any kind, the

•

TV/VCR/DVD will retain its memory for this feature.

- 20 - EN

1C29

V-CHIP SET UP

Make sure ...

TV/VCR/DVD is turned on.

•

1 Select “V-CHIP SET UP”

Press the SETUP button on the remote control.

Press the Arrow button select “V-CHIP SET UP”.

Then press the ENTER button.

2 Enter Access code

Use the number buttons on the remote control to enter the access code.

For the first time set-up or in the

•

event the TV/VCR/DVD has lost power, enter the default code of the numbers: 0000.

K or L to

TV/VCR

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH

INDEX SEARCH

ACCESS CODE

_ _ _ _

V-CHIP SET UP SUB RATINGS

When you select the ratings of TV-Y7,TV-PG,TV-14 or TV-MA you will have the option of selecting sub

rating categories.

1 Select “V-CHIP SET UP”

Press the SETUP button on the remote control.

Press the Arrow button

K or L to select “V-CHIP SET UP”. Then press the ENTER button.

2 Enter Access code

Use the number buttons on the remote control to enter the access code. (Default code is 0000.)

3 Select “TV RATING”

Press the Arrow button K or L to select “TV RATING”.

Then press the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

ACCESS CODE

_ _ _ _

– V-CHIP SET UP –

B TV RATING

MPAA RATING CHANGE CODE

3 Select “TV RATING”

Press the Arrow button K or L to select “TV RATING”.

– V-CHIP SET UP –

B TV RATING

MPAA RATING CHANGE CODE

Then press the ENTER button.

4 Blocking TV programs

Press the Arrow button K or L to select “TV rating” that you wish to block.

Press the ENTER button to turn it [BLOCK].

When you select the rating category and turn it

•

[BLOCK], the higher rating will turn [BLOCK] automatically. Also, the lower rating will turn [VIEW] automatically.

When you turn “TV-Y” to [VIEW], all ratings will

•

turn to [VIEW] automatically.

Selection Rating Category Explanations

TV-Y Appropriate for all children TV-Y7 Appropriate for children seven and older TV-G General Audience TV-PG Parental Guidance suggested. TV-14 Unsuitable for children under 14

TV-MA Mature audience only

B TV–Y [VIEW]

TV–Y7 ( ) [VIEW] TV–G [VIEW] TV–PG ( ) [VIEW] TV–14 ( ) [VIEW] TV–MA( ) [VIEW]

4 Selecting “Sub-Ratings”

Press the Arrow button K or L to select the sub-rating you wish to block. Then, press the ENTER button twice.

When you select [TV-Y7]:

•

Press the Arrow button K or L to select “FV” (Fantasy Violence).

TV–Y7 [BLOCK]

B FV [BLOCK]

Then press the ENTER button to select [BLOCK] or [VIEW].

When you select [TV-PG], [TV-

•

14] or [TV-MA]:

Press the Arrow button K or L to select “D”(Suggestive Dialog),

TV–PG [BLOCK]

B D [BLOCK]

L [BLOCK] S [BLOCK] V [BLOCK]

“L”(Coarse Language), “S”(Sexual Situation) or “V”(Violence). Then press the ENTER button to select [BLOCK] or [VIEW].

Note: When you select [TV-MA], “D” does not appear on the TV screen.

The sub-ratings which are set to

•

[BLOCK] appears next to the rating category in the TV rating

TV–Y [VIEW] TV–Y7 ( ) [VIEW] TV–G [VIEW]

B TV–PG (DLSV ) [BLOCK]

TV–14 (DLSV) [BLOCK] TV–MA ( LSV) [BLOCK]

menu.

5 Exit the V-Chip setting mode

Press the SETUP button on the remote control to enter the setting and exit the screen.

5 Exit the V-Chip setting mode

Press the SETUP button on the remote control to exit the screen.

- 21 - EN

1C29

CHANGING V-CHIP BLOCKED PROGRAMMING

Note: To change the rating, the TV must be turned to a station that is not protected. If the (PROTECTED) appears on the screen, please change the channel to a station that is not protected.

1)Follow steps [1] to [2].

2)Press the Arrow button ING”. Then press the ENTER button. Select a TV rating to be unblocked by pressing the Arrow button K or L.

Then press the ENTER button to unblock the rating.

3)Press the SETUP button on the remote control to exit the screen.

K or L to select “TV RAT-

5 Exit the V-Chip setting mode

Press the SETUP button on the remote control to exit the screen.

CHANGE ACCESS CODE

To change access code, follow the steps below.

1 Select “V-CHIP SET UP”

Press the SETUP button on the remote control. Press the Arrow button

SET UP”. Then press the ENTER button.

K or L to select “V-CHIP

MPAA RATING SET UP

1 Select “V-CHIP SET UP”

Press the SETUP button on the remote control.

Press the Arrow button

K or L to select “V-CHIP SET UP”. Then press the ENTER button.

2 Enter Access code

Use the number buttons on the remote control to enter the access code.

3 Select “MPAA RATING”

Press the Arrow button K or L to point to “MPAA RATING”.

Then press the ENTER button.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

ACCESS CODE

_ _ _ _

– V-CHIP SET UP –

TV RATING

B MPAA RATING

CHANGE CODE

4 Select your desired item

Press the Arrow button K or L to point to your desired item.

Then press the ENTER button to select [BLOCK] or [VIEW].

Selection Rating Category Explanations

G General Audience PG Parental Guidance suggested. PG-13 Unsuitable for children under 13 R Restricted; under 17 requires accompa-

nying parent or adult guardian

NC-17 No one under 17 admitted X Mature audience only

G [VIEW] PG [VIEW] PG–13 [VIEW]

B R [BLOCK]

NC–17 [BLOCK] X [BLOCK]

2 Enter Access code

Use the number buttons on the remote control to enter the access code.

ACCESS CODE

_ _ _ _

The default code is 0000.

3 Select “CHANGE CODE”

Press the Arrow button K or L to select “CHANGE CODE”. Then

– V-CHIP SET UP –

TV RATING MPAA RATING

B CHANGE CODE

press the ENTER button.

4 Enter New code

Use the number buttons to enter your desired access code in the NEW CODE space. Then enter the

NEW CODE

X X X X

CONFIRM CODE

_ _ _ _

same code in the CONFIRM CODE space. V-CHIP SET UP screen will appear on the screen.

If you enter wrong code, repeat step [4], making

•

sure you enter the same new code exactly in the confirm code space.

5 Exit the V-Chip setting mode

Press the SETUP button on the remote control to exit the screen.

Note: If you unplug the power cord or a power failure occurs, the changed access code will be lost and will return to default (0000). Change your access code again as necessary.

When you select the rating category and turn it

•

[BLOCK], the higher rating will turn [BLOCK] automatically. Also, the lower rating will turn [VIEW] automatically. When you turn “G” to [VIEW], all ratings will turn

•

to [VIEW] automatically.

- 22 - EN

1C29

MTS (Multi-Channel Television sound) SYSTEM

You can record or listen to a program in MTS stereo.

CHECKING THE SELECTED MTS MODE

When you play a VHS tape, or receive a broadcast on the TV/VCR/DVD tuner channel you are watching, the status shown below will appear when you press the DISPLAY button on the remote control.

SAP

HIFI

PLAY HIFI CH 123

SP COUNT 0:00:00

Second Audio Program, which means your program, can also be received in a second language or sometimes a radio station.

High Fidelity which produces better sound than standard stereo TV/VCR/DVDs.

12:00AM

STEREO/SAP

TV/VCR

1) When a program is broadcast in stereo, STEREO appears on the TV screen.

2) When a program is broadcast in second audio, SAP appears on the TV screen.

3) When a program broadcast both in stereo and second audio, STEREO and SAP appear on the TV screen.

NOTE: Although a program may be broadcast in

both stereo and second audio, you cannot record in both stereo and second audio at the same time.

4) While the TV/VCR/DVD is set in HIFI stereo mode and playback mode. HIFI appears on the TV screen. While the TV/VCR/DVD is set in monaural(MONO) mode, HIFI disappears from the TV screen.

NOTE: If you play non-HIFI tapes while the

TV/VCR/DVD is set in HIFI, HIFI will disappear from the TV screen and the TV/VCR/DVD will play automatically in monaural.

MTS RECORDING/MONITOR MODE

TV/VCR

Type of broadcast Display on STEREO/SAP Hi-Fi audio track(2-channel) Normal audio

the TV screen SELECTION L-channel R-channel track

Regular -None- -Invalid- Mono Mono Mono

(monaural audio)

Stereo broadcast STEREO -Invalid- L R L+R

Bilingual broadcast SAP STEREO* Main audio Main audio Main audio

program program program

SAP* Sub audio Sub audio Sub audio

Stereo & Bilingual STEREO STEREO* L R L+R

broadcast SAP

SAP* sub audio sub audio sub audio

*You must select the recording mode in TV AUDIO [STEREO] or [SAP] when you record a broadcast.

- 23 - EN

program program program

1C29

SELECTING THE MTS SYSTEM

TV/VCR

Make sure ...

TV/VCR/DVD power must be turned on.

•

TO SELECT HIFI MODE

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button

K or L to point to “USER’S SET UP”. Then press the ENTER button.

2 Select “VCR AUDIO”

Press the Arrow button K or L to point to “VCR AUDIO”.

3 Select [HIFI]

Press the ENTER button until [HIFI] appears.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– USER’S SET UP –

RENTAL [OFF] REPEAT PLAY [OFF] AUTO RETURN [OFF]

B VCR AUDIO [HIFI]

TV AUDIO [STEREO]

– USER’S SET UP –

RENTAL [OFF] REPEAT PLAY [OFF] AUTO RETURN [OFF]

B VCR AUDIO [HIFI]

TV AUDIO [STEREO]

TO SELECT MONO MODE

You can change the selection to “MONO” if you want to listen to HIFI tapes in normal audio playback.

Press the SETUP button on the remote control.

1) Press the Arrow button

K or L to point to “USER’S

SET UP”. Then press the ENTER button.

2) Press the Arrow button K or L to point to

“VCR AUDIO”.

3) Press the ENTER button until [MONO] appears.

4) Press the SETUP button on the remote control to return to TV mode.

TO SELECT STEREO, SAP, OR MONO

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button

K or L to

point to “USER’S SET UP”.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

4 To return to TV mode

Press the SETUP button on the remote control to return to TV mode.

NOTES:

Normally “HIFI” should be selected for playback

•

with HIFI sound.

When you play non-HIFI tapes, the TV/VCR/DVD

•

will play automatically in the monaural mode.

The TV/VCR/DVD records automatically MTS

•

broadcasts in HIFI stereo sound unless you select SAP mode recording before you begin recording.

2 Select “TV AUDIO”

Press the Arrow button K or L to point to “TV AUDIO”.

– USER’S SET UP –

RENTAL [OFF] REPEAT PLAY [OFF] AUTO RETURN [OFF] VCR AUDIO [HIFI]

B TV AUDIO [STEREO]

3 Select [STEREO], [SAP] or [MONO]

Press the ENTER button until [STEREO], [SAP] or [MONO] appears.

4 To return to TV mode

Press the SETUP button on the remote control to return to TV mode.

NOTES:

You must select the recording mode, either TV

•

AUDIO [STEREO] or [SAP] when you record a broadcast. Refer to MODE”.

If you select second audio when second audio is

•

not available, the TV/VCR/DVD will record normal audio.

The TV/VCR/DVD records automatically MTS

•

broadcasts in HIFI stereo sound unless you select SAP mode recording before you begin recording.

“MTS RECORDING/MONITOR

- 24 - EN

1C29

VIDEO CASSETTE

This TV/VCR/DVD will operate with any cassette that has the mark. For best results, we recommend the use of high-quality tapes. Do not use poor quality or damaged tapes.

PRECAUTIONS

Avoid moisture. Moisture condensation may occur

•

on the tape if it is moved from a cold place to a warm place or visa versa. Before using a tape with these conditions, to avoid damage of the tape and your TV/VCR/DVD, wait until the tape has warmed to room temperature and the moisture has evaporated.

Avoid extreme heat, high humidity and magnetic

•

fields. Do not tamper with the cassette mechanism.

•

Do not touch the tape with your fingers.

•

TWO DIFFERENT TAPE SPEEDS

Before recording, select the tape speed from : SP mode (Standard Play) or SLP mode (Super Long

Play). The table below shows the maximum recording/play-

back time using T60, T120 or T160 tapes in each mode.

