OWNER’S MANUAL

27-INCH COLOR TV/DVD/VHS

SSC727B

This Owner’s Manual is

made of recycled paper.

INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

If you need additional operating assistance after reading this owner’s manual or to order replacement accessories, please call

TOLL FREE : 1-800-968-3429.

Please read before using this equipment

SUPPLIED ACCESSORIES

ACCESSORIES Remote Control Unit Batteries

PART NO. N0288UD 2 AA Batteries

WARNING:TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE

TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The caution marking is located on the rear of the cabinet.

IMPORTANT SAFEGUARDS

1.Read instructions-All the safety and operating instructions

should be read before the appliance is operated.

2.Retain Instructions-The safety and operating instructions

should be retained for future reference.

3.Heed Warnings-All warnings on the appliance and in the

operating instructions should be adhered to.

4.Follow Instructions-All operating and use instructions

should be followed.

5.Cleaning-Unplug TV/DVD/VHS from the wall outlet before

cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6.Attachments-Do not use attachments not recommended by

the TV/DVD/VHS manufacturer as they may cause hazards.

7.Water and Moisture-Do not use this TV/DVD/VHS near

water-for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8.Accessories-Do not place this TV/DVD/VHS on an unstable

cart, stand, tripod, bracket, or table. The TV/DVD/VHS may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the TV/DVD/VHS. Any mounting of the appliance should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care.Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

PORTABLE CART WARNING

S3126A

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

AMEUBLES- Cet appareil ne doit être placé que sur un meuble (avec ou sans roulettes) recommandé par le fabricant. Si vous l’installez sur un meuble à roulettes, déplacez les deux ensembles avec précaution. Un arrêt brusque, l’utilisation d’une force excessive et des surfaces irrégulières risquent de déstabiliser l’ensemble et de le renverser.

9. Ventilation-Slots and openings in the cabinet and the back

or bottom are provided for ventilation and to ensure reliable operation of the TV/DVD/VHS and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the TV/DVD/VHS on a bed, sofa, rug, or other similar surface. This TV/DVD/VHS should never be placed near or over a radiator or heat register. This TV/DVD/VHS should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10.Power Sources-This TV/DVD/VHS should be operated

only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For TV/DVD/VHSs intended to operate from battery power, or other sources, refer to the operating instructions.

11.Grounding orPolarization-This TV/DVD/VHS is

equipped with a polarized alternating-current line plug(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12.Power-Cord Protection-Power-supply cords should be

routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

SYMBOLE D'AVERTISSEMENT POUR

LES COMPOSANTES

APPAREIL ET MEUBLE A ROULETTES

S3126A

- 2 - EN

1B15

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELE CTRICAL CODE

S2898A

FIGURE A

ELECTRIC SERVICE EQUIPMENT

NEC - NATIO NAL EL ECTR ICAL CODE

GROUND

CLAMP

ANTENNA

LEAD IN WIRE

ANTENNA

DISCHARGE UNI T (NEC SECTIO N 810 -20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CL AMPS

POWER SERVICE GRO UNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

13.Outdoor Antenna grounding-If an outside antenna or

cable system is connected to the TV/DVD/VHS, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14.Lightning-For added protection for this TV/DVD/VHS

receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV/DVD/VHS due to lightning and power-line surges.

15.Power Lines-An outside antenna system should not be

located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16.Overloading-Do not overload wall outlets and extension

cords as this can result in a risk of fire or electric shock.

17.Object and Liquid Entry-Never push objects of any kind

into this TV/DVD/VHS through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the TV/DVD/VHS.

18.Servicing-Do not attempt to service this TV/DVD/VHS

yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19.Damage Requiring Service-Unplug this TV/DVD/VHS

from the wall outlet and refer servicing to qualified service

personnel under the following conditions: a. When the power-supply cord or plug is damaged or frayed. b. If liquid has been spilled, or objects have fallen into the

TV/DVD/VHS. c. If the TV/DVD/VHS has been exposed to rain or water. d. If the TV/DVD/VHS does not operate normally by follow-

ing the operating instructions. Adjust only those controls

that are covered by the operating instructions, as improper

adjustment of other controls may result in damage and will

often require extensive work by a qualified technician to

restore the TV/DVD/VHS to its normal operation. e. If the TV/DVD/VHS has been dropped or damaged in any

way. f. When the TV/DVD/VHS exhibits a distinct change in per-

formance-this indicates a need for service.

20.Replacement Parts-When replacement parts are required,

be sure the service technician has used replacement parts

specified by the manufacturer that have the same character-

istics as the original part. Unauthorized substitutions may

result in fire, electric shock, injury to persons or other haz-

ards.

21.Safety Check-Upon completion of any service or repairs to

this TV/DVD/VHS, ask the service technician to perform

routine safety checks to determine that the TV/DVD/VHS

is in proper operating condition.

22.Heat-This TV/DVD/VHS product should be situated away

from heat sources such as radiators, heat registers, stoves,

or other products (including amplifiers) that produce heat.

CAUTION:TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

- 3 - EN

1B15

PRECAUTIONS

IMPORTANT COPYRIGHT INFORMATION

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.

FCC WARNING- This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

LASER SAFETY

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK MECHANISM.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

CAUTION: TO PREVENT ELECTRIC SHOCK,

MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

- 4 - EN

1B15

LOCATION

For safe operation and satisfactory performance of your TV/DVD/VHS, keep the following in mind when selecting a place for its installation:

Shield it from direct sunlight and keep it away from

•

sources of intense heat. Avoid dusty or humid places.

•

Avoid places with insufficient ventilation for proper

•

heat dissipation. Do not block the ventilation holes at the top and bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.

Install unit in a horizontal position.

•

Avoid locations subject to strong vibration.

•

Do not place the TV/DVD/VHS near strong magnetic

•

fields. Avoid moving TV/DVD/VHS to locations where

•

temperature differences are extreme.

AVOID THE HAZARDS OF

ELECTRICAL SHOCK AND FIRE

Do not handle the power cord with wet hands.

•

Do not pull on the power cord when disconnecting

•

it from an AC wall outlet. Grasp it by the plug. If, by accident, water is spilled on your unit, unplug

•

the power cord immediately and take the unit to our Authorized Service Center for servicing.

Do not put your fingers or objects into the

•

TV/DVD/VHS disc loading tray. Do not place anything directly on top of the unit.

•

WARNING

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, or after heating a cold room or under conditions of high humidity. If a DVD is played in a TV/DVD/ VHS which has moisture, it may damage the DVD and TV/DVD/VHS. Therefore when the condensation occurs inside the unit, turn the POWER button on and allow at least 2 hours for the unit to dry out.

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

The serial number of this product may be found on the back of the unit. No other TV/DVD/VHS has the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase Dealer Purchase from Dealer Address Dealer Phone No. Model No. Serial No.

- 5 - EN

1F12

TABLE OF CONTENTS

C IMPORTANT SAFEGUARDS . . . . .2

C PRECAUTIONS . . . . . . . . . . . . . . . .4

LOCATION . . . . . . . . . . . . . . . . . . .5

AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE .5

WARNING . . . . . . . . . . . . . . . . . . . .5

C FEATURES . . . . . . . . . . . . . . . . . . . .7

C OPERATING CONTROLS AND

FUNCTIONS . . . . . . . . . . . . . . . . . . .9

C PREPARATION FOR USE . . . . . . .11

ANTENNA/CABLE

CONNECTIONS . . . . . . . . . . . . . . .11

CONNECTING TO EXTERNAL

INPT JACKS . . . . . . . . . . . . . . . . .12

INSTALLING THE BATTERIES . .12

EXTERNAL INPUT MODE . . . . . .12

CONNECTING TO ASTEREO

SYSTEM (for DVD) . . . . . . . . . . . .13

CONNECTING TO AN AMPLIFIER EQUIPPED WITH DIGITALINPUT JACKS, MD DECK OR DAT DECK

(for DVD) . . . . . . . . . . . . . . . . . . . .13

CONNECTING TO ADOLBY DIGITALDECODER OR DTS DECODER (for DVD) . . .14

C SET UP FOR USE . . . . . . . . . . . . .15

CHANNEL SET UP

FOR THE FIRST TIME . . . . . . . . .15

DELETING (OR ADDING)

CHANNEL . . . . . . . . . . . . . . . . . . .15

CHANNEL SET UP AGAIN . . . . . .16

SELECTING THE LANGUAGE . .16

DAYLIGHT-SAVING TIME . . . . . .16

CLOCK SET UP

(AUTO / MANUAL) . . . . . . . . . . . .17

TV/VCR SECTION

C TV OPERATION . . . . . . . . . . . . . . .19

WATCHING ATV PROGRAM . . .19

DEGAUSSING . . . . . . . . . . . . . . . .19

PICTURE CONTROL . . . . . . . . . . .19

CLOSED CAPTION SYSTEM . . . .20

V-CHIP SET UP . . . . . . . . . . . . . . .21

C MTS(Multi-Channel Television

sound)SYSTEM . . . . . . . . . . . . . . . .23

CHECKING THE SELECTED

MTS MODE . . . . . . . . . . . . . . . . . .23

MTS RECORDING/MONITOR

MODE . . . . . . . . . . . . . . . . . . . . . .23

SELECTING THE MTS SYSTEM .24

C VIDEO CASSETTE . . . . . . . . . . . . .25

PLAYBACK . . . . . . . . . . . . . . . . . . .26

NORMAL PLAYBACK . . . . . . . . .26

TRACKING ADJUSTMENT . . . . .26

SLOW MOTION . . . . . . . . . . . . . .26

PICTURE SEARCH . . . . . . . . . . . .26

STILL PICTURE . . . . . . . . . . . . . .26

VERTICALHOLD CONTROL . . .26

C SPECIAL PLAYBACK . . . . . . . . . .27

RENTALPLAYBACK . . . . . . . . . .27

AUTO REPEAT PLAYBACK . . . . .27

C SEARCH . . . . . . . . . . . . . . . . . . . . .28

ZERO RETURN . . . . . . . . . . . . . . .28

TIME SEARCH . . . . . . . . . . . . . . .28

INDEX SEARCH . . . . . . . . . . . . . .29

C SPECIAL FEATURES . . . . . . . . . .29

REAL TIME TAPE COUNTER . . .29

AUTO REWIND-EJECT . . . . . . . .29

C RECORDING . . . . . . . . . . . . . . . . .30

NORMAL RECORDING . . . . . . . .30

SKIPPING UNWANTED SCENES

DURING RECORDING . . . . . . . . .30

OTR (One Touch Recording) . . . . . .31

COPYING A VIDEO CASSETTE (Requires a VCR or camcorder) . . .31

C TIMER . . . . . . . . . . . . . . . . . . . . . .32

AUTOMATIC

TIMER RECORDING . . . . . . . . . .32

TIMER PROGRAM EXTENSION .33 HINTS FOR AUTOMATIC TIMER

RECORDING . . . . . . . . . . . . . . . . .34

AUTO RETURN . . . . . . . . . . . . . . .34

SLEEP TIMER . . . . . . . . . . . . . . . .34

C ON SCREEN DISPLAY . . . . . . . . .35

C CABLE CHANNEL

DESIGNATIONS . . . . . . . . . . . . . .35

VD SECTION

C ABOUT THE DISCS . . . . . . . . . . . .36

PLAYABLE DISCS . . . . . . . . . . . .36

DISC TYPES . . . . . . . . . . . . . . . . .36

SYMBOLS USED IN

THIS MANUAL . . . . . . . . . . . . . . .36

C PLAYING ADISC . . . . . . . . . . . . . .37

PLA YING ADVD VIDEO OR AN AUDIO CD

USING THE DVD MENUS . . . . . .36

USING THE TITLE MENU . . . . . .36

RESUMING PLAYBACK FROM THE POINT WHERE

PLAYBACK STOPPED . . . . . . . . .38

FAST FORWARD/REVERSE . . . . .38

PAUSING PLAYBACK OR DIS-

PLAYING A STILL PICTURE . . . .38

STEPPING THROUGH FRAMES .38

SLOW MOTION . . . . . . . . . . . . . .39

PLAYING FROM A DESIRED

TITLE OR CHAPTER . . . . . . . . . .39

STARTING FROM A DESIRED TIME COUNT

STARTING FROM A DESIRED

TRACK . . . . . . . . . . . . . . . . . . . . . .39

REPEAT . . . . . . . . . . . . . . . . . . . . .40

A-B REPEAT . . . . . . . . . . . . . . . . .40

PROGRAM (Audio CD) . . . . . . . . .41

RANDOM (Audio CD) . . . . . . . . . .41

ZOOM PLAYBCK . . . . . . . . . . . . .41

C SETTINGS . . . . . . . . . . . . . . . . . . .42

CHANGING THE AUDIO LANGUAGE OR SOUND MODE .42

CHANGING THE SUBTITLE

LANGUAGE . . . . . . . . . . . . . . . . .43

CHANGING THE CAMERA

ANGLE (Multi-Angle Pictures) . . . .43

CHANGING THE ON-SCREEN

DISPLAY . . . . . . . . . . . . . . . . . . . .44

C CHANGING THE SETUP ITEMS .45

LANGUAGE SETTINGS . . . . . . . .45

VIDEO SETTINGS . . . . . . . . . . . . .46

AUDIO SETTINGS . . . . . . . . . . . .46

PARENTALLOCK . . . . . . . . . . . . .47

OTHER SETTINGS . . . . . . . . . . . .48

C LANGUAGE CODE LIST . . . . . . . .49

C TROUBLESHOOTING GUIDE . . .50

C MAINTENANCE . . . . . . . . . . . . . . .53

DISC HANDLING . . . . . . . . . . . . .53

C SPECIFICATIONS . . . . . . . . . . . . .54

C WARRANTY . . . . . . . . . . .Back Cover

. . . . . . . . . . . . . . . . . . .36

. . . . . . . . . . . . . . . . .39

- 6 - EN

1F12

FEATURES

TV/VCR

Hi-Fi system

•

offers you excellent sound quality with a dynamic range of 80dB, frequency response from 20Hz to 20kHz, and 0.005% wow and flutter.

Rotary 4-head Record/Playback System–Four heads

•

ensure excellent picture quality and special effects playback.

Index Search–

•

Slow Motion–View recorded program at slower

•

than normal speed.

Trilingual on screen tv/vcr setup display selec-

•

table in English or Spanish or French Real time counter–This shows the elapsed recording

•

or playback time in hours, minutes, and seconds. “–” indication will appear when the tape is rewound further than the tape counter position “0:00:00”.

181 channel capability PLL frequency synthesiz-

•

er tuner with direct station call–

be necessary to view scrambled cable channels.)

Auto Clock Setting–Allows you to set the clock

•

function from a PBS broadcast station.

Closed caption system–You may view specially

•

labeled (cc) TV programs, movies, news, prerecorded tapes, etc. with either a dialogue caption or text display added to the program.

Auto power on and off system–Automatically

•

turns on the TV/DVD/VHS when you insert the cassette, turns off after auto-rewind, and ejects when the beginning of the tape is reached.

Auto rewind when the end of a tape is

•

reached–

timer recording.

–The Hi-Fi stereo recording system

Fast-forwards to start of next recording.

(A converter may

This function doesn’t occur when using

The

2 Step picture search operation–You can view a

•

video program at a high speed or super high speed in either a forward or reverse direction in LP and SLP mode. For SP mode only high speed.

Three different playback tape speeds : SP/LP/SLP

•

Two different recording tape speeds : SP/SLP

•

Auto Head Cleaner–Automatically cleans video

•

heads as you insert or remove a cassette.

Zero Return–The tape returns to counter of

•

0:00:00 by rewinding or fast forwarding.

Still–“Freeze” the picture at any time, for close

•

viewing of a particular scene.

Digital Auto Tracking (DTR)–Automatically

•

adjusts the tracking for each tape you play.

Rental play mode–Improves playback picture

•

quality from worn tapes, such as rental tapes.

Auto repeat–Allows you to repeat the playing of a

•

tape indefinitely without pressing the PLAY button.

Time search–Let you set the TV/DVD/VHS to

•

advance the tape by entering the desired playback time you want to skip.

OTR (One Touch Recording)–Instant timed

•

recording from 30 to 480 minutes is possible at the push of the REC/OTR button.

1 Year, 8 events (including Daily and Weekly

•

Timer Recording)–

record up to 8 programs at different times on different channels up to 1 year in advance. The Daily timer allows recordings to be made of daily broadcasts, and the Weekly timer allows recording to be made once a week up to the end of the tape.

Auto return–After timer recording is finished, the

•

TV/DVD/VHS can return to the beginning of the recording.

Sleep timer–Allows you to have the

•

automatically turn on or off at a desired time. (This feature is not available for DVD mode.)

Timer Program Extension–Allow you to shift the

time schedule for automatic timer recording.

V-CHIP–Enables parents to prevent their children

•

from watching inappropriate material on TV.

The built-in timer allows you to

TV/DVD/VHS

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

- 7 - EN

1F12

DVD

¡Dolby Digital sound

This player can handle Dolby Digital surround sound having 5.1 channels when connected to a Dolby Digital decoder.

¡Still/fast/slow/step playback

Various playback modes are available including still pictures, fast forward/reverse, slow motion and step frames.

¡Random playback for audio CD

This player can shuffle the order of tracks to play them in random order.

¡Program playback for audio CD

You can program the order of tracks to play them in any desired order.

¡DVD menus in a desired language

You can display DVD menus in a desired language, if available on a DVD.

¡Screen saver/Auto power-off functions

The screen saver program starts when there is no input from the player for five minutes in the stop mode. When the screen saver program is activated for 30 minutes, the DVD power is automatically turned off, and "DVD" appears on the screen.

¡Subtitles in a desired language

You can select a desired language for the display subtitles, if that language is available on a disc.

¡Selecting a camera angle

You can select the desired camera angle, if a disc contains sequences recorded from different angles.

¡Choices for audio language and sound mode

You can select the desired audio language and sound mode, if different languages and modes are available on a disc.

¡Parental lock

You can set the control level to limit playback of discs which may not be suitable for children.

¡Automatic detection of discs

This player automatically detects if a loaded disc is DVD or audio CD.

¡On-screen display

Information about the current operation can be displayed on a TV screen, allowing you to confirm the currently active functions (such as program playback), on the TV screen using the remote control.

¡DTS (Digital Theater System)

Sound system different from Dolby Digital sound system

¡Search

Chapter search: Search for the chapter designated by user Title search: Search for the title designated by user is Track search: Search for the track designated by user is Time search: Search for the time designated by user is

¡Repeat

Chapter: Repeated playback of the chapter of the Title: Repeated playback of the title of the disc Track: Repeated playback of the track of the disc

(audio CD)

Disc

A-B: The part between A and B designated by

¡Zoom

4-time magnified screen can be displayed.

¡Marker

The part designated by user can be called back.

¡Resume Play

User can resume to playback from the part at which the play was stopped.

¡SRS T ruSurround

You can enjoy stereophonic virtual space on your existing stereo system.

¡Dimmer

Brightness of the display can be varied.

¡Bit rate indication ¡Dynamic range control

This unit employs TruSurround system of SRS Labs, Inc. as virtual

technology. TruSurround and the symbol are trademarks of

SRS Labs, Inc. TruSurround technology is incorporated under license

from SRS Labs, Inc.

is possible. possible. possible. possible.

disc being played is possible. being played is possible. being played is possible.