Tape Speed Recording/Playback Time

Type of tape

SP mode 1 hour 2 hours 2-2/3 hours SLP mode 3 hours 6 hours 8 hours

Note: You can play back a tape recorded in LP mode (Long Play).

T60 T120 T160

INSERTING A CASSETTE

Insert the cassette in the direction as shown. Push in gently, but continuously, on the center-back of the cassette until it is drawn into the TV/VCR/DVD. The TV/VCR/DVD will automatically turn on.

Window

CORRECT

WRONG

REMOVING A CASSETTE

1)In the Stop mode, press the STOP/EJECT button

on the TV/VCR/DVD. The cassette will eject.

2)Pull the cassette out of the cassette compartment.

3)Store the cassette in its case as shown.

ERASE PREVENTION

You can prevent accidental erasing of recording by breaking off the tab on the back edge of the cassette.

Ta b

If you decide to record on the tape again, cover the hole with plastic tape.

Plastic Tape

NOTE:

• In DVD mode, Whether the cassette is with tab or

without tab you insert, it doesn’t start playing until you press the PLAY button. In TV/VCR mode, if a cassette without tab is inserted, playback will automatically start.

- 25 - EN

1C29

PLAYBACK

NORMAL PLAYBACK

TV/VCR

Make sure ...

TV/VCR/DVD power must be turned on.

•

1 Insert a prerecorded tape

If the erase-protection tab has been removed, the TV/VCR/DVD will start playback automatically.

2 To begin playback

Press the PLAY button.

3 To stop playback

Press the STOP button when playback is completed.

NOTES:

If you press the PLAY button (of the TV/VCR side)

•

in the DVD mode, you can start the VCR playback. If you press the SELECT button during the VCR

•

playback, it will stop and the mode will change to the DVD mode. In addition, the same function operates with the DVD side PLAY button or the OPEN/CLOSE button.

PLAY

STOP

TRACKING ADJUSTMENT

TV/VCR

Tracking adjustment will be set automatically

•

(Digital Tracking function) when you start playback. However when playing pre-recorded tapes or tapes

•

recorded on other VCR, noise lines (black and white streaks) may appear on the playback picture. If this occurs, you can adjust the tracking control manually by pressing the CHANNEL button K or L until the streaks disappear. To return to the DTR function, stop the tape once and start playback again.

You can reduce the noise lines by pressing the

•

CHANNEL button K or L in slow mode too. Tracking adjustment in Slow mode will not be set automatically.

SLOW MOTION

TV/VCR

Press the PAUSE button, then press the F.FWD g button to start the playback in slow motion. The TV/VCR/DVD mutes the sound during slow motion. Press the PLAY button to return to normal playback. NOTE: If it is left in the Slow mode for more than 5 minutes, the TV/VCR/DVD will automatically go into the Stop mode.

STILL PICTURE

TV/VCR

You can view a still picture on the TV screen during playback (the Still mode). Press the PAUSE button during playback. Only tapes recorded in the SLP mode will show the least amount of lines. Press the PLAY button to return to playback.

NOTES:

You can advance the picture one frame at a time by

•

pressing the PAUSE button during the Still mode. If it is left in the Pause mode for more than 5 min-

•

utes, the TV/VCR/DVD will automatically switch to the Stop mode.

VERTICAL HOLD CONTROL

TV/VCR

In the Pause/Still mode only, when the picture begins to vibrate vertically, stabilize the picture by pressing the CHANNEL button K or L.

NOTE:

If there are video noise lines on the screen, see Tracking Adjustment section.

- 26 - EN

1C29

SPECIAL PLAYBACK

Make sure ...

TV/VCR/DVD’s power must be turned on.

•

Insert a prerecorded tape.

•

RENTAL PLAYBACK

TV/VCR

This function enables you to improve the picture quality when playing back worn cassettes such as rented tapes.

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button

K or L to

point to “USER’S SET UP”. Then press the ENTER button.

2 Set “RENTAL” to [ON]

Press the Arrow button K or L to point to “RENTAL”.

Press the ENTER button until [ON] appears.

3 Exit the Rental setting

Press the SETUP button on the remote control to return to the TV mode.

4 Start playback

Press the PLAY button to start playback. “RENTAL PLAY B” appears.

Once you select the Rental mode, it stays in effect

•

even after you turn off the TV/VCR/DVD.

TO CANCEL THE RENTAL MODE

Repeat steps [1] to [2], select [OFF] using the ENTER button on the remote control. Press the SETUP button on the remote control to return to TV mode.

If there is a power failure of any kind, the TV/VCR/DVD will retain its memory for this feature.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

USER’S SET UP

–

B RENTAL [ON]

REPEAT PLAY [OFF] AUTO RETURN [OFF] VCR AUDIO [HIFI] TV AUDIO [STEREO]

–

AUTO REPEAT PLAYBACK

TV/VCR

The TV/VCR/DVD has the auto repeat function that allows you to repeat a tape indefinitely without touching the PLAY button.

ALL REPEAT: Repeat playback from the beginning

to the end of the tape.

BLANK REPEAT: Repeat playback from the begin-

ning to a blank part, which is blank for more than 10 seconds.

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button

K or L to

point to “USER’S SET UP”. Then press the ENTER button.

2 Select “ALL” or “BLANK”

Press the Arrow button K or L to point to “REPEAT PLAY”.

Press the ENTER button repeatedly until your desired selection [ALL] or [BLANK] appears.

3 Exit the Repeat Play setting

Press the SETUP button on the remote control to return to the TV mode.

4 Start playback

Press the PLAY button to start the Repeat Play. “REPEAT PLAY B” appears.

Once you select the Repeat Play mode, it stays in

•

effect even after you turn off the TV/VCR/DVD. If the Rental mode is set [ON], the “RENTAL

•

PLAY B” display has priority.

TO CANCEL THE REPEAT PLAY MODE

Repeat steps [1] to [2], select [OFF] using the ENTER button on the remote control. Press the SETUP button on the remote control to return to TV mode.

If there is a power failure of any kind, the TV/VCR/DVD will retain its memory for this feature.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

USER’S SET UP

–

RENTAL [OFF]

B REPEAT PLAY [ALL]

AUTO RETURN [OFF] VCR AUDIO [HIFI] TV AUDIO [STEREO]

–

- 27 - EN

1C29

Make sure ...

TV/VCR/DVD power must be turned on.

•

Insert a tape.

•

ZERO RETURN

TV/VCR

This function allows you to search easily a specific point that you want to review by rewinding or fast forwarding.

NOTE:

The Time Search function makes it possible to quickly advance the tape to your desired location simply by entering the exact amount of playback time you want to skip.

NOTES:

•

Zero Return WILL NOT work on a blank tape or a blank portion of a tape.

1 Stop a tape at your desired point

Rewind or fast forward the tape to the beginning point at which you want to review.

2 Reset the counter to 0:00:00

•

In the example below: To watch a program before/ after 2 hour 50 minutes from the present position, in either direction.

Press the C.RESET button repeatedly.

1 Insert a tape

3 Begin recording or playback

Press the RECORD or PLAY button. Press the STOP button when recording or playback is

completed.

4 To activate “ZERO RETURN” mode

Press the SETUP button on the remote control.

Press the Arrow button

K or L to

point to “ZERO RETURN”. Then press the ENTER button. The counter will appear on the TV screen. The tape will automatically stop when the counter

returns to 0:00:00.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF]

B ZERO RETURN

TIME SEARCH INDEX SEARCH

PICTURE SEARCH

TV/VCR

This feature is very useful in finding or skipping over a particular scene on a tape. In this mode, the sound will be muted.

1)You may view a video tape at a high speed in either a forward or reverse direction by pressing the F.FWD g or REW h button during playback. (in the SP / LP / SLP modes)

NOTE:

If you press the F.FWD gor REW

•

on the front panel in the DVD mode, the VCR forward or reverse will start. Please press the STOP / EJECT button once to stop it, twice to eject it.

Press it again and the TV/VCR/DVD will now search in super high speed. (in the LP / SLP modes only)

NOTE:

Tapes recorded in the SP or LP mode will dis-

•

play a noise bar on the TV screen and the picture may revert to Black and White. This is normal.

3)Press the PLAY button to return to normal speed.

button

2 Select “TIME SEARCH” mode

Press the SETUP button on the remote control.

Press the Arrow button point to “TIME SEARCH”.

Then press the ENTER button.

3 Enter your desired time

Press the Arrow button K or L until your desired time appears. (Example: “2:50” stands for 2 hours 50 minutes)

If you wish to cancel the Time Search at this point, press the SETUP button on the remote control.

4 Begin Time Search

By pressing the Arrow button s or B, the TV/VCR/DVD will rewind or fast forward to the specified point.

The time counts down as the searching progresses. When 0:00 is reached, the tape will start playback automatically.

TO CANCEL THE TIME SEARCH at this point

Press the STOP/EJECT button on the TV/VCR/DVD or the STOP button on the remote control. This will delete the selected time.

- 28 - EN

TIME SEARCH

TV/VCR

Time Search can be set up to a maximum of 9 hours 50 minutes (9:50) by 10 minutes at a time.

This function will not operate in recording mode. This function is not operative when a cassette tape

is not inserted in the TV/VCR/DVD.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP

K or L to

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN

B TIME SEARCH

INDEX SEARCH

TIME SEARCH

2 : 50

1C29

INDEX SEARCH

TV/VCR

This feature provides a method of indexing the starting point so that it can be easily returned to in either fast forward or rewind mode.

The index mark will be made automatically when

•

the RECORD button is pressed. It will also be marked at the starting point of Timer recording and OTR.

The index mark will not be recorded if the PAUSE

•

button is pressed and released during recording. The time gap between making the index marks on

•

the tape should be greater than 1 minute for SP recording, 2 minutes for LP recording and 3 minutes for SLP recording.

In some cases, the index mark at the beginning of

•

video tape cannot be detected.

Example: You are watching program number 4 and

want to fast forward to program number 7. You must skip three programs.

CURRENT PLAYBACK PROGRAM

1 Select “INDEX SEARCH”

Press the SETUP button on the remote control. Press the Arrow button K or L to point to “INDEX SEARCH”. Then

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH

B INDEX SEARCH

press the ENTER button.

2 Enter your desired number

Press the Arrow button K or L until the number of programs that you want to skip appears. (Example: “03” for 3 programs)

The Index Search mode will be

•

canceled if the procedures are not activated in 30 seconds.

INDEX SEARCH

0 3

3 Begin Index Search

Press the Arrow button s or B. The TV/VCR/DVD begins rewinding or fast forwarding to the beginning of desired program.

NOTE: Every time an index signal is skipped, the number in the program indicator decreases by one.

Beginning of tape

Pro.1 Pro.2 Pro.3 Pro.4 Pro.5 Pro.6 Pro.7

4321123

INDEX MARK

End of tape

SPECIAL FEATURES

REAL TIME TAPE COUNTER

TV/VCR

This shows the elapsed recording or playback time in hours, minutes, and seconds. (The displayed time will not change on a blank tape or blank portions on the tape.)The “–” indication will appear when the tape has rewound further than “0:00:00” on the tape counter.

4 After Index Search

When the preset program is reached, the TV/VCR/DVD will start playback automatically.

A video cassette must be inserted in the

•

TV/VCR/DVD for this function to work. The number of Index Searches can be set up to 20.

•

This function will not operate in the recording mode.

•

When you want to cancel the Index Search while

•

in progress, press the STOP button.

AUTO REWIND-EJECT

TV/VCR

When the end of a tape is reached during record-

•

ing, playback, or fast-forward, the tape will automatically rewind to the beginning. After rewinding finishes, the TV/VCR/DVD will eject the tape and turn itself off.

This function is operative when Repeat Play is set

•

to the [OFF] position. The tape will not auto-rewind during timer record-

•

ing or One Touch Recording.

- 29 - EN

1C29

RECORDING

Make sure ...

TV/VCR/DVD power must be turned on.

•

Insert a cassette tape with its erase prevention tab in place. (If necessary, rewind or fast forward the tape to

•

the point at which you want to begin recording.)

NOTES:

This TV/VCR/DVD will ONLY record and view the same channel.

•

This TV/VCR/DVD cannot record the contents from the built-in DVD.

•

NORMAL RECORDING

TV/VCR

You can ONL being recorded.

1 Select the channel to be recorded

Press the number buttons on the remote control or the CHANNEL button K or L.

Remember: If the TV/VCR/DVD is connected to a cable box or satellite box, the TV/VCR/DVD must be on CH3 or CH4, then the channel to be recorded must be selected on the cable box or satellite box.

2 Select the tape speed

Press the SPEED button to select the desired tape speed (SP/ SLP).

3 Begin recording

Press the RECORD button.

Y watch the same TV program that is

REC

CH 10

SKIPPING UNWANTED

SCENES DURING RECORDING

TV/VCR

Press the PAUSE button to temporarily stop recording.

Press the PAUSE or RECORD button to resume recording.

NOTES:

After 5 minutes, the

•

TV/VCR/DVD will automatically switch to the Recording mode to prevent tape damage.

If “CLOSED CAPTION (ON)” is selected, the On-

•

Screen Display will appear for 5 seconds, then disappear.

PAUSE

4 Stop recording

Press the STOP button when recording is completed.

- 30 - EN

1C29

OTR (One Touch Recording)

REC/OTRTRSELECTPOWER

This function enables you to set a recording length simply by pressing the REC/OTR button on the TV/VCR/DVD.

Make sure ...

TV/VCR/DVD power must be turned on.

•

Insert a cassette tape with its erase prevention tab in

•

place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.)

NOTES:

You cannot start OTR with the remote control.

•

Recording starts immediately when the REC/OTR

•

button is pressed. When the REC/OTR button is pressed 18 times, the

•

TV/VCR/DVD returns to the Normal Recording mode. To stop the OTR operation, press the STOP button

•

on the TV/VCR/DVD or on the remote control. To show the remaining time, press the DISPLAY

•

button on the remote control so that “OTR” appears on the TV screen. (It will show up momentarily then disappear.)

Recording stops when 0:00 is reached.

•

Please note that in the SLP mode maximum record-

•

ing time, assuming the tape is started at the beginning, is 8 hours using T-160 (or 6 hours using T-120).

If the tape runs out before the end time, the

•

TV/VCR/DVD will switch to the Stop mode immediately, ejects the tape and turns itself off.

If you press the POWER button during OTR, the

•

TV/VCR/DVD continues recording until the selected length is reached.

1 Select the channel to be recorded

Press the number buttons on the remote control or the CHANNEL button K or L.

Remember: If the TV/VCR/DVD is connected to a cable box or satellite box, the TV/VCR/DVD must be on CH3 or CH4, then the channel to be recorded is selected on the cable box or satellite box.

2 Select the tape speed

Press the SPEED button to select the desired tape speed (SP/ SLP).

3 Begin OTR

Press the REC/OTR button on the TV/VCR/DVD as many times as needed. The recording length will be determined by the number of times you press the REC/OTR button. Each additional push will increase the recording time by 30 minutes. It is set up to a maximum of 8 hours.

OTR(2 : 30)

TV/VCR

Push(es) Display Recording length

1 push (normal recording) 2 pushes 0:30 30 minutes 3 pushes 1:00 60 minutes

17 pushes 8:00 480 minutes

COPYING A VIDEO CASSETTE

(Requires a VCR or camcorder)

TV/VCR

You can make copies of video tapes made by friends or relatives for your enjoyment.

You can not copy a DVD to a videotape.

WARNING: Unauthorized recordings of copyrighted video tapes may be an infringement of copyright laws.

Connect your TV/VCR/DVD and a Source (Playing) VCR or camcorder using the following diagram.

OUT

AUDIO

VIDEO

[Fig.8]

[The TV/VCR/DVD]

STOP

F.FWDREWREC/O

PLAY

EJECT

HEADPHONE

AUDIO RL

VIDEO

[Ex: Source (playing) VCR or camcorder]

Audio/Video adapter cable (not supplied)

1)Insert a pre-recorded video cassette into the Source (Playing) VCR or camcorder.

2)Insert a blank video cassette or one you want to record over, into the unit’s cassette compartment.

3)Press the SPEED button on remote control for the TV/VCR/DVD to select the desired recording speed (SP/SLP).

4)Press the CHANNEL button

K or L on the unit

until “AUX” appears on the screen.

5)Press the RECORD button on the unit.

6)Begin playback of the tape in the source (Playing) VCR or camcorder.

NOTE: For best results during copying, use the unit’s front panel controls whenever possible. The remote control might affect the source (Playing) VCR’s playback operation.

7)To stop copying, press the STOP/EJECT button on the unit, then stop the tape on the source VCR or camcorder.

- 31 - EN

1C29

TIMER

9:00AM 10:00AM 12:00PM

Program 1 10:00AM-11:00AM Program 2 9:00AM-10:00AM Program 3 9:30AM-12:00PM

11:00AM

Recording Sequence

*Recording period is SHADED

AUTOMATIC TIMER

RECORDING

TV/VCR

You may set the TV/VCR/DVD to start and end a recording while you are away. You can set 8 programs to record on specific days, daily or weekly within a 1 year period.

In the example below, the timer is being set to record:

DATE: July 4th, 2004 SETTING TIME: from 7:30PM to 8:50PM CHANNEL: CH61 TAPE SPEED: SP

Make sure ...

If a cable box or satellite box is connected with the

•

TV/VCR/DVD you will be limited to record only one channel, and the channel on the TV/VCR/DVD must be selected to the output channel of the box CH 3 or CH 4 and then the actual channel to be recorded must be selected on the box.

Clock must be set to the correct time and date

•

before setting the timer. TV/VCR/DVD power must be turn on to program it.

•

Insert a cassette tape with its erase prevention tab

•

in place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.)

The channel you want to record is properly set in

•

advance. (See page 18.)

Avoid over lap of programs ...

There is a chance that a program will not be recorded, when programs overlap;

The program with an earlier start has priority.

•

Once the earliest program finishes, the overlapping

•

programs will begin recording in sequence. When the starting time is the same, a program set

•

previously has priority. The illustration below demonstrates the sequence

•

of recordings. Program 1 10:00AM - 11:00AM

Program 2 9:00AM - 10:00AM Program 3 9:30AM - 12:00PM

1 Select “TIMER PROGRAMMING”

Press the SETUP button on the remote control.

Confirm “TIMER PROGRAMMING” is pointed by pressing the Arrow button

K, then press the

ENTER button.

If you have not yet set the clock, “MANUAL

•

CLOCK SET” appears. If so, follow steps [3] to [8] on pages 15, 16. Then set the timer recording.

2 Select your desired program

position (1~8)

Press the Arrow button K or L to select the desired program position.

Then press the Arrow button

- TV/VCR SETUP -

B TIMER PROGRAMMING

SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

3 Set the channel number

Press the Arrow button K or L until the desired channel number appears. (Example: CH61)

Then press the Arrow button

Remember: If the TV/VCR/DVD is connected to a cable box or satellite box, the TV/VCR/DVD must be on CH3 or CH4, then the channel to be recorded is selected on the cable box or satellite box.

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

4 Select once, every day or weekly recording

For once recording :

Press the Arrow button K (up) until the desired date appears. (Example: “7/04” for July 4th). Then press the Arrow button B.

For every day recording : To r ecord a TV program at the same time on the same channel every day. (Example: Monday through Sunday)

Press the Arrow button L (down) until “EVRY DAY” appears. Then press the Arrow button B.

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 7/04 SUN -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 EVRY DAY -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

For weekly recording : To r ecord a TV program at the same time on the same channel every week. (Example: every Monday)

Press the Arrow button L (down) until “EVRY” and your desired day of the week appear together. Then press the Arrow button B.

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 EVRY MON -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

- 32 - EN

1C29

5 Set beginning hour

Press the Arrow button K or L until the desired hour appears. (Example: “ 7, PM” for 7:30PM)

Then press the Arrow button

6 Set beginning minute

Press the Arrow button K or L until the desired minute appears. (Example: “30” for 7:

Then press the Arrow button

30PM)

7 Set end hour

Press the Arrow button K or L until the desired hour appears. (Example: “8, PM” for 8:50PM)

Then press the Arrow button

8 Set end minute

Press the Arrow button K or L until the desired minute appears. (Example: “50” for 8:50PM)

Then press the Arrow button

9 Set the tape speed

Press the Arrow button K or L until the desired tape speed appears. (Example: SP)

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 7/04 SUN 7:12

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 7/04 SUN 7:30

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 7/04 SUN 7:30

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 7/04 SUN 7:30

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

61 7/04 SUN 7:30

- - -/- - - - - -:- - -:- - - -

M 8:50PM- -

-:- - - -

8:30

8:50

10 Finish setting the program

Press the ENTER or RETURN button. The program is now completed.

To set another program, repeat steps [2] to [10].

•

Press the SETUP button on the remote control to

•

return to original mode.

TIMER PROGRAM EXTENSION

To shift the time schedule of an automatic timer recording.

1)Press the POWER button.

2)Repeat step [1] on page 32.

3)Press the RECORD button and select the desired program using the Arrow button

4)Press the RECORD button again. Each additional push will shift forward the

begin/end time for recording by 10 minutes. When the recording is already in progress, each additional push will shift forward the end time only. If you want to cancel while setting, press the PAUSE but-

- -

ton on the remote control. The recording time returns to the original time.

NOTE: When you shift forward the time schedule during recording, the recording speed will automatically be set to the SLP mode.

5)Press the ENTER or RETURN button to exit the setting menu. Then press the SETUP button on the remote control to return to original mode.

TO CORRECT A PROGRAM

While setting a program; press the Arrow button

•

s to go back one step and enter the correct num-

bers using the Arrow button K or L.

After setting a program;

•

1)Press the POWER button.

2)Repeat steps [1] to [2] on page 32.

3)Press the Arrow button

button s to go back one step) until the part you want to correct begins flashing, then make the changes pressing the Arrow button K or L.

4)Press the POWER button to set automatic timer

recording.

K or L.

B (or press the Arrow

TV/VCR

11 Set the timer

Press the POWER button to set automatic timer recording. The RECORDING indicator lights up.

You must turn off the TV/VCR/DVD to activate

•

automatic timer recording. If power is not turned off and you continue watch-

ing TV, “TIMER REC STANDBY” starts flashing on the TV screen 2 minutes before the programmed start time.

TO CANCEL AN AUTOMATIC TIMER RECORDING

After setting a program;

•

1)Press the POWER button.

2)Repeat steps [1] to [2] on page 32 and select a

program you want to cancel.

3)Press the C.RESET button.

4)Press the SETUP button on the remote control to

return to TV mode.

While recording is in progress;

•

1)Press the POWER button.

2)Press the STOP/EJECT button on the

TV/VCR/DVD.

- 33 - EN

1C29

TO CHECK THE BEGIN/END TIME

1)Press the POWER button so that the Recording indicator goes off.

2)Press the SETUP button on the remote control.

3)Confirm “TIMER PROGRAMMING” is pointed.

4)Press the ENTER button. The details of programs appear on the TV screen.

5)Press the SETUP button on the remote control to return to TV mode.

HINTS FOR AUTOMATIC

TIMER RECORDING

TV/VCR

Make sure the channel you want to record is prop-

•

erly set in advance. It is not necessary to press the RECORD button for

•

timer recording. Recording begins automatically at the Start time.

•

The display will not be turned on when the programmed

•

recording begins. To watch the currently recorded TV program or to play a DVD disc, press the POWER button to turn on the display and use the SELECT button to choose the TV/VCR mode or the DVD mode.

The erase-prevention tab on the cassette must be in

•

place (or you must put tape over the hole). If the erase-prevention tab is removed, the cassette will

•

be ejected when the POWER button is pressed to off. If the tape runs out before the end time, the

•

TV/VCR/DVD will switch to the Stop mode immediately and the tape will be ejected.

AUTO RETURN

3 Auto Return will begin

When all the timer recordings are completed, the TV/VCR/DVD will rewind to the beginning of the recorded program(s).

NOTE:

If you press the POWER button while tape is

•

rewinding, the Auto Return will stop.

4 Watch the recorded program

Press the PLAY button.

TO CANCEL THE AUTO RETURN MODE

Repeat steps [1] to [2], select [OFF] using the ENTER button.

If there is a power failure of any kind, the TV/VCR/DVD will retain its memory for this feature.

SLEEP TIMER

TV/VCR

The Sleep Timer function turns off the TV/VCR/DVD without using the POWER button after a desired period of time.

NOTE:

This function does not operate during Recording

•

mode.

1 Select “SLEEP TIMER”

Press the SLEEP button on the remote control until “SLEEP TIMER” appears.

TV/VCR

With this feature, after timer recording is finished, the beginning of the recorded program(s) can be searched for automatically.

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow button

K or L to

point to “USER’S SET UP”. Then press the ENTER button.

2 Set “AUTO RETURN” to [ON]

Press the Arrow button K or L to point to “AUTO RETURN”.