: Repeated playback of the entire disc being

played is possible.

user is possible.

NOTE:

We do not recommend the use of universal remote controls. Not all of the functions may be controlled with

•

a universal remote control. If you decide to use a universal remote control with this unit, please be aware that the code number given

may not operate this unit. In this case, please call the manufacturer of the universal remote control.

- 8 - EN

1F12

OPERATING CONTROLS AND FUNCTIONS

- TV/DVD/VHS FRONT PANEL - [Fig.1]

POWER

VOLUME

PLAY

SKIP

12 4 5 6 107 1514983 3 411 12 13 212019181716

- REMOTE CONTROL -

POWER PICTURE TV/VCR

[Fig. 2]

DVD

22 23

24 25

123 456 789

PAUSE

SPEED C.RESET

+100

0 +10

CH.

VOL.

MUTEZOOM

(DVD) 3

(TV/VCR) 14

13 27

28 29 30

31 32

RECORD

DISPLAY

CLEAR

MODE

PLAY

STOP

ENTER

REPEATSEARCH MODE

DISC

RETURNTITLESETUP

ANGLESUBTITLEAUDIO

SLEEP

POWER button

Press to turn the power on and off.

2.VOLUME K/L buttons

Press to control the volume level for the DVD and TV.

3.SKIP buttons (for DVD)

Skip chapters or tracks to a desired point. Press and hold in a second or more to get the function of fast forward or fast reverse.

PLAY button

Starts playback of the disc or tape contents.

STOP button(Front Panel)

Stops operation of the disc.

STOP button(Remote Control)

Stops operation of the disc or the tape.

OPEN/CLOSE

STOP

45 44

2 43

3 (DVD)

15 (TV/VCR)

5 41

40 39

38 37

36 35

CHANNEL

REC/OTR

SELECT

TV/VCR

DVD

F.FWD

PLAY

REW

6.OPEN/CLOSE button

Press to insert discs into or remove them from the tray.

Disc loading tray

8.DVD indicator

Lights on during DVD mode.

SELECT button

Press to change to TV/VCR mode or DVD mode. NOTE: For about 4 seconds jast after the DVD mode has switched to the TV mode, the button does not work to switch back to the DVD mode.

TV/VCR indicator

10.

Lights on during TV/VCR mode.

CHANNEL K/L buttons

11.

Press to select memorized channel.

Recording indicator

12.

Flashes during recording. Lights up in the Standby mode for Timer Recording.

13.REC/OTR (RECORD) button

Press for manual recording. Activates One Touch Recording. (OTR is only during TV/VCR mode)

REW button (for TV/VCR)

14.

Press to rewind the tape, or to view the picture rapidly in reverse during playback mode. (Rewind Search)

FWD button (for TV/VCR)

15.

Press to rapidly advance the tape, or to view the picture rapidly in forward during playback mode. (Forward Search)

STOP/EJECT button

16.

Press to stop the tape motion. Press in the Stop mode to remove tape from the unit.

Remote sensor window

17.

18.HEADPHONE jack

To connect headphone (not supplied) for personal listening.

VIDEO input jack

19.

Connect to the video output jack of a video camera or VCR.

STOP/EJECT

HEADPHONE

AUDIO

VIDEO

- 9 - EN

1F12

ANT.

AUDIO OUT

COAXIAL

46 47 48 49

- TV/DVD/VHS REAR PANEL - [Fig.3]

20.AUDIO L/R input jacks

Connect to the audio output jacks of a video camera or VCR.

Cassette compartment

21.

22.PICTURE button

Press to adjust the picture.

Number buttons

23.

TV Mode:

Press two digits to directly access the desired channel. Remember to press a "0" before a single digit channel.

+100 button–

Press to select cable channels which are equal or greater than number 100.

DVD Mode:

Press to enter the desired number.

+10 button–

Press to enter the desired numbers which are equal or greater than number 10.

PAUSE button

24.

Pauses the current disc or tape operation.

SPEED button

25.

Press to choose the desired recording speed: SP/SLP.

C.RESET button

26.

Press to reset counter to 0:00:00. Press to cancel a setting of timer program. (See page 33.)

DISPLAY button

27.

TV/VCR Mode:

Display the counter or the current channel number and current time on the TV screen.

DVD Mode:

Displays the current status on the TV screen for checking purposes.

SETUP button

28.

Press to enter or exit the TV menu or DVD setup mode.

TITLE button

29.

Displays the title menu.

CLEAR button

30.

Resets a setting.

31.

MODE button

Activates program playback or random playback mode.

32.SEARCH MODE button

Press to locate a desired point.

AUDIO button

33.

Press to select a desired audio language or sound mode.

SUBTITLE button

34.

Press to select a desired subtitle language.

REPEAT button

35.

Repeats playback of the current disc, title, chapter or track.

ANGLE button (DVD mode)

36.

Press to change the camera angle to see the sequence being played back from a different angle.

SLEEP button (TV/VCR mode)

Sets the Sleep Timer. (See page 34.)

A-B REPEAT button

37.

Repeats playback of a selected section.

RETURN button

38.

Returns to the previous operation.

ENTER button

39.

Press to accept a setting.

Arrow buttons

40.

TV/VCR Mode:

Press to select a setting mode from the menu on the TV screen. Press to select or adjust from a particular menu.

DVD Mode:

Use when making settings while watching the display on a TV screen.

DISC MENU button

41.

Displays the menus in the DVD.

ZOOM Button

42.

Enlarges part of a DVD-reproduced image.

43.MUTE button

Mutes the sound. Press it again to resume sound.

DVD button

44.

Press to switch to DVD mode. DVD indicator on the front will lights on.

- 10 - EN

1F12

ANT.

OUT

ANT.

AUDIO OUT

COAXIAL

45.TV/VCR button

Press to switch to TV/VCR mode. TV/VCR indicator on the front will lights on.

ANT. in jack

46.

Connect to an antenna, cable system, or satellite system.

Power cord

47.

Connect to a standard AC outlet (120V/60Hz).

NOTE: Remove the power cord from the hook to

avoid breaking a wire before you connect to a standard AC outlet.

PREPARATION FOR USE

ANTENNA/CABLE CONNECTION

COAXIAL digital audio out jack

48.

Connect to the digital input of an external amplifier or decoder.

AUDIO L/R output jack

49.

Connect to the analog audio input of an external amplifier or decoder.

Satellite Box or Cable Box (Not supplied)

From Cable System or Satellite Dish

75-ohm From Cable System

Coaxial

Cable

(Not sup-

plied)

75-ohm Coaxial Cable (Not

supplied)

VHF/UHF SEPARATE ANTENNAS

In some areas it will be necessary to use an outdoor antenna.

CABLE WITHOUT CONVERTER/ DESCRAMBLER BOX

Use this connection if your cable system connects directly to your TV/DVD/VHS without a converter box.

By using this connection you can:

1) Use the TV/DVD/VHS remote to select channels.

2) Program one or more unscrambled channels for Automatic Timer Recording.

NOTE: This unit will ONL same channel.

Y record and view the

VHF/UHF Antenna (Not supplied)

VHF Antenna (Not supplied)

UHF Antenna (Not supplied)

VHF/UHF Combiner (Not supplied)

[Fig. 4]

Flat twin-lead cable

CABLE WITH CONVERTER/ DESCRAMBLER BOX OR SATELLITE BOX

If your cable service supplies you with a converter box or if you use a satellite system, you can use the basic connection shown in the ilustration.

By using this connection you can also record scrambled channels. However, channel selection must be made with the converter box or satellite box. This means that channels cannot be changed using the TV/DVD/VHS Remote Control. Unattended timer recording is limited to one channel at a time.

Antenna/Cable Connections Continued on the Next Page.

- 11 - EN

1F12

TO RECORD A SCRAMBLED/UNSCRAM-

VIDEO

HEADPHONE

AUDIO

BLED CHANNEL

1. Set the TV/DVD/VHS channel selector to the output channel of the Cable Converter Box or Satellite Box. (Ex. CH3)

2.Select the channel to record from your Cable

Converter Box or Satellite Box.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

INSTALLING THE BATTERIES

1)Open the battery compartment cover by pressing the cover on the remote unit in the direction of the arrow.

2)Insert 2 “AA” penlight batteries into the battery compartment in the direction indicated by the polarity (+/-) markings.

3)Replace the cover.

EXTERNAL INPUT MODE

CONNECTING TO EXTERNAL

INPUT JACKS

When you watch a program recorded on an another source (VCR or video camera), use the audio/video input jacks on the front of the TV/DVD/VHS.

Connect the audio/video output jacks of another source to the AUDIO L/R and VIDEO jacks of this TV/DVD/VHS.

Then press the SELECT button until "VIDEO" appears on the screen.

NOTE:

When you connect a monaural VCR (another

•

source) to this TV/DVD/VHS, connect the Audio output jack of the monaural VCR (another source) to the AUDIO L jack of this TV/DVD/VHS. The audio will output in both L and R channel equally.

To the audio output jacks

[Another source]

Audio/Video coaxial cable (not supplied)

etc.

To the video output jack

[Front of the TV/DVD/VHS]

[Fig. 5]

When using an external input signal (another VCR or video camera), connect the player’s audio/video output cables to the AUDIO L/R IN/ VIDEO IN jacks of your

AUX

TV/DVD/VHS. Then press the CHANNEL K or L button until “AUX” appears on the screen.

- 12 - EN

1F12

CONNECTING TO A STEREO SYSTEM (for DVD)

AUDIO OUT

COAXIAL

To Right (red) and Left (white) AUDIO OUT jacks (only DVD AUDIO OUT)

Stereo system

To ANALOG AUDIO INPUT jacks

AUDIO OUT

COAXIAL

Amplifier equipped with digital

input jacks, MD deck,

DAT deck, etc.

To COAXIAL DIGITAL AUDIO INPUT jack

To DIGITAL AUDIO OUT (PCM/BITSTREAM) COAXIAL jack

(only DVD AUDIO OUT)

NOTES:

Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner's Manuals for your, stereo system and any other components to be connected to the

•

TV/DVD/VHS.

CONNECTING TO AN AMPLIFIER EQUIPPED WITH DIGIT AL

INPUT JACKS, MD DECK OR DAT DECK (for DVD)

[Fig. 6]

Use an audio coaxial digital cable (commercially available) for the audio connections.

[Fig. 7]

NOTES:

The audio source on a disc in a 5.1 channel Dolby Digital surround format cannot be recorded as digital

•

sound by an MD or DAT deck. Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner's Manuals for the components to be connected to the TV/DVD/VHS.

•

Set DOLBY DIGITAL and DTS to OFF for audio output in the setup mode. Playing a TV/DVD/VHS using

•

incorrect settings may generate noise distortion, and may also damage the speakers. When DOLBY DIGITAL is set to OFF and VIRTUAL 3D to ON for audio output in the setup mode and

•

you select the audio source in a 5.1 channel Dolby Digital surround format, the audio will be muted.

- 13 - EN

1F12

CONNECTING TO A DOLBY DIGITAL DECODER

AUDIO OUT

COAXIAL

Front speaker

(left)

Center speaker

Front speaker

(right)

Surround

speaker

(left)

Surround

speaker

(right)

Subwoofer

To DIGITAL AUDIO OUT (PCM/BITSTREAM) COAXIAL jack

To COAXIAL DIGITAL AUDIO INPUT jack

Dolby Digital

or DTS decoder

OR DTS DECODER (for DVD)

If using this TV/DVD/VHS to play back a TV/DVD/VHS in a 5.1 channel Dolby Digital surround or DTS surround format, the TV/DVD/VHS outputs a Dolby Digital or DTS data stream from its COAXIAL digital audio out jack. By hooking the player up to a Dolby Digital or DTS decoder, you can enjoy a more convincing, realistic ambience with powerful and high-quality surround sound of a professional standard such as can be heard in movie theaters.

Use audio coaxial digital cables (commercially available) for the audio connections.

[Fig. 8]

NOTES:

Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner's Manuals for the components to be connected to the TV/DVD/VHS.

•

If connected to a Dolby Digital decoder, set DOLBY DIGITAL to ON for audio output in the setup mode.

•

If connected to a DTS decoder, set DTS to ON for audio output in the setup mode.

•

Unless connected to a Dolby Digital decoder or a DTS decoder, set DOLBY DIGITAL and DTS to OFF for

•

audio output in the setup mode. Playing a TV/DVD/VHS using incorrect settings may generate noise distortion, and may also damage the speakers.

When DOLBY DIGITAL is set to OFF and VIRTUAL 3D to ON for audio output in the setup mode and

•

you select the audio source in a 5.1 channel Dolby Digital surround format, the audio will be muted.

“DTS”and “DTS Digital Out”are trademarks of Digital Theater Systems, Inc.

- 14 - EN

1F12

TV/VCR SECTION

SET UP FOR USE

You can program the tuner to scan all the channels you receive in your area. NOTE: Channel memory programming is NOT needed when connected to a cable box or satellite box. Just

select the TV/DVD/VHS channel selector to the output channel of the cable box or satellite box (Ex CH3). Then select the channel to be viewed on the Cable Box or Satellite Box.

CHANNEL SET UP FOR THE

FIRST TIME

1 Plug in the TV/DVD/VHS power cord

Plug the TV/DVD/VHS power cord into a standard AC outlet.

NOTE:

If some digits appear in the corner of

•

the screen, press the POWER button without unplugging the power cord.

2 Turn on the TV/DVD/VHS

Press the POWER button to turn on the TV/DVD/VHS.

3 Select “ENGLISH” or “ESPAÑOL” or

“FRANÇAIS”

Select “ENGLISH” or “ESPAÑOL”=Spanish or “FRANÇAIS” =French using the

Arrow B or s button. “[ ]” indicate the selected language.

4 Begin auto preset

Press the Arrow K or L button to point to “AUTO PRESET”.

Then press the Arrow B button. The tuner scans and memorizes all

active channels in your area.

NOTES:

The TV/DVD/VHS distinguishes between standard

•

TV channels and cable channels. If you want to play or record a video tape

•

BEFORE presetting the tuner, you must press the SETUP button on the remote control. To preset the tuner again, see “CHANNEL SET UP AGAIN” on page 15.

The TV/DVD/VHS may memorize TV channels as

•

CATV channels if reception conditions is poor. If this happens, try AUTO MEMO action again when reception conditions are better.

5 After scanning

The tuner stops on the lowest memorized channel. If you want to recall the selected channels, you can

select the desired channel directly with the remote control number buttons or CHANNEL K or L.

– SET UP –

B LANGUAGE

[ENGLISH] ESP FRA

AUTO PRESET

– SET UP –

LANGUAGE [ENGLISH] ESP FRA

B AUTO PRESET

DELETING (OR ADDING)

CHANNEL

The channels you no longer receive or seldom watch can be deleted from the memory. (Of course, you can add the deleted channel into the memory again.)

1 Select “CHANNEL SET UP”

Press the SETUP button on the remote control.

Press the Arrow K or L button to point to “CHANNEL SET UP”.

Then, press the Arrow B button.

2 Select “ADD/DELETE CH”

Press the Arrow K or L button to point to “ADD/DELETE CH”.

Press the Arrow B button.

3 Enter the desired channel number

Press the Arrow K or L button until your desired channel number appears. (You can also use the number buttons or the CHANNEL K/L button to enter it) (Example: CH8)

4 Delete (or add) it from (into) memory

Press the Arrow B or s button. The channel number changes to light red. The channel is deleted from memory.

To delete another channel, repeat steps [3] and [4].

•

If you press the Arrow B or s button again, the

•

channel is memorized again.

5 Exit the channel setup mode

Added channel: Light blue. Deleted channel: Light red.

Press the SETUP button on the remote control to returns to TV mode.

NOTE: To confirm that channel(s) has been deleted or added, press the CHANNEL K or L button.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK

B CHANNEL SET UP

USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– CHANNEL SET UP –

B ADD / DELETE CH (TV)

AUTO PRESET

ADD / DELETE

- 15 - EN

1F12

CHANNEL SET UPAGAIN

Make sure ...

Press the POWER button to turn on the

•

TV/DVD/VHS.

NOTE: If Spanish or French is selected accidentally, press the SETUP button on the remote control, press the Arrow K button to point to “IDIOMA [ESPAÑOL]” or “LANGAGE” [FRANÇAIS], then press the Arrow B button, then press the SETUP button on the remote control.

1 Select “CHANNEL SET UP”

Press the SETUP button on the remote control.

Press the Arrow K or L button to point to “CHANNEL SET UP”.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK

B CHANNEL SET UP

USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

Then, press the Arrow B button.

2 Begin auto preset

Press the Arrow K or L button to point to “AUTO PRESET”.

– CHANNEL SET UP –

ADD / DELETE CH (TV)

B AUTO PRESET

Then, press the Arrow B button. The tuner scans and memorizes all

the active channels in your area.

3 After scanning

The tuner stops on the lowest memorized channel.

SELECTING THE LANGUAGE

Make sure ...

Press the POWER button to turn on the

•

TV/DVD/VHS.

NOTE: This function effects only the language on the screen menu and not the audio source.

1 Select “LANGUAGE”

Press the SETUP button on the remote control.

Press the Arrow K or L button to point to “LANGUAGE”.

2 Select “ENGLISH” or “ESPAÑOL” or

“FRANÇAIS”

Select “ENGLISH” or “ESPAÑOL”= Spanish or “FRANÇAIS”= French using the Arrow B or s

button.

3 Exit the Language mode

Press the SETUP button on the remote control to return to TV mode.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP

B LANGUAGE [ENGLISH]

CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

DAYLIGHT-SAVING TIME

Select this feature and the TV/DVD/VHS’s clock automatically will advance one hour in April, then reverse one hour in October.

When Daylight-Saving Time is ON, the clock will change automatically as follows:

First Sunday of April : At 2 AM the clock imme-

•

diately changes to 3 AM. Any timer programming you have set to occur between 2 AM and 3 AM will not record.

Last Sunday of October : At 2 AM the clock

•

immediately changes to 1 AM.

Make sure ...

Press the POWER button to turn on the

•

TV/DVD/VHS.

1 Select “SETTING CLOCK”

Press the SETUP button on the remote control.

Press the Arrow K or L button to point to “SETTING CLOCK”.

Then, press the Arrow B button.

2 Set “D.S.T.” (Daylight-Saving Time) to [ON]

Press the Arrow K or L button to point to “D.S.T.”.

Then, press the Arrow B or s button until [ON] appears.

3 Exit the Daylight-Saving Time mode

Press the SETUP button on the remote control to return to TV mode.

TO CANCEL THE DAYLIGHT-SAVING TIME

Repeat steps [1] to [2], select [OFF] using the Arrow B or s button.

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH [AUTO]

MANUAL CLOCK SET

B D.S.T. [ON]

- 16 - EN

1F12

CLOCK SET UP

(AUTO / MANUAL)

Set the clock accurately for proper automatic timer recording. If the Public Broadcasting Station (PBS) is available in your area, follow “AUTO CLOCK SETTING”. If it is not, follow “MANUAL CLOCK SETTING”.