Press the ENTER button until [ON] appears.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

USER’S SET UP

–

RENTAL [OFF] REPEAT PLAY [OFF]

B AUTO RETURN [ON]

VCR AUDIO [HIFI] TV AUDIO [STEREO]

2 Set sleep time

Press the SLEEP button until your desired sleep time appears.

Each additional push will increase the time by 30 minutes up to 120 minutes.

SLEEP 120 MINUTES

After 5 seconds, the Sleep Timer setting will disappear automatically.

TO CANCEL THE SLEEP TIMER

Press the SLEEP button on the remote control until “SLEEP TIMER” appears. Press the SLEEP button

–

until “SLEEP 0 MINUTES” appears.

- 34 - EN

1C29

ON SCREEN DISPLAY

TV Display

CATV channel

TV Display

W+80 W+81 W+82 W+83 W+84

W+65 W+66 W+67 W+68 W+69 W+70 W+71 W+72 W+73 W+74 W+75 W+76 W+77 W+78 W+79

W+55 W+56 W+57 W+58 A-4 A-3 A-2 A-1 W+59 W+60 W+61 W+62 W+63 W+64

W+40 W+41 W+42 W+43 W+44 W+45 W+46 W+47 W+48 W+49 W+50 W+51 W+52 W+53 W+54

W+25 W+26 W+27 W+28 W+29 W+30 W+31 W+32 W+33 W+34 W+35 W+36 W+37 W+38 W+39

W+10 W+11 W+12 W+13 W+14 W+15 W+16 W+17 W+18 W+19 W+20 W+21 W+22 W+23 W+24

A-5

RSTUVWW+1 W+2 W+3 W+4 W+5 W+6 W+7 W+8 W+9

CDEFGH I JKLMNOPQ

5A 2 3 4 5 6 7 8 9 10 11 12 13 A B

123456789101112131415

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30

31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

46 47 48 49 50 51 52 53 54 55 56 57 58 59 60

61 62 63 64 65 66 67 68 69 70 71 72 73 74 75

76 77 78 79 80 81 82 83 84 85 86 87 88 89 90

91 92 93 94 95 96 97 98 99 100 101 102 103 104 105

106 107 108 109 110 111 112 113 114 115 116 117 118 119 120

121 122 123 124 125

CATV channel

To check the Counter, Clock and Channel number on the TV screen, press the DISPLAY button on the remote control. Each time you press the DISPLAY button on the remote control, the TV screen will change as follows:

When the Closed Caption mode is OFF:

Counter mode: After 5 seconds, only the counter

•

remains. To clear it, press the DISPLAY button. Clock mode: After 5 seconds, only the clock and

•

When the Closed Caption mode is ON:

The On Screen Display disappears after 5 seconds.

•

This is true even if the MUTE button is pressed or

•

the PAUSE button is pressed while recording. the channel number remain. To clear them, press the DISPLAY button.

OFF mode Counter mode Clock mode

STOP STOP

SP SPCOUNT 0:12:34

After 5 seconds After 5 seconds

COUNT 0:12:34

Counter remains

Clock & Channel remains

5:40PM

CH2

OFF mode Clock/Counter mode

STOP 5:40 PM

SP COUNT 0:12:34

CH2

CABLE CHANNEL DESIGNATIONS

If you subscribe to cable TV, the channels are displayed as 1-125. Cable companies often designate channels with letters or letter-number combinations. Please check with your local cable company. The following is a chart of common cable channel designations.

- 35 - EN

1C29

DVD SECTION

Example

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1 Chapter 2Chapter 3 Chapter 4

Example

Track 1 Track 2 Track 3 Track 4 Track 5 Track 6

ABOUT THE DISCS

PLAYABLE DISCS

The following discs can be played back on this TV/VCR/DVD.

DVD video

DVD+R/RW*

CD-R/RW*

* Depending on the types or the writing method of the

medium, some discs can not be played.

• Some DVD-R/RW, DVD+R/RW or CD-R/RW discs made on personal computers or on DVD recorders may not be played back properly due to the factors such as scratches, dirt or special properties of the disc.

• Discs made on personal computers may not be played back properly due to the different environment or the settings of the application you use. We recommend to always use standard, correctly formatted discs.

This TV/VCR/DVD conforms to the NTSC color system. You cannot play discs recorded in other color systems such as PAL or SECAM.

¡Some discs include region codes as shown below.

DVD-R/RW*

Audio CD

DISC TYPES

[

]

DVD

Data on a DVD is divided into sections called "titles" and then into subsections called "chapters", each of which is given a title or chapter number. Playback conditions are preset on some DVD video discs and these playback conditions take priority over user operations on this TV/VCR/DVD. If a function you selected does not run as desired, refer to the manual accompanying the disc.

[

AUDIO CD

Data on an audio CD is divided into sections called “tracks”, each of which is given a track number.

]

¡The number inside the symbol refers to a region of the

world and a disc encoded in a specific region format can only be played back on TV/VCR/DVD with the same region code.

The following discs cannot be played back on this TV/VCR/DVD.

DVD with region codes other than 1 or ALL

DVD-ROM

DVD-RAM (Never play back, otherwise malfunc-

CD-ROM

VSD

CDV (Only plays back the audio part.)

CD-G (Only plays back the sound.)

CD-I (Never play back, otherwise malfunction

SACD

Photo CD (Never play back, otherwise malfunc-

Video CD (Never play back, otherwise malfunc-

MP3

DTS-CD

tion may result.)

may result.)

tion may result.)

Any other discs without compatibility indications

–36–

01A11

PLAYING A DISC

BASIC PLAYBACK

DVD-V

Getting started

¡Turn on the power of any other components, if nec-

essary.

1 Press the POWER button.

The power will turn on.

2 Press the OPEN/CLOSE button to open disc

loading tray.

3 Place the chosen disc in the tray, with the

label facing up.

4 Press the PLAY button.

The tray will close automatically and playback will then start from the first chapter or track of the disc. If the playback does not start automatically, press the PLAY button.

¡When you playback a DVD which features a title

menu, it may appear on the screen. In this case, refer to “TITLE MENU”.

5 Press the STOP button to stop playback.

GENERAL FEATURES

DVD-V

VD may contain menus to navigate the disc and

access special features. Press the appropriate number buttons or use the Arrow button (K/L/s /B) to highlight your selection in the DVD main menu and press the ENTER button to confirm.

NOTES

¡Select DVD mode by pressing the SELECT button on

the remote control. Then operate the DVD functions.

¡Unless stated, all operations described are based on

remote control use. Some operations can be carried out using the menu bar on the TV screen.

DISC MENU

DVD-V

1 Press the DISC MENU button.

The DVD main menu will appear.

2 If the feature is not available, symbol

may appear on the TV screen.

3 If disc menu is available on the disc, audio

language, subtitle options, chapters for the title and other options will appear for selection.

4 Press the Arrow button (K/L/s /B) to

select an item and the ENTER button to confirm selection.

NOTES

¡When the DVD mode has been switched to the

TV/VCR mode, the DVD mode shuts down first and then the TV picture and sound appears in about 4 seconds. Similarly, when the POWER button is pressed to turn off in the DVD mode, this mode shuts down first and then the TV/VCR/DVD’s power is turned off.

¡A “prohibited icon” may appear at

the top-right on the TV screen during operation, warning that a prohibited operation has been encountered by the DVD or the disc.

¡With DVDs that use titles for playback program sig-

nals, playback may start from the second title or it may skip these titles.

¡During the playback of a two layered disc, pictures

may stop for a moment. This happens when the 1st layer switches to the 2nd layer. This is not a malfunction.

TITLE MENU

1 Press the TITLE button.

The title menu will appear.

2 If the feature is not available, symbol

may appear on the TV screen.

3 Press the Arrow button (K/L/s/B) to

select an item and the ENTER button to confirm selection.

CALLING UP A MENU SCREEN DURING PLAYBACK

¡Press the DISC MENU button to call up the DVD menu. ¡Press the TITLE button to call up the title menu.

NOTE

¡Contents of menus and corresponding menu opera-

tions may vary between discs. Refer to the manual accompanying the disc for details.

–37–

DVD-V

01A11

RESUME

DVD-V

FAST FORWARD/REVERSE

DVD-V

1 During playback, press the STOP button.

Resume message will appear on the TV screen.

2 Press the PLAY button, playback will resume

from the point at which playback was stopped.

To cancel resume, press the STOP button twice.

¡If TV/VCR/DVD is turned off, resume function will

be cancelled.

PAUSE

DVD-V

1 During playback, press the PAUSE button.

Playback will pause and sound will be muted.

2 To continue playback, press the PLAY button.

STEP BY STEP PLAYBACK

DVD-V

1 During playback, press the PAUSE button.

Playback will pause and sound will be muted.

1 During playback, press and hold the SKIP

(

h/g

“ g 1” or “h 1” appears on the screen.

) button for a few seconds.

2 To select another speed, repeat step [1] until

your required speed appears on the screen.

For DVDs, fast forward/reverse search speed is different depending on the disc. Approximate speed is 1 (×2), 2 (×8), 3 (×50) and 4 (×100).

¡For audio CDs, approximate speed is ×16. ¡When you use buttons on the front panel, use the

SKIP G / SEARCH g or SKIP H / SEARCH h button.

3 To return to normal playback, press the

PLAY button.

SLOW FORWARD /

SLOW REVERSE

DVD-V

1 During playback, press the PAUSE button.

2 Press and hold the SKIP (

for a few seconds.

“ 1” or “ 1” appears on the screen.

h/g

) button

2 The disc goes forward by one frame each

time the PAUSE button is pressed.

3 To exit step by step playback, press the

PLAY button.

3 To select another speed, repeat step [2] until

your required speed appears on the screen.

Slow forward or reverse speed varies with the disc. Approximate speed is 1 (1/16), 2 (1/8) and 3 (1/2).

¡When you use buttons on the front panel, use the

SKIP G / SEARCH g or SKIP H / SEARCH h button.

4 To return to normal playback, press the

PLAY button.

–38–

01A11

SEARCH FUNCTION

TRACK SEARCH

There are three ways to begin playback on an Audio CD at a specific track.

Using the Number buttons on the remote control

1 Press the Number buttons to enter the

desired Track number.

Playback will start at the selected track.

¡For single digit tracks (1-9), press a single number

(eg. track 3, press 3).

¡To play track 26, press +10, 2, 6.

Using the SEARCH MODE button

1 Press the SEARCH MODE button.

The track search display appears.

2 Within 30 seconds, select a desired track

number using the Number buttons on the remote control.

For single digits press 0 first, if the total track of the disc is more than 10 tracks.

¡Playback will start at the selected track.

Using the SKIP

During playback, press the SKIP G button to move the next track. Press it repeatedly to skip subsequent tracks. Press the SKIP H button to go back to beginning of the current track. Press it repeatedly to go to the previous tracks.

¡If the SKIP button is pressed while the playback is

paused, the playback will be paused again after skipping to the next track.

NOTE

¡The SKIP HGbuttons are not available when

playback is stopped.

buttons

TITLE / CHAPTER SEARCH

DVD-V

1 Press the SEARCH MODE button once for

the Chapter search, twice for the Title search during playback.

_/2

2 Enter the desired chapter/title number using

the Number buttons on the remote control.

Playback will start at the selected chapter or title.

¡Press the CLEAR button to erase the incorrect input. ¡For single digits press 0 first, if the total chapter or

title of the disc is more than 10.

TIME SEARCH

DVD-V

1 During playback, press the SEARCH MODE

button three times (CD: twice) to display the Time Search on the TV screen.

2 Within 30 seconds, enter a desired disc

time using the Number buttons on the remote control.

Playback will start at the specified time.

¡Press the CLEAR button to erase the incorrect input. ¡When there is no need to enter a number, “0”

appears automatically. For example, “ 0 : 0 - : appears in the Time Search display if the total time of the track or title is less than 10 minutes.

MARKER SETUP SCREEN

DVD-V

Use markers to memorize your favorite places on a disc.

1 Press the SEARCH MODE button four times

(CD: three times) during playback.

The display screen and Markers will appear on the TV screen.

2 Press the Arrow button (s/ B) to select 1, 2,

3, 4, 5, 6, 7, 8, 9, or 10 and ensure that “

- :- - :- -

3 When you reach the desired point, press the

ENTER button.

The Title or Track and elapsed playing time will appear in the TV screen.

4 To return to the Marker later, press the

SEARCH MODE button four times (CD: three times) during playback and the Arrow button (s / B) to choose the desired marker, then press the ENTER button.

NOTES

¡Opening the disc tray or turning off the power or

pressing the SELECT button or selecting AC at step [2] and pressing the ENTER button will erase all Markers.

¡To clear a marker, using the Arrow button (s /B

position the cursor on to the marker number to be cleared and press the CLEAR button.

¡Yo u can mark up to 10 points.

5 Press the SEARCH MODE or RETURN but-

ton to exit.

–39–

” appears in the display.

- - -

01A11

- -

”

)

SPECIAL PLAYBACK FUNCTION

REPEAT

REPEAT is available only during playback.

REPEAT TITLE / CHAPTER

DVD-V

To activate the repeat function, press the REPEAT button during playback.

The repeat mode changes as described below every time you press the button.

CHAPTER TITLE OFF

(current chapter repeat) (current title repeat)

NOTES

¡Repeat Title/Chapter is not available with some

scenes.

¡The REPEAT setting will be cleared when moving

to other title or chapter.

REPEAT TRACK/ALL

To activate the repeat function, press the REPEAT button during playback.

The repeat mode changes as described below every time you press the button.

TRACK ALL OFF

(current track repeat) (entire disc repeat)

NOTES

¡Repeat setting will be cleared when moving to other

track.

¡Repeat playback does not function during repeat A-B

playback.

A-B REPEAT

DVD-V

(repeat off)

PROGRAM

You may determine the order in which tracks will play.

1 In stop mode, press the MODE button.

The PROGRAM screen will appear.

2 Press the Arrow button ▲ or ▼ to select a

track, then press the ENTER button.

Press the CLEAR button to

erase the most recently entered program.

TOTAL

3 Repeat step [2] until you have selected all

the tracks you want to play in the program.

4 Press the PLAY button to play the pro-

grammed tracks.

NOTES

¡While the program is being played back, the STOP

works as follows.

¡Press the STOP button once and then the PLAY but-

ton again, playback will restart from the point where the STOP button was pressed. (Program continued)

¡Press the STOP button twice and then the PLAY but-

ton again, playback will restart from the track in the usual way. (Program canceled)

¡Up to 99 programs can be entered. ¡To erase all tracks in the program at once, select

ALL CLEAR at the bottom of the list at step [2].

¡If you like to repeat the current track in the program,

press the REPEAT button repeatedly until “ TRACK” appears during playback. If you like to repeat the entire program press the REPEAT button repeatedly until “ ALL” appears during playback.

RANDOM PLAYBACK

1 Press the A-B REPEAT button at your cho-

sen starting point.

A- appears briefly on the TV screen.

2 Press the A-B REPEAT button again at your

chosen end point.

A-B appears briefly on the TV screen and the

repeat sequence begins.

To exit the sequence, press the A-B REPEAT button.

NOTES

¡The A-B repeat section can only be set within the cur-

rent title (for DVDs) or current track (for audio CDs).

¡A-B repeat is not available with some scenes in DVD. ¡To cancel the A point which was set, press the

CLEAR button.

¡A-B repeat playback does not function during title,

chapter, track or all repeat playback.

This shuffles the playing order of tracks instead of playback in sequence.

1 In stop mode, press the MODE button twice.

RANDOM screen appears.

RANDOM

CD-DA TOTAL 0:45:55

PLAY

2 Press the PLAY button to start random playback.

NOTE

¡If you like to repeat the current track in the random

selection, press the REPEAT button repeatedly until “ TRACK” appears during playback. If you like to repeat the entire random selection press the REPEAT button repeatedly until “ ALL” appears during playback.

–40–

RANDOM PROGRAM

- - no indication - -

01A11

CHANGING THE SETTINGS

SUBTITLE LANGUAGE CAMERA ANGLE

DVD-V

The TV/VCR/DVD allows you to select a language for subtitles during DVD (if available) playback.

1 Press the SUBTITLE button during playback. 2 Press the SUBTITLE button repeatedly to

select your desired subtitle language.

The subtitle language will appear on the display bar at the top of the TV screen.

3 To turn off subtitles, press the SUBTITLE

button repeatedly until OFF appears.

NOTES

Some discs allow audio language setting/subtitle language setting on the disc menu. (Operation varies between discs, so refer to the manual accompanying the disc.)

¡If the desired language is not shown after pressing

the SUBTITLE button several times, the disc does not have subtitles in that language.

¡If you choose a Language that has a 3 letter language

code, the code will be displayed every time you change the Subtitle language setting. If you choose any other languages, ‘---’ will be displayed instead. (Refer to page 43.)

AUDIO LANGUAGE

DVD-V

The TV/VCR/DVD allows you to select a language during DVD disc (if multi languages are available) playback.

1 Press the AUDIO button during playback. 2 Press the AUDIO button repeatedly to select

your desired language.

NOTE

¡Pressing the AUDIO button may not work on some

DVDs with multiple audio languages (e.g. DVDs which allow audio language setting on the disc menu).

DVD-V

Some DVD discs contain scenes which have been shot simultaneously from various angles. You can change the camera angle when the ( ) icon appears on the screen.

1 Press the ANGLE button during playback.

The selected angle will be displayed on the display

bar at the top of the screen.

2 Press the ANGLE button repeatedly to

select your desired angle.

BLACK LEVEL SETTING

DVD-V

Adjust the Black Level Settings to make the black parts of the picture brighter.

1 Press the MODE button during playback.

OFF

2 Press the ENTER button to switch OFF.

ON : Makes the dark parts brighter. OFF : Shows the original picture as recorded.

3 Press the MODE button twice or the

RETURN button to exit.

NOTE

¡The setting will be saved even if the TV/VCR/DVD

is turned off.

VIRTUAL SURROUND

DVD-V

You can enjoy surround-sound effect over two speakers on this TV/VCR/DVD.

STEREO SOUND MODE

1 Press the AUDIO button repeatedly during

playback to select between STEREO, L-CH or R-CH.

STEREO - both right and left channels are active (stereo) L-CH - only left channel is active R-CH - only right channel is active

NOTE

¡I

f the Virtual Surround setting is ON, the sound mode

will be set to STEREO and can not be changed.

–41–

1 Press the V.SURR button once or the MODE

button twice (CD: once) during playback.

OFF

2 Press the ENTER button to set it 1 (Natural

effect) or 2 (Emphasized effect) or OFF.

3 Press the V. SURR, MODE, or RETURN button

to exit.

NOTE

(for CD play only) This function is not effective if the sound mode is set to something other than STEREO

01A11

THE ON-SCREEN INFORMATION

DVD-V

You can check the information about the current disc by pressing the DISPLAY button on the remote control.

For DVD-Vs

1 Press the DISPLAY button during playback

to show current Chapter.

The elapsed and remaining playing time of the current

9/49 0:00:00 -0:03:30

For audio CDs

1 Press the DISPLAY button during playback

to show the current Track.

The elapsed and remaining playing time of the current track will be displayed.

chapter will be displayed.

2 Press the DISPLAY button again to show

current Title.

The elapsed and remaining playing time of the current title will be displayed.

current Total Track.

The elapsed and remaining playing time of the total track will be displayed.

3 Press the DISPLAY button again to exit the

3 Press the DISPLAY button again.

The BIT RATE and the current repeat setting will be

displayed.

¡If you are playing a dual layered disc, the layer num-

ber will also be displayed (L0: Layer 0 is playing. L1: Layer 1 is playing).

display.

4 Press the DISPLAY button again to exit the

display.

–42–

01A11

CHANGING THE DVD SETUP ITEMS

LANGUAGE SETTING

DVD-V

Language options are not available with some discs.

1 Press the SETUP button twice in STOP

mode so that the DVD SETUP menu appears.

If the menu does not appear, press the PLAY button, the STOP button, then the SETUP button twice.

SETUP

QUICK CUSTOM INITIALIZE

2 Press the Arrow button L to select CUS-

TOM, then press the ENTER button.

CUSTOM mode will appear.

3 Press the Arrow button (K/L) to select

“LANGUAGE”, then press the ENTER button to confirm.

SETUP CUSTOM

LANGUAGE DISPLAY AUDIO PARENTAL

4 Press the Arrow button (K/L) to select the

next items, then press the ENTER button.

AUDIO: Sets the audio language. SUBTITLE: Sets the subtitle language. DISC MENU: Sets the language for DVD menu.

5 Press the Arrow button (K/L) to select a

setting, then press the ENTER button.

If OTHER is selected on the AUDIO, SUBTITLE or

DISC MENU screen, press four-digit number to enter the code for the desired language. (Refer to the language code list.)

¡Only the languages supported by the disc can be

selected.

6 Press the SETUP button to exit.

NOTE

¡Language Setting for Audio and Subtitle is not avail-

able with some discs. Then use the AUDIO and the SUBTITLE buttons. (Details are on page 41.)

TO CHANGE THE ON-SCREEN MENUS

You can access the TV/VCR SETUP menu by pressing the SETUP button from the DVD mode. Refer to “SELECTING THE LANGUAGE” on page 15 to changing the on-screen menus.

Language Code

Abkhazian 4748 Afar 4747 Afrikaans 4752 Albanian 6563 Amharic 4759 Arabic 4764 Armenian 5471 Assamese 4765 Aymara 4771 Azerbaijani 4772 Bashkir 4847 Basque 5167 Bengali;Bangla 4860 Bhutani 5072 Bihari 4854 Bislama 4855 Breton 4864 Bulgarian 4853 Burmese 5971 Byelorussian 4851

Cambodian 5759 Catalan 4947 Chinese [CHI] 7254 Corsican 4961 Croatian 5464 Czech 4965 Danish [DAN] 5047 Dutch [DUT] 6058 English [ENG] 5160 Esperanto 5161 Estonian 5166

Faroese 5261 Fiji 5256 Finnish [FIN] 5255 French [FRE] 5264 Frisian 5271 Galician 5358 Georgian 5747 German [GER] 5051 Greek [GRE] 5158 Greenlandic 5758 Guarani 5360 Gujarati 5367 Hausa 5447 Hebrew 5569 Hindi 5455 Hungarian [HUN] 5467

Icelandic [ICE] 5565 Indonesian 5560 Interlingua 5547 Interlingue 5551 Inupiak 5557 Irish [IRI] 5347 Italian [ITA] 5566 Japanese [JPN] 5647 Javanese 5669 Kannada 5760 Kashmiri 5765 Kazakh 5757 Kinyarwanda 6469 Kirghiz 5771 Kirundi 6460 Korean [KOR] 5761 Kurdish 5767

A-B

C-E

F-H

I-K

Language Code

Laothian 5861 Latin 5847 Latvian;Lettish 5868 Lingala 5860 Lithuanian 5866 Macedonian 5957 Malagasy 5953 Malay 5965 Malayalam 5958 Maltese 5966 Maori 5955 Marathi 5964 Moldavian 5961 Mongolian 5960 Nauru 6047 Nepali 6051 Norwegian [NOR] 6061

Occitan 6149 Oriya 6164 Oromo(Afan) 6159 Panjabi 6247 Pashto;Pushto 6265 Persian 5247 Polish 6258 Por tuguese [POR] 6266 Quechua 6367 Rhaeto-Romance 6459 Romanian [RUM] 6461 Russian [RUS] 6467

Samoan 6559 Sangho 6553 Sanskrit 6547 Scots Gaelic 5350 Serbian 6564 Serbo-Croatian 6554 Sesotho 6566 Setswana 6660 Shona 6560 Sindhi 6550 Singhalese 6555 Siswat 6565 Slovak 6557 Slovenian 6558 Somali 6561 Spanish [SPA] 5165 Sundanese 6567 Swahili 6569 Swedish [SWE] 6568

Tagalog 6658 Tajik 6653 Tamil 6647 Tatar 6666 Telugu 6651 Thai 6654 Tibetan 4861 Tigrinya 6655 Tonga 6661 Tsonga 6665 Tu rkish [TUR] 6664 Tu rkmen 6657 Tw i 6669

Ukrainian 6757 Urdu 6764 Uzbek 6772 Vietnamese 6855 Volapuk 6861 Welsh 4971 Wolof 6961 Xhosa 7054 Yiddish 5655 Yo r uba 7161 Zulu 7267

L-N

O-R

U-Z

If you choose a Language that has a 3 letter language code, the code will be displayed every time you change the Audio or Subtitle language setting on page 41. If you choose any other languages, ‘---’ will be displayed instead. (3 letter language code is written in bracket.)

–43–

01A11

DISPLAY SETTING

AUDIO SETTINGS

DVD-V

You can change certain aspects of the DVD display screens and on-screen messages on the TV screen.