AUTO CLOCK SETTING

You can have the TV/DVD/VHS set the clock automatically by using the Public Broadcasting Station (PBS) channel in your area. Once you have set the clock by using the following procedure, the TV/DVD/VHS will automatically monitor the correct time and date being broadcast by the PBS station in your area, using a new service called Extended Data Service (XDS).

Make sure ...

TV/DVD/VHS power must be turned on.

•

Confirm that the antenna connections are correct.

•

The cable converter box must be turned on if your

•

TV/DVD/VHS is connected directly to it. (See NOTES:)

The channel is properly set in advance. (See page

•

16.)

NOTES:

Auto clock setting only needs to be set once. But it

•

can be done again if the clock’s time has become incorrect for some reason.

If the TV/DVD/VHS is connected directly to a

•

cable converter box or satellite box, the local PBS station must be selected on the cable box itself, and the TV/DVD/VHS must be set to the output channel of the cable converter box or satellite box (usually channel 3 or 4), to be able to set up or correct the clock automatically.

If you do not know what your local PBS station is, then follow “Manual Clock Settings” on page 18.

The TV/DVD/VHS cannot control the channels of the cable converter box or satellite box.

2 Set “AUTO CLOCK” to [ON]

Press the Arrow B or s button repeatedly until [ON] appears.

– SETTING CLOCK –

B AUTO CLOCK [ON]

AUTO CLOCK CH [AUTO]

MANUAL CLOCK SET D.S.T. [OFF]

3 Enter the channel number for the PBS station

Press the Arrow K or L button to point to “AUTO CLOCK CH”.

Then press the Arrow B or s button until the channel number for your local PBS station appears.

If you do not know the PBS channel number, leave it set to [AUTO] which is located before [2]. The TV/DVD/VHS will search automatically all available channels for the local PBS station, and will select that channel.

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH [AUTO]

MANUAL CLOCK SET

B D.S.T. [OFF]

4 Exit the Auto Clock Setting

Press the SETUP button on the remote control to return to TV mode.

5 Turn off the TV/DVD/VHS

Turn the TV/DVD/VHS off. Because the Auto Clock functions automatically while the TV/DVD/VHS is off.

If you choose [AUTO],

the TV/DVD/VHS must search until the PBS chan-

•

nel is found. It must scan each channel for a couple of seconds to determine if that channel is transmitting the XDS signal.

if the time, that is automatically set by this selected

•

PBS station is incorrect, it may not be your local PBS station, but one from a different time zone. Or there is a case that no channel is broadcasting the XDS signal in your area, as shown by no time. In these cases, you must manually enter the correct local PBS station, or set the clock manually and turn off the Auto Clock Setting feature.

1 Select “SETTING CLOCK”

Press the SETUP button on the remote control.

Press the Arrow K or L button to point to “SETTING CLOCK”.

Then, press the Arrow B button.

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

- 17 - EN

1F12

MANUAL CLOCK SETTING

Make sure ...

TV/DVD/VHS power must be turned on.

•

In the example below, the clock is to be set to:

DATE May 1st, 2001 SETTING TIME 5:40PM

1 Select “SETTING CLOCK”

Press the SETUP button on the remote control.

Press the Arrow K or L button to point to “SETTING CLOCK”.

Then, press the Arrow B button.

2 Select “MANUAL CLOCK

SET”

Press the Arrow K or L button to point to “MANUAL CLOCK SET”.

Then, press the Arrow B button.

3 Select the month

Press the Arrow K or L button until your desired month appears. (Example: May → 05)

Then, press the Arrow B button.

4 Select the day

Press the Arrow K or L button until your desired day appears. (Example: 1st → 01)

Then, press the Arrow B button.

5 Select the year

Press the Arrow K or L button until your desired year appears. (Example: 2001)

Then, press the Arrow B button.

- TV/VCR SETUP -

TIMER PROGRAMMING

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH [AUTO]

B MANUAL CLOCK SET

D.S.T. [OFF]

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / – – – – – – – – –

HOUR MINUTE

– – : – – – –

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 1 – – – – – – –

HOUR MINUTE

– – : – – – –

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 1 TUE 2 0 0 1

HOUR MINUTE

– – : – – – –

6 Select the hour

Press the Arrow K or L button until your desired hour appears. (Example: 5, PM)

Then, press the Arrow B button.

7 Select the minute

Press the Arrow K or L button until the desired minute appears. (Example: 40)

8 Start the clock

Press the SETUP button on the

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 1 TUE 2 0 0 1

HOUR MINUTE

0 5 : – – PM

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 1 TUE 2 0 0 1

HOUR MINUTE

0 5 : 4 0 PM

5:40 PM

remote control. Although seconds are not displayed,

they begin counting from 00 when you press the SETUP button on the remote control. Use this feature to synchronize the clock with the correct time.

NOTE:

When unplugging the AC cord or if there is a power failure for more than 30 seconds, you may have to reset the clock.

TO CHANGE CLOCK SETTING

If you want to change the clock,

1)Follow steps [1] and [2].

2)Select where you want to change using the Arrow B or s button.

3)Enter correct numbers using the Arrow K or L button.

4)Press the SETUP button on the remote control to start the clock.

PLEASE NOTE:

If there is no local PBS station in your area or on your cable system, select “AUTO CLOCK” and press the Arrow B or s button to turn [OFF] this function. Then you can manually adjust the clock.

- 18 - EN

1F12

TV OPERATION

WA TCHING ATV PROGRAM

1 Turn on the TV/DVD/VHS

Press the POWER button to turn on the TV/DVD/VHS.

2 Select the channel number

Press the CHANNEL K or L button to select your desired channel number or press the number buttons on the remote control.

Remember: If the TV/DVD/VHS is connected to a cable box or satellite box, the TV/DVD/VHS must be on CH3 or CH4, then the channel to be viewed must be selected on the cable box or satellite box.

3 Adjust sound

Press the VOLUME XXor YYbutton to adjust the volume.

VOLUME 20

C C C C C C C C C C C C

DEGAUSSING

Magnetism from nearby appliances might affect the color of the TV picture.

If this happens, move this unit away from the appliance. If the color is still not correct, disconnect power cord from AC outlet then reconnect it after 30 minutes.

PICTURE CONTROL

The TV/DVD/VHS’s picture controls – BRIGHT, CONTRAST, COLOR, TINT and SHARPNESS –

are preset to factory specifications. Although they are usually the best, you may need to make some further adjustments for a natural looking image.

NOTES:

Procedures must be followed within 5 seconds or

•

the Picture Control mode will be cancelled. When setting the Picture Control, the Game mode

•

will be cancelled.

Make sure ...

TV/DVD/VHS power must be turned on.

•

1 Select “PICTURE CONTROL”

Press the PICTURE button on the remote control.

2 Select item you want to adjust

Press the Arrow K or L button until desired control is displayed.

BRIGHT CONTRAST COLOR TINT SHARPNESS

BRIGHT

PP PP PP PP PP PP PP CC PP PP PP PP PP PP PP

–

3 Adjust the picture control

Press the Arrow B or s button to adjust to your desired level.

Arrow s Arrow B

BRIGHT to decrease to increase

brightness brightness

CONTRAST to decrease to increase

contrast contrast

COLOR to pale to brilliant TINT to purple to green

SHARPNESS to soft to clear

If there is a power failure of any kind, the unit will

•

retain its memory for this feature.

- 19 - EN

1F12

CLOSED CAPTION SYSTEM

You can view specially labeled (cc) TV programs, movies, news, pre-recorded tapes with either a dialogue caption or text display.

CAPTION mode: By choosing the caption mode, you

can watch dramas, movies and news while captioning the dialogues and the contents of news.

TEXT mode: By choosing the text mode, you can

watch half screen text information if you want.

1-2: You may get these captions or text information

by selecting either “1” or “2”. Caption “2” is used, usually for a second language if available.

1 Select “CAPTION”

Press the SETUP button on the remote control.

Press the Arrow K or L button to point to “CAPTION”.

2 Select your desired caption menu

Press the Arrow B or s button until your desired caption menu appears.

([CAPTION1], [CAPTION2], [TEXT1] or [TEXT2])

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [OFF]

ZERO RETURN TIME SEARCH INDEX SEARCH

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCKB CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [CAPTION1]

ZERO RETURN TIME SEARCH INDEX SEARCH

NOTE:

Not all programs are broadcast with closed captions. Your television is designed to provide error free closed captions from high quality antenna, cable and VCR signals. Conversely, poor quality signals are likely to result in caption errors or no captions at all. Common signal conditions which may cause captions errors are listed below:

Automobile ignition noise

•

Electric motor brush noise

•

Weak snowy reception on TV screen

•

Multiplex signal reception displaying picture

•

ghosts or airplane flutter. Playback of poorly recorded or worn VCR tapes.

•

NOTE:

If the TV/DVD/VHS displays a black box on the TV screen, this means that the TV/DVD/VHS is set to the TEXT mode. To clear screen, select [CAPTION1], [CAPTION2] or [OFF].

Make sure ...

TV/DVD/VHS power must be turned on.

•

3 Exit the caption setting mode

Press the SETUP button on the remote control to return to TV mode.

TO CANCEL THE CLOSED CAPTION SYSTEM

Repeat steps [1] and [2], select [OFF] using the Arrow B or s button. Press the SETUP button on the remote control to return to TV mode.

WHEN THE CLOSED CAPTION MODE IS ON

The On-Screen Display will disappear after 5 seconds.

This is also true when the MUTE button is pressed,

•

and when the PAUSE button is pressed while recording.

If there is a power failure of any kind, the unit will

•

retain its memory for this feature.

- 20 - EN

1F12

V-CHIP SET UP

V-CHIP enables parents to prevent their children from watching inappropriate material on TV.

V-CHIP reads the ratings for programming (except for news and sports programs, unedited movies on premium cable channels, and Emergency Broadcast System signals), then denies access to programming if the program’s rating meets the limitations you select. In this case, “PROTECTED PROGRAM by ...” message appears on the TV screen. You can watch the protected program by entering access code (default 0000).

To block ratings, follow the steps below.

Programming may be rated by the Motion Picture

•

Association of America (MPAA) or according to the Television Parental Guidelines. In order to block any inappropriate programming, set your limits in both places (MPAA RATING and TV RATING).

TV RATING SET UP

Make sure ...

TV/DVD/VHS power must be turned on.

•

1 Select “V-CHIP SET UP”

Press the SETUP button on the remote control.

Press the Arrow K or L button to point to “V-CHIP SET UP”.

Then, press the Arrow B button.

2 Input Access code

Use the number buttons to enter 4digit access code. The default code is 0000.

3 Select “TV RATING”

Press the Arrow K or L button to point to “TV RATING”.

Then, press the Arrow B button.

4 Select your desired item

Press the Arrow K or L button to point to your desired item.

Then, press the Arrow B button to select [BLOCK] or [VIEW].

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

ACCESS CODE

_ _ _ _

– V-CHIP SET UP –

B TV RATING

MPAA RATING CHANGE CODE

B TV–Y [VIEW]

TV–Y7 ( ) [VIEW] TV–G [VIEW] TV–PG( ) [VIEW] TV–14 ( ) [VIEW] TV–MA( ) [VIEW]

When you select the rating category and turn it

•

[BLOCK], the higher rating will turn [BLOCK] automatically. Also, the lower rating will turn [VIEW] automatically.

When you turn “TV-Y” to [VIEW], the all ratings

•

will turn to [VIEW] automatically.

Selection Rating Category Explanations

TV-Y Appropriate for all children TV-Y7 Appropriate for children seven and older TV -G General Audience TV-PG Parental Guidance suggested. TV-14 Unsuitable for children under 14

TV-MA Mature audience only

When you select TV-Y7, TV-PG, TV-14, or TV-MA and you press the Arrow B button, the sub-ratings will appear on the TV screen.

If you select the rating category (example: TV-PG) and turn it [BLOCK] or [VIEW], the sub-ratings (example: V for Violence) will turn [BLOCK] or [VIEW] automatically.

You can set the sub-ratings to [BLOCK] or [VIEW] individually when the rating category is set to [BLOCK].

To set the sub-ratings individually, follow the steps below.

When you select [TV-Y7]:

•

Press the Arrow L or K button to select “FV” (Fantasy Violence).

TV–Y7 [BLOCK]

B FV [BLOCK]

Then, press the Arrow B button to select [BLOCK] or [VIEW].

When you select [TV-PG], [TV-14] or [TV-MA]:

•

Press the Arrow L or K button to select “D”(Suggestive Dialog),

“L”(Coarse Language), “S”(Sexual Situation), or

TV–PG [BLOCK]

B D [BLOCK]

L [BLOCK] S [BLOCK] V [BLOCK]

“V”(Violence). Then, press the Arrow B button to select [BLOCK] or [VIEW].

Note: When you select [TV-MA], “D” does not appear on the TV screen.

The sub-ratings which set to

•

[BLOCK] appears next to the rating category in the TV RATING

B TV–Y [VIEW]

TV–Y7 ( ) [VIEW] TV–G [VIEW] TV–PG (DLSV) [BLOCK] TV–14 (DLSV ) [BLOCK] TV–MA ( LSV ) [BLOCK]

menu.

5 Exit the V-Chip setting mode

Press the SETUP button on the remote control to return to original mode.

- 21 - EN

1F12

MPAA RATING SET UP

Make sure ...

TV/DVD/VHS power must be turned on.

•

1 Select “V-CHIP SET UP”

Press the SETUP button on the remote control.

Press the Arrow K or L button to point to “V-CHIP SET UP”.

Then, press the Arrow B button.

Use the number buttons to enter 4digit access code. The default code is 0000.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

ACCESS CODE

_ _ _ _

CHANGE ACCESS CODE

To change access code, follow the steps.

Press the SETUP button so that the TV/VCR SETUP display appears on the TV screen.

Press the Arrow K or L button to point to "V-CHIP SET UP". Then, press the Arrow B button.

Use the number buttons to enter 4digit access code. The default code is 0000.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

ACCESS CODE

_ _ _ _

3 Select “MPAA RATING”

Press the Arrow K or L button to

– V-CHIP SET UP –

TV RATING

B MPAA RATING

CHANGE CODE

point to “MPAA RATING”. Then, press the Arrow B button.

Selection Rating Category Explanations

G General Audience PG Parental Guidance suggested. PG-13 Unsuitable for children under 13 R Restricted; under 17 requires accompa-

nying parent or adult guardian

NC-17 No one under 17 admitted X Mature audience only

4 Select your desired item

Press the Arrow K or L button to point to your desired item.

Then, press the Arrow B button to select [BLOCK] or [VIEW].

When you select the rating cate-

•

gory and turn it [BLOCK], the higher rating will turn [BLOCK] automatically. Also, the lower rating will turn [VIEW] automatically.

When you turn “G” to [VIEW], the all ratings will

•

turn to [VIEW] automatically.

G [VIEW] PG [VIEW] PG–13 [VIEW]

B R [BLOCK]

NC–17 [BLOCK] X [BLOCK]

Press the Arrow K or L button to

– V-CHIP SET UP –

TV RATING MPAA RATING

B CHANGE CODE

point to "CHANGE CODE". Then, press the Arrow B button.

Use the number buttons to enter your desired access code in the NEW CODE space. Then enter the

NEW CODE

_ _ _ _

CONFIRM CODE

_ _ _ _

same code in the CONFIRM CODE space. V-CHIP SET UP screen appear on the screen.

If you enter wrong code, repeat

•

step 5, making sure you enter the

NEW CODE

X X X X

CONFIRM CODE

_ _ _ _

same new code exactly in the confirm code space.

Press the SETUP button to exit the TV/VCR SETUP.

Note:

If you unplug the power code or power failure

•

occures, the changed access code will be lost and will return to default (0000). Change your access code again as necessary.

5 Exit the V-Chip setting mode

Press the SETUP button on the remote control to return to original mode.

- 22 - EN

1F12

MTS(Multi-Channel Television sound)SYSTEM

You can record or listen to a program in MTS stereo.

CHECKING THE SELECTED MTS MODE

When you play a VHS tape, or receive a broadcast on the TV/DVD/VHS tuner channel you are watching, the status shown below will appear when you press the DISPLAY button on the remote control.

SAP

HIFI

PLAY HIFI CH 123

SP COUNT 0:00:00

Second Audio Program, which means your program, can also be received in a second language or sometimes a radio station.

High Fidelity which produces better sound than standard stereo TV/DVD/VHSs.

12:00AM

STEREO/SAP

3] 2] 1]

1] When a program is broadcast in stereo, STEREO

appears on the TV screen.

2] When a program is broadcast in second audio,

SAP appears on the TV screen.

3] When a program broadcast both in stereo and sec-

ond audio, STEREO and SAP appear on the TV screen.

NOTE: Although a program may be broadcast in

both stereo and second audio, you cannot record in both stereo and second audio at the same time.

4] While the TV/DVD/VHS is set in HIFI stereo

mode and playback mode. HIFI appears on the TV screen. While the TV/DVD/VHS is set in monaural(MONO) mode, HIFI disappears from the TV screen.

NOTE: If you play non-HIFI tapes while the

TV/DVD/VHS is set in HIFI, HIFI will disappear from the TV screen and the TV/DVD/VHS will play automatically in monaural.

MTS RECORDING/MONITOR MODE

Type of broadcast Display on STEREO/SAP Hi-Fi audio track(2-channel) Normal audio

the TV screen SELECTION L-channel R-channel track

Regular -None- -Invalid- Mono Mono Mono

(monaural audio)

Stereo broadcast STEREO -Invalid- L R L+R

Bilingual broadcast SAP STEREO* Main audio Main audio Main audio

program program program

SAP* Sub audio Sub audio Sub audio

Stereo & Bilingual STEREO STEREO* L R L+R

broadcast SAP

SAP* sub audio sub audio sub audio

*You must select the recording mode in TVAUDIO [STEREO] or [SAP] when you record a broadcast.

- 23 - EN

program program program

1F12

SELECTING THE MTS SYSTEM

Make sure ...

TV/DVD/VHS power must be turned on.

•

TO SELECT HIFI MODE

Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow K or L button to point to “USER’S SET UP”. Then, press the Arrow Bbutton.

2 Select“VCR AUDIO”

Press the Arrow K or L button to point to“VCR AUDIO”. Then, press the Arrow Bbutton.

3 Select [HIFI]

Press the Arrow B or s button until [HIFI] appears.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

– USER’S SET UP –

RENTAL [OFF] REPEAT PLAY [OFF] AUTO RETURN [OFF]

B VCR AUDIO [HIFI]

TV AUDIO [STEREO]

– USER’S SET UP –

RENTAL [OFF] REPEAT PLAY [OFF] AUTO RETURN [OFF]

B VCR AUDIO [HIFI]

TV AUDIO [STEREO]

TO SELECT MONO MODE

You can change the selection to “MONO” if you want to listen to HIFI tapes in normal audio playback.

1) Press the SETUP button on the remote control. Press the Arrow K or L button to point to “USER’S SET UP”.Then, press the Arrow B

button.

2) Press the Arrow K or L button to point to

“VCR AUDIO”. Then, press Arrow Bbutton.

3) Press the Arrow B or s button until [MONO] appears.

4) Press the SETUP button on the remote control to return to TV mode.

TO SELECT STEREO, SAP, OR MONO

Select “USER’S SET UP”

Press the “SETUP” button on the remote control.

Press the Arrow K or L button to point to “USER’S SET UP”.Then, press the Arrow B button.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

4 To return to TV mode

Press the SETUP button on the remote control to return to TV mode.

NOTES:

Normally, “HIFI” should be selected for playback-

•

with HIFI sound.

When you play non-HIFI tapes, the TV/DVD/VHS

•

will play automatically in the monaural mode.

The TV/DVD/VHS records automatically MTS

•

broadcasts in HIFI stereo sound unless you select SAP mode recording before you begin recording.

2 Select “TV AUDIO”

Press the Arrow K or L button to point to“TV AUDIO”. Then, press the Arrow Bbutton.

– USER’S SET UP –

RENTAL [OFF] REPEAT PLAY [OFF] AUTO RETURN [OFF] VCR AUDIO [HIFI]

B TV AUDIO [STEREO]

3 Select [STEREO], [SAP], or [MONO]

Press the Arrow B or s button until [STEREO], [SAP], or [MONO] appears.

4 To return to TV mode

Press the SETUP button on the remote control to return to TV mode.

NOTES:

• You must select the recording mode,either TV AUDIO [STEREO] or [SAP] when you record a broadcast. Refer to

• If you select second audio when second audio is not available, the TV/DVD/VHS will record normal audio.

“MTS RECORDING/MONITOR MODE”.

- 24 - EN

1F12

VIDEO CASSETTE

This TV/DVD/VHS will operate with any cassette that has the mark. For best results, we recommend the use of high-quality tapes. Do not use poor quality or damaged tapes.

PRECAUTIONS

Avoid moisture. Moisture condensation may occur

•

on the tape if it is moved from a cold place to a warm place or visa versa. Before using a tape with these conditions, to avoid damage of the tape and your TV/DVD/VHS, wait until the tape has warmed to room temperature and the moisture has evaporated.

Avoid extreme heat, high humidity and magnetic

•

fields. Do not tamper with the cassette mechanism.

•

Do not touch the tape with your fingers.

•

TWO DIFFERENT TAPE SPEEDS

Before recording, select the tape speed from : SP mode (Standard Play) or SLP mode (Super Long

Play). The table below shows the maximum recording/play-

back time using T60, T120 or T160 tapes in each mode.

Tape Speed Recording/Playback Time

Type of tape

SP mode 1 hour 2 hours 2-2/3 hours SLP mode 3 hours 6 hours 8 hours

Note: You can play back a tape recorded in LPmode (Long Play).

T60 T120 T160

INSERTING A CASSETTE

Insert the cassette in the direction as shown. Push in gently, but continuously, on the center-back of the cassette until it is drawn into the TV/DVD/VHS. The TV/DVD/VHS will automatically turn on.

Window

CORRECT

WRONG

REMOVING A CASSETTE

1)In the Stop mode, press the EJECT button on the remote control or press the STOP/EJECT button on the TV/DVD/VHS. The cassette will eject.

2)Pull the cassette out of the cassette compartment.

3)Store the cassette in its case as shown.

ERASE PREVENTION

You can prevent accidental erasing of recording by breaking off the tab on the back edge of the cassette.

Tab

If you decide to record on the tape again, cover the hole with plastic tape.

Transparent Tape

- 25 - EN

1F12

PLAYBACK

NORMAL PLAYBACK

Make sure ...

TV/DVD/VHS power must be turned on.

•

1 Insert a prerecorded tape

If the erase-protection tab has been removed, the TV/DVD/VHS will start playback automatically.

2 To begin playback

Press the PLAY button.

3 To stop playback

Press the STOP button when playback is completed.

NOTE: When you insert a tape without tab during the DVD mode, the playback does NOT start automatically. If you want to play the tape, press the SELECT button to switch to the TV/VCR mode, then press the PLAY button.

PLAY

STOP

SLOW MOTION

During pause, press the FWD button to reduce the playback speed. The TV/DVD/VHS mutes the sound during slow motion. Press the PLAY button to return to normal playback.

NOTE: If it is left in the Slow mode for more than five minutes, the TV/DVD/VHS will automatically go into the Stop mode.

PICTURE SEARCH

This feature is very useful in finding or skipping over a particular scene on a tape. In this mode, the sound will be muted.

1)You may view a video tape at a high speed in either a forward or reverse direction by pressing the F.FWD or REW button. (in the SP / LP / SLP modes)

2)Press it again and the TV/DVD/VHS will now search in super high speed. (in the LP / SLP modes only)

NOTE: Tapes recorded in the SP or LP mode will display a noise bar on the TV screen and the picture may revert to Black and White. This is normal.

3)Press the PLAY button to return to normal speed.

STILL PICTURE

TRACKING ADJUSTMENT

Tracking adjustment will be set automatically

•

(Digital Tracking function) when you start playback.

However when playing pre-recorded tapes or tapes

•

recorded on units other than your own, noise lines (black and white streaks) may appear on the playback picture. If this occurs, you can adjust the tracking control manually by pressing the CHANNEL K or L button until the streaks disappear. To return to the DTR function, stop the tape once and start playback again.

You can reduce the noise lines by pressing the

•

CHANNEL K or L button in slow mode, too. Tracking adjustment in Slow mode will not be set automatically.

NOTE:

In Still mode, press the SLOW button and press the

•

CHANNEL K or L button until streaks disappear. To return to Still mode, press the PAUSE button again.

You can view a still picture on the TV screen during playback (the Still mode). Press the PAUSE button during playback. Only tapes recorded in the SLP mode will show the least amount of lines.Press the PLAY button to return to playback.

NOTES:

You can advance the picture one frame at a time by

•

pressing the PAUSE button during the Still mode. If it is left in the Pause mode for more than five

•

minutes, the TV/DVD/VHS will automatically switch to the Stop mode.

VERTICALHOLD CONTROL

In the Pause/Still mode only, when the picture begins to vibrate vertically, stabilize the picture by pressing the CHANNEL K or L button.

NOTE:

If there are video noise lines on the screen, see Tracking Adjustment section.

- 26 - EN

1F12

SPECIAL PLAYBACK

Make sure ...

TV/DVD/VHS power must be turned on.

•

Insert a prerecorded tape.

•

Before playback, follow steps below.

•

RENTAL PLAYBACK

This function enables you to improve the picture quality when playing back worn cassettes such as rented tapes.

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow K or L button to point to “USER’S SET UP”.

Then, press the Arrow B button.

2 Set “RENTAL” to [ON]

Press the Arrow K or L button to point to “RENTAL”.

Press the Arrow B or s button until [ON] appears.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

USER’S SET UP

–

B RENTAL [ON]

REPEAT PLAY [OFF] AUTO RETURN [OFF] VCR AUDIO [HIFI] TV AUDIO [STEREO]

AUTO REPEAT PLAYBACK

The TV/DVD/VHS has the auto repeat function that allows you to repeat a tape indefinitely without touching the PLAY button.

ALL REPEAT: Repeat playback from the beginning

to the end of the tape.

BLANK REPEAT: Repeat playback from the begin-

ning to a blank part, which is blank for more than 10 seconds.

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow K or L button to point to “USER’S SET UP”.

Then, press the Arrow B button.

–

2 Select “ALL” or “BLANK”

Press the Arrow K or L button to point to “REPEAT PLAY”.

Press the Arrow B or s button repeatedly until your desired selection [ALL] or [BLANK] appears.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

USER’S SET UP

–

RENTAL [OFF]

B REPEAT PLAY [ALL]

AUTO RETURN [OFF] VCR AUDIO [HIFI] TV AUDIO [STEREO]

–

3 Exit the Rental setting

Press the SETUP button on the remote control to return to the TV mode.

4 Start playback

Press the PLAY button to start playback. “RENTAL PLAY B” appears.

Once you select the Rental mode, it stays in effect

•

even after you turn off the TV/DVD/VHS.

TO CANCEL THE RENTAL MODE

Repeat steps [1] and [2], select [OFF] using the Arrow B or s button on the remote control. Press the SETUP button on the remote control to return to TV mode.

If there is a power failure of any kind, the unit will retain its memory for this feature.

3 Exit the Repeat Play setting

Press the SETUP button on the remote control to return to the TV mode.

4 Start playback

Press the PLAY button to start the Repeat Play. ”REPEAT PLAY B” appears.

Once you select the Repeat Play mode, it stays in

•

effect even after you turn off the TV/DVD/VHS. If the Rental mode is set [ON], the “RENTAL

•

PLAY B” display has priority.

TO CANCEL THE REPEAT PLAYMODE

Repeat steps [1] and [2], select [OFF] using the Arrow B or s button on the remote control. Press the SETUP button on the remote control to return to TV mode.

If there is a power failure of any kind, the unit will retain its memory for this feature.

- 27 - EN

1F12

Make sure ...

TV/DVD/VHS power must be turned on.

•

Insert a tape.

•

ZERO RETURN

This function allows you to search easily a beginning point that you want to review by rewinding or fast forwarding.

NOTE:

Zero Return WILL blank portion of a tape.

NOT work on a blank tape or a

This function will not operate in recording mode.

•

This function is not operative when a cassette tape

•

is not inserted in the TV/DVD/VHS.

In the example below: To watch a program after 2 hour 50 minutes from the present position, in either direction.

1 Insert a tape.

1 Stop a tape at your desired point

Rewind or fast forward the tape to the beginning point at which you want to review.

2 Reset the counter to 0:00:00

Press the COUNTER RESET button repeatedly.

3 Begin recording or playback

Press the RECORD or PLAY button. Press the STOP button when recording or playback is

completed.

4 To activate “ZERO RETURN” mode

Press the SETUP button on the remote control.

Press the Arrow K or L button to point to “ZERO RETURN”.

Then, press the Arrow B button. The counter will appear on the TV screen. The tape will automatically stop when the counter

returns to 0:00:00.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF]

B ZERO RETURN

TIME SEARCH INDEX SEARCH

TIME SEARCH

The Time Search function makes it possible to quickly advance the tape to your desired position simply by entering the exact amount of playback time you want to skip.

NOTES:

Time Search can be set up to a maximum of 9

•

hours 50 minutes (9:50) by 10 minutes at a time.

2 Select “TIME SEARCH” mode

Press the SETUP button on the remote control.

Press the Arrow K or L button to point to “TIME SEARCH”.

Then, press the Arrow B button.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN

B TIME SEARCH

INDEX SEARCH

3 Enter your desired time

Press the Arrow K or L button until your desired time appears. (Example: “2:50” stands for 2 hours 50 minutes)

If you wish to cancel the Time Search at this point, press the SETUP button on the remote control.

TIME SEARCH

2 : 50

4 Begin Time Search

By pressing the Arrow s or B button, the TV/DVD/VHS will rewind or fast forward to the specified point.

The time counts down as the searching progresses. When 0:00 is reached, the tape will start playback automatically.

TO CANCEL THE TIME SEARCH at this point

Press the STOP/EJECT button on the TV/DVD/VHS or the remote control. This will delete the selected time.

- 28 - EN

1F12

INDEX SEARCH

This feature provides a method of indexing the starting point so that it can be easily returned to in either fast forward or rewind mode.

The index mark will be made automatically when

•

the REC button is pressed. It will also be marked at the starting point of Timer recording and OTR.

The index mark will not be recorded if the PAUSE

•

button is pressed and released during recording. The time gap between making the index marks on

•

the tape should be greater than 1 minute for SP recording, 2 minutes for LP recording and 3 minutes for SLP recording.

In some cases, the index mark at the beginning of

•

video tape cannot be detected.

Example: You are watching program number 4 and

want to fast forward to program number 7. You must skip three programs.

CURRENT PLAYBACK PROGRAM

1 Select “INDEX SEARCH”

Press the SETUP button on the remote control. Press the Arrow K or L button to point to “INDEX SEARCH”. Then,

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH

B INDEX SEARCH

press the Arrow Bbutton

2 Enter your desired number

Press the Arrow K or L button until the number of programs that you want to skip appears. (Example: “03” for 3 programs)

The Index Search mode will be

•

canceled if the procedures are not activated in 30 seconds.

INDEX SEACH

0 3

3 Begin Index Search

Press the Arrow s or B button. The TV/DVD/VHS begins rewinding or fast forwarding to the beginning of desired program.

NOTE: Every time an index signal is skipped, the number in the program indicator decreases by one.

Beginning of tape

Pro.1 Pro.2 Pro.3 Pro.4 Pro.5 Pro.6 Pro.7

4321123

INDEX MARK

End of tape

SPECIAL FEATURES

REAL TIME TAPE COUNTER

This shows the elapsed recording or playback time in hours, minutes, and seconds. (The displayed time will not change on a blank tape or blank portions on the tape.)The “–” indication will appear when the tape has rewound further than “0:00:00” on the tape counter.

4 After Index Search

When the preset program is reached, the TV/DVD/VHS will start playback automatically.

A video cassette must be inserted in the

•

TV/DVD/VHS for this function to work. The number of Index Searches can be set up to 20.

•

This function will not operate in the recording mode.

•

When you want to cancel the Index Search while

•

in progress, press the STOP button.

AUTO REWIND-EJECT

When the end of a tape is reached during record-

•

ing, playback, or fast-forward, the tape will automatically rewind to the beginning. After rewinding finishes, the TV/DVD/VHS will eject the tape and turn itself to off.

This function is operative when Repeat Play is set

•

to the [OFF] position. The tape will not auto-rewind during timer record-

•

ing or One Touch Recording.

- 29 - EN

1F12

RECORDING

Make sure ...

TV/DVD/VHS power must be turned on.

•

Insert a cassette tape with its erase prevention tab in place. (If necessary, rewind or fast forward the tape to

•

the point at which you want to begin recording.)

NOTES:

This unit will ONLY record and view the same channel.

•

This unit cannot record the contents from the built-in DVD.

•

NORMAL RECORDING

You can ONLY watch the same TV program that is being recorded.

1 Select the channel to be recorded

Press the number buttons on the remote control or the CHANNEL K or L button.

Remember: If the TV/DVD/VHS is connected to a cable box or satellite box, the TV/DVD/VHS must be on CH3 or CH4, then the channel to be recorded must be selected on the cable box or satellite box.

2 Select the tape speed

Press the SPEED button to select the desired tape speed (SP/ SLP).

3 Begin recording

Press the RECORD button.

REC

CH 10

SKIPPING UNWANTED

SCENES DURING RECORDING

Press the PAUSE button to temporarily stop recording.

Press the PAUSE or RECORD button to resume recording.

NOTES:

After five minutes, the

•

TV/DVD/VHS will automatically switch to the Recording mode to prevent tape damage.

If “CLOSED CAPTION (ON)” is selected, the On-

•

Screen Display will appear for 5 seconds, then disappear.

PAUSE

4 Stop recording

Press the STOP button when recording is completed.

- 30 - EN

1F12

OTR (One Touch Recording)

This function enables you to set a recording length simply by pressing the REC/OTR button on the TV/DVD/VHS.

Make sure ...

TV/DVD/VHS power must be turned on.

•

Insert a cassette tape with its erase prevention tab

•

in place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.)

NOTES:

This function CANNOT be done from the remote

•

control. Recording starts immediately when the REC/OTR

•

button is pressed. When the REC/OTR button is pressed 18 times, the

•

TV/DVD/VHS returns to the Normal Recording mode.

To stop the OTR operation, press the STOP button

•

on the TV/DVD/VHS or on the remote control. To show the remaining time, press the DISPLAY

•

button on the remote control so that “OTR” appears on the TV screen. (It will show up momentarily then disappear.)

Recording stops when 0:00 is reached.

•

Please note that in the SLP mode maximum record-

•

ing time, assuming the tape is started at the beginning, is 8 hours using T-160 (or 6 hours using T-

120). If the tape runs out before the end time, the

•

TV/DVD/VHS will switch to the Stop mode immediately, ejects the tape and turns itself off.

1 Select the channel to be recorded

Press the number buttons on the remote control or the CHANNEL K or L button.

Remember: If the TV/DVD/VHS is connected to a cable box or satellite box, the TV/DVD/VHS must be on CH3 or CH4, then the channel to be recorded is selected on the cable box or satellite box.

2 Select the tape speed

Press the SPEED button to select the desired tape speed (SP/ SLP).

3 Begin OTR

Press the REC/OTR button on the TV/DVD/VHS as many times as needed. The recording length will be determined by the number of times you press the REC/OTR button. Each additional push will increase the recording time by 30 minutes. It is set up to 8 hours.

OTR(2 : 30)

Push(es) Display Recording length

1 push (normal recording) 2 pushes 0:30 30 minutes 3 pushes 1:00 60 minutes

17 pushes 8:00 480 minutes

COPYING A VIDEO CASSETTE

(Requires a VCR or camcorder)

You can make copies of video tapes made by friends or relatives for your enjoyment.

WARNING: Unauthorized recordings of copyrighted video tapes may be an infringement of copyright laws.

Connect your TV/DVD/VHS and a Source (Playing) VCR using the following diagram.

[The TV/DVD/VHS]

STOP/EJECT

F.FWD

PLAY

Audio/Video adapter cable (not supplied)

HEADPHONE

VIDEO

RL AUDIO

[Ex: Source (playing) VCR or camcorder]

1)Insert a pre-recorded video cassette into the Source (Playing) VCR or camcorder.

2)Insert a blank video cassette, or one you want to record over, into the TV/DVD/VHS’s cassette com- partment.

3)Press the SPEED button on remote control for the TV/DVD/VHS to select the desired recording speed (SP/SLP).

4)Press the CHANNEL K or L button on the TV/DVD/VHS until “AUX” appears on the screen.

5)Press the RECORD button on the TV/DVD/VHS.

6)Begin playback of the tape in the source (Playing) VCR or camcorder.

NOTE: For best results during copying, use the TV/DVD/VHS’s front panel controls whenever possible. The remote control might affect the source (Playing) VCR’s playback operation.

- 31 - EN

[Fig.8]

AUDIO

OUT

VIDEO

OUT

1F12

TIMER

9:00AM 10:00AM 12:00PM

Program 1 10:00AM-11:00AM Program 2 9:00AM-10:00AM Program 3 9:30AM-12:00PM

11:00AM

Recording Sequence

*Recording period is SHADED

AUTOMATIC TIMER

RECORDING

You may set the TV/DVD/VHS to start and end a recording while you are away. You can set 8 programs to record on specific days, daily or weekly within a 1 year period.

In the example below, the timer is being set to record:

DATE: July 6th, 2001 SETTING TIME: from 7:30PM to 8:50PM CHANNEL: CH61 TAPE SPEED: SP

Make sure ...

If a cable box or satellite box is connected with the

•

TV/DVD/VHS you will be limited to record only one channel. And the channel selector on the TV/DVD/VHS must be selected to the output channel of the boxes CH 3 or CH 4 and then the actual channel to be recorded must be selected on the boxes.

Clock must be set to the correct time and date

•

before setting the timer. TV/DVD/VHS power must be turn on to program

•

it. Insert a cassette tape with its erase prevention tab

•

in place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.)

The channel you want to record is properly set in

•

advance. (See page 16.)

Avoid over lap of programs ...

There is a chance that a program will not be recorded. when programs overlap;

The program with an earlier start has priority.