1 Press the SETUP button twice in STOP mode

so that the DVD SETUP menu appears.

If the menu does not appear, press the PLAY button, the STOP button, then the SETUP button twice.

SETUP

QUICK CUSTOM INITIALIZE

2 Press the Arrow button L to select CUS-

TOM, then press the ENTER button.

CUSTOM mode will appear.

3 Press the Arrow button (K/L) to select “DIS-

PLAY”, then press the ENTER button to confirm.

SETUP CUSTOM

LANGUAGE DISPLAY AUDIO PARENTAL

Press the Arrow button (K/L) to select the below items, then press the ENTER button.

DVD-V

Choose the appropriate Audio settings for your equipment as it only affects during the playback of DVD discs.

1 Press the SETUP button twice in STOP mode

so that the DVD SETUP menu appears.

If the menu does not appear, press the PLAY button, the STOP button, then the SETUP button twice.

SETUP

QUICK CUSTOM INITIALIZE

2 Press the Arrow button L to select “CUS-

TOM”, then press the ENTER button.

CUSTOM mode will appear.

3 Press the Arrow button (K/L) to select

“AUDIO”, then press the ENTER button to confirm.

SETUP CUSTOM

LANGUAGE DISPLAY AUDIO PARENTAL

TV MODE:

QUICK

¡Press the Arrow button (K/L) for an item selection,

then press the ENTER button.

¡Select 4:3 LETTER BOX for black bars to appear on

top and bottom of the screen.

Select 4:3 PAN & SCAN for a widescreen DVD presentation as full height picture with both sides trimmed. This allows you to fill your entire screen by eliminating some of the widescreen picture content.

¡The default setting is 4:3 LETTER BOX.

STILL MODE

¡Press the Arrow button (K/L) for an item selection,

then press the ENTER button.

¡Select “AUTO” usually. ¡If you select “FIELD”, the picture in the still mode

will be stabilized.

¡If you select “FRAME”, the picture in the still mode

will be highly defined.

ANGLE ICON:

¡Press the ENTER button repeatedly to turn Angle

icon ON or OFF.

¡The default setting is ON.

AUTO POWER OFF:

¡Press the ENTER button repeatedly to turn Auto

Power off ON or OFF.

The default setting is ON and the screen saver program starts when there is no input from the TV/VCR/DVD for 5 minutes in the stop mode. When the screen saver program is activated for 15 minutes, the power automatically turns off.

4 Press the Arrow button (K/L) to select the

below items, then press the ENTER buttons.

DRC (Dynamic Range Control):

¡To compress the range of soft to loud sound. ¡The default setting is ON.

DOWN SAMPLING:

¡Set to ON when outputting in 48 kHz. ¡The default setting is ON.

When playing disc with copyright Protection

¡If you select OFF, copyright protection will be acti-

vated and sound will be down sampled at 48kHz.

DOLBY DIGITAL:

QUICK

Set to On when the unit is connected to a Dolby Digital Decoder.

(ON: Output a Dolby Digital signal) (OFF: Convert the Dolby Digital to PCM (2 channel stereo))

¡The default setting is ON.

5 Press the SETUP button to exit.

–44–

01A11

PARENTAL CONTROL

DVD-V

Parental Control limits the disc viewing that exceed your settings (with a password or playback will stop). This feature allows you to prevent discs with objectionable material from being played by your children.

PARENTAL LEVEL

Parental Level allows you to prevent the playback of DVDs that exceed rating levels that you choose. You create a password, and unless the password is entered, DVDs that exceed your chosen ratings will not play. This feature allows you to prevent children from playing inappropriate DVDs.

CONTROL LEVELS

ALL

All parental lock is cancelled.

Level 8

DVD software of any grade (adult/general/children) can be played back.

Levels 7 to 2

Only DVD software intended for general use and children can be played back.

Level 1

Only DVD software intended for children can be played back, with those intended for adult and general use is prohibited.

IF YOU FORGET THE PASSWORD

1 Press the SETUP button twice in STOP mode

so that the QUICK SETUP menu appears.

If the menu does not appear, press the PLAY button, the STOP button, then the SETUP button twice.

2 Press the Arrow button L to select “CUS-

TOM”, then press the ENTER button.

SETUP

QUICK CUSTOM INITIALIZE

3 Press the Arrow button (K/L) to select

“PARENTAL”, then press the ENTER button.

SETUP CUSTOM

LANGUAGE DISPLAY AUDIO PARENTAL

4 Enter your four-digit password then press

the ENTER button.

5 Press the Arrow button (K/L) to select

“PARENTAL LEVEL”, then press the ENTER button.

6 Press the Arrow button (K/L) to select the

desired level, then press the ENTER button.

1 Press the number buttons 4, 7, 3, 7 at step

[4]. Then enter your new password.

Password will be cleared and parental level will be set to ALL.

2 Proceed the steps [5] to [7] again.

INITIALIZE

This allows you to return all selections of SETUP (except for PARENTAL) to their default settings.

1 Press the SETUP button twice in STOP

mode so that the INITIALIZE menu appears.

2 Press the Arrow button (K/L) to select “INI-

TIALIZE”, then press the ENTER button.

3 Select “YES”, then press the ENTER button

twice. All the settings (except for “PARENTAL”) will be cleared.

To cancel the initialization, select “NO”.

4 Press the SETUP button to exit.

7 Press the SETUP button to exit

NOTES

¡When doing this for the first time, enter any 4 digits.

(except for 4737) That number will be used as the password.(in the event you forget the password, see below)

¡To change the password, press the Arrow button

(K/L) to select CHANGE at step [5], then press the ENTER button. Enter the four-digit password, then press the ENTER button.

¡With some DVDs, it may be difficult to find if they

are compatible with parental lock. Be sure to check if the parental lock function operates in the way that you have set.

¡Record the password in case you forget it.

–45–

01A11

TROUBLESHOOTING GUIDE

If the TV/VCR/DVD does not perform properly when operated as instructed in this Owner’s Manual, check the TV/VCR/DVD, consulting the following checklist.

PROBLEM CORRECTIVE ACTION

No power

The TV/VCR/DVD does not respond to the remote control

TV/VCR Mode

Sometimes a performance problem can be easily solved by checking seemingly apparent but often overlooked possibilities. Before arranging for service, check these items. It could save your time and money.

PROBLEM CORRECTIVE ACTION

No picture and sound

No picture or poor picture on TV/VCR/DVD

No sound or poor sound

Bars On Screen

Picture Distorted or Blurred

Picture Rolls Vertically Lines or Streaks in Picture

No Color

Poor Reception on Some Channels Ghosts in Picture

Weak Picture

Sound OK, Picture Poor

Make sure the power plug is connected to an AC outlet.

•

Make sure the power is turned on.

•

Check if the power plug is connected to an AC outlet.

•

Check the batteries in the remote control.

•

Aim the remote control directly at the remote sensor. If necessary,

•

remove all the obstacles between the sensor and the remote. You have to be within 23 feet of the TV/VCR/DVD.

•

Check if the correct mode is selected. If not switch the mode by

•

pressing the SELECT button on the remote control,whichever you need.

Make sure the AC cord is connected to an AC outlet.

•

Check antenna connection.

•

Press the SELECT button on the remote control to select TV mode.

•

Then try other TV feature. Let the TV/VCR/DVD program its tuner memory.

•

Adjust direction or replace antenna.

•

Adjust picture controls.

•

Adjust volume control on remote control or main unit.

•

Press the MUTE button to restore sound.

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Try a new channel, if OK, then possible station trouble.

•

If outside antenna is being used, check for broken wire.

•

Try a new channel, if OK, then possible station trouble.

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Adjust COLOR control.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Adjust CONTRAST & BRIGHT control.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Adjust CONTRAST & BRIGHT control.

•

–46–

01A11

PROBLEM CORRECTIVE ACTION

Picture OK, Sound Poor

Timer recording is not possible

Cannot go into Record mode

Playback picture is partially noisy •

No picture but the audio is OK in • Head cleaning may be necessary. Refer to “AUTO HEAD playback • CLEANING” on page 49.

No operation by infrared Remote

Control Video or color fades in and out

when making a copy of a video tape Distorted color appears on screen

Try a new channel, if OK, then possible station trouble.

•

Check for local interference.

•

Make sure the timer recording is set correctly.

•

Make sure the power is off.

•

Make sure the TV/VCR/DVD clock is set correctly.

•

Make sure the tape has an erase-prevention tab. If need, cover the

•

hole with plastic tape.

•

Adjust tracking control for a better picture using the CHANNEL button K or L on the TV/VCR/DVD.

•

Make sure the AC cord is connected to an AC outlet.

•

Check batteries in remote control.

•

You can not copy a copyrighted video tape. You are experiencing

• copy guard protection.

Magnetism from nearby appliances and unshielded speakers and

•

geomagnetism might affect the color of the TV picture. Move the TV/VCR/DVD

TV/VCR/DVD immediately,

minutes later or so. This automatically resets the TV/VCR/DVD.

away from the appliances or unshielded speakers, the can repair itself automatically. If you want to repair

unplug the power cord, then plug it in again after 30

CLOSED CAPTION PROBLEM POSSIBLE REMEDY

My TV/VCR/DVD is showing • You are watching a live broadcast and spelling errors made by the captions that are misspelled. • closed captioning production company may pass through uncorrected.

• A prerecorded program will not show any misspelled words because

• of the normal time available for editing the captions.

My TV/VCR/DVD will not show • Captions that are delayed a few seconds behind the actual the text dialogue in its entirety or are common for live broadcast. Most captioning production there is a delay of what is being • companies can display a dialogue to a maximum of 220 words said. • per minute. If a dialogue exceeds that rate, selective editing is used

• to insure that the captions remain up-to-date with the current

• TV screen dialogue.

My captions are scrambled with • Interference caused by building, power lines, thunderstorms, etc. white boxes on the TV screen. • may cause scrambled or incomplete captions to appear.

My program guide listed a TV show as being closed captioned but none • up the actual program so that additional advertising time can be of the captions were displayed. • given. Since the decoder cannot read the compressed information,

My prerecorded video tape does not show any captions. The tape box • company accidentally left out the captioning signals during the mentions it being closed captioned. • copying process.

My TV screen shows a black box • You are in the TEXT mode. Select CAPTION mode to CAPTION on certain channels. • [OFF].

• Broadcasters may at times use a time compression process to speed

• captions will be lost.

• The video tape was either an illegal copy or the tape duplicating

–47–

01A11

DVD Mode

PROBLEM CORRECTIVE ACTION

No picture • Insert a correct video disc that plays on this TV/VCR/DVD.

• Press the SELECT button on the remote control to select DVD mode. Then, try other DVD feature.

Disc cannot be played

No sound

No DTS audio is output

Distorted picture

Audio or subtitle language • does not match the set up The camera angle cannot be changed •

Audio or subtitle language cannot be • The DVD does not contain audio source or subtitles in the selected changed language. “Prohibited icon” appears on the • That operation is prohibited by the TV/VCR/DVD or the disc. screen, prohibiting an operation CD sound dropout • Scratched disc. Replace the disc with an unscratched one. No CD reproduction DVD picture dropout DVD picture freeze DVD picture in mosaic No DVD reproduction

• Insert the disc.

• Clean the disc.

• Place the disc correctly, with the label side up.

• Cancel the parental lock or change the control level.

• Connect the audio cables firmly.

• Turn the power of the audio component on.

• Correct the audio output settings.

• Correct the input settings on the audio component.

• This TV/VCR/DVD does not support DTS audio. This is not a malfunction.

• There are some cases where pictures may be slightly distorted, which are not a sign of a malfunction.

• Although pictures may stop for a moment, this is not a malfunction. The selected language is not available for audio or subtitles on the DVD.

This is not a malfunction

The DVD does not angles.

This is not a malfunction.

This is not a malfunction

contain sequences recorded from different camera

This is not a malfunction.

NOTES:

Some functions are not available in specific modes, but this is not a malfunction. Read the description in

•

this Owner’s Manual for details on correct operations.

Playback from a desired track and random playback are not available during program playback.

•

–48–

01A11

MAINTENANCE

Recordable

ReWritableReWritable

CABINET CLEANING

Wipe the front panel and other exterior surfaces of

•

the TV/VCR/DVD with a soft cloth immersed in lukewarm water and wrung dry.

Never use a solvent or alcohol. Do not spray insec-

•

ticide liquid near the TV/VCR/DVD. Such chemicals may cause damage and discoloration to the exposed surfaces.

1.Please visit your local Audio/Video store and purchase a good quality VHS Video Head Cleaner.