•

Once the earliest program finishes, the overlapping

•

programs will begin recording in sequence. The illustration below demonstrates the sequence

•

of recordings. Program 1 10:00AM - 11:00AM

Program 2 9:00AM - 10:00AM Program 3 9:30AM - 12:00PM

pressing the Arrow K button. And press the Arrow B button.

If you have not yet set the clock,

•

“MANUAL CLOCK SET”

appears. If so, follow stops [3] to [8] on page 18. Then set the timer

- TV/VCR SETUP -

B TIMER PROGRAMMING

SETTING CLOCK CHANNEL SET UP USER’S SET UP V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

recording.

2 Select your desired program

position (1~8)

Press the Arrow K or L button to select the desired program position.

Then, press the Arrow B button.

3 Set the channel number

Press the Arrow K or L button until the desired channel number appears.

(Example: CH61)

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

Then, press the Arrow B button. Remember: If the TV/DVD/VHS is connected to a

cable box or satellite box, the TV/DVD/VHS must be on CH3 or CH4, then the channel to be recorded is selected on the cable box or satellite box.

4 Select once, every day or

weekly recording

For once recording :

Press the Arrow K (up) button

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 7/06 FRI -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

until the desired date appears. (Example: “7/06” for July 6th). Then, press the Arrow B button.

For every day recording : To record a TV program at the same time on the same channel every day. (Example: Monday through Sunday)

Press the Arrow L (down) button until “EVRY DAY” appears.

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 EVRY DAY -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

Then, press the Arrow B button.

1 Select “TIMER PROGRAMMING”

Press the SETUP button on the remote control. Confirm “TIMER PROGRAMMING” is pointed by

For weekly recording : To record a TV program at the same time on the same channel every week. (Example: every Monday)

Press the Arrow L (down) button until “EVRY” and your desired

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 EVRY MON -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

day of the week appear together. Then, press the Arrow B button.

- 32 - EN

1F12

– TIMER PROGRAMMING –

5 Set beginning hour

Press the Arrow K or L button until the desired hour appears. (Example: “ 7, PM” for 7:30PM)

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 7/06 FRI 7:12

- - -/- - - - - -:- - -:- - - -

M -:- - - -

Then, press the Arrow B button.

6 Set beginning minute

Press the Arrow K or L button until the desired minute appears. (Example: “30” for 7:30PM)

Then, press the Arrow B button.

7 Set end hour

Press the Arrow K or L button until the desired hour appears. (Example: “8, PM” for 8:50PM)

Then, press the Arrow B button.

8 Set end minute

Press the Arrow K or L button until the desired minute appears. (Example: “50” for 8:50PM)

Then, press the Arrow B button.

9 Set the tape speed

Press the Arrow K or L button until the desired tape speed appears. (Example: SP)

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 7/06 FRI 7:30

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 7/06 FRI 7:30

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 7/06 FRI 7:30

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 7/06 FRI 7:30

- - -/- - - - - -:- - -:- - - -

8:50

8:30

-:- - - -

10 Finish setting the program

Press the Arrow B or s button. The program is now completed.

To set another program, repeat steps [2] to [10].

•

Press the SETUP button on the remote control to

•

return to original mode.

11 Set the timer

Press the POWER button to set automatic timer recording. The TIMER REC indicator lights up.

You must turn off the TV/DVD/VHS to activate

•

automatic timer recording. If power is not turned off and you continue watch-

ing TV, “TIMER REC STANDBY” starts flashing on the TV screen 2 minutes before the programmed start time.

TIMER PROGRAM EXTENSION

To shift the time schedule of an automatic timer recording.

1)Press the POWER button.

2)Repeat step [1] on page 32.

3)Press the RECORD button and select the desired

program using the Arrow K or L button.

4)Press the RECORD button again. Each additional push will shift forward the

begin/end time for recording by 10 minutes. When the recording is already in progress, each additional push will shift forward the end time only. If you want to cancel while setting, press the PAUSE button on the remote control. The recording time

- -

returns to the original time.

NOTE: When you shift forward the time schedule during recording, the recording speed will automatically be set to the SLP mode.

5)Press the Arrow B or s button to exit the setting

menu. Then press the SETUP button on the remote control to return to original mode.

TO CORRECT APROGRAM

While setting a program; press the Arrow s but-

•

ton to go back one step and enter the correct numbers using the Arrow K or L button.

After setting a program;

•

1)Press the POWER button.

2)Repeat steps [1] - [2] on page 32.

3)Press the Arrow B button (or press the Arrow s

button to go back one step) until the part you want to correct begins flashing, then make the changes pressing the Arrow K or L button.

4)Press the POWER button to set automatic timer

recording.

TO CANCELAN AUTOMATIC TIMER RECORDING

After setting a program;

•

1)Press the POWER button.

2)Repeat steps [1] ~ [2] on page 32 and select a

program you want to cancel.

3)Press the C.RESET button.

4)Press the SETUP button on the remote control to

return to TV mode.

While recording is in progress;

•

1)Press POWER button.

2)Press the STOP/EJECT button on the

TV/DVD/VHS.

- 33 - EN

1F12

TO CHECK THE BEGIN/END TIME

1)Press the POWER button so that the REC indicator goes off.

2)Press the SETUP button on the remote control.

3)Confirm “TIMER PROGRAMMING” is pointed.

4)Press the Arrow B button. The details of programs appear on the TV screen.

5)Press the SETUP button on the remote control to return to TV mode.

HINTS FOR AUTOMATIC

TIMER RECORDING

Make sure the channel you want to record is prop-

•

erly set in advance. It is not necessary to press the RECORD button for

•

timer recording. Recording begins automatically at the Start time.

•

If you are recording using a Timer mode, you may

•

not operate the unit manually. The erase-prevention tab on the cassette must be in

•

place (or you must put tape over the hole). If the erase-prevention tab is removed, the cassette

•

will be ejected when the POWER button is pressed to off.

If the tape runs out before the end time, the

•

TV/DVD/VHS will switch to the Stop mode immediately, and the tape will be ejected.

3 Auto Return will begin

When all the timer recordings are completed, the TV/DVD/VHS will rewind to the beginning of the recorded program(s).

NOTE:

If you press the POWER button while tape is

•

rewinding, the Auto Return will stop.

4 Watch the recorded program

Press the PLAY button.

TO CANCEL THE AUTO RETURN MODE

Repeat steps [1] and [2], select [OFF] using the Arrow B or s button.

If there is a power failure of any kind, the unit will retain its memory for this feature.

SLEEP TIMER

The Sleep Timer function turns off the TV/DVD/VHS without using the POWER button after a desired period of time.

NOTE:

This function does not operate during Recording

•

mode.

AUTO RETURN

With this feature, after timer recording is finished, the beginning of the recorded program(s) can be searched for automatically.

1 Select “USER’S SET UP”

Press the SETUP button on the remote control.

Press the Arrow K or L button to point to “USER’S SET UP”.

Then, press the Arrow B button.

2 Set “AUTO RETURN” to [ON]

Press the Arrow K or L button to point to “AUTO RETURN”.

Press the Arrow B or s button until [ON] appears.

- TV/VCR SETUP -

TIMER PROGRAMMING SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF] ZERO RETURN TIME SEARCH INDEX SEARCH

USER’S SET UP

–

RENTAL [OFF] REPEAT PLAY [OFF]

B AUTO RETURN [ON]

VCR AUDIO [HIFI] TV AUDIO [STEREO]

1 Select “SLEEP TIMER”

Press the SLEEP button on the remote control until “SLEEP TIMER” appears.

2 Set sleep time

Press the SLEEP button until your desired sleep time appears.

Each additional push will increase the time by 30 minutes up to 120 minutes.

SLEEP 120 MINUTES

After 5 seconds, exit the Sleep Timer setting.

TO CANCEL THE SLEEP TIMER

–

Press the SLEEP button on the remote control until “SLEEP TIMER” appears. Press the SLEEP button until “SLEEP 0 MINUTES” appears.

- 34 - EN

1F12

ON SCREEN DISPLAY

TV Display

CATV channel

TV Display

W+80 W+81 W+82 W+83 W+84

W+65 W+66 W+67 W+68 W+69 W+70 W+71 W+72 W+73 W+74 W+75 W+76 W+77 W+78 W+79

W+55 W+56 W+57 W+58 A-4 A-3 A-2 A-1 W+59 W+60 W+61 W+62 W+63 W+64

W+40 W+41 W+42 W+43 W+44 W+45 W+46 W+47 W+48 W+49 W+50 W+51 W+52 W+53 W+54

W+25 W+26 W+27 W+28 W+29 W+30 W+31 W+32 W+33 W+34 W+35 W+36 W+37 W+38 W+39

W+10 W+11 W+12 W+13 W+14 W+15 W+16 W+17 W+18 W+19 W+20 W+21 W+22 W+23 W+24

A-5

R S T U V W W+1 W+2 W+3 W+4 W+5 W+6 W+7 W+8 W+9

CDEFGHI JKLMNOPQ

5A 2 3 4 5 6 7 8 9 10 11 12 13 A B

123456789101112131415

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30

31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

46 47 48 49 50 51 52 53 54 55 56 57 58 59 60

61 62 63 64 65 66 67 68 69 70 71 72 73 74 75

76 77 78 79 80 81 82 83 84 85 86 87 88 89 90

91 92 93 94 95 96 97 98 99 100 101 102 103 104 105

106 107 108 109 110 111 112 113 114 115 116 117 118 119 120

121 122 123 124 125

CATV channel

To check the Counter, Clock and Channel number on the TV screen, press the DISPLAY button on the remote control. Each time you press the DISPLAY button on the remote control, the TV screen will change as follows:

When the Closed Caption mode is OFF:

Counter mode: After 5 seconds, only the counter

•

remains. To clear it, press the DISPLAY button. Clock mode: After 5 seconds, only the clock and

•

When the Closed Caption mode is ON:

The On Screen Display disappear after 5 seconds.

•

This is true even if the MUTE button is pressed, or

•

the PAUSE button is pressed while recording. the channel number remain. To clear them, press the DISPLAY button.

OFF mode Counter mode Clock mode

STOP STOP

SP SPCOUNT 0:12:34

After 5 seconds After 5 seconds

COUNT 0:12:34

Counter remains

Clock & Channel remains

5:40PM

CH2

OFF mode Clock/Counter mode

STOP 5:40 PM

SP COUNT 0:12:34

CH2

CABLE CHANNEL DESIGNATIONS

If you subscribe to cable TV, the channels are displayed as 1-125. Cable companies often designate channels with letters or letter-number combinations. Please check with your local cable company. The following is a chart of common cable channel designations.

- 35 - EN

1F12

DVD

Video

12 cm

Approx. 4 h

(single-sided)

Approx. 8 h

(double-sided)

Approx. 80 min

(single-sided)

Approx. 160 min

(double-sided)

20 min

8 cm

(singles)

Logo

Maximum

Playback Time

ContentsDisc Type

Sound

and

Pictures

Audio

Disc Size

Sound

74 min

Example

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1 Chapter 2Chapter 3 Chapter 4

Example

Track 1 Track 2 Track 3 Track 4 Track 5 Track 6

DVD SECTION

ABOUT THE DISCS

PLAYABLE DISCS

The following discs can be played back on this DVD player.

This player conforms to the NTSC color system. You cannot play discs recorded in other color systems such as PAL or SECAM.

¡Some discs include region codes as shown below.

Photo CD (Never play back, otherwise malfunction may result.)

Video CD (Never play back, otherwise malfunction may result.)

Any other discs without compatibility indications

DISC TYPES

[

]

DVD

Data on a DVD is divided into sections called "titles", and then into subsections called "chapters", each of which is given a title or chapter number. Playback conditions are preset on some DVD video discs, and these playback conditions take priority over user operations on this player. If a function you selected do not run as desired, refer to the manual accompanying the disc.

¡The number inside the symbol refers to a region of the

world, and a disc encoded in a specific region format can only be played back on DVD players with the same region code.

The following discs cannot be played back on this DVD player.

DVD with region codes other than 1 or ALL.

DVD-ROM

DVD-RAM (Never play back, otherwise malfunction may result.)

CD-ROM

VSD

CDV (Only plays back the audio part.)

CD-G (Only plays back the sound.)

CD-R

(Never play back, otherwise malfunction may result.)

CD-I

(Never play back, otherwise malfunction may result.)

[

AUDIO CD

]

Data on an audio CD is divided into sections called

“tracks”, each of which is given a track number.

–36–

1F12

PLAYING A DISC

PLAYING A DVD VIDEO

OR AN AUDIO CD

CDDVD

Getting started

Turn on the power of the TV, amplifier and any other components which are connected to the DVD player. (Change the input system to suit the DVD player, and check that the sound volume is correct.)

1 Press the POWER button.

The power will turn on.

2 Press the OPEN/CLOSE button.

The disc loading tray will open.

3 Place a disc into the tray.

Make sure the disc is sitting properly in the correct

recess, with the label side up.

¡With DVDs that use some titles for playback

program signals, playback may start from the second title, or it may skip these titles.

USING THE DVD MENUS

DVD

Some DVDs contain their own menus, such as a guidance menu which describes the contents of the disc or a selection menu for sound, language and other customized settings.

1 Press the DISC MENU button.

The DVD menu will appear.

2 Select the desired title.

Press the arrow buttons (L/K/B/s) to change the

setting, and then press the ENTER button.

3 Playback will start from the selected title.

4 Press the PLAY button.

¡The tray will close automatically, and playback will

then start from the first chapter or track of the disc. You need to press the PLAY button only when the tray has been closed by pressing the OPEN/CLOSE button.

¡When you play back the DVD which a title menu is

recorded, the menu may appear on the screen. In this case, refer to “USING THE TITLE MENU”.

5 Press the STOP button to stop play.

Notes

¡A“prohibited icon” may appear at

the top-right on the TV screen during operation, warning that a prohibited operation has been encountered by the DVD player or the disc.

¡If a disc is dirty or has scratches, the pictures may

appear distorted and the playback operation may stop. In such cases, clean the disc and unplug the power cord and then plug it again before resuming playback.

USING THE TITLE MENU

With a DVD containing a title menu, you can select desired titles from the menu.

1 Press the TITLE button.

¡The title menu will appear.

2 Select the desired title.

Press the arrow buttons (L/K/B/s) to change the

setting, and then press the ENTER button.

CALLING UP A MENU SCREEN DURING PLAYBACK

For DVDs

¡Press the DISC MENU button to call up the DVD

menu.

¡Press the TITLE button to call up the title menu.

Note

¡Contents of menus and corresponding menu

operations may vary between discs. Refer to the manual accompanying the disc for details.

–37–

DVD

1F12

Pause F

Play B

Pause F

Play B

RESUMING PLAYBACK FROM

Press 'PLAY' to play from here To play beginning, press 'STOP' first and the 'PLAY'.

Play B

Ex2

Ex8

Ex32 Ex32

Dx8

Dx2

REV Button Button

FWD

THE POINT WHERE

PLAYBACK STOPPED

CDDVD

2 Press the PLAY button to return to normal

playback speed.

1 Press the STOP button during playback.

Playback will stop, and then

appear the resuming message at the center.

2 Press the PLAY button. Playback will start

from the point where the previous playback session was stopped.

Notes

¡Resuming playback is not available with some discs. ¡It is possible to switch from the DVD play mode to

the TV mode. Even if the power is turned off, the resume function enables to playback on from the previously interrupted point. But note that the Marker commands are not saved.

¡The resume function can be reset by pressing the

STOP button twice or by opening the disc loading tray.

PAUSING PLAYBACK OR

DISPLAYING A STILL PICTURE

CDDVD

1 Press the PAUSE button during playback.

Playback will pause, with sound

muted.

2 Press the PLAY button to resume playback.

STEPPING THROUGH FRAMES

DVD

FAST FORWARD/REVERSE

1 Press and hold the g or h button for

more than 1 second during playback.

For DVDs, pressing and more than 1 second holding the g or h button cycles the playback speed in three steps.

¡For audio CDs, the playback speed is ×16 fixed.

1 Press the PAUSE/STILL button while play-

back is paused.

The next picture frame is displayed with sound muted each

CDDVD

time the button is pressed.

2 Press the PLAY button to resume playback.

–38–

1F12

Search Title : 1 / 4 Chapter:__ / 17

SLOW MOTION

×1/16

×1/8

×1/2

Button

Time _:__:__

Total Time 1:29:00

Time _:__:__

Total Time 1:29:00

DVD

1 Press and hold the g button for more than

1 second while playback is paused. (Sound remains muted.)

Slow motion mode will be activated.

¡Pressing and holding the g button for more than

1 second cycles the playback speed in three steps. Select an appropriate speed while referring to the speed indication on the screen.

2 Press the PLAY button to return to normal

playback speed.

Notes

¡Slow playback is not available with audio CDs. ¡The reverse of slow playback is not available. ¡If you press the g button and release immediate-

ly during playback is paused or slow, it returns to normal playback.

STARTING FROM A DESIRED

TIME COUNT

CDDVD

1 Press the SEARCH MODE button.

Press the button twice.

2 Press the numeric buttons to set the desired

time count.

¡Example: 1 hour, 23 minutes and

30 seconds

1 → 2 → 3 → 3 → 0

Notes

¡In the case of DVD, Time Search in Title is effec-

tive. (But Time Search in Chapter is ineffective.)

¡In the case of CD, Time Search in Track is effective.

(But Time Search in the entire disc is ineffective.)

¡Playback from a desired time count is not available

with some discs.

¡Specific time playback is not available with some

discs or if the unit is in stop mode.

PLAYING FROM A DESIRED

TITLE OR CHAPTER

You can also press the SEARCH MODE button, use the numeric buttons to enter the chapter number.

Perform the title search and the chapter search after setting them on the same screen at the same time. Changeover by

Note

¡Playback from a desired title or

chapter is not available with some DVDs.

K/L

buttons.

DVD

STARTING FROM A DESIRED

TRACK

1 Press the SEARCH MODE button.

se the numeric buttons to enter

the track number. When the track number is entered in the entry box, playback of the desired track will start automatically.

TRICKS WITH THE SKIP BUTTONS (H, G)

If the SKIP button G is pressed during playback or while playback is paused, the current track is skipped and the next track is played. When the SKIP button H is pressed once, the top of the current track is located for replaying. When the SKIP button H is pressed again while Within 2-second playback, the previous track is located.

–39–

Track: __ / 26

1F12

REPEAT

Repeat

[Title]

Repeat

[Chapter]

Repeat [Off]

The current Title is played back repeatedly.

The current Chapter is played back repeatedly.

No repeat playback.

Repeat

[Off]

Repeat

[Track]

The current Track is played back repeatedly.

The whole Disc is played back repeatedly.

No repeat playback.

Repeat

[All]

Repeat [ A - ]

Repeat [ A - B ]

Repeat [ off ]

A-B REPEAT

CDDVD

1 Press the REPEAT button.

For DVDs

¡A single title or chapter is played back repeatedly. ¡Pressing the REPEAT button cycles the display on

the screen as follows.

For audio CDs

¡The whole disc or a single track is played back

repeatedly.

¡Pressing the REPEAT button cycles the display on

the screen through All, Repeat Track and Off.

CDDVD

You can define a section to be played back repeatedly.

Press the A-B REPEAT button during playback.

¡The starting point (A) will then be

selected.

2 Press the A-B REPEAT button again at the

end point (B) of the desired section.

The selected section will be played back repeatedly.

3 To exit A-B repeat playback, press the A-B

REPEAT button and set it to OFF.

If the REPEAT button is pressed once during program/random playback, the program/random playback is performed repeatedly.

If the REPEAT button is pressed again, the current track is played back repeatedly.

Notes

¡Repeat playback is not available with some discs. ¡The REPEAT setting will be cleared when moving

to other title, chapter or track.

Notes

¡With DVDs, the A-B repeat section can be set only

within the current title.

¡With audio CDs, the A-B repeat section can be set

within the current track.

¡A-B repeat is not available with some scenes in

DVD.

¡T o cancel the Apoint which was set, press RETURN

button.

–40–

1F12

Zoom [on]

PROGRAM (Audio CD)

Audio CD Program

Total [Track] – –

[Time] 0:00:00

Random : MODE

Track 00 / 15

Exit

: RETURN

Start : PLAY

Delete

: CLEAR

02 05 07 14 01 09 13 10 03 11 08 04

Audio CD Program

Total [Track] 12

[Time] 0:47:29

Random : MODE

Track 04 / 15

Exit

: RETURN

Start : PLAY

Delete

: CLEAR

Audio CD Random

Exit : MODEStart : PLAY

RANDOM (Audio CD)

Press the MODE button in stop mode.

¡The program screen will appear.

2 Press the numeric buttons to enter the

desired track numbers.

The total playback time for the selected tracks will appear on the TOTAL line.

3 Press the PLAY button.

Playback will start in the programmed order.

¡While the program is being played back, the STOP

button works as follows.

¡Press the STOP button once and then the PLAY

button again, playback will restart from the point where the STOP button was pressed. (Program continued)

¡Press the STOP button twice and then the PLAY

button again, playback will restart from the first tune in the program in the usual way. (Program continued)

¡Press the STOP button three times and then the

PLAY button again, playback will restart from the track in the usual way. (Program cleared)

1 Press the MODE button in stop mode.

The program setting menu screen will appear.

2 Press the MODE button again.

3 Press the PLAY button. Random playback

will then start.

Note

¡Program playback is not available during random

playback.

ZOOM PLAYBACK

(enlargement onscreen)

DVD

Images can be enlarged four times on the screen to your taste.

Press the ZOOM button during playback.

An image will be enlarged at the center of the

screen.

¡Press the ZOOM button again, and the image will be

back to the previous size.

Notes

¡Adding programs is not possible during program

playback. You must stop the current playback before such operations can be carried out.

¡Press the CLEAR button to cancel a program. The

most recently entered program will then be deleted.

¡Numbers which exceed the number of tracks on the

disc in the tray are not accepted.

¡Playback from a desired track and random playback

are not available during program playback.

¡Program settings are cleared when the power is

turned off or the disc loading tray is opened.

¡If the track no. is once set in the program, the setting

cannot be changed.

When the cursor (K/L/s / B) button is pressed during zoom play, the part to be zoomed moves.

The zooming frame can be moved from the center

.... 4 steps to the right. 4 steps to the left. 4 steps to

the top. 4 steps to the bottom.

–41–

1F12

Audio 1 , English / 8

Audio 2 , French

Audio 8 , Japanese

HELLO

Bonjour

Note

¡Zooming function does not work while operation

display screen is shown.

SETTINGS

CHANGING THE AUDIO

LANGUAGE OR SOUND MODE

DVD

The DVD player has a function which allows you to select the desired audio language and sound mode.

For DVDs

Press the AUDIO button during playback, and then press the AUDIO button to select the desired audio language.

The audio language can be changed if multiple languages are recorded on the DVD being played.

Notes

¡Pressing the Audio button may not work on some

DVDs with multiple audio languages (e.g. DVDs which allow audio language setting on the disc menu). Operation varies between discs, so refer to the manual accompanying the disc.

¡If a desired language is not shown after pressing the

Audio button several times, the disc does not have an audio source in that language.

¡The audio language resets to the one which has been

selected in the setup mode, every time the power is turned on or discs are replaced. If that language is not available on a disc, a language defined by the disc is selected.

¡The screen display will disappear after about 5

seconds.

–42–

1F12

CHANGING THE SUBTITLE

Subtitle 1

No subtitles

Subtitle 2

Subtitle 1 , English / 8

Subtitle 2 , French

Subtitle Off

Angle 1

Angle 2

Angle 8

Angle 1 / 8

Angle 2 / 8

Angle 8 / 8

HELLO

Bonjour

LANGUAGE

CHANGING THE CAMERA

ANGLE (Multi-Angle Pictures)

DVD

The DVD player has a function which allows you to select the desired language for subtitles.

Press the SUBTITLE button during playback, and then press the SUBTITLE button to select the desired subtitle language.

The subtitle language can be changed if the subtitles

are recorded in multiple languages on the DVD being played.

¡The subtitle language cannot be changed if the

subtitles are recorded in a single language on the DVD being played.

DVD

The DVD player has a function which allows you to select the desired camera angle.

Press the ANGLE button during playback.

¡If the disc contains sequences recorded from differ-

ent camera angles, the angle icon ( ) will appear at the top-right of the screen. You can change the camera angle when the icon appears on the screen.

¡The camera angle cannot be changed if the disc does

not contain sequences recorded from different camera angles.

Press the ANGLE button while the angle number is shown on the screen.

¡Pressing the SUBTITLE button cycles the subtitle

language from SUBTITLE 1, SUBTITLE 2 and all the languages recorded through to off.

Notes

¡Some discs allow subtitle language setting on the

disc menu. (Operation varies between discs, so refer to the manual accompanying the disc.)

¡If the desired language is not shown after pressing

the SUBTITLE button several times, the disc does not have subtitles in that language.

¡The subtitle language resets to the one which has

been selected in the setup mode, every time the power is turned on or discs are replaced. If that language is not available on a disc, a language defined by the disc is selected.

¡It may take time to display the subtitles in the

selected language.

¡The screen display will disappear after about 5

seconds.

¡When “Subtitle Not Available” appears onscreen, it

means no subtitle is recorded on the scene.

Note

¡The screen display will disappear after about 5

seconds.

–43–

1F12

CHANGING THE ON-SCREEN

DVD Play Repeat [Chapter]

Title

Chapter

Time

0:17:52

-1:38:46

Bit Rate

Chapter 18 / 30 Title 1 / 5 Time 1:56:38 Audio 1.English / 4

•

Picture in play back

Playback Setup Window

Info. Window

Elapsed time of the current title and

Remaining time of the current title.

Current chapter number

Current title number

Current repeat status

Current playback status

Kind of disc in playbacking

Audio CD Play

Repeat [Track]

Track

2 Play Mode Normal

Time

[Track]

0:01:46

-0:03:27

Track 2 / 12 Time 0:05:13 Maker ... Time Display Track

01 02 03 04 05 06 07 08 09 10 11 12

Playback Setup Window

[Track]

Elapsed time of the current track and

Remaining time of the current track.

[All]

Elapsed time of the current disc and

Remaining time of the current disc.

Current track number

Nomal playback

Programedplayback

Random playback

Current repeat status

Current playback status

Kind of disc in playbacking

Info. Window

DISPLAY

CDDVD

You can check the information about the disc by pressing the DISPLAY button on the remote control.

For audio CDs and DVDs

For DVDs

Press the DISPLAY button, the display appears on the screen.

For the selecting the item of the Playback Setup Window, press the K

/Lbutton to select the item,

then press the ENTER button.

For audio CDs

Playback Setup Window (CD)

ITEM DISPLAY CONTENTS Track Time Total time of the current track

Marker

Time Display

Current track number / the number of total tracks

Place the cursor and press the ENTER button to activate the Marker function.

[Set the marker]

K/L

Using to the marker number shown as “Not

button, position the cursor on

Set”. Press the ENTER button when the screen to be reviewed appears. Up to 5 points can be marked.

[Call back the marker]

K/L

Using

button, position the cursor on to the marker number to be called back and press the ENTER button.

[Clear the marker] Using

to the marker number to be cleared and press the CLEAR button.

To clear all markers, place the cursor on “All Clear Markers” and press the ENTER button.

The time informations displays on the left side of the screen (Track/All)

K/L

button, position the cursor on

Playback Setup Window (DVD)

ITEM DISPLAY CONTENTS

Chapter

Title

Current chapter number / the number of total chapters

Current title number / the number of total titles

Time Total time of the current title Audio

Audio No., audio language / the number of available audio languages in the disc

Subtitle No., subtitle language / the number of available subtitle languages in

Subtitle

the disc Off : Subtitle is not displays. Not Available : Subtitle is not included.

Angle No. / total number of the angles

Angle

1/1 : Multi angle is not included in the disc.

Place the cursor and press the ENTER button to activate the Marker function.

[Set the marker] Using K/Lbutton, position the cursor on

to the marker number shown as “Not Set”. Press the ENTER button when the screen to be reviewed appears. Up to 5 points can be marked.

[Call back the marker]

Marker

Using

K/L

button, position the cursor on to the marker number to be called back and press the ENTER button.

[Clear the marker]

K/L

Using

button, position the cursor on to the marker number to be cleared and press the CLEAR button.

To clear all markers, place the cursor on “All Clear Markers” and press the ENTER button.

SRS TruSurround

The current setting (On/Off) is displayed.

To exit the display (DVD and CD):

Press the RETURN button.

In the playback Setup Window, press the RETURN button to change the present indication to the former one.

–44–

1F12

CHANGING THE SETUP ITEMS

Language

Display

Audio

Parental

Select : / Set : ENTER Cancel : Exit : SETUP

Language Controls

Audio English

Subtitle English Disc Menu English Player Menu English

Select : / Set : ENTER Cancel : Exit : SETUP

Language

Display

Audio

Parental

Audio

Irish Portuguese Dutch

Other _.......

Language Controls

Audio English

Subtitle English Disc Menu English Player Menu English

Language

Display

Audio

Parental

Select : / Set : ENTER Cancel : Exit : SETUP

Language Controls

Audio English

Subtitle English Disc Menu English Player Menu English

Audio

Original

English French Spanish

Language

Display

Audio

Parental

Select : / Set : ENTER Cancel : Exit : SETUP

Language Controls

Audio English

Subtitle English

Disc Menu English Player Menu English

Subtitle

Off

English

Spanish French

Select : / Set : ENTER Cancel : Exit : SETUP

Language

Display

Audio

Parental

Language Controls

Audio English Subtitle English

Disc Menu English

Player Menu English

Disc Menus

Original

English French Spanish

Select : / Set : ENTER Cancel : Exit : SETUP

Language

Display

Audio

Parental

Language Controls

Audio English Subtitle English Disc Menu English

Player Menu English

Player Menu

English

Français Español

Select : / Set : ENTER Cancel : Exit : SETUP

Language

Display

Audio

Parental

Note

¡When you change the setup items, press the STOP

button if you are in playback mode.

LANGUAGE SETTINGS

Press the SETUP button.

¡The setup screen appears.

2 Press the K/L buttons to select Language,

and then press the ENTER button.

3 Press the K/L buttons to select an item, and

then press the ENTER button.

Press the

K/L

buttons to select a desired

item, and then press the ENTER button.

¡If Other is selected on the Audio, Subtitle or Disc

Menu setting screen, the Language Code setting screen will appear. Press the numeric buttons to enter the desired language code while referring to the list on page 49.

5 Press the SETUP button.

The setup mode will be canceled and the ordinary

screen will appear.

Note

¡Language Setting for Audio and Subtitle is not avail-

able with some discs. Then use the Audio and Subtitle button. Details are on pages 42 and 43.

(Voice is played back in selected language.)

(Subtitles are shown in selected language.)

(The disc menu appears in selected language.)

(The on-screen display appears in selected language.)

–45–

1F12

DISPLAY SETTINGS

Language

Display

Audio

Parental

Select : / Set : ENTER Cancel : Exit : SETUP

Display Controls

TV Aspect 4:3 Pan & Scan

On Screen Info

On Panel Display Bright Angle Icon On

Language

Display

Audio

Parental

Select : / Set : ENTER Cancel : Exit : SETUP

Display Controls

TV Aspect 4:3 Pan & Scan

On Screen Info

On Angle Icon On Background Color

Gray

TV Aspect

4:3 Pan & Scan

4:3 Letterbox

Language

Display

Audio

Parental

Select : / Set : ENTER Cancel : Exit : SETUP

Display Controls

TV Aspect 4:3 Pan & Scan

On Screen Info

Angle Icon On Background Color

Gray

Language

Display

Audio

Parental

Select : / Set : ENTER Cancel : Exit : SETUP

Display Controls

TV Aspect 4:3 Pan & Scan On Screen Info

Angle Icon On

Background Color

Gray

Language

Display

Audio

Parental

Select : / Set : ENTER Cancel : Exit : SETUP

Display Controls

On Screen Info On Angle Icon On

Background Color

Gray

Auto Power Off On

Language

Display

Audio

Parental

Select : / Set : ENTER Cancel : Exit : SETUP

Display Controls

On Screen Info On Angle Icon On Background Color Blue

Auto Power Off On

Language

Display

Audio

Parental

Select : / Set : ENTER Cancel : Exit : SETUP

Press the SETUP button.

¡The setup screen will appear.

2 Press the K/L buttons to select Display and

then press the ENTER button.

3 Press the K/L buttons to select an item, and

then press the ENTER button.

TV Aspect

(Default : 4:3 Pan & Scan) 4:3 Pan & Scan : Full height picture, trimmed both sides 4:3 Letter Box : Wide screen with black bars on top and bottom

Press the

K/L

buttons to select a desired

item, and then press the ENTER button.

5 Press the SETUP button.

The setup mode will be canceled and the ordinary

screen will appear.

Notes

• Some discs do not contain pan and scan images.

• Some discs do not contain letter box images.

On Screen Info (Default : On) Display or not display the disc status (Example “PLAYB”).

Angle Icon (Default : On) Display or not display the Angle icon on the screen.

Background Color (Default : Gray) Select gray or blue.

Auto Power Off (Default : On) Set or not set to turn off after the screen saver is started and no keys are pressed for 30 minutes.

–46–

1F12

AUDIO SETTINGS

Language

Display

Audio

Parental

Select : / Set : ENTER Cancel : Exit : SETUP

Audio Controls

Digital Audio Out ...

Dynamic Range On Downmix Mode Dolby Surround Down Sampling 48kHz

Language

Display

Audio

Parental

Select : / Set : ENTER Cancel : Exit : SETUP

Audio Controls

Digital Audio Out ...

Dynamic Range On Downmix Mode Dolby Surround Down Sampling 48kHz

Digital Audio Out

Dolby Digital Off

DTS On MPEG Off

Select : / Set : ENTER Cancel : Exit : SETUP

Language

Display

Audio

Parental

Audio Controls

Digital Audio Out ...

Dynamic Range On

Downmix Mode Dolby Surround Down Sampling 48kHz

Select : / Set : ENTER Cancel : Exit : SETUP

Language

Display

Audio

Parental

Audio Controls

Digital Audio Out ... Dynamic Range On

Downmix Mode Dolby Surround

Down Sampling 48kHz

Select : / Set : ENTER Cancel : Exit : SETUP

Language

Display

Audio

Parental

Audio Controls

Digital Audio Out ...

Dynamic Range On Downmix Mode Dolby Surround Down Sampling 48kHz

Digital Audio Out

Dolby Digital Off

DTS On MPEG Off

Select : / Set : ENTER Cancel : Exit : SETUP

Language

Display

Audio

Parental

Audio Controls

Digital Audio Out ...

Dynamic Range On Downmix Mode Dolby Surround Down Sampling 48kHz

Digital Audio Out

Dolby Digital Off

DTS On

MPEG Off

Select : / Set : ENTER Cancel : Exit : SETUP

Language

Display

Audio

Parental

Audio Controls

Digital Audio Out ...

Dynamic Range On Downmix Mode Dolby Surround Down Sampling 48kHz

Digital Audio Out

Dolby Digital Off DTS On

MPEG Off

Select : / Set : ENTER Cancel : Exit : SETUP

Language

Display

Audio

Parental

Audio Controls

Digital Audio Out ... Dynamic Range On Downmix Mode Dolby Surround

Down Sampling 48kHz

Select : / Set : ENTER Cancel : Exit : SETUP

Language

Display

Audio

Parental

Press the SETUP button.

¡The setup screen will appear.

2 Press the K/L buttons to select Audio and

then press the ENTER button.

3 Press the K/L buttons to select an item, and

then press the ENTER button.

Digital audio out setting (Next step)

Down Sampling

(Default : 48kHz) Set the output for the DVD recorded in PCM 96kHz (96kHz or 48kHz)

Press the

K/L

buttons to select a desired

item, and then press the ENTER button.

¡If PCM, Dolby Digital or DTS MPEG is selected on

the Digital Audio Out setting screen, press the K/L buttons again to select a further item, and then press the ENTER button.

Dolby Digital (Default : Off) On : Output by Dolby Digital. Set to On when the unit is connected to Dolby Digital Decoder.

DTS (Default : Off) On : Output DTS sound Set to On when the unit is connected to DTS Decoder.

Dynamic Range (Default : Off) On : Dynamic range is available

¡This function is for controlling

the range of sound volume. By compressing the range of sound volume, it is possible not only to suppress the output of loud sound at night and but also to raise the volume of low sound.

¡However, this function is effec-

tive only for the sound recorded by Dolby Digital recording. When the sound recorded by Dolby Digital 5.1ch is outputted, the sound is compressed automatically even with this function being set at “Off”.

Downmix Mode

(Default: Dolby surround) Dolby Surround: When the unitis connected to an audio component that conforms to Dolby Surround Pro Logic Stereo: When the unit is connected to a normal audio component

MPEG (Default : Off) On : Output by MPEG Off : Convert the MPEG to PCM Set to On when the unit is connected to MPEG2 Decoder.

Press the SETUP button.

¡The setup mode will be canceled and the ordinary

screen will appear.

–47–

1F12

PARENTAL LOCK

Language

Display

Audio

Parental

Select : / Set : ENTER Cancel : Exit : SETUP

Parental Contorols

Parental Level 7[NC-17]

Change

Language

Display

Audio

Parental

Select : / Set : ENTER Cancel : Exit : SETUP

Language

Display

Audio

Parental

Parental Level

5 4 [PG-13] 3 [PG] 2

Parental Contorols

Parental Level 7[NC-17]

Change

Select : / Set : ENTER Cancel : Exit : SETUP

Language

Display

Audio

Parental

Parental Contorols

Parental Level 7[NC-17]

Change

Password

Enter current password

_ _ _ _

Select : / Set : ENTER Cancel : Exit : SETUP

Password

Enter current password...

_ _ _ _

Language

Display

Audio

Parental

Select : / Set : ENTER Cancel : Exit : SETUP

Press the SETUP button.

¡The setup screen will appear.

2 Press the K/L buttons to select Parental,

and then press the ENTER button.

3 Press the numeric buttons to enter the 4-

digit password, and then press the ENTER button.

When doing this for the first time, enter any 4 digits. That number will be used as the password from the second time onward.

¡By entering the password, you

can then change the control level and password settings.

Press the then press the ENTER button.

When Parental Level is selected

¡Press the K/L buttons to select an item from 8 to 1

and then press the ENTER button.