2.If a Video Head Cleaner does not solve the problem, please call our help line at 1-800-488-1222, to locate an Authorized Service Center.

NOTES:

Remember to read the instructions included with

•

the video head cleaner before use. Clean video heads only when problems occur.

•

AUTO HEAD CLEANING

Automatically cleans video heads as you insert or

•

remove a cassette, so you can see a clearer picture. Playback picture may become blurred or interrupt-

•

ed while the TV program reception is clear. Dirt accumulated on the video heads after long periods of use or the usage of rental or worn tapes can cause this problem. If a streaky or snowy picture appears during playback, the video heads in your TV/VCR/DVD may need to be cleaned.

SERVICING

Should your TV/VCR/DVD become inoperative,

•

do not try to correct the problem by yourself. There are no user-serviceable parts inside. Turn off, unplug the power cord and please call our help line at 1-800-488-1222, to locate an Authorized Service Center.

IF THE LASER OPTICAL PICKUP UNIT IS DIRTY

If the TV/VCR/DVD still does not perform properly when it is operated, while referring to the relevant sec-

•

tions and to "TROUBLESHOOTING GUIDE" in this Owner's Manual, the laser optical pickup unit may be dirty. Consult your dealer or an Authorized Service Center for inspection and cleaning of the laser optical pickup unit.

DISC HANDLING

Use discs which have the following logos on them.

•

(Optical audio digital discs.)

Handle the discs so that fingerprints and dust do

•

not adhere to the surfaces of the discs.

Always store the disc in its protective case when it

•

is not used.

To clean-off, use a soft cloth.

•

Do not use a hard cloth since this will mar the disc.

•

Wipe the disc in a straight line from center to edge.

•

Never wipe with a circular motion.

•

Do not use detergent or abrasive cleaning agents.

•

–49–

01A11

SPECIFICATIONS

GENERAL SPECIFICATIONS ELECTRICAL SPECIFICATIONS

TV/VCR

Sound output: 2 speakers, 1W, 8 ohm

CRT 20 inch in-line gun,

90˚ deflection tube Television system : NTSC-M Closed caption system :§15.119/FCC Video Heads : Rotary four-head Tape width : 1/2 inch Tape speed

SP : 33.40mm/sec. LP : 16.67mm/sec. SLP : 11.12mm/sec.

Tuner channel

TV VHF Low : #2~#6 TV VHF High : #7~#13 TV UHF : #14~#69 CATV VHF : 5A MID band : A5~A1, A~I SUPER band : J~W HYPER band : W+1~W+84

DVD

Product type: DVD Player Discs: DVD video, Audio CD Output signal format: NTSC color

OTHER SPECIFICATIONS

Terminals

Antenna input: VHF/UHF/CATV

75 ohm unbalanced (F-type) Video input: RCA connector [ 1 Audio L/R input: RCA connector [ 2 Headphone: 1/8” stereo (3.5 mm) Coaxial digital audio output: One pin jack,

500m Vpp (75 ohm)

Remote control: Digital encoded

infrared light system

Operating temperature: 5˚C to 40˚C

(41˚F~104˚F)

Power requirements: AC 120V, 60Hz Power consumption (Maximum): 90W Picture tube: 20" PF Dimensions: H:20-3/16” (513mm)

W:22-1/8” (562mm)

D:20-3/16” (513mm)

Weight: 50.7 lbs (23kg)

Designs and specifications are subject to change without notice.

•

If there is a discrepancy between languages, the default language will be English.

•

–50–

01A11

INDICE

■ CONTROLES DE OPERACIÓN Y FUNCIONES. . . . . 51

PANEL FRONTAL DEL

TELEVISOR/VIDEOGRABADORA/DVD. . . . . . . . . . . 51

MANDO A DISTANCIA. . . . . . . . . . . . . . . . . . . . . . . . . 51

VISTA POSTERIOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

■ PREPARACIÓN PARA LA UTILIZACIÓN . . . . . . . . . . 52

CONEXIONES DE ANTENA/CABLE . . . . . . . . . . . . . . 52

CONEXIÓN A TOMAS DE ENTRADA EXTERNA. . . . 52

PARA INSERTAR LAS PILAS . . . . . . . . . . . . . . . . . . . . 53

MODO DE ENTRADA EXTERNA . . . . . . . . . . . . . . . . 53

CONEXIÓN A UN AMPLIFICADOR ESTÉREO EQUIPADO CON TOMAS DE ENTRADA DIGITAL,

PLATINA MD O PLATINA DAT (Para DVD). . . . . . . . . 53

CONEXIÓN A UN DECODIFICADOR DOLBY DIGITAL

(para DVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

SECCIÓN DE TV/VCR

■ PREPARACIÓN PARA LA UTILIZACIÓN . . . . . . . . . . 53

SELECCIÓN DE IDIOMA . . . . . . . . . . . . . . . . . . . . . . . 53

AJUSTE DE CANALES . . . . . . . . . . . . . . . . . . . . . . . . . 54

AJUSTE DEL RELOJ . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

SECCIÓN DE DVD

REPRODUCCIÓN BÁSICA . . . . . . . . . . . . . . . . . . . . . . 54

CONTROLES DE

OPERACIÓN Y FUNCIONES

PANEL FRONTAL DEL

TELEVISOR/VIDEOGRABADORA/DVD

Consulte la figura 1 de la página 9

MANDO A DISTANCIA

Consulte la figura 2 de la página 9

VISTA POSTERIOR

Consulte la figura 3 de la página 10

1. Botón POWER

Presione este botón para conectar y desconectar la alimentación.

2. Botones VOLUME X/Y

Presione estos botones para controlar el nivel de volumen del DVD y el televisor.

3. Botones SKIP (para DVD)

Presione el botón correspondiente una vez para omitir capítulos o pistas y desplazarse a un punto específico. Mantenga el botón presionado para cambiar la velocidad de reproducción en avance o retroceso.

4. Botón PLAY

Inicia la reproducción del contenido del disco o cinta.

5. Botón STOP

Detiene la reproducción del disco.

6. Botón OPEN/CLOSE

Presione este botón para insertar discos en la bandeja o retirarlos de ella.

7. Bandeja de carga del disco

8. Indicador DVD

Se ilumina durante el modo DVD.

9. Botón SELECT

Presione este botón para cambiar al modo TV/VCR, modo de entrada externa o modo de DVD.

10. Indicador TV/VCR

Se ilumina durante el modo TV/VCR.

11. Botones CHANNEL K/L

Utilice estos botones para seleccionar canales memorizados.

12. Indicador de grabación

Parpadea durante la grabación. Se ilumina durante el modo de espera de grabación controlada por temporizador.

13. Botón REC/OTR (Panel frontal)

Presione para empezar la grabación manual. Presione repetidamente para empezar la grabación instantánea (OTR).

Botón RECORD (Mando a distancia)

Presione para empezar la grabación manual.

14. Botón REW (para TV/VCR)

Presione este botón para rebobinar la cinta o para ver la imagen rápidamente en dirección de retroceso durante el modo de reproducción. (Búsqueda en dirección de retroceso)

15. Botón F.FWD (para TV/VCR)

Presione este botón para adelantar rápidamente la cinta o para ver la imagen rápidamente en dirección de avance durante el modo de reproducción. (Búsqueda en dirección de avance)

16. Botón STOP/EJECT

Presione este botón para detener la cinta. Presiónelo en el modo de parada para retirar la cinta del televisor/videograbadora/DVD.

17. Ventanilla del sensor de mando a distancia

18. Toma HEADPHONE

Para conectar auriculares (no suministrados) y escuchar en privado.

19. To ma de entrada VIDEO

Conecte aquí la toma de salida de vídeo de una videocámara o de una videograbadora.

20. To mas de entrada AUDIO L/R

Conecte aquí las tomas de salida de audio de una videocámara o de una videograbadora.

21. Compartimiento del cassette

22. Botón PICTURE

Presione este botón para ajustar la imagen.

23. Botones numéricos Modo TV:

Presione dos botones para acceder directamente al canal deseado. No olvide presionar “0” antes de elegir un canal de un solo dígito.

Botón +100

Presione este botón para seleccionar canales de televisión por cable cuyo número sea igual o superior a 100.

Modo DVD:

Presione este botón para introducir el número deseado.

Botón +10

Presione este botón para introducir números mayores que 10

24. Botón PAUSE

Hace una pausa en la reproducción del disco o cinta.

25. Botón SPEED

Presione este botón para seleccionar la velocidad de grabación deseada: SP/SLP.

26. Botón C.RESET

Presione este botón para poner el contador en 0:00:00.

Presiónelo también para cancelar un ajuste de programa de temporizador.

27. Botón DISPLAY Modo TV/VCR:

Para visualizar el contador o el número del canal y la fecha actual en la pantalla del televisor.

Modo DVD:

Indica el estado actual en la pantalla del televisor para fines de comprobación.

iguales o

–51–

0C28

28. Botón SETUP

Presione este botón para activar o salir del modo de menús de televisor o configuración de DVD.

29. Botón TITLE

Para visualizar el menú de títulos.

30. Botón CLEAR

Para cancelar ajustes.

31. Botón MODE

Activa el modo de reproducción programada o el modo de reproducción aleatoria.

32. Botón SEARCH MODE

Presione este botón para localizar un punto deseado.

33. Botón AUDIO

Presione este botón para seleccionar un idioma de audio o el modo de sonido deseado.

34. Botón SUBTITLE

Presione este botón para seleccionar el idioma de subtítulos deseado.

35. Botón REPEAT

Repite la reproducción del disco, título, capítulo o pista actual.

36. Botón ANGLE (modo DVD)

Presione este botón para cambiar el ángulo de la cámara y ver la secuencia que se está reproduciendo desde un ángulo diferente.

37. Botón A-B REPEAT

Repite la reproducción de una sección seleccionada.

38. Botón RETURN

Permite volver a la operación anterior en el modo de configuración de DVD.

39. Botón ENTER

Presione este botón para establecer un ajuste.

40. Botones de flechas Modo TV/VCR:

Presione estos botones para seleccionar un modo de ajuste en el menú que aparece en la pantalla del televisor. Presiónelos también para seleccionar opciones o establecer ajustes en un menú en particular.

Modo DVD:

Use estos botones para hacer ajustes mientras observa la imagen en la pantalla del televisor.

41. Botón DISC MENU

Muestra los menús contenidos en el DVD.

42. Botón V.SURR

Activar/desactivar el envolvente virtal.

43. Botón MUTE

Suprime la salida de sonido. Presiónelo de nuevo para restablecer el sonido.

44. Botón SLEEP

Utilice este botón para ajustar el temporizador de dormir.

45. Botón SELECT

Presione este botón para cambiar entre los modos TV/VCR y DVD. El modo seleccionado (TV/VCR o DVD) se visualiza en el indicador del panel delantero.

46. To ma de entrada ANT.

Conéctela a una antena, sistema de televisión por cable o sistema de satélite.

47. Cable de alimentación

Conéctelo a una toma de CA estándar (120 V, /60 Hz). NOTA: Antes de conectar el cable de alimentación a

una toma de CA estándar, retírelo del gancho para evitar dañarlo.

48. Toma de salida de audio digital COAXIAL

Conéctela solamente a la entrada digital de un amplificador externo o decodificador de audio de DVD.

PREPARACIÓN PARA LA

UTILIZACIÓN

CONEXIONES DE ANTENA/CABLE

Consulte la figura 4 de la página 11

ANTENAS SEPARADAS DE VHF/UHF

En algunas zonas será necesario utilizar una antena exterior.

TELEVISIÓN POR CABLE SIN CAJA DE CONVERTIDOR/DECODIFICADOR

Utilice esta conexión si su sistema de televisión por cable se conecta directamente a su televisor/ videograbadora/DVD , sin una caja de convertidor. Con esta conexión podrá:

1) Utilizar el mando a distancia del televisor/ videograbadora/DVD para seleccionar canales.

2) Programar uno o más canales decodificados para grabación automática controlada por temporizador.

NOTA: Este televisor/videograbadora/DVD SÓLO puede grabar el canal que se está viendo.

TELEVISIÓN POR CABLE CON CAJA DE CONVERTIDOR/DECODIFICADOR O CAJA DE SATÉLITE

Si su compañía de televisión por cable le suministra una caja de convertidor o si utiliza un sistema de satélite, podrá utilizar la conexión básica que se muestra en la ilustración. Al utilizar esta conexión, también podrá grabar canales codificados. Sin embargo, la selección de los canales deberá hacerse con la caja de convertidor o con la caja de satélite. Esto significa que no es posible cambiar de canal utilizando el mando a distancia del televisor /videograbadora/DVD. La grabación en ausencia (controlada por temporizador) está limitada a un canal a la vez.