¡When Change is selected, press the numeric buttons

to enter the four digits password. Then press the ENTER button.

K/L

buttons to select an item, and

CONTROL LEVELS

Level 8

DVD software of any grade (adult/general/children) can be played back.

Levels 7 to 2

Only DVD software intended for general use and children can be played back.

Level 1

Only DVD software intended for children can be played back, with those intended for adult and general use prohibited.

Notes

¡With some DVDs, it may be difficult to find if they

are compatible with parental lock. Be sure to check if the parental lock function operates in the way that you have set.

¡Record the password in case you forget it.

IF YOU FORGET THE PASSWORD

1) Open the tray.

2) Press the 1, 2, 3, 4, then DISPLAY button on the remote control. the default setup screen will appear. Then, press the ENTER button.

3) Disconnect the power once and reconnect, then proceed the step 1 to 4 of the PARENTAL LOCK again.

Note: If you proceed the above steps, ALL the settings of the DVD player will be cleared. To use the DVD player under the previous settings, set each setting item all over again.

Press the RETURN button.

¡The setup screen will appear.

–48–

1F12

1 Afar 4747 2 Abkhazian 4748 3 Afrikaans 4752 4 Amharic 4759 5 Arabic 4764 6 Assamese 4765 7 Aymara 4771 8 Azerbaijani 4772 9 Bashkir 48 47

10 Byelorussian 4851

11 Bulgarian 4853 12 Bihari 4854 13 Bislama 4855 14 Bengali;Bangla 4860 15 Tibetan 4861 16 Breton 48 64 17 Catalan 4947 18 Corsican 4961 19 Czech 4965 20 Welsh 4971 21 Danish 5047 22 German (GER) 5051 23 Bhutani 5072 24 Greek 5158 25 English (ENG) 5160 26 Esperanto 5161 27 Spanish (SPA) 5165 28 Estonian 5166 29 Basque 5167 30 Persian 5247 31 Finnish 5255 32 Fiji 5256 33 Faroese 5261 34 French (FRE) 5264 35 Frisian 5271 36 Irish 5347 37 Scots Gaelic 5350 38 Galician 5358 39 Guarani 5360 40 Gujarati 5367 41 Hausa 5447 42 Hindi 5455 43 Croatian 54 64 44 Hungarian 5467 45 Armenian 5471 46 Interlingua 5547 47 Interlingue 5551 48 Inupiak 5557 49 Indonesian 5560 50 Icelandic 5565 51 Italian (ITA) 5566 52 Hebrew 5569 53 Japanese (JPN) 5 647 54 Yiddish 5655 55 Javanese 5669 56 Georgian 57 47 57 Kazakh 5757 58 Greenlandic 5758 59 Cambodian 5 759 60 Kannada 5760 61 Korean (KOR) 5761 62 Kashmiri 5765 63 Kurdish 5767 64 Kirghiz 5771 65 Latin 5847 66 Lingala 5860 67 Laothian 5861 68 Lithuanian 5866

No. Language Country code

69 Latvian;Lettish 5868 70 Malagasy 5953 71 Maori 5955 72 Macedonian 5957 73 Malayalam 5958 74 Mongolian 5960 75 Moldavian 5961 76 Marathi 5964 77 Malay 5965 78 Maltese 5966 79 Burmese 5971 80 Nauru 6047 81 Nepali 6051 82 Dutch (DUT) 6058 83 Norwegian 6061 84 Occitan 6149 85 (Afan)Oromo 6159 86 Oriya 6164 87 Panjabi 6247 88 Polish 6258 89 Pashto;Pushto 6265 90 Portuguese 6 266 91 Quechua 6367 92 Rhaeto-Romance 6459 93 Kirundi 6460 94 Romanian 6461 95 Russian 6467 96 Kinyarwanda 6469 97 Sanskrit 6547 98 Sindhi 6550

99 Sangho 6553 100 Serbo-Croatian 6 554 101 Singhalese 6555 102 Slovak 655 7 103 Slovenian 6558 104 Samoan 6559 105 Shona 6560 106 Somali 6 561 107 Albanian 6 563 108 Serbian 6564 109 Siswat 6 565 110 Sesotho 656 6

111 Sundanese 6567 112 Swedish 65 68 113 Swahili 65 69 114 Tamil 6647 115 Telugu 665 2 116 Tajik 6653 117 Thai 6 654 118 Tigrinya 6655 119 Turkmen 6 657 120 Tagalog 6658 121 Setswana 6660 122 Tonga 6661 123 Turkish 6664 124 Tsonga 666 5 125 Tatar 6 666 126 Twi 6669 127 Ukrainian 6757 128 Urdu 676 4 129 Uzbek 6772 130 Vietnamese 6855 131 Volapuk 6861 132 Wolof 696 1 133 Xhosa 7054 134 Yoruba 716 1 135 Chinese (CHI) 7254 136 Zulu 7267

No. Language Country code

LANGUAGE CODE LIST

–49–

1F12

TROUBLESHOOTING GUIDE

TV/VCR

Sometimes a performance problem can be easily solved by checking seemingly apparent but often overlooked possibilities. Before arranging for service, check these items. It could save your time and money.

PROBLEM CORRECTIVE ACTION

No power.

Remote Control Doesn’t Work

No picture and sound.

No picture or poor picture on TV/DVD/VHS.

No sound or poor sound.

Bars On Screen

Picture Distorted or Blurred

Picture Rolls Vertically Lines or Streaks in Picture

No Color

Poor Reception on Some Channels Ghosts in Picture

Weak Picture

Sound OK, Picture Poor

Picture OK, Sound Poor

Timer recording is not possible.

Cannot go into Record mode.

Make sure the AC cord is connected to an AC outlet.

•

Make sure the power is turned on.

•

Is TV/DVD plugged in?

•

Power at outlet?

•

Check batteries in Remote Control.

•

Make sure the AC cord is connected to an AC outlet.

•

Check antenna connection.

•

Let the TV/DVD/VHS program its tuner memory.

•

Adjust direction or replace antenna.

•

Adjust picture controls.

•

Adjust volume control on remote control or main unit.

•

Press the MUTE button to restore sound.

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Try a new channel, if OK, then possible station trouble.

•

If outside antenna is being used, check for broken wire.

•

Try a new channel, if OK, then possible station trouble.

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Adjust COLOR control.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Adjust CONTRAST & BRIGHT control.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Adjust CONTRAST & BRIGHT control.

•

Try a new channel, if OK, then possible station trouble.

•

Check for local interference.

•

Make sure the timer recording is set correctly.

•

Make sure the power is off.

•

Make sure the TV/DVD/VHS clock is set correctly.

•

Make sure the tape has an erase-prevention tab. If need, cover the

•

hole with plastic tape.

•

–50–

1F12

PROBLEM CORRECTIVE ACTION

Playback picture is partially noisy.

No picture but the audio is OK in playback.

No operation by infrared Remote Control. Video or color fades in and out

when making a copy of a video tape

CLOSED CAPTION PROBLEM POSSIBLE REMEDY

My TV/DVD/VHS is showing • You are watching a live broadcast and spelling errors made by the captions that are misspelled. • closed captioning production company may pass through uncorrected.

My TV/DVD/VHS will not show • Captions that are delayed a few seconds behind the actual the text dialogue are common for live broadcast. Most captioning production in its entirety or there is a delay of • companies can display a dialogue to a maximum of 220 words what is being said. • per minute. If a dialogue exceeds that rate, selective editing is used

My captions are scrambled with • Interference caused by building, power lines, thunderstorms, etc. white boxes on the TV screen. • may cause scrambled or incomplete captions to appear.

My program guide listed a TV show as being closed captioned but none • up the actual program so that additional advertising time can be of the captions were displayed. • given. Since the decoder cannot read the compressed information,

My prerecorded video tape does not show any captions. The tape box • company accidentally left out the captioning signals during the mentions it being closed captioned. • copying process.

My TV screen shows a black box • You are in the TEXT mode. Select CAPTION mode to CAPTION on certain channels. • [OFF].

Adjust tracking control for a better picture using the CHANNEL K

•

or L button on the TV/DVD/VHS.

•

Head cleaning may be necessary. Refer to “AUTO HEAD

•

CLEANING” on page 53.

•

Make sure the AC cord is connected to an AC outlet.

•

Check batteries in remote control.

•

You can not copy a copyrighted video tape. You are experiencing

•

copy guard protection.

•

• A prerecorded program will not show any misspelled words because

• of the normal time available for editing the captions.

• to insure that the captions remain up-to-date with the current

• TV screen dialogue.

• Broadcasters may at times use a time compression process to speed

• captions will be lost.

• The video tape was either an illegal copy or the tape duplicating

–51–

1F12

DVD

If the TV/DVD does not perform properly when operated as instructed in this Owner’s Manual, check the player, consulting the following checklist.

Symptom Cause Remedy

No power.

The player does not respond to the

remote control.

No picture

Disc cannot be played

No sound

Distorted picture

Audio or subtitle language does not match the setup.

The camera angle cannot be changed.

Audio or subtitle language cannot be changed.

"Prohibited icon" appears on the screen, prohibiting an operation.

CD sound dropout No CD reproduction DVD picture dropout DVD picture freeze DVD picture in mosaic No DVD reproduction

Loose power plug.

•

The remote control is not aimed•Aim the remote control directly at the sensor

•

at the sensor on the TV/DVD.

•

Obstacles present between the

•

remote control and the sensor.

•

The remote control is too far

•

away from the TV/DVD.

•

Dead batteries.

•

Loose video connection.

•

Wrong disc.

•

No disc.

•

Dirty disc.

•

Disc is placed upside down.

•

Parental lock is active.

•

Loose audio connection.

•

The power of the connected

•

audio component is off.

•

Wrong audio output settings.

•

Wrong input settings on the

•

connected audio component.

•

Immediately after playing,

•

press fast forward or in reverse.•slightly distorted, which are not a sign of a

•

The selected language is not

•

available for audio or subtitles

•

on the DVD.

•

The DVD does not contain

•

sequences recorded from

•

different camera angles.

•

The DVD does not contain

•

audio source or subtitles in the

•

selected language.

•

That operation is prohibited by•No malfunction.

•

the TV/DVD or disc.

•

Scratched disc

•

Insert the power plug firmly into the wall out

•

let.

on the TV/DVD.

•

Remove the obstacles from the signal path.

•

Use the remote control within 7m of

•

the TV/DVD.

•

Replace the batteries.

•

Connect the video cables firmly.

•

Insert a correct video disc that plays on this

•

TV/DVD.

•

Insert a disc.

•

Clean the disc.

•

Place the disc correctly, with the label side up.

•

Cancel the parental lock or change the control

•

level.

•

Connect the audio cables firmly.

•

Turn the power of the audio component on.

•

Correct the audio output settings.

•

Correct the input settings on the audio

•

component.

•

There are some cases where pictures may be

•

malfunction.

•

No malfunction.

•

No malfunction.

•

No malfunction.

•

Replace the disc with unscratched one.

•

NOTES:

Some functions are not available in specific modes, but this is not a malfunction. Read the description in

•

this Owner’s Manual for details on correct operations. Playback from a desired track and random playback are not available during program playback.

•

–52–

1F12

MAINTENANCE

CABINET CLEANING

Wipe the front panel and other exterior surfaces of

•

the TV/DVD with a soft cloth immersed in lukewarm water and wrung dry.

Never use a solvent or alcohol. Do not spray insec-

•

ticide liquid near the TV/DVD. Such chemicals may cause damage and discoloration to the exposed surfaces.

1.Please visit your local Audio/Video store and purchase a good quality VHS Video Head Cleaner.

2.If a Video Head Cleaner does not solve the problem, please call our help line at 1-800-968-3429, to locate an Authorized Service Center.

NOTES:

Remember to read the instructions included with

•

the video head cleaner before use. Clean video heads only when problems occur.

•

AUTO HEAD CLEANING

Automatically cleans video heads as you insert or

•

remove a cassette, so you can see a clear picture. Playback picture may become blurred of interrupt-

•

ed while the TV program reception is clear. Dirt accumulated on the video heads after long periods of use, or the usage of rental or worn tapes can cause this problem. If a streaky or snowy picture appears during playback, the video heads in your TV/DVD/VHS may need to be cleaned.

SERVICING

Should your TV/DVD become inoperative, do not

•

try to correct the problem by yourself. There are no user-serviceable parts inside. Turn off, unplug the power cord, and please call our help line at 1-800968-3429, to locate an Authorized Service Center.

IF THE LASER OPTICAL PICKUP UNIT IS DIRTY

If the player still does not perform properly when it is operated while referring to the relevant sections and to

•

"TROUBLESHOOTING GUIDE" in this Owner's Manual, the laser optical pickup unit may be dirty. Consult your dealer or an Authorized Service Center for inspection and cleaning of the laser optical pickup unit.

DISC HANDLING

Use discs which have the following logos on them.

•

(Optical audio digital discs.)

Handle the discs so that fingerprints and dust do

•

not adhere to the surfaces of the discs. Always store the disc in its protective case when it

•

is not used.

To clean-off, use a soft cloth.

•

Do not use a hard cloth since this will mar the disc.

•

Wipe the disc in a straight line from center to edge.

•

Never wipe with a circular motion.

•

Do not use detergent or abrasive cleaning agents.

•

–53–

1F12

01A11

SPECIFICATIONS

GENERAL SPECIFICATIONS ELECTRICAL SPECIFICATIONS

TV/VCR

Sound output: 2 speakers, 1W, 8 ohm

CRT : 27 inch in-line gun, 110˚

deflection tube Television system : NTSC-M Closed caption system :§15.119/FCC Video Heads : Rotary four-head Tape width : 1/2 inch Tape speed

SP : 33.40mm/sec. LP : 16.67mm/sec. SLP : 11.12mm/sec.

Tuner channel

TV VHF Low : #2~#6 TV VHF High : #7~#13 TV UHF : #14~#69 CATV VHF : 5A MID band : A5~A1, A~I SUPER band : J~W HYPER band : W+1~W+84

DVD

Product type: DVD Player Discs: DVD video, Audio CD Output signal format: NTSC color Frequency response (out put jack)

DVD (linear sound): 20 Hz to 22 kHz

(sample rate: 48 kHz)

20 Hz to 44 kHz

(sample rate: 96 kHz)

CD: 20 Hz to 20 kHz Signal-to-noise ratio (S/N ratio)(out put jack)

CD: 100 dB (EIAJ) Dynamic range (out put jack)

DVD (linear sound): 85 dB

CD: 84 dB (EIAJ) Total distortion factor

CD: 0.07% (EIAJ) Wow and flutter: Below the measurement

limitation (+/-0.001% W PEAK) (EIAJ)

OTHER SPECIFICATIONS

Terminals

Antenna input: VHF/UHF/CATV

75 ohm unbalanced (F-type) Video input: RCA connector [ 1 Audio L/R input: RCA connector [ 2 Headphone: 1/8” stereo (3.5 mm) Coaxial digital audio output (only DVD): One pin jack,

500m Vpp (75 ohm) Analog audio L/R output: RCA connector [ 2

Remote control: Digital encoded

infrared light system

Operating temperature: 5ºC to 40ºC

(41ºF~104ºF)

Power requirements: AC 120V, 60Hz Power consumption (Maximum): 125W Picture tube: 27" Dimensions: H:25-1/2” (648mm)

W:26-9/16” (675mm)

D:19-11/16” (500mm)

Weight: 86 lbs (39.0kg) Accessories: Remote Control Unit with

2"AA"batteries

Owner’s Manual

Designs and specifications are subject to change without notice and without our legal obligation.

•

If there is a discrepancy between languages, the default language will be English.

•

–54–

1F12

MEMO

–55–

1F12

INDICE

■ CONTROLES DE OPERACIÓN Y FUNCIONES. . . . . 56

PANEL FRONTALDEL televisor/DVD/VHS . . . . . . . . . 56

MANDO ADISTANCIA . . . . . . . . . . . . . . . . . . . . . . . . . 56

VISTA POSTERIOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

■ PREPARACIÓN PARA LA UTILIZACIÓN . . . . . . . . . . 58

CONEXIONES DE ANTENA/TELEVISIÓN

POR CABLE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

INSTALACIÓN DE LAS PILAS . . . . . . . . . . . . . . . . . . . 58

CONEXIÓN ATOMAS DE ENTRADA EXTERNA. . . . 58

MODE DE ENTRADA EXTERNA . . . . . . . . . . . . . . . . . 58

CONEXIÓN AUN SISTEMA ESTÉREO (Para DVD) . . 58 CONEXIÓN A UN AMPLIFICADOR EQUIPADO CON TOMAS DE ENTRADA DIGITAL, PLATINA MD O

PLATINA DAT (Para DVD) . . . . . . . . . . . . . . . . . . . . . . 58

CONEXIÓN AUN DECODIFICADOR DOLBY DIGITAL

O AUN DECODIFICADOR DTS (Para DVD) . . . . . . . . 59

TV SECTION

■

PREPARACIÓN PARA LA UTILIZACIÓN

SELECCIÓN DE IDIOMA . . . . . . . . . . . . . . . . . . . . . . . 60

PREAJUSTE DE CANALES. . . . . . . . . . . . . . . . . . . . . . 60

. . . . . . . . . . . . 60

DVD SECTION

■ REPRODUCCIÓN DE UN DISCO . . . . . . . . . . . . . . . . 61

REPRODUCCIÓN DE UN DVD DE VÍDEO O UN CD DE

AUDIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

CONTROLES DE

OPERACIÓN Y FUNCIONES

PANEL FRONTAL DEL

TELEVISOR/DVD

Consulte la figura 1 de la página 8

MANDO A DISTANCIA

Consulte la figura 2 de la página 8

VISTA POSTERIOR

Consulte la figura 3 de la página 9

1.Botón POWER

Púlselo para conectar y desconectar la alimentación.

Botones VOLUME K/L

Púlselos para controlar el nivel del volumen para el DVD y el televisor.

Botones SKIP (para DVD)

Salta capítulos o pistas hasta un punto deseado.

Botón PLAY

Inicia la reproducción del contenido del disco o la cinta.

5.Botón STOP

Detiene la operación del disco o la cinta.

Botón OPEN/CLOSE

Púlselo para insertar discos en la bandeja o

retirarlos de ella.

Bandeja de carga del disco

8.Indicador de DVD

Parpadea durante el modo del DVD.

9.Botón SELECT

Púlselo para cambiar a un modo de televisor, modo de entrada externa o modo de DVD.

Indicador del televisor/ la videograbadora

10.

(TV/VCR)

Parpadea durante el modo del televisor/ la videograbadora

11. Botones CHANNEL K/L

Púlselo para seleccionar el canal memorizado. Púlselo para cambiar a un modo de televisor cuando modo de DVD.

Indicador de grabación (RECORD)

12.

Parpadea durante la grabación. Se enciende en el modo de espera de la grabación con temporizador.

Botón de grabación de un toque (OTR)

Activa la grabación de un toque. (Sólo en el televisor/DVD/VHS)

13.Botón de grabación (REC)

Púlselo para iniciar la grabación manual.

14.Botón de rebobinado (REW) (para televisor/

videograbadora)

Púlselo para rebobinar la cinta, o para ver la imagen en retroceso rápido durante el modo de reproducción. (Búsqueda con rebobinado)

15.Botón de avance rápido (FWD) (para televisor/

videograbadora)

Púlselo para avanzar rápidamente la cinta, o para ver la imagen en avance rápido durante el modo de reproducción. (Búsqueda con avance rápido)

16.Botón de parada (STOP)

Púlselo para detener la cinta.

Botón de expulsión (EJECT)

Púlselo en el modo de parada para expulsar la cinta del televisor/videograbadora.

17.Ventanilla del sensor del mando a distancia

18.Toma HEADPHONE

Para conectar auriculares (no suministrados) y escuchar en privado.

Toma de entrada VIDEO

19.

Conecte aquí la toma de salida de vídeo de una videocámara o de una videograbadora.

20.Tomas de entrada AUDIO L/R

Conecte aquí las tomas de salida de audio de una videocámara o de una videograbadora.

Compartimiento del videocasete

21.

22.Botón PICTURE

Presione para entrar en el modo de ajuste de imagen.

–56–

1F12

23.Botones de números

Modo del televisor:

Pulse dos dígitos para tener acceso directamente al canal deseado.

Recuerde pulsar "0" antes de elegir un canal de un solo dígito.

Botón +100

Púlselo para seleccionar canales de televisión por cable cuyo número sea igual o superior al 100.

Modo DVD:

Púlselo para introducir el número deseado.

Botón +10

Púlselo para introducir los números deseados cuyo número sea igual o superior al 10.

Botón PAUSE

24.

Hace una pausa en la operación del disco o la cinta.

Botón de velocidad de cinta (SPEED)

25.

Púlselo para elegir la velocidad de grabación deseada: SP/SLP.

26.Botón C-RESET

Púlselo para reponer el contador a 0:00:00.

27.Botón DISPLAY

Modo del televisor/ la videograbadora:

Púlselo para visualizar el número del canal en la pantalla. Si lo pulsa de nuevo, el número del canal desaparecerá.

Modo de DVD:

Visualiza el estado actual en la pantalla del televisor con fines de comprobación.

Botón SETUP

28.

Púlselo para activar o salir del modo de menús de televisor o preparación de DVD.

Botón TITLE

29.

Visualiza el menú de títulos.

Botón CLEAR

30.

Repone un ajuste.

Botón MODE

31.

Activa el modo de reproducción programada o el modo de reproducción aleatoria.

Botón SEARCH MODE

32.

Púlselo para localizar un punto deseado.

Botón AUDIO

33.

Púlselo para seleccionar un idioma de audio o un modo de sonido deseado.

Botón SUBTITLE

34.

Púlselo para seleccionar un idioma de subtítulos deseado.

Botón REPEAT

35.

Repite la reproducción del disco, título, capítulo o pista actual.

Botón ANGLE

36.

Púlselo para cambiar el ángulo de la cámara y verde, desde un ángulo diferente, la secuencia que está siendo reproducida.

Botón A-B REPEAT

37.

Repite la reproducción de una sección seleccionada.

38.Botón RETURN

Para volver a la operación anterior.

Botón ENTER

39.

Púlselo para establecer un ajuste.

Botones de flechas

40.

Modo de televisor:

Púlselo para seleccionar un modo de ajuste desde el menú que aparece en la pantalla del televisor. Púlselo para seleccionar o ajustar desde un menú particular.

Modo de DVD:

Se utiliza cuando se hacen ajustes mientras se observa la visualización en una pantalla de televisor.

41.Botón DISC MENU

Visualiza menús de DVD.

Botón ZOOM

42.

Amplia parte de una imagen de DVD reproducida.

43.Botón MUTE

Pulse el botón MUTE para apagar el sonido de un programa de TV. La visualización del nivel del sonido cambia de ROJO CLARO a AZUL CLARO.) Pulse de nuevo el botón MUTE o el botón VOL K o L para restaurar el sonido.

Botón DVD

44.

Púlselo para cambiar a un modo de DVD.

Botón TV/VCR

45.

Púlselo para cambiar a un modo de televisor/ videograbadora.

Toma de entrada ANT.

46.

Conéctela a una antena, sistema de televisión por cable o sistema de satélite.

Cable de alimentación

47.

Conéctelo a una toma de CA convencional (120 V/60 Hz).

NOTA: Retire el cable de alimentación del gancho

para evitar romperlo antes de conectarlo a una toma de CA convencional.

Toma de salida de audio digital COAXIAL

48.

Conéctela a la entrada digital de un amplificador o decodificador externo.

Toma de salida AUDIO L/R

49.

Conéctela a la entrada de audio analógico de un amplificador o decodificador externo. NOTA: Las tomas de entrada de audio (roha y

blanca) en el lado trasero sirven para producir no el son televisor ni el son de entrada externa, sino el son DVD.

–57–

1F12

PREPARACIÓN PARALA

UTILIZACIÓN

fuente a las tomas AUDIO L/R y VIDEO de este televisor/DVD/VHS. Y luego pulse el botón SELECT hasta que "VIDEO" aparezca en la pantalla.

CONEXIONES DE ANTENA/

TELEVISIÓN POR CABLE

Consulte la figura 4 de la página 11

ANTENAS SEPARADAS DE VHF/UHF

En algunas áreas será necesario utilizar una antena exterior.

Consulte la figura 4 de la página 11

TELEVISIÓN POR CABLE SIN CAJA DE CONVERTIDOR/DECODIFICADOR

Utilice esta conexión si su sistema de televisión por cable se conecta directamente a su televisor/DVD/VHS sin necesidad de caja de convertidor.

Consulte la figura 4 de la página 11

TELEVISIÓN POR CABLE CON CAJA DE CONVERTIDOR/DECODIFICADOR O CAJA DE SATÉLITE

Si su proveedor de servicios de televisión por cable le suministra una caja de convertidor o si usted utiliza un sistema de satélite, podrá utilizar la conexión básica mostrada aquí.

Consulte la figura 4 de la página 11

INSTALACIÓN DE LAS PILAS

1) Abra la tapa del compartimiento de las pilas del mando a distancia presionándola en el sentido de la flecha.

2) Inserte 2 pilas tamaño "AA" en su compartimiento colocando las polaridades (+/-) en sus posiciones correspondientes.

3) Vuelva a poner la tapa.

CONEXIÓN A TOMAS DE

ENTRADA EXTERNA

Cuando vea un programa grabado en otra fuente (videograbadora o videocámara), utilice las tomas de entrada de audio/vídeo de la parte delantera del televisor/DVD/VHS.

Conecte las tomas de salida de audio/vídeo de otra

NOTA:

Cuando conecte una videograbadora monoaural

•

(otra fuente) a este televisor/DVD/VHS, conecte la toma de salida de audio de la videograbadora monoaural (otra fuente) a la toma AUDIO L de este televisor/DVD/VHS. El audio saldrá igualmente en los canales L y R.

Consulte la figura 5 de la página 12

Conexiones de antena/televisión por cable Continúa en la página siguiente.

MODO DE ENTRADA EXTERNA

Cuando utilice una señal de entrada externa (otra videograbadora o una videocámara), conecte los cables de salida de audio/vídeo del equipo de reproducción a las tomas AUDIO IN/VIDEO IN de su televisor/videograbadora. Y luego pulse el botón CHANNEL K o L hasta que “AUX” aparezca en la pantalla.

Usted puede programar el temporizador para que explore todos los canales que puedan recibirse en su zona.

CONEXIÓN A UN SISTEMA

ESTÉREO (Para DVD)

Consulte la figura 6 de la página 13

NOTAS:

Asegúrese de desconectar la alimentación a todos

•

los componentes del sistema antes de hacer la conexión a otro componente.

Consulte el manual del propietario de su sistema

•

estéreo y de cualquier otro componente que vaya a conectar al televisor/DVD/VHS.

Las tomas de entrada de audio (roha y blanca) en el

•

lado trasero sirven para producir no el son televisor ni el son de entrada externa, sino el son DVD.

CONEXIÓN A UN

AMPLIFICADOR EQUIPADO

CON TOMAS DE ENTRADA

DIGITAL, PLATINA MD O PLATINA DAT (Para DVD)

Utilice un cable digital coaxial (de venta en el comercio) para las conexiones de audio.

Consulte la figura 7 de la página 13

–58–

1F12

NOTAS:

La fuente de audio de un disco del formato de

•

sonido ambiental Dolby Digital de 5,1 canales no puede ser grabada como sonido digital por una platina MD o DAT.

Asegúrese de desconectar la alimentación de todos

•

los componentes del sistema antes de hacer la conexión a otro componente.

Consulte los manuales del propietario de los com-

•

ponentes que vaya a conectar al televisor/DVD/VHS.

Ponga DOLBY DIGITAL y DTS en OFF para la

•

salida de audio en el modo de preparación. La reproducción en el televisor/DVD/VHS utilizando los ajustes incorrectos puede generar distorsión de ruido, y también puede estropear los altavoces.

El audio se silenciará cuando DOLBY DIGITAL se

•

ponga en OFF y VIRTUAL 3D se ponga en ON para la salida de audio en el modo de preparación y usted seleccione la fuente de audio del formato de sonido ambiental Dolby Digital de 5,1 canales.

CONEXIÓN A UN

DECODIFICADOR DOLBY

DIGIT ALO A UN

DECODIFICADOR DTS

(Para DVD)

A menos que se haga la conexión a un decodifi-

•

cador Dolby Digital o DTS, ponga DOLBY DIGITAL y DTS en OFF para la salida de audio en el modo de preparación. La reproducción en el televisor/DVD/VHS utilizando los ajustes incorrectos puede generar distorsión de ruido, y también puede estropear los altavoces.

El audio se silenciará cuando DOLBY DIGITAL se

•

ponga en OFF y VIRTUAL 3D se ponga en ON para la salida de audio en el modo de preparación y usted seleccione la fuente de audio del formato de sonido ambiental Dolby Digital de 5,1 canales.

“DTS” y “DTS Digital Out” son marcas de fábrica de Digital Theater Systems, Inc.

Si se utiliza este televisor/DVD/VHS para reproducir fuentes del formato de sonido ambiental Dolby Digital de 5,1 canales o de sonido ambiental DTS, el televisor/DVD/VHS dará salida a un flujo de datos Dolby Digital o DTS desde su toma de salida de audio digital COAXIAL. Conectando el reproductor a un decodificador Dolby Digital o DTS, usted podrá disfrutar de un ambiente más convincente y real con un sonido ambiental potente y de alta calidad de tipo profesional tal como el que se oye en salas de cine.

Utilice cables digitales coaxiales (de venta en el comercio) para las conexiones de audio.

Consulte la figura 8 de la página 14

NOTAS:

Asegúrese de desconectar la alimentación de todos

•

los componentes del sistema antes de hacer la conexión a otro componente.

Consulte los manuales del propietario de los com-

•

ponentes que vaya a conectar al televisor/DVD/VHS.

Si conecta un decodificador Dolby Digital, ponga

•

DOLBY DIGITAL en ON para la salida de audio en el modo de preparación.

Si conecta un decodificador DTS, ponga DTS en

•

ON para la salida de audio en el modo de preparación.

–59–

1F12

TV SECTION

AJUSTE DEL RELOJ

PREPARACIÓN PARALA

UTILIZACIÓN

PREPARACIÓN DE CANALES

POR PRIMERA VEZ

Conecte el cable de alimentación a una toma de CA convencional.

NOTA: Si aparecen algunos dígitos en la esquina de

la pantalla, pulse el botón POWER sin desenchufar el cable de alimentación.

Pulse el botón POWER para encender el televisor/DVD/VHS.

Seleccione "ESPAÑOL" o "ENGLISH" (inglés), "FRANÇAIS" (francés) utilizando el botón de flecha B o s.

Pulse el botón flecha K o L para señalar “AUTOPRESELECCION”.

Luego pulse el botón flecha B. El sintonizador explorará y memorizará todos los canales activos de su área.

NOTAS:

El televisor/videograbadora distingue entre los

•

canales de televisión estándar y los canales de televisor por cable.

Si desea reproducir o grabar una cinta ANTES de

•

preajustar el sintonizador, usted tendrá que pulsar el botón SETUP en el mando a distancia. Para preajustar de nuevo el sintonizador, consulte “REPETICIÓN DE LA PREPARACIÓN DE CANALES”.

La unidad de televisor/videograbadora puede

•

reconocer los canales de TV como ellos de TV por cable a causa de los condiciones de recepción. En este caso, pruebe el preajuste automático de nuevo en los condiciones finas de recepción.

El sintonizador se para en el canal memorizado más bajo. Si desea recuperar canales seleccionados, usted podrá seleccionar directamente el canal deseado con los botones numerados del mando a distancia o con los botones CHANNEL K o L.

Cerciórese...

La alimentación del televisor/videograbadora

• deberá estar conectada.

En el ejemplo de abajo, el reloj va a ajustarse así:

FECHA: 1 de mayo de 2001 HORA: 5:40 PM

Pulse el botón SETUP en el mando a distancia. Pulse el botón PLAY/K o STOP/L para indicar

“AJUSTE RELOJ”. Luego, pulse el botón F.FWD/B.

Pulse el botón PLAY/K o STOP/L para indicar “AJUSTE MANUAL RELOJ”. Luego, pulse el botón F.FWD/B.

Pulse el botón PLAY/K o STOP/L hasta que aparezca el mes deseado. (Ejemplo: Mayo - 05) Luego, pulse el botón F.FWD/B.

Pulse el botón PLAY/K o STOP/L hasta que aparezca el día del mes deseado. (Ejemplo: 1 - 01) Luego, pulse el botón F.FWD/B.

Pulse el botón PLAY/K o STOP/L hasta que aparezca el año deseado. (Ejemplo: 2001) Luego, pulse el botón F.FWD/B.

Pulse el botón PLAY/K o STOP/L hasta que aparezca la hora deseada. (Ejemplo: 5, PM) Luego, pulse el botón F.FWD/B.

Pulse el botón PLAY/K o STOP/L hasta que aparezca el minuto deseado. (Ejemplo: 40)

Pulse el botón SETUP en el mando a distancia. Aunque los segundos no se visualizan, éstos empiezan a contar desde 00 cuando se pulsa SETUP en el mando a distancia. Utilice esta función para sincronizar el reloj con la hora correcta.

–60–

1F12

DVD SECTION

REPRODUCCIÓN DE UN

DISCO

REPRODUCCIÓN DE UN DVD

DE VÍDEO O UN CD DE AUDIO

CDDVD

Para empezar

Conecte la alimentación del televisor, amplificador y cualquier otro componente que esté conectado al reproductor DVD. (Cambie el sistema de entrada para adaptarlo al reproductor DVD, y compruebe que el volumen del sonido sea correcto.)

1 Pulse el botón POWER.

La alimentación se conectará.

2 Pulse el botón OPEN/CLOSE.

La bandeja de carga del disco se abrirá.

3 Ponga un disco en la bandeja.

¡Asegúrese de que el disco esté correctamente asen-

tado en el hueco correcto, con el lado de la etiqueta hacia arriba.

4 Pulse el botón PLAY.

¡La bandeja se cerrará automáticamente y la repro-

ducción empezará desde el primer capítulo o pista del disco. Necesitará pulsar el botón PLAY sólo cuando la bandeja haya sido cerrada pulsando el botón OPEN/CLOSE.

¡Cuando reproduzca un DVD que tenga grabado un

menú de títulos, el menú tal vez aparezca en la pantalla. En este caso, consulte "UTILIZACIÓN DEL MENÚ DE TÍTULOS".

Pulse el botón STOP para detener la reproducción.

–61–

1F12

MEMO

–62–

1F12

MEMO

–63–

1F12

LIMITED WARRANTY

FUNAI CORP. will repair this SYLVANIA product, free of charge in the USA in the event of defect in materials or workmanship as follows:

DURATION: PARTS: FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the

date of original retail purchase. Two (2) years for Picture Tube. Certain parts are excluded from this warranty.

LABOR: FUNAI CORP. will provide the labor without charge for a period of ninety (90) days from the date of

original retail purchase.

LIMITS AND EXCLUSIONS:

This warranty is extended only to the original retail purchaser. A purchase receipt or other proof of original retail purchase will be required together with the product to obtain service under this warranty.

This warranty shall not be extended to any other person or transferee.

This warranty is void and of no effect if any serial numbers on the product are altered, replaced, defaced, missing or if service was attempted by an unauthorized service center. This SYLVANIA Limited warranty does not apply to any product not purchased and used in the United States.

This warranty only covers failures due to defects in material or workmanship which occurs during normal use. It does not cover damage which occurs in shipment, or failures which are caused by repairs, alterations or product not supplied by FUNAI CORP., or damage which results from accident, misuse, abuse, mishandling, misapplication, alteration, faulty installation, improper maintenance, commercial use such as hotel, rental or office use of this product or damage which results from fire, flood, lightning or other acts of God.

THIS WARRANTY DOES NOT COVER PACKING MATERIALS, ANY ACCESSORIES (EXCEPT REMOTE CONTROL), ANY COSMETIC PARTS, COMPLETE ASSEMBLY PARTS, DEMO OR FLOOR MODELS.

FUNAI CORP. AND ITS REPRESENTATIVES OR AGENTS SHALL IN NO EVENT BE LIABLE FOR ANY GENERAL, INDIRECT OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR OCCASIONED BY THE USE OF OR THE INABILITY TO USE THIS PRODUCT. THIS WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND OF ALL OTHER LIABILITIES ON THE PART OF FUNAI, ALL OTHER WARRANTIES INCLUDING THE WARRANTY OF MERCHANTABILITY, AND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED BY FUNAI AND ITS REPRESENTATIVES IN THE UNITED STATES.

ALL WARRANTY INSPECTIONS AND REPAIRS MUST BE PERFORMED BY A FUNAI AUTHORIZED SERVICE CENTER. THIS WARRANTY IS VALID WHEN THE UNIT IS CARRIED-IN TO FUNAI AUTHORIZED SERVICE FACILITY.

IMPORTANT:

THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE, IF, AT ANY TIME DURING THE WARRANTY PERIOD, YOU ARE UNABLE TO OBTAIN SATISFACTION WITH THE REPAIR OF THIS PRODUCT, PLEASE CONT ACTFUNAI CORP.

ATTENTION:

FUNAI CORP. RESERVES THE RIGHT TO MODIFY ANY DESIGN OF THIS PRODUCT WITHOUT PRIOR NOTICE.

To locate your nearest SYLVANIA Authorized Service Center or for general service procedure, please call 1-800-968-3429 or write to the following:

FUNAI CORPORATION, INC.

Customer Service

100 North Street; Teterboro, NJ 07608

Tel :1-800-968-3429

PLEASE DO NOT SHIP YOUR UNIT TO THE TETERBORO ADDRESS.

Printed in Malaysia 0EMN01869

TD374UE★★★★★

documentation manual, user maintenance, brochure, user reference, pdf manual

This file has been downloaded from:

User Manual and User Guide for many equipments like mobile phones, photo cameras, monther board, monitors, software, tv, dvd, and othes..

Manual users, user manuals, user guide manual, owners manual, instruction manual, manual owner, manual owner's, manual guide,

manual operation, operating manual, user's manual, operating instructions, manual operators, manual operator, manual product,

Funai SSC727B User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