PARA GRABAR UN CANAL CODIFICADO/ DECODIFICADO

1.Ajuste el selector de canales del televisor/video-

grabadora/DVD al canal de salida de la caja de convertidor de televisión por cable o caja de satélite. (Ej., CH3)

2.Seleccione el canal que desea grabar en la caja de

convertidor de televisión por cable o caja de satélite.

Nota para el instalador de sistemas CATV

Esta nota tiene la finalidad de llamar la atención del instalador de sistemas CATV para que tenga en cuenta el Artículo 820-40 de la NEC, que proporciona recomendaciones para hacer una conexión a tierra apropiada y, en particular, especifica que la tierra del cable debe conectarse al sistema de puesta a tierra del edificio, tan cerca del punto de entrada del cable como sea posible.

–52–

0C28

CONEXIÓN A TOMAS DE ENTRADA

EXTERNA

Cuando vea un programa grabado en otra fuente (videograbadora o videocámara), utilice las tomas de entrada de audio/ vídeo de la parte delantera del televisor/videograbadora/ DVD. Conecte las tomas de salida de audio/vídeo de otra fuente a las tomas AUDIO L/R y VIDEO de este televisor/ videograbadora/DVD. Luego, presione los botones CHANNEL K/L hasta que aparezca "AUX" en la pantalla.

NOTA:

Cuando conecte una videograbadora monofónica (otra

• fuente) a este televisor/videograbadora/DVD, conecte la toma de salida de audio de la videograbadora monofónica (otra fuente) a la toma AUDIO L de este televisor/ videograbadora/DVD. El audio saldrá igualmente por los canales izquierdo y derecho.

Consulte la figura 5 de la página 12

PARA INSERTAR LAS PILAS

1) Abra la cubierta del compartimiento de las pilas

empujando la cubierta del mando a distancia en el sentido de la flecha.

2) Inserte 2 pilas "AA" en el compartimiento de las

pilas, en el sentido indicado por las marcas de polaridad (+/-).

3) Vuelva a poner la cubierta.

NOTAS:

•

La fuente de audio de un disco grabado en formato de sonido envolvente Dolby Digital de 5,1 canales no se puede grabar como sonido digital mediante una platina MD o DAT.

• Asegúrese de desconectar la alimentación de todos

los componentes del sistema antes de conectar otro componente.

• Consulte los manuales de instrucciones de los

componentes que va a conectar al televisor/videograbadora/ DVD.

• Ajuste la función Dolby Digital a OFF para salida

de audio en el modo de configuración. La reproducción en un televisor/videograbadora/DVD utilizando ajustes incorrectos puede generar ruido y distorsión, y también puede causar daños a los altavoces.

CONEXIÓN A UN DECODIFICADOR

DOLBY DIGITAL (para DVD)

Si utiliza este televisor/videograbadora/DVD para reproducir un disco DVD grabado en formato de sonido envolvente Dolby Digital de 5,1 canales, el televisor/videograbadora/DVD emitirá un flujo de datos DOLBY DIGITAL desde su toma de salida de audio digital COAXIAL. Si conecta el reproductor a un decodificador Dolby Digital, podrá disfrutar de una tonalidad más convincente y real, con un sonido envolvente potente y de alta calidad similar al de los cines.

Utilice cables digitales coaxiales de audio disponibles en el comercio especializado para hacer las conexiones de audio.

MODO DE ENTRADA EXTERNA

Al usar una señal de entrada externa (otra videograbadora o una videocámara), conecte los cables de salida de audio/vídeo del equipo externo a las tomas AUDIO L/R IN/ VIDEO IN de su televisor/ videograbadora/ DVD. Luego, presione los botones CHANNEL hasta que aparezca "AUX" en la pantalla.

K o L

CONEXIÓN A UN AMPLIFICADOR

ESTÉREO EQUIPADO CON TOMAS DE

ENTRADA DIGITAL, PLATINA MD O

PLATINA DAT (Para DVD)

Utilice un cable digital coaxial de audio de venta en el comercio especializado para hacer las conexiones de audio. Conexión a un amplificador equipado con tomas de entrada digital, platina MD o platina DAT.

Consulte la figura 6 de la página 13

Consulte la figura 7 de la página 14

NOTAS:

Asegúrese de desconectar la alimentación de todos

•

los componentes del sistema antes de conectar otro componente. Consulte los manuales de instrucciones de los

•

componentes que va a conectar al televisor/videograbadora/DVD. Si conecta un decodificador Dolby Digital, ajuste

•

la función DOLBY DIGITAL a ON para salida de audio en el modo de configuración. A menos que se haga la conexión a un decodifi-

•

cador Dolby Digital, ajuste la función Dolby Digital a OFF para salida de audio en el modo de configuración. La reproducción en un televisor/videograbadora/DVD utilizando ajustes incorrectos puede generar ruido y distorsión, y también puede causar daños a los altavoces.

Fabricado bajo licencia de Dolby Laboratories. “Dolby” y el símbolo de la D doble son marcas de fábrica de Dolby Laboratories.

–53–

0C28

SECCIÓN DE TV/VCR

AJUSTE DE CANAL

PREPARACIÓN PARA LA

UTILIZACIÓN

SELECCIÓN DE IDIOMA

TV/VCR

Enchufe el cordón de alimentación del televisor/videograbadora/DVD

Enchufe el cordón de alimentación del televisor/ videograbadora/DVD en una toma de CA estándar.

NOTA:

Si aparecen algunas cifras en la esquina de la pan-

•

talla, pulse el botón POWER sin desenchufar el cordón de alimentación.

Asegúrese de que ...

Pulse el botón POWER para encender el televi-

•

sor/videograbadora/DVD.

NOTA: Esta función afecta sólo el idioma en el menú de la pantalla y no la fuente de audio.

Seleccione “LANGUAGE”

Pulse el botón SETUP en el mando a distancia. Pulse el botón

Seleccione “ENGLISH”, “ESPAÑOL” o

“FRANÇAIS”

Seleccione “ENGLISH”, “ESPAÑOL” o “FRANÇAIS” con el botón ENTER.

Salga del modo de idioma

Pulse el botón SETUP en el mando a distancia para volver al modo del televisor.

NOTA: Si, por alguna razón, el menú está en inglés o francés, pulse el botón SETUP en el mando a distancia, pulse el botón K o L para señalar el “LANGUAGE [ENGLISH]” o “LANGAGE [FRANÇAIS]”, a continuación, pulse el botón ENTER y pulse el botón ENTER en el mando a distancia.

K o L para señalar “LANGUAGE”.

TV/VCR

Puede programar el sintonizador para buscar todos los canales que recibe en su localidad.

NOTA: El canal preparado NO es necesario cuando esté conectado a una caja de cable o caja de satélite. Sólo tiene que seleccionar con el selector de canal del televisor/videograbadora/DVD al canal de salida de la caja de cabe o caja de satélite (por ejemplo el canal CH3). Seleccione el canal a ver en la caja de cable o caja de satélite.

Asegúrese de que ...

Pulse el botón POWER para encender el televi-

•

sor/videograbadora/DVD.

1 Seleccione “AJUSTE DE CANAL”

Pulse el botón SETUP en el mando a distancia. Pulse el botón

CANAL”. A continuación, pulse el botón ENTER.

K o L para señalar “AJUSTE DE

2 Empiece el prefijado automático

Pulse el botón K o L para señalar “AUTOPROGRAMACION DE CA”.

A continuación, pulse el botón ENTER. El sintonizador busca y memoriza todos los canales

activos en su localidad.

3 Después de buscar

El sintonizador se detiene en el canal memorizado más bajo.

Cuando se activa AUTOPROGRAMACION DE

•

CA, donde no hay entrada de señal del televisor, aparecerá “NO HAY SEÑAL DE TV” en la pantalla después de terminar la búsqueda de canales.

El televisor/videograbadora/DVD puede reconocer

•

los canales de TV para que sean canales de TV de antena de cable con las condiciones de recepción. En este caso, pruebe nuevamente con el prefijado automático en las condiciones de recepción fina.

–54–

0C28

AJUSTE DEL RELOJ

TV/VCR

Cerciórese...

La alimentación del televisor/videograbadora/DVD

• deberá estar conectada.

En el ejemplo de abajo, el reloj va a ajustarse así:

FECHA: 6 de mayo de 2004 HORA: 5:40 PM

1) Pulse el botón SETUP en el mando a distancia. Pulse el botón

RELOJ”. Luego, pulse el botón ENTER.

2)Pulse el botón MANUAL RELOJ”.

Luego, pulse el botón ENTER.

3)Pulse el botón deseado. (Ejemplo: Mayo - 05)

Luego, pulse el botón

4)Pulse el botón del mes deseado. (Ejemplo: 6 - 06)

Luego, pulse el botón

5)Pulse el botón deseado. (Ejemplo: 2004)

Luego, pulse el botón

6)Pulse el botón deseada. (Ejemplo: 5, PM)

Luego, pulse el botón

7)Pulse el botón to deseado. (Ejemplo: 40)

8)Pulse el botón SETUP en el mando a distancia. Aunque los segundos no se visualizan, éstos empiezan a contar desde 00 cuando se pulsa SETUP en el mando a distancia. Utilice esta función para sincronizar el reloj con la hora correcta.

K o L para indicar “AJUSTE

K o L hasta que aparezca el mes

K o L hasta que aparezca el día

K o L hasta que aparezca el año

K o L hasta que aparezca la hora

K o L hasta que aparezca el minu-

SECCIÓN DE DVD

REPRODUCCIÓN BÁSICA

DVD-V

Para empezar

¡Conecte la alimentación del amplificador y otros

componentes, si es necesario.

1 Presione el botón POWER.

¡La alimentación se conectará.

2 Presione el botón OPEN/CLOSE para abrir

la bandeja de carga del disco.

3 Ponga el disco deseado en la bandeja, con

la etiqueta hacia arriba.

4 Presione el botón PLAY.

¡La bandeja se cerrará automáticamente y la repro-

ducción comenzará desde el primer capítulo o pista del disco. Si la reproducción no comienza automáticamente, presione el botón PLAY.

¡Cuando reproduzca un DVD que tenga grabado un

menú de títulos, el menú podrá aparecer en la pantalla.

5 Presione el botón STOP para detener la

reproducción.

–55–

0C28

Registered Trademark / TM Trademark /

Service Mark of Sears, Roebuck and Co.

Marca Registrada /

Marca de Fábrica / SM Marca de Servicio de Sears, Roebuck and Co.

Get it fixed, at your home or ours!

Our Home

For repair of carry-in items like vacuums, lawn equipment,

and electronics, call or go on-line for the location of your nearest

Sears Parts & Repair Center.

1-800-488-1222

Call anytime, day or night (U.S.A. only)

www.sears.com

To purchase a protection agreement on a product serviced by Sears:

1-800-827-6655 (U.S.A.) 1-800-361-6665 (Canada)

Para pedir servicio de reparación

a domicilio, y para ordenar piezas:

1-888-SU-HOGAR

(1-888-784-6427)

Au Canada pour service en français:

1-800-LE-FOYER

(1-800-533-6937)

www.sears.ca

Your Home

For repair- in your home -of all major brand appliances,

lawn and garden equipment, or heating and cooling systems,

no matter who made it, no matter who sold it!

For the replacement parts, accessories and

owner's manuals that you need to do-it-yourself.

For Sears professional installation of home appliances

and items like garage door openers and water heaters.

1-800-4-MY-HOME

(1-800-469-4663)

Call anytime, day or night

(U.S.A. and Canada)

www.sears.com www.sears.ca

90 Day Full Warranty

If this (product) experiences any failure due to a defect in material or workmanship within 90 days from the date of purchase, return it to your nearest Sears Parts & Repair Center, and Sears will repair it free of charge.

After 90 days and until one (1) year from the date of purchase, Sears will replace defective parts free of charge. You pay for labor.

After 90 days and until two (2) years from the date of purchase, Sears will replace the Picture Tube if it is defective.You pay for labor.

This warranty applies only if this (product) is used for private household purposes. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

Sears, Roebuck and Co., Dept. 817WA, Hoffman Estates, IL 60179 For the location of a Sears Service Center in your area : 1-800-488-1222

Printed in Malaysia 1EMN20126

T1061UM ★★★★★

FUNAI SSF420TR User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
